TaoTronics TT-AH008 User Manual

TAOTRONICS ULTRASONIC COOL AND WARM MIST HUMIDIFIER

User Guide

Hello

TT-AH008

EUROPE

E-mail:
[e-mail](UK)
[e-mail](DE)
[e-mail](FR)
[e-mail](ES)
[e-mail](IT)
EU Importer: ZBT International Trading GmbH, Halstenbeker Weg
98C, 25462 Rellingen, Deutschland

NORTH AMERICA

E-mail : [e-mail](US)
[e-mail](CA)
Tel : [phone] (Monday-Friday: 9:00 – 17:00 PST)
Address: 46724 Lakeview Blvd, Fremont, CA 94538

ASIA PACIFIC

E-mail : [e-mail](JP)

MADE IN CHINA

www.taotronics.com

MANUFACTURER

Shenzhen NearbyExpress Technology Development Company Limited
Address: Block D, Minle Industrial Park, Meiban Road, Longhua District,
Shenzhen, China. 518131

CONTENTS

English
Deutsch
Français
Español
Italiano

01/09

10/18

19/27

28/36

37/46

Thank you for choosing the TaoTronics Ultrasonic Cool
and Warm Mist Humidier. Please read this manual

carefully and keep it for future reference.

US UK CA

01/02

Features

• Quiet and eco-friendly ultrasonic technology

• Select between cool and warm mist

• Contemporary home décor design

• LED status indicator

• Adjustable mist output

• Auto relative humidity (RH) adjustment

• 1 to 12 hours auto-shutdown timer

• Sleep mode

Package Contents

• 1 x TaoTronics Ultrasonic Cool and Warm
Mist Humidier(Model: TT-AH008)

• 1 x User Guide

Specications (US /CA/UK)

Model

Operating Voltage

Power

Water Tank Volume

Max Mist Output

Working Time

TT-AH008

US/CA: AC 100-130V / 60Hz
UK: AC 220-240V / 50Hz

Cool: 30W
Warm: 110W

6 L / 1.6 Gal

Cool: ≥350 mL (11.8 oz) per hour
Warm: ≥400 mL (13.5 oz) per hour

Cool: Approx. 17 hours
Warm: Approx. 13 hours

Product Diagram

⑴ Nozzle
⑵ Water Tank Lid
⑶ Water Tank Handle
⑷ Water Tank
⑸ Filter
⑹ Water Inlet Cap
⑺ Cleaning Brush
⑻ Tank LED Light
⑼ Air Inlet
⑽ Power Cable
⑾ Pour Side
⑿ Safety Lock
⒀ Base
⒁ LED Display
⒂ Touchpad

03/04

Adding Water

• Turn the safety lock counter-clockwise by 90 degrees to unlock the
water tank.

• Remove the water tank lid, lift the water tank from the base, and place it
upside down to access the water tank cap.

• Rotate the tank cap counterclockwise to remove the cap and add
clean water into the tank. Make sure water does not overow.
Note: Please rotate the cap gently; do not screw with too much force to
avoid hurting your hand or the product.

• Put the cap back on the tank and screw clockwise to lock in place. Stop
twisting when no water comes out.

• Put the water tank back on the base.

• Turn the safety lock by clockwise 90 degrees to lock in place.

How to Use

• Power on the humidier. The unit now is in standby mode and the current
relative humidity (RH) will be shown on the display. You can operate the
humidier through:

⑴
⑵

⑶

⑷

⑸

⑹

⑺
⑻

⑼
⑽

⑾

⑿

⒀

⒁

⒂

1. ON / OFF: Tap the ON / OFF Button to turn on / off the unit. When
turned on, the display lights up indicating the current ambient
temperature, and RH value (no water icon will be shown instead if there
is no water). Level 4 MIST VOLUME will be activated. Tap the ON / OFF
Button again to enter standby mode again.

2. HEATING: Tap the HEATING Button to turn on warm mist and a red

heating icon will appear on the display. Tap again to shut off warm mist.
Note: The humidier will heat the mist, it will take up to 25 minutes for the

mist to warm up. Warm mist can increase mist output by 50 to 100 mL /
hour, but it uses more power than cool mist.

3. HUMIDITY: Tap the HUMIDITY Button to cycle through the RH level

from 30% to 75%. Once selected, the RH value ashes for 5 seconds. An
“AUTO” icon and the corresponding MIST VOLUME indicator icon will
appear. In this mode, the unit will automatically adjust the mist output
based on the set RH. When the set RH is 1% - 10%, 11% - 15%, or over 15%
higher than the ambient RH, Level 1, 4, or 7 mist volume will be
automatically activated accordingly.

4. MIST VOLUME: Slide across the MIST VOLUME Buttons to exit

humidity setting and manually cycle through 7 levels of mist output. The
corresponding mist volume indicator icons will appear.

5. TIMER: Press the TIMER button to set an automatic timer between 1

to 12 hours. The TIMER icon and the set time will appear on the display
and after approx. 5 seconds, the display will show countdown
remaining time by hour. After the timer is set, you can tap the TIMER
Button once to check the current timer setting. Tap and hold the TIMER
Button for 1.5 seconds to exit the timer function.

6. SLEEP: Tap the SLEEP Button to turn on sleep mode. The display will
dim down to a third of the original brightness. In 15 seconds, all the LED
lights and display will turn off except the sleep icon. The beep sound for
button pushing or no water reminder will be disabled. In sleep mode,
when the ambient RH is at 55% - 70%, Level 2 mist volume will be

activated; when the ambient RH is below 55%, Level 4 mist volume will be
activated. The unit will stop putting out mist when the ambient RH is higher
than 70% and resume working once it drops to or below 70%. In sleep
mode, you can tap any button to wake up the display. All buttons are
disabled except the SLEEP and ON / OFF Button. You can tap the SLEEP
Button once again to exit sleep mode.

7. LIGHT: Tap the LIGHT Button to turn on / off the LED light of the water
tank. This function is disabled in standby or sleep mode. Tap and hold
the LIGHT Button for 1.5 seconds can switch between Celsius and
Fahrenheit on the display. The unit is set to Celcius by default for
Europen market and Fahrenehit for the North American market.

The unit comes with a memory function. When the unit is shut off and
power is still connected, it will return to the previous setting when turned
back on.

When water is depleted, the unit will stop working and a no water icon will
appear on the display. It will resume working and return to the previous
setting once water is added in the water tank. The unit will automatically
shut off in 15 minutes after running out of water.

In any mode, once the ambient RH reaches over 90%, the humidier will
stop working and resume working once it drops below 85%.

The display will dim down in 15 seconds after left alone without any operation.
When water has run out, three beep sounds will be heard. This function is

invalid in sleep mode.

Important

• Make sure water does not overow when lling the water tank.

• Stop using when the water level is low.

• Do not power on the humidier when the water tank is not in place.

• Never add water hotter than 40°C / 104°F to avoid any possible damage

or malfunction of the device.

05/06

ON/OFF

HEATING

LIGHT

• Do not pour the water through the mist outlet. Always drain water from
the pour side. Wipe off any water outside the body with a dry cloth.

• When moving the humidier, move the entire unit together. Do not move
just the water tank.

• When the room temperature is 0°C / 32°F or below, please empty the
water from the unit. Ice can damage the components.

• Do not place metals, chemicals and detergents into the water to avoid
any possible damage or malfunction of the device.

• When the water tank is full, do not move it as the water might overow or
ow into the body and cause damages.

• After usage turn the unit off and unplug it from the power outlet.

• Never pour out the water remaining in the water tank without the power
turned off and unplugged from the socket.

Cleaning the Water Tank

Before cleaning, make sure that the unit is turned off and unplugged from
the power socket.

• Clean the water tank regularly (recommended once every 2 - 3 weeks) ­Remove the water tank cap, wipe off the lime scale in it and rinse off with
clean water.

• Cleaning the base (recommended once a week): Wipe the base with a
soft cloth dipped with a mild cleaning agent and rinse off with clean
water.

• Cleaning the humidier: Rinse a soft cloth in warm water and wipe off
surface stains. You can rinse the nozzle under tap water directly.

• Storing the humidier: When the unit has not been used for a long time,
clean and dry the unit and store it in a dry place in the original package.

Caution

• Please do not dismantle the product by yourself, always ask a
professional electrician or authorized technician for repairs.

• If you notice an unusual odor, please turn off the unit immediately.

• Please do not remove the power plug with wet hands as it may cause
electric shock.

• Do not place this unit on a slope or uneven surface to avoid water
leaking or component damage.

• Do not put this unit near any heat source or under direct sunlight.

• Keep away from other electric appliances that are prone to
humidity damage.

• Regularly clean the unit if it won’t be used for a long period. Store in a
dry and shady place.

• Not a toy. Keep away from children.

Troubleshooting Guide

07/08

Solutions

Connect power adapter

Tap the MIST VOLUME Buttons
to adjust the mist output

Add water into water tank

Power off and place in a well
ventilated place for
10 minutes

Tap the HUMIDITY Button to
increase the RH level

Causes

No power

Misting not turned on

Not enough water in the tank

The diffuser is getting too hot

The set RH is lower than
the ambient RH

Problem

No mist coming out

Warranty

TaoTronics products are covered by a 12 month limited warranty from the
date of its original purchase. Register your product on the TaoTronics
website for a free warranty extension. If any problems occur, please
contact our support team.

We can only provide after sales service for products that are sold by
TaoTronics or TaoTronics authorized retailers and distributors. If you have
purchased your unit from a different place, please contact your seller for
return and warranty issues.

Get rid of some water

Clean the water tank
as instructed

Clean air inlet

Water exceeding the inlet

Stain built up inside water tank

Air inlet blocked by dust

Cover not properly covered Cap on the cover properly

High mist output Adjust the mist output to low

Contaminated water Use clean water

Unit is new

Clean water tank as instructed,
use after air drying

Dirty water

Mist or drops of
water from around
the device

Clean water tank as instructed,
use clean water

Temperature and humidity of
environment is too high

Move the unit to a
well-ventilated area

Abnormal mist

Water leakage

Bad / strange smell

Vielen Dank, dass Sie sich für den TaoTronics Ultrasonic Kalter und
Warmer Sprühnebel Luftbefeuchter entschieden haben. Bitte lesen
Sie dieses Merkblatt aufmerksam durch und bewahren es für die
Zukunft auf.

DE

09/10

Support

Email: [e-mail] Tel: [phone]
ext: 4 (Mon to Fri, 8 am to 5 pm, PST) Website: www.taotronics.com

⑴ Sprühdüse
⑵ Wassertank- Deckel
⑶ Wassertank- Griff
⑷ Wassertank
⑸ Filter
⑹ Wassereinlass- Kappe
⑺ Reinigungsbürste
⑻ LED Licht Tank
⑼ Lufteinlass
⑽ Stromkabel
⑾ Abtropfäche
⑿ Sicherheitsschloss
⒀ Sockel
⒁ LED Display
⒂ Touchpad

Besonderheiten

• Ruhige und umweltfreundliche Technologie

• Wählen Sie zwischen kaltem und warmem Sprühnebel

• Modernes Home- Décor Design

• LED Status Indikator

• Einstellbarer Sprühnebel-Auslass

• Automatische relative Feuchtigkeitseinstellung (RH)

• 1 bis 12 Stunden automatische Ausschaltfunktion

• Schlafmodus

Dieses Set umfasst

• 1 x TaoTronics Ultrasonic Kalter und Warmer Sprühnebel
Luftbefeuchter (Modell: TT-AH008)

• 1 x Nutzerhandbuch

Spezikationen

Modell

Bedienungsstrom

Leistung

Wassertank Volumen

Maximaler
Sprühnebel-Auslass

Betriebszeit

TT-AH008

AC 220-240V / 50Hz

Kalt: 30W
Warm: 110W

6 L / 1.6 Gal l

Kalt: ≥350 mL pro Stunde
Warm: ≥400 mL pro Stunde

Kalt: ca. 17 Stunden
Warm: ca. 13 Stunden

Produkt Diagramm

11/12

⑴
⑵

⑶

⑷

⑸

⑹

⑺
⑻

⑼
⑽

⑾

⑿

⒀

⒁

⒂
