TomTom Mazda NB1 Reference Guide

Mazda NB1

Reference Guide

Contents

Read me first 6

Switching on and off .......................................................................................................................... 6

Setting up............................................................................................................................................ 6

GPS reception ..................................................................................................................................... 6

Device not starting ............................................................................................................................. 6

Sharing information with TomTom ................................................................................................... 6

Take care of your device .................................................................................................................... 7

More information ................................................................................................................................ 8

The memory card 9

About your memory card .................................................................................................................. 9

Inserting your memory card .............................................................................................................. 9

Removing your memory card ............................................................................................................ 9

About TomTom HOME ...................................................................................................................... 9

Installing TomTom HOME ................................................................................................................ 10

Initialising your memory card .......................................................................................................... 10

Updating your device ....................................................................................................................... 10

Backing up your navigation device ................................................................................................. 11

Safety Notice 12

Safety settings .................................................................................................................................. 12

The commander 13

About the commander ..................................................................................................................... 13

Using the commander ...................................................................................................................... 13

Planning a route 14

Planning a route................................................................................................................................ 14

Route summary ................................................................................................................................ 16

Selecting a route type ...................................................................................................................... 17

Using arrival times ............................................................................................................................ 17

Navigation menu options ................................................................................................................. 17

Planning a route in advance ............................................................................................................ 18

Viewing route information ............................................................................................................... 19

Voice control 21

Voice control ..................................................................................................................................... 21

About navigation device voice control............................................................................................ 21

Using voice control .......................................................................................................................... 21

Planning a trip using your voice ...................................................................................................... 22

Entering addresses using your voice .............................................................................................. 23

The Driving View 25

About the Driving View .................................................................................................................... 25

The Driving View .............................................................................................................................. 25

Driving View Symbols ...................................................................................................................... 26

Advanced Lane Guidance 27

About lane guidance ........................................................................................................................ 27

Using lane guidance ......................................................................................................................... 27

Changing your route 28

Making changes to your route ......................................................................................................... 28

Change route menu .......................................................................................................................... 28

About waypoints .............................................................................................................................. 29

Adding the first waypoint to your route .......................................................................................... 29

Adding further waypoints to your route ......................................................................................... 30

Changing the order of waypoints .................................................................................................... 30

Deleting a waypoint .......................................................................................................................... 31

Changing notification settings for a waypoint ................................................................................ 31

Reactivating a waypoint ................................................................................................................... 31

View map 33

About viewing the map .................................................................................................................... 33

View map .......................................................................................................................................... 33

Options .............................................................................................................................................. 34

Cursor menu ..................................................................................................................................... 34

Map corrections 36

About Map Share ............................................................................................................................. 36

Correcting a map error ..................................................................................................................... 36

Types of map correction .................................................................................................................. 36

Sounds and voices 40

About sounds and voices ................................................................................................................ 40

About voices that speak street names ............................................................................................ 40

Selecting a voice .............................................................................................................................. 40

Changing the volume level .............................................................................................................. 40

Settings 41

About Settings .................................................................................................................................. 41

2D/3D settings .................................................................................................................................. 41

Advanced settings ............................................................................................................................ 41

Car symbol ........................................................................................................................................ 42

Home location .................................................................................................................................. 42

Favorites ........................................................................................................................................... 42

Keyboard ........................................................................................................................................... 43

Make your own menu ...................................................................................................................... 43

Map colors ........................................................................................................................................ 44

Manage POIs ..................................................................................................................................... 44

Reset factory settings ....................................................................................................................... 44

Planning settings .............................................................................................................................. 45

Safety settings .................................................................................................................................. 46

Show POI on map ............................................................................................................................ 46

Status bar .......................................................................................................................................... 46

Switch map ....................................................................................................................................... 47

Turn off voice guidance / Turn on voice guidance ......................................................................... 47

Units .................................................................................................................................................. 47

Version information .......................................................................................................................... 48

Voices ................................................................................................................................................ 48

Points of Interest 49

About Points of Interest ................................................................................................................... 49

Creating POIs .................................................................................................................................... 49

Using POIs to plan a route ............................................................................................................... 50

Showing POIs on the map ............................................................................................................... 51

Calling a POI...................................................................................................................................... 51

Setting warnings for POIs ................................................................................................................ 52

Manage POIs ..................................................................................................................................... 52

Help 53

About getting help ............................................................................................................................ 53

Using Help to drive to a local service .............................................................................................. 53

Help menu options ........................................................................................................................... 53

Favorites 55

About Favorites ................................................................................................................................ 55

Creating a Favorite ........................................................................................................................... 55

Using a Favorite ................................................................................................................................ 56

Changing the name of a Favorite .................................................................................................... 56

Deleting a Favorite ........................................................................................................................... 57

Traffic 58

About RDS-TMC ............................................................................................................................... 58

Safety Notice .................................................................................................................................... 58

Using traffic information .................................................................................................................. 58

Taking the fastest route .................................................................................................................... 59

Minimizing delays ............................................................................................................................. 59

Making commuting to work easier .................................................................................................. 60

Getting more information about an incident................................................................................... 61

Checking traffic incidents in your area ............................................................................................ 61

Changing traffic settings .................................................................................................................. 62

Traffic incidents ................................................................................................................................ 62

Traffic menu ...................................................................................................................................... 63

Speed Cameras 65

Important .......................................................................................................................................... 65

About Speed Cameras ..................................................................................................................... 65

Speed Camera warnings .................................................................................................................. 65

Changing the way you are warned .................................................................................................. 66

Safety camera symbols .................................................................................................................... 66

Report button .................................................................................................................................... 67

Reporting a new speed camera while on the move ....................................................................... 68

Reporting a new speed camera while at home .............................................................................. 68

Reporting incorrect camera alerts ................................................................................................... 68

Types of fixed speed camera you can report ................................................................................. 68

Speed Enforcement Zone warnings ................................................................................................ 69

Speed Cameras menu ...................................................................................................................... 70

TomTom HOME 72

About TomTom HOME .................................................................................................................... 72

Installing TomTom HOME ................................................................................................................ 72

MyTomTom account ........................................................................................................................ 72

Updating your device ....................................................................................................................... 73

Introducing HOME help ................................................................................................................... 74

Customer support 75

Getting help to use your navigation device .................................................................................... 75

Status & information ......................................................................................................................... 75

Addendum 76

Switching on and off

Read me first

Your Mazda NB1 switches on when your car engine starts and switches off automatically when you turn off your car's engine.

Until a connection has been established between the car and the Mazda NB1, the screen shows audio-related information and the NAV button on the main display is inactive. In some situations when you start the car, the navigation device may restart. If this happens, press the NAV button. A black screen is shown and it may take up to 30 seconds for the main screen to appear.

Under extreme temperature conditions, the navigation device may not start. When the temperature is within the normal range again, the device should start. If the device fails to start automatically in this situation, stop your car engine and start the car engine again.

Note: In some situations, your navigation system may restart when turning your key in the ignition from ACC-ON to the engine start position. If this happens, it may take up to 30 seconds for the main screen to appear on the navigation system.

Setting up

When you first switch on your device, you have to answer a few questions to set up the device. Answer the questions by tapping the screen.

GPS reception

When you first start your Mazda NB1 navigation device, the device may need a few minutes to determine your GPS position and show your current position on the map. In the future, your position will be found much faster, usually within a few seconds.

In areas where GPS reception is not possible, such as tunnels, your location may not be accurate.

Important: The GPS antenna is located in the dashboard so do not put objects on the dashboard.

Device not starting

In rare cases, your TomTom navigation module may not start correctly or may stop responding to your taps. For example, if the device temperature is too high or too low, the system shuts down.

In rare circumstances, you may need to reset your navigation device. To reset your device, switch off the car engine and then remove the memory card. Re-insert the memory card and switch the car engine on again.

Sharing information with TomTom

When you first start navigating or perform a reset, your device asks for permission to collect some information about your use of the navigation device. The information is stored on the device until we retrieve it. We use it anonymously to improve our products and services.

You can change whether you share this information with us at any time by doing the following:

1. In the Main Menu, tap Settings.

2. Tap Me and my device.

3. Tap My information.

4. Tap No to stop sharing or tap Yes to start sharing.

Additional information

Your navigation device will continuously collect information only if you give us your permission. The information is stored on your device until you connect it to your PC; then the information is sent to TomTom and deleted from your device. The information includes details that identify the navigation device, details about routes and locations and information entered while you were using the navigation device.

Immediately after receiving this information, TomTom automatically and irreversibly destroys any information that allows identification of you or your device. This, now anonymous, information is

used to improve TomTom’s products and services, such as maps, reports on Points of Interest

and average speeds driven. These products and services are also used by government agencies and businesses.

Using your navigation device, you can join the MapShare Community, or report speed cameras or danger zones. If you choose to use either of these services, your reports, that include location information and your MyTomTom account name, are sent to TomTom and kept together with your MyTomTom account. TomTom then uses your information to improve its maps and safety cameras.

If you no longer allow sharing of information, none of the above information is sent to TomTom and information previously stored on your device is deleted.

TomTom will not give anyone else access to the information collected from your navigation device.

In choosing to provide TomTom with information you are helping to make driving better, specifically by improving maps and traffic flows and reducing congestion. We appreciate your help.

If you think that your information is not being used for the purpose for which you have provided it to TomTom, contact us at tomtom.com/support.

See our privacy policy at tomtom.com/privacy.

Take care of your device

It is important to take care of your device as follows:

 Your device is not designed for use in extreme temperatures and any such exposure may

cause permanent damage.

 Do not open the casing of your device under any circumstances. Doing so may be dangerous

and will void the warranty.

Important: If you sell your car, you should remove all personal information from your navigation device first. To remove your personal information, tap Settings and then tap Reset factory set- tings.

More information

The website mazdanav.com offers direct access to additional information for your product (English only). This includes information on the use of voice-recognition and on performing updates.

On the website, click Navigation system owner information.

About your memory card

The memory card

A memory card is supplied with your navigation system. It includes a map of your group of countries.

Updates are regularly produced by TomTom, particularly for maps and services like speed cameras. These updates are only available for download by inserting your navigation system's memory card into a computer that is connected to the internet.

Once your new vehicle has been delivered, if a newer version of your map is available within 60 days of first using your navigation device, you can download this map for free.

Important: In order to qualify for the Latest Map Guarantee you need to check if a new map is available within the 60 day period, and you are only entitled to one free map download.

Inserting your memory card

To insert your memory card into your Mazda NB1 in your car, do the following:

1. Switch off the ignition in the car so that the navigation system is switched off.

2. Insert the memory card, taking care to handle it carefully and that it is the right way around.

Note: Only use your memory card for operating and updating your navigation system. Do not insert the memory card into another vehicle or into any other device such as a camera.

Removing your memory card

1. Push gently on the memory card.

2. Remove the memory card, taking care to handle it carefully.

About TomTom HOME

Using TomTom HOME you can register and manage your Mazda NB1 to receive free updates and buy new services. It's a good idea to connect to HOME frequently so you can do the following:

 Download for free the most recent map available for your device, if you connect to TomTom

HOME within 60 days of buying your device.

 Download updates for your device for free, including Map Share updates and other services

included with your product.

 Add new items to your device, like maps, voices and POIs, as well as buy TomTom services

and manage your subscriptions.

 Share your map corrections and other content with the TomTom community.  Make and restore backups of your device.

When using HOME, you can get help with what you are doing from the HOME Help. You can also read about all the other things that HOME can do for you.

Tip: We recommend using a broadband internet connection whenever you connect to HOME.

Installing TomTom HOME

The steps below refer to Internet Explorer on Windows XP. If you're using another browser or operating system, visit tomtom.com/support for more information.

To install TomTom HOME on your computer, do the following:

1. Connect your computer to the internet.

2. Click the link below to download the latest version of TomTom HOME:

tomtom.com/home

3. We recommend downloading the file to your computer by clicking Save.

4. Once the download is complete, click Open.

If you accidentally closed the Download Complete window, locate the file TomTomHOME2winlatest.exe on your computer and double-click it.

5. If you get a security warning, click Run.

6. Click Next, then click Install.

The installation starts.

7. Once the installation is complete click Finish.

Initialising your memory card

To use a new or empty memory card with TomTom HOME, it needs to be initialized so that HOME can detect it. To initialize your card, do the following:

1. Start the car and switch on your Mazda NB1.

2. Press the NAV button to switch to navigation mode.

The navigation screen appears.

3. Insert the new memory card into your Mazda NB1.

4. Wait for a few seconds so that the card can be initialized by your Mazda NB1.

5. Remove the card from your Mazda NB1 and insert it into the card reader connected to your

computer.

Your new card is now ready for use with TomTom HOME.

Updating your device

Before you start, make sure you have a backup of your device or memory card. For more information, see Backing up your navigation device.

You can check for updates for your maps, services and for a whole range of other free items or items for purchase. The instructions below describe how to update the TomTom application on your device.

Note: LIVE Services are not available in all countries or regions, and not all LIVE Services are available in all countries or regions. You may be able to use LIVE Services when traveling abroad. For more information on available services, go to tomtom.com/services.

To check for an updated application version do the following:

1. Insert your memory card into the card reader connected to your computer.

2. Wait for TomTom HOME to start.

3. If HOME does not automatically check for updates, click Update my device in the HOME

menu.

Note: If you would like to install an application you downloaded previously, click Add Traffic, Voices, Speedy Cameras, etc. and then click Items on my computer.

4. If a new application is available, it is listed on the next screen.

5. Make sure the new application is selected, then click Download updates.

HOME downloads the selected items.

6. HOME then installs the selected items on your memory card.

7. Click Done.

8. Click Device > Disconnect Device. You can then disconnect your card from your computer.

Backing up your navigation device

The easiest way to make a backup of all the contents of your TomTom navigation device is by using TomTom HOME. You can make one backup for your device and store it on your computer. When you make a new backup, the old backup for that device is overwritten.

1. Insert your memory card into the card reader connected to your computer.

TomTom HOME starts automatically.

Tip: If TomTom HOME does not start, do one of the following:

Windows: Click on the Start menu and go to All Programs > TomTom and then click on TomTom HOME.

Mac: Click Go in the Finder menu and choose Applications, then double-click TomTom HOME.

2. Click Back up and restore.

3. Click Back up my device.

4. Click Back up now.

HOME backs up your device by backing up the contents of your memory card.

5. Wait until HOME has finished creating the backup, then click Done.

To see where HOME saves your backups do one of the following:

Windows: Click Tools > TomTom HOME Preferences and then select the Folder Preferences tab.

Mac: Click TomTom HOME > Preferences... and then select the Folder Preferences tab.

To restore a backup, click Back up and restore in the HOME menu and then click Restore my device.

Some navigation devices contain a GSM/GPRS module which can interfere with electrical devices

Safety Notice

such as cardiac pacemakers, hearing aids and aviation equipment.

Interference with these devices may endanger the health or life of you or others.

If your device includes a GSM/GPRS module, do not use it near unprotected electrical units or in areas where the use of mobile telephones is prohibited, such as hospitals and aircraft.

Safety settings

We recommend using the safety settings to make your driving as safe as possible.

These are some of the options included in the safety settings:

 Show safety reminders  Warn when driving faster than allowed

If your device supports voice control, you can also drive more safely by using voice commands to control your navigation device.

About the commander

The commander

The commander is an input device located near the arm rest of your car in the central console.

It has a central stick that you can move in the following ways:

 Push.  Rotate left or right.  Tilt up or down.  Tilt left or right.

Using the commander

1. Push - selects the item in focus, for example, the volume control when focused on the middle

panel of the status bar in the Driving View. Switches items on or off.

2. Rotate left or right - operates slider bars, such as the volume control, and zoom in/out in the

Driving View.

3. Tilt up or down - moves the focus around the different areas of the screen or around the map

when browsing.

4. Tilt left or right - moves you between pages in a menu or between tabs on a screen.

Examples of how to carry out common tasks using the commander

 To access the Main menu from the Driving View, push the stick in.  To zoom in or out in the Driving View, rotate the stick right and left.  When focused on the map in the Driving View, tilt right to access the traffic menu.  When focused on the map in the Driving View, tilt left to access the quick menu and the voice

control microphone button.

 When focused on the map in the Driving View, tilt down to access the volume control in the

centre panel of the status bar.

 To access the Driving View from the Main menu, tilt the stick down until you are focused on

the Done button, then push in.

 To move between letters on the keyboard screen, tilt left or right. Use tilt up or down to move

to the letter above or below. You can also use rotate left or right to move between letters.

Planning a route

Important: In the interest of safety and to reduce distractions while you are driving, you should

always plan a route before you start driving.

To plan a route on your Mazda NB1, do the following:

1. Tap the screen to open the Main Menu.

2. Tap Navigate to or Drive to.

3. Tap Address.

You can change the country or state setting by tapping the flag before you select a city.

4. Enter the town or city name, or the postcode.

Tip: Instead of typing the address, tap the microphone button to enter the address by speaking to your Mazda NB1.

Towns with similar names are shown in the list while you type.

When the correct city or town appears in the list, tap the name to select the destination.

5. Enter the street name.

Streets with similar names are shown in the list while you type.

When the correct street name appears in the list, tap the name to select the destination.

6. Enter the house number, then tap Done.

7. The location is shown on the map. Tap Select to continue or tap Back to enter another ad-

dress.

Tip: If you want your final destination to be a car park, tap Car park and select a location from the list of car parks close to your general destination.

8. When the new route is shown, tap Done.

For more information about the route, tap Details.

To change your route, for example, to travel via a particular location or to select a new destination, tap Change route.

Your device starts to guide you to your destination, using spoken instructions and on-screen directions.

Route summary

The route summary shows an overview of your route, the remaining distance to your destination and the remaining estimated trip time.

To view the route summary, tap the right-hand panel on the status bar in the Driving view or tap View route in the Main Menu and then tap Show route summary.

If you have HD Traffic or an RDS-TMC receiver, the route summary also shows traffic information about delays on your route.

Note: To use a TomTom traffic information service, you may need a subscription or a receiver. Traffic services are not supported in all countries or regions. For more information, visit

tomtom.com/services.

Selecting a route type

Status bar

Tap Status bar in the Settings menu to enable or disable arrival time notifications.

To enable arrival time notifications select Leeway.

Every time you plan a route, you can choose to be asked about the type of route you want to plan. To do this, tap Settings followed by Route planning and then tap Ask me every time I plan.

The types of route you can choose from are as follows:

 Fastest route - the route which takes the least time.  Eco route - the most fuel-efficient route for your trip.  Shortest route - the shortest distance between the locations you set. This may not be the

quickest route, especially if the shortest route is through a town or city.

 Avoid highways - a route which avoids highways.

Using arrival times

When you plan a route, your Mazda NB1 asks you if you need to arrive at a particular time.

Tap YES to enter a preferred arrival time.

Your Mazda NB1 calculates your arrival time and shows you whether you will arrive on time.

You can also use this information to work out when you need to leave. If your Mazda NB1 shows that you will arrive 30 minutes early, you can wait and leave in 30 minutes time, rather than arrive early.

Your arrival time is constantly recalculated during your trip. The status bar shows whether you will arrive on time or if you are going to be late.

Navigation menu options

When you tap Navigate to or Drive to, you can set your destination in many ways, not just by entering the address. The other options are listed below:

Home

Tap this button to navigate to your Home location.

You will probably use this button more than any other.

Favorite

Tap this button to select a Favorite as your destination.

Address

Tap this button to enter an address as your destination.

Recent destination

Tap this button to select your destination from a list of places you have recently used as destinations.

Point of Interest

Tap this button to navigate to a Point of Interest (POI).

Point on map

Tap this button to select a point on the map as your destination using the map browser.

Latitude Longitude

Tap this button to enter a destination using latitude and longitude values.

Planning a route in advance

You can use your Mazda NB1 to plan a route in advance, selecting your starting point and your destination.

Here are some more reasons to plan a route in advance:

 Find out how long a trip is going to take before you start.  You can also compare trip times for the same route at different times of the day or on different

days of the week. Your Mazda NB1 uses IQ Routes when planning a route. IQ Routes calculates routes based on the real average speeds measured on roads.

 Study the route of a trip you are planning.  Check a route for someone who is coming to visit you and then explain the route to them in

detail.

To plan a route in advance, follow these steps:

Show instructions

Tap this button for a list of all the turn instructions on the route.

This is very useful if you need to explain a route to someone else.

Show map of route

Tap this button to see an overview of the route using the map browser.

Show route demo

Tap this button to watch a demo of the trip. You can interrupt the demo at any time by tapping the screen.

1. Tap the screen to bring up the Main menu.

2. Tap the arrow button to move to the next menu screen and tap Plan route.

This button is shown while there is no planned route on your Mazda NB1.

3. Select the starting point for your trip in the same way that you would select your destination.

4. Set the destination for your trip.

5. If Route planning settings are set to Ask me every time I plan, select the type of route you

want to plan:

quickest route, especially if the shortest route is through a town or city.

 Avoid highways - a route which avoids highways.

6. Choose the date and time that you will make the trip you are planning.

Your Mazda NB1 uses IQ Routes to work out the best possible route at that time. This is useful to see how long a trip takes at different times of the day or on different days of the week.

Your Mazda NB1 plans the route between the two locations you selected.

Viewing route information

You can access these options for the route you last planned by tapping View route in the Main Menu or the Details button on the route summary screen.

You can then select from the following options:

Show route sum-

mary

Tap this button to open the route summary screen.

Show destination

Tap this button to see a preview of your destination.

You can navigate to a parking lot near your destination, and view any available information about your destination, for example, the phone number.

Show traffic on

route

Tap this button to see all the traffic incidents on your route.

Note: This button is only shown if your device has either a traffic subscription or an RDS-TMC Receiver. Traffic information is not available in all countries or regions. For more information about TomTom traffic information services, go to tomtom.com/services.

Voice control

There are two types of voice control.

The first type is provided by Mazda and you can read about it in the guide that came with your car.

The second type is provided by your navigation device and you can use it to plan routes and control other features of your navigation device. You do this by initially tapping the screen on the navigation device.

About navigation device voice control

Note: Voice control is not supported on all devices or in all languages.

Instead of tapping the screen to control your Mazda NB1, you can use your voice to control your Mazda NB1.

For example, to increase the volume on your Mazda NB1, you can say, "Increase volume" or "Volume 50%."

To view the list of available commands, tap Help in the Main menu then tap Product manuals and then tap What can I say.

Important: Voice control requires a computer voice. When there are no computer voices installed on your Mazda NB1, this feature is not available.

To select a computer voice, tap Voices in the Settings menu, then tap Change voice and select a computer voice.

Using voice control

Voice control is switched on by default if it is supported for your chosen language.

The following example shows how to use voice control to plan a trip to your Home address:

1. Tap the microphone button in the Driving view to turn on the microphone.

You see a screen with examples of commands you can say.

Tap Help in the Main menu then tap Product manuals followed by What can I say to see a full list of commands you can say.

2. When you hear "Say a command" followed by a tone, say a command of your choice. For

example, you can say "Drive home." Your Mazda NB1 is only ready to listen after your hear the tone.

While you are speaking the microphone monitor shows how well the device can hear your voice:

A green bar means the device can hear your voice.

A red bar means your voice is too loud for the device to recognize individual words.

A gray bar means your voice is too quiet for the device to recognize individual words.

For some phrases, your Mazda NB1 repeats what you say and asks for confirmation.

Tip: For the best recognition of what you say, speak normally without trying to articulate words in an unnatural way. If there is excessive road noise, for example, you may need to speak in the direction of the microphone.

3. If the command is correct, say "Yes."

If the command is incorrect, say "No" and repeat the command after you hear the prompt and tone again.

Your Mazda NB1 plans a route from your current location to your destination.

Tip: To stop your Mazda NB1 from listening for further commands, say "Cancel." To go back one step, say "Back."

Planning a trip using your voice

Note: It's not possible to plan a route using your voice for all maps in all countries, or in all lan-

guages.

You can navigate to any of the following types of places using your voice:

 An address, including home.  Cities and towns and their centers.  Favorites.  POI categories.  POIs for named brands of, for example, restaurants, gas stations, car rental companies and

gyms.

 A recent destination.

To plan a route to an address using speech, do the following:

1. Tap the voice control button in the Driving view.

2. When you hear the tone, you can say, for example "Drive to an address."

Tip: Your device has either Navigate to or Drive to on the button in the Main Menu. When

Spoken address

Tap this button to enter an address entirely using speech.

Spoken address helps you to enter information without tapping the screen.

planning a route to an address using speech, say "Navigate to address" if the button shows Navigate to or "Drive to address" if the button shows Drive to.

3. Say the full address for your destination, for example, 112 Main Street, Riverside, California.

Numbers can be pronounced naturally or one at a time. For example, 357 can be pronounced as "Three fifty seven" or "Three, five, seven."

Your Mazda NB1 tells you what it heard.

4. Say "Yes" if the address is correct. If shown a list of addresses, say the list number for the cor-

rect address or say "none of these."

If part of the address is incorrect, you can say something like "change the number," "change the street," "change the city" or "change the state" to correct the incorrect part.

To begin again, say "start over."

Tip: You may want to limit the search area for addresses to one state if you drive within the same state most of the time. To change the search area for addresses, tap Settings in the Main menu then tap Voice control and then tap Set address search area.

Your Mazda NB1 starts to guide you to your destination, using spoken instructions and on-screen directions.

Tips:

You can also use your voice to search for the nearest Point of interest (POI) category or a popular brand name by saying something like "Drive to the nearest doctor" or "Drive to the nearest Starbucks."

To select a Recent destination or a Favorite, say "Drive to a recent destination" or "Drive to a Favorite."

Entering addresses using your voice

Even if you don't use voice control to start planning a trip, you can still use your voice to enter the address.

To start planning a trip tap Navigate to or Drive to in the Main menu, then tap Address, and then

Spoken Address.

Tips

To make it easier to start entering an address using your voice, you can add this button to the Quick Menu on the Driving View. To do this, tap Make your own menu in the Settings menu and then tap Drive to spoken address.

Your Mazda NB1 recognizes places and street names when they are spoken in the local language using local pronunciation.

Spoken address entry is not possible for postal codes which must be entered using the keyboard.

About the Driving View

The Driving View

When your Mazda NB1 navigation device starts for the first time, you are shown the Driving View along with detailed information about your current position.

Tap the center of the screen at any time to open the Main Menu.

The Driving View

1. Zoom button - tap the magnifying glass to show buttons for zooming in and out.

2. Quick menu - to enable the quick menu, tap Make your own menu in the Settings menu.

3. Your current position.

4. Road sign information or the next street name.

5. Traffic sidebar. Tap the sidebar to open the Traffic menu.

The traffic sidebar is only shown if your device has either an HD Traffic subscription or an RDS-TMC Receiver. Traffic information is not available in all countries or regions.

6. Microphone button for voice command and control.

7. The time, your current speed and the speed limit, if known. To see the difference between

your preerred arrival time and your estimated arrival time, check the Leeway checkbox in the Status bar settings.

Note: Not all options may be available.

Tap this part of the status bar to switch between a 3D map and a 2D map.

8. The name of the street you are on.

9. Navigation instruction for the road ahead and the distance to the next instruction. If the second

Sound muted - this symbol is shown when the sound has been muted.

To turn the sound back on, tap the middle panel in the status bar.

Enhanced Positioning Technology (EPT) - this symbol is shown when your device is using EPT to estimate your current location.

EPT automatically estimates your position when the GPS signal is lost while you are driving, such as when you are in a tunnel.

instruction is less that 150m after the first instruction, you see it shown immediately instead of the distance.

Tap this part of the status bar to repeat the last voice instruction and to change the volume. You can also tap here to mute the sound.

10. The remaining trip time, the remaining distance and your estimated arrival time.

Tap this part of the status bar to open the Route Summary screen.

To change the information shown in the status bar, tap Status bar in the Settings menu.

Driving View Symbols

About lane guidance

Advanced Lane Guidance

Note: Lane guidance is not available for all junctions or in all countries.

Your Mazda NB1 navigation device helps you prepare for highway exits and junctions by showing the correct driving lane for your planned route.

As you approach an exit or junction, the lane you need is shown on the screen.

Using lane guidance

There are two types of lane guidance:

 Lane images

To turn lane images off, tap Settings in the Main menu, then tap Advanced settings. Clear the checkbox for Show lane images.

Tip: Tap anywhere on the screen to return to the Driving View.

 Instructions in the status bar

Tip: If no lane guidance is shown in the status bar and all lanes are highlighted, you can use any lane.

Making changes to your route

Change route

Tap this button to change the current route.

This button is only shown while there is a planned route on your device.

Calculate alterna-

tive

Tap this button to find an alternative to the current route.

This button is only shown while there is a planned route on your Mazda NB1 device.

This is a simple way to search for a different route to your current destination.

Your device calculates a new route from your current location, to reach your destination using completely different roads.

The new route is shown next to the original route so that you can select the route you want to use.

Avoid roadblock

Tap this button while driving on a planned route, to avoid a roadblock or traffic congestion on the road ahead.

Your device will suggest a new route which avoids the roads on your current route for the selected distance.

If the roadblock or traffic congestion suddenly clears, tap Recalculate

route to replan your original route.

Important: Be aware that when a new route is calculated you might be

asked to turn off the current road immediately.

Minimize delays

Tap this button to avoid traffic delays on a planned route.

It is not always possible to avoid all traffic delays. Though your device continuously checks for delays on your route, you can tap this button to manually start a check. Your device then calculates the best route to avoid all or most of the delays.

Note: This button is only shown if your device has either a traffic subscription or an RDS-TMC Receiver. Traffic information is not available

Changing your route

After you plan a route, you may want to change the route or even the destination. There are various ways to change your route without the need to completely replan the entire trip.

To change the current route, tap Change route in the Main menu:

Change route menu

To change the current route or your destination, tap one of the following buttons:

in all countries or regions. For more information about TomTom traffic information services, go to tomtom.com/services.

Change destination

Tap this button to change the current destination.

When you change the destination, you are shown the same options and asked to enter the new address in the same way as when you plan a new route.

Avoid part of route

Tap this button to avoid part of the current route.

You are shown a list of the street names on your route. When you tap one of the street names, your device calculates a detour to avoid the selected street. The route summary shows both the new route and your original route. Tap the panel at the right to select one of the routes and then tap Done.

If you do not want to use either of the routes shown in the route summary, tap Change route to find another way to change your route.

Add waypoint...

Tap this button to change your route by selecting a location you want to travel past, perhaps to meet someone along the way.

When you select a location to travel past, you are shown the same options and asked to enter the new address in the same way as when you plan a new route.

Your device calculates the route to your destination via the selected location.

The selected location is shown on the map using a marker.

You receive a warning when you reach your destination and when you travel past a marked location.

About waypoints

Note: This feature is not available on all TomTom navigation devices.

You can choose to use waypoints for any of the following reasons:

 You want to travel along a certain road or through a certain area on the way to your destina-

tion.

 You want to make stops before reaching your final destination.

Your route can include the following types of waypoints:

 Waypoints with notification - a waypoint that you are likely to want to stop and get out at, for

example, a POI, a gas station or a friend's house. You are notified when nearing and arriving at the waypoint with voice instructions or a message.

 Waypoints without notification - a waypoint that you are using to help guide your route, for

example, you want to travel from Amsterdam to Rotterdam using a certain highway. You are not notified when nearing the waypoint.

Adding the first waypoint to your route

To add the first waypoint to your route, do the following:

1. Tap the screen to bring up the Main menu.

2. Tap Change route.

3. Tap Add waypoint.

Tip: You can also tap View map and then tap Add waypoint in the cursor menu. If your device supports Voice control, you also speak commands to add waypoints.

4. Choose the location for your waypoint from a choice of Home, Favorite, Address, Recent des-

tination, POI or you can perform a search.

On the route summary screen, a message confirms that the route is being recalculated to include the waypoint. On the Change route menu, the Travel via button changes to show that you now have one waypoint on your current route.

Note: All waypoints are added initially as waypoints with notification. The maximum number of waypoints you can add is four.

Adding further waypoints to your route

To add more waypoints to your route after the first one has been added, do the following:

1. Tap the screen to bring up the Main menu.

2. Tap Change route.

3. Tap Manage waypoints.

Tip: If your device supports Voice control, you also speak commands to add waypoints.

4. Tap Add.

5. Choose the location for your waypoint from a choice of Home, Favorite, Address, Recent des-

tination, POI or you can perform a search.

A message tells you where in the list of waypoints the new one has been inserted.

6. Tap Done.

On the route summary screen, a message confirms that the route is being recalculated to include your waypoints.

7. Repeat to add more waypoints.

On the Change route menu, the Manage waypoints button changes to show that you now have several waypoints on your current route.

Note: All waypoints are added initially as waypoints with notification.

Changing the order of waypoints

Waypoints are automatically added in an optimized order but you can still change the order manually if you need to. To change the order of waypoints, do the following:

1. Tap the screen to bring up the Main menu.

2. Tap Change route.

3. Tap Manage waypoints.

You see a list of your waypoints.

4. Tap the waypoint you want to move up or down.

You see a screen with the name of your waypoint at the top.

5. Tap Move up or Move down.

Your waypoint changes its position in the list and you are immediately returned to your list of waypoints.

Tip: You cannot move an unvisited waypoint into a list of already visited waypoints.

Deleting a waypoint

To delete a waypoint, do the following:

1. Tap the screen to bring up the Main Menu.

2. Tap Change route.

3. Tap Manage waypoints.

You see a list of your waypoints.

4. Tap the waypoint you want to delete.

You see a screen with the name of your waypoint at the top.

5. Tap Delete.

Your waypoint is deleted and you are immediately returned to your list of waypoints.

Changing notification settings for a waypoint

If a waypoint has notification switched on, you see an icon next to it in your list of waypoints. To switch notification on or off for a waypoint, do the following:

1. Tap the screen to bring up the Main menu.

2. Tap Change route.

3. Tap Manage waypoints.

You see a list of your waypoints.

4. Tap the waypoint that you want to change the notification setting for.

You see a screen with the name of your waypoint at the top.

5. Tap Switch on/off notification.

The notification setting changes for your waypoint and you are immediately returned to your list of waypoints.

Tip: If a waypoint has already been visited, you cannot switch notification on or off.

Reactivating a waypoint

Note: You can only reactivate a waypoint that has already been visited. Visited waypoints are

grayed out.

To reactivate a waypoint, do the following:

1. Tap the screen to bring up the Main menu.

2. Tap Change route.

3. Tap Manage waypoints.

You see a list of your waypoints.

4. Tap the visited waypoint that you want to reactivate.

You see a screen with the name of your waypoint at the top.

5. Tap Reactivate.

The waypoint is deleted and reinserted into the list of waypoints that haven't yet been visited.

About viewing the map

View map

You can view the map in the same way as you might look at a traditional paper map. The map shows your current location and many other locations such as Favorites and POIs.

To view the map in this way, tap View map or View route in the Main menu.

You view different locations on the map by moving the map across the screen. To move the map, touch the screen and drag your finger across the screen.

To select a location on the map, tap the location on the map. The cursor highlights the location and displays useful information about the location in an information panel. Tap the information panel to create a Favorite or plan a route to that location.

View map

Important: Not all features on this screen can be controlled using the commander. Use the

touchscreen instead.

1. The scale bar

2. Traffic - current traffic incidents. Use the Options button to select whether traffic information is

shown on the map. When traffic information is shown on the map, POIs and Favorites are not shown.

Note: To use a TomTom traffic information service, you may need a subscription or a receiver. Traffic services are not supported in all countries or regions. For more information, visit tomtom.com/services.

3. Marker

Markers point to your current location (blue), your home location (yellow) and your destination (red). The marker shows the distance to the location.

Tap a marker to center the map on the location pointed to by the marker.

You can also set your own marker. Tap the cursor button, then tap Set marker position to place a green marker at the cursor position.

To turn markers off, tap Options, then Advanced and clear the Markers checkbox.

4. Options button

5. The cursor with street name balloon

Tap the button in the street name balloon to open the cursor menu. You can navigate to the cursor position, make a Favorite of the cursor position, or find a Point of Interest near the cursor position.

6. The Find button

Tap this button to find specific addresses, favorites or Points of Interest.

7. The zoom bar

Zoom in and out by moving the slider.

Options

Tap the Options button to set the information shown on the map and show the following information:

 Traffic - select this option to show traffic information on the map. When traffic information is

shown, POIs and Favorites are not shown.

Note: To use a TomTom traffic information service, you may need a subscription. Traffic services are not supported in all countries or regions. For more information, visit

tomtom.com/services.

 Names - select this option to show street and city names on the map.  Points of interest - select this option to show POIs on the map. Tap Choose POIs to choose

which POI categories are shown on the map.

 Images - select this option to show satellite images of the area being viewed. Satellite images

are not available in every map or for every location on the map.

 Favorites - select this option to show your Favorites on the map.

Tap Advanced to show or hide the following information:

 Markers - select this option to enable markers. Markers point to your current location (blue),

your home location (yellow) and your destination (red). The marker shows the distance to the location.

Tap a marker to center the map on the location the marker is pointing to.

To create your own marker, tap the cursor button. Then tap Set marker position to place a green marker at the cursor position.

To disable markers, tap Options, then tap Advanced and deselect Markers.

 Coordinates - select this option to show GPS coordinates in the lower left corner of the map.

Cursor menu

The cursor can be used to do more than highlight a location on the map.

Position the cursor on a location on the map, then tap the arrow and then tap one of the following

Navigate there

Tap this button to plan a route to the cursor position on the map.

View location

Tap this button to view information about the location on the map such as the address.

Set marker posi-

tion

Tap this button to create your own green marker and place it at the cursor position.

If a green marker exists, this button changes to Delete marker.

Find POI nearby

Tap this button to find a POI near the cursor position on the map.

For example, if the cursor currently highlights a restaurant location on the map, you can search for a nearby parking garage.

Correct location

Tap this button to make a map correction for the cursor position on the map.

You can make the correction only on your own map or you can share the correction with the TomTom Map Share community.

Add as Favorite

Tap this button to create a Favorite at the cursor position on the map.

Add as POI

Tap this button to create a POI at the cursor position on the map.

Travel via...

Tap this button to travel via the cursor position on the map as part of your current route. Your destination remains the same as before but your route now includes this location.

This button is only available while there is a planned route.

Center on map

Tap this button to center the map on the cursor position.

buttons:

About Map Share

(Un)block street

Tap this button to block or unblock a street. You can block or unblock the street in one or both directions.

For example, to correct a street near to your current location, do the following:

1. Tap (Un)block street.

2. Tap Near you to select a street near your current location. You can

select a street by name, a street near your Home location or a street on the map.

Map corrections

Map Share helps you correct map errors. You can correct several types of map error.

To make corrections to your own map, tap Map corrections in the Services menu.

Note: Map Share is not available in all regions. For more information, go to

tomtom.com/mapshare.

Correcting a map error

Important: For safety reasons, do not enter the full details of a map correction while you are driv-

ing. Mark the location of the map error instead and enter the full details later.

To correct a map error, do the following:

1. Tap Map corrections in the Services menu.

2. Tap Correct a map error.

3. Select the type of map correction you want to apply.

4. Select how you want to select the location.

5. Select the location. Then tap Done.

6. Enter the details of the correction. Then tap Done.

7. Select whether the correction is temporary or permanent.

8. Tap Continue.

The correction is saved.

Types of map correction

To make a correction to your map, tap Map corrections in the Services menu, then tap Correct a map error. There are several types of map correction available.

3. Select the street or section of a street you want to correct by tapping

it on the map.

The street you select is highlighted and the cursor shows the name of the street.

4. Tap Done.

Your device shows the street and whether the traffic is blocked or allowed in each direction.

Important: Not all features on this screen can be controlled using the commander. Use the touchscreen instead.

5. Tap one of the direction buttons to block or unblock the flow of traffic

in that direction.

6. Tap Done.

Reverse traffic

direction

Tap this button to correct the traffic direction of a one-way street, where the direction of traffic is different to the direction shown on your map.

Note: Reverse traffic direction only works for one-way streets. If you select a two-way street you will be given the chance to block/unblock the street rather than changing the direction.

Edit street name

Tap this button to change the name of a street on your map.

For example, to rename a street near to your current location:

1. Tap Edit street name.

2. Tap Near you.

3. Select the street or section of a street you want to correct by tapping

it on the map.

The street you select is highlighted and the cursor shows the name of the street.

4. Tap Done.

5. Type the correct street name.

6. Tap Done.

Change turn re-

strictions

Tap this button to change and report incorrect road turn restrictions.

Change road speed

Tap this button to change and report the road speed limit.

Add or remove

rotary

Tap this button to add or remove a rotary.

Add missing POI

Tap this button to add a new Point of Interest (POI).

For example to add a new restaurant near to your current location:

1. Tap Add missing POI.

2. Tap Restaurant in the list of POI categories.

3. Tap Near you.

4. Select the location of the missing restaurant.

You can select the location by entering the address or by selecting the location on the map. Select Near you or Near home to open the map at your current location or at your Home location.

5. Tap Done.

6. Type the name of the restaurant then tap OK.

7. If you know the telephone number of the restaurant you can type it,

then tap OK.

If you don't know the number, just tap OK without typing a number.

Edit POI

Tap this button to edit an existing POI.

You can use this button to make the following changes to a POI:

 Delete the POI.  Rename the POI.  Change the telephone number of the POI.  Change the category that a POI belongs to.  Move the POI on the map.

Comment on POI

Tap this button to enter a comment about a POI. Use this button if you cannot edit the error with the POI using the Edit POI button.

Correct house

number

Tap this button to correct the location of a house number. Enter the address that you wish to correct and then indicate on the map the correct location of that house number.

Existing street

Tap this button to edit an existing street. Once you have selected the street, you can select an error to report. You can select more than one type of error for a street.

Missing street

Tap this button to report a missing street. You have to select the start and end points of the missing street.

City

Tap this button to report an error about a city, town or village. You can report the following types of error:

 City is missing  Wrong city name  Alternative city name  Other

Highway en-

trance/exit

Tap this button to report an error about a highway entrance or exit.

ZIP code

Tap this button to report an error about a ZIP code.

Other

Tap this button to report other types of corrections.

These corrections are not immediately applied to your map but are saved in a special report.

You can report missing streets, errors in highway entrances and exits and missing rotaries. If the correction you want to report is not covered by any of these report types, enter a general description then tap Other.

About sounds and voices

Sounds and voices

Your Mazda NB1 device uses sound for some or all of the following:

 Driving directions and other route instructions  Traffic information

Note: To use a TomTom traffic information service, you may need a subscription. Traffic services are not supported in all countries or regions. For more information, visit

tomtom.com/services.

 Warnings that you set

There are two types of voice available for your device:

 Voices that speak street names

Voices that speak street names are generated by your Mazda NB1. They provide route instructions and read aloud city and street names, traffic and other useful information.

 Human voices

These are recorded by an actor and only provide route instructions.

About voices that speak street names

Your Mazda NB1 uses text-to-speech technology to read the street names on your map as it guides you on your route.

A voice that speaks street names analyzes the whole phrase or sentence before speaking, to ensure that the sentence sounds as close as possible to natural speech.

This type of voice can also recognize and pronounce foreign towns and street names. For example, the English voice can read and pronounce French street names.

Selecting a voice

To select a different voice on your Mazda NB1 device, either tap Change voice in the Settings menu or tap Voices, then tap Change voice and select the required voice.

Changing the volume level

You can change the volume on your Mazda NB1 in the Driving view.

Tap the central panel on the status bar and move the slider to adjust the volume. The last route instruction is played so you can hear the new volume level.

About Settings

2D/3D settings

Tap this button to set the default view of the map. To switch between 2D and 3D views while driving, tap the left side of the status bar in Driving View.

It is sometimes easier to view the map from above, such as when navigating a complex road network.

The 2D view shows a two dimensional view of the map as though viewed from above.

The 3D view shows a three dimensional view of the map as though you are driving through the landscape.

The following buttons are available:

 In 2D view: rotate map in direction of travel - tap this button so the

map is rotated automatically with the direction you are traveling always at the top.

 Switch to 3D view when following a route - tap this button to show

the map automatically in 3D view when you are following a route.

Advanced settings

Tap this button to select the following advanced settings:

 Show house number before street name - when this setting is se-

lected, addresses are shown with the house number followed by the street name, such as 1600 Pennsylvania Avenue.

 Show street names - when this setting is selected, street names are

shown on the map in the Driving View. You do not need to select this option when your Mazda NB1 is set to read aloud street names using a computer voice.

 Show next street name - when this setting is selected, the name of

the next street on your route is shown at the top of the Driving view.

 Show current street name on map - when this setting is selected,

the name of the street you are on is shown at the bottom of the Driving view.

 Show location preview - when this setting is selected, a graphical

Settings

You can change the way your Mazda NB1 device looks and behaves. Most of the settings on your device can be accessed by tapping Settings in the Main menu.

Note: Not all settings described here are available on all devices.

2D/3D settings

Advanced settings

preview of your destination is shown during route planning.

 Enable automatic zooming in 2D view  Enable automatic zooming in 3D view  Show lane images - when this setting is selected, a graphical view of

the road ahead shows which lane you need when you approach a junction or highway exit. This feature is not available for all roads.

 Show tips - this setting switches tips on and off.  Automatically adjust clock for time zone - when this setting is se-

lected, your clock is automatically adjusted for your time zone.

Car symbol

Tap this button to select the car symbol that shows your current location in the Driving view.

Home location

Tap this button to set or change your Home location. You enter the address in the same way as you do when you plan a route.

Your Home location provides an easy way to plan a route to an important location.

For most people, your Home location will be your home address. However, you might prefer to set the location to another regular destination, such as your place of work.

Favorites

Tap this button to add, rename or delete Favorites.

Favorites provide an easy way to select a location without the need to enter the address. They do not need to be favorite places, they can simply be seen as a collection of useful addresses.

To create a new Favorite, tap Add. Then enter the location address in the same way that you enter an address when you plan a route.

Car symbol

Home location

Favorites

To view or change an existing Favorite, tap one of the items in the list. To see more Favorites on the map, tap the left or right buttons.

Keyboard

Tap this button to select the keyboards that will be available for your use and the layout of the Latin keyboard.

You use the keyboard to enter names and addresses, such as when you plan a route or search for the name of a town or a local restaurant.

Make your own

Tap this button to add up to six buttons to your own personalized menu.

If there are only one or two buttons in your menu, both buttons are shown in the Driving view.

If you have three or more buttons in your menu, then a single button is shown in the Driving view which opens your menu when tapped.

Keyboard

Make your own menu

Map colors

Tap this button to select the color schemes for day and night map colors.

Tap Search to search for a color scheme by typing the name.

Manage POIs

Tap this button to manage your own Point of Interest (POI) categories and locations.

You can set your Mazda NB1 device to let you know when you are near to selected POI locations. For example, you could set the device to let you know when you are approaching a gas station.

You can create your own POI categories and add your own POI locations to these categories.

You can, for example, create a new POI category called Friends. You could then add all your friends' addresses as POIs in this new category.

Tap the following buttons to create and maintain your own POIs:

 Add POI - tap this button to add a location to one of your own POI

categories.

 Warn when near POI - tap this button to set your device to warn you

when you are near selected POIs.

 Delete POI - tap this button to delete a POI.  Edit POI - tap this button to edit one of your own POIs.  Add POI category - tap this button to create a new POI category.  Delete POI category - tap this button to delete one of your own POI

categories.

Reset factory set-

tings

Tap this button to delete all your personal settings and restore the standard factory settings to your Mazda NB1.

This is not a software update and will not affect the version of the software application installed on your Mazda NB1.

Important: This feature deletes all your personal settings!

If you want to keep your personal information and settings, you should perform a full backup of your Mazda NB1 before you reset the device. You can then restore all your personal information and settings after you reset the device.

Manage POIs

Reset factory settings

Important: If you sell your car, you should remove all personal information from your navigation device first. To remove your personal information, tap Settings and then tap Reset factory settings.

This includes items such as your Home and Favorite locations, your personal menu and your POI categories and POI locations.

Planning settings

Tap the Planning settings button to set the way your Mazda NB1 calculates the routes that you plan. The settings for planning consist of several options that are spread over several screens. Each setting is described below.

Planning settings

Route planning

Set the type of route you want your Mazda NB1 to calculate.

Tap IQ Routes to set if you want the device to use IQ Routes information to help find the best route.

Fastest route

Choose whether you want to avoid highways.

Replanning settings

Note: This setting is only available if your device has either a traffic subscription or an

RDS-TMC Receiver. Traffic information is not available in all countries or regions. For more information about TomTom traffic information services, go to tomtom.com/services.

Set whether you want your Mazda NB1 to replan the current route if a faster route is found while you are driving. This is useful if traffic builds up or clears further ahead on your route. Choose from the following settings:

 Always switch to that route - select this option to receive no messages when a faster route is

found. The current route is automatically re-calculated to be the fastest one.

 Ask me if I want that route - select this option to be asked if you want to take the new route.

When asked if you want to take the alternative route, tap Yes to have the current route re-calculated as the fastest one. Tap No if you don't want to take alternative route.

Tap Info to see a summary of both the original and the alternative routes. You can then tap Done to take the fastest route or Current route to remain on your original route.

 Never change my route - select this option to receive no messages and simply be shown the

new route on the screen.

Map information settings

Set whether you want to be warned if your route passes through an area where your map contains only limited information.

Toll road, ferry, carpool lanes and unpaved road settings

Set how your Mazda NB1 should manage each of these four road features when the device calculates a route.

Carpool lanes are sometimes known as High Occupancy Vehicle Lanes and are not present in

Safety settings

Tap this button to select the safety features you want to use on your device.

Show POI on map

Tap this button to select the types of Point of Interest (POI) you want to see on the map.

1. Tap Show POI on map in the Settings menu.

2. Select the POI categories you want to be shown on the map.

Tap Search and use the keyboard to search for a category name.

3. Select whether you want POIs to be shown in 2D or 3D views of the

map.

4. Tap Done.

Point of Interest locations are shown on the map as symbols.

Status bar

Note: Not all options may be available.

Tap this button to select the information you want to see on the status bar:

 Horizontal - show the status bar at the bottom of the Driving view.  Vertical - show the status bar on the right-hand side of the Driving

view.

 Maximum speed

Important: The speed limit is shown next to your current speed. If you

drive faster than the speed limit, you see a warning indicator in the status bar, for example the status bar pane turns red.

Information about speed limits is not available for all roads.

 Remaining distance - the distance to your destination.  Leeway - your Mazda NB1 shows how late or early you will arrive,

compared with your preferred arrival time that was set when you

every country. To travel on these lanes, you may need to have more than one person in the car, for example, or the car may need to use environmentally-friendly fuel.

Route summary

Set whether you want the route summary screen to close automatically after you plan a route. If you select No, then you will need to tap Done to close the route summary screen every time you plan a route.

Safety settings

Show POI on map

Status bar

planned the route.

Maps

Tap this button to select the map you want to use for route planning and navigation.

Although you can store more than one map on the device, you can only use one map at a time for planning and navigation.

To switch from the current map to plan a route in another country or region, simply tap this button.

Note: The first time you switch to a map, you may need to connect to your MyTomTom account and activate the map.

Turn off Voice

guidance

Tap this button to switch off voice guidance. You will no longer hear spoken route instructions but you will still hear information such as traffic information and warnings.

Voice guidance is also switched off if you tap Turn off sound in the Settings menu.

Note: If you change the voice on your device, then voice guidance is automatically switched on for the new voice.

Turn on Voice

guidance

Tap this button to switch on voice guidance and hear spoken route instructions.

Units

Tap this button to set the units used on your device for features such as route planning.

Switch map

Turn off voice guidance / Turn on voice guidance

Units

Version information

Version infor-

mation

Tap this button to find technical information on your device, such as the device serial number, application version and the map version.

You can also view the current status for GPS reception and your LIVE Services, if you have a subscription.

Change voice

Tap this button to change the voice that gives spoken directions and other route instructions.

A wide range of voices are available. There are computer voices which can read street names and other information directly from the map and there are human voices which have been recorded by actors.

Voice settings

Tap this button to set the type of spoken directions and other route instructions your device will read aloud.

Voices

About Points of Interest

Home

Tap this button to set your Home location as a POI.

This is useful if you decide to change your Home location but first want to create a POI using the current Home address.

Favorite

Tap this button to create a POI from a Favorite.

You might want to create a POI from a Favorite because you can only create a limited number of Favorites. If you want to create more Favorites you need to delete some Favorites. To avoid losing a Favor-

Points of Interest

Points of Interest or POIs are useful places on the map.

Here are some examples:

 Restaurants  Hotels  Museums  Parking garages  Gas stations

Creating POIs

Tip: For help on managing third party POIs, search for "Third party POIs" at:

tomtom.com/support.

1. Tap the screen to open the Main menu.

2. Tap Settings.

3. Tap Manage POIs.

4. If there are no POI categories or the one you want to use does not exist, tap Add POI category

and create a new category.

Every POI must be assigned to a POI category. This means you need to have created at least one POI category before you can create your first POI.

You can only add POIs to POI categories you have created.

For more information on creating POI categories, read Managing POIs.

5. Tap Add POI.

6. Select the POI category you want to use for the new POI.

7. Tap a button to enter the POI address in the same way that you plan a route.

The POI is created and saved in the selected category.

ite, save the location as a POI before you delete the Favorite.

Address

Tap this button to enter an address as a new POI.

When you enter an address, you can choose from four options.

 City center  Street and house number  ZIP code  Cross street or intersection

Recent destination

Tap this button to select a POI location from a list of places you have recently used as destinations.

Point of Interest

Tap this button to add a Point of Interest (POI) as a POI.

For example, if you are creating a category of POIs for your favorite restaurants, use this option instead of entering the addresses of the restaurants.

My location

Tap this button to add your current location as a POI.

For example, if you stop somewhere interesting, you can tap this button to create a new POI at the current location.

Point on map

Tap this button to create a POI using the map browser.

Use the cursor to select the location of the POI, then tap Done.

Latitude Longitude

Tap this button to create a POI by entering latitude and longitude values.

Spoken address

Tap this button to create a POI by saying the address.

Using POIs to plan a route

When you plan a route, you can use a POI for the destination.

The following example shows how to plan a route to a parking lot in a city:

1. Tap Navigate to or Drive to in the Main menu.

2. Tap Point of Interest.

3. Tap POI in a city.

Tip: The last POI you viewed on your Mazda NB1 device is also shown in the menu.

4. Enter the name of the town or city and select it when it is shown in the list.

5. Tap the arrow button to expand the list of POI categories.

Tip: If you already know the name of the POI you want to use, you can tap Search by name to enter the name and select this location.

6. Scroll down the list and tap Parking lot.

7. The parking lot closest to the city center is shown at the top of the list.

8. The following list explains the distances shown next to each POI. How the distance is meas-

ured varies depending on how you initially searched for the POI:

 POI near you - distance from your current location  POI in a city - distance from the city center  POI near Home - distance from your Home location  POI along route - distance from your current location  POI near destination - distance from your destination

9. Tap the name of the parking lot you want to use and tap Done when the route has been calcu-

lated.

Your device starts to guide you to the parking lot.

Showing POIs on the map

You can select the types of POI locations you want to see on your maps.

1. Tap Show POI on map in the Settings menu.

2. Select the categories you want to be shown on the map.

3. Tap Done.

4. Select whether you want to see POI locations in 2D and 3D views of the map.

5. Tap Done.

The types of POI you have selected are shown as symbols on the map.

Calling a POI

Many of the POIs on your Mazda NB1 include phone numbers. This means that you can use your Mazda NB1 to find out the phone number for a POI, call them using a phone and then plan a route to the location of the POI.

For example, you can search for a cinema, call to book a ticket and then plan a route to the cinema.

1. Tap Navigate to or Drive to in the Main menu.

2. Tap Point of Interest.

3. Select how you want to search for the POI.

For example, if you want to search for a POI on your route, tap POI along route.

4. Tap the type of POI you want to navigate to.

For example, if you want to call a cinema to reserve a ticket, tap Cinema and then select the name of the cinema you want to call. Then tap Show info to see the phone number.

5. Call the POI on a phone to, for example, reserve tickets or check their opening hours.

6. Tap Select.

Your Mazda NB1 starts navigating to the POI.

Setting warnings for POIs

You can set a warning sound to be played when you approach a selected type of POI, such as a gas station.

The following example will show how to set a warning sound to be played when you are 250 yards from a gas station.

1. Tap Manage POIs and then Warn when near POI in the Settings menu.

2. Scroll down the list and tap Gas station.

Tip: To remove a warning, tap on the category name and then tap Yes. POI categories which have been set with a warning have a sound symbol next to the category name.

3. Set the distance as 250 yards and tap OK.

4. Select Sound effect and then tap Next.

5. Select the warning sound for the POI and then tap Next.

6. If you only want to hear the warning when the POI is directly on a planned route, select Warn

only if POI is on route. Then tap Done.

The warning is set for the selected POI category. You will hear a warning sound when you are 250 yards from a gas station on your route.

Manage POIs

Tap Manage POIs to manage your POI categories and locations.

You can set your Mazda NB1 device to let you know when you are near to selected POI locations. In this way you could, for example, set the device to let you know you when you are approaching a gas station.

You can create your own POI categories and add your own POI locations to these categories.

This means you can, for example, create a new POI category called Friends. You could then add all your friends' addresses as POIs in this new category.

Tap the following buttons to create and maintain your own POIs:

 Add POI - tap this button to add a location to one of your own POI categories.  Warn when near POI - tap this button to set your device to warn you when you are near se-

lected POIs.

 Delete POI - tap this button to delete one of your own POI categories.  Edit POI - tap this button to edit one of your own POIs.  Add POI category - tap this button to create a new POI category.  Delete POI category - tap this button to delete one of your own POI categories.

About getting help

Drive to help

Tap this button to plan a driving route to a service center.

Where am I?

Tap this button to see your current location on the map.

Safety and other

guides

Tap this button to read a selection of guides, including a First Aid guide.

Help

Tap Help in the Main menu to navigate to emergency services centers and other special services.

For example, if you are involved in a car accident, you could use the Help menu to find the contact details for the nearest hospital, call them using a phone and tell them your exact location.

Tip: If you do not see the Help button in the Main menu, tap Settings and then Safety settings. Clear the checkbox for Show only essential menu options while driving.

Using Help to drive to a local service

To use Help to locate a service center and navigate from your current location to the center, do the following:

1. Tap the screen to show the Main Menu.

2. Tap Help.

3. Tap Drive to help.

4. Select the type of service you require, for example, Nearest hospital.

5. Select a center from the list; the nearest is shown at the top of the list.

Your Mazda NB1 shows a description of the location.

6. To navigate your way to the center by car, tap Navigate there.

Your Mazda NB1 starts guiding you to your destination.

Help menu options

Note: In some countries, information may not be available for all services.

Product manuals

Tap this button to read a selection of guides relating to your navigation device.

About Favorites

Home

You can set your Home location as a Favorite.

Favorite

You cannot create a Favorite from another Favorite. This option will always be unavailable in this menu.

To rename a Favorite, tap Favorites in the Settings menu.

Address

You can enter an address as a Favorite.

Recent destination

Create a new Favorite by selecting a location from a list of your recent destinations.

Point of Interest

If you visit a POI you particularly like, for example a restaurant, you can add it as a Favorite.

My location

Tap this button to add your current location as a Favorite.

For example, if you stop somewhere interesting, while you are there you can tap this button to create the Favorite.

Favorites

Favorites provide an easy way to select a location without the need to enter the address. They do not need to be favorite places, they can simply be seen as a collection of useful addresses.

Creating a Favorite

To create a Favorite, do the following:

1. Tap the screen to bring up the Main menu.

2. Tap Settings to open the Settings menu.

3. Tap Favorites.

4. Tap Add.

Select the type of the Favorite by tapping one of the buttons described below:

Point on map

Tap this button to create a Favorite using the Map Browser.

Select the location of the Favorite using the cursor, then tap Done.

Latitude Longitude

Tap this button to create a Favorite by entering latitude and longitude values.

Spoken address

Tap this button to create a Favorite by saying the address.

Your device suggests a name for your new Favorite. To enter a new name, there is no need to delete the suggested name, you just start typing.

Tip: It is a good idea to give your Favorite a name that is easy to remember.

Tap OK.

Your new favorite appears in the list.

After you have added two or more Favorites, and Tips are switched on, you are asked whether you make regular trips to the same locations. If you tap YES, you can enter these destinations as your favorite destinations. Every time you switch on your device, you can immediately select one of these locations as your destination. To change these destinations or select a new destination, tap Start-up in the Settings menu, then select Ask for a destination.

Using a Favorite

You can use a Favorite as a way of navigating to a place without having to enter the address. To navigate to a Favorite, do the following:

1. Tap the screen to bring up the Main menu.

2. Tap Navigate to or Drive to.

3. Tap Favorite.

4. Select a Favorite from the list.

Your Mazda NB1 device calculates the route for you.

5. When the route is calculated, tap Done.

Your device immediately starts guiding you to your destination with spoken instructions and visual instructions on the screen.

Changing the name of a Favorite

To change the name of a Favorite, do the following:

1. Tap the screen to bring up the Main menu.

2. Tap Settings to open the Settings menu.

3. Tap Favorites.

4. Tap the Favorite you want to rename.

Tip: Use the left and right arrows to choose another Favorite from your list.

5. Tap Rename.

6. Type in the new name and then tap Done.

7. Tap Done.

Deleting a Favorite

To delete a Favorite, do the following:

1. Tap the screen to bring up the Main menu.

2. Tap Settings to open the Settings menu.

3. Tap Favorites.

4. Tap the Favorite you want to delete.

Tip: Use the left and right arrows to choose another Favorite from your list.

5. Tap Delete.

6. Tap Yes to confirm the deletion.

7. Tap Done.

About RDS-TMC

The top of the traffic sidebar represents your destination and shows the total time delay due to traffic jams and other incidents on your route.

The central section of the traffic sidebar shows individual traffic incidents in the order they occur on your route.

The bottom of the traffic sidebar represents your current location and shows the distance to the next incident on your route.

Traffic

The Traffic Message Channel (TMC), also known as RDS-TMC, transmits traffic information as a radio signal and is available free of charge in many countries.

TMC is not a TomTom Service, but is available when using the TomTom RDS-TMC Traffic Receiver.

Note: TomTom is not responsible for the availability or quality of traffic information provided by the Traffic Message Channel.

The Traffic Message Channel (TMC) is not available in all countries. To check the availability of TMC services in your country, go to tomtom.com/5826.

Safety Notice

Some navigation devices contain a GSM/GPRS module which can interfere with electrical devices such as cardiac pacemakers, hearing aids and aviation equipment.

Interference with these devices may endanger the health or life of you or others.

If your device includes a GSM/GPRS module, do not use it near unprotected electrical units or in areas where the use of mobile telephones is prohibited, such as hospitals and aircraft.

Using traffic information

If you are using an RDS-TMC receiver to view TMC traffic information on your Mazda NB1, no connections need to be made as the receiver is built into your device.

The traffic sidebar is shown on the right side of the Driving view. The sidebar informs you about traffic delays while you drive, using glowing dots to show you where each traffic incident is located on your route.

To make the traffic sidebar more readable some incidents may not be shown. These incidents will always be of minor importance and only cause short delays.

The color of the pointers, as shown below, gives you an instant indication of the type of incident:

Unknown or undetermined situation.

Slow traffic.

Developing traffic jam.

Stationary traffic or road closure.

Taking the fastest route

Your Mazda NB1 device regularly looks for a faster route to your destination. If the traffic situation changes and a faster route is found, your device offers to replan your trip so you can use the faster route.

You can also set your device to automatically replan your trip whenever a faster route is found. To apply this setting, tap Traffic settings in the Traffic menu.

To manually find and replan the fastest route to your destination, do the following:

1. Tap the traffic sidebar.

Tip: If you find that tapping the sidebar opens the Main menu instead of the traffic menu, try tapping the sidebar with your finger resting on the edge of the screen.

A summary of traffic on your route is shown.

2. Tap Options.

3. Tap Minimize delays.

Your device searches for the fastest route to your destination.

The new route may include traffic delays. You can replan the route to avoid all traffic delays, but a route which avoids all delays will usually take longer than the fastest route.

4. Tap Done.

Minimizing delays

You can use TomTom Traffic to minimize the impact of traffic delays on your route. To minimize delays automatically, do the following:

1. Tap Services in the Main Menu.

2. Tap Traffic.

3. Tap Traffic settings.

4. Choose between always taking the faster route automatically, being asked or never changing

your route.

5. Tap Next and then Done.

6. Tap Minimize delays.

Your device plans the quickest route to your destination. The new route may include traffic delays and may remain the same as the original route.

You can re-plan the route to avoid all delays, but this route is unlikely to be the quickest possible route.

7. Tap Done.

Making commuting to work easier

The Home to work and Work to home buttons in the Show home-work traffic menu let you check your route to and from work with one tap of a button.

When you use either of these buttons, your device plans a route between your home and work locations and checks the route for possible delays.

The first time you use Home to work, you must set your traffic home and work locations by doing the following:

1. Tap the traffic sidebar to open the Traffic menu.

Note: If you already have a route planned, a summary of traffic incidents on your route is shown. Tap Options to open the Traffic menu.

2. Tap Show home-work traffic.

3. Set your home location and your work location.

If you have already set the locations and want to change them, tap Change home-work.

You can now use the Home to work and Work to home buttons.

Note: The home location you set here is not the same as the home location you can set in the Settings Menu. In addition, the locations you use here do not have to be your actual home and

work locations. If there is another route that you often travel, you can set Work/Home to use these locations instead.

For example, to check for delays on your route home before you leave the office, do the following:

1. Tap the traffic sidebar to open the Traffic menu.

Note: If you already have a route planned, a summary of traffic incidents on your route is shown. Tap Options to open the Traffic menu.

2. Tap Show home-work traffic.

3. Tap Work to home.

The Driving View is shown and a message is displayed telling you about traffic incidents on this route. The Traffic sidebar also shows any delays.

Getting more information about an incident

To check for delays on your route, tap Show traffic on route in the Traffic menu. Your navigation device shows a summary of the traffic delays on your route.

The total includes any delays due to traffic incidents and those due to busy roads, with information provided by IQ Routes.

Tap Minimize delays to check if you can reduce the delay.

Tap the left and right arrow buttons to move through each incident in turn, viewing the details of each one. This includes the type of incident, for example road works, and the length of delay caused by this incident.

You can also access the details about individual incidents by tapping View map in the Main Menu and then tapping on the traffic incident symbol.

When shown on the map, a traffic incident starts with an icon. In the case of a traffic jam, the direction of the incident is from the icon towards the other end.

Checking traffic incidents in your area

Get an overview of the traffic situation in your area, using the map. To find local incidents and their details, do the following:

1. Tap the traffic sidebar then tap Options to open the Traffic menu.

2. Tap View map.

The map overview screen is shown.

3. If the map does not show your location, tap the marker to center the map on your current

location.

The map shows traffic incidents in the area.

4. Tap on any traffic incident to get more information.

A screen is shown that gives you detailed information about the incident you chose. To display information about surrounding incidents use the left and right arrows at the bottom of this screen.

Changing traffic settings

Use the Traffic settings button to choose how traffic information works on your navigation device.

1. Tap the traffic sidebar then tap Options to open the Traffic menu.

2. Tap Traffic settings.

3. If you are using an RDS-TMC Traffic Receiver, you will be able to select the setting Tune man-

ually by entering a frequency. If you select this option, the button Tune manually is shown in the Traffic menu. Tap Tune manually to enter the frequency of a particular radio station you want to use for RDS-TMC traffic information

4. If a faster route is found while you are driving, Traffic can replan your journey to use the faster

route. Select one of the following options and then tap Done.

 Always switch to that route  Ask me if I want that route  Never change my route

Traffic incidents

Traffic incidents and warnings are shown on the map, in the Driving View and on the Traffic sidebar.

To find out more about an incident, tap View Map in the Main Menu. Tap on a traffic incident symbol on the map to see information about that incident. To display information about surrounding incidents, use the left and right arrows at the bottom of the screen.

There are two types of incident and warning signs:

 Symbols shown in a red square are traffic incidents. Your navigation device can replan to

Accident

Road works

One or more lanes closed

Road closed

Traffic incident

Traffic jam

Fog

Rain

Wind

Ice

Snow

Note: The incident avoided symbol is shown for any traffic incident

that you avoid using a traffic service.

avoid them.

 Symbols shown in a red triangle are weather related. Your device does not replan to avoid

these warnings.

Traffic incident symbols:

Weather related symbols:

Traffic menu

To open the Traffic menu, tap the Traffic sidebar in the Driving View then tap Options, or tap Traffic in the Services menu.

The following buttons are available:

Minimize traffic

delays

Tap this button to re-plan your route based on the latest traffic information.

Show home-work

traffic

Tap this button to calculate the quickest route from your home location to your place of work and back.

Show traffic on

route

Tap this button for an overview of traffic incidents along your route.

Tap the left and right buttons for more detailed information about each incident.

Tap Minimize delays to replan your route and avoid the traffic incidents that are shown on the map.

View map

Tap this button to browse the map and see the traffic incidents shown on the map.

Change Traffic

settings

Tap this button to change your settings for how the Traffic service works on your device.

Read aloud traffic

info

Tap this button to hear spoken information about traffic incidents on your route.

Note: Your TomTom device must have a voice that speaks street names installed to read information aloud.

Important

Speed Cameras

Important: When you purchase your car with its Mazda NB1, alerts for Speed Cameras are switched off. If you wish to receive alerts for speed camera locations, tap Services, then tap Speed Cameras. Tap Enable alerts. You then receive alerts for speed camera locations.

Important

Important: If you hear beeps and see no message on your screen, this is because you are in radio

mode and the beeps are coming from your navigation device. The beeps are warning sounds given by the Speed Camera service to warn you of the presence of a speed camera.

About Speed Cameras

Note: LIVE Services are not available in all countries or regions, and not all LIVE Services are

available in all countries or regions. You may be able to use LIVE Services when traveling abroad. For more information on available services, go to tomtom.com/services.

The Speed Cameras service warns you about the following roadside camera locations:

 Speed Camera locations.  Dangerous roads.  Speed trap locations.  Average speed camera locations.  Traffic light camera locations.

Note: In France, no warnings are given for individual cameras or different types of camera. It is only possible to warn about danger zones. Danger zones are areas where there may be cameras. It's possible to report or confirm the location of danger zones, but it's not possible to remove them.

Speed Camera warnings

By default, warnings are given 15 seconds before you reach a speed camera location. To change the number of seconds or warning sound, tap Alert settings in the Speed Cameras menu.

You are warned in three ways:

 Your device plays a warning sound.  The type of speed camera and your distance from the camera location is shown in the Driving

View. If a speed restriction has been reported for the camera, the speed is also shown in the Driving View.

 The location of the speed camera is shown on the map.

Note: For speed enforcement zone cameras, you are warned by a combination of icons and

Alert settings

To change the way your Mazda NB1 warns you about speed cameras, tap the Alert settings button.

You can then set how close you want to be to a speed camera before you are warned and what type of sound will be played.

For example, to change the sound that is played when you approach a fixed speed camera, do the following:

1. Tap Services in the Main Menu.

2. Tap Speed Cameras.

3. Tap Alert settings.

A list of speed camera types is displayed. A speaker is shown next to the speed camera types that have been set for an alert.

4. Tap Fixed cameras.

5. Tap NO to keep the fixed safety camera alerts.

6. Enter the time in seconds for when a warning is given before you

reach a camera. Then tap Next.

7. Tap the sound you want to be used for the warning.

Tips: To switch off warning sounds for a camera type, tap Silence in step 7 above. You still see a warning in the Driving View if you switch off the warning sound.

8. Tap Done to save your changes.

Fixed speed camera

Red light camera

sounds at the start, middle and end of the Speed Enforcement Zone.

Changing the way you are warned

Safety camera symbols

Safety cameras are shown as symbols on the Driving View.

When you approach an area where an alert is located, you see a symbol and a warning sound is played.

You can change both the warning sound and the number of seconds that the warning is issued before reaching the alert.

Toll booth camera

Restricted road camera - located on a minor road that reduces traffic on a larger road

Other cameras

Speed trap hotspot

Speed Enforcement Zone

Accident black spot

Bi-directional speed camera

Ungated railroad crossing

Report button

To show the report button in the Driving View, do the following:

1. Tap Services in the Main Menu.

2. Tap Speed Cameras.

3. Tap Enable report button.

4. Tap Back.

The report button is shown on left-hand side of the Driving View or, if you are already using the quick menu, it's added to the buttons available in the quick menu.

Tip: To hide the report button, tap Disable report button in the Speed Cameras menu.

Reporting a new speed camera while on the move

To report a speed camera on the move, do the following:

1. Tap the report button shown in the Driving View or in the quick menu to record the location of

the camera.

If you tap the report button within 20 seconds of receiving a speed camera warning, you get the option to add a camera or remove a camera. Tap Add camera.

2. Tap Fixed camera or Speed trap, depending on the type of camera you are reporting.

3. Select the camera location on the map and confirm that it is correct.

4. Tap the type of fixed camera you want to report, for example, a red light camera.

Note: If the type of camera you choose has a safety restriction, you can also enter the speed.

You see a message confirming that a report has been created.

Reporting a new speed camera while at home

You do not need to be at the location of a speed camera to report the new location. To report a new speed camera location while you are at home, do the following:

1. Tap Services in the Main Menu on your navigation device.

2. Tap Speed Cameras.

3. Tap Report speed camera.

4. Tap Fixed camera or Speed trap depending upon the type of speed camera.

5. Use the cursor to mark the exact location of the camera on the map, then tap Done.

6. Tap Yes to confirm the location of the camera.

7. Tap on the type of camera you want to report and if necessary, choose the speed restriction

for the camera.

You see a message confirming that a report has been created.

Reporting incorrect camera alerts

You may receive an alert for a camera that is no longer there. To report an incorrect camera alert, do the following:

Note: You can only report an incorrect camera alert while you are at the location.

1. While you are at the location of the missing camera, tap Report in the Driving View.

Note: This must be done within 20 seconds of receiving the camera alert.

2. Tap Remove.

Note: It's possible to report or confirm the location of danger zones, but it's not possible to remove them.

Types of fixed speed camera you can report

When you report a fixed speed camera, you can select the type of fixed camera you are reporting.

These are the different types of fixed speed camera:

Speed Camera

This type of speed camera checks the speed of passing vehicles.

Red light camera

This type of camera checks for vehicles breaking traffic rules at traffic lights.

Toll booth speed

camera

This type of camera monitors traffic at toll road barriers.

Speed Enforce-

ment Zone

This type of speed camera checks the average speed of vehicles between two fixed points.

Vehicle restriction

This type of camera checks traffic on roads where access is restricted.

Other cameras

All other types of cameras that do not fall into any of the above categories.

Start of zone warning

As you approach the start of a Speed Enforcement Zone, you see a visual warning in the top left hand corner of the Driving View with a distance to the camera underneath it. You hear an audible warning.

You also see a small icon on the road showing the position of the speed enforcement zone camera at the start of the zone.

Speed Enforcement Zone warnings

There are several types of visual and audible warnings that you may see and hear when you meet a speed enforcement zone camera.

You always receive a start and end zone warning regardless of the speed you are traveling at. Intermediate warnings, if given, occur every 200 meters.

All the warnings are described below:

Intermediate warning - type 1

Once in the speed check zone, if you are not speeding and have already received a start of zone warning, you see a visual warning in the Driving View. This reminds you that you are still in the speed check zone.

Intermediate warning - type 2

Once in the speed check zone, if you are driving faster than the permitted speed and have already received a start of zone warning, you see a visual warning in the Driving View indicating the maximum permitted speed. You also hear a quiet audible warning. These warnings are there to remind you to slow down...

Intermediate warning - type 3

Once in the speed check zone, if you are driving faster than the permitted speed and have not received a start of zone warning, you see a visual warning in the Driving View indicating the maximum permitted speed. You also hear a loud audible warning.

These warnings occur at the FIRST intermediate point only and are there to remind you to slow down...

End of zone warning

As you approach the end of a Speed Enforcement Zone, you see a visual warning in the Driving View with a distance to the camera shown underneath it. You hear an audible warning.

You also see a small icon on the road showing the position of the speed enforcement zone camera at the end of the zone.

Report safety

camera

Tap this button to report a new safety camera location.

Alert settings

Tap this button to set the alerts you will receive and the sounds used for each alert.

Disable alerts

Tap this button to disable alerts.

Speed Cameras menu

To open the Speed Cameras menu, tap Services in the Main Menu and then tap Speed Cameras.

Enable report but-

ton

Tap this button to enable the report button. The report button is shown in the Driving View or in the quick menu.

When the report button is shown in the Driving View, this button changes to Disable report button.

About TomTom HOME

TomTom HOME

Using TomTom HOME you can register and manage your Mazda NB1 to receive free updates and buy new services. It's a good idea to connect to HOME frequently so you can do the following:

 Download for free the most recent map available for your device, if you connect to TomTom

HOME within 60 days of buying your device.

 Download updates for your device for free, including Map Share updates and other services

included with your product.

 Add new items to your device, like maps, voices and POIs, as well as buy TomTom services

and manage your subscriptions.

 Share your map corrections and other content with the TomTom community.  Make and restore backups of your device.

When using HOME, you can get help with what you are doing from the HOME Help. You can also read about all the other things that HOME can do for you.

Tip: We recommend using a broadband internet connection whenever you connect to HOME.

Installing TomTom HOME

The steps below refer to Internet Explorer on Windows XP. If you're using another browser or operating system, visit tomtom.com/support for more information.

To install TomTom HOME on your computer, do the following:

1. Connect your computer to the internet.

2. Click the link below to download the latest version of TomTom HOME:

tomtom.com/home

3. We recommend downloading the file to your computer by clicking Save.

4. Once the download is complete, click Open.

If you accidentally closed the Download Complete window, locate the file TomTomHOME2winlatest.exe on your computer and double-click it.

5. If you get a security warning, click Run.

6. Click Next, then click Install.

The installation starts.

7. Once the installation is complete click Finish.

MyTomTom account

To download content and services using TomTom HOME, you need a MyTomTom account. You can create an account when you start using TomTom HOME.

Note: If you have more than one TomTom device, you need a separate MyTomTom account for each device.

If you have a MyTomTom account, you can access the following benefits online using HOME or by using the MyTomTom section of tomtom.com:

 Services - click Services on the TomTom website to subscribe to services such as real-time

traffic and safety camera information.

 Newsletters - click MyTomTom followed by Account details on the TomTom website to man-

age newsletter subscriptions and language preferences for product news

 Support - click My Questions on the TomTom website to track and view your case history and

all email conversations you have with TomTom about technical support issues via the website. You can also update cases with new information.

 Orders - click My Orders on the TomTom website to view items you ordered from the

TomTom website and your order history.

 TomTom Map Share - report and download map corrections by joining the Map Share com-

munity using HOME. You can then benefit from shared reporting of map issues such as missing streets and wrong driving instructions.

 Downloads - download free items using TomTom HOME.

Updating your device

Before you start, make sure you have a backup of your device or memory card. For more information, see Backing up your navigation device.

You can check for updates for your maps, services and for a whole range of other free items or items for purchase. The instructions below describe how to update the TomTom application on your device.

To check for an updated application version do the following:

1. Insert your memory card into the card reader connected to your computer.

2. Wait for TomTom HOME to start.

3. If HOME does not automatically check for updates, click Update my device in the HOME

menu.

Note: If you would like to install an application you downloaded previously, click Add Traffic, Voices, Speedy Cameras, etc. and then click Items on my computer.

4. If a new application is available, it is listed on the next screen.

5. Make sure the new application is selected, then click Download updates.

HOME downloads the selected items.

6. HOME then installs the selected items on your memory card.

7. Click Done.

8. Click Device > Disconnect Device. You can then disconnect your card from your computer.

Introducing HOME help

In the TomTom HOME Help topics you can find a lot more information about how HOME can help you to manage contents and services on your navigation device.

You can also get help on the following:

 Initializing a memory card  Using a card reader  Updating your device-account combination  The TomTom Route Planner  Downloading free or shared sounds, images and symbols  Installing themes and extensions

For information on how to create your own POIs, themes, voices, routes, color schemes, symbols and sounds, see create.tomtom.com.

Getting help to use your navigation device

Version infor-

mation

Tap this button to view technical information about your device, such as the serial number for your device and the version of the main TomTom application.

GPS Status

Tap this button to see the current status for GPS reception.

My Services

Tap this button to check the status of your subscriptions to TomTom Services.

My information

Tap this button to change whether you want to share information with TomTom.

Customer support

You can get further help by going to tomtom.com/support.

For warranty information, go to tomtom.com/legal.

Status & information

Important Safety Notices and Warnings

Addendum

Global Positioning System

The Global Positioning System (GPS) is a satellite-based system that provides location and timing information around the globe. GPS is operated and controlled under the sole responsibility of the Government of the United States of America, which is responsible for its availability and accuracy. Any changes in GPS availability and accuracy, or in environmental conditions, may impact the operation of this device. TomTom does not accept any liability for the availability and accuracy of GPS.

Use with care

Use of TomTom products while driving still means that you need to drive with due care and attention.

Aircraft and hospitals

Use of devices with an antenna is prohibited on most aircraft, in many hospitals and in many other locations. This device must not be used in these environments.

SPECIAL NOTE REGARDING DRIVING IN CALIFORNIA AND MINNESOTA

California Vehicle Code Section 26708 "Material Obstructing or Reducing Driver's View" permits mounting of a navigation device on the windshield as follows: "A portable Global Positioning System (GPS), which may be mounted in a seven-inch square in the lower corner of the windshield farthest removed from the driver or in a five-inch square in the lower corner of the windshield nearest to the driver and outside of an airbag deployment zone, if the system is used only for door-to-door navigation while the motor vehicle is being operated." Drivers in California should not use a suction mount on their side or rear windows.

Note: This section of the California Vehicle Code applies to anyone driving in California, not just California residents.

Minnesota State Legislature Statutes Section 169.71, subdivision 1, section 2 provides that "A person shall not drive or operate with any objects suspended between the driver and the windshield other than sun visors and rearview mirrors and electronic toll collection devices."

Note: this Minnesota Stature applies to anyone driving in Minnesota, not just Minnesota residents.

TomTom Inc. bears no responsibility for any fines, penalties or damage that may be incurred by disregarding this notice. While driving in any state with windshield mounting restrictions, TomTom recommends the use of the supplied Adhesive Mounting Disk or its Alternative Mounting Kit, which includes multiple options for mounting TomTom devices on the dashboard and the air vents. See tomtom.com for more information about these mounting options.

FCC information for the user

THE DEVICE COMPLIES WITH PART 15 OF THE FCC RULES

Federal Communications Commission (FCC) Statement

Radio and television interference

This equipment radiates radio frequency energy and if not used properly - that is, in strict accordance with the instructions in this manual - may cause interference to radio communications and television reception.

This device has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

Important

This equipment was tested for FCC compliance under conditions that included the use of shielded cables and connectors between it and the peripherals. It is important that you use shielded cables and connectors to reduce the possibility of causing radio and television interference. Shielded cables, suitable for the product range, can be obtained from an authorized dealer. If the user modifies the equipment or its peripherals in any way, and these modifications are not approved by

TomTom, the FCC may withdraw the user’s right to operate the equipment. For customers in the

USA, the following booklet prepared by the Federal Communications Commission may be of help: "How to Identify and Resolve Radio-TV Interference Problems." This booklet is available from the US Government Printing Office, Washington, DC 20402. Stock No 004-000-00345-4.

FCC Declaration of Conformity

Tested to comply with FCC standards for home or office use.

This device complies with part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions:

This device may not cause harmful interference.

This device must accept any interference received, including interference that may cause undesired operation.

Responsible party in North America

TomTom, Inc., 150 Baker Avenue Extension, Concord, MA 01742

Tel: 866 486-6866 option 1 (1-866-4-TomTom)

Emissions information for Canada

Operation is subject to the following two conditions:

This device may not cause interference.

This device must accept any interference, including interference that may cause undesired oper ation of the device.

Operation is subject to the condition that this device does not cause harmful interference.

This Class B digital apparatus complies with Canadian ICES-003.

Pacemakers

Pacemaker manufacturers recommend that a minimum of 15cm (6 inches) be maintained between a handheld wireless device and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with independent research and recommendations by Wireless Technology Research.

Guidelines for people with pacemakers

You should ALWAYS keep the device more than 15 cm (6 inches) from your pacemaker.

You should not carry the device in a breast pocket.

Other medical devices

Please consult your physician or the manufacturer of the medical device, to determine if the operation of your wireless product may interfere with the medical device.

Exposure limits

This device complies with radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the radio frequency exposure limits, human proximity to the antenna shall not be less than 8 inches (20 cm) during normal operation.

Model names

1MI01, 1MI011

This document

Great care was taken in preparing this document. Constant product development may mean that some information is not entirely up to date. The information in this document is subject to change without notice.

TomTom shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from the performance or use of this document. This document contains information protected by copyright. No part of this document may be photocopied or reproduced in any form without prior written consent from TomTom N.V.

Copyright notices

marks of TomTom N.V. or one of its subsidiaries. Please see tomtom.com/legal for limited warranty and end user license agreements applying to this product.

© 2012 TomTom. All rights reserved. This material is proprietary and the subject of copyright protection and/or database rights protection and/or other intellectual property rights owned by TomTom or its suppliers. The use of this material is subject to the terms of a license agreement. Any unauthorized copying or disclosure of this material will lead to criminal and civil liabilities.

Nuance® is a registered trademark of Nuance Communications, Inc. and is used here under license.

Some images are taken from NASA’s Earth Observatory. The purpose of NASA's Earth Observatory is to provide a freely-accessible publication on the Internet where the public can obtain new satellite imagery and scientific information about our home planet. The focus is on Earth’s climate and environmental change: earthobservatory.nasa.gov

The software included in this product contains copyrighted software that is licensed under the GPL. A copy of that license can be viewed in the License section. You can obtain the complete corresponding source code from us for a period of three years after our last shipment of this product. For more information, visit tomtom.com/gpl or contact your local TomTom customer support team via tomtom.com/support. Upon request, we will send you a CD with the corresponding source code.

Linotype, Frutiger and Univers are trademarks of Linotype GmbH registered in the U.S. Patent and Trademark Office and may be registered in certain other jurisdictions. MHei is a trademark of The Monotype Corporation and may be registered in certain jurisdictions.

TomTom Mazda NB1 Reference Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Switching on and off

Read me first

Setting up

GPS reception

Device not starting

Sharing information with TomTom

Take care of your device

More information

About your memory card

The memory card

Inserting your memory card

Removing your memory card

About TomTom HOME

Installing TomTom HOME

Initialising your memory card

Updating your device

Backing up your navigation device

Safety Notice

Safety settings

About the commander

The commander

Using the commander

Planning a route

Planning a route

Route summary

Selecting a route type

Using arrival times

Navigation menu options

Planning a route in advance

Viewing route information

Voice control

Voice control

About navigation device voice control

Using voice control

Planning a trip using your voice

Entering addresses using your voice

About the Driving View

The Driving View

The Driving View

Driving View Symbols

About lane guidance

Advanced Lane Guidance

Using lane guidance

Making changes to your route

Changing your route

Change route menu

About waypoints

Adding the first waypoint to your route

Adding further waypoints to your route

Changing the order of waypoints

Deleting a waypoint

Changing notification settings for a waypoint

Reactivating a waypoint

About viewing the map

View map

View map

Options

Cursor menu

About Map Share

Map corrections

Correcting a map error

Types of map correction

About sounds and voices

Sounds and voices

About voices that speak street names

Selecting a voice

Changing the volume level

About Settings

2D/3D settings

Settings

Advanced settings

Car symbol

Home location

Favorites

Keyboard

Make your own menu
