Operating Instructions
VEGALOG 571 AT
Output card transistor
on
VEGALOGVEGALOG
571 AT
!
inin
outout
Contents
1 About this document
1.1 Function .............................
3
1.2 Target group ..........................
3
1.3 Symbolism used .......................
3
2 For your safety
2.1 Authorised personnel....................
4
2.2 Appropriate use........................
4
2.3 Warning about misuse ...................
4
2.4 CE conformity .........................
4
2.5 Environmental instructions ................
5
3 Product description
3.1 Configuration..........................
6
3.2 Principle of operation ....................
6
3.3 Operation ............................
6
3.4 Storage and transport ...................
7
4 Mounting
4.1 General instructions.....................
8
4.2 Module ..............................
8
4.3 Coding ..............................
8
5 Connecting to voltage supply
5.1 Preparing the connection .................
11
5.2 Connection cable.......................
11
5.3 Wiring plan ...........................
12
6 Set up
6.1 Indicating and adjustment elements .........
13
7 Maintenance and fault rectification
7.1 Maintenance ..........................
15
7.2 Fault rectification .......................
15
7.3 Instrument repair .......................
16
8 Dismounting
8.1 Dismounting procedure ..................
17
8.2 Disposal .............................
17
9 Supplement
9.1 Technical data.........................
18
9.2 Dimensions ...........................
20
2 VEGALOG 571 AT - Output card transistor
Contents
31951-EN-060720
1 About this document
1.1 Function
This operating instructions manual has all the information you
need for quick setup and safe operation. Please read this
manual before you start setup.
1.2 Target group
This operating instructions manual is directed to trained,
qualified personnel. The contents of this manual should be
made available to these personnel and put into practice by
them.
1.3 Symbolism used
Information, tip, note
This symbol indicates helpful additional information.
Caution: If this warning is ignored, faults or
malfunctions can result.
Warning: If this warning is ignored, injury to persons and/or
serious damage to the instrument can result.
Danger: If this warning is ignored, serious injury to persons
and/or destruction of the instrument can result.
Ex applications
This symbol indicates special instructions for Ex applications.
l List
The dot set in front indicates a list with no implied sequence.
à Action
This arrow indicates a single action.
1 Sequence
Numbers set in front indicate successive steps in a procedure.
VEGALOG 571 AT - Output card transistor 3
About this document
31951-EN-060720
2 For your safety
2.1 Authorised personnel
All operations described in this operating instructions manual
must be carried out only by trained specialist personnel
authorised by the operator. For safety and warranty reasons,
any internal work on the instruments must be carried out only
by personnel authorised by the manufacturer.
2.2 Appropriate use
The AT card (output transistor) provides together with the
VEGALOG 571 processing system ten floating outputs via
NPN transistors.
2.3 Warning about misuse
Inappropriate or incorrect use of the instrument can give rise to
application-specific hazards, e.g. vessel overfill or damage to
system components through incorrect mounting or adjustment.
2.4 General safety instructions
VEGALOG 571 AT is a high-tech instrument requiring the strict
observance of standard regulations and guidelines. The user
must take note of the safety instructions in this operating
instructions manual, the country-specific installation standards
(e.g. the VDE regulations in Germany) as well as all prevailing
safety regulations and accident prevention rules.
2.5 CE conformity
The VEGALOG 571 AT(Ex) module card is in CE conformity
with EMVG (89/336/EWG) and LVD (73/23/EWG).
Conformity has been judged according to the following
standards:
l EMC:
- Emission EN 50081-2
- Susceptibility EN 50082-1
l LVD: EN 61010
4 VEGALOG 571 AT - Output card transistor
For your safety
31951-EN-060720
2.6 Environmental instructions
Protection of the environment is one of our most important
duties. That is why we have introduced an environment
management system with the goal of continuously improving
company environmental protection. The environment management system is certified according to DIN EN ISO 14001.
Please help us fulfil this obligation by observing the environmental instructions in this manual:
l Chapter "Storage and transport"
l Chapter "Disposal"
VEGALOG 571 AT - Output card transistor 5
For your safety
31951-EN-060720
3 Product description
3.1 Configuration
The scope of delivery encompasses:
l 19" module card VEGALOG 571 AT
l Documentation
- this operating instructions manual
3.2 Principle of operation
The AT card (output transistor) provides together with the
VEGALOG 571 processing system ten floating outputs via
NPN transistors.
These can be used for transmission of the measuring results,
e.g. to binary input cards of a PLC.
The VEGALOG 571 AT card makes the processing results
available on up to ten outputs. It is suitable for outputting level,
single or sum fault messages. The switching condition of each
output is displayed via a two-coloured LED in the front plate.
Depending on the parameter adjustment, this LED lights
yellow as switching output, or if so configured, red as fault
output.
The voltage supply of the module card is provide via the
common power supply unit of the VEGALOG system.
You can find detailed information on the power supply in the
"Technical data" in the "Supplement".
3.3 Operation
The operation of VEGALOG 571 is carried out via a PC which
can be connected via the RS232 interface of the CPU. Asan
alternative, connection via Ethernet and VEGACOM 558 is
possible.
The adjustment software PACTware™ with the corresponding
DTMs is installed under Windows™ and ensures easy
configuration of measuring systems as well as parameter
adjustment of connected VEGA sensors. For this purpose,
PACTware™ provides a clear adjustment interface with menu
structure, window technology and graphic support. In addition,
online help is available which describes the available functions
Scope of delivery
Area of application
Physical principle
Power supply
6 VEGALOG 571 AT - Output card transistor
Product description
31951-EN-060720
and parameter adjustment options. For earlier VEGALOG
systems with CPU software 1.xx, the previous software VVO
(VEGA Visual Operating) must be used for operation.
3.4 Storage and transport
Your instrument was protected by packaging during transport.
Its capacity to handle normal loads during transport is assured
by a test according to DIN EN 24180.
The packaging of standard instruments consists of environ-
ment-friendly, recyclable cardboard. For special versions, PE
foam or PE foil is also used. Dispose of the packaging material
via specialised recycling companies.
l Storage and transport temperature see "Supplement -
Technical data - Ambient conditions"
l Relative humidity 20 … 85 %
Packaging
Storage and transport tem-
perature
VEGALOG 571 AT - Output card transistor 7
Product description
31951-EN-060720
4 Mounting
4.1 General instructions
The module cards of VEGALOG 571 can only be mounted into
the 19" carrier BGT LOG 571. It is provided with a special bus
board for data transmission between CPU and the individual
peripheral cards (LOGBUS). The carrier is designed for
mounting into a switching cabinet or 19" housing.
The plug position for the individual cards is individually
selectable, the system saves the card positions when switching on.
Note:
The plug positions must not be changed after the parameter
adjustment because measurement loops that have already
been set up would otherwise have to be reconfigured.
4.2 Module
Provide a module for the VEGALOG 571 AT card. You will find
the description in the operating instructions manual "CPU and
carrier".
4.3 Coding
A mechanical coding system avoids later interchanging of the
various module cards in the carrier.
The coding system consists of:
l two coded pins in the female multipoint connector
l two holes in the male multipoint connector of the respective
component
The coded pins are attached to the module.
Equip the female multipoint connector with the two coded pins
according to the "Coding chart" and "Position of the coded
pins". The function coding points out that these are module
cards of VEGALOG. The instrument coding is used to
differentiate between the individual module cards.
The male multipoint connectors of the individual module cards
point to the holes suiting the pin positions.
Mounting instructions
8 VEGALOG 571 AT - Output card transistor
Mounting
31951-EN-060720
Instrument coding Function coding
CPU card a1 c3
EP card a3 c3 and c23 with Ex
AA card a5 c3
AR card a7 c3
AT card a9 c3
EA card a11 c3
VEGACOM 557 a27 c3, c11
VEGACOM 558 a29 c11
VEGASTAB 593 -- --
o 9 o
z b d
o 1 o
a c
a1
a3
a5
a7
o 3 o
o 5 o
o 7 o
o11o
o13o
o15o
c3
o17o
o19o
o21o
o23o
o25o
o27o
o29o
o31o
a9
a11
a13
c11
c23
a23
a25
a27
3
1
2
Fig. 1: Positioning of the coded pins on the male multipoint connector
1 Instrument coding
2 Function coding
3 Ex coding
VEGALOG 571 AT - Output card transistor 9
Mounting
31951-EN-060720
1
Fig. 2: Detail coded pin mounting
1 Coded pin
10 VEGALOG 571 AT - Output card transistor
Mounting
31951-EN-060720
5 Connecting to voltage supply
5.1 Preparing the connection
Generally not the following safety instructions:
l Connect only in the complete absence of line voltage
l If overvoltage surges are expected, overvoltage arresters
should be installed
In hazardous areas you should take note of the appropriate
regulations, conformity and type approval certificates of the
sensors and power supply units.
The voltage supply of the module card is provide via the
common power supply unit of the VEGALOG system.
You can find detailed information on the power supply in the
"Technical data" in the "Supplement".
5.2 Connection cable
Power supply is connected with standard cable according to
the national installation standards.
To connect the transistor outputs, standard two-wire cable
without screen can be used. If electromagnetic interference is
expected which is above the test values of EN 61326 for
industrial areas, screened cable should be used.
Connect the cable screen on both ends to ground potential.
If potential equalisation currents are expected, the screen
connection on the side of VEGALOG 571 AT must be made
via a ceramic capacitor (e.g. 1 nF, 1500 V). The low frequency
potential equalisation currents are thus suppressed, but the
protective effect against high frequency interference signals
remains.
Take note of the corresponding installation regulations for Ex
applications. In particular, make sure that no potential equalisation currents flow over the cable screen. In case of
grounding on both sides this can be achieved by the use of a
capacitor or a separate potential equalisation.
The total capacitance of the cable and of all capacitors must
not exceed 10 nF in Ex applications.
Note safety instructions
Take note of safety
instructions for Ex
applications
Select power supply
Selecting the connection ca-
ble
Cable screening and grounding
Select connection
cable for Ex applications
VEGALOG 571 AT - Output card transistor 11
Connecting to voltage supply
31951-EN-060720
5.3 Wiring plan
Output
+
-
+
-
+
-
+
-
+
-
+
-
+
-
+
-
+
-
+
-
4
6
5
2
3
9
8
10
1
7
d20
d24
d22
d16
d18
d30
d28
d32
d14
d26
z20
z24
z22
z16
z18
z30
z28
z32
z14
z26
2
1
L (+)
N (-)
2
6
12
20
24
22
10
16
18
30
28
32
dbz
14
26
8
4
Fig. 3: VEGALOG 571 AT
1 Voltage supply for VEGALOG 571 AT
2 Assignment of the transistor outputs
12 VEGALOG 571 AT - Output card transistor
Connecting to voltage supply
31951-EN-060720
6 Set up
6.1 Indicating and adjustment elements
1
2
3
4
5
6
7
8
9
10
2
3
on
VEGALOGVEGALOG
571
!
1
Fig. 4: Indicating and adjustment elements
1 LEDs for switching condition of the outputs
2 LED for fault signal
3 LED for operating voltage
l LED status indication of the outputs [1]
- lights yellow when the output is switched (configuration
as switching output)
- lights red in case of fault signal (configuration as failure
output)
l LED fault signal [2]
- flashes in case of communication problems on the
LOGBUS
- lights during initialisation and during the self-test
- lights permanently during a hardware error
l LED operating voltage [3]
- lights when voltage supply is on
The module cards of the VEGALOG system have no own
adjustment elements. All adjustment measures are carried out
with the PC through the adjustment software PACTware™.
Description of the status
LEDs
VEGALOG 571 AT - Output card transistor 13
Set up
31951-EN-060720
Setup information is available in the operating instructions
manual "VEGALOG 571 CPU" as well as in the online help of
PACTware™.
14 VEGALOG 571 AT - Output card transistor
Set up
31951-EN-060720
7 Maintenance and fault rectification
7.1 Maintenance
When used as directed in normal operation, the module card
VEGALOG 571 AT is completely maintenance-free.
7.2 Fault rectification
VEGALOG 571 AT offers maximum reliability. Nevertheless
faults can occur during operation. These may be caused by the
following, e.g.:
l Measured value of the sensor not correct
l Voltage supply
l Interference on the cables
The first measures to be taken are checking the input/output
signal as well as processing failure messages. The diagnostic
information are updated cyclically in a 5 sec. pattern.
PACTware™ with the suitable DTM offers comprehensive
diagnostics options. The integrated online help offers you
additional information. In many cases, these cause can be thus
determined and faults can be rectified.
However, should this measures not be successful, call the
VEGA service hotline in urgent cases under the phone no. +49
1805 858550.
The hotline is available to you 7 days a week round-the-clock.
Since we offer this service world-wide, the support is only
available in the English language. The service is free of
charge, only the standard telephone costs will be charged.
The operating condition of the CPU and peripheral cards is
displayed via the status LEDs in the front plate.
l LED failure message (red)
- flashes in case of communication problems on the
LOGBUS
- lights during initialisation and during the self-test
- lights permanently during a hardware error
l LED operating voltage (green)
- lights when voltage supply is on
Causes of malfunction
Fault rectification
24 hour service hotline
Fault messages via LED status indication
VEGALOG 571 AT - Output card transistor 15
Maintenance and fault rectification
31951-EN-060720
7.3 Instrument repair
If a repair is necessary, please proceed as follows:
You can download a return form (23 KB) in the Internet from
our homepage
www.vega.com under: "Downloads - Forms
and Certificates - Repair form".
By doing this you help us carry out the repair quickly and
without having to call back for needed information.
l Print and fill out one form per instrument
l Clean the instrument and pack it damage-proof
l Attach the completed form and possibly also a safety data
sheet to the instrument
l Please contact the agency serving you for the address of
the return shipment
16 VEGALOG 571 AT - Output card transistor
Maintenance and fault rectification
31951-EN-060720
8 Dismounting
8.1 Dismounting procedure
Warning:
Before dismounting, be aware of dangerous process conditions such as e.g. pressure in the vessel, high temperatures,
corrosive or toxic products etc.
Take note of chapters "Mounting" and "Connecting to power
supply" and carry out the listed steps in reverse order.
8.2 Disposal
The instrument consists of materials which can be recycled by
specialised recycling companies. We use recyclable materials
and have designed the electronic modules to be easily
separable.
WEEE directive 2002/96/EG
This instrument is not subject to the WEEE directive 2002/96/
EG and the respective national laws (in Germany, e.g.
ElektroG). Pass the instrument directly on to a specialised
recycling company and do not use the municipal collecting
points. These may be used only for privately used products
according to the WEEE directive.
Correct disposal avoids negative effects to persons and
environment and ensures recycling of useful raw materials.
Materials: see "Technical data"
If you cannot dispose of the instrument properly, please
contact us about disposal methods or return.
VEGALOG 571 AT - Output card transistor 17
Dismounting
31951-EN-060720
9 Supplement
9.1 Technical data
General data
Series 19" module card for BGT LOG 571
Dimensions W = 25.4 mm (1 in), H = 128.4 mm (5.06 in), D
= 166 mm (6.54 in)
Weights approx. 400 g (0.882 lbs)
Voltage supply
Operating voltage (PIN d2, z2) 24 VDC(18 … 36 V)
Power consumption max. 6 W
Electrical connection
Module card Multipoint connector according to DIN 41612,
series F, 48-pole (d, b, z) with coding hole
Module in carrier BGT LOG 571 Suitable female multipoint connector according
to DIN 41612 with connection via standard
connection technologies
Transistor outputs
Quantity 10 outputs
Function Output of the processing results
Type NPN transistor
Turn-on voltage max. 36 VDC
Switching current max. 60 mA, short-circuit proof
Voltage loss <1.5 V at IB = 60 mA
Displays
LED displays
- Status indication operating voltage 1x LED green
- Status indication fault signal 1x LED red
- Switching status outputs 10x LED red/yellow
Ambient conditions
Ambient temperature -20 … +60 °C (-4 … +140 °F)
Storage and transport temperature -20 … +80 °C (-4 … +176 °F)
18 VEGALOG 571 AT - Output card transistor
Supplement
31951-EN-060720
Electrical protective measures
Protection mounted into BGT LOG 571
- front side completely equipped or
covered
IP 40
- upper and lower side IP 20
- wiring side IP 00
Protection class I (in the carrier BGT LOG 571)
Overvoltage category II
Electrical separating measures
Galvanic separation according to
VDE 0106, part 1
1)
between voltage supply, LOGBUS connection
and transistor outputs
- Reference voltage 250 V
Potential separation among transistor outputs
- Reference voltage 50 V
- Isolation resistance 0.5 kV
1)
All current outputs have a common reference potential (GND).
VEGALOG 571 AT - Output card transistor 19
Supplement
31951-EN-060720
9.2 Dimensions
100mm (3
15
/16")
162mm (6 3/8")
5,5mm (
7
/32")
9mm (
23
/64")
128,4mm (5
1
/16")
25,4mm
(1")
5 TE
on
VEGALOGVEGALOG
571
!
Fig. 5: Dimensions VEGALOG 571 AT
20 VEGALOG 571 AT - Output card transistor
Supplement
31951-EN-060720
VEGALOG 571 AT - Output card transistor 21
Supplement
31951-EN-060720
22 VEGALOG 571 AT - Output card transistor
Supplement
31951-EN-060720
VEGALOG 571 AT - Output card transistor 23
Supplement
31951-EN-060720
VEGA Grieshaber KG
Am Hohenstein 113
77761 Schiltach
Germany
Phone +49 7836 50-0
Fax +49 7836 50-201
E-mail: info@de.vega.com
www.vega.com
ISO 9001
All statements concerning scope of delivery, application,
practical use and operating conditions of the sensors and
processing systems correspond to the information avail-
able at the time of printing.
© VEGA Grieshaber KG, Schiltach/Germany 2006
Subject to change without prior notice 31951-EN-060720
Loading...
