Teac PowerMax-950 User Manual
Dolby Digital 5.1
Multimedia Entertainment System
with AC 3 Decoder
PowerMax-950
User Manual
®
To ensure the smooth handling of your warranty please write the serial number of
your drive into the box. In the case of warranty you are expected to send it together
with a copy of your invoice to your nearest TEAC sales representative.
18
Contents
Important Safeguards ...................................................................................... 19
Features ........................................................................................................... 21
Package List..................................................................................................... 21
Precautions ...................................................................................................... 22
PowerMax-950 User Controls .......................................................................... 23
Connecting Speakers....................................................................................... 24
Connecting Equipment..................................................................................... 25
How to connect the XBOX ............................................................................... 26
How to connect PlayStation2 (PS2) ................................................................. 26
Positioning of the Speakers ............................................................................. 26
Surround Sound ............................................................................................... 28
Specifications ................................................................................................... 29
Warranty ........................................................................................................... 30
• Copyright © 2003, TEAC Corporation. All rights reserved. First Edition:
February 2003
• Company and product names provided herein are trademarks of their
respective companies.
• Changes in specifications and features may be made without notice or
obligation.
19
Placement
Place this unit on a stable, vibration-free, level
shelf, table or stand.
Use of a Cart or Stand
When placing this unit on a cart or stand, be
sure to follow recommendations for this unit in
the operating instructions. An appliance and
cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.
Check the voltage rating of this unit before connecting the unit to a power supply.
Be sure to connect the unit only to the type of
power supply indicated in the operating instruc-
tions, or as indicated on the unit itself.
Care of the Power Cord and Plug
Take care that the cord is not bent sharply (especially near its connection to the unit or near
the plug), that nothing is placed on it, and that
it is not pinched or crushed.
Never take hold of the plug or cord if your hand
is wet and always be sure to grasp the plug
body when connecting or disconnecting it.
Important Safeguards
For your protection, please read these instructions completely, and keep this manual for
future reference.
Carefully observe and comply with all warnings, cautions and instructions placed or de-
scribed in the operating instructions or service manual.
Warning
To guard against injury, the following basic safety precautions should be observed in the
installation, use, and servicing of the set.
Lightning
For added protection when using this speaker
unit during a lightning storm, or when it is left
unattended and unused for long periods of time,
unplug it from the wall outlet. This will prevent
damage to the receiver due to lightning and
power line surges.
Do not use this unit near water.
Don’t allow any foreign objects or liquid to get
inside this unit.
Don’t place small metal objects or anything
containing liquid on or near the unit.
Avoid placement of the unit where ventilation
is inadequate.
Do not place this unit in a bookcase or between
cabinets, or where curtains of furniture may
obstruct the ventilation openings.
Place this unit away from heat-emitting appliances.
Never place this unit near a radiator, heater,
stove, or any other heat-emitting equipment (including amplifiers).
By strong electromagnetic fields (e.g. wireless phones) noisy sound may be caused.
As long as the distortions may last we recommend to reduce the volume of the unit
with the master volume control.
20
Polarization
If this unit is equipped with a polarized AC line
plug (a plug having one blade wider that the
other), that plug will fit into the power outlet only
one way. This is a safety feature. If you are unable to insert the plug or if the plug should still
fail to fit, contact your electrician to replace the
obsolete outlet.
If the unit will not be used for a long time, turn
the set off. When the set is left unattended and
unused for long periods of time, unplug it from
the wall outlet as a precaution against the possibility of an internal malfunction that could
create a fire hazard.
Warning
To prevent fire or shock hazard, do not expose
the unit to rain or moisture.
CAUTION
Risk of electric shock.
Do not open.
Caution: to reduce the risk of electric shock, do
not remove cover (or back).
No user-serviceable parts inside.
Refer servicing to qualified service personnel.
Maintenance
Never attempt to repair the unit yourself if:
(a) The power cord or plug is damaged.
(b) A foreign object or liquid falls into the unit.
(c) The unit is exposed to rain.
(d) The unit does not function normally, or if
operation shows an unusual change.
(e) The unit has been dropped and the cabi-
net or chassis are damaged, etc.
Unplug the power cord and consult a qualified
technician (or the dealer from whom the unit
was purchased or the nearest service center).
This symbol is intended to alert
the user to the presence of uninsulated “dangerous voltage” with-
in the product’s enclosure that
may be of sufficient magnitude to constitute a
risk of electric shock to persons.
This symbol is intended to alert the
user to the presence of important
operating and maintenance servicing) instructions in the literature
accompanying the appliance.
CAUTION
TO PREVENT ELECTRIC SHOCK, DO
NOT USE THIS POLARIZED AC PLUG
WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS
THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
Repairs
Except for adjustments explained in the operating instructions do not attempt any repairs
by yourself. Be sure to request service from a
qualified technician (or the nearest service
center).
Cleaning
Unplug the set from the wall outlet before cleaning or polishing it. Do not use liquid cleaners or
aerosol cleaners. Use a cloth lightly dampened
with water for cleaning the exterior of the set.
21
■ Dolby Digital (5.1 channel) surround
sound
■ Dolby Pro • Logic surround sound
■ Stereo sound
■ Two digital inputs (optical and
coaxial)
■ One analog stereo input
(ø3,5mm)
■ Adapter for the optical audio output
of the XBOX
Features
■ Compact design with separate panel
at the decoder unit
■ Five satellite speakers (wall mount-
ing possible)
■ Powerful subwoofer in a wooden
case
■ Magnetically shielded speakers
■ Connectable to:
XBOX, PS2, DVD, TV, PC, Notebook,
MP3 player, VCR, LDP, CD-ROM
1 Decoder unit
1 Subwoofer
4 Satellite speakers
1 Center speaker
1 9pin connecting cable
1 12V power cable for connecting the
decoder unit
1 XBOX adapter
1 Coaxial cable
1 Optical cable (for connecting PS2)
1 User manual including warranty card
Package List
22
Precautions
Please read this owner's manual carefully. It has been prepared to help you
with initial set up procedures.
•
Do not open the cabinet. Doing so may
cause an electric shock.
•
Don't touch the main set with wet
hands, as this may cause an electric
shock.
•
When removing the power plug from
the wall outlet, pull the plug directly
away and never pull the cord.
•
Don't install the set under direct sun
light.
•
Never put anything, especially metal
into the unit.
•
Do not attempt to clean the unit with
alcohol, benzene or thinner, as this
may damage the finish.
•
Keep away from heating equipment.
•
Put the subwoofer more than 10cm
(0.3 feet) distant from wall and more
than 30cm (1 feet) distant from TV set
or PC monitor.
Caution!!!
P ower ON-OFF switch does not separate main power!!
