ESPRIT
EZ serie
PASSION OF SOUND
INCE THE VERY BEGINNING, TRIANGLE HAS
MADE TECHNOLOGICAL RESEARCH AND
INNOVATION ITS PRINCIPAL PRIORITIES,
S
A NATURAL SOUND OF THE HIGHEST QUALITY.
An enthusiastic team of engineers and technicians,
constantly seeking to improve and innovate, are part
of what makes TRIANGLE loudspeakers unique.
Each component is designed, engineered and
developed, according to technical innovations and
solutions, that are exclusive to TRIANGLE.
WITH THE AIM OF OFFERING MUSIC-LOVERS
1980
2015
35 years
of inNovation
TRIANGLE strives hard to give each new
generation of loudspeakers a distinctive
musicality, created by using materials of the
highest quality. 35 years of experience have
forged a unique sound expertise that provides
extraordinary sonic realism and details.
ESPRIT Ez is the genuine materialisation of
TRIANGLE’s philosophy: it offers music lovers
an uncompromising, dynamic and living sound,
which conveys all the finesse and beauty of any
musical composition.
Rediscover your first musical sensations and
pleasure - and be astounded by the enjoyment
delivered by the new ESPRIT Ez.
ESPRIT EZ
design, musicality
& enjoyment
ESPRIT features a sleek design that compliments
the excellent sound. The loud speakers’ clean and
sharp lines are underscored by aluminium trims
with concealed screws. The floorstanders sit on a
glass pedestal with adaptable spikes. The ESPRIT Ez
speakers are desirable and aesthetic objects that fit in
perfectly into your home environment.
The grills attach to the cabinet through the clever use
of hidden magnets.
The speaker blends into its surroundings and brings
out all the intensity of music.
BLACK,
WHITE,
WALNUT,
follow your style
ESPRIT Ez speakers are available in three different
finishes: Walnut, Black or White High Gloss.
Select a black or white high gloss finish to bring
modernity and light in your living room, or choose
the walnut finish for a warm and natural touch.
walnutwhite lacquerblack lacquer
JAZZ,
HIP-HOP
OR ROCK
your tracks
High fidelity is above all about the pleasure
of listening to a perfect reproduction of your
favourite tracks. Whether classical, rock, jazz,
hip-hop or electronic music, a great speaker
must excel.
TRIANGLE speakers are extremely versatile
thanks to their high sensitivity and strong
dynamics. The horn-loaded tweeter can relay the
fine, detailed subtleness of a large orchestra’s
string section.
The midrange driver catches and reproduces
all aspects and nuances of emotionally charged
instruments, including the human voice.
The woofer provides deep and tight bass
reproduction, essential for full enjoyment of
rhythmical music, such as hip-hop or electro.
The objective is to express and convey all the
emotions and the musical mastery that went into
the tracks your favourite artists cut in the studio
or on stage.
The ESPRIT Ez - series provides strong versatility
both as a stereo system and as a home theatre
system. Its vigorous performance makes it a
perfect sound system for your television or home
theatre installation.
The centre channel, VOCE Ez, is specifically
designed to maintain the tonal balance in 5.1
configurations and give coherence and realism to
the audio tracks of films and TV-series.
For the rear channels, the range offers options
such as the HEYDA Ez satellites to create the full
360° surround effect, while the subwoofer THETIS
thickens the sound, thereby providing a clear and
deep bass. These products are designed with the
sole objective of placing you at the heart of the
action.
1
1
2
3
4
4
4
4
HOME- THEATRE
SYSTEM
1 ANTAL EZ or GAÏA EZ
2 Center channel VOCE EZ
3 Subwoofer THETIS 280 or 380
4 Surround Channels : TITUS EZ or HEYDA EZ.
”
TRIANGLE’s philosophy is to
design and build speakers
reproducing a lively and dynamic
sound that puts you in the
universe of your favourite artist
from the first tone. Always looking
for innovations, our team has a
genuine desire to make you feel
the music intensely and find
yourself at the heart of a concert.
When you really feel a «live»
experience, the music is taken to
a new dimension; the soundstage
opens, the musicians stand in
front of you, each instrument is
distinguished accurately and the
music gives you the chills.
„
THE PURSUIT
OF LIVE SOUND
Sensitivity
& Realism
First of all, the TRIANGLE sound is
built on a decision to build « high
performing » speakers.
Our tweeters have a sensitivity of
96 db, which increases the overall
efciency of our speakers, thereby
producing tremendous energy and
vitality.
They provide a natural reproduction
of the instruments and voices. As a
result, the sound is literally brought
to life.
fast
& Detailed
To create an excellent realism of
voices, as well as the nesse and
details of each instrument, a driver
needs to be fast and accurate.
TRIANGLE uses light and resistant
materials to maintain maximum
information levels even at low
volume.
The research conducted with the Magellan
range improves the directivity and efciency of
the horn loaded tweeter.
TRIANGLE favours cellulose pulp
membranes (paper) for the midrange
drivers, due to the low weight and
high rigidity. Combined with the small
pleated suspensions, this assures low
coloration, amazing accuracy and
quality of voices.
The woofers have a glass bre
membrane, with an inverted half-roll
suspension, to assure the driver stops
quickly and precisely. This technology
prevents any unwanted resonance
and produces top quality sound.
NOBLE
MATERIALS
”
As with a musical instrument,
the quality of each part has a
decisive impact on the speakers’
acoustic performance.
TRIANGLE carefully selects
each component with the sole
purpose of enhancing your
experience.
„
The art of cabinet making
In order to reach the highest possible acoustical performance, particular
attention is paid to the construction of the cabinet. Thanks to a highdensity fiberboard cabinet of up to 21 mm of thickness and clever use of
reinforcements, ESPRIT Ez’s cabinets ensure very high rigidity in order to
minimize vibrations from the drivers.
The Magellan project was a huge leap forward in the understanding of
vibrational behaviour. TRIANGLE now uses high-precision laser sensors in
order to place cabinet reinforcements at the optimal locations.
Hence the ESPRIT Ez cabinet significantly reduces coloration and sound
distortion, and only delivers the beauty and depth of the musical work.
Glass
Pedestal
Brushed
aluminium
terminal
Specially designed for
ESPRIT Ez, the terminal is
created in brushed aluminium,
providing ease of use and
extraordinary visual quality. The
material prevents vibrations and
seals the cabinet. Each terminal
is equipped with high quality
cooper binding posts with a
self-locking system for banana
plugs.
They can also accommodate
a number of other cable
choices.
Sitting on a glass pedestal,
the GAÏA and the ANTAL Ez
offer a perfect balance
between elegance and acoustic
performance.
The ANTAL Ez comes with a
set of rubber and adjustable
aluminium spikes to assure
stability and performance,
adapted to the characteristics of
your interior. The bookshelves
and center channel models are
equipped with rubber pads
to decouple and protect your
speakers.
tweeter
A real TRIANGLE trademark of
technology and performance, the
TZ2510, is the latest incarnation
of a titanium dome in combination
with a compression chamber.
This technology provides high
efficiency with low distortion and
excellent directivity.
Studies from the signature project
helped to develop a new profile
of the horn and also improved
the phase plug. It reduces the
directivity and provides almost
the same sound level throughout
the room.
THE HEART OF
TRIANGLE’S
TECHNOLOGY
The phase plug reduces
the directivity of the high
frequencies and assures an
almost identic sound level
throughout the room.
We have developed a compact
engine with high magnetic power,
by using a neodymium ring
combined with an absorption
chamber. The latter has been
designed in view of stopping the
propagation of the back sound
wave and of reducing distortions.
As a result, the high-pitched
frequencies offer a more natural
listening experience.
Without phase plug TRIANGLE tweeter
Midrange WOOFER
woofer/Midrange
Made out of 100% natural
cellulose paper, white membrane
is used to avoid any coloration.
It is combined with a small pleat
peripheral suspension to increase
the emissive surface area.
Special attention has been paid
to a number of details in the
development of the midrange:
the profile of the membrane, the
shape of the suspension, and the
new dust cap, are directly inspired
from the MAGELLAN project.
With the new ANTAL Ez, the midrange driver increases to 165 mm
to provide an even more open
sound.
The MAGELLAN program showed
the importance of how the bass
driver influences the behaviour
of the medium driver. We control
the cone so it efficiently muffles
any resonance in the «upper
bass» area.
Fiberglass was selected for
its excellent affect on the
lower midrange / higher bass.
An ESPRIT Ez innovation is the
overlay of textile material and
fiberglass, which improves the
rigidity of the membrane.
The speaker is equipped with
a new chassis, which quickly
dissolves the heat generated by
the coil, and with a double ferrite
to improve sensitivity.
To sustain the TRIANGLE
midrange quality, while providing
deep bass, we have developed a
half-roll suspension made of foam
and treated rubber. It provides a
dynamic performance due to the
low inertia combined with the
cellulose pulp cone. The profile
of the cone was also redesigned
and now provides an extended
frequency response.
Thanks to the new suspension,
the bookshelf speakers in the
ESPRIT Ez range provide a
generous bass, all the while
remaining dynamic.
CROSSOVER & cables
All components used in the crossover have been selected due to their
quality: copper coils with a diameter of 1mm and met capacitors. The
signal is transferred by a TRIANGLE OFC cable, which assures resistance
and quality over time.
ANTAL EZ
GAÏA EZ
COMÈTE EZ
Description
Cabinet type
Woofer
Midrange
Tweeter
Frequency range
(+ - 3dB Hz - kHz)
Sensitivity (dB/W/m)
Nominale Impedance (Ohms)
Minimum Impedance (Ohms)
This 3-way floorstander
introduces the latest triangle
innovations. It is fitted with a
horn-loaded tweeter, a mid
range of natural cellulose and
two glass fiber woofers.
3
bass-reflex
2x6,5”
1x6,5”
Titanium 1”dome
40 - 22
92
8
3
The GAÏA Ez is a 3-way
compact floorstander, with
a horn-loaded tweeter and
three 5’’ drivers. Discrete,
elegant and highly musical, the
GAÏAEz fits all tastes.
3
bass-reflex
2x5,25”
1x5,25”
Titanium 1”dome
47 - 22
89,5
8
3,3
The COMÈTE Ez provides a
similar listening experience to
a oorstander, without taking
up the space. Ideally suited
for rooms with limited surface
(15 and 30m2), it guarantees
incredible performance when it
comes to lower frequencies.
2
bass-reflex
-
1x6,5”
Titanium 1”dome
49 - 22
90
8
4,2
Power Handling (W)
Repetitive
peak power (W)
Dimensions with pedestal
(inch, W x D x H)
Unit net weight (kg)
120
240
11,81x15,75x43,9
27
90
180
9,06x12,4x38,58
18,1
80
160
7,87x12,76x16,06
9,3
TITUS EZ
HEYDA EZ
VOCE EZ
Description
Cabinet type
Woofer
Midrange
Tweeter
Frequency range
(+ - 3dB Hz - kHz)
Sensitivity (dB/W/m)
Nominale Impedance (Ohms)
Minimum Impedance (Ohms)
Consisting of a 5” driver
and a horn-loaded tweeter,
the TITUS Ez offers strength
and depth in the bass that is
stunning for its size. It can be
used either as a stereo speaker
or as the surround channels in a
home theatre system.
2
bass-reflex
-
2x5,25”
Titanium 1”dome
55 - 22
90
8
3,8
This product has been
developed to provide an
excellent performance in home
theatre configurations. Discrete
and easy to install, HEYDA Ez
is a satellite speaker. It contains
a 5” driver and a horn loaded
tweeter.
2
charge close
-
1x5,25”
Titanium 1”dome
75 - 22
90
8
3,8
The center channel provides the
full home theatre performance.
It has two 5” drivers with half
roll suspension and a horn
loaded tweeter.
2
bass-reflex
-
2x5,25”mm
Titanium 1”dome
60 - 22
91
8
5,3
Power Handling (W)
Repetitive
peak power (W)
Dimensions with pedestal
(inch, W x D x H)
Unit net weight (kg)
60
120
6,21x10,51x12,32
5,9
60
120
-
4,55
80
160
20,08x11,42x6,93
9,5
www.trianglehifi.com
WEBSITE
Visit our website to get access to more information about
TRIANGLE’s products.
ressellers.trianglehifi.com
RESELLERS
Here you will find all our resellers worldwide.
blog.trianglehifi.com
HAUTE FRÉQUENCE
This is TRIANGLE’s music blog that shares our passion for
original artists.
support.trianglehifi.com
f
t
SUPPORT & FAQ
Last but not least, TRIANGLE’s support community answers
all your technical and practical questions and shares
information regarding the installation and maintenance of
your TRIANGLE products.
facebook.com/triangle.electroacoustique
twitter.com/trianglehifi
Our facebook page and twitter account keeps you updated
on all our latest news. It is also the place for you to exchange
and share your experiences with us.
LIGHT
DYNAMIC
FAST
PRECISE
discover the triangle sound
visit the triangle workshop
35 years of passion
TRIANGLE continues to strive for the highest possible goals with the objective
of providing music lovers with perfection in terms of no compromise sound
reproduction, faithfully conveying the emotion and beauty of music.
triangle-fr.com/madeinfrance-en
WWW.TRIANGLEHIFI.COM
The Art of sound with a french touch
Loading...
