Strong SRT 6511 User Manual

Digital Satellite Receiver SRT 6511

Picture similar

User Manual

PART 1 • English

TABLE OF CONTENTS

1.0 INTRODUCTION 2

1.1 Safety Instructions 2

1.2 Storage 3

1.3 Equipment Set-up 3

1.4 Features & Accessories 3

2.0 YOUR RECEIVER 4

2.1 Front Panel 4

2.2 Rear Panel 4

2.3 Remote Control Unit (RCU) 4

3.0 CONNECTIONS 5

3.1 Connecting to TV & VCR 5

3.2 Connecting to Digital Audio Ampliﬁer 5

3.3 Connecting to Satellite Dish 5

3.4 Connecting to computer by serial cable 5

4.0 STARTING UP FOR THE FIRST TIME 5

4.1 Language Selection 6

4.2 Audio Language Selection 6

4.3 Time Zone adjustment 6

4.4 Satellite conﬁguration 6

5.0 MAIN MENU 6

5.1 Installation 6

5.2 Program Setting 8

5.3 User preference 8

5.4 System Setting 9

5.5 Utility 9

6.0 OTHER OPERATIONS 10

6.1 Electronic program guide (EPG) 10

6.2 Zapping and information banners 10

6.3 Audio Language selection 10

6.4 Channel list and view mode 11

6.5 FAV list 11

6.6 Teletext function 11

6.7 Subtitle function 11

6.8 Sleep Timer function 11

6.9 Zoom function 11

A.1 TROUBLESHOOTING 11

A.2 PIN CODE 12

A.3 SPECIFICATIONS 12

English

1.0 INTRODUCTION

1.1 Safety Instructions

CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE FOR SERVICING.

Explanation of WARNING symbols

The lightning ﬂash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of not isolated dangerous voltage within the inside of the product that may be of

electric shock to persons.

WARNING: TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK OR ANNOYING INTERFRERENCE, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE AND ONLY USE THE RECOMMENDED ACCESSORIES.

n Read All Instructions — Before you use the product, read all

operating instructions. For more information on accessories such as the lithium ion battery, refer to the manuals provided with those products

n Save These Instructions — Save all safety and operating

instructions for future reference

n Heed Warnings — Read carefully and follow all warning labels on

the product and those described in the instructions.

n Follow Instructions — Follow all instructions provided with

this product

n Cleaning — Always unplug this product from the wall outlet

before cleaning. Use only a damp cloth for cleaning. Never use any type of liquid or aerosol cleaner, or any type of organic solvent to clean this product

n Attachments — For your safety, and to avoid damaging the

product, use only accessories recommended by STRONG.

n Water and Moisture — Never use this product around water (near

a bathtub, kitchen sink, laundry tub, wet basement, swimming pool or in the rain)

n Location — To avoid damage to the product and prevent personal

injury, never place this product on an unstable stand, tripod, bracket, table or cart. Mount only on a stable tripod, stand, or bracket. Follow the instructions that describe how to safely mount the product,and use only the mounting devices recommended by the manufacturer

n Power Sources — Connect this product only to the power source

described on the product label. If you are not sure about the type of power supply in your home, consult your local power company

n Refer to instruction pages for information on using the product

with a battery

sufﬁcient magnitude to constitute a risk of

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and servicing instructions in the literature accompanying the appliance.

Read the following instructions carefully

PART 1 • English

n Grounding, Polarization — If this product is used with a speciﬁed

AC adapter, the adaptermay be equipped with a polarized alternating current line plug (a plug with one blade wider than the other). This safety feature allows the plug to ﬁt into the power outlet only one way. If you cannot insert the plug into the wall outlet, pull it out, reverse it, and then reinsert it. If the plug still fails to ﬁt, contact an electrician and have the receptacle replaced

n Protecting the Power Cord — The power supply

cord should be placed so it will not bewalked on. Never put a heavy object on the power cord or wrap it around the leg of a table or chair. Keep the area around the power cord connection points, at the power outlet, and at the product connection, free of all AC adapter or accessory power cords

GENERAL PRECAUTIONS SAFETY PRECAUTIONS

n Lightning — If a lightning storm occurs while using a speciﬁed

AC adapter, remove it from the wall outlet immediately. To avoid damage from unexpected power surges, always unplug the AC adapter from the power outlet and disconnect it from the receiver when the receiver is not in use

n Overloading — Never overload wall outlets, extension cords,

power strips, or other power connection points with too many plugs

n Foreign Objects, Liquid Spillage — To avoid personal injury

caused by ﬁre or electrical shock from contact with internal high voltage points, never insert a metal object into the product. Avoid using the product where there is a danger of spillage

n Heat — Never use or store this product near any heat source

such as a radiator, heat register,stove, or any type of equipment or appliance that generates heat, including stereo ampliﬁers

n Servicing — Refer all servicing to qualiﬁed personnel. Attempting

to remove the covers or disassemble the product, could expose you to dangerous high voltage points

n Damage Requiring Service — If you notice any of the conditions

described below while using a speciﬁed AC adapter, unplug it from the wall outlet and refer servicing to qualiﬁed service personnel:

1. Liquid has been spilled onto the product or some other object has fallen into the product.

2. The product has been exposed to water.

3. The product does not operate normally despite following operating instructions. Adjust only the controls described in the operating instructions as improper adjustment of other controls could damage the product and require extensive repair work by a qualiﬁed technician.

4. The product has been dropped or damaged in any way.

5. The product exhibits a distinct change in performance.

n Replacement Parts — When replacement parts are required, make

sure that the authorized service center uses only parts with the same characteristics as the originals, as recommended by the manufacturer. Unauthorized substitution of parts could result in ﬁre, electrical shock, or create other hazards

n Safety Check — Upon completion of servicing or repairs, ask the

service technician toperform safety checks to determine that the product is in good working order

n Apparatus shall not be exposed to dripping or splashing and no objects

ﬁlled with liquids, such as vases, shall be placed on the apparatus.

n Where the mains plug or all-pole mains switch is used as the disconnect

device, the disconnect device shall remain readily operable.
