Tp-link M7300 User Manual [ru]

M7300

REV 1.0.0
1910011532

LTE-Advanced Mobile Wi-Fi

COPYRIGHT & TRADEMARKS

Specifications are subject to change without notice. is a registered trademark
of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or
registered trademarks of their respective holders.
No part of the specifications may be reproduced in any form or by any means or used to make any
derivative such as translation, transformation, or adaptation without permission from TP-LINK
TECHNOLOGIES CO., LTD. Copyright © 2015 TP-LINK TECHNOLOGIES CO., LTD. All rights
reserved.

http://www.tp-link.com

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:

 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and receiver.
 Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.
 Consult the dealer or an experienced radio/ TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:
1） This device may not cause harmful interference.

2） This device must accept any interference received, including interference that may cause

undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.
Note: The manufacturer is not responsible for any radio or TV interference caused by

unauthorized modifications to this equipment. Such modifications could void the user’s authority

to operate the equipment.

FCC RF Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. End users must follow the specific operating instructions for satisfying RF exposure
compliance. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter. This equipment has been SAR-evaluated for use in hand. SAR
measurements are based on a 5mm spacing from the body and that compliance is achieved at
that distance.

Country

Restriction

Reason/remark

Belarus

Not implemented

Norway

Implemented

This subsection does not apply for the geographical area
within a radius of 20 km from the centre of Ny-Ålesund on
Svalbard.

Italy

Implemented

The public use is subject to general authorisation by the
respective service provider.

Russian
Federation

Limited
implementation

1. SRD with FHSS modulation

1.1. Maximum 2.5 mW e.i.r.p.

1.2. Maximum 100 mW e.i.r.p. Permitted for use SRD for
outdoor applications without restriction on installation height
only for purposes of gathering telemetry information for
automated monitoring and resources accounting systems.
Permitted to use SRD for other purposes for outdoor

CE Mark Warning

This is a class B product. In a domestic environment, this product may cause radio interference, in
which case the user may be required to take adequate measures.

RF Exposure Information

This device meets the EU requirements (1999/519/EC) on the limitation of exposure of the
general public to electromagnetic fields by way of health protection.

This device has been tested and meets the ICNIRP exposure guidelines and the European
Standard EN 62209-2. SAR is measured with this device at a separation of 0.5 cm to the body,
while transmitting at the highest certified output power level in all frequency bands of this device.
Carry this device at least 0.5 cm away from your body to ensure exposure levels remain at or
below the as-tested levels.

National Restrictions

This device is intended for home and office use in all EU countries (and other countries following
the EU directive 1999/5/EC) without any limitation except for the countries mentioned below:

applications only when the installation height is not exceeding
10 m above the ground surface.

1.3.Maximum 100 mW e.i.r.p. Indoor applications.

2. SRD with DSSS and other than FHSS wideband
modulation

2.1. Maximum mean e.i.r.p. density is 2 mW/MHz. Maximum
100 mW e.i.r.p.

2.2. Maximum mean e.i.r.p. density is 20 mW/MHz. Maximum
100 mW e.i.r.p. It is permitted to use SRD for outdoor
applications only for purposes of gathering telemetry
information for automated monitoring and resources
accounting systems or security systems.

2.3. Maximum mean e.i.r.p. density is 10 mW/MHz. Maximum
100 mW e.i.r.p. Indoor applications.

Ukraine

Limited
implementation

e.i.r.p. ≤100 mW with built-in antenna with amplification factor
up to 6 dBi.

ATTENTION: Due to EU law, the country settings must be identical to the country where the
device is operating (important due to non-harmonised frequencies in the EU).

Canadian Compliance Statement

This device complies with Industry Canada license-exempt RSSs. Operation is subject to the
following two conditions:

1） This device may not cause interference, and
2） This device must accept any interference, including interference that may cause undesired

operation of the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :

1) l’appareil ne doit pas produire de brouillage;

2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, meme si le

brouillage est susceptible d’en compromettre le fonctionnement.

Radiation Exposure Statement:

This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm

between the radiator & your body.

Déclaration d'exposition aux radiations:

Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un
environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20
cm de distance entre la source de rayonnement et votre corps.

Industry Canada Statement

CAN ICES-3 (B)/NMB-3(B)

Korea Warning Statements

당해 무선설비는 운용중 전파혼신 가능성이 있음.

NCC Notice & BSMI Notice

注意！
依據 低功率電波輻射性電機管理辦法
第十二條 經型式認證合格之低功率射頻電機，費經許可，公司、商號或使用者均不得擅自變更頻
率、加大功率或變更原設計之特性或功能。
第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通行；經發現有干擾現象時，應立

即停用，并改善至無干擾時方得繼續使用。前項合法通信，指依電信規定作業之無線電信。低功率

射頻電機需忍受合法通信或工業、科學以及醫療用電波輻射性電機設備之干擾。
減少電磁波影響，請妥適使用。

安全諮詢及注意事項

● 請使用原裝電源供應器或只能按照本產品注明的電源類型使用本產品。

● 清潔本產品之前請先拔掉電源線。請勿使用液體、噴霧清潔劑或濕布進行清潔。

● 注意防潮，請勿將水或其他液體潑灑到本產品上。

● 插槽與開口供通風使用，以確保本產品的操作可靠並防止過熱，請勿堵塞或覆蓋開口。

● 請勿將本產品置放於靠近熱源的地方。除非有正常的通風，否則不可放在密閉位置中。

● 請不要私自打開機殼，不要嘗試自行維修本產品，請由授權的專業人士進行此項工作。

Продукт сертифіковано згідно с правилами системи УкрСЕПРО на відповідність вимогам
нормативних документів та вимогам, що передбачені чинними законодавчими актами
України.

AT

BG

BY

CA

CZ

DE

DK

EE

ES

FI

FR

GB

GR

HU

IE

IT

LT

LV

MT

NL

NO

PL

PT

RO

RU

SE

SG

SK

TR

UA

US

Safety Information

 When product has power button, the power button is one of the way to shut off the product;

when there is no power button, the only way to completely shut off power is to disconnect the

product or the power adapter from the power source.
 Don’t disassemble the product, or make repairs yourself. You run the risk of electric shock

and voiding the limited warranty. If you need service, please contact us.

 Avoid water and wet locations.
 Adapter shall be installed near the equipment and shall be easily accessible.
 The plug considered as disconnect device of adapter.

CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

Use only power supplies which are provided by manufacturer and in the original packing

of this product. If you have any questions, please don't hesitate to contact us.
Alert to service person

CAUTION
DOUBLE POLE / NEUTRAL FUSING
This product can be used in the following countries:

Symbol

Explanation

RECYCLING

This product bears the selective sorting symbol for Waste electrical and electronic
equipment (WEEE). This means that this product must be handled pursuant to
European directive 2012/19/EU in order to be recycled or dismantled to minimize
its impact on the environment.

User has the choice to give his product to a competent recycling organization or to
the retailer when he buys a new electrical or electronic equipment.

Explanation of the symbols on the product label

TP-LINK TECHNOLOGIES CO., LTD

DECLARATION OF CONFORMITY

For the following equipment:
Product Description: LTE-Advanced Mobile Wi-Fi
Model No.: M7300
Trademark: TP-LINK
We declare under our own responsibility that the above products satisfy all the technical
regulations applicable to the product within the scope of Council Directives:
Directives 1999/5/EC, Directives 2004/108/EC, Directives 2006/95/EC, Directives 1999/519/EC,
Directives 2011/65/EU
The above product is in conformity with the following standards or other normative documents

EN 300328 V1.8.1
EN 301893 V1.7.1
EN 301511 V9.0.2
EN 301908-1 V6.2.1 & EN 301908-2 V6.2.1 & EN 301908-13 V6.2.1
EN 301489-1 V1.9.2 & EN 301489-7 V1.3.1 & EN 301489-17 V2.2.1 & EN 301489-24 V1.5.1
EN 55022: 2010+AC: 2011
EN 55024: 2010
EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 +A2: 2013
EN 50566: 2013
EN 50581: 2012

The product carries the CE Mark:

Person responsible for marking this declaration:

Yang Hongliang
Product Manager of International Business

Date of issue: Nov. 23, 2015

TP-LINK TECHNOLOGIES CO., LTD.

Building 24 (floors 1, 3, 4, 5), and 28 (floors 1-4) Central Science and Technology Park,

Shennan Rd, Nanshan, Shenzhen, China

CONTENTS

Package Contents ....................................................................................................... 1

Chapter 1. Introduction ......................................................................................... 2

1.1 Product Overview ........................................................................................................... 2

1.2 Main Features ................................................................................................................. 2

1.3 Physical Description ....................................................................................................... 3

1.4 Environment Requirements ............................................................................................ 4

1.5 Hardware Installation ...................................................................................................... 4

Chapter 2. Quick Installation Guide ..................................................................... 7

2.1 System Requirements .................................................................................................... 7

2.2 TCP/IP Configuration ...................................................................................................... 7

2.3 Connect to the Internet ................................................................................................... 7

2.4 Quick Setup .................................................................................................................... 9

2.4.1 Quick Setup via your phone ................................................................................ 9

2.4.2 Quick Setup via your PC ................................................................................... 10

Chapter 3. Device Configuration ........................................................................ 14

3.1 Wizard ........................................................................................................................... 14

3.2 Status ............................................................................................................................ 14

3.3 SMS .............................................................................................................................. 15

3.3.1 Inbox ................................................................................................................. 15

3.3.2 New Message ................................................................................................... 16

3.3.3 Outbox ............................................................................................................... 16

3.4 Advanced ...................................................................................................................... 17

3.4.1 Dial-up ............................................................................................................... 17

3.4.2 Wireless ............................................................................................................ 22

3.4.3 DHCP Server .................................................................................................... 24

3.4.4 Data Usage Settings ......................................................................................... 25

3.4.5 Storage Sharing ................................................................................................ 26

3.4.6 Power Saving .................................................................................................... 29

3.4.7 Device ............................................................................................................... 29

Appendix A: FAQ....................................................................................................... 35

Appendix B: Configuring the PC ............................................................................. 40

Appendix C: Specifications ...................................................................................... 45

Appendix D: Glossary .............................................................................................. 46

I

M7300

LTE-Advanced Mobile Wi-Fi User Guide

Package Contents

The following items should be found in your package:

 LTE-Advanced Mobile Wi-Fi M7300
 Micro USB Cable
 Micro to Standard SIM Card Adapter
 Nano to Standard SIM Card Adapter
 Power Adapter
 2000mAh Battery
 Quick Installation Guide

Note:



Make sure that the package contains the above items. If any of the listed items is damaged or
missing, please contact your distributor.

Conventions

The Device or M7300 mentioned in this guide stands for M7300 LTE-Advanced Mobile Wi-Fi
without any explanation.

-1-

M7300

LTE-Advanced Mobile Wi-Fi User Guide

Chapter 1. Introduction

1.1 Product Overview

TP-LINK’s M7300 is at the forefront of wireless 4G sharing. Just insert a 4G SIM card into the
device to instantly establish a Wi-Fi hotspot. With up to 150Mbps download and 50Mbps upload
speeds, M7300 is able to provide 4G wireless sharing to up to 11 users simultaneously. Its
pocket-sized design and powerful 2000mAh internal battery make it an ideal travel companion,
allowing users to work or play for 10 hours.

1.2 Main Features

 Full coverage of 4G/3G/2G network

FDD-LTE (800/900/1800/2100/2600MHz)

DC-HSPA+/HSPA/UMTS (900/2100MHz)

EDGE/GPRS/GSM (850/900/1800/1900MHz)

 4G LTE supports with up to 150Mbps downloads and 50Mbps uploads speeds
 High speed Wi-Fi hotspot at speed of 300Mbps
 Wi-Fi share up to 11 devices simultaneously (10 Wireless+1 Wired)
 2000mAh battery for 10 hours of usage
 Portable and compact design ideal for travel use
 A micro USB port for versatile recharging
 A micro SD card slot for up to 32GB of optional storage
 Easy management with the tpMiFi App

-2-

M7300

LTE-Advanced Mobile Wi-Fi User Guide

1.3 Physical Description

Item

Status

Indication

On

The Wi-Fi is enable.

On

The M7300 is connected to the Internet.

On

The M7300 is on.

Red

The battery level is less than 10%.

Blinking Green

The M7300 is charging.

The details about the Exterior are explained as below.

 LED indicators:

Note:



The LEDs will turn off automatically after 15 seconds. Please press the Power button to turn
them on again.

 Power Button: When the Device is successfully installed, press and hold this button until

all the LEDs are lit. You can also press and hold this button to turn off the M7300.
 Micro USB Input: It’s for you to connect the Device with the power adapter (attached in the

package) via the USB cable.
 Reset Button (hole): It’s the button to restore the Device to its factory defaults. With the

-3-

M7300

LTE-Advanced Mobile Wi-Fi User Guide

Device powered on, remove the cover. Use a pin to press and hold the Reset button until

all LEDs turn on momentarily.

1.4 Environment Requirements

 Place the Device in a well-ventilated place far from any heater or heating vent
 Avoid direct irradiation of any strong light (such as sunlight)
 Operating Temperature: 0℃ ~35℃ (32℉~95℉)
 Operating Humidity: 10%~90%RH, Non-condensing

1.5 Hardware Installation

STEP 1: Install SIM card and memory card.

1) Open the cover upwards (as the arrow shows).

2) Make sure to have the SIM card’s metal chip downwards and the triangle notch outwards,

and then slide the card into its slot (in the direction as the arrow shows).

Note:



If you have a Micro-SIM or Nano-SIM, please use an adapter to convert it to a standard SIM
card.

3) First, push and then lift the Micro-SD card locker to open it. Second, have the memory
card’s metal chip downwards and inwards, and then fit it in its slot. Finally, put down and
then pull the locker to lock it.

-4-

M7300

LTE-Advanced Mobile Wi-Fi User Guide

Note:



The micro SD memory card is optional. You can purchase it appropriate to your own need.

STEP 2: Install the battery.

1) Touch the metal contacts of the battery to the metal points of the Device, and then press to

fit the battery body into the slot.

2) Close the cover by pressing it.

STEP 3: Turn on the M7300

Press and hold the Power button until all the LEDs are lit.

Charging your M7300

Via the power adapter

-5-

M7300

LTE-Advanced Mobile Wi-Fi User Guide

Via the computer USB

Note:



1. The M7300 is fully charged when the Battery LED is solid green.

2. Recommend using the provided power adapter.

-6-

M7300

LTE-Advanced Mobile Wi-Fi User Guide

Chapter 2. Quick Installation Guide

This chapter will guide you to quickly set up the basic functions for your M7300.

2.1 System Requirements

 SIM card with Internet access enabled.
 Computer supports the 2.4GHz wireless band.
 Web browser, such as Mozilla Firefox, Internet Explorer, Google Chrome, Apple Safari, etc.

2.2 TCP/IP Configuration

The default IP address of the M7300 is 192.168.0.1, and the default Subnet Mask is

255.255.255.0, which values can be changed as you desire. In this guide, we use all the default
values for description, and take the configuration in Windows 7 for example. While, Pads or
Wi-Fi cellphones by default obtain IP address and DNS server address automatically, so you
can just skip this step and continue with the 2.3 Connect to the Internet.

Note:



Before configuration, please make sure your computer has been equipped with a wireless
network adapter.

 Obtain an IP address automatically

1) Set up the TCP/IP Protocol in "Obtain an IP address automatically" mode on your PC.
Please refer to Appendix B: Configuring the PC for the detailed instructions.

2) Then the built-in DHCP server will assign an IP address for the PC.

 Configure the IP address manually

1) Set up the TCP/IP Protocol for your PC. Please refer to Appendix B: Configuring the PC for
the detailed instructions.

2) Configure the network parameters. The IP address is 192.168.0.X ( X stands for any
number from 2 to 254), Subnet Mask is 255.255.255.0, and Gateway is 192.168.0.1 (the
device's default IP address).

2.3 Connect to the Internet

Note:



To log in the Device’s web-management page, you need to first connect to the wireless network
of the Device.

1. Click the icon at the bottom of your desktop.

2. Click the refresh button , select the SSID of M7300 and then click Connect.

-7-
