TDS1000B and TDS2000B Series
Digital Storage Oscilloscopes
User Manual
*P071181701*
071-1817-01
xx
ZZZ
TDS1000B and TDS2000B Se
Digital Storage Oscill
oscopes
User Manual
ries
www.tektronix.com
071-1817-01
Copyright © Tektronix. A ll rights re
owned by Tektronix or its subsidiaries or suppliers, and are protected by national
copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pendin g.
Information in this publication supersedes that in all previously published
material. Specifications and p
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
OpenChoice™ is a registered trademark of Tektronix, Inc.
served. Licensed software products are
rice change privileges reserved.
PictBridge is a register
Products Association CIPA DC-001-2003 Digital Photo Solutions for Imaging
Devices.
ed trademark of the Standard of Camera & Imaging
Contacting Tektronix
Tektronix, Inc.
14200 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For pro duct information, sales, service, and technical support:
In North Am erica, call 1-800-833-9200.
Worldwide, visit www.tektronix.com to find contacts in your area.
TDS1000B and TDS2000B Oscilloscopes
Limited Lifetime Warranty
Tektronix warrants to the original end user purchaser (“original purchaser”) of the product
listed below that the product will be free from defects in materials and workmanship for
the lifetime of the product. As used herein, “lifetime of the product” is defined as a
period ending five (5) years after Tektronix discontinues manufacturing the product
(as determined by Tektronix), but the warranty period shall be at least ten (10) years
from the date of purchase of the product by the original purchaser from Tektronix or
an authorized Tektronix distributor. This limited lifetime warranty only applies to
the original purchaser and is not transferable. In the event of a warranty claim under
the limited lifetime warranty, the purchaser must provide satisfactory evidence of the date
of purchase from Tektronix or an authorized Tektronix distributor and that it is the original
purchaser. In the event of the sale or other transfer of the product by t he original purchaser
to a third party within three (3) years of the date of purchase of the product by the original
purchaser, the warranty period shall be three (3) years from the date of purchase of the
product by the original purchaser from Tektronix or an authorized Tektronix distributor.
Probes and other accessories and batteries and fuses are not covered by this warranty.
If the product proves defective during the applicable warranty period, Tektronix, at its
option, either will repair the defective product without charge for parts and labor, or will
provide a replacement of an equivalent product (as determined by Tektronix) in exchange
for the defective product. Parts, modules and replacement products used by Tektronix for
warranty work may be new or reconditioned to like new performance. All replaced parts,
modules and products become the property of Tektronix.
As used hereafter, “Customer” refers to the person or entity asserting rights under this
warranty. In order to obtain service under this warranty, Customer must notify Tektronix
of the defect before the expiration of the applicable warranty period and make suitable
arrangements for the performance of service. Customer shall be responsible for packaging
and shipping the defective product to the service c enter designated by Tektronix, shipping
charges prepaid and with a copy of proof of purchase by the original purchaser. Tektronix
shall pay for the return of the product to Customer if the shipment is to a location within
the country in which the Tektronix service center is located. Customer shall be responsible
for paying all shipping charges, duties, taxes, and any other charges for products returned
to any other locations.
This warranty shall not apply to any defect, failure or damage caused by accident, ordinary
wear and tear of mechanical components, use outside of the product’s specifications,
improper use or improper or inadequate maintenance and care. Tektronix shall not
be obligated to furnish service under this warranty a) to repair damage resulting from
attempts by personnel other than Tektronix representatives to install, repair or service the
product; b) to repair damage resulting from improper use or connection to incompatible
equipment; c) to repair any damage or malfunction caused by the use of non-Tektronix
supplies; or d) to service a product that has been modified or integrated with other
products when the effect of such modification or integration increases the time or difficulty
of servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE
PRODUCT IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED.
TEKTRONIX AND ITS VENDORS D ISCLAIM ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TEKTRONIX’
RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE
SOLE AN D EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR
BREACH OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE
LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
[W18 – 25MAY06]
P2220 Probe
Warra nty
Tektronix warrants that this product will be free from defects in materials and
workmanship for a period of one (
proves defective during this warranty period, Tektronix, at its option, either will repair
the defective product without
in exchange for the defective product. Parts, modules and replacement products used by
Tektronix for warranty work
replaced parts, modules and products become the property of Tektronix.
In order to obtain service under this warranty, Customer must notify Tektronix of the
defect before the expiration of the warranty period and make suitable arrangements for the
performance of service. Customer shall be responsible for packaging and shipping the
defective product to the service center designated by Tektronix, with shipping charges
prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to
a location within the country in which the Tektronix service center is located. Customer
shall be responsible for paying all shipping charges, duties, taxes, and any other charges
for products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or
improper or inadequate maintenance and care. Tektronix shall not be obligated to furnish
service under this warranty a) to repair damage resulting from attempts by personnel other
than Tektronix representatives to install, repair or service t he product; b) to repair damage
resulting from improper use or connection to incompatible equipment; c) to repair any
damage or malfunction caused by the use of non-Tektronix supplies; or d) to service a
product that has been modified or integrated with other products when the effect of such
modification or integration increases the time or difficulty of servicing the product.
THIS WARRA
PRODUCT IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED.
TEKTRON
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TEKTRONIX’
RESPON
SOLE AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FO R
BREAC
LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMA
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
[W2 – 15AUG04]
NTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE
IX AND ITS VENDORS D ISCLAIM ANY IMPLIED WARRANTIES OF
SIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE
H OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE
GES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS
1) year from the date of shipment. If any such product
charge for parts and labor, or will provide a replacement
may be new or reconditioned to like new performance. All
Table of Contents
General Safety Summary ....................................... ........ iv
Compliance Information................... ............................ vii
EMC Compliance .................. ............................... vii
Safety Compliance ...................................... ........... ix
Environmental Considerations .................................... xi
Preface......................................................... ......... xiii
Help System .............................. ........................ xiv
Firmware Updates Through the Internet ........................ xv
Conventions........................................ ............... xvi
Getting Started ................................................ ............ 1
General Features........... .......................................... 1
Installation ......................................... .................. 3
Functional Check................................................. ... 4
Probe Safety ......... ................................................ 5
Voltage Probe Check Wizard........................ ............... 5
Manual Probe Compensation........................ ............... 7
Probe Attenuation Setting ................................. ......... 8
Current Probe Scaling.............. ................................. 8
Self Calibration.......................................... ............ 9
Operating Basics.............................................. .......... 11
Display Area ....................................... ................ 12
Using the Menu System ...................................... .... 15
Vertical Controls................................................... 16
Horizontal Controls ................... ............................ 17
Trigger Controls ............................................... .... 18
Menu and Control Buttons ................................ ....... 19
Input Connectors .............................................. .... 22
Other Front-Panel Items ....................... ................... 23
Understanding Oscilloscope Functions......... ...................... 25
Setting Up the Oscilloscope ............. ......................... 25
Triggering........................... ............................... 26
quiring Signals ............ ..................................... 29
Ac
TDS1000B/2000B Series Oscilloscope User Manual i
Table of Contents
Scaling and Positioning Waveforms..... ........................ 30
Taking Measurements............ ................................. 34
Application Examples.................................................. 37
Taking Simple Measurements .................................... 38
Using Autorange to Examine a Series of Test Points........... 43
Taking Cursor Measurements .................. .................. 44
Analyzing Signal Detail ... ....................................... 48
Capturing a Single-Shot Signal . ................................. 51
Measuring Propagation Delay.................................... 53
Triggering on a Specific Pulse Width............................ 54
Triggering on a Video Signal..................................... 56
Analyzing a Differential Communication Signal ............... 61
Viewing Impedance Changes in a Network............... ...... 63
Math FFT..................................... ........................... 67
Setting Up the Time-Domain Waveform ............ ............ 67
Displaying the FFT Spectrum .................................... 69
Selecting an FFT Window........................................ 70
Magnifying and Positioning an FFT Spectrum ..... ............ 74
Measuring an FFT Spectrum Using Cursors .................... 75
USB Flash Drive and Device Ports ....................... ............ 77
USB Flash Drive Port ............................................. 77
File Management Conventions................................... 79
Saving and Recalling Files With a USB Flash Drive........... 80
Using the Save Function of the PRINT Front Panel Button . . . 82
USB Device Port ................. ................................. 85
Installing the PC Communications Software on a PC.......... 85
Connecting to a PC............ .................................... 86
Connecting to a GPIB System.................. .................. 89
Command Entry............ ....................................... 89
Connecting to a Printer ............. .............................. 90
Printing a Screen Image ... ....................................... 90
Reference.......... ................................................... ... 93
Acquire...................... ....................................... 93
Autorange................... ....................................... 96
Autoset ................... .......................................... 98
ii TDS1000B/2000B Series Oscilloscope User Manual
Table of Contents
Cursor ......................... .................................... 102
Default Setup ....................... .............................. 103
Display ..................... ....................................... 103
Help ............... ................................................ 107
Horizontal........................... .............................. 107
Math ............................................. .................. 109
Measure ........... ................................................ 111
Print .................................... ........................... 112
Probe Check ......... ............................................. 113
Ref Menu. ................................................... ...... 114
Save/Recall . . .. . .. .. .. . .. .. .. . .. .. .. .. . .. .. .. .. . .. .. .. .. . .. .. .. . .. 114
Trigger Controls ............................................... ... 120
Utility...................................... ........................ 128
Vertical Controls.................................................. 131
Appendix A : Specifications........................................... 135
Oscilloscope Specifications...................................... 135
P2220 Probe Specifications........... ........................... 149
Appendix B: Accessories ........................ ..................... 153
Appendix C: Cleaning .................. .............................. 157
General Care ....................................... ............... 157
Cleaning.................... ....................................... 157
Appendix D: Default Setup. .......................................... 159
Appendix E: Font Licenses......................... .................. 163
Index
TDS1000B/2000B Series Oscilloscope User Manual iii
General Safety Summary
General Safety Summary
Review the following safety precautions to avoid injury and prevent
damage to this product or an y products connected to it.
To avoid potential hazards, use this product only as specified.
Only q ualified personnel should perform service procedures.
To Avoid Fire or Personal Injury
Use Proper Power Cord. Use only the power cord specified for this
product and certified for the country of use.
Connect and Disconnect Properly. Connect the probe output to the
measurement instrument before connecting the probe to the circuit
under test. Connect
before connecting the probe input. Disconnect the probe input and t he
probe r eference lead from the circuit under test before disconnecting
the probe from the
Ground the Product. Th is product is grounded through the grounding
conductor of the
conductor must be connected to earth ground. Before making
connections to the input or output terminals of the product, ensure that
the product is
the probe re fer ence lead to the circuit under test
measurement instrument.
power cord. To avoid electric shock, the grounding
properly grounded.
Observe All Terminal Ratings. To avoid fire or shock hazard, observe all
ratings and m
further ratings information before making connections to th e product.
Connect th
Do not apply a potential to any terminal, including the common
terminal
Power Disconnect. The power switch disconnects the product from the
power so
switch; it must remain accessible to the user at all times.
Do Not O
or panels removed.
iv TDS1000B/2000B Series Oscilloscope User Manual
arkings on the product. Consult the product manual for
e p rob e reference lead to earth ground only.
, that exceeds the maximum rating of that terminal.
urce. See instructions for the location. Do not block the power
perate Without Covers.
Do no t operate this product w ith covers
General Safety Summary
Do Not Operate With Suspected Failures. If you suspect that there is
damage to this product, have it inspected by qualified service personnel.
Avoid Exposed Circuitry. Do not touch exposed connections and
components when power is present.
Do Not Operate in Wet/Damp Conditions.
Do Not Operate in an Explosive Atmosphere.
Keep Product Surfaces Clean and Dry.
Provide Proper Ventilation.
Refer to the manual’s installation instructions
for details on installing t he product so it has proper ventilation.
TDS1000B/2000B Series Oscilloscope User Manual v
General Safety Summary
Terms in this Manual
These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could
result in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could
result in damage to this product or other property.
Symbols and Terms on the Product
These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you
read the marking.
WARNING indicates an injury hazard not immediately accessible
as you read the marking.
CAUTION indicates a hazard to property including the product.
The follow ing symbol(s) may appear on the product:
vi TDS1000B/2000B Series Oscilloscope User Manual
Compliance Information
This section lists the EMC (ele
environmental standards with which the instrument complies.
EMC Compliance
EC Declaration of Conformity – EMC
Meets intent of Directive 2004/108/EC for Electromagnetic
Compatibility. Compliance was demonstrated to the following
specifications as listed in the O fficial Journal of the European
Communities:
EN 61326-1:2006, EN 61326-2-1:2006. EMC requirements f or electrical
equipment for measurement, control, and laboratory use.
CISPR 11:2003. Radiated and conducted emissions, Group 1,
Class A
IEC 610 00-4-2:2 001 . Electrostatic discharge immunity
IEC 61000 -4 -3:200 2. RF electromagnetic field immunity
IEC 61000-4-4:2 004 . Electrical fast transient/burst immunity
IEC 6 100 0-4-5 :20 01. Power l ine surge immunity
IEC 61000-4-6:2003. Conducted RF immunity
IEC 61000-4 -11:2004. Voltage dips an d interruptions immunity
ctromagnetic compliance), safety, and
1234
5
6
7
EN 61000-3-2:2006. AC power line harmonic emissions
EN 61000-3-3:1995. Voltage changes, fluctuations, and flicker
European Contact.
Tektronix UK, Ltd.
Western Peninsula
Western Road
Bracknell, RG12 1RF
United Kingdom
TDS1000B/2000B Series Oscilloscope User Manual vii
Compliance Information
1
This product is intended for use in nonresidential areas only. Use in residential areas
may cause electromagnetic interference.
2
Emissions which exceed the levels required by this standard may occur when this
equipment is connected to a test o
3
To ensure compliance with the EMC standards listed here, high quality shielded interface
cables should be used.
4
Instrument rebooting may be experience where the EUT takes longer than 10 seconds
to recover from IEC61000-4-11 transient immunity test.
5
The increase in trace noise while subjected to the test field (3 V/m over the frequency
ranges of 80 MHz to 1 GHz and 1.4 G
1 kHz) and (1 V/m over the frequency range of 2.0 GHz to 2.7 GHz, with 80% amplitude
modulation at 1 kHz) is not to exceed 2 major divisions peak-to-peak. Ambient conducted
fields may induce triggering when the trigger threshold is offset less than 1 major division
from ground reference.
6
The increase in trace noise while subjected to the test field (3 V rms over the frequency
range of 150 kHz to 80 MHz, with 80% amplitude modulation at 1 kHz) is not to exceed
1 major division peak-to-peak. Ambient conducted fields may induce t riggering when the
trigger threshold is offset less than 0.5 major divisions from ground reference.
7
Performance Criterion C applied at the 70%/25 cycle Voltage-Dip and the 0%/250 cycle
Voltage-Interruption test levels (IEC 61000-4-11).
Australia / New Zealand Declaration of Conformity – EMC
bject.
Hz to 2.0 GHz, with 80% amplitude modulation at
Complies with the EMC provision of the Radiocommunications Act per
the following standard, in accordance with ACMA:
CISPR 11:2003. Radiated and Conducted Emissions, Group
1, Class A, in accordance with EN 61326-1:2006 and
EN 61326-2-1:2006.
viii TDS1000B/2000B Series Oscilloscope User Manual
Safety Compliance
EC Declaration of Conformity – Low Voltage
Compliance was demonstrated to the following specification as listed in
the Official Journal of the European Communities:
Low Voltage Directive 2006/95/EC.
EN 6 101 0-1 : 200 1. Safety requirements for electrical equipment
for measurement control and laboratory use.
U.S. Nationally Recognized Testing Laboratory Listing
UL 61 010-1:2004, 2ndEdition. Standard for electrical measuring
and test equipment.
Canadian Certification
CAN/CSA-C22.2 No. 61010-1:2004. Safety requirements for
electrical equipment for measurement, control, and laboratory use.
Part 1.
Additional Compliances
IEC 610 10-1: 2001. Safety requirements for electrical equipment
for measurement, control, and laboratory use.
Compliance Information
Equipment Type
Test and measuring equipment.
Safety Class
Class 1 – grounded product.
Pollution Degree Description
A measure of the contaminants that could occur in the environment
around and within a product. Typically the internal environm ent inside
a pro duct is considered to be the same as the extern al. Products should
be used only in the environment for which they are rated.
Pollution Degree 1. No pollution or only dry, nonconductive
pollution occurs. Products in this category are generally
encapsulated, hermetically sealed, or located in clean rooms.
TDS1000B/2000B Series Oscilloscope User Manual ix
Compliance Information
Pollution Degree 2. Normally only dry, nonconductive pollution
occurs. Occasionally a temporary conductivity that is caused
by condensation must be expected. This location is a typical
office/home environment. Temporary c ondensatio n occurs only
when the p roduct is out of service.
Pollution Degree 3. Conductive pollution, or dry, nonconductive
pollution that becomes conductive due to con densation. These
are sheltered locations where neither temperature nor humidity
is controlled. The area is protected from direct sunshine, rain, or
direct wind.
Pollution Deg ree 4. Pollution that generates per s istent conductivity
through conductive dust, rain, or snow. Ty pical outdoor locations.
Installation (Overvoltage) Category Descriptions
Terminals on this product may have different installation (overvoltage)
category designations. The installation categories are:
Measurement Category IV. For measurements performed at the
source of low-voltage installation.
Measurement Category III. For measurements perform ed in the
building installation.
Measurement Category II. For measurements performed o n circuits
directly connected to the low-voltage installation.
Measurement Category I. For measurements performed on circuits
not directly connected to MAINS.
Overvoltage Category
Overvoltage C ategory II (as defined in IEC 61010-1).
x TDS1000B/2000B Series Oscilloscope User Manual
Environmental Considerations
This section provides information about the environ men tal impact of
the product.
Product End-of-Life Handling
Observe the following guidelines when recycling an instrument or
component:
Equipment Recycling. Production of this equipment required the
extraction and use of natural resources. The equipment may contain
substances that could b
if improperly handled at the product’s end of life. In order to avoid
release of such substances into the environment and to reduce the use
of natural resources
appropriate system that will ensure that most of the materials are reused
or recycled appropriately.
e harmful to the environment or human health
, we encourage y ou to recycle this product in an
Compliance Information
This symbol indica
applicable Europ
Directives 2002
electronic equi
about recyclin
the Tektronix
Mercury Notification.
This product uses an LCD backlight lamp that
tes that this product complies with the
ean Union requirements according to
/96/EC and 2006/66/EC on waste electrical and
pment (WEEE) and batteries. For information
g options, check the Support/Service section of
Web site (www.tektronix.com).
contains mercury. Disposal may be regulated due to environmental
considerations. Please contact your local authorities or, within the
United States, refer to the E-cycling Central Web page (www.eiae.org)
for disposal or recycling information.
Restriction of Hazardous Substances
This product has been classified as Monitoring and Control equipment,
and is outside the scope of the 2002/9 5/EC RoHS Directive.
TDS1000B/2000B Series Oscilloscope User Manual xi
Compliance Information
xii TDS1000B/2000B Series Oscillo sco pe User Manual
Preface
This manual contains o peratin g information for the TDS1000B and
TDS2000B Series Digital Storage Oscilloscopes. The manual consists
of the following chapters:
Preface
The Getting Started chapter briefly describes features of the
oscilloscope and provides installation instructions.
The Operating Basics chapter covers operating principles of the
oscilloscopes.
The Understanding Oscilloscope Functions chapter describes
basic operations and functions of an oscilloscope: setting up th e
oscilloscope, triggering, acquiring data, scaling and positionin g
waveforms, and taking measurements.
The A p plication Examples chapter provides examples on how to
solve a variety of measurement problems.
The Math FFT chapter describes how to use the Math Fast Fourier
Transform function to convert a time-domain signal into its
frequency components (spectrum).
The USB Flash Drive and Device Ports chapter describes how to
use the USB Flash Drive port and how to connect the oscilloscope
to printers and computers throug h the USB Device port.
The Reference chapter describes the selections or available range of
values for each option.
The Appendix A: Specifications chapter includes electrical,
environmental, and physical specifications for the oscilloscope and
the P2220 probe, as well as certifications and com pliances.
The Appendix B: Accessories chapter briefly describes standard
and optional accessories.
The Appen dix C: Cleaning chapter describes how to take care of
the oscilloscope.
The Appendix D: Default Setup chapter contains a list of the menus
and controls with the default (factory) settings that are recalled
when you push the DEFAULT SETUP f ron t-panel button.
TDS1000B/2000B Series Oscilloscope User Manual xiii
Preface
The Appendix E: Font Licenses chapter provides the licenses to
use specific Asian fonts.
Help System
The oscilloscope has a Help system with topics that cover all the
features of the oscilloscope. You can use the Help system to display
several kinds of information:
General information about understandin g and using the
oscilloscope, such as Using the Menu System.
Information about specific menus and controls, such as the Vertical
Position Control.
Advice about problems you may face while using an oscilloscope,
such as Reducing Noise.
The Help system provides several ways to find the inform a tio n you
need: context-sensitive help, hyperlinks, and an index.
Context-Sensitive Help
The oscilloscope displays information about the last menu displayed on
the screen when yo u push the HELP front-panel b utton. When viewing
help topics, an
that the knob is active. If the topic uses more than one pag e, turn the
multipurpose knob to move from page to page within the topic.
LED lights next to the multipurpose knob to indicate
Hyperlinks
Most of the help topics contain phrases marked with angle brackets, such
as <Autoset>. These are links to other topics. Turn the multipurpose
knob to m ove the highlight from one link to another. Push the Show
Topic option button to display the topic corresponding to the highlighted
link. Pu sh the Back option button to return to the previous topic.
xiv TDS1000B/2000B Series Oscilloscope User Manual
Index
Push the front-panel HELP button, then push the Index option button.
Push the Page Up or Page Dow n option buttons until you find the index
page that contains the topic you wan t to view. Turn the multipurpose
knob to highlight a help topic. Push the Show Topic option button to
display the topic.
NOTE. Push the Exit option button or any menu button to remove the He lp
text from the screen and return to displaying waveforms.
Firmware Updates Through the Internet
If a newer version of firmware becomes available, you can use the
Internet and a USB flash drive to update your oscillo scope. If you do
not have access to the Internet, contact Tektronix for information on
update procedures.
To update the firmware from the Internet, follow th ese steps:
1. Push the UTILITY ► System Status option, and write down the
firmware version num ber of the oscilloscop
2. From your computer, access the www.tektronix.com web site and
check if a n ewer version of oscilloscope firmware is available.
Preface
e.
3. If there is a newer version of firmware, download the firmware
file from the web page.
You may need to unzip the downloaded file.
4. Copy the T DS1K 2KB.TEK firmware file to the root folder of a
USB flash drive.
5. Insert the USB flash drive into the USB Flash Drive port on the
front of the oscilloscope.
6. From your oscilloscope, push the UTILITY ► File Utilities ►
- more - page 2 of 2 ► Update Firmware option button.
It takes several minutes to update the firmware.
Your oscilloscope will prompt you to press a button when the firmware
update is complete. You must not remove the USB flash drive, or power
off the oscilloscope until the firmware update is complete.
TDS1000B/2000B Series Oscilloscope User Manual xv
Preface
Conventions
This manual uses the following conventions:
Front-panel button s, knobs and c on nectors appear in all uppercase
letters. For example: HELP, PRINT.
Menu options appear with the first letter of each word in upper case.
For example: P eak Detect, Window Zone.
Multipurpose knob
Front-panel buttons and knob labels
— All upper case
Option buttons — First le tter of each word on screen is upper case
NOTE. Option buttons may also be called screen buttons, side-menu
buttons, bezel buttons, or soft keys.
The ► deli
miter separates a series of button pushes. For example,
UTILITY ► Options ► Set Date and Time means that you
push the UTILITY front-panel button, then push the Options
option b
utton, and then push th e Set Date and Time option button.
Multiple pushes of an option button may be required to select the
desired option.
xvi TDS10 00B/2000B Series Oscilloscope User Manual
Getting Started
TDS1000B and TDS2000B Series D
are small, lightweight, benchtop oscilloscope you can use to take
ground-referenced measurements.
This chapter describes how to do the following tasks:
Install your product
Perform a brief functional check
Perform a probe check and compensate probes
Match your probe atten
Use the self calibra ti on routi ne
NOTE. You can select a language to display on the screen when you power
on the oscilloscope. At any time, you can also access the UTILITY ►
Language optio n to select a language.
General Features
The next table and list describe the general features.
Model Channels Bandwidth Sample rate Display
TDS1001B
TDS1002B
TDS1012B
TDS2002B
TDS2004B
TDS2012B
TDS2014B
TDS2022B
TDS2024B
igital Storage Oscilloscopes
uation factor
240MHz
260MHz
2 100 MHz
260MHz
460MHz
2 100 MHz
4 100 MHz
2 200 MHz
4 200 MHz
500 MS/s
1.0 GS/s
1.0 GS/s
1.0 GS/s Color
1.0 GS/s Color
1.0 GS/s Color
1.0 GS/s Color
2.0 GS/s Color
2.0 GS/s Color
Monochrome
Monochro
Monochrome
me
TDS1000B/2000B Series Oscilloscope User Manual 1
Getting Started
Context-sensitive help system
Color or monochrome LCD display
Selectable 20 M Hz bandwidth limit
2500 point record length for each channel
Autoset
Autoranging
Probe Check Wizard
Setup and waveform storage
USB Flash Drive port for file storage
Direct print ing to any PictBridge compatible print er
PC communications through the USB Device port with Op enCh oice
PC Communications software
Connect to a GPIB controller through an optional TEK-USB-488
adapter
Cursors with readouts
Trigger frequency readout
Eleven automatic measurements
Waveform averaging and peak detection
Dual time base
Math functions: +, -, and × operations
Math Fast Fourier Transform (FFT)
Pulse Width trigger capability
Video trigger capability with line-selectable triggering
External trigger
Variable persistence display
User interface and help topics in ten languages
2 TDS1000B/2000B Series Oscilloscope User Manual
Installation
Power Cord
Use only the power cord provided with your oscilloscope. Appendix B:
Accessories lists the standard and the optional accessories.
Power Source
Getting Started
Use a p ower source that delivers 90 to 264 VAC
you have a 400 Hz power source, it must deliver 90 to 132 VAC
,45to66Hz. If
RMS
RMS
,
360to440Hz.
Security Loop
Use a standard laptop computer security lock, or thread a security cable
through t he built-in cable channel to secure your oscilloscope to your
location.
Security cable channel Security lock hole
Power cord
Ventilation
NOTE. The oscilloscope cools by convection. Keep two inches clear on the
sides and top of the product to allow adequate air flow.
TDS1000B/2000B Series Oscilloscope User Manual 3
Getting Started
Functional Check
Perform this functional check to verify that your oscilloscope is
operating correctly.
ON/OFF button
DEFAULT SETUP button
PROBE COMP
1. Power on the oscilloscope.
Push the DEFAULT SETUP butto
The default Probe option at
setting is 10X.
2. Set the switch to 10X on the P222 0
probe and connect the probe to channel
1 on the oscilloscope. To do this, align
the slot in the probe connector with the
key on the CH 1 BNC, push to connect,
and twist to the right to lock the probe
in place.
Connect the probe tip and reference
lead to the PROBE COMP terminals.
n.
tenuation
3. Push the AUTOSET button. Within
a few seconds, you should see a
square wave in the display of about 5V
peak-to-peak at 1 kHz.
Push the CH1 MENU button on the
front panel twice to remove channel 1,
push the CH 2 MENU button to display
channel 2, and repeat steps 2 and 3.
For 4-channel models, repeat for CH 3
and CH 4.
4 TDS1000B/2000B Series Oscilloscope User Manual
Probe Safety
Check and observe probe ratings before using probes.
A guard around the P2220 probe body provides a finger barrier for
protection from electric shock.
WARNING. To avoid electric shock when using the probe, keep fingers
behind the guard on the probe body.
Getting Started
Finger guard
To avoid electric s
of the probe head w
Connect the probe to the oscilloscope, and connect the ground terminal
to g rou nd before you take any measurements.
hock while using the probe, do n ot touch metallic portions
hile it is connected to a voltage source.
Vo ltage Probe Check Wizard
You can use the Probe Check Wizard to verify that a voltage probe is
operating properly. The wizard does not support current probes.
The wizard helps you adjust the compensation for voltage probes
(usually with a screw on the probe body or probe connector) and set the
factor for the Attenuation option for each channel, such as in the CH 1
MENU ► Probe ► Vo l ta g e ► Attenuation option.
TDS1000B/2000B Series Oscilloscope User Manual 5
Getting Started
You should use the Probe Check Wizard each time you connect a
voltage probe to an input channel.
To use the Probe Check Wizard, push the PROBE CHECK button. If
the voltage probe is connected properly, compensated properly, and the
Attenuation option in the os cill oscope VERTICAL menu is set to match
the probe, the oscilloscope displays a PASSED message at the bottom
of the screen. Otherwise, the oscilloscope displays directions on the
screen to guide you in correcting these problems.
NOTE. The Probe Check Wizard is useful for 1X, 10X, 20X, 50X, and 100X
probes. It is not useful for 500X or 1000X probes, or for probes connected
to the EXT TRIG BNC.
NOTE. When the process is complete, the Probe Check Wizard restores the
oscilloscope settings (other than the Probe option) to what they were before
you pushed the PROBE CHECK button.
To compensate a probe that you plan to use with the EXT TRIG input,
follow these steps:
1. Connect the probe to any input channel BNC, such as to CH 1.
2. Push the PROBE CHECK button and follow the directions on
the screen.
3. After you verify that the probe functions and is compensated
properly, connect the probe to the EXT TRIG BNC.
6 TDS1000B/2000B Series Oscilloscope User Manual
Loading...
