Sony HC46, DCR-HC36, HC96 User Manual

2-659-813-11(1)

Digital Video Camera Recorder

Operating Guide

DCR-HC36/HC46/HC96

Getting Started 12

Recording/

Playback

Using the Menu 44

Dubbing/Editing 71

Using a Computer 86

Troubleshooting 99

Additional Information 122

WARNING

To reduce fire or shock hazard, do not expose the unit to rain or moisture.

This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

IMPORTANT SAFEGUARDS

For your protection, please read these safety instructions completely before operating the appliance, and keep this manual for future reference. Carefully observe all warnings, precautions and instructions on the appliance, or the one described in the operating instructions and adhere to them.

Use

Power Sources

This set should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of electrical power supplied to your home, consult your dealer or local power company. For those sets designed to operate from battery power, or other sources, refer to the operating instructions.

Polarization

This set may be equipped with a polarized ac power cord plug (a plug having one blade wider than the other).

This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to have a suitable outlet installed. Do not defeat the safety purpose of the polarized plug by forcing it in.

Overloading

Do not overload wall outlets, extension cords or convenience receptacles beyond their capacity, since this can result in fire or electric shock.

Object and Liquid Entry

Never push objects of any kind into the set through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the set.

Attachments

Do not use attachments not recommended by the manufacturer, as they may cause hazards.

Cleaning

Unplug the set from the wall outlet before cleaning or polishing it. Do not use liquid cleaners or aerosol cleaners. Use a cloth lightly dampened with water for cleaning the exterior of the set.

Installation

Water and Moisture

Do not use power-line operated sets near water – for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, etc.

Power-Cord Protection

Route the power cord so that it is not likely to be walked on or pinched by items placed upon or against them, paying particular attention to the plugs, receptacles, and the point where the cord exits from the appliance.

Accessories

Do not place the set on an unstable cart, stand, tripod, bracket, or table. The set may fall, causing serious injury to a child or an adult, and serious damage to the set. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer.

Ventilation

The slots and openings in the cabinet are provided for necessary ventilation. To ensure reliable operation of the set, and to protect it from overheating, these slots and openings must never be blocked or covered.

– Never cover the slots and openings with a cloth

or other materials.

– Never block the slots and openings by placing

the set on a bed, sofa, rug, or other similar surface.

– Never place the set in a confined space, such as

a bookcase, or built-in cabinet, unless proper ventilation is provided.

– Do not place the set near or over a radiator or

heat register, or where it is exposed to direct sunlight.

Continued ,

IMPORTANT SAFEGUARDS (Continued)

Lightning

For added protection for this set during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the set due to lightning and power-line surges.

Service

Damage Requiring Service

Unplug the set from the wall outlet and refer servicing to qualified service personnel under the following conditions:

– When the power cord or plug is damaged or

frayed.

– If liquid has been spilled or objects have fallen

into the set. – If the set has been exposed to rain or water. – If the set has been subject to excessive shock by

being dropped, or the cabinet has been

damaged. – If the set does not operate normally when

following the operating instructions. Adjust

only those controls that are specified in the

operating instructions. Improper adjustment of

other controls may result in damage and will

often require extensive work by a qualified

technician to restore the set to normal operation. – When the set exhibits a distinct change in

performance – this indicates a need for service.

Servicing

Do not attempt to service the set yourself as opening or removing covers may expose you to dangerous voltage or other hazards.

Refer all servicing to qualified service personnel.

Safety Check

Upon completion of any service or repairs to the set, as the service technician to perform routine safety checks (as specified by the manufacturer) to determine that the set is in safe operating condition.

Replacement parts

When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer that have the same characteristics as the original parts.

Unauthorized substitutions may result in fire, electric shock, or other hazards.

Read this first

Before operating the unit, please read this manual thoroughly, and retain it for future reference.

CAUTION

Replace the battery with the specified type only. Otherwise, fire or injury may result.

For customers in the U.S.A. and CANADA

RECYCLING LITHIUM-ION BATTERIES

Lithium-Ion batteries are recyclable. You can help preserve our environment by returning your used rechargeable batteries to the collection and recycling location nearest you.

For more information regarding recycling of rechargeable batteries, call toll free 1-800-8228837, or visit http://www.rbrc.org/

Caution: Do not handle damaged or leaking Lithium-Ion batteries.

Battery pack

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This Class B digital apparatus complies with Canadian ICES-003.

For customers in the U.S.A.

If you have any questions about this product, you may call: Sony Customer Information Center 1-800222-SONY (7669). The number below is for the FCC related matters only.

Regulatory Information

Declaration of Conformity

Trade Name: SONY Model No.: DCR-HC36 Responsible Party: Sony Electronics Inc. Address: 16450 W. Bernardo Dr, San Diego,

CA 92127 U.S.A. Telephone Number: 858-942-2230 This device complies with Part 15 of the FCC

Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Declaration of Conformity

Trade Name: SONY Model No.: DCR-HC46 Responsible Party: Sony Electronics Inc. Address: 16450 W. Bernardo Dr, San Diego,

CA 92127 U.S.A. Telephone Number: 858-942-2230 This device complies with Part 15 of the FCC

Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Continued ,

Read this first (Continued)

Declaration of Conformity

Trade Name: SONY Model No.: DCR-HC96 Responsible Party: Sony Electronics Inc. Address: 16450 W. Bernardo Dr, San Diego,

CA 92127 U.S.A. Telephone Number: 858-942-2230 This device complies with Part 15 of the FCC

Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Notes

• DCR-HC46 is to be used with the Handycam

Station Model DCRA-C151 and AC Adaptor

Model AC-L25A/L25B.

• DCR-HC96 is to be used with the Handycam

Station Model DCRA-C152 and AC Adaptor

Model AC-L25A/L25B.

Owner’s Record

The model and serial numbers are located on the bottom. Record the serial number in the space provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product.

Model No. DCR-HC Serial No. Model No. ACNo.

CAUTION

You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.

Note

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna. – Increase the separation between the equipment

and receiver.

– Connect the equipment into an outlet on a

circuit different from that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV

technician for help.

The supplied interface cable must be used with the equipment in order to comply with the limits for a digital device pursuant to Subpart B of Part 15 of FCC Rules.

Notes on use

Your camcorder is supplied with two kinds of operation guides.

– “Operating Guide” (This manual) – “First Step Guide” for connecting the

camcorder to a computer and using the supplied software (stored on the supplied CD-ROM)

Types of cassette you can use in your camcorder

You can use mini DV cassettes marked with . Mini DV cassettes with Cassette Memory are incompatible (p. 123).

Types of “Memory Stick” you can use in your camcorder

There are two sizes of “Memory Stick.” You can use “Memory Stick Duo” marked with or

(p. 124).

“Memory Stick Duo” (This size can be used with your camcorder.)

“Memory Stick” (You cannot use it in your camcorder.)

Using the camcorder

• Do not hold the camcorder by the following parts.

Viewfinder Battery pack

• You cannot use any type of memory card except “Memory Stick Duo.”

• “Memory Stick PRO” and “Memory Stick PRO Duo” can be used only with “Memory Stick PRO” compatible equipment.

When using a “Memory Stick Duo” with “Memory Stick” compatible equipment

Be sure to insert the “Memory Stick Duo” into the Memory Stick Duo Adaptor.

Memory Stick Duo Adaptor

LCD panel Shoe cover

(DCR-HC96)

• The camcorder is not dustproof, dripproof or waterproof. See “Maintenance and precautions” (p. 128).

• Before connecting your camcorder to another device with a USB or i.LINK cable, be sure to insert the connector plug the correct way, and not forcibly to avoid damaging the terminal, or cause a malfunction of your camcorder.

• For DCR-HC46/HC96: Disconnect the AC Adaptor from the Handycam Station holding both the Handycam Station and the DC plug.

• For DCR-HC46/HC96: Be sure to slide the POWER switch to OFF (CHG) when you insert the camcorder into the Handycam Station or remove the camcorder from it.

About menu items, LCD panel, viewfinder, and lens

• A menu item that is grayed out is not available under the current recording or playback conditions.

Continued ,

Read this first (Continued)

• The LCD screen and the viewfinder are manufactured using extremely highprecision technology, so over 99.99% of the pixels are operational for effective use. However, there may be some tiny black points and/or bright points (white, red, blue, or green in color) that appear constantly on the LCD screen and the viewfinder. These points are normal results of the manufacturing process and do not affect the recording in any way.

Black point

White, red, blue or green point

• Exposing the LCD screen, the viewfinder, or the lens to direct sunlight for long periods of time may cause malfunctions.

• Do not aim at the sun. Doing so might cause your camcorder to malfunction. Take pictures of the sun only in low light conditions, such as at dusk.

On recording

• Before starting to record, test the recording function to make sure the picture and sound are recorded without any problems.

• Compensation for the contents of recordings cannot be provided, even if recording or playback is not possible due to a malfunction of the camcorder, storage media, etc.

• TV color systems differ depending on the countries/regions. To view your recordings on a TV, you need an NTSC system-based TV.

• Television programs, films, video tapes, and other materials may be copyrighted. Unauthorized recording of such materials may be contrary to the copyright laws.

About this manual

• The images of the LCD screen and the viewfinder used in this manual for illustration purposes are captured using a digital still camera, and therefore may appear different.

• The on-screen displays in each local language are used for illustrating the operating procedures. Change the screen language before using your camcorder if necessary (p. 69).

• The illustrations used on this manual are based on the model DCR-HC96. The model name is indicated on the bottom of your camcorder.

• Design and specifications of recording media and accessories are subject to change without notice.

About the Carl Zeiss lens

• Your camcorder is equipped with a Carl Zeiss lens, which was developed jointly by Carl Zeiss, in Germany, and Sony Corporation, and produces superior images. It adopts the MTF measurement system for video cameras and offers a quality typical of a Carl Zeiss lens. MTF= Modulation Transfer Function. The number value indicates the amount of light from a subject coming into the lens.

• For DCR-HC96: The lens for your camcorder is T -coated to suppress unwanted reflections and faithfully reproduce colors.

Table of Contents

IMPORTANT SAFEGUARDS .................................................................. 3

Read this first ...........................................................................................5

Getting Started

Step 1: Checking supplied items ............................................................12

Step 2: Charging the battery pack ..........................................................13

Step 3: Turning the power on and holding your camcorder firmly ..........18

Step 4: Adjusting the LCD panel and viewfinder ....................................20

Step 5: Using the touch panel ................................................................21

Changing the language setting .................................................................... 21

Checking the screen indicators (Display guide) .......................................... 21

Step 6: Setting the date and time ...........................................................23

Step 7: Inserting a tape or a “Memory Stick Duo” ..................................24

Step 8: Selecting the aspect ratio (16:9 or 4:3) of the recording picture

(DCR-HC46/HC96) .......................................................................26

Recording/Playback

Easy Recording/Playback (Easy Handycam) .........................................28

Recording ...............................................................................................30

Playback .................................................................................................31

Functions used for recording/playback, etc. ...........................................32

Recording

To use zoom To use the flash (DCR-HC96) To record in dark places (NightShot plus) (DCR-HC36/HC46) To record in dark places (NightShot) (DCR-HC96) To adjust the exposure for backlit subjects (BACK LIGHT) To adjust the focus for an off center subject (SPOT FOCUS) To fix the exposure for the selected subject (Flexible spot meter) To record in mirror mode To use a tripod To use a Shoulder belt

Playback

To play back the images in sequence (SLIDE SHOW) To use PB zoom

Recording/playback

To check the remaining battery (Battery Info) To turn off the operation confirmation beep (BEEP) To use special effects To initialize the settings (RESET)

Continued ,

Other part names and functions

Indicators displayed during recording/playback .....................................36

Searching for the starting point ..............................................................39

Searching for the last scene of the most recent recording

(END SEARCH) .................................................................................. 39

Searching manually (EDIT SEARCH) ........................................................... 39

Reviewing the most recently recorded scenes (Rec review) ....................... 39

Remote Commander ..............................................................................40

Searching quickly for a desired scene (Zero set memory) .......................... 40

Searching for a scene by date of recording (Date search) .......................... 41

Playing the picture on a TV .................................................................... 42

Using the Menu

Using the menu items ........................................................... 44

Menu items ............................................................................................ 46

CAMERA SET menu ........................................................................ 49

Settings to adjust your camcorder to the recording conditions (EXPOSURE/ WHITE BAL./STEADYSHOT, etc.)

MEMORY SET menu ......................................................................55

Settings for the “Memory Stick Duo” (BURST/QUALITY/IMAGE SIZE/ ALL ERASE/NEW FOLDER, etc.)

PICT.APPLI. menu .........................................................................59

Special effects on pictures or additional functions on recording/playback (SLIDE SHOW/PICT. EFFECT/FRAME REC, etc.)

EDIT/PLAY menu ...........................................................................64

Settings for editing or playing back in various modes (VAR.SPD PB/ END SEARCH, etc.)

STANDARD SET menu .................................................................. 65

Settings while recording on a tape or other basic settings (REC MODE/ MULTI-SOUND/LCD/VF SET/DISP OUTPUT, etc.)

TIME/LANGU. menu .......................................................................69

(CLOCK SET/WORLD TIME/LANGUAGE)

Customizing Personal Menu ..................................................................69

Dubbing/Editing

Dubbing to VCR/DVD device, etc. ......................................................... 71

Recording pictures from a TV or VCR/DVD device, etc. ........................74

Dubbing pictures from a tape to a “Memory Stick Duo” ......................... 77

Dubbing sound to a recorded tape ......................................................... 78

Deleting recorded pictures from the “Memory Stick Duo” ......................80

Marking images on the “Memory Stick Duo” with specific information

(Print mark/Image protection) .......................................................81

Printing recorded images (PictBridge compliant printer) ........................82

Jacks to connect external devices ..........................................................84

Using a Computer

Before referring to the “First Step Guide” on your computer ..................86

Installing the software and “First Step Guide” on a computer ................89

Viewing “First Step Guide” .....................................................................93

Creating a DVD (Direct Access to “Click to DVD”) .................................94

Connecting an analog VCR to the computer via your camcorder

(Signal convert function) (DCR-HC96) .........................................97

Troubleshooting

Troubleshooting ......................................................................................99

Warning indicators and messages .......................................................117

Additional Information

Using your camcorder abroad ..............................................................122

Usable cassette tapes ..........................................................................123

About the “Memory Stick” .....................................................................124

About the “InfoLITHIUM” battery pack ..................................................126

About i.LINK .........................................................................................127

Maintenance and precautions ..............................................................128

Specifications .......................................................................................132

Index .....................................................................................................137

Getting Started

Step 1: Checking supplied items

Make sure that you have following items supplied with your camcorder. The number in the parentheses indicates the number of that item supplied.

• The cassette tape and “Memory Stick Duo” are not supplied. See page 6, 123, 124, for compatible cassettes and “Memory Stick Duo” for your camcorder.

AC Adaptor (1) (p. 13)

Power cord (1) (p. 13)

Handycam Station (1) (DCR-HC46/HC96) (p. 13)

Wireless Remote Commander (1) (p. 40)

USB cable (1) (p. 82, 86)

Lens cap (1) (DCR-HC36/HC46) (p. 18, 28, 30)

• To attach the lens cap Attach the lens cap to the metal fittings of the Grip belt, as illustrated below, using the strap.

Rechargeable battery pack (1) (p. 13, 126)

NP-FP30 (DCR-HC36) NP-FP50 (DCR-HC46/HC96)

CD-ROM “Picture Package Ver.1.5.1” (1) (p. 86)

A button-type lithium battery is already installed.

A/V connecting cable (1) (p. 42, 74, 97)

Operating Guide (This manual) (1)

Step 2: Charging the battery pack

You can charge the “InfoLITHIUM” battery pack (P series) (p. 126) after attaching it to your camcorder.

For DCR-HC46/HC96:

POWER switch

DC IN jack

Handycam Station

To the wall outlet

DC plug

AC Adaptor

Power cord

For DCR-HC36:

POWER switch

DC IN jack

DC plug

To the wall outlet

AC Adaptor

Power cord

1 Align the terminals of the battery

pack and your camcorder (1), then attach the battery pack and click it into place (2).

Getting Started

2 Slide the POWER switch in the

direction of the arrow to OFF (CHG) (The default setting).

3 Connect the AC Adaptor to the

DC IN jack on the Handycam Station for the DCR-HC46/HC96 or on your camcorder for the DCRHC36.

For DCR-HC46/HC96:

DC IN jack

With the v mark facing up

Continued ,

Step2: Charging the battery pack (Continued)

For DCR-HC36:

With the v mark facing to the LCD screen

DC IN jack

4 For DCR-HC46/HC96:

Connect the power cord to the AC Adaptor and the wall outlet. Insert the camcorder into the Handycam Station securely, all the way to the bottom.

DCR-HC96:

/CHG

(charge) lamp

DCR-HC46:

CHG (charge) lamp

The CHG (charge) lamp lights up and charging starts.

• When inserting the camcorder into the Handycam Station, close the DC IN jack cover.

For DCR-HC36: Connect the power cord to the AC Adaptor and the wall outlet.

CHG (charge) lamp

The CHG (charge) lamp lights up and charging starts.

5 The CHG (charge) lamp turns off

when the battery is fully charged. Disconnect the AC Adaptor from the DC IN jack.

For DCR-HC46/HC96: Disconnect the AC Adaptor from the DC IN jack holding both the Handycam Station and the DC plug.

For DCR-HC46/HC96: To charge the battery pack using only the AC Adaptor

Turn off the power, then connect the AC Adaptor to the DC IN jack on your camcorder.

• You can operate your camcorder connected to a power source such as a wall outlet as shown in the illustration. The battery pack will not lose its charge in this case.

POWER switch

With the v mark facing to the LCD screen

DC plug

To remove the battery pack

1 Slide the POWER switch to OFF

(CHG). Hold down the V BATT (battery) release lever with one hand.

2 Remove the battery in the direction of

the arrow with the other hand.

POWER switch

Getting Started

DC IN jack

To the wall outlet

AC Adaptor

Power cord

For DCR-HC46/HC96: To remove your camcorder from the Handycam Station

Turn off the power, then remove the camcorder from the Handycam Station holding both your camcorder and the Handycam Station.

For DCR-HC36: To use an outside power source

You can operate your camcorder using the power from the wall outlet by making the same connections as you do when charging the battery pack. The battery pack will not lose its charge in this case.

V BATT (battery) release lever

When storing the battery pack

Fully discharge the battery before storing it for an extended period (p. 126).

Charging time

Approximate time (min.) required when you fully charge a fully discharged battery pack.

Battery pack Charging time

NP-FP30*

NP-FP50*

NP-FP70 155

NP-FP71 170

NP-FP90 220

*1supplied with DCR-HC36

supplied with DCR-HC46/HC96

115

125

Recording time

Approximate time (min.) available when you use a fully charged battery pack.

Continued ,

Step2: Charging the battery pack (Continued)

DCR-HC36

Continuous

Battery pack

recording time

NP-FP30 (supplied) 85

NP-FP50 120

NP-FP70 255

NP-FP71 300

NP-FP90 455

• All times measured under the following conditions: Top: Recording with LCD screen. Bottom: Recording with viewfinder while the LCD panel closed.

* Typical recording time shows the time when

you repeat recording start/stop, turning the power on/off and zooming.

DCR-HC46

Continuous

Battery pack

recording time

NP-FP50 (supplied) 100

NP-FP70 215

NP-FP71 255

NP-FP90 385

• All times measured under the following conditions: Top: Recording with LCD screen. Middle: When the LCD backlight turns off. Bottom: Recording with viewfinder while the LCD panel closed.

105

150

310

370

550

115 115

240 240

290 290

435 435

Typical recording time*

40 50

60 75

125 155

150 185

225 275

Typical recording time*

55 65 65

120 130 130

140 160 160

210 240 240

* Typical recording time shows the time when

you repeat recording start/stop, turning the power on/off and zooming.

DCR-HC96

Battery pack

Continuous recording time

NP-FP50 (supplied) 80

NP-FP70 170

NP-FP71 200

NP-FP90 300

• All times measured under the following conditions: Top: Recording with LCD screen. Middle: When the LCD backlight turns off. Bottom: Recording with viewfinder while the LCD panel closed.

* Typical recording time shows the time when

you repeat recording start/stop, turning the power on/off and zooming.

185 190

220 230

335 345

Typical recording time*

45 85 90

100 105

110 120 125

165 185 190

Playing time

Approximate time (min.) available when you use a fully charged battery pack.

DCR-HC36

Battery pack

LCD panel opened

NP-FP30 (supplied) 90 110

NP-FP50 125 160

NP-FP70 265 330

NP-FP71 315 395

NP-FP90 475 580

LCD panel closed

DCR-HC46

Battery pack

LCD panel opened*

LCD panel closed

NP-FP50 (supplied) 120 150

NP-FP70 255 310

NP-FP71 300 370

NP-FP90 455 550

* When the LCD backlight turns on.

DCR-HC96

Battery pack

LCD panel opened*

LCD panel closed

NP-FP50 (supplied) 115 140

NP-FP70 240 295

NP-FP71 290 350

NP-FP90 435 525

* When the LCD backlight turns on.

On the battery pack

• Before changing the battery pack, slide the POWER switch to OFF (CHG).

• The CHG (charge) lamp flashes during charging, or the Battery Info (p. 35) will not be correctly displayed under the following conditions.

– The battery pack is not attached correctly. – The battery pack is damaged. – The battery pack is worn-out (For Battery

Info only).

• The power will not be supplied from the battery as long as the AC Adaptor is connected to the DC IN jack of your camcorder or the Handycam Station supplied with the DCR-HC46/HC96, even when the power cord is disconnected from the wall outlet.

On the AC Adaptor

• Use the nearby wall outlet when using the AC Adaptor. Disconnect the AC Adaptor from the wall outlet immediately if any malfunction occurs while using your camcorder.

• Do not use the AC Adaptor placed in a narrow space, such as between a wall and furniture.

• Do not short-circuit the DC plug of the AC Adaptor or battery terminal with any metallic objects. This may cause a malfunction.

PRECAUTION

• Even if your camcorder is turned off, AC power (house current) is still supplied to it while connected to the wall outlet via the AC Adaptor.

Getting Started

On the charging/recording/playback time

• Times measured with the camcorder at 25°C (77°F). (10 - 30 °C (50 - 86°F) is recommended.)

• The recording and playback time will be shorter when you use your camcorder in low temperatures.

• The recording and playback time will be shorter depending on the conditions under which you use your camcorder.

Step 3: Turning the power on and holding your camcorder firmly

To record or play back, slide the POWER switch repeatedly to turn on the respective lamp. When using it for the first time, the [CLOCK SET] screen appears (p. 23).

POWER switch

1 Slide the POWER switch

repeatedly in the direction of the arrow to turn on the respective lamp.

For DCR-HC36/HC46: Remove the lens cap by pressing both knobs on the sides of the cap.

Lamps that light up CAMERA-TAPE: To record on a tape. CAMERA-MEMORY: To record on a

“Memory Stick Duo.” PLAY/EDIT: To play or edit pictures.

• After you have set the date and time ([CLOCK SET], p. 23), the next time you turn on the power of your camcorder, the current date and time will be displayed on the LCD screen for a few seconds.

2 Hold the camcorder correctly.

3 Ensure a good grip, then fasten

the Grip belt.

For DCR-HC96: The lens cover opens automatically when the POWER switch is set to CAMERA-TAPE or CAMERAMEMORY.

If the POWER switch is set to OFF (CHG), slide it while pressing the green button.

To turn off the power

Slide the POWER switch to OFF (CHG).

For DCR-HC36/HC46: Attach the lens cap after turning off the power.

• At the time of purchase, the power will be set to turn off automatically if you leave your camcorder without any operation attempted for approximately 5 minutes, to save battery power ([A.SHUT OFF], p. 68).

• If warning messages appear on the screen, follow the instructions (p. 118).

Getting Started

Step 4: Adjusting the LCD panel and viewfinder

The LCD panel

Open the LCD panel 90 degrees to the camcorder (1), then rotate it to the best angle to record or play (2 ).

DISP/BATT INFO

180 degrees (max.)

90 degrees (max.)

• Do not press the buttons on the LCD frame

accidentally when you open or adjust the LCD panel.

• If you rotate the LCD panel 180 degrees to the

lens side, you can close the LCD panel with the LCD screen facing out. This is convenient during playback operations.

For DCR-HC46/HC96: To turn off the LCD backlight to make the battery last longer

Press and hold DISP/BATT INFO for a few seconds until appears. This setting is practical when you use your camcorder in bright conditions or where you want to save battery power. The recorded picture will not be affected by the setting. To turn on the LCD backlight, press and hold DISP/BATT INFO for a few seconds until disappears.

• See [LCD/VF SET] - [LCD BRIGHT] (p. 66) to

adjust the brightness of the LCD screen.

90 degrees to the camcorder

The viewfinder

You can view pictures using the viewfinder to avoid wearing down the battery, or when the picture seen on the LCD screen is poor.

Viewfinder

Viewfinder lens adjustment lever

Move it until the picture is clear.

• You can adjust the brightness of the viewfinder backlight by selecting [LCD/VF SET] - [VF B.LIGHT] (p. 66).

• You can adjust the [FADER] and the [EXPOSURE] setting using the viewfinder (p. 60).

Step 5: Using the touch panel

You can play back recorded pictures (p. 31), or change the settings (p. 44) using the touch panel.

Place your hand on the rear side of the LCD panel to support it. Then, touch the buttons displayed on the screen.

DISP/BATT INFO

DCR-HC36/ HC46

DCR-HC96

Touch the button on the LCD screen.

• Perform the same actions as explained above when you press the buttons on the LCD frame.

• Be careful not to press buttons on the LCD frame accidentally while using the touch panel.

• If the buttons on the touch panel do not work correctly, adjust the LCD screen (CALIBRATION) (p. 130).

• Dots in lines may appear on the LCD screen, but this is not a malfunction. These dots are not recorded.

Changing the language setting

You can change the on-screen displays to show messages in a specified language. Select the screen language in [LANGUAGE] on the (TIME/ LANGU.) menu (p. 44, 69).

Checking the screen indicators (Display guide)

You can easily check the meaning of each indicator (p. 38) that appears on the LCD screen.

1 Touch .

60min

TELE

1/3

MACRO

SPOT FOCUS

Touch [MENU] during Easy Handycam operation (p. 28).

DISP GUIDE

EXPOSURE

FADE R

–:––:––

2 Touch [DISP GUIDE].

Select area for guide.

DISP GUIDE

END

Getting Started

To hide the screen indicators

Press DISP/BATT INFO to toggle the screen indicators (such as time code) on or off.

The indicators vary depending on the settings.

Continued ,

Step 5: Using the touch panel (Continued)

3 Touch the area including the

indicator that you want to check.

DISP GUIDE

1/2

FOCUS: MANUAL PROGRAM AE: SPOTLIGHT STEADYSHOT: OFF

END

The meanings of the indicators in the area are listed on the screen. If you cannot find the indicator you want to check, touch / to toggle.

When you touch , the screen returns to the area selecting display.

To finish the operation

Touch [END].

Step 6: Setting the date and time

Set the date and time when using this camcorder for the first time. If you do not set the date and time, the [CLOCK SET] screen appears every time you turn on your camcorder or change the POWER switch position.

• If you do not use your camcorder for about 3 months, the built-in rechargeable battery gets discharged and the date and time settings may be cleared from the memory. In that case, charge the rechargeable battery and then set the date and time again (p. 131).

POWER switch

Skip to step 4 when you set the clock for the first time.

1 Touch t [MENU].

60min

–:––:––

3 Select [CLOCK SET] with / ,

then touch .

CLOCK SET

DATE

4 Set [Y] (year) with / , then

touch .

You can set any year up to the year

2079.

CLOCK SET

DATE

5 Set [M] (month), [D] (day), hour

and minute, then touch .

For midnight, set it to 12:00 AM. For midday, set it to 12:00 PM.

The clock starts.

JANM1D12: 00

2006

JAN M1D 12: 00

–:––:––

Getting Started

CAMERA SET

PROGRAM AE SPOT METER EXPOSURE

2 Select (TIME/LANGU.) menu

with / , then touch .

60min

DISP OUTPUT

MENU ROTATE

A. SHUT OFF

CLOCK SET

WORLD

LANGUAGE

PROGRAM AE

–:––:––

––:––:––

• The date and time are not displayed while recording, but they are automatically recorded on the tape, and can be displayed during playback (see page 67 for [DATA CODE] (During Easy Handycam operation, you can set only [DATE/TIME])).

Step 7: Inserting a tape or a “Memory Stick

{DO NOT PUSH}

Duo”

Cassette tape

You can use mini DV cassettes only (p. 123).

• The recordable time varies depending on [ REC MODE] (p. 65).

1 Slide and hold the OPEN/

EJECT lever in the direction of the arrow and open the lid.

OPEN/EJECT lever

Lid

The cassette compartment automatically comes out and opens up.

2 Insert a cassette with its window

facing outwards, then press

Push the center of the back of the cassette lightly.

Cassette compartment

The cassette compartment automatically slides back in.

• Do not force the cassette compartment closed by pressing the portion marked while it is sliding in. It may cause a malfunction.

Window

3 Close the lid.

To eject the cassette

Open the lid following the same procedure as described in Step 1 and remove the cassette.

• For DCR-HC46/HC96: Do not insert/eject the cassette while your camcorder is on the Handycam Station. This may cause a malfunction.

“Memory Stick Duo”

You can use only a “Memory Stick Duo” marked with or

(p. 124).

• The number and time of recordable pictures varies depending on the image quality or the image size. For details, see page 56.

1 Open the LCD panel.

DCR-HC36/HC46:

Access lamp

With the v mark facing to the LCD screen

• If you force the “Memory Stick Duo” into the slot in the wrong direction, th e “Memory Stick Duo,” the “Memory Stick Duo” slot, or image data may be damaged.

Getting Started

2 Insert the “Memory Stick Duo”

into the “Memory Stick Duo” slot in the right direction until it clicks.

DCR-HC96:

Access lamp

With the v mark facing to the LCD screen

To eject a “Memory Stick Duo”

Lightly push in once and slide out the “Memory Stick Duo” alongside the camcorder body.

• Do not remove the “Memory Stick Duo” forcibly with the fingers as it may be damaged.

• When the access lamp is lit or flashing, your camcorder is reading/writing data. Do not shake or knock your camcorder, turn the power off, eject the “Memory Stick Duo,” or remove the battery pack. Otherwise, image data may be damaged.

• When inserting or ejecting the “Memory Stick Duo,” be careful that the “Memory Stick Duo” does not pop out and drop.

Step 8: Selecting the aspect ratio (16:9 or 4:3) of the recording picture (DCR-HC46/HC96)

By recording in the 16:9 (wide) mode, you can enjoy wide-angle, high-quality pictures.

• If you intend to view pictures on a wide TV, recording in the 16:9 (wide) mode is recommended.

WIDE SELECT button POWER switch

Selecting the aspect ratio for recording movies on a tape

Be sure to set the POWER switch to CAMERA-TAPE.

Press WIDE SELECT repeatedly to select the desired screen aspect ratio.

16:9* 4:3*

• When viewing pictures recorded in 16:9 aspect ratio with [TV TYPE] set to [4:3], pictures may appear rough depending on the subject (p. 43).

Recording a moving picture or still image on the “Memory Stick Duo”

1 Set the POWER switch to CAMERA-

MEMORY. The aspect ratio of the picture switches to 4:3.

2 Press WIDE SELECT to select the

desired screen aspect ratio.

• If you record movies (MPEG MOVIE EX) in the 16:9 (wide) mode, black bands appear at the top and bottom of the picture when they are played back.

• For the number of recordable pictures, see page

56.

• For DCR-HC46: Still images will be fixed to image size [0.7M] ( ) in the 16:9 (wide) mode. In the 4:3 mode, you can select up to [1.0M] ( ).

• For DCR-HC96: Still images will be fixed to image size [2.3M] ( ) in the 16:9 (wide) mode. In the 4:3 mode, you can select up to [3.0M] ( ).

* When viewing on the LCD screen. It may be

different in the viewfinder.

• Differences in the angle of view between 4:3 and 16:9 vary depending on the zoom position.

• If you play back a picture on TV, set [TV TYPE] for playback in the aspect ratio of the TV (p. 43).

Getting Started

Recording/Playback

Easy Recording/Playback (Easy Handycam)

With this Easy Handycam operation, most of the camera settings are automatically optimally adjusted, which frees you from detailed adjustments. The screen font size increases for easy viewing.

DCR-HC36/HC46:

Remove the lens cap (p. 18).

DCR-HC36:

DCR-HC36/ HC46

DCR-HC96

If the POWER switch is set to OFF (CHG), slide it while pressing the green button.

Movies

1 Slide the POWER

switch E to turn on the CAMERA-TAPE lamp.

2 Press EASY A.

appears on the screen B.

3 Press REC START/STOP F (or

C) to start recording.*

60min

The indicator changes [STBY] to [REC].

To stop recording, press F again.

*1Movies are recorded in SP (Standard Play) mode on a cassette.

Still images are recorded in [FINE] quality on a “Memory Stick Duo.”

EASY

REC

Still images (4:3)

1 Slide the POWER

switch E to turn on the CAMERA-MEMORY lamp.

2 Press EASY A.

appears on the screen B.

3 Press PHOTO D to record.*

3.0M

60min

EASY

Press and hold lightly

Flashing t Lit

to adjust the focus.

When disappears, the image has been recorded.

Press fully to record.

Playing back movies/still images

Slide the POWER switch E to turn on the PLAY/EDIT lamp. Touch the buttons on the screen B as follows.

Movies

Touch , then touch

to start playback.

A Stop B Play/Pause toggles C Rewind/Fast forward

till images

Touch t /

to select a picture.

A Tape playback B Previous/Next C Delete (p. 80)

x To cancel Easy Handycam operation

Press EASY A again. disappears from the screen.

x Adjustable menu settings during Easy Handycam operation

Touch [MENU] to display adjustable menu settings. See page 45 for details on settings.

• Almost all the settings return to the default setting automatically (p. 46).

• is not displayed during Easy Handycam operation.

• Cancel Easy Handycam operation if you want to add any effects or settings to the images. Almost all

the settings are returned to the previous status.

x Unavailable buttons during Easy Handycam

During Easy Handycam operation, the following buttons are unavailable, since the items are set automatically. [Invalid during Easy Handycam operation.] may appear if operations not available during Easy Handycam are attempted.

• BACK LIGHT button (p. 33)

• PHOTO button (in the CAMERA-TAPE mode) (p. 30)

• REC START/STOP button (in the CAMERA-MEMORY mode) (p. 30).

• For DCR-HC46/HC96:

Pressing and holding DISP/BATT INFO button (p. 20)

• For DCR-HC46/HC96:

WIDE SELECT button (in the CAMERA-MEMORY mode) (p. 26)

Recording/Playback

Recording

Lens cap (DCR-HC36/HC46)

Remove the lens cap by pressing both knobs on the sides of the cap.

Lens cover (DCR-HC96)

Opens in accordance with the setting of the POWER switch.


DCR-HC36:

REC START/STOP B

1 Slide the POWER switch in the direction of the arrow repeatedly to turn on

the respective lamp to select a recording medium.

POWER switch

REC START/STOP A

To record on a tape, light up the CAMERA-TAPE lamp. To record on a “Memory Stick Duo,” light up the CAMERA-MEMORY lamp.

2 Start recording.

Movies Still images

Press REC START/STOP A (or B).

60min

REC

The indicator (A) changes [STBY] (tape only) to [REC].

• The sound of a movie (MPEG MOVIE EX) recorded on a “Memory Stick Duo” will be monaural.

To stop movie recording

Press REC START/STOP again.

• While recording movies on a tape, or while in standby mode, you can record a still image on a “Memory Stick Duo” by pressing PHOTO fully. Still images will be fixed to image size [0.2M] in 16:9 screen (DCR-HC46/HC96), or [VGA (0.3M)] in 4:3 screen.

If the POWER switch is set to OFF (CHG), slide it while pressing the green button.

Press and hold PHOTO lightly to adjust the focus (A), then press it

60min

fully (B).

3.0M

Flashing t Lit

A shutter sound is heard. When disappears, the image has been recorded.

To check the latest recording on a “Memory Stick Duo”

Touch . To delete the picture, touch

t [YES].

+ 110 hidden pages
