Tait TP8110 User Manual

0 (0)

TP8110

Conventional Portable Radios

User’s Guide

MPC-00026-07 · Issue 7 · January 2013

Directive 1999/5/EC Declaration of Conformity

da Dansk

Undertegnede Tait Limited erklærer herved, at følgende udstyr TPCB1A, TPCC0A, TPCH5A & TPCH6A overholder de væsentlige krav og øvrige relevante krav i

direktiv 1999/5/EF.

Se endvidere: www.taitradio.com/eudoc

de Deutsch

Hiermit erklärt Tait Limited die Übereinstimmung der Geräte TPCB1A, TPCC0A, TPCH5A & TPCH6A mit den grundlegenden Anforderungen und den anderen relevanten Festlegungen der Richtlinie 1999/5/EG.

Siehe auch: www.taitradio.com/eudoc

el Ελληνικά

Η Tait Limited δηλώνει ότι το TPCB1A, TPCC0A, TPCH5A & TPCH6A

συμμορφώνεται προς τις ουσιώδεις απαιτήσεις και τις λοιπές σχετικές διατάξεις της Οδηγίας 1999/5/ΕΚ.

Βλέπε επίσης: www.taitradio.com/eudoc

en English

Tait Limited declares that this TPCB1A, TPCC0A, TPCH5A & TPCH6A complies with the essential requirements and other relevant provisions of Directive 1999/5/EC.

es Español

Por medio de la presente Tait Limited declara que el TPCB1A, TPCC0A, TPCH5A & TPCH6A cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.

Vea también: www.taitradio.com/eudoc

fi Suomi

Tait Limited vakuuttaa täten että TPCB1A, TPCC0A, TPCH5A & TPCH6A tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin

muiden ehtojen mukainen. Katso: www.taitradio.com/eudoc

fr Français

Par la présente, Tait Limited déclare que l'appareil TPCB1A, TPCC0A, TPCH5A & TPCH6A est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE. Voir aussi: www.taitradio.com/eudoc

it Italiano

Con la presente Tait Limited dichiara che questo TPCB1A, TPCC0A, TPCH5A & TPCH6A è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.

Vedi anche: www.taitradio.com/eudoc

nl Nederlands

Hierbij verklaart Tait Limited dat het toestel TPCB1A, TPCC0A, TPCH5A & TPCH6A in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/ EG.

Zie ook: www.taitradio.com/eudoc

pt Português

Tait Limited declara que este TPCB1A, TPCC0A, TPCH5A & TPCH6A está conforme com os requisitos essenciais e outras provisões da Directiva 1999/5/CE.

Veja também: www.taitradio.com/eudoc

sv Svensk

Härmed intygar Tait Limited att denna TPCB1A, TPCC0A, TPCH5A & TPCH6A står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.

Se även: www.taitradio.com/eudoc

Contents
Directive 1999/5/EC Declaration of Conformity ............................................	3
For your safety ...........................................................................................	10
Safety warnings used in this guide .......................................................	10
Radio frequency exposure information ..................................................	10
Compliance with RF energy exposure standards ...................................	12
Radio frequency emissions limits in the USA .........................................	12
Radio frequency emissions limits in Canada ..........................................	12
Frequency band reserved for distress beacons ......................................	13
Australia and New Zealand citizens band (476.4 to 477.4MHz) ...........	13
Health, safety and electromagnetic compatibility in Europe ..................	14
Interference with electronic devices ......................................................	15
Potentially explosive atmospheres and blasting areas ...........................	16
Intrinsically Safe radios .........................................................................	16
Radio installation and operation in vehicles ..........................................	17
Vehicle charger installation and operation ............................................	18
Electromagnetic compatibility in European vehicles ..............................	18
Unapproved modifications or changes to radio .....................................	18
Attaching of labels ...............................................................................	18
Use of lithium-ion batteries ..................................................................	19
Short-circuiting battery contacts ...........................................................	19
Multicharger safety information ............................................................	19
Charger compliance information ..........................................................	20
Custom radio settings ................................................................................	21
About this guide ........................................................................................	22
Related documentation ........................................................................	22
Before using your radio ..............................................................................	23
For your safety—battery warning ........................................................	24
Attaching labels to the radio or battery ................................................	24
Charging the battery before first use ....................................................	25
Attaching the battery ...........................................................................	25
Removing the battery ...........................................................................	26
Attaching the antenna .........................................................................	26
Attaching a belt clip .............................................................................	26

Removing a belt clip .............................................................................	26
Installing an accessory ..........................................................................	27
Getting started ...........................................................................................	28
About the radio controls .......................................................................	29
Understanding the radio indicators .......................................................	31
Accessing frequently used features .......................................................	32
Turning the radio on and off .................................................................	33
Adjusting the volume ...........................................................................	33
Extending battery life ............................................................................	33
Basic operation ..........................................................................................	35
Selecting a channel ..............................................................................	36
Selecting a group .................................................................................	36
Checking that a channel is clear ...........................................................	36
Communicating directly with other radios .............................................	37
Activating the repeater before a call .....................................................	37
Making a call .......................................................................................	38
Receiving a call .....................................................................................	39
Using voice inversion scrambling ..........................................................	39
Using encryption ..................................................................................	40
Hearing faint and noisy signals .............................................................	41
Using the radio in different repeater areas ............................................	41
Scanning a group of channels ...............................................................	42
Making and receiving different types of calls ..............................................	44
Making an individual or group call ........................................................	45
Resending calls automatically ...............................................................	45
Receiving an individual or group call .....................................................	46
Receiving a two-tone call .....................................................................	46
Calling a telephone or a remote device .................................................	47
Making one-touch preset calls ..............................................................	47
Making an emergency call ....................................................................	48
Using the lone worker emergency features ...........................................	49
Charging and caring for batteries ...............................................................	52
About the chargers ...............................................................................	53
Special conditions when using IS radios ................................................	54
Before using the charger ......................................................................	54

Charging the battery ............................................................................	57
Maintaining battery life and performance .............................................	59
Storing batteries ...................................................................................	60
Disposing of batteries ...........................................................................	60
Troubleshooting .........................................................................................	61
When your radio won’t turn on ............................................................	62
Troubleshooting your charger ...............................................................	62
General care ........................................................................................	63
Function key options ..................................................................................	64
Common functions ...............................................................................	64
Tait Software Licence Agreement ...............................................................	66

All information contained in this document is the property of Tait Limited. All rights reserved. This document may not, in whole or in part, be copied, photocopied, reproduced, translated, stored, or reduced to any electronic medium or machine-readable form, without prior written permission from Tait Limited.

The word TAIT and the TAIT logo are trademarks of Tait Limited. All trade names referenced are the service mark, trademark or registered trademark of the respective manufacturers.

Disclaimer

There are no warranties extended or granted by this document. Tait Limited accepts no responsibility for damage arising from use of the information contained in the document or of the equipment and software it describes. It is the responsibility of the user to ensure that use of such information, equipment and software complies with the laws, rules and regulations of the applicable jurisdictions.

Enquiries and comments

If you have any enquiries regarding this document, or any comments, suggestions and notifications of errors, please contact your regional Tait office.

Updates of manual and equipment

In the interests of improving the performance, reliability or servicing of the equipment, Tait Limited reserves the right to update the equipment or this document or both without prior notice.

Intellectual property rights

This product may be protected by one or more patents or designs of Tait Limited together with their international equivalents, pending patent or design applications, and registered trade marks: NZ409837, NZ409838, NZ508806, NZ508807, NZ509242, NZ509640, NZ509959, NZ510496, NZ511155, NZ511421, NZ516280/NZ519742, NZ520650/NZ537902, NZ521450, NZ522236, NZ524369, NZ524378, NZ524509, NZ524537, NZ524630, NZ530819, NZ534475, NZ534692, NZ535471, NZ537434, NZ546295, NZ547713, NZ569985, NZ577009, NZ579051, NZ579364, NZ580361, AU2003281447, AU2004216984, AU2005267973, AU11677/2008, AU13745/2008, CN200930004200.4, CN200930009301.0, CN1031871, CN1070368, EU000915475-0001, EU000915475-0002, GB2386010, GB23865476, GB2413249, GB2413445, US5745840, US7411461, US7649893, US10/523952, US10/546696, US10/546697, US10/547964, US10/597339, US11/572700, US29/306491, US61/218015, US61/236663, US61/238769, US61/251372.

Angled volume knob produced under license from Motorola Solutions Inc., US Patent No. 5,784,688.

Environmental responsibilities

Tait Limited is an environmentally responsible company which supports waste minimization, material recovery and restrictions in the use of hazardous materials.

The European Union’s Waste Electrical and Electronic Equipment (WEEE) Directive requires that this product be disposed of separately from the general waste stream when its service life is over. For more information about how to dispose of your unwanted Tait product, visit the Tait WEEE website at www.taitradio.com/weee. Please be environmentally responsible and dispose through the original supplier, or contact Tait Limited.

Tait Limited also complies with the Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment (RoHS) Directive in the European Union.

In China, we comply with the Measures for Administration of the Pollution Control of Electronic Information Products. We will comply with environmental requirements in other markets as they are introduced.

For your safety

Before using the radio, please read the important safety and compliance information in the following sections. Before using an intrinsically safe (IS) radio, see also "Intrinsically Safe radios" on page 16.

Safety warnings used in this guide

Please follow exactly any instruction that appears in the text as an ‘alert’. An alert provides necessary safety information as well as instruction in the proper use of the product. This user’s guide uses the following types of alert:

Warning This alert is used when there is a hazardous situation which, if not avoided, could result in death or serious injury.

Caution This alert is used when there is a hazardous situation which, if not avoided, could result in minor or moderate injury.

Notice This alert is used to highlight information that is required to ensure procedures are performed correctly. Incorrectly performed procedures could result in equipment damage or malfunction.

This icon is used to draw your attention to information that may improve your understanding of the equipment or procedure.

Radio frequency exposure information

For your own safety and to ensure you comply with the Federal Communication Commission’s (FCC) radio frequency (RF) exposure guidelines, please read the following information before using this radio.

Using this radio

You should use this radio only for work-related purposes (it is not authorized for any other use) and if you are fully aware of, and can exercise control over, your exposure to RF energy. To prevent

exceeding FCC RF exposure limits, you must control the amount and duration of RF that you and other people are exposed to. It is also important that you:

■Do not remove the RF Exposure label from the radio.

■Ensure this RF exposure information accompanies the radio when it is transferred to other users.

■Do not use the radio if you do not adhere to the guidelines on controlling your exposure to RF.

Controlling your exposure to RF energy

This radio emits radio frequency (RF) energy or radio waves primarily when calls are made. RF is a form of electromagnetic energy (as is sunlight), and there are recommended levels of maximum RF exposure.

To control your exposure to RF and comply with the maximum exposure limits for occupational/controlled environments, follow these guidelines:

■Do not talk (transmit) on the radio more than the rated transmit duty cycle. This is important because the radio radiates more energy when it is transmitting than when it is receiving.

■When listening and talking on the radio, hold it upright in front of your face so that it is at least one inch (2.5cm) away from any part of your face. Keeping the radio at the recommended distance is important because exposure to RF decreases rapidly the further away the antenna is from your body.

■Keep the antenna at least one inch (2.5cm) from your face at all times.

■If you wear your radio, you must always put it in a carrying accessory that has been specifically approved by Tait for this radio. Using non-approved body-worn accessories may mean you expose yourself to higher levels of RF than recommended

by the FCC’s occupational/controlled environment RF exposure limits.

■Ensure you only use Tait-approved antennas, batteries, and accessories.

For more information on what RF energy is and how to control your exposure to it, visit the FCC website at www.fcc.gov/oet/rfsafety/rf-faqs.html.

Compliance with RF energy exposure standards

This two-way radio complies with these RF energy exposure standards and guidelines:

■United States Federal Communications Commission, Code of Federal Regulations; 47 CFR §§ 1.1307, 1.1310, and 2.1093.

■American National Standards Institute (ANSI) / Institute of Electrical and Electronic Engineers (IEEE) C95.1-1992.

■Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition.

This radio complies with the IEEE and ICNIRP exposure limits for occupational/controlled RF exposure environments at operating duty factors of up to 50% talk to 50% listen.

Radio frequency emissions limits in the USA

Part 15 of the FCC Rules imposes RF emission limits on receivers. This radio complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause

harmful interference.

Radio frequency emissions limits in Canada

This device complies with Industry Canada licence exempt RSS standard(s). Operation is subject to the following two conditions:

(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

Frequency band reserved for distress beacons

Frequency band 406 to 406.1MHz is reserved for use by distress beacons. Transmissions should not be made within this frequency band.

Australia and New Zealand citizens band (476.4 to 477.4MHz)

AS/NZS 4365 deals with the use of frequencies in the 476.425 to 477.400 MHz band. Products capable of operating in this band have been approved for operation in the UHF Citizens Band Radio Service which is licensed in Australia by the ACMA Radiocommunications (Citizens Band Radio Stations) Class Licence and in New Zealand by the MED General User Radio Licence for Citizens Band Radio. Operation is subject to conditions contained within those licences.

Repeaters operate by receiving a transmission on one channel and re-transmitting it on another. Operators are required to avoid using local repeater input channels, which will be in the range of 31 to 38, unless it is intended to use the repeater facility, and to avoid using local repeater output channels, which will be in the range 1 to 8, at any time.

No voice transmissions are permitted on data channels 22 and 23. Equipment meeting this standard will inhibit voice operation on channels 22 and 23.

In Australia:

■Except in an emergency, a CB transmitter must not be operated on UHF channels 5 and 35.

■Channel 11 is the customary calling channel for establishing communications.

■Channel 40 is the customary road vehicle channel.

Health, safety and electromagnetic compatibility in Europe

In the European Community, radio and telecommunications equipment is regulated by Directive 1999/5/EC, also known as the Radio and Telecommunications Terminal Equipment (R&TTE) directive. The requirements of this directive include protection of health and safety of users, as well as electromagnetic compatibility.

Intended purpose of product

This product is an FM radio transceiver. It is intended for radiocommunication in the Private Mobile Radio (PMR) or Public Access Mobile Radio (PAMR) services, to be used in all member states of the European Union (EU) and states within the European Economic Area (EEA).

Restrictions

This product can be programmed to transmit on frequencies that are not harmonized throughout the EU/EEA, and will require a licence to operate in each member state.

This product can be programmed for frequencies or emissions that may make its use illegal. Where applicable, a license must be obtained before this product is used. All license requirements must be observed. Limitations may apply to transmitter power, operating frequency, channel spacing, and emission.

Declaration of conformity

Brief Declarations of Conformity appear on on page 3 of this document. To download the formal declaration of conformity, go to www.taitradio.com/eudoc.

Interference with electronic devices

Warning Some electronic devices may be prone to malfunction due to the lack of protection from RF energy that is present when

your radio is transmitting.

Examples of electronic devices that may be affected by RF energy are:

■aircraft electronic systems

■vehicular electronic systems such as fuel injection, anti-skid brakes, and cruise control

■medical devices such as pacemakers and hearing aids

■medical equipment in hospitals or health care facilities.

Switch off the radio before boarding an aircraft. Using your radio while in the air is not permitted.

Consult the manufacturer (or its representative) of any such electronic devices to determine whether electronic circuits in those devices will perform normally when the radio is transmitting. Warning If you have a pacemaker:

■ immediately turn off the radio if you suspect it is interfering with the pacemaker

■keep the radio at least 6 inches (15cm) from the pacemaker while the radio is on

■use the radio on your right side to minimize interference

■never carry the radio in a breast pocket.

If there is interference between your hearing aid and the radio, please discuss an alternative solution with the hearing aid manufacturer.

Potentially explosive atmospheres and blasting areas

Warning Unless the radio is specifically certified for use in a

potentially explosive atmosphere, turn off the radio before entering such an atmosphere. An explosion could cause serious injury or death. Examples of potentially explosive atmospheres include filling stations, and any environment where there are flammable liquids, gases, or dusts.

Warning Turn off the radio before approaching blasting caps, a blasting area, or any area where you are instructed to turn off a two-way radio. Obey all signs and instructions. Interference with blasting operations could cause serious injury or death.

Intrinsically Safe radios

Intrinsically Safe (IS) radios are certified by a third party to be safe to use in particular hazardous locations.

One or more of the following marks identifies a TP8100 portable as an IS radio:

■an IS circle logo on the radio’s front panel

■a label on the radio, showing IS information and the FM

diamond logo

APPROVED

■ a label on the radio battery, showing IS information and the FM diamond logo .

APPROVED

An IS radio must be serviced only by an agency certified by both the approval authority and by Tait Limited. Any unauthorized repair or substitution of parts invalidates the intrinsic safety rating and the third party IS approval. To have an IS radio serviced, return it to an authorized Tait branch or subsidiary.

Intrinsically safe TP8100 radios and accessories are approved by Factory Mutual Corporation (FM) to the following ratings:

■IS / I, II, III / 1 / CDEFG / T4, Ta=40°C; IP67

■NI / I / 2 / ABCD / T4, Ta=40°C

■S / II, III / EFG; IP67.

TP8100 radios with the product code “T03-20x” have FM IS approval.

The following communication accessories can be used with an Intrinsically Safe TP8100 radio, but are suitable for IS / I / 1 / CD and NI / I / 2 / CD applications only.

■TPK-AA-101 heavy-duty speaker microphone (MIL-STD) with volume control and programmable button

■T952-051 in-ear earphone

Warning Use only an IS-approved battery with an IS radio, and do not charge the battery in a hazardous location. An explosion could cause serious injury or death.

Use only IS-approved accessories with IS radios. For an up-to-date list of FM-approved accessories, go to the Tait website or contact your nearest Tait office.

Warning IS certification applies only while the product is used in accordance with these instructions.

Radio installation and operation in vehicles

Warning Keep the radio away from airbags and airbag deployment areas. Do not install, charge, or place a radio near such

areas. An activated airbag can propel a portable radio with sufficient force to cause serious injury to vehicle occupants. An airbag may not perform to specification if obstructed by a radio.

Warning To avoid damage to existing wiring, airbags, fuel tanks, fuel and brake lines, or battery cables, refer to the installation

guide for the radio, and to the vehicle manufacturer’s manual, before installing electronic equipment in the vehicle.

Using a handheld microphone or a radio while driving a vehicle may violate the laws and legislation that apply in your country or state. Please check the vehicle regulations in your area.

Vehicle charger installation and operation

For detailed instructions necessary to the safe installation and operation of the vehicle charger, please refer to the documentation supplied with the vehicle charger.

Electromagnetic compatibility in European vehicles

In the European Community, radio equipment fitted to automotive vehicles is regulated by Directive 72/245/EEC and its amendments. The requirements of this directive cover the electromagnetic compatibility of electrical or electronic equipment fitted to automotive vehicles.

Unapproved modifications or changes to radio

The radio is designed to satisfy the applicable compliance regulations. Do not make modifications or changes to the radio that are not expressly approved by Tait Limited. Failure to do so could invalidate compliance requirements and void the user’s authority to operate the radio.

Attaching of labels

Warning Do not obstruct the vent hole on the battery or the vent hole on the radio chassis label. If the vent on the battery is

obstructed the battery may explode, causing personal injury and/or damage to property. If the vent on the radio is obstructed, audio quality and/or key function may deteriorate and radio seals may be damaged.

Notice Tait Limited recommends that you do not affix additional labels to the surfaces between the radio chassis and the battery. The fit between these surfaces is intentionally firm and any added thickness will damage the points of attachment between radio and battery. If you must attach a customized label, use only a thin gummed paper label applied to the bottom 25% of the radio chassis label and/or to the top 25% of the battery label. Do not obstruct the vent holes (see Warning above). Do not allow the

paper label to extend beyond the recessed label area or to conceal relevant product information.

Use of lithium-ion batteries

Warning A damaged battery can cause an explosion or fire, and can result in personal injury and/or property damage. To prevent personal injury and/or damage to property, read the important safety information supplied with the battery.

Short-circuiting battery contacts

Caution Do not short-circuit the battery contacts, neither intentionally nor accidentally, e.g. by placing the battery with conductive materials such as keys or jewelry inside a pocket or container. Short-circuiting the battery contacts can heat up the conductive material and cause personal injury and/or damage to property.

Multicharger safety information

Warning English (en): This equipment must be connected to an earthed mains socket-outlet.

Norsk (no): Apparatet må tilkoples jordet stikkontakt. Suomi (fi): Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan.

Svenska (sv): Apparaten skall anslutas till jordat uttag.

Charger compliance information

United States

This battery charger has been tested and found to comply with the limits for a Class B digital device, in accordance with part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This battery charger generates, and can radiate, radio frequency energy. If it is not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur. If this charger does cause harmful interference to radio or television reception (which can be determined by turning the charger off and on), try to correct the interference by:

■Reorienting or relocating the receiving antenna.

■Increasing the separation between the equipment and receiver.

■Connecting the equipment into an outlet on a circuit different from that to which the receiver is connected.

■Consulting the dealer or an experienced radio or television technician for help.

Canada

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de classe B est conforme à la norme canadienne NMB-003.

Custom radio settings

Use the following table to list your radio’s programmed settings

	Top key
	short press:	top key
	long press:	top key
	long press:
	Function key 1
	short press:	F1
	long press:
	Function key 2	F2
	short press:
	long press:
	Channel selector
	1	9
	2	10
	3	11
	4	12
	5	13
	6	14
	7	15
	8	16

About this guide

This user’s guide provides information about the TP8110 portable radio.

The radio behavior described in this guide applies to radios with firmware version 1.07 or higher. If your radio does not operate as you expect, contact your radio provider for assistance.

Before using your radio

Once you have unpacked your radio, there are a few tasks you must do before you can use it. The most important of these is to charge your battery for the first time—allow 2.5 hours for this. Warning Fit only an IS-approved battery and IS-approved accessories to an intrinsically safe (IS) radio. Fitting a battery or accessory that is not IS-approved exposes the customer to a risk of explosion which could cause serious injury or death. For detailed information about IS radios and how to identify them, see "Intrinsically Safe radios" on page 16.

This section covers:

■For your safety—battery warning

■Attaching labels to the radio or battery

■Charging the battery before first use

■Attaching the battery

■Removing the battery

■Attaching the antenna

■Attaching a belt clip

■Removing a belt clip

■Installing an accessory

+ 51 hidden pages
