Whole Home Powerline Mesh Wi-Fi System
Seamless Roaming† | Parental Controls | Powerline Backhaul
AC1200 + AV1000
Whole Home Powerline
Mesh Wi-Fi System
Deco P9
Highlights
Highlights
Wi-Fi + Powerline Hybrid Bandwidth
Deco P9 combines dual-band Wi-Fi and powerline to transmit data between Deco
units, delivering a whole home Wi-Fi coverage up to 6,000 ft2 / 560 m2‡.
Works Through Walls
Powerline technology uses your home’s electrical wiring to create stronger
connections between Deco units, reducing the impact of walls and other
obstacles on signal.
Thick wall
Existing electrical wiring
Wi-Fi Dead-Zone Killer
Eliminate weak signal areas with whole home Wi-Fi. No more searching
around for a stable connection.
Seamless Roaming with One Wi-Fi Name
Deco units work together to form a unied Wi-Fi network with a single
network name. Walk through your home and stay connected with the
fastest possible speeds, made possible by Deco’s seamless coverage and
Plug & Play Mesh Technology†.
Stays Fast, Always
2.4 GHz wireless connection
5 GHz wireless connection
AV1000 Gigabit Powerline
AV1000 Gigabit Powerline
Works through Walls
Internet
Adaptive path selection and band steering keep your network running at
top-speed by automatically choosing the fastest connection path.
Parental Controls
Limit online time and block inappropriate content according to unique
proles created for each family member.
Simple Setup and Control
The easy-to-use Deco app lets you set up quickly, see the connected
devices, prioritize devices, check internet history, create a guest network
and more.
TP-Link AC1200 + AV1000 Whole Home Powerline Mesh Wi-Fi System
Deco P9
Features
Assisted Setup
Easily set up Decos and nd the ideal spot to
place each unit
· Auto Connection Test – Test the internet connection of your
Decos and helps to identify a suitable location for them
· Remote Management – Manage your Deco network from
a smartphone or tablet via the app, no matter where you
nd yourself
· Online Upgrade – Keep informed of the latest rmware updates
· WPS connection – Easily connect a client to the network by
turning on WPS for a nearby Deco and then for the client
Robust Parental Controls
Manage content and control when each
device can access the internet
· Proles – Create a prole for each family member, and manage
them individually
· Content Filter – Four levels are available for ltering content,
each catering to a specic age group
· Time Controls – Set daily time limits for the total time spent
online and block a person’s internet access between certain
times
· Pause the Internet – Pause a family member's internet and
resume it whenever you like
Two Modes in One
Choose the router or access point mode for
your network needs
· Router Mode – Create an instant private wireless network
· Access Point Mode – Create Wi-Fi access for any existing wired
network
Quality of Service
Prioritize devices for faster performance
when needed
Give high priority to the devices that need the fastest internet
connection
Blacklist
Block access to your network from specic
devices
Add your clients or specic devices to blacklist to protect
your network from unauthorized users
Work with All Deco Models
Form a Mesh network with your desired
Deco models
All Deco models can work together. Just expand Mesh Wi-Fi
coverage anytime by adding more Decos
TP-Link AC1200 + AV1000 Whole Home Powerline Mesh Wi-Fi System
Deco P9
Specications
Hardware
· Ports: 2 WAN/LAN Gigabit Ethernet ports, 1 Power port
· Buttons: 1 Reset button on the underside
· Antenna Type: 2 internal dual-band antennas per Deco unit
· Dimensions: 7.5 × 3.6 × 3.6 in. (190 × 90.7 × 90.7 mm)
· Power Input: 100-240V~ 50/60Hz 0.5A
LED
Gigabit Ethernet Ports
Software
· Working Mode: Router, Access Point
· WAN Type:
Dynamic IP/Static IP/PPPoE/L2TP/PPTP
· DHCP: Server, Client
· Quality of Service: WMM
· Firewall Security: SPI Firewall
· Protocols: Supports IPv4 and IPv6
· Guest Network: 2.4 GHz Guest Network x 1, 5 GHz Guest
Network x 1
· Features: Parental Controls, QoS (Quality of Service),
Monthly Report, Address Reservation, Port Forwarding,
TP-Link DDNS, VLAN, IPv6, LED Control
· Management: Local Management, Remote Management
Others
· Certication: CE, FCC, EAC, RCM, RoHS
· Smartphone/Tablet Requirements:
iOS 9.0 or later
Android 4.4 or later
· Environment:
Operating Temperature: 0
Storage Temperature: -40
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
· Package Contents for Deco P9 (3-pack):
•3 Deco P9 units (routers with powerline)
1 RJ45 Ethernet cable
3 Power cords
1 Quick installation guide
~40°C (32°F~104°F)
°C
~60°C (-40°F~140°F)
°C
Power Port
Wireless
· Package Contents for Deco P9 (2-pack):
Reset Button
· Wireless Standards:
IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2.4 GHz
Powerline
· Powerline Rate: 1000Mbps
· Standard: HomePlug AV2
· Range: 300 meters / 1000 feet over electrical circuit
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Attention: this device may only be used indoors in all EU member states and EFTA countries.
Specications are subject to change without notice. All the brands and product names are trademarks or registered trademarks of their respective holders.
†
Seamless roaming requires that clients need to support 802.11k/v/r and may require additional setup. Performance may vary depending on the client device.
‡
Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specications. Actual wireless data throughput and wireless coverage, and quantity of connected devices are not guaranteed and will vary as a result of network conditions, client limitations, and environmental factors, including building materials, obstacles,
volume and density of trac, and client location.
§
Maximum Powerline signal rates are the physical rates derived from HomeplugAV/AV2 specications. Actual Powerline data throughput and Powerline range are not guaranteed and will vary as a result of network conditions and environmental factors, including electrical interference, volume of trac and network overhead, AFCI circuit breaker, and
Powerline being located in a separate circuit.
△
Use of MU-MIMO requires clients to also support MU-MIMO.
©2020 TP-Link
www.tp-link.com
· Frequency: 2.4 GHz and 5 GHz
· Signal Rate: 867 Mbps at 5 GHz, 300 Mbps at 2.4 GHz
· Transmit Power:
FCC: <30 dBm, CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz)
· Wireless Security: WPA-PSK/WPA2-PSK
• 2 Deco P9 units (routers with powerline)
1 RJ45 Ethernet cable
2 Power cords
1 Quick installation guide
