PSP™ (PlayStation®Portable)

Internet Radio Player

Development Guide

Document Version 1.1(E)

System Software Version 5.00

[Trademarks]

"PlayStation" and PSP™ are registered trademarks of Sony Computer Entertainment, Inc.

"Memory Stick" and "Memory Stick Duo" are trademarks of Sony Corporation.

"XMB" is a trademark of Sony Corporation and Sony Computer Entertainment, Inc. "PSP (PlayStation Portable)" Internet features include of ACCESS CO., LTD.

ACCESS and NetFront are trademarks or registered trademarks of ACCESS CO., LTD. in Japan and other countries.

Java and JavaScript are trademarks or registered trademarks of Sun Microsystems, Inc. in the

United States and other countries.

Flash, Macromedia, and Macromedia Flash are trademarks or registered trademarks of Adobe

Systems Incorporated in the United States and other countries.

SHOUTcast and Winamp™ are trademarks or registered trademarks of AOL.

SHOUTCAST is a trademark of AOL LLC. Winamp is a trademark of AOL LLC.

Macintosh is a trademark of Apple Inc.

Windows is a registered trademark of Microsoft Corporation in the United States and other

countries.

All other product and company names mentioned herein are generally trademarks and/or registered

trademarks of their respective owners.

[Terms and Conditions] All rights (including, but not limited to, copyright) pertaining to all the materials and information that are made available from this Guideline are managed, owned, or used with permission by, SCEI. All materials in this Guideline are protected by copyright laws, and other applicable laws. Except for personal, non-commercial, internal use, you are prohibited from using (including, without limitation, copying, modifying, reproducing in whole or in part, uploading, transmitting, distributing, licensing, selling and publishing) any of the materials, without obtaining SCEI's prior written permission. The contents of this Guideline are not guaranteed to be valid for future versions of system software.

SCEI OR ANY OF ITS AFFILIATES SHALL NOT BE LIABLE FOR ANY DAMAGES ARISING

OUT OF ANY CHANGE OF THE SYSTEM SOFTWARE SPECIFICATIONS.

©SCEI PSP™ Internet Radio Player Development Guide

- 2 -

Table of Contents

1 About This Document................................................................................ 6

Overview ........................................................................................................................6

Who Should Read This Document? ..............................................................................6

What Specifically gets Created when an Internet Radio Player is Developed?........7

Related Documents .....................................................................................................10

2 PSP™ Internet Radio Structure and Operation..................................... 11

PSP™ Internal ............................................................................................................12

PSP™ External............................................................................................................13

3 Creating the Internet Radio Player .........................................................20

List of JavaScript Extended Methods........................................................................22

JavaScript Extended Method Reference Details.......................................................26

sysRadioPlayStream ...................................................................................................27

sysRadioPlayPls ..........................................................................................................30

sysRadioPlayM3u........................................................................................................33

sysRadioStop ...............................................................................................................36

sysRadioSetMasterVolume .........................................................................................40

sysRadioSetSubVolume...............................................................................................43

sysRadioGetLeftAudioPeakLevel...............................................................................46

sysRadioGetRightAudioPeakLevel ............................................................................50

sysRadioGetLeftAudioAverageLevel..........................................................................54

sysRadioGetRightAudioAverageLevel .......................................................................58

sysRadioSetSineWaveOscillatorFrequencyAndVolume............................................62

sysRadioSetWhiteNoiseOscillatorVolume .................................................................65

sysRadioSetAudioShiftWidth .....................................................................................68

sysRadioSetAudioCutOffWidth..................................................................................73

sysRadioSetAudioPitchShiftWidth ............................................................................77

sysRadioPlayEffectSound ...........................................................................................81

sysRadioPrepareForHttpGet......................................................................................84

sysRadioGetHttpGetStatus ........................................................................................88

sysRadioGetHttpGetResult ........................................................................................91

©SCEI PSP™ Internet Radio Player Development Guide

- 3 -

sysRadioHttpGetTerminate........................................................................................94

sysRadioGetPlayerStatus ...........................................................................................97

sysRadioGetNetworkBandQuality...........................................................................100

sysRadioGetAudioSoundDistortionRate..................................................................103

sysRadioGetContentMetaInfo ..................................................................................106

sysRadioGetBitRate ..................................................................................................109

sysRadioGetSamplingRate .......................................................................................112

sysRadioGetStreamUrl .............................................................................................115

sysRadioGetStreamTitle...........................................................................................118

sysRadioGetRelatedPageUrl ....................................................................................121

sysRadioGetStreamIpAddress..................................................................................124

sysRadioGetStreamPort ...........................................................................................127

sysRadioGetStreamBufferLevel ...............................................................................130

sysRadioPrepareForScanDir ....................................................................................133

sysRadioScanDir .......................................................................................................136

sysRadioGetMediaInOutStatus ...............................................................................139

sysRadioPrepareForStrOperation............................................................................142

sysRadioStrLength....................................................................................................145

sysRadioStrIndexOf ..................................................................................................148

sysRadioStrSlice........................................................................................................152

sysRadioStrCharCodeAt ...........................................................................................156

sysRadioStrOperationTerminate..............................................................................159

sysRadioCharacterEntityConvert ............................................................................162

sysRadioCharacterCodeConvert ..............................................................................165

sysRadioGetAnalogStickXValue...............................................................................168

sysRadioGetAnalogStickYValue...............................................................................170

sysRadioGetAnalogStickAngleValue........................................................................172

sysRadioGetAnalogStickRadiusValue......................................................................174

sysRadioSetDebugMode............................................................................................177

sysRadioDebugLog ....................................................................................................179

sysRadioSetDebugLogTextStyle...............................................................................182

sysRadioClearDebugLog...........................................................................................188

sysRadioGetPlayerCoreVersionInfo .........................................................................190

sysRadioCapabilityCheck .........................................................................................192

sysRadioGetStartButtonToggleStatus .....................................................................195

sysRadioBackLightAlwaysOn ..................................................................................197

sysRadioBusyIndicator .............................................................................................200

©SCEI PSP™ Internet Radio Player Development Guide

- 4 -

sysRadioCaptureScreenShot ....................................................................................202

sysRadioSleep............................................................................................................205

sysRadioGetSystemStatus........................................................................................207

4 Procedure for Developing an Internet Radio Player...........................209

Overview ....................................................................................................................209

1. Create an image of the completed form ...............................................................211

2. Create graphic elements .......................................................................................212

3. Create directories on the Memory Stick Duo™ and copy image files................214

4. Create html, css, and JavaScript files and copy them to the Memory Stick

Duo™..........................................................................................................................216

5. Copy the test Internet radio player icon file to the Memory Stick Duo™ .........219

6. Unmount the PSP™ system from the PC and then cancel the PSP™ system’s

USB mode ..................................................................................................................219

7. Try starting up the Internet radio player from the test Internet player icon...220

8. Create JavaScript code .........................................................................................222

9. Change css and image files to create another Internet radio player .................230

10. Create an Internet radio player with completely different functions and design233

11. Supplement..........................................................................................................233

5 Creating the Internet Radio Player Icon............................................... 234

What is an Internet Radio Player Icon? ..................................................................234

What is the Internet Radio Player Icon Generation Tool?......................................236

How Do you Start Up the Internet Radio Player Icon Generation Tool?...............237

How Do You Make the Internet Radio Player Icon That You Created Publicly

Available? ...................................................................................................................241

6 Appendix ................................................................................................242

Terms and Phrases That are Often Used ................................................................242

7 Update History

©SCEI PSP™ Internet Radio Player Development Guide

.......................................................................................244

- 5 -

1 About This Document

Overview

This document contains information that is needed to develop a PSP™ Internet radio player.

The procedure is explained through the use of sample programs and data.

Specifically, this document contains the following information.

z Overview of the structure and operation of an Internet radio player

z Procedure for developing an Internet radio player

z Extended JavaScript method reference

z Overview of Internet radio player icons and how to create them

Who Should Read This Document?

This document is intended for anyone who is interested in developing a PSP™ Internet radio

player.

For example, a broadcaster who provides an existing Internet radio service can develop a

special-purpose Internet radio player that receives their local broadcasts. Users who obtain

that Internet radio player will be able to listen to those broadcasts on the PSP™ Internet

radio.

In addition, a normal user who is not a broadcaster can create and release an Internet radio

player that has a unique user interface, is easier to use, or has features not found in the player

released by SCE.

The difference between the two types of Internet radio player software developers mentioned

above is that one type has broadcast station information from which the audio data stream is

transmitted and the other does not. Although the essential part of the Internet radio player

implementation will be exactly the same, the two implementations can result in different

amounts of JavaScript program code that must be written.

A person who is not a broadcaster (i.e. someone who is not personally broadcasting) must

©SCEI PSP™ Internet Radio Player Development Guide

- 6 -

somehow obtain broadcast station information. Both "Internet Radio Player I" and "Internet

Radio Player II" provided by SCE rely on the SHOUTcast and icecast.org protocols to

dynamically obtain this information. When a person who is not a broadcaster develops an

Internet radio player, that person must use this same process to obtain this information

dynamically.

Since broadcast station information by nature is constantly changing over time, having the

Internet radio player save this information either internally or externally is not recommended

because of the long-term maintenance and software stability problems it can create.

One method of addressing this problem is to have the JavaScript program code that forms the

Internet radio player dynamically collect the information. Another method would be to

perform this processing on a regular basis using a service such as cron, or to have it done at

some specific time using a cgi program running on the Web server where the Internet radio

player is located.

The second half of this document describes an example implementation in JavaScript for

performing this processing, similar to the method used by "Internet Radio Player I" and

"Internet Radio Player II".

A broadcaster should remove the JavaScript code that accesses the broadcast station database

from this example implementation.

Specific details concerning the implementation of a cgi program or cron job running on a Web

server have been omitted from this document.

This document assumes that readers have a basic knowledge of HTML, XML, JavaScript, Web

servers, and Internet radio.

What Specifically gets Created when an Internet Radio Player is Developed?

Developing an Internet radio player means creating the following two items.

z The Internet radio player itself

z An Internet radio player icon

©SCEI PSP™ Internet Radio Player Development Guide

- 7 -

The "Internet radio player" is made up of HTML, JavaScript, and image data. These comprise

the Internet radio GUI, which acts in conjunction with PSP™ system software to govern the

behavior of the Internet radio player.

Example of an Internet Radio Player GUI

©SCEI PSP™ Internet Radio Player Development Guide

- 8 -

The Internet radio player icon is used to launch the Internet radio player. It is displayed on

the XMB™ under the "Network" category, in the layer below "Internet radio".

The Internet radio player icon is created using a tool that is bundled with the SDK. This

document is also included in the SDK.

There is a 1-to-1 correspondence between an Internet radio player and an Internet radio

player icon.

Example of an Internet Radio Player Icon

©SCEI PSP™ Internet Radio Player Development Guide

- 9 -

2 PSP™ Internet Radio Structure and Operation

The PSP™ Internet radio system is conceptually divided into the following three main

components.

1. An Internet radio player icon, which is displayed on the XMB™ as explained in the

previous chapter.

2. An Internet radio player, which appears as a GUI in the PSP™ Internet browser.

3. The SHOUTcast/icecast2 protocol handler, which receives SHOUTcast or icecast2

protocol audio data streams for playback.

The following figure shows the position of these three components within the entire Internet

radio player system.

©SCEI PSP™ Internet Radio Player Development Guide

- 11 -

PSP™ Internal

Ⓐ PSP™ system (hardware)

The PSP™ (PlayStation®Portable) system.

Ⓑ PSP™ system software

Includes the operating system, device drivers, audio decoders, network access libraries,

graphics libraries, and other basic software.

Xross media bar.

The XMB™ displays the Internet radio player icon under the "Network" category, in the

layer below "Internet radio". The XMB™ also displays information associated with the

Internet radio player icon and is responsible for launching the Internet radio player.

Ⓓ Internet browser

PSP™ Internet browser.

The functionality of the PSP™ Internet browser has been extended so that it works with

the Ⓔ SHOUTcast/icecast2 protocol handler. The Ⓖ Internet radio player can use

JavaScript methods to access this additional functionality for controlling the incoming

audio data stream and for obtaining additional information.

Ⓔ SHOUTcast/icecast2 protocol handler

The SHOUTcast/icecast2 protocol handler connects to the broadcast server, receives an

audio data stream that contains content meta information, then passes that stream to an

audio decoder to decode and output audio. The Ⓔ SHOUTcast/icecast2 protocol handler

has functions for parsing Playlist (PLS) data, and for creating a JavaScript String object

representing the response from an HTTP GET sent to an arbitrary URL.

In addition, the Ⓖ Internet radio player can interface with the JavaScript extended

methods provided by the Ⓓ Internet browser to obtain content meta information extracted

by the Ⓔ SHOUTcast/icecast2 protocol handler in the form of a JavaScript String object.

The complete system comprising these components Ⓐ to Ⓔ is referred to as the “PSP™

Internet radio player core system.”

©SCEI PSP™ Internet Radio Player Development Guide

- 12 -

PSP™ External

Ⓕ Internet radio player icon

A file containing data that is used for displaying the Internet radio player icon on the

XMB™.

The file is located in the "/PSP/RADIOPLAYER" directory on a Memory Stick Duo™. The

file extension is ".prs".

The data contains the following information (details described later).

z Name of Internet radio player (required)

z URL of Internet radio player (required)

z Icon image (optional)

z Icon focus image (optional)

z Comment about the Internet radio player (optional)

z URL of author's website (optional)

z Author's name (optional)

z Copyright information (optional)

The above information can be displayed from the Ⓒ XMB™.

The Internet radio player's author is responsible for creating the Internet radio player icon.

The Internet Radio Player SDK comes with a tool that can be used to create the icon. This

document is also included in the SDK.

Ⓖ Internet radio player

GUI of the PSP™ Internet radio player.

The GUI consists of HTML, JavaScript, and image files.

The Ⓓ Internet browser can control functions provided by the Ⓔ SHOUTcast/icecast2

protocol handler by invoking JavaScript methods defined in the Internet radio player.

These functions can be used to control the connection to a broadcast server. Information

obtained from the Ⓔ SHOUTcast/icecast2 protocol handler is displayed on-screen via the

Ⓓ Internet browser.

The Ⓖ Internet radio player is placed on a Web server provided by the Internet radio

player's author. The Ⓖ Internet radio player is a client-side application that runs on the

Ⓓ Internet browser. It is not a server-side application. Therefore, server-side scripts are

not necessary.

©SCEI PSP™ Internet Radio Player Development Guide

- 13 -

HINT

As described in Chapter 1, part of the processing of an Internet radio player can also be

implemented by a server-side cgi program or service such as cron.

Ⓗ Broadcast server

Distributes the SHOUTcast or icecast2 protocol audio data stream.

To receive an audio stream, the Ⓖ Internet radio player connects to the Ⓗ broadcast

server either by directly specifying its URL, or from information contained in playlist or

M3U data that points to the desired server.

Broadcast server URL information or playlist (PLS or M3U) information can be obtained

from the Stream Directory page administered by icecast.org or the SHOUTcast

SHOWCASE page administered by AOL.

©SCEI PSP™ Internet Radio Player Development Guide

- 14 -

The PSP™ Internet radio can also be implemented in JavaScript that describes the

information collection processing related to the Ⓗ broadcast server, using the Ⓓ Internet

browser and Ⓔ SHOUTcast/icecast2 protocol handler functions.

The following figure shows this type of implementation.

"Internet Radio Player I," which is an Internet radio player that SCE made publicly

available, uses SHOUTcast SHOWCASE information. Similarly, "Internet Radio Player II"

uses the Stream Directory of icecast.org.

The second half of this document describes a sample Internet radio player that uses the

Stream Directory of icecast.org.

《Ⓘ Broadcast station information database》

Database system containing broadcast station information used for distributing audio data

streams via the SHOUTcast or icecast2 protocols.

Specifically, this database system corresponds to the SHOUTcast SHOWCASE administered

by AOL and the Stream Directory administered by icecast.org.

Each database system has its own proprietary set of Web APIs. For details related to these,

refer to the documentation for the database system in use.

©SCEI PSP™ Internet Radio Player Development Guide

- 15 -

The Ⓖ Internet radio player uses these Web APIs to find specific broadcast stations such as

those offering a particular music genre. This information can be used to create a broadcast

station list.

This processing is performed by the part in the figure marked as "database accessor". However,

the database accessor is not a real entity, but rather an abstract entity defined in JavaScript.

It is a set of components that provide functions such as HTTP GET processing, string parsing,

and processing for generating an information array.

When the URL of the broadcast server is fixed such as when a broadcaster develops software

for a local station-specific Internet radio player, the database accessor and the Ⓘ broadcast

station information database are unnecessary.

©SCEI PSP™ Internet Radio Player Development Guide

- 16 -

The explanation below divides the interrelationships among resources related to PSP™

Internet radio into three main scenarios.

The PSP™ Internet radio can support all three of these scenarios.

Scenario 1: The broadcast content provider and the broadcast server provider create a

dedicated Internet radio player for receiving their own broadcasts

The scenario shown in this figure applies when a broadcaster creates a local station-specific

Internet radio player.

Since the broadcaster (= player author) knows the information required for the connection

such as the URL and port number of the broadcast server, the broadcast station information

database is unnecessary.

This information (which are default values) can be hardcoded into the Internet radio player.

The Internet radio player can also be implemented so that default information related to the

broadcast server is dynamically read by the Internet radio player from a separate file apart

from the html or JavaScript. In this case, the format of this file is arbitrary.

The Internet radio player can be implemented in this way without requiring any non-local

station resources.

©SCEI PSP™ Internet Radio Player Development Guide

- 17 -

Scenario 2: The broadcast station information database provider and the broadcast server

provider are the same

The scenario shown in this figure applies when the broadcast content provider is separate

from the broadcast server provider and the broadcast station information database provider.

Scenario 2 can has the same form as Scenario 3 where the broadcast station information

database provider, the broadcast server provider, the broadcast content provider, and the

Internet radio player provider are separate entities.

The "Broadcast client" in this figure refers to music player software such as Winamp and

plugin software for connecting to the broadcast server.

©SCEI PSP™ Internet Radio Player Development Guide

- 18 -

Scenario 3: The broadcast station information database provider, the broadcast server

provider, the broadcast content provider, and the Internet radio player provider are separate

entities

"Internet Radio Player I" and "Internet Radio Player II," which are provided by SCE, are

implementations based on this format.

©SCEI PSP™ Internet Radio Player Development Guide

- 19 -

3 Creating the Internet Radio Player

This chapter explains how to create the PSP™ Internet radio player, which was briefly

mentioned in Chapter 1.

As explained in the previous chapters, the PSP™ Internet radio player consists of HTML and

JavaScript. Some css and image files are also added as components to create the external

appearance of the Internet radio player and to increase maintainability. Since the Internet

radio player is created by the same process as creating an ordinary Web page, the effort

required is also the same.

However, an ordinary Web page alone cannot function as an Internet radio player.

Mechanisms for producing sound and for finding broadcast stations are required for it to

function as an Internet radio player.

To implement these capabilities on an ordinary Web page, 59 JavaScript extended methods

are provided as part of the PSP™ Internet radio system. These extended methods will give the

Web page the additional capabilities needed to function as an Internet radio player.

When the Internet browser is launched as a PSP™ Internet radio player from the Internet

radio icon under the "Network" category of the XMB™, this group of 52 extended methods is

added to the PSP™ Internet browser. When the browser is started up as a normal PSP™

Internet browser, this group of methods cannot be used.

Some of the principal extended methods include sysRadioPlayPls, which accesses a playlist file

to play audio, sysRadioPlayStream for directly connecting to a broadcast server, and

sysRadioPrepareForHttpGet, which accesses an arbitrary URL to perform an HTTP GET

operation.

By combining these extended methods, you can perform a series of functions such as: obtaining

broadcast station information from the Stream Directory page of icecast.org, parsing the

HTML or XML string that is obtained, constructing the URL for accessing the broadcast

station's playlist file, using the playlist's URL to connect to the broadcast server (audio data

stream server), and finally receiving the audio data stream.

The PSP™ Internet radio player is the entity that performs this processing, interacts with the

user, and displays information on-screen such as the broadcast station's name and the content

being played.

©SCEI PSP™ Internet Radio Player Development Guide

- 20 -

HINT

It is technically possible to receive a live audio data stream by invoking the action script

"Sound.loadSound()" on the Flash player within the PSP™ Internet browser, however,

proper operation is not currently guaranteed. This is because the Flash player that is

currently implemented in system software will continuously accumulate a received audio

data stream in the PSP™ system's internal memory. Therefore, playing (receiving) audio

using the Flash player's "Sound.loadSound()" will eventually cause an "Insufficient

memory" alert dialog to appear.

©SCEI PSP™ Internet Radio Player Development Guide

- 21 -

List of JavaScript Extended Methods

A list of extended JavaScript methods for the PSP™ Internet radio player is given below.

Methods for starting and stopping playback

Method Name Function

sysRadioPlayStream Start playback by specifying URL of audio data

stream sysRadioPlayPls Start playback by specifying URL of PLS file sysRadioPlayM3u Start playback by specifying URL of M3U file sysRadioStop Stop playback

Methods for controlling output volume

Method Name Function

sysRadioSetMasterVolume Set master volume level sysRadioSetSubVolume Set sub volume level

Methods for getting audio output level

Method Name Function

sysRadioGetLeftAudioPeakLevel Get peak audio level being output from audio left

channel.

Used for displaying audio level meter, etc. sysRadioGetRightAudioPeakLevel Get peak audio level being output from audio

right channel.

Used for displaying audio level meter, etc. sysRadioGetLeftAudioAverageLevel Get average audio level being output from audio

left channel.

Used for displaying audio level meter, etc. sysRadioGetRightAudioAverageLevel Get average audio level being output from audio

right channel.

Used for displaying audio level meter, etc.

Methods for controlling sound effects

Method Name Function

sysRadioSetSineWaveOscillatorFrequencyAndVolume Set oscillation frequency and

volume level of sine wave oscillator

sysRadioSetWhiteNoiseOscillatorVolume Set volume level of pseudo white

noise oscillator sysRadioSetAudioShiftWidth Set shift width of audio frequency component sysRadioSetAudioCutOffWidth Set cut-off width of audio frequency component sysRadioSetAudioPitchShiftWidth Set pitch shift width of audio frequency

component

sysRadioPlayEffectSound Play sound effect

©SCEI PSP™ Internet Radio Player Development Guide

- 22 -

Methods related to "HTTP GET" processing

Method Name Function

sysRadioPrepareForHttpGet Prepare to perform HTTP GET for specified URL sysRadioGetHttpGetStatus Report status of sysRadioPrepareForHttpGet

processing

sysRadioGetHttpGetResult Return sysRadioPrepareForHttpGet processing

result as string

sysRadioHttpGetTerminate Perform sysRadioPrepareForHttpGet

housekeeping

Method for getting internal status

Method Name Function

sysRadioGetPlayerStatus Get internal status of player system

Methods for getting playback quality numeric values and playback information strings

Method Name Function

sysRadioGetNetworkBandQuality Get communication circuit band quality

evaluation value sysRadioGetAudioSoundDistortionRa te

Get audio distortion rate (upper and lower limit

saturation frequency of sound) sysRadioGetContentMetaInfo Get content meta information related to audio

data stream being played sysRadioGetBitRate Get bit rate of audio data stream being played sysRadioGetSamplingRate Get sampling rate value of audio data stream

being played

Methods for getting information related to audio data stream being played

Method Name Function

sysRadioGetStreamUrl Get URL of audio data stream being played sysRadioGetStreamTitle Get title information of audio data stream being

played sysRadioGetRelatedPageUrl Get related Web page URL string of audio data

stream being played sysRadioGetStreamIpAddress Get IP address of broadcast server of audio data

stream being played sysRadioGetStreamPort Get connection port number of broadcast server of

audio data stream being played sysRadioGetStreamBufferLevel Get level indicating residual amount of audio data

stream buffer being played

- 23 -

Methods for finding files on the Memory Stick Duo™

Method Name Function

sysRadioPrepareForScanDir Prepare for directory entry scan on the

sysRadioScanDir Scan directory and return file entry (filename)

sysRadioGetMediaInOutStatus Detect whether a Memory Stick Duo™ was

String search processing methods

Method Name Function

sysRadioPrepareForStrOperation Prepare for string search or string extraction

sysRadioStrLength Nearly equivalent to JavaScript standard method

sysRadioStrIndexOf Nearly equivalent to JavaScript standard method

sysRadioStrSlice Nearly equivalent to JavaScript standard method

sysRadioStrCharCodeAt Nearly equivalent to JavaScript standard method

sysRadioStrOperationTerminate Terminate string search processing.

Memory Stick Duo™

that was found first.

For the second and subsequent calls, return the

file entry (filename) that was found next.

inserted or removed following previous

sysRadioPrepareForScanDir

processing

"length."

Returns string length as value in terms of bytes.

"indexOf."

Searches for string pattern.

"slice."

Extracts substring.

"charCodeAt."

Returns character code of specific position in

string.

String conversion processing methods

Method Name Function

sysRadioCharacterEntityConvert Convert characters that contain a character entity

name to an actual character sysRadioCharacterCodeConvert Convert UTF-8 string to SJIS or EUC-KR string.

Methods for getting analog pad values

Method Name Function

sysRadioGetAnalogStickXValue Get analog stick's X value sysRadioGetAnalogStickYValue Get analog stick's Y value sysRadioGetAnalogStickAngleValue Get analog stick's angle value sysRadioGetAnalogStickRadiusValue Get analog stick's radius value

- 24 -

Methods related to debug log console

Method Name Function

sysRadioSetDebugMode Set debug mode sysRadioDebugLog Display string on debug log console sysRadioSetDebugLogTextStyle Set debug log console's text style (typeface,

sysRadioClearDebugLog Clear strings displayed on debug log console

Miscellaneous

Method Name Function

sysRadioGetPlayerCoreVersionInfo Get Internet radio player system core version

sysRadioCapabilityCheck Get support information related to a specific

sysRadioGetStartButtonToggleStatus Get PSP™ system's START button toggle status sysRadioBackLightAlwaysOn Control backlight's always on state when powered

sysRadioBusyIndicator Control busy indicator display at bottom left of

sysRadioCaptureScreenShot Capture screenshot sysRadioSleep Set PSP™ system sleep mode sysRadioGetSystemStatus Inquire about internal status of PSP™ system.

character color, background color, existence of

shadow, character align attribute)

information

function

by external power supply

screen

- 25 -

JavaScript Extended Method Reference Details

Descriptions of the individual extended JavaScript methods for the PSP™ Internet radio

player are presented below.

The description of each method contains a simple sample program that runs independently.

Programs that are almost identical to these sample programs are also provided on SCE's Web

server.

You can access this page and run these programs by using the special Internet radio player

icon sysRadio_method_sample.prs, which is included in the SDK that contains this document.

This icon was created to allow you to run the sample code.

- 26 -

sysRadioPlayStream

Start playback by specifying URL of audio data stream

Syntax

result = psp.sysRadioPlayStream (url, userAgentName)

Arguments

url userAgentName

URL of playlist User agent name used when performing HTTP GET for getting playlist information

Return Value

-1

Description

This extended method connects to the broadcast server specified by url to play audio.

The user agent name specification argument is used for controlling the behavior of the

broadcast server.

If there is no free space in the JavaScript extended method processing queue, -1 is returned.

At this time, the processing request is ignored (discarded). As long as method calls of types

that are queued are not continuously issued (such as in an endless loop), this state does not

normally occur.

The following methods are types that are queued.

Method Names of Types That are Queued

sysRadioPlayStream Starts playback by specifying URL of audio data stream sysRadioPlayPls Starts playback by specifying URL of PLS file sysRadioPlayM3u Starts playback by specifying URL of M3U file sysRadioPrepareForHttpGet Prepares for performing HTTP GET for specified URL sysRadioCaptureScreenShot Captures screenshot

Normal Error

Overview

- 27 -

Example

HINT

If the broadcast server is accessed by the Internet browser using an ordinary user

agent name such as "Mozilla/4.0 (PSP (PlayStation Portable); 2.00)," the audio data

stream may not be able to be received. When the broadcast server is accessed from the

Internet browser in this manner, it may just output a Web page for management.

var result = psp.sysRadioPlayStream ("http://radio.psp.dl.playstation.net:80" +"/psp/radio/sample/pseudo_stream/teststream_a.stream.mp3", "pspRadioPlayer");

This statement accesses the broadcast server "http://radio.psp.dl.playstation.net:80/psp/radio/sample/pseudo_stream/teststream_a.strea m.mp3" to play audio.

Sample

<title>sysRadioPlayStream</title>

</head>

<body>

<h1>sysRadioPlayStream</h1>

<!--

window.onload = function () { setTimeout ('initProc ()', 500); }

function initProc () {

psp.sysRadioSetMasterVolume (255);

}

function test () {

psp.sysRadioPlayStream

("http://radio.psp.dl.playstation.net:80"

+"/psp/radio/sample/pseudo_stream/teststream_a.stream.mp3",

"pspRadioPlayer");

psp.sysRadioSetSubVolume (255);

- 28 -

}

// -->

</script>

</body></html>

Note) The URL in the sample code accesses a "pseudo broadcast server" that was created

to run this sample code.

Since it is not a genuine SHOUTcast or icecast2 broadcast server, its behavior will differ

from an actual server in that playback always begins from the same timecode position

immediately after connection, for example.

sysRadioPlayPls

Syntax

result = psp.sysRadioPlayPls (url, userAgentName0, userAgentName1)

Arguments

url userAgentName0

userAgentName1

URL of playlist User agent name used when performing HTTP GET for getting playlist information User agent name used when connecting to broadcast server

Start playback by specifying URL of playlist

Return Value

-1

Description

This extended method connects to the HTTP server specified by url to get playlist

information and connects to the broadcast server described in this playlist information to

play audio.

The two user agent name specification arguments are used to control the behavior of the

HTTP server and broadcast server.

A playlist that is handled by a PSP™ internet radio has the following format.

[playlist] numberofentries=2 File1=http://radio.psp.dl.playstation.net/psp/radio/sample/pseudo_stream/teststream_a.stream.mp3 Title1=(#1 - 1/100) PSP Internet Radio Test Audio Stream [RADIO PSP] Length1=-1 Browser1= File2=http://radio.psp.dl.playstation.net/psp/radio/sample/pseudo_stream/teststream_b.stream.mp3 Title2=(#2 - 1/100) PSP Internet Radio Test Audio Stream [RADIO PSP] Length2=-1 Browser2= Version=2

Normal Error

If there is no free space in the JavaScript extended method processing queue, -1 is returned.

- 30 -

+ 192 hidden pages

Sony PSP User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1 About This Document

Overview

Who Should Read This Document?

What Specifically gets Created when an Internet Radio Player is Developed?

Related Documents

2 PSP™ Internet Radio Structure and Operation

PSP™ Internal

PSP™ External

3 Creating the Internet Radio Player

List of JavaScript Extended Methods

JavaScript Extended Method Reference Details

sysRadioPlayStream

sysRadioPlayPls
