STM32F412xE/xG
Errata sheet
STM32F412xE/xG device limitations
Applicability
This document applies to the part numbers of STM32F412xx devices listed in Table 1 and
their variants shown in Table 2.
Section 1 gives a summary and Section 2 a description of / workaround for device
limitations, with respect to the device datasheet and reference manual [RM0402.
Table 1. Device summary
Reference Part numbers
STM32F412xx
Reference
STM32F412xx Z 0x1001
STM32F412xx C 0x3000
STM32F412xx 1 0x3000
1. Refer to the device data sheet for how to identify this code on different types of package.
2. REV_ID[15:0] bit field of DBGMCU_IDCODE register. Refer to the reference manual.
STM32F412CE, STM32F412RE, STM32F412VE, STM32F412ZE,
STM32F412CG, STM32F412RG, STM32F412VG, STM32F412ZG
Table 2. Device variants
Silicon revision codes
Device marking
(1)
REV_ID
(2)
October 2020 ES0305 Rev 9 1/25
www.st.com
1
Contents STM32F412xE/xG
Contents
1 Arm® 32-bit Cortex®-M4 with FPU limitations . . . . . . . . . . . . . . . . . . . . 5
1.1 Cortex-M4 interrupted loads to stack pointer can cause
erroneous behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 VDIV or VSQRT instructions might not complete correctly
when very short ISRs are used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 STM32F412xx silicon limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 System limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1.1 Debugging Sleep/Stop mode with WFE/WFI entry . . . . . . . . . . . . . . . . . 9
2.1.2 Wakeup sequence from Standby mode when using more than
one wakeup source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1.3 Full JTAG configuration without NJTRST pin cannot be used . . . . . . . . 10
2.1.4 MPU attribute to RTC and IWDG registers could be managed
incorrectly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1.5 Delay after an RCC peripheral clock enabling . . . . . . . . . . . . . . . . . . . . 10
2.1.6 Internal noise impacting the ADC accuracy . . . . . . . . . . . . . . . . . . . . . . 10
2.1.7 Flash sector erase issue for sectors 5 to 11 . . . . . . . . . . . . . . . . . . . . . 11
2.1.8 In some specific cases, DMA2 data corruption occurs when managing
AHB and APB2 peripherals in a concurrent way . . . . . . . . . . . . . . . . . . 11
2.2 IWDG peripheral limitation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.2.1 RVU and PVU flags are not reset in STOP mode . . . . . . . . . . . . . . . . . 12
2.3 I2C peripheral limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.3.1 SMBus standard not fully supported . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.3.2 Start cannot be generated after a misplaced Stop . . . . . . . . . . . . . . . . 12
2.3.3 Mismatch on the “Setup time for a repeated Start condition” timing
parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.3.4 Data valid time (t
2.3.5 Both SDA and SCL maximum rise time (t
higher than ((VDD+0.3) / 0.7) V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.3.6 Last received byte can be lost when using Reload mode
with NBYTES > 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
) violated without the OVR flag being set . . . . . 13
VD;DAT
) violated when VDD_I2C bus
r
2.4 FMPI2C peripheral limitation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.4.1 Wrong data sampling when data set-up time (tSU;DAT) is smaller than
one FMPI2CCLK period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.5 SPI/I2S peripheral limitation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.5.1 Wrong CRC calculation when the polynomial is even. . . . . . . . . . . . . . 15
2/25 ES0305 Rev 9
STM32F412xE/xG Contents
2.5.2 BSY bit may stay high at the end of a data transfer in slave mode . . . . 15
2.5.3 Corrupted last bit of data and/or CRC, received in Master mode with
delayed SCK feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.6 USART peripheral limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.6.1 Idle frame is not detected if receiver clock speed is deviated . . . . . . . . 17
2.6.2 In full duplex mode, the Parity Error (PE) flag can be cleared by
writing to the data register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.6.3 Parity Error (PE) flag is not set when receiving in Mute mode
using address mark detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.6.4 Break frame is transmitted regardless of nCTS input line status . . . . . . 18
2.6.5 nRTS signal abnormally driven low after a protocol violation . . . . . . . . 18
2.6.6 Start bit detected too soon when sampling for NACK signal
from the smartcard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.6.7 Break request can prevent the Transmission Complete flag (TC)
from being set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.6.8 Guard time is not respected when data are sent on TXE events . . . . . . 19
2.6.9 nRTS is active while RE or UE = 0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.7 bxCAN limitation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.7.1 bxCAN time triggered communication mode not supported . . . . . . . . . 20
2.8 FSMC peripheral limitation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.8.1 Dummy read cycles inserted when reading synchronous memories . . . 20
2.9 SDIO peripheral limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.9.1 Wrong CCRCFAIL status after a response without CRC is received . . . 20
2.9.2 No underrun detection with wrong data transmission . . . . . . . . . . . . . . 21
2.10 ADC peripheral limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.10.1 ADC sequencer modification during conversion . . . . . . . . . . . . . . . . . . 21
2.11 QuadSPI limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.11.1 First nibble of data is not written after dummy phase . . . . . . . . . . . . . . 21
2.11.2 Wrong data can be read in memory-mapped after an indirect mode
operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
ES0305 Rev 9 3/25
3
List of tables STM32F412xE/xG
List of tables
Table 1. Device summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Table 2. Device variants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Table 3. Cortex-M4 core limitations and impact on microcontroller behavior . . . . . . . . . . . . . . . . . . . 5
Table 4. Summary of silicon limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Table 5. Maximum allowable APB frequency at 30 pF load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Table 6. Document revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4/25 ES0305 Rev 9
STM32F412xE/xG Arm® 32-bit Cortex®-M4 with FPU limitations
1 Arm® 32-bit Cortex®-M4 with FPU limitations
An errata notice of the STM32F412xx core is available from http://infocenter.arm.com.
All the described limitations are minor and related to the revision r0p1-v1 of the Cortex-M4
core. Table 3 summarizes these limitations and their implications on the behavior of
STM32F412xx devices.
Table 3. Cortex-M4 core limitations and impact on microcontroller behavior
Arm ID
752770 Cat B
776924 Cat B
Arm
category
Arm summary of errata Impact on STM32F412xx
Interrupted loads to SP can cause erroneous
behavior
VDIV or VSQRT instructions might not complete
correctly when very short ISRs are used
Minor
Minor
1.1 Cortex-M4 interrupted loads to stack pointer can cause erroneous behavior
Description
An interrupt occurring during the data-phase of a single word load to the stack pointer
(SP/R13) can cause an erroneous behavior of the device. In addition, returning from the
interrupt results in the load instruction being executed an additional time.
For all the instructions performing an update of the base register, the base register is
erroneously updated on each execution, resulting in the stack pointer being loaded from an
incorrect memory location.
The instructions affected by this limitation are the following:
• LDR SP, [Rn],#imm
• LDR SP, [Rn,#imm]!
• LDR SP, [Rn,#imm]
• LDR SP, [Rn]
• LDR SP, [Rn,Rm]
Workaround
As of today, no compiler generates these particular instructions. This limitation can only
occur with hand-written assembly code.
Both limitations can be solved by replacing the direct load to the stack pointer by an
intermediate load to a general-purpose register followed by a move to the stack pointer.
Example:
Replace LDR SP, [R0] by
LDR R2,[R0]
MOV SP,R2
ES0305 Rev 9 5/25
24
Arm® 32-bit Cortex®-M4 with FPU limitations STM32F412xE/xG
1.2 VDIV or VSQRT instructions might not complete correctly when very short ISRs are used
Description
On Cortex-M4 with FPU core, 14 cycles are required to execute a VDIV or VSQRT
instruction.
This limitation is present when the following conditions are met:
• A VDIV or VSQRT is executed
• The destination register for VDIV or VSQRT is one of s0 - s15
• An interrupt occurs and is taken
• The ISR being executed does not contain a floating point instruction
• 14 cycles after the VDIV or VSQRT is executed, an interrupt return is executed
In this case, if there are only one or two instructions inside the interrupt service routine, then
the VDIV or VQSRT instruction does not complete correctly and the register bank and
FPSCR are not updated, meaning that these registers hold incorrect out-of-date data.
Workaround
Two workarounds are applicable:
• Disable lazy context save of floating point state by clearing LSPEN to 0 (bit 30 of the
FPCCR at address 0xE000EF34).
• Ensure that every ISR contains more than 2 instructions in addition to the exception
return instruction.
6/25 ES0305 Rev 9
STM32F412xE/xG STM32F412xx silicon limitations
2 STM32F412xx silicon limitations
Table 4 gives quick references to all documented limitations.
Legend for Table 4: A = workaround available; N = no workaround available; P = partial
workaround available, ‘-’ and grayed = fixed.
Section 2.1.1: Debugging Sleep/Stop mode with WFE/WFI entry AA
Section 2.1.2: Wakeup sequence from Standby mode when using
more than one wakeup source
Table 4. Summary of silicon limitations
Links to silicon limitations Revision Z
AA
Revision C
and
Revision 1
Section 2.1:
System limitations
Section 2.2: IWDG
peripheral
limitation
Section 2.3: I2C
peripheral
limitations
Section 2.1.3: Full JTAG configuration without NJTRST pin cannot
be used
Section 2.1.4: MPU attribute to RTC and IWDG registers could be
managed incorrectly
AA
AA
Section 2.1.5: Delay after an RCC peripheral clock enabling AA
Section 2.1.6: Internal noise impacting the ADC accuracy AA
Section 2.1.7: Flash sector erase issue for sectors 5 to 11 A
-
Section 2.1.8: In some specific cases, DMA2 data corruption
occurs when managing AHB and APB2 peripherals in a concurrent
AA
way
Section 2.2.1: RVU and PVU flags are not reset in STOP mode AA
Section 2.3.1: SMBus standard not fully supported AA
Section 2.3.2: Start cannot be generated after a misplaced Stop AA
Section 2.3.3: Mismatch on the “Setup time for a repeated Start
condition” timing parameter
Section 2.3.4: Data valid time (t
) violated without the OVR
VD;DAT
flag being set
Section 2.3.5: Both SDA and SCL maximum rise time (t
) violated
r
when VDD_I2C bus higher than ((VDD+0.3) / 0.7) V
Section 2.3.6: Last received byte can be lost when using Reload
mode with NBYTES > 1
AA
AA
AA
PP
Section 2.4:
FMPI2C peripheral
limitation
Section 2.4.1: Wrong data sampling when data set-up time
(tSU;DAT) is smaller than one FMPI2CCLK period
ES0305 Rev 9 7/25
AA
24
STM32F412xx silicon limitations STM32F412xE/xG
Table 4. Summary of silicon limitations (continued)
Revision C
Links to silicon limitations Revision Z
and
Revision 1
Section 2.5:
SPI/I2S peripheral
limitation
Section 2.6:
USART peripheral
limitations
Section 2.5.1: Wrong CRC calculation when the polynomial is
even.
Section 2.5.2: BSY bit may stay high at the end of a data transfer in
slave mode
Section 2.5.3: Corrupted last bit of data and/or CRC, received in
Master mode with delayed SCK feedback
Section 2.6.1: Idle frame is not detected if receiver clock speed is
deviated
Section 2.6.2: In full duplex mode, the Parity Error (PE) flag can be
cleared by writing to the data register
Section 2.6.3: Parity Error (PE) flag is not set when receiving in
Mute mode using address mark detection
Section 2.6.4: Break frame is transmitted regardless of nCTS input
line status
Section 2.6.5: nRTS signal abnormally driven low after a protocol
violation
Section 2.6.6: Start bit detected too soon when sampling for NACK
signal from the smartcard
Section 2.6.7: Break request can prevent the Transmission
Complete flag (TC) from being set
Section 2.6.8: Guard time is not respected when data are sent on
TXE events
AA
AA
AA
NN
AA
NN
NN
AA
AA
AA
AA
Section 2.6.9: nRTS is active while RE or UE = 0 AA
Section 2.7:
bxCAN limitation
Section 2.8: FSMC
peripheral
limitation
Section 2.9: SDIO
peripheral
limitations
Section 2.10: ADC
peripheral
limitations
Section 2.11:
QuadSPI
limitations
8/25 ES0305 Rev 9
Section 2.7.1: bxCAN time triggered communication mode not
supported
Section 2.8.1: Dummy read cycles inserted when reading
synchronous memories
Section 2.9.1: Wrong CCRCFAIL status after a response without
CRC is received
Section 2.9.2: No underrun detection with wrong data transmission AA
Section 2.10.1: ADC sequencer modification during conversion AA
Section 2.11.1: First nibble of data is not written after dummy phase AA
Section 2.11.2: Wrong data can be read in memory-mapped after
an indirect mode operation
AA
NN
AA
AA
STM32F412xE/xG STM32F412xx silicon limitations
2.1 System limitations
2.1.1 Debugging Sleep/Stop mode with WFE/WFI entry
Description
When the Sleep debug or Stop debug mode is enabled (DBG_SLEEP bit or DBG_STOP bit
are set in the DBGMCU_CR register), this allows software debugging during Sleep or Stop
mode. After wakeup some unreachable instructions could be executed if the following
condition are met:
• If the application software disables the Prefetch queue
• The number of wait state configured on Flash interface is higher than 0
• And Linker place WFE or WFI instructions on 4-bytes aligned addresses
(0x080xx_xxx4)
Workaround
• Add three NOPs after WFI/WFE instruction
• Keep one AHB master active during sleep (example keep DMA1 or DMA2 RCC clock
enable bit set)
• Execute WFI/WFE instruction from routines inside the SRAM
2.1.2 Wakeup sequence from Standby mode when using more than one wakeup source
Description
The various wakeup sources are logically OR-ed in front of the rising-edge detector which
generates the wakeup flag (WUF). The WUF needs to be cleared prior to Standby mode
entry, otherwise the MCU wakes up immediately.
If one of the configured wakeup sources is kept high during the clearing of the WUF (by
setting the CWUF bit), it may mask further wakeup events on the input of the edge detector.
As a consequence, the MCU might not be able to wake up from Standby mode.
Workaround
To avoid this problem, the following sequence should be applied before entering
Standby mode:
• Disable all used wakeup sources,
• Clear all related wakeup flags,
• Re-enable all used wakeup sources,
• Enter Standby mode
Note: Be aware that, when applying this workaround, if one of the wakeup sources is still kept
high, the MCU enters Standby mode but then it wakes up immediately generating a power
reset.
ES0305 Rev 9 9/25
24
STM32F412xx silicon limitations STM32F412xE/xG
2.1.3 Full JTAG configuration without NJTRST pin cannot be used
Description
When using the JTAG debug port in debug mode, the connection with the debugger is lost if
the NJTRST pin (PB4) is used as a GPIO. Only the 4-wire JTAG port configuration is
impacted.
Workaround
Use the SWD debug port instead of the full 4-wire JTAG port.
2.1.4 MPU attribute to RTC and IWDG registers could be managed incorrectly
Description
If the MPU is used and the non bufferable attribute is set to the RTC or IWDG memory map
region, the CPU access to the RTC or IWDG registers could be treated as bufferable,
provided that there is no APB prescaler configured (AHB/APB prescaler is equal to 1).
Workaround
If the non bufferable attribute is required for these registers, the software could perform a
read after the write to guaranty the completion of the write access.
2.1.5 Delay after an RCC peripheral clock enabling
Description
A delay between an RCC peripheral clock enable and the effective peripheral enabling
should be taken into account in order to manage the peripheral read/write to registers.
This delay depends on the peripheral’s mapping:
• If the peripheral is mapped on AHB: the delay should be equal to 2 AHB cycles.
• If the peripheral is mapped on APB: the delay should be equal to 1 + (AHB/APB
prescaler) cycles.
Workarounds
1. Use the DSB instruction to stall the Cortex-M4 CPU pipeline until the instruction is
completed.
2. Insert “n” NOPs between the RCC enable bit write and the peripheral register writes
(n = 2 for AHB peripherals, n = 1 + AHB/APB prescaler in case of APB peripherals).
2.1.6 Internal noise impacting the ADC accuracy
Description
An internal noise generated on VDD supplies and propagated internally may impact the ADC
accuracy.
This noise is always active whatever the power mode of the MCU (RUN or Sleep).
10/25 ES0305 Rev 9
STM32F412xE/xG STM32F412xx silicon limitations
Workarounds
To adapt the accuracy level to the application requirements, set one of the following options:
• Option1
Set the ADCDC1 bit in the PWR_CR register.
• Option2
Set the corresponding ADCxDC2 bit in the SYSCFG_PMC register.
Only one option can be set at a time.
For more details on option 1 and option2 mechanisms, refer to AN4073.
2.1.7 Flash sector erase issue for sectors 5 to 11
Description
Under specific conditions, flash erase issues are observed.
The involved sectors are: 5 to 11
Workaround
Do not perform sector erase on sectors 5 to 11.
Use flash mass erase to erase sectors 5 to 11.
2.1.8 In some specific cases, DMA2 data corruption occurs when managing AHB and APB2 peripherals in a concurrent way
Description
When the DMA2 is managing concurrent requests of AHB and APB2 peripherals, the
transfer on the AHB could be performed several times.
Impacted peripheral are:
• Quad-SPI: indirect mode read and write transfers
• FSMC: read and write operation with external device having FIFO
• GPIO: DMA2 transfers to GPIO registers (in memory-to-peripheral transfer mode).The
transfers from GPIOs register are not impacted.
The data corruption is due to multiple DMA2 accesses over AHB peripheral port impacting
peripherals embedding a FIFO.
For transfer to the internal SRAM through the DMA2 AHB peripheral port the accesses
could be performed several times but without data corruptions in cases of concurrent
requests.
Workaround
• The DMA2 AHB memory port must be used when reading/writing from/to Quad-SPI
and FSMC instead of DMA2 AHB default peripheral port.
• The DMA2 AHB memory port must be used when writing to GPIOs instead of DMA2
AHB default peripheral port.
Refer to application note AN4031 section “Take benefits of DMA2 controller and system
architecture flexibility” for more details about DMA controller feature.
ES0305 Rev 9 11/25
24
STM32F412xx silicon limitations STM32F412xE/xG
2.2 IWDG peripheral limitation
2.2.1 RVU and PVU flags are not reset in STOP mode
Description
The RVU and PVU flags of the IWDG_SR register are set by hardware after a write access
to the IWDG_RLR and the IWDG_PR registers, respectively. If the Stop mode is entered
immediately after the write access, the RVU and PVU flags are not reset by hardware.
Before performing a second write operation to the IWDG_RLR or the IWDG_PR register,
the application software must wait for the RVU or PVU flag to be reset. However, since the
RVU/PVU bit is not reset after exiting the Stop mode, the software goes into an infinite loop
and the independent watchdog (IWDG) generates a reset after the programmed timeout
period.
Workaround
Wait until the RVU or PVU flag of the IWDG_SR register is reset before entering the Stop
mode.
2.3 I2C peripheral limitations
2.3.1 SMBus standard not fully supported
Description
The I2C peripheral is not fully compliant with the SMBus v2.0 standard since It does not
support the capability to NACK an invalid byte/command.
Workarounds
A higher-level mechanism should be used to verify that a write operation is being performed
correctly at the target device, such as:
1. Using the SMBAL pin if supported by the host
2. the alert response address (ARA) protocol
3. the Host notify protocol
2.3.2 Start cannot be generated after a misplaced Stop
Description
If a master generates a misplaced Stop on the bus (bus error), the peripheral cannot
generate a Start anymore.
Workaround
In the I²C standard, it is allowed to send a Stop only at the end of the full byte (8 bits +
acknowledge), so this scenario is not allowed. Other derived protocols like CBUS allow it,
but they are not supported by the I²C peripheral.
A software workaround consists in asserting the software reset using the SWRST bit in the
I2C_CR1 control register.
12/25 ES0305 Rev 9
STM32F412xE/xG STM32F412xx silicon limitations
2.3.3 Mismatch on the “Setup time for a repeated Start condition” timing parameter
Description
In case of a repeated Start, the “Setup time for a repeated Start condition” (named Tsu;sta in
the I²C specification) can be slightly violated when the I²C operates in Master Standard
mode at a frequency between 88 kHz and 100 kHz.
The limitation can occur only in the following configuration:
• in Master mode
• in Standard mode at a frequency between 88 kHz and 100 kHz (no limitation in Fast-
mode)
• SCL rise time:
– If the slave does not stretch the clock and the SCL rise time is more than 300 ns (if
the SCL rise time is less than 300 ns, the limitation cannot occur)
– If the slave stretches the clock
The setup time can be violated independently of the APB peripheral frequency.
Workaround
Reduce the frequency down to 88 kHz or use the I²C Fast-mode, if supported by the slave.
2.3.4 Data valid time (t
Description
The data valid time (t
as the maximum data hold time of the current data (t
below. This violation cannot be detected because the OVR flag is not set (no transmit buffer
underrun is detected).
This limitation can occur only under the following conditions:
• in Slave transmit mode
• with clock stretching disabled (NOSTRETCH=1)
• if the software is late to write the DR data register, but not late enough to set the OVR
flag (the data register is written before)
Workaround
If the master device allows it, use the clock stretching mechanism by programming the bit
NOSTRETCH=0 in the I2C_CR1 register.
If the master device does not allow it, ensure that the software is fast enough when polling
the TXE or ADDR flag to immediately write to the DR data register. For instance, use an
interrupt on the TXE or ADDR flag and boost its priority to the higher level.
VD;DAT
VD;DAT
) violated without the OVR flag being set
, t
) described by the I²C standard can be violated (as well
VD;ACK
)) under the conditions described
HD;DAT
ES0305 Rev 9 13/25
24
STM32F412xx silicon limitations STM32F412xE/xG
2.3.5 Both SDA and SCL maximum rise time (tr) violated when VDD_I2C bus higher than ((VDD+0.3) / 0.7) V
Description
When an external legacy I2C bus voltage (VDD_I2C) is set to 5 V while the MCU is powered
from V
reaches the V
prevents the external pull-up resistor (R
maximum timing (t
The rise time (t
, the internal 5-Volt tolerant circuitry is activated as soon the input voltage (VIN)
DD
+ diode threshold level. An additional internal large capacitance then
DD
) which is 300 ns in fast mode and 1000 ns in Standard mode.
r
) is measured from VIL and VIH with levels set at 0.3VDD_I2C and
r
) from rising the SDA and SCL signals within the
P
0.7VDD_I2C.
Workaround
The external VDD_I2C bus voltage should be limited to a maximum value of
((VDD+0.3) / 0.7) V. As a result, when the MCU is powered from V
should not exceed 5.14 V to be compliant with I
2
C specifications.
=3.3 V, VDD_I2C
DD
2.3.6 Last received byte can be lost when using Reload mode with NBYTES > 1
Description
The limitation can occur in master mode when reload mode is used (needed for transferring
more than 255 bytes), or in slave byte control mode (SBC=1 in the I2C_CR1 register). The
limitation occurs only when NBYTES > 1.
In Reload mode (RELOAD=1 in the I2C_CR2 register) with NBYTES programmed with a
value N in the I2C_CR2, the Transfer Complete Reload flag (TCR) is set in the I2C_ISR
register when the last byte is received in the shift register, even if not yet transferred in the
Receive Data Register because the byte N-1 is not yet read.
The last received data is definitively lost (never transferred in the Data Register) if the data
N-1 is read between 0 and 4 APB clock cycles before the TCR flag is being set is the
I2C_ISR register.
Workaround
In slave byte control mode : Use the Reload mode with NBYTES=1.
In master mode: Do not use the Reload mode. If the number of bytes to be transferred is
greater than 255 bytes, the total transfer should be split in several transfers not exceeding
255 bytes, separated by Repeated Start conditions.
Note that the use of DMA could manage that the data N-1 is always transferred before the 4
APB cycles preceding the TCR flag. However this must be evaluated carefully for each
application depending on the bus bandwidth, maximum latency, and DMA channel priority.
14/25 ES0305 Rev 9
STM32F412xE/xG STM32F412xx silicon limitations
2.4 FMPI2C peripheral limitation
2.4.1 Wrong data sampling when data set-up time (tSU;DAT) is smaller than one FMPI2CCLK period
Description
The I2C bus specification and user manual specifies a minimum data set-up time (tSU;DAT)
at:
• 250ns in Standard-mode,
• 100 ns in Fast-mode,
• 50 ns in Fast-mode Plus.
The I2C SDA line is not correctly sampled when tSU;DAT is smaller than one FMPI2CCLK
(FMPI2C clock) period: the previous SDA value is sampled instead of the current one. This
can result in a wrong slave address reception, a wrong received data byte, or a wrong
received acknowledge bit.
Workaround
Increase the I2CCLK frequency to get I2CCLK period smaller than the transmitter minimum
data set-up time. Or, if it is possible, increase the transmitter minimum data set-up time
2.5 SPI/I2S peripheral limitation
2.5.1 Wrong CRC calculation when the polynomial is even.
Description:
When the CRC is enabled, the CRC calculation will be wrong if the polynomial is even.
Workaround:
Use odd polynomial.
2.5.2 BSY bit may stay high at the end of a data transfer in slave mode
Description
The BSY flag may sporadically remain high at the end of a data transfer in Slave mode. The
issue appears when an accidental synchronization happens between the internal CPU clock
and the external SCK clock provided by master.
This is related to the end of data transfer detection while the SPI is enabled in Slave mode.
As a consequence, the end of data transaction may not be recognized when the software
needs to monitor it (for example at the end of a session before entering the low-power mode
or before the direction of data line has to be changed at half duplex bidirectional mode). The
BSY flag is unreliable to detect the end of any data sequence transaction.
ES0305 Rev 9 15/25
24
STM32F412xx silicon limitations STM32F412xE/xG
Workaround
When NSS hardware management is applied and NSS signal is provided by master, the end
of a transaction can be detected by the NSS polling by slave.
• If SPI receiving mode is enabled, the end of a transaction with master can be detected
by the corresponding RXNE event signalizing the last data transfer completion.
• In SPI transmit mode, user can check the BSY under timeout corresponding to the time
necessary to complete the last data frame transaction. The timeout should be
measured from TXE event signalizing the last data frame transaction start (it is raised
once the second bit transaction is ongoing). Either BSY becomes low normally or the
timeout expires when the synchronization issue happens.
When upper workarounds are not applicable, the following sequence can be used to
prevent the synchronization issue at SPI transmit mode:
1. Write last data to data register
2. Poll TXE until it becomes high to ensure the data transfer has started
3. Disable SPI by clearing SPE while the last data transfer is still ongoing
4. Poll the BSY bit until it becomes low
5. The BSY flag works correctly and can be used to recognize the end of the transaction.
Note: This workaround can be used only when CPU has enough performance to disable SPI after
TXE event is detected while the data frame transfer is still ongoing. It is impossible to
achieve it when ratio between CPU and SPI clock is low and data frame is short especially.
In this specific case timeout can be measured from TXE, while calculating fixed number of
CPU clock periods corresponding to the time necessary to complete the data frame
transaction.
2.5.3 Corrupted last bit of data and/or CRC, received in Master mode with delayed SCK feedback
Description
In receive transaction, in both I2S and SPI Master modes, the last bit of the transacted frame
is not captured when the signal provided by internal feedback loop from the SCK pin
exceeds a critical delay. The lastly transacted bit of the stored data then keeps the value
from the pattern received previously. As a consequence, the last receive data bit may be
wrong and/or the CRCERR flag can be unduly asserted in the SPI mode if any data under
check sum and/or just the CRC pattern is wrongly captured.
In SPI mode, data are synchronous with the APB clock. A delay of up to two APB clock
periods can thus be tolerated for the internal feedback delay. The I
sensitive than the SPI mode since the SCK clock is not synchronized with the APB. In this
case, the margin of the internal feedback delay is lower than one APB clock period.
The main factors contributing to the delay increase are low V
high SCK pin capacitive load and low SCK I/O output speed. The SPI communication speed
has no impact.
2
S mode is more
level, high temperature,
DD
16/25 ES0305 Rev 9
STM32F412xE/xG STM32F412xx silicon limitations
Workarounds
The following workaround can be adopted, jointly or individually:
• Decrease the APB clock speed.
• Configure the IO pad of the SCK pin to be faster.
The following table gives the maximum allowable APB frequency versus GPIOx_OSPEEDR
output speed control field setting for the SCK pin, at 30 pF of capacitive load.
Table 5. Maximum allowable APB frequency at 30 pF load
OSPEEDR [1:0]
for SCK pin
11 (very high) 100 84 (100 if V
10 (high) 100 60
01 (medium) 80 30
00 (low) 28 14
Max. APB frequency
for SPI mode
[MHz]
Max. APB frequency
for I
2
S mode
[MHz]
2.6 USART peripheral limitations
2.6.1 Idle frame is not detected if receiver clock speed is deviated
Description
If the USART receives an idle frame followed by a character, and the clock of the transmitter
device is faster than the USART receiver clock, the USART receive signal falls too early
when receiving the character start bit, with the result that the idle frame is not detected
(IDLE flag is not set).
Workaround
None.
> 2.7 V)
DD
2.6.2 In full duplex mode, the Parity Error (PE) flag can be cleared by writing to the data register
Description
In full duplex mode, when the Parity Error flag is set by the receiver at the end of a
reception, it may be cleared while transmitting by reading the USART_SR register to check
the TXE or TC flags and writing data to the data register.
Consequently, the software receiver can read the PE flag as '0' even if a parity error
occurred.
Workaround
The Parity Error flag should be checked after the end of reception and before transmission.
ES0305 Rev 9 17/25
24
STM32F412xx silicon limitations STM32F412xE/xG
2.6.3 Parity Error (PE) flag is not set when receiving in Mute mode using address mark detection
Description
The USART receiver is in Mute mode and is configured to exit the Mute mode using the
address mark detection. When the USART receiver recognizes a valid address with a parity
error, it exits the Mute mode without setting the Parity Error flag.
Workaround
None.
2.6.4 Break frame is transmitted regardless of nCTS input line status
Description
When CTS hardware flow control is enabled (CTSE = 1) and the Send Break bit (SBK) is
set, the transmitter sends a break frame at the end of the current transmission regardless of
nCTS input line status.
Consequently, if an external receiver device is not ready to accept a frame, the transmitted
break frame is lost.
Workaround
None.
2.6.5 nRTS signal abnormally driven low after a protocol violation
Description
When RTS hardware flow control is enabled, the nRTS signal goes high when data is
received. If this data was not read and new data is sent to the USART (protocol violation),
the nRTS signal goes back to low level at the end of this new data.
Consequently, the sender gets the wrong information that the USART is ready to receive
further data.
On USART side, an overrun is detected, which indicates that data has been lost.
Workaround
Workarounds are required only if the other USART device violates the communication
protocol, which is not the case in most applications.
Two workarounds can be used:
• After data reception and before reading the data in the data register, the software takes
over the control of the nRTS signal as a GPIO and holds it high as long as needed. If
the USART device is not ready, the software holds the nRTS pin high, and releases it
when the device is ready to receive new data.
• The time required by the software to read the received data must always be lower than
the duration of the second data reception. For example, this can be ensured by treating
all the receptions by DMA mode.
18/25 ES0305 Rev 9
STM32F412xE/xG STM32F412xx silicon limitations
2.6.6 Start bit detected too soon when sampling for NACK signal from the smartcard
Description
In the ISO7816, when a character parity error is incorrect, the Smartcard receiver shall
transmit a NACK error signal at (10.5 +/- 0.2) etu after the character START bit falling edge.
In this case, the USART transmitter should be able to detect correctly the NACK signal by
sampling at (11.0 +/-0.2) etu after the character START bit falling edge.
The USART peripheral used in Smartcard mode doesn't respect the (11 +/-0.2) etu timing,
and when the NACK falling edge arrives at 10.68 etu or later, the USART might misinterpret
this transition as a START bit even if the NACK is correctly detected.
Workaround
None
2.6.7 Break request can prevent the Transmission Complete flag (TC) from being set
Description
After the end of transmission of a data (D1), the Transmission Complete (TC) flag will not be
set if the following conditions are met:
• CTS hardware flow control is enabled.
• D1 is being transmitted.
• A break transfer is requested before the end of D1 transfer.
• nCTS is de-asserted before the end of D1 data transfer.
Workaround
If the application needs to detect the end of a data transfer, the break request should be
issued after checking that the TC flag is set.
2.6.8 Guard time is not respected when data are sent on TXE events
Description
In smartcard mode, when sending a data on TXE event, the programmed guard time is not
respected i.e. the data written in the data register is transferred on the bus without waiting
the completion of the guardtime duration corresponding to the previous transmitted data.
Workaround
Write the data after TC is set because in smartcard mode, the TC flag is set at the end of the
guard time duration.
2.6.9 nRTS is active while RE or UE = 0
Description
The nRTS line is driven low as soon as RTSE bit is set even if the USART is disabled (UE =
0) or if the receiver is disabled (RE=0) i.e. not ready to receive data.
ES0305 Rev 9 19/25
24
STM32F412xx silicon limitations STM32F412xE/xG
Workaround
Configure the I/O used for nRTS as an alternate function after setting the UE and RE bits.
2.7 bxCAN limitation
2.7.1 bxCAN time triggered communication mode not supported
Description
The time triggered communication mode described in the reference manual is not
supported. As a result timestamp values are not available. TTCM bit must be kept cleared in
the CAN_MCR register (time triggered communication mode disabled).
Workaround
None
2.8 FSMC peripheral limitation
2.8.1 Dummy read cycles inserted when reading synchronous memories
Description
When performing a burst read access to a synchronous memory, two dummy read accesses
are performed at the end of the burst cycle whatever the type of AHB burst access.
However, the extra data values which are read are not used by the FSMC and there is no
functional failure.
Workaround
None.
2.9 SDIO peripheral limitations
2.9.1 Wrong CCRCFAIL status after a response without CRC is received
Description
The CRC is calculated even if the response to a command does not contain any CRC field.
As a consequence, after the SDIO command IO_SEND_OP_COND (CMD5) is sent, the
CCRCFAIL bit of the SDIO_STA register is set.
Workaround
The CCRCFAIL bit in the SDIO_STA register shall be ignored by the software. CCRCFAIL
must be cleared by setting CCRCFAILC bit of the SDIO_ICR register after reception of the
response to the CMD5 command.
20/25 ES0305 Rev 9
STM32F412xE/xG STM32F412xx silicon limitations
2.9.2 No underrun detection with wrong data transmission
Description
In case there is an ongoing data transfer from the SDIO host to the SD card and the
hardware flow control is disabled (bit 14 of the SDIO_CLKCR is not set), if an underrun
condition occurs, the controller may transmit a corrupted data block (with wrong data word)
without detecting the underrun condition when the clock frequencies have the following
relationship:
[3 x period(PCLK2) + 3 x period(SDIOCLK)] >= (32 / (BusWidth)) x period(SDIO_CK)
Workaround
Avoid the above-mentioned clock frequency relationship, by:
• Incrementing the APB frequency
• or decreasing the transfer bandwidth
• or reducing SDIO_CK frequency
2.10 ADC peripheral limitations
2.10.1 ADC sequencer modification during conversion
Description
If an ADC conversion is started by software (writing the SWSTART bit), and if the
ADC_SQRx or ADC_JSQRx registers are modified during the conversion, the current
conversion is reset and the ADC does not restart a new conversion sequence automatically.
If an ADC conversion is started by hardware trigger, this limitation does not apply. The ADC
restarts a new conversion sequence automatically.
Workaround
When an ADC conversion sequence is started by software, a new conversion sequence can
be restarted only by setting the SWSTART bit in the ADC_CR2 register.
2.11 QuadSPI limitations
2.11.1 First nibble of data is not written after dummy phase
Description:
• The first nibble of data to be written to an external flash is lost if:
• QUADSPI is used in indirect write mode, and
• at least one dummy cycle is used
Workaround
Do not use dummy cycles for creating latency between address phase and data phase, in
indirect write mode. Instead, use alternate bytes to substitute the dummy cycles. The same
ES0305 Rev 9 21/25
24
STM32F412xx silicon limitations STM32F412xE/xG
latency can be achieved if the number of dummy cycles to substitute with alternate-byte
cycles is an integer multiple of the number of cycles required for transferring one alternate
byte, as shown in the table:
QUADSPI mode Number of cycles per alternative byte
4-data-line DDR 1
4-data-line SDR 2
2-data-line SDR 4
1-data-line SDR 8
For example, the latency corresponding to eight dummy cycles can be exactly substituted
with one single alternate byte in 1-data-line SDR mode, but two alternate bytes are required
in 2-data-line SDR mode. One single dummy cycle can only exactly be substituted in
4-data-line DDR mode, using one alternate byte.
Note: This is also applicable to dual-flash memory mode.
2.11.2 Wrong data can be read in memory-mapped after an indirect mode operation
Description
Wrong data can be read with the first memory-mapped read request in the following
condition:
Quad-SPI peripheral entered memory-mapped mode with both LSB bits in the address
register QUADSPI_AR[1:0] not reset.
Workaround
QUADSPI_AR register must be reset just before entering memory-mapped mode.
Depending on the current Quad-SPI operating mode, one of the two workarounds listed
below can be used:
• Indirect read mode: reset address register then do an abort request to stop reading and
clear busy bit. Then enter to memory-mapped mode.
• Indirect write mode: reset the address register then enter to memory-mapped mode.
Note: User should take care to not write to QUADSPI_DR register after resetting address register.
22/25 ES0305 Rev 9
STM32F412xE/xG Revision history
3 Revision history
Table 6. Document revision history
Date Revision Changes
21-Sep-2015 1 Initial release
Updated:
24-Mar-2016 2
– Table 1: Device identification
– Table 4: Summary of silicon limitations
Updated:
15-Apr-2016 3
– Table 1: Device identification
– Table 4: Summary of silicon limitations
Updated:
23-May-2016 4
– Table 1: Device identification
– Table 4: Summary of silicon limitations
Updated:
– Table 1: Device identification
Added:
17-Jun-2016 5
– Section 2.1.8: In some specific cases, DMA2 data corruption occurs when managing
AHB and APB2 peripherals in a concurrent way
Removed:
– Section 2.12: Quad-SPI limitation
Updated:
– Table 4: Summary of silicon limitations
30-Jun-2016 6
– Section 2.5: SPI/I2S peripheral limitation
Removed:
– Section 2.11: DAC peripheral limitations
Updated:
– Table 4: Summary of silicon limitations
– Section 2.5: SPI/I2S peripheral limitation
25-Jan-2017 7
– Section 2.5.2: BSY bit may stay high at the end of a data transfer in slave mode
– Section 2.5.3: Corrupted last bit of data and/or CRC, received in Master mode with
delayed SCK feedback
Added:
– Table 5: Maximum allowable APB frequency at 30 pF load
ES0305 Rev 9 23/25
24
Revision history STM32F412xE/xG
Table 6. Document revision history (continued)
Date Revision Changes
Updated:
– Table 4: Summary of silicon limitations
Added:
– Section 2.3.6: Last received byte can be lost when using Reload mode with NBYTES
16-Oct-2017 8
01-Oct-2020 9
> 1
– Section 2.11: QuadSPI limitations
– Section 2.11.1: First nibble of data is not written after dummy phase
– Section 2.11.2: Wrong data can be read in memory-mapped after an indirect mode
operation
Updated:
– Table 2: Device variants
– Table 4: Summary of silicon limitations
24/25 ES0305 Rev 9
STM32F412xE/xG
IMPORTANT NOTICE – PLEASE READ CAREFULLY
STMicroelectronics NV and its subsidiaries (“ST”) reserve the right to make changes, corrections, enhancements, modifications, and
improvements to ST products and/or to this document at any time without notice. Purchasers should obtain the latest relevant information on
ST products before placing orders. ST products are sold pursuant to ST’s terms and conditions of sale in place at the time of order
acknowledgement.
Purchasers are solely responsible for the choice, selection, and use of ST products and ST assumes no liability for application assistance or
the design of Purchasers’ products.
No license, express or implied, to any intellectual property right is granted by ST herein.
Resale of ST products with provisions different from the information set forth herein shall void any warranty granted by ST for such product.
ST and the ST logo are trademarks of ST. For additional information about ST trademarks, please refer to www.st.com/trademarks. All other
product or service names are the property of their respective owners.
Information in this document supersedes and replaces information previously supplied in any prior versions of this document.
© 2020 STMicroelectronics – All rights reserved
ES0305 Rev 9 25/25
25
Loading...
