UDM-Pro Quick Start Guide
Package Contents
UniFi Dream Machine Pro Rack-Mount Brackets (Qty. 2) Bracket Screws (Qty. 8)
UDM-Pro Quick Start Guide
Mounting Screws (Qty. 4) Cage Nuts (Qty. 4) Security Screw
2.5" HDD Screws (Qty. 4) Power Cord Rubber Feet (Qty. 4)
System Requirement
Either of the following is required:
iOS or Android™ Mobile Device with UniFi Network App Installed
Web Browser: Google Chrome (Other browsers may have limited functionality)
IMPORTANT: We strongly recommend using UPS backup and power regulation to
prevent equipment damage due to stability issues with local AC power.
http://dl-origin.ubnt.com/qsg/UDM-Pro/UDM-Pro_EN.html[03.04.2020 10:43:36]
UDM-Pro Quick Start Guide
Hardware Overview
Touchscreen Display
Bootup Animation Initializing.
This indicates that you clicked Locate in the UniFi
Location Animation
Controller software. The software will also display the
location of the device on the map.
HDD LED
Flashing White Indicates Read/Write Activity
Steady Amber Indicates HDD Error
RJ-45 Speed/Link/Activity LED (Ports 1 - 9)
Off No Link
Link Established at 10/100 Mbps
Amber
Flashing Indicates Activity
Link Established at 1 Gbps
Green
Flashing Indicates Activity
SFP+ Speed/Link/Activity LED (Ports 10 - 11)
Off No Link
http://dl-origin.ubnt.com/qsg/UDM-Pro/UDM-Pro_EN.html[03.04.2020 10:43:36]
UDM-Pro Quick Start Guide
Link Established at 1 Gbps
Green
White
HDD Bay
Install a 3.5" or 2.5" HDD (not included) to use the device as an NVR for UniFi Protect.
RJ45 LAN (Ports 1 - 8)
The RJ45 ports support 10/100/1000 Ethernet connections. By default, they are set to
DHCP Server with the fallback IP address, 192.168.1.1/24.
RJ45 Internet (Port 9)
Flashing Indicates Activity
Link Established at 10 Gbps
Flashing Indicates Activity
The RJ45 port supports a 10/100/1000 Ethernet connection. Set to DHCP Client by default.
SFP+ Internet (Port 10)
The SFP+ port supports a 1/10G Ethernet connection. Set to DHCP Client by default.
SFP+ LAN (Port 11)
The SFP+ port supports a 1/10G Ethernet connection. By default, it is set to DHCP Server
with the fallback IP address, 192.168.1.1/24.
Reset Button
Resets to factory defaults. The device should be running after bootup is complete. Press
and hold the Reset button for about 10 seconds until the display indicates that the device
has reset itself. After a few seconds, the LED will turn off, and the device will automatically
reboot.
USP RPS LED
Reserved for future use.
USP Connect DC Input
Reserved for future use.
Power Port
Connect the included Power Cord to the Power port.
http://dl-origin.ubnt.com/qsg/UDM-Pro/UDM-Pro_EN.html[03.04.2020 10:43:36]
UDM-Pro Quick Start Guide
Installation Requirements
Phillips screwdriver
Standard-sized, 19" wide rack with a minimum of 1U height available
For indoor applications, use Category 5 (or above) UTP cabling approved for indoor use.
For outdoor applications, shielded Category 5 (or above) cabling should be used for all
wired Ethernet connections and should be grounded through the AC ground of the power
supply.
We recommend that you protect your networks from harmful outdoor environments and
destructive ESD events with industrial-grade, shielded Ethernet cable from Ubiquiti. For
more details, visit:
Installing an HDD
ui.com/toughcable
Note: Although the cabling can be located outdoors, the UDM-Pro itself should be
housed inside a protective enclosure.
Ensure the device is powered off before you install the 3.5" or 2.5" HDD (not included).
1.
2.
http://dl-origin.ubnt.com/qsg/UDM-Pro/UDM-Pro_EN.html[03.04.2020 10:43:36]
UDM-Pro Quick Start Guide
3.
4.
http://dl-origin.ubnt.com/qsg/UDM-Pro/UDM-Pro_EN.html[03.04.2020 10:43:36]
UDM-Pro Quick Start Guide
http://dl-origin.ubnt.com/qsg/UDM-Pro/UDM-Pro_EN.html[03.04.2020 10:43:36]
UDM-Pro Quick Start Guide
OR
5.
http://dl-origin.ubnt.com/qsg/UDM-Pro/UDM-Pro_EN.html[03.04.2020 10:43:36]
