OWNER’S MANUAL

Outdoor Fireplace

Model No. WAD1081W-C

WARNING

FOR YOUR SAFETY:

For Outdoor Use Only

(outside any enclosure)

WARNING

FOR YOUR SAFETY:

1.Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage.

2.Read the installation, operation, and maintenance instructions thoroughly before installing or servicing this equipment.

3.Failure to follow these instructions could result in fire or explosion, which could cause property damage, personal injury, or death.

4.This instruction manual contains important information necessary for the proper assembly and safe use of the appliance.

5.Read and follow all warnings and instructions before assembling and using the appliance.

6.Follow all warnings and instructions when using the appliance.

7.Keep this manual for future reference.

Save these instructions for future reference.

If you are assembling this unit for someone else, give this manual to him or her to read and save for future reference.

Table of Contents



Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Page 2

Exploded View & Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . 3

Assembly Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . 4

Operating Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . 6

Lighting Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . 6

Tending the Fire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . 6

Cooking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . 6

Extinguishing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . 6

Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . 6

Inspecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . 6

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . 6

Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . 6

Product Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . 6

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . 6

Made from 75% Bagasse

(Environmentally Friendly Sugar

Cane Pulp By-product)

Manufactured in China for: Blue Rhino Global Sourcing, Inc.

Winston-Salem, NC USA • 1.800.762.1142, www.bluerhino.com

© 2011 Blue Rhino Global Sourcing, Inc. All Rights Reserved.



UniFlame® is a Registered Trademark of Blue Rhino Global Sourcing, Inc. All Rights Reserved.

WAD1081W-C-OM-106 EF

Outdoor Fireplace Model No. WAD1081W-C





WARNING







DANGER



















FOR YOUR SAFETY





















Do not store or use gasoline or other flammable liquids or vapors in the





Never operate this appliance unattended.

vincinity of this or any other appliance.





























DANGER: Failure to follow the dangers, warning and cautions in this manual may result in serious bodily injury or death, or in a fire or an explosion causing damage to property.

WARNING:

This appliance is for outdoor use only, and shall NOT be used in a building, garage or any other enclosed area.

Do NOT use this outdoor fireplace for indoor heating. TOXIC carbon monoxide fumes can accumulate and cause asphyxiation.

This outdoor fireplace is NOT for commercial use.

This outdoor fireplace is safety certified for use in the United States and Canada only. Do not modify for use in any other location. Modification will result in a safety hazard and will void the warranty.

This outdoor fireplace is NOT to be operated by children.

Do NOT operate, light or use this appliance within ten (10) feet (3.05 m) of walls, structures or buildings.

Do NOT store or use gasoline or other flammable vapors or liquids within 25 feet (7.62 m) in the vicinity of this or any other appliance.

Do NOT use in an explosive atmosphere. Keep outdoor fireplace area clear and free from combustible materials, gasoline and other flammable liquids.

Apartment Dwellers: Check with management to learn the requirements and fire codes for using an outdoor fireplace in your apartment complex. If allowed, use outside on the ground floor with a ten (10) foot (3.05 m) clearance from walls or rails. Do not use on or under balconies.

Always use in accordance with all applicable local, state and national codes. Contact your local fire department for details on outdoor burning.

When using this outdoor fireplace, exercise the same precautions you would with any open fire.

This outdoor fireplace is NOT to be used in or on boats or recreational vehicles.

Do NOT use this outdoor fireplace under any overhead or near any unprotected combustible constructions. Avoid using near or under overhanging trees and shrubs.

Do NOT use this outdoor fireplace without reading the entire “Owner’s Manual”.

This outdoor fireplace is for use with dry, seasoned hardwood. It will burn hotter, more completely and create less smoke.

Do NOT burn charcoal briquets, lump charcoal, manufactured logs, driftwood, trash, leaves, paper, cardboard, plywood, painted, stained or pressure treated wood. Avoid using softwoods such as pine or cedar which can throw sparks.

Do NOT use gasoline, kerosene, diesel fuel, lighter fluid or alcohol to light or relight fires.

Do NOT alter this outdoor fireplace in any manner. Any alteration will void your warranty.

Do NOT use this outdoor fireplace until it is COMPLETELY assembled and all parts are securely fastened and tightened.

The use of alcohol, prescription or non-prescription drugs may impair the consumer’s ability to properly assemble and/or safely operate this outdoor fireplace.

Do NOT use this outdoor fireplace near automobiles, trucks, vans or recreational vehicles.

Always use this outdoor fireplace on a hard, level, non-combustible surface such a concrete, rock or stone. An asphalt or blacktop surface may not be acceptable for this purpose. Do NOT use on wooden decks.

Do NOT wear flammable or loose clothing when operating this outdoor fireplace.

Do NOT use in windy conditions.

Do NOT lean over this outdoor fireplace when lighting or while in use.

Do NOT use this outdoor fireplace unless spark guards are securely in place.

Keep all electrical cords away from a hot fireplace.

All surfaces of this outdoor fireplace are hot when in operation. To avoid burns, do NOT touch fireplace until it has completely cooled (about 45 minutes) unless you are wearing protective gear (potholders, gloves, BBQ mittens, hot pads & etc.). Never touch ashes or coals to see if they are hot.

Do NOT leave a lit outdoor fireplace unattended, especially around children and pets.

Always empty this outdoor fireplace before each use.

Do NOT attempt to move or store this outdoor fireplace until all ashes and coals are completely extinguished.

Do NOT remove ashes or coals until they are completely and fully extinguished and the outdoor fireplace has completely cooled (about 45 minutes).

Do NOT place wood directly into bottom of the outdoor fireplace. Place wood only on the wood grate provided.

Do NOT overload the fireplace. Do not add additional firewood until the fire burns down. NOTICE: If any portion of the bowl, lid or spark guards of this outdoor fireplace are glowing red it is overloaded.

Do NOT place a hot spark guard or hot fireplace tools onto combustible surfaces such as grass, wooden deck or furniture.

Avoid breathing smoke from the fire and avoid getting it into your eyes.

This outdoor fireplace should be thoroughly inspected and cleaned on a regular basis.

After a period of storage and/or non-use, check for signs of damage and creosote build-up. Do NOT operate until necessary repairs and/or cleanup are executed.

Do NOT use oven cleaner or abrasive cleaners as they will damage this product.

Do NOT clean any part of this outdoor fireplace in a self cleaning oven as it may damage the finish.

Use only Blue Rhino Global Sourcing, Inc. factory authorized parts. The use of any part that is NOT factory authorized can be dangerous and will void your warranty.

Use heat-resistant gloves or hot pads when contacting handles. Use long, sturdy fireplace tools when adding or moving logs. Use protective gloves when assembling this product.

Do not force parts together as this can result in personal injury or damage to the product.

Deaths, serious injury or damage to property may occur if the above is not followed exactly.

Contact 1.800.762.1142 for assistance. Do not return to place of purchase.

Parts List





Exploded View

1

Handle

58-11-013

1















2

Spark Guard

58-11-014















3

Cooking Grid

58-11-015















4

Wood Grate

58-11-016



2









5

Bowl A

58-11-017

















6

Bowl B

58-11-018















7

Bowl Support

58-11-019















8

Fireplace Tool

58-11-020















9

Leg (4)

58-11-021



3



























4

5

6

7

8

page no.

3

9



Hardware







Tools Required for Assembly (Included)



A

Screw

M5x20 Nickel Plated

4 pcs



Allen Wrench



































B

Screw

M6x10 Nickel Plated

4 pcs

































C

Nut

M5 Nickel Plated

8 pcs

































D

Nut

M6 Nickel Plated

1 pc















Tools Required for Assembly (Not Included)















E

Lock Washer

ø5 Nickel Plated

4 pcs











#2 Phillips Head Screwdriver



















































Outdoor Fireplace Model No. WAD1081W-C

Assembly Instructions

1









DO NOT RETURN PRODUCT TO STORE.

2

Attach Handle







For assistance call 1.800.762.1142 toll free. Please have your owner’s manual and model number available for reference.

For Easiest Assembly:

To avoid losing any small components or hardware, assemble your product on a hard, level surface that does not have cracks or openings.

Clear an area large enough to layout all components and hardware.

When applicable, tighten all hardware connections by hand first. Once the step is completed go back and fully tighten all hardware.

Follow all steps in order to properly assemble your product.

Typical assembly: approximately 20 minutes.

D

x 1

3 Assemble Bowl

A

x 4

C

E

x8

x4

4 Assemble Base

B

x 4
