ZMaster
®
Professional5000or6000SeriesRiding
Mower
with48in,52in,60in,or72inTURBOFORCE
ModelNo.72911—SerialNo.400000000andUp
FormNo.3433-925RevC
®
Mower
SoftwareGuide
Readthisinformationcarefullytolearnhowtooperateandmaintainyourproductproperlyandtoavoidinjury andproductdamage.Youareresponsibleforoperatingtheproductproperlyandsafely .ReadyourOperator’s Manualformoreinformation.
Thehourmetermonitorsenginetemperature,oilpressure,andtheoverallelectricalsystem.Italsodisplays machinehours,safety-interlockstatus,fuellevel,andmaintenancereminders.
©2021—TheT oro®Company 8111LyndaleAvenueSouth Bloomington,MN55420Registeratwww.T oro.com.
OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved
*3433-925*
ScreenIcons
Thescreenusesthefollowingicons:
PTOParkingBrake
OperatorPresenceControl(OPC)
HourMeter
CheckEngineErrorVoltageError
BatteryV oltage
Transmission-FluidMaintenanceEngine-OilMaintenance
NeutralLock
FuelLevel
PowertoRunError
LowEngine-OilPressureError
CheckFaultError
ClutchErrorClutchResetRequired
2
ProductOverview
Controls
InformationScreen
Theinformationscreendisplaysiconsandinformation relativetomachineoperation.
LEDStatusLight
TheLEDismulti-coloredtoindicatethesystemstatus andislocatedontherightsideofthepanel.
•SolidGreen—indicatesnormaloperatingactivity.
•BlinkingRed—indicatesafaultisactive.
g031090
Figure1
ModelswithFuelSender
•BlinkingGreenandOrange—indicatesaclutch
resetisrequired.
•SolidRed—indicatesmaintenanceisrequired.
1.Screen
2.LEDstatuslight
InformationScreens
Themaininformationscreensareasfollows:
•StartupScreens(page3)
•PTOHourMeterScreen(page5)
•BatteryVoltageScreen(page5)
•FuelMeterScreen(page5)
•HourMeterScreen(page5)
•DefaultScreen(page6)
•MaintenanceRemindersandAlerts(page7)
g037701
Figure2
ModelswithoutFuelSender
1.Screen
2.LEDstatuslight
•ManuallyResettingMaintenanceReminders
(page8)
•AlertsandErrorMessages(page8)
StartupScreens
WhenthekeyisintheRUNposition,thescreens (Figure3)displayforapproximately2seconds.The LEDstatuslightchangesfromredtoorangetogreen.
3
Figure3
StartupScreen
1.Firmwareversion
2.PTOhours
3.Batteryvoltage
4.Hoursuntilengine-oilmaintenanceisrequired
5.Hoursuntiltransmission-oilmaintenanceisrequired
g030964
4
PTOHourMeterScreen
HourMeterScreen
ThisdisplaysthenumberofhoursthatthePTOhas beenengaged(Figure4).
Figure4
BatteryVoltageScreen
Thisscreendisplaysthecurrentbatteryvoltage (Figure5).
Thehourmeterrecordshourswhenthehourmeter symbolashes.
Hoursdisplaywhenthemachineisofforwhenthe machineisrunning.Thedisplayturnsoffafter5 minutes.
g222036
g031198
Figure7
Hourmeterwithoutafuelsender
Figure5
FuelMeterScreen
Ifthemachineisequippedwithafuelsender,thefuel leveldisplaysinthesamepanelasthehourmeter andisshownasan8-segmentbar(Figure6).
Eightsolidbarsindicatesafullfueltank.
Figure6
Fuelmeterandhourmeter
g030962
g030963
1.Hourmeter2.Fuellevel
5
DefaultScreen
Afterthestartupscreensdisplay,thedefaultscreen displays(Figure8).
Thesafety-interlockindicatorsilluminatewhen eachcontrolmeetstheSAFETOST ARTmode(PTO disengaged,parkingbrakeengaged,motion-control leversintheNEUTRAL-LOCKposition,andoperator present).
Figure8
1.Safety-interlockindicators
2.Hourmeter
3.Fuellevel(ifequipped)
g037702
Figure9
1.Safety-interlockindicators
2.Hourmeter
g030961
•YoumusthavethePTOdisengaged,theparking
brakeengaged,andthemotion-controlleversin theNEUTRAL-LOCKpositiontostarttheengine.
Note:Youdonotneedtobeintheseattostart
theengine.
Note:Themoduleallowstheenginetostartwith
thePTOswitchengaged;however,thesystem willdisengagethePTOandaPTOreseterrorwill occur.EngagingthePTOrequiresyoutoresetthe PTOswitchbydisengagingit,thenengagingit.
•YoumustbeintheseatwhenthePTOis
engaged,theparkingbrakeisdisengaged,orthe motion-controlleversaremovedin;otherwise,the engineshutsoff.
•Theengineshutsoffifeithertheleft,right,orboth
leversmovefromtheNEUTRAL-LOCKpositionwhile theparkingbrakeisengaged.
•Ifthemowerisequippedwithafuelsender,the
defaultscreenshowninFigure8willdisplay.
•Ifthemowerisnotequippedwithafuelsender,
onlythesafety-interlockindicatorsandthehour meterwilldisplayasshowninFigure9.
6
MaintenanceRemindersand Alerts
Thereare2maintenancereminders:
•ServiceEngine
Thehourmeterdisplaysthenumberofengine hoursuntileithertheengineoilortransmission-uid maintenanceisdue.Thereminderashesandthe LEDdisplaysasolid,redlight.
Analertoccurswhenthehourcounterhasreached zero.Ifyoudonotperformthemaintenance,thetime recordsasnegativehourstoindicatethenumber ofhourspastdueformaintenance(upto-100.0 hours);refertoFigure10andFigure11.Thehour meterswitchesbetweenthedefaultscreenandthe activealertscreen.Ifmorethan1alertisactive,the displaycyclesbetweenthealertsintheorderthatthey occurredbeforecyclingbacktothedefaultscreen.
Thealertsdisplayonlyafterthedefaultscreenhas beenactivefor2seconds;however,ifthekeymoves totheSTARTposition,thealertsoccurimmediately.
Theengineoilserviceremindercountsdownfrom theinitialbreak-inserviceintervalof5engine hoursandthencountsdownfrom100hoursfor eachserviceintervalthereafter.
g030960
Figure10
•ServiceTransmission
Thetransmissionuidmaintenancereminder countsdownfromtheinitialbreak-inservice intervalof250enginehoursandthencountsdown from500hoursforeachserviceintervalthereafter.
Figure11
g030965
7
ManuallyResettingMaintenance
AlertsandErrorMessages
Reminders
ToaccesstheServiceEnginescreenyoumustsit intheoperator’sseat,disengagetheblade-control switch(PTO),movethemotion-controlleverstothe NEUTRAL-LOCKposition,andengagetheparking brake.
•Youcanentertheengineservicereminderreset
modebycyclingthekeyswitchbetweentheRUN positionandOFFposition4timeswithin8seconds, withallthesafetyinterlocksintheSAFEposition.
WhentheServiceEnginescreendisplaysand ashes,youcanresettheengineoilmaintenance reminderbycyclingeither1orbothmotion-control leversfromtheNEUTRAL-LOCKpositiontothe NEUTRALposition,andbacktotheNEUTRAL-LOCK position.Oncethereminderresets,thescreen exitstheServiceEnginescreenandreturnsto thedefaultscreen.
YoucanexittheServiceEnginescreenatany timebyturningthekeytoeithertheOFForST ART position.
•Youcanenterthetransmissionuidmaintenance
reminderresetmodebycyclingthekeyswitch fromtheRUNpositiontotheOFFpositionandback totheRUNposition6timeswithin8seconds,with allthesafetyinterlocksintheSAFEposition.
Thesystemiscapableofdisplayingthefollowing errors:
•VoltageError
Whenthekey-runvoltageislessthan12.3Vor greaterthan16V,avoltageerrorashes.The LEDashesaredlight.
g030966
Figure12
•LowFuelLevelError
Ifthefuelsenderisinstalled,anerrorappears whenthefuellevelis1/8orless.TheLEDashes aredlightandthefuel-levelsymbolonthedefault screenashes.
WhentheServiceTransmissionscreendisplays andashes,youcanresetthetransmissionuid maintenancereminderbycyclingeither1orboth motion-controlleversfromtheNEUTRAL-LOCK positiontotheNEUTRALposition,andbacktothe NEUTRAL-LOCKposition.
YoucanexittheServiceTransmissionscreen atanytimebyturningthekeytoeithertheOFF orSTARTposition.
g031204
Figure13
•PowertoRunOutputOver-CurrentError
Ifanover-currentoccurs,thenumber“2”displays inthelower,leftcornerofthescreen.TheLED ashesaredlight.
g030968
Figure14
8
1.Number“2”displays
•EngineOverTemperatureError
•ClutchOpenError
Thisoccursifanengineovertemperatureis detected.Checktheengineoilandcleandebris fromtheengine.TheLEDashesaredlightand theclutchdisengages.
Afteryouresolvetheissuethatcausedtheerror, themoduledisplaystheClutchResetRequired alerttoindicatethatyoumustdisengagethePTO switchandthenengageit.
Figure15
•Low-OilPressureError
Thisoccurswhenlow-oilpressureisdetected. ChecktheengineoilandcontactanAuthorized ServiceDealer.TheLEDashesaredlightand theclutchdisengages.
Iftheclutchoutputdisconnects,thenumber“6” displaysinthelower,leftcornerofthescreen.The LEDashesaredlight.
g030971
Figure17
1.Number“6”displays
•ClutchOver-CurrentError
g030969
Ifthecurrentdrawontheclutchoutputisexcessive ortheoutputcircuitoverheats,thenumber“2” displaysinthelower,leftcornerofthescreen. CheckthePTOclutchandinspectfordamageand wear.TheLEDashesaredlight.
Afteryouresolvetheissuethatcausedtheerror, themoduledisplaystheClutchResetRequired alerttoindicatethatyoumustdisengagethePTO switchandthenengageit.
Figure16
g030972
Figure18
1.Number“2”displays
•ClutchResetRequired
IfthePTOswitchisengagedandthemodule disengages,theclutch-outputerrordisplays.The
g030970
LEDlightilluminatesgreen,thenorange.You mustthendisengagethePTOswitchandthen engageit.
g030973
Figure19
9
•Check-EngineError
Ifanenginefaultoccurs,thesystemdisplaysthe CheckEnginealertandashesaredlight.T o retrievethespecicfault(s),followthekeycycle procedureprovidedintheengineowner’smanual.
Ifmorethan1erroroccurs,thedisplayalternates betweencodes.Inordertodisplaythediagnostic codes,youmustcyclethekeyswitch2times betweentheONandOFFpositions,thentotheON position,butdonotstarttheengine.
Figure20
g030975
Figure21
•CheckFaultError
ThesystemdisplaystheCheckFaultalertand theLEDashesredwhenanerrorisdetectedby anoptionalswitch.
Figure22
g030976
g030977
10
Notes:
