TC Electronic Gold Channel 2-Channel Microphone Preamp with EQ, Dynamics and Digital Outputs Software Addendum

1
ADDENDUM FOR GOLD CHANNEL SW 1.10
At the Utility page a new function with two parameters has been added:
Security Lock
When activating this parameter the User Interface is locked, and a special preset recall page appears. In “Lock” Stage” the only changes that are possible to perform are Total Recalls from the User- and Card-preset banks. The complete front-panel including Power on/off and Input level adjust is locked. A self-defined PIN code must be used to release the Gold Channel from the Lock status.
Assigning a new PIN-Code
T
o access the PIN-Code page from Unlocked mode:
• Press UTILITY and select the PIN-CODE parameter using the PARAMETER wheel.
• Press ENTER.
• Enter any four digit code from 0001 to 9999.
• Press ENTER to confirm the new code.
Activating the Lock Function
• Press UTILITY and select Security Lock using the PARAMETER wheel.
• Press ENTER.
The Gold Channel is now locked.
De-activating the Lock Function
To go back to normal operation with full access to all parameters:
• Press and hold the Power button for three seconds.
• When releasing POWER button a PIN-code page pops up. (See below)
• Dial in the PIN-code and press ENTER.
The Gold Channel is now un-locked and you are back to normal full operation mode with access to all parameters.
PIN-Code 0000 is the default value and DOES NOT give any security, meaning as long as you have not changed the PIN-code from 0000, all values will be accepted as valid when you want to unlock the user-interface.
If you forget your security PIN-code
In case you should forget your PIN-code a new function has been added at the Reset page:
• Press and hold the Program button while powering up with the power-button on the back-panel
to access the
Reset page.
• Select "Reset PIN-Code" and press Enter.
Now the PIN-code is set to default: 0000, and the machine will power up in full operation mode.
English version Prod. No: 608022211
