TomTom LTO 200D, LTO 400D User Manual

TomTom

Before you start

Switching on

Setting up

Before you start1.

Follow the instructions at the start of this manual to dock your TomTom in your car stereo. Your TomTom can also be used without docking it in your car stereo. A mount is available as an accessory so that you can use your TomTom in other cars.

The first time you switch on your TomTom, it may take up to 20 seconds to start. To switch off your TomTom, press and hold the On/Off button for 2 seconds.

To set up your navigation device, you need to answer a few questions by tapping the screen.

Important: Take care to select the correct language, since the language you

choose will be used for all menus and written instructions.

Troubleshooting

Always make sure that you are using the latest version of the TomTom application on your TomTom. You can update the application using TomTom HOME.

If you have problems turning on your TomTom, try resetting your TomTom. To reset your TomTom, use a straightened paper clip, or something similar, to

push the reset button. The reset button is on the bottom of your TomTom. Then turn your TomTom on.

Take care of your TomTom

Never leave your TomTom or accessories on view when you leave the car or they may become an easy target for thieves.

You can set a password for your TomTom which must be entered every time you start your TomTom.

It is important to take care of your TomTom.

• Your TomTom is not designed for use in extreme temperatures and any such exposure may cause permanent damage.

• Do not open the casing of your TomTom under any circumstances. Doing so may be dangerous and will invalidate the warranty.

• Wipe or dry the screen of your TomTom using a soft cloth. Do not use any liquid cleaners.

Light sensor

Your TomTom uses a light sensor to detect the background light level and can automatically adjusts the brightness of the screen and switch to night view.

To use the light sensor to make these changes, tap Brightness preferences in the Preferences menu. You can then select these options:

• Turn brightness down when dark

• Switch to night view when dark

Link night view to headlights

If you select Link night view to headlights in the settings on your car stereo, your TomTom will switch to night view when you switch on th e headlights in your car. See the manual for your car stereo for information about the settings.

Driving View2.

Driving View

When your TomTom starts, you are shown the Driving View along with detailed information about your current location.

Tap the centre of the screen at any time to open the Main Menu.

Note: The Driving View is shown in black and white until your TomTom locates your current position.

ATap + and - to zoom in and out. BQuick menu - switch this on in the Preferences menu. CYour current position. DThe name of the next major road or road sign information, if applicable. ETraffic bar - traffic information is available either through the stereo using

RDS-TMC or from TomTom Traffic. TomTom Traffic requires a Bluetooth®enabled mobile phone. For more information about how to subscribe to and receive TomTom Traffic, go to tomtom.com/services.

To set up traffic information, tap TomTom Traffic in the Main Menu.

FNavigation instruction for the road ahead.

Tap this area to repeat the last spoken instruction and to change the volume.

GThe name of the street you are on. HInformation about your journey such as journey time, remaining distance

and arrival time. To change the information shown, tap Status bar preferences in the

Preferences menu.

IGPS signal strength.

Making your first journey3.

Making your first journey

Planning a route with your TomTom is easy. To plan your first route, follow the steps below.

Important: You should always plan your journey before you start driving. It is

dangerous to plan a route while driving.

1. Tap the screen to bring up the Main Menu.

Note: The buttons on your TomTom are shown in full colour unless a button is currently unavailable. For example, the button named Find alternative... in the Main Menu is not available until you have planned a route.

2. Tap Navigate to...

3. Tap Address.

When you enter an address, you can choose from the following options:

• City centre - tap this button to set your destination as the centre of a city

or town.

• Street and house number - tap this button to set an exact address as your

destination.

• Postcode - tap this button to enter a postcode as your destination.

Note: You can enter a postcode for any country. In the UK and the Netherlands, postcodes are detailed enough to identify a house on their own. In other countries you can enter a postcode to identify a town or area. You will then have to enter a street and house number.

• Crossing or intersection - tap this button to set your destination as the

point where two streets meet.

• Spoken address - tap this button to set your destination by announcing

the address to your TomTom.

In this example, we will enter an exact address.

4. Tap Street and house number.

Note: When planning a trip for the first time your TomTom asks you to choose a country. Your choice is saved and used for all routes you plan.

You can change this setting at any time by tapping the country flag.

Note: Spoken address input is not supported for all maps or for all languages.

5. Start to type the name of the town where you want to go.

As you type, the names of the towns that match what you have typed are shown. When your destination appears in the list, tap the name of the town to set the destination.

Tip: Instead of typing the name, tap this button to say the address by

speaking to your TomTom.

6. Start to type the name of the street and select it when it is shown. As with the name of the town, the names of the streets that match what you

have typed are shown. When your destination appears in the list, tap the name of the street to set the destination.

7. Now enter the house number of your destination and then tap Done.

Arrival times

8. Your TomTom asks if you need to arrive at a particular time. For this exercise, tap NO.

The route is calculated by your TomTom.

9. When the route has been calculated, tap Done.

Your TomTom will immediately begin to guide you to your destination, using both spoken instructions and on-screen directions.

When you plan a route, your TomTom asks you if you need to arrive at a particular time.

Tap YES to enter a preferred arrival time. Your TomTom calculates your arrival time and shows you whether you will

arrive on time. You can also use this information to work out when you need to leave. If your

TomTom shows that you will arrive 30 minutes early, you can wait and leave in 30 minutes time, rather than arrive early.

Your arrival time is constantly recalculated during your journey. The status bar shows whether you will arrive on time or if you are going to be late, as shown below:

You will arrive 55 minutes before the arrival time you entered. If the estimated arrival time is more than five minutes before

the time you entered, it is shown in green. You will arrive 3 minutes before the arrival time you entered. If the estimated arrival time is less than 5 minutes before the

time you entered, it is shown in yellow. You will arrive 19 minutes late. If the estimated arrival time is later than the time you entered,

it is shown in red.

Tap Status bar preferences in the Preferences menu, to enable or disable arrival time notifications.

Status bar

preferences

Select the required options on the first menu screen and then tap Done. To enable arrival time notifications, select Show leeway to arrival time.

What are the other navigation options?

When you tap Navigate to..., you can set your destination in many ways, not just by entering the address. The other options are listed below:

Tap this button to navigate to your Home location. You will probably use this button more than any other.

Home

Tap this button to select a Favourite as your destination.

Favourite

Tap this button to enter an address as your destination.

Address

Recent

destination

Point of Interest

Point on map

Latitude

Longitude

Tap this button to select your destination from a list of places you have recently used as destinations.

Tap this button to navigate to a Point of Interest (POI).

Tap this button to select a point on the map as your destination using the map browser.

Tap this button to enter a destination using latitude and longitude values.

Tap this button to navigate to the last known position of a TomTom Buddy. Don’t forget that the Buddy may move before you reach him.

TomTom

Buddy

Tap this button to select the last recorded position where your TomTom navigation device was docked, as your destination.

Last docked

Planning a route in advance

You can also use your TomTom to plan journeys in advance by selecting both your starting point and your destination. You could, for example, do the following:

• Find out how long a journey is going to take before you start.

• Check the route of a journey you are planning.

• Check a route for someone who is coming to visit you, so that you can explain the route to them.

To plan a route in advance, follow these steps:

1. Tap the screen to bring up the main menu.

2. Tap the arrow button to move to the next menu screen and tap Prepare

route.

Prepare route

3. Select the starting point for your journey in the same way that you would select your destination.

4. Set the destination for your journey.

5. Choose the type of route that should be planned.

• Fastest route - the route which takes the least time.

• Shortest route - the shortest distance between the locations you set. This

may not be the quickest route, especially if the shortest route is through a town or city.

• Avoid motorways - a route which avoids motorways.

• Walking route - a route designed for making the journey on foot.

• Bicycle route - a route designed for making the journey on a bicycle.

• Limited speed - a route for a vehicle which can only be driven at a limited

speed. You have to specify the maximum speed.

6. Your TomTom plans the route between the two locations you selected.

More information about a route

You can access these options for the route you last planned by tapping View route in the Main Menu or the Details button on the route summary screen.

You can then select from the following options:

Browse as

text

Tap this button for a list of all the turn instructions on the route. This is very useful if you need to explain a route to someone else.

Tap this button to see each turn in the journey. Tap the right and left arrows to move forwards and backwards through the journey.

Browse as

images

Browse map

of route

Show route

demo

Show route

summary

Tap the screen to turn off the 3D display and view the map from above.

Tap this button to see an overview of the route using the map browser.

Tap this button to watch a demo of the journey . You can interrupt the demo at any time by tapping the screen.

Tap this button to open the route summary screen.

Finding alternative routes4.

Finding alternative routes

Once you have planned a route, you may want to change something about the route, without changing your destination.

Why change the route?

Maybe for one of these reasons:

• You can see a roadblock or a line of traffic ahead.

• You want to travel via a particular location, to pick someone up, stop for lunch or fill up with petrol.

• You want to avoid a difficult junction or a road you don’t like.

Tap Find alternative... in the Main Menu to change the route that is currently planned.

Find alterna-

tive...

Calculate

alternative

Then tap one of the options below.

Tap this button to calculate an alternative to the route already planned. Your TomTom will look for another route from your current location to your

destination. If you decide you would prefer to use the original route after all, tap

Recalculate original.

Avoid

roadblock

Why would I need to do this?

Apart from the roads near your position and near your destination, the new route will use totally different roads to reach your destination. This is an easy way of calculating a totally different route.

Tap this button if you can see a roadblock or a line of traffic ahead. Y ou then have to choose how much of the route ahead you want to avoid.

Choose from the different options: 100m, 500m, 2000m, 5000m. Your TomT om will recalculate your r oute avoiding the section of the r oute for the distance you selected.

Don’t forget that once a new route is calculated, you may have to turn off the road you are on very soon.

If the roadblock suddenly clears, tap Recalculate original to return to your original route.

Tap this button to change your route so that it passes a particular location, perhaps to pick someone up on the way.

Travel via...

Recalculate

original

Avoid part of

route

You choose the location you want to pass in the same way as you choose a destination. So you can select from all the same options: for example, Address, Favourite, Point of Interest and Point on map.

Your TomTom will calculate a new route to your destination that passes the location you chose. Unlike your final destination, your TomTom does not inform you when you pass by this location.

Using this button, you can only travel via one location. If you want to pass more than one, use an Itinerary.

Tap this button to return to the original route without deviations to avoid roadblocks or travelling via particular locations.

Tap this button to avoid a part of the route. Use this button if you see that your route includes a road or junction you don’t like, or which is wellknown for traffic problems.

You then choose the road you want to avoid from a list of the roads on your route.

Tap this button to recalculate your route so that it avoids traffic problems as much as possible. Your TomTom will check if there are any traffic problems on your route and work out the best route to avoid the problems.

Minimise

delays

Note: This button is only available if your device is receiving traffic information from TomTom Traffic or RDS-TMC (the Traffic Message Channel).

Menus

Main menu

Menus5.

Tap the screen at any time when TomTom displays the Driving View to open the Main Menu.

• Navigate to... Tap this button to start planning a route.

• Find alternative... Tap this button if you want to avoid part of your route, travel via a specific

location or calculate an alternative route.

• Help me! Help me! provides an easy way for you to find and contact emergency

service centres and other specialist services.

• Mobile phone This button opens the mobile phone menu. You can, for example, make

calls, and write or read messages.

• Change preferences This button opens the Preferences menu. You can change many things

about the way TomTom looks and behaves.

Hidden buttons and features

When you first start using your TomTom, not all the buttons will be shown in the menu.

Many buttons and some more advanced features are hidden because you will not need these features very often.

To show all buttons and features, tap Show ALL menu options in the Preferences menu.

To hide these buttons again, tap Show fewer menu options in the Preferences menu.

Sounds and voices6.

Sounds and voices

The sound on your TomTom is used for features such as:

• Spoken instructions

• Hands-free calls

• Warnings

How do I change the volume level?

You can change the volume in three ways:

• Tap the bottom left hand area of the Driving View. The last spoken instruction is repeated and the volume level is shown.

Move the volume slider to adjust the volume.

• In the Main Menu, tap Change preferences, then tap Volume preferences. Tap Test to check your changes.

• You can set your TomTom to change the volume automatically depending on how noisy it is in the car.

Changing the volume automatically

Your TomTom can change the volume automatically.

Volume

preferences

1. In the Main Menu, tap Change preferences.

2. Tap Volume preferences.

3. Select Link volume to car speed.

4. Tap Done.

Selecting a voice

To change the voice being used by your TomTom, tap Voice preferences in the Preferences menu, then tap Change voice. Select a voice from the list.

Your TomTom has two different kinds of voices:

Voice

preferences

• Computer voices

•Human voices

Note: Human voices only provide spoken instructions.

These are generated by your TomTom. They provide spoken instructions while you are driving and can pronounce street n ames an d announce messages, traffic reports, weather reports, tips and tutorials.

These are recorded by an actor.

Using the car stereo7.

Using the car stereo

The car stereo uses the TomTom navigation device to display information, play videos, and show controls.

Through your TomTom navigation device, you can control the following:

•The radio

• The Audio CD/CD-ROM/DVD player

•An iPod

• Music stored on a USB stick

For full details, see the owner’s manual included with the car stereo.

Switching to audio

To use your TomTom navigation device to control your car stereo, press and immediately release the Screen button on the car stereo. You can switch back to the navigation functions at any time by pressing the Screen button again. To switch to other audio input sources, press the Source button on the car stereo.

The volume of music and the radio is set by the volume control on the car stereo. You can adjust the volume of spoken instructions and hands-free calls separately by changing the volume on your TomTom navigation device.

Using the radio

Your TomTom navigation device shows the radio station that you are tuned to and the frequency.

You can save the a station so that it is a preset. There are 6 presets per radio band. To save a frequency, press and hold the number that you want to use to save the frequency. When the colour of the button changes, the frequency is saved.

Using an iPod® and USB storage devices

You can use your TomTom navigation device to play songs and videos saved on an iPod® and songs stored on a USB storage device. The cable for connecting an iPod to your car stereo is available as an accessory.

Note: Your TomTom must be docked in the car stereo to play back music or videos stored on an iPod® or USB storage device

When you connect an iPod® or USB storage device and select one of these as the audio input source, your car stereo starts to play the first song on the iPod® or USB storage device.

To select your iPod® or USB storage device, press the Source button on your car stereo until iPod or USB is shown on the display on your car stereo. To select the song to play, tap Select. You can then choose the songs you want to listen to.

• Playlist - tap this button to select a playlist.

Note: You can create playlists in a third-party application like iTunes®, Musicmatch® or Winamp®. You must change the extension of playlist files on USB storage devices from .M3U to .PLA.

• Song - tap this button to select from all the so ngs.

• Artist - tap this button to select a song by a particular singer or group.

• Genre - tap this button to select a particular type of music.

• Album - tap this button to select from a list of all the albums.

• Audiobooks - tap this button to select an Audiobook. Audiobooks can be

• Video - tap this button to play videos stored on your iPod. Videos stored on

Important: You should not select songs or videos, or watch videos while

driving as this is dangerous.

To skip to the next or previous song, use the controls on the car stereo.

Note: Not all mp3 files contain information about the song, such as the artist or genre. If the file contains no information, the file name is used as the song title.

Back eye camera

played from an iPod.

a USB storage device cannot be played.

The view from the back eye camera on your car can be shown on your TomTom navigation device. The back eye camera must be connected properly and your navigation device must be docked in the car stereo.

To show the view from the back eye camera, press and hold the Screen button on the car stereo until the back eye camera is shown. To switch back from the back eye camera, press and immediately release the Screen button.

To switch automatically to the back eye camera when you are reversing the car, set this in the Main unit settings.

For information about the Main unit settings, see the documentation for the car stereo.

Browse Map8.

Browse Map

To look at the map in the same way as you might look at a traditional paper map, tap Browse map in the Main Menu.

You can move the map by touching the screen and moving your finger across the screen.

AThe scale bar BYour current position. CGPS button

Tap this button to centre the map on your current position.

DOptions

Cursor button

EThe cursor FThe Find button

Tap this button to find specific addresses.

GThe Cursor button

Tap this button to navigate to the cursor position, make a Favourite of the cursor position, or find a Point of Interest near the cursor position.

HThe zoom bar

Zoom in and out by moving the slider.

You can use the cursor to find addresses and Points of Interest (POIs), for example, restaurants, train stations and petrol stations.

Navigate

there

Find POI

nearby

Position the cursor over a location on the map, then tap one of the following buttons:

Tap this button to navigate to the cursor position. Your TomTom will calculate the route.

Tap this button to find a POI near the cursor position. For example, if you have found a restaurant to go to, you can search for a parking garage nearby.

Tap this button to call the location at the cursor position. This button is only available if your TomTom has the phone number for the location.

Call...

Add as

Favourite

Add as POI

Correct

location

The phone numbers of many POIs are stored in your TomT om. If you ente r phone numbers for POIs that you create, you can also call them.

Tap this button to create a Favourite at the cursor position.

Tap this button to create a POI at the cursor position.

Tap this button to correct the location shown at the cursor position.

TomTom Map Share9.

TomTom Map Share

TomTom Map ShareTM is a free service that lets you make updates to your map and share those updates with other members of the TomTom Map Share community.

If you find a street that has recently been blocked to traffic, you can use Map Share to update your map and then share the update with other Map Share members.

You can use Map Share to send and receive map updates during the first year after the map’s release date. This means that one year after the release date, you will no longer be able to send or receive map updates for that version of the map. You will still be able to make your own map updates for use on your device.

When you join the TomTom Map Share community you can keep your maps up-to-date with the latest updates made by other Map Share community members.

You choose the type of updates you want and each time you connect your TomTom to TomTom HOME, the map is automatically updated.

TomTom Map Share community

To join the Map Share community, do the following:

1. Tap Map corrections in the Main Menu.

Map updates

Tip: If you cannot see the Map corrections button in the Main Menu, tap Show

ALL menu options in the Preferences menu.

2. Tap Download corrections made by others.

3. Tap Join.

When you connect your TomTom to your computer, TomTom HOME automatically downloads any available map updates and sends any changes you have made, to the Map Share community.

There are two types of map update:

• Updates that are immediately shown on the map. These include, changing the traffic flow of a street, blocking or renaming a street and adding or editing POIs.

This type of change is immediately shown on your own map. You can h ide these updates at any time in the Map Share preferences menu.

• Updates that are reported to TomTom to be shown on the map after they are verified. These include, missing streets, errors in motorway entrances and exits and missing roundabouts.

This type of update is investigated by TomTom and once verified, is included in the next map release. These updates are therefore not shared with the Map Share community.

Tip: If you cannot see the Map corrections button in the Main Menu, tap Show

ALL menu options in the Preferences menu.

Making a map update

1. Tap Map corrections in the Main Menu.

2. Tap Correct a map error.

Correct a map

error

A list of possible map updates is shown.

3. Tap the button to select the type of update you want to report.

Note: If you tap Add missing POI or Report other error you will be asked for some additional information before the next step.

4. Tap the button to select how to search for the location on the map.

5. When you have found the location, tap Done.

6. Enter the details of the update and decide if you want to share the update.

Marking a map error while on the move

If you notice an item on your map that needs attention, you can mark the location using the Report button and then enter the details when you are no longer driving.

To show the Report button in the Driving View, do the following:

1. Tap Map corrections in the Main Menu.

Tip: If you cannot see the Map corrections button in the Main Menu, tap Show

ALL menu options in the Preferences menu.

2. Tap Correction preferences.

3. Tap Done and then tap Done again.

4. Select Show report button, then tap Done.

The Report button is shown on the left-hand side of the Driving View. After you mark a location, you can add more information about the change when you open the Map corrections menu.

For example, you are driving to a friend's house and you notice that the name of the street you are on is different from the one on your map. To report the change, tap the Report button and your TomTom will save your current location. You can then send the update to TomTom Map Share when you have finished your journey.

Receiving the latest map updates

When you connect your TomTom to your computer, TomTom HOME automatically downloads any available map updates and sends any changes you have made, to the Map Share community.

Changing my preferences for map updates

Open Correction preferences to change the settings for TomTom Map Share. You can change the following settings:

• Choose what types of updates you want to use on your maps.

• Decide if you want to share your updates with others.

• Show or hide the Report button in the Driving View.

To set your preferences, do the following:

1. Tap Map corrections in the Main Menu.

2. Tap Correction preferences. A list of update types is shown.

3. Tick the box next to each update type you want use.

4. Tap Done.

5. Choose how you want to share your map updates with the Map Share community, then tap Done.

6. Choose if you want to see the Report button in the Driving View.

7. Tap Done.

Tip: If you later decide you want to remove updates from the map, clear the

checkbox next to the types of update you want to remove. If you clear all the checkboxes, your map returns to the original state before the first update.

Map update categories

There are several types of update that you can make to a map.

+ 55 hidden pages
