Tp-Link TAPO C310 Product Data Sheet

Outdoor Security Wi-Fi Camera

Model: Tapo C310

Secure, Smart, Easy.

3MP High

Denition

Wired or Wireless

Networking

Motion Detection

and Notications

Weatherproof

Datasheet

Highlight

Motion Detection, Instant Notications, and Automatic Siren
Protect You Day and Night

Tapo C310 is a full-featured weatherproof security camera that you can access from anywhere. Receive instant

notications and check feeds when the motion is detected. Moreover, the automatic siren system will trigger light
and sound to frighten away unwanted visitors after the camera detects motion.
Day or night, rain or shine, the Tapo camera protects what you love most.

Features

3MP High Denition

Delivers high resolution video helping you never
miss a detail.

Wired or Wireless Networking

Connect the camera to your network through
Ethernet or Wi-Fi for more exible installation.

Weatherproof

Helps Tapo C310 perform well even in harsh
environments with rain and dust.

Night Vision

Provides a visual distance of up to 98 ft (30m)
even in total darkness to always keep you safe.

Two-Way Audio

Enables you to communicate in real-time
through the built-in microphone and speaker.

Local Storage (up to 128 GB)

Stores 3MP video directly to a local microSD card,
oering convenient access to your video footage.

*microSD card needs to be purchased separately.

Specications

Datasheet

Camera

· Image Sensor: 1/2.7“

· Resolution: 3MP (2304 × 1296)

· Night Vision: 850 nm IR LED (up to 98 ft)

· Lens: F/NO: 2.2; Focal Length: 3.89 mm

· Viewing Angle: FOV=104°

Audio

· Audio Communication: 2-way audio

· Audio Input & Output: Built-in microphone and speaker

Video

Activity Notications

· Input Trigger: Motion detection

· Output Notication: Push notication

Network

· Wireless Protocols: IEEE 802.11b/g/n, 2.4 GHz,

2T2R

· Frequency: 2.4 GHz

· Wireless Security: WEP, WPA/WPA2-PSK

· Security: 128 bit AES encryption with SSL/TLS

· Protocol: TCP/IP, DHCP, ARP, ICMP ,DNS, NTP,

HTTP, HTTPS, UDP, ONVIF, RTSP

· Video Compression: H.264

· Frame Rate: 15fps

· Video Streaming: 1296p

Specications

Datasheet

Hardware

· Port: Ethernet through RJ45 Port

· Button: RESET button

· LED: System LED

· Adapter Input: 100-240 V, 50/60 Hz, 0.3 A

· Adapter Output: 9.0 V, 0.6 A (DC Power)

· External Storage: microSD card slot (Supports up to

128GB)

· Dimensions (W x D x H): 5.6*4.1*2.5 in.

(142.3*103.4*64.3 mm)

MIC
microSD Card Slot

microSD

Card Slot

RESET

Others

· Weatherproof Ratings: IP66

· Certication: CE, RCM, RoHS

· System Requirement: iOS 10+, Android 4.4+

· Package Contents:

Tapo C310

Power Adapter

Quick Start Guide

Anchors and Screws

Mounting Template

Waterproof Seal

Waterproof Cable Attachments

· Operating Temperature: -20 ºC ~ 45 ºC (-4°F ~ 113°F )

Speaker

IR LED

System LED

DC Power Connector

Ethernet Port

· Operating Humidity: 10%~90%RH, Non-condensing

Specications are subject to change without notice. Tapo is a registered trademark of TP-Link
Technologies Co., Ltd. Other brands and product names are trademarks or registered trademarks of
their respective holders. Copyright ©2020 TP-Link Technologies Co., Ltd. All rights reserved.

*

The microSD card is not included in the package.
