Texas Instruments TMS320F20x, TMS320F24x DSP User Manual

TMS320F20x/F24x DSP

Embedded Flash Memory

Technical Reference

This document contains preliminary data

current as of publication date and is subject

to change without notice.

Literature Number: SPRU282

September 1998

Printed on Recycled Paper

IMPORTANT NOTICE

T exas Instruments and its subsidiaries (TI) reserve the right to make changes to their products or to discontinue
any product or service without notice, and advise customers to obtain the latest version of relevant information
to verify, before placing orders, that information being relied on is current and complete. All products are sold
subject to the terms and conditions of sale supplied at the time of order acknowledgement, including those
pertaining to warranty, patent infringement, and limitation of liability.

TI warrants performance of its semiconductor products to the specifications applicable at the time of sale in
accordance with TI’s standard warranty. Testing and other quality control techniques are utilized to the extent
TI deems necessary to support this warranty . Specific testing of all parameters of each device is not necessarily
performed, except those mandated by government requirements.

CERTAIN APPLICATIONS USING SEMICONDUCT OR PRODUCTS MAY INVOLVE POTENTIAL RISKS OF
DEATH, PERSONAL INJURY, OR SEVERE PROPERTY OR ENVIRONMENTAL DAMAGE (“CRITICAL
APPLICATIONS”). TI SEMICONDUCTOR PRODUCTS ARE NOT DESIGNED, AUTHORIZED, OR
WARRANTED TO BE SUITABLE FOR USE IN LIFE-SUPPORT DEVICES OR SYSTEMS OR OTHER
CRITICAL APPLICA TIONS. INCLUSION OF TI PRODUCTS IN SUCH APPLICATIONS IS UNDERST OOD TO
BE FULLY AT THE CUSTOMER’S RISK.

In order to minimize risks associated with the customer’s applications, adequate design and operating
safeguards must be provided by the customer to minimize inherent or procedural hazards.

TI assumes no liability for applications assistance or customer product design. TI does not warrant or represent
that any license, either express or implied, is granted under any patent right, copyright, mask work right, or other
intellectual property right of TI covering or relating to any combination, machine, or process in which such
semiconductor products or services might be or are used. TI’s publication of information regarding any third
party’s products or services does not constitute TI’s approval, warranty or endorsement thereof.

Copyright  1998, Texas Instruments Incorporated

PRELIMINARY

About This Manual

This reference guide describes the operation of the embedded flash EEPROM
module on the TMS320F20x/F24x digital signal processor (DSP) devices and
provides sample code that you can use in developing your own software. The
performance specifications of the embedded flash memory have been evalu­ated using the algorithms and techniques described in this guide. TI does not
recommend deviation from these algorithms and techniques, since doing so
could affect device performance. The book does not describe the use of any
specific flash programming tool nor does it describe the external interface to
the DSP. For information about any aspect of the TMS320F20x/F24x devices
other than the embedded flash EEPROM module, see

tion from Texas Instruments

How to Use This Manual

Preface

Read This First

Related Documenta-

on page v.

PRELIMINARY

There are several stand-alone flash programming tools for TMS320F20x/
F24x generation of DSPs. Using one of these stand-alone tools with the
TMS320F20x/F24x requires only a basic understanding of the flash opera­tions. More information about these flash programming tools is available on
the TI web page, http://www.ti.com. This guide is intended to provide a
complete understanding of the flash operations. This level of understanding
is necessary for making modifications to existing flash programming tools
or for developing alternative programming schemes.

If you are looking for in­formation about:

Algorithms Chapter 3,

Erasing the flash array Section 1.1,

T urn to these locations:

Algorithm Implementations and

Software Considerations

Basic Concepts of Flash Memory

Technology

Section 2.1,

TMS320F20x/F24x Flash Array

Section 2.6,
Section 3.3,

Modifying the Contents of the
Erase Operation

Erase Algorithm

iii

If you are looking for in­formation about:

T urn to these locations:

PRELIMINARY

Over-erasure (depletion) and
recovery

Programming the flash array Section 1.1,

Sample code Appendix A,

Notational Conventions

This document uses the following conventions.

- The flash EEPROM is referred to as flash memory or the flash module.

Section 1.1,

Technology

Section 2.7,

(Flash-Write Operation)

Section 3.4,

Technology

Section 2.1,

TMS320F20x/F24x Flash Array

Section 2.5,
Section 3.2,

Program Examples

Basic Concepts of Flash Memory
Recovering From Over-Erasure
Flash-Write Algorithm

Basic Concepts of Flash Memory
Modifying the Contents of the
Program Operation

Programming Algorithm

Assembly Source Listings and

The term flash array refers to the actual memory array within the flash
module. The flash module includes the flash memory array and the associ­ated control circuitry.

- The DSP generation and devices are abbreviated as follows:
J TMS320F20x/24x generation: ’F20x/24x
J TMS320F20x devices: ’F20x
J TMS320F24x devices: ’F24x

- Program listings and code examples are shown in a special type-

face.
Here is a sample program listing:

0011 0005 0001 .field 1, 2
0012 0005 0003 .field 3, 4
0013 0005 0006 .field 6, 3
0014 0006 .even

iv

PRELIMINARY

PRELIMINARY

Related Documentation From Texas Instruments

The following books describe the ’F20x/24x and related support tools. To ob­tain a copy of any of these TI documents, call the T exas Instruments Literature
Response Center at (800) 477–8924. When ordering, please identify the book
by its title and literature number.

TMS320C24x DSP Controllers Reference Set, Volume 1: CPU, System,

and Instruction Set

TMS320C24x 16-bit, fixed-point, digital signal processor controller.
Covered are its architecture, internal register structure, data and
program addressing, and instruction set. Also includes instruction set
comparisons and design considerations for using the XDS510 emulator .

TMS320C24x DSP Controllers Reference Set Volume 2: Peripheral

Library and Specific Devices

the peripherals available on the TMS320C24x digital signal processor
controllers and their operation. Also described are specific device
configurations of the ’C24x family.

(literature number SPRU160) describes the

Related Documentation From Texas Instruments

(literature number SPRU161) describes

TMS320C240, TMS320F240 DSP Controllers

data sheet contains the electrical and timing specifications for these
devices, as well as signal descriptions and pinouts for all of the available
packages.

(literature number SPRS042)

TMS320C2x/C2xx/C5x Optimizing C Compiler User’s Guide

number SPRU024) describes the ’C2x/C2xx/C5x C compiler. This C
compiler accepts ANSI standard C source code and produces TMS320
assembly language source code for the ’C2x, ’C2xx, and ’C5x genera­tions of devices.

TMS320F206 Digital Signal Processor

sheet contains the electrical and timing specifications for the ’F206
device, as well as signal descriptions and the pinout.

(literature number SPRS050) data

TMS320F241, TMS320C241, TMS320C242 DSP Controllers

number SPRS063) data sheet contains the electrical and timing
specifications for the ’F241, ’C241, and ’C242 devices, as well as signal
descriptions and pinouts.

TMS320F243 DSP Controller

contains the electrical and timing specifications for the ’F243 device, as
well as signal descriptions and the pinout.

TMS320C2xx User’s Guide

hardware aspects of the ’C2xx 16-bit, fixed-point digital signal proces­sors. It describes the architecture, the instruction set, and the on-chip pe­ripherals.

(literature number SPRS064) data sheet

(literature number SPRU127) discusses the

(literature

(literature

PRELIMINARY

Read This First

v

Related Documentation From Texas Instruments

PRELIMINARY

TMS320C2xx C Source Debugger User’s Guide

SPRU151) tells you how to invoke the ’C2xx emulator and simulator ver­sions of the C source debugger interface. This book discusses various
aspects of the debugger interface, including window management, com­mand entry , code execution, data management, and breakpoints. It also
includes a tutorial that introduces basic debugger functionality.

(literature number

vi

PRELIMINARY

PRELIMINARY

If You Need Assistance . . .

If You Need Assistance . . .

- World-Wide Web Sites

TI Online http://www.ti.com
Semiconductor Product Information Center (PIC) http://www.ti.com/sc/docs/pic/home.htm
DSP Solutions http://www.ti.com/dsps
320 Hotline On-linet http://www.ti.com/sc/docs/dsps/support.htm

- North America, South America, Central America

Product Information Center (PIC) [phone]
TI Literature Response Center U.S.A. [phone]
Software Registration/Upgrades [phone] Fax: [phone]
U.S.A. Factory Repair/Hardware Upgrades [phone]
U.S. Technical Training Organization [phone]
DSP Hotline [phone] Fax: [phone] Email: [e-mail]
DSP Modem BBS [phone]
DSP Internet BBS via anonymous ftp to ftp://ftp.ti.com/pub/tms320bbs

- Europe, Middle East, Africa

European Product Information Center (EPIC) Hotlines:

Multi-Language Support [phone] Fax: [phone]

Email: [e-mail]

Deutsch [phone] or [phone]
English [phone]
Francais [phone]

Italiano [phone]
EPIC Modem BBS [phone]
European Factory Repair [phone]
Europe Customer Training Helpline Fax: [phone]

- Asia-Pacific

Literature Response Center [phone] Fax: [phone]
Hong Kong DSP Hotline [phone] Fax: [phone]
Korea DSP Hotline [phone] Fax: [phone]
Korea DSP Modem BBS [phone]
Singapore DSP Hotline Fax: [phone]
Taiwan DSP Hotline [phone] Fax: [phone]
Taiwan DSP Modem BBS [phone]
Taiwan DSP Internet BBS via anonymous ftp to ftp://dsp.ee.tit.edu.tw/pub/TI/

- Japan

Product Information Center +0120-81-0026 (in Japan) Fax: [phone] (in Japan)

DSP Hotline [phone] or (INTL) 813-3769-8735 Fax: [phone] or (INTL) 813-3457-7071
DSP BBS via Nifty-Serve Type “Go TIASP”

- Documentation

When making suggestions or reporting errors in documentation, please include the following information that is on the title
page: the full title of the book, the publication date, and the literature number.

Mail: Texas Instruments Incorporated Email: [e-mail]

Technical Documentation Services, MS 702
P.O. Box 1443
Houston, Texas 77251-1443

Note: When calling a Literature Response Center to order documentation, please specify the literature number of the

book.

PRELIMINARY

+03-3457-0972 or (INTL) 813-3457-0972 Fax: [phone] or (INTL) 813-3457-1259

Read This First

vii

PRELIMINARY

viii

PRELIMINARY

Contents

Contents

1 Introduction 1Ć1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Discusses basic flash memory technology; summarizes the features and benefits of the
TMS320F20x/F24x flash module

1.1 Basic Concepts of Flash Memory Technology 1Ć2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 TMS320F20x/F24x Flash Module 1Ć3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 Benefits of Embedded Flash Memory in a DSP System 1Ć5. . . . . . . . . . . . . . . . . . . . . . . . . .

2 Flash Operations and Control Registers 2Ć1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Describes the operations that modify the content of the flash module; explains the role of the
control registers

2.1 Operations that Modify the Contents of the ’F20x/F24x Flash Array 2Ć2. . . . . . . . . . . . . . .

2.2 Accessing the Flash Module 2Ć5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2.1 TMS320F206 Flash Access-Control Register 2Ć6. . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2.2 TMS320F24x Flash Access-Control Register 2Ć7. . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3 Flash Module Control Registers 2Ć8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3.1 Segment Control Register (SEG_CTR) 2Ć8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3.2 Flash Test Register (TST) 2Ć10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3.3 Write Address Register (WADRS) 2Ć10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3.4 Write Data Register (WDATA) 2Ć11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.4 Read Modes 2Ć12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.5 Program Operation 2Ć13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.6 Erase Operation 2Ć14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.7 Recovering From Over-Erasure (Flash-Write Operation) 2Ć15. . . . . . . . . . . . . . . . . . . . . . . .

2.8 Reading From the Flash Array 2Ć16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.9 Protecting the Array 2Ć16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Algorithm Implementations and Software Considerations 3

Describes the algorithms used for the programming, erase, and flash-write operations; dis­cusses considerations necessary for developing your software

3.1 How the Algorithms Fit Into the Program-Erase-Reprogram Flow 3Ć2. . . . . . . . . . . . . . . . .

3.2 Programming (or Clear) Algorithm 3Ć4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3 Erase Algorithm 3Ć10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.4 Flash-Write Algorithm 3Ć14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A Assembly Source Listings and Program Examples AĆ1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A.1 Assembly Source for Algorithms AĆ2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Ć1. . . . . . . . . . . . . . . . . . . . . . . . . .

ix

Contents

A.1.1 Header File for Constants and Variables, SVAR20.H AĆ2. . . . . . . . . . . . . . . . . . . . .

A.1.2 Clear Algorithm, SCLR20.ASM AĆ5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A.1.3 Erase Algorithm, SERA20.ASM AĆ10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A.1.4 Flash-Write Algorithm, SFLW20.ASM AĆ15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A.1.5 Programming Algorithm, SPGM20.ASM AĆ19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A.1.6 Subroutines Used By All Four Algorithms, SUTILS20.ASM AĆ25. . . . . . . . . . . . . . .

A.2 C-Callable Interface to Flash Algorithms AĆ27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A.3 Sample Assembly Code to Erase and Reprogram the TMS320F206 AĆ32. . . . . . . . . . . . . .

A.3.1 Assembly Code for TMS320F206 AĆ32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A.3.2 Linker Command File for TMS320F206 Sample Assembly Code AĆ35. . . . . . . . . .

A.4 Sample C Code to Erase and Reprogram the TMS320F206 AĆ37. . . . . . . . . . . . . . . . . . . . .

A.4.1 C Code That Calls the Interface to Flash Algorithms for TMS320F206 AĆ37. . . . .

A.4.2 Linker Command File for TMS320F206 Sample C Code AĆ38. . . . . . . . . . . . . . . . .

A.5 Sample Assembly Code to Erase and Reprogram the TMS320F240 AĆ40. . . . . . . . . . . . . .

A.5.1 Assembly Code for TMS320F240 AĆ40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A.5.2 Linker Command File for TMS320F240 Sample Assembly Code AĆ45. . . . . . . . . .

A.6 Using the Algorithms With C Code to Erase and Reprogram the ’F240 AĆ47. . . . . . . . . . . .

A.6.1 C Code That Calls the Interface to Flash Algorithms for TMS320F240 AĆ47. . . . .

A.6.2 Linker Command File for TMS320F240 Sample C Code AĆ48. . . . . . . . . . . . . . . . .

A.6.3 C Function for Disabling TMS320F240 Watchdog Timer AĆ50. . . . . . . . . . . . . . . . .

A.6.4 C Functions for Initializing the TMS320F240 AĆ51. . . . . . . . . . . . . . . . . . . . . . . . . . .

x

Figures

Figures

1–1 TMS320F20x/F24x Program Space Memory Maps 1Ć4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–1 Flash Memory Logic Levels During Programming and Erasing 2Ć4. . . . . . . . . . . . . . . . . . . . . .

2–2 Memory Maps in Register and Array Access Modes 2Ć6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–3 Segment Control Register (SEG_CTR) 2Ć8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–1 Algorithms in the Overall Flow 3Ć3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–2 The Programming Algorithm in the Overall Flow 3Ć4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–3 Programming or Clear Algorithm Flow 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–4 Erase Algorithm in the Overall Flow 3Ć10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–5 Erase Algorithm Flow 3Ć13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–6 Flash-Write Algorithm in the Overall Flow 3Ć14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–7 Flash-Write Algorithm Flow 3Ć16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents

xi

Tables

Tables

1–1 TMS320 Devices With On-Chip Flash EEPROM 1Ć3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–1 Operations that Modify the Contents of the Flash Array 2Ć4. . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–2 Flash Module Control Registers 2Ć8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–3 Segment Control Register Field Descriptions 2Ć9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–4 Flash Array Segments Summary 2Ć10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–1 Steps for Verifying Programmed Bits and Applying One Program or Clear Pulse 3Ć8. . . . . .

3–2 Steps for Applying One Erase Pulse 3Ć11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–3 Steps for Applying One Flash-Write Pulse 3Ć15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

xii

PRELIMINARY

Chapter 1

Introduction

The TMS320F20x/F24x digital signal processors (DSPs) contain on-chip flash
EEPROM (electrically-erasable programmable read-only memory). The em­bedded flash memory provides an attractive alternative to masked program
ROM. Like ROM, flash memory is nonvolatile, but it has an advantage over

in-system

ROM:
This chapter discusses basic flash memory technology, introduces the flash

memory module of the ’F20x/F24x DSP , and lists the benefits of flash memory
embedded in a DSP chip.

reprogrammability.

Topic Page

1.1 Basic Concepts of Flash Memory Technology 1-2. . . . . . . . . . . . . . . . . . .

1.2 TMS320F20x/F24x Flash Module 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 Benefits of Embedded Flash Memory in a DSP System 1-5. . . . . . . . . . .

PRELIMINARY

1-1

Basic Concepts of Flash Memory Technology

1.1 Basic Concepts of Flash Memory Technology

The term flash in this EEPROM technology refers to the speed of some of the
operations performed on the memory (these operations will be described in
greater detail later in this document). An entire block of bits is affected simulta-

block

or

neously in a
time. In contrast, writing data to the flash memory cannot be a block operation,
since normally a selection of ones and zeroes are written (all bits are not the
same value). Writing selected bits to create a desired pattern is known as pro­gramming the flash memory, and a written bit is called a programmed bit.

Several different types of program and erase operations are performed on the
flash memory in order to properly produce the desired pattern of ones and ze­roes in the memory. It should be noted that, under some conditions, flash
memory may become overerased, resulting in a condition known as depletion.
The ’F20x/F24x algorithms avoid overerasure by using an approach that
erases in small increments until complete erasure is achieved.

The ’F20x/F24x flash EEPROM includes a special operation, flash-write, that
is used only to recover from over-erasure. Because of the implementation of
the flash memory, when over-erasure occurs, any particular bit in depletion
mode is difficult to identify. For this reason, the ’F20x/F24x simply writes an
entire block of bits simultaneously; hence, the name flash-write.

flash operation

, rather than being affected one bit at a

PRELIMINARY

1-2

The program and erase operations in flash memory must provide sufficient
charge margin on 1s and 0s to ensure data retention, so the ’F20x/F24x flash
module includes a hardware mechanism that provides margin for erasing or
programming. This mechanism implements voltage reference levels which
ensure this logic level margin when modifying the contents of the flash
memory.

PRELIMINARY

PRELIMINARY

1.2 TMS320F20x/F24x Flash Module

The ’F20x/F24x flash EEPROM is implemented with one or two independent
flash memory modules of 8K or 16K words. Each flash module is composed
of a flash memory array , four control registers, and circuitry that produces ana­log voltages for programming and erasing. The flash array size of the
TMS320F206 and TMS320F240 is 16K × 16 bits, while the TMS320F241 and
TMS320F243 incorporate an 8K × 16-bit flash array (see Table 1–1). Unlike
most discrete flash memories, the ’F20x/F24x flash module does not require
a dedicated state machine, because the algorithms for programming and eras­ing the flash are executed in software by the DSP core. The use of these so­phisticated, adaptive programming algorithms results in reduced chip size and
greater programming flexibility . In addition, the application code can manage
the use of the flash memory without the requirement of external programming
equipment.

Table 1–1. TMS320 Devices With On-Chip Flash EEPROM

Device Array Size T otal Flash Memory

TMS320F20x/F24x Flash Module

TMS320F206 16K 32K
TMS320F240 16K 16K
TMS320F241 8K 8K
TMS320F243

†

Each array can be independently erased.

8K 8K

†

PRELIMINARY

Introduction

1-3

TMS320F20x/F24x Flash Module

Simplified memory maps for the program space of the TMS320F20x/F24x de­vices are shown in Figure 1–1 to illustrate the location of the flash modules.

Figure 1–1. TMS320F20x/F24x Program Space Memory Maps

PRELIMINARY

0000h

3FFFh

4000h

7FFFh

8000h

FFFFh

TMS320F206

MP/MC = 0

Flash0

Flash1

0000h

3FFFh

4000h

FFFFh

TMS320F240

MP/MC = 0

0000h

1FFFhFlash0

TMS320F241

Flash0

no external memory available

0000h

1FFFh

FFFFh

TMS320F243

MP/MC = 0

Flash0

1-4

PRELIMINARY

PRELIMINARY

Benefits of Embedded Flash Memory in a DSP System

1.3 Benefits of Embedded Flash Memory in a DSP System

The circuitry density of flash memory is about half that of conventional EE­PROM memory, making it possible to approach DRAM densities with flash
memory. This increased density allows flash memory to be integrated with a
CPU and other peripherals in a single ’F20x/F24x DSP chip. Embedded flash
memory expands the capabilities of the ’F20x/F24x DSPs in the areas of proto­typing, integrated solutions, and field upgradeable designs.

Embedded flash memory facilitates system development and early field test­ing. Throughout the development process, the system software can be up­dated and reprogrammed into the flash memory for testing at various stages.
Since flash is a non-volatile memory type, the resulting standalone prototype
can be tested in the appropriate environment without the need for battery
backup. In addition to its nonvolatile nature, embedded flash memory has the
advantage of in-system programming. Unlike some discrete flash or EEPROM
chips, embedded flash memory can be programmed without removing the de­vice from the system board. In fact, the embedded flash memory of ’F20x/F24x
DSPs can be programmed using hardware emulators which are already an in­tegral part of the DSP development process; no external programming equip­ment is required.

The embedded flash memory of ’F20x/F24x DSPs also makes these devices
ideal for highly integrated, low-cost systems. The initial investment involved
with making a ROM memory is not justifiable for certain low-cost applications.
Accordingly , when on-chip ROM is not an option, DSP system designers usu­ally resort to using expensive static RAM (SRAM), to store system software
and data. The SRAM provides the fast access times required by the DSP, but
has the disadvantage of being a volatile memory type. To address the issue
of memory volatility , designers often use a low-cost EPROM or flash device to
load the SRAM after system power-up. This approach is very expensive, and
the increased chip count is often prohibitive. The ’F20x/F24x DSPs, with their
on-chip flash memory modules, provide a single chip solution with nonvolatile
memory that supports full speed DSP access rates.

Another benefit of embedded flash memory in a DSP system is remote repro­grammability. Field upgradeability is an extremely useful feature for em­bedded systems. For example, many modem manufacturers offer algorithm
upgrades remotely , without requiring the modem to be removed from the host
computer system. The same type of feature is also being offered for many
handheld consumer products. Adding this capability to a product requires the
addition of EEPROM or flash devices, which increase chip count and system
cost. Since no external equipment is required to program the embedded flash
memory of the ’F20x/F24x DSPs, these devices enable field upgradeability
without impacting system cost.

PRELIMINARY

Introduction

1-5

PRELIMINARY

1-6

PRELIMINARY

PRELIMINARY

Flash Operations and Control Registers

Chapter 2

The operations that modify the contents of the ’F20x/F24x flash array are per­formed in software through the use of dedicated programming algorithms. This
chapter introduces the operations performed by these algorithms and explains
the role of the control registers in this process. The actual algorithms are dis­cussed in Chapter 3.

Topic Page

2.1 Operations that Modify the Contents of the ’F20x/F24x

Flash Array 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 Accessing the Flash Module 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3 Flash Module Control Registers 2-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.4 Read Modes 2-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.5 Program Operation 2-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.6 Erase Operation 2-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.7 Recovering From Over-Erasure (Flash-Write Operation) 2-15. . . . . . . . .

2.8 Reading From the Flash Array 2-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.9 Protecting the Array 2-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

PRELIMINARY

2-1

Operations that Modify the Contents of the ’F20x/F24x Flash Array

PRELIMINARY

2.1 Operations that Modify the Contents of the ’F20x/F24x Flash Array

Operations that modify the contents of the flash array are generically referred
to as either “programming,” which drives one or more bits toward the logic zero
state, or “erasing,” which drives all bits towards the logic one state. It should
be noted that since these operations are performed incrementally, a single
“programming” or “erasing” operation does not ALW A YS result in a valid logic
one or zero. The result of each of these types of operations depends on the
initial state of the bit(s) prior to the operation. This is described in more detail
below.

Within these two basic types of operations (which are related to the fact that
there are only two valid logic levels in the F20x/F24x device) are four distinctly
different types of functions which are actually performed.

In the category of “programming” operations, there are three actual types of
functions that are performed:

 Clear – which is used to write ALL array bits to a zero state,
 Program – which is used to write SELECTED array bits to zero, and
 Flash-Write – which is used to recover ALL array bits from depletion

In the category of “erase” operations, there is only one type of operation:

 Erase – which is used to write ALL array bits to a one state.

Clear, Program, Flash-Write, and Erase are the only four functions that are
used to modify the flash array.

Assuming that the intent of a modification of the contents of the flash array is
to program the array with a selection of ones and zeroes, the following se­quence of operations must be performed for proper operation of the flash
memory:

1) The array is first CLEARED to all zeroes.

2) The array is then ERASED to all ones.

3) The array is then checked for depletion and recovered using FLASH­WRITE if necessary (note that if Flash-Write is used to recover from deple­tion, this sequence must be started over again with the Clear and Erase
functions).

4) Once the array is properly cleared and erased, and verified not to be in
depletion, the array is then PROGRAMMED with the desired selection of
zero bits.

2-2

PRELIMINARY

PRELIMINARY

Operations that Modify the Contents of the ’F20x/F24x Flash Array

This procedure is discussed in complete detail in Chapter 3.
During these operations that are used to modify the contents of the flash array ,

three special read modes, and a corresponding set of reference voltage levels,
are used when reading back data values to verify programming and erase op­erations.

These read modes and reference levels are:

 VER0 – which is used to verify the logic zero level including margin,
 VER1 – which is used to verify the logic one level including margin, and
 Inverse Erase – which is used to verify depletion recovery.

These concepts are illustrated graphically in Figure 2–1 and summarized in
Table 2–1.

Note that ONL Y the Erase and the Flash-Write functions are truly “flash” in the
sense that these functions actually affect all bits in the array simultaneously.
In contrast, bit programming levels in the Program and Clear functions can be
controlled individually on a bit-by-bit basis.

Therefore, when using the Erase or Flash-Write functions, the whole array is
modified, and then the whole array is read, word by word, to verify whether all
words have reached the same value (if not, further iterations of the Erase or
Flash-Write functions continue).

In these cases, as mentioned previously , all the bits in the array are modified
simultaneously , but some bits may react more quickly, potentially resulting in
variation in actual levels on different bits. Therefore, when performing an
Erase, it is possible that some bits may reach depletion even before other bits
reach the logic one reference level (VER1).

The reason that it is critical to clear the array to a consistent zero level before
erasing the array is to give maximum immunity to depletion when erasing.
Note, however, that even when following this sequence, some flash arrays
may experience depletion, and may require recovery using the Flash-Write
function.

In contrast to the true “flash” operations Erase and Flash-Write, after each in­cremental Program or Clear operation, each bit is tested against the VER0 ref­erence level to determine the exact point at which it has reached the proper
value, following which, no further incremental adjustment of the level is made
on that bit. Therefore, when the Program or Clear operation is complete, all bits
are at the same zero level, which greatly increases proper data retention and
depletion immunity for the device. Again, note that the programming and erase
operations are discussed in complete detail in Chapter 3.

PRELIMINARY

Flash Operations and Control Registers

2-3

Operations that Modify the Contents of the ’F20x/F24x Flash Array

Figure 2–1. Flash Memory Logic Levels During Programming and Erasing

Depletion Mode

Inverse Erase
Reference Level

Logic 1

Program operations

Clear



Program



Flash Write



(Towards logic

zero level)

Erase



(Towards logic

one level)

Erase operation

VER1
Reference Level

1 Margin

PRELIMINARY

0 Margin

VER0

Reference
level

Logic 0

Table 2–1. Operations that Modify the Contents of the Flash Array

Change in Bit Level

Towards Logic 1 Towards Logic 0

Function Reference

Level

Erase (all bits) VER1

Function Reference

Program (selected bits) VER0
Clear (all bits) VER0
Flash-Write (all bits) Inverse Erase

Level

2-4

PRELIMINARY

PRELIMINARY

2.2 Accessing the Flash Module

In addition to the flash memory array , each flash module has four registers that
control operations on the flash array. These registers are:

 Segment control register (SEG_CTR)
 Test register (TST)
 Write address register (WADRS)
 Write data register (WDATA)

The flash module operates in one of two modes: one in which the flash memory
is accessed directly by the CPU, and one in which the memory array cannot
be accessed directly , but the four control registers are accessible. This mode
is used for programming. Each flash module has a flash access-control regis­ter that selects between these two access modes. The register is a single-bit,
I/O-mapped register.

The two access modes are summarized as follows:

Accessing the Flash Module

 Array-access mode. Y ou can access the flash array in the memory space

decoded for the flash module. The flash module remains in this mode most
of the time, because it allows the DSP core to read from the memory array .

 Register-access mode. You can access the four control registers in the

memory space decoded for the flash module. This mode is used for pro­gramming. When the flash module is in register-access mode, the regis­ters are repeated every four address locations within the flash module’s
address range.

The flash array is not directly accessible as memory in register-access mode,
and the control registers are not directly accessible in array-access mode.

Figure 2–2 shows memory maps of the flash array in register and array access
modes.

PRELIMINARY

Flash Operations and Control Registers

2-5

Accessing the Flash Module

Figure 2–2. Memory Maps in Register and Array Access Modes

Flash access control register

(single bit)

MODE = 1: Array-access mode
MODE = 0: Register access mode

PRELIMINARY

0100 ... 010
0100 ... 01 1

Flash memory

array

1 110 ...110
01 10 ...111

2.2.1 TMS320F206 Flash Access-Control Register

Because each flash module has an access-control register associated with it,
the ’F206 has two access-control registers. These registers are standard I/O­mapped registers that can be read with an IN instruction and must be modified
with an OUT instruction.

SEG_CTR register

TST register

WADRS register

WDATA register

4 registers duplicated

4 registers duplicated

4 registers duplicated

2-6

 F_ACCESS0 is mapped in I/O space at 0FFE0h.
 F_ACCESS1 is mapped in I/O space at 0FFE1h.

The MODE bit (bit 0) of the access-control register selects the access mode:

MODE = 0 Register-access mode
MODE = 1 Array-access mode

Bits 15–1 of each access-control register are always read as 0 and are unaf­fected by writes.

PRELIMINARY

PRELIMINARY

Although the function is the same, the access control registers of the ’F206 de­vice are mapped at different addresses from that of the ’F24x devices, and
their values are modified in a different way.

2.2.2 TMS320F24x Flash Access-Control Register

The access-control register of the ’F24x devices is a special type of I/O­mapped register that cannot be read. The register is mapped at I/O address
0FF0Fh, and it functions as indicated below.

Note:

For both the IN and OUT instructions, the data operand (dummy) is not used,
and can be any valid memory location.

An OUT instruction using the register address as an I/O port places the flash
module in register-access mode.

For example:

OUT dummy, 0FF0Fh ;Selects register-access mode

Accessing the Flash Module

An IN instruction using the register address as an I/O port places the flash
module in array-access mode.

The data operand (dummy) is not used, and can be any valid memory location.
For example:

IN dummy, 0FF0Fh;Selects array-access mode

PRELIMINARY

Flash Operations and Control Registers

2-7

Flash Module Control Registers

Relati

Regi

2.3 Flash Module Control Registers

T able 2–2 lists the control registers and their relative addresses within the four
locations that repeat throughout the module’s address range.

Table 2–2. Flash Module Control Registers

PRELIMINARY

ve

Address

0 SEG_CTR Segment control register. The eight MSBs enable spe-

1 TST Test register. Reserved for test; not accessible to the

2 WADRS Write address register. Holds the address for a write

3

ster

Name

WDATA Write data register . Holds the data for a write operation. 2.3.4 2-8

Description

cific segments for programming. Setting a bit to 1 en­ables the segment. The eight LSBs control the pro­gram, erase, and verify operations of the module.

user.

operation.

2.3.1 Segment Control Register (SEG_CTR)

SEG_CTR is a 16-bit register that initiates and monitors the programming and
erasing of the flash array . This register contains the bits that initiate the active
operations (the WRITE/ERASE field and EXE bit), those used for verification
(VER0 and VER1), and those used for protection (KEY0, KEY1, and
SEG7–SEG0). All bits of SEG_CTR register are cleared to 0 upon reset.

Described in ...

Section

2.3.1 2-5

2.3.2 2-8

2.3.3 2-8

Page

SEG_CTR is shown in Figure 2–3 and the fields are described in Table 2–3.

Figure 2–3. Segment Control Register (SEG_CTR)

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

SEG7 SEG6 SEG5 SEG4 SEG3 SEG2 SEG1 SEG0 Res KEY1 KEY0 VER0 VER1

RW–0 RW–0 RW–0 RW–0 RW–0 RW–0 RW–0 RW–0 X RW–0 RW–0 RW–0 RW–0 RW–0 RW–0

Legend: R = read

2-8

W = write
–0 = value after reset
X = don’t care

WRITE/
ERASE

PRELIMINARY

EXE

PRELIMINARY

Flash Module Control Registers

Table 2–3. Segment Control Register Field Descriptions

Bits Name Description

15–8 SEG7–SEG0 Segment enable bits. Each of these bits protects the specified segment against pro-

gramming or enables programming for the specified segment in the array . Any number
of segments (from 0 to 7 in any combination) can be enabled at any one time. See
T able 2–4 for segment address ranges. EXE must be cleared to modify the SEGx bits.

SEGx = 1 enables programming of the corresponding segment.

SEGx = 0 protects the segment from programming.
7 Reserved This bit is not affected by writes, and reads of this bit are undefined.
6–5 KEY1, KEY0 Execute key bits. A binary value of 10 must be written to these bits in the same DSP

core access in which the EXE bit is set for the selected operation (erase, program, or

flash-write) to start. KEY1 and KEY0 must be cleared in the same write access that

clears EXE. These bits are used as additional protection against inadvertent program-

ming or erasure of the array. These bits are read as 0s.
4–3 VER0, VER1 Verify bits. These bits select special read modes used to verify proper erasure or pro-

gramming.

Possible values:

00: Normal read mode

01: Verify 1s (VER1) read mode to verify margin of 1s for proper erasure

10: Verify 0s (VER0) read mode to verify margin of 0s for proper programming

1 1: Inverse-read mode; tests for bits erased into depletion
2–1 WRITE/ERASE Write/erase enable field. These bits select the program, erase, or flash-write operation.

However, modification of the array data does not actually start until the EXE bit is set.

Reset clears these bits to zero.

Possible values:

00: Read operation is enabled. These bit values are required to read the array.

01: Erase operation is enabled

10: Write operation is enabled

1 1: Flash-write operation is enabled
0

EXE Execute bit. In conjunction with WRITE/ERASE, KEY1, and KEY0, this bit controls the

program, erase, and flash-write operations. Setting EXE starts and stops program-

ming and erasing of the flash array. The KEY1 and KEY0 bits must be written in the

same write access that sets EXE, and EXE must be cleared in the same write access

that clears KEY1 and KEY0. EXE must be cleared to modify the SEGx bits.

Note: The segment enable bits are not intended for protection during the erase or flash-write operations. During these opera-

PRELIMINARY

all

segments must be enabled.

tions,

Flash Operations and Control Registers

2-9

Flash Module Control Registers

3

Segme

F241/F243

Array Segment

Table 2–4. Flash Array Segments Summary

PRELIMINARY

SEG7–SEG0 Bits ’F206/F240 Flash Module

15 14 13 12 11 10 9 8 Flash0 Flash1

0 0 0 0 0 0 1 0000–07FFh 4000–47FFh 0000–03FFh 0

0
000000100800–0FFFh 4800–4FFFh 0400–07FFh 1
000001001000–17FFh 5000–57FFh 0800–0BFFh 2
000010001800–1FFFh 5800–5FFFh 0C00–0FFFh 3
000100002000–27FFh 6000–67FFh 1000–13FFh 4
001000002800–2FFFh 6800–6FFFh 1400–17FFh 5
010000003000–37FFh 7000–77FFh 1800–1BFFh 6

0 0 0 0 0 0 0 3800–3FFFh 7800–7FFFh 1C00–1FFFh 7

1

†

The TMS320F206 has two flash modules. The TMS320F240 device uses the address ranges shown for Flash0.

†

’F241/F24

Flash Module

Array

Although segmentation is not supported during erase (i.e., the entire array
must be erased simultaneously), the segment enable bits can be used to pro­tect portions of the array against unintentional programming. This is useful for
applications in which different portions of the array are programmed at differ­ent times. For example, an application might program the flash module with
a large table in 2K × 16 blocks. Some time after the first block is programmed,
the next block is programmed. The segment enable bits can be used to prevent
corruption of the first block while the second block is being programmed.

nt

Enabled

2.3.2 Flash Test Register (TST)

The flash test register (TST) is a 5-bit register used during manufacturing test
of the flash array. This register is not accessible to the DSP core.

2.3.3 Write Address Register (WADRS)

The write address register (WADRS) is a 16-bit register that holds the latched
write address for a programming operation. In array-access mode, this regis­ter is loaded with the value on the address bus when you are writing a data
value to the flash module. It can be loaded directly in register-access mode by
writing to it.

2-10

PRELIMINARY

PRELIMINARY

2.3.4 Write Data Register (WDATA)

The write data register (WDA TA) is a 16-bit register that contains the latched
write data for a programming operation. In array-access mode, this register
can be loaded by writing a data value to the flash module. It can be loaded di­rectly in register-access mode by writing to it. The WDATA register must be
loaded with the value FFFFh before an erase operation starts.

Flash Module Control Registers

PRELIMINARY

Flash Operations and Control Registers

2-11

Read Modes

2.4 Read Modes

PRELIMINARY

The ’F20x/F24x flash module uses four read modes and corresponding sets
of reference levels:

 Standard
 Verify 0s (VER0)
 Verify 1s (VER1)
 Inverse-erase

Read mode selection is accomplished through the verify bits (bits 3 and 4) in
SEG_CTR during execution of the algorithms.

In the standard read mode of the ’F20x/F24x flash module, the supply voltage
(VDD) is internally applied to the cell to select it for reading. The VER0, VER1,
and inverse-erase read modes differ from the standard read mode in the inter­nal voltage level applied to the flash cell.

Because the program and erase operations must provide sufficient margin on
1s and 0s to ensure data retention, the verify 0s (VER0) and verify 1s (VER1),
are provided on the flash module to check for sufficient margin.

The VER0 and VER1 read modes provide a method for adjusting the level on
the cells during programming or erasing, beyond the point required for reading
a 0 or a 1, creating the required logic level margin. In VER0 mode, a voltage
closer to an ideal logic zero level than necessary to read a logic zero is internal­ly applied to the cell to select it for reading. This is the worst-case condition for
reading a programmed cell, and if a cell can be read as 0 in VER0 mode, then
it can also be read as 0 in standard read mode. Similarly, in the VER1 read
mode, a voltage closer to an ideal logic one level than necessary to read a logic
one is internally applied to the cell to select it for reading. This is the worst-case
condition for reading an erased cell, and if a cell can be read as 1 in the VER1
mode, then it can be read as 1 in standard read mode.

The inverse-erase read mode detects flash bits that are in depletion mode.
This read mode applies a voltage to all array cells so that all cells are dese­lected. The entire array can be tested for bits in depletion mode by reading the
first row (32 words) of the array in inverse-erase read mode. If there are no bits
in depletion mode, all 32 words are read as 0000h.

2-12

PRELIMINARY

PRELIMINARY

2.5 Program Operation

The program operation of the ’F20x/F24x flash module loads the application­specific data (a pattern of 0s) into the flash array. The basis of the operation
is applying a program pulse to a single word of flash memory. The term

gram pulse

and the clearing of the EXE bit ( bit 0 of SEG_CTR). During the program pulse,
charge is added to the addressed bits via the programming mechanism. Sev­eral program pulses may be required to fully program the bits of a word, and
the application of program pulses is controlled by the programming algorithm.

The flash location to be programmed is specified by the address in the WADRS
register, and the data pattern to be programmed is loaded into the WDA T A reg­ister. Only the bits that contain a 0 are programmed; any bit positions contain­ing a 1 remain unchanged. (See sections 2.3.3 and 2.3.4 for information about
how to load the WADRS and WDATA registers.)

T o assure that the 0 bits are programmed with enough margin, the reads asso­ciated with programming are performed using the VER0 read mode. After a
program pulse has been applied, the byte is read back in VER0 mode to assure
that programmed bits can be read as 0 over the entire operating range of the
device.

Program Operation

pro-

refers to the time during the program operation between the setting

The flash module supports programming of up to eight bits of data. Therefore,
although the flash bits are addressed on 16-bit word boundaries, only eight bits
can be programmed at a time. The algorithm must limit the programming to
eight bits by masking the word to be programmed before writing it to the WDA­TA register. For example, to mask off the upper byte while programming the
lower byte, the data value is logically 0Red with 0FF00h in software. When a
program pulse is applied, only the selected bits are programmed.

PRELIMINARY

Flash Operations and Control Registers

2-13

Erase Operation

2.6 Erase Operation

The erase operation of the ’F20x/F24x flash module prepares the flash array
for programming and enables reprogrammability of the flash array . Before the
array can be erased, all bits must be programmed to 0s. This procedure of pro­gramming all array locations in preparation for the erase is called

array

the erase is finished, a depletion mode test is made to determine whether any
bits have been over-erased. If over-erased bits are detected, they must be re­covered with the flash-write algorithm, and the clear and erase algorithms
must be repeated.

PRELIMINARY

clearing the

. During the erase, all bits in the array are changed from 0s to 1s. After

erase pulse

An
the clearing of the EXE bit ( bit 0 of SEG_CTR). During the erase pulse, the
level on all array bits is modified via the erase mechanism.

Erasing the flash array is a block operation. During the erase pulse, all array
bits are af fected simultaneously . (See Figure 2–1,

els During Programming and Erasing

this mechanism.) Multiple erase pulses may be required to fully erase all bits
in the array , and the application of erase pulses is controlled by the erase algo­rithm.

The erase operation uses the VER1 read mode to determine when erasure is
complete. After erasure is complete, the inverse-erase read mode is used to
determine if any bits are over-erased. For more information about these read
modes, see section 2.4,

is the time during the erase operation between the setting and

Flash Memory Logic Lev-

, on page 2-4 for an illustration of

Read Modes

, on page 2-12.

2-14

PRELIMINARY

PRELIMINARY

Recovering From Over-Erasure (Flash-Write Operation)

2.7 Recovering From Over-Erasure (Flash-Write Operation)

Generally, not all bits in the flash array have the same amount of charge re­moved with each erase pulse. By the time all bits have reached the VER1 read
margin (and erase is complete), some of the bits in the array may be over­erased. They are said to be in depletion mode. If even one single flash cell is
over-erased into depletion mode, it is always read as logic 1 and can corrupt
the reading of other bits. This condition must be detected and corrected, be­cause it also inhibits reprogramming of the flash array.

The ’F20x/F24x flash array employs the flash-write operation to recover bits
that are erased into depletion mode. The flash-write operation is similar to the
erase operation in that it affects all bits in the array simultaneously. This en­ables recovery of multiple bits from depletion mode, but requires the flash­write operation to be followed by the clear and erase operations to restore the
erase margin on all bits.

flash-write pulse

A
ting and the clearing of the EXE bit (bit 0 of SEG_CTR). During the flash-write
pulse, all array bits are affected simultaneously. (See Figure 2–1,

Memory Logic Levels During Programming and Erasing

illustration of this mechanism.) Multiple flash-write pulses may be required to
fully recover all bits in the array , and the application of flash-write pulses is con­trolled by the flash-write algorithm.

The flash-write operation uses the inverse-erase read mode and inverse­erase reference level to detect bits that are in depletion mode. For more infor­mation about the inverse-erase read mode, see section 2.4,
page 2-12.

is the time during the flash-write operation between the set-

Flash

, on page 2-4 for an

Read Modes

, on

PRELIMINARY

Flash Operations and Control Registers

2-15

Reading From the Flash Array

2.8 Reading From the Flash Array

Once the array is programmed, it is read in the same manner as other memory
devices on the DSP memory interface. The flash module operates with zero
wait states. When you are reading the flash module, the flash segment control
register (SEG_CTR) bits should be 0 and the flash array must be in the array­access mode.

2.9 Protecting the Array

After the flash memory array is programmed, it is desirable to protect the array
against corruption. The flash module of the ’F20x/F24x DSPs includes several
protection mechanisms to prevent unintentional modification of the array.

Flash programming is facilitated via the supply voltage connected to the VCCP
pin. If this pin is grounded, the program operation will not modify the flash array .
Note, that grounding the VCCP pin does not prevent the erase operation; other
protection mechanisms for the erase operation are discussed below.

The control registers provide the following mechanisms for protecting the flash
array from unintentional modification.

PRELIMINARY

 Segment enable bits
 EXE, KEY0, and KEY1 bits
 WDATA register

An array segment is prevented from being programmed when the correspond­ing segment enable bit in the SEG_CTR is cleared to zero. Additionally , all seg­ment enable bits are cleared by reset, making unintentional programming less
likely . Even if the segment enable bits are set to one, the program, erase, and
flash-write operations are not initiated unless the appropriate values are set
in the EXE, KEY0, and KEY1 bits of the SEG_CTR.

At the start of an operation, the KEY1 and KEY0 bits must be written in the
same write access that sets EXE. When the program pulse, erase pulse, or
flash-write pulse is finished, EXE must be cleared in the same write that clears
KEY1 and KEY0. The data and address latches are locked whenever the EXE
bit is set, and all attempts to read from or write to the array are ignored (read
data is indeterminate). Once the EXE bit is set, all register bits are latched and
protected. Y ou must clear EXE to modify the SEGx bits. This protects the array
from inadvertent change. Unprotected segments cannot be masked in the
same register load with the deactivation of EXE. Additional security is provided
by a function of the WDATA register to prevent unintentional erasure. The
WDA TA register must be loaded with FFFFh before the erase operation is initi­ated. If the register is not loaded with this value, the array will not be modified.

2-16

PRELIMINARY

PRELIMINARY

Chapter 3

Algorithm Implementations

and Software Considerations

This chapter discusses the implementations of the algorithms for performing
the operations described in the previous chapter. It also discusses items you
must consider when incorporating the algorithms into your ’F20x/F24x DSP
application code.

Topic Page

3.1 How the Algorithms Fit Into the Program-Erase-Reprogram

Flow 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2 Programming (or Clear) Algorithm 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3 Erase Algorithm 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.4 Flash-Write Algorithm 3-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

PRELIMINARY

3-1

How the Algorithms Fit Into the Program-Erase-Reprogram Flow

PRELIMINARY

3.1 How the Algorithms Fit Into the Program-Erase-Reprogram Flow

The algorithms discussed in this chapter can be used to reprogram the
’F20x/F24x flash module multiple times. The clear algorithm, erase algorithm,
and flash-write algorithm are used to prepare the flash memory for program­ming, while the programming algorithm is used to write a desired pattern of 0s
to the array (program the array).

The programming algorithm and the clear algorithm are both implementations
of the program operation. The difference between the two is the data that is
written: the programming algorithm programs the user data, while the clear al­gorithm uses all 0s. All of the algorithms can be viewed as portions of a single
flow diagram, as shown in Figure 3–1.

Note that in the algorithm flowcharts, the variable X represents the number of
attempts at depletion recovery using the flash-write algorithm. It has been
shown that if flash-write is not successful in depletion recovery after ten at­tempts, depletion recovery is not possible, and a device failure has occurred.
Therefore, if ten flash-write attempts at depletion recovery are not successful,
the algorithm returns a device failure error message.

3-2

PRELIMINARY

PRELIMINARY

How the Algorithms Fit Into the Program-Erase-Reprogram Flow

Figure 3–1. Algorithms in the Overall Flow

Start
X = 1

Initialization flow

Clear

algorithm

Erase

algorithm

Clear the

array

Erase the

array

Bits in

depletion?

No

Yes

Flash-write

algorithm

Recover using

flash-write

X = X+1

Yes

X < 10 ?

No

Fail

Yes

No

Reprogram?

Done/Stop

Program
the array

Programming
algorithm

PRELIMINARY

Algorithm Implementations and Software Considerations

3-3

Programming (or Clear) Algorithm

3.2 Programming (or Clear) Algorithm

The programming algorithm sequentially writes any number of addresses with
a specified bit pattern.This algorithm is used to program application code or
data into the flash array. With a slight modification, the same algorithm per­forms the clear portion of the initialization flow (i.e., programs all bits to zero).
In this role, the algorithm is called the clear algorithm. For the clear algorithm,
the values programmed are always 0000h, while the values for application
code can be any combination of 1s and 0s. Figure 3–2 highlights the program­ming and clear algorithms’ place in the overall flow.

Figure 3–2. The Programming Algorithm in the Overall Flow

Initialization flow

Start
X = 1

PRELIMINARY

Clear

algorithm

Erase

algorithm

Clear the

array

Erase the

array

Bits in

depletion?

No

Yes

Flash-write

algorithm

Recover using

flash-write

X = X+1

Yes

X < 10 ?

No

Fail

Yes

No

Reprogram?

Done/Stop

Program
the array

Programming
algorithm

3-4

PRELIMINARY

PRELIMINARY

Programming (or Clear) Algorithm

The main feature of the program/clear algorithm is the concept of program­ming an entire row of bits in a group. The ’F20x/F24x flash array is organized
in rows of 32 words. That is, addresses 0000h through 001Fh are physically
located on the same row of the flash memory array . The array is designed so
that there is a dependence between the charge levels on adjacent (even–odd)
addresses during programming. Programming the bits of an odd address re­duces the charge margin of the programmed bits (the 0s) in the preceding ad­jacent (even) address within the row. Similarly, programming the bits of an
even address reduces the charge margin of the programmed bits in the next
adjacent (odd) address within the row. Because of this dependence, if each
address is programmed individually, the charge levels among programmed
bits is not uniform. The programming algorithm improves the uniformity of
charge levels on programmed bits by programming all of the words of a row
in a group. For example, the contents of address 0000h is compared with the
data to be programmed and one program pulse is applied if necessary. The
same procedure is performed on addresses 0001h through 001Fh. The proce­dure repeats starting at address 0000h until no more program pulses are re­quired for any address in the row. The number of iterations of this loop equals

s

the maximum number of program pulse
row.

required to program the bits in the

The flow for the programming algorithm is shown in Figure 3–3, and the as­sembly code is given in Appendix A.

An important consideration for programming the flash array is the CPU fre­quency range for the application. Because of the actual implementation of the
flash memory circuitry, a 0 bit is most easily read at high frequency; pro­grammed bits have less margin when read at lower frequency. So, if the ap­plication requires a variable CPU clock rate, programming should be per­formed at the lowest frequency in the range. (A similar condition exists for the
erase operation, which requires execution of the erase algorithm at the highest
frequency in the range. See section 3.3, page 3-10.)

Only the read portion of the program operation must be performed at the lower
frequency , because the read is used to determine margin. The read operation
can be extended by sequentially executing multiple reads on the same loca­tion. Because the same address is selected the entire time and internal control
signals are maintained between reads, the final read is equivalent to a slow
read. For example, if the DSP core is executing the programming algorithm at
a CLKOUT rate of 20 MHz (50 ns), sequentially reading a location three times
is equivalent to reading it once at 6.67 MHz (150 ns). This is important, be­cause it facilitates execution of the program and erase algorithms at the same
CLKOUT rate.

PRELIMINARY

Algorithm Implementations and Software Considerations

3-5

Programming (or Clear) Algorithm

Figure 3–3. Programming or Clear Algorithm Flow

Start

New row

Save row start

address

Same row

Current address

= row start address;

row_done = true

PRELIMINARY

No

No

Verify con-

tents

of current

address

Program

pulse

required?

No

Increment

address

End

of

row?

Yes

Row_done

=

true?

Steps 2–5 in Table 3–1

Step 6 in Table 3–1

Yes

No

Steps 7–25
in Table 3–1

Apply program

pulse;

row_done = false

Pulsecount

=max†?

Yes

†

See the device data sheet for the timing
parameter values.

3-6

No

Yes

Current

address >

end address?

Yes

Device failureContinue

PRELIMINARY

PRELIMINARY

Programming (or Clear) Algorithm

Another important consideration is the total amount of time required to do the
programming. The number of programming pulses required to completely pro­gram a flash memory cell increases as ambient temperature increases and/or
supply voltage decreases. More programming pulses are required when the
minimum supply voltage is used than when the nominal or maximum supply
voltage is used. The number of program pulses required also increases
throughout the life of the device, as more program-erase cycles are carried
out. The device data sheet specifies the maximum number of program pulses
under all operating conditions; use this number when you calculate the maxi­mum amount of time required for programming.

The algorithm incorporates the steps for applying a program pulse (outlined
in Table 3–1) along with some other techniques to ensure margin. In general,
not all flash bits require the same number of program pulses to reach the pro­grammed margin level. For this reason, the programming algorithm applies a
series of short program pulses until the memory location is programmed. How­ever, to understand how the series of program pulses works, you must first un­derstand how the algorithm applies a single program pulse. T able 3–1 outlines
the steps involved in verifying programmed bits and applying a single pulse to
each of the upper and lower bytes of a single location. This process corre­sponds to the steps enclosed in the dashed box in the flowchart in Figure 3–3.

Table 3–1. Steps for Verifying Programmed Bits and Applying One Program or Clear
Pulse

Step Action Description

1 Power up the V

2 Activate VER0 mode. Set the VER0 bit in SEG_CTR (load SEG_CTR with 0010h).
3 Delay for VER0 reference

voltage stabilization.

4 Read flash array contents for

verification.

5 Deactivate VER0 mode. Clear the VER0 bit in SEG_CTR (load SEG_CTR with 0000h).
6 Compare contents of flash

location (16 bits) with de­sired data.

PRELIMINARY

pin. Set the V

CCP

grammed is not set to VDD, then the array will not be programmed.

The CPU executes a delay loop for the t

The CPU reads the addressed location. The flash module must be in
array-access mode (see section 2.2,
2-5).

If the verification passes (i.e., if the data read in step 4 is equal to the de­sired data value), then no further program pulses are required. The flash
word has been programmed with the desired data value. The program
or clear function is completed and this algorithm is exited.

If the verification fails (i.e., if the data read in step 4 is not equal to the
desired data value), then proceed to step 7.

Algorithm Implementations and Software Considerations

CCP

pin to V

DD.

If the V

pin for the flash module to be pro-

CCP

d(VERIFY -SETUP†)

Accessing the Flash Module

time period.

, page

3-7

Programming (or Clear) Algorithm

PRELIMINARY

Table 3–1. Steps for Verifying Programmed Bits and Applying One Program or Clear
Pulse (Continued)

Step DescriptionAction

7 Mask the data to program

lower byte.

8 Load WADRS and WDATA

registers.

10 Activate the WRITE/ERASE

field and enable segments.

†

See the device data sheet for the timing parameter values.

1 1 W ait for internally generated

supply voltage stabilization
time.

12 Initiate the program pulse. Load the EXE, KEY1, and KEY0 bits with 1, 1, and 0, respectively. All

13 Delay for program pulse

time.

14 Terminate the program

pulse.

Mask any bits in the lower byte that do not require programming (are al­ready read as zero), and mask off upper byte. Recall that the algorithm
should mask one byte while programming the other because a maximum
of eight bits can be programmed simultaneously .

If the flash module is in array access mode, write the data to be pro­grammed to its address. If the flash module is in register access mode,
load the individual registers directly.

Set the WRITE/ERASE field in SEG_CTR to 10 and set the correspond­ing segment enable bits (SEG0–SEG7) for the segments where the pro-
grammed word resides.

The CPU executes a delay loop for the t

three bits must be loaded in the same write cycle.
The segment enable bits and the WRITE/ERASE field must also be

maintained.
The CPU executes a delay loop for the t

Clear the WRITE/ERASE field and EXE bit in SEG_CTR (e.g., load
SEG_CTR with 0000h).

d(PGM–MODE†)

d(PGM†)

time period.

time period.

15 Delay for array stabilization

time.

16–25 Program upper byte if nec-

essary.

†

See the device data sheet for the timing parameter values.

3-8

The CPU executes a delay loop for the t

Repeat steps 7–15 for the upper byte. Mask the lower byte to 1s when
programming the upper byte.

d(BUSY†)

time period.

PRELIMINARY

PRELIMINARY

Programming (or Clear) Algorithm

Before each program pulse is applied, a read of the byte is performed to deter­mine which bits have reached the programmed level. Any bits that have
reached the programmed level are masked (set to 1 in the WDA TA register).
This method of programming provides uniform charge levels among pro­grammed bits, whereas using a single, long program pulse could result in
some bits having much more charge than others. The uniformity of charge lev­els among bits has the primary effect of reducing programming time and the
secondary effect of reducing the time for a subsequent erase operation. T o as­sure that the bits are programmed with enough margin, the reads associated
with programming use the VER0 read mode.

PRELIMINARY

Algorithm Implementations and Software Considerations

3-9

Erase Algorithm

3.3 Erase Algorithm

The erase algorithm follows the clear algorithm in executing the entire initial­ization flow. Figure 3–4 highlights the erase algorithm’s place in the overall
flow.

Figure 3–4. Erase Algorithm in the Overall Flow

Start
X = 1

PRELIMINARY

Initialization flow

Clear

algorithm

Erase

algorithm

Clear the

array

Erase the

array

Bits in

depletion?

No

The erase algorithm consists of multiple iterations of a loop with one erase
pulse applied in each iteration. Table 3–2 outlines the steps involved in apply­ing a single erase pulse.

Yes

Flash-write

algorithm

Recover using

flash-write

X = X+1

Yes

X < 10 ?

No

Fail

Yes

No

Reprogram?

Done/Stop

Program
the array

Programming
algorithm

3-10

PRELIMINARY

PRELIMINARY

Table 3–2. Steps for Applying One Erase Pulse

Step Action Description

Erase Algorithm

1 Power up the V

2 Load WDATA register with

FFFFh.

3 Activate the erase mode and

enable segments.

4 Wait for internally generated

supply voltage stabilization
time.

5 Initiate the erase pulse. Load the EXE, KEY1, and KEY0 bits with 1, 1, and 0, respectively. All

6 Delay for erase pulse time. The CPU executes a delay loop for the t
7 Terminate the erase pulse. Clear the EXE bit and WRITE/ERASE field in the SEG_CTR register

8

†

See the device data sheet for the timing parameter values.

Delay for mode deselect
time.

pin. Set V

CCP

is not set to VDD, then the array will not be erased properly .
This load overrides the erase protection mechanism.

Set the WRITE/ERASE field to 01 and set SEG0–SEG7 bits in the
SEG_CTR register. The flash module must be in register-access
mode (see section 2.2).

The CPU executes a delay loop for the t

three bits must be loaded in the same write cycle.
The segment enable bits and the WRITE/ERASE field must also be

maintained.

(load SEG_CTR with 0000h to clear all bits).
CPU executes a delay loop for the t

CCP

pin to V

DD.

If the V

pin for the flash module to be erased

CCP

d(ERASE-MODE†)

d(ERASE†)

d(BUSY†)

time period.

time period.

time period.

PRELIMINARY

At the beginning of each iteration, a read operation is performed on all the bits
in the array to determine if an erase pulse is required. Erasure is complete
when all array locations are read as FFFFh. To assure that the flash array is
erased with enough margin, the reads associated with the erase use the VER1
read mode. Additional margin can be gained during the erase operation if the
reads are performed using

address complementing

. When the array is read
with address complementing, the following sequence is used for each address
read:

1) All of the bits of the address to be read are complemented.

2) The contents of the resulting address are read.

3) The value read at the complemented address is discarded.

Algorithm Implementations and Software Considerations

3-1 1

Erase Algorithm

PRELIMINARY

4) The actual address is restored.

5) The contents of the restored address are read.
The advantage of this approach is that it forces the worst-case switching condi-

tion on the flash addressing logic during the reads, thus improving the margin
of the erase. Address complementing on the ’F20x/F24x can be accomplished
easily by using the XOR instruction to complement the bits of the address.

An important consideration for erasing the flash array is the CPU frequency
range for the application. Because of the actual implementation of the flash
memory circuitry, a logic 1 is most easily read at low frequency; erased bits
have less margin when read at higher frequency . Accordingly, if the application
requires a variable CPU clock rate, the erase should be performed at the high­est frequency in the range. (A similar condition exists for the programming op­eration, which requires execution of the programming algorithm at the lowest
frequency in the range. See section 3.2, page 3-4.)

Another important consideration is the total amount of time required to erase
the array. The number of erase pulses required to completely erase a flash
memory cell increases as ambient temperature increases or decreases rela­tive to the nominal temperature and as supply voltage decreases. More erase
pulses are required when the ambient temperature is toward the extremes of
the operating range. Also, more erase pulses are required when the minimum
supply voltage is used than when the nominal or maximum supply voltage is
used. The number of erase pulses required also increases throughout the life
of the device, as more program-erase cycles are carried out. The device data
sheet specifies the maximum number of erase pulses under all operating con­ditions; use this number when you calculate the maximum amount of time re­quired for the erase algorithm.

3-12

The complete erase algorithm including depletion check is shown in the flow­chart in Figure 3–5.

PRELIMINARY

PRELIMINARY

Figure 3–5. Erase Algorithm Flow

(all words=0000h)

Set VER1

bit in SEG_CTR

Wait for

t

d(BUSY-VERIFY)

Read all locations

using address

complementing

Clear all bits

in SEG_CTR

Erase Algorithm

Start

Verify
erase

†

See the device data sheet for
the timing parameter values.

(see Table 3–2)

No

All

words =

FFFFh

?

No

Apply one

erase pulse

to flash array

Erase

pulse count

†

?

≥ Max

Yes

Device failure

Yes

Depletion

recovery

Set VER0 and

VER1 bits in

SEG_CTR

Wait for

t

d(BUSY-INVERSE)

Read first
32 words

No

32 words
= 0000h?

Program array

Depletion

check

All

Yes

PRELIMINARY

Algorithm Implementations and Software Considerations

3-13

Flash-Write Algorithm

3.4 Flash-Write Algorithm

The flash-write operation recovers bits in depletion mode, which can be
caused by over-erasure. The flash-write algorithm’s place in the overall flow
is highlighted in Figure 3–6.

Figure 3–6. Flash-Write Algorithm in the Overall Flow

Initialization flow

Start
X = 1

PRELIMINARY

Clear

algorithm

Erase

algorithm

Clear the

array

Erase the

array

Bits in

depletion?

No

A
ting and the clearing of the EXE bit (bit 0 of SEG_CTR). Charge is added to
the bits of the flash memory array via the flash-write mechanism. The flash­write algorithm may require multiple flash-write pulses. The steps required to
apply one flash-write pulse are outlined in Table 3–3.

Flash-write

algorithm

Yes

flash-write pulse

Yes

Recover using

flash-write

X = X+1

Yes

X < 10 ?

No

Fail

Reprogram?

Program
the array

Programming
algorithm

No

Done/Stop

is the time during the flash-write operation between the set-

3-14

PRELIMINARY

PRELIMINARY

Table 3–3. Steps for Applying One Flash-Write Pulse

Steps Action Description

Flash-Write Algorithm

1 Power up the V

2 Activate the flash-write

mode and enable all seg­ments.

3 Wait for the internally gener-

ated supply voltage stabi­lization time.

4 Initiate the flash-write pulse. Load the EXE, KEY1, and KEY0 bits with 1, 1, and 0, respectively . All

5 Delay for the flash-write

pulse time.

6 Terminate the flash-write

pulse.

7 Delay for mode deselect

time.

†

See the device data sheet for the timing parameter values.

pin. Set the V

CCP

pin to VDD. If the V
covered is not set to V
fective.

Set the WRITE/ERASE field to 10 and set SEG0–SEG7 in the
SEG_CTR register. The flash module must be in register access
mode (see section 2.2).

The CPU executes a delay loop for the t

three bits must be loaded in the same write cycle.
The segment enable bits and WRITE/ERASE field must also be main-

tained.
The CPU executes a delay loop for the t

Clear all bits in the SEG_CTR register (load SEG_CTR with 0000h).

CPU executes a delay loop for the t

CCP

, then the flash-write operation will not be ef-

DD

pin for the flash module to be re-

CCP

d(FLW-MODE†)

d(FLW†)

d(BUSY†)

time period.

time period.

time period.

PRELIMINARY

The flash-write algorithm consists of multiple iterations of a loop with one flash­write pulse applied in each iteration. At the beginning of each iteration, a deple­tion test is performed to determine if a flash-write pulse is required. Figure 3–7
shows the flow of the flash-write algorithm.

The flash-write operation uses the inverse-erase read mode to detect bits that
are in depletion mode. For more information about the inverse-erase read
mode, see section 2.4,

Algorithm Implementations and Software Considerations

Read Modes

, on page 2-12.

3-15

Flash-Write Algorithm

Figure 3–7. Flash-Write Algorithm Flow

Start

Set VER0 and VER1

bits in SEG_CTR

Wait for

t

d(RD-VERIFY)

Read first 32 words

PRELIMINARY

Depletion

check

†

See the device data sheet for the timing
parameter values.

All 32

words =

0000h?

Apply one flash-write

pulse to flash array

(see Table 3–3)

No

Flash-write

pulse count

†

≥ Max

Yes

Device failure

Yes

No

?

Go to clear

3-16

PRELIMINARY

PRELIMINARY

Flash-Write Algorithm

The CPU frequency range for the application is an important consideration for
the depletion test, as well as for the program and erase operations. Because
of the actual implementation of the flash memory circuitry, a bit in depletion
mode is most easily detected at low frequency . Accordingly, if the application
requires a variable CPU clock rate, the depletion test should be performed at
the lowest frequency in the range. Only the read portion of the depletion test
must be performed at the lower frequency , because it is the read that is used
to detect depletion. The effective duration of the read operation can be ex­tended by sequentially executing multiple reads on the same location. Be­cause the same address is selected the entire time and internal control signals
are maintained between reads, the final read is equivalent to a slow read. For
example, if the DSP core is executing the programming algorithm at a
CLKOUT rate of 20 MHz (50 ns), sequentially reading a location three times
is equivalent to reading it once at 6.67 MHz (150 ns). The erase and flash-write
algorithm implementations given in Appendix A use three reads to check for
depletion.

PRELIMINARY

Algorithm Implementations and Software Considerations

3-17

PRELIMINARY

3-18

PRELIMINARY

PRELIMINARY

Appendix A

Appendix A

Assembly Source Listings and

Program Examples

The flash array is erased and programmed by code running on the DSP core.
This code can originate from off-chip memory or can be loaded into on-chip
RAM. The available flash programming tools for the ’F20x/F24x allow you to
program the on-chip flash module without having knowledge or visibility of the
algorithms. One scheme uses the scan emulation feature of the ’F20x/F24x to
load the algorithms onto the DSP and control execution, and another scheme
relies on boot loader code preprogrammed into the flash memory at the facto­ry . Y ou can find more information about these stand-alone flash programming
tools on the Texas Instruments web page at http://www .ti.com. This appendix
explains how to use the algorithm source files to program the flash module.
You need this information to create new flash programming tools or to add
such features as remote reprogrammability to a design.

PRELIMINARY

Topic Page

A.1 Assembly Source for Algorithms A-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A.2 C-Callable Interface to Flash Algorithms A-27. . . . . . . . . . . . . . . . . . . . . . .

A.3 Sample Assembly Code to Erase and Reprogram

the TMS320F206 A-32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A.4 Sample C Code to Erase and Reprogram the TMS320F206 A-37. . . . . .

A.5 Sample Assembly Code to Erase and Reprogram

the TMS320F240 A-40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A.6 Using the Algorithms with C Code to Erase and Reprogram the

TMS320F240 A-47. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A-1

Assembly Source for Algorithms

A.1 Assembly Source for Algorithms

The algorithm source files implement the flows given in Chapter 3. Each algo­rithm is written as an assembly language subroutine, beginning with a label at
an entry point and ending with a return instruction. The algorithms share a set
of 16 relocatable variables for which pointers are defined in the header file,
SVAR20.H.

The variables are defined at the beginning of B1 RAM, and an uninitialized sec­tion should be declared at link time to reserve this space. Also, the data page
pointer (DP) should be initialized to point to this space before a call is made to
any of the algorithms.

In addition to these variables, each algorithm references parameters that
should be declared globally in the calling code. These parameters are listed in
the introduction to each of the algorithm source files below.

The source files given are:

 SVAR20.H: header file that defines variables and constants
 SCLR20.ASM: clear algorithm
 SERA20.ASM: erase algorithm
 SFLW20.ASM: flash-write algorithm
 SPGM20.ASM: programming algorithm
 SUTILS20.ASM: subroutines common to all four algorithms

PRELIMINARY

The same algorithm files can be used for the TMS320F206 and the
TMS320F240/1/3 devices. A conditional assembly variable is provided in the
header file, SVAR20.H, for assembling the algorithms for the correct device.
For more details on this conditional assembly variable, see A.1.1.

A.1.1 Header File for Constants and Variables, SVAR20.H

This header file is included in each of the algorithm files using the .include di­rective. All of the constants used for flash programming are defined in this file.
Also, the conditional assembly constant, F24x, is defined here to allow reuse
of the algorithms for multiple device types. This constant should be modified
to select the correct device when the algorithms are assembled. The
SV AR20.H header file can also be included in the calling code, to allow visibility
to the variable names.

A-2

PRELIMINARY

PRELIMINARY

Assembly Source for Algorithms

**************************************************************
** Variable declaration file **
* **
* TMS320F2XX Flash Utilities. **
* Revision: 2.0, 9/10/97 **
* Revision: 2.1, 1/31/98 **
* **
* Filename: svar20.asm **
* **
*Note: **
*DLOOP is a delay loop variable used in flash algorithms. **
*This is a function of CLKOUT1. If the F206 device runs at **
*any CLKOUT1 speed other than 20 MHz, DLOOP value should be **
*redefined per the equation explained below. Use of **
*current DLOOP for flash programming at speeds other than **
*20 MHz is not recommended. **
**************************************************************

.mmregs

BASE .set 0300h ;Base address for variables

;can be changed to relocate

;variable space in RAM.
BASE_0 .set BASE+0 ;Scratch pad registers.
BASE_1 .set BASE+1 ;
BASE_2 .set BASE+2 ;
BASE_3 .set BASE+3 ;
BASE_4 .set BASE+4 ;
BASE_5 .set BASE+5 ;
BASE_6 .set BASE+6 ;
SPAD1 .set BASE+7 ;
SPAD2 .set BASE+8 ;
FL_ADRS .set BASE+10 ;Flash load address.
FL_DATA .set BASE+11 ;Flash load data.
ERROR .set BASE+15 ;Error flag register.
*Variables for ERASE and CLEAR
RPG_CNT .set BASE+12 ;Program pulse count.
FL_ST .set BASE+13 ;Flash start addr/Seg Cntrl Reg.
FL_END .set BASE+14 ;Flash end address.
*

PRELIMINARY

Assembly Source Listings and Program Examples

A-3

Assembly Source for Algorithms

*CONSTANTS
*
*********************************************************
*Conditional assembly variable for F24X vs F206. *
*If F24X = 1, then assemble for F24X; otherwise, *
*assemble for F206. *
*********************************************************
F24X .set 0 ;Assemble for F206
;F24X .set 1 ;Assemble for F24X
***********************************************
* Delay variables for CLEAR,ERASE and PROGRAM *
***********************************************
D5 .set 0 ;5 us delay
D10 .set 1 ;10 us delay
D100 .set 19 ;100 us delay
D5K .set 999 ;5 ms delay
D7K .set 1399 ;7 ms delay
*************************************************************
*DLOOP constant proportional to CLKOUT1 *
*Calculate DLOOP in decimal using the following equation: *
* DLOOP=FLOOR{(5us/tCLKOUT1)–6}; *
*Examples *
*a. @ 15 MHz, DLOOP= 69; *
*b. @ 9.8304 MHz, DLOOP= 43; *
*c. @ 16.384 MHz, DLOOP= 75; *
**************************************************************
;DLOOP .set 14 ;5–us delay loop @ 4.032 MIPs
;DLOOP .set 19 ;5–us delay loop @ 5 MIPs
;DLOOP .set 44 ;5–us delay loop @ 10 MIPs
;DLOOP .set 75 ;5–us delay loop @ 16.384 MIPs
;DLOOP .set 94 ;5–us delay loop @ 20 MIPs
*************************
* On–chip I/O registers *
*************************
F_ACCESS0 .set 0FFE0h ;F206 ACCESS CNTRL REGISTER 0.
F_ACCESS1 .set 0FFE1h ;F206 ACCESS CNTRL REGISTER 1.
PMST .set 0FFE4h ;Defines SARAM in PM/DM and MP/MC bit.
F24X_ACCS .set 0FF0Fh ;F240 ACCESS CNTRL REGISTER.
;–––––––––––––––––––––––––––––––––––––––––––
;Register Declarations for F240 Peripherals |
;–––––––––––––––––––––––––––––––––––––––––––
;Watch–Dog(WD)/Real Time Int(RTI)/Phase–Locked Loop (PLL)
;Registers
;~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
RTI_CNTR .set 07021h ;RTI Counter reg
WD_CNTR .set 07023h ;WD Counter reg
WD_KEY .set 07025h ;WD Key reg
RTI_CNTL .set 07027h ;RTI Control reg
WD_CNTL .set 07029h ;WD Control reg
PLL_CNTL1 .set 0702Bh ;PLL control reg 1
PLL_CNTL2 .set 0702Dh ;PLL control reg 2

PRELIMINARY

A-4

PRELIMINARY

PRELIMINARY

A.1.2 Clear Algorithm, SCLR20.ASM

This code is an implementation of the clear (programming) algorithm de­scribed in section 3.2 on page 3-4. Recall that the clear algorithm is identical to
the programming algorithm with the data forced to 0000h for all flash address­es.

Memory section: fl_clr
Entry point: GCLR
Parameters to be declared and initialized by the calling code are:

 PROTECT defines the values of bits 8–15 of SEG_CTR during the clear

algorithm.

 SEG_ST defines the start address of the flash array to be cleared.
 SEG_END defines the end address of the flash array to be cleared.

Return value: ERROR (@BASE+15); 0 = Pass, 1 = Fail

Assembly Source for Algorithms

**************************************************************
** CLEAR Subroutine **
* **
* TMS320F2XX Flash Utilities. **
* Revision: 2.0, 9/10/97 **
* Revision: 2.1, 1/31/98 **
* **
* Filename: sclr20.asm **
* **
* Called by: c2xx_bcx.asm or flash application programs. **
* **
* !!CAUTION – INITIALIZE DP BEFORE CALLING THIS ROUTINE!! **
* **
* Function: Clears one or more contiguous segments of **
* array 0/1 as specified by the following **
* variables. **
* SEG_ST Segment start address **
* SEG_END Segment end address **
* PROTECT Sector protect enable **
* *
* The algorithm used is ”row-horizontal”, which means that *
* an entire flash row (32 words) is programmed in parallel.*
* This method provides better uniformity of programming *
* levels between adjacent bits than if each address were *
* programmed independently. The algorithm also uses a *
* 3-read check for VER0 margin (i.e.,the flash location is *
* read three times and the first two values are discarded.)*
* This provides low–frequency read–back margin on *

PRELIMINARY

Assembly Source Listings and Program Examples

A-5

Assembly Source for Algorithms

* programmed bits. For example, if the flash is programmed *
* using a CLKOUT period of 50 ns, the flash can be read back
* reliably over the CLKOUT period range of 50 ns to 150 ns *
* (6.67 MHz–20 MHz). The programming pulse-duration is *
* 100 us, and a maximum of 150 pulses is applied per row. *
* *
* The following resources are used for temporary storage: *
* AR0 Used for comparisons *
* AR1 Used for pgm pulse count *
* AR2 Used for row banz loop. *
* AR6 Parameter passed to Delay *
* FL_ADRS Used for flash address *
* FL_DATA Used for flash data. *
* FL_ST Used for flash start address *
* BASE_0 Used for row–done flag *
* BASE_1 Used for row start address *
* SPAD1 Flash commands *
* SPAD2 Flash commands *
* **
**************************************************************

*
MAX_PGM .set 150 ;Only allow 150 pulses per row.
VER0 .set 010h ;VER0 command.
WR_CMND .set 4 ;Write command.
WR_EXE .set 045h ;Write EXEBIN command.
STOP .set 0 ;Reset command.

*************************************************************
* GCLR: This routine performs a clear operation on the *
* flash array defined by the FL_ST variable. The segments *
* to be cleared are defined by the SEG_ST, SEG_END, and *
* PROTECT variables. *
* The following resources are used for temp storage: *
* AR0 Used for comparisons *
* AR1 Used for pgm pulse count *
* AR2 Used for row banz loop *
* FL_ADRS Used for flash address *
* FL_DATA Used for flash data *
* BASE_0 Used for row–done flag *
* BASE_1 Used for row start address *
* BASE_2 Used for byte mask. *
*************************************************************
GCLR:

PRELIMINARY

.include ”svar20.h”

.def GCLR
.ref PROTECT,SEG_ST,SEG_END
.ref DELAY,REGS,ARRAY

.sect ”fl_clr”

SETC INTM ;Disable all ints.
CLRC SXM ;Disable sign extension.
SPLK #0,ERROR ;Reset error flag
LACL SEG_ST ;Get segment start address.
SACL FL_ADRS ;Save as current address.
AND #04000h ;Get array start address.

A-6

PRELIMINARY

PRELIMINARY

Assembly Source for Algorithms

SACL FL_ST ;Save array start address.
LACL FL_ADRS ;Get segment start address.

NEWROW ;********Begin a new row.*

SACL BASE_1 ;Save row start address.
LAR AR1,#0 ;Init pulse count to zero.

SAMEROW ;********Same row, next pulse.*

SPLK #1,BASE_0 ;Set row done flag = 1(True).
LACL BASE_1 ;Get row start address.
SACL FL_ADRS ;Save as current address.

LAR AR2,#31 ;Init row index.
********Repeat the following code 32 times until end of row.*
LOBYTE ;********First, do low byte.*

SPLK #0FFh,BASE_2 ;Get lo–byte mask.

CALL PRG_BYTE ;Check/Program lo–byte

SPLK #0FF00h,BASE_2 ;Get hi–byte mask.

CALL PRG_BYTE ;Check/Program hi–byte.
NEXTWORD ;********Next word in row.

LACL FL_ADRS ;Load address for next word.

ADD #1 ;Increment address.

SACL FL_ADRS ;Save as current address.

MAR *,AR2 ;Point to row index.

BANZ LOBYTE ;Do next word,and dec AR2.
********Reached end of row. Check if row done.*

BIT BASE_0,15 ;Get row_done flag.

BCND ROW_DONE,TC ;If 1, then row is done.

MAR *,AR1 ;Else, row is not done, so

MAR *+ ;inc row pulse count.

LAR AR0,#MAX_PGM ;Check if passed allowable max.

CMPR 2 ;If AR1>MAX_PGM, then

BCND EXIT,TC ;fail, don’t continue.

B SAMEROW ;else, go to beginning

;of same row.
********If row done, then check if Array done.*
ROW_DONE ;Check if end of array.

SUB SEG_END ;Subtract segment end address.
BCND DONE,GEQ ;If >0, then done.

********Else, go to next row.*

LACL FL_ADRS ;Get current address.

B NEWROW ;Start new row.
********If here, then done.
DONE CALL ARRAY ;Access flash in array mode.

RET
********If here, then unit failed to program.*
EXIT SPLK #1,ERROR ;Update error flag.

B DONE ;Get outa here.

.page
*************************************************************
* THIS SECTION PROGRAMS THE VALUE STORED IN FL_DATA INTO *
* THE FLASH ADDRESS DEFINED BY FL_ADRS. *
* *
* The following resources are used for temporary storage: *
* AR6 Parameter passed to Delay. *
* SPAD1 Flash program and STOP commands. *

PRELIMINARY

Assembly Source Listings and Program Examples

A-7

Assembly Source for Algorithms

* SPAD2 Flash program + EXE command. *
*************************************************************
EXE_PGM ;*

*LOAD WADRS AND WDATA **

*SET UP WRITE COMMAND WORDS **

* *

* ACTIVATE WRITE BIT **

* SET EXEBIN BIT **

* STOP WRITE OPERATION *

* *

************************************************************

************************************************************
* ACTIVATE VER0 ON FLASH READS *
* LOADS FLASH WORD AT ADDR FL_ADRS TO FL_DATA. *
* Uses SPAD1 for temporary storage of flash commands. *
************************************************************
SET_RD_VER0 ;*

PRELIMINARY

CALL ARRAY ;ACCESS ARRAY *

LACL FL_ADRS ;ACC => PROGRAM ADRS *
TBLW FL_DATA ;LOAD WADRS AND WDATA *

CALL REGS ;ACCESS FLASH REGS *

LACL PROTECT ;GET SEGMENT PROTECT MASK **
OR #WR_CMND ;OR IN WRITE COMMAND **
SACL SPAD1 ;SPAD1 = WRITE COMMAND **
OR #WR_EXE ;OR IN EXEBIN COMMAND **
SACL SPAD2 ;SPAD2 = WRITE EXE COMMAND **

LACL FL_ST ;ACC => 0 (FLASH0) *

TBLW SPAD1 ;EXECUTE COMMAND **
LAR AR6,#D10 ;SET DELAY **

CALL DELAY,*,AR6 ;WAIT **

TBLW SPAD2 ;EXECUTE COMMAND **
LAR AR6,#D100 ;SET DELAY **

CALL DELAY,*,AR6 ;WAIT **

SPLK #0,SPAD1 ;SHUTDOWN WRITE OPERATION *
TBLW SPAD1 ;EXECUTE COMMAND *
LAR AR6,#D10 ;SET DELAY *

CALL DELAY,*,AR6 ;WAIT *

RET ;RETURN TO CALLING SEQUENCE*

.page

CALL REGS ;ACCESS FLASH REGISTERS*
LACL FL_ST ;ACC => FLASH *
SPLK #VER0,SPAD1 ;ACTIVATE VER0 *
TBLW SPAD1 ;EXECUTE COMMAND*
LAR AR6,#D10 ;SET DELAY *
CALL DELAY,*,AR6 ;WAIT *
CALL ARRAY ;ACCESS FLASH ARRAY *
LACL FL_ADRS ;POINT TO ADRS *
TBLR FL_DATA ;GET FLASH WORD 1x read *
TBLR FL_DATA ;2x read *
TBLR FL_DATA ;3x read *
CALL REGS ;ACCESS FLASH REGISTERS *
LACL FL_ST ;ACC => FLASH *
SPLK #STOP,SPAD1 ;DEACTIVATE VER0 *

A-8

PRELIMINARY

PRELIMINARY

Assembly Source for Algorithms

TBLW SPAD1 ;EXECUTE COMMAND *
LAR AR6,#D10 ;SET DELAY *
CALL DELAY,*,AR6 ;WAIT *
CALL ARRAY ;ACCESS FLASH ARRAY *

RET ;RETURN TO CALLING SEQUENCE*
*************************************************************
*************************************************
* PRG_BYTE: Programs hi or lo byte depending on *
* byte mask (BASE_2). *
*************************************************
PRG_BYTE:

CALL SET_RD_VER0 ;Read word at VER0 level.

LACL BASE_2 ;Get lo/hi byte mask.

AND FL_DATA ;Xor with read–back value.

BCND PB_DONE,EQ ;If zero, then done.

XOR #0FFFFh ;else, mask off good bits.

SACL FL_DATA ;New data.

CALL EXE_PGM ;PGM Pulse.

SPLK #0,BASE_0 ;Set row done flag = 0(False).
PB_DONE RET
************************************************

.end

PRELIMINARY

Assembly Source Listings and Program Examples

A-9

Assembly Source for Algorithms

A.1.3 Erase Algorithm, SERA20.ASM

This code is an implementation of the erase algorithm described in section 3.3
on page 3-10.

Memory section: fl_ers

Entry point: GERS

Parameters to be declared and initialized by the calling code are:

 PROTECT defines the values of bits 8–15 of SEG_CTR during the erase

algorithm.

 SEG_ST defines the start address of the flash array to be erased.
 SEG_END defines the end address of the flash array to be erased.

Return value: ERROR (@BASE+15); 0 = Pass, 1 = Fail

**************************************************************
* ERASE subroutine **
* **
* TMS320F2XX Flash Utilities. **
* Revision: 2.0, 9/10/97 **
* Revision: 2.1, 1/31/98 **
* **
* Filename: sera20.asm **
* **
* Called by: c2xx_bex.asm or flash application programs. **
* **
* !!CAUTION – INITIALIZE DP BEFORE CALLING THIS ROUTINE!! **
* **
* Function: Erases one or more contiguous segments of **
* flash array 0/1 as specified by the **
* following variables. **
* SEG_ST Segment start address **
* SEG_END Segment end address **
* PROTECT Sector protect enable **
* **
* The algorithm used is XOR–VER1, which means that in **
* addition to the VER1 read mode, an XOR readback is used **
* to gain more margin. During the read portion of the **
* erase, two reads are performed for each address; for the **
* first read, all address bits are complemented using a **
* logical XOR with the array end address. The data read **
* during the first read is discarded, and the second read **
* is performed on the actual address. This scheme **
* simulates the worst–case branching condition for code **
* executing from the flash array. **

PRELIMINARY

A-10

PRELIMINARY

PRELIMINARY

Assembly Source for Algorithms

* The erase pulse duration is 7ms, and a maximum of **
* 1000 pulses is applied to the array. **
* **
* The following resources are used for temporary storage: **
* AR0 Used for comparisons **
* AR1 Used for erase pulse count **
* AR2 Used for main banz loop **
* AR6 Parameter passed to DELAY **
* BASE_0 Parameter passed to Set_mode **
* BASE_1 Used for flash address. **
* BASE_2 Used for flash data **
* BASE_3 Used for flash checksum **
* BASE_4 Used for segment size **
* BASE_5 Flash Erase command **
* BASE_6 Flash Erase+EXE command **
*************************************************************

.include ”svar20.h” ;defines variables for flash0

;or for flash1 array
*
MAX_ER .set 1000 ;Allow only 1000 erase pulses.
VER1 .set 8 ;VER1 command.
ER_CMND .set 2 ;ERASE COMMAND WORD
ER_EXE .set 043h ;ERASE EXEBIN COMMAND WORD
INV_ER .set 018h ;INVERSE ERASE COMMAND WORD
FL_WR .set 6 ;FLASH WRITE COMMAND WORD
FLWR_EX .set 047h ;FLASH WRITE EXEBIN COMMAND WORD
STOP .set 0 ;RESET REGISTER COMMAND WORD

.def GERS
.ref PROTECT,SEG_ST,SEG_END
.ref DELAY,REGS,ARRAY

.sect ”fl_ers”
*************************************************************
* GERS: This routine performs an erase to *
* xorver1 level. The Seg to erase is defined by *
* the vars SEG_ST and SEG_END. The following *
* resources are used for temporary storage: *
* AR0 Used for comparisons *
* AR1 Used for erase pulse count *
* AR2 Used for main banz loop *
* BASE_0 Parameter passed to Set_mode *
* BASE_1 Used for flash address. *
* BASE_2 Used for flash data *
* BASE_3 Used for flash checksum *
* BASE_4 Used for segment size *
*************************************************************
GERS:
*************************************************************
* Code initialization section *
* Initialize test loop counters: *
* AR1 is the number of ERASE pulses. *
*************************************************************

SETC INTM ;Disable all maskable ints.
SETC SXM ;Enable sign extension.

PRELIMINARY

Assembly Source Listings and Program Examples

A-1 1

Assembly Source for Algorithms

XOR_ERASE
** Compute checksum for flash, using address complementing.**

RD1_LOOP ;For I = SEG_ST to SEG_END.

PRELIMINARY

CLRC OVM ;Disable overflow mode.
LACL SEG_ST ;Get segment start address.
AND #04000h ;Get array start address.
SACL FL_ST ;Save array start address.
OR #03FFFh ;Get array end address.
SACL FL_END ;Save array end address.
SPLK #0,ERROR ;Reset error flag
LAR AR1,#0 ;Set erase count to 0.
SPLK #STOP, BASE_0 ;Stop command.
CALL SET_MODE ;Disable any flash cmds.

LACC SEG_END
SUB SEG_ST
SAC BASE_4 ;Segment length–1.
LAR AR2,BASE_4 ;load n–1 to loop n times.
ADD #1
SACL BASE_4 ;Segment length.
SPLK #VER1,BASE_0 ;VER1 command.
CALL SET_MODE ;Set VER1 mode.
MAR *,AR2
BLDD #SEG_ST,BASE_1 ;Segment start address.
SPLK #0,BASE_3 ;Clear checksum.

LACC BASE_1 ;ACC => CURRENT ADDR.
XOR FL_END ;XOR addr with flash end addr.
TBLR BASE_2 ;Dummy Read.
LACC BASE_1 ;Get actual addr again.
TBLR BASE_2 ;True Read.
ADD #1 ;Increment flash addr.
SACL BASE_1 ;Store for next read.
LACC BASE_3 ;Get old check sum.
ADD BASE_2 ;ACC=>ACC+FL_DATA.
SACL BASE_3 ;Save new check sum.
BANZ RD1_LOOP,*–
ADD BASE_4 ;Should make ACC = 0 for

;erased array.

BCND XOR_ERFIN,EQ ;If BASE_3 = 0, finished.

A-12

***** If not erased, apply an erase pulse.

CALL ERASE_A ;Else, pulse it again.
MAR *,AR1 ;ARP–>AR1 (Erase pulse count)
MAR *+ ;Increment Erase count.
LAR AR0,#MAX_ER
CMPR2 ;If AR1>MAX_ER then
BCND EXIT,TC ;fail, don’t continue erasing.

B XOR_ERASE ;Else, check again.
***** If here, then erase passed; now check for depletion.
XOR_ERFIN

SPLK #STOP, BASE_0 ;Stop command.

CALL SET_MODE ;Disable any flash cmds.

CALL INV_ERASE ;Check for depletion.
DONE RET ;Return to calling code.

PRELIMINARY

PRELIMINARY

Assembly Source for Algorithms

***** If here, then an error has occurred.
EXIT SPLK #1,ERROR ;Update error flag

SPLK #STOP,BASE_0 ;Stop command.
CALL SET_MODE ;Disable any flash cmds.
B DONE ;Get outa here.

************************************************************

.page
**************************************************
* SET_MODE: This routine sets the flash in the *
* mode specified by the contents of BASE_0. This *
* can be used for VER0,VER1,INVERASE, or STOP. *
* AR6: Parameter passed to DELAY. *
**************************************************
SET_MODE

CALL REGS ;ACCESS FLASH REGS

LACL FL_ST ;ACC => SEG_CTR.

TBLW BASE_0 ;Activate MODE.

LAR AR6,#D10 ;SET DELAY

CALL DELAY,*,AR6 ;WAIT *

CALL ARRAY ;ACCESS FLASH ARRAY *

RET
************************************************
* INV_ERASE: This routine is used to check for *
* depletion in the flash array. *
* AR2 Used for main banz loop *
* BASE_0 Parameter passed to Set_mode *
* BASE_1 Used for flash address *
* BASE_2 Used for flash data *
************************************************
INV_ERASE

SPLK #INV_ER,BASE_0

CALL SET_MODE ;Set inverse–erase mode.

BLDD #FL_ST,BASE_1 ;Array start address.

LAR AR2,#31 ;Loop count.

MAR *,AR2
NEXT_IVERS

LACL BASE_1 ;Get address.

TBLR BASE_2 ;Dummy read.

TBLR BASE_2 ;Read data.

ADD #1 ;Increment address.

SACL BASE_1 ;Save address.

ZAC

ADD BASE_2 ;Add data.

BCND EXIT,NEQ ;If ACC<>0, then fail.
*Else continue, until until done with row.

BANZ NEXT_IVERS ;Loop 32 times.

SPLK #STOP,BASE_0 ;Stop command.

CALL SET_MODE ;Disable any flash cmds.

RET ;If here then test passed.

.page
*************************************************************
* ERASE_A: This subroutine applies one erase pulse to the *
* flash array. *

PRELIMINARY

Assembly Source Listings and Program Examples

A-13

Assembly Source for Algorithms

* *
* The following resources are used for temporary storage: *
* BASE_0 Flash STOP command, and FFFF for WDATA. *
* BASE_5 Flash erase command. *
* BASE_6 Flash erase + EXE command. *
*************************************************************
ERASE_A
* SET UP FLASH ERASE COMMANDS FOR PROTECT MASK. **

* **
* MUST LOAD WDATA WITH FFFF. **

* **
* THIS SECTION ACTIVATES THE WRITE COMMAND. **

* **
* THIS SECTION ACTIVATES THE EXEBIN COMMAND. **

**************************************************************

PRELIMINARY

LACL PROTECT ;GET SEGMENT PROTECT MASK **
OR #ER_CMND ;OR IN ERASE COMMAND **
SACL BASE_5 ;BASE_5 = ERASE COMMAND **
OR #ER_EXE ;OR IN EXEBIN COMMAND **
SACL BASE_6 ;BASE_6 = ERASE EXE COMMAND **

SPLK #0FFFFh,BASE_0 ;WDATA VALUE FOR ERASE **
LACC FL_ST ;ACC => FLASH **
TBLW BASE_0 ;SET WDATA = FFFF **

SPLK #STOP,BASE_0 ;Stop command. **
CALL SET_MODE ;Disable any flash cmds. **

CALL REGS ;ACCESS FLASH REGS **

LACC FL_ST ;ACC => FLASH **
TBLW BASE_5 ;ACTIVATE ERASE **
LAR AR6,#D10 ;SET DELAY **

CALL DELAY,*,AR6 ;WAIT **

TBLW BASE_6 ;START ERASURE **
LAR AR6,#D7K ;SET DELAY to 7 ms **

CALL DELAY,*,AR6 ;WAIT **

SPLK #STOP,BASE_0 ;STOP COMMAND **
CALL SET_MODE ;STOP ERASE **
RET ;RETURN TO CALLING CODE **

.end

A-14

PRELIMINARY

PRELIMINARY

A.1.4 Flash-Write Algorithm, SFLW20.ASM

This code is an implementation of the flash-write algorithm described in sec­tion 3.4 on page 3-14.

Memory section: fl_wrt

Entry point: FLWS

Parameters to be declared and initialized by the calling code are:

 PROTECT defines the values of bits 8–15 of SEG_CTR during the flash-

write algorithm.

 SEG_ST defines the start address of the flash array to be recovered.
 SEG_END defines the end address of the flash array to be recovered.

Return value: ERROR (@BASE+15) 0=Pass, 1=Fail

**************************************************************
** FLASH–WRITE subroutine **
* **
* TMS320F2XX Flash Utilities. **
* Revision: 2.0, 9/10/97 **
* Revision: 2.1, 1/31/98 **
* **
* Filename: sflw20.asm **
* **
* Called by : c2xx_bfx.asm or flash application programs. **
* **
* !!CAUTION – INITIALIZE DP BEFORE CALLING THIS ROUTINE!! **
* **
* Function: Performs flash writes on flash array 0/1 as **
* specified by the following vars: **
* SEG_ST Array segment start address **
* PROTECT Sector protect enable **
* *
* The flash–write pulse duration used is 14 ms, and a *
* maximum of 10000 pulses is applied until the device *
* passes the depletion test. *
* *
* The following resources are used for temp storage: *
* AR0 Used for comparison *
* AR1 Flash–Write Pulse Count *
* AR2 Used for main BANZ loop *
* AR6 Parameter passed to DELAY *
* BASE_0 Parameter passed to SET_MODE *
* BASE_1 Used for flash address *
* BASE_2 Used for flash data *

Assembly Source for Algorithms

PRELIMINARY

Assembly Source Listings and Program Examples

A-15

Assembly Source for Algorithms

* BASE_3 Used for EXE + flw cmd *
**************************************************************

*
MAX_FLW .set 10000 ;Allow only 10000 flw pulses.
INV_ER .set 018h ;INVERSE ERASE COMMAND WORD
FLWR .set 6 ;FLASH WRITE COMMAND WORD
FLWR_EX .set 047h ;FLASH WRITE EXEBIN COMMAND WORD
STOP .set 0 ;RESET REGISTER COMMAND WORD

******************************************************
* FLWS: This routine is used to check for bits *
* in depletion mode. If any are found, flash– *
* write is used to recover. *
* AR1 Flash–write pulse count. *
* AR2 Used for main banz loop. *
* BASE_0 Parameter passed to Set_mode. *
* BASE_1 Used for flash address. *
* BASE_2 Used for flash data. *
******************************************************
FLWS:
******************************************************
* Code initialization section *
* Initialize test loop counters: *
* AR1 is the number of flash–write pulses. *
******************************************************

INV_ERASE

NEXT_IVERS

PRELIMINARY

.include ”svar20.h” ;defines variables for flash0

;or for flash1 array

.def FLWS
.ref PROTECT,SEG_ST,SEG_END
.ref DELAY,REGS,ARRAY

.sect ”fl_wrt”

SETC INTM ;Disable maskable ints.
LACL SEG_ST ;Get segment start address.
AND #04000h ;Get array start address.
SACL FL_ST ;Save array start address.
SPLK #0,ERROR ;Reset error flag.
LAR AR1,#0 ;Set FLW count to 0.
SPLK #STOP,BASE_0 ;Flash STOP command.
CALL SET_MODE ;Disable any flash commands.

SPLK #INV_ER,BASE_0
CALL SET_MODE ;Set inverse–erase mode.
BLDD #FL_ST,BASE_1 ;Array start address.
LAR AR2,#31 ;Loop count.
MAR *,AR2

LACL BASE_1 ;Get address.
TBLR BASE_2 ;Dummy read.
TBLR BASE_2 ;Dummy read.
TBLR BASE_2 ;Read data.
ADD #1 ;Increment address.
SACL BASE_1 ;Save address.
ZAC
ADD BASE_2 ;Add data.

A-16

PRELIMINARY

PRELIMINARY

Assembly Source for Algorithms

BCND FL_WRITE, NEQ ;If ACC<>0, then flwrite.
*Else, continue until until done with row.

BANZ NEXT_IVERS ;Loop 32 times.

SPLK #STOP,BASE_0 ;Flash STOP command.

CALL SET_MODE ;Disable flash commands.

;If here then test passed.
DONE RET ;Return to calling code.
* If here, then an error has occurred.
EXIT SPLK #1,ERROR ;Update error flag

SPLK #STOP,BASE_0 ;Flash STOP command.
CALL SET_MODE ;Disable flash commands.
CALL ARRAY ;ACCESS FLASH ARRAY
B DONE ;Get outa here.

.page
***************************************************
* FL_WRITE: This routine performs a fl_write on *
* the flash until a maximum is reached. The *
* array is defined by the variable FL_ST *
* and the segment(s) is defined by the PROTECT *
* mask. The following resources are used for *
* temporary storage: *
* AR0 Used for comparison *
* AR1 Used for pulse count (Global) *
* AR6 Parameter passed to DELAY *
* BASE_0 Parameter passed to SET_MODE *
* BASE_2 Used for flw cmd *
* BASE_3 Used for EXE + flw cmd *
***************************************************
FL_WRITE

SPLK #STOP,BASE_0 ;Flash STOP command.

CALL SET_MODE ;Disable flash commands.

LACL PROTECT ;Get sector_prot mask.

OR #FLWR ;Or in fl_write cmd.

SACL BASE_2 ;BASE_2 = fl_write cmd.

OR #FLWR_EX ;Or in EXE + fl_write cmd.

SACL BASE_3 ;BASE_3 = EXE + fl_write cmd.
*Set the flash–write command.

CALL REGS ;Access flash regs.

LACC FL_ST ;ACC => SEG_CTL.

TBLW BASE_2 ;Initiate fl_write.

LAR AR6,#D10 ;Set delay.

CALL DELAY,*,AR6 ;Wait,10US flw stabilization time.
*Set the EXE bit (start flash–write pulse).

TBLW BASE_3 ;Start flw pulse.

LAR AR6,#D7K ;Set delay to 7 ms.

CALL DELAY,*,AR6 ;WAIT,7 ms.

LAR AR6,#D7K ;Set delay to 7 ms.

CALL DELAY,*,AR6 ;WAIT 7 ms.
*A 14–mS flash write pulse has been applied.

SPLK #STOP,BASE_0 ;Flash STOP command.

CALL SET_MODE ;Disable flash commands.

MAR *,AR1

MAR *+ ;Increment flw count.

PRELIMINARY

Assembly Source Listings and Program Examples

A-17

Assembly Source for Algorithms

**************************************************
* SET_MODE: This routine sets the flash in the *
* mode specified by the contents of BASE_0. This *
* can be used for VER0,VER1,INVERASE,or STOP. *
**************************************************
SET_MODE

*************************************************

PRELIMINARY

LAR AR0,#MAX_FLW
CMPR 2 ;If AR1>MAX_FLW then
BCND EXIT,TC ;Fail, don’t continue recovery.
B INV_ERASE ;Else, perform iverase again.

CALL REGS ;ACCESS FLASH REGS
LACL FL_ST ;ACC => SEG_CTR.
TBLW BASE_0 ;Activate MODE.
LAR AR6,#D10 ;SET DELAY
CALL DELAY,*,AR6 ;WAIT
CALL ARRAY ;ACCESS FLASH ARRAY

RET

.end

A-18

PRELIMINARY

PRELIMINARY

A.1.5 Programming Algorithm, SPGM20.ASM

This code is an implementation of the program algorithm described in section

3.2 on page 3-4.
Memory section: fl_prg
Entry point: GPGMJ
Parameters to be declared and initialized by the calling code are:

 PRG_bufaddr defines the destination start address.
 PRG_length defines the source buffer length.
 PRG_paddr defines the source buffer start address (data space).
 PROTECT defines the values of bits 8–15 of SEG_CTR during the pro-

gramming algorithm.

Return value: ERROR (@BASE+15); 0 = Pass, 1 = Fail

Assembly Source for Algorithms

**************************************************************
** PROGRAM Subroutine **
* **
* TMS320F2XX Flash Utilities. **
* Revision: 2.0, 9/10/97 **
* Revision: 2.0b, 12/5/97 **
* Revision: 2.1, 1/31/98 **
* **
* Filename: spgm20.asm **
* **
* Called by: c2xx_bpx.asm or flash application programs. **
* **
* !!CAUTION – INITIALIZE DP BEFORE CALLING THIS ROUTINE!! **
* **
* Function: This routine programs all or part of the **
* flash as specified by the variables: **
* PRG_paddr Destination start address *
* PRG_length Source buffer length *
* PRG_bufaddr Source buffer start address *
* *
* The algorithm used is ”row–horizontal”, which means that *
* an entire flash row (32 words) is programmed in parallel.*
* This method provides better uniformity of programming *
* levels between adjacent bits than if each address were *
* programmed independently. The algorithm also uses a *
* 3–read check for VER0 margin (i.e., the flash location is*
* read three times and the first two values are discarded.)*
* This provides low–freq read–back margin on programmed *

PRELIMINARY

Assembly Source Listings and Program Examples

A-19

Assembly Source for Algorithms

* bits. For example, if the flash is programmed using a *
* CLKOUT period of 50 ns, the flash can be reliably read *
* back over the CLKOUT period range of 50 ns to 150 ns *
* (6.67MHz–20 MHz). The programming pulse duration is *
* 100 us, and a maximum of 150 pulses is applied per row. *
* *
* The following variables are used for temp storage: *
* AR0 Used for comparisons *
* AR1 Used for pgm pulse count *
* AR2 Used for row banz loop *
* AR3 Used for buffer addr index *
* AR4 Used for flash address. *
* AR6 Parameter passed to Delay *
* SPAD1 Flash program and STOP commands *
* SPAD2 Flash program + EXE command *
* FL_ADRS Used for flash address *
* FL_DATA Used for flash data *
* BASE_0 Used for row–done flag *
* BASE_1 Used for row start address *
* BASE_2 Used for row length–1 *
* BASE_3 Used for buffer/row start addr *
* BASE_4 Used for destination end addr *
* BASE_5 Used for byte mask *
*************************************************************

*
MAX_PGM .set 150 ;Allow only 150 pulses per row.
VER0 .set 010h ;VER0 command.
WR_CMND .set 4 ;Write command.
WR_EXE .set 045h ;Write EXEBIN command.
STOP .set 0 ;Reset command.

*********************************************************
* GPGMJ: This routine programs all or part of *
* the flash as specified by the variables: *
* PRG_paddr Destination start address *
* PRG_length Source buffer length *
* PRG_bufaddr Buffer start address *
**
* The following variables are used for temp *
* storage: *
* AR0 Used for comparisons *
* AR1 Used for pgm pulse count *
* AR2 Used for row banz loop *
* AR3 Used for buffer addr index *
* FL_ADRS Used for flash address *
* FL_DATA Used for flash data *
* BASE_0 Used for row–done flag *
* BASE_1 Used for row start address *
* BASE_2 Used for row length–1 *

PRELIMINARY

.include ”svar20.h”

.def GPGMJ
.ref PRG_bufaddr,PRG_length,PRG_paddr
.ref PROTECT,DELAY,REGS,ARRAY
.sect ”fl_prg”

A-20

PRELIMINARY

PRELIMINARY

Assembly Source for Algorithms

* BASE_3 Used for buffer/row start addr *
* BASE_4 Used for destination end addr *
* BASE_5 Used for byte mask *
******************************************************
GPGMJ: SPLK #0,IMR ;MASK ALL INTERRUPTS

SETC INTM ;GLOBALLY MASK ALL INTERRUPTS

SPLK #0,ERROR ;Initialize error flag (no error).

LACL PRG_paddr ;Get destination start address.

SACL FL_ADRS ;Save as current address.

ADD PRG_length ;Determine destination end addr.

SUB #1 ;

SACL BASE_4 ;Save destination end addr.

LACL PRG_paddr ;Get destination start addr.

LAR AR3,PRG_bufaddr ;Get buffer start address.
********Begin a new row.*
NEWROW

SACL BASE_1 ;Save row start address.

SAR AR3,BASE_3 ;Save buffer/row start address.

LAR AR1,#0 ;Init pulse count to zero.

SPLK #31,BASE_2 ;Init row length–1 to 31.

AND #001Fh ;Is start addr on row boundary?

CC ADJ_ROW,NEQ ;If not then adjust row length.

LACL BASE_1 ;Get row start address.

OR #001Fh ;Get row end address.

SUB BASE_4 ;Is end address on row boundary?

CC ADJ_ROW,GT ;If not then adjust row length.
********Same row, next pulse.*
SAMEROW SPLK #1,BASE_0 ;Set row done flag = 1(True).

LACL BASE_1 ;Get row start address.
SACL FL_ADRS ;Save as current address.
LAR AR3,BASE_3 ;Get buffer/row start addr.

LAR AR2,BASE_2 ;Init row index.
** Repeat the following code 32 times or until end of row.*
LOBYTE ;********First, do low byte.*

CALL SET_MODULE,AR4 ;Determine which flash module.

SPLK #0FFh,BASE_5 ;Set lo–byte mask.
CALL PRG_BYTE ;Check/Program lo–byte.
SPLK #0FF00h,BASE_5 ;Set hi–byte mask.

CALL PRG_BYTE ;Check/Program hi–byte.

NEXTWORD ;********Next word in row.

LACL FL_ADRS ;Load address for next word.
ADD #1 ;Increment address.
SACL FL_ADRS ;Save as current address.
MAR *,AR3 ;ARP –> buffer addr index.
MAR *+,AR2 ;Inc, and ARP –> row index.
BANZ LOBYTE ;Do next word,and dec AR2.

** Reached end of row. Check if row done. *

BIT BASE_0,15 ;Get row_done flag.
BCND ROW_DONE,TC ;If 1 then row is done.
MAR *,AR1 ;Else, row is not done, so
MAR *+ ;inc row pulse count.
LAR AR0,#MAX_PGM ;Check if passed allowable max.
CMPR 2 ;If AR1>MAX_PGM then

PRELIMINARY

Assembly Source Listings and Program Examples

A-21

Assembly Source for Algorithms

** If row done, then check if Array done. *
ROW_DONE

** Else, go to next row. *

** If here, then done.
DONE

** If here, then unit failed to program. *
EXIT SPLK #1,ERROR ;Update error flag (error).

************************************************

************************************************
* ADJ_ROW: This routine is used to adjust the *
* row length, if the start or end address of *
* code being programmed does not fall on a row *
* boundary. The row length is passed in the *
* BASE_2 variable, and the adjustment value to *
* be subtracted is passed in the accumulator. *
***********************************************
ADJ_ROW

*************************************************
* SET_MODULE: This routine is used to point to *
* the appropriate flash array control register *
* This is only important for ’F2XX devices with *
* multiple flash modules like the 320F206. The *
* variable FL_ST is returned with the correct *
* register address. *
* The following resources are used *
* temporarily: *
* AR0 Used for comparisons *
* AR4 Used for flash address *
***************************************************
SET_MODULE

* ;Else address is in FL1.

PRELIMINARY

BCND EXIT,TC ;fail, don’t continue.
B SAMEROW ;else, go to beginning

;of same row.

LACL FL_ADRS ;Check if end of array.
SUB BASE_4 ;Subtract end addr.
BCND DONE, GT ;If >0 then done.

LACL FL_ADRS
B NEWROW ;Start new row.

CALL ARRAY ;Access flash in array mode.
RET ;Return to calling program.

B DONE ;Get outa here.

.page

NEG ;Take twos complement.
ADD BASE_2 ;Add row length.
SACL BASE_2 ;Save new row length.
RET

LAR AR4,FL_ADRS ;AR4 = current address.
SPLK #0,FL_ST ;FL_ST = FLASH0 CTRL REGS
LAR AR0,#4000H ;AR0 = compare value.
CMPR 1 ;If AR4 < AR0 then

;FL_ADRS < 4000H; SET TC

BCND FL0,TC ;Address is in FL0.

A-22

PRELIMINARY

PRELIMINARY

Assembly Source for Algorithms

SPLK #04000h,FL_ST ;FL_ST = FLASH1 CTRL REGS
FL0 RET
*************************************************************

.page
*************************************************************
* THIS SECTION PROGRAMS THE VALUE STORED IN FL_DATA INTO *
* THE FLASH ADDRESS DEFINED BY FL_ADRS. *
* *
* The following resources are used for temporary storage: *
* AR6 Parameter passed to Delay *
* SPAD1 Flash program and STOP commands *
* SPAD2 Flash program + EXE command. *
**************************************************************
EXE_PGM ; *
* *

CALL ARRAY ;ACCESS ARRAY *
* LOAD WADRS AND WDATA **

LACL FL_ADRS ;ACC => PROGRAM ADRS *
TBLW FL_DATA ;LOAD WADRS AND WDATA *

CALL REGS ;ACCESS FLASH REGS *
* SET UP WRITE COMMAND WORDS **

LACL PROTECT ;GET SEGMENT PROTECT MASK **
OR #WR_CMND ;OR IN WRITE COMMAND **
SACL SPAD1 ;SPAD1 = WRITE COMMAND **
OR #WR_EXE ;OR IN EXEBIN COMMAND **
SACL SPAD2 ;SPAD2 = WRITE EXE COMMAND **

LACL FL_ST ;ACC => (FLASH) *
* *
* ACTIVATE WRITE BIT **

TBLW SPAD1 ;EXECUTE COMMAND **

LAR AR6,#D10 ;SET DELAY **

CALL DELAY,*,AR6 ;WAIT **

* SET EXEBIN BIT **

TBLW SPAD2 ;EXECUTE COMMAND **

LAR AR6,#D100 ;SET DELAY **

CALL DELAY,*,AR6 ;WAIT **

* STOP WRITE OPERATION *

SPLK #0,SPAD1 ;SHUT DOWN WRITE OPERATION *

TBLW SPAD1 ;EXECUTE COMMAND *

TBLW SPAD1 ;EXECUTE COMMAND *

LAR AR6,#D10 ;SET DELAY *

CALL DELAY,*,AR6 ;WAIT *

* *

RET ;RETURN TO CALLING SEQUENCE *

*************************************************************

.page
*************************************************************
* ACTIVATE VER0 ON FLASH READS *
* LOADS FLASH WORD AT ADDR FL_ADRS TO FL_DATA. *
* Uses SPAD1 for temporary storage of flash commands. *
*************************************************************
SET_RD_VER0 ; *

CALL REGS ;ACCESS FLASH REGISTERS *

PRELIMINARY

Assembly Source Listings and Program Examples

A-23

Assembly Source for Algorithms

*************************************************************

*************************************************
* PRG_BYTE: Programs hi or lo byte depending on*
* byte mask (BASE_5). *
*************************************************
PRG_BYTE:

PB_END RET
**************************************************************

PRELIMINARY

LACL FL_ST ;ACC => FLASH *
SPLK #VER0,SPAD1 ;ACTIVATE VER0 *
TBLW SPAD1 ;EXECUTE COMMAND *

LAR AR6,#D10 ;SET DELAY *
CALL DELAY,*,AR6 ;WAIT *
CALL ARRAY ;ACCESS FLASH ARRAY *

LACL FL_ADRS ;POINT TO ADRS *

TBLR FL_DATA ;GET FLASH WORD 1x read *

TBLR FL_DATA ; 2x read *

TBLR FL_DATA ; 3x read *
CALL REGS ;ACCESS FLASH REGISTERS *

LACL FL_ST ;ACC => FLASH *

SPLK #STOP,SPAD1 ;DEACTIVATE VER0 *

TBLW SPAD1 ;EXECUTE COMMAND *

LAR AR6,#D10 ;SET DELAY *
CALL DELAY,*,AR6 ;WAIT *
CALL ARRAY ;ACCESS FLASH ARRAY *

RET ;RETURN TO CALLING SEQUENCE *

.page

CALL SET_RD_VER0 ;Read word at VER0 level.

MAR *,AR3 ;ARP –> buffer addr index.

LACL * ;Get word to program.

XOR FL_DATA ;Xor with read–back value.

AND BASE_5 ;Mask off hi/lo byte.

BCND PB_END,EQ ;If zero then done.

XOR #0FFFFh ;else, mask off good bits.

SACL FL_DATA ;New data.

CALL EXE_PGM ;PGM Pulse.

SPLK #0,BASE_0 ;Set row done flag = 0(False).

.end

A-24

PRELIMINARY

PRELIMINARY

Assembly Source for Algorithms

A.1.6 Subroutines Used By All Four Algorithms, SUTILS20.ASM

This assembly file includes two subroutines that change the flash module ac­cess mode and one subroutine that performs software delays. More details on
the individual functions are given in the comments.

**************************************************************
** Delay And Access Mode Subroutines **
* **
* TMS320F2XX Flash Utilities. **
* Revision: 2.0, 9/10/97 **
* Revision: 2.1, 1/31/98 **
* **
* Filename: sutils20.asm **
* **
* Called by: These utilities are used by CLEAR,ERASE, **
* PROGRAM algorithms written for F2xx **
* devices. **
* Function: DELAY Delay loop specified by AR6. **
* REGS Clears MODE bit of F_ACCESS0/1 to **
* access flash module control registers. **
* ARRAY Sets MODE bit of F_ACCESS0/1 to access **
* the flash array. **
**************************************************************

.include ”svar20.h”
.def DELAY,REGS,ARRAY

.sect ”DLY”
*************************************
*Delays as follows: *
* LAR AR6,#N 2 Cycles *
* CALL DELAY 4 Cycles *
* RPT #DLOOP 2*(N+1) Cycles *
* NOP DLOOP*(N+1) Cycles *
* BANZ DLY_LP 4*N+2 Cycles *
* RET 4 Cycles *
* –––––––––––––––––––––––– *
* = DLOOP(N+1)+6*N+14 Cycles *
* Set N and DLOOP appropriately to *
* get desired delay. *
**************************************
DELAY ;AR6 = OUTER LOOP COUNT
DLY_LP RPT #DLOOP ;APPROX 5US DELAY

NOP
BANZ DLY_LP,*– ;LOOP UNTIL DONE
RET ;RETURN TO CALLING SEQUENCE
.page

**************************************************
* REGS Clears MODE bit of F_ACCESS0/1 to **
* access flash module control registers. **
*******************************************************

.sect ”REG”

REGS

PRELIMINARY

Assembly Source Listings and Program Examples

A-25

Assembly Source for Algorithms

***********The next instruction is for F240 only*************

*************************************************************

reg1 OUT SPAD2,F_ACCESS1 ;Change mode of flash1.

****************************************************
* ARRAY Sets MODE bit of F_ACCESS0/1 to access **
* the flash array. **
****************************************************

ARRAY

***********The next instruction is for F240 only*************

*************************************************************

ary1 OUT SPAD2,F_ACCESS1 ;Change mode of flash1.

PRELIMINARY

SPLK #0000h,SPAD2

.if F24X = 1 ;Assemble for F24X only.
OUT SPAD2,F24X_ACCS ;Enable F240 flash reg mode.

;SPAD1 is dummy value.

.endif

.if F24X = 0 ;Assemble for F206 only.
LACC FL_ST
SUB #4000h
BCND reg1,geq ;if address>= 4000h,set

;set reg mode for flash1 array
OUT SPAD2,F_ACCESS0 ;Change mode of flash0.
RET

.endif
RET ;RETURN TO CALLING SEQUENCE

.page

.sect ”ARY”

SPLK #0001h,SPAD2

.if F24X = 1 ;Assemble for F240 only.
IN SPAD1,F24X_ACCS ;Enable F240 flash array mode.

;SPAD1 is dummy value.
.endif

.if F24X = 0 ;Assemble for F206 only.
LACC FL_ST
SUB #4000h
BCND ary1,geq ;if address>= 4000h,set

;set reg mode for flash1 array
OUT SPAD2,F_ACCESS0 ;Change mode of flash0.
RET

.endif
RET ;RETURN TO CALLING SEQUENCE

.end

A-26

PRELIMINARY

PRELIMINARY

A.2 C-Callable Interface to Flash Algorithms

The two functions erase() and program() are intended for in-application pro­gramming of the ’F20x/F24x flash module. These functions were written to be
C callable, but they can also be called from assembly as long as the C stack
calling convention is used.

*****************************************************
* This file contains two C–callable functions: *
* program(), and erase() *
* These functions are used for programming and *
* erasing the on–chip flash EEPROM of the ’F2XX *
* product family. *
*****************************************************
* The functions provide a C–callable, interface to *
* the standard ’F2XX flash algorithms. They can *
* also be used from assembly code, as long as the *
* C stack calling convention is used. Since the *
* standard flash algorithms are actually used to *
* perform the various flash operations, they must *
* must be combined with this code at link time. *
**
* The erase function includes all the operations *
* (clear+erase+flw) required to prepare the flash *
* for programming. In addition to providing the *
* C–callable interface, this function is very *
* useful since it provides a single call to erase *
* the flash memory. *
* Since programming the device requires a single *
* algorithm, the only purpose for the program() *
* function is to provide a C–callable interface. *
* The program() function transfers a specified *
* block of data memory into a specified, erased *
* flash array. *
**
* The parameters for each function are described *
* in detail below. Note these functions cannot *
* reside in the same flash module that they are *
* meant to modify. *
**
* 10/29/97 Ruben D. Perez *
* DSP Applications Team *
* Texas Instruments, Inc. *
* 03/20/98 Updated for inclusion in flash *
* technical reference. *
***************************************************

C-Callable Interface to Flash Algorithms

PRELIMINARY

.title ”C–callable Interface to ’F2XX Flash Algorithms**”

;**C–callable functions defined in this file.

.global _erase, _program

Assembly Source Listings and Program Examples

A-27

C-Callable Interface to Flash Algorithms

;**Variables included from flash algorithms.

.include ”svar20.h” ;Variable declarations
.ref GCLR ;References clear algo.
.ref GPGMJ ;References program algo.
.ref GERS ;References erase algo.
.ref FLWS ;References flash–write algo.

;**Parameters used by flash algorithms.

.def PRG_bufaddr, PRG_paddr
.def PRG_length, PARMS
.def SEG_ST,SEG_END,PROTECT

*************************************************************
VARS: .usect ”PRG_data”,16 ;This is an uninitialized data *

*************************************************************
PARMS: .usect ”PRG_parm”,10 ;This is an uninitialized data *

*************************************************************
PROTECT .set PARMS ;Segment enable bits. *
*************************************************************
***** Parameters needed for Programming algorithm. ********
*************************************************************
PRG_bufaddr .set PARMS+1 ;Addr of buffer for pgm data *
PRG_paddr .set PARMS+2 ;First flash addr to program *
PRG_length .set PARMS+3 ;Length of block to program *
*************************************************************
** Parameters needed for CLEAR, ERASE, and FLW algorithms. *
*************************************************************
SEG_ST .set PARMS+4 ;Segment start address. *
SEG_END .set PARMS+5 ;Segment end address. *
*************************************************************
**** Other misc variables. ****
*************************************************************
ERS_COUNT .set PARMS+6 ;Used for erase fail count. *
SV_AR1 .set PARMS+7 ;Used to save AR1. *
**************************************************************

.sect ”PRG_text”

**********************************************************
* function erase(PROTECT,SEG_ST,SEG_END) *
* Status is returned in the accumulator. *
* 0 = Fail,1 = Pass *
**********************************************************
* This function performs the clear and erase operation *
* on the ’F2XX flash. If the erase operation fails, the *
* flash–write operation is used to try to recover from *
* depletion. If the array recovers, the entire process *
* (clr+ers+flw) is repeated a maximum of 10 times. The *
* return value indicates the status. If this function *

PRELIMINARY

;section required by the standard *
;flash algos for temporary *
;variables. Pointers to this *
;space are hardcoded in SVAR20.H, *
;and variables are init’d at *
;run time. *

;section used for temporary *
;variables and for passing *
;parameters to the flash *
;algorithms. *

A-28

PRELIMINARY

PRELIMINARY

C-Callable Interface to Flash Algorithms

* passes, the flash is ready to be reprogrammed. The *
* operations are performed on the segments of the flash *
* module described by the parameter list: *
* 1)PROTECT–defines which flash segments to protect.*
* 2)SEG_ST –start address of segment to be erased. *
* 3)SEG_END–end address of segment to be erased. *
* To erase flash0 use erase(0xff00,0x0000,0x3fff). *
* To erase flash1 use erase(0xff00,0x4000,0x7fff). *
*********************************************************
* CAUTION: Erasing individual segments is not allowed. *
* The PROTECT parameter should always be set to *
* enable all segments, and SEG_ST and SEG_END *
* should be set to the end and start address of *
* the array to be erased. *
*********************************************************
_erase:
ERS_PARAMS .set 3
AR_STACK .set ar1
AR_PROTECT .set ar2
AR_SEG_ST .set ar3
AR_SEG_END .set ar4

;Begin C Preprocessing

POPD *+ ;pop return address, push on software stack
sar ar0,*+ ;save FP
sar ar6,* ;save ar6
sbrk #3

;get arguments and place them properly – take them from
;the software stack and place them into their correct

;positions
lar AR_PROTECT,*–
lar AR_SEG_ST,*–
lar AR_SEG_END,*–
adrk #ERS_PARAMS+4 ;ar1 = next empty point on stack (SP)

;End C Preprocessing

LDP #PARMS
SAR AR1,SV_AR1 ;Save AR1.
SPLK #0,ERS_COUNT ;Set erase fail count to 0.
SPLK #0,ERROR ;Set algo error flag to 0 (no errors).

**********Put parameters where they belong.**********

SAR AR_PROTECT,PROTECT
SAR AR_SEG_ST,SEG_ST
SAR AR_SEG_END,SEG_END

***********Next Setup to clear flash ************
ers_loop:

CALL GCLR ;Clear flash.

LACL ERROR ;Check for CLEAR/ERASE error

BCND ers_error,neq ;If error, then hard fail.

***********Next Setup to erase flash ************

CALL GERS ;Erase flash.

LACL ERROR ;Check for CLEAR/ERASE error

BCND depletion,neq ;If error, try Flash–write.

LACL #1 ;Else, no errors erasing.

B ers_done ;Restore registers and return.

depletion:

LACL ERS_COUNT ;Get erase fail count.

PRELIMINARY

Assembly Source Listings and Program Examples

A-29

C-Callable Interface to Flash Algorithms

ADD #1 ;Increment fail count.
SACL ERS_COUNT ;Save new count.
SUB #10 ;CHECK for max of 10.
BCND ers_error,GT ;If ers_cout>10 then hard fail.
CALL FLWS ;Else, try to recover from depletion.
LACL ERROR ;Check for FLASH–WRITE error.
BCND ers_error,neq ;If couldn’t recover, then hard fail.
B ers_loop ;Else, try erase again.

ers_error:

LACL #0 ;Error while erasing.

ers_done:

LAR AR1,SV_AR1 ;Restore AR1.

CLRC OVM ;Disable overflow.
********************************************
;Begin C Post Processing

mar *,ar1

sbrk #1

lar ar6,*– ;save FP

lar ar0,*– ;save ar6

pshd * ;pop return address, push on s/w stack
;End C Post Processing

ret
*****************END of _erase****************************

**********************************************************
* function program(PROTECT,PRG_bufaddr,PRG_paddr, *
* PRG_length) *
* Status will be returned in the accumulator. *
* 0 = Fail, 1 = Pass *
*********************************************************
* This function performs the program operation on the *
* ’F2XX flash. The values to be programmed will be read *
* from a buffer in data memory. The function can program*
* one to n words of flash in a single call; restricted *
* only by the data buffer size. If the function passes, *
* the flash was programmed correctly. The function is *
* controlled by the following parameter list: *
* 1)PROTECT –flash segments to protect. *
* 2)PRG_bufaddr–Start address of program buffer in *
* data memory. *
* 3)PRG_paddr –Start address of flash locations to *
* be programmed. *
* 4)PRG_length –Number of words to be programmed. *
* *
* To program 20 words of flash1 starting at address *
* 0x4020, from a buffer at 0x0800@data use this: *
* program(0xff00,0x0800,0x4020,20). *
*********************************************************
_program:
PRG_PARAMS .set 4
AR_STACK .set ar1
;**Parameters to be popped from s/w stack.
AR_PROTECT .set ar2
AR_bufaddr .set ar3
AR_paddr .set ar4
AR_length .set ar5

PRELIMINARY

A-30

PRELIMINARY

PRELIMINARY

C-Callable Interface to Flash Algorithms

;Begin C Preprocessing

POPD *+ ; pop return address, push on s/w stack
sar ar0,*+ ; save FP
sar ar6,* ; save ar6
sbrk #3
; Local variables (and parameters) are set up as follows:
;
;get arguments and place them properly – take them from
;the software stack and place them into their correct
;positions
lar AR_PROTECT,*–
lar AR_bufaddr,*–
lar AR_paddr,*–
lar AR_length,*–
adrk #PRG_PARAMS+4 ; ar1 = next empty point on stack (SP)

; End C Preprocessing

LDP #PARMS
SAR AR1,SV_AR1 ;Save AR1.
SPLK #0,ERROR ;Set algo error flag to 0

;(no errors).

**********Put parameters where they belong.**********

SAR AR_PROTECT,PROTECT
SAR AR_bufaddr,PRG_bufaddr
SAR AR_paddr,PRG_paddr
SAR AR_length,PRG_length

***********Next, program flash ************

CALL GPGMJ ;Program flash from buffer.
LACL ERROR ;Check for program error.
BCND prg_error,neq ;If error then clear ACC.
LACL #1 ;Else, No errors programming.
B prg_done

prg_error:

LACL #0 ;Error while programming.

prg_done:

LAR AR1,SV_AR1 ;Restore AR1.

CLRC OVM ;Disable overflow.
********************************************
;Begin C Post Processing

mar *,ar1
sbrk #1
lar ar6,*– ;save FP
lar ar0,*– ;save ar6
pshd * ;pop return address, push on s/w stack

;End C Post Processing

ret

*****************END of _program************************

PRELIMINARY

Assembly Source Listings and Program Examples

A-31

Sample Assembly Code to Erase and Reprogram the TMS320F206

PRELIMINARY

A.3 Sample Assembly Code to Erase and Reprogram the TMS320F206

The algorithm files can be used from assembly in a straightforward manner. In
general, the algorithms can reside anywhere in program space. However, the
algorithms cannot be executed from the flash module that is being modified,
and the algorithms must execute with zero wait states. The assembly code and
linker command file in this section provide a working example for the ’F206. In
this example, the algorithms reside in SARAM, and flash1 is erased and repro­grammed.

A.3.1 Assembly Code for TMS320F206

*******************************************************
* Filename: ASMEXAMP.ASM *
* Description: *
* This file contains an example of how to erase *
* and program the TMS320F206 flash from assembly *
* code using the standard flash algorithm modules. *
* The example erases one of the ’F206 flash *
* modules, then programs the first three words. *
* Since the standard flash algorithms are actually *
* used to perform the various flash operations, *
* they must must be combined with this code at *
* link time. *
**
* 03/20/98 Updated for inclusion in flash *
* technical reference. *
*******************************************************

.title ”**Example of Using ’F2XX Flash Algorithms**”

;**Variables included from flash algorithms.

.include ”svar20.h” ;Variable declarations
.ref GCLR ;References clear algo.
.ref GPGMJ ;References program algo.
.ref GERS ;References erase algo.
.ref FLWS ;References Flash–write algo.

;**Parameters used by flash algorithms.

.def PRG_bufaddr, PRG_paddr
.def PRG_length, PARMS

.def SEG_ST,SEG_END,PROTECT
**********************************************************
VARS: .usect”PRG_data”,16 ;This is an uninitialized *

;data section required by *
;the standard flash algos *
;for temporary variables. *
;Pointers to this space *
;are hardcoded in SVAR20.H, *
;and variables are *

;init’d at run time. *
**********************************************************
PARMS: .usect”PRG_parm”,10 ;This is an uninitialized *

A-32

PRELIMINARY

PRELIMINARY

Sample Assembly Code to Erase and Reprogram the TMS320F206

;data section used for *
;temporary variables, and *
;for passing parameters *

;to the flash algorithms. *
*********************************************************
PROTECT .set PARMS ;Segment enable bits. *
**********************************************************
*** Parameters needed for Programming algorithm. ***
**********************************************************
PRG_bufaddr .set PARMS+1 ;Address of buffer for *

;program data. *
PRG_paddr .set PARMS+2 ;First flash address to *

;program. *
PRG_length .set PARMS+3 ;Length of block to program.*
**********************************************************
* Parameters needed for CLEAR, ERASE, and FLW algorithms.
*
**********************************************************
SEG_ST .set PARMS+4 ;Segment start address. *
SEG_END .set PARMS+5 ;Segment end address. *
**********************************************************
**** Other misc variables. ****
**********************************************************
ERS_COUNT .set PARMS+6 ;Used for erase fail count. *
**********************************************************

.text
*********************************************************
** First, erase flash1 by invoking the clear and erase *
** algorithms. *
** Note: three parameters must be initialized before *
** calling the algorithms. *
*********************************************************

LDP #PARMS

SPLK #0,ERS_COUNT ;Set erase fail count to 0.
**********Put parameters where they belong.**********

SPLK #0ff00h,PROTECT

SPLK #04000h,SEG_ST

SPLK #07FFFh,SEG_END
***********First clear flash ************
ers_loop:

CALL GCLR ;Clear flash.

LACL ERROR ;Check for CLEAR error

BCND ers_error,neq ;If error, then hard fail.
***********Next erase flash ************

CALL GERS ;Erase flash.

LACL ERROR ;Check for CLEAR error

BCND depletion,neq ;If error, then try

;flash–write.

B ers_done ;Else, no errors erasing.
depletion:

LACL ERS_COUNT ;Get erase fail count.

ADD #1 ;Increment fail count.

SACL ERS_COUNT ;Save new count.

PRELIMINARY

Assembly Source Listings and Program Examples

A-33

Sample Assembly Code to Erase and Reprogram the TMS320F206

SUB #10 ;CHECK for max of 10.
BCND ers_error,GT ;If ers_cout>10 then hard

CALL FLWS ;Else, try to recover from

;depletion.
LACL ERROR ;Check for FLASH–WRITE error.
BCND ers_error,neq ;If couldn’t recover, then

B ers_loop ;Else, try erase again.

ers_error:
********************************************************
** If here, then an unrecoverable error has occurred **
** during erase. In an actual application, the system**
** takes some action to indicate that service is **
** required. **
********************************************************

B ers_error ;Error while erasing.

ers_done:
********************************************************
** If here, then flash is erased and ready to be **
** reprogrammed. This is a good place in the example **
** to set a breakpoint so that erasure can be **
** verified (i.e., all flash bits should be 1). **
********************************************************

**********************************************************
** At this point, an actual application fills a buffer **
** with the data to be programmed. To simulate this in **
** the example, three SARAM locations are initialized. **
**********************************************************

LAR AR1, #0c00h;Using last 3K of SARAM as

;buffer.
MAR *,AR1
SPLK #0AAAAh,*+ ;Use dummy data for buffer.
SPLK #05555h,*+
SPLK #0AAAAh,*

**********************************************************
** Now that the data to be programmed is ready, the **
** programming algorithm is invoked. Note that four **
** parameters must be initialized before calling the **
** algorithm. **
**********************************************************

LDP #PARMS

**********Put parameters where they belong.**********

splk #0ff00h,PROTECT
splk #0c00h,PRG_bufaddr
splk #04000h,PRG_paddr
splk #3,PRG_length

***********Next program flash ************

CALL GPGMJ ;Program flash from buffer.
LACL ERROR ;Check for program error.
BCND prg_error,neq ;If error then clear ACC.
B prg_done ;Else, No errors programming.

PRELIMINARY

;fail.

;hard fail.

A-34

PRELIMINARY

PRELIMINARY

Sample Assembly Code to Erase and Reprogram the TMS320F206

prg_error:
********************************************************
** If here, then an error has occurred during **
** programming. In an actual application, the system **
** takes some action to indicate that service is **
** required. **
********************************************************

B prg_error ;Error while programming.

prg_done:
**********************************************************
*********
** If here, then flash has been successfully programmed.**
**********************************************************

B prg_done ;Done programming.

A.3.2 Linker Command File for TMS320F206 Sample Assembly Code

/********************************************************************************/
/* Filename: ASMEXAMP.CMD */
/* Description: Linker command file for ’F206 example of on–chip */
/* flash programming from assembly. This command file links the example to addr */
/* 0x8000 of the on–chip SARAM so that the debugger can be used to set */
/* breakpoints. Another benefit of linking the example to SARAM is that the */
/* code can be modified to operate on either flash module0, or module1, or */
/* both. */
/* Notes: */
/* 1. This example expects the ’F206 SARAM to be mapped in both data space */
/* and program space (DON=PON=1). */
/* 2. The object modules for the standard flash algos are expected to be in */
/* a subdirectory (ALGOS) of the path of this file. */
/********************************************************************************/
/* Rev1.0 3/98 RDP */
/********************************************************************************/

/*****************************Command Line Options*******************************/
–e .text
–o asmexamp.out
–m asmexamp.map

/**************************Input Files*******************************************/
asmexamp.obj /*User assembly code that calls flash algos. */
algos\spgm20.obj /*Standard Programming algorithm. */
algos\sclr20.obj /*Standard Clear algorithm. */
algos\sera20.obj /*Standard Erase algorithm. */
algos\sflw20.obj /*Standard Flash–write algorithm. */
algos\sutils20.obj /*Subroutines used by standard algos. */

/*****************************Memory Map*****************************************/
MEMORY
{
PAGE 0: /* PM – Program memory */

FLASH0: origin = 0x0000, length = 0x3fff
FLASH1: origin = 0x4000, length = 0x3fff
PSARAM: origin = 0x8000, length = 0x400 /*Use 1K of SARAM for PROGRAM */
B0: origin = 0xff00, length = 0x1ff

PRELIMINARY

Assembly Source Listings and Program Examples

A-35

Sample Assembly Code to Erase and Reprogram the TMS320F206

PAGE 1: /* DM – Data memory */

BLK_B2: origin = 0x60,length = 0x20 /*BLOCK B2 */
DSARAM: origin = 0xc00, length = 0xC00 /*Use 3K of SARAM for data DON=1 */
EX1_DM: origin = 0x4000, length = 0x4000 /*External data RAM */
B1: origin = 0x300, length = 0x1ff /*B1 Ram (Used for algo vars ) */

}
/*************************Section Allocation************************************/

SECTIONS
{

.text : {} > PSARAM PAGE 0 /* asmexamp.asm */

/*All these sections are for flash programming.*/
fl_prg : {} > PSARAM PAGE 0 /**Programming Algorithm*****/
fl_clr : {} > PSARAM PAGE 0 /******Clear Algorithm*******/
fl_ers : {} > PSARAM PAGE 0 /******Erase Algorithm*******/
fl_wrt : {} > PSARAM PAGE 0 /****Flash–write Algorithm***/
DLY : {} > PSARAM PAGE 0 /******Delay Subroutine******/
REG : {} > PSARAM PAGE 0 /*******Regs Subroutine******/
ARY : {} > PSARAM PAGE 0 /******Array Subroutine******/
PRG_data : {} > B1 PAGE 1 /*Reserved in asmexamp.asm **/

/*for flash algo variables.**/

PRG_parm : {} > B1 PAGE 1 /*Reserved in asmexamp.asm **/

/*for param passing to algos*/

/*End of sections for flash programming. */

}

PRELIMINARY

A-36

PRELIMINARY

PRELIMINARY

Sample C Code to Erase and Reprogram the TMS320F206

A.4 Sample C Code to Erase and Reprogram the TMS320F206

Because the algorithm implementations do not follow the C-calling convention
of the ’C2000 C environment, they cannot be used directly from C. The assem­bly code of section A.2,
as a C-callable interface to the programming algorithms. The following C
source file and linker command file provide a working example for the ’F206. In
this example, the algorithms reside in the on-chip SARAM, and either flash0 or
flash1 can be reprogrammed. The code can be relocated anywhere in pro­gram space, with the exceptions described in section A.3,

rithms With Assembly Code

A.4.1 C Code That Calls the Interface to Flash Algorithms for TMS320F206

/***************************************************/
/* Filename: sample.c */
/* Description: This is an example of how to */
/* program the ’F2XX flash from C code. */
/* The C–callable interface for the standard */
/* flash algorithms is used. This interface is */
/* defined in the file <flash.asm>, as two */
/* C–callable functions: erase(), and program() */
/* At link time, this example must be combined */
/* with the code in <flash.asm> as well as with */
/* the object modules for the standard algos. */
/***************************************************/
/* This example is set up for the TMS320F206, */
/* and uses the SARAM as a buffer for programming */
/* data. The code first erases module1, */
/* then programs the first three locations. */
/***************************************************/
/* Rev1.0 10/97 RDP */
/***************************************************/
extern int erase(); /* Declare external func for flash erase. */
extern int program(); /* Declare external func for flash programming. */
main()
{

int *a;
if (erase(0xff00,0x4000,0x7fff))
{ /*Flash is erased, now let’s program it.*/

/* Init program buffer. */
a=(int *)0xC00; /*Use last 3K of SARAM for data buffer*/
a[0]=0x7A80;
a[1]=0x0FDF;
a[2]=0x7A80;

C-Callable Interface to Flash Algorithms

Using the Algo-

.

, is provided

/*Program the flash from the buffer*/
if (program(0xff00,0xc00,0x4000,0x3))
{ /*Flash programmed ok.*/

while(1){} /*Spin here forever*/
}
else

PRELIMINARY

Assembly Source Listings and Program Examples

A-37

Sample C Code to Erase and Reprogram the TMS320F206

{ /*Flash fails programming, EXIT*/

while(1){} /*Spin here forever*/

}
}
else
{ /*Flash fails erase, EXIT*/

while(1){} /*Spin here forever*/
}

}

PRELIMINARY

A.4.2 Linker Command File for TMS320F206 Sample C Code

/*************************************************************************/
/* Filename: F206_SA.CMD */
/* Description: Linker command file for ’F206 example of on–chip flash */
/* programming from C code. This command file links the */
/* example to addr 0x8000 of the on–chip SARAM so that */
/* the debugger can be used to set breakpoints. Another */
/* benefit of linking the example to SARAM is that the */
/* C code can be modified to operate on either flash */
/* module0, or module1, or both. */
/* Notes: */
/* 1. This example expects the ’F206 SARAM to be */
/* mapped in both data space and program space */
/* (DON=PON=1). */
/* 2. The object modules for the standard flash algos */
/* are expected to be in a subdirectory (ALGOS) of */
/* the path of this file. */
/**********************************************************************/
/* Rev1.0 10/97 RDP */
/**********************************************************************/

/************************Command Line Options**************************/
–cr /*Use Ram init model. */
–heap 0x0 /*No heap needed for this example. */
–stack 0x96 /*150–word stack is enough for this example. */
–x /*Force rereading of libraries. */
–l c:\dsptools\rts2xx.lib
–o sample_S.out
–m sample_S.map

/*****************************Input Files******************************/
sample.obj /*User C code with calls to erase() and program() */
flash.obj /*C–callable interface to standard algorithms. */
algos\spgm20.obj /*Standard Programming algorithms. */
algos\sclr20.obj /*Standard Clear algorithm. */
algos\sera20.obj /*Standard Erase algorithm. */
algos\sflw20.obj /*Standard Flash–write algorithm. */
algos\sutils20.obj /*Subroutines used by standard algorithms. */

/*****************************Memory Map*******************************/
MEMORY
{
PAGE 0: /* PM – Program memory */

A-38

PRELIMINARY

PRELIMINARY

FLASH0: origin = 0x0000, length = 0x3fff
FLASH1: origin = 0x4000, length = 0x3fff
PSARAM: origin = 0x8000, length = 0x400 /*Use 1K of SARAM for PROGRAM*/
B0: origin = 0xff00, length = 0x1ff

PAGE 1: /* DM – Data memory */

BLK_B2: origin = 0x60, length = 0x20 /*BLOCK B2 */
DSARAM: origin = 0xc00, length = 0xC00 /*Use 3K of SARAM for data */

EX1_DM: origin = 0x4000, length = 0x4000 /*External data RAM */
B1: origin = 0x300, length = 0x1ff /*B1 RAM (Used for algo vars )*/

}
/*************************Section Allocation***************************/

SECTIONS
{

.text : {} > PSARAM PAGE 0 /* sample.c */
/*All these sections are for flash programming.*/

PRG_text : {} > PSARAM PAGE 0 /**erase() and program()*****/

fl_prg : {} > PSARAM PAGE 0 /**Programming Algorithm*****/
fl_clr : {} > PSARAM PAGE 0 /******Clear Algorithm*******/
fl_ers : {} > PSARAM PAGE 0 /******Erase Algorithm*******/
fl_wrt : {} > PSARAM PAGE 0 /****Flash–write Algorithm***/
DLY : {} > PSARAM PAGE 0 /******Delay Subroutine******/
REG : {} > PSARAM PAGE 0 /*******Regs Subroutine******/
ARY : {} > PSARAM PAGE 0 /******Array Subroutine******/
PRG_data : {} > B1 PAGE 1 /*Reserved in flash.asm for**/

PRG_parm : {} > B1 PAGE 1 /*Reserved in flash.asm for**/

/*End of sections for flash programming. */
.bss : {} > B1 PAGE 1

.cinit : {} > B1 PAGE 1
.const : {} > B1 PAGE 1
.data : {} > B1 PAGE 1
.stack : {} > B1 PAGE 1 /*C stack. */

}

Sample C Code to Erase and Reprogram the TMS320F206

/*DON=1*/

/*****from flash.asm file****/

/***flash algo variables.****/

/*parameter passing to algos*/

PRELIMINARY

Assembly Source Listings and Program Examples

A-39

Sample Assembly Code to Erase and Reprogram the TMS320F240

PRELIMINARY

A.5 Sample Assembly Code to Erase and Reprogram the TMS320F240

The algorithm files can be used from assembly in a straightforward manner. In
general, the algorithms can reside anywhere in program space. However, the
algorithms cannot be executed from the flash module that is being modified,
and the algorithms must execute with zero wait states. The assembly code and
linker command file in this section provide a working example for the ’F240.

Note:

This is not an actual application example since a boot mechanism is required
to load the external SRAM on powerup. This example uses the ’C2xx C­source Debugger to download the code to the external SRAM. In addition,
no reset or interrupt vectors are initialized.

The system requirements are F240 EVM or target board with external pro­gram space SRAM located at 0x8000 and a minumum of 1K words.

A.5.1 Assembly Code for TMS320F240

*************************************************************
* Filename: ASMEXA24.ASM *
* Description: *
* This file contains an example of how to erase *
* and program the TMS320F240 flash from assembly *
* code using the standard flash algorithm modules. *
* The example erases the ’F240 flash *
* modules, then programs the first three words. *
* Since the standard flash algorithms are actually *
* used to perform the various flash operations, *
* they must must be combined with this code at *
* link time. *
* *
* 03/25/98 Updated for inclusion in flash *
* technical reference. *
*************************************************************

.title ”**Example of Using ’F2XX Flash Algorithms**”

A-40

PRELIMINARY

PRELIMINARY

Sample Assembly Code to Erase and Reprogram the TMS320F240

;**Variables included from flash algorithms.

;**Parameters used by flash algorithms.

;**F240 Register definitions
RTICR .set 07027h ;RTI Control Register
WDCR .set 07029h ;WD Control Register
CKCR0 .set 0702Bh ;Clock Control Register 0
CKCR1 .set 0702Dh ;Clock Control Register 1
SYSSR .set 0701Ah ;System Module Status Register
DP_PF1 .set 224 ;page 1 of peripheral file

*************************************************************
VARS: .usect ”PRG_data”,16 ;This is an uninitialized data *

*************************************************************
PARMS: .usect ”PRG_parm”,10 ;This is an uninitialized data *

*************************************************************
PROTECT .set PARMS ;Segment enable bits. *
**************************************************************
***** Parameters needed for Programming algorithm. ***
*************************************************************
PRG_bufaddr .set PARMS+1 ;Addr of buffer for pgm data. *
PRG_paddr .set PARMS+2 ;1st flash addr to program. *
PRG_length .set PARMS+3 ;Length of block to program. *
*************************************************************
*** Parameters needed for CLEAR, ERASE, and FLW algorithms. **
*************************************************************
SEG_ST .set PARMS+4 ;Segment start address. *
SEG_END .set PARMS+5 ;Segment end address. *
*************************************************************
**** Other misc variables. ****
*************************************************************
ERS_COUNT .set PARMS+6 ;Used for erase fail count. *
*************************************************************

*************************************************************
** First, initialize the key F240 registers for use with *
** the EVM. *
*************************************************************

.include ”svar20.h” ;Variable declarations
.ref GCLR ;References clear algo.
.ref GPGMJ ;References program algo.
.ref GERS ;References erase algo.
.ref FLWS ;References flash–write algo.

.def PRG_bufaddr, PRG_paddr
.def PRG_length, PARMS
.def SEG_ST,SEG_END,PROTECT

;(7000h/80h)

;section required by the standard *
;flash algos for temporary *
;variables. Pointers to this *
;space are hardcoded in SVAR20.H, *
;and variables are init’d at *
;run time. *

;section that is used for *
;temporary variables and for *
;passing parameters to the flash *
;algorithms. *

.text

PRELIMINARY

Assembly Source Listings and Program Examples

A-41

Sample Assembly Code to Erase and Reprogram the TMS320F240

PRELIMINARY

F240INIT: ;Set Data Page pointer to page 1 of the

**********************************************************
** First, erase flash1 by invoking the clear and erase **
** algorithms. **
** Note: Three parameters must be initialized before **
** calling the algorithms. **
**********************************************************

**********Put parameters where they belong.**********

***********First, clear flash ************

;peripheral frame

LDP #DP_PF1 ;Page DP_PF1 includes WET through*

;EINT frames
;initialize WDT registers
SPLK #06Fh, WDCR ;clear WDFLAG, Disable WDT

;(if Vpp=5V), set WDT

;for 1 second overflow (max)
SPLK #07h, RTICR ;clear RTI Flag,

;set RTI for 1 second overflow

;(max)
;EVM 10–MHz oscillator settings.
;(XTAL2 open, OSCBYP_=GND)
SPLK #00B1h,CKCR1 ;CLKIN(OSC)=10MHz,

;Mult by 2, Div by 1.
SPLK #00C3h,CKCR0 ;CLKMD=PLL Enable,SYSCLK=CPUCLK/2

;Clear reset flag bits in SYSSR
;(PORRST, PLLRST, ILLRST, SWRST, WDRST)
LACL SYSSR ;ACCL <= SYSSR
AND #00FFh ;Clear upper 8 bits of SYSSR
SACL SYSSR ;Load new value into SYSSR

LDP #PARMS
SPLK #0,ERS_COUNT ;Set erase fail count to 0.

SPLK #0ff00h,PROTECT
SPLK #00000h,SEG_ST
SPLK #03FFFh,SEG_END

A-42

ers_loop:

clrerr: BCND ers_error,neq ;If error, then hard fail.
***********Next erase flash ************

CALL GCLR ;Clear flash.
LACL ERROR ;Check for CLEAR/ERASE error

CALL GERS ;Erase flash.
LACL ERROR ;Check for CLEAR/ERASE error
BCND depletion,neq ;If error, then try Flash–write.
B ers_done ;Else, no errors erasing.

PRELIMINARY

PRELIMINARY

Sample Assembly Code to Erase and Reprogram the TMS320F240

depletion:

ers_error:
**************************************************************
** If here, then an unrecoverable error occurred during **
** erase. **
** In an actual application, the system takes some action **
** to indicate that service is required. **
**************************************************************

ers_done:
**********************************************************
** If here, then flash is erased and ready to be **
** reprogrammed. **
** This is a good place in the example to set a **
** breakpoint so that erasure can be verified (i.e., **
** all flash bits should be 1). **
**********************************************************

**************************************************************
** At this point, an actual application fills a buffer with **
** the data to be programmed. To simulate this in the **
** example, three DARAM locations are initialized. **
**************************************************************

LACL ERS_COUNT ;Get erase fail count.
ADD #1 ;Increment fail count.
SACL ERS_COUNT ;Save new count.
SUB #10 ;CHECK for max of 10.
BCND ers_error,GT ;If ers_cout>10 then hard fail.
CALL FLWS ;Else, try to recover from

;depletion.
LACL ERROR ;Check for FLASH–WRITE error.
BCND ers_error,neq ;If couldn’t recover, then hard

;fail.
B ers_loop ;Else, Try erase again.

B ers_error ;Error while erasing.

LAR AR1, #0380h ;Using last 128 words of B1 DARAM

;as buffer.
MAR *,AR1
SPLK #0AAAAh,*+ ;Use dummy data for buffer.
SPLK #05555h,*+
SPLK #0AAAAh,*

PRELIMINARY

Assembly Source Listings and Program Examples

A-43

Sample Assembly Code to Erase and Reprogram the TMS320F240

**************************************************************
** Now that the data to be programmed is ready, the **
** programming algorithm is invoked. Note: Four parameters **
** must be initialized before calling the algorithm. **
**************************************************************

LDP #PARMS

**********Put parameters where they belong.**********

splk #0ff00h,PROTECT
splk #0380h,PRG_bufaddr
splk #00000h,PRG_paddr
splk #3,PRG_length

***********Next, program flash************

CALL GPGMJ ;Program flash from buffer.
LACL ERROR ;Check for program error.
BCND prg_error,neq ;If error then clear ACC.
B prg_done ;Else, No errors programming.

prg_error:
**********************************************************
** If here, then an error occurred during programming. **
** In an actual application, the system takes some **
** action to indicate that service is required. **
**********************************************************

B prg_error ;Error while programming.

prg_done:
**********************************************************
** If here, then flash has been successfully programmed. *
**********************************************************

B prg_done ;Done programming.

PRELIMINARY

A-44

PRELIMINARY

PRELIMINARY

Sample Assembly Code to Erase and Reprogram the TMS320F240

A.5.2 Linker Command File for TMS320F240 Sample Assembly Code

/************************************************************/
/* Filename: ASMEXA24.CMD */
/* Description: Linker command file for ’F240 example of */
/* on–chip flash programming from assembly. This command */
/* file links the example to addr 0x8000 of the off–chip */
/* pgm RAM, so that the debugger can be used to set */
/* breakpoints. */
/* Notes: */
/* 1. The object modules for the standard flash */
/* algos are expected to be in a subdirectory */
/* (ALGOS) of the path of this file. */
/************************************************************/
/* Rev1.0 3/98 JGC */
/************************************************************/

/*******************Command Line Options*********************/
–e .text
–o asmexa24.out
–m asmexa24.map

/************************Input Files*************************/
asmexa24.obj /*User assembly code that calls flash algos. */
algos\spgm20.obj /*Standard Programming algorithm. */
algos\sclr20.obj /*Standard Clear algorithm. */
algos\sera20.obj /*Standard Erase algorithm. */
algos\sflw20.obj /*Standard Flash–write algorithm. */
algos\sutils20.obj /*Subroutines used by standard algorithms. */

/************************Memory Map**************************/
MEMORY
{
PAGE 0: /* PM – Program memory */

FLASH0: origin = 0x0000, length = 0x4000
EXTRAM: origin = 0x8000, length = 0x400 /*Use 1K of Ext. RAM for PROGRAM*/
B0PGM: origin = 0xfe00, length = 0x100

PAGE 1: /* DM – Data memory */

BLK_B2: origin = 0x60, length = 0x20 /* BLOCK B2*/
EX1_DM: origin = 0x8000, length = 0x4000 /* External data RAM */
B0: origin = 0x200, length = 0x100 /* B0 Ram (Used for temp data )*/
B1: origin = 0x300, length = 0x100 /* B1 Ram (Used for algo vars )*/

}
/*************************Section Allocation***************************/

SECTIONS
{

.text :{} > EXTRAM PAGE 0 /* asmexa24.asm */

PRELIMINARY

Assembly Source Listings and Program Examples

A-45

Sample Assembly Code to Erase and Reprogram the TMS320F240

/*All these sections are for flash programming.*/
fl_prg : {} > EXTRAM PAGE 0 /**Programming Algorithm*****/
fl_clr : {} > EXTRAM PAGE 0 /******Clear Algorithm*******/
fl_ers : {} > EXTRAM PAGE 0 /******Erase Algorithm*******/
fl_wrt : {} > EXTRAM PAGE 0 /****Flash–write Algorithm***/
DLY : {} > EXTRAM PAGE 0 /******Delay Subroutine******/
REG : {} > EXTRAM PAGE 0 /*******Regs Subroutine******/
ARY : {} > EXTRAM PAGE 0 /******Array Subroutine******/
PRG_data : {} > B1 PAGE 1 /*Reserved in asmexamp.asm **/

/*for flash algo variables.**/

PRG_parm : {} > B1 PAGE 1 /*Reserved in asmexamp.asm **/

/*for param passing to algos*/

/*End of sections for flash programming. */

}

PRELIMINARY

A-46

PRELIMINARY

PRELIMINARY

Using the Algorithms With C Code to Erase and Reprogram the ’F240

A.6 Using the Algorithms With C Code to Erase and Reprogram the ’F240

Because the algorithm implementations do not follow the C-calling convention
of the ’C2000 C environment, they cannot be used directly from C. The assem­bly code of section A.2,
as a C-callable interface to the programming algorithms. The C source file and
linker command file provide a working example for the ’F240.

In this example, the algorithms reside in external SRAM. The code can be relo­cated anywhere in program space, with the exceptions described in section
A.3,

Using the Algorithms With Assembly Code

Note:

This is not an actual application example since a boot mechanism is required
to load the external SRAM on powerup. This example uses the ’C2xx C­source Debugger to download the code to the external SRAM. In addition,
no reset or interrupt vectors are initialized.

The system requirements are F240 EVM or target board with external pro­gram space SRAM located at 0x8000 and a minimum of 1K words.

C-Callable Interface to Flash Algorithms

.

, is provided

A.6.1 C Code That Calls the Interface to Flash Algorithms for TMS320F240

/***********************************************/
/* Filname: sample24.c */
/* Description: This is an example of how to */
/* program the ’F2XX flash from C code. */
/* The C–callable interface for the standard */
/* flash algorithms is used. This interface is */
/* defined in the file <flash.asm>, as two */
/* C–callable functions: erase(), and program() */
/* At link time, this example must be combined */
/* with the code in <flash.asm> as well as with */
/* the object modules for the standard algos. */
/***************************************************/
/* This example is setup for the TMS320F240, */
/* and uses the B1 DARAM as a buffer for program– */
/* –ming data. The code first claers, erases, */
/* then programs the first three locations. */
/***************************************************/
/* Rev1.0 03/98 JGC */
/***************************************************/

PRELIMINARY

Assembly Source Listings and Program Examples

A-47

Using the Algorithms With C Code to Erase and Reprogram the ’F240

extern int erase(); /* Declare external func for flash erase. */
extern int program(); /* Declare external func for flash programming */
extern c240init(); /* Declare external func for C240 register init’l’n */
extern wdtoff(); /* Declare external func for wdt disable */
main()
{

int *a;
asm(” CLRC CNF ”); /* map B0 to data space */
c240init(); /* initialize key ’240 registers */
wdtoff(); /* disable WD timer (works when VCCP=5v) */
if (erase(0xff00,0x0000,0x3fff))
{ /*Flash is erased, now let’s program it.*/

/* Init program buffer. */
a=(int *)0x200; /*Use last 128 words of B1 DARAM for data buffer*/
a[0]=0x7A80;
a[1]=0x0FDF;
a[2]=0x7A80;

/*Program the flash from the buffer*/
if (program(0xff00,0x200,0x0000,0x3))
{ /*Flash programmed ok.*/

while(1){} /*Spin here forever*/
}
else
{ /*Flash fails programming, EXIT*/

while(1){} /*Spin here forever*/
}

}
else
{ /*Flash fails erase, EXIT*/

while(1){} /*Spin here forever*/

}

}

PRELIMINARY

A.6.2 Linker Command File for TMS320F240 Sample C Code

/**********************************************************************/
/* Filename: F240_EXT.CMD */
/* Description: Linker command file for ’F240 example of on–chip flash */
/* programming from C–code. This command file links the */
/* example to addr 0x8000 of the offchip SRAM, so that */
/* the debugger can be used to set breakpoints. */
/* Notes: */
/* 1. The object modules for the standard flash algos */
/* are expected to be in a subdirectory (ALGOS) of */
/* the path of this file. */
/**********************************************************************/
/* Rev1.0 03/98 JGC */
/**********************************************************************/

A-48

PRELIMINARY
