4G LTE Mobile Wi-Fi
Go Anywhere
Connect Everywhere
M7300
4G LTE
150Mbps
Dual Band
Wi-Fi Hotspot
tpMiFi
App
Highlights
Share 4G LTE Connection on the Go
The M7300 features a compact, elegant design very suitable for travel,
business trips, outdoor activities or wherever you may be.
Easy Management with the tpMiFi App
With the tpMiFi App, you can easily access and manage the M7300 from your
connected iOS/Android devices. The tpMiFi app allows you to establish data
limits, control which devices can access your Wi-Fi, send messages, and share
media les to/from a removable Micro SD card.
4G LTE Mobile Wi-FiTP-Link
M7300
Features
Lightning 4G LTE Dual Band Wi-Fi 8 Hours Usage
· Lightning generation 4G LTE – Supports 4G LTE network,
compatible with 3G/2G network
· The Faster Connections – reaches up to 150Mbps download
speed and 50Mbps upload one, to enjoy HD movies without
interruption, download les in seconds, and hold a video chat
without dropouts
· Dual Band Wi-Fi– Selectable 2.4GHz or 5GHz dual band Wi-Fi,
achieves better network connectivity when you are in network
interference
· High-Speed Hotspots– Shares 2.4GHz at speed at 150Mbps or
5GHz at speed of 433Mbps
· 2000mAh – 2000mAh rechargeable battery capacity
· 8 hours – 8 hours of 4G sharing
· 480 hours – 480 hours of standby
* Actual battery time may vary due to dierent user environments
4G LTE Mobile Wi-FiTP-Link
M7300
Features
Easy Using Storage Wireless Sharing
· One-Key Setup – To create a hotspot, just insert a SIM card and
press the power button.
· 10 devices – Supports up to 10 devices simultaneously to share
4G/3G/2G network
· Compact design – Suitable for travel, business trips, outdoor
activities or wherever you may be
· Storage Sharing – Easily share photos, music, videos and more
wirelessly across your network
· Up to 32GB – Equipped with a micro SD card slot for up to 32GB
of optional storage
4G LTE Mobile Wi-FiTP-Link
M7300
Specications
Hardware
· Interface : 1 micro USB port, 1 SIM card slot, 1 Micro SD card slot
· Button: Power Button, Reset Button
· LED: Wi-Fi LED, Internet LED, Battery LED
· External Power Supply: 5V/1A
· Dimensions (W x D x H): 4.04 × 2.48 × 0.65 in. (102.6 × 63.0 × 16.5mm)
· Antenna: Internal Antennas
Wireless
· Network Type:
4G: FDD-LTE: B1/B3/B7/B8/B20 (2100/1800/2600/900/800MHz)
TDD-LTE: B38/B40/B41 (2600/2300/2500MHz)
3G: DC-HSPA+/HSPA/UMTS: B1/B8(2100/900MHz)
2G: EDGE/GPRS/GSM:850/900/1800/1900MHz
· Wireless Standards: IEEE 802.11n/a/ac 5GHz, IEEE 802.11b/g/n
2.4GHz
· Frequency: 5GHz and 2.4GHz
· Signal Rate: Selectable dual band, 150Mbps at 2.4GHz or
433Mbps at 5GHz
· Transmit Power: <20dBm(2.4GHz & 5GHz)
· Reception Sensitivity: 5GHz: 11a 54Mbps: -75dBm;
11n HT20 MCS7: -71.5dBm;
11n HT40 MCS7: -69.5dBm;
11ac VHT80 MCS9:-60dBm;
2.4GHz: 11b 11Mbps: -87.5dBm;
11g 54Mbps: -74dBm;
11n HT20 MCS7: -70dBm;
11n HT40 MCS7: -68dBm;
· Wireless Security: Support WPA-PSK/WPA2-PSK,Wireless MAC
Filtering, Enable/Disable SSID Broadcast
· DHCP: Server, Client, DHCP Client List
4G LTE Mobile Wi-FiTP-Link
M7300
Specications
Others
· Certication: CE, RoHS
· System Requirements:
Windows 10/8/7/vista/XP, Mac OS, Android, iOS, Windows Phone
· Environment
Operating Temperature: 0℃~35℃ (32℉ ~95℉)
Storage Temperature: -20℃~60℃ (4℉ ~140℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
· Package Contents
Mobile Wi-Fi M7300
Micro USB Cable
Micro and Nano to Standard SIM Card Adapter
Quick Installation Guide
2000mAh Battery
For more information, please visit
http://www.tp-link.com/en/products/details/M7300.html
www.tp-link.com
