User Guide
Smart Open-Closed Sensor
1910012161 REV1.0.0
Contents
About This Guide ···················································· 1
Introduction ······························································· 2
Appearance ······························································· 3
Set Up Your Open-Closed Sensor ················ 4
Main Pages ································································· 6
Authentication ·························································· 7
About This Guide
This guide provides a brief introduction to Open-Closed Sensor and the Kasa app, as well as regulatory information.
Please note that features of Open-Closed Sensor may vary slightly depending on the model and software version you have, and on your location,
language and internet service provider. All images, parameters and descriptions documented in this guide are used for demonstration only.
Conventions
In this guide, the following convention is used:
Convention Description
Teal
Underline
Key information appears in teal, including management page text such as menus, items, buttons and so on.
Hyperlinks are in teal and underlined. You can click to redirect to a website.
More Info
• Specic product information can be found on the product page at http://www.tp-link.com
• The latest rmware and management app are available from Download Center at http://www.tp-link.com/support.
• A Technical Support Forum is provided for you to discuss our products at http://forum.tp-link.com.
• Our Technical Support and troubleshooting information can be found at http://www.tp-link.com/support.
.
1
Introduction
With Open-Closed Sensor connected to your Kasa Smart Home Router, you can keep an eye on doors, windows and drawers in your home
wherever you are.
• Automatic Smart Actions - Choose to have plugs and bulbs turn on or o when sensors are triggered.
• Remote Notications - Receive alerts whenever something is opened or closed no matter where you are.
• Simple Setup - Easily connect the sensor to your Kasa Smart Home Router with Kasa app
2
Appearance
Open-Closed Sensor has a LED that changes color according to its status, a magnet, and a battery compartment. See the explanation below:
Battery
Compartment
Restart/Reset Button:
Press for 1 second to restart
the pairng mode.
Press and hold for 5 seconds
to reset the sensor to factory
default settings.
Magnet
Orange
Power up or fail to join the network.
Blue
Sensor event or succeed to join the network.
Flashing orange
Factory resetting the sensor.
Flashing orange and blue
Searching for the network or joining the network.
3
Set Up Your Open-Closed Sensor
Follow the steps below to set up your Open-Closed Sensor via Kasa for Mobile app.
1. Download and install the Kasa app
Go to Google Play or the Apple App Store
or scan the QR code below to download the
Kasa app on your Android or iOS smartphone
or tablet.
2. Log in or sign up with TP-Link ID
Open the app. Use your TP-Link ID to log in.
If you don’t have a TP-Link ID, tap Create
Account. The Kasa app will guide you through
the rest.
3. Place the sensor
Take your sensor to the door or window that
you would like to monitor. Don‘t ax it yet.
4
Set Up Your Open-Closed Sensor
Follow the steps below to set up your Open-Closed Sensor via Kasa for Mobile app.
4. Connect to Smart Home Router
Slide off the top cover to reveal the battery
compartment.
Insert the AA battery to enter pairing mode.
5. Install the sensor
It is almost set up. The Kasa app will guide
you through the whole process of installation.
And remember to affix the sensor body and
magnet within10mm.
5
Main Pages
After you successfully set up your Open-Closed Sensor, you will see the home page of the Kasa app. Here you can view the working status of all
devices that you've added to Kasa and manage them. Tap on a sensor to check the current status, time of last motion, the current battery level of your
sensor. Click on Sensor Status page to view your device settings.
Home Page
Sensor Status Device Settings
6
Authentication
COPYRIGHT & TRADEMARKS
Specifications are subject to change without notice. is a registered trademark of TP-Link Technologies Co., Ltd. Other brands and product
names are trademarks or registered trademarks of their respective holders.
No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or
adaptation without permission from TP-Link Technologies Co., Ltd. Copyright © 2017 TP-Link Technologies Co., Ltd. All rights reserved.
7
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/ TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications
could void the user’s authority to operate the equipment.
FCC RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be
co-located or operating in conjunction with any other antenna or transmitter.
“To comply with FCC RF exposure compliance requirements, this grant is applicable to only Mobile Configurations. The antennas used for this
transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction
with any other antenna or transmitter.”
8
CE Mark Warning
This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take
adequate measures.
RF Exposure Information
This device meets the EU requirements (2014/53/EU Article 3.1a) on the limitation of exposure of the general public to electromagnetic fields by way
of health protection.
The device complies with RF specifications when the device used at 20 cm from your body.
Canadian Compliance Statement
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux
deux conditions suivantes :
1. l’appareil ne doit pas produire de brouillage;
2. l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, meme si le brouillage est susceptible d’en compromettre le fonctionnement
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
Déclaration d’exposition aux radiations:
Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet équipement doit être
installé et utilisé avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps.
9
Industry Canada Statement
CAN ICES-3 (B)/NMB-3(B)
Korea Warning Statements:
당해 무선설비는 운용중 전파혼신 가능성이 있음.
NCC Notice & BSMI Notice:
注意！
依據 低功率電波輻射性電機管理辦法
第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性或功能。
第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通行；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。前項合法
通信，指依電信規定作業之無線電信。低功率射頻電機需忍受合法通信或工業、科學以及醫療用電波輻射性電機設備之干擾。
安全諮詢及注意事項
• 請使用原裝電源供應器或只能按照本產品注明的電源類型使用本產品。
• 清潔本產品之前請先拔掉電源線。請勿使用液體、噴霧清潔劑或濕布進行清潔。
• 注意防潮，請勿將水或其他液體潑灑到本產品上。
• 插槽與開口供通風使用，以確保本產品的操作可靠並防止過熱，請勿堵塞或覆蓋開口。
• 請勿將本產品置放於靠近熱源的地方。除非有正常的通風，否則不可放在密閉位置中。
• 請不要私自打開機殼，不要嘗試自行維修本產品，請由授權的專業人士進行此項工作。
Продукт сертифіковано згідно с правилами системи УкрСЕПРО на відповідність вимогам нормативних документів та вимогам, що
передбачені чинними законодавчими актами України.
10
Safety Information
• When product has power button, the power button is one of the ways to shut off the product; when there is no power button, the only way to
completely shut off power is to disconnect the product or the power adapter from the power source.
• Don’t disassemble the product, or make repairs yourself. You run the risk of electric shock and voiding the limited warranty. If you need service,
please contact us.
• Avoid water and wet locations.
Explanation of the symbols on the product label
Symbol Explanation
DC voltage
Indoor use only
RECYCLING
This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE). This means that this product must be handled pursuant to
European directive 2012/19/EU in order to be recycled or dismantled to minimize its impact on the environment.
User has the choice to give his product to a competent recycling organization or to the retailer when he buys a new electrical or electronic equipment.
