Ubiquiti USW-FLEX-MINI Data sheet

DATASHEET
Compact 5-Port Gigabit Switch
Powered by 802.3af/at PoE or USB Type C
Compact Desktop Footprint
Energy-Ecient Design
Model: USW-Flex-Mini
Overview
DATASHEET
Expand your network with the UniFi® Switch Flex Mini, part of the Ubiquiti® UniFi Enterprise System.
Compact Desktop Design
The cost-eective UniFi Switch Flex Mini can be discreetly integrated into any environment.
Copper Connectivity
Five RJ45 ports oer 10/100/1000 links. One port also supports
802.3af/at PoEinput.
Deployment Example
Printer
Game Console
Ecient Use of Energy
The UniFi Switch Flex Mini uses only a maximum of 2.5W.
For your convenience, it can be powered by 802.3af/at PoE or a 5V,1A USB-C power adapter*.
Switching Performance
The UniFi Switch Flex Mini oers the forwarding capacity to simultaneously process trac on all ports at line rate without any packet loss.
* Included only with the single-pack of the USW-Flex-Mini.
UDM
Internet
NAS
Computer
Remote Access to
UniFi Controller
The UniFi Switch Flex Mini connects a variety of devices, including a printer, game console, NAS, and computer.
2
Scalable UniFi Network Controller
DATASHEET
Management Capabilities
The UniFi Network™ Controller can provision UniFi devices, map out networks, and quickly manage system trac. Important network details are logically organized for a simplied, yet powerful,interface.
Network Overview
From a single pane of glass, view network topology and conguration, real-time statistics, and debugging metrics. Monitor your network’s vitals and make on-the-y adjustments as needed.
Deep Packet Inspection
Ubiquiti’s proprietary Deep Packet Inspection (DPI) engine includes the latest application identication signatures to track which applications (and IP addresses) are using the most bandwidth.
Detailed Analytics
The UniFi Network Controller provides congurable reporting and analytics to manage large user populations and expedite troubleshooting. Advanced search and sorting capabilities make network management more ecient.
Multi-Site Management
A single controller running in the cloud can manage multiple sites: multiple, distributed deployments and multi-tenancy for managed service providers. Each site is logically separated and has its own conguration, maps, statistics, guest portal, and administratoraccounts.
Switch Conguration
You can access the UniFi Switch Flex Mini through the UniFi Controller to congure a variety of features:
Operation mode (switching or mirroring) per port
Network/VLAN conguration
Jumbo frame and ow control services
Network settings
Storm control setting per port
Switch Port Status
You can also view status information for each port:
Connection speed and duplexmode
TX/RX data rates
Network/VLAN setting
Software Features
The UniFi Network Controller software oers the following features for the UniFi Switch Flex Mini:
Centralized conguration management (including conguration
cloning)
Auto-MDIX automatically adjusts as needed for straight through
or crossover cable
3
USW-Flex-Mini
Dimensions 107.16 x 70.15 x 21.17 mm
(4.22 x 2.76 x 0.83")
Weight 150 g (5.29 oz)
Interfaces
Networking PoE In Management
(5) 10/100/1000 RJ45 Ports
802.3af/at PoE (Pins 1, 2+; 3, 6-) Ethernet In-Band
SPECIFICATIONS
Total Non-Blocking
5 Gbps
Throughput
Switching Capacity 10 Gbps
Forwarding Rate 7.44 Mpps
Power Method
USB Type C, 5V
802.3af/at PoE
(44 - 57VDC, 0.05 - 0.04A)
Power Supply 5V, 1A Power Adapter*
Voltage Range
USB Type C
802.3af/at PoE
4.7 - 5.3V
44 - 57VDC
Max Power Consumption 2.5W
LEDs
System RJ45 Data Ports
Speed/Link/Activity
Status
ESD/EMP Protection Air: ± 16 kV, Contact: ± 12 kV
Shock and Vibration ETSI300-019-1.4 Standard
Operating Temperature -5 to 45° C (23 to 113° F)
Operating Humidity 10 - 90% Noncondensing
Certications CE, FCC, IC
* Included only with the single-pack of the USW-Flex-Mini
