Stanford Research Systems PS355, PS365, PS370, PS375 Operation And Service Manual

Operation and Service Manual

High Voltage Power Supplies

PS355, PS365, PS370, PS375

Stanford Research Systems

Revision 1.0 · December, 2008

Certi cation

Stanford Research Systems certifi es that this product met its published specifi cations at the time
of shipment.

Warranty

This Stanford Research Systems product is warranted against defects in materials and workmanship
for a period of one (1) year from the date of shipment.

Service

For warranty service or repair, this product must be returned to a Stanford Research Systems
authorized service facility. Contact Stanford Research Systems or an authorized representative
before returning this product for repair.

Contact Information

Stanford Research Systems, Inc.
1290-D Reamwood Avenue
Sunnyvale, CA 94089 USA

Phone: [phone]
Fax: [phone]
www.thinkSRS.com
[e-mail]

Information in this document is subject to change without notice.
Copyright © Stanford Research Systems, Inc., 2008. All rights reserved.
Printed in U.S.A.

Document number: 9-01637-903

Stanford Research Systems

PS300 Series High Voltage Power Supplies

Contents

General Information . . . . . . . . . . . . . . . . . . iii

Symbols . . . . . . . . . . . . . . . . . . . . . . . . . iv

Notation. . . . . . . . . . . . . . . . . . . . . . . . . v

Specifi cations . . . . . . . . . . . . . . . . . . . . . . vi

1 Instrument Overview . . . . . . . . . . . . . . . . . 1 – 1

1.1 Front Panel . . . . . . . . . . . . . . . . . . . . 1 – 2

1.2 Rear Panel . . . . . . . . . . . . . . . . . . . . 1 – 3

2 Guide to Operation . . . . . . . . . . . . . . . . . . 2 – 1

2.1 Se ing Parameters . . . . . . . . . . . . . . . . 2 – 2

2.2 Reset. . . . . . . . . . . . . . . . . . . . . . . . 2 – 3

2.3 Store and Recall . . . . . . . . . . . . . . . . . 2 – 3

2.4 Error Messages. . . . . . . . . . . . . . . . . . 2 – 4

2.5 Analog Monitor and Control . . . . . . . . . . 2 – 4

2.6 Default State . . . . . . . . . . . . . . . . . . . 2 – 5

3 Remote Operation . . . . . . . . . . . . . . . . . . . 3 – 1

3.1 Index of Common Commands . . . . . . . . . 3 – 2

3.2 Alphabetic List of Commands . . . . . . . . . 3 – 3

3.3 Introduction . . . . . . . . . . . . . . . . . . . 3 – 4

3.4 Commands . . . . . . . . . . . . . . . . . . . . 3 – 4

3.5 Status Model . . . . . . . . . . . . . . . . . . . 3 – 12

3.6 Status Reporting . . . . . . . . . . . . . . . . . 3 – 13

4 Troubleshooting . . . . . . . . . . . . . . . . . . . . 4 – 1

4.1 Troubleshooting the PS300 . . . . . . . . . . . 4 – 2

i

Contentsii

Stanford Research Systems

PS300 Series High Voltage Power Supplies

General Information

The PS300 Series High Voltage Power Supplies are general purpose
instruments designed for laboratory environments.

Warning

This unit contains hazardous high voltages. Make certain the high
voltage is completely discharged before removing the cable. The
charge on the cable can cause injury or damage.

Line Voltage

The PS300 series supplies operate from a 90 VAC to 264 VAC
power source having a line frequency between 47 Hz and 63 Hz.
Power consumption is less than 80 VA total.

A power entry module, labeled AC POWER on the back panel of the
PS300, provides connection to the power source and to a protective
ground.

Service

The PS300 uses a detachable, three-wire power cord for connection to
the power source. The exposed metal parts of the box are connected
to the power ground to protect against electrical shock. Always use
an outlet which has a properly connected protective ground.

The rear-panel high voltage connector and the BNC shields are also
connected to chassis ground. The PS300 series supplies CANNOT
be fl oated.

The line fuse is internal to the instrument and may not be serviced
by the user. Operate only with covers in place to avoid personal
injury. Do not remove the product covers or panels. Do not operate
the product without all covers and panels in place.

The PS300 does not include any user-serviceable parts inside. Refer
service to a qualifi ed technician.

iii

Symbols you may  nd on SRS products

Symbol Description

Alternating current

Caution - risk of electric shock

Frame or chassis terminal

Contentsiv

Caution - refer to accompanying documents

Earth (ground) terminal

Battery

Fuse

On (supply)

Off (supply)

Stanford Research Systems

PS300 Series High Voltage Power Supplies

Contents

Notation

v

Typese ing conventions used in this manual are as follows:

· Front-panel bu ons are represented as [Bu on]

· The [▲] and [▼] keys increment and decrement a digit.

· The [◄] and [►] keys select a digit.

· Front-panel indicators are represented as

· The state of a switch is represented in italics as ON

Overload

· Remote command names are represented as *IDN?

· Literal text other than command names is represented as OFF

Remote command examples will all be set in monospaced font.
In these examples, data sent by the host computer is set as
straight teletype font, while responses received by the
host computer are set as

slanted teletype font

.

PS300 Series High Voltage Power Supplies

Phone: [phone]

www.thinkSRS.com

Speci cations

Model Output Voltage (±) Maximum Current

PS355
PS365 +100 V to +10 kV 1 mA
PS370
PS375 +100 V to +20 kV 500 µA

Voltage Output

Voltage set accuracy 0.01 % + 0.05 % of full scale
Voltage display accuracy V
Voltage resolution 1 V (set and display)
Voltage rese ability 1 V
Voltage limit range 0 to 100 % of full scale
Voltage regulation 0.001 % for ±10 % line change,

0.04 % for 100 % load change.
Specifi cations apply for >0.5 % (full load) to
>1 % (no load) of full-scale voltage.
Output ripple (rms) <0.01 % of full scale (max.)
Current limit range 0 to 105 % of full scale
Current trip range 0 to 105 % of full scale
Trip response time <10 ms
Current set accuracy 1 µA
Current resolution 1 µA
Current display accuracy ±1 µA (typ.), ±2 µA (max.)
Stability 0.01 % per hr., <0.03 % per 8 hrs.
Temperature dri 50 ppm/°C, 0 to 50 °C (typ.)
Protection Arc and short circuit protected (programmable
voltage limit, current limit, and current trip)
HV output slew rate 7,000 V/s, typ. (PS355 and PS365)
14,000 V/s, typ. (PS370 and PS375)
Recovery time 12 ms for 40 % step change in load current (typ.)
Discharge time <6 s (to <1 % of full-scale voltage with no load, typ.)

Monitor Output

Output scale 0 to +10 V
(0 to full-scale output regardless of polarity)
Current rating 10 mA (max.)
Output impedance <1 Ω

-

100 V to -10 kV 1 mA

-

100 V to -20 kV 500 µA

accuracy ± 1 V, typ. (± 2 V, max.)

set

General Informationvi

Stanford Research Systems

PS300 Series High Voltage Power Supplies

General Information

Accuracy 0.2 % of full scale
Update rate 87.5 Hz

External Voltage Set

Input scale 0 to +10 V
(0 to full-scale output regardless of polarity)
Input impedance 1 MΩ
Accuracy 0.2 % of full scale
Update rate 87.5 Hz

Mechanical

HV connector Kings type 1064-1 (PS355 and PS365)
Kings type 1764-1 (PS370 and PS375)
Mating connector Kings type 1065-1 (PS355 and PS365)
Kings type 1765-1 (PS370 and PS375)
Dimensions 8.1″ × 3.5″ × 16″ (WHD)
Weight 8 lbs.
Power 50 W, 90 to 264 VAC, 47 to 63 Hz
Warranty One year parts and labor on defects in materials
or workmanship

vii

All performance specifi cations apply aĞ er a one hour warm-up period

PS300 Series HighVoltage Power Supplies

Phone: [phone]

www.thinkSRS.com

General Information

viii

PS300 Series HighVoltage Power Supplies

Phone: [phone]

www.thinkSRS.com

1 Instrument Overview

In This Chapter

This chapter gives the user the necessary information to get
started with the PS300 Series High Voltage Power Supplies.

1.1 Front Panel . . . . . . . . . . . . . . . . . . . . . . . 1–2

1.1.1 Power Bu on . . . . . . . . . . . . . . . . . 1–2

1.1.2 High Voltage Enable Switch . . . . . . . . . 1–2

1.1.3 Numeric Displays . . . . . . . . . . . . . . . 1–3

1.1.4 Select, Enter, Clear . . . . . . . . . . . . . . 1–3

1.1.5 Numeric and Cursor Keys . . . . . . . . . . 1–3

1.1.6 Instrument Status . . . . . . . . . . . . . . . 1–3

1.1.7 Other Keys . . . . . . . . . . . . . . . . . . . 1–3

1.1.8 Store and Recall . . . . . . . . . . . . . . . . 1–4

1.2 Rear Panel. . . . . . . . . . . . . . . . . . . . . . . . 1–4

1.2.1 Power Entry Module . . . . . . . . . . . . . 1–4

1.2.2 High Voltage Connector . . . . . . . . . . . 1–4

1.2.3 Analog I/O . . . . . . . . . . . . . . . . . . . 1–5

1.2.4 IEEE-488 Port . . . . . . . . . . . . . . . . . 1–5

1.2.5 RS-232 Port. . . . . . . . . . . . . . . . . . . 1–5

1 – 1

1.1 Front Panel

Instrument Overview1 – 2

The front-panel features of the PS300 Series High Voltage Power
Supplies are examined in this section.

1.1.1 Power Button

The PS300 is turned on by depressing the [POWER] bu on. The
unit always powers up with the high voltage OFF. The current
instrument confi guration and any saved instrument presets are
stored in non-volatile memory. The model number (355, 365, 370
or 375), fi rmware version, and serial number are displayed when
power is turned on. If an error appears on power up, the current
instrument confi guration and any saved presets are lost, and the
default se ings are used. If the default se ings are desired, hold
down the clear key [CLR] while turning on the power. Note that
this will clear out all buff ers and erase any saved presets.

1.1.2 High Voltage Enable Switch

The [High Voltage] enable switch has three positions that perform
several functions. In the down position, the high voltage is OFF,
and all trips are cleared. In this position, the high voltage is locked

OFF and cannot be turned on over the computer interface. The
UP position is momentary, and it turns on the high voltage for

manual or rear-panel analog control. In the middle position, the
high voltage is enabled (but not necessarily ON) and can be turned
on over the computer interface. The large red ON LED above the
switch indicates that the high voltage is on; the yellow TRIP LED
indicates a trip has occurred.

Stanford Research Systems

PS300 Series High Voltage Power Supplies

Front Panel

1.1.3 Numeric Displays

The two large displays show output voltage to fi ve signifi cant digits
and output current to four signifi cant digits. The polarity is indicated
below the voltage display as either POSITIVE or NEGATIVE. The
smaller center display shows the value of the parameter that is
being entered or adjusted. That parameter is indicated by the row
of LEDs directly below the center display.

1.1.4 Select, Enter, Clear

[SELECT] is used to choose which parameter is being displayed in
the center display. [ENTER] confi rms the entry in the center display.
[CLR] erases the value in the middle display and recalls the last
value that was entered. To adjust a value, [SELECT] is pressed until
the appropriate LED is lit. When the value is being changed, the LED
will fl ash to indicate the value is in a state of change. If an incorrect
value is entered, press [CLR] to start over. When the desired value
is displayed, [ENTER] updates the unit’s actual se ing and stops
the LED from fl ashing.

1 – 3

1.1.5 Numeric and Cursor Keys

All parameters may be adjusted using the cursor or numeric keys.
When using the cursor, the digit being adjusted in the center display
will fl ash. The [▲] and [▼] keys increment and decrement the digit.
The [◄] and [►] keys select the fl ashing digit. When using direct
numerical entry, simply press the number and decimal point keys
until the desired value appears on the center display. Note that the
current is specifi ed in microamps.

1.1.6 Instrument Status

Three LEDs indicate the instrument’s status. The
when the unit is in a current limit state.
panel is locked out.
programmed by the rear-panel analog input.

1.1.7 Other Keys

[RESET] toggles the reset mode between

[GPIB] displays the GPIB address in the center display so it can be
adjusted. It also functions as the [LOCAL] key when the unit is in
the remote mode.

LIMIT

REM

is on when the front

REAR

is on when the high voltage se ing is

AUTO

and

MAN

LED is on

(manual).

PS300 Series High Voltage Power Supplies

Phone: [phone]

www.thinkSRS.com

Instrument Overview1 – 4

1.1.8 Store and Recall

1.2 Rear Panel

Store [STO] and Recall [RCL] allow up to nine complete instrument
confi gurations to be saved in nonvolatile memory. [RCL] 0 recalls
the default se ings.

The rear panel of the PS300 Series High Voltage Power Supplies is
discussed next.

1.2.1 Power Entry Module

The AC line cord plugs into the power entry module. Refer to the
General Information section of this manual for instructions on line
voltage.

1.2.2 High Voltage Connector

WARNING — This unit contains hazardous voltages. Please make
certain that the high voltage is completely discharged before
removing or connecting the high voltage cable. High voltage cables
can store charge. If they are disconnected from the supply while
high voltage is present, electric shock can occur which may cause
injury or damage the unit.

The high voltage output connector is a Kings type 1064-1 (PS355
and PS365) or a Kings type 1764-1 (PS370 and PS375). Please make
certain that the high voltage is completely discharged before
changing the cable. Cables are available from SRS.

Stanford Research Systems

PS300 Series High Voltage Power Supplies

1.2.3 Analog I/O

1.2.4 IEEE-488 Port

1.2.5 RS-232 Port

Instrument Overview1 – 5

The two MONITOR output BNCs are used to monitor the voltage
and current signals. Both are 0 to +10 V outputs corresponding to
0 to full scale. The SET input BNC receives an analog programming
voltage, 0 to +10 VDC corresponding to 0 to full scale (independent
of high voltage polarity). To select the rear SET analog high voltage
control, press [SELECT] on the front panel until REAR is selected,
and then use the [▲] and [▼] keys to choose between “Front” and
“Rear”. Press [ENTER] to confi rm the selection.

The 24-pin IEEE-488 (GPIB) connector allows computer control of
PS300 series supplies. The address is set from the front panel using
the [GPIB] key.

The 9-pin female D-sub connector allows computer control of
power supply via RS-232. The interface se ings are fi xed as DCE,
9600 baud, no parity, 8 bits, 1 stop bit.

Stanford Research Systems

PS300 Series High Voltage Power Supplies

Instrument Overview1 – 6

Stanford Research Systems

PS300 Series High Voltage Power Supplies

2 Guide To Operation

In This Chapter

This chapter explains how to operate the PS300 Series High
Voltage Power Supplies.

2.1 Se ing Parameters . . . . . . . . . . . . . . . . . . . 2–2

2.1.1 Se ing the Output Voltage . . . . . . . . . . 2–2

2.1.2 Se ing the Voltage Limit . . . . . . . . . . . 2–2

2.1.3 Se ing the Current Limit . . . . . . . . . . . 2–3

2.1.4 Se ing the Current Trip . . . . . . . . . . . 2–3

2.2 Reset . . . . . . . . . . . . . . . . . . . . . . . . . 2–3

2.3 Store and Recall . . . . . . . . . . . . . . . . . . . . 2–3

2.4 Error Messages . . . . . . . . . . . . . . . . . . . . . 2–4

2.5 Analog Monitor & Control . . . . . . . . . . . . . . 2–4

2.5.1 Voltage Set . . . . . . . . . . . . . . . . . . . 2–4

2.5.2 Voltage Monitor . . . . . . . . . . . . . . . . 2–4

2.5.3 Current Monitor. . . . . . . . . . . . . . . . 2–4

2.6 Default State . . . . . . . . . . . . . . . . . . . . . . 2–5

2 – 1

2.1 Setting Parameters

This section describes how to set the front-panel parameters.

2.1.1 Setting the Output Voltage

The voltage set can be changed with the high voltage in either the
ON or OFF mode.

To set the high voltage output, press the [SELECT] key until the
voltage
be displayed in the center window. To change the value, enter the
desired voltage by using either the numeric keys or cursor. A er the
new value has been entered into the center display, press [ENTER]
to update the output voltage. The voltage
[ENTER] or [CLR] is pressed to remind you that the displayed value
is not the actual programmed value. If an Err2 message appears
(illegal parameter entered), check the voltage limit to see that it is
greater than or equal to the desired set voltage. Use the [CLR] key
to clear any error message.

SET

LED is lit. The present value of the set voltage will

Guide to Operation2 – 2

SET

LED will fl ash until

If the

REAR

the analog set input on the rear panel. In this mode, if the center
display is showing voltage
value of the high voltage programmed by the 0 to 10 V input and
cannot be adjusted from the front panel.

2.1.2 Setting the Voltage Limit

The voltage limit is a protection feature to prevent the output voltage
from being set too high or overshooting because of dramatic load
changes. The output voltage cannot be set higher than the voltage
limit. In addition, if the output ever exceeds the limit by more than
2 % of full scale, the unit trips and the high voltage is disabled. If
this occurs, a VTRP (voltage trip) message appears in the middle
display.

A er a trip, it is not necessary to clear the trip before turning the
high voltage back on. If it is necessary to change a parameter before
turning the high voltage back on, pressing [CLR] or pu ing the
high voltage switch in the OFF position will clear the trip.

To set the voltage limit, press [SELECT] until the voltage
LED is lit. The present value of the voltage limit is displayed in
the center window. Change it with either the numeric keys or the

status LED is lit, the high voltage is programmed from

SET

, the displayed value is the present

LIMIT

Stanford Research Systems

PS300 Series High Voltage Power Supplies

Se ing Parameters

cursor and press [ENTER] to update the actual limit value. If an
Err2 message appears (illegal parameter entered), check to see that
the output voltage is less than or equal to the voltage limit.

2.1.3 Setting the Current Limit

Current limiting varies the output voltage to limit the output current
to less than or equal to the programmed current limit value. When
the unit is current limited, the
set in the same fashion as the voltage limit — selecting the present
value on the center window, changing it and then entering the new
value.

2.1.4 Setting the Current Trip

The current trip shuts off the high voltage when the output current
exceeds the trip value. The current trip value is set in the same
fashion as the voltage and current limits. A er a current trip occurs,
the ITRP (current trip) message will appear in the middle display.
Current trips are cleared just like voltage trips.

LIMIT

2 – 3

LED is lit. The current limit is

2.2 Reset

2.3 Store and Recall

The reset mode determines how the unit responds a er a voltage
or current trip.

In MAN (manual) mode, the high voltage remains OFF a er a trip
and requires that the operator turn it back ON.

In AUTO (automatic) mode, the unit waits until the later of the time
for the output voltage to fall to 0.5 % of full-scale or two seconds,
and then turns the high voltage back ON. This is useful when
dealing with loads that occasionally short circuit but recover a er
removing the high voltage.

The store and recall functions allow up to nine complete instrument
setups to be saved. To store a setup, press the [STO] key followed by
a number (1 to 9) and then the [ENTER] key. To recall a setup, press
the [RCL] key, followed by a number (0 to 9) and then the [ENTER]
key. [RCL] 0 returns the setup to the factory default. Whenever
a setup is recalled, the high voltage is turned off for safety. If an
Err3 (recall error) occurs, then that stored setup was lost due to a
memory error and must be re-entered.

PS300 Series High Voltage Power Supplies

Phone: [phone]

www.thinkSRS.com

2.4 Error Messages

Guide to Operation2 – 4

The following error messages may appear in the center display. The
[CLR] key clears the errors.

Err1 Memory error – Power on memory error of the unit’s
last setup. Default setup is recalled.

Err2 Illegal parameter entered.

Err3 Recall Error – the stored setup was lost.

Err4 Illegal storage address.
(Address 0 is reserved for default se ings)

Err5 Device dependent

Err6 Syntax error over GPIB.

Err7 Illegal parameter entered over GPIB.
Parameter entered is out of range.

Err 8 Remote communication error

Err9 Hardware watchdog

2.5 Analog Monitor & Control

2.5.1 Voltage Set

When confi gured for rear control (see § 1.2.3) the rear-panel SET
voltage will set the output voltage. When enabled, the
panel) status LED is lit, and the output voltage being set by the
rear panel is displayed in the middle display (when it is showing
voltage

2.5.2 Voltage Monitor

the rear-panel voltage to set the output above the voltage limit. If
the rear-panel voltage is too high, the output voltage will stop at
the limit voltage. An input from 0 to +10 V will program the high
voltage from 0 to full scale, regardless of polarity.

The voltage monitor BNC is a monitor output providing 0 to +10
volts for a 0 to full-scale output, regardless of polarity.

REAR

SET)

. The voltage limit is still active and does not allow

(rear

Stanford Research Systems

PS300 Series High Voltage Power Supplies

Analog Monitor and Control

2.5.3 Current Monitor

The current monitor output BNC provides a 0 to +10 volt output for
0 to full-scale output, regardless of the output polarity.

2.6 Default State

The factory default setup can be recalled by pressing the [CLR] key
while turning the unit on, or recalling setup 0. Note that pressing
the [CLR] key while turning the unit on will also clear all buff ers
and erase any saved presets. The default setup is also recalled a er
a power on memory error (ERR 1). The default parameters are
shown below.

PS355 Voltage Set 0 V
Voltage Limit ₋10,000 V
Current Limit ₋1,050 µA
Current Trip ₋1,050 µA
Reset Mode MAN
High Voltage OFF
GPIB Addr 14

2 – 5

PS365 Voltage Set 0 V
Voltage Limit +10,000 V
Current Limit +1,050 µA
Current Trip +1,050 µA
Reset Mode MAN
High Voltage OFF
GPIB Addr 14

PS370 Voltage Set 0 V
Voltage Limit ₋20,000 V
Current Limit ₋525 µA
Current Trip ₋525 µA
Reset Mode MAN
High Voltage OFF
GPIB Addr 14

PS375 Voltage Set 0 V
Voltage Limit +20,000 V
Current Limit +525 µA
Current Trip +525 µA
Reset Mode MAN
High Voltage OFF
GPIB Addr 14

PS300 Series High Voltage Power Supplies

Phone: [phone]

www.thinkSRS.com

Guide to Operation2 – 6

Stanford Research Systems

PS300 Series High Voltage Power Supplies

3 Remote Operation

In This Chapter

This chapter describes operating the PS300 series over the RS-232
and GPIB computer interfaces.

3.1 Index of Common Commands . . . . . . . . . . . . 3 – 2

3.2 Alphabetic List of Commands . . . . . . . . . . . . 3 – 3

3.3 Introduction . . . . . . . . . . . . . . . . . . . . . . 3 – 4

3.3.1 Power-On Confi guration . . . . . . . . . . . 3 – 4

3.3.2 Buff ers . . . . . . . . . . . . . . . . . . . . . 3 – 4

3.4 Commands . . . . . . . . . . . . . . . . . . . . . . . 3 – 4

3.4.1 Command Syntax . . . . . . . . . . . . . . . 3 – 4

3.4.2 Notation . . . . . . . . . . . . . . . . . . . . 3 – 5

3.4.3 Examples. . . . . . . . . . . . . . . . . . . . 3 – 5

3.4.4 Output Control Commands . . . . . . . . . 3 – 6

3.4.5 Se ing Control Commands . . . . . . . . . 3 – 6

3.4.6 Interface Control Commands . . . . . . . . 3 – 8

3.4.7 Status Reporting Commands . . . . . . . . 3 – 10

3.5 Status Model . . . . . . . . . . . . . . . . . . . . . . 3 – 12

3.6 Status Reporting . . . . . . . . . . . . . . . . . . . . 3 – 13

3.6.1 Serial Poll Status Byte. . . . . . . . . . . . . 3 – 13

3.6.2 Standard Event Status Byte . . . . . . . . . 3 – 14

3.6.3 GPIB Error Messages . . . . . . . . . . . . . 3 – 14

3 – 1

3.1 Index of Common Commands

Symbol Defi nition

i

Unsigned integer

x

(?) Required for queries; illegal for set commands

var

Parameter always required

{

var

} Parameter required for set commands; illegal
for queries
[

var

] Optional for both set and query commands

Output Commands

HVOF 3 – 6 High Voltage Off
HVON 3 – 6 High Voltage On
IOUT? 3 – 6 Output Current
VOUT? 3 – 6 Output Voltage

Remote Operation3 – 2

Assigned value

Setting Control Commands

*RCL i 3 – 6 Recall
*SAV i 3 – 7 Save
ILIM(?) {x } 3 – 7 Current Limit
ITRP(?) {x } 3 – 7 Current Trip
SMOD(?) {i } 3 – 7 V Set Mode
TCLR 3 – 7 Trip Clear
TMOD(?) {i } 3 – 8 Trip Mode
VLIM(?) {x } 3 – 8 Voltage Limit
VSET(?) {x } 3 – 8 Voltage Set

Interface Control Commands

*RST 3 – 8 Reset
*IDN? 3 – 9 Identify

*OPC(?) 3 – 9 Operation Complete
LERR? 3 – 9 Last Error

Status Reporting Commands

*CLS 3 – 10 Clear Status
*ESE(?) i 3 – 10 Standard Event Status Enable
*ESR? [i] 3 – 10 Standard Event Status
*PSC(?) {i } 3 – 11 Power-On Status Clear
*SRE(?) {
*STB(?) [

i

} 3 – 11 Service Request Enable

i

] 3 – 11 Status Byte

Stanford Research Systems

PS300 Series High Voltage Power Supplies

Remote Operation

3.2 Alphabetic List of Commands

*

*CLS 3 – 10 Clear Status
*ESE(?) i 3 – 10 Standard Event Status Enable
*ESR? [i] 3 – 10 Standard Event Status
*IDN? 3 – 9 Identify

*OPC(?) 3 – 9 Operation Complete

*PSC(?) {i } 3 – 11 Power-On Status Clear
*RCL i 3 – 6 Recall
*RST 3 – 8 Reset
*SAV i 3 – 7 Save
*SRE(?) {i } 3 – 11 Service Request Enable
*STB(?) [i] 3 – 11 Status Byte

H

HVOF 3 – 6 High Voltage Off
HVON 3 – 6 High Voltage On

3 – 3

I

ILIM(?) {x } 3 – 7 Current Limit
IOUT? 3 – 6 Output Current
ITRP(?) {x } 3 – 10 Current Trip

L

LERR? 3 – 9 Last Error

S

SMOD(?) {i } 3 – 7 V Set Mode

T

TCLR 3 – 7 Trip Clear
TMOD(?) {i } 3 – 8 Trip Mode

V

VLIM(?) {x } 3 – 8 Voltage Limit
VOUT? 3 – 6 Output Voltage
VSET(?) {x } 3 – 8 Voltage Set

PS300 Series High Voltage Power Supplies

Phone: [phone]

www.thinkSRS.com

Remote Operation3 – 4

3.3 Introduction

Remote operation of the PS300 series is through a simple command
language documented in this chapter. Both set and query forms of
most commands are supported, allowing the user complete control
of the instrument from a remote computer. Both RS-232 and GPIB
(IEEE488.2) interfaces are supported.

3.3.1 Power-On Con guration

The se ings for the RS-232 interface are 9600 baud and no parity.
The default GPIB address is 14. The complete instrument confi gu-
ration is retained in non-volatile memory.

When appropriate, the default value for parameters is listed in
boldface in the command descriptions.

3.3.2 Bu ers

The PS300 series stores incoming bytes in a 128 character input
buff er. Characters accumulate in the input buff er until a command
terminator (either <CR> or <LF>) is received, at which point the mes­sage is parsed and executed. Query responses are buff ered in a 128
character output queue.

If the input buff er overfl ows, then all data in both the input buff er
and output queue are discarded, and an error is reported in the
Standard Event Status Byte.

3.4 Commands

This section provides syntax and operational descriptions for re­mote commands.

3.4.1 Command Syntax

The four le er mnemonic (shown in CAPS) in each command se-
quence specifi es the command. The rest of the sequence consists of
parameters.

Commands may take either set or query form, depending on wheth­er the “?” character follows the mnemonic. Set only commands are
listed without the “?”, query only commands show the “?” a er the
mnemonic, and optionally query commands are marked with a “(?)”.

Parameters shown in { } and [ ] are not always required. Parameters
in { } are required to set a value, and should be omi ed for queries.

Stanford Research Systems

PS300 Series High Voltage Power Supplies

Commands

3.4.2 Notation

3 – 5

Parameters in [ ] are optional in both set and query commands.
Parameters listed without surrounding characters are always re­quired.

Do not send ( ) or { } or [ ] as part of the command.

Multiple parameters are separated by commas. Multiple commands
may be sent on one command line by separating them with semi­colons (;) so long as the input buff er does not overfl ow. Commands
are terminated by either <CR> or <LF> characters. Null commands
and whitespaces are ignored. Execution of the command does not
begin until the command terminator is received.

The following table summarizes the notation used in the command
descriptions.

Symbol Defi nition

i

Unsigned integer

x

Assigned value

3.4.3 Examples

(?) Required for queries; illegal for set commands

var

Parameter always required

{

var

} Parameter required for set commands; illegal
for queries
[

var

] Optional for both set and query commands

Each command is provided with a simple example illustrating its
usage. In these examples, all data sent by the host computer to the
PS300 are set as straight teletype font, while responses
received by the host computer from the PS300 are set as

teletype font

.

slanted

The usage examples vary with respect to set/query and optional
parameters. These examples are not exhaustive and are intended to
provide a convenient starting point for user programming.

PS300 Series High Voltage Power Supplies

Phone: [phone]

www.thinkSRS.com

Remote Operation3 – 6

3.4.4 Output Control Commands

HVOF High Voltage Off

The HVOF command turns the high voltage output OFF.

Example:

HVOF

HVON

The HVON command turns the high voltage ON, provided the
front-panel high voltage switch is not in the OFF position. If the
switch is in the OFF position, the high voltage is le off and an
execution error is reported. This command also automatically
clears any voltage or current trips.

IOUT?

The IOUT? query returns the actual output current, in amperes.
This is the same value shown on the front-panel meter. The value
is always returned as an unsigned number, regardless of the
polarity of the power supply.

VOUT? Output Voltage

High Voltage On

Example:

HVON

Output Current

Example:

IOUT?

4.78E-4

The VOUT? query returns the actual output voltage, in volts. This is
the same value shown on the front-panel meter. The value
returned is a fl oating point value and includes the sign of the
output voltage.

-

Example:

3.4.5 Setting Control Commands

*RCL

The *RCL command recalls stored se ings i. *RCL 0 restores the
default se ings. If the stored se ing is corrupted, an error is returned.

Stanford Research Systems

i

Recall Confi guration

Example:

VOUT?

1.8998E4

*RCL 3

PS300 Series High Voltage Power Supplies

Commands

3 – 7

*SAV

The *SAV command stores the present setup as se ing i. i may
range from 1 to 9.

ILIM(?) {

The ILIM command sets (queries) the value of the current limit
(to

ITRP(?) {x } Trip Current

The ITRP command sets (queries) the value of the current trip
(to

i

Save Confi guration

Example:

x

} Limit Current

Example:

*SAV 3

x

), in amperes. ILIM may be set from 0 to 105 % of full scale.

ILIM 120E-6; ILIM?

1.20E-4

x

), in amperes. ITRP may be set from 0 to 105 % of full scale.

Example:

ITRP? 5.25E-4

SMOD(?) {

The SMOD? command sets (queries) the VSet se ing mode. SMOD 0
means that the voltage value is controlled by the front-panel
se ing, while SMOD 1 indicates that the output is controlled by
the rear-panel VSET voltage control input.

Note that changing the SMOD value while the high voltage is ON
causes the high voltage to be switched OFF.

TCLR

The TCLR command clears any voltage or current trips.

i

} Rear Programming Mode

Example:

SMOD 1

Clear Trips

Example:

TCLR

PS300 Series High Voltage Power Supplies

Phone: [phone]

www.thinkSRS.com

Remote Operation3 – 8

TMOD(?) {i} Trip Mode

The TMOD command sets (queries) the trip reset mode {to i}. The
value

i

= 1 sets manual trip reset, while the value i = 1 sets the trip

reset mode to automatic.

VLIM(?) {

Example:

x

} Voltage Limit

TMOD 1

The VLIM command sets (queries) the value of the voltage limit
{to

x

}, in volts. The sign of value x must match the polarity of the
power supply. As with front-panel control, the VLIM value must be
greater than or equal to the VSET value or an execution error will
be returned.

Example:

VLIM?

-2.0000E4

VSET(?) {x } Voltage Set

The VSET command sets (queries) the value of the voltage se ing
{to

x

}, in volts. If SMOD 1 (rear-panel control) is enabled, then
se ing the VSET command returns an error. The value x must
match the polarity of the power supply.

When SMOD = 0 (front-panel control), the VSET? query returns
the set parameter (not the measured output voltage, see VOUT?

§ 3.4.4). When SMOD = 1 (rear-panel control), the VSET? query
returns the high voltage se ing programmed by the rear-panel
HVSET input. As with front-panel control, the VSET value must
be less than or equal to the VLIM value or an execution error will
be returned.

Example:

3.4.6 Interface Control Commands

*RST Reset

The *RST common command resets the power supply to its default
confi guration. It is the same as holding the [CLR] bu on
depressed at power on.

Stanford Research Systems

Example:

VSET?

19555

*RST

PS300 Series High Voltage Power Supplies

Commands

3 – 9

*IDN? Identify

The *IDN? common query returns the PS300’s device identifi cation.
This string is forma ed as follows:

StanfordResearchSystems, PS3XX, <serial>, <version>

where XX is the model number, <serial> is the 6-digit serial
number of the unit, and <version> is the 3-digit fi rmware
revision number.

Example:

*IDN?

StanfordResearchSystems,PS370,100003,0.29

*OPC(?) Operation Complete

The *OPC common command causes remote command execution
to pause until all pending operations are complete. The *OPC?
query will return the value “1” when operations are complete,
while the *OPC set command will set the OPC bit (bit 0) in the
ESR register.

Example:

*OPC?

1

LERR? Last Error

The LERR? query returns the error code of the last remote interface
error. A list of the possible error codes are as follows:

Code Meaning
10 Illegal value (execution)
100 Lost data (query)
101 No data (query)
102 No listener (query)
103 Overfl ow (query)
110 Illegal command (parser)
111 Undefi ned command (parser)
112 Illegal query (parser)
113 Illegal set (parser)
114 Null parameter (parser)
115 Extra parameter (parser)
116 Missing parameter (parser)
117 Overfl ow (parser)
118 Bad fl oat (parser)
119 Float overfl ow (parser)

PS300 Series High Voltage Power Supplies

Phone: [phone]

www.thinkSRS.com

120 Bad integer (parser)
121 Integer overfl ow (parser)
122 Bad hex value (parser)
123 Hex overfl ow (parser)
124 Bad token integer (parser)
125 Unknown token (parser)
126 Syntax error (parser)
151 CMF reset (device dependent)
152 COP reset (device dependent)
153 Illegal reset (device dependent)
154 Recall error (device dependent)
155 Watchdog (device dependent)

Remote Operation3 – 10

Example:

*IDN; LERR?

113

3.4.7 Status Reporting Commands

*CLS Clear Status

The *CLS common command clears all status registers.

*ESE(?)

Example:

i

Standard Event Enable

*CLS

The *ESE common command sets (queries) the standard event
status enable register {to i}. The parameter i is the decimal value
for the enable register, and can range from 0 to 255.

Example:

*ESE 16

i

*ESR? [

] Standard Event

The *ESR common command query reads the value of the
standard event status register. If the optional parameter i is
present, then only the value of bit i is returned. Reading this
register will clear it. Reading bit i will clear bit i only.

Example:

1

Stanford Research Systems

*ESR? 5

PS300 Series High Voltage Power Supplies

Commands

3 – 11

*PSC(?) {i } Power-On Status Clear

The *PSC common command sets (queries) the value of the
power-on status clear bit {to i}. If i = 1, the power-on status clear
bit is set, and all status registers and enable registers are cleared
on power up. If i = 0, the bit is cleared, and the status enable
registers maintain the values at power down. This allows the
generation of a service request at power up, for example.

Example:

*PSC?

1

*SRE(?) {i } Service Request Enable

The *SRE common command sets (queries) the value of the service
request enable register {to i}.

*STB? [

Example:

i

] Standard Byte

*SRE 6

The *STB? common command query reads the value of the serial
poll status byte. If the optional parameter i is present, the value
of bit

i

is returned. Reading this register will clear bits 1, 2, and 3;
the remaining bits are either real-time monitors of underlying
conditions (such as bit 7: HVON), or summary bits (such as
bit 5: ESB).

Example:

*STB?

129

PS300 Series High Voltage Power Supplies

Phone: [phone]

www.thinkSRS.com

Remote Operation3 – 12

3.5 Status Model

The PS300 series instruments follow the hierarchical IEEE-488.2
format. A block diagram of the status register array is given in Fig­ure 3.1

Standard Event Status

7

6

5

4

3

2

1

0

ESR ESE

7

6

5

4

3

2

1

0

Status Byte

7

7

6

5

4

3

2

1

0

SB SRE

HVON: High Voltage ON

X

RQS / MSS: Master Summary Status

5

ESB: Event Status Bit

4

MAV: Message Available

3

ILIM: Current Limit

2

ITRIP: Current Trip

1

VTRIP: Voltage Trip

0

STABLE: High Voltage Stable

PON: Power On

URQ: User Request

CME: Command Error

EXE: Execution Error

DDE: Device Error

QYE: Query Error

undef

OPC: Operation Complete

Figure 3.1: Status register model for the PS300 series High Voltage Power
Supplies.

The two categories of registers in the PS300 series status model are
as follows:

Event Registers

These read-only registers record the occurrence of defi ned events.
If the event occurs, the corresponding bit is set to 1. Upon querying
an event register, all set bits within it are cleared. These are some­times known as sticky bits, since once set, a bit can only be cleared
by reading its value. Event register names end with SR.

Enable Registers

These read/write registers defi ne a bitwise mask for their corre-
sponding event register. If a bit position is set in an event register
while the same bit position is also set in the enable register, then the
corresponding summary bit message is set. Enable register names
end with SE.

At power-on, all status registers are cleared.

Stanford Research Systems

PS300 Series High Voltage Power Supplies

Status

3.6 Status Reporting

The PS300 series reports on its status by means of two status bytes:
The serial poll byte and the standard status byte.

Upon power-on, the instrument may either clear all of its status
enable registers, or maintain them in the state they were in during
power-down. The action taken is set by the *PSC command and al­lows things such as SRQ on power-on to be produced if desired.

3.6.1 Serial Poll Status Byte

Bit Name Usage

0 stable Indicates VSET or ILIM value is stable. The
value depends on whether the PS300 is in
contant current or constant voltage mode.
1 vtrip Indicates a voltage trip has occurred
2 itrip Indicates a current trip has occurred
3 ilim Indicates a current limit condition has
occurred
4 MAV Indicates GPIB output queue is non-empty
5 ESB Indicates an unmasked bit in the standard
status byte has been set
6 RQS/MSS SRQ bit
7 hvon Indicates high voltage is on

3 – 13

The PS300 will make a service request (SRQ) whenever one of these
bits is set and the corresponding bit in the serial poll enable register
is set. Note that any status condition will produce only one SRQ
even if it is never cleared. The vtrip, itrip and ilim bits are latched
bits. They are set on the occurrence of the appropriate event and
stay set until either the status byte is read or the *CLS command is
sent. This allows one to detect if a trip condition has ever occurred.
All the other bits indicate the current states of their respective func­tions.

PS300 Series High Voltage Power Supplies

Phone: [phone]

www.thinkSRS.com

3.6.2 Standard Event Status Byte

Bit Name Usage

0 OPC Set by *OPC
1 unused
2 Query Error Set by an output queue overfl ow
3 Recall Err Set if a stored se ing is corrupt
4 Execution Err Set by an out-of-range parameter or
incomplete command.
5 Command Err Set by a command syntax error or an
unrecognizable command
6 URQ Set by any key press
7 PON Set by a power-on condition

This status byte is defi ned by IEEE488.2 (1987) and is used primar-
ily to report errors in commands received over the communication
interface. Once set, the bits in this register stay set, and are cleared
when read or when a *CLS command is received.

If a bit in the standard status register is set, and the corresponding
bit in the standard status enable register is set, then the ESB bit in
the serial poll register is set.

3.6.3 GPIB Error Messages

Remote Operation3 – 14

If an error occurs due to an incomplete command, the following er­ror messages will appear on the middle display:

Err6 Syntax Error Over GPIB

The command has an error in syntax or was unrecognizable.
This is the same error as seen in the Command Error (bit 5)
of the Standard Event Status Byte.

Err7 Illegal Parameter Entered Over GPIB

A parameter was set out-of-range, or a command could not
be completed because of an overload condition. This is the
same error seen in the Execution Err (bit 4) of the Standard
Event Status Byte.

Err8 GPIB Output Queue Full

The output queue overfl owed and was cleared. This could
be due to querying the instrument repeatedly and not

Stanford Research Systems

PS300 Series High Voltage Power Supplies

Status

3 – 15

reading back all the bytes. This is the same error seen in the
Query Error (bit 2) of the Standard Event Status Byte.

PS300 Series High Voltage Power Supplies

Phone: [phone]

www.thinkSRS.com

Remote Operation3 – 16

Stanford Research Systems

PS300 Series High Voltage Power Supplies

4 Troubleshooting

In This Chapter

This chapter is wri en to guide a qualifi ed electronics technician
through troubleshooting the PS300 Series Power Supplies.

4.1 Troubleshooting the PS300 . . . . . . . . . . . . . . 4–2

4.1.1 Power On Reset . . . . . . . . . . . . . . . . 4–2

4.1.2 Stuck Keys . . . . . . . . . . . . . . . . . . . 4–2

4.1.3 No High Voltage . . . . . . . . . . . . . . . 4–2

4.1.4 Repeated Trips. . . . . . . . . . . . . . . . . 4–2

4.1.5 Rear-Panel Voltage Set . . . . . . . . . . . . 4–3

4.1.6 Front-Panel Test . . . . . . . . . . . . . . . . 4–3

4.1.7 Calibration . . . . . . . . . . . . . . . . . . . 4–3

4 – 1

4.1 Troubleshooting the PS300

Verify that the line cord is plugged all the way into the power entry
module, and the power bu on on the front panel is pressed in.

4.1.1 Power On Reset

If the instrument turns on with odd combinations of illuminated
LEDs, garbled displays, or is unresponsive to the keyboard, the
memory contents may have been corrupted. To remedy the situation,
turn the unit off , and hold down the [CLR] key while turning the
power back on. This causes the unit to initialize the memory and
load the default setup.

4.1.2 Stuck Keys

If the center display is fi lled with a particular number (like 4444), or
one particular message (like Err2), and the keyboard is unresponsive,
check to see if a key is stuck down. If so, gently fl ick the stuck key
back to the center of its hole.

Troubleshooting4 – 2

4.1.3 No High Voltage

Check to make sure that the

HIGH VOLTAGE

1) Check the voltage limit and current trip levels to see that they are
not too low for your load.

If the
lower than expected, check the following:

1) Check if the
be too low, or the load could be drawing excessive current.

2) Make sure the voltage limit is as large or larger than the desired
output voltage.

3) Check the
is being programmed by the analog set voltage input on the rear
panel and not by the front panel. If so, make sure the rear-panel
programming voltage is correct.

LED is OFF, check the following:

HIGH VOLTAGE

LIMIT

REAR

LED is ON. If so, the current limit value could

status LED. If it is ON, then the high voltage

HIGH VOLTAGE

LED is ON but the output voltage is zero or

LED is ON. If the

4.1.4 Repeated Trips

Stanford Research Systems

Repeated trips can be caused by a change in load, or a load that is

PS300 Series High Voltage Power Supplies

Troubleshooting

drawing too much current. This may eff ect the voltage trip or the
current trip.

Voltage Trips

A voltage trip may occur if the load changes too rapidly, causing
the voltage to overshoot. Raising the voltage limit may eliminate
the problem.

Current Trips

Disconnect the load and see if the unit still trips. If it works with
no load, there may be a problem with the load. If it still trips,
the unit may be damaged. Please contact the factory for further
information.

4.1.5 Rear-Panel Voltage Set

4 – 3

If the output voltage output is inaccurate, check the
LED and rear-panel connection to see that it is in the SET BNC.
Make certain the voltage limit is set higher than the desired voltage.

4.1.6 Front-Panel Test

To test the front panel, hold down the [ENTER] key while turning
on the unit. A er power is turned on, you should see all indicators
and numeric segments (except for HV ON) lit. By pressing the [▲]
arrow key, individual annunciator lamps will light one by one
across the front panel, except again for the HV ON indicator, which
is controlled directly by hardware wired to the high voltage enable
circuitry. Continue pressing the [▲] key to then test the individual
segments of the numeric displays. A er the fi nal segment (the
decimal point), press [▲] again and all digits will be lit as “8”. At
this point, press the [AUTO/MANUAL] bu on (upper-le most
bu on), and the display should read “0”. Continue across the front
panel, testing each bu on, which should display a unique key code
per bu on. The codes increase from top to bo om and le to right.
A er this test, turn the power off and restart the instrument.

4.1.7 Calibration

REAR

status

PS300 Series High Voltage Power Supplies

The calibration parameters are determined by a computer aided
calibration procedure at the factory. These values are stored in the
permanent memory of each unit. Because of this, there are no user­adjustable components to calibrate.

Phone: [phone]

www.thinkSRS.com

Troubleshooting4 – 4

Stanford Research Systems

PS300 Series High Voltage Power Supplies
