Hardware Guide
PCV-RS series (PCV-2226)
N
Read this first
Hardware Guide
nN
1
Read this first
Notice
© 2003 Sony Corporation. All rights reserved.
This manual and the software described herein, in whole or in part, may not be reproduced, translated, or reduced to any machinereadable form without prior written approval.
Sony Corporation provides no warranty with regard to this manual, the software, or other information contained herein and hereby
expressl y disc laims any implied warranties or merchantability or fitness for any particular purpose with regard to this manual, the
software or such other information. In no event shall Sony Corporation be liable for any incidental, consequential, or special dam ages,
whether based on tort, contract, or otherwise, arising out of or in connection with this manual, the software, or other information
contained herein or the use thereof.
Macrovision: This product incorporates copyright protection technology that is protected by U.S.patents and other intellectual property
rights. Use of this copyright protection technology must be authorised by Macrovision, and is intended for home and other limited
viewing uses only unless otherwise authorised by Macrovision. Reverse engineering or disassembly is prohibited.
In the manual, the ™ or ® marks are not specified.
Sony Corporation reserves the right to make any modification to this manual or the information contained herein at any t ime without
notice. The software described herein is governed by the terms of a separate user licence agreement.
Please note that the illustrations in this manual may not necessarily apply to your model. Please
see the Specifications sheet for the specific configuration of your VAIO.
Read this first
Hardware Guide
nN
2
ENERGY STAR
As a n ENERGY STAR Partner, Sony has determined that this product meets the ENERGY STAR guidelines for energy efficiency. The
Internati onal ENERGY STAR Office Equipment Program is an international program that promotes energy saving through the use of
computers and their office equipment. The program backs the development and dissemination of products with functions that
effectively reduce energy consumption. It is an open system in which business proprietors can participate voluntarily. The targeted
products are office equipment such as computers, displays, printers, facsimiles and copiers. Their standards and logos are uniform
among participating nations.
ENERGY STAR is a U.S. registered mark.
Environmental information
Halogenated flame retardant not used in cabinets.
Cushions formed by corrugated board used in packaging.
Owner's record
The serial number and model number are located on the back of your Sony desktop. Record the numbers
and refer to them if you call VAIO-Link. See also the printed Specifications document.
Read this first
nN
3
Safety information
General
Hardware Guide
❑ Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the
instructio ns.
❑ Opening the unit, for whatever reason, could lead to damages that are not covered by the guarantee.
❑ To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.
❑ To prevent fire or shock hazard, do not expose your VAIO desktop to rain or moisture.
❑ If reporting a gas leak, do not use the modem or a telephone in the vicinity of the leak.
❑ Avoid using the modem during a severe electrical storm.
❑ The power socket outlet you are using must be installed near the equipment and must be easily
accessible.
❑ Do not move your computer while the system is in Standby mode.
❑ The magnetic properties of some objects can have serious consequences for your hard disk drive. They
can erase the data on the hard disk drive and cause the computer to malfunction. Do not place your
computer near or on any objects, which emit magnetic fields, mainly:
❑ TV sets
❑ Speakers
❑ Magnets and magnetic bracelets.
Audio/video
Audio and picture distortion may occur if this equipment is positioned in close proximity to any equipment
emitting electromagnetic radiation.
Read this first
Hardware Guide
nN
4
Connectivity
❑ Never install modem or telephone wiring during a severe lightning storm.
❑ Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.
❑ Take care when installing or modifying telephone lines.
❑ To disconnect your VAIO desktop completely from the mains voltage, unplug the power cable.
❑ Make sure that the socket outlet is easily accessible.
Regulatory information
Sony hereby declares that this product is in compliance with the essential requirements and other relevant provisions of European
Directive 1999/5/EC (radio equipment and telecommunications terminal equipment Directive).
Declaration of Conformity
The European Union is targeting the free movement of goods for the internal market and to prevent technical barriers to trade. Thi s
effort has result ed in several EU Directives asking that manufacturers make their product s comply with essential standards.
Manufacturers are required to affix the "CE" mark on the products they sell and to draw up a "Declaration of Conformity" (DoC).
Primarily, the Declarations of Conformity are intended for the mar ket surveillance autho riti es as proof that product s satisfy the requi red
standards. Additionally, Sony provides these EU DoC's on the website http://www.compliance.sony.de as a service to our customers.
You can search for all Declarations of Conformity available for a specific product by typing in the model name in the search box. A list
of matc hing documents will be displayed and can be downloaded. Please note that the availability of declarations depends on the scope
of the EU Directives and the individual product specifications.
This product complies with EN 55022 Class B and EN 55024 for use in the following areas: residential, commercial, and light industrial.
This product has been tested and found compliant with the limits set out in the EMC Directive for using connection cables not longer
than 3 metres (9.8 feet).
Before activating the built-in modem, please read the Modem Regulations leaflet.
Read this first
Hardware Guide
nN
5
Disposing of the internal memory backup battery
❑ Your Sony VAIO desktop is equipped with an internal back-up memory battery (motherboard battery)
that should not have to be replaced during the lifetime of the product. If you want to replace the
battery, please contact VAIO-Link: http://www.vaio-link.com
❑ Keep away from children.
❑ Dispose of the battery properly at its end-of-life.
❑ In some areas the disposal of non-hazardous batteries in household or business waste may be prohibited.
Please use the public waste collection system.
Welcome
Hardware Guide
nN
6
Welcome
Congratulations on purchasing a Sony VAIO desktop. Sony has combined leading-edge technology in audio,
video, computing and communications to provide you with state-of-the-art personal computing.
Here are the main features you will be able to enjoy:
❑ Exceptional performance.
❑ Dual drives – Enjoy the freedom of two disc drives*.
❑ Sony audio and video quality – The advanced graphics and high-quality external stereo speakers
enable you to take advantage of today’s advanced multimedia applications, games, and entertainment
software.
❑ Multimedia features – Enjoy audio and video CDs and DVDs.
❑ Interconnectivity – Your computer has USB 2.0 and i.LINK functionalities.
❑ Windows XP Home Edition Service Pack 1 - Your system includes the latest consumer operating
system from Microsoft.
❑ Excellent customer support – If you are experiencing any problems with your computer, please check
the VAIO-Link website for a possible solution: www.vaio-link.com .
Before contacting VAIO-Link, please try to solve the problem by reading this guide, your printed Guide
to Troubleshooting and Using the VAIO Recovery and Documentation Disc, or the manuals and
help files for the peripherals or software.
* See the printed Specifications document for information about the drive.
Welcome
Hardware Guide
nN
7
Documentation pack
Your documentation pack contains printed information and user guides to read on your computer. The user
guides are compiled in the VAIO Info Centre on the VAIO Recovery and Documentation Disc.
Printed documentation
The printed part of your documentation pack includes the following:
❑ A Getting Started brochure, where you will find a brief description of the items in your box, and how
to set up your computer;
❑ A Specifications sheet, containing a table of specifications, a list of bundled software and, on the
reverse side, a guide to setting up your VAIO;
❑ A Guide to Troubleshooting / Using the VAIO Recovery and Documentation Disc, where you will
find solutions to common problems, an explanation of the purpose and use of the VAIO disc delivered
with your computer, and VAIO-Link information;
❑ A Dual Language Operating System leaflet (not applicable for all countries);
❑ Yo u r Sony Guarantee conditions;
❑ A Safety Regulations leaflet;
❑ A Modem Regulations leaflet.
Non-printed documentation
The documentation available in the VAIO Info Centre on disc includes the following guides:
❑ The Ha rdwa re Guide (this guide).
❑ The Software Guide, which contains short descriptions of the software features available with VAIO
systems.
Welcome
Hardware Guide
nN
8
Further sources
❑ Consult the Online Help files of the software you are using for detailed information on features and
troubleshooting.
❑ Go to www.club-vaio.com to fin d online tutorials about your favourite VAIO software.
Welcome
Hardware Guide
nN
9
Ergonomic considerations
Whenever possible, try and take into account the following ergonomic considerations when using your new
computer, whether at home or in the office:
Welcome
Hardware Guide
nN
10
❑ Position of the keyboard and mouse – Place the keyboard directly in front of you (1). Keep your
forearms horizontal, with your wrists in a neutral, comfortable position (2) while using the keyboard or
mouse – not at an angle. Let your upper arms hang naturally at your sides. Use the palm rest only briefly,
to relax your wrists when you are not typing. Place the mouse at the same level as the keyboard and use
your whole arm to move it.
❑ Position and viewing angle of the monitor – Set the display at a comfortable viewing distance (3).
Make sure the display screen is at eye level or slightly lower. Use the display’s tilting feature, if available,
to find the best position. You can reduce eye-strain and muscle-fatigue by adjusting the tilt of the display
to the proper position. Remember to adjust the brightness setting of the display. If you are using a CRT
monitor, make sure that the refresh rate is at an optimal level, that is, at least 75Hz.
❑ Furniture and posture – Sit in a chair with good back support (4). Adjust the level of the chair so your
feet are flat on the floor. A footrest may make you more comfortable. Sit in a relaxed, upright posture
and avoid slouching forward or leaning too far backwards.
❑ Lighting – Choose a location where windows and lights do not create glare or reflection on the display.
Use indirect lighting to avoid bright spots reflecting on the display. You can also purchase accessories for
your display that help reduce glare. Proper lighting adds to your comfort and work effectiveness.
❑ Ven til ation – Make sure you leave at least 25 cm of space behind and on the left of the main unit (5).
❑ And finally – Remember to have breaks during sessions with your computer. Excessive use of the
computer may strain muscles or tendons.
Using your VAIO computer
Using your VAIO computer
Once you have read and followed the information in the printed Getting Started guide and
Specifications sheet, you can start using your computer safely and confidently. Read on to get the most
Hardware Guide
out of using your VAIO computer.
❑ Shutting down your computer safely (page 12)
❑ Using the keyboard (page 13)
❑ Using the mouse (page 15)
❑ Using the disc drives (page 17)
❑ Using the floppy disk drive (page 21)
❑ Using the modem (page 22)
❑ Expansion capabilities (page 24)
❑ Using power modes (page 25)
nN
11
Using your VAIO computer
Shutting down your computer safely
It is important that you shut down your computer properly so you do not lose unsaved data.
To shut down your computer, proceed as follows:
Hardware Guide
1 Turn off any peripherals connected to your computer.
2 Click the Start button.
3 Click Turn Off Computer.
The Turn off computer window appears.
4 Click Tu r n Off .
5 Respond to any prompts warning you to save documents or to consider other users and wait for your
computer to turn off automatically.
The power indicator turns off.
✍ See the printed Troubleshooting Guide if you have problems shutting down your computer.
nN
12
Using your VAIO computer
Using the keyboard
Your computer is delivered with a VAIO keyboard. The features are much the same a standard keyboard,
with some additional functions which you may be unfamiliar with.
Hardware Guide
For more information on the standard keys, please go to the Windows Help and Support Center. The
VAIO-Link website (www.vaio-link.com) also contains glossary information to help you use the keyboard.
Key Description
Press this button to enter or resume from Stand by mode.
<Fn> key The <Fn> key is used in combination with 5 other keys to execute certain
PgUp
nN
13
commands.
These keys are used in combination with the <Fn> key to execute the
commands depicted within the box on the key.
<Fn> + <PgUp>: Moves the view to the next page up.
PgDn
Home
End
ScrLk
<Fn> + <PgDn: Moves the view to the next page down.
<Fn> + <Home>: Moves the cursor to the beginning of the line.
<Fn> + <End>: Moves the cursor to the end of the line.
<Fn> + <ScrLk>: Changes the way in which you can scroll the screen,
depending on the application.
Using your VAIO computer
Indicators
Light On Off
Num Lock Turns on w hen the number keys in the numeric
Hardware Guide
Caps Lock Turns on when the letters appear in uppercase as
Scroll Lock Turns on w hen the screen scrolls di fferently (not all
keypad are active.
you type. The <Shift> key lowers the c ase of t yped
letters when Caps Lock is on.
applications support this function).
nN
14
Turns off when the alphanumeric character keys in
the keypad area are active.
Turns off when t he letters appear in lowercase as
you type (unless you hold down the <Shift> key).
Turns off when t he information moves across the
display normally.
Using your VAIO computer
Using the mouse
The VAIO wheel mouse allows you to control the cursor in a number of ways. You can point to, select, drag,
and scroll objects on the screen using the buttons and the wheel.
Hardware Guide
The mouse has the following functions:
nN
15
Function Action
point Move the entire mouse across a flat surface to place
the pointer on an item or object.
click Press the left button (1) once.
double-click Press the left button twice.
right-click Press the right button (2) once. In many applicati ons,
this action displays a context-sensitive shortcut
menu.
drag and drop Hold the left button down while sliding the mouse.
Then release the button to drop the object.
scroll Turn the central wheel (3) to scroll up or down a
page. Or press the wheel once to lock the scroll
action and control the movement by moving the
entire mouse (the scroll function is available only
with applications that support a scroll feature).
You can adjust the mouse pointer speed and other functions under Mouse Properties. To displa y Mouse
Properties, go to the Control Panel, select Printers and Other Hardware, then select Mouse.
Using your VAIO computer
Setting up the mouse for left-handed users
To set your mouse up for left-handed users, proceed as follows:
1 Go to Start, select Control Panel, then click the Printers and Other Hardware option.
Hardware Guide
2 Click the mouse icon.
The Mouse Properties dialog box appears.
3 In the Buttons tab, select the option button next to Switch primary and secondary buttons.
4 Click OK.
The new mouse settings are now in place.
nN
16
Using your VAIO computer
Using the disc drives
Your computer is equipped with two separate optical drives.
nN
17
Hardware Guide
❑ The DVD±RW drive reads data from and writes data onto DVD and CD.
❑ The DVD-ROM drive reads data from DVDs and CDs.
To insert a disc, proceed as follows:
1 Turn on the computer.
2 Press the appropriate eject button to open the drive.
The cover flap opens and the tray slides out.
3 Place a disc in the tray with the label side facing upwards.
Make sure the disc is secure in the centre of the tray.
4 Close the tray by pushing it gently.
✍ See the printed Troubleshooting Guide if you have problems using discs.
Using your VAIO computer
Reading and writing CDs and DVDs
To achieve optimum performance when writing data on to disc (also called ’burning’), follow these
recommendations:
Hardware Guide
❑ Only use circular discs. Do not use discs with any other shape (star, heart, card, etc.), as this may damage
the disc drive.
❑ Do not strike or shake the computer while writing data to a disc.
❑ For optimum writing speed, deactivate the screensaver before writing data to a disc.
❑ Memory-resident disc utilities may cause unstable operation or data loss. Deactivate these utilities before
writing data to a disc.
❑ When using a software application to burn discs, make sure you exit and close all other applications.
❑ Never touch the surface of the disc. Fingerprints and dust on the surface of a disc may cause writing
errors.
❑ Never put stickers on discs. This will affect the use of the disc irreparably.
nN
18
Using your VAIO computer
Playing DVDs
To achieve optimum performance when playing DVDs, you should follow these recommendations:
❑ Close all open applications before playing a DVD movie.
Hardware Guide
❑ You can play DVDs in both drives with the software PowerDVD for VAIO.
❑ Do not switch power saving modes while playing a DVD.
❑ Do not use built- in utility applications to speed up the access of discs, because they may cause the system
to become unstable.
❑ Make sure that the screensaver is deactivated.
❑ Region codes indicators are labelled on the DVDs to indicate in which region and on what type of player
you can play the disc. Unless a '2' (Europe belongs to region '2') or 'all' (this means that you can play this
DVD everywhere in the world) is labelled on your DVD disc or on the packaging, you cannot play the disc
on this player.
❑ Do not try to change the region code settings of the DVD drive. Any difficulties caused by changing the
region code settings of the DVD drive are out of warranty.
nN
19
Using your VAIO computer
Using two screens while watching a DVD film
By connecting a TV to your computer, you can watch a DVD film while still working on your desktop as
normal.
nN
20
Hardware Guide
To use the two screens and change the DVD playback settings, proceed as follows:
1 Connect your TV to the computer as described in Connecting a TV (page 31).
2 Go to Control Panel.
3 Click Appearance and Themes and then Display.
The Display Properties dialog box appears.
4 Click the Settings tab.
5 Click Advanced.
The ... NVIDIA GeForce FX... dialog box appears.
6 Click nView Display Mode on the left.
7 Select the Clone check box.
8 Click Overlay Controls on the left.
9 Make your required settings here and click OK when you have finished.
Using your VAIO computer
Using the floppy disk drive
Your VAIO desktop is equipped with a floppy disk drive.
nN
21
Hardware Guide
Inserting a floppy disk
To insert a floppy disk, proceed as follows:
1 Hold the floppy disk with the label side facing up.
2 Gently push the disk into the floppy disk drive until it clicks into place.
Removing a floppy disk
To remove a floppy disk, proceed as follows:
1 Wait until the LED indicator turns off.
2 Press the eject button and pull the disk out gently.
✍ Do not press the eject button when the LED indicator is turned on. Otherwise, data may be lost.
Using your VAIO computer
Using the modem
Your VAIO desktop is equipped with an internal modem. As described in the printed Getting Started
guide, use the single RJ-11 jack to connect the supplied modem cable to the phone line. Once you have
Hardware Guide
connected the phone line and registered with an Internet Service Provider, you can take advantage of online
services and the Internet, to register your computer and software online, and to contact VAIO-Link.
Troubleshooting the modem
My modem does not work or cannot establish a connection
❑ Check that the phone line is plugged into your computer.
❑ Make sure that the modem is the only device connected to your phone line.
❑ Check that the phone line is working. You can check the line by plugging in an ordinary phone and
listening for a dial tone.
❑ Check that the phone number the program is dialling is correct. The modem dialling mode may be
incompatible with your telephone line.
❑ The modem may not work properly if you are with a Private Automatic Branch eXchange (PABX).
❑ In the Phone and Modem Options dialog box (Control Panel / Phone and Modem Options), check
that your modem is listed in the Modems tab, and that the location information is correct on the
Dialing Rules tab.
If you do not see the Phone and Modem Options icon, click Switch to Classic View on the left side.
❑ For users in UK: A country-specific phone plug is supplied with your VAIO desktop, allowing you to plug
the phone line into the wall jack. We recommend you to use the supplied plug, because the usage of any
other phone plug can decrease the connection quality.
nN
22
Using your VAIO computer
❑ Your computer cannot be connected to a coin-operated telephone, and may not work with multiple
phone lines or a private branch exchange (PBX). If you connect the modem to a parallel connected phone
line, the modem or the other connected device may not function properly. Some of these connections
may result in excess electrical current and could cause a malfunction in the internal modem.
Hardware Guide
❑ Only DTMF (Dual Tone Multi Frequency) signalling (tone dialling) is supported.
My modem connection is slow
Many factors influence modem connection speed, including telephone line noise or compatibility with
telephone equipment (such as fax machines or other modems). If you think your modem is not connecting
properly to other PC-based modems, fax machines, or your Internet Service Provider, check the following:
❑ Have your phone company check that your phone line is free from any line noise.
❑ If your problem is fax-related, check that there are no problems with the fax machine you are calling and
that it is compatible with fax modems.
❑ If you are having a problem connecting with your Internet Service Provider, check that the ISP is not
experiencing technical problems.
❑ If you have a second phone line available, try connecting the modem to that line.
nN
23
Using your VAIO computer
Expansion capabilities
There are four expansion slots at the rear of your VAIO computer, as follows:
❑ Top slot: AGP slot containing the graphics card.
Hardware Guide
❑ Empty PCI slot.
❑ Empty PCI slot.
❑ Bottom slot: CNR/PCI slot containing the modem card.
The empty PCI slots allow you the choice of adding to the expansion capabilities of your computer.
You are strongly advised not to add hardware yourself. Please contact your local Sony dealer for advice on
changing the internal hardware components.
nN
24
Using your VAIO computer
Using power modes
The colour of the VAIO and power indicator lights on the main unit tells you which mode the computer is in.
nN
25
Hardware Guide
VAIO light Power indicator Mode
Blue No light Computer is in Normal mode
No ligh t Am ber Com puter is in Stan dby mode
No light No light Computer is turned off or in Hibern ate mode
To set the timer for your computer to automatically enter Standby or Hibernate mode after a certain
amount of time, go to Control Panel, click Performance and Maintenance and change the settings
under Power Op tion s.
Using your VAIO computer
Using Standby mode
If you plan to stop using your computer for a short period of time (not overnight), you can put it into
Standby mode instead of turning it off completely. Putting the computer into Standby mode saves energy
Hardware Guide
and allows a quick return to normal computer use.
To activate Standby mode manually, save your work and use one of these two methods:
Use the Standby button:
❑ Press the Standby button at the top of the keyboard.
The computer goes into Standby mode, indicated by the amber light under the power button.
Use the Windows taskbar:
❑ From the Start menu, select Turn Off Computer then Stand By.
Alternatively, press <Alt>+<F4> to get to the same dialog box.
The computer goes into Standby mode, indicated by the amber light under the power button.
To return to Normal mode, choose from the following:
❑ Press any key on the keyboard.
❑ Press the Standby button again.
✍ You can leave Windows running when using Standby.
When the computer is in Standby mode, you cannot insert a disc.
The computer comes out of Standby mode quicker than out of Hibernate mode and uses more power.
nN
26
Using your VAIO computer
Using Hibernate mode
If you are interrupted and need to leave your computer suddenly, you can put it into Hibernate mode. This
power saving mode saves you the time of shutting down in the normal way.
Hardware Guide
When you put your computer into Hibernate mode:
❑ Everything in the memory is saved to the hard disk.
❑ The monitor and system are turned off.
❑ The computer is turned off.
❑ The power indicator light turns off.
To activate Hibernate mode manually, proceed as follows:
1 Save your work.
2 From the Start menu on the Windows taskbar, select Turn Off Computer.
Alternatively, press <Alt>+<F4> until the Tur n Off Computer screen is displayed.
3 In the Turn Off Computer screen, hold down the <Shift> key to reveal the Hibernate button.
4 Click Hibernate.
The computer goes into Hibernate mode, the computer turns off.
To retu rn to Normal mode, quickly press the power button.
Operation returns to the same state as before.
✍ You can leave Windows
If you press the power button for more than six seconds, your computer will turn off completely.
When the computer is in Hibernate mode, you cannot insert a disc.
Hibernate uses less power than Standby and requires more time.
running when using Hibernate.
nN
27
Connecting peripheral devices
Connecting peripheral devices
You can add functionality to your computer by using the various ports on your unit.
Hardware Guide
❑ Connecting a display (page 29)
❑ Connecting a Universal Serial Bus (USB) device (page 33)
❑ Connecting a printer (page 34)
❑ Connecting an i.LINK device (page 35)
❑ Connecting an S/PDIF device (page 38)
❑ Connecting a microphone (page 38)
❑ Connecting to a network (page 39)
To identify and locate the ports on your computer, please see the printed Specifications sheet.
❑ Sony computer supplies, accessories and peripherals can be purchased from your local retailer or from
the Sony website: www.sonystyle-europe.com
❑ For more information about connection compatibility, go to the VAIO-Link website: www.vaio-link.com
nN
28
Connecting peripheral devices
Connecting a display
You can connect multiple displays to your desktop, each using a different port on the back of your computer:
❑ an LCD screen using the DVI connector,
Hardware Guide
❑ a CRT or LCD screen using the VGA connector,
❑ a TV using the TV/video out connector.
Please make note of the following viewing possibilities:
❑ If you have a VGA and a DVI display connected at the same time, you can switch from one display to the
other (the default is VGA), but you cannot display the image on both at the same time.
❑ If you have a VGA and a TV connected, the image is shown on both screens by default.
❑ If you have a DVI and a TV connected, the image is shown on both screens by default.
❑ If you have a VGA, a DVI and a TV connected, the image will be shown either on both the VGA and the
TV, or both the DVI and the TV.
To change your display from VGA to DVI or vice versa, proceed as follows:
1 Connect the display(s), as described in the printed Getting Started or in the instructions delivered with
the display, if applicable.
2 Go to Control Panel.
3 Click Appearance and Themes then Display.
The Display Properties dialog box appears.
4 Click the Settings tab.
5 Click Advanced.
The ...NVIDIA GeForce FX… dialog box appears.
6 Click nView Display Mode on the left.
7 Select the Device Settings button.
nN
29
Connecting peripheral devices
8 Click Select Output Device... and select the required display.
9 Click OK.
If you reboot after changing the settings as above, the default setting returns and the image is shown on
Hardware Guide
the VGA screen again. If you want the image to be shown on both the DVI and the TV after rebooting, please
disconnect the VGA.
Similarly, if you have all three displays connected and want the computer to select DVI and TV when you
start your computer, simply make your settings again.
nN
30
Connecting peripheral devices
Connecting a TV
You can connect a TV directly to your computer.
In order to be able to use a TV screen, you also have to enable the TV output function.
Hardware Guide
Your VAIO desktop is delivered with a TV/video out cable (or ’converter cable’), which is for use with TV sets
without an s-video port.
Connecting a TV that has no s-video port
To connect a TV to your VAIO desktop with the supplied TV/video out cable, proceed as follows:
1 Plug one end of the TV/video out cable into the TV/video out port on the back of your computer.
2 Take your composite cable (not supplied) and connect one end to the inserted TV/video out cable.
3 Connect the other end to the yellow-coloured port (video-in) on your TV set.
The video output is now in place.
4 Connect the single end of your audio cable (not supplied) to the headphones port, either on the back of
your computer or on the connected speaker.
5 Connect the double end of the audio cable to the red and white ports respectively on your TV set.
The audio output is now in place and your TV is ready for use with your computer.
nN
31
Connecting peripheral devices
Connecting a TV that has an s-video port
To connect a TV to your VAIO desktop with an s-video cable (not supplied), proceed as follows:
1 Plug one end of the s-video cable into the TV/video out port on the back of your computer.
Hardware Guide
2 Plug the other end of the s-video cable into your TV’s s-video port.
To enable TV output, proceed as follows:
1 Go to Control Panel.
2 Click Appearance and Themes.
3 Click Display.
The Display Properties dialog box appears.
4 Click the Settings tab.
5 Click Advanced.
The ...NVIDIA GeForce FX… dialog box appears.
6 Click nView Display Mode on the left.
7 Select Clone and click Ap ply.
nN
32
Connecting peripheral devices
Connecting a Universal Serial Bus (USB) device
You can connect a USB device such as a scanner, a floppy disk drive or a printer, to your VAIO desktop.
To connect a USB device, simply plug in the USB cable of the device into one of the ports on your computer.
Hardware Guide
There are USB 2.0 ports on the front and back of your system unit.
USB devices are hot plug and play devices. You do not need to shut down your computer prior to connecting
these devices unless the manual supplied with the device states otherwise.
For some USB devices you need to install the software before you connect the device. Not following this
procedure might cause the device not to work properly. For more information, check the manual provided
with the USB device.
nN
33
Connecting peripheral devices
Connecting a printer
To connect a printer, you can use either the printer port or a USB port, depending on the cable you use for
your printer. Please see your printer’s documentation for details on connection and installation.
Hardware Guide
Always check the printer manufacturer’s website for the latest drivers for Windows XP Home Edition Service
Pack 1. Some printers do not function properly without updated drivers.
USB printer drivers should be automatically installed. Once you plug the printer’s USB cable into one of the
USB ports on your computer, the Found New Hardware Wizard will guide you through any setup
procedure you need to follow.
If the printer is not automatically installed, you can try the following:
1 From the Control Panel, select Printers and Other Hardware, then Printers and Faxes.
2 Under Printer Tasks, click Add a printer.
3 Let the Add Printer Wizard guide you through the installation process.
4 Click Finish.
The printer is now installed.
✍ This procedure applies for most, but not for all printers.
Troubleshooting printing
nN
34
If you have problems printing, check the printed Troubleshooting Guide, the documentation delivered
with your printer, and the VAIO-Link website (www.vaio-link.com).
Connecting peripheral devices
Connecting an i.LINK device
Your VAIO computer includes a 4-pin i.LINK port on the front of the system and a 6-pin i.LINK port on the
back of the system. Use these ports to connect an i.LINK device such as an optical disc drive or a digital video
Hardware Guide
camera recorder, or to link up two VAIO computers so you can copy, delete or edit files.
❑ The i.LINK device will need its own power supply.
❑ You are strongly advised to use only Sony i.LINK cables, as using other brands may cause problems with
the i.LINK devices.
❑ The i.LINK connection may vary, depending on the software applications, operating system, and
compatible i.LINK devices. Not all products with an i.LINK connection may communicate with each other.
❑ Please refer to the documentation that came with your compatible i.LINK device and software for
information on operating conditions and proper connection.
nN
35
Connecting peripheral devices
S400
Connecting a digital video camera recorder
To connect a digital video camera recorder, proceed as follows:
1 Plug one end of the i.LINK cable (not supplied) into the i.LINK port of the computer and the other end
Hardware Guide
into the DV out port on your digital video camera recorder.
On Sony digital video cameras, ports marked DV out, DV in/out or i.LINK are i.LINK-compatible.
S400
nN
36
2 Launch the DVgate application (see the Software Guide in the VAIO Info Centre for more
information).
✍ The Sony digital video camera recorder is an example; your digital video camera recorder may need to be connected differently.
If the connected i.LINK device is not recognised, disconn ect the i.LINK device, then connect it again.
Connecting peripheral devices
Troubleshooting i.LINK devices
I cannot establish an i.LINK connection between two VAIO computers
nN
37
Hardware Guide
❑ You must have administrator rights on your computer to be able to link the two.
❑ Disconnect then reconnect the i.LINK cable.
❑ If you still have no connection after waiting for a while, restart both computers.
❑ If either computer has just returned from a power saving mode, the connection may be affected. In this
case, make sure you perform a full restart before connecting them.
❑ Check that both units are in the same workgroup, and that the Sharing option is enabled.
When I record images to a digital video device using DVgate, I see an error message
Close all open applications and restart your computer. Frequently recording images to a digital video device
while using DVgate sometimes causes this error.
I cannot use digital devices
❑ Check that the DV device is turned on and that the cables are properly connected.
❑ If you are using multiple i.LINK devices, the combination of the connected devices may cause unstable
operation. If this is the case, turn off all connected devices and disconnect unused devices. Check the
connection and then turn on the power again.
❑ You are strongly advised to use only Sony i.LINK cables, as using other brands may cause problems with
the i.LINK devices.
Connecting peripheral devices
Connecting an S/PDIF device
The S/PDIF (Sony/Philips Digital Interface) port on your computer allows you to transfer audio files to optical
devices. The advantage is that is does not use the conversion to and from an analog format, which could
Hardware Guide
degrade the signal quality.
Please read the documentation provided with your optical device for connection information.
Connecting a microphone
Your VAIO desktop does not contain an internal microphone. If you need to use a sound input device, for
example to chat on the Internet, you need to plug in an external microphone.
To connect an external microphone, plug the microphone cable (1) into the microphone connector (2)
identified by the symbol .
nN
38
✍ Make sure your microphone is designed for computer use.
Connecting peripheral devices
Connecting to a network
Your computer comes with a built-in Ethernet interface.
To connect to a network, proceed as follows:
Hardware Guide
1 Connect your 10BASE-T/100BASE-TX Ethernet cable (not supplied) to the Ethernet port on the back of
the computer.
If there is a sticker covering the Ethernet port, this is to remind customers in Germany not to insert an
ISDN cable (see caution below).
nN
39
Connecting peripheral devices
2 Go to Start, right-click My Computer and select Properties.
3 Click the Hardware tab and select Device Manager.
The Device Manager screen appears with the list of devices.
4 Under Network Adapters, right-click the name of the adapter.
Hardware Guide
5 Click Properties.
6 Under Device Usage, select Use this device (enable).
7 Click OK to close the Properties window.
The Ethernet connection is now enabled.
! Connect only 10BASE-T/100BASE-TX cables to the Ethernet port. Using other cables o r a telephone cable may cause a malfunction, excessive heat
or even fire in the port. If using this computer in Germany, please make sure you do not use an ISDN cable. It is physically very similar, but its higher
voltage of 12V may destroy the motherboard inside the computer.
✍ For more information about connecting your VAIO desktop to the network, please consult the hardware troubleshooting section of the VAIO-Link
website (www.vaio-link.com
For help on connecting to a network, see your network administrator if you have one.
This illustration may not correspond to the configuration of your model. Please check the section Back Panel of your printed Specifications sheet
to see where the ports are exactly.
nN
40
):
Upgrading your VAIO computer
Upgrading your VAIO computer
Sony recommends contacting your local dealer for upgrade or maintenance of your new computer. Your
local dealer has knowledge of this specialised personal computer and familiar with the safety practices and
Hardware Guide
regulatory compliance required for using and modifying electronic equipment.
The upgrading procedures described in this section assume that you are familiar with the general
terminology associated with personal computers and with the safety practices and regulatory compliance
required for using and modifying electronic equipment.
Disconnect the computer from its power source and from telecommunication links, networks, or modems
before you open the unit or follow any procedures described in this section.
Your computer may not be equipped with all of the hardware features mentioned in this section. The
interior configuration of your system may vary from the illustrations, depending on the computer
purchased.
To view the hardware configuration for your computer, see the printed Specifications sheet.
Your VAIO desktop and memory modules use high precision components and electronic connector
technology. To avoid the invalidation of your guarantee by mishandling, it is recommended that:
❑ You contact your local Sony dealer to install any new internal hardware components.
❑ You do not install memory modules yourself, if you are not familiar with upgrading memory on a
computer.
❑ Please contact VAIO-Link if you need assistance.
! Failure to disconnect your computer from its power source may result in personal injury or equipment dam age.
! Electrostatic discharg e (ESD) can damage disk drives, add-on cards, and other components. Follow the procedures h ere on ly at an ESD workstation.
Otherwise, do not work on a carpeted area and do not handle materials that produce or hold static electricity, such as cellophane wrappers. Ground
yourself by keeping constant contact with an unpainted metal part of the unit while carrying out any of these procedures.
nN
41
Upgrading your VAIO computer
Opening the unit
To remove the cover from the main unit, proceed as follows:
1 Shut down your computer and disconnect all peripheral devices, such as your printer.
Hardware Guide
2 Unplug the computer from the mains.
3 Wait until the computer cools down.
The inside of the main unit becomes very hot during operation. Wait for about one hour for the
computer to cool down before opening the unit.
4 Position the main unit so the back panel is facing you.
5 Unscrew the cover release screws located on the edges of the back panel, and set them aside.
The cover is released.
nN
42
6 Slide the cover towards the back of the unit to remove it.
Upgrading your VAIO computer
Upgrading memory
In the future, you may want to upgrade the memory installed on your VAIO by replacing / adding memory
modules. However, we recommend that you do not install them yourself unless you are familiar with
Hardware Guide
upgrading memory on a computer.
For memory upgrades, use only those modules mentioned in the printed Specifications table.
Be careful when adding memory yourself. Mistakes on installation or removal of the memory module may
cause a malfunction.
Electrostatic discharge can damage electronic components. Before touching a memory expansion board,
remember the following:
❑ Handle the memory module gently.
❑ The procedures described in this document assume familiarity with the general terminology associated
with personal computers and with the safety practices and regulatory compliance required for using and
modifying electronic equipment.
❑ Disconnect the system from its power source and from any telecommunication links, networks, or
modems before you open the system. Failure to do so may result in personal injury or equipment
damage.
❑ Do not open the memory module package until you are ready to install the module. The package
protects the module from ESD.
❑ Use the special bag delivered with the memory module, or wrap the module in aluminium foil to protect
it from electrostatic discharge.
✍ Do not pl ace the memory m odule in places s ubject to: Heat s ources s uch as radiators o r air ducts, d irect sunlight, excessive dust, mechanical vibration
or shock, strong magnets or speakers that are not magnetically shielded, ambient temperature of more than +35°C or less than +5°C , or high
humidity.
! Introducing any liquids or any foreign substances or objects into the memory slots, or other internal components of the computer, wi ll re sult in damag e
to the computer and any repairs will be out of warranty.
nN
43
Upgrading your VAIO computer
Adding / replacing a memory module
If you are not familiar with upgrading memory on a computer, we highly recommend that you contact your
dealer.
nN
44
Hardware Guide
To add or change a memory module, proceed as follows:
1 Shut down the computer, unplug it, and remove any peripheral devices.
2 Wait for the computer to cool down, then open the unit as described in Opening the unit (page 42).
3 Gently place the unit on its side.
4 To remove an existing memory module, release the end latches and gently lift out the module, as shown
(may vary from actual configuration).
Upgrading your VAIO computer
5 To insert a new memory module, remove it from its anti-static package, handling it only by the edges.
6 Locate the notch on the bottom edge of the memory module.
7 Align the memory module over the slot, making sure the module is facing the correct way.
Hardware Guide
8 Press evenly against the memory module's upper corners. The end latches snap into position
automatically.
9 Reinstall any add-on cards or components you removed.
10 Replace the cover as described in Closing the unit (page 46).
✍ There is only one correct way to insert the memory module. Make sure the rivet of the module is lined up with the connector.
! Use only the memory modules specified on the printed Specifications sheet.
! To avoid damaging a memory module or the memory module slot, move the side latches slightly outward to relieve pressure. The
module is properly inserted when the side latches click into place.
Viewing the amount of memory
To view the amount of memory, proceed as follows:
1 Turn on the computer.
2 Click the Start button, point to All Programs, then VAIO System Information, and click VAIO
System Information again.
You can view the amount of installed memory here.
nN
45
Upgrading your VAIO computer
Closing the unit
To replace the cover, proceed as follows:
1 Align the cover to the frame of the unit.
Hardware Guide
2 Slide the side cover firmly over the unit, sliding it forward until the cover snaps into place.
3 Replace the release screws.
nN
46
Getting help
Hardware Guide
nN
47
Getting help
This section describes how to get help and support if something goes wrong with your computer.
Sony offers you many support options for your computer.
Sony documentation
Please see the section Documentation pack (page 7) for details on the printed and online documentation
delivered with your computer, as well as further sources of reference.
Other sources of information
❑ Go to the online help files that accompany your software for instructions on using the software.
❑ VAIO-Link web site: If you have any problems with your computer, you can access the VAIO-Link website
for troubleshooting. Go to: www.vaio-link.com
❑ e-Support: This interactive part of our website www.vaio-link.com allows you to get in contact with our
dedicated support team over the internet. Using a personalised account, you can log your technical
queries with ease.
❑ VAIO-Link help lines: Before contacting VAIO-Link by telephone, try to solve the problem by reading
the online and printed documentation.
❑ Visit the other Sony websites:
❑ www.club-vaio.com if you want to know more about VAIO and become part of the growing VAIO
community.
❑ www.sonystyle-europe.com for online purchases.
❑ www.sony.com for other Sony products.
✍ You need to set up an Internet connection before you can access the online features described here.
Getting help
nN
48
e-Support
What is e-Support?
Hardware Guide
You have searched our user guides and website (www.vaio-link.com) but have not found an answer to your
question/issue? e-Support is the ideal solution for you!
Our e-Support Web Portal is an interactive website on which you can submit any technical query you may
have regarding your VAIO and receive answers from our dedicated support team.
Every submitted query will result in a unique 'case number' to ensure smooth communication between
yourself and the e-Support Team.
Who can use e-Support?
All registered VAIO customers are entitled to unlimited access to the VAIO-Link e-Support Web Portal.
How can I access the e-Support portal?
When you register your VAIO computer online at Club-VAIO (www.club-vaio.com), you will automatically
receive an email with the link to the e-Support Web Portal, your Customer ID and some basic explanation a
few hours later.
All you need to do is activate your account by clicking on the provided link in the email.
You are now ready to create your first case!
You can access the e-Support Web Portal from any computer with an active Internet connection.
A complete help file is available on the e-Support Web Portal to help you use our e-Support Service.
Getting help
nN
49
Can I submit questions in my native language?
Since you are interacting with our e-Support Team through a portal, which connects you directly to our
central database, e-Support will only accept and deal with queries submitted in English.
Hardware Guide
Can I submit my questions at any time?
Yes, you can submit your questions 24/7, but please keep in mind that our e-Support Team can only treat
your queries from Monday till Friday between 8am and 6pm.
Is there a cost involved for using e-Support?
No, this is a complete free of charge service offered to all registered VAIO customers!
How do I know when the e-Support Team has handled my query/case?
As soon as your case has been dealt with by our e-Support Team, you will receive an email, notifying you
that your case has been updated.
Precautions
Hardware Guide
nN
50
Precautions
This section describes safety guidelines and precautions to help you protect your computer from potential
damage.
Please contact VAIO-Link if you need assistance.
❑ On handling the hard disk (page 51)
❑ On using the power source (page 52)
❑ On handling your computer (page 53)
❑ On handling LCD screens (page 54)
❑ On handling floppy disks (pa ge 55)
❑ On handling compact discs (page 55)
Precautions
Hardware Guide
nN
51
On handling the hard disk
The hard disk has a high storage density and reads or writes data in a short time. However, it can be easily
damaged by mechanical vibration, shock or dust.
Although the hard disk has the internal safety device to prevent losing data due to mechanical vibration,
shock or dust, you should be careful when handling your computer.
To avoid damaging your hard disk:
❑ Do not subject your computer to sudden movements.
❑ Keep the computer away from magnets.
❑ Do not place your computer in a location subject to mechanical vibration or in an unstable position.
❑ Do not move your computer while the power is on.
❑ Do not turn off the power or restart the computer while reading or writing data to disk.
❑ Do not use your computer in a place subject to extreme changes in temperature.
✍ If the hard disk is damaged, th e data cannot be restored.
Precautions
Hardware Guide
nN
52
On using the power source
❑ See the printed Specifications sheet to check the power operation of your VAIO.
❑ Do not share the AC outlet with other high power-consuming equipment, such as a photocopier or
shredder.
❑ You can purchase a power strip with a surge protector. This device prevents damage to your computer
caused by sudden power surges, in an electrical storm, for example.
❑ Do not place heavy objects on the power cord.
❑ To disconnect the cord, pull it out by the plug. Never pull the cord itself.
❑ Unplug your computer from the wall outlet if you are planning to not use the computer for a long time.
❑ Make sure that the socket outlet is easily accessible.
Precautions
Hardware Guide
nN
53
On handling your computer
❑ Clean the unit with a soft cloth, which is either dry or lightly moistened with a mild detergent solution.
Do not use any type of abrasive pad, scouring powder, or solvent such as alcohol or benzine, as these
may damage the finish of your computer.
❑ Should you drop a solid object or any liquid onto the computer, shut down your computer and then
unplug it. You may want to have the computer checked by qualified personnel before operating it again.
❑ Do not drop the computer or place heavy objects on top of the computer.
❑ Do not place your computer in a location subject to:
❑ Heat sources, such as radiators or air ducts
❑ Direct sunlight
❑ Excessive dust
❑ Moisture or rain
❑ Mechanical vibration or shock
❑ Strong magnets or speakers that are not magnetically shielded
❑ An ambient temperature of more than 35ºC or less than 5ºC
❑ High humidity.
❑ Do not place electronic equipment near your computer. The electromagnetic field of your computer may
cause a malfunction.
❑ Provide adequate air circulation to prevent internal heat from building up. Do not place your computer
on porous surfaces such as rugs or blankets, or near material such as curtains or draperies that may block
its ventilation slots.
❑ The computer uses high-frequency radio signals and may cause interference to radio or TV reception.
Should this occur, relocate the computer a suitable distance away from the set.
❑ Use only specified peripheral equipment and interface cables; otherwise, problems may occur.
Precautions
Hardware Guide
nN
54
❑ Do not use cut or damaged connection cables.
❑ If the computer is brought directly from a cold location to a warm one, moisture may condense inside
your computer. In this case, allow at least one hour before turning on your computer. If any problems
occur, unplug your computer and contact VAIO-Link.
❑ Make sure you disconnect the power cord before cleaning the computer.
❑ As you may lose important data once your computer is damaged, you should back up your data regularly.
You can restore most of the original application programs from the supplied disc (read the Guide to
Troubleshooting and Using the VAIO Recovery and Documentation Disc for details).
On handling LCD screens
❑ Do not leave the LCD facing the sun as it can damage the LCD. Be careful when using the computer near
a window.
❑ Do not scratch the LCD or exert pressure on it. This could cause malfunction.
❑ Using the computer in low temperature conditions may produce a residual image on the screen. This is
not a malfunction. When the computer returns to normal temperature, the screen returns to normal.
❑ A residual image may appear on the screen if the same image is displayed for a lengthy period of time.
The residual image disappears in a while. You can use a screensaver to prevent residual images.
❑ The screen becomes warm during operation. This is normal and does not indicate a malfunction.
❑ The LCD is manufactured using high-precision technology. You may, however, see tiny black points and/
or bright points (red, blue, or green) that continuously appear on the LCD. This is a normal result of the
manufacturing process and does not indicate a malfunction.
❑ Avoid rubbing the LCD screen, as this can damage the screen. Use a soft, dry cloth to wipe the LCD screen.
Precautions
Hardware Guide
nN
55
On handling floppy disks
❑ Do not open the shutter manually or touch the surface of the floppy disk.
❑ Keep floppy disks away from magnets.
❑ Keep floppy disks away from direct sunlight and other sources of heat.
On handling compact discs
❑ Do not touch the surface of the disc.
❑ Do not drop or bend the disc.
❑ Fingerprints and dust on the surface of a disc may cause reading errors. Always hold the disc by its edge
and central hole, as shown.
❑ Proper care of the disc is essential to its continuous reliability. Do not use solvents such as benzene,
thinning agents, commercially available cleaners or anti-static spray, as they may cause damage to the
disc.
❑ For normal cleaning, hold the disc by its edge and use a soft cloth to wipe the surface from the centre
out.
❑ If the disc is badly soiled, moisten a soft cloth with water, wring it out well, and use it to wipe the surface
of the disc from the centre out. Wipe off any remaining moisture with a dry soft cloth.
❑ Never put stickers on discs. This will affect the use of the disc irreparably.
Precautions
Hardware Guide
nN
56
Trademarks
Sony, BlueSpace NE, DVgate, Giga Pocket, HotKey Utility, Memory Stick Formatter, PicoPlayer, PictureGear Studio,
Network Smart Capture, SonicStage, Sony Notebook Setup, Sony Style Imaging, UI Design Selector, VAIO Action Setup,
VAIO Edit Components, VAIO Media, VAIO System Information, VAIO Web Phone, Memory Stick, the Memory Stick logo, VAIO and the
VAIO logo are trademarks of Sony Corporation.
Microsoft, Internet Explorer, Windows Movie Maker, Windows Media Player, Windows XP Professional, Windows Home Edition and the
Windows logo are trademarks or registered trademarks of Microsoft Corporation in the U.S. and other countries.
i.LINK is a trademark of Sony used only to designate that a product contains an IEEE1394 connection.
Adobe, Adobe Acrobat Reader, Adobe Premiere LE and Adobe Photoshop Elements are trademarks of Adobe Systems Incorporated.
QuickTime and the QuickTime logo are trademarks used under licence. QuickTime is registered in the U.S. and other countries.
RealOne Player is a trademark or registered trademark of RealNetworks, Inc. in the U.S. and other countries.
PowerPanel is a trademark of Phoenix Technologies Ltd.
Symantec Norton Antivirus is a trademark of Symantec Corporation.
EverQuest is a registered trademark of Sony Computer Entertainment America Inc.
Click to DVD is a trademark of Sony Electronics.
Drag’n Drop CD+DVD is a registered trademark of Easy Systems Japan Ltd.
WinDVD for VAIO is a trademark of InterVideo, Inc.
RecordNow is a trademark or registered trademark of VERITAS.
PowerDVD for VAIO is a trademark or registered trademark of CyberLink Corporation.
All other names of systems, products and servi ces ar e trademarks of their res pective owners. In the manual, the ™ or ® marks are not
specified.
Specifications are subject to change without notice.
All other trademarks are trademarks of their respective owners.
Please see the printed Specifications sheet to see what software is available for your model.
Loading...
