VIZIO M43-C1, M49-C1, M50-C1, M65-C1, M75-C1 User Manual

VIZIO

USER MANUAL

Model M43-C1, M49-C1, M50-C1, M65-C1, & M75-C1

Safety & Certication



THANK YOU FOR CHOOSING VIZIO

And congratulations on your new VIZIO HDTV.

To get the most out of your new VIZIO product, read these instructions before using your product and retain them for future reference. Be sure to inspect the package contents to ensure there are no missing or damaged parts.

PRODUCT REGISTRATION

To purchase or inquire about accessories and installation services for your VIZIO product, visit our website at www.VIZIO.com or call toll free at (877) 878-4946.

We recommend that you register your VIZIO product at www.VIZIO.com

Extended Warranties

For peace of mind, and to protect your investment beyond the

standard warranty, VIZIO oers on-site extended warranty service

plans. These plans provide additional coverage during the standard

warranty period. To purchase an extended warranty service plan,

visit www.VIZIO.com.

WHEN READING THIS MANUAL

When you see this symbol, please read the accompanying important warning or notice. It is intended to alert you to the presence of important operating instructions.

When you see this symbol, please read the accompanying helpful tip.

IMPORTANT SAFETY INSTRUCTIONS

Your TV is designed and manufactured to operate within dened design limits. Misuse may result in electric shock or re. To prevent

your TV from being damaged, the following instructions should be observed for the installation, use, and maintenance of your TV. Read the following safety instructions before operating your TV. Keep these instructions in a safe place for future reference.

• To reduce the risk of electric shock or component damage,

switch o the power before connecting other components

to your TV.

• Read these instructions.

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Clean only with dry cloth.

• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

• Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including ampliers)

that produce heat.

• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided

plug does not t into your outlet, consult an electrician for

replacement of the obsolete outlet.

• Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point

where they exit from the apparatus.

• Only use attachments/accessories specied by the manufacturer.

• Use only with the cart, stand, tripod, bracket,

or table specied by the manufacturer, or

sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

• Unplug this apparatus during lightning storms or when unused for long periods of time.

• Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as when the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into

the apparatus, the apparatus has been exposed to rain or

moisture, does not operate normally, or has been dropped.

• Unplug the power cord before cleaning your TV.

• When moving your TV from an area of low temperature to an area of high temperature, condensation may form in the housing. Wait before turning on your TV to avoid causing

re, electric shock, or component damage.

• A distance of at least three feet should be maintained between your TV and any heat source, such as a radiator,

heater, oven, amplier etc. Do not install your TV close to

smoke. Operating your TV close to smoke or moisture may

cause re or electric shock.

• Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure reliable operation of your TV and to protect it from overheating, be sure these openings are not blocked or covered. Do not place your TV in a bookcase or cabinet unless proper ventilation is provided.

• Never push any object into the slots and openings on your TV cabinet. Do not place any objects on the top of your TV.

Doing so could short circuit parts causing a re or electric

shock. Never spill liquids on your TV.

• Your TV should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company.

• Do not apply pressure or throw objects at your TV. This may compromise the integrity of the display. The manufacturer’s warranty does not cover user abuse or improper installations.

• The power cord must be replaced when using dierent

voltage than the voltage specied. For more information,

contact your dealer.

• When connected to a power outlet, power is always owing into your TV. To totally disconnect power, unplug the power cord.

• The lightning ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of un-isolated, dangerous voltage within the

inside of your TV that may be of sucient magnitude to

constitute a risk of electric shock to persons.

• Do not use your TV if any abnormality occurs. If any smoke or odor becomes apparent, unplug the power cord and contact your dealer immediately. Do not try to repair your TV yourself.

• Avoid using dropped or damaged appliances. If your TV is dropped and the housing is damaged, the internal components may function abnormally. Unplug the power cord immediately and contact your dealer for repair.

Continued use of your TV may cause re or electric shock.

• Do not install your TV in an area with heavy dust or high humidity. Operating your TV in environments with heavy

dust or high humidity may cause re or electric shock.

• Follow instructions for moving your TV. Ensure that the power cord and any other cables are unplugged before moving your TV.

• The mains plug or appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.

• CAUTION - These servicing instructions are for use by

qualied service personnel only. To reduce the risk of

electric shock, do not perform any servicing other than that contained in the operating instructions unless you are

qualied to do so.

• The lightning ash with arrowhead symbol within

an equilateral triangle is intended to alert the user to the

presence of uninsulated DANGEROUS VOLTAGE within the product’s enclosure that may be of sucient magnitude to

constitute a risk of electrical shock to persons.

• Do not overload power strips and extension cords.

Overloading can result in re or electric shock.

• The wall socket should be installed near your TV and easily accessible.

• Only power of the marked voltage can be used for your TV.

Any other voltage than the specied voltage may cause re

or electric shock.

• Do not touch the power cord during lightning. To avoid electric shock, avoid handling the power cord during electrical storms.

• Unplug your TV during a lightning storm or when it will not be used for long period of time. This will protect your TV from damage due to power surges.

• Do not attempt to repair or service your TV yourself.

Opening or removing the back cover may expose you to

high voltages, electric shock, and other hazards. If repair is required, contact your dealer and refer all servicing to

qualied service personnel.

• WARNING: Keep your TV away from moisture. Do not expose your TV to rain or moisture. If water penetrates into your TV, unplug the power cord and contact your dealer. Continuous

use in this case may result in re or electric shock.

• When unplugging your TV, hold the AC/DC power adapter, not the cord. Pulling on the power cord may damage the

wires inside the cord and cause re or electric shock. When your TV will not be used for an extended period of time,

unplug the power cord.

• To reduce risk of electric shock, do not touch the connector with wet hands.

• Insert batteries in accordance with instructions. Incorrect polarities may cause the batteries to leak which can damage the remote control or injure the operator. Do not

expose batteries to excessive heat such as sunshine, re or

the like.

• If any of the following occurs, contact the dealer:

- The power cord fails or frays.

- Liquid sprays or any object drops into your TV.

- Your TV is exposed to rain or other moisture.

- Your TV is dropped or damaged in any way.

- The performance of your TV changes substantially.

• This apparatus shall not be exposed to dripping or

splashing and no objects lled with liquids, such as vases,

shall be placed on the apparatus.

iii

TELEVISION ANTENNA CONNECTION PROTECTION

If an outside antenna/satellite dish or cable system is to be connected to the TV, make sure that the antenna or cable system is electrically grounded to provide some protection against voltage surges and static charges.

Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides

information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of the grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements of the grounding electrode.

Lightning Protection

For added protection of the TV during a lightning storm or when it is left unattended or unused for long periods of time, unplug the TV from the wall outlet and disconnect the antenna or cable system.

Power Lines

Ground Clamp

Antenna Lead In Wire

Antenna Discharge Unit

(NEC Section 810-20)

Do not locate the antenna near overhead light or power circuits, or where it could fall into such power lines or circuits. Remember, the

screen of the coaxial cable is intended to be connected to earth in

the building installation.

Electric Service Equipment

Grounding Conductors

(NEC Section 810-21)

Ground Clamps

Power Service Grounding Electrode System

(NEC ART 250, part H)

For DTS patents, see http://patents.dts.com.

Manufactured under license from DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS Studio Sound is a

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby

Laboratories.

HDMI, the HDMI logo and High-Denition Multimedia

Interface are trademarks or registered trademarks of

HDMI Licensing LLC.

Table Of Contents

Getting to Know Your TV .............................................7

Inspecting the Package Contents ......................................................7

Installing the TV ..................................................................................8

Installing the TV Stand .................................................................... 8

Installing the TV on a Wall ............................................................... 9

Front Panel .......................................................................................... 10

Rear Panel ...........................................................................................11

Remote Control Front ......................................................................... 12

Replacing the Batteries ...................................................................13

Connecting Your Devices .............................................14

Connecting A Device ........................................................................... 14

Connecting A Device - Audio & Video Cable Types...........................15

Connecting an Audio Device ..............................................................16

Connecting An Audio Device - Audio Cable Types ............................ 17

Connecting an Audio Device - Arc .....................................................18

Connecting to Your Network..............................................................19

Connecting to a Wired Network (Best) ........................................... 19

Connecting to a Wireless Network .................................................19

Completing The First-Time Setup ...............................20

Using the On-Screen Menu .........................................23

Navigating the On-Screen Menu ........................................................ 23

Changing the Input Source ................................................................ 23

Changing the Screen Aspect Ratio ..................................................... 24

Viewing Video with the Menu Open ..................................................24

Adjusting the Picture Settings ............................................................ 25

Adjusting More Picture Settings ..................................................... 26

Adjusting the Picture Mode Edit Settings ......................................26

Saving a Custom Picture Mode ....................................................... 27

Locking/Unlocking a Custom Picture Mode ................................... 27

Deleting a Custom Picture Mode .................................................... 28

Resetting Picture Mode ................................................................... 28

Adjusting the Color Tuner Settings ................................................29

Adjusting the Audio Settings .............................................................. 31

Changing the Equalizer Settings ..................................................... 31

Deleting the Custom Audio Mode ..................................................32

Setting Timers ..................................................................................... 33

Setting the Sleep Timer ................................................................... 33

Setting the Auto Power O Feature ...............................................33

Enabling the Screen Saver .............................................................. 33

Blank Screen Feature ......................................................................33

Using the Network Connection Menu ...............................................34

Connecting to a Wireless Network .................................................34

Changing the Manual Setup Settings .............................................34

Finding MAC Addresses for Network Setup ...................................34

Connecting to a Hidden Network ...................................................35

Setting Up channels ............................................................................ 36

Selecting a Channel Source ............................................................. 36

Scanning for Channels ....................................................................36

Adding New Channels .....................................................................36

Skipping Channels ...........................................................................37

Listening to Alternate Audio ..............................................................38

Changing the Analog Audio Language ...........................................38

Changing the Digital Audio Language ............................................ 38

Setting Up Closed Captioning ............................................................ 39

Changing the Appearance of Digital Closed Captions ..................39

Renaming Devices on the Input Menu .............................................. 41

Changing the TV Settings ................................................................... 42

Viewing System Information ........................................................... 42

Changing the On-Screen Menu Language .....................................42

Setting the Time and Local Settings ............................................... 43

Using the Parental Controls ............................................................ 43

Accessing the Parental Controls Menu ..........................................43

Enabling or Disabling Program Ratings .........................................43

Locking and Unlocking Channels .................................................... 43

Blocking and Unblocking Content by Rating .................................44

Changing the Parental Control PIN ................................................44

Resetting the Content Locks ........................................................... 44

Changing the View Mode Settings .................................................. 45

Adjusting the Wide Mode (Aspect Ratio) ........................................ 45

Changing your TV Name..................................................................45

Adjusting the CEC Settings .............................................................. 46

Turning the Power Indicator On or O .......................................... 46

Using the Reset & Admin Menu ......................................................... 47

Restoring the TV to Factory Default Settings ................................. 47

Using the Guided Setup Menu ........................................................ 48

Using Guided Setup ......................................................................... 48

Using the Info Window .......................................................................48

Using the USB Media Player ........................................49

Using the USB Media Player ............................................................... 49

Preparing Your USB Drive to Play USB Media ...............................49

Playing USB Media ........................................................................... 49

Removing the USB Drive from the TV ............................................49

Using VIZIO Internet Apps Plus® (V.I.A. Plus) .............53

Using the fullscreen V.I.A. Apps Window ..........................................54

Fullscreen V.I.A. Plus Apps Window Overview .................................. 55

Customizing the V.I.A. Plus Apps Window ........................................56

Adding an App to the My Apps Tab ................................................ 56

Deleting an App from the My Apps Tab ......................................... 56

Moving an App in My Apps .............................................................56

Viewing Ultra HD Content ...........................................58

What is Ultra HD? ................................................................................ 58

What You Need to View Ultra HD Content ........................................ 58

What is HDMI 2.0 and HDCP 2.2? ......................................................58

Troubleshooting & Technical Support ........................59

Specications ...............................................................63

Warranty .......................................................................68

Legal & Compliance .....................................................69

Getting to Know Your TV

INSPECTING THE PACKAGE CONTENTS

Before installing your new TV, take a moment to inspect the package contents. Use the images below to ensure nothing is missing or damaged.

INPUT

LIST

EXIT

VOL

1 2 3

4 5 6

7 809

ENTER

INFO

GUIDEBACK

Power CordVIZIO LED UHDTV with Stand Two-Sided Remote with Keyboard

2 x Quick Start Guides

(1 English, 1 French-Spanish)

(Batteries Included)

4 x Phillips ScrewsTV Stands

PACKAGE CONTENTS

INSTALLING THE TV

After removing the TV from the box and inspecting the package

contents you can begin installing the TV. Your TV can be installed in two ways:

• On a at surface, using the included stand

• On a wall, using a VESA-standard wall mount (not included)

Installing the TV Stand

Your TV includes a stand designed to support the weight of the TV and keep it from falling over. However, the TV can still fall over if:

• It is placed on an uneven, unstable, or non-level surface

• It is pushed, pulled, or otherwise improperly moved

• If an earthquake occurs and the TV is not properly secured

It is recommended that two people take part in the base installation.

Place the TV screen-down on a clean, at surface. To prevent

scratches or damage to the screen, place the TV on a soft surface, such as carpet, rug, or blanket.

To install the stands:

1. Insert the stands into the base of the TV.

2. Secure each stand to the TV with two (2) Phillips screws (included).

Insert the screws into the back of the TV and tighten them using a Phillips screwdriver.

3. When you are nished, place the TV on a stable, level surface.

Installing the TV on a Wall

To mount your TV on a wall, you will need a wall mount. Consult the information below to nd the appropriate mount for your TV model:

Installing a TV on a wall requires lifting. To prevent injury or damage to the TV, ask someone to help you.

M43-C1 M49-C1 M50-C1 M65-C1 M75-C1

Screw Size: M6 M6 M6 M6 M8

Hole Pattern: 200mm (V) x 200mm (H) 200mm (V) x 200mm (H) 200mm (V) x 200mm (H) 400mm (V) x 400mm (H) 400mm (V) x 400mm (H)

Weight w/o

Stand:

Be sure the mount you choose is capable of supporting the weight of the TV. After you have determined that you have the correct mount for your TV, you can begin the installation.

To install your TV on a wall:

1. Disconnect any cables connected to your TV.

2. Place the TV face-down on a clean, at, stable surface. Be sure the surface is clear of debris that can scratch or damage the TV.

3. Remove the stands by loosening and removing the screws.

4. Attach your TV and wall mount to the wall, carefully following the instructions that came with your mount. Use only with a UL-listed wall mount bracket rated for the weight/load of this TV.

22.05 lbs 30.07 lbs 32.19 lbs 60.72 lbs 102.29 lbs

For some wall mounts, you may want to use cables with right-angle connectors. This allows the TV to rest closer to the wall.

WALL-MOUNT SCREW LOCATIONS

REMOTE SENSOR & POWER INDICATOR

When using the remote, aim it directly at this sensor.

The power indicator ashes on when the TV turns on, then goes out after several seconds. To keep the power indicator on as long as the TV is on, see

Turning the Power Indicator On or O on page 46.

FRONT PANEL

USB - Connect USB thumb drive to play photo, music, or video.

HDMI - Connect HDMI device.

Ethernet - Connect Ethernet cable from home network.

Coaxial - Connect coaxial cable from cable, satellite, or antenna.

Component/Composite - Connect component or composite device.

Note: The image shown here is for illustrative purposes only and may be subject to change.

The actual number of ports and their locations may vary, depending on the model.

Stereo Audio Out - Connect RCA audio device, such as sound bar.

Optical Audio Out - Connect optical/SPDIF audio device, such as home audio receiver.

HDMI - Connect HDMI device.

Power - Press once to turn on the TV.

Volume - Press the + button to increase volume and the - button to decrease volume.

Input - Press once to access the input menu.

REAR PANEL

APP LAUNCHER

Quickly launch the pictured App.

INPUT

Change the currently

displayed input.

A/V CONTROLS

Control USB media player and

video streaming playback.

CLOSED CAPTIONS

Turn closed captions on and o.

Close the on-screen menu.

Select the highlighted option.

BACK

Go to the previous on-screen menu.

VOLUME UP/DOWN

Increase or decrease loudness

of the audio.

MUTE

Turn the audio o or on.

WIDE

Change the display mode.

NUMBER PAD

Manually enter a channel.

ENTER

Conrm channel or passcode

entered using the Number Pad.

EXIT

POWER

Turn TV on or o.

Display the on-screen menu.

INFO Display the info window.

ARROW Navigate the on-screen menu.

GUIDE

Display the info window.

CHANNEL UP/DOWN

Change the channel.

V BUTTON Open the VIZIO Internet Apps Plus® (V.I.A. Plus) dock.

LAST Return to the channel last viewed.

PIC

Opens the Picture Mode menu.

DASH

Use with number pad to manually enter a digital sub-channel.

(For example, 18-4 or 18-5.)

SHIFT

Press and hold while

pressing another key to

enter a capital letter.

DO NOT COVER THIS AREA

This is the transmitter.

ALT

Press and hold while pressing another key to enter a blue character. For

example, press ALT and W to enter a

# character.

ARROWS

Navigate the

on-screen menu.

REMOTE CONTROL

Replacing the Batteries

3. Insert two AAA batteries into the remote control. Make sure that the (+) and (-) symbols on the batteries match the (+) and (-) symbols inside the battery compartment.

2. Remove the battery cover.

4. Replace the battery cover.1. Press in on the button on the rear of the remote.

CONNECTING A DEVICE

Your TV can be used to display output from most devices.

1. Verify that your device has a video port that matches an available port on the TV (HDMI, Component, etc.).

2. Turn the TV and your device o.

3. Connect the appropriate cable (not included) to the TV and the device.

4. Turn the TV and your device on. Set the TV’s input to match the

connection you used (HDMI-1, HDMI-2, etc.).

2Connecting Your Devices

Maximum Resolution

HDCP 2.2 supported on HDMI ports 1,2, and 5

* Recommended for use with high-performance devices only

†

Available for compatible gaming systems or high-performance PCs for display of 1080p @ 60 fps

Note:

The image shown here is for illustrative purposes only and may be subject to change. The actual number of ports and their locations may vary, depending on the model.

AV CABLE

GOOD

COMPONENT CABLE

BETTER

COAXIAL CABLE

BETTER

HDMI CABLE (HDMI 1-4)

BEST

HDMI CABLE (HDMI 5)*

BEST

• ANALOG

• SD VIDEO (480i)1

• STEREO AUDIO

• ANALOG

• HD VIDEO (1080p)1

• STEREO AUDIO

• ANALOG/DIGITAL

• HD VIDEO (1080i)1

• STEREO/HD AUDIO

• DIGITAL

• ULTRA HD VIDEO (4K @ 30 Hz)1

• HD AUDIO

• DIGITAL

• ULTRA HD VIDEO (4K @ 60 Hz)1

• HD AUDIO

• HIGH VELOCITY MODE

†

CONNECTING A DEVICE - AUDIO & VIDEO CABLE TYPES

COMPONENT VIDEO

AV CABLE

AV cables (or Composite cables) are the traditional way of connecting your devices to your TV. Video signals are sent over the yellow connector while audio is sent over the red and white connectors.

• Video Resolutions up to 480i

• Analog Connection

• Audio and Video Signals

Y L R

COAXIAL CABLE

Coaxial cables are the traditional way of

connecting antennas and cable television

signals to your TV. Coaxial cables carry both

audio and video signals through a single connector.

• HD Video Resolutions up to 1080i

• Analog Connection

• Audio and Video Signals

Coaxial

COMPONENT CABLE

Component cables are designed to carry high

denition video signals along with additional

audio connections. Colors are delivered with color

information split up three dierent ways over

three connectors for video (separated into Red, Blue and Green signals) and the left and right audio connectors (Red and White).

• HD Video Resolutions up to 1080p

• Analog Connection

• Audio and Video Signals

R L Pr/Cr Pb/Cb Y

HDMI CABLE

HDMI is the intelligent, all-digital interface that delivers both dazzling quality and unmatched ease of use. HDMI technology transmits crystal-clear digital video along with multi-channel surround audio. HDMI-connected devices have the ability to automatically adjust themselves for optimal viewing.

• HD Video Resolutions up to UHD*

• HD Audio

• Digital Connection

• Audio and Video Signals

HDMI

GOOD

* High-Speed HDMI cable required for UHD resolutions

BETTER

BEST

CONNECTING AN AUDIO DEVICE

Your TV can output sound to an audio device, such as a receiver or sound bar.

1. Verify that your device has an audio port that matches an available port on the TV (Optical, RCA, etc).

2. Turn the TV and your audio device o.

3. Connect the appropriate cable (not included) to the TV and the device.

4. Turn the TV and your device on.

Home Audio Receiver VIZIO Sound Bar

RCA CABLE

GOOD

OPTICAL/SPDIF CABLE

BETTER

• ANALOG STEREO CONNECTION

• 2.0 CHANNEL

• PCM STREAM

• DOLBY DIGITAL 5.1 CHANNEL

• DTS 5.1 CHANNEL

Note:

The image shown here is for illustrative purposes only and may be subject to change. The actual number of ports and their locations may vary, depending on the model.

HDMI CABLE

BEST

• ARC 2-WAY COMMUNICATION

• 2.0-5.1 DIGITAL AUDIO

• PCM, DTS, DOLBY DIGITAL

CONNECTING AN AUDIO DEVICE - AUDIO CABLE TYPES

COMPONENT VIDEO

RCA CABLE

RCA cables (or Composite cables) are the traditional way of connecting your devices to your audio device. Audio signals are sent over the red and white connectors.

• Quality Stereo Connection

• 2.0 Channel

• Analog Connection

• Audio Signal Only

L R

OPTICAL/SPDIF CABLE

Optical/SPDIF cables transmit audio signals as

pulses of light through a cable made of plastic

bers. Audio signals are digitally transmitted

between devices.

• PCM Stream (Lossless)

• Dolby Digital 5.1 Channel

• DTS 5.1 Channel

• Digital Connection

• Audio Signal Only

Optical/SPDIF

HDMI CABLE

HDMI technology transmits crystal-clear digital multi-channel surround audio through a single HDMI cable. Audio Return Channel-enabled (ARC) TVs allow audio to be sent over an already connected HDMI cable, eliminating the need for

a separate audio cable. See Connecting an Audio

Device - Arc on page 18.

• ARC 2-way Communication (Auto setup)

• PCM, DTS, Dolby Digital

• 2.0 - 5.1 Scaleable Lossless Digital Audio Connection

• Audio and Video Signals

HDMI

GOOD

BETTER

BEST

CONNECTING AN AUDIO DEVICE - ARC

WITHOUT HDMI ARC

Without an HDMI ARC setup, your TV will transmit audio signal from the built-in tuner and VIA apps to your home audio receiver through a separate audio connection.

Your TV

RCA (Audio)

HDMI Cable

WITH HDMI ARC

With an HDMI ARC setup, the audio connection between your TV and Home Audio Receiver can be removed. The HDMI cable will transmit audio signal to and from your TV with an all-digital audio/video connection.

Your TV

HDMI Cable

Your Home Audio Receiver

HDMI Cable

Your Blu-Ray Player

Your Home Audio Receiver

HDMI Cable

Your Blu-Ray Player

CONNECTING TO YOUR NETWORK

Your TV is Internet-ready. It can be connected to your home network with a Wired or Wireless connection.

Connecting to a Wired Network (Best)

1. Connect an Ethernet cable to your router and to the Ethernet

port on the back of the TV. See below.

2. Use the Guided Network Setup to congure the TV. See Using Guided Setup on page 48.

Connecting to a Wireless Network

1. Ensure you have a router or modem broadcasting as

high-speed wireless signal (802.11n recommended).

2. Use the Guided Network Setup to congure the TV. See Using Guided Setup on page 48

Router / ModemEthernet Cable

Note:

The image shown here is for illustrative purposes only and may be subject to change. The actual number of ports and their locations may vary, depending on the model.

3Completing The First-Time Setup

The first time you turn on the TV, the Setup App will guide you through each of the steps necessary to get your TV ready for use.

Before you begin the first-time setup:

• Your TV should be installed and the power cord should be connected to an electrical outlet.

• Your devices should be connected.

• If you have a wireless network, have the network password ready.

• If you are connecting to your network with an Ethernet cable, connect it to the Ethernet port on the TV.

To complete the first-time setup:

Press the Power button on the remote. The TV

powers on and the Setup App starts.

Use the Arrow buttons on the remote to highlight

your language of preference and press OK.

Select Store Demo for in-store display.

Seleccione "Home Use" para Modo de Casa o "Store Demo" para Demostración en la Tienda.

Choisissez "Home Use" pour le Mode Domicile ou "Store Demo" pour la Démo en Magasin.

Use the Arrow buttons on the remote to

highlight Home Use and press OK.

Choose your mode.

Select Home Use for in-home use.

Store Demo Home Use

Use the Arrow buttons on the remote to

highlight your country, and then press OK.

Select your time zone and press OK.

Select the name of your wireless network from the

list of available networks and press OK.

Use the Arrow and OK buttons on the remote to

review the Terms Of Service and Privacy Policy.

When you are nished, highlight I Accept

and press OK.

Enter the network password using the keyboard on the

remote, then highlight Connect and press OK.

Enter your E-mail Address, First Name, Last

Name, and Zip Code using the keyboard

on the remote.

Highlight Next and press OK.

Use the Arrow buttons on the remote to highlight

your TV source and press OK.

If the TV Signal channel scan screen appears, the

TV will need to scan for channels, which takes

several minutes.

Use the arrow buttons on the remote to highlight

Begin Scan and press OK.

If you have cable TV, select whether you have

a cable box or if you connect the TV directly

to a cable from the wall.

Note: Number of ports may differ by TV.

Otherwise, use the Arrow and OK buttons on the remote to select the input your TV source

is connected to.

When you are nished, the message

“Setup is complete.” will appear.

The First-Time Setup is complete.

+ 50 hidden pages
