C75KIT - Combustion Analyzer Kit:
The C75KIT is a solution for technicians working to set and maintain optimum efficiencies for boilers or furnaces. This kit includes the feature packed user-friendly interface as well as a DMM style rotary selector, a real time clock and a magnet built-in to the boot, the C75 captures and cal­culates data with professional accuracy and ease.
• Measures: Flue temperature, oxygen, carbon monoxide (CO)
• Calculates: Carbon dioxide, gross/net efficiency, excess air, CO air free
• Unique DMM style rotary selector
• Protective boot w/integral magnet
• Real time clock
• CO readings to 1 ppm
• Large 2 line back-lit display
• Infrared printer port
• User programmable header
• 20 memory positions
• 3 year limited warranty
Eagle 1 Combustion Analyzer. Equipped with a new improved
(2 year warranty on sensor)
Includes: C75 Analyzer, Flue Probe, Particle Filter, and Manual.
Includes: C75 Analyzer, Flue Probe, Smoke Pump Test Kit, Draft Pressure Gauge, AC Adapter, AC75 Soft Carrying Case, Particle filter, & Owners Guide.
Kit Includes:
Eagle 1 (C75) Combustion Analyzer
• KMIRP2 Infrared Thermal Printer
• Flue Probe ACA4 AC adapter
• A
• AC75 soft carrying case w/protective
foam interior
• Particle filter
• Thermal printer paper roll
• Owners guide
C125KIT - Combustion Analyzer Kit:
The C125KIT is 4 instruments in 1. Designed to offer advanced system analysis and productivity this kit includes the ground-breaking Eagle 2 Combustion Analyzer. This multi-functional instrument is a superior combustion analyzer with unmatched simplicity and a unique combination of features to enhance a technician’s efficiency and safety. The EAGLE 2 is perfect for combustion efficiency analysis but also doubles as a differential thermometer, differential manometer, and an ambient CO detector.
Same features as the EAGLE 1 (C75) Plus:
• Measures: Differential flue temperature, oxygen, flue & ambient carbon monoxide (CO), & Differential Pressure
• Calculates: Carbon dioxide, gross/net efficienc & CO air free
• Worklight
• 4 line backlit LCD display
• 179 memory positions
• User customizable par
ameters vie
w
• Individual report printouts
• 3 year limited warranty (2 year warranty on sensor)
y, excess air,
Includes: C125 Analyzer, Flue Probe, Particle Filter, AC75 Soft Carrying Case, Quick Start Manual, and Owners Guide.
Includes: C125 Analyzer, KMIRP2 Printer, Flue Probe, Smoke Pump Test Kit, (2) K-Type Temp. Probes, AC Adapter, AC75 Soft Carrying Case, Particle filter, Thermal printer paper roll, Quick Start Manual, & Owners Guide.
Kit Includes:
Eagle 2 (C125) Combustion Analyzer
• KMIRP2 Infrared Thermal Printer
• Flue Probe ype Temperature Probe
T
• (1) K-
• AACA4 AC adapter
• AC75 soft carrying case w/protective
foam interior
• Particle filter
• Thermal printer paper roll
• Quick start manual
• Owners guide
C127KIT - Combustion Analyzer Kit:
The C127KIT offers the same benefits of the Eagle 2 (C125KIT) with the additional ability to measure Nitric Oxide. This allows technicians to work in commercial and light industrial applications measuring Nitric Oxide at 1ppm resolution. The C127KIT offers a complete system analysis solution with clear-cut navigation.
Same features as the EAGLE 2 (C125) Plus:
• Measures: Nitric Oxide (NOx)
Includes: C127 Analyzer, Flue Probe, Particle Filter, AC75 Soft Carrying Case,Quick Start Manual, and Owners Guide.
Includes: C127 Analyzer, KMIRP2 Printer, Flue Probe, Smoke Pump Test Kit, (2) K-Type Temp. Probes, AC Adapter, AC75 Soft Carrying Case, Particle filter, Thermal printer paper roll, Quick Start Manual, & Owners Guide.
Kit Includes:
Eagle 3 (C127) Combustion Analyzer
• KMIRP2 Infrared Thermal Printer
• Flue Probe emperature Probe
ype T
T
• (1) K-
• AACA4 AC adapter
C75 soft carrying case w/protective
• A
foam interior
article filter
• P
• Thermal printer paper roll
• Quick start manual
• Owners guide
Specifications
Features C75 C125 C127
Worklight 44 Low battery indicator 44 Individual print-out reports 44 Rotary selector 44 4 Memory positions (various tests) 20 179 179 Infrared printer port Backlit display 2 Lines 4 Lines 4 Lines Boot with integral magnet User programmable headers 44 4 Time & date stamp 44 4 3 yr warranty (2 yr sensor warranty) 44 4
Temp Measurement
Flue Temp Range (T1 C125/C127) 32 ~ 1112˚F / 0 ~ 600˚C 20 ~ 2400˚F / -29 ~ 1315˚C Inlet Temp Range (T2 C125/C127) ­Inlet Temp Range (Ambient) 32 ~ 112˚F / 0 ~ 50˚C 32 ~ 112˚F / 0 ~ 50˚C Net Temp (∆T)** 32 ~ 1112˚F / 0 ~ 600˚C 20 ~ 2400˚F / -29 ~ 1315˚C Resolution 1˚F/˚C 0.1˚F/˚C Flue (T1, Inlet T2, & Net ∆T) Accuracy ±[0.3% rdg +5˚F(3˚C)] ±[0.3% rdg +3.6˚F(2˚C)] Inlet Temp Ambient Accuracy ±[0.3% rdg +1˚F(1˚C)] ±[0.3% rdg +1.8˚F(1˚C)]
Gas Measurement
Oxygen 0 ~ 21% 0 ~ 21% 0 ~ 21% O2 Resolution/Accuracy 0.1% / ±0.2%* 0.1% / ±0.2%* 0.1% / ±0.2%* Carbon Monoxide 0 ~ 1000 ppm 0 ~ 4000 ppm 0 ~ 4000 ppm CO Resolution/Accuracy 1 ppm/±10 ppm < 100 ppm* 1 ppm/±10 ppm < 100 ppm* 1 ppm/±10 ppm < 100 ppm*
±5% reading ±5% reading ±5% reading Carbon Dioxide** 0 ~ 30% 0 ~ 30% 0 ~ 30% CO2 Resolution/Accuracy 1.0%/±0.3% reading 1.0%/±0.3% reading 1.0%/±0.3% reading Efficiency** Efficiency Resolution/Accuracy 0.1%/±1.0% reading 0.1%/±1.0% reading 0.1%/±1.0% reading Excess Air** 0 ~ 250% 0 ~ 250% 0 ~ 250% Excess Air Resolution/Accuracy 0.1%/±0.2% reading 0.1%/±0.2% reading 0.1%/±0.2% reading Nitric Oxide - Range - - 0 ~ 100ppm Nitric Oxide Resolution/Accuracy - - 1ppm Resolution
0 ~ 99.9% 0 ~ 99.9% 0 ~ 99.9%
44 4
44 4
±2ppm <30ppm ±5ppm >30ppm
Pressure (Differential) Range Accuracy Resolution (High)
C125 & C127 ONL
Eagle Dimensions
Weight 2.2lbs. with boot Handset 7.9 x 1.8 x 3.5” Probe 11.8 x 0.25 x 9.4” stainless steel shaft, type K thermocouple (9’ hose) Operating temp 0 to 40˚C/10% to 90% Relative Humidity non-condensing Battery x4 “AA” cells / 12 hour life typical with Alkaline “AA” cells Warranty 3 year limited warranty (2 year sensor warranty)
Y
±0.08”wg (±0.2mBar) ±0.4”wg (±1mBar) ±0.01”wg (±0.03mBar) ±32”wg (±80mBar) ±3% reading
±0.002”wg (±0.005mBar)
Pre-Programmed Fuels
Natural Gas, Propane, Butane, LPG, Light Oil
*Measures **Calculates
0.001” wg to 9.999”
0.01” 10.00 to 32.00
++Eagle Series Accessories
ITEM# Description UPC
KMIRP2 Thermal Printer - IR Link 05353360520 EABT Eagle Bluetooth Upgrade 05353360594 AACA4 AC Adapter/Charger 05353360530 S
PT1 Smoke Pump Test Kit 05353360519 AC509 Hard Carrying Case (red) 05353360572 D460 Draft Velocity Gauge 05353350522 ATT100 Inlet Temp Probe, K-Type Liquid 6” 05353360235 EAKit Eagle II/III Acc Kit BF100/AACA4/2-ATT29/Hoses/AC519 05353360564 EARS232 Eagle RS232 Cable 05353360593
Eagle Replacement Parts/Supplies
KMCP2 Flue Probe 05353360492 FPTEXT Flue Probe Extention 05353360575 13124 Compression Ferrule (Eagle,CO91,Smart Bell.) 05353360615 16646 Thermal Paper for KMIRP2 05353360420 16646PACK Thermal Paper (10pack) 05353360611 SP9 Smoke Paper and Chart 05353360480 17631 Particle Filter 05353360401 17631PACK Particle Filter (10pack) 05353360612 16184* CO Sensor 05353360581 17662* O2 Sensor 05353360506 17979* SM11103 Inlet Tube 05353360583 SM11827 Water Trap 05353360609 CM11667/2 Water Trap Drain Plug 05353360535 CM11667/2PACK Water Trap Drain Plug (10 pack) 05353360608 ATT29 K-Type Thermocouple 05353360126 * Factory Installed ONLY.
NO Sensor (C127) 05353360582
