TEXAS INSTRUMENTS PCI4410A Technical data

查询PCI4410A供应商

 

    

Data Manual

2000 PCI Bus Solutions

SCPS059

IMPORTANT NOTICE

Texas Instruments and its subsidiaries (TI) reserve the right to make changes to their products
or to discontinue any product or service without notice, and advise customers to obtain the latest
version of relevant information to verify, before placing orders, that information being relied on
is current and complete. All products are sold subject to the terms and conditions of sale supplied
at the time of order acknowledgment, including those pertaining to warranty , patent infringement,
and limitation of liability.

TI warrants performance of its semiconductor products to the specifications applicable at the
time of sale in accordance with TI’s standard warranty. Testing and other quality control
techniques are utilized to the extent TI deems necessary to support this warranty. Specific testing
of all parameters of each device is not necessarily performed, except those mandated by
government requirements.

Customers are responsible for their applications using TI components.
In order to minimize risks associated with the customer’s applications, adequate design and

operating safeguards must be provided by the customer to minimize inherent or procedural
hazards.

TI assumes no liability for applications assistance or customer product design. TI does not
warrant or represent that any license, either express or implied, is granted under any patent right,
copyright, mask work right, or other intellectual property right of TI covering or relating to any
combination, machine, or process in which such semiconductor products or services might be
or are used. TI’s publication of information regarding any third party’s products or services does
not constitute TI’s approval, warranty or endorsement thereof.

Copyright  2000, Texas Instruments Incorporated

Contents

Section Title Page

1 Introduction 1–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.1 Description 1–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Features 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 Related Documents 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.4 Trademarks 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.5 Ordering Information 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 Terminal Descriptions 2–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Feature/Protocol Descriptions 3–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1 Power-Supply Sequencing 3–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2 I/O Characteristics 3–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3 Clamping Voltages 3–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.4 Peripheral Component Interconnect (PCI) Interface 3–2. . . . . . . . . . . . . .

3.4.1 PCI Bus Lock (LOCK

3.4.2 Loading Subsystem Identification 3–3. . . . . . . . . . . . . . . . . . . . .

3.5 PC Card Applications 3–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.5.1 PC Card Insertion/Removal and Recognition 3–3. . . . . . . . . . .

3.5.2 P

3.5.3 Zoomed-Video Support 3–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.5.4 Ultra Zoomed Video 3–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.5.5 D3_STAT

3.5.6 Internal Ring Oscillator 3–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.5.7 Integrated Pullup Resistors for PC Card Interface 3–7. . . . . . .

3.5.8 SPKROUT and CAUDPWM Usage 3–7. . . . . . . . . . . . . . . . . . .

3.5.9 LED Socket Activity Indicators 3–8. . . . . . . . . . . . . . . . . . . . . . . .

3.5.10 PC Card-16 Distributed DMA Support 3–8. . . . . . . . . . . . . . . . .

3.5.11 PC Card-16 PC/PCI DMA 3–10. . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.5.12 CardBus Socket Registers 3–10. . . . . . . . . . . . . . . . . . . . . . . . . . .

3.6 Serial Bus Interface 3–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.6.1 Serial Bus-Interface Implementation 3–11. . . . . . . . . . . . . . . . . . .

3.6.2 Serial Bus-Interface Protocol 3–11. . . . . . . . . . . . . . . . . . . . . . . . .

3.6.3 Serial Bus EEPROM Application 3–13. . . . . . . . . . . . . . . . . . . . . .

3.6.4 Accessing Serial Bus Devices Through Software 3–15. . . . . . . .

3.7 Programmable Interrupt Subsystem 3–15. . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.7.1 PC Card Functional and Card Status Change Interrupts 3–16.

3.7.2 Interrupt Masks and Flags 3–17. . . . . . . . . . . . . . . . . . . . . . . . . . .

3.7.3 Using Parallel IRQ Interrupts 3–18. . . . . . . . . . . . . . . . . . . . . . . . .

3.7.4 Using Parallel PCI Interrupts 3–18. . . . . . . . . . . . . . . . . . . . . . . . .

2

C Power Switch Interface (TPS2211) 3–4. . . . . . . . . . . . . . . .

Terminal 3–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

)3–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

iii

3.7.5 Using Serialized IRQSER Interrupts 3–18. . . . . . . . . . . . . . . . . . .

3.7.6 SMI Support in the PCI4410A Device 3–19. . . . . . . . . . . . . . . . . .

3.8 Power-Management Overview 3–19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.8.1 Clock-Run Protocol 3–19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.8.2 CardBus PC Card Power Management 3–19. . . . . . . . . . . . . . . .

3.8.3 16-Bit PC Card Power Management 3–20. . . . . . . . . . . . . . . . . . .

3.8.4 Suspend Mode 3–20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.8.5 Requirements for Suspend Mode 3–21. . . . . . . . . . . . . . . . . . . . .

3.8.6 Ring Indicate 3–21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.8.7 PCI Power Management 3–22. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.8.8 CardBus Bridge Power Management 3–23. . . . . . . . . . . . . . . . . .

3.8.9 ACPI Support 3–23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.8.10 Master List of PME

Context Bits and Global Reset-Only

Bits 3–24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4 PC Card Controller Programming Model 4–1. . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.1 PCI Configuration Registers (Functions 0 and 1) 4–1. . . . . . . . . . . . . . . . .

4.2 Vendor ID Register 4–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.3 Device ID Register 4–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.4 Command Register 4–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.5 Status Register 4–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.6 Revision ID Register 4–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.7 PCI Class Code Register 4–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.8 Cache Line Size Register 4–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.9 Latency Timer Register 4–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.10 Header Type Register 4–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.11 BIST Register 4–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.12 CardBus Socket/ExCA Base Address Register 4–7. . . . . . . . . . . . . . . . . .

4.13 Capability Pointer Register 4–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.14 Secondary Status Register 4–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.15 PCI Bus Number Register 4–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.16 CardBus Bus Number Register 4–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.17 Subordinate Bus Number Register 4–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.18 CardBus Latency Timer Register 4–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.19 Memory Base Registers 0, 1 4–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.20 Memory Limit Registers 0, 1 4–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.21 I/O Base Registers 0, 1 4–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.22 I/O Limit Registers 0, 1 4–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.23 Interrupt Line Register 4–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.24 Interrupt Pin Register 4–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.25 Bridge Control Register 4–14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.26 Subsystem Vendor ID Register 4–15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.27 Subsystem ID Register 4–15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.28 PC Card 16-Bit I/F Legacy-Mode Base Address Register 4–15. . . . . . . . .

4.29 System Control Register 4–16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

iv

4.30 General Status Register 4–19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.31 General Control Register 4–19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.32 Multifunction Routing Register 4–20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.33 Retry Status Register 4–21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.34 Card Control Register 4–22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.35 Device Control Register 4–23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.36 Diagnostic Register 4–24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.37 Socket DMA Register 0 4–25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.38 Socket DMA Register 1 4–26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.39 Capability ID Register 4–27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.40 Next-Item Pointer Register 4–27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.41 Power Management Capabilities Register 4–28. . . . . . . . . . . . . . . . . . . . . .

4.42 Power Management Control/Status Register 4–29. . . . . . . . . . . . . . . . . . . .

4.43 Power Management Control/Status Register Bridge Support

Extensions 4–30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.44 Power Management Data Register 4–30. . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.45 General-Purpose Event Status Register 4–31. . . . . . . . . . . . . . . . . . . . . . . .

4.46 General-Purpose Event Enable Register 4–32. . . . . . . . . . . . . . . . . . . . . . .

4.47 General-Purpose Input Register 4–33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.48 General-Purpose Output Register 4–34. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5 ExCA Compatibility Registers 5–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.1 ExCA Identification and Revision Register 5–4. . . . . . . . . . . . . . . . . . . . . .

5.2 ExCA Interface Status Register 5–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.3 ExCA Power Control Register 5–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.4 ExCA Interrupt and General Control Register 5–8. . . . . . . . . . . . . . . . . . .

5.5 ExCA Card Status-Change Register 5–9. . . . . . . . . . . . . . . . . . . . . . . . . . .

5.6 ExCA Card Status-Change-Interrupt Configuration Register 5–10. . . . . . .

5.7 ExCA Address Window Enable Register 5–11. . . . . . . . . . . . . . . . . . . . . . . .

5.8 ExCA I/O Window Control Register 5–12. . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.9 ExCA I/O Windows 0 and 1 Start-Address Low-Byte Registers 5–13. . . .

5.10 ExCA I/O Windows 0 and 1 Start-Address High-Byte Registers 5–13. . . .

5.11 ExCA I/O Windows 0 and 1 End-Address Low-Byte Registers 5–14. . . . .

5.12 ExCA I/O Windows 0 and 1 End-Address High-Byte Registers 5–14. . . .

5.13 ExCA Memory Windows 0–4 Start-Address Low-Byte Registers 5–15. . .

5.14 ExCA Memory Windows 0–4 Start-Address High-Byte Registers 5–16. . .

5.15 ExCA Memory Windows 0–4 End-Address Low-Byte Registers 5–17. . . .

5.16 ExCA Memory Windows 0–4 End-Address High-Byte Registers 5–18. . .

5.17 ExCA Memory Windows 0–4 Offset-Address Low-Byte Registers 5–19. .

5.18 ExCA Memory Windows 0–4 Offset-Address High-Byte Registers 5–20.

5.19 ExCA I/O Windows 0 and 1 Offset-Address Low-Byte Registers 5–21. . .

5.20 ExCA I/O Windows 0 and 1 Offset-Address High-Byte Registers 5–21. . .

5.21 ExCA I/O Card Detect and General Control Register 5–22. . . . . . . . . . . . .

5.22 ExCA Global Control Register 5–23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.23 ExCA Memory Windows 0–4 Page Register 5–23. . . . . . . . . . . . . . . . . . . .

v

6 CardBus Socket Registers 6–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.1 Socket Event Register 6–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.2 Socket Mask Register 6–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.3 Socket Present State Register 6–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.4 Socket Force Event Register 6–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.5 Socket Control Register 6–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.6 Socket Power Management Register 6–8. . . . . . . . . . . . . . . . . . . . . . . . . . .

7 Distributed DMA (DDMA) Registers 7–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7.1 DMA Current Address/Base Address Register 7–2. . . . . . . . . . . . . . . . . . .

7.2 DMA Page Register 7–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7.3 DMA Current Count/Base Count Register 7–3. . . . . . . . . . . . . . . . . . . . . . .

7.4 DMA Command Register 7–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7.5 DMA Status Register 7–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7.6 DMA Request Register 7–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7.7 DMA Mode Register 7–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7.8 DMA Master Clear Register 7–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7.9 DMA Multichannel/Mask Register 7–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8 OHCI-Lynx Controller Programming Model 8–1. . . . . . . . . . . . . . . . . . . . . . . . .

8.1 PCI Configuration Registers 8–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8.2 Vendor ID Register 8–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8.3 Device ID Register 8–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8.4 PCI Command Register 8–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8.5 PCI Status Register 8–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8.6 Class Code and Revision ID Register 8–5. . . . . . . . . . . . . . . . . . . . . . . . . .

8.7 Latency Timer and Class Cache Line Size Register 8–5. . . . . . . . . . . . . .

8.8 Header Type and BIST Register 8–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8.9 Open HCI Registers Base Address Register 8–6. . . . . . . . . . . . . . . . . . . .

8.10 TI Extension Base Address Register 8–7. . . . . . . . . . . . . . . . . . . . . . . . . . .

8.11 PCI Subsystem Identification Register 8–8. . . . . . . . . . . . . . . . . . . . . . . . . .

8.12 PCI Power Management Capabilities Pointer Register 8–8. . . . . . . . . . . .

8.13 Interrupt Line and Interrupt Pin Registers 8–9. . . . . . . . . . . . . . . . . . . . . . .

8.14 MIN_GNT and MAX_LAT Registers 8–9. . . . . . . . . . . . . . . . . . . . . . . . . . . .

8.15 PCI OHCI Control Register 8–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8.16 Capability ID and Next Item Pointer Registers 8–10. . . . . . . . . . . . . . . . . . .

8.17 Power Management Capabilities Register 8–11. . . . . . . . . . . . . . . . . . . . . .

8.18 Power Management Control and Status Register 8–12. . . . . . . . . . . . . . . .

8.19 Power Management Extension Register 8–13. . . . . . . . . . . . . . . . . . . . . . . .

8.20 PCI Miscellaneous Configuration Register 8–14. . . . . . . . . . . . . . . . . . . . . .

8.21 Link Enhancement Control Register 8–15. . . . . . . . . . . . . . . . . . . . . . . . . . . .

8.22 Subsystem Access Identification Register 8–16. . . . . . . . . . . . . . . . . . . . . .

8.23 GPIO Control Register 8–17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9 Open HCI Registers 9–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.1 OHCI Version Register 9–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.2 GUID ROM Register 9–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

vi

9.3 Asynchronous Transmit Retries Register 9–6. . . . . . . . . . . . . . . . . . . . . . .

9.4 CSR Data Register 9–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.5 CSR Compare Register 9–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.6 CSR Control Register 9–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.7 Configuration ROM Header Register 9–8. . . . . . . . . . . . . . . . . . . . . . . . . . .

9.8 Bus Identification Register 9–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.9 Bus Options Register 9–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.10 GUID High Register 9–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.11 GUID Low Register 9–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.12 Configuration ROM Mapping Register 9–11. . . . . . . . . . . . . . . . . . . . . . . . . .

9.13 Posted Write Address Low Register 9–11. . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.14 Posted Write Address High Register 9–12. . . . . . . . . . . . . . . . . . . . . . . . . . .

9.15 Vendor ID Register 9–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.16 Host Controller Control Register 9–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.17 Self ID Buffer Pointer Register 9–14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.18 Self ID Count Register 9–14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.19 Isochronous Receive Channel Mask High Register 9–15. . . . . . . . . . . . . .

9.20 Isochronous Receive Channel Mask Low Register 9–16. . . . . . . . . . . . . . .

9.21 Interrupt Event Register 9–17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.22 Interrupt Mask Register 9–19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.23 Isochronous Transmit Interrupt Event Register 9–20. . . . . . . . . . . . . . . . . .

9.24 Isochronous Transmit Interrupt Mask Register 9–21. . . . . . . . . . . . . . . . . . .

9.25 Isochronous Receive Interrupt Event Register 9–22. . . . . . . . . . . . . . . . . . .

9.26 Isochronous Receive Interrupt Mask Register 9–23. . . . . . . . . . . . . . . . . . .

9.27 Fairness Control Register (Optional Register) 9–23. . . . . . . . . . . . . . . . . . .

9.28 Link Control Register 9–24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.29 Node Identification Register 9–25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.30 PHY Control Register 9–26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.31 Isochronous Cycle Timer Register 9–27. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9.32 Asynchronous Request Filter High Register 9–28. . . . . . . . . . . . . . . . . . . . .

9.33 Asynchronous Request Filter Low Register 9–30. . . . . . . . . . . . . . . . . . . . .

9.34 Physical Request Filter High Register 9–31. . . . . . . . . . . . . . . . . . . . . . . . . .

9.35 Physical Request Filter Low Register 9–33. . . . . . . . . . . . . . . . . . . . . . . . . .

9.36 Physical Upper Bound Register (Optional Register) 9–33. . . . . . . . . . . . . .

9.37 Asynchronous Context Control Register 9–34. . . . . . . . . . . . . . . . . . . . . . . .

9.38 Asynchronous Context Command Pointer Register 9–35. . . . . . . . . . . . . .

9.39 Isochronous Transmit Context Control Register 9–36. . . . . . . . . . . . . . . . . .

9.40 Isochronous Transmit Context Command Pointer Register 9–37. . . . . . . .

9.41 Isochronous Receive Context Control Register 9–37. . . . . . . . . . . . . . . . . .

9.42 Isochronous Receive Context Command Pointer Register 9–39. . . . . . . .

9.43 Isochronous Receive Context Match Register 9–40. . . . . . . . . . . . . . . . . . .

10 Electrical Characteristics 10–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

10.1 Absolute Maximum Ratings Over Operating Temperature Ranges 10–1.

10.2 Recommended Operating Conditions 10–2. . . . . . . . . . . . . . . . . . . . . . . . . .

vii

10.3 Electrical Characteristics Over Recommended Operating Conditions

(unless otherwise noted) 10–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

10.4 PCI Clock/Reset Timing Requirements Over Recommended Ranges

of Supply Voltage and Operating Free-Air Temperature 10–4. . . . . . . . . . .

10.5 PCI Timing Requirements Over Recommended Ranges of Supply

Voltage and Operating Free-Air Temperature 10–4. . . . . . . . . . . . . . . . . . . .

11 Mechanical Information 11–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

List of Illustrations

Figure Title Page

2–1 PCI-to-CardBus Terminal Diagram 2–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–2 PCI-to-PC Card (16-Bit) Terminal Diagram 2–2. . . . . . . . . . . . . . . . . . . . . . . . .

2–3 MicroStar BGAt Ball Diagram 2–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–1 PCI4410A System Block Diagram 3–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–2 3-State Bidirectional Buffer 3–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–3 TPS2211 Terminal Assignments 3–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–4 TPS2211 Typical Application 3–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–5 Zoomed-Video Subsystem 3–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–6 Sample Application of SPKROUT and CAUDPWM 3–8. . . . . . . . . . . . . . . . . .

3–7 Two Sample LED Circuits 3–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–8 Serial EEPROM Application 3–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–9 Serial Bus Start/Stop Conditions and Bit Transfers 3–12. . . . . . . . . . . . . . . . . .

3–10 Serial Bus-Protocol Acknowledge 3–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–11 Serial Bus Protocol – Byte Write 3–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–12 Serial Bus Protocol – Byte Read 3–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–13 EEPROM Interface Doubleword Data Collection 3–13. . . . . . . . . . . . . . . . . . . .

3–14 EEPROM Data Format 3–15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–15 IRQ Implementation 3–18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–16 Suspend Functional Implementation 3–20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–17 Signal Diagram of Suspend Function 3–21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–18 RI_OUT

5–1 ExCA Register Access Through I/O 5–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5–2 ExCA Register Access Through Memory 5–1. . . . . . . . . . . . . . . . . . . . . . . . . . .

6–1 Accessing CardBus Socket Registers Through PCI Memory 6–1. . . . . . . . . .

Functional Diagram 3–22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

viii

List of Tables

Table Title Page

2–1 CardBus And 16-Bit PC Card Signal Names by PDV Terminal Number 2–4
2–2 CardBus And 16-Bit PC Card Signal Names by GHK Terminal Number 2–6
2–3 CardBus PC Card Signal Names Sorted Alphabetically to GHK/PDV

Terminal Number 2–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–4 16-Bit PC Card Signal Names Sorted Alphabetically to GHK/PDV

Terminal Number 2–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–5 Power Supply Terminals 2–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–6 PC Card Power Switch Terminals 2–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–7 PCI System Terminals 2–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–8 PCI Address and Data Terminals 2–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–9 PCI Interface Control Terminals 2–14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–10 Multifunction and Miscellaneous Terminals 2–15. . . . . . . . . . . . . . . . . . . . . . . . .

2–11 16-Bit PC Card Address and Data Terminals 2–16. . . . . . . . . . . . . . . . . . . . . . .

2–12 16-Bit PC Card Interface Control Terminals 2–17. . . . . . . . . . . . . . . . . . . . . . . . .

2–13 CardBus PC Card Interface System Terminals 2–18. . . . . . . . . . . . . . . . . . . . . .

2–14 CardBus PC Card Address and Data Terminals 2–19. . . . . . . . . . . . . . . . . . . . .

2–15 CardBus PC Card Interface Control Terminals 2–20. . . . . . . . . . . . . . . . . . . . . .

2–16 IEEE1394 PHY/Link Interface Terminals 2–21. . . . . . . . . . . . . . . . . . . . . . . . . . .

2–17 Zoomed-Video Interface Terminals 2–21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–1 PC Card Card-Detect and Voltage-Sense Connections 3–4. . . . . . . . . . . . . .

3–2 Integrated Pullup Resistors 3–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–3 Distributed DMA Registers 3–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–4 PC/PCI Channel Assignments 3–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–5 I/O Addresses Used for PC/PCI DMA 3–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–6 CardBus Socket Registers 3–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–7 Registers and Bits Loadable Through Serial EEPROM 3–14. . . . . . . . . . . . . . .

3–8 Interrupt Mask and Flag Registers 3–16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–9 PC Card Interrupt Events and Description 3–17. . . . . . . . . . . . . . . . . . . . . . . . . .

3–10 SMI Control 3–19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–11 Power-Management Registers 3–23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4–1 PCI Configuration Registers (Functions 0 and 1) 4–1. . . . . . . . . . . . . . . . . . . .

4–2 Bit-Field Access Tag Descriptions 4–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4–3 Command Register Description 4–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4–4 Status Register Description 4–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4–5 Secondary Status Register Description 4–8. . . . . . . . . . . . . . . . . . . . . . . . . . . .

4–6 Bridge Control Register Description 4–14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4–7 System Control Register Description 4–17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4–8 General Status Register Description 4–19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ix

4–9 General Control Register Description 4–19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4–10 Multifunction Routing Register Description 4–20. . . . . . . . . . . . . . . . . . . . . . . . .

4–11 Retry Status Register Description 4–21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4–12 Card Control Register Description 4–22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4–13 Device Control Register Description 4–23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4–14 Diagnostic Register Description 4–24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4–15 Socket DMA Register 0 Description 4–25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4–16 Socket DMA Register 1 Description 4–26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4–17 Power Management Capabilities Register Description 4–28. . . . . . . . . . . . . . .

4–18 Power Management Control/Status Register Description 4–29. . . . . . . . . . . . .

4–19 Power Management Control/Status Register Bridge Support Extensions

Description 4–30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4–20 General-Purpose Event Status Register Description 4–31. . . . . . . . . . . . . . . . .

4–21 General-Purpose Event Enable Register Description 4–32. . . . . . . . . . . . . . . .

4–22 General-Purpose Input Register Description 4–33. . . . . . . . . . . . . . . . . . . . . . . .

4–23 General-Purpose Output Register Description 4–34. . . . . . . . . . . . . . . . . . . . . .

5–1 ExCA Registers and Offsets 5–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5–2 ExCA Identification and Revision Register Description 5–4. . . . . . . . . . . . . . .

5–3 ExCA Interface Status Register Description 5–5. . . . . . . . . . . . . . . . . . . . . . . .

5–4 ExCA Power Control Register 82365SL Support Description 5–6. . . . . . . . .

5–5 ExCA Power Control Register 82365SL-DF Support Description 5–7. . . . . .

5–6 ExCA Interrupt and General Control Register Description 5–8. . . . . . . . . . . .

5–7 ExCA Card Status-Change Register Description 5–9. . . . . . . . . . . . . . . . . . . .

5–8 ExCA Card Status-Change-Interrupt Configuration Register Description 5–10

5–9 ExCA Address Window Enable Register Description 5–11. . . . . . . . . . . . . . . .

5–10 ExCA I/O Window Control Register Description 5–12. . . . . . . . . . . . . . . . . . . . .

5–11 ExCA Memory Windows 0–4 Start-Address High-Byte Registers

Description 5–16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5–12 ExCA Memory Windows 0–4 End-Address High-Byte Registers

Description 5–18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5–13 ExCA Memory Windows 0–4 Offset-Address High-Byte Registers

Description 5–20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5–14 ExCA I/O Card-Detect and General Control Register Description 5–22. . . . . .

5–15 ExCA Global Control Register Description 5–23. . . . . . . . . . . . . . . . . . . . . . . . .

6–1 CardBus Socket Registers 6–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6–2 Socket Event Register Description 6–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6–3 Socket Mask Register Description 6–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6–4 Socket Present State Register Description 6–4. . . . . . . . . . . . . . . . . . . . . . . . .

6–5 Socket Force Event Register Description 6–6. . . . . . . . . . . . . . . . . . . . . . . . . .

6–6 Socket Control Register Description 6–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6–7 Socket Power Management Register Description 6–8. . . . . . . . . . . . . . . . . . .

7–1 Distributed DMA Registers 7–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7–2 DMA Command Register Description 7–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7–3 DMA Status Register Description 7–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7–4 DMA Mode Register Description 7–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

x

7–5 DMA Multichannel/Mask Register Description 7–6. . . . . . . . . . . . . . . . . . . . . .

8–1 Bit-Field Access Tag Descriptions 8–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8–2 PCI Configuration Register Map 8–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8–3 PCI Command Register Description 8–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8–4 PCI Status Register Description 8–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8–5 Class Code and Revision ID Register Description 8–5. . . . . . . . . . . . . . . . . . .

8–6 Latency Timer and Class Cache Line Size Register Description 8–5. . . . . . .

8–7 Header Type and BIST Register Description 8–6. . . . . . . . . . . . . . . . . . . . . . . .

8–8 Open HCI Registers Base Address Register Description 8–6. . . . . . . . . . . . .

8–9 TI Extension Base Address Register Description 8–7. . . . . . . . . . . . . . . . . . . .

8–10 PCI Subsystem Identification Register Description 8–8. . . . . . . . . . . . . . . . . .

8–11 Interrupt Line and Interrupt Pin Registers Description 8–9. . . . . . . . . . . . . . . .

8–12 MIN_GNT and MAX_LAT Registers Description 8–9. . . . . . . . . . . . . . . . . . . .

8–13 Capability ID and Next Item Pointer Registers Description 8–10. . . . . . . . . . . .

8–14 Power Management Capabilities Register Description 8–11. . . . . . . . . . . . . . .

8–15 Power Management Control and Status Register Description 8–12. . . . . . . . .

8–16 Power Management Extension Register Description 8–13. . . . . . . . . . . . . . . . .

8–17 PCI Miscellaneous Configuration Register Description 8–14. . . . . . . . . . . . . . .

8–18 Link Enhancement Control Register Description 8–15. . . . . . . . . . . . . . . . . . . .

8–19 Subsystem Access Identification Register Description 8–16. . . . . . . . . . . . . . .

8–20 GPIO Control Register Description 8–17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9–1 Open HCI Register Map 9–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9–2 OHCI Version Register Description 9–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9–3 GUID ROM Register Description 9–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9–4 Asynchronous Transmit Retries Register Description 9–6. . . . . . . . . . . . . . . .

9–5 CSR Control Register Description 9–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9–6 Configuration ROM Header Register Description 9–8. . . . . . . . . . . . . . . . . . . .

9–7 Bus Options Register Description 9–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9–8 Configuration ROM Mapping Register Description 9–11. . . . . . . . . . . . . . . . . . .

9–9 Posted Write Address Low Register Description 9–11. . . . . . . . . . . . . . . . . . . .

9–10 Posted Write Address High Register Description 9–12. . . . . . . . . . . . . . . . . . . .

9–11 Host Controller Control Register Description 9–13. . . . . . . . . . . . . . . . . . . . . . . .

9–12 Self ID Count Register Description 9–14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9–13 Isochronous Receive Channel Mask High Register Description 9–15. . . . . . .

9–14 Isochronous Receive Channel Mask Low Register Description 9–16. . . . . . . .

9–15 Interrupt Event Register Description 9–17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9–16 Interrupt Mask Register Description 9–19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9–17 Isochronous Transmit Interrupt Event Register Description 9–20. . . . . . . . . . .

9–18 Isochronous Receive Interrupt Event Register Description 9–22. . . . . . . . . . .

9–19 Fairness Control Register Description 9–23. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9–20 Link Control Register Description 9–24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9–21 Node Identification Register Description 9–25. . . . . . . . . . . . . . . . . . . . . . . . . . .

9–22 PHY Control Register Description 9–26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9–23 Isochronous Cycle Timer Register Description 9–27. . . . . . . . . . . . . . . . . . . . . .

xi

9–24 Asynchronous Request Filter High Register Description 9–28. . . . . . . . . . . . .

9–25 Asynchronous Request Filter Low Register Description 9–30. . . . . . . . . . . . . .

9–26 Physical Request Filter High Register Description 9–31. . . . . . . . . . . . . . . . . . .

9–27 Physical Request Filter Low Register Description 9–33. . . . . . . . . . . . . . . . . . .

9–28 Asynchronous Context Control Register Description 9–34. . . . . . . . . . . . . . . . .

9–29 Asynchronous Context Command Pointer Register Description 9–35. . . . . . .

9–30 Isochronous Transmit Context Control Register Description 9–36. . . . . . . . . .

9–31 Isochronous Receive Context Control Register Description 9–38. . . . . . . . . . .

9–32 Isochronous Receive Context Match Register Description 9–40. . . . . . . . . . . .

xii

1 Introduction

The Texas Instruments PCI4410A device is an integrated single-socket PC Card controller and IEEE 1394 Open HCI
host controller. This high-performance integrated solution provides the latest in both PC Card and IEEE 1394
technology.

1.1 Description

The PCI4410A device is a dual-function PCI device compliant with the PCI Local Bus Specification. Function 0
provides the independent PC Card socket controller compliant with the PC Card Standard. The PCI4410A device
provides features that make it the best choice for bridging between the PCI bus and PC Cards, and supports either
16-bit or CardBus PC Cards in the socket, powered at 5 V or 3.3 V, as required.

All card signals are buffered internally to allow hot insertion and removal without external buffering. The PCI4410A
device is compatible with the register of the Intel 82365SL–DF and 82365SL ExCA controllers. The PCI4410A
internal data-path logic allows the host to access 8-, 16-, and 32-bit cards using full 32-bit PCI cycles for maximum
performance. Independent buffering and a pipeline architecture provide an unsurpassed performance level with
sustained bursting. The PCI4410A device can be programmed to accept posted writes to improve bus utilization.

Function 1 of the PCI4410A device is compatible with IEEE 1394a-2000 and the latest 1394 open host controller
interface (OHCI) specifications. The chip provides the IEEE 1394 link function and is compatible with data rates of
100, 200, and 400 Mbits/s. Deep FIFOs are provided to buffer 1394 data and accommodate large host bus latencies.
The PCI4410A device provides physical write posting and a highly tuned physical data path for SBP-2 performance.
Multiple-cache line burst transfers, advanced internal arbitration, and bus-holding buffers on the PHY/Link interface
are other features that make the PCI4410A device the best-in-class 1394 OHCI solution.

The PCI4410A device provides an internally buffered zoomed-video (ZV) path. This reduces the design effort of PC
board manufacturers to add a ZV-compatible solution and ensures compliance with the CardBus loading
specifications.

Various implementation-specific functions and general-purpose inputs and outputs are provided through eight
multifunction terminals. These terminals present a system with options in PC/PCI DMA, PCI LOCK
interrupts, PC Card activity indicator LEDs, and other platform-specific signals. ACPI-compliant general-purpose
events can be programmed and controlled through the multifunction terminals, and an ACPI-compliant programming
interface is included for the general-purpose inputs and outputs.

The PCI4410A device is compliant with the latest PCI Bus Power Management Specification, and provides several
low-power modes that enable the host power system to further reduce power consumption. The PC Card (CardBus)
Controller and IEEE 1394 Host Controller Device Class Specifications required for Microsoft OnNowt power
management are supported. Furthermore, an advanced complementary metal-oxide semiconductor (CMOS)
process achieves low system power consumption.

Unused PCI4410A device inputs must be pulled to a valid logic level using a 43-kΩ resistor.

and parallel

1–1

1.2 Features

The PCI4410A device supports the following features:

• Ability to wake from D3

and D3

hot

cold

• Fully compatible with the Intel 430TX (Mobile Triton II) chipset

• A 208-pin low-profile QFP (PDV) or 209-ball MicroStar BGA ball grid array (GHK) package

• 3.3-V core logic with universal PCI interfaces compatible with 3.3-V and 5-V PCI signaling environments

• Mix-and-match 5-V/3.3-V 16-bit PC Cards and 3.3-V CardBus Cards

• Single PC Card or CardBus slot with hot insertion and removal

• Burst transfers to maximize data throughput on the PCI bus and the CardBus bus

• Parallel PCI interrupts, parallel ISA IRQ and parallel PCI interrupts, serial ISA IRQ with parallel PCI

interrupts, and serial ISA IRQ and PCI interrupts

• Serial EEPROM interface for loading subsystem ID and subsystem vendor ID

• Pipelined architecture allows greater than 130 Mbit/s sustained throughput from CardBus-to-PCI and from

PCI-to-CardBus

• Interface to parallel single-slot PC Card power-switch interfaces like the TI TPS2211 device

• Up to five general-purpose I/Os

• Programmable output select for CLKRUN

• Five PCI memory windows and two I/O windows available to the 16-bit PC Card socket

• Two I/O windows and two memory windows available to the CardBus socket

• Exchangeable Card Architecture (ExCA) compatible registers are mapped in memory and I/O space

• Compatibility with Intel 82365SL-DF and 82365SL registers

• Distributed DMA (DDMA) and PC/PCI DMA

• 16-bit DMA on the PC Card socket

• Ring indicate, SUSPEND

, PCI CLKRUN, and CardBus CLKRUN

• Socket-activity LED pins

• PCI bus lock (LOCK

)

• Advanced submicron, low-power CMOS technology

• Internal ring oscillator

• OHCI link function designed to IEEE 1394 Open Host Controller Interface (OHCI) Specification

• Implements PCI burst transfers and deep FIFOs to tolerate large host latency

• Supports physical write posting of up to three outstanding transactions

• OHCI link function is compliant with IEEE 1394-1995 and compatible with IEEE 1394a-2000

• Supports serial bus data rates of 100, 200, and 400 Mbits/s

• Provides bus-hold buffers on the PHY-Link I/F for low-cost single-capacitor isolation

1–2

1.3 Related Documents

• Advanced Configuration and Power Interface (ACPI) Specification (Revision 2.0)

• PCI Bus Power Management Interface Specification (Revision 1.1)

• PCI Bus Power Management Interface Specification for PCI to CardBus Bridges (Revision 1.1)

• PCI Local Bus Specification (Revision 2.2)

• PCI Mobile Design Guide (Revision 1.0)

• PCI14xx Implemenation Guide for D3 Wake-Up

• PC Card Standard, Release 7

• PC 98/99

• Serialized IRQ Support for PCI Systems (Revision 6)

• Serial Bus Protocol 2 (SBP-2)

• 1394 Open Host Controller Interface Specification (Revision 1.0)

• P1394 Standard for a High-Performance Serial Bus (IEEE 1394-1995)

• IEEE Standard for a High-Performance Serial Bus—Amendment 1 (IEEE 1394a-2000)

1.4 Trademarks

MicroStar BGA, OHCI-Lynx, and TI are trademarks of Texas Instruments.
Microsoft OnNow is a trademark of Microsoft Corporation.
Intel is a trademark of Intel Corporation.
Maxim is a trademark of Maxim Integrated Products, Inc.
Other trademarks are the property of their respective owners.

1.5 Ordering Information

ORDERING NUMBER NAME VOLTAGE PACKAGE

PCI4410A PC Card controller 3.3-V, 5-V tolerant I/Os 208-pin LQFP

209-ball PBGA

1–3

1–4

2 Terminal Descriptions

The PCI4410A device is packaged in either a 209-ball GHK MicroStar BGAt or a 208-terminal PDV package. The
PCI4410A device is a single-socket CardBus bridge with integrated OHCI link. Figure 2–1 is a terminal diagram of
the PDV package with PCI-to-CardBus signal names. Figure 2–2 is a terminal diagram of the PDV package with
PCI-to-PC Card signal names. Figure 2–3 is a terminal diagram of the GHK package.

CCLK

CDEVSEL

CGNT

CSTOP

CPERR

CBLOCK

VCC

CPAR

CRSVD

CC/BE1

CAD16

CAD14

CAD15

CAD12

GND

CAD13

CAD11

CAD10

VCCCB

CAD9

CC/BE0

CAD8

VCC

CAD7

CRSVD

CAD5

CAD6

CAD3

CAD4

CAD1

GND

CAD2

CAD0

CCD1

VCCD1

VCCD0

ZV_PCLK

ZV_SDATA

ZV_LRCLK

ZV_MCLK

ZV_UV(7)

VCC

ZV_SCLK

ZV_UV(5)

ZV_UV(6)

ZV_UV(3)

GND

ZV_UV(4)

ZV_UV(1)

ZV_UV(2)

ZV_UV(0)

ZV_Y(7)

CTRDY

CIRDY

CFRAME

CC/BE2

CAD17

GND
CAD18
CAD19

CVS2

CAD20

CRST
CAD21
CAD22

VCC

CREQ

CAD23

CC/BE3
VCCCB

CAD24
CAD25
CAD26

GND

CVS1

CINT

CSERR

CAUDIO
CSTSCHG
CCLKRUN

CCD2

VCC
CAD27
CAD28
CAD29
CAD30

CRSVD

CAD31

LPS

PHY_LREQ

VCC

PHY_CLK
PHY_CTL(0)
PHY_CTL(1)

LINKON

PHY_DATA0

VCCL

PHY_DATA1

GND
PHY_DATA2
PHY_DATA3
PHY_DATA4
PHY_DATA5
PHY_DATA6

156

155

154

153

152

151

150

149

148

147

146

145

144

143
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208

123456789101112131415161718192021

142

141

140

119

118

139

138

137

136

135

134

133

132

131

130

129

128

127

126

125

124

123

2324252627282930313233343536373839404142434445464748495051

22

122

121

120

117

111

116

115

114

113

112

110

109

108

107

106

105

ZV_Y(6)

104

ZV_Y(5)

103

ZV_Y(4)

102

ZV_Y(3)

101

GND

100

ZV_Y(2)

99

ZV_Y(1)

98

ZV_Y(0)

97

ZV_VSYNC

96

ZV_HREF

95

RSVD

94

INTB

93

INTA

92

VCC

91

LED_SKT

90

RSVD

89

VPPD1

88

VPPD0

87

SUSPEND

86

MFUNC6

85

MFUNC5

84

MFUNC4

83

GRST

82

MFUNC3

81

MFUNC2

80

VCCI

79

SPKROUT

78

MFUNC1

77

MFUNC0

76

RI_OUT/PME

75

GND

74

AD0

73

AD1

72

AD2

71

AD3

70

AD4

69

AD5

68

AD6

67

VCC

66

AD7

65

C/BE0

64

AD8

63

AD9

62

AD10

61

VCCP

60

AD11

59

GND

58

AD12

57

AD13

56

AD14

55

AD15

54

C/BE1

53

52

PHY_RSVD

PHY_RSVD

PHY_DATA7

GND

PHY_RSVD

PHY_RSVD

PHY_RSVD

PHY_RSVD

PHY_RSVD

PHY_RSVD

PHY_RSVD

PHY_RSVD

PHY_RSVD

PHY_RSVD

GNT

REQ

AD31

PHY_RSVD

AD30

AD29

GND

AD28

AD27

AD26

AD25

AD24

C/BE3

IDSEL

VCC

AD23

AD22

AD21

AD20

VCCP

PRST

PCLK

GND

VCC

Figure 2–1. PCI-to-CardBus Terminal Diagram

AD19

AD18

AD17

AD16

C/BE2

FRAME

IRDY

VCC

TRDY

DEVSEL

STOP

PERR

SERR

PAR

2–1

ADDR16

ADDR21WEADDR20

ADDR14

ADDR19

VCC

ADDR13

ADDR18

ADDR8

ADDR17

ADDR9

IOWR

ADDR11

GND

IORDOECE2

VCCCB

ADDR10

CE1

DATA15

VCC

DATA7

DATA14

DATA6

DATA13

DATA5

DATA12

DATA4

GND

DATA11

DATA3

CD1

VCCD1

VCCD0

ZV_PCLK

ZV_SDATA

ZV_LRCLKZV_MCLK

ZV_UV(7)

VCC

ZV_SCLK

ZV_UV(5)

ZV_UV(6)

ZV_UV(3)

GND

ZV_UV(4)

ZV_UV(1)

ZV_UV(2)

ZV_UV(0)

ZV_Y(7)

ADDR22
ADDR15
ADDR23
ADDR12
ADDR24

GND

ADDR7

ADDR25

VS2
ADDR6
RESET
ADDR5
ADDR4

VCC

INPACK

ADDR3

REG
VCCCB
ADDR2
ADDR1
ADDR0

GND

VS1

READY(IREQ)

WAIT

BVD2(SPKR)

BVD1(STSCHG/RI)

WP(IOIS16)

CD2

VCC

DATA0
DATA8
DATA1
DATA9
DATA2

DATA10

LPS

PHY_LREQ

VCC

PHY_CLK
PHY_CTL(0)
PHY_CTL(1)

LINKON

PHY_DATA0

VCCL

PHY_DATA1

GND
PHY_DATA2
PHY_DATA3
PHY_DATA4
PHY_DATA5
PHY_DATA6

156

155

154

153

152

151

150

149
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208

123456789101112131415

148

147

146

119

118

145

144

143

142

141

140

139

138

137

136

135

134

133

132

131

130

129

128

127

126

125

124

123

1718192021222324252627282930313233343536373839404142434445464748495051

16

122

121

120

117

111

116

115

114

113

112

110

109

108

107

106

105

ZV_Y(6)

104

ZV_Y(5)

103

ZV_Y(4)

102

ZV_Y(3)

101

GND

100

ZV_Y(2)

99

ZV_Y(1)

98

ZV_Y(0)

97

ZV_VSYNC

96

ZV_HREF

95

RSVD

94

INTB

93

INTA

92

VCC

91

LED_SKT

90

RSVD

89

VPPD1

88

VPPD0

87

SUSPEND

86

MFUNC6

85

MFUNC5

84

MFUNC4

83

GRST

82

MFUNC3

81

MFUNC2

80

VCCI

79

SPKROUT

78

MFUNC1

77

MFUNC0

76

RI_OUT/PME

75

GND

74

AD0

73

AD1

72

AD2

71

AD3

70

AD4

69

AD5

68

AD6

67

VCC

66

AD7

65

C/BE0

64

AD8

63

AD9

62

AD10

61

VCCP

60

AD11

59

GND

58

AD12

57

AD13

56

AD14

55

AD15

54

C/BE1

53

52

VCC

PHY_RSVD

PHY_RSVD

PHY_DATA7

GND

PHY_RSVD

PHY_RSVD

PHY_RSVD

PHY_RSVD

PHY_RSVD

PHY_RSVD

PHY_RSVD

PHY_RSVD

PHY_RSVD

PHY_RSVD

GNT

REQ

AD31

PHY_RSVD

AD30

AD29

GND

AD28

AD27

AD26

AD25

AD24

C/BE3

IDSEL

VCC

AD23

AD22

AD21

AD20

VCCP

PRST

PCLK

GND

AD19

AD18

AD17

AD16

C/BE2

Figure 2–2. PCI-to-PC Card (16-Bit) Terminal Diagram

IRDY

FRAME

VCC

TRDY

DEVSEL

STOP

PERR

SERR

PAR

2–2

W
V
U
T
R
P
N
M
L
K
J
H
G
F
E
D
C
B
A

1

3

2

4

75

6

9

810

12

13141511

16

18

1917

Figure 2–3. MicroStar BGAt Ball Diagram

Table 2–1 shows the terminal assignments for the 208-terminal PDV CardBus and 16-bit PC Card signal names.
Table 2–2 shows the terminal assignments for the 209-ball GHK CardBus and 16-bit PC Card signal names.
Table 2–3 shows the CardBus PC Card signal names, sorted alphabetically to the GHK/PDV terminal numbers.
Table 2–4 shows the 16-bit PC Card signal names, sorted alphabetically to the GHK/PDV terminal numbers.

2–3

Table 2–1. CardBus and 16-Bit PC Card Signal Names by PDV Terminal Number

TERM.

NO.

1 PHY_DATA7 PHY_DATA7 44 FRAME FRAME 87 VPPD0 VPPD0
2 PHY_RSVD PHY_RSVD 45 IRDY IRDY 88 VPPD1 VPPD1
3 PHY_RSVD PHY_RSVD 46 V
4 PHY_RSVD PHY_RSVD 47 TRDY TRDY 90 LED_SKT LED_SKT
5 PHY_RSVD PHY_RSVD 48 DEVSEL DEVSEL 91 V
6 GND GND 49 STOP STOP 92 INTA INTA
7 PHY_RSVD PHY_RSVD 50 PERR PERR 93 INTB INTB
8 PHY_RSVD PHY_RSVD 51 SERR SERR 94 RSVD RSVD

9 PHY_RSVD PHY_RSVD 52 PAR PAR 95 ZV_HREF ZV_HREF
10 PHY_RSVD PHY_RSVD 53 C/BE1 C/BE1 96 ZV_VSYNC ZV_VSYNC
11 PHY_RSVD PHY_RSVD 54 AD15 AD15 97 ZV_Y(0) ZV_Y(0)
12 PHY_RSVD PHY_RSVD 55 AD14 AD14 98 ZV_Y(1) ZV_Y(1)
13 PHY_RSVD PHY_RSVD 56 AD13 AD13 99 ZV_Y(2) ZV_Y(2)
14 V
15 PHY_RSVD PHY_RSVD 58 GND GND 101 ZV_Y(3) ZV_Y(3)
16 PHY_RSVD PHY_RSVD 59 AD11 AD11 102 ZV_Y(4) ZV_Y(4)
17 REQ REQ 60 V
18 GNT GNT 61 AD10 AD10 104 ZV_Y(6) ZV_Y(6)
19 AD31 AD31 62 AD9 AD9 105 ZV_Y(7) ZV_Y(7)
20 AD30 AD30 63 AD8 AD8 106 ZV_UV(0) ZV_UV(0)
21 AD29 AD29 64 C/BE0 C/BE0 107 ZV_UV(2) ZV_UV(2)
22 GND GND 65 AD7 AD7 108 ZV_UV(1) ZV_UV(1)
23 AD28 AD28 66 V
24 AD27 AD27 67 AD6 AD6 110 GND GND
25 AD26 AD26 68 AD5 AD5 111 ZV_UV(3) ZV_UV(3)
26 AD25 AD25 69 AD4 AD4 112 ZV_UV(6) ZV_UV(6)
27 AD24 AD24 70 AD3 AD3 113 ZV_UV(5) ZV_UV(5)
28 C/BE3 C/BE3 71 AD2 AD2 114 ZV_SCLK ZV_SCLK
29 IDSEL IDSEL 72 AD1 AD1 115 V
30 V
31 AD23 AD23 74 GND GND 117 ZV_MCLK ZV_MCLK
32 AD22 AD22 75 RI_OUT/PME RI_OUT/PME 118 ZV_LRCLK ZV_LRCLK
33 AD21 AD21 76 MFUNC0 MFUNC0 119 ZV_SDATA ZV_SDATA
34 V
35 AD20 AD20 78 SPKROUT SPKROUT 121 VCCD0 VCCD0
36 PRST PRST 79 V
37 PCLK PCLK 80 MFUNC2 MFUNC2 123 CCD1 CD1
38 GND GND 81 MFUNC3 MFUNC3 124 CAD0 DATA3
39 AD19 AD19 82 GRST GRST 125 CAD2 DATA11
40 AD18 AD18 83 MFUNC4 MFUNC4 126 GND GND
41 AD17 AD17 84 MFUNC5 MFUNC5 127 CAD1 DATA4
42 AD16 AD16 85 MFUNC6 MFUNC6 128 CAD4 DATA12
43 C/BE2 C/BE2 86 SUSPEND SUSPEND 129 CAD3 DATA5

SIGNAL NAME

CARDBUS 16-BIT

CC

CC

CCP

V

V

V

CC

CC

CCP

TERM.

NO.

57 AD12 AD12 100 GND GND

73 AD0 AD0 116 ZV_UV(7) ZV_UV(7)

77 MFUNC1 MFUNC1 120 ZV_PCLK ZV_PCLK

SIGNAL NAME

CARDBUS 16-BIT

CC

CCP

CC

CCI

V

V

V

V

CC

CCP

CC

CCI

TERM.

NO.

89 RSVD RSVD

103 ZV_Y(5) ZV_Y(5)

109 ZV_UV(4) ZV_UV(4)

122 VCCD1 VCCD1

SIGNAL NAME

CARDBUS 16-BIT

CC

CC

V

CC

V

CC

2–4

Table 2–1. CardBus and 16-Bit PC Card Signal Names by PDV Terminal Number (Continued)

TERM.

NO.

130 CAD6 DATA13 157 CTRDY ADDR22 184 CCLKRUN WP(IOIS16)
131 CAD5 DATA6 158 CIRDY ADDR15 185 CCD2 CD2
132 CRSVD DATA14 159 CFRAME ADDR23 186 V
133 CAD7 DATA7 160 CC/BE2 ADDR12 187 CAD27 DATA0
134 V
135 CAD8 DATA15 162 GND GND 189 CAD29 DATA1
136 CC/BE0 CE1 163 CAD18 ADDR7 190 CAD30 DATA9
137 CAD9 ADDR10 164 CAD19 ADDR25 191 CRSVD DATA2
138 V
139 CAD10 CE2 166 CAD20 ADDR6 193 LPS LPS
140 CAD11 OE 167 CRST RESET 194 PHY_LREQ PHY_LREQ
141 CAD13 IORD 168 CAD21 ADDR5 195 V
142 GND GND 169 CAD22 ADDR4 196 PHY_CLK PHY_CLK
143 CAD12 ADDR11 170 V
144 CAD15 IOWR 171 CREQ INPACK 198 PHY_CTL(1) PHY_CTL(1)
145 CAD14 ADDR9 172 CAD23 ADDR3 199 LINKON LINKON
146 CAD16 ADDR17 173 CC/BE3 REG 200 PHY_DATA0 PHY_DATA0
147 CC/BE1 ADDR8 174 V
148 CRSVD ADDR18 175 CAD24 ADDR2 202 PHY_DATA1 PHY_DATA1
149 CPAR ADDR13 176 CAD25 ADDR1 203 GND GND
150 V
151 CBLOCK ADDR19 178 GND GND 205 PHY_DATA3 PHY_DATA3
152 CPERR ADDR14 179 CVS1 VS1 206 PHY_DATA4 PHY_DATA4
153 CSTOP ADDR20 180 CINT READY(IREQ) 207 PHY_DATA5 PHY_DATA5
154 CGNT WE 181 CSERR WAIT 208 PHY_DATA6 PHY_DATA6
155 CDEVSEL ADDR21 182 CAUDIO BVD2(SPKR)

156 CCLK ADDR16 183 CSTSCHG

SIGNAL NAME

CARDBUS 16-BIT

CC

CCCB

CC

V

CC

V

CCCB

V

CC

TERM.

NO.

161 CAD17 ADDR24 188 CAD28 DATA8

165 CVS2 VS2 192 CAD31 DATA10

177 CAD26 ADDR0 204 PHY_DATA2 PHY_DATA2

SIGNAL NAME

CARDBUS 16-BIT

CC

CCCB

V

CC

V

CCCB

BVD1
(STSCHG

/RI)

TERM.

NO.

197 PHY_CTL(0) PHY_CTL(0)

201 V

SIGNAL NAME

CARDBUS 16-BIT

CC

CC

CCL

V

V

V

CC

CC

CCL

2–5

Table 2–2. CardBus and 16-Bit PC Card Signal Names by GHK Terminal Number

TERM

TERM

TERM

TERM.

.

NO.

A4 PHY_DATA6 PHY_DATA6 E8 PHY_LREQ PHY_LREQ H14 CAD13 IORD
A5 GND GND E9 CAD29 DATA1 H15 GND GND

A6 LINKON LINKON E10 CSTSCHG
A7 V

A8 CAD30 DATA9 E12 CREQ INPACK H19 V
A9 CCD2 CD2 E13 CVS2 VS2 J1 AD31 AD31

A10 CINT READY(IREQ) E14 CFRAME ADDR23 J2 AD30 AD30
A11 CAD24 ADDR2 E17 CDEVSEL ADDR21 J3 AD29 AD29
A12 V
A13 V
A14 CAD20 ADDR6 F1 PHY_RSVD PHY_RSVD J14 CC/BE0 CE1
A15 GND GND F2 PHY_RSVD PHY_RSVD J15 CAD9 ADDR10
A16 CTRDY ADDR22 F3 PHY_RSVD PHY_RSVD J17 CAD8 DATA15

B5 PHY_DATA3 PHY_DATA3 F5 PHY_RSVD PHY_RSVD J18 V
B6 PHY_DATA0 PHY_DATA0 F6 PHY_DATA2 PHY_DATA2 J19 CAD7 DATA7
B7 PHY_CLK PHY_CLK F7 PHY_CTL(1) PHY_CTL(1) K1 AD27 AD27
B8 CRSVD DATA2 F8 LPS LPS K2 AD26 AD26
B9 V

B10 CSERR WAIT F10 CCLKRUN WP(IOIS16) K5 AD24 AD24
B11 CAD25 ADDR1 F11 CVS1 VS1 K6 C/BE3 C/BE3
B12 CC/BE3 REG F12 CRST RESET K14 CRSVD DATA14
B13 CAD22 ADDR4 F13 CC/BE2 ADDR12 K15 CAD5 DATA6
B14 CAD19 ADDR25 F14 CPERR ADDR14 K17 CAD6 DATA13
B15 CAD17 ADDR24 F15 CGNT WE K18 CAD3 DATA5

C5 PHY_DATA5 PHY_DATA5 F17 V
C6 PHY_DATA1 PHY_DATA1 F18 CRSVD ADDR18 L1 IDSEL IDSEL
C7 PHY_CTL(0) PHY_CTL(0) F19 CC/BE1 ADDR8 L2 V
C8 CAD31 DATA10 G1 V

C9 CAD27 DATA0 G2 PHY_RSVD PHY_RSVD L5 AD21 AD21
C10 CAUDIO BVD2(SPKR) G3 PHY_RSVD PHY_RSVD L6 AD22 AD22
C11 CAD26 ADDR0 G5 PHY_RSVD PHY_RSVD L14 CAD1 DATA4
C12 CAD23 ADDR3 G6 PHY_RSVD PHY_RSVD L15 GND GND
C13 CAD21 ADDR5 G14 CAD16 ADDR17 L17 CAD2 DATA11
C14 CAD18 ADDR7 G15 CPAR ADDR13 L18 CAD0 DATA3
C15 CIRDY ADDR15 G17 CAD14 ADDR9 L19 CCD1 CD1

D1 PHY_DATA7 PHY_DATA7 G18 CAD15 IOWR M1 V
D19 CCLK ADDR16 G19 CAD12 ADDR11 M2 AD20 AD20

E1 GND GND H1 GNT GNT M3 PRST PRST

E2 PHY_RSVD PHY_RSVD H2 REQ REQ M5 GND GND

E3 PHY_RSVD PHY_RSVD H3 PHY_RSVD PHY_RSVD M6 PCLK PCLK

E6 PHY_DATA4 PHY_DATA4 H5 PHY_RSVD PHY_RSVD M14 V

E7 V

SIGNAL NAME

CARDBUS 16-BIT

CC

CCCB
CC

CC

CCL

V

CC

V

CCCB

V

CC

V

CC

V

CCL

TERM.

.

NO.

E11 GND GND H18 CAD10 CE2

E18 CSTOP ADDR20 J5 GND GND
E19 CBLOCK ADDR19 J6 AD28 AD28

F9 CAD28 DATA8 K3 AD25 AD25

H6 PHY_RSVD PHY_RSVD M15 ZV_SDATA ZV_SDATA

SIGNAL NAME

CARDBUS 16-BIT

BVD1
(STSCHG

CC

CC

V

CC

V

CC

/RI)

TERM.

.

NO.

H17 CAD11 OE

K19 CAD4 DATA12

L3 AD23 AD23

SIGNAL NAME

CARDBUS 16-BIT

CCCB

CC

CC

CCP

CC

V

CCCB

V

CC

V

CC

V

CCP

V

CC

2–6

Table 2–2. CardBus and 16-Bit PC Card Signal Names by GHK Terminal Number (Continued)

TERM

TERM

TERM

TERM.

.

NO.

M17 ZV_PCLK ZV_PCLK P18 ZV_UV(6) ZV_UV(6) U14 ZV_Y(1) ZV_Y(1)
M18 VCCD0 VCCD0 P19 ZV_SCLK ZV_SCLK U15 ZV_Y(5) ZV_Y(5)
M19 VCCD1 VCCD1 R1 TRDY TRDY V5 AD12 AD12

N1 AD19 AD19 R2 STOP STOP V6 V
N2 AD18 AD18 R3 SERR SERR V7 AD7 AD7
N3 AD17 AD17 R6 AD14 AD14 V8 AD4 AD4
N5 IRDY IRDY R7 AD10 AD10 V9 AD1 AD1

N6 AD16 AD16 R8 AD6 AD6 V10 MFUNC1 MFUNC1
N14 ZV_UV(1) ZV_UV(1) R9 GND GND V11 GRST GRST
N15 ZV_UV(5) ZV_UV(5) R10 V
N17 ZV_UV(7) ZV_UV(7) R11 MFUNC6 MFUNC6 V13 INTA INTA
N18 ZV_MCLK ZV_MCLK R12 LED_SKT LED_SKT V14 ZV_VSYNC ZV_VSYNC
N19 ZV_LRCLK ZV_LRCLK R13 ZV_Y(0) ZV_Y(0) V15 ZV_Y(3) ZV_Y(3)

P1 C/BE2 C/BE2 R14 ZV_Y(4) ZV_Y(4) W4 C/BE1 C/BE1

P2 FRAME FRAME R17 ZV_UV(0) ZV_UV(0) W5 GND GND

P3 V

P5 PERR PERR R19 GND GND W7 V

P6 DEVSEL DEVSEL T1 PAR PAR W8 AD3 AD3

P7 AD13 AD13 T19 ZV_Y(7) ZV_Y(7) W9 AD2 AD2

P8 AD8 AD8 U5 AD15 AD15 W10 MFUNC0 MFUNC0

P9 RI_OUT/PME RI_OUT/PME U6 AD11 AD11 W11 MFUNC3 MFUNC3
P10 MFUNC2 MFUNC2 U7 C/BE0 C/BE0 W12 SUSPEND SUSPEND
P11 MFUNC5 MFUNC5 U8 AD5 AD5 W13 V
P12 RSVD RSVD U9 AD0 AD0 W14 ZV_HREF ZV_HREF
P13 RSVD RSVD U10 SPKROUT SPKROUT W15 ZV_Y(2) ZV_Y(2)
P14 GND GND U11 MFUNC4 MFUNC4 W16 ZV_Y(6) ZV_Y(6)
P15 ZV_UV(2) ZV_UV(2) U12 VPPD1 VPPD1
P17 ZV_UV(3) ZV_UV(3) U13 INTB INTB

SIGNAL NAME

CARDBUS 16-BIT

CC

V

CC

TERM.

.

NO.

R18 ZV_UV(4) ZV_UV(4) W6 AD9 AD9

SIGNAL NAME

CARDBUS 16-BIT

CCI

V

CCI

TERM.

.

NO.

V12 VPPD0 VPPD0

SIGNAL NAME

CARDBUS 16-BIT

CCP

CC

CC

V

V

V

CCP

CC

CC

2–7

Table 2–3. CardBus PC Card Signal Names Sorted Alphabetically to GHK/PDV Terminal Number

SIGNAL NAME

AD0 73 U9 CAD11 140 H17 CRST 167 F12 PHY_CLK 196 B7
AD1 72 V9 CAD12 143 G19 CRSVD 132 K14 PHY_CTL(0) 197 C7
AD2 71 W9 CAD13 141 H14 CRSVD 148 F18 PHY_CTL(1) 198 F7
AD3 70 W8 CAD14 145 G17 CRSVD 191 B8 PHY_DATA0 200 B6
AD4 69 V8 CAD15 144 G18 CSERR 181 B10 PHY_DATA1 202 C6
AD5 68 U8 CAD16 146 G14 CSTOP 153 E18 PHY_DATA2 204 F6
AD6 67 R8 CAD17 161 B15 CSTSCHG 183 E10 PHY_DATA3 205 B5
AD7 65 V7 CAD18 163 C14 CTRDY 157 A16 PHY_DATA4 206 E6
AD8 63 P8 CAD19 164 B14 CVS1 179 F11 PHY_DATA5 207 C5
AD9 62 W6 CAD20 166 A14 CVS2 165 E13 PHY_DATA6 208 A4
AD10 61 R7 CAD21 168 C13 DEVSEL 48 P6 PHY_DATA7 1 D1
AD11 59 U6 CAD22 169 B13 FRAME 44 P2 PHY_LREQ 194 E8
AD12 57 V5 CAD23 172 C12 GND 6 E1 PHY_RSVD 2 E3
AD13 56 P7 CAD24 175 A11 GND 22 J5 PHY_RSVD 3 F5
AD14 55 R6 CAD25 176 B11 GND 38 M5 PHY_RSVD 4 G6
AD15 54 U5 CAD26 177 C11 GND 58 W5 PHY_RSVD 5 E2
AD16 42 N6 CAD27 187 C9 GND 74 R9 PHY_RSVD 7 F3
AD17 41 N3 CAD28 188 F9 GND 100 P14 PHY_RSVD 8 F2
AD18 40 N2 CAD29 189 E9 GND 110 R19 PHY_RSVD 9 G5
AD19 39 N1 CAD30 190 A8 GND 126 L15 PHY_RSVD 10 F1
AD20 35 M2 CAD31 192 C8 GND 142 H15 PHY_RSVD 11 H6
AD21 33 L5 CAUDIO 182 C10 GND 162 A15 PHY_RSVD 12 G3
AD22 32 L6 C/BE0 64 U7 GND 178 E11 PHY_RSVD 13 G2
AD23 31 L3 C/BE1 53 W4 GND 203 A5 PHY_RSVD 15 H5
AD24 27 K5 C/BE2 43 P1 GNT 18 H1 PHY_RSVD 16 H3
AD25 26 K3 C/BE3 28 K6 GRST 82 V11 PRST 36 M3
AD26 25 K2 CBLOCK 151 E19 IDSEL 29 L1 REQ 17 H2
AD27 24 K1 CC/BE0 136 J14 INTA 92 V13 RI_OUT/PME 75 P9
AD28 23 J6 CC/BE1 147 F19 INTB 93 U13 RSVD 89 P12
AD29 21 J3 CC/BE2 160 F13 IRDY 45 N5 RSVD 94 P13
AD30 20 J2 CC/BE3 173 B12 LED_SKT 90 R12 SERR 51 R3
AD31 19 J1 CCD1 123 L19 LINKON 199 A6 SPKROUT 78 U10
CAD0 124 L18 CCD2 185 A9 LPS 193 F8 STOP 49 R2
CAD1 127 L14 CCLK 156 D19 MFUNC0 76 W10 SUSPEND 86 W12
CAD2 125 L17 CCLKRUN 184 F10 MFUNC1 77 V10 TRDY 47 R1
CAD3 129 K18 CDEVSEL 155 E17 MFUNC2 80 P10 V
CAD4 128 K19 CFRAME 159 E14 MFUNC3 81 W11 V
CAD5 131 K15 CGNT 154 F15 MFUNC4 83 U11 V
CAD6 130 K17 CINT 180 A10 MFUNC5 84 P11 V
CAD7 133 J19 CIRDY 158 C15 MFUNC6 85 R11 V
CAD8 135 J17 CPAR 149 G15 PAR 52 T1 V
CAD9 137 J15 CPERR 152 F14 PCLK 37 M6 V
CAD10 139 H18 CREQ 171 E12 PERR 50 P5 V

TERM. NO.

PDV GHK

SIGNAL NAME

TERM. NO.

PDV GHK

SIGNAL NAME

TERM. NO.

PDV GHK

SIGNAL NAME

CC
CC
CC
CC
CC
CC
CC
CC

TERM. NO.

PDV GHK

14 G1
30 L2
46 P3
66 W7

91 W13
115 M14
134 J18
150 F17

2–8

Table 2–3. CardBus PC Card Signal Names Sorted Alphabetically to GHK/PDV Terminal Number

(Continued)

SIGNAL NAME

V

CC

V

CC

V

CC

V

CCCB

V

CCCB

VCCD0 121 M18 ZV_LRCLK 118 N19 ZV_UV(4) 109 R18 ZV_Y(4) 102 R14
VCCD1 122 M19 ZV_MCLK 117 N18 ZV_UV(5) 113 N15 ZV_Y(5) 103 U15
V

CCI

V

CCL

TERM. NO.

PDV GHK

170 A13 V
186 B9 V
195 A7 VPPD0 87 V12 ZV_UV(1) 108 N14 ZV_Y(1) 98 U14
138 H19 VPPD1 88 U12 ZV_UV(2) 107 P15 ZV_Y(2) 99 W15
174 A12 ZV_HREF 95 W14 ZV_UV(3) 111 P17 ZV_Y(3) 101 V15

79 R10 ZV_PCLK 120 M17 ZV_UV(6) 112 P18 ZV_Y(6) 104 W16

201 E7 ZV_SCLK 114 P19 ZV_UV(7) 116 N17 ZV_Y(7) 105 T19

SIGNAL NAME

CCP
CCP

TERM. NO.

PDV GHK

34 M1 ZV_SDATA 119 M15 ZV_VSYNC 96 V14
60 V6 ZV_UV(0) 106 R17 ZV_Y(0) 97 R13

SIGNAL NAME

TERM. NO.

PDV GHK

SIGNAL NAME

TERM. NO.

PDV GHK

2–9

Table 2–4. 16-Bit PC Card Signal Names Sorted Alphabetically to GHK/PDV Terminal Number

SIGNAL NAME

AD0 73 U9 ADDR10 137 J15 DEVSEL 48 P6 PHY_DATA2 204 F6
AD1 72 V9 ADDR11 143 G19 FRAME 44 P2 PHY_DATA3 205 B5
AD2 71 W9 ADDR12 160 F13 GND 6 E1 PHY_DATA4 206 E6
AD3 70 W8 ADDR13 149 G15 GND 22 J5 PHY_DATA5 207 C5
AD4 69 V8 ADDR14 152 F14 GND 38 M5 PHY_DATA6 208 A4
AD5 68 U8 ADDR15 158 C15 GND 58 W5 PHY_DATA7 1 D1
AD6 67 R8 ADDR16 156 D19 GND 74 R9 PHY_LREQ 194 E8
AD7 65 V7 ADDR17 146 G14 GND 100 P14 PHY_RSVD 2 E3
AD8 63 P8 ADDR18 148 F18 GND 110 R19 PHY_RSVD 3 F5
AD9 62 W6 ADDR19 151 E19 GND 126 L15 PHY_RSVD 4 G6
AD10 61 R7 ADDR20 153 E18 GND 142 H15 PHY_RSVD 5 E2
AD11 59 U6 ADDR21 155 E17 GND 162 A15 PHY_RSVD 7 F3
AD12 57 V5 ADDR22 157 A16 GND 178 E11 PHY_RSVD 8 F2
AD13 56 P7 ADDR23 159 E14 GND 203 A5 PHY_RSVD 9 G5
AD14 55 R6 ADDR24 161 B15 GNT 18 H1 PHY_RSVD 10 F1
AD15 54 U5 ADDR25 164 B14 GRST 82 V11 PHY_RSVD 11 H6

AD16 42 N6
AD17 41 N3 BVD2(SPKR) 182 C10 INPACK 171 E12 PHY_RSVD 13 G2

AD18 40 N2 C/BE0 64 U7 INTA 92 V13 PHY_RSVD 15 H5
AD19 39 N1 C/BE1 53 W4 INTB 93 U13 PHY_RSVD 16 H3
AD20 35 M2 C/BE2 43 P1 IRDY 45 N5 PRST 36 M3
AD21 33 L5 C/BE3 28 K6 IORD 141 H14 READY(IREQ) 180 A10
AD22 32 L6 CD1 123 L19 IOWR 144 G18 REG 173 B12
AD23 31 L3 CD2 185 A9 LED_SKT 90 R12 REQ 17 H2
AD24 27 K5 CE1 136 J14 LINKON 199 A6 RESET 167 F12
AD25 26 K3 CE2 139 H18 LPS 193 F8 RI_OUT/PME 75 P9
AD26 25 K2 DATA0 187 C9 MFUNC0 76 W10 RSVD 89 P12
AD27 24 K1 DATA1 189 E9 MFUNC1 77 V10 RSVD 94 P13
AD28 23 J6 DATA2 191 B8 MFUNC2 80 P10 SERR 51 R3
AD29 21 J3 DATA3 124 L18 MFUNC3 81 W11 SPKROUT 78 U10
AD30 20 J2 DATA4 127 L14 MFUNC4 83 U11 STOP 49 R2
AD31 19 J1 DATA5 129 K18 MFUNC5 84 P11 SUSPEND 86 W12
ADDR0 177 C11 DATA6 131 K15 MFUNC6 85 R11 TRDY 47 R1
ADDR1 176 B11 DATA7 133 J19 OE 140 H17 V
ADDR2 175 A11 DATA8 188 F9 PAR 52 T1 V
ADDR3 172 C12 DATA9 190 A8 PCLK 37 M6 V
ADDR4 169 B13 DATA10 192 C8 PERR 50 P5 V
ADDR5 168 C13 DATA11 125 L17 PHY_CLK 196 B7 V
ADDR6 166 A14 DATA12 128 K19 PHY_CTL(0) 197 C7 V
ADDR7 163 C14 DATA13 130 K17 PHY_CTL(1) 198 F7 V
ADDR8 147 F19 DATA14 132 K14 PHY_DATA0 200 B6 V
ADDR9 145 G17 DATA15 135 J17 PHY_DATA1 202 C6 V

TERM. NO.

PDV GHK

SIGNAL NAME

BVD1
(STSCHG

/RI)

TERM. NO.

PDV GHK

183 E10 IDSEL 29 L1 PHY_RSVD 12 G3

SIGNAL NAME

TERM. NO.

PDV GHK

SIGNAL NAME

CC
CC
CC
CC
CC
CC
CC
CC
CC

TERM. NO.

PDV GHK

14 G1

30 L2

46 P3

66 W7

91 W13
115 M14
134 J18
150 F17
170 A13

2–10

Table 2–4. 16-Bit PC Card Signal Names Sorted Alphabetically to GHK/PDV Terminal Number (Continued)

SIGNAL NAME

V

CC

V

CC

V

CCCB

V

CCCB

VCCD0 121 M18 WAIT 181 B10 ZV_UV(1) 108 N14 ZV_Y(2) 99 W15
VCCD1 122 M19 WE 154 F15 ZV_UV(2) 107 P15 ZV_Y(3) 101 V15
V

CCI

V

CCL

V

CCP

V

CCP

TERM. NO.

PDV GHK

186 B9 VPPD0 87 V12 ZV_PCLK 120 M17 ZV_UV(7) 116 N17
195 A7 VPPD1 88 U12 ZV_SCLK 114 P19 ZV_VSYNC 96 V14
138 H19 VS1 179 F11 ZV_SDATA 119 M15 ZV_Y(0) 97 R13
174 A12 VS2 165 E13 ZV_UV(0) 106 R17 ZV_Y(1) 98 U14

79 R10 WP(IOIS16) 184 F10 ZV_UV(3) 111 P17 ZV_Y(4) 102 R14

201 E7 ZV_HREF 95 W14 ZV_UV(4) 109 R18 ZV_Y(5) 103 U15

34 M1 ZV_LRCLK 118 N19 ZV_UV(5) 113 N15 ZV_Y(6) 104 W16
60 V6 ZV_MCLK 117 N18 ZV_UV(6) 112 P18 ZV_Y(7) 105 T19

SIGNAL NAME

TERM. NO.

PDV GHK

SIGNAL NAME

TERM. NO.

PDV GHK

SIGNAL NAME

TERM. NO.

PDV GHK

2–11

The terminals are grouped in tables by functionality, such as PCI system function and power-supply function (see

DESCRIPTION

I/O

DESCRIPTION

Table 2–5 through Table 2–17). The terminal numbers also are listed for convenient reference.

Table 2–5. Power-Supply Terminals

TERMINAL

NAME

GND

V

CC

V

CCCB
V

CCI

V

CCL

V

CCP

NUMBER

PDV GHK

6, 22, 38, 58, 74,

100, 110, 126,
142, 162, 178,

203

14, 30, 46, 66,

91, 115, 134,

150, 170, 186,

195

138, 174 A12, H19 Clamp voltage for PC Card interface. Matches card signaling environment, 5 V or 3.3 V.

79 R10 Clamp voltage for miscellaneous I/O signals (MFUNC, GRST, and SUSPEND)

201 E7 Clamp voltage for 1394 link function

34, 60 M1, V6

A5, A15, E1, E11,
H15, J5, L15, M5,

P14, R9, W5

A7, A13, B9, F17,
G1, J18, L2, M14,

P3, W7, W13

Device ground terminals

Power-supply terminal for core logic (3.3 V)

Clamp voltage for PCI interface, ZV interface, SPKROUT, INTA, INTB LED_SKT,
VCCD0

, VCCD1, VPPD0, VPPD1

DESCRIPTION

Table 2–6. PC Card Power-Switch Terminals

TERMINAL

NAME

VCCD0
VCCD1

VPPD0
VPPD18788

PDV GHK

121
122

NUMBER

M18
M19

V12
U12

I/O DESCRIPTION

O Logic controls to the TPS2211 PC Card power-switch interface to control AVCC

O Logic controls to the TPS2211 PC Card power-switch interface to control AVPP

TERMINAL

NAME

GRST 82 V11 I

PCLK 37 M6 I

PRST

2–12

NUMBER

PDV GHK

36 M3 I

Table 2–7. PCI System Terminals

I/O DESCRIPTION

Global reset. When global reset is asserted, GRST causes the PCI4410A device to place all output buffers
in a high-impedance state and reset all internal registers. When GRST
in its default state. For systems that require wake-up from D3, GRST
boot. PRST
D3 to D0. For systems that do not require wake-up from D3, GRST

When the SUSPEND
preserved. All outputs are placed in a high-impedance state, but the contents of the registers are preserved.

PCI bus clock. PCLK provides timing for all transactions on the PCI bus. All PCI signals are sampled at the
rising edge of PCLK.

PCI bus reset. When the PCI bus reset is asserted, PRST causes the PCI4410A device to place all output
buffers in a high-impedance state and reset internal registers. When PRST
completely nonfunctional. After PRST

When SUSPEND
All outputs are placed in a high-impedance state, but the contents of the registers are preserved.

should be asserted following initial boot so that PME context is retained when transitioning from

mode is enabled, the device is protected from GRST, and the internal registers are

is deasserted, the PCI4410A device is in a default state.

and PRST are asserted, the device is protected from PRST clearing the internal registers.

is asserted, the device is completely

normally is asserted only during initial

should be tied to PRST.

is asserted, the device is

TERMINAL

I/O

DESCRIPTION

NAME

AD31
AD30
AD29
AD28
AD27
AD26
AD25
AD24
AD23
AD22
AD21
AD20
AD19
AD18
AD17
AD16
AD15
AD14
AD13
AD12

AD11

AD10

AD9
AD8
AD7
AD6
AD5
AD4
AD3
AD2
AD1
AD0

C/BE3
C/BE2
C/BE1
C/BE0

PAR 52 T1 I/O

NUMBER

PDV GHK

19

J1

20

J2

21

J3

23

J6

24

K1

25

K2

26

K3

27

K5

31

L3

32

L6

33

L5

35

M2

39

N1

40

N2

41

N3

42

N6

54

U5

55

R6

56

P7

57

V5

59

U6

61

R7

62

W6

63

P8

65

V7

67

R8

68

U8

69

V8

70

W8

71

W9

72

V9

73

U9

28

K6

43

P1

53

W4

64

U7

Table 2–8. PCI Address and Data Terminals

I/O DESCRIPTION

PCI address/data bus. These signals make up the multiplexed PCI address and data bus on the primary
interface. During the address phase of a primary bus PCI cycle, AD31–AD0 contain a 32-bit address or other

I/O

destination information. During the data phase, AD31–AD0 contain data.

PCI bus commands and byte enables. These signals are multiplexed on the same PCI terminals. During the
address phase of a primary bus PCI cycle, C/BE3
this 4-bit bus is used as byte enables. The byte enables determine which byte paths of the full 32-bit data

I/O

bus carry meaningful data. C/BE0
applies to byte 2 (AD23–AD16), and C/BE3 applies to byte 3 (AD31–AD24).

PCI bus parity. In all PCI bus read and write cycles, the PCI4410A device calculates even parity across the
AD31–AD0 and C/BE3
parity indicator with a one-PCLK delay. As a target during PCI cycles, the calculated parity is compared to
the initiator’s parity indicator. A compare error results in the assertion of a parity error (PERR).

–C/BE0 buses. As an initiator during PCI cycles, the PCI4410A device outputs this

applies to byte 0 (AD7–AD0), C/BE1 applies to byte 1 (AD15–AD8), C/BE2

–C/BE0 define the bus command. During the data phase,

2–13

TERMINAL

I/O

DESCRIPTION

NAME

DEVSEL

FRAME

GNT

IDSEL 29 L1 I

IRDY

PERR

REQ

SERR

STOP

TRDY

NUMBER

PDV GHK

48 P6 I/O

44 P2 I/O

18 H1 I

45 N5 I/O

50 P5 I/O

17 H2 O PCI bus request. REQ is asserted by the PCI4410A device to request access to the PCI bus as an initiator.

51 R3 O

49 R2 I/O

47 R1 I/O

Table 2–9. PCI Interface Control Terminals

I/O DESCRIPTION

PCI device select. The PCI4410A device asserts DEVSEL to claim a PCI cycle as the target device. As a PCI
initiator on the bus, the PCI4410A device monitors DEVSEL
before timeout occurs, the PCI4410A device terminates the cycle with an initiator abort.

PCI cycle frame. FRAME is driven by the initiator of a bus cycle. FRAME is asserted to indicate that a bus
transaction is beginning, and data transfers continue while this signal is asserted. When FRAME
deasserted, the PCI bus transaction is in the final data phase.

PCI bus grant. GNT is driven by the PCI bus arbiter to grant the PCI4410A device access to the PCI bus after
the current data transaction has completed. GNT
PCI bus parking algorithm.

Initialization device select. IDSEL selects the PCI4410A device during configuration space accesses. IDSEL
can be connected to one of the upper 24 PCI address lines on the PCI bus.

PCI initiator ready. IRDY indicates the PCI bus initiator’s ability to complete the current data phase of the
transaction. A data phase is completed on a rising edge of PCLK, when both IRDY
Until IRDY

PCI parity error indicator. PERR is driven by a PCI device to indicate that calculated parity does not match
PAR when PERR
Section 4.4).

PCI system error. SERR is an output that is pulsed from the PCI4410A device when enabled through bit 8
(SERR_EN) of the command register (PCI offset 04h, see Section 4.4) indicating a system error has
occurred. The PCI4410A device need not be the target of the PCI cycle to assert this signal. When SERR
is enabled in the command register, this signal also pulses, indicating that an address parity error has occurred
on a CardBus interface.

PCI cycle stop signal. STOP is driven by a PCI target to request the initiator to stop the current PCI bus
transaction. STOP
support burst data transfers.

PCI target ready. TRDY indicates the primary bus target’s ability to complete the current data phase of the
transaction. A data phase is completed on a rising edge of PCLK, when both IRDY
Until both IRDY

and TRDY are both sampled asserted, wait states are inserted.

is enabled through bit 6 (PERR_EN) of the command register (PCI offset 04h, see

is used for target disconnects and is commonly asserted by target devices that do not

and TRDY are asserted, wait states are inserted.

may or may not follow a PCI bus request, depending on the

until a target responds. If no target responds

and TRDY are asserted.

and TRDY are asserted.

is

2–14

Table 2–10. Multifunction and Miscellaneous Terminals

I/O

DESCRIPTION

TERMINAL

NAME

INTA 92 V13 O Parallel PCI interrupt. INTA
INTB 93 U13 O Parallel PCI interrupt. INTB

LED_SKT 90 R12 O PC Card socket activity LED indicator. LED_SKT provides an output indicating PC Card socket activity .

MFUNC0 76 W10 I/O

MFUNC1 77 V10 I/O

MFUNC2 80 P10 I/O

MFUNC3 81 W11 I/O

MFUNC4 83 U11 I/O

MFUNC5 84 P11 I/O

MFUNC6 85 R11 I/O

RI_OUT/PME 75 P9 O

SPKROUT

SUSPEND 86 W12 I

NUMBER

PDV GHK

78 U10 O

I/O DESCRIPTION

Multifunction ter m i n a l 0 . M F UNC0 can be configured as parallel PCI interrupt INTA, GPI0, GPO0, socket
activity LED output, ZV switching outputs, CardBus audio PWM, GPE
Section 4.32, Multifunction Routing Register, for configuration details.

Multifunction terminal 1. MFUNC1 can be configured as GPI1, GPO1, socket activity LED output, ZV
switching outputs, CardBus audio PWM, GPE
Register, for configuration details.

Serial data (SDA). When VCCD0
the SDA signaling for the serial bus interface. The two-terminal serial interface loads the subsystem
identification and other register defaults from an EEPROM after a PCI reset. See Section 3.6.1, Serial
Bus Interface Implementation, for details on other serial bus applications.

Multifunction terminal 2. MFUNC2 can be configured as PC/PCI DMA request, GPI2, GPO2, ZV
switching outputs, CardBus audio PWM, GPE
Multifunction Routing Register, for configuration details.

Multifunction terminal 3. MFUNC3 can be configured as a parallel IRQ or the serialized interrupt signal
IRQSER. See Section 4.32, Multifunction Routing Register, for configuration details.

Multifunction terminal 4. MFUNC4 can be configured as PCI LOCK, GPI3, GPO3, socket activity LED
output, ZV switching outputs, CardBus audio PWM, GPE
Multifunction Routing Register, for configuration details.

Serial clock (SCL). When VCCD0
the SCL signaling for the serial bus interface. The two-terminal serial interface loads the subsystem
identification and other register defaults from an EEPROM after a PCI reset. See Section 3.6.1, Serial
Bus Interface Implementation, for details on other serial bus applications.

Multifunction terminal 5. MFUNC5 can be configured as PC/PCI DMA grant, GPI4, GPO4, socket activity
LED output, ZV switching outputs, CardBus audio PWM, GPE
Multifunction Routing Register, for configuration details.

Multifunction terminal 6. MFUNC6 can be configured as a PCI CLKRUN or a parallel IRQ. See
Section 4.32, Multifunction Routing Register, for configuration details.

Ring indicate out and power-management event output. Terminal provides an output for ring-indicate
or PME

signals.

Speaker output. SPKROUT is the output to the host system that can carry SPKR or CAUDIO through
the PCI4410A device from the PC Card interface. SPKROUT is driven as the exclusive-OR combination
of card SPKR

Suspend. SUSPEND protects the internal registers from clearing when the GRST or PRST signal is
asserted. See Section 3.8.4, Suspend Mode, for details.

//CAUDIO inputs.

and VCCD1 are high after a PCI reset, the MFUNC1 terminal provides

and VCCD1 are high after a PCI reset, the MFUNC4 terminal provides

, or a parallel IRQ. See Section 4.32, Multifunction Routing

, RI_OUT, or a parallel IRQ. See Section 4.32,

, RI_OUT, or a parallel IRQ. See Section 4.32,

, or a parallel IRQ. See Section 4.32,

, or a parallel IRQ. See

2–15

NAME

I/O

DESCRIPTION

ADDR25
ADDR24
ADDR23
ADDR22
ADDR21
ADDR20
ADDR19
ADDR18
ADDR17
ADDR16
ADDR15
ADDR14
ADDR13
ADDR12
ADDR11
ADDR10

ADDR9
ADDR8
ADDR7
ADDR6
ADDR5
ADDR4
ADDR3
ADDR2
ADDR1
ADDR0

DATA15
DATA14
DATA13
DATA12
DATA11
DATA10

DATA9
DATA8
DATA7
DATA6
DATA5
DATA4
DATA3
DATA2
DATA1
DATA0

TERMINAL

NUMBER

PDV GHK

164
161
159
157
155
153
151
148
146
156
158
152
149
160
143
137
145
147
163
166
168
169
172
175
176
177

135
132
130
128
125
192
190
188
133
131
129
127
124
191
189
187

B14
B15
E14
A16
E17
E18
E19
F18
G14
D19
C15
F14
G15
F13
G19

J15
G17
F19
C14
A14
C13
B13
C12
A11
B11
C11

J17
K14
K17
K19

L17

C8

A8
F9

J19
K15
K18

L14

L18

B8
E9

C9

Table 2–11. 16-Bit PC Card Address and Data Terminals

I/O DESCRIPTION

O PC Card address. 16-bit PC Card address lines. ADDR25 is the most significant bit.

I/O PC Card data. 16-bit PC Card data lines. DATA15 is the most significant bit.

2–16

TERMINAL

I/O

DESCRIPTION

NAME

BVD1

(STSCHG

/RI)

BVD2

(SPKR

)

CD1
CD2

CE1
CE2

INPACK 171 E12 I

IORD

IOWR

OE 140 H17 O

NUMBER

PDV GHK

183 E10 I

182 C10 I

123

L19

185
136

139

141 H14 O

144 G18 O

A9

J14

H18

Table 2–12. 16-Bit PC Card Interface Control Terminals

I/O DESCRIPTION

Battery voltage detect 1. BVD1 is generated by 16-bit memory PC Cards that include batteries. BVD1
is used with BVD2 as an indication of the condition of the batteries on a memory PC Card. Both BVD1
and BVD2 are high when the battery is good. When BVD2 is low and BVD1 is high, the battery is weak
and should be replaced. When BVD1 is low, the battery is no longer serviceable and the data in the
memory PC Card is lost. See Section 5.6, ExCA Card Status-Change-Interrupt Configuration

Register, for enable bits. See Section 5.5, ExCA Card Status-Change Register, and Section 5.2,
ExCA Interface Status Register, for the status bits for this signal.

Status change. STSCHG
battery voltage dead condition of a 16-bit I/O PC Card.

Ring indicate. RI
Battery voltage detect 2. BVD2 is generated by 16-bit memory PC Cards that include batteries. BVD2

is used with BVD1 as an indication of the condition of the batteries on a memory PC Card. Both BVD1
and BVD2 are high when the battery is good. When BVD2 is low and BVD1 is high, the battery is weak
and should be replaced. When BVD1 is low, the battery is no longer serviceable and the data in the
memory PC Card is lost. See Section 5.6, ExCA Card Status-Change-Interrupt Configuration

Register, for enable bits. See Section 5.5, ExCA Card Status-Change Register, and Section 5.2,
ExCA Interface Status Register, for the status bits for this signal.

Speaker. SPKR
configured for the 16-bit I/O interface. The audio signals from cards A and B are combined by the
PCI4410A device and are output on SPKROUT.

DMA request. BVD2 can be used as the DMA request signal during DMA operations to a 16-bit
PC Card that supports DMA. The PC Card asserts BVD2 to indicate a request for a DMA operation.

Card detect 1 and Card detect 2. CD1 and CD2 are connected internally to ground on the PC Card.
When a PC Card is inserted into a socket, CD1

I

Section 5.2, ExCA Interface Status Register.
Card enable 1 and card enable 2. CE1 and CE2 enable even- and odd-numbered address bytes. CE1

O

enables even-numbered address bytes, and CE2 enables odd-numbered address bytes.
Input acknowledge. INPACK is asserted by the PC Card when it can respond to an I/O read cycle

at the current address.
DMA request. INPACK

PC Card that supports DMA. If it is used as a strobe, the PC Card asserts this signal to indicate a
request for a DMA operation.

I/O read. IORD is asserted by the PCI4410A device to enable 16-bit I/O PC Card data output during
host I/O read cycles.

DMA write. IORD is used as the DMA write strobe during DMA operations from a 16-bit PC Card that
supports DMA. The PCI4410A device asserts IORD
memory.

I/O write. IOWR is driven low by the PCI4410A device to strobe write data into 16-bit I/O PC Cards
during host I/O write cycles.

DMA read. IOWR
supports DMA. The PCI4410A device asserts IOWR
Card.

Output enable. OE is driven low by the PCI4410A device to enable 16-bit memory PC Card data
output during host memory read cycles.

DMA terminal count. OE
that supports DMA. The PCI4410A device asserts OE

is used by 16-bit modem cards to indicate a ring detection.

is an optional binary audio signal available only when the card and socket have been

is used to alert the system to a change in the READY, write protect, or

and CD2 are pulled low. For signal status, see

can be used as the DMA request signal during DMA operations from a 16-bit

during DMA transfers from the PC Card to host

is used as the DMA write strobe during DMA operations from a 16-bit PC Card that

during transfers from host memory to the PC

is used as terminal count (TC) during DMA operations to a 16-bit PC Card

to indicate TC for a DMA write operation.

2–17

Table 2–12. 16-Bit PC Card Interface Control Terminals (Continued)

I/O

DESCRIPTION

TERMINAL

NAME

READY

(IREQ

REG

RESET 167 F12 O PC Card reset. RESET forces a hard reset to a 16-bit PC Card.

WAIT

WE 154 F15 O

WP

(IOIS16

VS1
VS2

NUMBER

PDV GHK

180 A10 I

)

173 B12 O

181 B10 I

184 F10 I

)

179
165

I/O DESCRIPTION

Ready. The ready function is provided by READY when the 16-bit PC Card and the host socket are
configured for the memory-only interface. READY is driven low by the 16-bit memory PC Cards to indicate
that the memory card circuits are busy processing a previous write command. READY is driven high when
the 16-bit memory PC Card is ready to accept a new data-transfer command.

F11
E13

Interrupt request. IREQ
I /O PC Card requires service by the host software. IREQ
requested.

Attribute memory select. REG remains high for all common memory accesses. When REG is asserted,
access is limited to attribute memory (OE
Attribute memory is a separately accessed section of card memory and generally is used to record card
capacity and other configuration and attribute information.

DMA acknowledge. REG
Card that supports DMA. The PCI4410A device asserts REG
in conjunction with the DMA read (IOWR

Bus cycle wait. WAIT is driven by a 16-bit PC Card to extend the completion of the memory or I/O cycle
in progress.

Write enable. WE is used to strobe memory write data into 16-bit memory PC Cards. WE also is used for
memory PC Cards that employ programmable memory technologies.

DMA terminal count. WE
The PCI4410A device asserts WE

Write protect. WP applies to 16-bit memory PC Cards. WP reflects the status of the write-protect switch
on 16-bit memory PC Cards. For 16-bit I/O PC cards, WP is used for the 16-bit port (IOIS16

I/O is 16 bits. IOIS16
address on the bus corresponds to an address to which the 16-bit PC Card responds, and the I/O port that
is addressed is capable of 16-bit accesses.

DMA request. WP can be used as the DMA request signal during DMA operations to a 16-bit PC Card that
supports DMA. If used, the PC Card asserts WP to indicate a request for a DMA operation.

Voltage sense 1 and voltage sense 2. VS1 and VS2, when used in conjunction with each other, determine

I/O

the operating voltage of the PC Card.

is asserted by a 16-bit I/O PC Card to indicate to the host that a device on the 16-bit

is used as a DMA acknowledge (DACK) during DMA operations to a 16-bit PC

) or DMA write (IORD) strobes to transfer data.

is used as TC during DMA operations to a 16-bit PC Card that supports DMA.

to indicate TC for a DMA read operation.

applies to 16-bit I/O PC Cards. IOIS16 is asserted by the 16-bit PC Card when the

or WE active) and to the I/O space (IORD or IOWR active).

is high (deasserted) when no interrupt is

to indicate a DMA operation. REG is used

) function.

TERMINAL

NAME

CCLK 156 D19 O

CCLKRUN

CRST

2–18

NUMBER

PDV GHK

184 F10 I/O

167 F12 O

Table 2–13. CardBus PC Card Interface System Terminals

I/O DESCRIPTION

CardBus clock. CCLK provides synchronous timing for all transactions on the CardBus interface. All
signals except CRST
sampled on the rising edge of CCLK, and all timing parameters are defined with the rising edge of this
signal. CCLK operates at the PCI bus clock frequency, but it can be stopped in the low state or slowed
down for power savings.

CardBus clock run. CCLKRUN is used by a CardBus PC Card to request an increase in the CCLK
frequency, and by the PCI4410A device to indicate that the CCLK frequency is going to be decreased.

CardBus reset. CRST brings CardBus PC Card-specific registers, sequencers, and signals to a known
state. When CRST
the PCI4410A device drives these signals to a valid logic level. Assertion can be asynchronous to CCLK,
but deassertion must be synchronous to CCLK.

, CCLKRUN, CINT, CSTSCHG, CAUDIO, CCD2, CCD1, CVS2, and CVS1 are

is asserted, all CardBus PC Card signals are placed in a high-impedance state, and

TERMINAL

I/O

DESCRIPTION

NAME

CAD31
CAD30
CAD29
CAD28
CAD27
CAD26
CAD25
CAD24
CAD23
CAD22
CAD21
CAD20
CAD19
CAD18
CAD17
CAD16
CAD15
CAD14
CAD13
CAD12

CAD11

CAD10

CAD9
CAD8
CAD7
CAD6
CAD5
CAD4
CAD3
CAD2
CAD1
CAD0

CC/BE3
CC/BE2
CC/BE1
CC/BE0

CPAR 149 G15 I/O

NUMBER

PDV GHK

192
190
189
188
187
177
176
175
172
169
168
166
164
163
161
146
144
145
141
143
140
139
137
135
133
130
131
128
129
125
127
124

173
160
147
136

C8

A8
E9
F9

C9
C11
B11
A11

C12

B13

C13

A14
B14

C14

B15

G14
G18
G17
H14
G19
H17
H18

J15
J17

J19
K17
K15
K19
K18
L17
L14
L18

B12
F13
F19

J14

Table 2–14. CardBus PC Card Address and Data Terminals

I/O DESCRIPTION

CardBus address and data. These signals make up the multiplexed CardBus address and data bus on
the CardBus interface. During the address phase of a CardBus cycle, CAD31–CAD0 contain a 32-bit

I/O

address. During the data phase of a CardBus cycle, CAD31–CAD0 contain data. CAD31 is the most
significant bit.

CardBus bus commands and byte enables. CC/BE3–CC/BE0 are multiplexed on the same CardBus
terminals. During the address phase of a CardBus cycle, CC/BE3
During the data phase, this 4-bit bus is used as byte enables. The byte enables determine which byte paths

I/O

of the full 32-bit data bus carry meaningful data. CC/BE0
to byte 1 (CAD15–CAD8), CC/BE2
(CAD31–CAD24).

CardBus parity. In all CardBus read and write cycles, the PCI4410A device calculates even parity across
the CAD and CC/BE
with a one-CCLK delay. As a target during CardBus cycles, the calculated parity is compared to the
initiator’s parity indicator; a compare error results in a parity-error assertion.

buses. As an initiator during CardBus cycles, the PCI4410A device outputs CPAR

applies to byte 2 (CAD23–CAD16), and CC/BE3 applies to byte 3

applies to byte 0 (CAD7–CAD0), CC/BE1 applies

–CC/BE0 define the bus command.

2–19

TERMINAL

I/O

DESCRIPTION

NAME

CAUDIO 182 C10 I

CBLOCK

CCD1
CCD2

CDEVSEL

CFRAME

CGNT

CINT

CIRDY

CPERR

CREQ

CSERR

CSTOP

CSTSCHG

CTRDY

CVS1
CVS2

NUMBER

PDV GHK

151 E19 I/O
123

L19

185

155 E17 I/O

159 E14 I/O

154 F15 O

180 A10 I

158 C15 I/O

152 F14 I/O

171 E12 I

181 B10 I

153 E18 I/O

183 E10 I

157 A16 I/O

179
165

A9

F11
E13

Table 2–15. CardBus PC Card Interface Control Terminals

I/O DESCRIPTION

CardBus audio. CAUDIO is a digital input signal from a PC Card to the system speaker. The PCI4410A
device supports the binary audio mode and outputs a binary signal from the card to SPKROUT.

CardBus lock. CBLOCK is used to gain exclusive access to a target.
CardBus detect 1 and CardBus detect 2. CCD1 and CCD2 are used in conjunction with CVS1 and

I

CVS2 to identify card insertion and interrogate cards to determine the operating voltage and card type.
CardBus device select. The PCI4410A device asserts CDEVSEL to claim a CardBus cycle as the

target device. As a CardBus initiator on the bus, the PCI4410A device monitors CDEVSEL
responds. If no target responds before timeout occurs, the PCI4410A device terminates the cycle with
an initiator abort.

CardBus cycle frame. CFRAME is driven by the initiator of a CardBus bus cycle. CFRAME is asserted
to indicate that a bus transaction is beginning, and data transfers continue while this signal is asserted.
When CFRAME

CardBus bus grant. CGNT is driven by the PCI4410A device to grant a CardBus PC Card access to
the CardBus bus after the current data transaction has been completed.

CardBus interrupt. CINT is asserted low by a CardBus PC Card to request interrupt servicing from the
host.

CardBus initiator ready. CIRDY indicates the CardBus initiator’s ability to complete the current data
phase of the transaction. A data phase is completed on a rising edge of CCLK when both CIRDY
CTRDY

CardBus parity error. CPERR reports parity errors during CardBus transactions, except during special
cycles. It is driven low by a target two clocks following that data when a parity error is detected.

CardBus request. CREQ indicates to the arbiter that the CardBus PC Card desires use of the CardBus
bus as an initiator.

CardBus system error. CSERR reports address parity errors and other system errors that could lead
to catastrophic results. CSERR
pullup, and may take several CCLK periods. The PCI4410A device can report CSERR
by assertion of SERR

CardBus stop. CSTOP is driven by a CardBus target to request the initiator to stop the current CardBus
transaction. CSTOP
do not support burst data transfers.

CardBus status change. CSTSCHG alerts the system to a change in the card’s status, and is used as
a wake-up mechanism.

CardBus target ready . CTRDY indicates the CardBus target’s ability to complete the current data phase
of the transaction. A data phase is completed on a rising edge of CCLK, when both CIRDY
are asserted; until this time, wait states are inserted.

CardBus voltage sense 1 and CardBus voltage sense 2. CVS1 and CVS2 are used in conjunction with

I/O

CCD1

and CCD2 to identify card insertion and interrogate cards to determine the operating voltage and

card type.

is deasserted, the CardBus bus transaction is in the final data phase.

are asserted. Until both CIRDY and CTRDY are sampled asserted, wait states are inserted.

is driven by the card synchronous to CCLK, but deasserted by a weak

on the PCI interface.

is used for target disconnects, and is commonly asserted by target devices that

until a target

and

to the system

and CTRDY

2–20

Table 2–16. IEEE 1394 PHY/Link Interface Terminals

I/O

FUNCTION

I/O

FUNCTION

TERMINAL

NAME

PHY_CTL1
PHY_CTL0

PHY_DATA7
PHY_DATA6
PHY_DATA5
PHY_DATA4
PHY_DATA3
PHY_DATA2
PHY_DATA1
PHY_DATA0

PHY_CLK

PHY_LREQ

LINKON

LPS

NUMBER

PDV GHK

198
197F7C7

1
208
207
206
205
204
202
200

196 B7 I

194 E8 O

199 A6 I
193 F8 O

I/O FUNCTION

PHY-link interface control. These bidirectional signals control passage of information between the
PHY and link. The link can drive these terminals only after the PHY has granted permission,

I/O

following a link request (LREQ).

D1
A4
C5
E6
B5
F6
C6
B6

PHY -link interface data. These bidirectional signals pass data between the PHY and link. These
terminals are driven by the link on transmissions and are driven by the PHY on receptions. Only

I/O

DATA1–DATA0 are valid for 100-Mbit speed. DATA4–DATA0 are valid for 200-Mbit speed and
DATA7–DATA0 are valid for 400-Mbit speed.

System clock. This input provides a 49.152-MHz clock signal for data synchronization.
Link request. This signal is driven by the link to initiate a request for the PHY to perform some

service.
1394 link on. This input from the PHY indicates that the link should turn on.
Link power status. LPS indicates that link is powered and fully functional.

Table 2–17. Zoomed-Video Interface Terminals

TERMINAL

NAME

ZV_HREF 95 W14 O Horizontal sync to the zoomed-video port

ZV_VSYNC

ZV_Y7
ZV_Y6
ZV_Y5
ZV_Y4
ZV_Y3
ZV_Y2
ZV_Y1
ZV_Y0

ZV_UV7
ZV_UV6
ZV_UV5
ZV_UV4
ZV_UV3
ZV_UV2
ZV_UV1

ZV_UV0
ZV_SCLK
ZV_MCLK
ZV_PCLK

ZV_LRCLK
ZV_SDATA

NUMBER

PDV GHK

96 V14 O

105

T19

104

W16

103

U15

102

R14

101

V15

99

W15

98

U14

97

R13

116

N17

112

P18

113

N15

109

R18

111

P17

107

P15

108

N14

106

R17
114 P19 O
117 N18 O
120 M17 O
118 N19 O
119 M15 O

I/O FUNCTION

Vertical sync to the zoomed-video port

O

Video data to the zoomed-video port in YUV:4:2:2 format

O

Video data to the zoomed-video port in YUV:4:2:2 format

Audio SCLK PCM
Audio MCLK PCM
Pixel clock to the zoomed-video port
Audio LRCLK PCM
Audio SDATA PCM

2–21

2–22

3 Feature/Protocol Descriptions

The following sections give an overview of the PCI4410A device. Figure 3–1 shows connections to the PCI4410A
device. The PCI interface includes all address/data and control signals for PCI protocol. The interrupt interface
includes terminals for parallel PCI, parallel ISA, and serialized PCI and ISA signaling. Miscellaneous system interface
terminals include multifunction terminals: SUSPEND
SPKROUT.

, RI_OUT/PME (power-management control signal), and

1394 Ports

1394

PHY

TPS2211

Power

Switch

Super

I/O

ISA

CPU

South

Bridge

Audio

Codec

North

Bridge

VGA

Controller

4

19

Zoomed

Video

PCI Bus

23

Memory

OHCI-PHY

Interface

14

PCI4410A

PC Card

Controller

PC Card Interface

Figure 3–1. PCI4410A System Block Diagram

3.1 Power-Supply Sequencing

The PCI4410A device contains 3.3-V I/O buffers with 5-V tolerance, requiring a core power supply and clamp
voltages. The core power supply always is 3.3 V. The clamp voltages can be either 3.3 V or 5 V, depending on the
interface. The following power-up and power-down sequences are recommended.

The power-up sequence is:

1. Apply 3.3-V power to the core.

2. Assert GRST
the high-impedance state to prevent high current levels through the clamp diodes to the 5-V supply.

3. Apply the clamp voltage.

The power-down sequence is:

1. Use GRST

2. Remove the clamp voltage.

3. Remove the 3.3-V power from the core.

to the device to disable the outputs during power up. Output drivers must be powered up in

to switch outputs to a high-impedance state.

3.2 I/O Characteristics

Figure 3–2 shows a 3-state bidirectional buffer. Section 10.2, Recommended Operating Conditions, provides the
electrical characteristics of the inputs and outputs.

NOTE: The PCI4410A device meets the ac specifications of the PC Card Standard and the PCI
Local Bus Specification.

3–1

V

Tied for Open Drain

OE

CCP

Pad

Figure 3–2. 3-State Bidirectional Buffer

NOTE: Unused pins (input or I/O) must be held high or low to prevent them from floating.

3.3 Clamping Voltages

The clamping voltages are set to match whatever external environment the PCI4410A device is interfaced with: 3.3 V
or 5 V. The I/O sites can be pulled through a clamping diode to a voltage rail that protects the core from external
signals. The core power supply always is 3.3 V and is independent of the clamping voltages. For example, PCI
signaling can be either 3.3 V or 5 V, and the PCI4410A device must reliably accommodate both voltage levels. This
is accomplished by using a 3.3-V I/O buffer that is 5-V tolerant, with the applicable clamping voltage applied. If a
system designer desires a 5-V PCI bus, V

can be connected to a 5-V power supply.

CCP

The PCI4410A device requires four separate clamping voltages because it supports a wide range of features. The
four voltages are listed and defined in Section 10.2, Recommended Operating Conditions.

3.4 Peripheral Component Interconnect (PCI) Interface

The PCI4410A device is fully compliant with the PCI Local Bus Specification. The PCI4410A device provides all
required signals for PCI master or slave operation, and can operate in either a 5-V or 3.3-V signaling environment
by connecting the V
device provides the optional interrupt signal INTA

terminals to the desired voltage level. In addition to the mandatory PCI signals, the PCI4410A

CCP

.

3.4.1 PCI Bus Lock (LOCK)

The bus-locking protocol defined in the PCI Local Bus Specification is not highly recommended, but is provided on
the PCI4410A device as an additional compatibility feature. The PCI LOCK
terminal via the multifunction routing register. See Section 4.32, Multifunction Routing Register,
the use of LOCK

PCI LOCK

is supported only by PCI-to-CardBus bridges in the downstream direction (away from the processor).

indicates an atomic operation that may require multiple transactions to complete. When LOCK is asserted,
nonexclusive transactions can proceed to an address that currently is not locked. A grant to start a transaction on
the PCI bus does not guarantee control of LOCK

; control of LOCK is obtained under its own protocol. It is possible
for different initiators to use the PCI bus while a single master retains ownership of LOCK
signal for this protocol is CBLOCK

to avoid confusion with the bus clock.

An agent may need to do an exclusive operation because a critical access to memory might be broken into several
transactions, but the master wants exclusive rights to a region of memory. The granularity of the lock is defined by
PCI to be 16 bytes, aligned. The LOCK

protocol defined by the PCI Local Bus Specification allows a resource lock

without interfering with nonexclusive real-time data transfer, such as video.
The PCI bus arbiter may be designed to support only complete bus locks using the LOCK

the arbiter will not grant the bus to any other agent (other than the LOCK
bus lock may have a significant impact on the performance of the video. The arbiter that supports complete bus lock
must grant the bus to the cache to perform a writeback due to a snoop to a modified line when a locked operation
is in progress.

signal can be routed to the MFUNC4

for details. Note that

. Note that the CardBus

protocol. In this scenario,

master) while LOCK is asserted. A complete

The PCI4410A device supports all LOCK

protocol associated with PCI-to-PCI bridges, as also defined for

PCI-to-CardBus bridges. This includes disabling write posting while a locked operation is in progress, which can solve

3–2

a potential deadlock when devices such as PCI-to-PCI bridges are used. The potential deadlock can occur if a
CardBus target supports delayed transactions and blocks access to the target until it completes a delayed read. This
target characteristic is prohibited by the PCI Local Bus Specification, and the issue is resolved by the PCI master using
LOCK

.

3.4.2 Loading Subsystem Identification

The subsystem vendor ID register (PCI offset 40h, see Section 4.26) and subsystem ID register (PCI offset 42h, see
Section 4.27) make up a doubleword of PCI configuration space located at offset 40h for functions 0 and 1. This
doubleword register is used for system and option card (mobile dock) identification purposes and is required by some
operating systems. Implementation of this unique identifier register is a PC 99 requirement.

The PCI4410A device offers two mechanisms to load a read-only value into the subsystem registers. The first
mechanism relies upon the system BIOS providing the subsystem ID value. The default access mode to the
subsystem registers is read-only, but can be made read/write by setting bit 5 (SUBSYSRW) in the system control
register (PCI offset 80h, see Section 4.29). When this bit is set, the BIOS can write a subsystem identification value
into the registers at PCI offset 40h. The BIOS must clear the SUBSYSRW bit such that the subsystem vendor ID
register and subsystem ID register are limited to read-only access. This approach saves the added cost of
implementing the serial electrically erasable programmable ROM (EEPROM).

In some conditions, such as in a docking environment, the subsystem vendor ID register and subsystem ID register
must be loaded with a unique identifier via a serial EEPROM. The PCI4410A device loads the data from the serial
EEPROM aft e r a r eset of the primary bus. Note that the SUSPEND
core, including the serial bus state machine (see Section 3.8.4, Suspend Mode, for details on using SUSPEND

The PCI4410A device provides a two-line serial bus host controller that can interface to a serial EEPROM. See
Section 3.6, Serial Bus Interface,

for details on the two-wire serial bus controller and applications.

input gates the PCI reset from the entire PCI4410A

).

3.5 PC Card Applications

This section describes the PC Card interfaces of the PCI4410A device:

• Card insertion/removal and recognition

2

• P

C power-switch interface

• Zoomed-video support

• Speaker and audio applications

• LED socket activity indicators

• PC Card-16 DMA support

• PC Card controller programming model

• CardBus socket registers

3.5.1 PC Card Insertion/Removal and Recognition

The PC Card Standard addresses the card-detection and recognition process through an interrogation procedure
that the socket must initiate on card insertion into a cold, nonpowered socket. Through this interrogation, card voltage
requirements and interface (16-bit versus CardBus) are determined.

The scheme uses the card-detect and voltage-sense signals. The configuration of these four terminals identifies the
card type and voltage requirements of the PC Card interface. The encoding scheme is defined in the PC Card
Standard and in Table 3–1.

3–3

Table 3–1. PC Card Card-Detect and Voltage-Sense Connections

CD2//CCD2 CD1//CCD1 VS2//CVS2 VS1//CVS1 KEY INTERFACE VOLTAGE

Ground Ground Open Open 5 V 16-bit PC Card 5 V
Ground Ground Open Ground 5 V 16-bit PC Card 5 V and 3.3 V
Ground Ground Ground Ground 5 V 16-bit PC Card 5 V, 3.3 V, and X.X V
Ground Ground Open Ground LV 16-bit PC Card 3.3 V
Ground Connect to CVS1 Open Connect to CCD1 LV CardBus PC Card 3.3 V

Ground Ground Ground Ground LV 16-bit PC Card 3.3 V and X.X V
Connect to CVS2 Ground Connect to CCD2 Ground LV CardBus PC Card 3.3 V and X.X V
Connect to CVS1 Ground Ground Connect to CCD2 LV CardBus PC Card 3.3 V, X.X V, and Y.Y V

Ground Ground Ground Open LV 16-bit PC Card Y.Y V
Connect to CVS2 Ground Connect to CCD2 Open LV CardBus PC Card Y.Y V

Ground Connect to CVS2 Connect to CCD1 Open LV CardBus PC Card X.X V and Y.Y V
Connect to CVS1 Ground Open Connect to CCD2 LV CardBus PC Card Y.Y V

Ground Connect to CVS1 Ground Connect to CCD1 Reserved

Ground Connect to CVS2 Connect to CCD1 Ground Reserved

3.5.2 P2C Power-Switch Interface (TPS2211)

The PCI4410A device provides a P2C (PCMCIA peripheral control) interface for control of the PC Card power switch.
The VCCD
power-switch support. Figure 3–3 shows terminal assignments for the TPS2211 power-switch interface. Figure 3–4
illustrates a typical application, where the PCI4410A device represents the PC Card controller.

and VPPD terminals are used with the TI TPS221 1 single-slot PC Card power-switch interface to provide

VCCD0
VCCD1

3.3 V

3.3 V
5 V

5 V

GND

OC

1
2
3
4
5
6
7
8

16
15
14
13
12

11

10

9

SHDN
VPPD0
VPPD1
AVCC
AVCC
AVCC
AVPP
12 V

Figure 3–3. TPS2211 Terminal Assignments

The PCI4410A device also includes support for the Maxim 1602 and Micrel MIC2562A single-channel CardBus
power switches. Application of these power switches is similar to that of the TPS2211 power-switch interface.

3–4

Power Supply

12 V

5 V

3.3 V

12 V
5 V

3.3 V

TPS2211

Supervisor

PCI4410A

(PCMCIA

Controller)

SHDN
SHDN

VCCD0
VCCD1
VPPD0
VPPD1

OC

AVPP

AVCC

V
V
V
V

PP1
PP2
CC
CC

PC Card

Figure 3–4. TPS2211 Typical Application

3.5.3 Zoomed-Video Support

The zoomed-video (ZV) port on the PCI4410A device provides an internally buffered 16-bit ZV PC Card data path.
This internal routing is programmed through the card control register (PCI offset 91h, bits 5 and 6). Figure 3–5
summarizes the ZV subsystem implemented in the PCI4410A device, and details the bit functions found in the card
control register.

When ZV PORT_ENABLE is enabled, the ZV output terminals are enabled and allow the PCI4410A device to route
the ZV data. However, no data is transmitted unless ZVENABLE (PCI offset 91h, bit 6) is enabled. If ZVENABLE is
set to low, the ZV output port drives a logic 0 on the ZV bus of the PCI4410A device.

3–5

Card Output

Enable Logic

PC Card

Socket

Zoomed-Video Subsystem

PORT_ENABLE

PC Card

I/F

ZV

Note: ZVSTAT must be enabled
through the GPIO Control Register

ZVSTAT

23

ZVENABLE

19 Video Signals

VGA

Audio

Codec

4 Audio Signals

Figure 3–5. Zoomed-Video Subsystem

3.5.4 Ultra Zoomed Video

Ultra zoomed video is an enhancement to the PCI4410A DMA engine and is intended to improve the 16-bit bandwidth
for MPEG I and MPEG II decoder PC Cards. This enhancement allows the PCI4410A device to fetch 32 bits of data
from memory, versus the PCI11XX/12XX 16-bit fetch capability. This enhancement allows a higher sustained
throughput to the 16-bit PC Card because the PCI4410A device prefetches an extra 16 bits (32 bits total) during each
PCI read transaction. If the PCI bus becomes busy, the PCI4410A device has an extra 16 bits of data to perform
back-to-back 16-bit transactions to the PC Card before having to fetch more data. This feature is built into the DMA
engine, and software is not required to enable this enhancement.

NOTE: The PCI11XX and PCI12XX series CardBus controllers have enough 16-bit bandwidth
to support MPEG II PC Card decoders. But, it was decided to improve the bandwidth even more
in the PCI14XX series CardBus controllers.

3.5.5 D3_STAT Terminal

Additional functionality for the PCI4410A device versus the PCI12xx series is the D3_STAT (D3 status) pin. This pin
is asserted under the following two conditions (both conditions must be true before D3_STAT

is asserted):

• Function 0 (PC Card controller) and function 1 (OHCI-Lynxt) are both in D3.

• PME

is enabled for either function.

3.5.6 Internal Ring Oscillator

The internal ring oscillator provides an internal clock source for the PCI4410A device so that neither the PCI clock
nor an external clock is required for the PCI4410A device to power down a socket or interrogate a PC Card. This
internal oscillator operates nominally at 16 kHz and can be enabled by setting bit 27 (P2CCLK) of the system control
register (PCI offset 80h, see Section 4.29) to a 1. This function is disabled by default.

3–6

3.5.7 Integrated Pullup Resistors for PC Card Interface

The PC Card Standard requires pullup resistors on various terminals to support both CardBus and 16-bit card
configurations. Unlike the PCI1210 or PCI1211 device, which required external pullup resistors, the PCI4410A device
has integrated all of these pullup resistors on the terminals shown in Table 3–2, except for the CCLKRUN
pullup resistor.

Table 3–2. Integrated Pullup Resistors

/WP(IOIS16)

SIGNAL NAME

ADDR14/CPERR 152 F14

ADDR15/CIRDY 158 C15

ADDR19/CBLOCK 151 E19

ADDR20/CSTOP 153 E18

ADDR21/CDEVSEL 155 E17

ADDR22/CTRDY 157 A16

BVD1(STSCHG)/CSTSCHG 183 E10

BVD2(SPKR)/CAUDIO 182 C10

CD1/CCD1 123 L19
CD2/CCD2 185 A9

INPACK/CREQ 171 E12

READY/CINT 180 A10
RESET/CRST 167 F12

VS1/CVS1 179 F11
VS2/CVS2 165 E13

WAIT/CSERR 181 B10

WP(IOIS16)/CLKRUN 184

†

This terminal requires pullup, but the PCI4410A lacks an integrated
pullup resistor.

TERMINAL NUMBER

PDV GHK

†

F10

†

3.5.8 SPKROUT and CAUDPWM Usage

SPKROUT carries the digital audio signal from the PC Card to the system. When a 16-bit PC Card is configured for
I/O mode, the BVD2 pin becomes SPKR
referred to a s CAUDIO. SPKR

passes a TTL-level digital audio signal to the PCI4410A device. The CardBus CAUDIO
signal also can pass a single-amplitude binary waveform. The binary audio signals from the PC Card socket is used
in the PCI4410A device to produce SPKROUT. This output is enabled by bit 1 (SPKROUTEN) in the card control
register (PCI offset 91h, see Section 4.34).

Older controllers support CAUDIO in binary or PWM mode, but use the same terminal (SPKROUT). Some audio chips
may not support both modes on one terminal and may have a separate terminal for binary and PWM. The PCI4410A
implementation includes a signal for PWM, CAUDPWM, which can be routed to a MFUNC terminal. Bit 2
(AUD2MUX), located in the card control register, is programmed to route a CardBus CAUDIO PWM terminal to
CAUDPWM. See Section 4.32, Multifunction Routing Register, for details on configuring the MFUNC terminals.

Figure 3–6 illustrates a sample application using SPKROUT and CAUDPWM.

. This terminal also is used in CardBus binary audio applications, and is

3–7

System

Core Logic

BINARY_SPKR

Speaker

Subsystem

PWM_SPKR

PCI4410A

SPKROUT

CAUDPWM

Figure 3–6. Sample Application of SPKROUT and CAUDPWM

3.5.9 LED Socket Activity Indicators

The socket activity LEDs indicate when a PC Card is being accessed. The LED_SKT signal can be routed to the
multifunction terminals and also is provided on a dedicated pin (LED_SKT). When configured for LED output, this
terminal outputs an active high signal to indicate socket activity. See Section 4.32, Multifunction Routing Register,
for details on configuring the multifunction terminals.

The LED signal is active high and is driven for 64-ms durations. When the LED is not being driven high, it is driven
to a low state. Either of the two circuits shown in Figure 3–7 can be implemented to provide LED signaling. It is left
for the board designer to implement the circuit that best fits the application.

The LED activity signals are valid when a card is inserted, powered, and not in reset. For PC Card-16, the LED activity
signal is pulsed when READY/IREQ
or CREQ

is active.

is low. For CardBus cards, the LED activity signal is pulsed if CFRAME, CIRDY,

Current Limiting

R ≈ 500 Ω

PCI4410A

PCI4410A

Application-

Specific Delay

Current Limiting

R ≈ 500 Ω

LED

LED

Figure 3–7. Two Sample LED Circuits

As indicated, the LED signals are driven for a period of 64 ms by a counter circuit. To avoid the possibility of the LED
appearing to be stuck when the PCI clock is stopped, the LED signaling is cut off when the SUSPEND

signal is

asserted, when the PCI clock is to be stopped during the clock run protocol, or in the D2 or D1 power state.
If any additional socket activity occurs during this counter cycle, the counter is reset and the LED signal remains

driven. If socket activity is frequent (at least once every 64 ms), the LED signal remains driven.

3.5.10 PC Card-16 Distributed DMA Support

The PCI4410A device supports a distributed DMA slave engine for 16-bit PC Card DMA support. The distributed DMA
(DDMA) slave register set provides the programmability necessary for the slave DDMA engine. Table 3–3 provides
the DDMA register configuration.

3–8

Two socket function-dependent PCI configuration header registers that are critical for DDMA are the socket DMA
register 0 (PCI offset 94h, see Section 4.37) and the socket DMA register 1 (PCI offset 98h, see Section 4.38).
Distributed DMA is enabled through socket DMA register 0, and the contents of this register configure the PC Card-16
terminal (SPKR

, IOIS16, or INPACK), which is used for the DMA request signal, DREQ. The base address of the
DDMA slave registers and the transfer size (bytes or words) are programmed through the socket DMA register 1. See
the programming model and register descriptions in Section 4 for details.

Table 3–3. Distributed DMA Registers

DDMA

TYPE REGISTER NAME

R

W

R

W

R N/A

W Mode

R Multichannel

W Mask

Reserved Page

Reserved Reserved

Reserved

Reserved

Master clear

Current address

Base address

Current count

Base count

N/A Status

Request Command

N/A

Reserved 0Ch

BASE ADDRESS

OFFSET

00h

04h

08h

The DDMA registers contain control and status information consistent with the 8237 DMA controller; however, the
register locations are reordered and expanded in some cases. While the DDMA register definitions are identical to
those in the 8237 DMA controller of the same name, some register bits defined in the 8237 DMA controller do not
apply to distributed DMA in a PCI environment. In such cases, the PCI4410A device implements these obsolete
register bits as read-only, nonfunctional bits. The reserved registers shown in Table 3–3 are implemented as
read-only and return 0s when read. Write transactions to reserved registers have no effect.

The DDMA transfer is prefaced by several configuration steps that are specific to the PC Card and must be completed
after the PC Card is inserted and interrogated. These steps include setting the proper DREQ

signal assignment,
setting the data transfer width, and mapping and enabling the DDMA register set. As discussed above, this is done
through socket DMA register 0 and socket DMA register 1. The DMA register set is then programmed similarly to an
8237 controller, and the PCI4410A device awaits a DREQ

assertion from the PC Card requesting a DMA transfer.

DMA writes transfer data from the PC Card-to-PCI memory addresses. The PCI4410A device accepts data 8 or
16 bits at a time, depending on the programmed data width, and then requests access to the PCI bus by asserting
its REQ signal. Once the PCI bus is granted in an idle state, the PCI4410A device initiates a PCI memory write
command to the current memory address and transfers the data in a single data phase. After terminating the PCI
cycle, the PCI4410A device accepts the next byte(s) from the PC Card until the transfer count expires.

DMA reads transfer data from PCI memory addresses to the PC Card application. Upon the assertion of DREQ
PCI4410A device asserts REQ

to acquire the PCI bus. Once the bus is granted in an idle state, the PCI4410A device

, the

initiates a PCI memory read operation to the current memory address and accepts 8 or 16 bits of data, depending
on the programmed data width. After terminating the PCI cycle, the data is passed on to the PC Card. After terminating
the PC Card cycle, the PCI4410A device requests access to the PCI bus again, until the transfer count has expired.

The PCI4410A target interface acts normally during this procedure and accepts I/O reads and writes to the DDMA
registers. While a DDMA transfer is in progress and the host resets the DMA channel, the PCI4410A device asserts
TC and ends the PC Card cycle(s). TC is indicated in the DDMA status register (see Section 7.5). At the PC Card
interface, the PCI4410A device supports demand mode transfers. The PCI4410A device asserts DACK during the
transfer unless DREQ
and is mapped to the WE
REG

signal in all transfers, and the DREQ terminal is routed to one of three options, which is programmed through

is deasserted before TC. TC is mapped to the OE PC Card terminal for DMA write operations

PC Card terminal for DMA read operations. The DACK signal is mapped to the PC Card

socket DMA register 0.

3–9

3.5.11 PC Card-16 PC/PCI DMA

DMA CHANNEL

Some chipsets provide a way for legacy I/O devices to do DMA transfers on the PCI bus. In the PC/PCI DMA protocol,
the PCI4410A device acts as a PCI target device to certain DMA-related I/O addresses. The PCI4410A PCREQ
PCGNT
PCGNT
Routing Register,

signals are provided as a point-to-point connection to a chipset supporting PC/PCI DMA. The PCREQ and
signals may be routed to the MFUNC2 and MFUNC5 terminals, respectively . See Section 4.32, Multifunction

for details on configuring the multifunction terminals.

Under the PC/PCI protocol, a PCI DMA slave device (such as the PCI4410A device) requests a DMA transfer on a
particular channel using a serialized protocol on PCREQ
grants the channel through a serialized protocol on PCGNT

. The I/O DMA bus master arbitrates for the PCI bus and

when it is ready for the transfer. The I/O cycle and memory

cycles are then presented on the PCI bus, which performs the DMA transfers similarly to legacy DMA master devices.
PC/PCI DMA is enabled for each PC Card-16 slot by setting bit 19 (CDREQEN) in the respective system control

register (PCI o ffset 80h, see Section 4.29). On power up, this bit is reset and the card PC/PCI DMA is disabled. Bit 3
(CDMA_EN) of the system control register is a global enable for PC/PCI DMA, and is set at power up and never
cleared if the PC/PCI DMA mechanism is implemented. The desired DMA channel for each PC Card-16 slot must
be configured through bits 18–16 (CDMACHAN field) in the system control register. The channels are configured as
indicated in Table 3–4.

Table 3–4. PC/PCI Channel Assignments

SYSTEM CONTROL

REGISTER

BIT 18 BIT 17 BIT16

0 0 0 Channel 0 8-bit DMA transfers
0 0 1 Channel 1 8-bit DMA transfers
0 1 0 Channel 2 8-bit DMA transfers
0 1 1 Channel 3 8-bit DMA transfers
1 0 0 Channel 4 Not used
1 0 1 Channel 5 16-bit DMA transfers
1 1 0 Channel 6 16-bit DMA transfers
1 1 1 Channel 7 16-bit DMA transfers

DMA CHANNEL

CHANNEL TRANSFER

DATA WIDTH

and

As in distributed DMA, the PC Card terminal mapped to DREQ must be configured through socket DMA register 0
(PCI offset 94h, see Section 4.37). The data transfer width is a function of channel number, and the DDMA slave
registers are not used. When a DREQ
device decodes the I/O addresses listed in Table 3–5 and performs actions dependent upon the address.

When the PC/PCI DMA is used as a PC Card-16 DMA mechanism, it may not provide the performance levels of
DDMA; however, the design of a PCI target implementing PC/PCI DMA is considerably less complex. No bus master
state machine is required to support PC/PCI DMA, because the DMA control is centralized in the chipset. This DMA
scheme often is referred to as centralized DMA for this reason.

3.5.12 CardBus Socket Registers

The PCI4410A device contains all registers for compatibility with the PC Card Standard. These registers exist as the
CardBus socket registers and are listed in Table 3–6.

3–10

is received from a PC Card and the channel has been granted, the PCI4410A

Table 3–5. I/O Addresses Used for PC/PCI DMA

DMA I/O ADDRESS DMA CYCLE TYPE TERMINAL COUNT PCI CYCLE TYPE

00h Normal 0 I/O read/write

04h Normal TC 1 I/O read/write
C0h Verify 0 I/O read
C4h Verify TC 1 I/O read

3.6 Serial Bus Interface

Table 3–6. CardBus Socket Registers

REGISTER NAME OFFSET

Socket event 00h
Socket mask 04h
Socket present state 08h
Socket force event 0Ch
Socket control 10h
Reserved 14h
Reserved 18h
Reserved 1Ch

Socket power management 20h

The PCI4410A device provides a serial bus interface to load subsystem identification and select register defaults
through a serial EEPROM and to provide a PC Card power switch interface alternative to P

2

P

C Power-Switch Interface (TPS2211), for details. The PCI4410A serial bus interface is compatible with various I2C

2

C. See Section 3.5.2,

and SMBus components.

3.6.1 Serial Bus-Interface Implementation

The PCI4410A device defaults to the serial bus interface are disabled. To enable the serial interface, a pullup resistor
must be implemented on the VCCD0
on the SDA and SCL signals, that is, the MFUNC1 and MFUNC4 terminals.

The PCI4410A device implements a two-pin serial interface with one clock signal (SCL) and one data signal (SDA).
When pullup resistors are provided on the VCCD0
terminal and the SDA signal is mapped to the MFUNC1 terminal. The PCI4410A device drives SCL at nearly 100 kHz
during data transfers, which is the maximum specified frequency for standard-mode I
be located at address A0h. Figure 3–8 illustrates an example application implementing the two-wire serial bus.

Serial

EEPROM

SCL

SDA

and VCCD1 terminals and the appropriate pullup resistors must be implemented

and VCCD1 terminals, the SCL signal is mapped to the MFUNC4

2

C. The serial EEPROM must

V

CC

PCI4410A

VCCD0
VCCD1

MFUNC4
MFUNC1

V

CC

Figure 3–8. Serial EEPROM Application

Some serial device applications may include PC Card power switches, ZV source switches, card ejectors, or other
devices that may enhance the user’s PC Card experience. The serial EEPROM device and PC Card power switches
are discussed in the sections that follow.

3.6.2 Serial Bus-Interface Protocol

The SCL and SDA signals are bidirectional, open-drain signals and require pullup resistors as shown in Figure 3–8.
The PCI4410A device supports up to 100 Kb/s data transfer rate and is compatible with standard-mode I
7-bit addressing.

All data transfers are initiated by the serial bus master. The beginning of a data transfer is indicated by a start
condition, which is signaled when the SDA line transitions to a low state while SCL is in the high state, as illustrated

2

C using

3–11

in Figure 3–9. The end of a requested data transfer is indicated by a stop condition, which is signaled by a low-to-high
transition of SDA while SCL is in the high state, as shown in Figure 3–9. Data on SDA must remain stable during the
high state of the SCL signal, because changes on the SDA signal during the high state of SCL are interpreted as
control signals, that is, a start or a stop condition.

SDA

SCL

Start

Condition

Stop

Condition

Change of

Data Allowed

Data Line Stable,

Data Valid

Figure 3–9. Serial Bus Start/Stop Conditions and Bit Transfers

Data is transferred serially in 8-bit bytes. The number of bytes that can be transmitted during a data transfer is
unlimited; however, each byte must be completed with an acknowledge bit. An acknowledge (ACK) is indicated by
the receiver pulling the SDA signal low so that it remains low during the high state of the SCL signal. Figure 3–10
illustrates the acknowledge protocol.

SCL From

Master

SDA Output

by Transmitter

SDA Output

by Receiver

123 789

Figure 3–10. Serial Bus-Protocol Acknowledge

The PCI4410A device is a serial bus master; all other devices connected to the serial bus external to the PCI4410A
device are slave devices. As the bus master, the PCI4410A device drives the SCL clock at nearly 100 kHz during
bus cycles and places SCL in a high-impedance state (zero frequency) during idle states.

Typically, the PCI4410A device masters byte reads and byte writes under software control. Doubleword reads are
performed by the serial EEPROM initialization circuitry upon a PCI reset, and may not be generated under software
control. See Section 3.6.3, Serial Bus EEPROM Application, for details on how the PCI4410A device automatically
loads the subsystem identification and other register defaults through a serial bus EEPROM.

Figure 3–11 illustrates a byte write. The PCI4410A device issues a start condition and sends the 7-bit slave device
address and the command bit 0. A 0 in the R/W

command bit indicates that the data transfer is a write. The slave
device acknowledges if it recognizes the address. The word address byte is then sent by the PCI4410A device and
another slave acknowledgment is expected. The PCI4410A device then delivers the data byte, MSB first, and expects
a final acknowledgment before issuing the stop condition.

3–12

Slave Address Word Address

Data Byte

Sb6 b4b5 b3 b2 b1 b0 0 b7 b6 b5 b4 b3 b2 b1 b0AA

R/W

S/P = Start/stop conditionA = Slave acknowledgement

b7 b6 b4b5 b3 b2 b1 b0 A P

Figure 3–11. Serial Bus Protocol – Byte Write

Figure 3–12 illustrates a byte read. The read protocol is very similar to the write protocol, except the R/W

command
bit must be set to 1 to indicate a read-data transfer. In addition, the PCI4410A master must acknowledge reception
of the read bytes from the slave transmitter. The slave transmitter drives the SDA signal during read data transfers.
The SCL signal remains driven by the PCI4410A master.

Slave Address Word Address

Sb6 b4b5 b3 b2 b1 b0 1 b7 b6 b5 b4 b3 b2 b1 b0A

R/W

Slave Address

A b7 b6 b4b5 b3 b2 b1 b0 M P

b6 b4b5 b3 b2 b1 b0

A b7 b6 b4b5 b3 b2 b1 b0 M P

M = Master acknowledgement

Data Byte

Data Byte

S/P = Start/stop conditionA = Slave acknowledgement

A

Figure 3–12. Serial Bus Protocol – Byte Read

Figure 3–13 illustrates EEPROM interface doubleword data-collection protocol.

Slave Address Word Address

S1 10 0 0 0 0 0 b7 b6 b5 b4 b3 b2 b1 b0AA

Start

Data Byte 3 M

R/W

Data Byte 2 Data Byte 1 Data Byte 0 M PMM

M = Master acknowledgement

S1 10 00001A

Restart

S/P = Start/stop conditionA = Slave acknowledgement

Slave Address

R/W

Figure 3–13. EEPROM Interface Doubleword Data Collection

3.6.3 Serial Bus EEPROM Application

When the PCI bus is reset and the serial bus interface is detected, the PCI4410A device attempts to read the
subsystem identification and other register defaults from a serial EEPROM. The registers and corresponding bits that
may be loaded with defaults through the EEPROM are provided in Table 3–7.

3–13

Table 3–7. Registers and Bits Loadable Through Serial EEPROM

OHCI REGISTERS LOADED

OFFSET

REFERENCE

0 3Eh MIN_GNT and MAX_LAT (see Section 8.14) Byte 0, bits 3–0
1 3Fh MIN_GNT and MAX_LAT (see Section 8.14) Byte 1, bits 3–0
2 PCI 2Ch Subsystem identification (see Section 8.11) Byte 0
3 PCI 2Ch Subsystem identification (see Section 8.11) Byte 1
4 PCI 2Ch Subsystem identification (see Section 8.11) Byte 2
5 PCI 2Ch Subsystem identification (see Section 8.11) Byte 3
6 PCI F4h Link enhancement control (see Section 8.21) Byte 0, bits 7, 2, 1
7 Mini-ROM address
8 PCI 24h GUID high (see Section 9.10) Byte 0

9 PCI 24h GUID high (see Section 9.10) Byte 1
10 PCI 24h GUID high (see Section 9.10) Byte 2
11 PCI 24h GUID high (see Section 9.10) Byte 3
12 PCI 28h GUID low (see Section 9.11) Byte 0
13 PCI 28h GUID low (see Section 9.11) Byte 1
14 PCI 28h GUID low (see Section 9.11) Byte 2
15 PCI 28h GUID low (see Section 9.11) Byte 3
16 Checksum
17 PCI F4h Link enhancement control (see Section 8.21) Byte 1, bits 5, 4, 1, 0
18 PCI F0h Miscellaneous configuration (see Section 8.20) Byte 0, bits 4, 2–0
19 PCI F0h Miscellaneous configuration (see Section 8.20) Byte 1, bits 7, 5, 2

REGISTER REGISTER NAME BITS LOADED FROM EEPROM

CARDBUS REGISTERS LOADED

OFFSET

REFERENCE

0 Flag byte

1 PCI 40h Subsystem vendor ID (see Section 4.26) Byte 0

2 PCI 40h Subsystem vendor ID (see Section 4.26) Byte 1

3 PCI 42h Subsystem ID (see Section 4.27) Byte 0

4 PCI 42h Subsystem ID (see Section 4.27) Byte 1

5 PCI 80h System control (see Section 4.29) Byte 0

6 PCI 80h System control (see Section 4.29) Byte 1, bits 7, 6

7 PCI 80h System control (see Section 4.29) Byte 3, bits 7, 5, 3, 2, 0

8 PCI 86h General control (see Section 4.31) Bits 3, 1, 0

9 PCI 8Ch Multifunction routing (see Section 4.32) Byte 0
10 PCI 8Ch Multifunction routing (see Section 4.32) Byte 1
11 PCI 8Ch Multifunction routing (see Section 4.32) Byte 2
12 PCI 8Ch Multifunction routing (see Section 4.32) Byte 3, bits 3–0
13 PCI 90h Retry status (see Section 4.33) Bits 7, 6
14 PCI 91h Card control (see Section 4.34) Bit 7
15 PCI 92h Device control (see Section 4.35) Bits 6–0
16 PCI 93h Diagnostic (see Section 4.36) Bits 7, 4–0
17 PCI A2h Power management capabilities (see Section 4.41) Bit 15
18 ExCA 00h ExCA Identification and revision (see Section 5.1) Bits 7–0

REGISTER REGISTER NAME BITS LOADED FROM EEPROM

3–14

Figure 3–14 details the EEPROM data format. This format must be followed for the PCI4410A device to properly load
initializations from a serial EEPROM.

Slave Address = 1010 000

Reference(0) Word Address 00h

Byte 3 (0) Word Address 01h
Byte 2 (0) Word Address 02h
Byte 1 (0) Word Address 03h
Byte 0 (0) Word Address 04h

RSVD
RSVD
RSVD

Reference(1) Word Address 08h

Reference(n) Word Address 8 × (n–1)

Byte 3 (n) Word Address 8 × (n–1) + 1
Byte 2 (n) Word Address 8 × (n–1) + 2
Byte 1 (n) Word Address 8 × (n–1) + 3
Byte 0 (n) Word Address 8 × (n–1) + 4

RSVD
RSVD
RSVD

EOL Word Address 8 × (n)

Figure 3–14. EEPROM Data Format

The byte at the EEPROM word address 00h must contain either a valid offset reference, as listed in Table 3–7, or
an end-of-list (EOL) indicator. The EOL indicator has a byte value of FFh, and indicates the end of the data to load
from the EEPROM. Only doubleword registers are loaded from the EEPROM, and all bit fields must be considered
when the EEPROM is programmed.

The serial EEPROM is addressed at slave address 101 0000b by the PCI4410A device. All hardware address bits
for the EEPROM should be tied to the appropriate level to achieve this address. The serial EEPROM chip in the
sample application circuit (see Figure 3–8) assumes the 1010b high address nibble. The lower three address bits
are terminal inputs to the chip, and the sample application shows these terminal inputs tied to GND.

When a valid offset reference is read, four bytes are read from the EEPROM, MSB first, as illustrated in Figure 3–13.
The address autoincrements after every byte transfer according to the doubleword read protocol. Note that the word
addresses align with the data format illustrated in Figure 3–14. The PCI4410A device continues to load data from
the serial EEPROM until an end-of-list indicator is read. Three reserved bytes are stuffed to maintain 8-byte data
structures.

Note, the 8-byte data structure is important to provide correct addressing per the doubleword read format shown in
Figure 3–13. In addition, the reference offsets must be loaded in the EEPROM in sequential order, that is, 01h, 02h,
03h, 04h. If the offsets are not sequential, the registers may be loaded incorrectly.

3.6.4 Accessing Serial Bus Devices Through Software

The PCI4410A device provides a programming mechanism to control serial bus devices through software. The
programming is accomplished through a doubleword of PCI configuration space at offset B0h.

3.7 Programmable Interrupt Subsystem

Interrupts provide a way for I/O devices to let the microprocessor know that they require servicing. The dynamic
nature of PC Cards and the abundance of PC Card I/O applications require substantial interrupt support from the
PCI4410A device. The PCI4410A device provides several interrupt signaling schemes to accommodate the needs
of a variety of platforms. The different mechanisms for dealing with interrupts in this device are based on various
specifications and industry standards. The ExCA register set provides interrupt control for some 16-bit PC Card
functions, and the CardBus socket register set provides interrupt control for the CardBus PC Card functions. The
PCI4410A device is, therefore, backward compatible with existing interrupt control register definitions, and new
registers have been defined where required.

3–15

The PCI4410A device detects PC Card interrupts and events at the PC Card interface and notifies the host controller,

16 bit

using one of several interrupt signaling protocols. To simplify the discussion of interrupts in the PCI4410A device, PC
Card interrupts are classified as either card status change (CSC) or as functional interrupts.

The method by which any type of PCI4410A interrupt is communicated to the host interrupt controller varies from
system to system. The PCI4410A device offers system designers the choice of using parallel PCI interrupt signaling,
parallel ISA-type IRQ interrupt signaling, or the IRQSER serialized ISA and/or PCI interrupt protocol. It is possible
to use the parallel PCI interrupts in combination with either parallel IRQs or serialized IRQs, as detailed in the sections
that follow. All interrupt signaling is provided through the seven multifunction terminals, MFUNC0–MFUNC6. In
addition, PCI interrupts (INTA

and INTB) are available on dedicated pins.

3.7.1 PC Card Functional and Card Status Change Interrupts

PC Card functional interrupts are defined as requests from a PC Card application for interrupt service and are
indicated by asserting specially defined signals on the PC Card interface. Functional interrupts are generated by
16-bit I/O PC Cards and by CardBus PC Cards.

Card status change (CSC)-type interrupts are defined as events at the PC Card interface that are detected by the
PCI4410A device, and may warrant notification of host card and socket services software for service. CSC events
include both card insertion and removal from PC Card sockets, as well as transitions of certain PC Card signals.

Table 3–8 summarizes the sources of PC Card interrupts and the type of card associated with them. CSC and
functional int e r r u p t sources are dependent on the type of card inserted in the PC Card socket. The three types of cards
that can be inserted into any PC Card socket are:

• 16-bit memory card

• 16-bit I/O card

• CardBus cards

CARD TYPE EVENT MASK FLAG

16-bit

memory

16-bit I/O

All 16-bit

PC Cards

CardBus

Table 3–8. Interrupt Mask and Flag Registers

Battery conditions

(BVD1, BVD2)

Wait states

(READY)

Change in card status

(STSCHG

Interrupt request

Power cycle complete
Change in card status

(CSTSCHG)

Interrupt request

Power cycle complete

Card insertion or

removal

(IREQ

(CINT

)

)

)

ExCA offset 05h/805h

bits 1 and 0

ExCA offset 05h/805h

bit 2

ExCA offset 05h/805h

bit 0

Always enabled

ExCA offset 05h/805h

bit 3

Socket mask

bit 0

Always enabled

Socket mask

bit 3

Socket mask

bits 2 and 1

ExCA offset 04h/804h

bits 1 and 0

ExCA offset 04h/804h

bit 2

ExCA offset 04h/804h

bit 0

PCI configuration offset 91h

bit 0

ExCA offset 04h/804h

bit 3

Socket event

bit 0

PCI configuration offset 91h

bit 0

Socket event

bit 3

Socket event

bits 2 and 1

Functional interrupt events are valid only for 16-bit I/O and CardBus cards; that is, the functional interrupts are not
valid for 16-bit memory cards. Furthermore, card insertion and removal-type CSC interrupts are independent of the
card type. Table 3–9 describes the PC Card interrupt events.

3–16

Table 3–9. PC Card Interrupt Events and Description

Battery conditions

memory

All PC Cards

CARD TYPE EVENT TYPE SIGNAL DESCRIPTION

A transition on BVD1 indicates a change in the
PC Card battery conditions.

A transition on BVD2 indicates a change in the
PC Card battery conditions.

A transition on READY indicates a change in the ability
of the memory PC Card to accept or provide data.

The assertion of STSCHG indicates a status change
on the PC Card.

The assertion of IREQ indicates an interrupt request
from the PC Card.

The assertion of CSTSCHG indicates a status change
on the PC Card.

The assertion of CINT indicates an interrupt request
from the PC Card.

A transition on either CD1//CCD1 or CD2//CCD2
indicates an insertion or removal of a 16-bit or CardBus
PC Card.

An interrupt is generated when a PC Card power-up
cycle has completed.

16-bit

memory

16-bit I/O

CardBus

All PC Cards

Battery conditions

(BVD1, BVD2)

Wait states

(READY)

Change in card

status (STSCHG)

Interrupt request

(IREQ)

Change in card

status (CSTSCHG)

Interrupt request

(CINT

)

Card insertion

or removal

Power cycle

complete

BVD1(STSCHG)//CSTSCHG

CSC

BVD2(SPKR)//CAUDIO

CSC READY(IREQ)//CINT

CSC BVD1(STSCHG)//CSTSCHG

Functional READY(IREQ)//CINT

CSC BVD1(STSCHG)//CSTSCHG

Functional READY(IREQ)//CINT

CSC

CSC N/A

CD1//CCD1,

CD2

//CCD2

The naming convention for PC Card signals describes the function for 16-bit memory, I/O cards, and CardBus. For
example, READY(IREQ

)//CINT includes READY for 16-bit memory cards, IREQ for 16-bit I/O cards, and CINT for
CardBus cards. The 16-bit memory card signal name is first, with the I/O card signal name second, enclosed in
parentheses. The CardBus signal name follows after a forward double slash (//).

The PC Card Standard describes the power-up sequence that must be followed by the PCI4410A device when an
insertion event occurs and the host requests that the socket V

and VPP be powered. Upon completion of this

CC

power-up sequence, the PCI4410A interrupt scheme can be used to notify the host system (see Table 3–9), denoted
by the power cycle complete event. This interrupt source is considered a PCI4410A internal event because it depends
on the completion of applying power to the socket rather than on a signal change at the PC Card interface.

3.7.2 Interrupt Masks and Flags

Host software may individually mask (or disable) most of the potential interrupt sources listed in Table 3–9 by setting
the appropriate bits in the PCI4410A device. By individually masking the interrupt sources listed, software can control
those events that cause a PCI4410A interrupt. Host software has some control over the system interrupt the
PCI4410A device asserts by programming the appropriate routing registers. The PCI4410A device allows host
software to route PC Card CSC and PC Card functional interrupts to separate system interrupts. Interrupt routing
somewhat specific to the interrupt signaling method used is discussed in more detail in the following sections.

When an interrupt is signaled by the PCI4410A device, the interrupt service routine must determine which of the
events listed in Table 3–8 caused the interrupt. Internal registers in the PCI4410A device provide flags that report the
source of an interrupt. By reading these status bits, the interrupt service routine can determine the action to be taken.

Table 3–8 details the registers and bits associated with masking and reporting potential interrupts. All interrupts can
be masked, except the functional PC Card interrupts, and an interrupt status flag is available for all types of interrupts.

Notice that there is not a mask bit to stop the PCI4410A device from passing PC Card functional interrupts through
to the appropriate interrupt scheme. These interrupts are not valid until the card is properly powered, and there never
should be a card interrupt that does not require service after proper initialization.

Table 3–8 lists the various methods of clearing the interrupt flag bits. The flag bits in the ExCA registers (16-bit PC
Card-related interrupt flags) can be cleared using two different methods. One method is an explicit write of 1 to the
flag bit to clear and the other is by reading the flag bit register. The selection of flag bit clearing is made by bit 2
(IFCMODE) in the ExCA global control register (see Section 5.22), located at ExCA offset 1Eh/5Eh/81Eh, and
defaults to the flag cleared on read method.

3–17

The CardBus-related interrupt flags can be cleared by an explicit write of 1 to the interrupt flag in the socket event
register (CardBus offset 00h, see Section 6.1). Although some of the functionality is shared between the CardBus
registers and the ExCA registers, software should not program the chip through both register sets when a CardBus
card is functioning.

3.7.3 Using Parallel IRQ Interrupts

The seven multifunction terminals, MFUNC6–MFUNC0, implemented in the PCI4410A device may be routed to
obtain a subset of the ISA IRQs. The IRQ choices provide ultimate flexibility in PC Card host interruptions. To use
the parallel ISA type IRQ interrupt signaling, software must program the device control register (PCI offset 92h, see
Section 4.35) to select the parallel IRQ signaling scheme. See Section 4.32, Multifunction Routing Register, for
details on configuring the multifunction terminals.

A system using parallel IRQs requires a minimum of one PCI terminal, INTA

, to signal CSC events. This requirement
is dictated by certain card and socket services software. The MFUNC pins provide (at a maximum) seven different
IRQs to support legacy 16-bit PC Card functions.

As an example, suppose the seven IRQs used by legacy PC Card applications are IRQ3, IRQ4, IRQ5, IRQ9, IRQ10,
IRQ11, and IRQ15. The multifunction routing register must be programmed to a value of 0x0FBA5439. This routes
the MFUNC terminals as illustrated in Figure 3–15. Not shown is that INTA

also must be routed to the programmable

interrupt controller (PIC), or to some circuitry that provides parallel PCI interrupts to the host.

PCI4410A PIC

MFUNC0
MFUNC1 IRQ3
MFUNC2
MFUNC3
MFUNC4
MFUNC5
MFUNC6

IRQ9

IRQ4
IRQ5
IRQ10
IRQ11
IRQ15

Figure 3–15. IRQ Implementation

Power-on software is responsible for programming the multifunction routing register to reflect the IRQ configuration
of a system implementing the PCI4410A device. See Section 4.32, Multifunction Routing Register,

for details on

configuring the multifunction terminals.
The parallel ISA-type IRQ signaling from the MFUNC6–MFUNC0 terminals is compatible with those input directly into

the 8259 PIC. The parallel IRQ option is provided for system designs that require legacy ISA IRQs. Design constraints
may demand more MFUNC6–MFUNC0 IRQ terminals than the PCI4410A device makes available.

3.7.4 Using Parallel PCI Interrupts

Parallel PCI interrupts are available in parallel PCI interrupt mode, parallel IRQ and parallel PCI interrupt mode, or
serialized IRQ and parallel PCI interrupt mode.

3.7.5 Using Serialized IRQSER Interrupts

The serialized interrupt protocol implemented in the PCI4410A device uses a single terminal to communicate all
interrupt status information to the host controller. The protocol defines a serial packet consisting of a start cycle,
multiple interrupt indication cycles, and a stop cycle. All data in the packet is synchronous with the PCI clock. The
packet data describes 16 parallel ISA IRQ signals and the optional 4 PCI interrupts INTA
details on the IRQSER protocol, refer to the document Serialized IRQ Support for PCI Systems.

3–18

, INTB, INTC, and INTD. For

3.7.6 SMI Support in the PCI4410A Device

The PCI4410A device provides a mechanism for interrupting the system when power changes have been made to
the PC Card socket interfaces. The interrupt mechanism is designed to fit into a system maintenance interrupt (SMI)
scheme. SMI interrupts are generated by the PCI4410A device, when enabled, after a write cycle to either the socket
control register (CardBus offset 10h, see Section 6.5) of the CardBus register set or the ExCA power control register
(ExCA offset 02h, see Section 5.3).

The SMI control is programmed through three bits in the system control register (PCI offset 80h, see Section 4.29).
These bits are SMIROUTE (bit 26), SMISTATUS (bit 25), and SMIENB (bit 24). Table 3–10 describes the SMI control
bits function.

Table 3–10. SMI Control

BIT NAME FUNCTION

SMIROUTE This shared bit controls whether the SMI interrupts are sent as a CSC interrupt or as IRQ2.
SMISTATUS This socket-dependent bit is set when an SMI interrupt is pending. This status flag is cleared by writing back a 1.
SMIENB When set, SMI interrupt generation is enabled.

If CSC SMI interrupts are selected, the SMI interrupt is sent as the CSC. The CSC interrupt can be either level or edge
mode, depending upon bit 1 (CSCMODE) in the ExCA global control register (ExCA offset 1Eh, see Section 5.22).

If IRQ2 is selected by SMIROUTE, the IRQSER signaling protocol supports SMI signaling in the IRQ2 IRQ/Data slot.
In a parallel ISA IRQ system, the support for an active low IRQ2 is provided only if IRQ2 is routed to MFUNC1,
MFUNC3, or MFUNC6 through the multifunction routing register (PCI offset 8Ch, see Section 4.32).

3.8 Power-Management Overview

In addition to the low-power CMOS technology process used for the PCI4410A device, various features are designed
into the device to allow implementation of popular power-saving techniques. These features and techniques are
discussed in this section.

3.8.1 Clock-Run Protocol

The PCI CLKRUN feature is the primary method of power management on the PCI interface of the PCI4410A device.
CLKRUN

signaling is provided through the MFUNC6 terminal. Because some chipsets do not implement CLKRUN,
this is not always available to the system designer, and alternative power-saving features are provided. For details
on the CLKRUN

protocol see the PCI Mobile Design Guide.

The PCI4410A device does not permit the central resource to stop the PCI clock under any of the following conditions:

• Bit 1 (KEEPCLK) in the system control register (PCI offset 80h, see Section 4.29) is set.

• The PC Card-16 resource manager is busy.

• The PCI4410A CardBus master state machine is busy. A cycle may be in progress on CardBus.

• The PCI4410A master is busy. There may be posted data from CardBus to PCI in the PCI4410A device.

• Interrupts are pending.

• The CardBus CCLK for either socket has not been stopped by the PCI4410A CCLKRUN

manager.

The PCI4410A device restarts the PCI clock using the CLKRUN protocol under any of the following conditions:

• A PC Card-16 IREQ or a CardBus CINT

• A CardBus CBWAKE (CSTSCHG) or PC Card-16 STSCHG

• A CardBus attempts to start the CCLK using CCLKRUN

• A CardBus card arbitrates for the CardBus bus using CREQ

• A 16-bit DMA PC Card asserts DREQ

has been asserted.

/RI event occurs.

.

.

.

3.8.2 CardBus PC Card Power Management

The PCI4410A device implements its own card power-management engine that can turn off the CCLK to a socket
when there is no activity to the CardBus PC Card. The PCI clock-run protocol is followed on the CardBus CCLKRUN
interface to control this clock management.

3–19

3.8.3 16-Bit PC Card Power Management

Bit 7 (COE) in the ExCA power control register (ExCA offset 02h, see Section 5.3) and bit 0 (PWRDWN) in the ExCA
global control register (ExCA offset 1Eh, Section 5.22) are provided for 16-bit PC Card power management. The COE
bit places the card interface in a high-impedance state to save power. The power savings when using this feature
are minimal. The COE bit will reset the PC Card when used, and the PWRDWN bit will not. Furthermore, the
PWRDWN bit is an automatic COE; that is, the PWRDWN performs the COE function when there is no card activity.

NOTE: The 16-bit PC Card must implement the proper pullup resistors for the COE and
PWRDWN modes.

3.8.4 Suspend Mode

The SUSPEND signal, provided for backward compatibility, gates the PRST (PCI reset) signal and the GRST (global
reset) signal from the PCI4410A device. Besides gating PRST
PCI4410A device to minimize power consumption.

Gating PCLK does not create any issues with respect to the power switch interface in the PCI4410A device. This is
because the PCI4410A device does not depend on the PCI clock to clock the power-switch interface. There are two
methods to clock the power-switch interface in the PCI4410A device:

• Use an external clock to the PCI4410A CLOCK terminal

• Use the internal oscillator

and GRST, SUSPEND also gates PCLK inside the

It also should be noted that asynchronous signals, such as card status change interrupts and RI_OUT

, can be passed
to the host system without a PCI clock. However, if card status change interrupts are routed over the serial interrupt
stream, the PCI clock must be restarted to pass the interrupt, because neither the internal oscillator nor an external
clock is routed to the serial interrupt state machine. Figure 3–16 shows the suspend functional implementation
diagram.

xRST

SUSPEND

GNT

PCLK

SUSPENDIN

xRSTIN

PCI4410A

Core

PCLKIN

Figure 3–16. Suspend Functional Implementation

Figure 3–17 is a signal diagram of the suspend function.

3–20

xRST

GNT

SUSPEND

PCLK

xRSTIN

SUSPENDIN

PCLKIN

External Terminals

Internal Signals

Figure 3–17. Signal Diagram of Suspend Function

3.8.5 Requirements for Suspend Mode

The suspend mode prevents the clearing of all register contents on the assertion of reset (PRST or GRST) that would
require the reconfiguration of the PCI4410A device by software. Asserting the SUSPEND

signal places the
controller’s PCI outputs in a high-impedance state and gates the PCLK signal internally to the controller unless a PCI
transaction currently is in process (GNT
device when SUSPEND

is asserted, because the outputs are in a high-impedance state.

The GPIOs, MFUNC signals, and RI_OUT

is asserted). It is important that the PCI bus not be parked on the PCI4410A

signals are all active during SUSPEND, unless they are disabled in the

appropriate PCI4410A registers.

3.8.6 Ring Indicate

The RI_OUT output is an important feature in power management, allowing a system to go into a suspended mode
and wake up on modem rings and other card events. TI-designed flexibility permits this signal to fit wide platform
requirements. RI_OUT

• A 16-bit PC Card modem in a powered socket asserts RI
incoming call.

• A powered-down CardBus card asserts CSTSCHG (CBWAKE), requesting system and interface wake-up.

• A powered CardBus card asserts CSTSCHG from the insertion/removal of cards or change in battery

voltage levels.

on the PCI4410A device can be asserted under any of the following conditions:

to indicate to the system the presence of an

Figure 3–18 shows various enable bits for the PCI4410A RI_OUT

function; however, it does not show the masking

of CSC events. See Table 3–8 for a detailed description of CSC interrupt masks and flags.

3–21

RI_OUT Function

PC Card

Socket

Card

I/F

CSTSMASK

RINGEN

CDRESUME

RIENB

RI_OUT

Figure 3–18. RI_OUT Functional Diagram

from the 16-bit PC Card interface is masked by bit 7 (RINGEN) in the ExCA interrupt and general control register

RI
(ExCA offset 03h, see Section 5.4). This is programmed on a per-socket basis and is applicable only when a 16-bit
card is powered in the socket.

The CBWAKE, signaling to RI_OUT

, is enabled through the same mask as the CSC event for CSTSCHG. The mask
bit (bit 0, CSTSMASK) is programmed through the socket mask register (CardBus offset 04h, see Section 6.2) in the
CardBus socket registers.

3.8.7 PCI Power Management

The PCI Bus Power Management Interface Specification for PCI to CardBus Bridges establishes the infrastructure
required for the operating system to control the power of PCI functions. This is done by defining a standard PCI
interface and operations to manage the power of PCI functions on the bus. The PCI bus and the PCI functions can
be assigned one of four software-visible power-management states that result in varying levels of power savings.

The four power-management states of PCI functions are:

• D0 – Fully-on state

• D1 and D2 – Intermediate states

• D3 – Off state

Similarly , b u s power states of the PCI bus are B0–B3. The bus power states B0–B3 are derived from the device power
state of the originating bridge device.

For the operating system (OS) to manage the device power states on the PCI bus, the PCI function must support four
power-management operations. These operations are:

• Capabilities reporting

• Power status reporting

• Setting the power state

• System wake-up

The OS identifies the capabilities of the PCI function by traversing the new capabilities list. The presence of
capabilities, in addition to the standard PCI capabilities, is indicated by a 1 in bit 4 (CAPLIST) of the status register
(PCI offset 06h, see Section 4.5).

The capabilities pointer provides access to the first item in the linked list of capabilities. For the PCI4410A device,
a CardBus bridge with PCI configuration space header type 2, the capabilities pointer is mapped to an offset of 14h.
The first byte of each capability register block is required to be a unique ID of that capability. PCI power management
has been assigned an ID of 01h. The next byte is a pointer to the next pointer item in the list of capabilities. If there
are no more items in the list, the next item pointer should be set to 0. The registers following the next item pointer
are specific to the function’s capability. The PCI power-management capability implements the register block outlined
in Table 3–11.

3–22

Table 3–11. Power-Management Registers

REGISTER NAME OFFSET

Power management capabilities Next item pointer Capability ID A0h

Data PMCSR bridge support extensions Power management control/status (CSR) A4h

The power management capabilities register (PCI offset A2h, see Section 4.41) is a static read-only register that
provides information on the capabilities of the function related to power management. The power management
control/status register (PCI offset A4h, see Section 4.42) enables control of power management states and
enables/monitors powe r m anagement events. The data register is an optional register that can provide dynamic data.

For more information on PCI power management, see the PCI Bus Power Management Interface Specification for
PCI to CardBus Bridges.

3.8.8 CardBus Bridge Power Management

The PCI Bus Power Management Interface Specification for PCI to CardBus Bridges was approved by PCMCIA in
December of 1997. This specification follows the device and bus state definitions provided in the PCI Bus Power
Management Interface Specification published by the PCI Special Interest Group (SIG). The main issue addressed
in the PCI Bus Power Management Interface Specification for PCI to CardBus Bridges is wake up from D3
without losing wake-up context (also called PME context).

The specific issues addressed by the PCI Bus Power Management Interface Specification for PCI to CardBus Bridges
for D3 wake up are as follows:

• Preservation of device context: The specification states that a reset must occur when transitioning from D3
to D0. Some method to preserve wake-up context must be implemented so that the reset does not clear
the PME

context registers.

hot

or D3

cold

• Power source in D3

if wake-up support is required from this state.

cold

The Texas Instruments PCI4410A device addresses these D3 wake-up issues in the following manner:

• Two resets are provided to handle preservation of PME
– Global reset (GRST

) is used only on the initial boot up of the system after power up. It places the

context bits:

PCI4410A device in its default state and requires BIOS to configure the device before becoming fully
functional.

– PCI reset (PRST

enabled, PME
Please see the master list of PME

• Power source in D3
an auxiliary power source must be supplied to the PCI4410A V

) now has dual functionality based on whether PME is enabled or not. If PME is

context is preserved. If PME is not enabled, PRST acts the same as a normal PCI reset.

context bits in Section 3.8.10.

if wake-up support is required from this state. Because VCC is removed in D3

cold

pins. Consult the PCI14xx Implementation

CC

cold

Guide for D3 Wake-Up or the PCI Power Management Interface Specification for PCI to CardBus Bridges
for further information.

3.8.9 ACPI Support

The Advanced Configuration and Power Interface (ACPI) Specification provides a mechanism that allows unique
pieces of hardware to be described to the ACPI driver. The PCI4410A device offers a generic interface that is
compliant with ACPI design rules.

Two doublewords of general-purpose ACPI programming bits reside in PCI4410A PCI configuration space at offset
A8h. The programming model is broken into status and control functions. In compliance with ACPI, the top-level event
status and enable bits reside in the general-purpose event status (PCI offset A8h, see Section 4.45) and
general-purpose event enable (PCI offset AAh, see Section 4.46) registers.

,

3–23

The status and enable bits generate an event that allows the ACPI driver to call a control method associated with the
pending status bit. The control method can then control the hardware by manipulating the hardware control bits or
by investigating child status bits and calling their respective control methods. A hierarchical implementation would
be somewhat limiting, however, as upstream devices would have to remain in some level of power state to report
events.

For more information on ACPI, see the Advanced Configuration and Power Interface (ACPI) Specification.

3.8.10 Master List of PME Context Bits and Global Reset-Only Bits

If the PME enable bit (PCI offset A4h, bit 8) is asserted, the assertion of PRST will not clear the following PME context
bits. If the PME

• Bridge control register (PCI offset 3Eh): bit 6

• Power management control/status register (PCI offset A4h): bits 15, 8

• ExCA power control register (ExCA offset 802h): bits 4, 3, 1, 0

• ExCA interrupt and general control (ExCA offset 803h): bits 6, 5

• ExCA card status change interrupt register (ExCA offset 805h): bits 3–0

• CardBus socket event register (CardBus offset 00h): bits 3–0

• CardBus socket mask register (CardBus offset 04h): bits 3–0

• CardBus socket present state register (CardBus offset 08h): bits 13–10, 7, 5–0

• CardBus socket control register (CardBus offset 10h): bits 6–4, 2–0

enable bit is not asserted, the PME context bits are cleared with PRST. The PME context bits are:

Global reset places all registers in their default state regardless of the state of the PME
is gated only by the SUSPEND
thus preserving all register contents. The registers cleared by GRST

signal. This means that assertion of SUSPEND blocks the GRST signal internally,

are:

enable bit. The GRST signal

• Subsystem ID/subsystem vendor ID (PCI offset 40h): bits 31–0

• PC Card 16-bit legacy mode base address register (PCI offset 44h): bits 31–1

• System control register (PCI offset 80h): bits 31–24, 22–14, 6–3, 1, 0

• General status register (PCI offset 85h): bits 2–0

• General control register (PCI offset 86h): bits 3, 1, 0

• Multifunction routing register (PCI offset 8Ch): bits 27–0

• Retry status register (PCI offset 90h): bits 7, 6, 3, 1

• Card control register (PCI offset 91h): bits 7–5, 2–0

• Device control register (PCI offset 92h): bits 7–0

• Diagnostic register (PCI offset 93h): bits 7–0

• Socket DMA register 0 (PCI offset 94h): bits 1–0

• Socket DMA register 1 (PCI offset 98h): bits 15–4, 2–0

• Power management capabilities register (PCI offset A2h): bit 15

• General-purpose event enable register (PCI offset AAh): bits 15, 11, 8, 4–0

• General-purpose output register (PCI offset AEh): bits 4–0

• PCI miscellaneous configuration register (OHCI function, PCI offset F0h): bits 15, 13, 10, 2–0

• Link enhancements register (OHCI function, PCI offset F4h): bits 13, 12, 9–7, 2, 1

• GPIO control register (OHCI function, PCI offset FCh): bits 29, 28, 24, 21, 20, 16, 15, 13, 12, 8, 7, 5, 4, 0

• Global unique ID low/high (OHCI function, PCI offset 24h–28h): bits 31–0

• ExCA identification and revision register (ExCA offset 00h): bits 7–0

• ExCA card status change register (ExCA offset 804h): bits 3–0

• ExCA global control register (ExCA offset 1Eh): bits 3–0

3–24

4 PC Card Controller Programming Model

This section describes the PCI4410A PCI configuration registers that make up the 256-byte PCI configuration header
for each PCI4410A function. As noted, some bits are global in nature and are accessed only through function 0.

4.1 PCI Configuration Registers (Functions 0 and 1)

The PCI4410A device is a multifunction PCI device, and the PC Card controller is integrated as PCI functions 0 and

1. The configuration header is compliant with the PCI Local Bus Specification as a CardBus bridge header and is
PC 99 compliant as well. Table 4–1 shows the PCI configuration header, which includes both the predefined portion
of the configuration space and the user-definable registers.

Table 4–1. PCI Configuration Registers (Functions 0 and 1)

REGISTER NAME OFFSET

Device ID Vendor ID 00h

Status Command 04h

PCI class code Revision ID 08h

BIST Header type Latency timer Cache line size 0Ch

CardBus socket/ExCA base address 10h

Secondary status Reserved Capability pointer 14h

CardBus latency timer Subordinate bus number CardBus bus number PCI bus number 18h

CardBus memory base register 0 1Ch

CardBus memory limit register 0 20h

CardBus memory base register 1 24h

CardBus memory limit register 1 28h

CardBus I/O base register 0 2Ch

CardBus I/O limit register 0 30h

CardBus I/O base register 1 34h

CardBus I/O limit register 1 38h
Bridge control Interrupt pin Interrupt line 3Ch
Subsystem ID Subsystem vendor ID 40h

PC Card 16-bit I/F legacy-mode base address 44h

Reserved 48h–7Ch

System control 80h

Reserved General control General status Reserved 84h

Reserved 88h–8Bh

Multifunction routing 8Ch

Diagnostic Device control Card control Retry status 90h

Socket DMA register 0 94h
Socket DMA register 1 98h

Reserved 9Ch

Power management capabilities Next-item pointer Capability ID A0h

Power management

Power management data

General-purpose event enable General-purpose event status A8h

General-purpose output General-purpose input ACh

control/status register

bridge support extensions

Power management control/status A4h

Reserved B0h–FCh

4–1

A bit description table, typically included when a register contains bits of more than one type or purpose, indicates
bit field names, a detailed field description, and field access tags, which appear in the type column of the
bit-description table. Table 4–2 describes the field access tags.

Table 4–2. Bit-Field Access Tag Descriptions

ACCESS TAG NAME MEANING

R Read Field can be read by software.

W Write Field can be written by software to any value.

S Set Field can be set by a write of 1. Writes of 0 have no effect.
C Clear Field can be cleared by a write of 1. Writes of 0 have no effect.
U Update Field can be autonomously updated by the PCI4410A device.

†

A bit can display either of two types of behavior when read. After
having been read, it can maintain the value it had previously, or the
read process can cause it to be reset to 0.

†

4.2 Vendor ID Register

This 16-bit register contains a value allocated by the PCI SIG (special interest group) and identifies the manufacturer
of the PCI device. The vendor ID assigned to TI is 104Ch.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Vendor ID
Type R R R R R R R R R R R R R R R R
Default 0 0 0 1 0 0 0 0 0 1 0 0 1 1 0 0

Register: Vendor ID
Type: Read-only
Offset: 00h
Default: 104Ch

4.3 Device ID Register

This 16-bit register contains a value assigned to the PCI4410A device by TI. The device identification for the
PCI4410A device is AC41h.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Device ID
Type R R R R R R R R R R R R R R R R
Default 1 0 1 0 1 1 0 0 0 1 0 0 0 0 0 1

Register: Device ID
Type: Read-only
Offset: 02h
Default: AC41h

4–2

4.4 Command Register

The command register provides control over the PCI4410A interface to the PCI bus. All bit functions adhere to the
definitions in PCI Local Bus Specification. See Table 4–3 for the complete description of the register contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Command
Type R R R R R R R R/W R R/W R/W R R R/W R/W R/W
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: Command
Type: Read-only, Read/Write
Offset: 04h
Default: 0000h

Table 4–3. Command Register Description

BIT SIGNAL TYPE FUNCTION

15–10 RSVD R Reserved. Bits 15–10 return 0s when read.

9 FBB_EN R

8 SERR_EN R/W

7 STEP_EN R

6 PERR_EN R/W

5 VGA_EN R/W

4 MWI_EN R

3 SPECIAL R

2 MAST_EN R/W

1 MEM_EN R/W

0 IO_EN R/W

Fast back-to-back enable. The PCI4410A device does not generate fast back-to-back transactions;
therefore, bit 9 returns 0 when read.

System error (SERR) enable. Bit 8 controls the enable for the SERR driver on the PCI interface. SERR can
be asserted after detecting an address parity error on the PCI bus. Both bits 8 and 6 must be set for the
PCI4410A device to report address parity errors.

0 = Disable SERR
1 = Enable SERR

Address/data stepping control. The PCI4410A device does not support address/data stepping; therefore,
bit 7 is hardwired to 0.

Parity-error response enable. Bit 6 controls the PCI4410A device’s response to parity errors through PERR.
Data parity errors are indicated by asserting PERR

0 = PCI4410A device ignores detected parity error (default).
1 = PCI4410A device responds to detected parity errors.

VGA palette snoop. When bit 5 is set to 1, palette snooping is enabled (that is, the PCI4410A device does
not respond to palette register writes and snoops the data). When bit 5 is 0, the PCI4410A device treats all
palette accesses like all other accesses.

Memory write and invalidate enable. Bit 4 controls whether a PCI initiator device can generate memory
write-and-Invalidate commands. The PCI4410A controller does not support memory write and invalidate
commands. It uses memory write commands instead; therefore, this bit is hardwired to 0.

Special cycles. Bit 3 controls whether or not a PCI device ignores PCI special cycles. The PCI4410A device
does not respond to special cycle operations; therefore, this bit is hardwired to 0.

Bus-master control. Bit 2 controls whether or not the PCI4410A device can act as a PCI bus initiator
(master). The PCI4410A device can take control of the PCI bus only when this bit is set.

0 = Disables the PCI4410A device’s ability to generate PCI bus accesses (default).
1 = Enables the PCI4410A device’s ability to generate PCI bus accesses.

Memory space enable. Bit 1 controls whether or not the PCI4410A device can claim cycles in PCI memory
space.

0 = Disables the PCI4410A device’s response to memory space accesses (default).
1 = Enables the PCI4410A device’s response to memory space accesses.

I/O space control. Bit 0 controls whether or not the PCI4410A device can claim cycles in PCI I/O space.

0 = Disables the PCI4410A device’s response to I/O space accesses (default).
1 = Enables the PCI4410A device’s response to I/O space accesses.

output driver (default)

output driver

; address parity errors are indicated by asserting SERR.

4–3

4.5 Status Register

The status register provides device information to the host system. Bits in this register can be read normally. A bit
in the status register is reset when a 1 is written to that bit location; a 0 written to a bit location has no effect. All bit
functions adhere to the definitions in the PCI Local Bus Specification. PCI bus status is shown through each function.
See Table 4–4 for the complete description of the register contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Status
Type R/C R/C R/C R/C R/C R R R/C R R R R R R R R
Default 0 0 0 0 0 0 1 0 0 0 0 1 0 0 0 0

Register: Status
Type: Read-only, Read/Clear
Offset: 06h
Default: 0210h

Table 4–4. Status Register Description

BIT SIGNAL TYPE FUNCTION

15 PAR_ERR R/C Detected parity error. Bit 15 is set when a parity error is detected (either address or data).
14 SYS_ERR R/C

13 MABORT R/C

12 TABT_REC R/C

11 TABT_SIG R/C

10–9 PCI_SPEED R

8 DATAPAR R/C

7 FBB_CAP R

6 UDF R

5 66MHZ R

4 CAPLIST R

3–0 RSVD R Reserved. Bits 3–0 return 0s when read.

Signaled system error. Bit 14 is set when SERR is enabled and the PCI4410A device signals a system error
to the host.

Received master abort. Bit 13 is set when a cycle initiated by the PCI4410A device on the PCI bus is
terminated by a master abort.

Received target abort. Bit 12 is set when a cycle initiated by the PCI4410A device on the PCI bus is
terminated by a target abort.

Signaled target abort. Bit 11 is set by the PCI4410A device when it terminates a transaction on the PCI bus
with a target abort.

DEVSEL timing. These bits encode the timing of DEVSEL and are hardwired 01b, indicating that the
PCI4410A device asserts PCI_SPEED at a medium speed on nonconfiguration cycle accesses.

Data parity error detected.

0 = The conditions for setting bit 8 have not been met.
1 = A data parity error occurred, and the following conditions were met:

a. PERR
b. The PCI4410A device was the bus master during the data parity error.
c. Bit 6 (PERR_EN) in the command register (PCI offset 04h, see Section 4.4) is set.

Fast back-to-back capable. The PCI4410A device cannot accept fast back-to-back transactions; therefore,
bit 7 is hardwired to 0.

User-definable feature support. The PCI4410A device does not support the user-definable features;
therefore, bit 6 is hardwired to 0.

66-MHz capable. The PCI4410A device operates at a maximum PCLK frequency of 33 MHz; therefore, bit
5 is hardwired to 0.

Capabilities list. Bit 4 returns 1 when read. This bit indicates that capabilities, in addition to standard PCI
capabilities, are implemented. The linked list of PCI power management capabilities is implemented in this
function.

was asserted by any PCI device, including the PCI4410A device.

4–4

4.6 Revision ID Register

The revision ID register indicates the silicon revision of the PCI4410A device.

Bit 7 6 5 4 3 2 1 0
Name Revision ID
Type R R R R R R R R
Default 0 0 0 0 0 0 1 0

Register: Revision ID
Type: Read-only
Offset: 08h
Default: 02h

4.7 PCI Class Code Register

The class code register recognizes the PCI4410A device as a bridge device (06h) and CardBus bridge device (07h)
with a 00h programming interface.

Bit 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name PCI class code

Base class Subclass Programming interface

Type R R R R R R R R R R R R R R R R R R R R R R R R
Default 0 0 0 0 0 1 1 0 0 0 0 0 0 1 1 1 0 0 0 0 0 0 0 0

Register: PCI class code
Type: Read-only
Offset: 09h
Default: 06 0700h

4.8 Cache Line Size Register

The cache line size register is programmed by host software to indicate the system cache line size.

Bit 7 6 5 4 3 2 1 0
Name Cache line size
Type R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0

Register: Cache line size
Type: Read/Write
Offset: 0Ch
Default: 00h

4–5

4.9 Latency Timer Register

The latency timer register specifies the latency timer for the PCI4410A device in units of PCI clock cycles. When the
PCI4410A device is a PCI bus initiator and asserts FRAME

, the latency timer begins counting from zero. If the latency
timer expires before the PCI4410A transaction has terminated, the PCI4410A device terminates the transaction when
its GNT

is deasserted.

Bit 7 6 5 4 3 2 1 0
Name Latency timer
Type R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0

Register: Latency timer
Type: Read/Write
Offset: 0Dh
Default: 00h

4.10 Header Type Register

This register returns 82h when read, indicating that the PCI4410A configuration spaces adhere to the CardBus bridge
PCI header. The CardBus bridge PCI header ranges from PCI register 0 to 7Fh, and 80h–FFh are user-definable
extension registers.

Bit 7 6 5 4 3 2 1 0
Name Header type
Type R R R R R R R R
Default 1 0 0 0 0 0 1 0

Register: Header type
Type: Read-only
Offset: 0Eh
Default: 82h

4.11 BIST Register

Because the PCI4410A device does not support a built-in self-test (BIST), this register returns the value of 00h when
read.

Bit 7 6 5 4 3 2 1 0
Name BIST
Type R R R R R R R R
Default 0 0 0 0 0 0 0 0

Register: BIST
Type: Read-only
Offset: 0Fh
Default: 00h

4–6

4.12 CardBus Socket/ExCA Base Address Register

The CardBus socket/ExCA base-address register is programmed with a base address referencing the CardBus
socket registers and the memory-mapped ExCA register set. Bits 31–12 are read/write and allow the base address
to be located anywhere in the 32-bit PCI memory address space on a 4-Kbyte boundary. Bits 11–0 are read-only,
returning 0s when read. When software writes all 1s to this register, the value read back is FFFF F000h, indicating
that at least 4 Kbytes of memory address space are required. The CardBus registers start at offset 000h, and the
memory-mapped ExCA registers begin at offset 800h.

Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Name CardBus socket/ExCA base-address
Type R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name CardBus socket/ExCA base-address
Type R/W R/W R/W R/W R R R R R R R R R R R R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: CardBus socket/ExCA base-address
Type: Read-only, Read/Write
Offset: 10h
Default: 0000 0000h

4.13 Capability Pointer Register

The capability pointer register provides a pointer into the PCI configuration header where the PCI
power-management register block resides. PCI header doublewords at A0h and A4h provide the power-management
(PM) registers. The socket has its own capability pointer register. This register returns A0h when read.

Bit 7 6 5 4 3 2 1 0
Name Capability pointer
Type R R R R R R R R
Default 1 0 1 0 0 0 0 0

Register: Capability pointer
Type: Read-only
Offset: 14h
Default: A0h

4–7

4.14 Secondary Status Register

The secondary status register is compatible with the PCI-to-PCI bridge secondary status register and indicates
CardBus-related device information to the host system. This register is very similar to the status register (PCI offset
06h); status bits are cleared by writing a 1. See Table 4–5 for a complete description of the register contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Secondary status
Type R/C R/C R/C R/C R/C R R R/C R R R R R R R R
Default 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0

Register: Secondary status
Type: Read-only, Read/Clear
Offset: 16h
Default: 0200h

Table 4–5. Secondary Status Register Description

BIT SIGNAL TYPE FUNCTION

15 CBPARITY R/C Detected parity error. Bit 15 is set when a CardBus parity error is detected (either address or data).
14 CBSERR R/C

13 CBMABORT R/C

12 REC_CBTA R/C

11 SIG_CBTA R/C

10–9 CB_SPEED R

8 CB_DPAR R/C

7 CBFBB_CAP R

6 CB_UDF R

5 CB66MHZ R

4–0 RSVD R Reserved. Bits 4–0 return 0s when read.

Signaled system error. Bit 14 is set when CSERR is signaled by a CardBus card. The PCI4410A device
does not assert CSERR

Received master abort. Bit 13 is set when a cycle initiated by the PCI4410A device on the CardBus bus
is terminated by a master abort.

Received target abort. Bit 12 is set when a cycle initiated by the PCI4410A device on the CardBus bus
is terminated by a target abort.

Signaled target abort. Bit 11 is set by the PCI4410A device when it terminates a transaction on the CardBus
bus with a target abort.

CDEVSEL timing. These bits encode the timing of CDEVSEL and are hardwired 01b, indicating that the
PCI4410A device asserts CB_SPEED at a medium speed.

CardBus data parity error detected.

0 = The conditions for setting bit 8 have not been met.
1 = A data parity error occurred and the following conditions were met:

a. CPERR
b. The PCI4410A device was the bus master during the data parity error.
c. Bit 0 (CPERREN) in the bridge control register (PCI offset 3Eh, see Section 4.25) is set.

Fast back-to-back capable. The PCI4410A device cannot accept fast back-to-back transactions;
therefore, bit 7 is hardwired to 0.

User-definable feature support. The PCI4410A device does not support the user-definable features;
therefore, bit 6 is hardwired to 0.

66-MHz capable. The PCI4410A CardBus interface operates at a maximum CCLK frequency of 33 MHz;
therefore, bit 5 is hardwired to 0.

.

was asserted on the CardBus interface.

4–8

4.15 PCI Bus Number Register

This register is programmed by the host system to indicate the bus number of the PCI bus to which the PCI4410A
device is connected. The PCI4410A device uses this register in conjunction with the CardBus bus number (PCI offset
19h, see Section 4.16) and subordinate bus number (PCI offset 1Ah, see Section 4.17) registers to determine when
to forward PCI configuration cycles to its secondary buses.

Bit 7 6 5 4 3 2 1 0
Name PCI bus number
Type R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0

Register: PCI bus number
Type: Read/Write
Offset: 18h
Default: 00h

4.16 CardBus Bus Number Register

This register is programmed by the host system to indicate the bus number of the CardBus bus to which the PCI4410A
device is connected. The PCI4410A device uses this register in conjunction with the PCI bus number (PCI offset 18h,
see Section 4.15) and subordinate bus number (PCI offset 1Ah, see Section 4.17) registers to determine when to
forward PCI configuration cycles to its secondary buses.

Bit 7 6 5 4 3 2 1 0
Name CardBus bus number
Type R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0

Register: CardBus bus number
Type: Read/Write
Offset: 19h
Default: 00h

4.17 Subordinate Bus Number Register

This register is programmed by the host system to indicate the highest-numbered bus below the CardBus bus. The
PCI4410A device uses this register in conjunction with the PCI bus number (PCI offset 18h, see Section 4.15) and
CardBus bus number (PCI offset 19h, see Section 4.16) registers to determine when to forward PCI configuration
cycles to its secondary buses.

Bit 7 6 5 4 3 2 1 0
Name Subordinate bus number
Type R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0

Register: Subordinate bus number
Type: Read/Write
Offset: 1Ah
Default: 00h

4–9

4.18 CardBus Latency Timer Register

This register is programmed by the host system to specify the latency timer for the PCI4410A CardBus interface in
units of CCLK cycles. When the PCI4410A device is a CardBus initiator and asserts CFRAME

, the CardBus latency
timer begins counting. If the latency timer expires before the PCI4410A transaction has terminated, the PCI4410A
device terminates the transaction at the end of the next data phase. A recommended minimum value for this register
is 20h, which allows most transactions to be completed.

Bit 7 6 5 4 3 2 1 0
Name CardBus latency timer
Type R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0

Register: CardBus latency timer
Type: Read/Write
Offset: 1Bh
Default: 00h

4.19 Memory Base Registers 0, 1

The memory base registers indicate the lower address of a PCI memory address range. These registers are used
by the PCI4410A device to determine when to forward a memory transaction to the CardBus bus and when to forward
a CardBus cycle to PCI. Bits 31–12 of these registers are read/write and allow the memory base to be located
anywhere in the 32-bit PCI memory space on 4-Kbyte boundaries. Bits 11–0 are read-only and always return 0s. Write
transactions to these bits have no effect. Bits 8 and 9 of the bridge control register (PCI offset 3Eh, see Section 4.25)
specify whether memory windows 0 and 1 are prefetchable or nonprefetchable. The memory base register or the
memory limit register must be nonzero for the PCI4410A device to claim any memory transactions through CardBus
memory windows (that is, these windows are not enabled by default to pass the first 4 Kbytes of memory to CardBus).

Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Name Memory base registers 0, 1
Type R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Memory base registers 0, 1
Type R/W R/W R/W R/W R R R R R R R R R R R R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: Memory base registers 0, 1
Type: Read-only, Read/Write
Offset: 1Ch, 24h
Default: 0000 0000h

4–10

4.20 Memory Limit Registers 0, 1

The memory limit registers indicate the upper address of a PCI memory address range. These registers are used
by the PCI4410A device to determine when to forward a memory transaction to the CardBus bus and when to forward
a CardBus cycle to PCI. Bits 31–12 of these registers are read/write and allow the memory base to be located
anywhere in the 32-bit PCI memory space on 4-Kbyte boundaries. Bits 11–0 are read-only and always return 0s. Write
transactions to these bits have no effect. Bits 8 and 9 of the bridge control register (PCI offset 3Eh, see Section 4.25)
specify whether memory windows 0 and 1 are prefetchable or nonprefetchable. The memory base register or the
memory limit register must be nonzero for the PCI4410A device to claim any memory transactions through CardBus
memory windows (that is, these windows are not enabled by default to pass the first 4 Kbytes of memory to CardBus).

Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Name Memory limit registers 0, 1
Type R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Memory limit registers 0, 1
Type R/W R/W R/W R/W R R R R R R R R R R R R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: Memory limit registers 0, 1
Type: Read-only, Read/Write
Offset: 20h, 28h
Default: 0000 0000h

4.21 I/O Base Registers 0, 1

The I/O base registers indicate the lower address of a PCI I/O address range. These registers are used by the
PCI4410A device to determine when to forward an I/O transaction to the CardBus bus and when to forward a CardBus
cycle to the PCI bus. The lower 16 bits of this register locate the bottom of the I/O window within a 64-Kbyte page,
and the upper 16 bits (31–16) are a page register that locates this 64-Kbyte page in 32-bit PCI I/O address space.
Bits 31–2 are read/write. Bits 1 and 0 are read-only and always return 0s, forcing I/O windows to be aligned on a
natural doubleword boundary.

NOTE: Either the I/O base or the I/O limit register must be nonzero to enable any I/O
transactions.

Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Name I/O base registers 0, 1
Type R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name I/O base registers 0, 1
Type R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: I/O base registers 0, 1
Type: Read-only, Read/Write
Offset: 2Ch, 34h
Default: 0000 0000h

4–11

4.22 I/O Limit Registers 0, 1

The I/O limit registers indicate the upper address of a PCI I/O address range. These registers are used by the
PCI4410A device to determine when to forward an I/O transaction to the CardBus bus and when to forward a CardBus
cycle to PCI. The lower 16 bits of this register locate the top of the I/O window within a 64-Kbyte page, and the upper
16 bits are a page register that locates this 64-Kbyte page in 32-bit PCI I/O address space. Bits 15–2 are read/write
and allow the I/O limit address to be located anywhere in the 64-Kbyte page (indicated by bits 31–16 of the appropriate
I/O base register) on doubleword boundaries.

Bits 31–16 are read-only and always return 0s when read. The page is set in the I/O base register. Bits 1 and 0 are
read-only and always return 0s, forcing I/O windows to be aligned on a natural doubleword boundary. Write
transactions to read-only bits have no effect. The PCI4410A device assumes that the lower 2 bits of the limit address
are 1s.

NOTE: The I/O base or the I/O limit register must be nonzero to enable an I/O transaction.

Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Name I/O limit registers 0, 1
Type R R R R R R R R R R R R R R R R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name I/O limit registers 0, 1
Type R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: I/O limit registers 0, 1
Type: Read-only, Read/Write
Offset: 30h, 38h
Default: 0000 0000h

4.23 Interrupt Line Register

The interrupt line register communicates interrupt line routing information.

Bit 7 6 5 4 3 2 1 0
Name Interrupt line
Type R/W R/W R/W R/W R/W R/W R/W R/W
Default 1 1 1 1 1 1 1 1

Register: Interrupt line
Type: Read/Write
Offset: 3Ch
Default: FFh

4–12

4.24 Interrupt Pin Register

The value read from the interrupt pin register is function dependent and depends on the interrupt signaling mode,
selected through bits 2–1 (INTMODE field) of the device control register (PCI offset 92h, see Section 4.35). The
PCI4410A device defaults to serialized PCI and ISA interrupt mode.

Bit 7 6 5 4 3 2 1 0
Name Interrupt pin
Type R R R R R R R R
Default 0 0 0 0 0 0 0 1

Register: Interrupt pin
Type: Read-only
Offset: 3Dh
Default: 01h

4–13

4.25 Bridge Control Register

The bridge control register provides control over various PCI4410A bridging functions. See Table 4–6 for a complete
description of the register contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Bridge control
Type R R R R R R/W R/W R/W R/W R/W R/W R R/W R/W R/W R/W
Default 0 0 0 0 0 0 1 1 0 1 0 0 0 0 0 0

Register: Bridge control
Type: Read-only, Read/Write
Offset: 3Eh
Default: 0340h

Table 4–6. Bridge Control Register Description

BIT SIGNAL TYPE FUNCTION

15–11 RSVD R Reserved. Bits 15–11 return 0s when read.

Write posting enable. Enables write posting to and from the CardBus sockets. Write posting enables

10 POSTEN R/W

9 PREFETCH1 R/W

8 PREFETCH0 R/W

7 INTR R/W

6 CRST R/W

5 MABTMODE R/W

4 RSVD R Reserved. Bit 4 returns 0 when read.
3 VGAEN R/W

2 ISAEN R/W

1 CSERREN R/W

0 CPERREN R/W

posting of write data on burst cycles. Operating with write posting disabled inhibits performance on burst
cycles. Note that bursted write data can be posted, but various write transactions cannot.

Memory window 1 type. Bit 9 specifies whether or not memory window 1 is prefetchable. This bit is socket
dependent. Bit 9 is encoded as:

0 = Memory window 1 is nonprefetchable.
1 = Memory window 1 is prefetchable (default).

Memory window 0 type. Bit 8 specifies whether or not memory window 0 is prefetchable. This bit is
encoded as:

0 = Memory window 0 is nonprefetchable.
1 = Memory window 0 is prefetchable (default).

PCI interrupt – IREQ routing enable. Bit 7 selects whether PC Card functional interrupts are routed to PCI
interrupts or to the IRQ specified in the ExCA registers.

0 = Functional interrupts are routed to PCI interrupts (default).
1 = Functional interrupts are routed to IRQ interrupts.

CardBus reset. When bit 6 is set, CRST is asserted on the CardBus interface. CRST also can be asserted
by passing a PRST

0 = CRST
1 = CRST

Master abort mode. Bit 5 controls how the PCI4410A device responds to a master abort when the
PCI4410A device is an initiator on the CardBus interface.

0 = Master aborts are not signaled (default).
1 = Signal target abort on PCI. Signal SERR

VGA enable. Bit 3 affects how the PCI4410A device responds to VGA addresses. When this bit is set,
accesses to VGA addresses are forwarded.

ISA mode enable. Bit 2 affects how the PCI4410A device passes I/O cycles within the 64-Kbyte ISA range.
This bit is not common between sockets. When this bit is set, the PCI4410A device does not forward the
last 768 bytes of each 1K I/O range to CardBus.

CSERR enable. Bit 1 controls the response of the PCI4410A device to CSERR signals on the CardBus
bus.

0 = CSERR is not forwarded to PCI SERR.
1 = CSERR

CardBus parity error response enable. Bit 0 controls the response of the PCI4410A device to CardBus
parity errors.

0 = CardBus parity errors are ignored.
1 = CardBus parity errors are reported using CPERR

assertion to CardBus.
is deasserted.
is asserted (default).

(if enabled)

is forwarded to PCI SERR.

.

4–14

4.26 Subsystem Vendor ID Register

The subsystem vendor ID register is used for system and option-card identification purposes and may be required
for certain operating systems. This register is read-only or read/write, depending on the setting of bit 5 (SUBSYSRW)
in the system control register (PCI offset 80h, see Section 4.29).

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Subsystem vendor ID
Type R R R R R R R R R R R R R R R R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: Subsystem vendor ID
Type: Read-only (Read/Write if enabled by SUBSYSRW)
Offset: 40h
Default: 0000h

4.27 Subsystem ID Register

The subsystem ID register is used for system and option-card identification purposes and may be required for certain
operating systems. This register is read-only or read/write, depending on the setting of bit 5 (SUBSYSRW) in the
system control register (PCI offset 80h, see Section 4.29).

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Subsystem ID
Type R R R R R R R R R R R R R R R R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: Subsystem ID
Type: Read-only (Read/Write if enabled by SUBSYSRW)
Offset: 42h
Default: 0000h

4.28 PC Card 16-Bit I/F Legacy-Mode Base-Address Register

The PCI4410A device supports the index/data scheme of accessing the ExCA registers, which is mapped by this
register. An address written to this register is the address for the index register and the address + 1 is the data address.
Using this access method, applications requiring index/data ExCA access can be supported. The base address can
be mapped anywhere in 32-bit I/O space on a word boundary; hence, bit 0 is read-only, returning 1 when read. See
Section 5, ExCA Compatibility Registers, for register offsets.

Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Name PC Card 16-bit I/F legacy-mode base address
Type R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name PC Card 16-bit I/F legacy-mode base address
Type R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1

Register: PC Card 16-bit I/F legacy-mode base address
Type: Read-only, Read/Write
Offset: 44h
Default: 0000 0001h

4–15

4.29 System Control Register

System-level initializations are performed through programming this doubleword register. See Table 4–7 for a
complete description of the register contents.

Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Name System control
Type R/W R/W R/W R/W R/W R/W R/C R/W R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0 0 1 0 0 0 1 0 0
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name System control
Type R/W R/W R R R R R R R/W R/W R/W R/W R/W R/W R/W R/W
Default 1 0 0 1 0 0 0 0 0 1 1 0 0 0 0 0

Register: System control
Type: Read-only, Read/Write, Read/Clear
Offset: 80h
Default: 0044 9060h

4–16

Table 4–7. System Control Register Description

BIT SIGNAL TYPE FUNCTION

Serialized PCI interrupt routing step. Bits 31 and 30 configure the serialized PCI interrupt stream signaling
and accomplish an even distribution of interrupts signaled on the four PCI interrupt slots. Bits 31 and 30
are global to all PCI4410A functions.

31–30 SER_STEP R/W

29 TIE_INTB_INTA R/W Tie INTB to INTA. When bit 29 is set to 1, INTB is tied to INTA (default is 0).
28 DIAGNOSTIC R/W TI diagnostic (IIC_Test) bit (default is 0).

27 OSEN R/W

26 SMIROUTE R/W

25 SMISTATUS R/C

24 SMIENB R/W

23 PCIPMEN R/W

22 CBRSVD R/W

21 VCCPROT R/W

20 REDUCEZV R/W

19 CDREQEN R/W

18–16 CDMACHAN R/W

15 MRBURSTDN R/W

00 = INTA
01 = INTA
10 = INTA
11 = INTA

Internal oscillator enable.

0 = Internal oscillator is disabled (default).
1 = Internal oscillator is enabled.

SMI interrupt routing. Bit 26 selects whether IRQ2 or CSC is signaled when a write occurs to power a PC
Card socket.

0 = PC Card power change interrupts are routed to IRQ2 (default).
1 = A CSC interrupt is generated on PC Card power changes.

SMI interrupt status. This bit is set when bit 24 (SMIENB) is set and a write occurs to set the socket power.
Writing a 1 to bit 25 clears the status.

0 = SMI interrupt is signaled (default).
1 = SMI interrupt is not signaled.

SMI interrupt mode enable. When bit 24 is set and a write to the socket power control occurs, the SMI
interrupt signaling is enabled and generates an interrupt.

PCI Bus Power Management Interface Specification (Revision 1.1) enable.

0 = Use PCI Bus Power Management Interface Specification (Revision 1.0) implementation (default).

1 = Use PCI Bus Power Management Interface Specification (Revision 1.1) implementation.
Note: See bits 2–0 (VERSION field) in the power management capability register (PCI offset A2h,
Section 4.41) for additional information.

CardBus reserved-terminals signaling. When a CardBus card is inserted and bit 22 is set, the RSVD
CardBus terminals are driven low. When this bit is 0, these signals are placed in a high-impedance state.

0 = 3-state CardBus RSVD

1 = Drive Cardbus RSVD low (default)
VCC protection enable.

0 = VCC protection is enabled for 16-bit cards (default).

1 = VCC protection is disabled for 16-bit cards.
Reduced zoomed-video enable. When this bit is enabled, pins A25–A22 of the card interface for PC

Card-16 cards are placed in the high-impedance state. This bit should not be set for normal ZV operation.
This bit is encoded as:

0 = Reduced zoomed video is disabled (default).

1 = Reduced zoomed video is enabled.
PC/PCI DMA card enable. When bit 19 is set, the PCI4410A device allows 16-bit PC Cards to request

PC/PCI DMA using the DREQ
94h, see Section 4.37).

0 = Ignore DREQ

1 = Signal DMA request on DREQ
PC/PCI DMA channel assignment. Bits 18–16 are encoded as:

0–3 = 8-bit DMA channels

4 = PCI master; not used (default)

5–7 = 16-bit DMA channels
Memory-read burst-enable downstream. When bit 15 is set, memory-read transactions are allowed to

burst downstream.

0 = Downstream memory-read burst is disabled.

1 = Downstream memory-read burst is enabled (default).

/INTB signal in INTA/INTB slots (default)
/INTB signal in INTB/INTC slots
/INTB signal in INTC/INTD slots
/INTB signal in INTD/INTA slots

signaling. DREQ is selected through the socket DMA register 0 (PCI offset

signaling from PC Cards (default)

4–17

Table 4–7. System Control Register Description (Continued)

BIT SIGNAL TYPE FUNCTION

Memory-read burst-enable upstream. When bit 14 is set, the PCI4410A device allows memory-read

14 MRBURSTUP R/W

13 SOCACTIVE R

12 RSVD R Reserved. Bit 12 returns 1 when read.

11 PWRSTREAM R

10 DELAYUP R

9 DELAYDOWN R

8 INTERROGATE R

7 AUTOPWRSWEN R/W

6 PWRSAVINGS R/W

5 SUBSYSRW R/W

4 CB_DPAR R/W

3 CDMA_EN R/W

2 ExCAPower R/W

1 KEEPCLK R/W

0 RIMUX R/W

transactions to burst upstream.

0 = Upstream memory-read burst is disabled (default).
1 = Upstream memory-read burst is enabled.

Socket activity status. When set, bit 13 indicates access has been performed to or from a PC card and
is cleared upon read of this status bit.

0 = No socket activity (default)
1 = Socket activity

Power stream in progress status bit. When set, bit 1 1 indicates that a power stream to the power switch
is in progress and a powering change has been requested. This bit is cleared when the power stream
is complete.

0 = Power stream is complete and delay has expired.
1 = Power stream is in progress.

Power-up delay in progress status. When set, bit 9 indicates that a power-up stream has been sent to
the power switch and proper power may not yet be stable. This bit is cleared when the power-up delay
has expired.

Power-down delay in progress status. When set, bit 10 indicates that a power-down stream has been
sent to the power switch and proper power may not yet be stable. This bit is cleared when the
power-down delay has expired.

Interrogation in progress. When set, bit 8 indicates an interrogation is in progress and clears when
interrogation completes. This bit is socket dependent.

0 = Interrogation is not in progress (default).
1 = Interrogation is in progress.

Auto power-switch enable.

0 = Bit 5 (AUTOPWRSWEN) in ExCA power control register (ExCA offset 02h, see Section 5.3)

is disabled. (default).

1 = Bit 5 (AUTOPWRSWEN) in ExCA power control register (ExCA offset 02h, see Section 5.3)

is enabled.

Power savings mode enable. When this bit is set, if a CB card is inserted, idle, and without a CB clock,
then the applicable CB state machine is not clocked.

Subsystem ID (PCI offset 42h, see Section 4.27), subsystem vendor ID (PCI offset 40h, see
Section 4.26), ExCA identification and revision (ExCA offset 00h, see Section 5.1) registers read/write
enable.

0 = Subsystem ID, subsystem vendor ID, ExCA identification and revision registers are read/write.
1 = Subsystem ID, subsystem vendor ID, ExCA identification and revision registers are read-only

(default).

CardBus data parity error SERR signaling enable

0 = CardBus data parity error is not signaled on PCI SERR
1 = CardBus data parity error is signaled on PCI SERR

PC/PCI DMA enable. Bit 3 enables PC/PCI DMA when set if MFUNC0–MFUNC6 are configured for
centralized DMA.

0 = Centralized DMA is disabled (default).
1 = Centralized DMA is enabled.

ExCA power control bit. Enabled by selecting the 82365SL mode.

0 = Enables 3.3 V
1 = Enables 5 V

Keep clock. This bit works with PCI and CB CLKRUN protocols.

0 = Allows normal functioning of both CLKRUN
1 = Does not allow CB clock or PCI clock to be stopped using the CLKRUN

RI_OUT/PME multiplex enable.

0 = RI_OUT

same time, RI_OUT

1 = Only PME

and PME are both routed to the RI_OUT/PME terminal. If both are enabled at the

has precedence over PME.

is routed to the RI_OUT/PME terminal.

protocols (default)

.

.

protocols

4–18

4.30 General Status Register

The general status register provides the general device status information. The status of the serial EEPROM interface
is provided through this register. See Table 4–8 for a complete description of the register contents.

Bit 7 6 5 4 3 2 1 0
Name General status
Type R R R R R R R/C R
Default 0 0 0 0 0 X 0 0

Register: General status
Type: Read/Clear, Read-only
Offset: 85h (Function 0)
Default: 00h

Table 4–8. General Status Register Description

BIT SIGNAL TYPE FUNCTION

7–3 RSVD R Reserved. Bits 7–3 return 0s when read.

Serial EEPROM detect. Serial EEPROM is detected by sampling a logic high on SCL while PRST is low.

2 EEDETECT R

1 DATAERR R/C

0 EEBUSY R

When this bit is set, the serial ROM is detected. This status bit is encoded as:

0 = EEPROM is not detected (default).
1 = EEPROM is detected.

Serial EEPROM data error status. This bit indicates when a data error occurs on the serial EEPROM
interface. This bit may be set due to a missing acknowledge. This bit is cleared by a writeback of 1.

0 = No error is detected (default).
1 = Data error is detected.

Serial EEPROM busy status. This bit indicates the status of the PCI4410A serial EEPROM circuitry. This
bit is set during the loading of the subsystem ID value.

0 = Serial EEPROM circuitry is not busy (default).
1 = Serial EEPROM circuitry is busy.

4.31 General Control Register

The general control register provides top-level PCI arbitration control. See Table 4–9 for a complete description of
the register contents.

Bit 7 6 5 4 3 2 1 0
Name General control
Type R R R R R/W R R/W R/W
Default 0 0 0 0 0 0 0 0

Register: General control
Type: Read-Only, Read/Write
Offset: 86h
Default: 00h

Table 4–9. General Control Register Description

BIT SIGNAL TYPE FUNCTION

7–4 RSVD R Reserved. Bits 7–4 return 0s when read.

3 DISABLE_OHCI R/W When bit 3 is set, the open HCI 1394 controller function is completely nonaccessible and nonfunctional.
2 RSVD R Reserved. Bit 2 returns 0 when read.

Controls top-level PCI arbitration.

00 = 1394 open HCI priority

1–0 ARB_CTRL R/W

01 = CardBus priority
10 = Fair round robin
11 = Reserved (fair round robin)

4–19

4.32 Multifunction Routing Register

The multifunction routing register is used to configure the MFUNC0–MFUNC6 terminals. These terminals can be
configured for various functions. All multifunction terminals default to the general-purpose input configuration. This
register is intended to be programmed once at power-on initialization. The default value for this register can also be
loaded through a serial bus EEPROM. See Table 4–10 for a complete description of the register contents.

Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Name Multifunction routing
Type R R R R R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Multifunction routing
Type R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: Multifunction routing
Type: Read-only, Read/Write
Offset: 8Ch
Default: 0000 0000h

Table 4–10. Multifunction Routing Register Description

BIT SIGNAL TYPE FUNCTION

31–28 RSVD R Bits 31–28 return 0s when read.

Multifunction terminal 6 configuration. These bits control the internal signal mapped to the MFUNC6 terminal
as follows:

27–24 MFUNC6 R/W

23–20 MFUNC5 R/W

19–16 MFUNC4 R/W

15–12 MFUNC3 R/W

11–8 MFUNC2 R/W

0000 = RSVD 0100 = IRQ4 1000 = IRQ8 1100 = IRQ12
0001 = CLKRUN
0010 = IRQ2 0110 = IRQ6 1010 = IRQ10 1110 = IRQ14
0011 = IRQ3 0111 = IRQ7 1011 = IRQ11 1111 = IRQ15

Multifunction terminal 5 configuration. These bits control the internal signal mapped to the MFUNC5 terminal
as follows:

0000 = GPI4 0100 = IRQ4 1000 = CAUDPWM 1100 = LED_SKT
0001 = GPO4 0101 = D3_STAT
0010 = PCGNT
0011 = IRQ3 0111 = ZVSEL0 1011 = IRQ11 1111 = IRQ15

Multifunction terminal 4 configuration. These bits control the internal signal mapped to the MFUNC4 terminal
as follows:

NOTE: When the serial bus mode is implemented by pulling up the VCCD0

MFUNC4 terminal provides the SCL signaling.

0000 = GPI3 0100 = IRQ4 1000 = CAUDPWM 1100 = RI_OUT
0001 = GPO3 0101 = IRQ5 1001 = IRQ9 1101 = LED_SKT
0010 = PCI LOCK
0011 = IRQ3 0111 = ZVSEL0 1011 = IRQ11 1111 = IRQ15

Multifunction terminal 3 configuration. These bits control the internal signal mapped to the MFUNC3 terminal
as follows:

0000 = RSVD 0100 = IRQ4 1000 = IRQ8 1100 = IRQ12
0001 = IRQSER 0101 = IRQ5 1001 = IRQ9 1101 = IRQ13
0010 = IRQ2 0110 = IRQ6 1010 = IRQ10 1110 = IRQ14
0011 = IRQ3 0111 = IRQ7 1011 = IRQ11 1111 = IRQ15

Multifunction terminal 2 configuration. These bits control the internal signal mapped to the MFUNC2 terminal
as follows:

0000 = GPI2 0100 = IRQ4 1000 = CAUDPWM 1100 = RI_OUT
0001 = GPO2 0101 = IRQ5 1001 = IRQ9 1101 = D3_STAT
0010 = PCREQ 0110 = ZVSTAT 1010 = IRQ10 1110 = GPE
0011 = IRQ3 0111 = ZVSEL0 1011 = IRQ11 1111 = IRQ7

0101 = IRQ5 1001 = IRQ9 1101 = IRQ13

1001 = IRQ9 1101 = Diagnostic setup: OHCI test

0110 = ZVSTAT 1010 = IRQ10 1110 = GPE

and VCCD1 terminals, the

0110 = ZVSTAT 1010 = IRQ10 1 110 = GPE

4–20

Table 4–10. Multifunction Routing Register Description (Continued)

BIT SIGNAL TYPE FUNCTION

Multifunction terminal 1 configuration. These bits control the internal signal mapped to the MFUNC1 terminal
as follows:

NOTE: When the serial bus mode is implemented by pulling up the VCCD0

7–4 MFUNC1 R/W

Multifunction terminal 0 configuration. These bits control the internal signal mapped to the MFUNC0 terminal
as follows:

3–0 MFUNC0 R/W

MFUNC1 terminal provides the SDA signaling.

0000 = GPI1 0100 = IRQ4 1000 = CAUDPWM 1100 = LED_SKT
0001 = GPO1 0101 = IRQ5 1001 = IRQ9 1101 = IRQ13
0010 = D3_STAT
0011 = IRQ3 0111 = ZVSEL0 1011 = IRQ11 1111 = IRQ15

0000 = GPI0 0100 = IRQ4 1000 = CAUDPWM 1100 = LED_SKT
0001 = GPO0 0101 = IRQ5 1001 = IRQ9 1101 = IRQ13
0010 = INTA
0011 = IRQ3 0111 = ZVSEL0 1011 = IRQ11 1111 = IRQ15

0110 = ZVSTAT 1010 = IRQ10 1110 = GPE

0110 = ZVSTAT 1010 = IRQ10 1110 = GPE

4.33 Retry Status Register

and VCCD1 terminals, the

The retry status register enables the retry timeout counters and displays the retry expiration status. The flags are set
when the PCI4410A device retries a PCI or CardBus master request and the master does not return within 2

15

PCI
clock cycles. The flags are cleared by writing a 1 to the bit. These bits are expected to be incorporated into the
command, status, and bridge control registers by the PCI SIG. See Table 4–11 for a complete description of the
register contents.

Bit 7 6 5 4 3 2 1 0
Name Retry status
Type R/W R/W R R R/C R R/C R
Default 1 1 0 0 0 0 0 0

Register: Retry status
Type: Read-only, Read/Write, Read/Clear
Offset: 90h
Default: C0h

Table 4–11. Retry Status Register Description

BIT SIGNAL TYPE FUNCTION

PCI retry timeout counter enable. Bit 7 is encoded:

7 PCIRETRY R/W

6 CBRETRY R/W

5–4 RSVD R Reserved. Bits 5 and 4 return 0s when read.

3 TEXP_CB R/C

2 RSVD R Reserved. Bit 2 returns 0 when read.

1 TEXP_PCI R/C

0 RSVD R Reserved. Bit 0 returns 0 when read.

0 = PCI retry counter is disabled.
1 = PCI retry counter is enabled (default).

CardBus retry timeout counter enable. Bit 6 is encoded:

0 = CardBus retry counter is disabled.
1 = CardBus retry counter is enabled (default).

CardBus target retry expired. Write a 1 to clear bit 3.

0 = Inactive (default)
1 = Retry has expired.

PCI target retry expired. Write a 1 to clear bit 1.

0 = Inactive (default)
1 = Retry has expired.

4–21

4.34 Card Control Register

The card control register is provided for PCI1130 compatibility. RI_OUT is enabled through this register. See
Table 4–12 for a complete description of the register contents.

Bit 7 6 5 4 3 2 1 0
Name Card control
Type R/W R/W R/W R R R/W R/W R/C
Default 0 0 0 0 0 0 0 0

Register: Card control
Type: Read-only, Read/Write, Read/Clear
Offset: 91h
Default: 00h

Table 4–12. Card Control Register Description

BIT SIGNAL TYPE FUNCTION

Ring indicate output enable.

0 = Disables any routing of RI_OUT

7 RIENB R/W

6 ZVENABLE R/W

5

4–3 RSVD R Reserved. Bits 4 and 3 return 0 when read.

2 AUD2MUX R/W

1 SPKROUTEN R/W

0 IFG R/C

ZV

PORT_ENABLE

R/W

1 = Enables RI_OUT

system control register (PCI offset 80h, see Section 4.29) is set to 0, and for routing to MFUNC2
or MFUNC4.

Compatibility ZV mode enable. When set, the PC Card socket interface ZV terminals enter a
high-impedance state. This bit defaults to 0.

ZV output port enable. When bit 5 is set, the ZV output port is enabled. If bit 6 (ZVENABLE) is set, ZV
data from the PC Card interface is routed to the ZV output port. Otherwise, the ZV output port drives
a stable 0 pattern on all pins.

When bit 5 is not set, the ZV output port pins are placed in a high-impedance state. Default is 0.

CardBus audio-to-IRQMUX. When set, the CAUDIO CardBus signal is routed to the corresponding
multifunction terminal, which may be configured for CAUDPWM.

Speaker out enable. When bit 1 is set, SPKR on the PC Card is enabled and is routed to SPKROUT.
The SPKROUT terminal drives data only when the socket’s SPKROUTEN bit is set. This bit is encoded
as:

0 = SPKR
1 = SPKR

Interrupt flag. Bit 0 is the interrupt flag for 16-bit I/O PC Cards and for CardBus cards. Bit 0 is set when
a functional interrupt is signaled from a PC Card interface. Write back a 1 to clear this bit.

0 = No PC Card functional interrupt is detected (default).
1 = PC Card functional interrupt is detected.

to SPKROUT is not enabled (default).
to SPKROUT is enabled.

signal for routing to the RI_OUT/PME terminal, when bit 0 (RIMUX) in the

signal (default).

4–22

4.35 Device Control Register

The device control register is provided for PCI1130 compatibility. The interrupt mode select and the socket-capable
force bits are programmed through this register. See Table 4–13 for a complete description of the register contents.

Bit 7 6 5 4 3 2 1 0
Name Device control
Type R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 1 1 0 0 1 1 0

Register: Device control
Type: Read-only, Read/Write
Offset: 92h
Default: 66h

Table 4–13. Device Control Register Description

BIT SIGNAL TYPE FUNCTION

Socket-power lock bit. When this bit is set to 1, software cannot power down the PC Card socket

7 SKTPWR_LOCK R/W

6 3VCAPABLE R/W

5 IO16V2 R/W Diagnostic bit. This bit defaults to 1.
4 BUS_HOLDER_EN R/W
3 TEST R/W TI test. Only a 0 should be written to bit 3.

2–1 INTMODE R/W

0 RSVD R/W Reserved. Bit 0 is reserved for test purposes. Only 0 should be written to this bit.

while in D3. This may be necessary to support wake on LAN or RING if the operating system is
programmed to power down a socket when the CardBus controller is placed in the D3 state.

3-V socket-capable force

0 = Not 3-V capable
1 = 3-V capable (default)

Bus-holder cell enable/disable. Setting bit 4 to 1 enables the bus-holder cells on the 1394 link
interface. Default state is 0, bus-holder cells disabled.

Interrupt signaling mode. Bits 2 and 1 select the interrupt signaling mode. The interrupt signaling
mode bits are encoded:

00 = Parallel PCI interrupts only
01 = Parallel IRQ and parallel PCI interrupts
10 = IRQ serialized interrupts and parallel PCI interrupt
11 = IRQ and PCI serialized interrupts (default)

4–23

4.36 Diagnostic Register

The diagnostic register is provided for internal TI test purposes. In addition, the diagnostic register can be used to
control CSC interrupt routing, enable asynchronous interrupts, and alter the PCI vendor ID and device ID register
fields. See Table 4–14 for a complete description of the register contents.

Bit 7 6 5 4 3 2 1 0
Name Diagnostic
Type R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 1 0 0 0 0 1

Register: Diagnostic
Type: Read/Write
Offset: 93h
Default: 21h

Table 4–14. Diagnostic Register Description

BIT SIGNAL TYPE FUNCTION

This bit defaults to 0. This bit causes software to fail to recognize the PCI4410A device when set to

7 TRUE_VAL R/W

6 RSVD R/W Reserved. Bit 6 returns 0 when read.

5 CSC R/W

4 DIAG4 R/W Diagnostic RETRY_DIS. Delayed transaction disabled.
3 DIAG3 R/W Diagnostic RETRY_EXT . Extends the latency from 16 to 64.
2 DIAG2 R/W Diagnostic DISCARD_TIM_SEL_CB. Set = 210, reset = 215.
1 DIAG1 R/W Diagnostic DISCARD_TIM_SEL_PCI. Set = 210, reset = 215.

0 ASYNCINT R/W

1. This bit is encoded as:
0 = Reads true values from the PCI vendor ID and PCI device ID registers (default).
1 = Reads all 1s from the PCI vendor ID and PCI device ID registers.

CSC interrupt routing control

0 = CSC interrupts are routed to PCI if ExCA 803 (see Section 5.4) bit 4 = 1.
1 = CSC interrupts are routed to PCI if ExCA 805 (see Section 5.6) bits 7–4 = 0000b (default).

In this case, the setting of ExCA 803 bit 4 is a don’t care.

Asynchronous interrupt enable.

0 = CSC interrupt is not generated asynchronously.
1 = CSC interrupt is generated asynchronously (default).

4–24

4.37 Socket DMA Register 0

The socket DMA register 0 provides control over the PC Card DMA request (DREQ) signaling. See Table 4–15 for
a complete description of the register contents.

Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Name Socket DMA register 0
Type R R R R R R R R R R R R R R R R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Socket DMA register 0
Type R R R R R R R R R R R R R R R/W R/W
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: Socket DMA register 0
Type: Read-only, Read/Write
Offset: 94h
Default: 0000 0000h

Table 4–15. Socket DMA Register 0 Description

BIT SIGNAL TYPE FUNCTION

31–2 RSVD R Reserved. Bits 31–2 return 0s when read.

DMA request (DREQ). Bits 1 and 0 indicate which pin on the 16-bit PC Card interface acts as DREQ during
DMA transfers. This field is encoded as:

1–0 DREQPIN R/W

00 = Socket is not configured for DMA (default).
01 = DREQ
10 = DREQ
11 = DREQ

uses SPKR.
uses IOIS16.

uses INPACK.

4–25

4.38 Socket DMA Register 1

The socket DMA register 1 provides control over the distributed DMA (DDMA) registers and the PCI portion of DMA
transfers. The DMA base address locates the DDMA registers in a 16-byte region within the first 64K bytes of PCI
I/O address space. See Table 4–16 for a complete description of the register contents.

NOTE: 32-bit transfers are not supported; the maximum transfer possible for 16-bit PC Cards
is 16 bits.

Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Name Socket DMA register 1
Type R R R R R R R R R R R R R R R R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Socket DMA register 1
Type R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R R/W R/W R/W
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: Socket DMA register 1
Type: Read-only, Read/Write
Offset: 98h
Default: 0000 0000h

Table 4–16. Socket DMA Register 1 Description

BIT SIGNAL TYPE FUNCTION

31–16 RSVD R Reserved. Bits 31–16 return 0s when read.

DMA base address. Locates the socket’s DMA registers in PCI I/O space. This field represents a 16-bit PCI

15–4 DMABASE R/W

3 EXTMODE R Extended addressing. This feature is not supported by the PCI4410A device and always returns a 0.

2–1 XFERSIZE R/W

0 DDMAEN R/W

I/O address. The upper 16 bits of the address are hardwired to 0, forcing this window to within the lower
64K bytes of I/O address space. The lower 4 bits are hardwired to 0 and are included in the address decode.
Thus, the window is aligned to a natural 16-byte boundary.

Transfer size. Bits 2 and 1 specify the width of the DMA transfer on the PC Card interface and are
encoded as:

00 = Transfers are 8 bits (default).
01 = Transfers are 16 bits.
10 = Reserved
11 = Reserved

DDMA registers decode enable. Enables the decoding of the distributed DMA registers based on the value
of bits 15–4 (DMABASE field).

0 = Disabled (default)
1 = Enabled

4–26

4.39 Capability ID Register

The capability ID register identifies the linked list item as the register for PCI power management. The register returns
01h when read, which is the unique ID assigned by the PCI SIG for the PCI location of the capabilities pointer and
the value.

Bit 7 6 5 4 3 2 1 0
Name Capability ID
Type R R R R R R R R
Default 0 0 0 0 0 0 0 1

Register: Capability ID
Type: Read-only
Offset: A0h
Default: 01h

4.40 Next-Item Pointer Register

The next-item pointer register indicates the next item in the linked list of the PCI power-management capabilities.
Because the PCI4410A functions include only one capabilities item, this register returns 0s when read.

Bit 7 6 5 4 3 2 1 0
Name Next-item pointer
Type R R R R R R R R
Default 0 0 0 0 0 0 0 0

Register: Next-item pointer
Type: Read-only
Offset: A1h
Default: 00h

4–27

4.41 Power Management Capabilities Register

This register contains information on the capabilities of the PC Card function related to power management. Both
PCI4410A CardBus bridge functions support D0, D1, D2, and D3 power states. See Table 4–17 for a complete
description of the register contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Power management capabilities
Type R/W R R R R R R R R R R R R R R R
Default 1 1 1 1 1 1 1 0 0 0 1 1 0 0 0 1

Register: Power management capabilities
Type: Read/Write, Read-only
Offset: A2h
Default: FE31h

Table 4–17. Power Management Capabilities Register Description

BIT SIGNAL TYPE FUNCTION

PME support. This 5-bit field indicates the power states from which the PCI4410A functions can assert
PME

. A 0 (zero) for any bit indicates that the function cannot assert the PME signal while in that power

state. These five bits return 11111b when read. Each of these bits is described below:

15 PME_SUPPORT R/W Bit 15 defaults to the value 1, indicating the PME signal can be asserted from the D3

14–11 PME_SUPPORT R Bit 14 contains the value 1, indicating that the PME signal can be asserted from D3

10 D2_SUPPORT R

9 D1_SUPPORT R

8–6 RSVD R Reserved. Bits 8–6 return 0s when read.

5 DSI R

4 AUX_PWR R

3 PMECLK R

2–0 VERSION R

bit is R/W because wake-up support from D3
power source to the VCC terminals. If the system designer chooses not to provide an auxiliary power
source to the VCC terminals for D3

Bit 13 contains the value 1, indicating that the PME
Bit 12 contains the value 1, indicating that the PME
Bit 11 contains the value 1, indicating that the PME

D2 support. Bit 10 returns a 1 when read, indicating that the CardBus function supports the D2 device
power state.

D1 support. Bit 9 returns a 1 when read, indicating that the CardBus function supports the D1 device
power state.

Device-specific initialization. Bit 5 returns 1 when read, indicating that the CardBus controller function
requires special initialization (beyond the standard PCI configuration header) before the generic class
device driver is able to use it.

Auxiliary power source. Bit 4 is meaningful only if bit 15 (PME_Support, D3
set, it indicates that support for PME
of a proprietary delivery vehicle. When bit 4 is 0, it indicates that the function supplies its own auxiliary
power source. Because the PCI4410A device requires an auxiliary power supply, this bit returns 1.

PME clock. Bit 3 returns 0 when read, indicating that no host bus clock is required for the PCI4410A
device to generate PME

Version. Bits 2–0 return 001b when read, indicating that there are four bytes of general-purpose power
management (PM) registers as described in the PCI Bus Power Management Interface Specification.
See bit 23 (PCIPMEN) in the system control register (PCI offset 80h, Section 4.29) for additional
information.
It is recommended that the PCIPMEN bit be set by BIOS. If PCIPMEN is set, bits 2–0 (VERSION field)
will return 010b, indicating support for the PCI Bus Power Management Interface Specification
(Revision 1.1).

.

wake-up support, the BIOS should write a 0 to this bit.

cold

in D3

is contingent on the system providing an auxiliary

cold

signal can be asserted from D2 state.
signal can be asserted from D1 state.
signal can be asserted from the D0 state.

) is set. When bit 4 is

requires auxiliary power supplied by the system by way

cold

cold

hot

cold

state.

state. This

4–28

4.42 Power Management Control/Status Register

The power management control/status register determines and changes the current power state of the PCI4410A
CardBus function. The contents of this register are not affected by the internally generated reset caused by the
transition from D3
transition. TI-specific registers, PCI power management registers, and the legacy base address register are not reset.
See Table 4–18 for a complete description of the register contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Power management control/status
Type R/C R R R R R R R/W R R R R R R R/W R/W
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: Power management control/status
Type: Read-only, Read/Write, Read/Clear
Offset: A4h
Default: 0000h

BIT SIGNAL TYPE FUNCTION

15 PMESTAT R/C

14–13 DATASCALE R

12–9 DATASEL R

8 PME_EN R/W

7–5 RSVD R Reserved. Bits 7–5 return 0s when read.

4 DYN_DATA_PME_EN R

3–2 RSVD R Reserved. Bits 3–2 return 0s when read.

1–0 PWR_STATE R/W

to D0 state. All PCI, ExCA, and CardBus registers are reset as a result of a D3

hot

Table 4–18. Power Management Control/Status Register Description

PME status. Bit 15 is set when the CardBus function normally would assert PME, independent
of the state of bit 8 (PME_EN). Bit 15 is cleared by a writeback of 1, and this also clears the PME
signal if PME was asserted by this function. Writing a 0 to this bit has no effect.

Data scale. This 2-bit field returns 0s when read. The CardBus function does not return any
dynamic data, as indicated by bit 4 (DYN_DATA_PME_EN).

Data select. This 4-bit field returns 0s when read. The CardBus function does not return any
dynamic data, as indicated by bit 4 (DYN_DATA_PME_EN).

PME enable. When set to 1, bit 8 enables the function to assert PME. When cleared to 0, the
assertion of PME

Dynamic data PME enable. Bit 4 returns 0 when read, because the CardBus function does not
report dynamic data.

Power state. This 2-bit field is used both to determine the current power state of a function and
to set the function into a new power state. This field is encoded as:

00 = D0
01 = D1
10 = D2
11 = D3

is disabled.

hot

to D0 state

hot

4–29

4.43 Power Management Control/Status Register Bridge Support Extensions

The power management control/status register bridge support extensions support PCI bridge-specific functionality.
See Table 4–19 for a complete description of the register contents.

Bit 7 6 5 4 3 2 1 0
Name Power management control/status register bridge support extensions
Type R R/W R R R R R R
Default 1 1 0 0 0 0 0 0

Register: Power management control/status register bridge support extensions
Type: Read-only
Offset: A6h
Default: C0h

Table 4–19. Power Management Control/Status Register Bridge Support Extensions Description

BIT SIGNAL TYPE FUNCTION

BPCC_Enable. Bus power/clock control enable. This bit returns 1 when read.
This bit is encoded as:

0 = Bus power/clock control is disabled.
1 = Bus power/clock control is enabled (default).

7 BPCC_EN R

6 B2_B3 R/W

5–0 RSVD R Reserved. Bits 5–0 return 0s when read.

A 0 indicates that the bus power/clock control policies defined in the PCI Bus Power Management
Interface Specification are disabled. When the bus power/clock control enable mechanism is disabled,
the bridge’s power management control/status register power state field (PCI offset A4h, see
Section 4.42, bits 1–0) cannot be used by the system software to control the power or the clock of the
bridge’s secondary bus. A 1 indicates that the bus power/clock control mechanism is enabled.

B2/B3 support for D3
programming the function to D3
as:

0 = When the bridge is programmed to D3
1 = When the bridge function is programmed to D3

stopped (B2). (Default)

. The state of this bit determines the action that is to occur as a direct result of

hot

. This bit is meaningful only if bit 7 (BPCC_EN) is a 1. This bit is encoded

hot

, its secondary bus will have its power removed (B3).

hot

, its secondary bus’s PCI clock will be

hot

4.44 Power Management Data Register

The power management data register returns 0s when read, because the CardBus functions do not report dynamic
data.

Bit 7 6 5 4 3 2 1 0
Name Power management data
Type R R R R R R R R
Default 0 0 0 0 0 0 0 0

Register: Power management data
Type: Read-only
Offset: A7h
Default: 00h

4–30

4.45 General-Purpose Event Status Register

The general-purpose event status register contains status bits that are set by different events. The bits in this register
and the corresponding GPE
description of the register contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name General-purpose event status
Type R/C R R R R/C R R R/C R R R R/C R/C R/C R/C R/C
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: General-purpose event status
Type: Read-only, Read/Clear
Offset: A8h
Default: 0000h

BIT SIGNAL TYPE FUNCTION

15 ZV_STS R/C

14–12 RSVD R Reserved. Bits 14–12 return 0s when read.

11 PWR_STS R/C

10–9 RSVD R Reserved. Bits 10 and 9 return 0s when read.

8 VPP12_STS R/C

7–5 RSVD R Reserved. Bits 7–5 return 0s when read.

4 GP4_STS R/C

3 GP3_STS R/C

2 GP2_STS R/C

1 GP1_STS R/C

0 GP0_STS R/C

are cleared by writing a 1 to the corresponding bit location. See Table 4–20 for a complete

Table 4–20. General-Purpose Event Status Register Description

PC card ZV status. Bit 15 is set on a change in status of bit 6 (ZVENABLE) in the card control register (PCI
offset 91h, see Section 4.34).

Power change status. Bit 11 is set when software has changed the power state of the socket. A change
in either VCC or VPP for the socket causes this bit to be set.

12-V VPP request status. Bit 8 is set when software has changed the requested VPP level to or from 12 V
for the PC Card socket.

GPI4 Status. Bit 4 is set on a change in status of the MFUNC5 terminal input level. This bit does not depend
upon the state of a corresponding bit in the general-purpose event enable register.

GPI3 Status. Bit 3 is set on a change in status of the MFUNC4 terminal input level. This bit does not depend
upon the state of a corresponding bit in the general-purpose event enable register.

GPI2 Status. Bit 2 is set on a change in status of the MFUNC2 terminal input level. This bit does not depend
upon the state of a corresponding bit in the general-purpose event enable register.

GPI1 Status. Bit 1 is set on a change in status of the MFUNC1 terminal input level. This bit does not depend
upon the state of a corresponding bit in the general-purpose event enable register.

GPI0 Status. Bit 0 is set on a change in status of the MFUNC0 terminal input level. This bit does not depend
upon the state of a corresponding bit in the general-purpose event enable register.

4–31

4.46 General-Purpose Event Enable Register

The general-purpose event enable register contains bits that are set to enable a GPE signal. The GPE signal is driven
until the corresponding status bit is cleared and the event is serviced. The GPE
multifunction terminals, MFUNC6–MFUNC0, is configured for GPE

signaling. See Table 4–21 for a complete

description of the register contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name General-purpose event enable
Type R/W R R R R/W R R R/W R R R R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: General-purpose event enable
Type: Read-only, Read/Write
Offset: AAh
Default: 0000h

Table 4–21. General-Purpose Event Enable Register Description

BIT SIGNAL TYPE FUNCTION

15 ZV_EN R/W

14–12 RSVD R Reserved. Bits 14–12 return 0s when read.

11 PWR_EN R/W

10–9 RSVD R Reserved. Bits 10 and 9 return 0s when read.

8 VPP12_EN R/W

7–5 RSVD R Reserved. Bits 7–5 return 0s when read.

4 GP4_EN R/W

3 GP3_EN R/W

2 GP2_EN R/W

1 GP1_EN R/W

0 GP0_EN R/W

PC card socket ZV enable. When bit 15 is set, a GPE is signaled on a change in status of bit 6 (ZVENABLE)
in the card control register (PCI offset 91h, see Section 4.34).

Power change enable. When bit 1 1 is set, a GPE is signaled when software has changed the power state
of the socket.

12-V VPP request enable. When bit 8 is set, a GPE is signaled when software has changed the requested
VPP level to or from 12 V for the card socket.

GPI4 enable. When bit 4 is set, a GPE is signaled when there has been a change in status of the MFUNC5
terminal input level if configured as GPI4.

GPI3 enable. When bit 3 is set, a GPE is signaled when there has been a change in status of the MFUNC4
terminal input level if configured as GPI3.

GPI2 enable. When bit 2 is set, a GPE is signaled when there has been a change in status of the MFUNC2
terminal input if configured as GPI2.

GPI1 enable. When bit 1 is set, a GPE is signaled when there has been a change in status of the MFUNC1
terminal input if configured as GPI1.

GPI0 enable. When bit 0 is set, a GPE is signaled when there has been a change in status of the MFUNC0
terminal input if configured as GPI0.

can be signaled only if one of the

4–32

4.47 General-Purpose Input Register

The general-purpose input register provides the logical value of the data input from the GPI terminals, MFUNC5,
MFUNC4, and MFUNC2–MFUNC0. See Table 4–22 for a complete description of the register contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name General-purpose input
Type R R R R R R R R R R R R R R R R
Default 0 0 0 0 0 0 0 0 0 0 0 X X X X X

Register: General-purpose input
Type: Read-only
Offset: ACh
Default: 00XXh

Table 4–22. General-Purpose Input Register Description

BIT SIGNAL TYPE FUNCTION

15–5 RSVD R Reserved. Bits 15–5 return 0s when read.

4 GPI4_DATA R

3 GPI3_DATA R

2 GPI2_DATA R

1 GPI1_DATA R

0 GPI0_DATA R

GPI4 data bit. The value read from bit 4 represents the logical value of the data input from the MFUNC5
terminal.

GPI3 data bit. The value read from bit 3 represents the logical value of the data input from the MFUNC4
terminal.

GPI2 data bit. The value read from bit 2 represents the logical value of the data input from the MFUNC2
terminal.

GPI1 data bit. The value read from bit 1 represents the logical value of the data input from the MFUNC1
terminal.

GPI0 data bit. The value read from bit 0 represents the logical value of the data input from the MFUNC0
terminal.

4–33

4.48 General-Purpose Output Register

The general-purpose output register is used for control of the general-purpose outputs. See Table 4–23 for a
complete description of the register contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name General-purpose output
Type R R R R R R R R R R R R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: General-purpose output
Type: Read-only, Read/Write
Offset: AEh
Default: 0000h

Table 4–23. General-Purpose Output Register Description

BIT SIGNAL TYPE FUNCTION

15–5 RSVD R Reserved. Bits 15–5 return 0s when read.

4 GPO4_DATA R/W

3 GPO3_DATA R/W

2 GPO2_DATA R/W

1 GPO1_DATA R/W

0 GPO0_DATA R/W

GPO4 data bit. The value written to bit 4 represents the logical value of the data driven to the MFUNC5
terminal if configured as GPO4. Read transactions return the last data value written.

GPO3 data bit. The value written to bit 3 represents the logical value of the data driven to the MFUNC4
terminal if configured as GPO3. Read transactions return the last data value written.

GPO2 data bit. The value written to bit 2 represents the logical value of the data driven to the MFUNC2
terminal if configured as GPO2. Read transactions return the last data value written.

GPO1 data bit. The value written to bit 1 represents the logical value of the data driven to the MFUNC1
terminal if configured as GPO1. Read transactions return the last data value written.

GPO0 data bit. The value written to bit 0 represents the logical value of the data driven to the MFUNC0
terminal if configured as GPO0. Read transactions return the last data value written.

4–34

5 ExCA Compatibility Registers

The ExCA registers implemented in the PCI4410A device are register-compatible with the Intel 82365SL–DF
PCMCIA controller. The ExCA registers are identified by an offset value that is compatible with the legacy I/O
index/data scheme used on the Intel 82365 ISA controller. The ExCA registers are accessed through this scheme
by writing the register offset value into the index register (I/O base) and reading or writing the data register (I/O base
+ 1). The I/O base address used in the index/data scheme is programmed in the PC Card 16-bit I/F legacy-mode base
address register (PCI offset 44h, see Section 4.28). The offsets from this base address run contiguously from 00h
to 3Fh for the socket. See Figure 5–1 for an ExCA I/O-mapping illustration.

PCI4410A Configuration Registers

CardBus Socket/ExCA Base Address

Offset

10h

Host I/O Space

Index

Data

PC Card

ExCA

Registers

Offset

00h

3Fh

16-Bit Legacy-Mode Base Address

44h

Figure 5–1. ExCA Register Access Through I/O

The TI PCI4410A device also provides a memory-mapped alias of the ExCA registers by directly mapping them into
PCI memory space. They are located through the CardBus socket/ExCA base address register (PCI offset 10h, see
Section 4.12) at mem ory offset 800h. See Figure 5–2 for an ExCA memory-mapping illustration. This illustration also
identifies the CardBus socket-register mapping, which is mapped into the same 4K window at memory offset 0h.

Host

PCI4410A Configuration Registers

CardBus Socket/ExCA Base Address

16-Bit Legacy-Mode Base Address

10h

44h

Memory Space

CardBus

Socket

Registers

ExCA

Registers

OffsetOffset

00h

20h

800h

844h

Figure 5–2. ExCA Register Access Through Memory

5–1

As defined by the 82365SL–DL Specification, the interrupt registers in the ExCA register set control such card
functions as reset, type, interrupt routing, and interrupt enables. Special attention must be paid to the interrupt routing
registers and the host-interrupt signaling method selected for the PCI4410A device to ensure that all possible
PCI4410A interrupts potentially can be routed to the programmable interrupt controller. The ExCA registers that are
critical to the interrupt signaling are the ExCA interrupt and general control register (ExCA offset 03h, see Section 5.4)
and the ExCA card status-change-interrupt configuration register (ExCA offset 05h, see Section 5.6).

Access to I/O - mapped 16-bit PC Cards is available to the host system via two ExCA I/O windows. These are regions
of host I/O address space into which the card I/O space is mapped. These windows are defined by start, end, and
offset addresses programmed in the ExCA registers described in this section. I/O windows have byte granularity.

Access to memory-mapped 16-bit PC Cards is available to the host system via five ExCA memory windows. These
are regions of host memory space into which the card memory space is mapped. These windows are defined by start,
end, and offset addresses programmed in the ExCA registers described in this section. Table 5–1 identifies each
ExCA register and its respective ExCA offset. Memory windows have 4-Kbyte granularity.

Table 5–1. ExCA Registers and Offsets

CARDBUS SOCKET

EXCA REGISTER NAME

Identification and revision 800 00
Interface status 801 01
Power control 802 02
Interrupt and general control 803 03
Card status change 804 04
Card status-change-interrupt configuration 805 05
Address window enable 806 06
I / O window control 807 07
I / O window 0 start-address low byte 808 08
I / O window 0 start-address high byte 809 09
I / O window 0 end-address low byte 80A 0A
I / O window 0 end-address high byte 80B 0B
I / O window 1 start-address low byte 80C 0C
I / O window 1 start-address high byte 80D 0D
I / O window 1 end-address low byte 80E 0E
I / O window 1 end-address high byte 80F 0F
Memory window 0 start-address low byte 810 10
Memory window 0 start-address high byte 811 11
Memory window 0 end-address low byte 812 12
Memory window 0 end-address high byte 813 13
Memory window 0 offset-address low byte 814 14
Memory window 0 offset-address high byte 815 15
Card detect and general control 816 16
Reserved 817 17
Memory window 1 start-address low byte 818 18
Memory window 1 start-address high byte 819 19
Memory window 1 end-address low byte 81A 1A

Memory window 1 end-address high byte 81B 1B
Memory window 1 offset-address low byte 81C 1C
Memory window 1 offset-address high byte 81D 1D

ADDRESS OFFSET

(HEX)

ExCA OFFSET

(HEX)

5–2

Table 5–1. ExCA Registers and Offsets (Continued)

CARDBUS SOCKET

EXCA REGISTER NAME

Global control 81E 1E
Reserved 81F 1F
Memory window 2 start-address low byte 820 20
Memory window 2 start-address high byte 821 21
Memory window 2 end-address low byte 822 22
Memory window 2 end-address high byte 823 23
Memory window 2 offset-address low byte 824 24
Memory window 2 offset-address high byte 825 25
Reserved 826 26
Reserved 827 27
Memory window 3 start-address low byte 828 28
Memory window 3 start-address high byte 829 29
Memory window 3 end-address low byte 82A 2A
Memory window 3 end-address high byte 82B 2B
Memory window 3 offset-address low byte 82C 2C
Memory window 3 offset-address high byte 82D 2D
Reserved 82E 2E
Reserved 82F 2F
Memory window 4 start-address low byte 830 30
Memory window 4 start-address high byte 831 31
Memory window 4 end-address low byte 832 32
Memory window 4 end-address high byte 833 33
Memory window 4 offset-address low byte 834 34
Memory window 4 offset-address high byte 835 35
I/O window 0 offset-address low byte 836 36
I/O window 0 offset-address high byte 837 37
I/O window 1 offset-address low byte 838 38
I/O window 1 offset-address high byte 839 39
Reserved 83A 3A
Reserved 83B 3B
Reserved 83C 3C
Reserved 83D 3D
Reserved 83E 3E
Reserved 83F 3F
Memory window page 0 840 –
Memory window page 1 841 –
Memory window page 2 842 –
Memory window page 3 843 –
Memory window page 4 844 –

ADDRESS OFFSET

(HEX)

ExCA OFFSET

(HEX)

5–3

5.1 ExCA Identification and Revision Register

The ExCA identification and revision register provides host software with information on 16-bit PC Card support and
Intel 82365SL-DF compatibility. This register is read-only or read/write, depending on the setting of bit 5
(SUBSYSRW) in the system control register (PCI offset 80h, see Section 4.29). See Table 5–2 for a complete
description of the register contents.

Bit 7 6 5 4 3 2 1 0
Name ExCA identification and revision
Type R R R/W R/W R/W R/W R/W R/W
Default 1 0 0 0 0 1 0 0

Register: ExCA identification and revision
Type: Read-only, Read/Write
Offset: CardBus socket address + 800h; ExCA offset 00h
Default: 84h

Table 5–2. ExCA Identification and Revision Register Description

BIT SIGNAL TYPE FUNCTION

7–6 IFTYPE R
5–4 RSVD R/W Reserved.

3–0 365REV R/W

Interface type. These bits, which are hardwired as 10b, identify the 16-bit PC Card support provided by the
PCI4410A device. The PCI4410A device supports both I/O and memory 16-bit PC cards.

Intel 82365SL-DF revision. This field stores the Intel 82365SL-DF revision supported by the PCI4410A
device. Host software can read this field to determine compatibility to the Intel
Writing 0010b to this field puts the controller in 82365SL mode. This field defaults to 0100b upon PCI4410A
reset.

82365SL-DF register set.

5–4
