Introduction

19/22-inch* Diagonal LCD TV/DVD COMBINATION

19LV505C 22LV505C

OWNER’S MANUAL

Connections

Basic setup

TV operation

Basic playback

Advanced playback

Function setup

Others

IIIustration of 19LV505C

50S0301A.indb 150S0301A.indb 1 2/5/08 5:57:50 PM2/5/08 5:57:50 PM

Ownerʼs Record

The model number and serial number are on the back of your TV/DVD. Record these numbers in the spaces below. Refer to these numbers whenever you communicate with your Toshiba dealer about this TV/DVD.

Model number: Serial number:

Introduction

Dear Customer,

Thank you for purchasing this Toshiba LCD TV or TV/DVD Combination television.

This manual will help you use the many exciting features of your new LCD TV. Before operating your LCD TV or TV/DVD Combination, please read this manual completely, and keep it nearby for future reference.

Safety Precautions

WARNING: TO REDUCE THE RISK OF FIRE OR

ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle, is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

CAUTION: To reduce the risk of electric shock,

do not use the polarized plug with an extension cord, receptacle, or other outlet unless the blades can be inserted completely to prevent blade exposure.

WARN ING: If you decide to wall mount this television, always use a UL Listed wall bracket appropriate for the size and weight of this television. The use of any wall bracket other than a UL Listed wall bracket appropriate for the size and weight of this television for wall mounting this television could result in serious bodily injury and/or property damage. See “Choosing a location for your LCD TV” (Pg.6).

ENE RGY STAR® qualified TV. Products that earn the ENE RGY STAR prevent green house gas emissions by meeting strict energy efficiency guidelines set by the U.S. Environmental Protection Agency and the U.S. Department of Energy. ENERGY STAR and the ENERGY STAR mark are registered U.S. marks.

This is a reminder to call the CATV system installer’s attention to Article 820-40 of the NEC, which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to grounding system of the building, as close to the point of cable entry as practical. For additional antenna grounding information, see item 26 on page 5.

NOTE TO CATV INSTALLERS

CHILD SAFETY:

It Makes A Difference How and Where You Use Your Flat Panel Display

Congratulations on your purchase! As you enjoy your new product, please keep these safety tips in mind:

The Issue

• The home theater entertainment experience is a growing trend

Tune Into Safety

•

• Carefully read and understand all enclosed instructions for

• Don’t allow children to climb on or play with furniture and

• Don’t place flat panel displays on furniture

• Remember that children can

• Care should be taken to route all cords and

Wall Mounting: If you decide to wall mount your flat panel display, always:

• Use a mount that has been recommended by the display

• Follow all instructions supplied by the display and wall mount

• If you have any doubts about your ability to safely install your

• Make sure that the wall where you are mounting the display is

• A minimum of two people are

and larger flat panel displays are popular purchases. However, flat panel displays are not always supported on the proper stands or installed according to the manufacturer’s recommendations.

• Flat panel displays that are inappropriately situated on dressers,

bookcases, shelves, desks,

speakers, chests or carts may fall

over and cause injury.

TOSHIBA Cares!

• The consumer electronics industry is committed to making home

entertainment enjoyable and safe.

One size does NOT fit all. Follow the manufacturer’s recommendations for the safe installation and use of your flat panel display.

proper use of this product.

television sets.

that can easily be used as steps, such as a chest of drawers.

become excited while watching a program, especially on a “larger than life” flat panel display. Care should be taken to place or install the display where it cannot be pushed, pulled over, or knocked down.

cables connected to the flat panel display so that they cannot be pulled or grabbed by curious children.

manufacturer and/or listed by an independent laboratory (such as UL, CSA, ETL).

manufacturers.

flat panel display, contact your retailer about professional installation.

appropriate. Some wall mounts are not designed to be mounted to walls with steel studs or old cinder block construction. If you are unsure, contact a professional installer.

required for installation. Flat panel displays can be heavy.

50S0301A.indb 250S0301A.indb 2 2/5/08 5:58:11 PM2/5/08 5:58:11 PM

CAUTION:

THIS DIGITAL VIDEO PLAYER EMPLOYS A LASER SYSTEM. TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE READ

THIS OWNER'S MANUAL CAREFULLYAND RETAINFOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE MAINTENANCE, CONTACT AN AUTHORIZED SERVICE LOCATION.

USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAYRESULT IN HAZARDOUS RADIATIONEXPOSURE.

TO PREVENT DIRECT EXPOSURE TO LASER BEAM, NEVER OPEN THE ENCLOSURE. VISIBLE LASER RADIATION MAY BE PRESENT WHEN THE ENCLOSURE IS OPENED. NEVER STARE INTO BEAM.

Location of the required Marking

The rating sheet and the safety caution are the rear of the unit.

Illustration of 19LV505C

CERTIFICATION: COMPLIES WITH FDA RADIATION PERFORMANCE STANDARDS,21 CFR SUBCHAPTER J.

ON DISPOSAL

The lamp(s) inside this product contain mercury. Disposal may be regulated due to environmental considerations. For disposal or recycling information, contact your local authorities or the Electronic Industries Alliance (www.eiae.org).

Introduction

50S0301A.indb 350S0301A.indb 3 2/5/08 5:58:12 PM2/5/08 5:58:12 PM

Introduction

SAFETY INSTRUCTIONS

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturerʼs instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus

(including ampliﬁ ers) that produce heat.

Do not defeat the safety purpose of the polarized or

9) grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong.

The wide blade or the third prong

are provided for your safety. If the provided plug does not ﬁ t into your outlet, consult an electrician for

replacement of the obsolete outlet.

10)

Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories speciﬁ ed by the

manufacturer.

Use only with the cart, stand, tripod,

12)

bracket, or table speciﬁ ed by the manufacturer, or sold with the apparatus.

caution when moving the cart/ apparatus combination to avoid

injury from tip-over.

Unplug this apparatus during

13)

lightning storms or when unused for long periods of time.

14) Refer all servicing to qualiﬁ ed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

When a cart is used, use

Wide plug

Additional Safety Precautions

14a) CAUTION: If the TV is dropped and the cabinet or enclosure surface has been damaged or the TV does

not operate normally, take the following precautions:

• ALWAYS turn off the TV and unplug the power

cord to avoid possible electric shock or ﬁ re.

• NEVER allow your body to come in contact with

any broken glass or liquid from the damaged television. The LCD panel inside the TV contains

glass and a toxic liquid. If the liquid comes in contact

with your mouth or eyes, or your skin is cut by

broken glass, rinse the affected area thoroughly

water and consult your doctor.

• ALWAYS contact a service technician to inspect

the TV any time it has been damaged or dropped. 14b) WARNING: To prevent the spread of ﬁ re, keep

candles or other open ﬂ ames away from this product at all times.

with

Installation, Care, and Service

Installation

Follow these recommendations and precautions and heed all warnings when installing your TV:

15) To avoid damage to this product, never place or store the TV in direct sunlight; hot, humid areas;

or areas subject to excessive dust or vibration.

16)

Never modify this equipment. Changes or modiﬁ cations may void: a) the warranty, and b) the userʼs authority operate this equipment under the rules of the Federal Communications Commission.

17) DANGER: RISK OF SERIOUS

PERSONAL INJURY, DEATH, OR

stand, or table. The TV may fall, causing serious personal injury, death, or serious damage to the TV.

18) Never place items such as vases, aquariums, or candles on top of the TV.

19) WARNING: Always place the TV on the ﬂ oor or a sturdy, level, stable surface that can support the weight of the unit. To secure the TV, use a sturdy strap from the hooks on the rear of the TV pedestal to a wall stud, pillar or other immovable structure. Make sure the strap is tight, secure, and parallel to the ﬂ oor.

Never expose the apparatus to dripping or splashing

20) liquid or place items such as vases, aquariums, any other item ﬁ lled with liquid, or candles on top of the TV.

21)

Never block or cover the slots or openings in the TV cabinet back, bottom, and sides.

Never place the TV:

on a bed, sofa, rug, or similar surface;

•

• too close to drapes, curtains, or walls; or

• in a conﬁ ned space such as a bookcase, built-in cabinet, or any other place with poor ventilation.

The slots and openings are provided to protect the TV from overheating and to help maintain reliable operation of the TV. Leave a space of at least 4 inches around the TV.

22) Always place the back of the television at least four (4) inches away from any vertical surface (such as a wall) to allow proper ventilation.

23) Never allow anything to rest on or roll over the power cord, and never place the TV where the power cord is subject to wear or abuse.

24) Never overload wall outlets and extension cords. Always operate the TV with a 120V AC, 60Hz power source only.

25)

CAUTION: To reduce the risk of electric shock, do not use the polarized plug with an extension cord, receptacle, or other outlet unless the blades can be inserted completely with three-wire grounding type to prevent blade exposure.

EQUIPMENT DAMAGE! Never place the TV on an unstable cart,

Sturdy tie (as short as possible; min. 4 in.)

TV side

Hooks

Band

TV top

Clip

Screw

50S0301A.indb 450S0301A.indb 4 2/5/08 5:58:16 PM2/5/08 5:58:16 PM

SAFETY INSTRUCTIONS

(Continued)

Installation (cont. from previous page)

26) Always make sure the antenna system is properly grounded to provide adequate protection against voltage surges and built-up static charges (see Section 810 of the National Electric Code.)

Antenna

Ground clamp

Electric service

equipment

Power service grounding

electrode system

(NEC Art 250 Part H)

27) DANGER: RISK OF SERIOUS

PERSONAL INJURY OR DEATH!

• Use extreme care to make sure you

(or any item such accidentally touch overhead power lines.

Never locate the antenna near overhead

power lines or other electrical circuits.

•

Never attempt to install any of the following during lightning activity: a) an antenna system; or b) cables, wires, or any home theater component connected

to an antenna or phone system.

are never in a position where your body

you are in contact with,

as a ladder or screwdriver) can

lead-in wire

Antenna discharge unit (NEC Section 810-20)

Grounding conductors (NEC Section 810-21)

Ground clamps

Care

For better performance and safer operation of your TOSHIBA TV, follow these recommendations and precautions:

28) Always unplug the TV before cleaning.

Wipe the display panel

surface gently using only a soft cloth (supplied.) A hard cloth may damage the surface of the panel. Avoid contact with alcohol, thinner, benzene, acidic or and alkaline solvent cleaners, abrasive cleaners, or chemical cloths, which may damage the surface. Never spray volatile compounds such as insecticide on the cabinet. Such products may damage or discolor the cabinet

29)

any kind into the TV cabinet slots.

WARNING: RISK OF ELECTRIC SHOCK!

Never spill liquids or push objects of

Care (cont. from previous column)

32) During normal use, the TV may make occasional snap ping or popping sounds. This is normal,

especially when the unit is being turned on or off. If these sounds become frequent or continuous,

unplug the power cord and contact a Toshiba Authorized Service Center.

Keep your ﬁ ngers well clear of the disc slot as it is closing.

33) Failure to do so may cause serious personal injury.

34) When you use headphones, keep the volume at a

moderate level. Using headphones continuously

at a high volume may cause hearing damage.

35)

NEVER look directly into the disc slot or ventilation slots at the source of the laser beam. Doing so may cause sight damage.

36) NEVER use a cracked, deformed, or repaired disc.

Such discs are easily broken and may cause serious personal injury or product damage. SUCH DAMAGE IS NOT COVERED UNDER YOUR WARRANTY.

37) WARNING: RISK OF SERIOUS PERSONAL

INJURY OR EQUIPMENT DAMAGE!

• Never strike the screen with a sharp or heavy

object.

• Never touch, press, or place anything on the

LCD screen. These actions will damage the LCD screen If you need to clean the LCD screen, follow the instructions in item 28 on this page.

Service

38)

may expose you to dangerous voltage or other hazards. Failure to follow this WARNING may result in death or serious injury.

Refer all servicing to a Toshiba Authorized Service

Center.

39) If you have the TV serviced:

•

Ask the service technician to use only replacement

parts speciﬁ ed by the manufacturer.

• Upon completion of service, ask the service

technician to perform routine safety checks to

determine that the TV is in safe operating condition.

40) When the TV reaches the end of its useful life,

ask a qualiﬁ ed service technician to properly dispose of the TV.

WARNING: RISK OF ELECTRIC SHOCK! Never attempt to service the TV yourself. Opening and removing the covers

Introduction

30)

While it is thundering, do not touch the connecting

cables or apparatus.

31)

For added protection of your TV from lightning and power surges, always unplug the power cord and disconnect the antenna from the TV if you leave the TV unattended or unused for long periods of time.

50S0301A.indb 550S0301A.indb 5 2/5/08 5:58:17 PM2/5/08 5:58:17 PM

Introduction

Precautions

Choosing a location for your LCD TV

■ Retractable pedestal stand and locating the LCD TV

Observe the following safety precautions:

1) Ensure that unpacking and transfer of the unit is carried out by two or more people.

2) Put the LCD TV on a large level area in a recumbent posture.

3) Grab the pedestal stand and lift the display up. Conﬁ rm the pivot is

locked.

4) Place the TV on a sturdy, level surface that

can support the weight of the TV.

5) Be sure to secure the TV to a wall stud,

pillar, surface, or other immovable structure. To secure the TV in this manner: (1) attach a clip to an immovable structure, then (2) pass a sturdy strap through the clip and attach each end to the hooks located at the back of the TV. Be sure to leave at least 4 inches between the TV and the wall or similar structure for ventilation. See item 19, page 4 for additional details.

■ To fold the pedestal stand

1) Slide the lever on the back side of the pedestal stand to the left.

2) Lay the display down.

Back side of the pedestal stand

NOTE: Do not operate the LCD TV while the pedestal stand is folded.

■ To Display your LCD TV using a Wall Bracket:

If you decide to wall mount your LCD TV, always use a UL Listed wall bracket appropriate for the size and weight of the LCD TV (see page 2):

1) CAUTION: Two people are required for installation.

2) Unplug and remove any cables and/or other component

connectors from the rear of the TV.

3) Follow the instructions provided with your wall bracket.

Before proceeding, make sure the appropriate bracket(s) are attached to the wall and the back of the TV as described in the instructions provided with the wall bracket.

4) After attaching the appropriate bracket(s) to the wall and the back

of the TV, remove the pedestal stand from the TV as described below.

■ Removing the Pedestal Stand

1) Carefully lay the front of the unit face down on a ﬂ at, cushioned

surface such as a quilt or blanket. Leave the stand protruding over the edge of the surface.

NOTE: Extreme care should always be used when removing

the pedestal stand to avoid damage to the LCD panel.

2) Remove the two screws shown in the diagram below.

This will allow removal of the pedestal stand.

3) Once you have removed all two screws holding the pedestal

stand in place, remove the pedestal stand from the TV by sliding the pedestal stand away from the TV.

Slide the lever to the left

Important notes about your LCD TV

The following symptoms are technical limitations Display technology and are not an indication therefore, Toshiba is not responsible resulting from these symptoms.

1) An after image (ghost) may appear on the screen if a ﬁ xed, non-moving image is displayed for a long period of time. The after image is not permanent and will disappear in a short period of time.

2) The LCD panel contained in this TV is manufactured using an extremely high level of precision technology; be an occasional pixel (dot of light) (does not light, remains property of LCD not covered under your warranty. Such pixels are not visible when the picture is viewed from a normal viewing distance. Note: Interactive video games that involve shooting a “gun” type

of joystick at an on-screen target may not work on this TV.

constantly lit, etc.). This is a structural

technology, is not a sign of malfunction, and is

for perceived defects

that does not operate properly

of LCD

of malfunction;

however, there may

Notes on handling

■ Do not subject the LCD panel to physical shock, such it. It may cause unit damage and malfunction.

■ When shipping the unit, the original shipping carton and packing materials come in handy. For fully protection, repack the unit as it was originally packed at the factory.

■ Do not use volatile liquids, such as insecticide, near the unit. Do not leave rubber or plastic products in contact with the unit for prolonged periods of time. Doing so will leave marks on the ﬁ nish.

The top and rear panels of the unit may become warm

■ period of use. This is not a malfunction.

■ When the unit is not in use, always remove the disc and turn off the power.

as dropping

after a long

Notes on locating the unit

■ When you place this unit near a TV, radio, or VCR, the playback picture may become poor and the sound may be distorted. In this case, place the unit away from the TV, radio, or VCR.

■ To avoid damage to this product, never place or store the TV/DVD in direct sunlight; hot, humid areas; or areas subject to excessive dust or vibration.

Two screws

50S0301A.indb 650S0301A.indb 6 2/5/08 5:58:18 PM2/5/08 5:58:18 PM

Precautions (Continued)/Notes on discs

Notes on moisture condensation

Moisture condensation damages the unit. Please read the following carefully.

Moisture condensation occurs, for example, when you pour a cold drink into a glass on a warm day and drops of water form on the outside of the glass. In the same way, moisture may condense on this unitʼs internal optical pick-up lens, one of the most crucial internal parts of the unit.

Optical pick-up

lens

■ Moisture condensation may occur in the following situations:

When you move the unit from a cold area to a warm area. When you use the unit in a room in which the heat

was just turned on.

When you use the unit in an area where cold air from

an air conditioner directly hits the unit.

When you use the unit in a humid area.

On handling discs

Do not touch the playback side of the disc.

For example, handle the disc so that it is shown in ﬁ gure below.

Do not attach paper or tape to discs.

Playback side

On cleaning discs

Fingerprints and dust on the disc cause picture and

sound deterioration. Wipe the disc from the center outwards with a soft cloth. Always keep the disc clean.

Do not use any type of solvent such as thinner,

benzine, commercially available cleaners or antistatic spray for vinyl LPs. It may damage the disc.

On storing discs

Do not store discs in a place subject to direct sunlight

or near heat sources.

Do not store discs in places subject to moisture and

dust such as a bathroom or near a humidiﬁ er.

Store discs vertically in a case. Stacking or placing

objects on discs outside of their case may cause warping.

Introduction

Structure of disc contents

Normally, DVD video discs are divided into titles, and

■ Never use the unit when moisture condensation

may occur

Using the unit when moisture condensation exists may damage discs and internal parts. Connect the power cord of the unit to the wall outlet, turn on the unit,

the titles are sub-divided into chapters. Video CDs and Audio CDs are divided into tracks.

DVD video disc

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3

remove the disc, and leave it for two or three hours. After two or three hours, the unit will have warmed up and evaporated any moisture. Leaving the TV connected to the wall outlet will help prevent moisture condensation in the TV or DVD Player.

Wait!

Wall outlet

Video CD/Audio CD

Track 1 Track 2 Track 3 Track 4 Track 5

Each title, chapter or track is assigned a number, which is called “title number”, “chapter number” or “track number” respectively. There may be discs that do not have these numbers.

50S0301A.indb 750S0301A.indb 7 2/5/08 5:58:23 PM2/5/08 5:58:23 PM

Introduction

Notes on discs (Continued)

Notes on copyright

The unauthorized recording, use, distribution, or revision of copyrighted materials including, without limitation, television programs, videotapes, and DVDs, is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.

About this ownerʼs manual

This ownerʼs manual explains the basic instructions of this unit. Some DVD video discs are produced in a manner that allows speciﬁ c or limited operation during playback. As such, the unit may not respond to all operating command. This is not a defect in the unit. Refer to instruction notes of discs.

The following symbol may appear on the TV screen during operation.

It means that the operation is not permitted by the TV/DVD or the disc. For example, sometimes it is unable to stop the playback of copyright message of the disc when the STOP (■) button is pressed. Alternatively, this symbol may also indicate that the feature is not available for the disc.

Notes on region numbers

The region number of this unit is 1. If region numbers, which stand for their playable area, are printed on your

ALL

DVD video disc and you do not ﬁ nd

, disc playback will not be allowed by the player. (In this case, the unit will display a message on-screen.) Some DVDs that have no region code label may still be subject to area restrictions and therefore not playable.

On Video CDs

This unit supports Video CDs equipped with the PBC (Version 2.0) function. (PBC is the abbreviation of Playback Control.) You can enjoy two playback variations depending on types of discs.

•

Video CD not equipped with PBC function (Version 1.1)

Sound and movie can be played on this unit in the same way as a DVD.

•

Video CD equipped with PBC function (Version 2.0)

In addition to operation of a Video CD not equipped with the PBC function, you can enjoy playback of interactive software with search function by using the menu displayed on the TV screen (Menu Playback). Some of the functions described in this ownerʼs manual may not work with some discs.

Playable discs

This unit can play the following discs.

Disc Mark Contents

DVD video discs

Video

CDs

DIGITAL VIDEO

Audio

CDs

DivX

The following discs are also available.

DVD-R/RW discs of DVD video format CD-R/CD-RW discs of CD-DA, Video CD, MP3, WMA,

JPEG or DivX

Kodak Picture CD and FUJICOLOR CD format

Some of these discs may be incompatible.

format

Audio Video

(moving

pictures)

Audio Video

(moving

pictures)

Audio

Audio Video

(moving

pictures)

Disc Size

12 cm

8 cm

12 cm

8 cm

12 cm

8 cm

12 cm

8 cm

• You cannot play discs other than those listed above.

• You cannot play discs of DVD-RAM, DVD-ROM, CD ROM, Photo CD, etc., or non standardized discs even if they may be labeled as above.

• Some CD-R/RWs cannot be played back depending on the recording conditions.

• This unit uses the NTSC color system, and cannot play DVD video discs recorded in any other color system (PAL, SECAM, etc.).

• This unit can play an 8cm disc. Please do not use a disc adapter. It may cause trouble.

• Please do not insert any disc of an irregular shape into the unit, as it may interfere with the function of the unit.

You may not be able to remove it.

• Please do not use after market accessories, such as a

ring protector, as this may cause trouble with the operation of the unit.

Because of problems and errors that can occur during the creation of DVD and CD Software and/or the manufacture of DVD and CD discs, Toshiba cannot assure that the DVD player contained in this TV will successfully play every disc bearing the DVD and CD logos. If you happen to experience any difﬁ culty playing a DVD and/or CD disc on the DVD player contained in this TV, please contact Toshiba Customer Service.

is a trademark of DVD Format/Logo Licensing

Corporation.

Maximum

playback time

Approx. 4 hours

(single sided disc)

Approx. 8 hours

(double sided disc)

Approx. 80 minutes

(single sided disc)

Approx. 160 minutes

(double sided disc)

Approx. 74 minutes

(single sided disc)

Approx. 20 minutes

(single sided disc)

Approx. 74 minutes

(single sided disc)

Approx. 20 minutes

(single sided disc)

It depends on DivX®

quality

50S0301A.indb 850S0301A.indb 8 2/5/08 5:58:23 PM2/5/08 5:58:23 PM

Contents

Introduction

SAFETY INSTRUCTIONS ................................4

Precautions.......................................................6

Notes on discs .................................................. 7

Contents ...........................................................9

Identiﬁ cation of controls ..................................10

Connections

Antenna connections ...................................... 14

Cable TV connections ....................................15

Connecting to optional equipment .................. 16

Power source..................................................20

Basic setup

Auto setup ......................................................21

Setting the language.......................................22

To memorize channels....................................23

TV operation

TV operation ................................................... 26

Labeling channels...........................................28

Labeling video inputs ...................................... 29

Setting the closed captions.............................30

CC advanced .................................................. 31

Adjusting the picture preference ..................... 32

Picture settings ............................................... 32

Viewing the wide-screen picture formats ........ 33

Film Mode ....................................................... 34

DNR ................................................................34

Picture control adjustment in the PC mode ....35

Sound control adjustment ............................... 36

Selecting Stereo/Second Audio Program (SAP) ....36

Selecting the audio language .........................37

Selecting the HDMI audio input source ..........37

Using the aspect feature.................................38

Adjusting the back lighting .............................. 38

Setting the Auto Shut Off ................................39

Resetting your settings ................................... 39

Basic playback

Playing a disc .................................................40

Advanced playback

Zooming.......................................................... 43

Locating desired scene................................... 43

Marking desired scenes..................................44

Repeat playback ............................................. 45

A-B Repeat playback ...................................... 45

Program playback........................................... 46

Random playback ........................................... 46

Changing angles..............................................47

Title selection ...................................................47

DVD menu .......................................................47

Changing soundtrack language .......................48

Subtitles ...........................................................48

Disc status .......................................................49

To turn off the PBC ..........................................49

MP3/WMA/JPEG/DivX®

and Audio CD operation ..................................50

Repeat, random and program playback

using ﬁ le browser.............................................54

Function setup

Customizing the function settings ....................56

Temporary cancel the rating level

by DVD disc .....................................................61

Others

Understanding the Power Return feature ........62

Troubleshooting ...............................................62

Reception disturbances ...................................64

Language code list ..........................................65

Speciﬁ cations ..................................................66

Limited Canadian Warranty .............................67

Introduction

50S0301A.indb 950S0301A.indb 9 2/5/08 5:58:24 PM2/5/08 5:58:24 PM

Introduction

Identification of controls

Front

Side

Disc slot

Speaker

Remote sensor

Left Side

POWER indicator

EJECT button

VOLUME (+/–) buttons CHANNEL

PLAY button

CHANNEL

■ STOP button MENU button 22 56

INPUT/ENTER button 16

Adjusting the angle of the base

Approx. 10°

Illustration of 19LV505C

Approx. 3°

You can adjust the angle of the TV-screen for 3° forward or for 10° backward from vertical angle. Hold the base of the TV while adjusting the angle.

POWER button

Illustration of 19LV505C

50S0301A.indb 1050S0301A.indb 10 2/5/08 5:58:25 PM2/5/08 5:58:25 PM

Rear

Introduction

AC INPUT 20

HEAD PHONE jack

COLORSTREAM HD IN jacks 17

VIDEO/GAME IN jack

16 17

HDMI IN jack

PC AUDIO IN jack

PC MONITOR IN jack

Antenna jack 14

COAXIAL DIGITAL AUDIO OUT jack 18

Illustration of 19LV505C

50S0301A.indb 1150S0301A.indb 11 2/5/08 5:58:27 PM2/5/08 5:58:27 PM

Introduction

Identification of controls (Continued)

Remote control

The instructions in this manual describe the function on the remote control. See the page in for details.

EJECT button

TV/DVD button

Direct channel selection buttons (0

Numbered buttons (0

DISPLAY button

CH / button

SUBTITLE button

INPUT button ZOOM button

PLAY MODE button

PLAY button

MENU button

SETUP button

PAUSE button

CH RTN button

SKIP ( ) button

REV button

SLOW ( ) button

TOP MENU button

RETURN button

GAME button

45 49

FF button

41 40

4927 26 48

POWER button SLEEP button

JUMP button Direct channel selection button ( )

AUDIO SELECT button VOL +/– button

16 43

MUTE button

*DVD MENU button ENTER button

22 56

41 27 42 42 42 42 47

5651

Direction buttons ( / / / )

EXIT/CANCEL button STOP button

CLOSED CAPTION button SKIP ( ) button

SLOW ( ) button MARKER button ANGLE button

REPEAT A-B button PIC SIZE button

30 42 42

SE-R0305

*DVD MENU button

Use the DVD MENU button to display the menu included on many DVD video discs. To operate a menu, follow the instructions in “DVD menu.” 47

50S0301A.indb 1250S0301A.indb 12 2/5/08 5:58:31 PM2/5/08 5:58:31 PM

Inserting batteries

Introduction

Open the battery compartment

cover in the direction of the arrow.

Install two “R03/AAA” batteries

(supplied), paying attention to the polarity indicated in the battery compartment.

Replace the compartment cover.

Operation

• Aim the remote control at the remote sensor and press control buttons to operate.

•

Operate the remote control within 30° angle on either side of the remote sensor, up to a distance of approx. 5 meters.

Approx. 5 meters

Caution:

• Never throw batteries into a ﬁ re.

Note:

• Be sure to use AAA size batteries.

• Dispose of batteries in a designated disposal area.

•

Batteries should always be disposed of with the environment in mind. Always dispose of batteries in accordance with applicable laws and regulations.

• If the remote control does not operate correctly, or if the operating range becomes reduced, replace batteries with new ones.

• When necessary to replace batteries in the remote control, always replace both batteries with new ones.

Never mix battery types or use new and used batteries in combination.

•

Always remove batteries from remote control if they are dead or if the remote control is not to be used for an extended

period of time. This will prevent battery acid from leaking into the battery compartment.

50S0301A.indb 1350S0301A.indb 13 2/5/08 5:58:31 PM2/5/08 5:58:31 PM

Connections

Antenna connections

If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If you are using a cable TV service (CABLE), see page 15 for Cable TV connections.

Combination VHF/UHF antenna (Single 75 ohm cable or 300 ohm twin-lead wire)

Antenna

jack

Antenna

jack

Connect the 75 ohm cable from the combination VHF/UHF antenna to the antenna jack on the back of the TV/DVD.

If your combination VHF/UHF antenna has a 300

75 ohm coaxial cable (not supplied)

300-75 ohm matching transformer (not supplied)

ohm twin-lead wire, use the 300-75 ohm matching transformer (not supplied).

Combination VHF/UHF antenna (Separate VHF and UHF 300 ohm twin-lead wires)

Antenna

jack

Combiner (not supplied)

300-75 ohm matching transformer (not supplied)

Connect the UHF 300 ohm twin-lead wire to the combiner (not supplied). Connect the VHF 300 ohm twin-lead wire to the 300-75 ohm matching transformer (not supplied). Attach the transformer to the combiner , then attach the combiner to the antenna jack on the back of the TV/DVD.

UHF 300 ohm twin-lead wire (not supplied)

VHF 300 ohm twin-lead wire (not supplied)

Separate VHF/UHF antennas (75 ohm VHF cable and 300 ohm UHF twin-lead wires)

Antenna

jack

VHF 75 ohm (not supplied)

Combiner (not supplied)

UHF 300 ohm twin-lead wire (not supplied)

Connect the VHF 75 ohm cable and UHF 300 ohm twin-lead wire to the combiner (not supplied). Attach the combiner to the antenna jack on the back of the TV/DVD.

50S0301A.indb 1450S0301A.indb 14 2/5/08 5:58:31 PM2/5/08 5:58:31 PM

Cable TV connections

This TV/DVD has an extended tuning range and can tune most cable channels without using a Cable TV converter box. Some cable companies offer “premium pay channels” in which the signal is scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device which is generally provided by the cable company.

For subscribers to basic cable TV service

Antenna

jack

75 ohm coaxial cable

For basic cable service not requiring a converter/descrambler box, connect the Cable TV 75 ohm coaxial cable directly to the Antenna jack on the back of the TV/DVD.

For subscribers to scrambled cable TV service

If you subscribe to a cable TV service which requires the use of a converter/descrambler box, connect the incoming 75 ohm coaxial cable to the converter/descrambler box. Using another 75 ohm coaxial cable, connect the output jack of the converter/descrambler box to the antenna jack on the TV/DVD. Follow the connections shown below. Set the TV/DVD to the output channel of the converter/descrambler box (usually channel 3 or 4) and use the converter/descrambler box to select channels.

Incoming 75 ohm

Cable TV

Converter/

descrambler

75 ohm cable to

TV/DVD

Antenna

jack

Connections

For subscribers to unscrambled basic cable TV service with scrambled premium channels

If you subscribe to a cable TV service in which basic channels are unscrambled and premium channels require the use of a converter/descrambler box, you may wish to use a signal splitter and an A/B Switch box (available from the cable company or an electronics supply store). Follow the connections shown below. With the switch in the “B” position, you can directly tune any nonscrambled channels on your TV/DVD. With the switch in the “A” position, tune your TV/DVD to the output of the converter/descrambler box (usually channel 3 or 4) and use the converter/descrambler box to tune scrambled channels.

Incoming 75 ohm Cable TV

Splitter

Converter/

descrambler

A/B switch

75 ohm cable

to TV/DVD

Antenna

jack

50S0301A.indb 1550S0301A.indb 15 2/5/08 5:58:32 PM2/5/08 5:58:32 PM

Connections

Connecting to optional equipment

Y ou can enjoy VCR, camcorder or TV game with connection to external input.

Using the audio/video inputs

Press INPUT to view a signal from another device connected to your TV/DVD, such as a VCR player. You can select TV, Video, ColorStream HD, HDMI or PC depending on which input jacks you used to connect your devices.

Press INPUT on the remote control to display the current signal source. To change the input source, press INPUT again or press 0-4. (5 is for selection DVD mode.)

Connecting to a VCR

To playback from the VCR, connect the VCR to the TV/DVD as shown. Select the “Video” by pressing INPUT repeatedly.

: Signal ﬂ ow

VCR

T o Audio/Video OUT

Audio/Video cable (not supplied)

(yellow)

(white)

(red)

Back side

0-5 CH /

INPUT

GAME

Source Selection

0.TV

1.Video

2.ColorStream HD

3.HDMI

4.PC

5.DVD

[0-5]:Select

To VIDEO/GAME IN

Connecting to a camcorder

To playback from the camcorder, connect the camcorder to the TV/DVD as shown. Select the “Video” by pressing INPUT repeatedly.

: Signal ﬂ ow

Camcorder

T o Audio/Video OUT

Audio/Video cable (not supplied)

(yellow)

(white)

(red)

Back side

To VIDEO/GAME IN

Connecting to a TV Game

You can enjoy playing a TV game on the screen by adjusting to the suitable brightness for your eyes.

1. Connect a TV Game to the TV/DVD.

2. Select the Game mode by pressing GAME. The Game mode screen appears.

• If GAME is pressed during standby mode, the unit turns on automatically and the Game mode screen appears on the screen.

: Signal ﬂ ow

T o Audio/Video OUT

Audio/Video cable (not supplied)

Note:

• You can also change the TV/DVD screen to the desired mode by pressing the CH / .

• The TV/DVD can also be used as a display device for many video games. However, due to the wide variety of

different types of signal generated by these devices and subsequent hook-up variations required, they have not all been included in the suggested connection diagrams. Youʼll need to consult each componentʼs Ownerʼs Manual for additional information.

• Interactive video games that involve shooting a “gun” type of joystick at on-screen target may not work on this

TV/DVD.

(yellow)

(white)

(red)

Back side

To VIDEO/GAME IN

50S0301A.indb 1650S0301A.indb 16 2/5/08 5:58:33 PM2/5/08 5:58:33 PM

Connecting to an optional equipment with S-video output

If you connect a VCR with an S-Video cable to the S-VIDEO IN jack on the left side of the TV/DVD, you must also connect the audio cables to the AUDIO IN jacks as shown below. The S-Video cable only carries the video signal. The audio signal is separated. Select the “Video” by pressing INPUT repeatedly.

: Signal ﬂ ow

Ex. VCR with S-Video

To S-VIDEO IN

(white)

To AUDIO (L/R) IN

Back side

(playback)

To S-VIDEO OUT

To Audio (L/R) OUT

S-Video cable (not supplied)

Audio cable (not supplied)

(red)

To VIDEO/GAME IN

Note:

When the S-Video cable and the standard video cable are connected at the same time, the S-video cable takes

•

precedence.

Connecting an optional equipment with ColorStream

Your TV/DVD is capable of using ColorStream® (component video). Connecting your TV/DVD to a component video compatible DVD player, such as a Toshiba DVD player with ColorStream

(Component video) output

can greatly enhance picture quality and performance. Select the “ColorStream HD” by pressing INPUT repeatedly.

Connections

(white)

Back side

(red)

To COLORSTREAM HD AUDIO (L/R) IN

: Signal ﬂ ow

To Audio (L/R) OUT

Ex. DVD player with Component video

To COLORSTREAM HD

To Component Video OUT

Component video cable

) IN

(Y, P

B, PR

(not supplied) Audio cable (not supplied)

When using the Component video cable, an Audio cable must be connected to COLORSTREAM HD AUDIO(L/R) IN jacks.

Note:

• The ColorStream

(component video) inputs on this unit are for use with devices that output 480i, 1080i inter-

laced signals and 480p, 720p progressive signals.

• Refer to the ownerʼs manual of the connected equipment as well.

• When you connect the unit to other equipment, be sure to turn off the power and unplug all of the equipment

from the wall outlet before making any connections.

• If you place the unit near a tuner or radio, the radio broadcast sound might be distorted. In this case, place the

unit away from the tuner and radio.

50S0301A.indb 1750S0301A.indb 17 2/5/08 5:58:35 PM2/5/08 5:58:35 PM

Connections

Connecting to optional equipment (Continued)

You can enjoy high quality dynamic sounds by connecting the TV/DVD to optional audio equipment.

Connecting to an ampliﬁ er equipped with a Dolby® Digital decoder

Dolby Digital

Dolby Digital is the surround sound technology used in theaters showing the latest movies, and is now available to reproduce this realistic effect in the home. You can enjoy motion picture and live concert DVD video discs encoded via the Dolby Digital recording system with this dynamic realistic sound by connecting the TV/DVD to a 6 channel ampliﬁ er equipped with a Dolby Digital decoder or Dolby Digital processor. If you have a Dolby Surround Pro Logic decoder, you will obtain the full beneﬁ t of Pro Logic from the same DVD movies that provide full 5.1-channel Dolby Digital soundtracks, as well as from titles with the Dolby Surround mark.

Ampliﬁ er equipped with a

Dolby Digital decoder

This section uses the following reference mark.

: Front speaker : Rear speaker

: Center speaker : Signal ﬂ ow

: Sub woofer

Back side

To COAXIAL DIGITAL AUDIO OUT

To COAXIAL type digital audio input

75 Ω coaxial cable (not supplied)

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

Connecting to an ampliﬁ er equipped with a DTS® decoder

Digital Theater Systems (DTS)

DTS is a high quality surround technology used in theaters and now available for home use, on DVD video discs or audio CDs. If you have a DTS decoder or processor, you can obtain the full beneﬁ t of 5.1 channel DTS encoded sound tracks on DVD video discs or audio CDs.

Ampliﬁ er equipped with

a DTS decoder

To COAXIAL type digital audio input

75 Ω coaxial cable (not supplied)

Back side

To COAXIAL DIGITAL AUDIO OUT

Manufactured under license under U.S. Patent #: 5,451,942 & other U.S. and worldwide patents issued & pending. DTS and DTS Digital Out are registered trademarks and the DTS logos and Symbol are trademarks of DTS, Inc. © 1996-2007 DTS, Inc. All Rights Reserved.

Connecting to an ampliﬁ er equipped with an MPEG audio decoder

MPEG2 sound

You can enjoy motion picture and live concert DVD video discs encoded via the MPEG2 recording system with dynamic realistic sound by connecting an ampliﬁ er equipped with an MPEG2 audio decoder or MPEG2 audio processor.

Back side

Ampliﬁ er equipped with an

MPEG2 audio decoder

To COAXIAL type digital audio input

75 Ω coaxial cable (not supplied)

To COAXIAL DIGITAL AUDIO OUT

50S0301A.indb 1850S0301A.indb 18 2/5/08 5:58:36 PM2/5/08 5:58:36 PM

Connecting to an ampliﬁ er equipped with a digital audio input

2 channel digital stereo

You can enjoy the dynamic sound of 2 channel digital stereo by connecting an ampliﬁ er equipped with a digital audio input and speaker system (right and left front speakers). Note: PCM audio is limited to DVD or CD playback.

Ampliﬁ er equipped with a

Digital audio input

To COAXIAL type digital audio input

Back side

To COAXIAL DIGITAL AUDIO OUT

75 Ω coaxial cable (not supplied)

Note:

• DO NOT connect the COAXIAL DIGITAL AUDIO OUT jack of the TV/DVD to the AC-3 RF input of a Dolby Digital Receiver. This input on your A/V Receiver is reserved for Laserdisc use only and is incompatible with the COAXIAL DIGITAL AUDIO OUT jack of the TV/DVD.

• Connect the COAXIAL DIGITAL AUDIO OUT jack of the TV/DVD to the “COAXIAL” input of a Receiver or Processor.

• Refer to the ownerʼs manual of the connected equipment as well.

• When you connect the TV/DVD to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before making any connections.

The output sound of the TV/DVD has a wide dynamic range. Be sure to adjust the receiverʼs volume to a moderate listening level.

• Otherwise, the speakers and your hearing may be damaged by a sudden high volume sound.

• Turn off the ampliﬁ er before you connect or disconnect the TV/DVDʼs power cord. If you leave the ampliﬁ erʼs power on, the speakers may be damaged.

Connecting to an HDMI or a DVI device

About HDMI

HDMI (High Deﬁ nition Multimedia Interface) supports both video and audio on a single digital connection for use with DVD players, DTV, set-top boxes, and other AV devices. HDMI was developed to provide the technologies of High Bandwidth Digital Content Protection (HDCP) as well as Digital Visual Interface (DVI) in one speciﬁ cation. HDCP is used to protect digital content transmitted and received by DVI-compliant or HDMI-compliant displays.

HDMI has the capability to support standard, enhanced, or highdeﬁ nition video plus standard to multi-channel surround-sound audio. HDMI features include uncompressed digital video, a bandwidth of up to 2.2 gigabytes per second (with HDTV signals), one connector (instead of several cables and connectors), and communication between the AV source and AV devices such as DTVs.

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI licensing LLC.

Back side

Connections

DVI device

HDMI device

To DVI output

Audio cord (not supplied)

To HDMI out

To PC AUDIO IN

HDMI - to - DVI adapter cable

(HDMI type A connector)

(not supplied)

HDMI cable (type A connector)

(not supplied)

To HDMI IN

Note:

You must select the corresponding audio input source (HDMI or DVI) on the menu screen (see ”Selecting the HDMI audio

•

input source” on page 37). Otherwise you will only see the image with no sound.

50S0301A.indb 1950S0301A.indb 19 2/5/08 5:58:37 PM2/5/08 5:58:37 PM

Connections

Connecting to optional equipment (Continued)/ Power source

Connecting to a PC (Personal Computer)

Before you connect this TV/DVD to your PC, change the adjustment of your PC’s Resolution and Refresh rate (60 Hz). Connect one end of a (male to male) VGA cable to the video card of the computer and the other end to the MONITOR on the rear of the connect the audio cord to the audio output of your Multimedia computer and to the AUDIO connector of the PC AUDIO IN jack of the TV/DVD. Select “PC” by pressing INPUT repeatedly. Switch on the computer. The TV/DVD can operate as the computer monitor

To PC MONITOR IN

Note:

The on-screen displays will have a different appearance in PC mode than in TV mode.

• If there is no video signal from the PC when the unit is in PC mode, “No signal” will appear on the TV/DVD-screen.

•

TV/DVD

Back side

To PC AUDIO IN jack

Audio cord (not supplied)

VGA cable (not supplied)

. Attach the connectors firmly with the screws on the plug.

Monitor Display modes

MODE Resolution Refresh rate VGA 640x480 60Hz VGA 720x400 70Hz SVGA 800x600 60Hz XGA 1024x768 60Hz WXGA 1280x768 60Hz WXGA 1280x720 60Hz WXGA 1360x768 60Hz

To return to normal mode

Press INPUT again.

In case of a Multimedia computer,

VGA connector PC

Power source

To use AC power source

Connect the AC cord plug into this TV/DVD’s AC INPUT jack.

1. Connect the AC cord into an AC outlet.

Illustration of 19LV505C

Wider Hole and Blade

AC 120V, 60Hz

AC cord (supplied)

Note:

Never connect the AC line cord plug to other than the specified voltage (120V 60Hz). Use the attached power cord only.

• If the polarized AC cord does not fit into a non-polarized AC outlet, do not attempt to file or cut the blade. It is the user’s

• responsibility to have an electrician replace the obsolete outlet. If you cause a static discharge when touching the unit and the unit fails to function, simply unplug the unit from the AC outlet

• and plug it back in. The unit should return to normal operation. If the AC cord plug is plugged in for the first time, wait for approx. 5 seconds before pressing POWER.

•

AC Outlet

50S0301A.indb 2050S0301A.indb 20 2/5/08 5:58:38 PM2/5/08 5:58:38 PM

Basic setup

Auto Setup

The Auto Setup function helps to install your TV/DVD easily. It leads you the Language selection, Air/Cable selection and Automatic channel search.

IMPORTANT: Make sure that the antenna or cable TV system connection is made!

Auto Setup

To turn on the TV/DVD, press POWER.

POWER indicator on the front of the unit

•

changes green. It may take approx. 10 seconds for a picture to appear on screen.

Auto Setup menu appears on the screen. Press ▲ or ▼ to select “Language”, then press ◀ or ▶ to select your desired language.

Auto Setup

Language

Signal Type Cable

Automatic Search

English

Start

Now the “Automatic Search” starts.

If you press EXIT/CANCEL, the Automatic

• Search stops and changes to the TV screen.

After the starting setup is completed, the TV

•

channel appears on the screen.

Auto Setup

Language

Signal Type Cable

Automatic Search

Analog Channel Found : 0

Digtal Channel Found :

POWER

ENTER

/ / /

EXIT/CANCEL

Basic setup

English

Start

EXIT : End

: Select

Press ▲ or ▼ to select “Signal Type”, then press ◀ or ▶ to select “Air” or “Cable”.

Auto Setup

Language

Signal Type Cable

Automatic Search

: Select

Air - VHF/UHF channels Cable

- Cable TV channels

Press ▲ or ▼ to select “Automatic Search”, then press ENTER.

Auto Setup

Language

Signal Type Cable

Automatic Search

: Adjust

English

Start

English

Start

Note:

•

The Auto Setup function will work only when you press POWER for the first time.

•

The process of “Automatic Search” may take 15 to 30 minutes to complete, depending on your regional cable service.

: Select

ENTER:Set

50S0301A.indb 2150S0301A.indb 21 2/5/08 5:58:39 PM2/5/08 5:58:39 PM

Basic setup

Setting the language

This TV/DVD can display the on screen language in English, French or Spanish. Select the language you prefer ﬁ rst, then proceed with the other menu options.

Setting the language

To turn on the TV/DVD, press POWER.

POWER indicator on the front of the unit

•

changes green. It may take approx. 10 seconds for a picture to appear on screen.

Press MENU. The TV menu screen will appear. Press ▲ or ▼ to select “Setup”, then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “Language”.

Setup

Closed Caption >>

Language English

Video Label >>

Backlight

Auto Shut Off

Aspect

Reset >>

: Select

: Adjust

Off On

Press ◀ or ▶ to select the desired language: English, French (Français) or Spanish

(Español).

Press EXIT/CANCEL to return to the normal screen.

Note:

•

If the unit does not operate properly, or No key operation (by the unit and/or the remote control):

Static electricity, etc., may affect the TV/DVD’s operation. In such case, disconnect the AC cord once, then connect it again.

•

If no buttons are pressed for more than about 60 seconds, the MENU screen will return to normal operation automatically.

•

The TV section has its own menu and the DVD

section also has its own menu

POWER

ENTER

/ / /

EXIT/CANCEL

50S0301A.indb 2250S0301A.indb 22 2/5/08 5:58:40 PM2/5/08 5:58:40 PM

To memorize channels

This TV/DVD is equipped with a channel memory feature which allows channels to skip up or down to the next channel set into memory, skipping over unwanted channels. Before selecting channels, they must be programmed into the TV/DVDʼs memory. To use this TV/DVD with an antenna, set the Tuning Band menu option to the Air mode. When shipped from the factory, this menu option is in the Cable mode.

ENTER

/ / /

EXIT/CANCEL MENU

Air/Cable selection

Press MENU in the TV mode. The TV menu screen will appear. Press ▲ or ▼ to select

“Channel”, then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “Auto Ch Memory”, then press ▶ or ENTER.

Channel

Add/Delete >>

Auto Ch Memory

Ch Label >>

Press ▲ or ▼ to select “Signal Type”.

Auto Ch Memory

Signal Type Cable Automatic Search Start

Automatic search

Press MENU in the TV mode. The TV menu screen will appear. Press ▲ or ▼ to select

“Channel”, then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “Auto Ch Memory”, then press ▶ or ENTER.

Channel

Add/Delete >>

Auto Ch Memory

Press ▲ or ▼ to select “Automatic Search”, then press ENTER.

Ch Label >>

: Select ENTER:Set

Auto Ch Memory

Signal Type Cable Automatic Search Stop

Basic setup

Press ◀ or ▶ to select “Air” or “Cable”.

Auto Ch Memory

Signal Type Air Automatic Search Start

Air - VHF/UHF channels Cable

- Cable TV channels

Press EXIT/CANCEL to return to the normal screen.

The TV/DVD will begin memorizing all the channels available in your area.

Analog Channel Found : 0 Digital Channel Found : 0

: Select

ENTER:Cancel

50S0301A.indb 2350S0301A.indb 23 2/5/08 5:58:41 PM2/5/08 5:58:41 PM

Basic setup

To memorize channels (Continued)

Add/Delete channel

You can select the channel that you want to skip.

ENTER

/ / /

EXIT/CANCEL MENU

Press MENU in the TV mode. Press ▲ or ▼ to select “Channel”, then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “Add/Delete”, then press ▶ or ENTER.

Channel

Add/Delete >>

Auto Ch Memory

Ch Label >>

: Select ENTER:Set

Press ▲ or ▼ to select “Add/Delete”, then press ▶ or ENTER.

Add/Delete

Adding Channel >>

Add/Delete >>

Clear All >>

Press ▲ or ▼ to select the channel that you want to skip.

Add/Delete

CH Signal

2 Analog

3 Analog Add

3-001 Digital Delete

3-002 Digital Add

4 Analog Delete

: Select

Press ◀ or ▶ to select “Add” or “Delete”, whichever function you want to perform.

Add/Delete

CH Signal

2 Analog

Repeat steps 4 - 5 for other channels you want to add or delete.

Press EXIT/CANCEL to return to the normal screen.

3 Analog Add

3-001 Digital Delete

3-002 Digital Add

4 Analog Delete

: Select

Add

: Adjust

Delete

: Adjust

: Select ENTER:Set

50S0301A.indb 2450S0301A.indb 24 2/5/08 5:58:43 PM2/5/08 5:58:43 PM

ENTER

/ /

EXIT/CANCEL MENU

Adding Channel

If you find a new channel unregistered, you can add the new channel into the channel memory.

Tune in the new channel.

Press MENU. Press ▲ or ▼ to select “Channel”, then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “Add/Delete”, then press ▶ or ENTER.

Channel

Add/Delete >>

Auto Ch Memory

Ch Label >>

Clear All

All channels are deleted from the channel memory.

Press MENU in the TV mode. Press ▲ or ▼ to select “Channel”, then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “Add/Delete”, then press ▶ or ENTER.

Channel

Add/Delete >>

Auto Ch Memory

Ch Label >>

: Select ENTER:Set

Basic setup

Press ▲ or ▼ to select “Clear All”, then press ▶ or ENTER.

: Select ENTER:Set

Press ▲ or ▼ to select “Adding Channel”, then press ▶ or ENTER. The new channel will

be added into the channel memory.

Add/Delete

Adding Channel >>

Add/Delete >>

Clear All >>

: Select ENTER:Set

Press EXIT/CANCEL to return to the normal screen.

Add/Delete

Adding Channel >>

Add/Delete >>

Clear All >>

: Select ENTER:Set

Press EXIT/CANCEL to return to the normal screen.

50S0301A.indb 2550S0301A.indb 25 2/5/08 5:58:44 PM2/5/08 5:58:44 PM

TV operation

To turn on the TV/DVD, press POWER. (POWER indicator on the front of the unit changes

green. It may take approx. 10 seconds for a picture to appear on screen.)

Adjust the volume level by pressing VOL + or – . The volume level will be indicated on the screen

by orange bars. As the volume level increases, so do the number of bars. If the volume decreases, the number of orange bars also decreases.

Set the Signal Type option to the appropriate position (see “Air/Cable selection” on page 23).

Air - VHF/UHF channels Cable

- Cable TV channels

Press the Direct Channel Selection (0-9, –) buttons or CH / to select the channel.

(If you press only channel number, channel selection will be delayed for a few seconds.)

POWER 0–9, –

VOL +/– CH /

TO SELECT ANALOG CHANNELS

1-9: Press 1-9 as needed. Example, to

select channel 2, press 2.

10-99: Press the 2 digits in order. Example, to

select channel 12, press 1, 2.

100-125: Press the 3 digits in order. Example, to

select channel 120, press 1, 2, 0.

TO SELECT DIGITAL CHANNELS

Press the first 3 digits, then press the – button, followed by the remaining number. Example, to select channel 015-001, press 0, 1, 5, –, 1.

•

If a channel is selected with only audio content, “Audio only” will be displayed on the screen.

•

If a channel is selected with a weak digital signal, “Digital channel signal strength is low” will be displayed on the screen. The same program may be available on either an analog channel or a digital channel. You may choose to watch either format.

•

If a channel is selected to which you have not subscribed, be displayed on the screen.

VHF/UHF/CABLE CHANNELS

Air Cable

VHF 2-13

UHF

14-69

“Digital channel is encrypted” will

VHF 2-13

STD/HRC/IRC 14-36 (A) (W) 37-59 (AA) (WW) 60-85 (AAA) (ZZZ) 86-94 (86) (94) 95-99 (A-5) (A-1) 100-125 (100) (125) 01 (5A)

Note:

If a channel with no broadcast is selected, the sound

• will automatically be muted.

•

It may take a few seconds for a digital channel picture to appear on screen after being selected.

50S0301A.indb 2650S0301A.indb 26 2/5/08 5:58:46 PM2/5/08 5:58:46 PM

TV operation (continued)

SLEEP

DISPLAY VOL +/– MUTE

CH RTN

■ DISPLAY

Press DISPLAY to display the current information on the screen.

Sleep Timer

Off

English

When the TV/DVD

62-001 HDTV Moving Picture1

CH-1

Digital Cable

No Program Information is available

receives a digital signal, the digital information will appear.

Channel number • Station name

• Channel label (if preset) •

• Signal type • Sleep timer

• Audio language • Program guide

• Picture size • Resolution

•

Natural

1080i

Broadcast program name

Analog Cable

Sleep Timer

Off

When the TV/DVD receives a analog signal, the analog information will appear.

Channel number • Channel label (if preset)

• Signal type • Sleep timer

• Audio information

• (Stereo or SAP)

• Picture size

• Resolution

Natural

480i

Press DISPLAY again to clear the call display.

Note:

After a few seconds, DISPLAY screen will return to

• normal TV-operation automatically.

■ CH RTN

This button allows you to go back to the last channel selected by pressing CH RTN. Press CH RTN again to return to the last channel you were watching.

■ SLEEP

To set the TV/DVD to turn off after a preset amount of time, press SLEEP on the remote control. The clock will count up 10 minutes for each press of the SLEEP button (Off, 0h 10m, 0h 20m, ..., 2h 0m). After the sleep time is programmed, the display will appear briefly every ten minutes to remind you that the sleep timer is operating. To confirm the sleep timer setting, press SLEEP and the remaining time will be displayed for a few seconds. To cancel the sleep timer, press SLEEP repeatedly until the display turns to Off.

■ HEAD PHONES

Insert a stereo headphones (not supplied) with a 1/8” mini plug into the HEAD PHONE jack on the rear panel. If you connect headphones, the sound from TV/DVD speakers is muted.

Sleep Timer

0h 10m

TV operation

■ MUTE

Press MUTE to switch off the sound. The TV/DVD’s sound will be silenced and “Mute” will appear on the screen. The sound can be switched back on by pressing this button again or the VOL + or –.

50S0301A.indb 2750S0301A.indb 27 2/5/08 5:58:46 PM2/5/08 5:58:46 PM

TV operation

Labeling channels

Channel label appear with the channel number display each time you turn on the TV/DVD, select a channel, or press DISPLAY. You can choose any four characters to identify a channel.

Labeling channels

ENTER

/ / /

EXIT/CANCEL MENU

Press MENU in the TV mode. Press then press ▲ or ▼ to select “Channel” menu, then press

▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “Ch Label”, then press ▶ or ENTER.

The “Ch Label” menu will appear.

Channel

Add/Delete >>

Auto Ch Memory

Ch Label >>

: Select ENTER:Set

Press ◀ or ▶ to select a channel you want to label, then press ▼.

Ch Label

Channel Number 15-1

Ch Label

Label Clear >>

Press ◀ or ▶ repeatedly until the character you want appears in the first space.

Ch Label

Channel Number 15-1

Ch Label A

Label Clear >>

: Adjust

: Select

The characters rotation as follows:

, () @ / + =

SPACE

If the character which you desire appears, press ENTER.

Repeat this step to enter the rest of the characters. If you would like a blank space in the label name, you must choose the empty space from the list of characters.

When you finish inputting the label name, press EXIT/CANCEL to return to the normal

screen.

Repeat steps 3-5 for other channel. You can assign a label to each channel.

ENTER:Set

: Select

: Adjust

To clear a Ch Label

After step 3 above, press ▲ or ▼ to select “Label Clear”, then press ▶ or ENTER.

Note:

The channel labels will be reset after “Automatic

• Search” on page 23.

50S0301A.indb 2850S0301A.indb 28 2/5/08 5:58:48 PM2/5/08 5:58:48 PM

Labeling video inputs

The Video Label feature allows you to label each input source for your TV/DVD.

Labeling video inputs

ENTER

/ / /

EXIT/CANCEL MENU

Press MENU in the TV mode. Press ▲ or ▼ to select “Setup”, then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “Video Label”, then press ▶ or ENTER.

Setup

Closed Caption >>

Language English

Video Label >>

Backlight Auto Shut Off Off

Aspect

Reset >>

: Select

Press ▲ or ▼ to select an input which you want to label.

Video Label

Video -

ColorStream HD -

HDMI -

Press ◀ or ▶ to select the desired label for that input source.

Video Label

Video -

ColorStream HD SAT

HDMI -

: Select

: Adjust

TV operation

– : Uses the default label name

VCR : Video cassette recorder DVD : DVD video DTV : Digital TV set-top box SAT : Satellite box CBL : Cable box HD : HDMI (only for HDMI input)

ENTER:Set

Press EXIT/CANCEL to return to the normal screen.

: Select

: Adjust

50S0301A.indb 2950S0301A.indb 29 2/5/08 5:58:50 PM2/5/08 5:58:50 PM

TV operation

Setting the closed captions

WHAT IS CLOSED CAPTIONING?

This television has the capability to decode and display closed captioned television programs. Closed captioning will display text on the screen for hearing impaired viewers or it will translate and display text in another language.

Setting the closed captions

ENTER

/ / /

EXIT/CANCEL MENU CLOSED CAPTION

Press MENU in the TV mode. Press ▲ or ▼ to select “Setup”, then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “Closed Caption”, then press ▶ or ENTER.

The Closed Caption menu will appear.

Setup

Closed Caption >>

Language English

Video Label >>

Backlight Auto Shut Off Off

Aspect Reset >>

: Select

Press ▲ or ▼ to select “CC Setting”, then press ◀ or ▶ to select “On”.

On: Captions will be displayed on the screen. Off: Captions will not be displayed on the screen.

Closed Caption

CC Setting Off

CC Priority

Analog Caption

Digital Caption

Digital CC Preset CC Advanced

ENTER:Set

Digital CC C1

CS1

Default >>

Press ▲ or ▼ to select “Analog Caption” or “Digital Caption”, then press ◀ or ▶ to select

the desired Closed Caption mode.

When you select “Analog Caption”, you can choose C1, C2, C3, C4, T1, T2, T3 and T4.

When you select “Digital Caption”, you can choose from CS1, CS2, CS3, CS4, CS5 and CS6.

Closed Caption

CC Setting On

CC Priority

Analog Caption

Digital Caption

Digital CC Preset CC Advanced

: Select

: Adjust

Press ▲ or ▼ to select “CC Priority”, then press ◀ or ▶ to select “Digital CC” or “Analog

CC”.

Note:

Depending on the broadcast signal, some

• Analog Captions will function with a Digital broadcast signal. This step prevent that two kind of captions are overlapping.

Press EXIT/CANCEL to return to the normal screen.

Digital CC C1

CS1

Default >>

: Select

: Adjust

Note:

You can also display the Closed Caption menu screen by pressing CLOSED CAPTION on the remote control.

• Digital caption feature is not available for analog channel.

•

Important Note: If text is not available in your viewing area, a black rectangle may appear on-screen. If this happens, set “CC Setting” to “Off”.

50S0301A.indb 3050S0301A.indb 30 2/5/08 5:58:51 PM2/5/08 5:58:51 PM

CC advanced

When you have selected Custom as the display method, you can adjust the various setting listed below as follows:

This feature is designed to customize Digital Captions only.

CC advanced

ENTER

/ / /

EXIT/CANCEL MENU

Press MENU in the TV mode. Press ▲ or ▼ to select “Setup”, then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “Closed Caption”, then press ▶ or ENTER.

The Closed Caption menu will appear.

Setup

Closed Caption >>

Language English

Video Label >>

Backlight Auto Shut Off Off

Aspect

Reset >>

: Select

Press ▲ or ▼ to select “Digital CC Preset”,

then press ◀ or ▶ to select “Custom”.

Closed Caption

CC Setting On

CC Priority

Analog Caption

Digital Caption

Digital CC Preset CC Advanced

: Select

Press ▲ or ▼ to select “CC Advanced”, then press ▶ or ENTER.

The CC Advanced menu will appear.

Closed Caption

CC Setting On

CC Priority

Analog Caption

Digital Caption

Digital CC Preset CC Advanced

: Select

: Adjust

ENTER:Set

Digital CC C1

CS1

Custom >>

Digital CC C1

CS1

Custom >>

Press ▲ or ▼ to select the desired item, then press ◀ or ▶ to change the setting.

CC Advanced

Text Size Auto

Text Type Auto

Text Edge Auto

Text Color Auto

Text Opacity Auto

Background Color Auto

Background Opacity Auto

: Select

: Adjust

You can select from among the following items and parameters.

Text Size:

Auto, Small, Standard, Large

Text Type: Auto, Style1, Style2, Style3,

Style4, Style5, Style6, Style7

Text Edge:

Auto, None, Raised, Depressed, Uniform, Left Shadow, Right Shadow

Text Color:

Auto, Black, White, Red, Green, Blue, Yellow, Magenta, Cyan

Text Opacity:

Auto, Solid, Transparent, Translucent, Flashing

Background Color:

Background Opacity:

Auto, Black, White, Red, Green, Blue, Yellow, Magenta, Cyan

Auto, Solid, Transparent, Translucent, Flashing

Press EXIT/CANCEL to return to the normal screen.

Note:

You cannnot select “CC Advanced” in the menu

• before set “Digital CC preset” to “Custom”. You cannot set the Closed Caption “Text Color” and

• “Background Color” as the same color.

TV operation

50S0301A.indb 3150S0301A.indb 31 2/5/08 5:58:52 PM2/5/08 5:58:52 PM

TV operation

Adjusting the picture preference/ Picture settings

You can select four picture modes—Sports, Standard, Movie and Memory— as described in the following table:

Picture settings are factory preset but you can adjust them individually as follows:

ENTER

/ / /

EXIT/CANCEL MENU

Adjusting the picture preference

Press MENU in the TV mode. Press ▲ or ▼ to select “Picture”, then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “Picture Preference”.


Picture Setting >> Picture Preference Sports Picture Size >> Film Mode PC Setting >> DNR On

: Select

Press ◀ or ▶ to select a mode you want to

adjust.


Picture Setting >> Picture Preference Standard Picture Size >> Film Mode PC Setting >> DNR On

: Select

Mode Picture Quality

Sports Standard Standard picture quality (factory-set) Movie Movie-like picture setting (factory-set) Memory Your personal preferences (set by

After your desired setting, press EXIT/ CANCEL to return to the normal screen.

Bright and dynamic picture (factory-set)

you; see “Picture settings” at right).

: Adjust

Picture settings

Press MENU in the TV mode. Press ▲ or ▼ to select “Picture”, then press ▶ or ENTER.

Press ▲ or ▼ to select “Picture Setting”, then press ▶ or ENTER. The Picture Setting menu

will appear.


Picture Setting >> Picture Preference Sports Picture Size >> Film Mode PC Setting >> DNR On

: Select

Press ▲ or ▼ to select the item you want to adjust. Press ◀ or ▶ to adjust the setting.

Picture Setting

Brightness Contrast Sharpness Color Tint Color Temperature Cool

: Select ENTER:Set

◀▶

Brightness

Contrast decrease

Sharpness makes picture

Color be pale color be brilliant color Tint be reddish color be greenish

Color Temperature

Cool Bluish Standard Neutral Warm Reddish

After your desired setting, press EXIT/ CANCEL to return to the normal screen.

Note:

The Contrast default setting is set to maximum at the

• factory.

decrease brightness

contrast

softer

increase brightness

increase contrast

makes picture clearer

color

Picture Quality

: Adjust

25 50 25 25

: Adjust

50S0301A.indb 3250S0301A.indb 32 2/5/08 5:58:53 PM2/5/08 5:58:53 PM

Viewing the wide-screen picture formats

You can view programs in a variety of picture sizes— Natural, Theather Wide1, Theather Wide2, Theather Wide3 and Full.

Viewing the wide-screen picture formats

Press MENU. Press ▲ or ▼ to select “Picture”, then press ▶ or ENTER.

Press ▲ or ▼ to select “Picture Size”, then press ▶ or ENTER to display Picture Size

menu. Press ▲/▼ or corresponding Number button (0-4) to select the desired picture size, as described below.

Picture Size

0.Natural

1.Theater Wide1

2.Theater Wide2

3.Theater Wide3

4.Full

[0-4]:Select

Note:

Selectable picture sizes may vary depending on the

• input source or broadcast signal. Picture Size menu also can be displayed by pressing

•

PIC SIZE on the remote control.

Theater Wide2 picture size (for letter box programs)

The entire picture is uniformly enlarged—it is stretched the same amount both wider and taller (retains its original proportion).

The top and bottom edges of the picture may be hidden.

A B C D E F G - - - - - - - - - - - - - - - -

Note:

This picture size is not available on 22LV505C.

•

Theater Wide3 picture size (for letter box programs with subtitles)

To fill the width of the screen, it is extended horizontally. However; it is only slightly extended at the top and the bottom.

The top and bottom edges of the picture may be hidden.

0-4

ENTER

/ /

EXIT/CANCEL PIC SIZE

TV operation

Press EXIT/CANCEL to return to the normal screen.

Natural picture size

In some cases, this image will display the size of standard 4:3 with a gray side bar.

Theater Wide1 picture size (for 4:3 format programs)

To fill the screen, the right and left edges are extended, however; the center of the picture remains near its former ratio. The top and bottom edges of the picture may be hidden.

A B C D E F G - - - - - - - - - - - - - - - -

Note:

To select this picture size on 22LV505C, select

• “Theater Wide2”.

Full picture size (for 16:9 source programs)

Full will display the picture at the maximum size.

Note:

Some High Definition and/or Digital broadcasts may

• not allow you to change the picture size. 19LV505C: In 720p or 1080i signal, only the Theater

• Wide2 and Full picture size features are available. 22LV505C: In 720p or 1080i signal, picture size

• feature will not work. In PC Mode, only the Natural and Full picture size

• features are available. Additionally this feature will not work when display mode is WXGA.

A B C D E F G - - - - - - - - - - - - - - - - - - - - - - - - - -

50S0301A.indb 3350S0301A.indb 33 2/5/08 5:58:55 PM2/5/08 5:58:55 PM

TV operation

Film Mode/DNR

A smoother motion may be obtained by setting the Film Mode to “On” when you view a DVD.

DNR (Digital Noise Reduction) can reduce the roughness of the picture. (This function is available only for analog broadcast.)

ENTER

/ / /

EXIT/CANCEL MENU

Film Mode

Press MENU in the TV mode. Press ▲ or ▼ to select “Picture”, then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “Film Mode”.


Picture Setting >> Picture Preference Spor ts Picture Size >> Film Mode On PC Setting >> DNR On

: Select

Press ◀ or ▶ to select “On” or “Off”.


Picture Setting >> Picture Preference Spor ts Picture Size >> Film Mode Off PC Setting >> DNR On

: Select

: Adjust

DNR

Press MENU in the TV mode. Then press ▲ or ▼ to select “Picture”, then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “DNR”.


Picture Setting >> Picture Preference Sports Picture Size >> Film Mode On PC Setting >> DNR On

: Select

Press ◀ or ▶ to select “On” or “Off”.

: Adjust


Picture Setting >> Picture Preference Sports Picture Size >> Film Mode On PC Setting >> DNR Off

: Select

: Adjust

Press EXIT/CANCEL to return to the normal screen.

Note:

A smoother motion may be obtained by setting the Film

• Mode to “On” when you view a DVD from the DVD player connected with ColorStream (component video) inputs.

50S0301A.indb 3450S0301A.indb 34 2/5/08 5:58:56 PM2/5/08 5:58:56 PM

Picture control adjustment in the PC mode

You can adjust to optimize the performance of the TV/DVD in the PC mode.

Picture control adjustment in the PC mode

ENTER

/ / /

EXIT/CANCEL MENU

Press INPUT, then press ▲/▼ or 4 to select the PC mode.

Press MENU. Then press ▲ or ▼ to select “Picture”, then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “PC Setting”, then

press ▶ or ENTER.


Picture Setting >> Picture Preference Memor y Picture Size >> Film Mode Off PC Setting >> DNR Off

: Select

Press ▲ or ▼ to select the desired item you

want to adjust.

PC Setting

Hor Position

Ver Position

Clock

Phase

: Adjust

Press ◀ or ▶ to adjust the setting.

Hor Position: To adjust the horizontal position of

the image on the PC mode.

Ver Position: To adjust the vertical position of

the image on the PC mode.

Clock: To minimize any vertical bars

or stripes visible on the screen

Phase: This must be adjusted after the

After adjusting, press ENTER to return to the PC Setting menu. Then continue to adjust the

other items.

Press EXIT/CANCEL to return to the normal screen.

background.

frequency of the PC mode has been set to 60Hz to optimize picture quality (page 20).

TV operation

: Select ENTER:Set

: Adjust

50S0301A.indb 3550S0301A.indb 35 2/5/08 5:58:57 PM2/5/08 5:58:57 PM

TV operation

Sound control adjustment/ Selecting Stereo/Second Audio Program (SAP)

The multi-channel TV sound (MTS) feature provides high-fidelity stereo sound. MTS also can transmit a second audio program (SAP) containing a second language or other audio information. When the TV/DVD receives a stereo or SAP broadcast, the word “Stereo” or “SAP” displays on-screen every time you press DISPLAY.

ENTER

/ / /

EXIT/CANCEL MENU

Sound control adjustment

Press MENU in the TV mode. Press ▲ or ▼ to select “Audio” , then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select the item you want to adjust. Then press ◀ or ▶ to adjust each

setting.

Audio

Bass

Treble

Balance

MTS Stereo

Audio Language English HDMI Audio HDMI

: Select

Bass: Press ◀ or ▶ to adjust the bass sound. Treble: Press ◀ or ▶ to adjust the treble

sound.

Balance: Press ◀ or ▶ to obtain an equal sound

level from both speakers.

15 15

: Adjust

Selecting Stereo/Second Audio Program (SAP)

Press MENU in the TV mode. Press ▲ or ▼ to select “Audio”, then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “MTS”, then press ◀ or ▶ to select “Stereo”.

Audio

Bass

Treble

Balance

MTS Stereo

Audio Language English HDMI Audio HDMI

: Select

Press EXIT/CANCEL to return to the normal screen.

15 15

: Adjust

After you desired setting, press EXIT/CANCEL to return to the normal screen.

Note:

Generally you can leave your TV in stereo mode

• because the TV automatically outputs the type of sound being broadcast (stereo or mono). If the stereo sound is noisy, select “Mono” to reduce

• the noise.

To listen to a second audio program (SAP)

Press ◀ or ▶ to select “SAP” in step 2 above. The TV speakers will output the second audio program instead of normal audio.

50S0301A.indb 3650S0301A.indb 36 2/5/08 5:58:58 PM2/5/08 5:58:58 PM

Selecting the audio language/ Selecting the HDMI audio input source

When two or more audio languages are included in a digital signal, you can select one of the audio language. (This function is available only for digital broadcast.)

When you use PC AUDIO IN jacks with HDMI or DVI device, you must select HDMI audio input source from “HDMI” or “DVI”.

0-6

ENTER

/ / /

EXIT/CANCEL MENU

Selecting the audio language

Press MENU in the TV mode. Then press ▲ or ▼ to select “Audio” , then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “Audio Language”, then press ▶ or ENTER to display the Audio

Language menu.

Audio

Bass

Treble

Balance

MTS Stereo

Audio Language English HDMI Audio HDMI

: Select

15 15

ENTER:Set

Selecting the HDMI audio input source

Press MENU in the TV mode. Press ▲ or ▼ to select “Audio” , then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “HDMI Audio”. Then press ◀ or ▶ to select “HDMI” or “DVI”.

Audio

Bass

Treble

Balance

MTS Stereo

Audio Language No Info. HDMI Audio HDMI

: Select

15 15

: Adjust

TV operation

Press ▲/▼ or Number buttons (0-6) to select

your desired language.

Audio Language

0. English

1. Language 1

2. Language 2

3. French

4. Language 3

5. Spanish

6. No Info

[0-6]: Select

After you desired setting, press EXIT/CANCEL to return to the normal screen.

HDMI: When you connect the HDMI device to

the TV, select this setting.

DVI: When you connect the DVI device to the

TV with analog audio cords, select this setting.

Press EXIT/CANCEL to return to the normal screen.

50S0301A.indb 3750S0301A.indb 37 2/5/08 5:59:00 PM2/5/08 5:59:00 PM

TV operation

Using the aspect feature/ Adjusting the back lighting

When the Aspect feature is set to On and the TV receives a 480i signal, the picture size is automatically selected (as described in the following table).

The Backlight feature adjusts the screen brightness for improved picture clarity.

ENTER

/ / /

EXIT/CANCEL MENU

Adjusting the back lightingUsing the aspect feature

Press MENU in the TV mode. Press ▲ or ▼ to select “Setup” , then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “Aspect”. Press ◀ or ▶ to select “On” or “Off”.

Setup

Closed Caption >>

Language English

Video Label >>

Backlight Auto Shut Off Off

Aspect

Reset >>

: Select

After you desired setting, press EXIT/CANCEL to return to the normal screen.

Aspect ratio of signal

source

Automatic aspect size

(When Aspect is On)

4:3 Normal Natural

16:9 Full Full

4:3 Letter box Theater Wide2

Not deﬁ ned User-set mode

ENTER:Set

Press MENU in the TV mode. Press ▲ or ▼ to select “Setup” , then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “Backlight”.

Setup

Closed Caption >>

Language English

Video Label >>

Backlight Auto Shut Off Off

Aspect

Reset >>

: Select

Press ◀ or ▶ to adjust the setting.

Setup

Closed Caption >>

Language English

Video Label >>

Backlight Auto Shut Off Off

Aspect

Reset >>

: Select

After you desired setting, press EXIT/CANCEL to return to the normal screen.

ENTER:Set

50S0301A.indb 3850S0301A.indb 38 2/5/08 5:59:01 PM2/5/08 5:59:01 PM

Setting the Auto Shut Off/ Resetting your settings

If the Auto Shut Off feature is On, a station being viewed stops broadcasting and the TV is not operated, the TV will automatically shut itself off after 15 minutes.

The Reset function returns your settings to the factory settings.

Resetting your settingsSetting the Auto Shut Off

ENTER

/ / /

EXIT/CANCEL MENU

Press MENU in the TV mode. Press ▲ or ▼ to select “Setup” , then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “Auto Shut Off”. Press ◀ or ▶ to select “On” or “Off”.

Setup

Closed Caption >>

Language English

Video Label >>

Backlight Auto Shut Off Off

Aspect

Reset >>

: Select

After you desired setting, press EXIT/CANCEL to return to the normal screen.

ENTER:Set

Press MENU in the TV mode. Press ▲ or ▼ to select “Setup” , then press ▶ or ENTER.

Main Menu


Audio

Channel

Setup

: Select ENTER:Set

Press ▲ or ▼ to select “Reset”.

Press ▶ or ENTER to return your settings to

the factory settings.

Setup

Closed Caption >>

Language English

Video Label >>

Backlight Auto Shut Off Off

Aspect

Reset >>

: Select

TV operation

ENTER:Set

“Reset” will appear on the screen approx. 3

seconds, then it returns to the normal

Note:

The Reset function returns your adjustments to the

• following factory settings:

Picture Setting

Brightness ......center (25)

Contrast ............ max (50)

Sharpness......center (25)

Color ..............center (25)

Tint ...................center (0)

Color Temperature ...Cool

Picture Preference ....Sports

Film Mode .......................On

PC Setting

Hor Position ...center (25)

Ver Position....center (25)

Clock ................center (0)

Phase.............center (25)

Bass...................center (15)

Treble ................center (15)

Balance................center (0)

50S0301A.indb 3950S0301A.indb 39 2/5/08 5:59:03 PM2/5/08 5:59:03 PM

Basic playback

Playing a disc

This section shows you the basics on how to play a disc.

CAUTION

Keep your ﬁ ngers well clear of the disc slot when disc is loading or unloading. Neglecting to do so may cause serious personal injury.

DVD VCD

Basic playback

Preparations:

• When connecting to other equipment, turn the power off.

EJECT VOLUME +/–

PLAY STOP

POWER

TV/DVD

POWER

VOL

/–

ENTER

/ / /

PLAY STOP

Press POWER on the unit or on the remote control to turn on the unit.

• POWER indicator on the front of the unit changes green. It may take approx. 10 seconds for a picture to appear on screen.

• Every time you press POWER, the TV/DVD starts from TV mode.

• When using an ampliﬁ er, switch on the ampliﬁ er.

Press TV/DVD on the remote control to select DVD mode.

The DVD startup screen will appear on the TV screen.

Load a disc in the disc slot.

• Load the disc in the disc slot with the label side

facing forward. (If the disc has a label.) Hold the disc without touching either of its surfaces, align it with the guides, and place it in position.

• If a disc is inserted during some modes other than

DVD mode, it may switch to DVD mode and then playback may be begun automatically.

On the TV screen, “ ” changes to “Reading” and then playback commences.

Reading

A menu screen will appear on the TV screen if the disc has a menu feature.

Press select title, then press ENTER. Title is selected and play commences.

Press VOLUME + or – to adjust the volume.

Press STOP to end playback.

■ To start playback in the stop mode

Press PLAY.

Note: If the unit does not operate properly:

Static electricity, etc., may affect the TV/DVDʼs operation. In such case, disconnect the AC cord, then connect it again.

/ or / on the remote control to

Volume : 25

■ Resuming facility

• The unit records the stopped point, depending on the disc.

“ ” appears on the screen.

Press PLAY to resume playback (from the scene point).

• If you press STOP again

(“■” appears on the TV screen),

the unit will clear the stopped point.

50S0301A.indb 4050S0301A.indb 40 2/5/08 5:59:04 PM2/5/08 5:59:04 PM

To obtain a higher quality picture

Occasionally, some picture noise may appear on the TV screen while playing a

DVD video disc because the high resolution pictures on these discs include a lot of information. In such case, you may reduce the Sharpness with the Picture Setting menu (see page 32).

About

The

DVD VCD CD

icons on the heading bar show the playable discs for the

function described under that heading.

: You can use this function with DVD video discs.

VCD

: You can use this functio n with Video CDs.

: You can use this function with Audio CDs and CD-R/RW CDs.

DVD VCD

Basic playback (continued)

EJECT

PLAY STOP

PAUSE

To pause playback (still mode)

Press PAUSE during playback.

To resume normal playback, press PLAY.

• The sound is muted during still mode.

To remove the disc

Press EJECT.

Remove the disc after the disc comes out.

To stop playback

Press STOP.

Note:

• If a non-compatible disc is loaded, “Incorrect Disc”, “Region Code Error” or “Parental Error” will appear on the TV screen

according to the type of loaded disc. In this case, check your disc again (see pages 7 and 60).

• Some discs may take a minute or so to start playback.

• When you set a single-faced disc label downwards (ie. the wrong way up), “Reading” will appear on the display for a few

minutes and then “Incorrect Disc” will continue to be displayed.

• Some discs may not work the resuming facility.

• Resuming cannot function when you play a PBC-featured Video CD while the PBC is on. To turn off the PBC, see page 49.

• Some playback operations of DVDs may be intentionally ﬁ xed by software producers. Since this unit plays DVDs according

to the disc contents the software producers designed, some playback features may not be available. Also refer to the instructions supplied with the DVDs.

• Do not move the unit during playback. Doing so may damage the disc.

• Use the EJECT to unload and eject the disc.

• Do not put any objects other than discs on the disc slot. Doing so may cause the unit to malfunctions.

• In many instances, a menu screen will appear after playback of a movie is completed. Prolonged display of an on-screen

menu may damage your television set, permanently etching that image onto its screen. To avoid this, be sure to press

POWER on the remote control once the movie is completed.

• There may be a slight delay between the button is pressed and the function activates.

Basic playback

50S0301A.indb 4150S0301A.indb 41 2/5/08 5:59:06 PM2/5/08 5:59:06 PM

Basic playback

Playing a disc (Continued)

DVD VCD

Playing in fast reverse or fast forward directions

Press REV or FF during playback.

REV: Fast reverse playback FF: Fast forward playback

Each time you press REV or FF button, the playback speed changes.

DVD

Playing frame by frame

VCD

To resume normal playback

Press PLAY.

Note:

• The TV/DVD mutes sound during reverse and forward scan of DVD/VCD/Audio CD discs.

• The playback speed may differ depending on the disc.

• You can use fast reverse/fast forward playback for DivX® CD.

PAUSE PLAY

SKIP / REV / FF

SLOW /

Press PAUSE during still playback.

Each time you press PAUSE, the

To resume normal playback

Press PLAY.

picture advances one frame.

Note:

• The sound is muted during frame by frame playback.

• You can use frame by frame playback for DivX® CD.

DVD

Playing in slow-motion

VCD

Press SLOW (REVERSE) or (FORWARD) during playback.

To resume normal playback

Press PLAY.

Each time you press the button, the slow-motion speed changes.

DVD VCD

Locating a chapter or track

Note:

• The sound is muted during slow-motion playback.

• The Video CD cannot play Reverse Slow.

Press SKIP or repeatedly to display the chapter or track number you want.

Playback starts from the selected chapter or track.

To locate succeeding chapters or tracks.

Playback starts from the beginning of the current chapter or track. When you press twice in quick successions, playback starts from the beginning of the preceding chapter or track.

Note:

• A “Prohibition” symbol “✕” may appear at the upper right of the screen. This symbol means either the feature you tried is not available on the disc, or the TV/DVD cannot access the feature at this time. This does not indicate a problem with the

TV/DVD.

50S0301A.indb 4250S0301A.indb 42 2/5/08 5:59:07 PM2/5/08 5:59:07 PM

Advanced playback

Zooming/Locating desired scene

This unit will allow you to zoom in on the frame image. Y ou can then make selections by switching the position of the frame.

Use the title, chapter and time recorded on the DVD disc to locate the desired point to playback. In the case of VCD/Audio CD discs, time and track are used to locate the desired point to playback. To check the title/track, chapter/track and time, press DISPLAY.

DVD VCD

Zooming

DVD VCD

Locating desired scene

0–9 JUMP

DISPLAY ZOOM

/ / /

ENTER EXIT/CANCEL

Press ZOOM during playback.

Press / / / to view a different part of the frame.

In the zoom mode, press ZOOM repeatedly to return to a 1:1 view ( Off).

The center part of the image will be zoomed in. Each press of ZOOM will change the ZOOM and 3 (x 2.0).

1 (x 1.3), 2 (x 1.5)

You may move the frame from the center position to UP , DOWN, LEFT or RIGHT direction.

Press JUMP during playback or resume stop mode.

Jump

Title Chapter Time

Press or to select the “Title/T rack”, ter” or

“Time”

Press Number buttons (0–9) to input the number.

Jump

Title Chapter Time

“Chap-

Advanced playback

Jump

Titl e Chapter 12 Time

• If you input a wrong number, press EXIT/CANCEL.

• Refer to the package supplied with the disc to check the numbers.

Press ENTER. Playback starts.

Note:

• You can select the Pause, Slow or Search playback in the zoom mode.

• Some discs may not respond to zoom feature.

• Zoom function can be used for DivX® CD.

Note:

• In case of the Audio CD and Video-CD, only Track and Time

can be selected.

• In case of the Video-CD playback with PBC, the JUMP does not work. To turn off PBC, see page 49.

• Only Time search function can be used for DivX® CD.

• When you change the title, playback starts from Chapter 1 of the selected title.

• Some discs may not work in the above operation.

50S0301A.indb 4350S0301A.indb 43 2/5/08 5:59:08 PM2/5/08 5:59:08 PM

Advanced playback

Marking desired scenes

The unit stores the points that you want to watch again up to 3 points. You can resume playback from each scene.

ENTER

EXIT/CANCEL

MARKER

DVD

Marking the scenes

VCD

Press MARKER during playback.

Select the blank Marker using or . Then press ENTER to mark the desired scene.

• Repeat this procedure to mark the other 2 scenes.

Press MARKER to clear the display.

Note:

• Some discs may not work with the marking operation.

• The marking is cancelled when you eject the disc or turn the power off.

• Some subtitles recorded around the marker may fail to

appear.

• In case of Video CD with PBC, Marker function is prohibited.

DVD

Returning to the scenes

VCD

Press MARKER during playback or stop mode.

Press or to select the Marker 1-3.

Press ENTER.

Playback starts from the marked scene.

■ To cancel the Marker

Follow the above steps 1~2, then press EXIT/CANCEL.

50S0301A.indb 4450S0301A.indb 44 2/5/08 5:59:09 PM2/5/08 5:59:09 PM

Repeat playback/A-B Repeat playback

PLAY MODE ENTER

PLAY SKIP /

REPEAT A-B

DVD

Repeat playback

VCD

Press PLAY MODE during playback or stop mode.

[DVD] Press ENTER repeatedly to select “Chapter”

or “Title”.

The unit automatically starts repeat playback after ﬁ nishing the current title or chapter.

Play Mode

Repeat : Off

[Video CD] Press Press ENTER repeatedly to select “Track” or “All”.

to select “Repeat”.

The unit automatically starts repeat playback after ﬁ nishing the current track.

Play Mode

Mode : Off

Repeat : Off

DVD VCD

A-B Repeat playback

A-B repeat playback allows you to repeat a section between two selected points.

Press REPEAT A-B during playback.

Press REPEAT A-B again.

The start point is selected.

The end point is selected. Playback starts at the point that you selected. Playback stops at the end point and returns to point A automatically, then starts again.

Advanced playback

• If you set the repeat mode during stop mode, press PLAY to start Repeat playback.

Press PLAY MODE again to clear the screen.

To resume normal playback

Select Repeat : “Off” in step 2.

Note:

• Some discs may not work with the repeat operation.

• In case of Video CD with PBC, Repeat function is prohibited during playback.

• Chapter/Track repeat function is canceled whenever SKIP

or is pressed.

To resume normal playback

Press REPEAT A-B again. “

Note:

• In A-B Repeat mode, subtitles near the A or B locations may not be displayed.

• You cannot set the A-B Repeat for the scenes that include multiple angles.

• A-B Repeat playback does not work when Repeat playback is activated.

• You may not be able to set A-B Repeat during certain scenes of the DVD.

• A-B Repeat does not work with an interactive DVD and MP3/WMA/JPEG CD.

• In case of Video CD with PBC, A-B Repeat is prohibited.

” appears on the screen.

Off

50S0301A.indb 4550S0301A.indb 45 2/5/08 5:59:10 PM2/5/08 5:59:10 PM

Advanced playback

Program playback/Random playback

You can arrange the playback order of tracks on the disc. And the unit can also select tracks at random and playback them. These features work for Video CD.

For Audio CD and MP3/WMA CD, please see “Random playback” (Audio CD/MP3/WMA/JPEG/DivX (Audio CD/MP3/WMA/JPEG/DivX®) 55.

VCD

Program playback

) 54 and “Program playback”

0–9

PLAY MODE ENTER

/ / /

EXIT/CANCEL PLAY

Press PLAY MODE in the stop mode.

Mode : Off

Repeat : Off

Play Mode

Program Playback

Press or to select “Mode”, then press ENTER repeatedly to select “Program”.

Mode : Program

Repeat : Off

Play Mode

Program Playback

Press / to select the programming position. Press

to input the track.

/ and then use

To program others, repeat this step.

•

Number buttons (0–9)

• If you input a wrong number, press EXIT/CANCEL.

Play Mode

Program Playback

VCD

Random playback

Mode : Program Repeat : Off

1 – – – 2 – – – 3 – – –

1 9

2 – – – 3 – – –

Press press

and press ENTER.

to return to the left column, then

to select the “Program Playback”

The programs you selected will start to playback in order.

• To resume normal playback, select Mode: “Off” in step 2.

Mode : Program Repeat : Off

■ To change the program

1. Select Mode to “Program” (as step 2), press to select the track number you want to change, then press EXIT/CANCEL.

2. Press Number buttons (0–9) to input the new track number.

■ To clear the program one by one

Select Mode to “Program”, press

track number. Then press EXIT/CANCEL.

■ To clear all the programs

At the left column, press

Then press ENTER.

Note:

• In playing back the Video CD with PBC, you cannot set

Program playback.

• The program is cancelled when you eject the disc or turn the

power off.

Play Mode

Program Playback

/ / /

to select “Clear Program”.

to select the

1 9 2 3 3 11

Press PLAY MODE during playback or stop mode.

Press PLAY

The Random Playback will start.

• If you set “Random” during playback mode,

Press / to select “Mode”, then press ENTER repeatedly to select “Random”.

Random playback will begin after the track that is currently being played has ended.

• To resume normal playback,

Mode : Random

Repeat : Off

Play Mode

Program Playback

1 – – – 2 – – – 3 – – –

select Mode: “Off” in step 2.

Note:

• In case of Video CD with PBC, you cannot set Random function during playback.

• The random playback is cancelled when you eject the disc or turn the power off.

50S0301A.indb 4650S0301A.indb 46 2/5/08 5:59:11 PM2/5/08 5:59:11 PM

Changing angles/Title selection/DVD menu

DVD MENU

/ / / ENTER PLAY

ANGLE TOP MENU

Changing angles

When playing back a disc recorded with multi-angle facility, you can change the angle that you are viewing the scene from.

Press ANGLE during playback.

The current angle will appear.

1/2

Press ANGLE repeatedly until the desired angle is selected.

Note:

• Depending on the DVD, you may not be able to change the angle even if multi-angles are recorded on the DVD.

Title selection

Two or more titles are recorded on some discs. If the title menu is recorded on the disc, you can select the desired title.

Press TOP MENU during playback.

Press / / / to select the desired title.

Title menu appears on the screen.

Press ENTER or PLAY.

The playback of the selected title will start.

Note:

•

Depending on the DVD, you may not be able to select the title.

•

Depending on the DVD, a “title menu” may simply be called a

“menu” or “title” in the instructions supplied with the disc.

Advanced playback

DVD menu

Some DVDs allow you to select the disc contents using the menu. When you playback these DVDs, you can select the subtitle language, soundtrack language, etc, using the menu.

Press DVD MENU during playback.

Press

The DVD menu appears on the TV screen.

• Press DVD MENU again to resume playback at the scene when you pressed DVD MENU.

/ / / to select the desired item.

Press ENTER.

Note:

• Depending on the DVD, you may not be able to resume

playback from the scene point when you press DVD MENU.

The menu continues to another screen. Repeat steps 2 and 3 to set the item completely.

50S0301A.indb 4750S0301A.indb 47 2/5/08 5:59:12 PM2/5/08 5:59:12 PM

Advanced playback

Changing soundtrack language/Subtitles

DVD

Changing soundtrack language

VCD

You can select the language when you play a multilingual disc.

Press AUDIO SELECT during playback.

Press AUDIO SELECT repeatedly until the desired language is selected.

The current soundtrack language will appear.

1/2 Eng Dolby Digital

2/2 Fre Dolby Digital

Subtitles

When playing back a disc recorded with subtitles, you can select the subtitle language or turn the subtitle off.

Press SUBTITLE repeatedly during playback until the desired language is selected.

To turn off the subtitle, press SUBTITLE until “Off” appears.

AUDIO SELECT SUBTITLE

1/5 Eng

Off

• The on screen display will disappear after a few seconds.

In case of Video CD playback

Audio type changes as follows each time you press AUDIO SELECT.

LR L R

Note:

• If the desired language is not heard after pressing the button several times, the language is not recorded on the disc.

• The selected soundtrack language is cancelled when

you eject the disc. The initial default language or available language will be heard if the disc is played

back again.

• If you select DTS in playing DTS-encoded disc, no sound will be heard from the TV/DVDʼs speakers.

• The on screen display will disappear after a few seconds.

Note:

• Depending on the DVD, you may not be able to change subtitles, or to turn subtitles on or off.

• While playing a DVD, the subtitle may change when you loaded or eject the disc.

• In some cases, a selected subtitle language may not be changed immediately.

50S0301A.indb 4850S0301A.indb 48 2/5/08 5:59:13 PM2/5/08 5:59:13 PM

Disc status/To turn off the PBC

DISPLAY

PLAY MODE

ENTER

DVD

Disc status

VCD

With press of DISPLAY, the status of the disc will appear on the screen. To cancel the display, press DISPLAY again.

DVD

DISC OPERATION

TITLE NO.

ANGLE NO.

AUDIO LANGUAGE A KIND OF AUDIO

DVD 00:15:25 01:41:39 Title 1/3 Chapter 2/24

1/1 Eng Dolby Digital 1/2 Eng 1/1

ELAPSED TIME

TOTAL TIME

SUBTITLE LANGUAGE

CHAPTER NO.

Video CD

DISC OPERATION

ELAPSED TIME

TOTAL TIME

VCD

To turn off the PBC (see page 8)

Press PLAY MODE in the stop mode.

Press / to select “Mode”, then press ENTER repeatedly until “Off” appear.

Mode : Off

Repeat : Off

Play Mode

Program Playback

1 – – – 2 – – – 3 – – –

Press PLAY MODE again to clear the screen.

■ To turn on the PBC

Follow the above steps 1~2, then press ENTER repeatedly until “PBC” appear.

Advanced playback

VCD 00:08:32 00:51:03 Track 3/15

TRACK NO.

50S0301A.indb 4950S0301A.indb 49 2/5/08 5:59:14 PM2/5/08 5:59:14 PM

Advanced playback

MP3/WMA/JPEG/DivX® and Audio CD operation

This unit can playback the MP3/WMA/JPEG/DivX®-data which has been recorded on CD-R or CD-RW. To produce the MP3/WMA/JPEG/DivX®-data, you need a Windows-PC with CD-RW drive and a MP3/WMA/JPEG/DivX®-encoding Software (not supplied). The Apple-HFS-System cannot be played.

This player requires discs/recordings to meet certain technical standards in order to achieve optimal playback quality. There are many different types of recordable disc formats (including CD-R containing MP3/WMA ﬁ les). Not all recordable discs will produce optimal playback quality. The technical criteria set forth in this ownerʼs manual are meant only as a guide. Use of CD-RW for MP3 ﬁ les is not recommended.

You must obtain any required permission from copyright owners to download or use copyrighted content. Toshiba cannot and does not grant such permission.

Audio CD/MP3/WMA/JPEG/DivX® CD information

Limitations on MP3/WMA/JPEG/DivX® CD playback

• MP3/WMA/JPEG/DivX letters, “.mp3”, “.wma”, “.jpg”, “.div”, “.divx”, “.avi”.

• MP3/WMA/JPEG/DivX

CD is the disc that is standardized by ISO9660, its ﬁ le name must include 3-digits extension

CD must be correspond to the ISO standardized ﬁ les.

• This unit can read 2000 ﬁ les per disc. If one disc has more than 2000 ﬁ les, it reads up to 2000 ﬁ les, the remaining ﬁ les will be omitted.

• MP3/WMA/JPEG/DivX

• If the CD has both audio tracks and MP3/WMA/JPEG/DivX

• It may take more than one minute for this unit to read MP3/WMA/JPEG/DivX

CDs cannot be used for the purpose of recording.

ﬁ les, only audio tracks will be played.

ﬁ les depending on its structure.

• Music recorded by “Joliet Recording Speciﬁ cation” can be played back, the ﬁ le name is displayed (within 15 letters) on the screen. Long ﬁ le names will be condensed.

• The music ﬁ les recorded by “Hierarchical File System” (HFS) cannot be played.

Limitations on display

• The maximum number for display is 15 letters.

Available letters for display are the following: capital or small alphabets of A through Z, numbers of 0 through 9, and _ (under score).

• Other letters than those above are replaced in hyphen.

Notes on MP3/WMA/JPEG/DivX

To playback MP3/WMA/JPEG/DivX

1. Use MP3/WMA/JPEG/DivX

ﬁ les

CD in the recorded order,

software that records data alphabetically or numerically.

2. Name each ﬁ le including two-digit or three-digit number (ex. “01” “02” or “001” “002”).

3. Refrain from making too many sub-folders.

CAUTION:

• Some MP3/WMA/JPEG/DivX

• The CD-R/RW that has no music data or non MP3/WMA/JPEG/DivX

CDs cannot be played back depending on the recording conditions.

ﬁ les cannot be played back.

Standard, sampling frequency and the bit rate:

MP3 CD MPEG-1 Audio 32kHz, 44.1kHz, 48kHz 32kbps ~ 320kbps (constant bit rate or variable bit rate) The recommend recording setting for a high-quality sound is 44.1kHz of sampling frequency and 128kbps of constant

bit rate.

WMA CD WMA version 7 and 8 32kHz/48kbps, 44.1kHz/48kbps~192kbps, 48kHz/128kbps~192kbps The ﬁ le recorded by mono, 48kHz, 48 kbps is not available to this unit.

DivX

video

DivX

version: DivX® 3, 4, 5, and 6 (speciﬁ cally 3.1.1, 4.1.2, 5.0.2, 5.0.5, 5.1.1, 5.2.1, 6.0 at Home Theater proﬁ le). Audio format: MPEG1 Layer2 (MP2), MPEG1 Layer3 (MP3) Sampling frequencies: 32kHz, 44.1kHz, 48kHz Bit rate: 32kbps ~ 320kbps Resolution: Max 720 x 576 (at 25fps), Max 720 x 480 (at 30fps)

Microsoft, Windows Media, and Windows Logo are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. DivX, DivX Certiﬁ ed, and associated logos are trademarks of DivX, Inc. and are used under license.

50S0301A.indb 5050S0301A.indb 50 2/5/08 5:59:15 PM2/5/08 5:59:15 PM

MP3/WMA and Audio CD playback

/ / /

ENTER STOP

PLAY RETURN

Load an Audio CD or a disc on which MP3 or WMA ﬁ les have been recorded in the disc

slot.

A ﬁ le browser screen will appear on the screen.



      

Press

/ to select ﬁ le.

/MP3-2.MP3

Folder-1 Folder-2 MP3-1

MP3-2

MP3-3 WMA-1 WMA-2 WMA-3

• In case the current directory includes more than 8 ﬁ les, press

or to scroll in the ﬁ le list.

• To see contents in folder, select the folder and then press ENTER. To return to the parent directory, press RETURN or select “

Go Up ...” then press ENTER.

• When PLAY is pressed after the ﬁ le browser displayed, playback begins automatically starting from the ﬁ rst ﬁ le. In this case, if the ﬁ rst ﬁ le is an MP3/WMA ﬁ le, only MP3/WMA ﬁ les are played back in order. If the ﬁ rst ﬁ le is a JPEG ﬁ le, the ﬁ rst JPEG

ﬁ le is played back. If the ﬁ rst ﬁ le is a DivX ﬁ rst DivX

ﬁ le is played back. If there is no ﬁ le at a

root directory, playback does not begin automatically.

Press ENTER.

The selected ﬁ le starts playing back.

Press STOP to end playback.

     

 

Select Files Repeat :Off Mode :Off

JPEG Preview

ﬁ le, the

About ﬁ le menu

3/15 00:00:00

/WMA-11.WMA

MP3-5 MP3-6

WMA-11

WMA-12 Picture-1 Picture-2 Movie-1 Movie-2

Select Files Repeat :Off Mode :Off

Music Playing

Note:

• In the case of a CD containing a mixture of MP3, WMA, JPEG and DivX® ﬁ les, the ﬁ les are played back by selecting them from the ﬁ le browser.

• MP3 or WMA ﬁ le on the Kodak Picture CD is not recognized on this unit.

Note:

• During MP3/WMA playback, you cannot use Jump and A-B Repeat functions.

• You can use Repeat (Track or All), Random functions and Program playback for Audio CD/MP3/WMA/JPEG/DivX® playback 54 55.

■ Select Files

The ﬁ le type to make it display in the ﬁ le browser can be chosen.

1.Press or to highlight “Select Files” at right column

in the ﬁ le browser.

2. Press ENTER, then press or to select ﬁ le type

from the list (Music, Picture or Movie).

3. Press ENTER to add/remove check mark. Checked

ﬁ le type will be displayed in the ﬁ le browser.

4. Press RETURN to save the setting.

Advanced playback

• The unit records the stopped point. “ ” appears on the TV screen. Press PLAY to resume playback (from the scene point).

• If you press STOP again or unload the disc, the unit will clear the stopped point.

50S0301A.indb 5150S0301A.indb 51 2/5/08 5:59:15 PM2/5/08 5:59:15 PM

Advanced playback

MP3/WMA/JPEG/DivX® and Audio CD operation (Continued)

ZOOM DVD MENU

ENTER

/ / /

PAUSE STOP PLAY

SKIP ANGLE TOP MENU

JPEG playback

Load a JPEG disc in the disc slot.

A ﬁ le browser screen will appear on the

screen.

Press / to select the ﬁ le. To display a thumbnail list, press DVD MENU.

Press (To return to the ﬁ le browser, press TOP MENU.)

• When PLAY is pressed after the ﬁ le browser

Press ENTER or PLAY. The selected picture appears on the screen.

Rotating an image

You can rotate an image by 90 degrees. Press ANGLE during playback of the image.

“ ”, “ ”, “ ” or “ ” appears on the screen.

Zooming an image

Zoom function also can be used in viewing JPEG

ﬁ les. Press ZOOM (See “Zooming”

/ / / to select the desired ﬁ le.

displayed, playback begins automatically starting from the ﬁ rst ﬁ le. In this case, if the ﬁ rst ﬁ le is a JPEG ﬁ le, the ﬁ rst JPEG ﬁ le is played back. If the ﬁ rst ﬁ le is a DivX ﬁ rst DivX is an MP3/WMA ﬁ le, only MP3/WMA ﬁ les are played back in order. If there is no ﬁ le at a root directory, playback does not begin automatically.

ﬁ le is played back. If the ﬁ rst ﬁ le

/Picture-01.JPG

Picture-01

Picture-02 Picture-03 Picture-04 Picture-05 Picture-06 Picture-07 Picture-08

Select Files Repeat :Off Mode :Off

JPEG Preview

W: 2048 H: 1536

ﬁ le, the

Slide show playback

The slide show enables you to view pictures (ﬁ les) one after another automatically.

Preparation:

• Set “JPEG Interval” setting to “5 Seconds”, “10 Seconds” or “15 Seconds”

Select your desired starting ﬁ le for the slide show in the step 3 on left.

Press ENTER or PLA Y to start slide show from the selected ﬁ le.

• If you press PAUSE during the slide show, the slide

show stops temporary. “ screen.

Press PLAY or SKIP again to resume the slide

show.

• If the picture appears upside down or sideways,

press ANGLE repeatedly until itʼs right side up.

”, “ ”, “ ” or “ ” appears on the TV screen.

“

• When the slide show playback ﬁ nished, the ﬁ le list

appears.

• T o stop the slide show, press STOP. The ﬁ le browser

appears.

Note:

• During JPEG playback, you cannot use Jump and A-B

Repeat functions.

• When an image exceeds 5760 x 3840 pixels, the entire

image may not be displayed on a screen, preview window or thumbnail list.

• It may have a longer interval due to the size of data.

❙❙” appears brieﬂ y on the TV

Press STOP to end playback.

The ﬁ le browser appears on the screen. If you want to watch the other ﬁ le, repeat steps 3 ~ 4.

50S0301A.indb 5250S0301A.indb 52 2/5/08 5:59:16 PM2/5/08 5:59:16 PM

ENTER

/ STOP PLAY

DivX® playback

Load a disc on which DivX® ﬁ les have been recorded in the disc slot.

A ﬁ le browser screen will appear on the TV screen.

Press / to select ﬁ le.

/Movie-01.DIVX

Movie-01

Movie-02 Movie-03 Movie-04 Movie-05 Movie-06 Movie-07 Movie-08

• When PLAY has been pressed after the

ﬁ le browser displayed, playback begins automatically starting from the ﬁ rst ﬁ le. In this case, if the ﬁ rst ﬁ le is a JPEG ﬁ le, the ﬁ rst JPEG

ﬁ le is played back. If the ﬁ rst ﬁ le is a DivX ﬁ le, the ﬁ rst DivX ﬁ rst ﬁ le is an MP3/WMA ﬁ le, only MP3/WMA ﬁ le are played back in order. If there is no ﬁ le

at a root directory, playback does not begin automatically.

ﬁ le is played back. If the

Select Files Repeat :Off Mode :Off

JPEG Preview

Playing DivX® VOD content

DivX® VOD content is protected by DRM (Digital Rights Management) system. This restricts playback of content to speciﬁ c registered devices.

If the incorrect DRM ﬁ le is loaded, “Authorization Error This player is not authorized to play this video.” will appear on the screen. When you attempt to play

VOD, the number

DivX of plays is limited and the right message will appear on the screen. If you wish to play it, select “Yes”.

• If the number of plays goes over the limit, then “Rental Expired” will be displayed. In this case, the ﬁ le will not be played.

Note:

• In order to play DivX need to register the unit with registration code. See page

• Depending on the recording conditions of DivX may not be able to use FF, REV or JUMP function.

VOD content on this unit, you ﬁ rst

View DivX® VOD Rental

This rental has 5 views left.

Do you want to use one

of your 5 views now?

NoYes

ﬁ le, you

Advanced playback

Press ENTER or PLAY. The selected DivX® movie will be played back on the TV screen.

Press STOP to end playback.

• The unit records the stopped

point. “ screen. Press PLAY to resume playback (from the scene

point).

• If you press STOP again or un load the disc, the unit will clear the stopped point. To want to watch the other ﬁ le, repeat steps

3 ~ 4.

50S0301A.indb 5350S0301A.indb 53 2/5/08 5:59:17 PM2/5/08 5:59:17 PM

” appears on the TV

Advanced playback

F F M M

Repeat, random and program playback using file browser

CD CD

Repeat playback (Audio CD/

MP3/WMA/JPEG/DivX

)

Random playback (Audio CD/ MP3/WMA/JPEG/DivX

/ / / ENTER PLAY

SKIP /

)

In the ﬁ le browser, press / / / to select “Repeat” during stop mode.

older-1 older-2

P3-1 P3-2

Press ENTER repeatedly to select “Track” or “All”.

2 2

older-1 older-2

P3-1 P3-2

Press PLAY.

To resume normal playback

Select Repeat : “Off” in step 2.

The unit automatically starts repeat playback after ﬁ nishing the current track.

Select Files Repeat :Off Mode :Off

Select Files

Repeat :Track Mode :Off

Select Mode : “Off” in step 2.

In the ﬁ le browser, press / / / to select “Mode” during stop mode.

   

Press ENTER to select “Random”.

   

Press PLAY.

To resume normal playback

The random playback will start.

     

     !"

Note:

• The repeat function is cancelled when you eject the disc or turn the power off.

• Track repeat function is canceled whenever SKIP or

is pressed.

• The function of A-B Repeat can be used for DivX® CD. See

“A-B Repeat playback” 45.

Note:

• The random function is cancelled when you eject the disc or turn the power off.

50S0301A.indb 5450S0301A.indb 54 2/5/08 5:59:18 PM2/5/08 5:59:18 PM

Program playback (Audio CD/MP3/WMA/JPEG/DivX®)

Press

In the ﬁ le browser, press / / / to select “Edit Mode”, then press ENTER.

ENTER. Program View shows only the

programmed ﬁ les that you have added in step 2.

to select “Program View”, then press

/ / /

ENTER PLAY

Folder-1 Folder-2 MP3-1 MP3-2

Repeat :Off Mode :Off

When “Edit Mode” is black color, you can mark the ﬁ les which you want to add into Program list.

Press

/ / /

add into the program list.

to select ﬁ le you want to

Folder-1 Folder-2

MP3-1

MP3-2 MP3-3 WMA-1

Press ENTER. Selected ﬁ le was marked. Repeat this procedure to select the other ﬁ les.

Press

/ / /

Then press ENTER. All marked ﬁ les are added

into the program list.

to select “Add To Program”.

Folder-1 Folder-2 MP3-1 MP3-2 MP3-3 WMA-1

Add To Program

JPEG Preview

When you ﬁ nish storing the ﬁ les which you want into the Program list, select “Edit Mode” and press ENTER to release edit mode.

Edit Mode

Repeat :Off Mode :Off

Edit Mode

JPEG Previe

Edit Mode

Program View

MP3-1 MP3-2 MP3-3 WMA-3

Edit Mode Browser View Clear Program

JPEG Preview

Program View

Browser View

Folder-1 Folder-2 MP3-1 MP3-2 MP3-3 WMA-1 WMA-2 WMA-3

Edit Mode Program View

Add To Program

JPEG Preview

In the Program View, press PLAY. The ﬁ les start to playback in programed order that were

added by you.

To remove ﬁ le from program list in stop mode

In the Edit Mode, switch to Program View. Select ﬁ le

you want to remove, then press ENTER. Select “Clear Program” and press ENTER. Marked ﬁ le is removed from program list.

Note:

•

The program function is cancelled when you eject the disc or turn the power off.

Advanced playback

50S0301A.indb 5550S0301A.indb 55 2/5/08 5:59:19 PM2/5/08 5:59:19 PM

Function setup

Customizing the function settings

You can change the default settings of the DVD mode to customize performance to your preference. Press TV/DVD on the remote control to select DVD mode.

DVD VCD

Setting procedure

TV/DVD

/ / /

ENTER SETUP

RETURN

Press SETUP during stop mode.

The following on-screen display appears.

Parental : Off

DRC : Off

E.B.L. : Off

Menu : English Set Password

QSound : On

TV Screen : 4:3

Subtitle : English Output : Interlace

Display : On

Audio : English DivX(R) VOD

Picture Mode : Auto JPEG Interval : 5 Seconds Screen Saver : On

Press or to select the desired section, then press

First option will be highlighted. Press to select the desired option.

or .

Parental : Off

DRC : Off

Menu : English

TV Screen : 16:9 Set Password

QSound : On

Subtitle : English

Display : On Output : Interlace

Audio : English

Picture Mode : Auto DivX(R) VOD

JPEG Interval : Off

Parental : Off

DRC : Off

Menu : English

TV Screen : 16:9

Set Password

QSound : On

Subtitle : English

Display : On Output : Interlace

Audio : English

Picture Mode : Auto DivX(R) VOD

JPEG Interval : Off

Then press or ENTER. The selectable settings will appear.

Parental : Off

DRC : Off

Menu : English

TV Screen 4:3

Set Password

QSound : On

Subtitle : English

Display Output : Interlace

Audio : English

Picture Mode : Auto DivX(R) VOD

JPEG Interval : Off

Change the selection using or , by referring to the corresponding pages 57 ~ 60.

Press ENTER to save the setting.

• Repeat steps 3, 4 and 5 to

change other option.

• To select another section, go

back to step 2 by pressing repeatedly.

To clear SETUP screen, press SETUP once or press RETURN repeatedly.

4:3 16:9

50S0301A.indb 5650S0301A.indb 56 2/5/08 5:59:20 PM2/5/08 5:59:20 PM

Setting details

Section Option Details Page

Menu Subtitle Audio

TV Screen

Display

Picture Mode JPEG Interval To select a preferred setting for the slide show playback.

Night Mode To select On or Off for Night Mode.

Digital Out

Parental Password To change the password. DivX(R) VOD To display your 8-character registration code.

To select the language of “Menu”, “Subtitle” and “Audio” if more than one language are available on the disc.

To select a picture size according to the aspect ratio of your TV .

To turn On or Off the operational status display on the TV screen.

To select a preferred picture mode from “Video”, “Film” or “Auto”.

To select a digital output sound format corresponding to your system connection.

To select a preferred parental level for the parental setting.

Function setup

50S0301A.indb 5750S0301A.indb 57 2/5/08 5:59:21 PM2/5/08 5:59:21 PM

Function setup

Customizing the function settings (Continued)

Setting details

Parental : Off

DRC : Off

E.B.L. : Off

Menu : English Set Password

QSound : On

TV Screen : 4:3

Subtitle : English Output : Interlace

Display : On

Audio : English DivX(R) VOD

Picture Mode : Auto JPEG Interval : 5 Seconds Screen Saver : On

Parental : Off

DRC : Off

Menu : English

TV Screen : 16:9 Set Password

QSound : On

Subtitle : English

Display : On Output : Interlace

Audio : English

Picture Mode : Auto DivX(R) VOD

JPEG Interval : Off

Menu, Subtitle, Audio

You can select the language of “Menu”, “Subtitle” and “Audio” if more than one languages are recorded onto the disc.

English, Francais, Espanol:

The selected language will be heard or seen.

Other:

Other language can be selected (see “Language code list”

Original (Audio):

The unit will select the ﬁ rst priority language of each disc.

Off (Subtitle):

Subtitles do not appear.

Note:

• If the selected language is not recorded on the disc, the ﬁ rst-priority language is selected.

• If you want to change the OSD language, you can perform

it by “Language” in the TV menu

TV Screen

You have the following screen sizes to choose from:

4:3

(Letter box):

When playing back a wide screen-DVD disc, it displays the wide picture with black bands at the top and bottom of screen.

4:3

(Pan & scan):

It displays the wide picture on the whole screen with left and right edges automatically cut off.

16:9

(Wide):

A wide screen picture is displayed full size.

Note:

• If the DVD disc is not formatted in the Pan & scan style, it will display 4:3 style.

Display

On screen display can be switched on or off when you press any buttons.

Off: On screen displays do not appear when you

press any buttons. On: On screen displays appear when you press the buttons (factory setting).

50S0301A.indb 5850S0301A.indb 58 2/5/08 5:59:22 PM2/5/08 5:59:22 PM

Setting details (continued)

Picture Mode

There are two types of source content in pictures recorded in DVD video discs: ﬁ lm content (pictures recorded from ﬁ lms at 24 frames per second) and video content (video signals recorded at 30 frames per second). Make this selection according to the type of content being viewed.

Auto: Select this selection normally. The DVD player automatically detects

source content, ﬁ lm or video of playback source, and converts that signal in an appropriate method.

Film: The DVD player converts ﬁ lm content

pictures appropriately. Suitable for playback of ﬁ lm content pictures.

Video: The DVD player ﬁ lters video signal and

converts it appropriately.

Suitable for playback of video content

pictures.

Note:

• Depending on the disc, pictures may be cut off or doubled. In this case, select “Video”.

JPEG Interval

You can continuously playback all JPEG ﬁ les automatically. After the selection below, the disc will start playback on JPEG ﬁ les which have been recorded.

Off:

Plays back one ﬁ le at a time.

5 Seconds:

Plays back images in the form of a slide show at 5 second intervals.

Parental : Off

Menu : English

E.B.L. : Off

Night Mode : Off

Set Password

Subtitle : English

TV Screen : 4:3

Digital Out : Bitstream

Output : Interlace

Audio : English

Display : On

DivX(R) VOD

Picture Mode : Auto

JPEG Interval : 5 Seconds

Screen Saver : On

■ Night Mode

Night Mode enables you to control the dynamic range so as to achieve a suitable sound for your equipment.

Off: It plays back at the recording level on the disc.

On: Loud sound such as explosion is toned down

slightly when played back. This is suitable when it is connected to a stereo.

Note:

This function works only when the disc recorded with

• Dolby Digital is played back. The level of Night Mode may differ depending on DVD

• video disc.

■ Digital Out

You can select the digital output sound format corresponding

our system connection.

to y

Off:

Ther

e is no sound output from DIGITAL AUDIO OUT

jack.

PCM:

Change Dolby Digital to PCM for the output. Select when connected to a 2 channel digital stereo amplifier.

Bitstream:

Disc audio bitstream data will be output.

Note:

Even if you select “Bitstream”, MPEG Audio will be output

• in PCM format.

Function setup

10 Seconds:

Plays back images in the form of a slide show at 10 second intervals.

15 Seconds:

Plays back images in the form of a slide show at 15 second intervals.

50S0301A.indb 5950S0301A.indb 59 2/5/08 5:59:22 PM2/5/08 5:59:22 PM

Function setup

Customizing the function settings (Continued)

Setting details (continued)

DRC : Off

Menu : English

E.B.L. : Off

Parental : Off QSound : On

Subtitle : English

TV Screen : 4:3

Password : Change Audio : English

Display : On

DivX(R) VOD : Display Picture Mode : Auto JPEG Interval : 5 Seconds Screen Saver : On

Parental control setting

Some discs are speciﬁ

ed as not suitable for children.

Such discs can be limited not to playback with the unit.

1) Press

or to select “Parental”, then press

ENTER. “Enter Password” screen will appear.

2) Press “0000” using Number buttons (0–9). (Please note, this is pre-setting password of this unit). Then press ENTER. The parental level list will appear.

• Level Off: The parental control setting does not

function.

• Level 8: Virtually all DVD software can be

played back.

• Level 1: DVD software for adults cannot be

played back.

3) Press

or to select from the level 1 to level 8. The limitation will be more severe as the level number is lower. Then press ENTER.

Note:

• Depending on the discs, the unit cannot limit

playback.

• Some discs may not be encoded with speciﬁ c rating level information though its disc jacket says “adult.” For those discs, the age restriction will not work.

• The password is required every time when you

change the parental level.

• If you input a wrong number, press EXIT/CANCEL.

■ Set the new password

1) Press

or to select “Password”, then press ENTER. “Enter Current Password” screen will appear.

2) Press Number buttons (0–9) to input the current password (If the password has not been set yet after you purchase this unit, it is “0000”).

3) Then press ENTER. “Enter New Password” screen will appear. Press Number buttons (0–9) to input the new password.

4) Press ENTER. Now your new password has been set. Be sure to remember this number!

If you forget the password

1) Press EJECT to remove the disc.

2) While holding 7 down on the remote control and

then press STOP on the unit. “Password Clear” appears on the screen. Now the password has been returned to the initial value (“0000”).

■ DivX

In order to play DivX on this unit, you ﬁ rst need to register the unit with your DivX a DivX

VOD

VOD (Video On Demand) content

VOD content provider. You do this by generating

VOD registration code, which you submit to

your provider.

Press

or to select “DivX(R) VOD”. Then press

ENTER. Your 8-character registration code is

displayed. Make a note of the code as you will need

it when you register with a DivX

VOD provider.

Then press ENTER to select Done.

Note:

• If each setup (pages 58 ~ 60) has completed, the unit can always work under the same condition (especially with DVD discs).

Each setup will be retained in the memory even if you turn

the power off.

50S0301A.indb 6050S0301A.indb 60 2/5/08 5:59:22 PM2/5/08 5:59:22 PM

Temporary cancel the rating level by DVD disc

Depending on the DVD disc, the disc may try to temporarily cancel the rating level that you have set. It is up to you to decide whether to cancel the rating level or not.

DVD

Temporary cancel the rating level by DVD disc

EJECT 0–9

ENTER

RETURN

Load a DVD disc.

If the DVD disc has been designed to temporarily cancel the Rating level, the screen

which follows the “Reading” screen will change, depending on which disc is played. If you select “YES” with the ENTER key, password input screen will then appear.

• If “NO” is selected, press EJECT to remove the disc.

Enter the password with Number buttons (0–9). Then press ENTER.

To exit from the entry, press RETURN.

Enter Password

Note:

• This temporary cancellation of rating level will be kept until the disc is ejected.

When the disc is ejected, the original rating level will be

set again automatically.

Function setup

Playback will commence if the entered password is correct.

50S0301A.indb 6150S0301A.indb 61 2/5/08 5:59:23 PM2/5/08 5:59:23 PM

Others

Understanding the Power Return feature

If the power is cut off while you are viewing the TV/DVD and the power is resupplied, the Power Return feature will turn the TV/DVD on automatically. If the power is going to be off for a long time or you are going to be away from the TV/DVD for a long time, unplug the power cord from the wall outlet to prevent the TV/DVD from turning on in your absence.

Troubleshooting

Use the following check list for troubleshooting when you have problems with your unit. Consult your local dealer or service outlet if problems persist. Be sure all connections are properly made when using with other units.

SYMPTOMS POSSIBLE SOLUTIONS PAGE

POWER

• Make sure the connection of AC cord is secured.

TV/DVD does not operate.

TV BROADCAST RECEPTION

Poor sound or No sound.

Poor picture or No picture.

Poor reception on some channels.

Poor color or no color.

Picture wobbles or drifts.

No CATV reception.

Horizontal or diagonal bars on screen.

No reception above channel 13.

TV shuts off.

Closed - Caption is not activated.

Display is not shown in your language.

• Try another AC outlet.

• Unplug unit, then plug it back in.

• Station or Cable TV may have problems, try another station.

• Check Volume adjustments or mute.

• Check for sources of possible interference.

• Station or Cable TV may have problems, try another station.

• Check antenna or Cable TV connections, reorient antenna.

• Check for sources of possible interference.

• Check Picture setting.

• Station or Cable TV may have problems, try another station.

• Station signal is weak, reorient antenna to receive weaker station.

• Check for sources of possible interference.

• Station or Cable TV may have problems, try another station.

• Make sure channels are set into memory.

• Check Picture setting.

• Check antenna or Cable TV connections, reorient antenna.

• Check for sources of possible interference.

• Station or Cable TV may have problems, try another station.

• Make sure channels are set into memory.

• Cable TV company is scrambling signal.

• Check antenna or Cable TV connections, reorient antenna.

• Check all Cable TV connections.

• Set Air/Cable selection to the Cable position.

• Station or Cable TV system problems, try another station.

• Check antenna or Cable TV connections, reorient antenna.

• Check for sources of possible interference.

• Make sure Air/Cable selection is in the appropriate position.

• If antenna is used, check UHF antenna connections.

• Auto shut off feature worked.

• Sleep Timer is set.

• Power interrupted.

• TV station experiencing problems or program tuned is not closed captioned. Try another channel.

• Check Cable TV connection or VHF/UHF antenna, reposition or rotate antenna.

• Set “CC Setting” to “On” to turn on the closed caption decoder.

• Select proper language in the menu options. 22

26, 27

64 26

14, 15

64 32

26 14 64

26 23 32

14, 15

64 26

14, 15

15 23 26

14, 15

64 23

14 39

14, 15

50S0301A.indb 6250S0301A.indb 62 2/5/08 5:59:24 PM2/5/08 5:59:24 PM

SYMPTOMS POSSIBLE SOLUTIONS PAGE

DVD

• No disc is loaded.

Playback doesnʼt start.

No picture. • TV/DVD selector is not set correctly. 40

No sound.

Picture is distorted during fast reverse/forward playback.

Stopping playback, search, slowmotion play, repeat play, or program play, etc. cannot be performed.

No on-screen display. • Set Display to On. 58 The unit or remote operation key

is not functioning. Playback does not start when

the title is selected. Audio soundtrack and/or subtitle

language is not changed when you playback a DVD.

No subtitle. Angle cannot be changed. • Multi-angles are not recorded on the DVD disc. 47

“✕” appears on the screen. • The function is prohibited with the unit or the disc. 42

REMOTE CONTROL

The remote control does not function.

• The disc may be dirty. Clean up the disc.

• The unit cannot play CD-ROMs, etc.

• Check the input selector of the ampliﬁ er is set properly.

• The unit is in the special playback mode.

• Select the correct Audio Input/Output position on AV ampliﬁ er.

• The picture will be distorted occasionally. -

• Some discs may not do some of the functions. -

• Turn off the unit and unplug the AC power cord for several minutes, then replug it.

• Check the Parental setup. 60

• Multilingual language is not recorded on the DVD disc. 48

• Some discs have no subtitles.

• Subtitles are cleared. Press SUBTITLE.

• Aim the remote control at the remote sensor.

• Operate within approx. 5 meters or reduce the light in the room.

• Clear the path of the beam.

• The batteries are weak. Replace the batteries.

• Check the batteries are inserted correctly.

18, 19

7 8

Others

50S0301A.indb 6350S0301A.indb 63 2/5/08 5:59:24 PM2/5/08 5:59:24 PM

Others

Reception disturbances

Most types of television interference can be remedied by adjusting the height and position of the VHF/UHF antenna. Outdoor antennas are recommended for best results. The most common types of television interference are shown below. If one of these symptoms appear when the TV/DVD is connected to a Cable TV system, the disturbance may be caused by the local Cable TV company broadcast.

IGNITION

Black spots or horizontal streaks may appear, the picture may ﬂ utter or drift. Usually caused by interference from automobile ignition systems, neon lamps or AC powered tools and appliances such as drills or hair dryers.

GHOSTS

Ghosts are caused by the television signal following two paths. One is the direct path and the other is reﬂ ected by tall buildings, hills or other large objects. Changing the direction or position of the antenna may improve the reception.

SNOW

If the TV/DVD is located far from the TV station, in a fringe reception area where the signal is weak, small dots may appear in the picture. If the signal is extremely weak, the installation of a larger external antenna may be necessary.

RADIO FREQUENCY INTERFERENCE (RFI)

Caused by two-way radios, this type of interference produces moving ripples or diagonal streaks in the picture. Some cases may cause a loss of contrast in the picture. Changing the direction and position of the antenna or installing an RFI ﬁ lter may improve the picture.

CARE AND MAINTENANCE

To prevent ﬁ re or shock hazard, disconnect the TV/DVD from the power source before cleaning. Use caution when cleaning or wiping the plastic parts.

50S0301A.indb 6450S0301A.indb 64 2/5/08 5:59:25 PM2/5/08 5:59:25 PM

Language code list

Enter the appropriate code number for the initial settings “Menu”, “Subtitle” and/or “Audio” 58.

Language Name Code Language Name Code Language Name Code Language Name Code

Abkhazian 1112 Fiji 1620 Lingala 2224 Singhalese 2919 Afar 1111 Finnish 1619 Lithuanian 2230 Slovak 2921 Afrikaans 1116 French 1628 Macedonian 2321 Slovenian 2922 Albanian 2927 Frisian 1635 Malagasy 2317 Somali 2925 Amharic 1123 Galician 1722 Malay 2329 Spanish 1529 Arabic 1128 Georgian 2111 Malayalam 2322 Sundanese 2931 Armenian 1835 German 1415 Maltese 2330 Swahili 2933 Assamese 1129 Greek 1522 Maori 2319 Swedish 2932 Aymara 1135 Greenlandic 2122 Marathi 2328 Tagalog 3022 Azerbaijani 1136 Guarani 1724 Moldavian 2325 Tajik 3017 Bashkir 1211 Gujarati 1731 Mongolian 2324 Tamil 3011 Basque 1531 Hausa 1811 Nauru 2411 Tatar 3030 Bengali; Bangla 1224 Hebrew 1933 Nepali 2415 Telugu 3015 Bhutani 1436 Hindi 1819 Norwegian 2425 Thai 3018 Bihari 1218 Hungarian 1831 Oriya 2528 Tibetan 1225 Breton 1228 Icelandic 1929 Panjabi 2611 Tigrinya 3019 Bulgarian 1217 Indonesian 1924 Pashto, Pushto 2629 Tonga 3025 Burmese 2335 Interlingua 1911 Persian 1611 Turkish 3028 Byelorussian 1215 Irish 1711 Polish 2622 Turkmen 3021 Cambodian 2123 Italian 1930 Portuguese 2630 Twi 3033 Catalan 1311 Japanese 2011 Quechua 2731 Ukrainian 3121 Chinese 3618 Javanese 2033 Rhaeto-Romance 2823 Urdu 3128 Corsican 1325 Kannada 2124 Romanian 2825 Uzbek 3136 Croatian 1828 Kashmiri 2129 Russian 2831 Vietnamese 3219 Czech 1329 Kazakh 2121 Samoan 2923 Volapük 3225 Danish 1411 Kirghiz 2135 Sanskrit 2911 Welsh 1335 Dutch 2422 Korean 2125 Scots Gaelic 1714 Wolof 3325 English 1524 Kurdish 2131 Serbian 2928 Xhosa 3418 Esperanto 1525 Laothian 2225 Serbo-Croatian 2918 Yiddish 2019 Estonian 1530 Latin 2211 Shona 2924 Yoruba 3525 Faroese 1625 Latvian, Lettish 2232 Sindhi 2914 Zulu 3631

Others

50S0301A.indb 6550S0301A.indb 65 2/5/08 5:59:25 PM2/5/08 5:59:25 PM

Others

Specifications

Model 19LV505C 22LV505C

General

Power supply AC 120V 60Hz Power consumption Operation: 60 W, Stand by: 1 W Operation: 65 W, Stand by: 1 W Weight 11.2 lbs (5.1 kg) 13.5 lbs (6.1 kg)

Dimensions

Operating temperature 5°C-40°C (41°F-104°F) Operating humidity Less than 80% RH (No condensation)

Television

LCD panel (Screen size is approximate.) 19-inch diagonal 22-inch diagonal Display method Color TFT LCD Number of pixels 1440 (Horizontal) x 900 (Vertical) 1680 (Horizontal) x 1050 (Vertical) Television system NTSC standard, ATSC standard (8VSB), QAM

Receiving channels

Antenna input VHF/UHF 75 Ω Speaker 1-3/16 x 2-13/16 inches (30.5 x 71.1 mm), 8 Ω x 2 Audio output power 1.5W + 1.5W

DVD/CD player

Signal system NTSC Applicable disc Pickup 1-Lens, 2-Beams System

Input/Output

S-Video input

ColorStream video input Video input 1.0 V (p-p), 75 Ω, negative sync., pin jack x 1

Audio input –8dBm, 50 kΩ, negative sync., pin jack (L/R) x 2

HDMI input

PC input MONITOR: Mini-Dsub 15pin x 1, AUDIO: 3.5ø mm Stereo jack x 1 Digital audio output (Coaxial) 0.5 V (p-p), 75 Ω, pin jack x 1 Headphone ø3.5mm stereo mini jack x 1

Accessories

Remote control (SE-R0305) ................................................................................................... 1

Batteries (R03/AAA) .............................................................................................................. 2

AC cord .................................................................................................................................. 1

Cleaning cloth .............................................................................. .......................................... 1

Ownerʼs manual (this booklet) ..................................................... ..........................................1

Width: 18-9/16 inches (472 mm) Height: 15-13/16 inches (401 mm) Depth: 8-1/8 inches (207 mm)

VHF: 2-13 UHF: 14-69 CATV: 1-125 (4A, A-5~A-1, A~I, J~W, W+1~W+84)

1. DVD (12cm, 8cm)

2. CD (12cm, 8cm)

(Y) 1.0 V (p-p), 75 Ω, negative sync., Mini DIN 4-pin x 1 (C) 1.0 V (p-p), 75 Ω

(Y) 1.0 V (p-p), 75 Ω, negative sync., pin jack x 1 (PB, PR) 0.7 V (p-p), 75 Ω, pin jack x 2

HDMI compliant (type A connector), HDCP compliant, E-EDID compliant Suggested scan rates: 1080i, 480p, 720p HDMI Audio: 2-channel PCM, 32/44.1/48 kHz sampling frequency, 16/20/24 bits per sample

• This model complies with the above speciﬁ cations.

• Designs and speciﬁ cations are subject to change without notice.

• This model may not be compatible with features and/or speciﬁ cations that may be added in the future.

Width: 21-1/8 inches (536.5 mm) Height: 17-5/16 inches (439.5 mm) Depth: 8-1/8 inches (207 mm)

50S0301A.indb 6650S0301A.indb 66 2/5/08 5:59:26 PM2/5/08 5:59:26 PM

Limited Canadian Warranty for Toshiba Brand Flat Panel Televisions

Toshiba of Canada Limited (“TCL”) makes the following limited warranties to original consumers in Canada. THESE LIMITED WARRANTIES EXTEND TO THE ORIGINAL CONSUMER PURCHASER OR ANY PERSON RECEIVING THIS TOSHIBA BRAND FLAT PANEL TELEVISION (the “TELEVISION(S)” or “Television(s)”) AS A GIFT FROM THE ORIGINAL CONSUMER PURCHASER AND TO NO OTHER PURCHASER OR TRANSFEREE.

TELEVISIONS PURCHASED IN CANADA, AND USED ANYWHERE OUTSIDE OF CANADA INCLUDING, WITHOUT LIMITATION, THE UNITED STATES AND MEXICO, ARE NOT COVERED BY THESE WARRANTIES.

TELEVISIONS PURCHASED ANYWHERE OUTSIDE OF CANADA, INCLUDING, WITHOUT LIMITATION, THE UNITED STATES AND MEXICO, AND USED IN CANADA, ARE NOT COVERED BY THESE WARRANTIES.

Limited One (1) Year Warranty on Parts and Labour

Subject to the more limited warranty if the Television is used for any commercial or business purposes as set out below, TCL warrants the Television and its parts against material defects in materials or workmanship that result in the Television failing for a period of one (1) year after the date of original retail purchase. DURING THIS PERIOD,

TCL WILL, AT TCLʼS OPTION, REPAIR OR REPLACE A DEFECTIVE PART WITH A NEW OR REFURBISHED PART WITHOUT CHARGE TO YOU FOR PARTS OR LABOUR.

(a) FOR TELEVISIONS 32 INCHES OR LESS: YOU MUST

DELIVER THE ENTIRE TELEVISION TO A TCL TELEVISION AUTHORIZED SERVICE PROVIDER (“ASP”). YOU MUST PAY FOR ALL TRANSPORTATION AND INSURANCE CHARGES FOR THE TELEVISION TO AND FROM THE ASP.

(b) FOR TELEVISIONS OVER 32 INCHES: During this period,

ASP personnel will come to your home when warranty service is required. Depending on the type of repair required, the service will either be performed in your home or the Television will be taken to an ASP for repair and returned to your home at no cost to you.

IN-HOME SERVICE ONLY APPLIES WITHIN 100 KILOMETERS OF AN ASP. IF YOU ARE NOT WITHIN 100 KILOMETERS OF AN ASP, YOU MUST DELIVER THE ENTIRE TELEVISION TO AN ASP. YOU MUST PAY FOR ALL TRANSPORTATION AND INSURANCE CHARGES FOR THE TELEVISION TO AND FROM THE ASP .

Limited Warranty for Commercial Units

TCL warrants Televisions that are used for any commercial or business purposes as follows: all parts are warranted against material defects in materials or workmanship that result in the Television failing for a period of ninety (90) days after the date of original retail purchase.

DURING THIS PERIOD, TCL WILL, AT TCLʼS OPTION, REPAIR OR REPLACE THE DEFECTIVE PART WITH A NEW OR REFURBISHED PART WITHOUT CHARGE TO YOU.

THE ENTIRE TELEVISION TO AN ASP. YOU MUST PAY FOR ALL TRANSPORTATION AND INSURANCE CHARGES FOR THE TELEVISION TO AND FROM THE ASP.

(d) FOR TELEVISIONS OVER OVER 32 INCHES: During this

period, ASP personnel will come on-site when warranty service is required. Depending on the type of repair required, the service will either be performed on-site or the Television will be taken to an ASP for repair and returned at no cost to you. ON-SITE SERVICE

ONLY APPLIES WITHIN 100 KILOMETERS OF AN ASP. IF YOU ARE NOT WITHIN 100 KILOMETERS OF AN ASP, YOU MUST DELIVER THE ENTIRE TELEVISION TO AN ASP. YOU MUST PAY FOR ALL TRANSPORTATION AND INSURANCE CHARGES FOR THE TELEVISION TO AND FROM THE ASP.

Your Responsibility

THE ABOVE WARRANTIES ARE SUBJECT TO THE FOLLOWING CONDITIONS:

(1) You must provide your bill of sale or other proof of purchase. (2) All warranty servicing of this Television must be performed by an

ASP.

(3) The warranties from TCL are effective only if the Television is

(i) purchased as new and unopened from TCL or from TCLʼs authorized distributors, dealers or resellers (“ADRʼs”) and (ii) located/operated in Canada.

(4) Labour charges for set installation, setup, adjustment of customer

controls, and installation or repair of antenna systems are not covered by these warranties. Reception problems caused by inadequate antenna systems are your responsibility.

(5) Warranties extend only to material defects in materials or

workmanship as limited above, and do not extend to:

a. Service, repairs or replacement made necessary by accident,

misuse, abuse, moisture, liquids, dust, dirt, neglect, accident, damage, 24/7 applications, improper installation, improper operation, improper cleaning, improper maintenance, normal wear and tear, screen burn or image retention caused by prolonged display of static images and/or phosphor aging, or any other external cause or event, act or omission outside the control of TCL, including ﬁ re, theft, acts of God, alteration, power failures, power surges or power shortages, lightning, other electrical faults, or repairs, modiﬁ cations or replacements by persons other than those authorized by TCL to service the Television;

b. Replacement of missing, discarded or lost parts, the provision of

retroﬁ ts, or preventive maintenance;

c. Repair of damage that is cosmetic only or does not affect the

Television functionality, such as wear and tear, scratches and dents;

d. Service on Toshiba-branded accessory items (such accessory

items may be covered by their own warranty);

e. Service on third party products or service made necessary by use

of incompatible third party products;

f. Service made necessary by the simultaneous use of this Television

and connected equipment;

g. Modiﬁ cations to the Television not approved in writing by TCL, and

service made necessary by the use or installation of non-Toshiba modiﬁ cations to the Television;

h. Service of a Television on which the TOSHIBA label or logo, rating

label or serial number have been defaced or removed; i. On-site service and repair of the Television; and j. Damage to the Television caused by failure to follow the

speciﬁ cations, User manuals or guides as to usage and/or storage.

Others

Rental Units

The warranty for Television rental units begins with the date of ﬁ rst rental or thirty (30) days from the date of shipment to the rental ﬁ rm, whichever comes ﬁ rst.

50S0301A.indb 6750S0301A.indb 67 2/5/08 5:59:26 PM2/5/08 5:59:26 PM

Disclaimer and Limitation of Remedy

TO THE EXTENT NOT PRECLUDED BY LAW, ALL OTHER EXPRESS AND IMPLIED WARRANTIES, CONDITIONS AND REPRESENTATIONS FOR THIS TELEVISION, INCLUDING THE IMPLIED WARRANTIES, CONDITIONS AND REPRESENTATIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED AND EXCLUDED. IF THE APPLICABLE LAW, STATUTORY OR OTHERWISE, PRECLUDES THE EXCLUSION OF ANY IMPLIED WARRANTIES, CONDITIONS AND REPRESENTATIONS THEN SUCH IMPLIED WARRANTIES, CONDITIONS AND REPRESENTATIONS ARE OTHERWISE LIMITED IN DURATION TO THE TERM OF THIS EXPRESS WRITTEN LIMITED WARRANTY. TO THE EXTENT NOT PRECLUDED BY LAW, STATUTORY OR OTHERWISE, THIS WRITTEN WARRANTY SUPERCEDES AND SPECIFICALLY DISCLAIMS ANY OTHER WARRANTY, CONDITION OR REPRESENTATION NOT STATED IN THIS WARRANTY, WHETHER MADE BY TCL, TOSHIBA CORPORATION, THEIR AFFILIATES, ADRs AND ASPs AND WHETHER MADE ORALLY OR IN WRITING (INCLUDING ANY STATEMENT IN ANY BROCHURE, PRESS RELEASE, ANNOUNCEMENT, ADVERTISEMENT, POINT OF SALE DISPLAY, ETC.).

YOU MUST READ AND FOLLOW ALL SET-UP AND USAGE INSTRUCTIONS IN THE APPLICABLE USER GUIDES AND/OR MANUALS. IF YOU FAIL TO DO SO, THIS TELEVISION MAY NOT FUNCTION PROPERLY AND YOU MAY SUFFER DAMAGE. THIS WARRANTY WILL NOT COVER ANY SERVICE THAT IS REQUIRED, IN PART OR IN WHOLE, AS A RESULT OF ANY FAILURE TO FOLLOW THE SET-UP AND USAGE INSTRUCTIONS. THIS WARRANTY DOES NOT APPLY AND SHALL BE VOID AND UNENFORCEABLE IF THE TELEVISION IS OPENED, SERVICED, OR REPAIRED BY PERSONS OTHER THAN THOSE AUTHORIZED BY TCL TO SERVICE OR REPAIR THE TELEVISION.

IF THE TELEVISION FAILS TO WORK AS WARRANTED ABOVE, YOUR SOLE AND EXCLUSIVE REMEDY SHALL BE REPAIR OR REPLACEMENT OF THE DEFECTIVE PART. IN NO EVENT WILL TCL, TOSHIBA CORPORATION, THEIR AFFILIATES, ADRs OR ASPs (THE “RELATED PARTIES”) BE LIABLE TO YOU OR ANY THIRD PARTY FOR ANY DAMAGES, MONEY, REIMBURSEMENT, COSTS OR EXPENSES. THIS LIMITATION APPLIES TO DAMAGES, MONEY, REIMBURSEMENT, COSTS OR EXPENSES OF ANY KIND WHATSOEVER INCLUDING ANY DIRECT OR INDIRECT DAMAGES, DAMAGE TO PROPERTY OR PERSON, LOST PROFITS, LOST SAVINGS, INCONVENIENCE OR OTHER SPECIAL, INCIDENTAL, EXEMPLARY OR CONSEQUENTIAL DAMAGES, WHETHER FOR BREACH OF WARRANTY, BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), UNDER A STATUTE OR UNDER ANY OTHER LAW OR FORM OR ACTION, OR WHETHER ARISING OUT OF THE USE OF OR INABILITY TO USE THE TELEVISION, EVEN IF ANY OF THE RELATED PARTIES HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR OF ANY CLAIM BY ANY OTHER PARTY.

No person, agent, distributor, dealer or company is authorized to change, modify or extend the terms of these warranties in any manner whatsoever.

Arbitration and Dispute Resolution

To the extent not precluded by law, any claim, dispute, controversy or disagreement (whether for breach of warranty, breach of contract, tort (including negligence), under a statute or under any other law or form of action) against any of the Related Parties arising out of, or otherwise relating to: (i) this warranty; (ii) the Television; (iii) any oral or written representations, statements, brochures, press releases, advertising, announcement, point of sale display, or promotional material relating to the Television; (iv) the relationships that result from this warranty, (the foregoing claims, disputes controversies and disagreements are collectively referred to as the “Dispute”), shall

be referred to and resolved by ﬁ nal and binding arbitration (to the exclusion of the courts). To the extent not precluded by law, you agree to waive any right that you may have to commence or participate in any representative or class proceeding against the Related Parties relating to any Dispute. If and where applicable and to the extent not precluded by law, you further agree to opt out of any such representative or class proceedings.Arbitration of any Dispute will be conducted in the forum and in the manner as agreed to between you and TCL. Failing such agreement, the arbitration will be conducted by one arbitrator pursuant to the laws and rules relating to arbitration generally in force in the jurisdiction in which you reside at the time that the Dispute arises. To the extent not precluded by law, no claim, dispute, controversy or disagreement of any other person may be joined or combined with any Dispute by you, without the prior written consent of TCL.

Critical Applications

The Television you have purchased is not designed for any “critical applications.” “Critical applications” means life support systems, medical applications, connections to implanted medical devices, commercial transportation, nuclear facilities or systems or any other applications where Television failure could lead to injury to persons or loss of life or catastrophic property damage.

IF THE CUSTOMER USES THE TELEVISION IN ANY CRITICAL APPLICATION, THE CUSTOMER – AND NOT TCL, ITS AFFILIATES, ADRs OR ASPs – ASSUME SOLE AND FULL RESPONSIBILITY FOR SUCH USE. TCL RESERVES THE RIGHT TO REFUSE TO SERVICE ANY TELEVISION USED IN A CRITICAL APPLICATION. TCL, ITS AFFILIATES, ADRs AND ASPs HEREBY DISCLAIM ANY AND ALL LIABILITY, DAMAGES AND CONSEQUENCES ARISING OUT OF THE SERVICE OR REFUSAL TO SERVICE SUCH TELEVISION AND FURTHER DISCLAIM ANY AND ALL LIABILITY, CONSEQUENCES AND DAMAGES THAT MAY ARISE OR RESULT FROM THE USE OF THE TELEVISION IN ANY CRITICAL APPLICATIONS.

General Provisions

If and to the extent that any provision of this limited warranty should generally be found to be unenforceable, the unenforceable provision shall be severed from the warranty and deemed not to form part of the warranty. The remaining provisions of this warranty shall be and remain valid and enforceable. If and to the extent that any provision of this limited warranty as it relates to any of the Related Parties is found to be invalid or unenforceable in respect of that party (the “Excluded Party”), the Excluded Party shall be deemed to be severed or excluded from the provision, and the provision shall remain valid, enforceable and applicable in respect of the other or remaining Related Parties.

To the extent permitted by law, this limited warranty shall be governed and construed in accordance with the laws of Ontario.

If there is any inconsistency between this limited warranty, on the one hand, and any statement in the packaging of the Television or in any other document enclosed with, or used in the context of the promotion or sale of, the Television, on the other hand, the provisions of this limited warranty shall prevail.

How to Obtain Warranty Services

If, after following all of the operating instructions in this manual and checking the “Troubleshooting” section, you ﬁ nd that service is needed:

(1) T o ﬁ nd the nearest ASP, visit TCLʼs web site at www.toshiba.ca, or

call toll free 1-800-268-3404 (2) Present your bill of sale or other proof of purchase to the ASP. For additional information, visit TCLʼs website at www.toshiba.ca

ColorStream is registered trademark of Toshiba America Consumer Products, L.L.C.

Printed in Thailand

J50S0301A SH 08/03

50S0301A.indb 6850S0301A.indb 68 2/5/08 5:59:27 PM2/5/08 5:59:27 PM
