Ubiquiti USG User Manual

Enterprise System Controller
Release Version: 4.8.7
Table of Contents
Chapter 1: Software Installation .....................................1
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
System Requirements ............................................................1
Network Topology Requirements .................................................1
Software Installation ..............................................................1
Chapter 2: UniFi Cloud ..............................................5
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
UniFi Cloud Key ..................................................................5
UniFi Cloud Account .............................................................12
Navigation Bar ..................................................................17
Common Interface Options ......................................................17
Table of ContentsUniFi Controller User Guide
Internet .........................................................................34
Gateway/Router .................................................................34
Local Area Network ..............................................................35
Wireless Local Area Network .....................................................35
Adding Custom Maps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Adding a Google Map ...........................................................38
Placing Devices on the Map ......................................................39
Map Display Options ............................................................40
Setting the Map Scale ...........................................................41
All ...............................................................................43
Gateway/Switches ...............................................................44
APs .............................................................................45
Phones ..........................................................................48
Properties .......................................................................48
All ...............................................................................51
Wireless .........................................................................52
Wired ...........................................................................53
Properties .......................................................................53
Ubiquiti Networks, Inc.
i
Table of Contents UniFi Controller User Guide
Clients (Total) ...................................................................56
Quick Look ......................................................................56
Current Usage - Top Access Points ...............................................56
Recent Activities .................................................................56
Filter ............................................................................57
Known Clients ...................................................................59
Rogue Access Points .............................................................60
Past Connections ................................................................61
Past Guest Authorizations .......................................................61
Switch Stats .....................................................................62
Remote User VPN ................................................................64
Dynamic DNS ...................................................................64
Port Forward Stats ...............................................................64
Properties .......................................................................67
UniFi Security Gateway – Details .................................................68
UniFi Security Gateway – Statistics ...............................................69
UniFi Security Gateway – Networks ..............................................69
UniFi Security Gateway – Configuration ..........................................70
Properties .......................................................................75
UniFi Switch – Details ............................................................76
UniFi Switch – Ports .............................................................77
UniFi Switch – Configuration .....................................................79
Properties .......................................................................83
UniFi Access Point – Details ......................................................84
UniFi Access Point – Users .......................................................87
UniFi Access Point – Guests ......................................................88
UniFi Access Point – Configuration ...............................................88
Properties .......................................................................95
UniFi VoIP Phone – Details .......................................................95
UniFi VoIP Phone – Configuration ................................................96
ii
Ubiquiti Networks, Inc.
Properties .......................................................................97
Wireless Client – Details .........................................................97
Wireless Client – Statistics .......................................................98
Wireless Client – History .........................................................98
Wireless Client – Configuration ..................................................99
Wired Client – Details .......................................................... 100
Wired Client – Statistics ........................................................ 100
Wired Client – History ......................................................... 101
Wired Client – Configuration ................................................... 101
Chapter 15: Hotspot Manager ....................................103
Guests ........................................................................ 103
Payments and Transactions .................................................... 104
Vouchers ...................................................................... 104
Operator Accounts ............................................................ 105
Table of ContentsUniFi Controller User Guide
Appendix A: Portal Customization ................................107
Overview ...................................................................... 107
Enabling Portal Customization ................................................. 107
Viewing the Default Portal ..................................................... 107
Setup ......................................................................... 108
Appendix B: UniFi Discovery Utility ...............................111
Overview ...................................................................... 111
Launching the UniFi Discovery Utility .......................................... 111
UniFi Discovery Utility Interface ................................................ 111
Appendix C: Mobile Apps ........................................115
Overview ...................................................................... 115
UniFi EasySetup App .......................................................... 115
UniFi EDU App ................................................................ 117
Appendix D: Controller Scenarios .................................119
Overview ...................................................................... 119
Hosting Controller Software ................................................... 119
Deployment Options .......................................................... 119
Layer-3 Adoption .............................................................. 122
Appendix E: Contact Information .................................125
Ubiquiti Networks, Inc.
Ubiquiti Networks Support .................................................... 125
iii
Table of Contents UniFi Controller User Guide
iv
Ubiquiti Networks, Inc.
Chapter 1: Software InstallationUniFi Controller User Guide
Internet
Cloud/NOC
Management
UAP-AC-Outdoor

Chapter 1: Software Installation

Introduction

Thank you for purchasing the Ubiquiti Networks® UniFi® Enterprise System. The UniFi devices are bundled with the UniFi Controller software, which allows you to manage your UniFi network using a web browser.
This User Guide is for use with version 4.8.7 or above of the UniFi Controller software.

System Requirements

• Linux, MacOSX, or Microsoft Windows 7/8/10
• Java Runtime Environment 1.6 (1.8 or above recommended)
• Web Browser: Mozilla Firefox, Google Chrome, Microsoft Edge, or Microsoft Internet Explorer 10 (or above)

Network Topology Requirements

• A DHCP-enabled network (so any device can obtain an IP address)
• One of the following:
• UniFi Cloud Key
• A management station running the UniFi Controller
software, located either on-site and connected to the same Layer-2 network, or off-site* in a cloud or NOC
• For the public address system capability of the UAP-AC-EDU: A compatible Android™ or iOS device located on the same Layer-2 network as the UniFi Controller and UniFi APs
All UniFi devices support off-site management controllers.
Follow the instructions in this chapter after you install the hardware, which is described in the Quick Start Guide.

Software Installation

Download the latest version of the UniFi Controller software at downloads.ubnt.com/unifi
Follow the instructions for your specific computer or device type.
UniFi Cloud Key Users
If you have the UniFi Cloud Key, please refer to “UniFi Cloud Key” on page 5 for more information.
UniFi Cloud Users
If you have a UniFi cloud account, please refer to “UniFi Cloud Account” on page 12 for more information.
Linux Users
Please refer to the UniFi blog on our community site at:
http://ubnt.link/UniFi-Blog
Mac Users
1. Launch UniFi.pkg.
2. Click Continue and follow the on-screen instructions to install the software.
* Requires Layer-3 adoption. For details, refer to:
http://ubnt.link/UniFi-Layer3-Adoption
Ubiquiti Networks, Inc.
CURRENT SITE
Default
DASHBOARD
Network Health
MAP
DEVICES
CLIENTS
CALLS
STATISTICS
INSIGHTS
SETTINGS
On-Site
Station
CURRENT SITE
Default
DASHBOARD
Network Health
MAP
DEVICES
CLIENTS
CALLS
STATISTICS
INSIGHTS
SETTINGS
O-Site
UAP-AC-PRO UAP-AC-PRO
REFRESH RATE
2 minutes
1G
UniFi Switch
3. Go to Go > Applications and double-click the UniFi icon.
LAN
or
REFRESH RATE
2 minutes
WAN
UniFi Security Gateway PRO
Proceed to “Configuring the UniFi Controller Software” on page 2.
Sample Network Diagram
1
Chapter 1: Software Installation UniFi Controller User Guide
PC Users
1. Launch UniFi-installer.exe.
2. Click Install.
3. If your computer doesn’t have Java 1.6 or above installed, you will be prompted to install it. Click Install to continue.
Configuring the UniFi Controller Software
1. The UniFi Controller software startup will begin. Click Launch a Browser to Manage Wireless Network.
2. Select your country and time zone. Alternatively, you can click restore from a previous backup to use a file that contains your backup settings. Click Next.
4. Click Next.
5. Ensure that the Start UniFi Controller after installation option is checked and click Finish.
Note: The UniFi Controller software can also be
launched from Start > All Programs.
Note: U.S. product versions are locked to the U.S.
Country Code to ensure compliance with FCC regulations.
3. Select the devices that you want to configure and clickNext.
2
Ubiquiti Networks, Inc.
Chapter 1: Software InstallationUniFi Controller User Guide
4. The UniFi Setup Wizard will create a secure primary wireless network for your devices. Perform the following steps:
a. Enter the wireless network name (SSID) in the Secure
SSID field.
b. Enter a passphrase to be used for your primary
network in the Security Key field.
c. To enable guest access, select Enable Guest Access,
and enter a guest network name in the Guest SSIDfield.
d. Click Next.
5. Enter an admin name in the Admin Name field and password in the Password field to use when accessing the management interface as a super admin. Confirm your password in the Confirm Password field. Click Next.
6. Review your settings. Click Finish to save your settings or click Back to make changes. Once the wizard is finished, the browser will be redirected to the management interface.
Congratulations, your wireless network is now configured.
A login screen will appear for the UniFi Controller management interface. Enter the admin name and password that you created and click Login.
Note: Only the super admin –not any site admin–
can view devices that are Pending Approval and then adopt them on the UniFi Controller. Ensure that you save the super admin login information for
futureuse.
Ubiquiti Networks, Inc.
Proceed to “Using the UniFi Controller Software” on page 17 for information on using the UniFi Controller
software.
3
Chapter 1: Software Installation UniFi Controller User Guide
4
Ubiquiti Networks, Inc.
Chapter 2: UniFi CloudUniFi Controller User Guide
UAP-AC Outdoor

UniFi Cloud Key

UniFi Switch
Internet
UAP-PRO
1G
UAP-AC-LR
UniFi Security
Gateway PRO
LAN
WAN
https://unifi.ubnt.com

Chapter 2: UniFi Cloud

Introduction

You can access the UniFi Controller via the UniFi Cloud Key and/or the UniFi cloud account. This chapter describes the following:
• UniFi Cloud Key
• “UniFi Cloud Account” on page 12
UniFi Cloud Key
The UniFi Cloud Key includes the pre-installed UniFi Controller software.
System Requirement
Web Browser: Google Chrome, Mozilla Firefox, Microsoft Edge, or Microsoft Internet Explorer 10 (or above)
Network Topology Requirement
A DHCP-enabled network (for the UniFi Cloud Key to obtain an IP address)
Chrome Instructions
1. Ensure that your host system is on the same Layer-2
network as the UniFi CloudKey.
2. Launch the Chrome web browser and type https://unifi.ubnt.com in the address field. Press enter (PC) or return (Mac).
3. Enter the username and password for your UBNT account. Click Sign In.
Software Installation
After you follow the hardware installation instructions in the UniFi Cloud Key Quick Start Guide, use one of the following methods to launch the software:
• If you are using Chrome, go to the Chrome Instructions section (recommended).
• If you are using a different web browser, go to “Instructions for Other Web Browsers” on page 7.
Sample Network Diagram
4. Click Find Cloud Key.
Note: The default fallback IP address of the UniFi
Cloud Key is 192.168.1.30.
5. If the Ubiquiti® Device Discovery Tool is already installed, proceed to step 7.
If the tool is not installed, you will be prompted to add it. Proceed to step 6.
Ubiquiti Networks, Inc.
5
Chapter 2: UniFi Cloud UniFi Controller User Guide
6. To install the tool:
a. Click Install.
b. Click Add app to confirm.
7. The Ubiquiti Device Discovery Tool will search for the UniFi Cloud Key. Select it to continue.
9. Wait for the UniFi Controller to be adopted, and then select it.
10. Click Launch Site.
8. Configure the UniFi Controller:
a. Select the appropriate country.
b. Select the appropriate time zone.
c. Enter an admin name in the Admin Name field
and a password in the Password field to use when accessing the management interface.
d. Confirm your password in the Confirm Password
field.
e. Keep the IP address or enter a hostname in the
Controller Hostname field.
f. If you want to set up an SSH login for management
access to the UniFi Cloud Key, then select Use non-default SSH credentials. Enter a username in the SSH Username field, and enter a password in the SSH Password field.
g. Click Submit to save your changes.
A login screen will appear for the UniFi Controller management interface. Enter the admin name and password that you created and click Login.
Proceed to “Using the UniFi Controller Software” on page 17 for information on using the UniFi Controller software.
Note: A future feature will enable backup of the
UniFi Controller database and configuration on the included microSD card.
6
Ubiquiti Networks, Inc.
Chapter 2: UniFi CloudUniFi Controller User Guide
Instructions for Other Web Browsers
1. Ensure that your host system is on the same Layer-2
network as the UniFi CloudKey.
2. The UniFi Cloud Key is set to DHCP by default, so it will try to automatically obtain an IP address. Assign a specific IP address to the UniFi Cloud Key, or check the DHCP server for its IP address.
Note: The default fallback IP address of the UniFi
Cloud Key is 192.168.1.30.
3. Launch the web browser. In the address field, type
https:// followed by the appropriate IP address. Press enter (PC) or return (Mac).
4. Click Manage to run the UniFi Setup Wizard.
6. Select the devices that you want to configure and clickNext.
7. The UniFi Setup Wizard will create a secure primary wireless network for your devices. Perform the following steps:
Note: You can click Configure to change the
settings of the UniFi Cloud Key (refer to “UniFi Cloud Key Configuration” on page 8 for more information). The default login is ubnt/ubnt or root/ubnt.
5. The UniFi Setup Wizard screen appears. Alternatively, you can click restore from a previous backup to use a file that contains your backup settings. Click Next.
Note: U.S. product versions are locked to the U.S.
Country Code to ensure compliance with FCC regulations.
a. Enter the wireless network name (SSID) in the Secure
SSID field.
b. Enter a passphrase to be used for your primary
network in the Security Key field.
c. To enable guest access, select Enable Guest Access,
and enter a guest network name in the Guest SSIDfield.
d. Click Next.
8. Enter an admin name in the Admin Name field and password in the Password field to use when accessing the management interface as a super admin. Confirm your password in the Confirm Password field. Click Next.
Ubiquiti Networks, Inc.
7
Chapter 2: UniFi Cloud UniFi Controller User Guide
Note: Only the super admin –not any site
admin– can view devices that are Pending Approval and then adopt them on the UniFi
Controller. Ensure that you save the super admin
login information for futureuse.
9. Review your settings. Click Finish to save your settings or click Back to make changes. Once the wizard is finished, the browser will be redirected to the management interface.
Congratulations, your wireless network is now configured.
A login screen will appear for the UniFi Controller management interface. Enter the admin name and password that you created and click Login.
UniFi Cloud Key Configuration
Login Instructions
1. Ensure that your host system is on the same Layer-2
network as the UniFi CloudKey.
2. The UniFi Cloud Key is set to DHCP by default, so it will try to automatically obtain an IP address. Assign a specific IP address to the UniFi Cloud Key, or check the DHCP server for its IP address.
Note: The default fallback IP address of the UniFi
Cloud Key is 192.168.1.30.
3. Launch the web browser. In the address field, type
https:// followed by the appropriate IP address. Press enter (PC) or return (Mac).
4. You have two options:
• Manage Click Manage to access the UniFi Controller. Proceed to “Using the UniFi Controller Software” on page 17 for more information.
• Configure Click Configure to change the settings of the UniFi Cloud Key.
Proceed to “Using the UniFi Controller Software” on page 17 for information on using the UniFi Controller software.
Note: A future feature will enable backup of the
UniFi Controller database and configuration on the included microSD card.
8
5. After you click Configure, enter the Username and Password (the default login is ubnt/ubnt). Then click Login.
The Main screen will appear.
Ubiquiti Networks, Inc.
Chapter 2: UniFi CloudUniFi Controller User Guide
Navigation Bar
The UniFi Cloud Key configuration consists of three primary pages:
• “Main” on page 9
• “Configuration” on page 10
• “Maintenance” on page 10
Username
At the top right of each screen, click the Username to display the Change Password and Logout options:
Change password To change the password, click
. The Change Password screen will appear:
Main
The Main screen displays basic status information about the UniFi Cloud Key.
Status
Device Name Displays the hostname or alias of the UniFi
Cloud Key.
MAC Address Displays the MAC address or hardware
identifier of the UniFi Cloud Key.
Version Displays the version number of the UniFi Cloud
Key firmware.
Uptime Displays the duration of time the UniFi Cloud Key
has been running.
Date Displays the current date and time.
Disk Space
Available Displays the percentage of available disk space.
Used Displays the amount of used disk space.
Free Displays the amount of available disk space.
Total Displays the total amount of disk space.
• Old password Enter the current password (the default is ubnt).
• New password Enter the new password.
• Confirm Password Enter the new password again.
• Submit Click Submit to apply changes.
• Cancel Click Cancel to discard changes.
Logout To manually sign out of the UniFi Cloud Key
configuration, click .
Ubiquiti Networks, Inc.
9
Chapter 2: UniFi Cloud UniFi Controller User Guide
Configuration
The Configuration screen allows you to configure the basic and network settings of the UniFi Cloud Key.
Basic Settings
Device Name Enter a descriptive name or identifier for
the UniFi Cloud Key. Also known as a host name.
Time Zone Select the appropriate time zone.
Reset Button Use of the hardware Reset button on the
UniFi Cloud Key is enabled by default. To prevent an accidental reset to default settings, click to toggle Off.
Network Settings
Configuration Mode Select the Internet connection type
for your service: Static or DHCP.
• Static The service provider assigns fixed network settings to your service for manual entry. Enter the following information:
- IP address Enter the Internet IP address of the UniFi Cloud Key.
- Netmask Enter the subnet mask of the UniFi Cloud Key.
- Gateway Enter the IP address of the network’s gateway router.
- Primary DNS Enter the IP address of the network’s primary DNS server.
- Secondary DNS Enter the IP address of the network’s secondary DNS server.
• DHCP The use of the Dynamic Host Configuration Protocol (DHCP) is the default. The UniFi Cloud Key automatically acquires network settings from the network’s DHCP server.
- Fallback IP Address Enter the IP address for the UniFi Cloud Key to use if an external DHCP server is not found.
- Fallback Netmask Enter the netmask for the UniFi Cloud Key to use if an external DHCP server is not found.
Apply Changes Click Apply Changes to save changes.
Discard Click Discard to cancel changes.
Maintenance
The Maintenance screen contains administrative options, so you can change the password, reboot the UniFi Cloud Key, power it off, reset it to factory defaults, upgrade the UniFi Cloud Key firmware, or upgrade the UniFi Controller software.
10
Ubiquiti Networks, Inc.
Chapter 2: UniFi CloudUniFi Controller User Guide
Security
Password To change the password, click Change
Password. The Change Password screen will appear:
• Old password Enter the current password (the default is ubnt).
• New password Enter the new password.
• Confirm Password Enter the new password again.
• Submit Click Submit to apply changes.
• Cancel Click Cancel to discard changes.
Maintenance
Reboot Click Reboot to powercycle the UniFi Cloud Key.
Power Off Click Power Off to turn off the UniFi Cloud Key.
Reset to Defaults Click Reset to Defaults to reset the
UniFi Cloud Key to its factory default settings. This option will reboot the UniFi Cloud Key, and all factory default settings will be restored.
Note: We recommend that you back up your UniFi
Controller configuration (refer to “Backup” on page 31 for more information) before resetting the UniFi Cloud Key to its defaults.
Firmware
Version Displays the version number of the UniFi Cloud
Key firmware.
Check for Updates Click Check for Updates to see if
there is a newer firmware version. If there is, then you can follow the on-screen instructions to upgrade now.
Update Manually Click Update Manually to update the
firmware. The Please Confirm Update screen will appear.
You have two options:
• upload file If you have the firmware saved in a specific location, then click Select File to browse for the file.
• get file from URL If you know the URL of the firmware’s location, then enter it in the URL field.
• Update Click Update to proceed with the update.
• Cancel Click Cancel to skip the update.
Note: Updating the UniFi Cloud Key firmware will
also update the UniFi Controller software. We recommend that you back up your UniFi Controller configuration (refer to “Backup” on page 31 for more information) before updating the UniFi Cloud Key firmware.
UniFi
Version Displays the version number of the UniFi
Controller software.
Check for Updates Click Check for Updates to see if
there is a newer software version. If there is, then you can follow the on-screen instructions to upgrade now.
Note: We recommend that you back up your UniFi
Controller configuration (refer to “Backup” on page 31 for more information) before upgrading.
Ubiquiti Networks, Inc.
11
Chapter 2: UniFi Cloud UniFi Controller User Guide

UniFi Cloud Account

You must be a super admin for initial cloud management. Once cloud access is enabled by the super admin, then any other admin can also enable cloud access.
Note: The cloud account is also known as the Single
Sign-On (SSO) account.
Login Instructions
1. Launch the Chrome web browser and type
https:// followed by the appropriate Controller Hostname/IP address as specified in “Settings >
Controller” on page 30. Press enter (PC) or return (Mac).
2. Enter the username and password for your UBNT account. Click Sign In.
(icon) Displays the icon corresponding to the device
running the UniFi Controller. Green indicates an active UniFi Controller. Gray indicates an inactive UniFi Controller.
UniFi Cloud Key
Computer
Controller Displays the hostname, alias, or MAC address
of the device running the UniFi Controller. You can click the name to get additional details at the bottom of the screen. (Go to “Additional Details” on page 13 for more information.)
IP Address Displays the IP address of the device running
the UniFi Controller.
Sites Displays the total number of sites managed by the
UniFi Controller.
Devices Displays the total number of devices managed
by the UniFi Controller.
Clients Displays the total number of clients on the sites
managed by the UniFi Controller.
Version Displays the software version number of your
UniFi Controller.
Actions Click a button to perform the desired action:
• Remove Click from your cloud account.
Chat At the lower left of the screen, click
window for online chat support.
to remove the UniFi Controller
to open a
Note: If you do not have an account, click
Register and follow the on-screen instructions.
A list of UniFi Controllers will appear.
# Displays the number of UniFi Controllers. Search Enter the text you want to search for. Simply
begin typing; there is no need to press Enter.
You can click any of the column headers to change the
listorder.
Admin
At the top right of the screen, click to display the My Account and Sign Out options:
My Account To change your account settings and/or
password, click . The Account Settings screen will appear:
12
Ubiquiti Networks, Inc.
Chapter 2: UniFi CloudUniFi Controller User Guide
There are three pages available:
• Profile Access your account settings:
- First Name Enter your first name.
- Last Name Enter your last name.
- Username Enter your login username.
- Email Enter the email address of your cloud account.
- Update Settings Click to apply your changes.
• Security Change your account password:
- Create a New Password Enter a new password with at least eight characters.
- Update Settings Click to apply your changes.
Manage
IP address Displays the IP address of the UniFi Cloud Key.
(status) Displays the status information: Adopted or
Pending Adoption.
mac Displays the MAC address or hardware identifier of
the UniFi Cloud Key.
firmware Displays the firmware version number of the
UniFi Cloud Key.
Manage Click to configure the UniFi Cloud Key. Refer to
“UniFi Cloud Key Configuration” on page 8 for more
information.
Cancel Click to exit this screen.
Additional Details
Select a UniFi Controller to display more information at the bottom of the screen.
• Beta Program Follow the on-screen instructions if you want to join the beta program.
Sign Out To manually sign out of the cloud account, click
.
Find Cloud Key
To add a UniFi Cloud Key, click Find Cloud Key at the top right of the screen. The Find Cloud Key screen will appear:
Adopt
IP address Displays the IP address of the UniFi Cloud Key.
(status) Displays the status information: Pending
Adoption.
mac Displays the MAC address or hardware identifier of
the UniFi Cloud Key.
firmware Displays the firmware version number of the
UniFi Cloud Key.
Adopt Click to adopt the UniFi Cloud Key. Refer to step
8 of “Chrome Instructions” on page 5 for more information.
Cancel Click to exit this screen.
• (icon) Green indicates an active UniFi Controller. Gray indicates an inactive UniFi Controller.
• (controller_name) Displays the Controller Hostname/IP address as specified in “Settings > Controller” on page
30.
• IP Address Displays the IP address of the device running the UniFi Controller.
• Sites Displays the total number of sites managed by the UniFi Controller.
• Software Version Displays the software version number of your UniFi Controller.
• Devices Displays the total number of devices managed by the UniFi Controller.
• Clients Displays the total number of clients on the sites managed by the UniFi Controller.
Ubiquiti Networks, Inc.
13
Chapter 2: UniFi Cloud UniFi Controller User Guide
Sites
• Search Enter the text you want to search for. Simply begin typing; there is no need to press Enter.
• (site_name) Displays the name of the site. You can click the name to get additional details on the right.
• (_ Unread Alerts) Displays the number of unread alerts.
(site_name)
• Launch Site Click Launch Site to access the UniFi Controller. Proceed to “Using the UniFi Controller Software” on page 17 for more information.
• (map) Displays a visual representation of your network’s status. The status of each dashboard node is indicated by color:
- Green Green indicates that the node is active and all devices are online.
www
WAN LAN
- Red Red indicates one of the following:
• WWW Internet connectivity is down.
• WAN The UniFi Security Gateway is offline.
• LAN One or more Switches are offline.
• WLAN More than half of the APs are offline.
www
WAN LAN
- Orange Orange indicates that half or fewer than half of the APs are offline.
Note: Orange is not applicable to the WWW,
WAN, and LAN nodes.
WLAN
WLAN
You can place the mouse over each node icon to display basic status information.
- WWW The basic details of the Internet connection are displayed.
• Gateway Displays the IP address of the service
provider’s gateway.
• DNS Displays the IP addresses of the Domain Name
System (DNS) servers.
• IP Displays the Internet IP address of the UniFi
Security Gateway.
• Uptime Displays the length of time the Internet
connection has been active.
• Latency Displays the amount of time it takes a
packet to travel from the UniFi Security Gateway to the service provider’s gateway.
• Up Displays the upload rate of your Internet
connection.
• Down Displays the download rate of your Internet
connection.
- WAN The basic details of the UniFi Security Gateway connection are displayed.
- Gray Gray indicates that there are no devices available for that node.
14
• LAN IP Displays the local IP address of the UniFi Security Gateway.
• Clients Displays the total number of local clients.
• Up Displays the upload rate of the UniFi Security Gateway.
• Down Displays the download rate of the UniFi Security Gateway.
Ubiquiti Networks, Inc.
- LAN The basic details of the wired network(s) are displayed.
• Gateway Displays the IP address of the service
provider’s gateway.
• Users Displays the number of clients connected to
the wired network.
• Guests Displays the number of clients connected
to the guest wired network.
• Switches Displays the number of UniFi Switches
connected to the wired network.
• Up Displays the upload rate of the wired
network(s).
• Down Displays the download rate of the wired
network(s).
- WLAN The basic details of the wireless network(s) are displayed.
Chapter 2: UniFi CloudUniFi Controller User Guide
• Users Displays the number of clients connected to
the primary wireless network(s).
• Guests Displays the number of clients connected
to the guest wireless network(s).
• APs Displays the number of APs in the primary
wireless network(s) and the number of APs in the guest wireless network(s).
• Up Displays the upload rate of the wireless
network(s).
• Down Displays the download rate of the wireless
network(s).
Ubiquiti Networks, Inc.
15
Chapter 2: UniFi Cloud UniFi Controller User Guide
16
Ubiquiti Networks, Inc.
UniFi Controller User Guide
CANCEL

Chapter 3: Using the UniFi Controller Software

Chapter 3: Using the UniFi Controller Software
The UniFi Controller software has a browser-based interface for easy configuration and management.
To access the interface, perform the following steps:
1. Launch the UniFi Controller application if hasn’t already been started.
• Mac users: Go > Applications > UniFi
• Windows users: Start > All Programs >
UbiquitiUniFi
2. The UniFi login screen will appear. Enter the username and password in the appropriate fields and clickLogIn.
Refresh
Click the refresh icon to update the on-screen information. Select the refresh interval: 15seconds,
1minute, 2minutes (default), 5minutes, or Never.
Admin
At the top right of the screen, click to display the Change Password and Sign Out options:
Change Password To change the login name and/or
password, click . The Change My Password screen will appear:

Navigation Bar

The UniFi software consists of six primary pages. This User Guide covers each page with a chapter. For details on a specific page, refer to the appropriate chapter.
“Dashboard” on page 33
“Map” on page 37
“Devices” on page 43
“Clients” on page 51
“Statistics” on page 55
“Insights” on page 59

Common Interface Options

The common interface options are accessible from all tabs in the UniFi interface.
• Admin Enter the admin name.
• Email Enter the email address of the admin account.
• Password Enter the new password.
• Confirm Password Enter the new password again.
• Save Click to apply changes.
• Cancel Click
Sign Out To manually sign out of the UniFi Configuration
Interface, click .
to discard changes.
Ubiquiti Networks, Inc.
17
Chapter 3: Using the UniFi Controller Software
UniFi Controller User Guide
Site
The UniFi Controller can manage multiple UniFi networks, which are called sites. Each site has its own configurations, maps, statistics, guest portals, and site administrator accounts. The multiple sites are logically separated, and the initial site is named Default.
Current Site To create a new site, click the drop-down
arrow to display the drop-down menu.
Click Add Site, and the Add Site screen will appear:
• Site Name Enter a name that describes the site. It will
be used in the Current Site drop-down menu.
• Submit Click
SUBMIT
to save changes.
Properties
The Properties tab is hidden by default. To display it, click the properties icon.
Information about each selected device appears as a popup within this tab. The information varies depending on the device type. For more information, see the appropriate chapter:
• “UniFi Security Gateway Details” on page 67
• “UniFi Switch Details” on page 75
• “UniFi Access Point Details” on page 83
• “UniFi VoIP Phone Details” on page 95
• “Client Details” on page 97
Settings
The tab displays a list of available sub-tabs:
• Site Site-related settings.
• Wireless Networks Wireless network and group setup, including Zero Handoff Roaming.
• Networks Wired network setup.
• Guest Control Guest portal and policies.
• Admins Admin accounts and privileges.
• User Groups User group settings.
• VoIP VoIP setup.
• Extensions VoIP extension, group, and conference options.
• Controller Identity, discovery, and email server settings.
• Cloud Access Cloud login credentials.
• Maintenance System configuration backup, system configuration restore, and support files.
Settings > Site
Configure the site-specific settings. To switch sites, select a different site from the Current Site drop-down menu at the top of any screen.
Controls and Live Chat
At the bottom left of the screen, there are three controls:
•
• Alerts (see “Alerts” on page 32)
•
Events (see “Events” on page 32)
At the bottom right of the screen, there is the live chat tab. Click
support.
18
Chat with us
to open a window for online chat
Site Configuration
Site Name Change the name of the site.
Country Select the appropriate country.
Time Zone Select the appropriate time zone.
Services
Automatic Upgrade When enabled, the following
options will automatically upgrade your firmware when an update is available.
• Automatically upgrade AP firmware Select this option to automatically upgrade firmware on the APs.
• Automatically upgrade phone firmware Select this option to automatically upgrade firmware on the Phones.
LED When enabled, the LED on the UniFi device will light
up. When disabled, the LED will turn off.
Ubiquiti Networks, Inc.
UniFi Controller User Guide
Chapter 3: Using the UniFi Controller Software
DPI (Beta) Deep Packet Inspection (DPI) is more
advanced than conventional Stateful Packet Inspection (SPI) filtering for traffic analysis. Ubiquiti’s proprietary DPI engine includes the latest application identification signatures to track which applications (and IP addresses) are using the most bandwidth.
• Clear DPI Counters Click to delete all collected DPI data. Click Confirm or Cancel.
Alert Select this option to enable alert emails, which will
be sent to the email addresses of the administrators.
Uplink Connectivity Monitor It monitors the uplinks of
the managed APs, either wired or wireless, by checking to see if the gateway/custom IP can be reached. The monitor and wireless uplink capability are enabled by default.
• Default Gateway Enabled by default. All managed APs will use the gateway of the AP that is providing IP information, either by DHCP or Static designation.
• Custom IP Click to specify an IP address.
- Uplink IP Address All managed APs will use the IP address you enter.
SNMP Select this option to activate the SNMP
(Simple Network Monitor Protocol) agent. SNMP is an application layer protocol that facilitates the exchange of management information between network devices. Network administrators use SNMP to monitor network-attached devices for issues that
warrantattention.
• Community String Specify the SNMP community string. It is required to authenticate access to MIB (Management Information Base) objects and functions as an embedded password. The device supports a read-only community string; authorized management stations have read access to all the objects in the MIB except the community strings, but do not have write access. The device supports SNMP v1. The default ispublic.
Remote Logging Enable to define a remote syslog server.
• Remote IP Address Enter the IP address of the syslog server.
• Port Enter the port number of the syslog server. The default is 514.
Device Authentication This option protects SSH access
to the UniFi devices. All devices in the same site share the same SSH username and password. You can also make changes:
• Username Enter the new username.
• Password Enter the new password.
Apply Click
to save changes.
Settings > Wireless Networks
Configure the wireless networks for each site. You can have up to four wireless network names or SSIDs per
WLANgroup.
WLAN Group The Default WLAN group is automatically
created.
Add a New WLAN Group To add a new WLAN group,
click the button. Go to the Add or Edit a WLAN Group section.
Add or Edit a WLAN Group
• Name Enter or edit a descriptive name for the WLAN group.
• Mobility To enable seamless roaming (Zero Handoff), select the checkbox.
Note: The UAP-AC, UAP-AC-Outdoor, UAP-AC-LITE,
UAP-AC-LR, UAP-AC-PRO, and UAP-AC-EDU do not support Zero Handoff Roaming.
When you enable this option, multiple Access Points (APs) act as an AP cluster, appearing as a single AP. The wireless client detects only one AP, so it seamlessly roams from AP to AP – there is no need to re-negotiate. The APs determine which AP has the best connection and should serve the client. They use multicasting to communicate so they must be wired in the same Layer 2 domain.
Zero Handoff Roaming does not support wireless uplinks and can only be used on a secured network. It is also not meant for all scenarios. For example, if there is too much load or interference, then Zero Handoff Roaming may not be appropriate for your scenario.
Ubiquiti Networks, Inc.
19
Chapter 3: Using the UniFi Controller Software
CANCEL
Configure the following options:
- Radio Select the appropriate radio, 2G or 5G.
- Channel Select the channel that all of the APs will use for Zero Handoff Roaming.
Load Balancing (Not available if you enabled the Mobility
option.) Select this option to balance the number of clients you specify per radio. Then enter the number of clients in the field provided.
Legacy Support (Not available if you enabled the Mobility
option.) By default, legacy devices, such as 802.11b devices, are excluded. Select this option if you want to support legacy devices.
Save Click to apply changes.
UniFi Controller User Guide
Create or Edit a Wireless Network
• Name/SSID Enter or edit the wireless network name
orSSID.
• Enabled Select this option to make this network active.
• Security Select the type of security to use on your wireless network.
- Open This option is typically only used on the guest network. When enabled, wireless network access is open to anyone without requiring a password.
- WEP WEP (Wired Equivalent Privacy) is the oldest
™
and least secure security algorithm. WPA
security
methods should be used when possible.
Cancel Click
to discard changes.
For each WLAN group, you have the following:
• Remove a WLAN Group To remove a WLAN group, select it from the drop-down menu, and then click the
button.
• Options To make changes, select the WLAN group from the drop-down menu, and then click . Go to “Add
or Edit a WLAN Group” on page 19.
Wireless Networks
Name Displays the wireless network name or SSID.
Security Displays the type of security being used on your
wireless network.
Guest Network Indicates whether or not the network is a
guest network.
Actions Click a button to perform the desired action:
• Edit Click to make changes to the wireless network settings. Go to the Create or Edit a Wireless Network section in the next column.
• Delete Click
Create Wireless Network Click
a wireless network. Go to the Create or Edit a Wireless Network section in the next column.
to remove the wireless network.
to add
• WEP Key Enter a WEP encryption key in
hexadecimal format. You can enter a 64-bit or 128-bit key:
Type Hex
64-bit 10 Hexadecimal Characters
(0-9, A-F, or a-f ) Example: 00112233AA Note: You can use 5 printable characters, which will be translated to the corresponding HEX code.
128-bit 26 Hexadecimal Characters
(0-9, A-F, or a-f ) Example:
00112233445566778899AABBCC
Note: You can use 13 printable characters, which will be translated to the corresponding HEX code.
• Key Index Specify which Index of the WEP Key
to use. Four different WEP keys can be configured at the same time, but only one is used. Select the effective key: 1, 2, 3, or 4.
- WPA-Personal WPA or Wi-Fi Protected Access was developed as an encryption method stronger than WEP. WPA-Personal requires a passphrase to connect to the wireless network.
• Security Key Enter the passphrase that users will
use to connect to the wireless network.
20
Ubiquiti Networks, Inc.
UniFi Controller User Guide
CANCEL
Chapter 3: Using the UniFi Controller Software
- WPA-Enterprise WPA Enterprise uses a RADIUS server to authenticate users on the wireless network.
• RADIUS Auth Server Provide the following
information about the RADIUS authentication server:
• IP Address Enter the IP address.
• Port Enter the port number. The default is 1812.
• Password Enter the password.
• Delete Click the delete
icon to remove this
authentication server.
• Add Auth Server If you have another
authentication server, click this option and complete the IP Address, Port, and Password fields.
• RADIUS Accounting Server Provide the following
information about the RADIUS server:
• IP Address Enter the IP address.
• Port Enter the port number. The default is 1813.
• Password Enter the password.
• Delete Click the delete
icon to remove this
accounting server.
• Add Acct Server If you have another accounting
server, click this option and complete the IP Address, Port, and Password fields.
• Guest Policy Select this option to enable guest access policies on this wireless network.
Advanced Options
• Hide SSID Select this option if you don’t want the wireless network name or SSID to be broadcast.
• WPA Mode (Available if WPA security is enabled.) Select the appropriate WPA method: Both, WPA1 Only, or WPA2 Only (default).
• Encryption Select the appropriate encryption method: Auto, TKIP Only, or AES/CCMPOnly (default).
• User Group Assign wireless users to a specific user group. For more information about user groups, see “Settings > User Groups” on page 28.
• UAPSD Disabled by default. Unscheduled Automatic Power Save Delivery. Select this option to enable the power save mode of Wi-Fi devices.
• Scheduled Select Enable WLAN Schedule to restrict wireless access to the schedule you set.
- Monday-Sunday Select the days you want to schedule.
- Hours Use the sliders to select the start and end times of the day’s wireless access.
• Save Click
• Cancel Click
to apply changes.
to discard changes.
Settings > Networks
Configure the networks for each site.
• VLAN To use a VLAN, select Use VLAN ID and enter the VLAN ID number.
Ubiquiti Networks, Inc.
Networks
Name Displays the network name.
Purpose Displays a description of this network.
Subnet Displays the IP address and prefix size.
VLAN Displays the VLAN ID, if applicable.
Actions Click a button to perform the desired action:
• Edit Click settings. Go to “Create or Edit a Network” on page
22.
• Delete (Not available for the default network.) Click
to remove the network.
Create New Network Click
network. Go to “Create or Edit a Network” on page 22.
to make changes to the network
to add a
21
Chapter 3: Using the UniFi Controller Software
UniFi Controller User Guide
Create or Edit a Network
• Name Enter or edit the network name.
• Purpose Select the most appropriate description:
Corporate, Guest, Remote User VPN, Site-to-Site VPN, Voice, or VLAN Only. Then follow the instructions for
your selection:
Corporate or Guest Network
• DHCP WINS Server Select this option to designate WINS (Windows Internet Naming Service) server(s).
- WINS Server 1/2 Enter the IP address of the WINS server in each field.
• DHCP Lease Time The IP addresses assigned by the DHCP server are valid only for the duration specified by the lease time. Increasing the time ensures client operation without interruption, but could introduce potential conflicts. Decreasing the lease time avoids potential address conflicts, but might cause more slight interruptions to the client while it acquires a new IP address from the DHCP server. Enter the number of seconds.
• DHCP Guarding Disabled by default. Select this option to detect and block unauthorized DHCP servers.
- Trusted DHCP Server IP Enter the IP address of the trusted DHCP server.
• Save Click
• Cancel Click
Remote User VPN
to apply changes.
CANCEL
to discard changes.
• IP/Subnet Enter the IP address and prefix size.
• VLAN (Not available for the default Corporate network, LAN.) Enter the VLAN ID.
• IGMP Snooping Select this option to monitor IGMP (Internet Group Management Protocol) traffic and thereby manage multicast traffic.
• DHCP Server Enabled by default. The local DHCP server assigns IP addresses to DHCP clients on the network.
• DHCP Range Enter the starting and ending IP addresses of the range in the fields provided.
• DHCP Name Server Configure the name or DNS (Domain Name System) server setting.
- Auto Enabled by default. Name servers are automatically assigned by the DHCP server.
- Manual Select this option to manually select name servers.
• Name Server 1/2 Enter the IP address of the name
server in each field.
• IP/Subnet Enter the IP address and prefix size.
• IP Pool The starting and ending IP addresses of the pool automatically appear after you complete the IP/Subnet field.
• Name Server Configure the name or DNS (Domain Name System) server setting.
- Auto Enabled by default. Name servers are automatically assigned by the DHCP server.
- Manual Select this option to manually select name servers.
• Name Server 1/2 Enter the IP address of the name
server in each field.
• WINS Server Select this option to designate WINS (Windows Internet Naming Service) server(s).
- WINS Server 1/2 Enter the IP address of the WINS server in each field.
• RADIUS IP Enter the IP address of the RADIUS server, which is used for authentication.
• RADIUS Password Enter the password of the RADIUS server.
22
Ubiquiti Networks, Inc.
UniFi Controller User Guide
CANCEL
Chapter 3: Using the UniFi Controller Software
• Site-to-Site VPN Enabled by default. The remote user can access the site’s resources as well as the resources of any other VPNs connected to the site. If you disable this option, then the remote user can only access the site’s resources.
• Save Click
• Cancel Click
Site-to-Site VPN
to apply changes.
to discard changes.
• Remote Site Select the appropriate site from the drop-down list.
Note: If you have admin privileges for the local and
remote sites, then you can view and select sites.
• Save Click
• Cancel Click
Voice
to apply changes.
CANCEL
to discard changes.
- Manual Select this option to manually select name servers.
• Name Server 1/2 Enter the IP address of the name
server in each field.
• DHCP WINS Server Select this option to designate WINS (Windows Internet Naming Service) server(s).
- WINS Server 1/2 Enter the IP address of the WINS server in each field.
• DHCP Lease Time The IP addresses assigned by the DHCP server are valid only for the duration specified by the lease time. Increasing the time ensures client operation without interruption, but could introduce potential conflicts. Decreasing the lease time avoids potential address conflicts, but might cause more slight interruptions to the client while it acquires a new IP address from the DHCP server. Enter the number of seconds.
• DHCP Guarding Select this option to detect and block unauthorized DHCP servers.
- Trusted DHCP Server IP Enter the IP address of the trusted DHCP server.
• Save Click
• Cancel Click
VLAN Only
to apply changes.
CANCEL
to discard changes.
If you enable VoIP, then the UniFi Controller automatically creates a Voice network; otherwise this network option is not available.
• IP/Subnet Enter the IP address and prefix size.
• IGMP Snooping Select this option to monitor IGMP (Internet Group Management Protocol) traffic and thereby manage multicast traffic.
• DHCP Server Enabled by default. The local DHCP server assigns IP addresses to DHCP clients on the network.
• DHCP Range Enter the starting and ending IP addresses of the range in the fields provided.
• DHCP Name Server Configure the name or DNS (Domain Name System) server setting.
- Auto Enabled by default. Name servers are automatically assigned by the DHCP server.
Ubiquiti Networks, Inc.
• VLAN Enter the ID number of the VLAN. Devices belonging to the same VLAN communicate as if they were attached to the same wire. Every VLAN ID represents a different VLAN. The VLAN ID range is 2 to
4009.
• IGMP Snooping Select this option to monitor IGMP (Internet Group Management Protocol) traffic and thereby manage multicast traffic.
• DHCP Guarding Select this option to detect and block unauthorized DHCP servers.
- Trusted DHCP Server IP Enter the IP address of the trusted DHCP server.
• Save Click
• Cancel Click
to apply changes.
CANCEL
to discard changes.
23
Chapter 3: Using the UniFi Controller Software
UniFi Controller User Guide
Settings > Guest Control
The Guest Control screen displays the following sections:
• Guest Policies (see below)
• “Hotspot” on page 25 (for Hotspot authentication)
• “Access Control” on page 27
Guest Policies
Enable Guest Portal Disabled by default. When disabled,
guests can access the Internet without entering a password or accepting the Terms of Use. When this option is enabled, you can control the Guest Portal.
Authentication When the Guest Portal is enabled, the
authentication options will appear:
• “Authentication > No Authentication” on page 24
• “Authentication > Simple Password” on page 24
• “Authentication > Hotspot” on page 25
• “Authentication > External Portal Server” on page 27
Authentication > No Authentication
Select this option if guests are not required to log in, but must accept the Terms of Use. You must also select Enable Guest Portal under Settings > Guest Control to enforce selection of the Terms of Use by the guest. See “Guest
Policy” on page 21 for more information.
Landing Page After accepting the Terms of Use, guests
are redirected to the landing page. Select one of the following options:
• Redirect to the original URL After accepting the Terms of Use, guests are directed to the URL they requested.
• Promotional URL After accepting the Terms of Use, guests are redirected to the URL that you specify. Ensure that the URL begins with http://. Example: http://www.ubnt.com
Portal Customization Select this option to have
customized portal pages appear in place of the default login pages. See “Portal Customization” on page 107 for details on setting up custom portal pages.
Portal URL Hostname Select this option to enter and
use a hostname for the portal URL in place of the default IP address. Paired with an SSL certificate, this ensures that site certificates are displayed as trusted in the guest browser. Example: www.ubnt.com
When logging in with No authentication, guests will be required to accept the Terms of Use before gaining access to the Internet.
Authentication > Simple Password
Select this option if guests are required to enter a simple password and accept the Terms of Use. You must also select Enable Guest Portal under Settings > Guest Control to enforce password entry and selection of the Terms of Use by the guest. See “Guest Policy” on page 21 for more information.
Expiration Specify the guest login expiration after a
designated period of time: 8 hours, 24hours, 2 days, 3 days, 4 days, 7 days, or User-defined, which can be designated in minutes, hours, and days.
24
Guest Password Enter a password that guests must enter
before accepting the Terms of Use and connecting to the Internet.
Expiration Specify the guest login expiration after a
designated period of time: 8 hours, 24hours, 2 days, 3 days, 4 days, 7 days, or User-defined, which can be designated in minutes, hours, and days.
Ubiquiti Networks, Inc.
Loading...
+ 102 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
