Page 1
DCR-HC47E/HC48/HC48E
RMT-831
SERVICE MANUAL
Ver. 1.1 2007.03
Revision History
Revision History
How to use
How to use
Acrobat Reader
Acrobat Reader
N MECHANISM (MDX-N110)
Link
Link
SPECIFICATIONS
Photo: DCR-HC48
DISASSEMBLY
LEVEL 2
US Model
Canadian Model
AEP Model
UK Model
East European Model
North European Model
E Model
Australian Model
Chinese Model
Korea Model
Tourist Model
Japanese Model
SCHEMATIC DIAGRAMS
MODEL INFORMATION TABLE
SERVICE NOTE
• Precaution on Replacing the VC-472 Board
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
BLOCK DIAGRAMS
FRAME SCHEMATIC DIAGRAM
PRINTED WIRING BOARDS
REPAIR PARTS LIST
DIGITAL VIDEO CAMERA RECORDER
DCR-HC47E/HC48/HC48E_L2
Sony EMCS Co.
2007C0500-1
© 2007.3
Published by Kohda TEC9-852-170-31
Page 2
These specifications are extracted from instruction
manual of DCR-HC47E/HC48E.
SPECIFICATIONS
ENGLISH JAPANESE
ENGLISH JAPANESE
System
Video recording system
2 rotary heads, Helical scanning system
Still image recording syste m
Exif Ver. 2.2*
Audio recording system
Rotary heads, PCM system
Quantization: 12 bits (Fs 32 kHz, stereo
1, stereo 2), 16 bits (Fs 48 kHz, stereo)
Video signal
PAL color, CCIR standards
Usable cassette
Mini DV ca ssette with the mark
printed
Tape speed
SP: Approx. 18.81 mm/s
LP: Approx. 12.56 mm/s
Recording/playback time
SP: 60 min (using a DVM60 cass ette)
LP: 90 min (using a DVM60 cassette)
Fast forward/rewind time
Approx. 2 min 40 s (using a DVM60
cassette and rechargeable battery pack)
Approx. 1 min 45 s (using a DVM60
cassette and AC Adaptor)
Viewfinder
Electric viewfinder (0.27 type, aspect
ratio 16:9, 123 200 dots)
Image device
3 mm (1/6 type) CCD (Charge Coupled
Device)
Gross: Approx. 1 070 000 pixels
Effective (still): 1 000 000 pixels
Effective (movie): 690 000 pixels
Lens
Carl Zeiss Vario-Tessar
25 × (Optical), 2 000 × (Digital)
Focal length
f=2.5 ~ 62.5 mm (1/8 ~ 2 1/2 in.)
When converted to a 35 mm still
camera
In CAMERA-TAPE:
41 ~ 1 189 mm** (1 5/8 ~ 46 7/8 in.)
(16:9)
43 ~ 1 075 mm (1 3/4 ~ 42 3/8 in.) (4:3)
In CAMERA-MEMORY:
36 ~ 900 mm (1 7/16 ~ 35 1/2 in.) (4:3)
39 ~ 975 mm (1 9/16 ~ 38 1/2 in.) (16:9)
F1.8 ~ 3.2
Filter diameter: 30 mm (1 3/16 in.)
Color temperature
[AUTO], [ONE PUSH], [INDOOR]
(3 200 K), [OUTDOOR] (5 800 K)
Minimum illumination
4 lx (lux) (AUTOSLW SHTR ON,
Shutter speed 1/25 s)
0 lx (lux) (during NightShot plus
function)
* “Exif” is a file format for still images,
established by the JEITA (Japan
Electronics and Information Technology
Industries Association). Files in this
format can have additional information
such as your camcorder’s setting
information at the time of recording.
**The focal length figures are actual figures
resulting from wide angle pixel read-out.
DCR-HC47E/HC48/HC48E_L2
Output connectors
Audio/Video output
10-pin connector
Video signal: 1 Vp-p, 75 Ω (ohms)
Luminance signal: 1 Vp-p, 75 Ω (ohms)
Chrominance signal: 0.3 Vp-p, 75 Ω
(ohms)
Audio signal: 327 mV (at load
impedance 47 kΩ (kilohms)), Output
impedance with less than 2.2 kΩ
(kilohms)
LCD screen
6.9 cm (2.7 type, aspect ratio 16:9)
Total dot number
123 200 (560 × 220)
General
Power requirements
DC 6.8 V/7.2 V (battery pack)
DC 8.4 V (AC Adaptor)
Average power consumption
During camera recordin g using the
viewfinder 2.5 W
During camera recordin g using the
LCD 2.8 W
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature
-20 °C to + 60 °C (-4 °F to + 140 °F)
Dimensions (approx.)
63 × 85 × 114 mm
(2 1/2 × 3 3/8 × 4 1/2 in.) (w/h/d)
including the projecting parts
63 × 85 × 115 mm
(2 1/2 × 3 3/8 × 4 5/8 in.) (w/h/d)
including the projecting parts with
supplied battery pack NP-FH40
attached
Mass (approx.)
400 g (14 oz) main unit only,
465 g (1 lb) including the NP-FH40
rechargeable battery pack and DVM60
cassette
Supplied accessories
AC Adaptor (1)
Mains lead (1)
Handycam Station (1)
Wireless Remote Commander (1)
A/V connecting cable (1)
USB cable (1)
Rechargeable battery pack NP-FH40 (1)
CD-ROM “Handycam Application
Software” (1)
21-pin adaptor (1)
Operating Guide (1)
See page 5-21.
Handycam Station Input/Output
connectors
DCRA-C155 (DCR-HC48E)
Audio/Video output
10-pin connector
Video signal: 1 Vp-p, 75 Ω (ohms)
Luminance signal: 1 Vp-p, 75 Ω (ohms)
Chrominance signal: 0.3 Vp-p, 75 Ω
(ohms)
— 2 —
Audio signal: 327 mV (at load
impedance 47 kΩ (kilohms)), Output
impedance with less than 2.2 kΩ
(kilohms)
USB jack
mini-B
DV input/output
i.LINK Interface (IEEE1394, 4-pin
connector S100)
DCRA-C156 (DCR-HC47E)
Audio/Video output
10-pin connector
Video signal: 1 Vp-p, 75 Ω (ohms)
Luminance signal: 1 Vp-p, 75 Ω (ohms)
Chrominance signal: 0.3 Vp-p, 75 Ω
(ohms)
Audio signal: 327 mV (at load
impedance 47 kΩ (kilohms)), Output
impedance with less than 2.2 kΩ
(kilohms)
USB jack
mini-B
DV output
i.LINK Interface (I EE E1394, 4-pin
connector S100)
AC Adaptor AC-L200/L200B
Power requirements
AC 100 - 240 V, 50/60 Hz
Current consumption
0.35 - 0.18 A
Power consumption
18 W
Output voltage
DC 8.4 V*
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature
-20 °C to + 60 °C (-4 °F to + 140 °F)
Dimensions (approx.)
48 × 29 × 81 mm
(1 15/16 × 1 3/16 × 3 1/4 in.) (w/h/d)
excluding the projecting parts
Mass (approx.)
170 g (6.0 oz) excluding the mains lead
See the label on the AC Adaptor for
*
other specifications.
Rechargeable battery pack NP-FH40
Maximum output voltage
DC 8.4 V
Output voltage
DC 7.2 V
Capacity
4.9 Wh (680 mAh)
Dimensions (approx.)
31.8 × 18.5 × 45.0 mm
(1 5/16 × 3/4 × 1 13/16 in.) (w/h/d)
Mass (approx.)
45 g (1.6 oz)
Operating temp erature
0 °C to 40 °C (32 °F to 104 °F)
Type
Lithium ion
Design and specifications are subject to change
without notice.
Page 3
概略仕様
システム
録画方式
回転
2
ヘッドヘリカルスキャン
静止画記録方式
Exif Ver.2.2*
1
録音方式
回転
2
ヘッド
12
ビット
32kHz
（ステレオ1、ステレオ2）
16
ビット
48kHz
（ステレオ）
映像信号
NTSC
カラー、
EIA
標準方式
使用可能カセット
マークのついたミニ
DV
カセット
テープ速度
SP
：約
18.81mm/
秒
LP
：約
12.56mm/
秒
録画
/
再生時間
SP：60
分（
DVM60
使用時）
LP：90
分（
DVM60
使用時）
早送り、巻き戻し時間
バッテリー使用時：
約
2分40
秒（
DVM60
使用時）
AC
アダプター使用時：
約
1分45
秒（
DVM60
使用時）
ファインダー
電子ファインダー（
0.27
型、アスペクト比
16:9、123 200
ドット）
撮像素子
3.0mm（1/6
型）
CCD
固体撮像素子
総画素数：約
107
万画素
静止画時有効画素数：約
100
万画素
動画時有効画素数：約
69
万画素
ズームレンズ
カール
ツァイス バリオテッサー
25
倍（光学）、
2000
倍（デジタル）
f=2.5〜62.5mm
35mm
カメラ換算では
「撮る−テープ」時：
41〜1189mm（16:9
モード）
*
2
（
4:3
モードでは43〜
1075mm
）
「撮る−メモリー」時：
36〜900mm（4:3
モード）
（
16:9
モードでは39〜
975
ｍｍ）
F1.8〜3.2
フィルター径
30mm
色温度切り換え
［オート］、［ワンプッシュ］、
［屋内］（
3200K
）、
［屋外］（
5800K
）
最低被写体照度
8lx
（ルクス）（オートスローシャッター 入、
シャッタースピード
1/30
秒）
0lx
（ルクス）（
NightShot plus
時）
出力端子
A/V OUT
端子
10
ピン特殊コネクター
映像：
1Vp-p、75
Ω
Y
出力
1Vp-p、75
Ω
C
出力
0.286Vp-p、75
Ω
音声：
327mV（47k
Ω負荷時）、出力インピー
ダン
ス2.2k
Ω以下
液晶画面
画面サイズ
6.9cm（2.7
型、アスペクト比
16:9
）
総ドット数
123 200
ドット
横
560×縦220
電源部、その他
電源電圧
バッテリー端子入力
6.8V/7.2V
DC
端子入力
8.4V
消費電力
2.5W
（ファインダー使用時、明るさ標準）
2.8W
（液晶画面使用時、明るさ標準）
動作温度
0
℃〜
+40
℃
保存温度
−
20℃〜+60
℃
外形寸法
63×85×114mm
（幅×高さ×奥行き）
（突起部含む）
63×85×115mm
（幅×高さ×奥行き）
（突起部含む、付属バッテリーパック
NP-
FH40
装着状態）
本体質量
約
400g
（本体のみ）
撮影時総質量
約
465g
（バッテリー
NP-FH40、
テープ
（
DVM60
）含む。）
付属品
AC
アダプター（1）
ハンディカムステーション
入出力端子
DCRA-C155
A/V OUT
端子
10
ピン特殊コネクター
映像：
1Vp-p、75
Ω
Y
出力
1Vp-p、75
Ω
C
出力
0.286Vp-p、75
Ω
音声：
327mV（47k
Ω負荷時）、出力インピー
ダンス
2.2k
Ω以下
USB
端子
mini-B
DV
端子
i.LINK（IEEE1394 4
ピンコネクター
S100
）
AC
アダプター
AC-L200/L200B
電源
AC100〜240V、50/60Hz
消費電力
18W
定格出力
DC8.4V *
動作温度
0
℃〜
+40
℃
保存温度
−
20
℃〜
+60
℃
外形寸法
約
48×29×81mm
（最大突起部をのぞく）
（幅×高さ×奥行き）
質量
約
170g
（本体のみ）
*
その他の仕様についてはACアダプターのラ
ベルをご覧ください。
リチャージャブルバッテリーパック
NP-FH40
最大電圧
DC8.4V
公称電圧
DC7.2V
容量
4.9Wh（680mAh
）
最大外形寸法
約
31.8×18.5×45.0mm
（幅×高さ×奥行き）
*
1
（社）電子情報技術産業協会（
JEITA
）にて制定
された、撮影情報などの付帯情報を追加する
ことができる静止画用のファイルフォーマッ
ト。
*
2
広角画素読み出しによる実動作値
質量
約
45g
使用温度
0
℃〜
+40
℃
使用電池
Li-ion
本機の仕様および外観は、改良のため予告なく変
更することがありますが、ご了承ください。
電源コード（
1
）
ハンディカムステーション（
1
）
ワイヤレスリモコン（
1
）
AV
接続ケーブル（1）
USB
ケーブル（1）
リチャージャブルバッテリーパック
NP-FH40（1
）
CD-ROM「Handycam Application
Software
」（1）
取扱説明書（
1
）
保証書（
1
）
ENGLISH JAPANESE
ENGLISH JAPANESE
DCR-HC47E/HC48/HC48E_L2
— 3 —
Page 4
Model information table
Model DCR-HC47E DCR-HC48 DCR-HC48E
Destination AEP, UK, EE, NE
Color system PAL NTSC PAL
DV Interface on the Cradle
(Handycam Station)
•Abbreviation
AR : Argentine model
AUS: Australian model
BR : Brazilian model
CH : Chinese model
CND: Canadian model
EE : East European model
HK : Hong Kong model
J: Japanese model
JE : Tourist model
KR : Korea model
NE : North European model
OUT IN/OUT IN/OUT
US, CND, E, KR, NE, E, AUS, CH,
JE, J JE
DCR-HC47E/HC48/HC48E_L2
— 4 —
Page 5
ENGLISH JAPANESE
ENGLISH JAPANESE
Danger of explosion if battery is incorrectly replaced.
CAUTION
Replace only with the same or equivalent type.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0 OR DO TTED LINE WITH
MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer.
1. Check the area of your repair for unsoldered or poorly-soldered
connections. Check the entire board surface for solder splashes
and bridges.
2. Check the interboard wiring to ensure that no wires are
"pinched" or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly
transistors, that were installed during a previous repair. Point
them out to the customer and recommend their replacement.
4. Look for parts which, through functioning, show obvious signs
of deterioration. Point them out to the customer and
recommend their replacement.
5. Check the B+ voltage to see it is at the values specified.
6. Flexible Circuit Board Repairing
•Keep the temperature of the soldering iron around 270˚C
during repairing.
• Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
• Be careful not to apply force on the conductor when soldering
or unsoldering.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFÉS P AR UNE MARQ UE 0 SUR LES
DIAGRAMMES SCHÉMA TIQ UES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE
REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY
DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.
Unleaded solder
Boards requiring use of unleaded solder are printed with the leadfree mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size.)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
• Unleaded solder melts at a temperature about 40°C higher than
ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350°C.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
• Strong viscosity
Unleaded solder is more viscous (sticky , less prone to flow) than
ordinary solder so use caution not to let solder bridges occur such
as on IC pins, etc.
•Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
DCR-HC47E/HC48/HC48E_L2
— 5 —
Page 6
ENGLISH JAPANESE
ENGLISH JAPANESE
電池の交換は，正しく行わないと破裂する恐れがあり
注意
ます。電池を交換する場合には必ず同じ型名の電池
又は同等品と交換してください。
サービス，点検時には次のことにご注意下さい。
1. 注意事項をお守りください。
サービスのとき特に注意を要する個所については，
キャビネット，シャーシ，部品などにラベルや捺印で
注意事項を表示しています。これらの注意書き及び取
扱説明書等の注意事項を必ずお守り下さい。
2. 指定部品のご使用を
セットの部品は難燃性や耐電圧など安全上の特性を
持ったものとなっています。従って交換部品は，使用
されていたものと同じ特性の部品を使用して下さい。
特に回路図，部品表に0印で指定されている安全上重要
な部品は必ず指定のものをご使用下さい。
3. 部品の取付けや配線の引きまわしはもとどおりに
安全上，チューブやテープなどの絶縁材料を使用した
り，プリント基板から浮かして取付けた部品がありま
す。また内部配線は引きまわしやクランパによって発
熱部品や高圧部品に接近しないよう配慮されています
ので，これらは必ずもとどおりにして下さい。
4. サービス後は安全点検を
サービスのために取外したネジ，部品，配線がもとど
おりになっているか，またサービスした個所の周辺を
劣化させてしまったところがないかなどを点検し，安
全性が確保されていることを確認して下さい。
5. チップ部品交換時の注意
• 取外した部品は再使用しないで下さい。
• タンタルコンデンサのマイナス側は熱に弱いため交
換時は注意して下さい。
6. フレキシブルプリント基板の取扱いについて
• コテ先温度を270℃前後にして行なって下さい。
• 同一パターンに何度もコテ先を当てないで下さい。
（3回以内）
• パターンに力が加わらないよう注意して下さい。
7. 無鉛半田について
無鉛半田を使用している基板には，無鉛（LeadFree）を意
味するレッドフリーマークがプリントされています。
（注意：基板サイズによっては，無鉛半田を使用して
いてもレッドフリーマークがプリントされて
いないものがあります）
：レッドフリーマーク
無鉛半田には，以下の特性があります。
• 融点が従来の半田よりも約40℃高い。
従来の半田こてをそのまま使用することは可能です
が，少し長めにこてを当てる必要があります。
温度調節機能のついた半田こてを使用する場合，約
350℃に設定して下さい。
注意： 半田こてを長く当てすぎると，基板のパター
ン（銅箔）がはがれてしまうことがあります
ので，注意して下さい。
• 粘性が強い
従来の半田よりも粘性が強いため，IC端子などが半田
ブリッジしないように注意して下さい。
• 従来の半田と混ぜて使用可能
無鉛半田には無鉛半田を追加するのが最適ですが，
従来の半田を追加しても構いません。
DCR-HC47E/HC48/HC48E_L2
— 6 —
Page 7
TABLE OF CONTENTS
Section Title Page
1. SERVICE NOTE
1-1. Power Supply During Repairs ·········································1-1
1-2. To Take Out a Cassette when not Eject (Force Eject) ·····1-1
1-3. Setting The “Forced Power On” Mode····························1-1
1-4. Using Service Jig····························································· 1-2
1-5. Self-diagnosis Function ···················································1-2
1-6. Precaution on Replacing The VC-472 Board ··················1-4
2. DISASSEMBLY
2-1. Disassembly·····································································2-2
3. BLOCK DIAGRAMS
3-1. Overall Block Diagram (1/6)···········································3-1
3-2. Overall Block Diagram (2/6)···········································3-2
3-3. Overall Block Diagram (3/6)···········································3-3
3-4. Overall Block Diagram (4/6)···········································3-4
3-5. Overall Block Diagram (5/6)···········································3-5
3-6. Overall Block Diagram (6/6)···········································3-6
3-7. Power Block Diagram (1/3)·············································3-7
3-8. Power Block Diagram (2/3)·············································3-8
3-9. Power Block Diagram (3/3)·············································3-9
4. PRINTED WIRING BOARDS AND
SCHEMATIC DIAGRAMS
4-1. Frame Schematic Diagram ··············································4-1
4-2. Schematic Diagrams························································ 4-3
4-3. Printed Wiring Boards ···················································4-29
4-4. Mounted Parts Location ················································4-41
5. REPAIR PARTS LIST
5-1. Exploded Vie ws ·······························································5-2
5-2. Electrical Parts List ·······················································5-11
DCR-HC47E/HC48/HC48E_L2
— 7 —
Page 8
ENGLISH JAPANESE
y
1. SERVICE NOTE
ENGLISH JAPANESE
1-1. POWER SUPPLY DURING REPAIRS
In this unit, about 10 seconds after power is supplied to the battery terminal using the regulated power supply (8.4V), the po wer is shut off so
that the unit cannot operate.
These following method is available to prevent this.
Method:
Use the AC power adaptor (AC-L200/L200B).
1-2. TO TAKE OUT A CASSETTE WHEN NOT EJECT (FORCE EJECT)
1 Refer to “2. DISASSEMBLY” to remove the mechanism deck block.
2 Supply +4.5V from the DC power supply to the loading motor and unload with a pressing the cassette compartment.
Loading motor
DC power suppl
(+ 4.5Vdc)
1-3. SETTING THE “FORCED POWER ON” MODE
It is possible to turn on power by adjustment remote commander (RM-95 or NEW LANC JIG).
Operate the VTR function using the adjustment remote commander.
1-3-1. Setting the “Forced Camera Power ON” Mode
1) Select page: 0, address: 01, and set data:01.
2) Select page: A, address: 10, set data:01 and press the “PAUSE (Write) ” button of the adjustment remote commander.
1-3-2. Setting the “Forced VTR Power ON” Mode
1) Select page: 0, address: 01, and set data:01.
2) Select page: A, address: 10, set data:02 and press the “PAUSE (Write) ” button of the adjustment remote commander.
1-3-3. Exiting the “Forced Power ON” Mode
1) Select page: 0, address: 01, and set data:01.
2) Select page: A, address: 10, set data:00 and press the “PAUSE (Write) ” button of the adjustment remote commander.
3) Select page: 0, address: 01, and set data: 00.
DCR-HC47E/HC48/HC48E_L2
1-1
Page 9
ENGLISH JAPANESE
ENGLISH JAPANESE
1-4. USING SERVICE JIG
Connect the CPC-15 jig connector (J-6082-564-A) and I/F unit for LANC control (J-6082-521-A) to the CN1014 of VC-472 board.
I/F unit for LANC control
(J-6082-521-A)
8
CN1014
VC-472 BOARD
(SIDE A)
1-5. SELF-DIAGNOSIS FUNCTION
1-5-1. Self-diagnosis Function
When problems occur while the unit is operating, the self-diagnosis
function starts working, and displays on the viewfinder or LCD
screen what to do.
Details of the self-diagnosis functions are provided in the Instruction
manual.
Viewfinder or LCD screen
C : 3 1 : 1 1
Blinks at 3.2Hz
1
CPC-15
(J-6082-564-A)
1-5-2. Self-diagnosis Display
When problems occur while the unit is operating, the counter of the
viewfinder or LCD screen shows a 4-digit display consisting of an
alphabet and numbers, which blinks at 3.2 Hz. This 5-character
display indicates the “repaired by:”, “block” in which the problem
occurred, and “detailed code” of the problem.
Repaired by:
C : Corrected by customer
H : Corrected by dealer
E : Corrected by service
engineer
Indicates the appropriate
step to be taken.
E.g.
31 ....Reload the tape.
32 ....Turn on power again.
DCR-HC47E/HC48/HC48E_L2
3 1C
Block
1 1
Detailed Code
Refer to “1-5-3. Self-diagnosis Code Table”.
1-2
Page 10
1-5-3. Self-diagnosis Code Table
Self-diagnosis Code
ENGLISH JAPANESE
ENGLISH JAPANESE
Repaired by:
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
Block
Function
04
21
22
31
31
31
31
31
31
31
31
31
31
31
31
31
32
32
32
32
32
32
32
32
32
32
32
32
32
Detailed
Code
00
00
00
10
11
20
21
22
23
30
31
40
41
42
43
44
10
11
20
21
22
23
30
31
40
41
42
43
44
Symptom/State
Non-standard battery is used.
Condensation.
Video head is dirty.
LOAD direction. Loading does not
complete within specified time
UNLOAD direction. Loading does not
complete within specified time
T reel side tape slacking when unloading
S reel
side tape slacking when unloading
T reel fault.
S reel fault.
FG fault when starting capstan.
FG fault during normal capstan operations.
FG fault when starting drum.
PG fault when starting drum.
FG fault during normal drum operations.
PG fault during normal drum operations.
Phase fault during normal drum operations.
LOAD direction loading motor time-
out.
UNLOAD direction loading motor
time-out.
T reel side tape slacking when
unloading.
S reel side tape slacking when
unloading.
T reel fault.
S reel fault.
FG fault when starting capstan.
FG fault during normal capstan
operations.
FG fault when starting drum.
PG fault when starting drum.
FG fault during normal drum
operations.
PG fault during normal drum
operations.
Phase fault during normal drum
operations.
Correction
Use the InfoLITHIUM battery.
Remove the cassette, and insert it again after one hour.
Clean with the optional cleaning cassette.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
.
Load the tape again, and perform operations from the beginning.
.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
DCR-HC47E/HC48/HC48E_L2
1-3
Page 11
Self-diagnosis Code
ENGLISH JAPANESE
ENGLISH JAPANESE
Repaired by:
E
E
E
E
E
Block
Function
61
61
61
62
62
Detailed
Code
00
10
11
00
01
Symptom/State
Difficult to adjust focus
(Cannot initialize focus.)
Zoom operations fault
(Cannot initialize zoom lens.)
Focus lens initializing failure and zoom
lens initializing failure occur simultaneously.
Steadyshot function does not work well.
(With pitch angular velocity sensor output
stopped.)
Steadyshot function does not work well.
(With yaw angular velocity sensor output
stopped.)
Inspect the lens block focus reset sensor (Pin 7 of CN3801 of VC472 board) when focusing is performed when the touch panel is
operated in the focus manual mode and the focus motor drive circuit
(IC3802 of VC-472 board) when the focusing is not performed.
Inspect the lens block zoom reset sensor (Pin qa of CN3801 of
VC-472 board) when zooming is performed when the zoom switch
is operated and the zoom motor drive circuit (IC3802 of VC-472
board) when zooming is not performed.
Inspect the flexible board for breakage or loose connection.
If not faulty, inspect the f ocus and zoom motor dri ve circuit (IC3802
of VC-472 board).
Inspect pitch angular velocity sensor (SE7002 of CD-672 board)
peripheral circuits.
Inspect yaw angular velocity sensor (SE7001 of CD-672 board)
peripheral circuits.
1-6. PRECAUTION ON REPLACING THE VC-472 BOARD
Correction
Exif Model Data Check
When you replace to the repairing board, the written data of repairing board also might be changed to original setting.
When the data has changed because of board replaceing etc, check the data setting (Exif Model Data) is right. If not, rewrite to the right value.
Exif Model Data
Page
C
C
C
Writing Method:
1) Select page: 0, address: 01 and set data: 01.
2) Select page: C, address: D2 to D4, and set the Exif Model Data.
Note: To write in the non-volatile memory (EEPROM), press the PAUSE (Write) button each time to set the data.
3) Select page: 0, address: 01, and set data: 00.
Address
D2
D3
D4
DCR-HC47E
34
37
45
Data
DCR-HC48
34
38
00
DCR-HC48E
34
38
45
DCR-HC47E/HC48/HC48E_L2
1-4
Page 12
ENGLISH JAPANESE
1. SERVICE NOTE
ENGLISH JAPANESE
1-1. 修理時の電源供給について
本機では，安定化電源（8.4Vdc）からバッテリ端子に電源を供給した場合，約10秒後にシャットオフし，動作しなくなります。
これを避けるため，下記の方法を用いてください。
方法：
DC入力端子を使用する。（ACアダプタ（AC-L200/L200B）を使用する。）
1-2. イジェクトしない時のカセット取出し方法（強制イジェクト）
1 2.DISASSEMBLYを参照し，メカデッキを外す。
2 カセコン組立を押さえながら，安定化電源より＋4.5Vをローディングモータに加え，アンローディングさせる。
ȕÀǯNjțǘȊÀǧ
ϖୖҍஏڿÎ8FEÏ
1-3. 強制電源ONモードの設定
調整リモコン（RM-95またはNEWLANCJIG）を使用して，電源を入れることが出来ます。
VTR操作は調整リモコンで行えます。
1-3-1. 強制カメラ電源ONモードの設定
1) ページ：0，アドレス：01にデータ：01をセット。
2) ページ：A，アドレス：10にデータ：01をセットしPAUSE（Write）ボタンを押す。
1-3-2. 強制VTR電源ONモードの設定
1) ページ：0，アドレス：01にデータ：01をセット。
2) ページ：A，アドレス：10にデータ：02をセットしPAUSE（Write）ボタンを押す。
1-3-3. 強制電源ONモードの解除
1) ページ：0，アドレス：01にデータ：01をセット。
2) ページ：A，アドレス：10にデータ：00をセットしPAUSE（Write）ボタンを押す。
3) ページ：0，アドレス：01にデータ：00をセット。
DCR-HC47E/HC48/HC48E_L2
1-5
Page 13
ENGLISH JAPANESE
ENGLISH JAPANESE
1-4. 使用サービス治具
CPC-15治具コネクタ（J-6082-564-A），LANC変換用I/F（J-6082-521-A）をVC-472基板CN1014に接続します。
I/F unit for LANC control
(J-6082-521-A)
8
CN1014
VC-472 BOARD
(SIDE A)
1-5. 自己診断機能
1-5-1. 自己診断機能について
本機の動作に不具合が生じたとき，自己診断機能が働き，
ビューファインダまたはL C D 画面に，どう処置したらよい
か判断できる表示を行います。自己診断機能については取扱
説明書にも掲載されています。
ǻȍÀǽljnjțǨƳƔƤ.%&Ҹศ
C : 3 1 : 1 1
1
CPC-15
(J-6082-564-A)
1-5-2. 自己診断表示
本機の動作に不具合が生じたとき，ビューファインダまたは
LCD画面のカウンタ表示部分がアルファベットと数字の4桁
表示になり，3.2H z で点滅します。この5 文字の表示によっ
て対応者分類および不具合の生じたブロックの分類，不具合
の詳細コードを示します。
Ѱࡐൌ
% «ſּƊƳࠧƜѰ
* «ಲ౪ஃƜѰ
' «ǝÀǻǡǐțǠdzNJ
ƜѰ
ǾȕǫǗൌ
ѰඝඟƣϷŹƠƽƿൌ
gggǮÀǿLJదǁପƎ
gggஏڿLJదǁପƎ
DCR-HC47E/HC48/HC48E_L2
*\ஊร
3 1C
1 1
ޙǛÀDZ
ÚࠧێǛÀDZÛ
LJߐ
1-6
Page 14
1-5-3. 自己診断コード表
自己診断コード
対
応
者
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
ブロック
機能
04
21
22
31
31
31
31
31
31
31
31
31
31
31
31
31
32
32
32
32
32
32
32
32
32
32
32
32
32
詳細
コード
00
00
00
10
11
20
21
22
23
30
31
40
41
42
43
44
10
11
20
21
22
23
30
31
40
41
42
43
44
症状／状態
標準でないバッテリを使用している
結露している
ビデオヘッドが汚れている
LOAD方向，ローディング所定時間
内終了せず
UNLOAD方向，ローディング所定時
間内終了せず
UNLOAD時，Tリール側テープ弛み
UNLOAD時，Sリール側テープ弛み
Tリール異常
Sリール異常
キャプスタン起動時FG異常
キャプスタン定常時FG異常
ドラム起動時FG異常
ドラム起動時PG異常
ドラム定常時FG異常
ドラム定常時PG異常
ドラム定常時位相異常
LOAD方向，ローディング所定時間
内終了せず
UNLOAD方向，ローディング所定時
間内終了せず
UNLOAD時，Tリール側テープ弛み
UNLOAD時，Sリール側テープ弛み
Tリール異常
Sリール異常
キャプスタン起動時FG異常
キャプスタン定常時FG異常
ドラム起動時FG異常
ドラム起動時PG異常
ドラム定常時FG異常
ドラム定常時PG異常
ドラム定常時位相異常
ENGLISH JAPANESE
ENGLISH JAPANESE
対応／方法
インフォリチウムバッテリを使用する
カセットを取り出して，約１時間してからもう一度入れ直す
別売のクリーニングカセットできれいにする
テープを入れ直し，再度操作し直す
テープを入れ直し，再度操作し直す
テープを入れ直し，再度操作し直す
テープを入れ直し，再度操作し直す
テープを入れ直し，再度操作し直す
テープを入れ直し，再度操作し直す
テープを入れ直し，再度操作し直す
テープを入れ直し，再度操作し直す
テープを入れ直し，再度操作し直す
テープを入れ直し，再度操作し直す
テープを入れ直し，再度操作し直す
テープを入れ直し，再度操作し直す
テープを入れ直し，再度操作し直す
バッテリまたは電源ケーブルを外して付け直し，再度操作し直す
バッテリまたは電源ケーブルを外して付け直し，再度操作し直す
バッテリまたは電源ケーブルを外して付け直し，再度操作し直す
バッテリまたは電源ケーブルを外して付け直し，再度操作し直す
バッテリまたは電源ケーブルを外して付け直し，再度操作し直す
バッテリまたは電源ケーブルを外して付け直し，再度操作し直す
バッテリまたは電源ケーブルを外して付け直し，再度操作し直す
バッテリまたは電源ケーブルを外して付け直し，再度操作し直す
バッテリまたは電源ケーブルを外して付け直し，再度操作し直す
バッテリまたは電源ケーブルを外して付け直し，再度操作し直す
バッテリまたは電源ケーブルを外して付け直し，再度操作し直す
バッテリまたは電源ケーブルを外して付け直し，再度操作し直す
バッテリまたは電源ケーブルを外して付け直し，再度操作し直す
DCR-HC47E/HC48/HC48E_L2
1-7
Page 15
自己診断コード
対
ブロック
応
機能
者
E
61
E
61
E
61
E
62
E
62
詳細
コード
00
10
11
00
01
（フォーカスの初期化ができない）
（PITCH角速度センサ出力張り付き）
（YAW角速度センサ出力張り付き）
症状／状態
フォーカスが合いにくい
ズーム動作の異常（ズームレンズの
初期化ができない）
フォーカスレンズ初期化異常，ズー
ムレンズ初期化異常の同時発生
手振れ補正が効きにくい
手振れ補正が効きにくい
ENGLISH JAPANESE
ENGLISH JAPANESE
対応／方法
フォーカス手動モードでタッチパネルを操作した時，
フォーカス動作をすればレンズブロックのフォーカスリ
セットセンサ（VC-472基板CN38017ピン）を点検。フォーカ
ス動作をしなければフォーカスモータドライブ回路（VC472基板IC3802）を点検。
ズームレバーを操作した時，ズーム動作をすればレンズブ
ロックのズームリセットセンサ（VC-472基板CN3801qaピ
ン）を点検。ズーム動作をしなければズームモータドライブ
回路（VC-472基板IC3802）を点検。
フレキシブル基板の切れ，半挿しを点検。
問題がなければフォーカス，ズームモータドライブ回路（VC472基板IC3802）を点検。
PITCH角速度センサ（CD-672基板SE7002）周辺回路点検
YAW角速度センサ（CD-672基板SE7001）周辺回路点検
1-6. VC-472基板交換時の注意
Exif機種データ確認
補修用基板と交換する時，補修用基板に書かれているデータは元の設定と違っている場合があります。
基板交換などでデータが変更された場合は，E x i f 機種データが正しいか確認し，違っている場合は正しい値に書き換えて下
さい。
Exif機種データ
ページ アドレス
CD2 34
CD3 38
CD4 00
書き換え方法：
1） ページ：0，アドレス：01にデータ：01をセットする。
2） ページ：C，アドレス：D2〜D4にExif機種データをセットする。
注：不揮発性メモリ（EEPROM）に書き込むため，データをセットする度にPAUSE（Write）ボタンを押してください。
3） ページ：0，アドレス：01にデータ：00をセットする。
データ
DCR-HC48
DCR-HC47E/HC48/HC48E_L2
1-8E
Page 16
NOTE FOR REPAIR
2. DISASSEMBLY
• Make sure that the flat cable and flexible board are not cracked of bent at the terminal.
Do not insert the cable insufficiently nor crookedly.
• When remove a connector, don’t pull at wire of connector. It is possible that a wire is snapped.
• When installing a connector, don’t press down at wire of connector.
It is possible that a wire is snapped.
Cut and remove the part of gilt
which comes off at the point.
(Be careful or some
pieces of gilt may be left inside)
DCR-HC47E/HC48/HC48E_L2
2-1
Page 17
HELP
EXPLODED VIEW
HELP
2-1. DISASSEMBLY
2-1-1. OVERALL SECTION
Follow the disassembly in the numerical order given.
1 Cabinet (R) Section (1-1 to 1-14)
2 Front Cabinet Block (2-1 to 2-6)
2-1 (#2)
2-3
2-4 (#1)
1-1
(Open)
1-2 (#2)
1-3
1-5
1-4
Note:On installation of the NS knob,
adjust the position of the NS
switch and the NS knob.
1-6
(#2)
1-12
(Boss)
HARDWARE LIST
1 Cabinet (R)
Section
1-11
(Boss)
1-10
(Claw)
2-2 (#2)
2-5 (#1)
2-6
2 Front Cabinet
Block
1-14
1-13
1-7
(#2)
1-9
(#2)
1-8
(Open)
DCR-HC47E/HC48/HC48E_L2
2-2
Page 18
2-1-2. BOTTOM FRAME SECTION
EXPLODED VIEW
Follow the disassembly in the numerical order given.
1 BT-EVF Section (1-1 to 1-3)
2 CR-082 Board (2-1 to 2-2)
3 MS-342 Board (3-1 to 3-7)
HARDWARE LIST
1 BT-EVF Section
1-1 (#2)
1-2
1-3
3-1
3-2
3-6
3-4
3-3 (#1)
3 MS-342 Board
MS-342
3-7 (#3)
3-5 (Claw)
2-1 (#3)
CR-082
2-2
2 CR-082 Board
DCR-HC47E/HC48/HC48E_L2
2-3
Page 19
2-1-3. CABINET (L) SECTION
EXPLODED VIEW
Follow the disassembly in the numerical order given.
1 Lens Block (1-1 to 1-3)
2 VC-472 Board (2-1 to 2-8)
3 Mechanism Deck (3-1 to 3-3)
3 Mechanism Deck
HARDWARE LIST
1-2 (#12)
2-3
3-3 (#15)
1 Lens Block
2-6
(Claw)
1-1
1-3
CD672
2 VC-472
Board
DCR-HC47E/HC48/HC48E_L2
3-1 (Claw)
3-2
2-5 (Claw)
2-4
2-2
VC-472
2-4 (#3)
2-1
2-8
2-7
Page 20
2-1-4. CABINET (R) SECTION
1 CF-102 Board
2 LCD Panel
Block
1-1
1-4
1-2 (#12)
1-6 (#12)
1-5 (#12)
1-3
2-2
2-1 (#12)
2-3 (#12)
HELP
Note:On installation of the CF-102
board, adjust the position of
the Panel Open/Close switch.
2-4
HELP
1-7
(Claw)
EXPLODED VIEW
Follow the disassembly in the numerical order given.
1 CF-102 Board (1-1 to 1-7)
2 LCD Panel Block (2-1 to 2-4)
HARDWARE LIST
DCR-HC47E/HC48/HC48E_L2
2-5E
Page 21
HELP
Sheet attachment positions and procedures of processing the flexible boards/harnesses are shown.
Harness arrangement
Loud SpeakerCF-102 Board
THE METHOD OF ATTACHMENT OF FP-625 FLEXIBLE BOARD
1 Fold dotted line parts of the FP-625 flexible board
as shown in figure.
Valley fold
Adhesive tape
Mountain
fold
Adhesive tape
Valley fold
Mountain
fold
DCR-HC47E/HC48/HC48E_L2
Stick it together in the adhesive tape
while bending the FP-625 flexible board.
HELP
Page 22
2 Put the FP-625 flexible board on the
hinge cover (M).
3 Fix hinge cover (M) and the panel hinge assy (M)
with the screw.
Hinge cover (M)
FP-625 flexible board
4 Install the hinge cover (C) in the hinge cover (M).
Hinge cover (M)
Screw
Hinge cover (M)
Panel hinge assy (M)
Hinge cover (C)
DCR-HC47E/HC48/HC48E_L2
Claw
HELP
Page 23
STICKING PROCEDURE OF R ORNAMENTAL PLATE
1 Peel off the stripping paper stuck on the adhesive
sheet on the R ornamental plate.
3 On the basis of the dents, stick the R ornamental
plate on the cabinet (R) assy.
4 Press strongly the adhesive sheet so as to settle
the R ornamental plate firmly.
2 Place two corners of the R ornamental plate in
contact with the dents of the cabinet (R) assy.
Adhesive sheet
R ornamental plate
Dents
R ornamental plate
R ornamental plate
Adhesive sheet
Cabinet (R) assy
Stripping paper
Cabinet (R) assy
Do not drop because it is easy to
CAUTION
bend in the R ornamental plate.
DCR-HC47E/HC48/HC48E_L2
HELP
Page 24
Link
Link
3. BLOCK DIAGRAMS
OVERALL BLOCK DIAGRAM (1/6)
OVERALL BLOCK DIAGRAM (2/6)
OVERALL BLOCK DIAGRAM (3/6)
OVERALL BLOCK DIAGRAM (4/6)
OVERALL BLOCK DIAGRAM (5/6)
OVERALL BLOCK DIAGRAM (6/6)
POWER BLOCK DIAGRAM (1/3)
POWER BLOCK DIAGRAM (2/3)
POWER BLOCK DIAGRAM (3/3)
DCR-HC47E/HC48/HC48E_L2
Page 25
3. BLOCK DIAGRAMS
3-1. OVERALL BLOCK DIAGRAM (1/6)
LENS BLOCK
IRIS
(SHUTTER)
IRIS
METER
M
H
FOCUS
MOTOR
M
ZOOM
MOTOR
M
FOCUS
SENSOR
ZOOM
SENSOR
LENS TEMP
SENSOR
IRIS_DRIVE (-)
IRIS_DRIVE (+)
IRIS_BIAS (-)
IRIS_HALL (-)
IRIS_BIAS (+)
IRIS_HALL (+)
FOCUS_XA, FOCUS_A,
FOCUS_XB, FOCUS_B
ZOOM_A, ZOOM_XA,
ZOOM_XB, ZOOM_B
FC_SENSE_OUT
ZM_SENSE_OUT
TEMP_OUT
CD-672 BOARD
IC7002
IMAGER
SE7002
PITCH SENSOR
SE7001
YAW SENSOR
CN3801
14
13
17
18
15
16
21 - 241 - 4
7
11
6
CCD
Q3801
IRIS
DRIVE
Q3803
AMP
12
V1 - V6, RG, H1, H2, SUB
7 - 2, 14, 18, 16, 19
1
Q7001
8
12
F3 G1
( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
VC-472 BOARD (1/6)
Q7002
CLAMP
IC7003
PITCH/YAW
SENSOR
AMP
IC3803
IC3804
(2/17)
IRIS DRIVE
HALL GAIN
HALL AMP
IC3802
(2/17)
IRIS DRIVE
FOCUS
MOTOR
DRIVE
F2, E2, D2, B1C6, B7, E6, D6
ZOOM
MOTOR
DRIVE
CN7001
RCSUB
2
18
19
E4F4
D5, B6, A6, C5 F5, G6, D3, E3
27
7
4
2
3
EN0, DIR0A, DIR0B
EN1, DIR1A, DIR1B
CN3201
2
23, 20 - 15, 12, 10, 8
6, 9 - 14, 17, 19, 21
22
25
27
26
IRIS_PWM
HALL_GAIN
HALL_REF
HALL_OFFSET
I_HALL_AD
SHUTTER_ON
CAM_DD_ON
FC_RST
ZM_RST
LENS_TEMP_AD
CCD_OUT+
PITCH_AD
YAW_AD
VST_C_RESET
K4
C8, C1, B7, B1, A1
H10, G8, F8, E8, C9,
IC3201
A/D CONVERTER,
TIMING
GENERATOR
(1/17)
AD2 - AD13
B8 - B10, C7,
E10, F9, F10, G9
C10, D8, D9, E9,
CAM_VD
C4
TG_HD
C5
TG_ID
J9
VSG1
G2 83
ZV1
J2
CHCK
A8
XSYS_RST
B6
X3201
27MHz : PAL
K9, J10, J6, H9
H2
CAM_DD_ON
CH_CS, CH_SI, CH_SO, CH_SCK
33MHz : NTSC
CAM_VD
XSYS_RST
SHUTTER_ON
PITCH_AD
YAW_AD
VST_C_RESET
IRIS_PWM
I_HALL_AD
LENS_TEMP_AD
XNS_SW
CSUB
TG_FLD
58, 59, 62 - 71
92
IC3901
84
CAMERA SIGNAL
PROCESS
(3/17)
82
137
99
98
90 25
D13
IC5301
AC9, Y9
Y6, Y10,
(1/2)
CAMERA
P22
CONTROL
P23
(13/17)
T2
Y16
P20
R22
A13 Y18
208 - 202,
115
167
195 - 191,
188 - 185,
182 - 178,
161 - 156,
153 - 148,
24
122
A7
AB10, C22
AB11, Y11,
D14
M22
Y17, L20
U2
199
9 - 611 - 13
175, 174
145, 144
32, 108, 109
20 - 23
ZOOM_VR_AD
XCS_AU1
XRST_VTR
XSYS_RST
SYS_V
SPCK
CAM_VD
IFI_Y0 - IFI_Y7
IFI_C0 - IFI_C3
IFI_HD, IFI_VD, IFI_OE
MEMCK_OUT
MDQ0 - MDQ15
MA0 - MA13
2, 4, 5, 7, 8, 10,
38
11, 13, 42, 44, 45,
47, 48, 50, 51, 53
CAM_SI, CAM_SO, CAM_SCK
CAM_VD
CAM_SI, CAM_SO, CAM_SCK, CAM_CS
VCK
VCK
20 - 26,
29 - 35
IC4002
64M SDRAM
(4/17)
EN0, DIR0A, DIR0B
EN1, DIR1A, DIR1B
FC_RST
ZM_RST
SPCK
SYS_VSYS_V
XSYS_RST
XSYS_RST
SYS_V
ZOOM_VR_AD
XPWAD, XPWDAXPWAD, XPWDA
XCS_AU1
XRST_VTR
SPCK
XRST_VTR
SPCK
1
216 - 223224 - 227228 - 230
VIDEO DSP,
241
LENS CONTROL
196
208, 207,
205 - 198
215 - 210,
171, 170
174, 173,
185 - 176,
156
159, 158,
236
239, 246, 247248, 250, 251
237
238
139
157
141
2
3
4
5
OVERALL (2/6)
(PAGE 3-2)
IC4001
(1/4)
(4/17)
OVERALL (6/6)
(PAGE 3-6)
OVERALL (5/6)
(PAGE 3-5)
OVERALL (3/6)
(PAGE 3-3)
OVERALL (4/6)
(PAGE 3-4)
NIGHTSHOT
PLUS
DCR-HC47E/HC48/HC48E_L2
NS_SW
19
A : VIDEO SIGNAL
05
XNS_SW
3-1
CAM_DD_ON
HALL_GAIN
HALL_REF
HALL_OFFSET
6
OVERALL (6/6)
(PAGE 3-6)
Page 26
3-2. OVERALL BLOCK DIAGRAM (2/6)
VC-472 BOARD (2/6)
( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
OVERALL (1/6)
(PAGE 3-1)
VCK
1
VCK
DSCK_VM
XSYS_RST
SFD_BCK
SFD_LRCK
143
119, 162,
121,
70,
164, 165168, 127
13, 72
14, 73
166
123 - 125,
12, 75
167, 126
15
62
21
78
120, 163
, 122
71
DV SIGNAL
IC4201
PROCESS
(7/17)
RECDT
45
RECA1, RECA2
48, 47
RECCK
41
RFIN
139
LBUS0 - LBUS3
150, 187
149, 186,
104
152 – 155,
189, 190, 192
54, 55, 57,
107, 109, 110,
188
XCS_IC_4201
158
60
VSP_SI, VSP_SO, XVSP_SCK
157, 114, 3
FRRV, TRRV,
TRRT, DRP
111, 59
58, 112,
TRCKO
RECDT
RECA1, RECA2
IC4101
DV
INTERFACE
24, 26 - 28
(8/17)
62
19
D24A00 - D31A07, DXXA08, DXXA09, ALE, WRX, RDX
TPA+, TPA-, TPB+, TPB-
52, 51, 48, 47
78
39
2 - 4,
75 - 77
6 - 9, 11,
XCS_IC_4101
IC_4101_SLEEP
D24A00 - D31A07,
ALE, WRX, RDX
CS_IC_4201_BUSCS_IC_4201_BUS
XCS_IC_4201
RECCK
RFIN
SWPSWP
11
12
OVERALL (3/6)
(PAGE 3-3)
OVERALL (3/6)
(PAGE 3-3)
TPA+, TPA-, TPB+, TPB-
13
OVERALL (5/6)
(PAGE 3-5)
IC4001
(2/4)
VIDEO/AUDIO
DSP
(4/17)
20
268 - 271
279 - 282
287, 288301, 302
264 - 267
275, 276
272, 273,
284, 285
298, 299
LCKO
RYO0 - RYO3
RCO0 - RCO3
HYO, HCO
ADATAIN0, ADATAIN1
RYI0 - RYI3
RCI0 - RCI3
HYI, HCI
ADATAOUT0,1
OVERALL (3/6)
(PAGE 3-3)
OVERALL (4/6)
(PAGE 3-4)
OVERALL (5/6)
(PAGE 3-5)
OVERALL (6/6)
(PAGE 3-6)
7
8
9
10
XCS_IC_4001
IC_4001_CS
USB_XEN
VFI_OE
ALIGN_VD
LINEOUT_V
VREF
DSCK_VM
SFD_BCK
SFD_LRCK
LINEOUT_V
149
154
80
160
161
164
165
86, 168, 169
150 - 152
28, 29
79
24
144
148
119
122, 121
137 - 124,
116 - 98
USB_CLK
LXCS
LXWAIT
DSCK_VM
D0_VM - D15_VM
A1_VM - A19_VM
TRRT, FRRV, TRRV
VSP_SI, VSP_SO, XVSP_SCK
D0_VM - D15_VM
A1_VM - A21_VM
2 - 11,
33 - 36,
20 - 27,
39 - 46,
30, 31, 55
49 - 52
IC5202
32M FLASH
(6/17)
LXWAIT
DSCK_VM
15
53
1913
USB_D+
USB_D+, USB_D-
A13_VM
A1_VM - A11_VM,
2, 3, 5, 6, 8, 9, 11,
19 - 24,
12, 39, 40, 42, 43,
27 - 32
45, 46, 48, 49
IC5203
16M SDRAM
(6/17)
Q4005
USB
PULL UP
DSCK_VM
D0_VM - D15_VM
35
USB_3.1V
USB_PULLUP
USB_D+, USB_D-
USB_CLK
SFD_LRCK
LXCS
LXWAIT
DSCK_VM
D0_VM - D15_VM
A1_VM - A21_VM
XCS_SDRAM_VM
18
XCS_FLASHXSYS_RST
FRRV, TRRV, TRRT, DRP
VSP_SI, VSP_SO, XVSP_SCK
V12
N1, P1
L1
IC5101
(1/3)
C7
DS CONTROL
(5/17)
B16
V19
A10
K18 - K21
F19 - F21,
G19, G20,
J18 - J21,
H18 - H20,
AA18, AA19
R18, R19, T19,
L20, M18, M19,
W18 - W21, Y19,
N18,N19, P18, P19,
U19, U20, V20, V21,
C17
A18
M2
Y18
A14, C15, D14
A15
Q5101
LED
DRIVE
MS_DIO, MS_BS, MS_SCLK
XMS_LED_ON
MS_INSERT
USB_D+, USB_D-USB_D+, USB_D-
USB_DET
MS-342 BOARD
(MS ACCESS)
CN1011
2 9
4, 5, 7
6
CN602
4, 6, 7
5
DIO, BS, SCLK
A : VIDEO SIGNAL
A : AUDIO SIGNAL
A : VIDEO/AUDIO SIGNAL
A : VIDEO/AUDIO/SERVO SIGNAL
D601
INS
CN601
6
4, 2, 8
MEMORY
STICK
DUO
05
DCR-HC47E/HC48/HC48E_L2
3-2
Page 27
3-3. OVERALL BLOCK DIAGRAM (3/6)
VC-472 BOARD (3/6)
( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
N MECHANISM DECK
(MDX-N110)
VIDEO HEAD
(FOR CHECK)
OVERALL (1/6)
(PAGE 3-1)
OVERALL (2/6)
(PAGE 3-2)
OVERALL (5/6)
(PAGE 3-5)
OVERALL (4/6)
(PAGE 3-4)
OVERALL (2/6)
(PAGE 3-2)
OVERALL (6/6)
(PAGE 3-6)
CPC
CN1014
RF_MON
1
SWP
2
XCS_EEP
4
EEP_SI, EEP_SO, EEP_SCK
7 - 5
XRST_VTR
4
IC5302
32k EEPROM
12
14
15
7
16
1
IC1002
REMOTE
SENSOR
(13/17)
2, 5, 6
EEP_SI, EEP_SO, EEP_SCK
3
(13/17)
D24A00 - D31A07, DXXA08, DXXA09, ALE, WRX, RDX
XCS_IC_4101
IC_4101_SLEEP
CS_IC_4201_BUS
XCS_IC_4201
SWP
FRRV, TRRV, TRRT, DRP
VSP_SI, VSP_SO, XVSP_SCK
VSP_SO, XVSP_SCK
VSP_SI, VSP_SO, XVSP_SCK
VD_SI, VD_SO, VD_SCK
XCS_EVF
EVF_BL_ON
PANEL_BL_ON
XCS_IC_4701
HI_SI, HI_SO, XHI_SCK, XCS_MECHA
CHIME_SDA, CHIME_SCK
XCS_IC_4001
IC_4001_CS
USB_XEN
VFI_OE
ALIGN_VD
LINEOUT_V
VREF
XSYS_RST
XCC_DOWN
XCS_EEP
SIRCS_SIG
A18, G2, M4
F1
AB14, AC14, AB13
W2, Y1, V4,
V2, W1, P2,
AA2, Y2, W4,
P1, K4, L1, L4
J2
A6
M1
IC5301
B2
(2/2)
B21
MECHA
CONTROL
L2, D15,
A16, A21
(13/17)
AC7
AC8, AB8,
Y12
Y13, AC12,
U1
V22
AB9
F20
Y7, AB7,
AB6, AC6
E23
B13
B10
Y8
B6
B8
B7
F2
F4
A10
RECDT
OVERALL (2/6)
(PAGE 3-2)
VSP_SO, XVSP_SCK
XRST_VTR
XCS_IC_6001
H4
DRUM_PWM
Y14
CAP_PWM
AC15
XFFREW_UP
AC13
A9
B9
CAP_FWD, CAP_ON
D19, B20
D11
DEW_AD
V23
MODE_SW_A - MODE_SW_C
AB22
-
AB20
LOAD, UNLOAD
H2, G4
LM_LIM_DET LM_LIM_DET
L22
TAPE_END
B12
TAPE_TOP
D10
TREEL_FG
B11
SREEL_FG
A11
TAPE_LED_ON
B15
REC_PROOF
Y23
D1
X5301
20MHz
C1
38, 36
IC6001
(3/3)
34
Q6001
35
37
44
41
(14/17)
SERIAL
INTERFACE
LPF
45
43
DRUM_ERROR
CAP_ERROR
DRUM_FG
DRUM_PG
CAP_FG
7
21
24
8
IC2201
(1/2)
DRUM/
CAPSTAN
PWM DRIVE
(17/17)
77
75
SPCKSPCK
Q2208
SWITCHING
SWITCHING
Q2217
11
RECA1, RECA2
RECCK
RFIN
CONT1, SW_PS, ALL_PSCONT1, SW_PS, ALL_PS
RF_MON
SWP
DRUM_VS
CAP_FWD, CAP_ON
Q6003
LED
DRIVE
46
40, 42
44
IC4301
35
REC/PB AMP
30
38
39, 37, 45
DRUM_FG
DRUM_PG
CAP_VS
CAP_FG
LOAD, UNLOAD
TAPE_END
TAPE_TOP
TREEL_FG
SREEL_FG
(9/17)
53
50
31
21 20
19
29
25
10, 93, 4
IC6001
(1/3)
(14/17)
DRUM
MOTOR
64, 67
DRIVE
FG AMP
52
PG AMP
49
CAPSTAN
75, 771, 80
MOTOR
DRIVE
FG AMP
4
MODE_SW_A - MODE_SW_C
IC6001
(2/3)
(14/17)
LOADING
MOTOR
32, 33
DRIVE
TAPE END
DETECT
TAPE TOP
18
DETECT
T REEL
FG AMP
S REEL
FG AMP
CHIME_SDA, CHIME_SCK
XODD, YODD
XEVEN, YEVEN
DRUM_U, V, W
63, 65, 6874, 76, 78
FG
PG
CAP U, V, W
UHE±,
VHE±,
WHE±
10 - 157, 8
FG1, FG2
DEW_AD
LM ±
69, 7226, 2722, 23
TAPE_END_C
TAPE_TOP_C
T_REEL ±
S_REEL ±
TAPE_LED_K
REC_PROOF
XCC_DOWN
CN1008
CN1009
CN1010
CN1007
10
9
6
28
16
25
11
18
6, 52, 3
1 - 6
20 - 92 - 77 - 91 - 420, 1922, 2313, 14 27, 24
M901
DRUM MOTOR
M
DRUM FG
DRUM PG
M903
CAPSTAN MOTOR
M
HU, HV, HW
CAPSTAN FG
DEW SENSOR
S903
MODE SWITCH
M902
LOADING MOTOR
M
Q901
TAPE END
SENSOR
Q902
TAPE TOP
SENSOR
H902
T REEL
SENSOR
H901
S REEL
SENSOR
MIC902
S902
REC PROOF
4PIN
CONNECTOR
S901
CC DOWN
ODD
EVEN
TAPE LED
D901
05
DCR-HC47E/HC48/HC48E_L2
A : VIDEO/AUDIO/SERVO SIGNAL
A : SERVO SIGNAL
3-3
Page 28
3-4. OVERALL BLOCK DIAGRAM (4/6)
VC-472 BOARD (4/6)
( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
LB-132 BOARD
IC4001
CONVERTER
OVERALL (1/6)
(PAGE 3-1)
OVERALL (2/6)
(PAGE 3-2)
OVERALL (5/6)
(PAGE 3-5)
OVERALL (3/6)
(PAGE 3-3)
(3/4)
D/A
(4/17)
40
39
45
92, 93
15
PANEL_R
PANEL_G
PANEL_B
PANEL_HD, PANEL_VD
XRST_VTR
5
8
17
SPCK
DSCK_VM
IC_4401_Y_OUT_M
IC_4401_C_OUT_M
VSP_SI, VSP_SO, XVSP_SCK
XCS_IC_4701
VD_SI, VD_SO, VD_SCK
XCS_EVF
EVF_BL_ON
PANEL_BL_ON
40
38
36
3, 4
5
19
7
42
44
10, 11, 13
12
IC4701
ASPECT
RATIO
CONVERTER
(10/17)
30
28
26
32
34
22, 23
IC_4701_Y
IC_4701_C
20
PANEL_R_M
PANEL_G_M
PANEL_B_M
PANEL_XHD_M, PANEL_XVD_M
OVERALL (5/6)
(PAGE 3-5)
XSYS_RST
VD_SI, VD_SO, VD_SCK
XCS_EVF
XSYS_RST
EXTDA
EVF BACKLIGHT
34
33
32
43
31
6
–
5
+
IC7002
(2/2)
CONTROL
(12/17)
IC7001
LCD/EVF
DRIVE
(12/17)
42, 45, 44 48, 1
3
7
EVF_BL_ON
PANEL_BL_ON
20
21
22
26
28
5 - 9, 11, 12,
14, 16, 30, 24
10
18
Q7006
BACKLIGHT
DRIVE
CN7001
15
16
14
18
9
20
EVF_COM
EVF_HST, EVF_HCK1,
EVF_HCK2,EVF_VCK,
EVF_PCG, EVF_REF,
EVF_VST, EVF_EN,
EVF_PSIG, EVF_DWN,
3 - 8, 10 - 13, 17
FP-625 FLEXIBLE
CN7002
BOARD (1/2)
(1/2)
PANEL_VR
1
PANEL_VG
2
PANEL_VB
3
30 1
HST, HCK1, HCK2,
VCK, PCG, REF,
VST, EN, PSIG,
RGT, DWN
17, 19 - 24, 26 - 29
25
XSTBY XSTBY
EVF_VR
EVF_VG
EVF_VB
EVF_RGT
EVF_STB
LED_K
COM
CN301
6
5
7
3
EVF_HST, EVF_HCK1,
EVF_HCK2,EVF_VCK,
EVF_PCG, EVF_REF,
EVF_VST, EVF_EN,
EVF_PSIG, EVF_DWN,
4, 8 - 11, 13 - 18
12
(BACKLIGHT)
1
EVF_VR
EVF_VG
EVF_VB
EVF_COM
EVF_RGT
EVF_STB
CN302
D301
PD-312 BOARD (1/2)
CN6301
(1/2)
30
29
28
PSIG, HCK1, HCK2,
14, 12 - 7, 5 - 2
6 14
CN6305
COM, CS
REF, HST, PCG,
EN, VCK, VST,
RGT, DWN
R
G
B
18
19
17
21
5 - 8, 10, 11, 13 - 16, 20
12
4
5
3
1, 24, 232, 6 - 8, 11 - 13, 19 - 22
LCD902
COLOR
EVF
UNIT
LCD901
2.7 inch
WIDE
COLOR
LCD
UNIT
OVERALL (6/6)
(PAGE 3-6)
OVERALL (5/6)
(PAGE 3-5)
05
DCR-HC47E/HC48/HC48E_L2
HI_SI, HI_SO, XHI_SCK, XCS_MECHA
CHIME_SDA, CHIME_SCK
XSYS_RST
18
BEEP
19
Q5103, Q5104
MODULATOR
MELODY
MELODY_ENV
IC5101
(2/3)
HI CONTROL
C9, C10, G10, P10
(5/17)
Y16, AA17
V10
V11
B5
A3
R11
Y12
TP_X
TP_Y
TP_SEL1
TP_SEL2
Q5108
TP SELECT
SWITCH
3-4
IC7002
(1/2)
3
+
2
–
LCD BACKLIGHT
CONTROL
(12/17)
1
BACKLIGHT
DRIVE
Q7010 – Q7013
14
16
15
11 - 9
TP_X
TP_Y
TP_SEL1
BL_H1 - BL_H3
17
15
20 - 22
TOUCH
PANEL
I/F
Q6301, Q6302
D6303 – D6305
(BACKLIGHT)
16
A : VIDEO SIGNAL
CN6304
TP_TOP
TP_L
TP_R
TP_BOT
5
2
1
4
TOUCH
PANEL
Page 29
3-5. OVERALL BLOCK DIAGRAM (5/6)
VC-472 BOARD (5/6)
( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
IC4001
(4/4)
VIDEO/AUDIO
DSP
(4/17)
OVERALL (2/6)
(PAGE 3-2)
OVERALL (4/6)
(PAGE 3-4)
OVERALL (3/6)
(PAGE 3-3)
OVERALL (1/6)
(PAGE 3-1)
53
60
IC_4001_Y_OUT
IC_4001_C_OUT
10
7
19
21
Q4404
BUFFER
IC_4401_Y_OUT_M
IC_4401_C_OUT_M
17
OVERALL (4/6)
(PAGE 3-4)
AV-112 BOARDFP-626 FLEXIBLE
BOARD (1/2)
CN2001
S_Y_I/O
S_C_I/O
VIDEO_I/O
AUDIO_L_I/O
AUDIO_R_I/O
13
OVERALL (2/6)
(PAGE 3-2)
MULTI_JACK_IN
AUDIO_L_I/O
AUDIO_R_I/O
MULTI_JACK_IN
AUDIO_L_I/O
AUDIO_R_I/O
TPA+, TPA-, TPB+, TPB-
USB_D+, USB_D- USB_D+, USB_D-
USB_DET
D1023
OVERALL (4/6)
(PAGE 3-4)
89
82
83
85
87
91
9
19
DATA_FROM_SFD
SFD_BCK
SFD_LRCK
SFD_FCK
DATA_TO_SFD
KASYAON
SFD_LRCK
SFD_BCK
BEEP
14
XPWAD, XPWDA
XCS_AU1
3
20
IC_4701_Y
IC_4701_C
9
12
10
11
8
13, 14
IC4402
A/D, D/A
CONVERTER
(11/17)
PBIN_L
15
PBIN_R
16
RECOUT_L
3
RECOUT_R
2
VSP_SO, XVSP_SCKVSP_SO, XVSP_SCK
31
30
35
34
65
25
9
6
23, 24
IC4401
VIDEO,
AUDIO I/O
(11/17)
88
3
90
57
61
S_Y_I/O
S_C_I/O
VIDEO_I/O
LANC_SIG
S_Y_I/O
S_C_I/O
VIDEO_I/O
LANC_SIG
(1/2)
CN1006
(1/2)
26
27
29
28
24
23
21
14
1
10 - 75, 4
CN401
6
5
3
4
8
9
11
CR-082 BOARD (1/2)
CN502
(1/2)
23
2116
1918
2413
1720
1621
36
27 - 3032, 33
2512
S_Y_I/O
S_C_I/O
VIDEO_I/O
MULTI_JACK_IN
AUDIO_L_I/O
AUDIO_R_I/O
LANC_SIG
TPA, NTPA, TPB, NTPB
USB_DET/VBUSUSB_DET
S-Y
S-C
VIDEO_IN/OUT
JACK_AD
AUDIO_L
AUDIO_R
LANC_SIG
CN501
(1/2)
CN402
9
13
10
8
18
14
25
31, 29, 33, 35
32, 3424, 26
10
5
9
7
1
6
2
CRADLE
(1/2)
A/V OUT
A : VIDEO SIGNAL
A : AUDIO SIGNAL
A : VIDEO/AUDIO SIGNAL
DCR-HC47E/HC48/HC48E_L2
MIC901
MICROPHONE
L
R
CN1001
INT_MIC_L
1
INT_MIC_R
3
OVERALL (6/6)
(PAGE 3-6)
05
LANC_SIG
MULTI_JACK_IN
21
MULTI_JACK_IN_CRADLE
51
52
70, 74
SP±
CN1002
(1/3)
SP± SP±
9, 10
CN802
(1/3) CN801
2, 1
1, 2
SP901
SPEAKER
3-5
CF-102 BOARD (1/3)
Page 30
3-6. OVERALL BLOCK DIAGRAM (6/6)
( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
FP-386 FLEXIBLE BOARD
S101
(PANEL REVERSE)
CONTROL KEY BLOCK
SELECT
(ZOOM)
START/STOP
S004
WIDE
S003
S002
S001
REC
(SB10600)
T
W
PD-312 BOARD (2/2)
CN6303
PANEL_REVERSE
3, 4
CN6302
WIDE/NORMAL_SW
2
2ND_ZOOM(T)
3
2ND_ZOOM(W)
4
2ND_S/S_SW
5
CF-102 BOARD (2/3)
S804
PANEL
OPEN/CLOSE
S805
BACK LIGHT
S803
EASY
S802
DISP/
BATT INFO
S801
RESET
D801
CHG
CONTROL KEY BLOCK (SS21200)
S004
START/STOP
(PHOTO FREEZE)
(PHOTO REC)
OFF (CHG)
POWER
ON
MODE
CAMERA
PLAY/EDIT
RV001
W T
(ZOOM)
OVERALL (1/6)
(PAGE 3-1)
OVERALL (2/6)
(PAGE 3-2)
OVERALL (3/6)
(PAGE 3-3)
OVERALL (5/6)
(PAGE 3-5)
VC-472 BOARD (6/6)
FP-625
FLEXIBLE
BOARD
CN6301
KEY_AD1
KEY_AD3 KEY_AD3
BATT_INFO XBATT_INFO_SW
XCHARGE_LED XCHARGE_LED
REC
S005
S003
S001
(EJECT)
D003
TAPE
D002
MEMORY
D001
2
10
16
21
(2/2)
(2/2)
18
CN802
(2/3)
7
8
XRESET
10
6
ZOOM_VR_AD
SYS_V
XSYS_RST
XSYS_RST
LINEOUT_V
XSYS_RST
XCC_DOWN
MULTI_JACK_IN
MULTI_JACK_IN_CRADLE
LANC_SIG
13
4
3
1
5
1
11
3
9
10
4
5
6
13
CN7002
(2/2)
CN1002
(2/3)
CN1012
KEY_AD1
KEY_AD0
KEY_AD2
XEJECT_SW
XPOWER_SW
XMODE_SW
XCAM_LED
XMEM_LED
XVTR_LED
ZOOM_VR
X5001
32.768kHz
L2
L3
B2
G11
B3
B4
A3
F11
F10
E11
A8
C7
A2
L6
J5
IC5001
HI CONTROL
(15/17)
D3
C8
G1
J4, H3
K5, L5,
IC_5001_TXD0,
IC_5001_RXD0,
IC_5001_SCK0,
G2
H2
A4
C2
INIT_CHARGE_ON
C1
K2
E3
D1, D2
A6
B10
C10
B1
B5
KEY_AD0
KEY_AD1
KEY_AD2
KEY_AD3
OSD_V
XDS_RESET
XVM_MAD
IC_5001_CS
SYS_V
BATT/XEXT
BATT_SIG
FAST_CHARGE
C5
B3
IC5101
B4
(3/3)
D2
HI CONTROL
(5/17)
W3
D13
N14
B10, B9
D11, H10,
V3
XRESET
VTR_DD_ON
HI_EVER_SO, HI_EVER_SCK
XCS_DD
BATT_IN
LANC_IN
LANC_OUT
XLANC_PWR_ON
XLANC_ON
P11
G1
F1
F2
C3
IR_ON
LI_3V
XRESET
CAM_DD_ON
LANC_SIG
Q1001
LED
DRIVE
HALL_OFFSET
HALL_GAIN
HALL_REF
CAM_DD_ON
VTR_UNREG
C/D_UNREG
BATT_UNREG
45
46
IC2201
51
DC CONTROL,
RESET,
LANC DRIVE
(17/17)
5
44
14, 15
13
50A7
54
56
55
52
57
MT_UNREG
Q2003,
Q2008
(2/2)
D1024
(NIGHTSHOT)
OVERALL (1/6)
6
(PAGE 3-1)
VTR_UNREG
C/D_UNREG
MT_UNREG
IC_6001_13.5V
D_1.2V (A_1.2V)
D_1.2V
USB_3.1V
A_1.5V
D_1.5V
MT_5V
D_2.8V (NS_2.8V)
RP_2.8V
A_2.8V
D_2.8V
AU_2.8V
A_2.8V (EP_2.8V)
A_4.6V
AU_4.6V
A_4.6V (EP_4.6V)
RP_4.6V
CAM_15V
EP_8.5V
CAM_-7.5V
EVER_3.0V
VOUT
LANC_DC
Q2001,
Q2002
CN1006
CN2001
CN1002
LI_3V
(2/2)
1 - 7
34 21
FP-626 FLEXIBLE BOARD (2/2)
BATT/XEXT
BATT_SIG
ACV_UNREG
BATT_UNREG
REG_GND
(2/2)
3
19
7
36 - 30
14 - 188 - 12
1 - 5
CF-102 BOARD (3/3)
CN802
CR-082 BOARD (2/2)
(3/3)
7
(3/3)
4
CN501 (2/2)CN502 (2/2)
ACV_UNREGACV_UNREG
BATT/XEXTBATT/XEXTBATT/XEXT_CR
BT901
LITHIUM
BATTERY
1 - 4
J001
DC IN
+
C
–
CRADLE
(2/2)
BH001
BATTERY
TERMINAL
OVERALL (4/6)
05
DCR-HC47E/HC48/HC48E_L2
(PAGE 3-4)
18
XSYS_RST
3-6
Page 31
3-7. POWER BLOCK DIAGRAM (1/3)
( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
A/V OUT
J001
DC IN
BH001
BATTERY
TERMINAL
CRADLE
AV-112 BOARD
CN402
4
CF-102 BOARD
FP-626
FLEXIBLE
BOARD (1/2)
ACV_UNREG
BATT/XEXT
+
C
−
BATT_UNREG
BATT_SIG BATT_SIG
REG_GND
19
7
CR-082 BOARD
CN501
1 - 4
27
CN502
ACV_UNREG ACV_UNREG
BATT/XEXT BATT/XEXT
LANC_DC LANC_DC
1 - 7
3421
35
3
2
FP-626
FLEXIBLE
BOARD (2/2)
CN401
LANC DC LANC_DC
D801
CHG
BT901
LITHIUM
BATTERY
12
4 7
5
20
6
CONTROL KEY BLOCK
(SS21200) (1/2)
OFF (CHG)
POWER
ON
MODE
9
10
VC-472 BOARD (1/3)
CN2001
(1/2)
14 - 188 - 12
1 - 5
CN1006
36 - 30
CN2001
(2/2)
CN1002CN802
LI_3V
CHARGE_LED_VDD
CN1012
(1/2)
XPOWER_SW
XMODE_SW
EVER_3.0V
xPowerSw
B4
xModeSw
A3
Q2001,
Q2002,
IC5001
HI CONTROL
(15/17)
batt_xExt_cra
batt_xExt
fastCharge
initCharge
acvSense
frEverSck
xLancPowerOn
SIO2
frEverSo
xCsDd
battIn
vtrDdOn
xLancOn
G2
H2
C2
C1
A4
K6battSense
J7
A6
A7
E3
B1
B5
D1, D2
Q2003,
Q2008
INIT_CHARGE_ON
INIT_CHARGE_ON
FAST_CHARGE
BATT/XEXT
BATT/XEXT_CR
VOUT
BATT/XEXT_CR
BATT/XEXT
FAST_CHARGE
BATT_SIG
F002
F003
F001
D2201
F004
VTR_UNREG
BATT_UNREG
HI_EVER_SO, HI_EVER_SCK
XCS_DD
BATT_IN
VTR_DD_ON
XLANC_PWR_ON
XLANC_ON
D2202
61
VCC1
60
VCC3
49
VCC2
IC2201
DC CONTROL,
RESET,
LANC DRIVE,
DRUM/CAPSTAN
PWM DRIVE
(17/17)
58
VOUT4
VBATT
45
VOUT3
46
47
VOUT2
48
VOUT1
DIN
CLK
15, 14
13
LD
50
OUTC1
44
CTL1
55
WAKE_UP
52
XCTL2
Q2217, Q2208
SWITCHING
Q2204
SWITCHING
SWITCHING
Q2206
SWITCHING
Q2209
SWITCHING
D2205
CAPSTAN/
DRUM
SWITCHING
D2203
L2201 L2228
L2202
L2203
L2204
L2209
L2211
L2212
L2213
L2214
L2216
L2217
L2219
Q2212
8.5V REG
3.1V REG (17/17)
5
6
Q2213, Q2214
-7.5V REG
Q2215, Q2216
1.2V REG
VTR_DD_ON
IC2203
+
-
Q2211
15V REG
D_1.2V (A_1.2V)
D_1.2V
VR
IC_6001_13.5V
A_1.5V
D_1.5V
MT_5V
RP_2.8V
A_2.8V
D_2.8V
AU_2.8V
A_4.6V
AU_4.6V
RP_4.6V
7
USB_3.1V
CAM_15V
CAM_-7.5V
CAM DD ON
D 2.8V
A_2.8V
D_2.8V (NS_2.8V)
A_2.8V (EP_2.8V)
A_4.6V (EP_4.6V)
EP_8.5V
C/D_UNREG
VTR_UNREG VTR_UNREG
MT_UNREG
OUT1-1
VS1
IN1
OUT2
VS2
IN2
OUT3-1
VS3
IN3
OUT4
VS4
IN4
OUT7
IN7
VCONT5
VOUT5
VCONT6
VOUT6
REG6CTL
62VB
63VCCO1
67VCCO2
64
66OUT1-2
65
12
68
69
11
70
72OUT3-2
71
10
73
74
9
79
6
1
2
3
4
CAM_DD_ON
5
41
VR
D2204
Q2201, Q2203
Q2202, Q2205
L2207
VR
A
POWER (2/3)
(PAGE 3-8)
B
POWER (3/3)
(PAGE 3-9)
DCR-HC47E/HC48/HC48E_L2
VTR_DD_ON
05
3-7
Page 32
3-8. POWER BLOCK DIAGRAM (2/3)
( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
VC-472 BOARD (2/3)
CAM_-7.5V
CAM_15V
RP_2.8V
RP_4.6V
AU_2.8V
AU_4.6V
A
POWER (1/3)
(PAGE 3-7)
A_2.8V
A_4.6V
D_2.8V
MT_5V
VTR_UNREG
IC_6001_13.5V
D_1.5V
D_1.2V
USB_3.1V
A_1.5V
D_1.2V (A_1.2V)
CAM_DD_ON
L4406
L4404
L4401
L4402
L4405
Q4401
3.7V REG
L4301
L4302
FB5102
FB5103
FB5105
FB5106
IC4301
REC/PB AMP
(9/17)
IC4402
A/D, D/A
CONVERTER
(11/17)
IC4401
VIDEO,
AUDIO I/O
(11/17)
VTR_UNREG
IC_6001_13.5V
USB_3.1V
FB3902
FB3901
L3901
A_2.8V
A_4.6V
D_2.8V
MT_5V
D_1.5V
D_1.2V
A_1.5V
IC3901
CAMERA
SIGNAL
PROCESS
(3/17)
IC5101
DS/HI CONTROL
(5/17)
MS_VCC_ON
C3 CAM_DD_ON
E3CHIME_PWR_CONT
W17
L4206
L4207
L4205
FB4101
L4101
1
4
FB5201
IC5204
1.8V REG
(6/17)
CE
VDD
VOUT
IC4201
DV SIGNAL
PROCESS
(7/17)
IC4101
DV INTERFACE
(8/17)
3
IC5203
16M SDRAM
(6/17)
FB4005
FB4001
FB4002
L4002
L4003
IC5202
32M FLASH
(6/17)
L4701
A_4.6V
CAM_-7.5V
CAM_15V
VCCCE4 3
1
IC4701
ASPECT
RATIO
CONVERTER
(10/17)
IC4002
64M SDRAM
(4/17)
IC4001
VIDEO/AUDIO
DSP
(4/17)
IC3202
3.4V REG
(1/17)
V_OUT
A_2.8V
D_2.8V
MT_5V
D_1.5V
L3205
L3203
L3201
L3204
FB3202
L3803
L3802
L3801
FB5301
IC3201
A/D CONVERTER,
TIMING
GENERATOR
(1/17)
X3201
IC3802
FOCUS/ZOOM
MOTOR DRIVE,
IRIS DRIVE
(2/17)
IC3803
IRIS DRIVE,
HALL BIAS/
HALL GAIN
CONTROL,
HALL AMP
(2/17)
IC3804
IRIS DRIVE
(2/17)
VTR_UNREG
IC_6001_13.5V
IC5302
32k EEPROM
(13/17)
ZM_RST_LED
FC_RST_LED
XREEL_HALL_ON
IC5301
CAMERA/MECHA
CONTROL
(13/17)
AC3, AB4
F22
ZM_RST_LED, FC_RST_LED
MOTOR DRIVE
Q5105
MT_5V
IC6001
DRUM/
CAPSTAN/
LOADING
(14/17)
2.9V REG
4
VDD
CE
1
Q3802
Q6002
IC1001
(5/17)
VMR
VOUT
VH
3
IRIS_DRIVE (+)
ZM_SENS_VCC
FC_SENS_VCC
17
3
TAPE_LED_A
CHIME_VDD
CN3201
CAM_-7.5V
CAM_15V
CN3801
CN1010
HE_VCC
FG_VCC
CN1007
HALL_VCC
D_2.8V
MS_VCC
(1/2)
5
4
13
10
8
8
25, 26
26
21
12
1 10
8
CD-672 BOARD (1/2)
CN7001
(1/2)
24
25
LENS BLOCK
IRIS
METER
ZOOM
SENSOR
FOCUS
SENSOR
N MECHANISM DECK
FB7001
L7001
(MDX-N110)
HU, HV, HW
CAPSTAN FG
S REEL
SENSOR
T REEL
SENSOR
MIC902
4PIN
CONNECTOR
MS-342 BOARD
CN602CN1011
D601
(MS ACCESS)
VCC
3
D901
TAPE LED
H901
H902
CN601
9
IC7002
CCD
IMAGER
MEMORY
STICK
DUO
05
DCR-HC47E/HC48/HC48E_L2
3-8
Page 33
3-9. POWER BLOCK DIAGRAM (3/3)
( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
VC-472 BOARD (3/3)
D_2.8V (NS_2.8V)
B
POWER (1/3)
(PAGE 3-7)
D_2.8V
IC1002
REMOTE
SENSOR
(13/17)
D1024
(NIGHTSHOT)
CN3201
A_2.8VA_2.8V
CN1012
D_2.8V
MODE_LED_VDD
(2/2)
28
CONTROL KEY BLOCK
(SS21200) (2/2)
(2/2)
12
7
CD-672 BOARD (2/2)
CN7001
(2/2)
L7002
1
RV001
T W
(ZOOM)
D003
TAPE
D002
MEMORY
D001
PLAY/EDIT
CAMERA
SE7002
PITCH SENSOR
SE7001
YAW SENSOR
IC7003
PITCH/YAW
SENSOR
AMP
LB-132
BOARD
18
14
15
TOUCH
PANEL I/F
LCD902
COLOR
EVF UNIT
VDD
XSTBY
VSSG
D6303 - D6305
(BACKLIGHT)
LCD901
2.7 inch
WIDE
COLOR
LCD UNIT
20
2
25
6
24
23
CN301
PD-312
BOARD
CN6301
20 - 22
CN302
EVF_VDD
2
EVF_STB
12
(BACKLIGHT)
Q6303
SWITCH
D301
CN6305
Q6301, Q6302
EP_8.5V
A_4.6V (EP_4.6V)
L7003
L7002
CN7001
1
9 12
19
EVF_VDD
EVF_STB
EP_4.6V
FP-625
A_2.8V (EP_2.8V)
05
L7001
D_2.8V
IC7001
LCD/EVF
DRIVE
(12/17)
POFF
XSTBY_E
XSTBY_P
IC7002
LCD/EVF
BACKLIGHT
CONTROL
(12/17)
2
10
18
A_OUT
Q7007, Q7014
Q7010 - Q7013
LCD
BACKLIGHT
DRIVE
1
CN7002
FLEXIBLE
BOARD
6
25
7
BL_H1 - BL_H3
11 - 9
8
VDD_P
XSTBY
EP_2.8V
D_2.8V
DCR-HC47E/HC48/HC48E_L2
3-9E
Page 34
4-1. FRAME SCHEMATIC DIAGRAM
PD-312 BOARD
301
CN6301
4. PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS
FP-386 FLEXIBLE
BOARD
130
CF-102 BOARD
1
6
CN6303
124
FP-625 FLEXIBLE BOARD
BT901
LITHIUM BATTERY
BH801
BATTERY
HOLDER
16
CN6305
2.7 INCH
WIDE COLOR
LCD UNIT
CN802
LCD901
110
CN801
12
16
CN6304
TOUCH
PANEL
16
CN6302
FLEXIBLE FLAT CABLE
(FFC-085)
SP901
SPEAKER
CONTROL KEY
BLOCK
(SB10600)
30
1
MIC901
MICROPHONE
CR-082 BOARD
42 2
41 1
44
CN501
MULTI CONNECTOR
CD-672 BOARD
LB-132 BOARD
1
2
21
FLEXIBLE FLAT CABLE
18
CN1014
(FFC-084)
CPC
(For Check)
FLEXIBLE FLAT CABLE
(FFC-089)
110
CN601
30
CN602
CONNECTOR
MEMORY STICK
1
110
LENS BLOCK
1
CN1001
361
CN502
43
2
1
2
CN7002
29
30
14
(FFC-086)
FLEXIBLE FLAT CABLE
23
24
9
CN1002
1
10
2
1
128
1
2
135
236
CN1006
LEVEL3
VC-472 BOARD (SIDE A)
2
28
CN1007
29
CN7001
(FFC-004)
FLEXIBLE FLAT CABLE
CN3201CN3801
IC5302
(EEPROM)
114
CN1012
27
28
CN1011
1
2910
226
CN1010
1
20
19
CN7001
2
1
30
CN2001
1
27
20
CN301
CN302
2
1
19
20
CONTROL KEY
BLOCK
(SS21200)
LCD902
COLOR
EVF UNIT
BH001
BATTERY
TERMINAL
C
FP-626 FLEXIBLE BOARD
12
11
J001
DC IN
AV-112 BOARD
(SIDE A)
610
15
CN402
A/V OUT
112
AV-112 BOARD
(SIDE B)
11
1
CN401
2
12
MS-342 BOARD
DCR-HC47E/HC48/HC48E_L2
IC5202
(Not supplied)
CN1009
CN1008
110 110
LEVEL3
VC-472 BOARD (SIDE B)
4-1
M903
CAPSTAN MOTOR
MM
VIDEO
HEAD
M901
DRUM MOTOR
MM
N MECHANISM DECK
(MDX-N110)
FP-228
FLEXIBLE
BOARD
1
29
FP-031 FLEXIBLE BOARD
M902
LOADING MOTOR
MM
1
2
1
4
FP-032
FLEXIBLE
BOARD
FRAME
Page 35
Link
Link
4-2. SCHEMATIC DIAGRAMS
CD-672 BOARD (CCD IMAGER)
PD-312 BOARD (LCD, LCD BACKLIGHT)
FP-386 FLEXIBLE BOARD
(PANEL REVERSE DETECT)
FP-625 FLEXIBLE BOARD
CONTROL KEY BLOCK (SB10600)
CR-082 BOARD (DRADLE TERMINAL)
FP-626 FLEXIBLE BOARD (DC IN)
COMMON NOTE FOR SCHEMATIC DIAGRAMS
AV-112 BOARD (AV CONNECTOR)
MS-342 BOARD (MS CONNECTOR)
LB-132 BOARD (EVF, EVF BACKLIGHT)
CF-102 BOARD (CONTROL SWITCH)
CONTROL KEY BLOCK (SS21200)
FP-031, FP-032, FP-228 FLEXIBLE BOARD
DCR-HC47E/HC48/HC48E_L2
Page 36
4-2. SCHEMATIC DIAGRAMS
Yellow
AABBA=B
Fig. a (Video output terminal output waveform)
H
Cyan
Green
White
Magenta
Red
Blue
Fig.b (Picture on monitor TV)
CRT picture frame
Electronic beam scanning frame
4-2. SCHEMATIC DIAGRAMS
4-2. SCHEMATIC DIAGRAMS
(ENGLISH)
THIS NOTE IS COMMON FOR SCHEMATIC DIAGRAMS
(In addition to this, the necessary note is printed in each block)
ENGLISH JAPANESE
ENGLISH JAPANESE
(For schematic diagrams)
• All capacitors are in µF unless otherwise noted. pF : µ
µF. 50 V or less are not indicated e xcept for electrolytics
and tantalums.
• Chip resistors are 1/10 W unless otherwise noted.
kΩ=1000 Ω, MΩ=1000 kΩ.
• Caution when replacing chip parts.
New parts must be attached after removal of chip.
Be careful not to heat the minus side of tantalum
capacitor, Because it is damaged by the heat.
• Some chip part will be indicated as follows.
Example C541 L452
22U 10UH
TA A 2520
Kinds of capacitor
External dimensions (mm)
Case size
• Constants of resistors, capacitors, ICs and etc with XX
indicate that they are not used.
In such cases, the unused circuits may be indicated.
•Parts with ★ differ according to the model/destination.
Refer to the mount table for each function.
• All variable and adjustable resistors have characteristic
curve B, unless otherwise noted.
• Signal name
XEDIT→ EDIT PB/XREC → PB/REC
• 2: non flammable resistor
• 5: fusible resistor
• C: panel designation
• A: B+ Line
• B : B– Line
• J : IN/OUT direction of (+,–) B LINE.
• C: adjustment for repair.
• A: not use circuit
(Measuring conditions voltage and waveform)
•Voltages and wavefor ms are measured between the
measurement points and ground when camera shoots
color bar chart of pattern box. They are ref erence values
and reference waveforms.
(VOM of DC 10 MΩ input impedance is used)
•Voltage values change depending upon input
impedance of VOM used.)
1. Connection
Pattern box
Pattern box PTB-450
J-6082-200-A
or
Small pattern box
PTB-1450
J-6082-557-A
L = 1 m (PTB-450)
L = 40 cm (PTB-1450)
Pattern box
Color bar chart
L
For PTB-450:
J-6020-250-A
For PTB-1450:
J-6082-559-A
Front of the lens
Camera
2. Adjust the distance so that the output waveform of
Fig. a and the Fig. b can be obtain.
Precautions for Replacement of Imager
• If the imager has been replaced, carry out all the adjustments
for the camera section.
•As the imager may be damaged by static electricity from
its structure, handle it carefully like for the MOS IC.
In addition, ensure that the receiver is not covered with
dusts nor exposed to strong light.
DCR-HC47E/HC48/HC48E_L2
When indicating parts by reference number, please
include the board name.
The components identified by mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0 sont
critiques pour la sécurité.
Ne les remplacer que par une pièce portant le numéro
spécifie.
4-3
Page 37
4-2. SCHEMATIC DIAGRAMS
4-2. SCHEMATIC DIAGRAMS
(JAPANESE)
回路図共通ノート
（他に必要なノートは各ブロックに記載してあります）
【回路図ノート】
・ケミコン，タンタルを除くコンデンサで，耐圧50V以下のもの
はその耐圧を省略。単位はすべてμF（pはpF）。
・チップ抵抗で指示のないものは，1／10W以下。
kΩ＝1000Ω，MΩ＝1000kΩ
・チップ部品交換時の注意
取り外した部品は再使用せず，未使用の部品をご使用くださ
い。
タンタルコンデンサのマイナス側は熱に弱いため注意してくだ
さい。
・チップ部品には下記のように表示したものがあります。
例 C541 L452
22U 10UH
TA A 2520
↑↑ ↑
種類 ケースサイズ 外形寸法（mm）
・抵抗，コンデンサ，ICなど定数にXXがあるものは，使用して
いない事を示しています。このため，使用していない回路が記
載されている事があります。
・★印のある部品は，機種などにより異なりますので機能別マウ
ント一覧表を参照してください。
・可変抵抗と半固定抵抗で，B特性の表示を省略。
・信号名表記について，下記のような場合があります。
XEDIT → EDIT PB/XREC → PB/REC
・2は不燃性抵抗。
・1はヒューズ抵抗。
・Cはパネル表示名称。
・AはB＋ライン。
・BはB−ライン。
・JはBライン（＋，−）の入出力方向を示す。
・Cは調整名称。
・Aは未使用回路。
【電圧・波形測定条件ノート】
・電圧値及び信号波形はパターンボックスのカラーバーチャート
を被写体としたときの測定点対アース間の参考値。
（デジタルマルチメータ；入力インピーダンス DC10MΩ使
用）
・使用テスタの入力インピーダンスにより電圧値が多少異なりま
す。
ENGLISH JAPANESE
ENGLISH JAPANESE
1. 接続図
パターンボックス
Pattern box PTB-450
J-6082-200-A
or
Small pattern box
PTB-1450
J-6082-557-A
L = 1 m (PTB-450)
L = 40 cm (PTB-1450)
パターンボックス
2. 図a及び図bの波形が得られるように画枠調整して下さい。
H
シ
ア
黄
ン白
緑
AABBA=B
図a（映像入出力端子出力波形）
電子ビーム走査線
図b（テレビモニタの映像）
カラーバーチャート
L
マ
ゼ
ン
ダ
赤
青
For PTB-450:
J-6020-250-A
For PTB-1450:
J-6082-559-A
レンズ前面
カメラ
ブラウン管の画像枠
イメージャ交換時の注意
・イメージャを交換した場合は，カメラ部の全調整を
行ってください。
・イメージャは構造上，静電気により破壊される恐れが
あるため，MOSICと同様に注意して取り扱ってくだ
さい。
また，受光部にはゴミの付着，および強い光がはいる
ことのないように注意してください。
DCR-HC47E/HC48/HC48E_L2
0印の部品，または0印付きの点線で囲まれた部品は，
安全性を維持するために重要な部品です。
従って交換時は，必ず指定の部品を使用して下さい。
お願い
図面番号で部品を指定するときは基板名又はブロック
を併せて指定して下さい。
4-4
Page 38
A
B
C
D
E
1
23
CD-672 BOARD
CCD IMAGER
XX MARK:NO MOUNT
NO MARK:REC/PB MODE
R:REC MODE
P:PB MODE
48
5
712
96
10
11
Note: IC7002 is not supplied, but this
is included in CCD block assy.
R10.8/P0
0
Q7001
UNR32A300LS0
SWITCH
V2
V1
VL
N.C
VDD
N.C12V_OUT13GND14RG15N.C16H217N.C18H119SUB20N.C
11
C7004
XX
C7003
0.1u
C7009
XX
C7010
0.1u
V3
C7002
0.1u
R7001
V4
XX
Note: Voltages of IC7002 can not be
measured, because this is mounted
by the side of the lens.
12345678910
V6
V5
RCSUB
R7012
R7009
XX
R7011
L7001
10uH
IC7002
XX
XX
CCD IMAGER
IC7002
ICX617AKF-13
R7.8/P0
2SC5096-O/R(TE85L)
1
IN
2
GND
3
OUT IDRV
Q7002
CLAMP
R7004
R7005
IC7001
XX
SE7002
PITCH SENSOR
C7008
C7030
XX
VccVcc
3
GND GND
3
SE7001
YAW SENSOR
12
4
12
4
C7005
0.1u
R7006
12k
R7002
1200
C7001
XX
C7012
XX
R7010
XX
C7014
XX
C7013
XX
XX
2.8 1.5
Vref
OUT
Vref
OUT
R7017
R7018
R7019
R7020
XX
C7016
0.1u
C7017
RB7001
XX
XX
XX
1
3
5
7
22k
C7015
0.1u
0.1u
2
4
6
8
C7018
0.1u
1.3
1.32.8
1.3
C7028
10u
C7024
10u
C7026
0.047u
2
4
1
3
0.7
0.9
1.3
1.3
1.3
1.3
1.3
HI1
LO1
GND
LIA1
LIB2
LIB212LIA213LO214HI215HO216Vref217AM218OUT219CRST20VCC
11
0.711.5
4
2
1
3
C7027
0.047u
C7025
10u
C7029
10u
HO1
AM1
Vref1
1.5
1.3
1.3
1.3
1.202.8
R7015
R7016
R7013
10k
R7014
1M
1.3
12345678910
PASS
IC7003
PITCH/YAW SENSOR
NJM3230V(TE2)
OUT1
1M
10k
AMP
IC7003
C7023
4.7u
10uH
L7002
10k
1k
R7.1/P0R12/P0
6
ISF
VCC
C7007
4.7u
5
4
R7007
R7008 XX
C7006
1u
XX
F
G
H
05
DCR-HC47E/HC48/HC48E_L2
CN7001 28P
28
GND
26
27
GND
CCD_OUT+
C7011
24
25
CAM_15V
CAM_-7.5V
10u
FB7001
23
GND
22
GND
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
V5
RG
GND
GND
GND
GND
VC-472
(1/17)
CN3201
Through the
Flexible Flat Cable
(FFC-004)
Page 4-6
of Level 3
V3
V2
V1
H1
H2
V6
V4
GND
RCSUB
SUB
GND
PITCH_AD
VST_C_RESET
A_2.8V
YAW_AD
4-5
CD-672
Page 39
Schematic diagrams of the VC-472 board are not sho wn.
Pages from 4-6 to 4-22 are not shown.
DCR-HC47E/HC48/HC48E_L2
Page 40
2
34
7
10
121 11
16141356 1598
17
A
B
C
VC-472
(12/17)
CN7002
Page 4-17
of Level 3
D
E
LND001
LND002
LND003
LND004
LND005
LND006
LND007
LND008
LND009
LND010
LND011
LND012
LND013
LND014
LND015
LND016
LND017
LND018
LND019
LND020
LND021
LND022
LND023
LND024
LND025
LND026
LND027
LND028
LND029
LND030
F
CONTROL KEY BLOCK (SB10600)
CONTROL KEY BLOCK (SB10600) is
replaced as block, so that
PRINTED WIRING BOARD is omitted.
G
S001
REC
START/STOP
S002
W
(ZOOM)
H
S003
SELECT
S004
WIDE
T
I
FP-386
FLEXIBLE BOARD
PANEL REVERSE DETECT
J
K
05
S101
(PANEL REVERSE)
FP-625
FLEXIBLE
BOARD
(PRINTED WIRING BOARD is omitted.)
PANEL_VR
1
PANEL_VG
2
PANEL_VB
3
REG_GND
4
REG_GND
5
VDD_P
6
EP_2.8V
7
D_2.8V
8
BL_H3
9
BL_H2
10
BL_H1
11
REG_GND
12
KEY_AD1
13
TP_X
14
TP_SEL1
15
TP_Y
16
REF
17
REG_GND
18
HCK1
19
HCK2
20
HST
21
PCG
EN
23
PSIG
24
XSTBY
25
DWN
26
RGT
27
VST
28
VCK
29
COM
30
3
4
2
1
3
4
2
1
3
4
2
1
3
4
2
1
6
REG_GND
2ND_S/S_SW
5
2ND_ZOOM(W)
4
2ND_ZOOM(T)
3
WIDE/NORMAL_SW
2
1
REG_GND
1
REG_GND
2N.C
PANEL_REVERSE
3
4
PANEL_REVERSE
5
N.C
6
REG_GND
LND006
LND005
LND004
LND003
LND002
LND001
LND101
LND102
LND103
LND104
LND105
LND106
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
PANEL_VR
PANEL_VG
PANEL_VB
REG_GND
REG_GND
VDD_P
EP_2.8V
D_2.8V
BL_H3
BL_H2
BL_H1
REG_GND
KEY_AD1
TP_X
TP_SEL1
TP_Y
REF
REG_GND
HCK1
HCK2
HST
PCG22
EN
PSIG
XSTBY
DWN
RGT
VST
VCK
COM
LND101
LND102
LND103
LND104
LND105
LND106
LND107
LND108
LND109
LND110
LND111
LND112
LND113
LND114
LND115
LND116
LND117
LND118
LND119
LND120
LND121
LND122
LND123
LND124
LND125
LND126
LND127
LND128
LND129
LND130
LCD901
TOUCH
PANEL
PD-312 BOARD
LCD, LCD BACKLIGHT
XX MARK:NO MOUNT
NO MARK:REC/PB MODE
30P
CN6301
PANEL_VR
30
PANEL_VG
29
PANEL_VB
28
REG_GND
27
REG_GND
26
VDD_P
25
EP_2.8V
24
D_2.8V
23
BL_H3
22
BL_H2
21
BL_H1
20
REG_GND
19
KEY_AD1
18
TP_X
17
TP_SEL1
16
TP_Y
15
REF
14
REG_GND
13
HCK1
12
HCK2
11
HST
10
PCG
9
EN
8
PSIG
7
XSTBY
6
DWN
5
RGT
4
VST
3
VCK
2
COM
NOR_REV
CN6302
REG_GND
REG_GND
CN6303 6P
REG_GND
N.C
N.C
REG_GND
CN6304
TP_R
TP_L
N.C.
TP_BOT
TP_TOP
N.C.
CH_GND
1
GND
6P
6
5
4
3
2
1
1
2
3
4
5
6
6P
1
2
3
4
5
6
R6326
LND632
LND633
2ND_S/S_SW
2ND_ZOOM(W)
2ND_ZOOM(T)
WIDE/NORMAL_SW
PANEL_REVERSE
PANEL_REVERSE
(2/2)
with
LCD
UNIT
LND631
C6301
XX
R6316
XX
R6331
R6330
R6329
R6313
XX
D6310
XX
1
R6327
XX
R6328
XX
VD6301
VD6302
VD6303
VD6304
XX
XX
XX
XX
2
3
R6302
R6303
R6304
R6305
1
2
D6301
XX
Q6301, Q6302
TOUCH PANEL I/F
R6301
1500
2200
3300
4700
REF_P
HCK1_P
HCK2_P
HST_P
PCG_P
XSTBY_P
DWN_P
RGT_P
VST_P
VCK_P
COM_P
XX
VR_P
VG_P
VB_P
EN_P
VP_P
6
5
43
Q6302
XP411F-TXE
Q6301
XP421F-TXE
VST_P
VCK_P
EN_P
DWN_P
R6315
XX
XX
R6314
D6308
CL6303
D6305
NSSW008CT-T071
XX
CL6301 CL6302
D6303-D6305
(BACKLIGHT)
D6306
XX
2.8
5
2.8
4
2.8
3
1
6
0
2
2.8
2
0
6
1
4
3
2.8
5
0
CL6304
C6302
4700p
C6303
4700p
D6303
NSSW008CT-T071
D6307
XX
D6304
NSSW008CT-T071
XSTBY_P
PCG_P
HST_P
REF_P
HCK2_P
HCK1_P
VP_P
VG_P
VR_P
VB_P
RGT_P
COM_P
C6304
1u
R6307
120k
Q6303
2SA207800LS0
SWITCH
0
D6302
MAZS056008S0
1u
1M
R6309
C6305
-5.5
C6306
0.1u
24P
CN6305
COM
24
CS
23
VST
22
VCK
21
EN
20
DWN
19
VDD
18
VSS
17
N.C.
16
VSSG
15
XSTBY
14
PCG
13
HST
12
REF
11
TEST1
10
N.C.
9
HCK2
8
HCK1
7
PSIG
6
G
5
R
4
B
3
RGT
2
COM
1
LCD901
(1/2)
2.7inch
wide
COLOR
LCD
UNIT
with
TOUCH
PANEL
DCR-HC47E/HC48/HC48E_L2
4-23
PD-312, FP-386, FP-625, SB10600
Page 41
1
23
48
5
7
96
10
11
A
B
C
D
E
CR-082 BOARD
CRADLE TERMINAL
XX MARK:NO MOUNT
VC-472
(16/17)
CN1006
Through the
Flexible Flat Cable
(FFC-086)
Page 4-21
of Level 3
CN502 36P
LANC_SIG
LANC_DC
BATT/XEXT
USB_D-
USB_D+
REG_GND
REG_GND
USB_DET
MULTI_JACK_IN
S_Y_I/O
REG_GND
S_C_I/O
REG_GND
VIDEO_I/O
REG_GND
AUDIO_L_I/O
AUDIO_R_I/O
ACV_GND
ACV_GND
ACV_GND
ACV_GND
ACV_GND
ACV_GND
ACV_GND
ACV_UNREG
ACV_UNREG
ACV_UNREG
ACV_UNREG
ACV_UNREG
ACV_UNREG
ACV_UNREG
NTPB
TPB
NTPA
TPA
N.C.
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
VD501
XX
VD502
XX
D503
XX
2
1
3
29
31
33
35
37
39
41
TPA
TPB
ACV_GND
ACV_GND
N.C.
NTPB
NTPA
3
2
1
25
27
LANC_DC
LANC_SIG
D502
XX
4
5
6
19
21
23
BATT/XEXT
XCRADLE_IN
(XLANC_JACK_IN)
17
N.C.
15
N.C.
13
S_C_I/O
9
11
S_Y_I/O
REG_GND
VD505
XX
5
7
N.C.
(S_JACK_IN)
1
3
ACV_UNREG
ACV_UNREG
LND502
STATIC_GND
LND501
STATIC_GND
Note: CN501 (multi connector) is not
supplied, but this is included in
CR-082 complete board.
F
G
H
05
DCR-HC47E/HC48/HC48E_L2
44
ACV_GND
42
VD503
XX
4-24
ACV_GND
USB_GND
38
40
USB_GND
USB_D-
34
36
USB_D+
USB_GND
30
32
TO CRADLE UNIT
USB_GND
USB_DET/VBUS
USB_DET/VBUS
24
26
28
VD504
XX
(USB_ID)
REG_GND
20
22
AUDIO_L_I/O
REG_GND
16
18
REG_GND
AUDIO_R_I/O
12
14
VIDEO_I/O
MULTI_JACK_IN
8
10
N.C.
6
43
ACV_UNREG
ACV_UNREG
2
4
CN501
44P
(MULTI CONNECTOR)
CR-082
Page 42
1
23
48
5
7
96
1110
A
B
C
D
E
VC-472
(16/17)
CN2001
Page 4-21
of Level 3
LND001
LND002
LND003
LND004
LND005
LND006
LND007
LND008
LND009
LND010
LND011
LND012
LND013
LND014
LND015
LND016
LND017
LND018
LND019
LND020
LND021
LND022
LND023
LND024
LND025
LND026
LND027
LND028
LND029
LND030
FP-626
FLEXIBLE BOARD
DC IN
Note: BH001 and J001 are not included
in FP-626 flexible board.
BATT_UNREG
BATT_UNREG
BATT_UNREG
BATT_UNREG
BATT_UNREG
BATT_SIG
REG_GND
REG_GND
REG_GND
REG_GND
REG_GND
ACV_UNREG
ACV_UNREG
ACV_UNREG
ACV_UNREG
ACV_UNREG
BATT/XEXT
LANC_SIG
REG_GND
AUDIO_R_I/O
AUDIO_L_I/O
REG_GND
MULTI_JACK_IN
VIDEO_I/O
REG_GND
LANC_DC
S_Y_I/O
S_C_I/O
N.C.
N.C.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
LND201
CHASSIS_GND
LANC_DC
12
LANC_SIG
11
REG_GND
10
AUDIO_R_I/O
9
8
AUDIO_L_I/O
REG_GND
7
6
S_Y_I/O
S_C_I/O
5
MULTI_JACK_IN
4
VIDEO_I/O
3
REG_GND
2
REG_GND
1
1
2
C
4
2
3
1
BH001
(BATTERY TERMINAL)
J001
DC IN
AV-112 BOARD
AV CONNECTOR
XX MARK:NO MOUNT
LND112
LND111
LND110
LND109
LND108
LND107
LND106
LND105
LND104
LND103
LND102
LND101
CN401 12P
LANC_DC
LANC_SIG
REG_GND
AUDIO_R_I/O
AUDIO_L_I/O
REG_GND
S_Y_I/O
S_C_I/O
MULTI_JACK_IN
VIDEO_I/O
REG_GND
REG_GND
R401
12
11
10
9
8
7
6
5
4
3
2
1
XX
R402 XX
R403
XX
FB401
FB402
1
2
3
4
5
6
7
8
9
10
14P
CN402
AUDIO_L
LANC_SIG
S_GND
LANC_DC
S_C
AUDIO_R
JACK_AD
VIDEO/AUDIO_GND
VIDEO_IN/OUT
S_Y
11
12
A/V OUT
13
14
F
05
DCR-HC47E/HC48/HC48E_L2
4-25
FP-626, AV-112
Page 43
• Refer to page 4-3 (English), 4-4 (Japanese) for mark 0.
1
MS-342 BOARD
A
MS CONNECTOR
XX MARK:NO MOUNT
B
VC-472
(5/17)
CN1011
Through the
Flexible Flat Cable
(FFC-089)
Page 4-10
of Level 3
C
D
05
23
CN602 10P
1
REG_GND
REG_GND
2
MS_VCC
3
MS_SCLK
4
MS_BS
REG_GND
D_2.8V
5
6
7
8
9
10
R601
100
CL-271HR-C-TS
(MS ACCESS)
MS_INSERT
MSDATA0 (DIO)
XMS_LED_ON
D601
4
57
6
A
1
23
LB-132 BOARD
4
57
6
EVF, EVF BACKLIGHT
XX MARK:NO MOUNT
D301
NESW007AT-T099
(BACKLIGHT)
C301
0.1u
C302
1u
D302
MAZS056008S0
R302
21P
CN302
EVF_COM
21
EVF_PSIG
20
EVF_VG
19
EVF_VR
18
EVF_VB
17
EVF_PCG
16
EVF_EN
15
EVF_VCK
14
EVF_VST
13
EVF_STB
12
EVF_REF
11
EVF_DWN
10
EVF_NRW
9
EVF_RGT
8
EVF_HCK1
7
EVF_HCK2
6
EVF_HST
5
VSSG
4
VSS
XX
C303
2.2u
3
EVF_VDD
2
N.C.
1
LCD902
COLOR
EVF
UNIT
C601
XX
654
12
D602
XX
10P
CN601
GND
10
VCC
9
SCLK
8
N.C.
7
INS
6
N.C.
5
DIO
4
N.C.
3
BS
2
GND
1
3
12
11
CHASSIS_GND
LND601
MEMORY
STICK
DUO
B
VC-472
(12/17)
CN7001
Through the
C
Flexible Flat Cable
(FFC-084)
Page 4-17
of Level 3
D
CN301 20P
LED_K
EP_4.6V
EVF_COM
EVF_PSIG
EVF_VG
EVF_VR
EVF_VB
EVF_PCG
EVF_EN
EVF_VCK
EVF_VST
EVF_STB
EVF_REF
EVF_DWN
EVF_RGT
EVF_HCK1
EVF_HCK2
EVF_HST
REG_GND
EVF_VDD
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
R301
47k
1
CF-102 BOARD
A
CONTROL SWITCH
XX MARK:NO MOUNT
B
VC-472
(15/17)
CN1002
Through the
Flexible Flat Cable
(FFC-085)
Page 4-20
of Level 3
C
D
E
05
23
10P
CN802
10
XRESET
9
REG_GND
KEY_AD3
LI_3V
REG_GND
8
7
6
5
4
3
2
SP+
1
SP-
D801
CL-271TLY-C-TS
CHG
32
1
Note: BT901 (lithium battery) is not
included in CF-102 complete board.
BATT_INFO
XCHARGE_LED
CHARGE_LED_VDD
LND802
CHASSIS_GND
D803
E
05
4
LND801
CHASSIS_GND
3
4
2
5
1
6
D802
XX
BH801
(BATTERY HOLDER)
XX
BT901
(LITHIUM BATTERY)
CN801
1
SP+
2
SP-
5
2
1
4
3
2
1
3
4
2
1
3
4
R801
1500
1
2
3
4
R802
2200
1
2
3
2P
S801
RESET
/BATT INFO
BACK LIGHT
PANEL
OPEN/CLOSE
SP901
SPEAKER
S802
DISP
S803
EASY
S804
S805
6
CONTROL KEY BLOCK (SS21200)
A
CONTROL KEY BLOCK (SS21200) is replaced as block,
so that PRINTED WIRING BOARD is omitted.
B
C
MODE
D
POWER
(CHG)
E
05
23
RV001
20k
WT
(ZOOM)
S003
(PHOTO REC)
S005
(PHOTO FREEZE)
ON
REG_GND
LND021
OFF
XMODE_SW
XPOWER_SW
R001
10k
R002
11.7k
LND019
LND020
4
D001
PLAY/
D002
MEMORY
D003
TAPE
EDIT
CAMERA
(EJECT)
START/STOP
S001
S004
6571
REG_GND
14
ZOOM_VR
13
D_2.8V
12
KEY_AD2
11
XMODE_SW
10
XPOWER_SW
9
REG_GND
8
MODE_LED_VDD
7
XVTR_LED
6
XMEM_LED
5
XCAM_LED
4
XEJECT_SW
3
REG_GND
2
KEY_AD0
1
REC
LND001
LND002
LND003
LND004
LND005
LND006
LND007
LND008
LND009
LND010
LND011
LND012
LND013
LND014
VC-472
(15/17)
CN1012
Page 4-20
of Level 3
DCR-HC47E/HC48/HC48E_L2
4-26
MS-342, LB-132, CF-102, SS21200
Page 44
1
538
62 974
B
C
D
MECHANISM BLOCK
A
DEW-
LM_LOAD
LM_LOAD
LM_UNLOAD
LM_UNLOAD
12345
DEW+
XMODE_SW_A
6
789
SW_COM
XMODE_SW_B
XMODE_SW_C
1011121314151617181920212223242526
CHIME_SDA
CHIME_VDD
XREC_PROOF
(14/17)
CN1007
Page 4-19
of Level 3
CHIME_SCK
Cin_GND
TAPE_TOP
MIC/REC_SW_GND
TREEL-
TREEL+
XCCDOWN_SW
SREEL+
HALL_VCC
SREEL-
HALL_GND
TAPE_LED_K
TAPE_LED_A
TOP/END_GND
27NC28
TAPE_END
29
M
VC-472
FP-228
FLEXIBLE
BOARD
FP-032
FLEXIBLE
BOARD
DEW
SENSOR
S903
(MODE SWITCH)
1
2
1
XMODE_SW_A
2
XMODE_SW_B
3
XMODE_SW_C
4
DEW-
DEW+
SW_COM
DEW-
DEW+
XMODE_SW_A
XMODE_SW_B
XMODE_SW_C
SW_COM
1
2
1
2
3
4
M902
LOADING MOTOR
MIC902
S902
(REC PROOF)
S901
Q902
PT4850FJE00F
TAPE TOP
SENSOR
(CC DOWN)
Vcc-+
H901
HW-105A-CDE-T
S REEL SENSOR
Vcc +
G
G-
Q901
PT4850FJE00F
TAPE END SENSOR
D901
GL453SE0000F
(TAPE LED)
4 PIN
CONNECTOR
E
H902
HW-105A-CDE-T
T REEL SENSOR
FP-031 FLEXIBLE BOARD
F
05
DCR-HC47E/HC48/HC48E_L2
4-27
FP-031, FP-032, FP-228
Page 45
4-3. PRINTED WIRING BOARDS
Link
Link
CD-672 BOARD AV-112 BOARD
PD-312 BOARD (SIDE A)
PD-312 BOARD (SIDE B)
FP-386 FLEXIBLE BOARD
CR-082 BOARD
FP-626 FLEXIBLE BOARD
COMMON NOTE FOR PRINTED WIRING BOARDS
MS-342 BOARD
LB-132 BOARD
CF-102 BOARD (SIDE A)
CF-102 BOARD (SIDE B)
FP-031, FP-032, FP-228 FLEXIBLE BOARD
MOUNTED PARTS LOCATION
DCR-HC47E/HC48/HC48E_L2
Page 46
4-3. PRINTED WIRING BOARDS
4-3. PRINTED WIRING BO ARDS
(ENGLISH)
THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS
• : Uses unleaded solder.
•
Pattern from the side which enables seeing.
(The other layers’ patterns are not indicated)
• Through hole is omitted.
• There are a few cases that the part printed on diagram
isn’t mounted in this model.
• C: panel designation
: Circuit board
: Flexible board
: pattern of the rear side
• Chip parts.
Transistor Diode
C
EB
654
46
123
3152
21
12
345
534
54
45
123
312
23
14
3
21321321
46
43
12
4
3
3152
12
23
31
4625
654
123
(JAPANESE)
プリント図共通ノート
【プリント図ノート】
・ ：無鉛半田を使用しています。
・ ：基板
：フレキシブル配線板
見ている面側のパターン。
：裏側のパターン
（他のパターンについては表示されていません）
・スルーホールは省略。
・プリント図には，本機で使用していない部品が記載されている
場合があります。
・Cはパネル表示名称。
14
DCR-HC47E/HC48/HC48E_L2
4-29
Page 47
CD-672 (4 layers)
: Uses unleaded solder.
CD-672 BOARD (SIDE A)
4
SE7002
(PITCH)
12
10
1
R7001
C7016
C
13
C7002
CN7001
BE
Q7001
24
C7026
C7024
C7001
C7011
C7028
A
B
24
C7027
13
R7017
C7029
C7025
11
IC7003
R7015 R7016
20
R7013
C7023
R7014
128
L7002
CD-672 BOARD (SIDE B)
3
R7018
28
C7017 C7018
R7019
17
RB7001
C7015
R7020
A
C7009
C7003
C7010
FB7001
L7001
C7006
C7007
R7012
R7009
C7008
C7004
R7011
C
Q7002
13
C7013
12
R7002
R7005
BE
6
4
IC7001
SE7001
C7012
R7007
R7008
(YAW)
C7005
R7006
C7014
4
3
R7004
R7010
C7030
Note: IC7002 is not supplied,
but this is included in
CCD block assy.
10
1
IC7002
2011
B
DCR-HC47E/HC48/HC48E_L2
111-871-068-
05
1
2
05
2
1
4-31
111-871-068-
CD-672
Page 48
Printed wiring boards of the VC-472 board are not shown.
Pages 4-32 and 4-33 are not shown.
DCR-HC47E/HC48/HC48E_L2
Page 49
PD-312 (2 layers)
: Uses unleaded solder.
PD-312 BOARD (SIDE A)
A
AKAKAK
D6305
(BACKLIGHT)
B
D6303
(BACKLIGHT)
D6304
(BACKLIGHT)
C
111-871-086-
05
1
2 3 4 5 6
DCR-HC47E/HC48/HC48E_L2
4-34
PD-312 (SIDE A)
Page 50
PD-312 (2 layers)
: Uses unleaded solder.
PD-312 BOARD (SIDE B)
LND631
R6326
LND632
LND633
R6313
1
D6310
23
301
CN6301
R6316
R6314
R6315
C6301
16
CN6303
R6307
BE
Q6303
C
C6304
C6305
Q6301
134613
C6302
D6302
CN6305
R6309
VD6301
VD6302
VD6303
16
CN6304
C6306
124
46
Q6302
C6303
VD6304
CL6304
R6301
R6302
R6303
R6304
R6305
13
R6327
D6301
R6328
16
CN6302
46
CL6303
CL6301
CL6302
R6331
R6329
R6330
A
D6308
D6306
B
D6307
C
DCR-HC47E/HC48/HC48E_L2
111-871-086-
05
4-35
23456
1
PD-312 (SIDE B)
Page 51
FP-386 (1 layer), CR-082 (2 layers), FP-626 (1 layer)
: Uses unleaded solder.
FP-386 FLEXIBLE BOARD
S101
(PANEL REVERSE)
FP-386
S101
>PI<
05
1-867-795- 11
FX
CR-082 BOARD
FP-626 FLEXIBLE BOARD
30
LND030
LND029
LND028
LND027
LND026
LND025
LND024
LND023
LND022
LND021
LND020
LND019
LND018
LND017
LND016
LND015
LND014
LND013
LND012
LND011
LND010
LND009
LND008
LND007
LND006
LND005
LND004
LND003
LND002
1
LND001
LND101
LND103
LND104
LND106
1
6
1
BH001
BATTERY
TERMINAL
12
36
1
3
46
D502
1
23
D503
VD505
VD502
VD501
VD503
VD504
42
2102030
CN502
1
123
Note: BH001 and J001 are not included in
FP-626 flexible board.
J001
DC IN
4
C
LND501
05
44
Note: CN501 (multi connector) is not supplied,
but this is included in CR-082 complete board.
DCR-HC47E/HC48/HC48E_L2
41
CN501
15152535
43
LND502
LND112
12
LND111
LND110
LND109
111-871-117-
LND201
05
4-36
LND108
LND107
LND106
LND105
LND104
LND103
LND102
LND101
1
111-871-485-
FP-386, CR-082, FP-626
Page 52
AV-112 (2 layers), MS-342 (2 layers), LB-132 (2 layers)
: Uses unleaded solder.
AV-112 BOARD (SIDE A)
A/V
OUT
CN402
6978 10
12345
FB402
FB401
R401
05
R402
R403
AV-112 BOARD (SIDE B)
13
11
12
11
CN401
2
1
111-871-093-
05
14
CN402
12
111-871-093-
MS-342 BOARD
C601
10
D602
3
1
64
1
CN601
CN602
R601
110
12
KA
D601
D601
(MS ACCESS)
MEMORY
STICK
DUO
LB-132 BOARD (SIDE A)
20
CN301
19
2
CN302
1
05
2
1
20
21
111-871-096-
LB-132 BOARD (SIDE B)
R301
05
D301
(BACKLIGHT)
AK
C301
R302
C303
C302
D302
11
05
LND601
111-871-143-
111-871-096-
DCR-HC47E/HC48/HC48E_L2
4-37
AV-112, MS-342, LB-132
Page 53
CF-102 (2 layers)
: Uses unleaded solder.
LND802
CF-102 BOARD (SIDE A)
LND801
AK
2
1
D801
S804
S803
4
EASY
3
CHG
RESET
05
PANEL
OPEN/CLOSE
3
1
S801
4
2
1
DISP/
S802
2
4
2
S805
4
BATT INFO
3
1
BACK LIGHT
3
DCR-HC47E/HC48/HC48E_L2
4-38
111-871-368-
CF-102 (SIDE A)
Page 54
CF-102 (2 layers)
: Uses unleaded solder.
CF-102 BOARD (SIDE B)
Note: BT901 (lithium battery) is not included
in CF-102 complete board.
R802
R801
BT901
13
64
D802
BH801
1
BT901
BATTERY,
LITHIUM SECONDARY
23
12
CN801
23
CN802
110
1
D803
111-871-368-
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
電池の交換は，正しく行わないと破裂する恐れがあり
ます。電池を交換する場合には必ず同じ型名の電池
又は同等品と交換してください。
CAUTION
注意
DCR-HC47E/HC48/HC48E_L2
Note: Replace the battery holder (BH801) together
05
ノート:CF-102基板のリチウム電池（BT901）を交換
4-39
when replacing the lithium battery (BT901) on
the CF-102 board. (The battery holder removed
once cannot be used again.)
When mounting these parts, mount new battery holder first and attach new lithium battery
next.
する場合はバッテリホルダ（BH801）も同時に
新品に交換して下さい。（一度使用したバッ
テリホルダは再使用できません。）
部品取り付けの際は，先にバッテリホルダを
取り付けてからリチウム電池を装着して下さ
い。
CF-102 (SIDE B)
Page 55
FP-031 (1 layer), FP-032 (1 layer), FP-228 (1 layer)
: Uses unleaded solder.
FP-032 FLEXIBLE BOARD
S903
MODE SWITCH
1-867-810-
11
MIC902
S902
(REC PROOF)
4 PIN
CONNECTOR
Q902
TAPE TOP SENSOR
S901
(CC DOWN)
D901
(TAPE LED)
FP-228 FLEXIBLE BOARD
FP-031 FLEXIBLE BOARD
1
DEW
SENSOR
1-677-049-
+
GND
-
VCC
H902
T REEL SENSOR
11
12
M902
LOADING MOTOR
M
H901
S REEL SENSOR
+
1
(Dilect Solder)
2
(Dilect Solder)
14
GND
VCC
-
29
DCR-HC47E/HC48/HC48E_L2
4-40
1-867-811-
12
Q901
TAPE END SENSOR
05
FP-031, FP-032, FP-228
Page 56
4-3. PRINTED WIRING BOARDS
4-4. MOUNTED PARTS LOCATION
CD-672 BOARD
C7002 B-1
C7003 B-2
C7005 B-2
C7006 A-2
C7007 A-2
C7010 A-2
C7011 A-2
C7015 A-2
C7016 A-1
C7017 A-2
C7018 A-2
C7023 B-1
C7024 B-1
C7025 A-1
C7026 A-1
C7027 A-1
C7028 B-1
C7029 A-1
CN7001 B-1
FB7001 A-2
* IC7002 B-2
IC7003 B-1
L7001 B-2
L7002 B-1
Q7001 A-1
Q7002 B-2
R7002 B-2
R7004 B-2
R7005 B-2
R7006 B-2
R7013 B-1
R7014 B-1
R7015 B-1
R7016 B-1
RB7001 A-2
SE7001 A-2
SE7002 A-1
no mark : side A
mark : side B
*
DCR-HC47E/HC48/HC48E_L2
4-41
CD-672
Page 57
Mounted parts location of the VC-472 board are not shown.
Pages 4-42 and 4-43 are not shown.
DCR-HC47E/HC48/HC48E_L2
Page 58
PD-312 BOARD
* C6302 C-3
* C6303 C-3
* C6304 C-4
* C6305 C-4
* C6306 C-5
* CN6301 A-5
* CN6302 C-2
* CN6303 B-5
* CN6304 C-3
* CN6305 C-4
* D6302 C-4
D6303 B-1
D6304 C-1
D6305 A-1
* Q6301 B-3
* Q6302 B-3
* Q6303 C-4
* R6302 B-2
* R6303 B-2
* R6304 B-2
* R6305 B-2
* R6307 B-4
* R6309 C-4
* VD6301 C-3
* VD6302 C-3
* VD6303 C-3
* VD6304 C-3
4-3. PRINTED WIRING BOARDS
no mark : side A
mark : side B
*
DCR-HC47E/HC48/HC48E_L2
4-44E
PD-312
Page 59
NOTE
CABINET (L) SECTION
MECHANISM DECK
SECTION
CD-672 BOARD
AV-112 BOARD
FP-228 FLEXIBLE BOARD
FP-032 FLEXIBLE BOARD
FP-386 FLEXIBLE BOARD
CR-082 BOARD
CF-102 BOARD
FP-031 FLEXIBLE BOARD
LB-132 BOARD
FP-626 FLEXIBLE BOARD
PD-312 BOARD
MS-342 BOARD
C
F
I
I
E
B
D
I
F
F
E
B
5. REPAIR PARTS LIST
NOTE: Characters A to Z of the electrical parts list indicate location of exploded views in which the desired part is shown.
Link
Link
ABCD
OVERALL SECTION
LCD PANEL BLOCK BT-EVF SECTION
BOTTOM FRAME SECTION
EF H
EXPLODED VIEWS
EXPLODED VIEWS
CABINET (R) SECTION
G
LS/MECHANICAL CHASSIS
BLOCK ASSEMBLY-1
I
LS/MECHANICAL CHASSIS
BLOCK ASSEMBLY-2
Link
Link
ELECTRICAL PARTS LIST
ELECTRICAL PARTS LIST
ACCESSORIES
DCR-HC47E/HC48/HC48E_L2
Page 60
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
(ENGLISH)
NOTE:
• -XX, -X mean standardized parts, so they may have some differences from
the original one.
• Items marked “*” are not stocked since they are seldom required for routine
service. Some delay should be anticipated when ordering these items.
•The mechanical parts with no reference number in the exploded views are not
supplied.
• Due to standardization, replacements in the parts list may be different from
the parts specified in the diagrams or the components used on the set.
• CAPACITORS:
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
• Color Indication of Appearance Parts
Example:
(SILVER) : Cabinet’s Color
(Silver) : Parts Color
(JAPANESE)
【使用上の注意】
• ここに記載されている部品は,補修用部品であるため,回路図及び
セットに付いている部品と異なる場合があります。
• -XX,-Xは標準化部品のため,セットに付いている部品と異なる場合
があります。
• *印の部品は常備在庫しておりません。
• コンデンサの単位でuFはμFを示します。
• 抵抗の単位Ωは省略してあります。
金 被：金属被膜抵抗。
サンキン：酸化金属被膜抵抗。
• インダクタの単位でuHはμHを示します。
• 半導体の名称でuA...,uPA...,uPB...,uPC...,uPD...等はそれぞれμ
A...,μPA...,μPB...,μPC...,μPD...を示します。
•Abbreviation
AR : Argentine model
AUS: Australian model
BR : Brazilian model
CH : Chinese model
CND : Canadian model
EE : East European model
HK : Hong Kong model
J: Japanese model
JE : Tourist model
KR : Korea model
NE : North European model
お願い
図面番号で部品を指定するときは基板名又はブロック
を併せて指定してください。
0印の部品，または0印付の点線で囲まれた部品は，
安全性を維持するために，重要な部品です。
従って交換時は，必ず指定の部品を使用してください。
• 外装部品色表示
例：
(SILVER):セットの色を表す。
(Silver) :部品の色を表す。
DCR-HC47E/HC48/HC48E_L2
5-1
Page 61
5. REPAIR PARTS LIST
DISASSEMBLY
5. REPAIR PARTS LIST
5-1. EXPLODED VIEWS
5-1-1. OVERALL SECTION
#2
1
#1
HARDWARE LIST
#2
2
3
Bottom Frame Section
(See Page 5-3)
#2
#2
#1
4
#2
#2
7
#12
5
6
MIC901
#2
Cabinet (R) Section
(See Page 5-5)
Ref. No. Part No. Description Ref. No. Part No. Description
1 X-2176-373-1 CABINET (L (215)) ASSY
2 2-899-773-01 CABINET (UPPER)
3 2-899-772-01 KNOB (215), NS
4 1-833-206-11 CABLE, FLEXIBLE FLAT (FFC-085)
5 2-899-716-01 RETAINER, MICROPHONE
6 2-899-717-01 CUSHION, MICROPHONE
7 X-2176-364-1 PANEL (215) ASSY, F (EXCEPT J)
7 X-2176-365-1 PANEL (215J) ASSY, F (J)
MIC901 1-542-712-11 MICROPHONE UNIT
#1 2-635-562-11 SCREW (M1.7) (Black)
#2 2-635-562-31 SCREW (M1.7) (Black)
#12 3-080-204-21 SCREW, TAPPING, P2 (Black)
DCR-HC47E/HC48/HC48E_L2
5-2
Page 62
DISASSEMBLY
5-1-2. BOTTOM FRAME SECTION
Cabinet (L) Section
(See Page 5-4)
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
HARDWARE LIST
#2
BT-EVF Section
(See Page 5-7)
53
54
55
52
#1
51
57
56
MS-342
#3
CR-082
#3
Ref. No. Part No. Description Ref. No. Part No. Description
51 2-899-769-01 SCREW, TRIPOD
* 52 2-899-767-01 FRAME, BOTTOM
53 1-833-207-11 CABLE, FLEXIBLE FLAT (FFC-086)
54 2-899-768-01 CABINET, MS
55 A-1212-565-A MS-342 BOARD, COMPLETE
DCR-HC47E/HC48/HC48E_L2
56 A-1212-567-A CR-082 BOARD, COMPLETE
57 1-833-210-11 CABLE, FLEXIBLE FLAT (FFC-089)
#1 2-635-562-11 SCREW (M1.7) (Black)
#2 2-635-562-31 SCREW (M1.7) (Black)
#3 2-660-401-01 SCREW (M1.7), NEW TRU-STAR, P2 (Red)
5-3
Page 63
5-1-3. CABINET (L) SECTION
DISASSEMBLY
ns: not supplied
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
HARDWARE LIST
Mechanism Deck Section
(See Page 5-8)
101
#12
#2
112
#15
102
ns
107
IC7002
(Note 1, 2)
ns
105
104
103
111
106
108
HC47E/
HC48: US/
HC48E: NE, E
CD672
#12
110
Note 1: IC7002は交換対象ではありません
が，CCDブクミに含まれます。
Note 1: IC7002 is not supplied, but this is
included in CCD block assy.
Note 2: イメージャの交換時は4 - 4 ペー
ジのイメージャ交換時の注
意を必ずお読みください。
Note 2: Be sure to read “Precautions for
Replacement of Imager” on page
4-3 when changing the imager.
Ref. No. Part No. Description Ref. No. Part No. Description
101 1-479-928-21 KEY BLOCK, CONTROL (SS21200) (EXCEPT J)
101 1-479-928-31 KEY BLOCK, CONTROL (SS21200) (J)
102 2-899-770-01 PLATE, NS CLICK
103 1-788-523-11 OPTICAL FILTER BLOCK (OFB-06-11)
104 3-088-645-01 RUBBER (Z), SEAL
105 A-1212-400-A CD-672 BOARD, COMPLETE
106 1-833-676-11 CABLE, FLEXIBLE FLAT (FFC-004)
107 A-1248-849-A LENS (BLOCK ASSY 1180 (J1))
108 A-1212-718-A VC-472 BOARD, COMPLETE (HC48)
108 A-1212-719-A VC-472 BOARD, COMPLETE (HC47E/HC48E)
109 2-659-500-01 LABEL, FUSE REPLACEMENT CAUTION
(HC47E/HC48: US/HC48E: NE, E)
* 110 3-095-468-01 SHEET (CD (215)), COPY
* 111 3-095-521-01 SHEET/GUARD
112 2-899-740-01 CUSHION, ELECTROSTATIC
IC7002 A-1216-665-A CCD BLOCK ASSY (1M) (CCD IMAGER)
#2 2-635-562-31 SCREW (M1.7) (Black)
#3 2-660-401-01 SCREW (M1.7), NEW TRU-STAR, P2 (Red)
#12 3-080-204-21 SCREW, TAPPING, P2 (Black)
#15 3-062-214-01 SCREW (M1.4X1.5) (Silver)
VC-472
109
#3
(Note1, 2)
DCR-HC47E/HC48/HC48E_L2
5-4
Page 64
5-1-4. CABINET (R) SECTION
k
DISASSEMBLY
ns: not supplied
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
HARDWARE LIST
#12
BT901
(Note)
ns
#12
ns
SP901
#12
#12
BH801
(Note)
153
154
151
155
ns
ns
152
!
: BT901 (BATTERY, LITHIUM SECONDARY)
Board on the mount position.
(See page 4-39.)
Note: Replace the battery holder (BH801) together when replac-
ing the lithium battery (BT901) on the CF-102 board. (The
battery holder removed once cannot be used again.)
When mounting these parts, mount new battery holder first
and attach new lithium battery next.
Note: CF-102基板のリチウム電池（BT901）を交換する場合はバッ
テリホルダ（BH801）も同時に新品に交換して下さい。（一度
使用したバッテリホルダは再使用できません。）
部品取り付けの際は，先にバッテリホルダを取り付けてか
らリチウム電池を装着して下さい。
• Refer to page 5-1 for mark 0.
Ref. No. Part No. Description Ref. No. Part No. Description
151 A-1212-683-A CF-102 BOARD, COMPLETE
152 3-089-565-01 CUSHION (R), PANEL
153 X-2176-367-1 BLIND ASSY, HINGE
154 2-899-759-11 PLATE, R ORNAMENTAL
155 X-2176-369-1 CABINET (R (215)) ASSY (EXCEPT J)
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
電池の交換は，正しく行わないと破裂する恐れがあり
ます。電池を交換する場合には必ず同じ型名の電池
又は同等品と交換してください。
155 X-2176-370-1 CABINET (R (215J)) ASSY (J)
0BH801 1-756-615-41 HOLDER, BATTERY (Note)
0BT901 1-756-134-12 BATTERY, STORAGE, LITHIUM (Note)
SP901 1-825-260-23 LOUD SPEAKER (1.6CM)
#12 3-080-204-21 SCREW, TAPPING, P2 (Black)
#12
CAUTION
注意
LCD Panel Bloc
(See Page 5-6)
DCR-HC47E/HC48/HC48E_L2
5-5
Page 65
5-1-5. LCD PANEL BLOCK
ns: not supplied
202
201
217
#1
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
204
203
HARDWARE LIST
LCD901
#1
220
219
218
215
213
#2
216
214
213
221
212
205
206
207
208
209
210
ns
PD-312
211
#12
Ref. No. Part No. Description Ref. No. Part No. Description
201 1-478-984-11 KEY BLOCK, CONTROL (SB10600)
202 2-899-743-01 CABINET (M (215)), P (EXCEPT J)
202 2-899-743-11 CABINET (M (215)), P (J)
* 203 2-899-745-01 PLATE (215), LCD GROUND
* 204 2-899-747-01 CUSHION (2.7), TP
205 2-694-516-01 FRONT FRAME (2.7)
206 2-694-512-01 PRISM SHEET V (2.7)
207 2-694-513-01 PRISM SHEET H (2.7)
208 2-694-514-01 DIFFUSION SHEET (2.7)
209 2-666-801-11 LIGHT GUIDE (2.7)
210 2-694-515-01 REFLECTION SHEET (2.7)
211 A-1212-630-A PD-312 BOARD, COMPLETE
212 2-899-738-11 PLATE, PANEL ORNAMENT (HC48/HC48E)
212 2-899-738-41 PLATE, PANEL ORNAMENT (HC47E)
213 2-899-740-01 CUSHION, ELECTROSTATIC
214 2-899-735-01 CABINET (C), P
215 A-1153-842-A FP-386 FLEXIBLE BOARD, COMPLETE
216 2-899-739-11 PLATE, HINGE ORNAMENTAL
217 1-871-484-11 FP-625 FLEXIBLE BOARD
218 2-899-736-01 COVER (C), HINGE
219 X-2149-207-1 HINGE ASSY (M), PANEL
220 2-899-737-01 COVER (M), HINGE
* 221 3-096-097-01 CUSHION (P), EMC
LCD901 A-1202-057-A TP BLOCK ASSY (27TSTNI07)
#1 2-635-562-11 SCREW (M1.7) (Black)
#2 2-635-562-31 SCREW (M1.7) (Black)
#12 3-080-204-21 SCREW, TAPPING, P2 (Black)
DCR-HC47E/HC48/HC48E_L2
5-6
Page 66
5-1-6. BT-EVF SECTION
#11
#11
259
260
261
258
257
256
255
254
253
252
251
265
LCD902
J001
BH001
264
263
266
262
267
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
HARDWARE LIST
Ref. No. Part No. Description Ref. No. Part No. Description
* 251 1-833-205-11 CABLE, FLEXIBLE FLAT (FFC-084)
252 A-1212-408-A LB-132 BOARD, COMPLETE
253 2-664-672-01 GUIDE, LAMP
* 254 2-638-819-01 CUSHION, LCD
* 255 2-638-818-01 ILLUMINATOR
* 256 2-638-816-01 PLATE (TFT), DEFLECTION
257 2-664-671-01 SPACER, LCD
258 2-899-659-01 CAP (215), INNER
259 2-899-660-01 PANEL (CF), POLARIZATION
260 2-899-657-01 CABINET, INNER
261 X-2176-362-1 EYE CUP (215) ASSY
262 2-899-886-01 COVER, DC-AV
263 2-899-887-01 LID, CPC
264 X-2176-359-1 BT-VF (215) ASSY
265 A-1212-459-A AV-112 BOARD, COMPLETE
266 2-899-661-01 FRAME, TERMINAL FIXED
* 267 1-871-485-11 FP-626 FLEXIBLE BOARD
BH001 1-780-064-21 BATTERY TERMINAL BOARD
J001 1-815-792-11 CONNECTOR, DC-IN (7.2V)
LCD902 8-753-241-14 LCX076AKE-1
#11 3-078-890-11 SCREW, TAPPING (Silver)
DCR-HC47E/HC48/HC48E_L2
5-7
Page 67
5-1-7. MECHANISM DECK SECTION
ns: not supplied
706
707
ns
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
708
709
702
705
703
701
705
704
LS / Mechanical chassis
block assembly-1
(See page 5-9)
M901
710
705
711
712
713
715
Ref. No. Part No. Description Ref. No. Part No. Description
701 X-2024-478-1 PENDULUM ASSY
702 2-342-917-02 LED BASE
703 7-627-850-77 SCREW, PRECISION +P 1.4X1.8
704 3-079-366-11 RELEASE, REEL LOCK
705 3-703-816-08 SCREW (M1.4X1.4), SPECIAL HEAD
706 X-2149-724-1 COMPARTMENT ASSY, CASSETTE
707 2-342-926-01 SPRING (ARM S), TENSION COIL
708 2-546-417-01 SCREW (1.4X1.0), POWER LOCK
709 2-342-933-02 PLATE, TOP
710 2-342-927-01 SPRING (ARM T), TENSION COIL
711 2-541-585-01 SHEET, FLEXIBLE ADHESIVE
712 2-342-918-01 TG6 CATCHER
713 A-1080-997-A MD (N100) SUB ASSY A
714 3-703-816-13 SCREW (M1.4X2.0), SPECIAL HEAD
715 3-315-414-31 WASHER
M901 A-1154-545-A DRUM (DEH-33E-R)
DCR-HC47E/HC48/HC48E_L2
5-8
714
Page 68
5. REPAIR PARTS LIST
s
5. REPAIR PARTS LIST
5-1-8. LS/MECHANICAL CHASSIS BLOCK ASSEMBLY-1
ns: not supplied
756
760
759
768
768
768
n
753
752
751
754
ns
755
757
772
(Note)
772
(Note)
762
761
763
764
765
766
767
758
769
770
771
Note: These two screws are the fixing screws of the LS cam plate.
These two fixing screws are used for adjsting the LS cam plate position.
(refar to 4-2. LS cam adjustment of DV mechanical adjustment manual IX)
Ref. No. Part No. Description Ref. No. Part No. Description
751 2-342-759-01 SPRING, RVS BRAKE
752 A-1083-005-A BLOCK ASSY, RVS BRAKE
753 2-342-731-01 POSITIONING, S
754 A-1083-006-A BLOCK ASSY, S BRAKE
755 3-075-097-11 SCREW (M1.4X1.4), SPECIAL HEAD
756 X-2024-473-1 TABLE ASSY, S REEL
757 A-1083-007-B BLOCK ASSY, TENSION REGULATOR
758 2-342-705-01 GEAR (T), GL
759 2-342-902-01 SPRING, TENSION REGULATOR
760 X-2024-474-1 TABLE ASSY, T REEL
761 X-2024-476-1 ARM ASSY, PINCH
762 2-342-906-01 SPRING (PINCH RETURN), TORSION
DCR-HC47E/HC48/HC48E_L2
LS / Mechanical chassis
block assembly-2
(See page 5-10)
755
763 2-342-626-01 SPRING (RETURN TG6), EXTENSION
764 A-1083-002-A BLOCK ASSY, TG6
765 X-2024-468-3 ARM ASSY (S), GL
766 X-2024-465-1 COASTER (S) ASSY
767 2-342-612-01 RAIL
768 3-703-816-13 SCREW (M1.4X2.0), SPECIAL HEAD
769 X-2024-466-1 COASTER (T) ASSY
770 X-2024-469-1 ARM (T) ASSY, GL
771 2-342-716-01 SPRING (T), TORSION COIL
772 3-703-816-08 SCREW (M1.4X1.4), SPECIAL HEAD
(for adjustment)
5-9
Page 69
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
5-1-9. LS/MECHANICAL CHASSIS BLOCK ASSEMBLY-2
ns: not supplied
ns
821
MIC902
820
H901
Q901
FP-031
(Note 1)
803
D901
Q902
804
S901
H902
806
804
FP-031
(Note 1)
810
811
(Note2)
807
808
M902
812
814
813
815
817
815
816
818
FP-032
(Note 1, 2)
ns
809
802
801
Note1:The FP-031 and FP-032 are supplied as the assembled part of
the MD (N100) sub ass'y A by attaching them with the adhesive agent.
These parts are not separately supplied because assembling of
these parts requires high accuracy.
Note2:The mode switch (S903) function works when the contactor of the FP-032
contacts with the bottom surface of wiper of the mode gear ass'y.
Ref. No. Part No. Description Ref. No. Part No. Description
801 2-342-624-01 SPRING (PINCH LIMITTER), EXTENSION
802 X-2024-463-2 SLIDER ASSY, MODE
803 X-2024-462-1 GEAR ASSY, CAM
804 3-075-097-11 SCREW (M1.4X1.4), SPECIAL HEAD
806 2-342-621-01 GEAR, RELAY
807 3-315-414-31 WASHER
808 2-342-620-01 GEAR, CONVERSION
809 3-084-377-01 HEAD (SCREW M1.2)
810 X-2024-460-1 BASE ASSY, CAM
811 X-2024-461-1 GEAR ASSY, MODE
812 2-342-615-01 GEAR, NO.2
813 2-342-691-01 GEAR, NO.1
814 2-637-945-01 HOLDER, MOTOR
815 3-895-822-71 SCREW (M1.2X2), SPECIAL, 0
816 2-342-689-01 WORM SHAFT (2J)
817 2-342-690-02 BASE, MOTOR HOLDER
818 1-677-049-11 FP-228 FLEXIBLE BOARD (DEW SENSOR)
819 2-342-686-01 COVER, CAPSTAN
820 2-541-984-01 MIC COVER
821 3-703-816-13 SCREW (M1.4X2.0), SPECIAL HEAD
D901 6-500-652-01 DIODE GL453SE0000F (TAPE LED)
H901 8-719-067-74 ELEMENT, HOLE HW-105A-CDE-T (S REEL)
H902 8-719-067-74 ELEMENT, HOLE HW-105A-CDE-T (T REEL)
M902 X-2024-464-1 MOTOR ASSY (LOADING)
MIC902 1-818-576-11 PIN, CONNECTOR (WITH DETECTION)
Q901 6-550-672-01 TRANSISTOR PT4850FJE00F (TAPE END)
Q902 6-550-672-01 TRANSISTOR PT4850FJE00F (TAPE TOP)
S901 1-786-448-22 SWITCH, PUSH (1 KEY) (CC DOWN)
819
ns
DCR-HC47E/HC48/HC48E_L2
5-10
Page 70
AV-112 CD-672 CF-102
5-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Ref. No. Part No. Description
A-1212-459-A AV-112 BOARD, COMPLETE
***********************
< CONNECTOR >
CN401 1-779-330-51 CONNECTOR, FFC/FPC 12P
CN402 1-815-794-13 CONNECTOR (MULTIPLE) (A/V OUT)
R7002 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R7004 1-218-965-11 RES-CHIP 10K 5% 1/16W
R7005 1-218-953-11 RES-CHIP 1K 5% 1/16W
R7006 1-218-966-11 RES-CHIP 12K 5% 1/16W
R7013 1-218-965-11 RES-CHIP 10K 5% 1/16W
< RESISTOR >
< FERRITE BEAD >
FB401 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
FB402 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
A-1212-400-A CD-672 BOARD, COMPLETE
***********************
(IC7002 is not supplied, but this is included in CCD block assy.)
< CAPACITOR >
C7002 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C7003 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C7005 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7006 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C7007 1-127-820-11 CERAMIC CHIP 4.7uF 10% 16V
C7010 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7011 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
C7015 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7016 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7017 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7018 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7023 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C7024 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C7025 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C7026 1-100-251-11 CERAMIC CHIP 0.047uF 10% 10V
C7027 1-100-251-11 CERAMIC CHIP 0.047uF 10% 10V
C7028 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C7029 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
< CONNECTOR >
R7014 1-218-989-11 RES-CHIP 1M 5% 1/16W
R7015 1-218-989-11 RES-CHIP 1M 5% 1/16W
R7016 1-218-965-11 RES-CHIP 10K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB7001 1-234-379-21 RES, NETWORK 22K (1005X4)
< SENSOR >
SE7001 1-479-022-61 SENSOR, ANGULAR VELOCITY (32.2 kHz)
SE7002 1-479-022-51 SENSOR, ANGULAR VELOCITY (30.8 kHz)
A-1212-683-A CF-102 BOARD, COMPLETE
**********************
(BT901 (lithium battery) is not included in CF-102 complete board.)
< BATTERY HOLDER >
0BH801 1-756-615-41 HOLDER, BATTERY (Note 2)
< BATTERY >
0BT901 1-756-134-12 BATTERY, STORAGE, LITHIUM (Note 2)
< CONNECTOR >
CN801 1-794-057-21 PIN, CONNECTOR (PC BOARD) 2P
CN802 1-766-646-51 CONNECTOR, FFC/FPC 10P
< DIODE >
* D801 6-501-573-01 DIODE CL-271TLY-C-TS (CHG)
CN7001 1-820-586-51 CONNECTOR, FFC/FPC 28P
FB7001 1-400-331-11 FERRITE, EMI (SMD) (1005)
IC7002 A-1216-665-A CCD BLOCK ASSY (1M) (CCD IMAGER)
IC7003 8-759-489-19 IC uPC6756GR-8JG-E2
L7001 1-400-588-11 INDUCTOR 10uH
L7002 1-400-588-11 INDUCTOR 10uH
Q7001 6-550-234-01 TRANSISTOR UNR32A300LS0
Q7002 8-729-055-21 TRANSISTOR 2SC5096-O/R (TE85L)
• Refer to page 5-1 for mark 0.
• Refer to page 5-1 for mark 0.
DCR-HC47E/HC48/HC48E_L2
< FERRITE BEAD >
< IC >
< COIL >
< TRANSISTOR >
(Note 1)
5-11
Danger of explosion if battery is incorrectly replaced.
CAUTION
Replace only with the same or equivalent type.
注意
電池の交換は，正しく行わないと破裂する恐れがあり
ます。電池を交換する場合には必ず同じ型名の電池
又は同等品と交換してください。
Note 1: Be sure to read “Precautions for Replacement of
Imager” on page 4-3 when changing the imager.
Note 1: イメージャの交換時は4 - 4 ページのイメージャ
交換時の注意を必ずお読みください。
Note 2: Replace the battery holder (BH801) together when
replacing the lithium battery (BT901) on the CF-102
board. (The battery holder removed once cannot be
used again.)
When mounting these parts, mount new battery
holder first and attach new lithium battery next.
Note 2: CF-102基板のリチウム電池（BT901）を交換する場
合はバッテリホルダ（BH801）も同時に新品に交換
して下さい。（一度使用したバッテリホルダは再使
用できません。）
部品取り付けの際は，先にバッテリホルダを取り付
けてからリチウム電池を装着して下さい。
Page 71
CF-102 CR-082 FP-031 FP-032 FP-228 FP-386 FP-626 LB-132
MS-342 PD-312
Ref. No. Part No. Description Ref. No. Part No. Description
< RESISTOR >
< SWITCH >
R801 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R802 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
< SWITCH >
S801 1-786-157-31 TACTILE SWITCH (RESET)
S802 1-786-157-31 TACTILE SWITCH (DISP/BATT INFO)
S803 1-786-157-31 TACTILE SWITCH (EASY)
* S804 1-786-545-41 SWITCH, PUSH LEVER (S)
(PANEL OPEN/CLOSE)
S805 1-786-157-31 TACTILE SWITCH (BACK LIGHT)
A-1212-567-A CR-082 BOARD, COMPLETE
***********************
(CN501 (multi connector) is not supplied, but
this is included in CR-082 complete board.)
< CONNECTOR >
CN501 (Not supplied) CONNECTOR, MULTIPLE (SOCKET)
* CN502 1-818-073-51 CONNECTOR, FFC/FPC (ZIF) 36P
(Not supplied) FP-031 FLEXIBLE BOARD
********************
(This flexible board is included in MD (N100) sub assy A (A-1080-997-A).)
< DIODE >
S101 1-786-180-31 SWITCH, PUSH (1KEY) (PANEL REVERSE)
* 1-871-485-11 FP-626 FLEXIBLE BOARD
*********************
(BH001 and J001 are not included in FP-626 flexible board.)
< BATTERY TERMINAL >
BH001 1-780-064-21 BATTERY TERMINAL BOARD
< JACK >
J001 1-815-792-11 CONNECTOR, DC-IN (7.2V)
A-1212-408-A LB-132 BOARD, COMPLETE
**********************
< CAPACITOR >
C301 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C302 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C303 1-164-505-11 CERAMIC CHIP 2.2uF 16V
< CONNECTOR >
CN301 1-779-334-51 CONNECTOR, FFC/FPC 20P
* CN302 1-817-560-71 CONNECTOR, FPC (ZIP) 21P
D901 6-500-652-01 DIODE GL453SE0000F (TAPE LED)
< HOLE ELEMENT >
H901 8-719-067-74 ELEMENT, HOLE HW-105A-CDE-T (S REEL )
H902 8-719-067-74 ELEMENT, HOLE HW-105A-CDE-T (T REEL)
< CONNECTOR >
MIC902 1-818-576-11 PIN, CONNECTOR (WITH DETECTION)
< TRANSISTOR >
Q901 6-550-672-01 TRANSISTOR PT4850FJE00F (TAPE END)
Q902 6-550-672-01 TRANSISTOR PT4850FJE00F (TAPE TOP)
< SWITCH >
S901 1-786-448-22 SWITCH, PUSH (1 KEY) (CC DOWN)
(Not supplied) FP-032 FLEXIBLE BOARD
********************
(This flexible board with S903 is included in MD (N100) sub assy A
(A-1080-997-A).)
1-677-049-11 FP-228 FLEXIBLE BOARD (DEW SENSOR)
********************
< DIODE >
* D301 6-501-591-01 DIODE NESW007AT-T099 (BACKLIGHT)
D302 6-500-941-01 DIODE MAZS056008S0
< RESISTOR >
R301 1-216-841-11 METAL CHIP 47K 5% 1/10W
A-1212-565-A MS-342 BOARD, COMPLETE
***********************
< CONNECTOR >
CN601 1-817-913-41 MEMORY STICK DUO CONNECTOR
* CN602 1-816-643-51 FFC/FPC CONNECTOR (LIF) 10P
< DIODE >
D601 6-501-216-01 DIODE CL-271HR-C-TS (MS ACCESS)
< RESISTOR >
R601 1-218-941-81 RES-CHIP 100 5% 1/16W
A-1212-630-A PD-312 BOARD, COMPLETE
***********************
A-1153-842-A FP-386 FLEXIBLE BOARD, COMPLETE
******************************
DCR-HC47E/HC48/HC48E_L2
< CAPACITOR >
C6302 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
C6303 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
C6304 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6305 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6306 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
5-12
Page 72
Ref. No. Part No. Description Ref. No. Part No. Description
< CONNECTOR >
CN6301 1-818-072-51 CONNECTOR, FFC/FPC (ZIF) 30P
CN6302 1-573-915-51 CONNECTOR, FFC/FPC (ZIF) 6P
CN6303 1-573-915-51 CONNECTOR, FFC/FPC (ZIF) 6P
* CN6304 1-818-069-51 CONNECTOR, FFC/FPC (ZIF) 6P
CN6305 1-818-071-51 CONNECTOR, FFC/FPC (ZIF) 24P
< DIODE >
D6302 6-500-941-01 DIODE MAZS056008S0
* D6303 6-501-476-01 DIODE NSSW008CT-T071 (BACKLIGHT)
* D6304 6-501-476-01 DIODE NSSW008CT-T071 (BACKLIGHT)
* D6305 6-501-476-01 DIODE NSSW008CT-T071 (BACKLIGHT)
< TRANSISTOR >
Q6301 8-729-427-67 TRANSISTOR XP421F-TXE
Q6302 8-729-427-37 TRANSISTOR XP411F-TXE
Q6303 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
< RESISTOR >
R6302 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R6303 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R6304 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R6305 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R6307 1-218-978-11 RES-CHIP 120K 5% 1/16W
PD-312
R6309 1-218-989-11 RES-CHIP 1M 5% 1/16W
< VARISTOR >
* VD6301 1-802-279-11 VARISTOR (SMD)
* VD6302 1-802-279-11 VARISTOR (SMD)
* VD6303 1-802-279-11 VARISTOR (SMD)
* VD6304 1-802-279-11 VARISTOR (SMD)
Electrical parts list of the VC-472 board is
not shown.
Pages 5-14 to 5-20 are not shown.
DCR-HC47E/HC48/HC48E_L2
5-13
Page 73
AC Adaptor
(AC-L200/L200B)
* Compatible in
L200 and L200B.
0 1-479-285-21
Power Cord
0 1-555-074-91 (AUS)
0 1-782-476-71 (CH)
0 1-823-945-41 (US, CND)
0 1-823-947-71 (KR)
0 1-827-269-31 (UK)
0 1-827-826-41 (AEP, EE, NE,
E: PAL, E: NTSC (Latin America))
0 1-828-050-31 (JE)
0 1-830-518-41
(E: NTSC (Except Latin America))
Conversion (2P) Adaptor
0 1-569-007-12
(E: NTSC (Except Latin America),
JE)
Conversion (2P) Adaptor
0 1-569-008-12
(E: NTSC (Latin America))
A/V Connecting Cable
1-823-156-51
USB Cable
1-829-868-31
CD-ROM
"Handycam Application Software"
3-093-483-01
Handycam Station
(DCRA-C155)
1-820-790-11 (HC48/HC48E)
(DCRA-C156)
1-820-790-21 (HC47E)
Rechargeable Battery Pack
NP-FH40
0 A-1201-658-A (US, CND)
0 A-1201-659-A
(EXCEPT US, CND, CH)
0 A-1201-660-A (CH)
Wireless Remote Commander
RMT-831
1-478-495-41
21-pin Adaptor
1-770-783-21
(AEP, UK, EE, NE)
DVD-ROM
“ENJOY HANDYCAM”
3-093-691-01 (KR)
ENGLISH/KOREAN/JAPANESE
3-093-691-11 (US, CND, E)
ENGLISH/FRENCH/SPANISH/PORTUGUESE
3-093-691-21 (UK, EE, NE)
ENGLISH/RUSSIAN/GERMAN
3-093-691-31 (AEP)
ENGLISH/SPANISH/PORTUGUESE/ITALIAN
3-093-691-41 (AEP)
ENGLISH/FRENCH/PORTUGUESE/DUTCH
3-093-691-61 (E, AUS, CH)
ENGLISH/FRENCH/SIMPLIFIED CHINESE for CHINA/
TRADITIONAL CHINESE for HONG KONG
3-093-691-71 (E)
ENGLISH/TRADITIONAL CHINESE for TAIWAN/
SPANISH/PORTUGUESE
Ver. 1.1 2007.03
• EXCEPT J MODEL
Checking supplied accessories.
to J MODEL
Other accessories
2-319-511-11 MANUAL, INSTRUCTION (ENGLISH)
2-319-511-21 MANUAL, INSTRUCTION (FRENCH) (HC48: CND)
2-319-511-31 MANUAL, INSTRUCTION (SPANISH) (HC48: E, JE)
2-319-511-51 MANUAL, INSTRUCTION (TRADITIONAL CHINESE)
2-319-511-61 MANUAL, INSTRUCTION (KOREAN) (HC48: KR, JE)
2-319-512-11 MANUAL, INSTRUCTION (ENGLISH)
2-319-512-21 MANUAL, INSTRUCTION (FRENCH) (HC47E: AEP)
2-319-512-31 MANUAL, INSTRUCTION (GERMAN) (HC47E: AEP)
2-319-512-41 MANUAL, INSTRUCTION (DUTCH) (HC47E: AEP)
2-319-512-51 MANUAL, INSTRUCTION (SPANISH) (HC47E: AEP)
2-319-512-61 MANUAL, INSTRUCTION (PORTUGUESE) (HC47E: AEP)
2-319-512-71 MANUAL, INSTRUCTION (ITALIAN) (HC47E: AEP)
2-319-512-81 MANUAL, INSTRUCTION (GREEK) (HC47E: AEP)
2-319-512-91 MANUAL, INSTRUCTION (SWEDISH)
2-319-513-11 MANUAL, INSTRUCTION (RUSSIAN)
(HC48: US, CND, E, JE)
(HC48: E)
(HC47E: AEP, UK/HC48E: E, AUS, JE)
(HC47E: NE, HC48E: NE)
(HC47E: NE/HC48E: NE, JE)
DCR-HC47E/HC48/HC48E_L2
2-319-513-21 MANUAL, INSTRUCTION (DANISH)
(HC47E: NE, HC48E: NE)
2-319-513-31 MANUAL, INSTRUCTION (FINNISH)
(HC47E: NE, HC48E: NE)
2-319-513-41 MANUAL, INSTRUCTION (POLISH) (HC47E: EE)
2-319-513-51 MANUAL, INSTRUCTION (CZECH) (HC47E: EE)
2-319-513-61 MANUAL, INSTRUCTION (HUNGARIAN) (HC47E: EE)
2-319-513-71 MANUAL, INSTRUCTION (SLOVAK) (HC47E: EE)
2-319-513-91 MANUAL, INSTRUCTION (SIMPLIFIED CHINESE)
(HC48E: E, CH, JE)
2-319-514-11 MANUAL, INSTRUCTION (ARABIC) (HC48E: E)
2-319-514-21 MANUAL, INSTRUCTION (PERSIAN) (HC48E: E)
• Refer to page 5-1 for mark 0.
5-21
Page 74
• J MODEL
付属品
Ver. 1.1 2007.03
その他の付属品
2-319-511-01 取扱説明書（日本語）
AC アダプター
(AC-L200/L200B)
* L200とL200Bには
互換性があります。
0 1-479-285-21
USB ケーブル
1-829-868-31
リチャージブルバッテリー
パック
NP-FH40
0 A-1201-657-A
電源コード
0 1-828-050-31
A/V 接続ケーブル
1-823-156-51
ワイヤレスリモコン
RMT-831
1-478-495-31
ハンディカムステーション
(DCRA-C155)
1-820-790-11
DVD-ROM
「エンジョイハンディーカム」
3-093-691-01
英語/韓国語/日本語
•0マークについては，5-1ページを参照して下さい。
CD-ROM
「Handycam Application
Software」
3-093-483-01
DCR-HC47E/HC48/HC48E_L2
5-22E
Page 75
HARDWARE LIST (1/4)
#1: M1.7 X 2.5
(Black)
2-635-562-11
2.5
#5: M1.7 X 3.5 (Tapping)
(Black)
3-080-204-01
3.5
#9: M1.7 X 5.0 (Tapping)
(Silver)
3-078-890-21
1.7
1.7
#2: M1.7 X 4.0
(Black)
2-635-562-31
#6: M1.4 X 1.7
(Silver)
2-598-474-01
#10:M1.7 X 4.0
(Silver)
2-599-475-31
4.0
1.7
1.4
1.7
#3: M1.7 X 2.5
(Red)
2-660-401-01
2.5
#7: M1.7 X 1.6
(Black)
7-627-552-18
1.6
#11:M1.7 X 4.0 (Tapping)
(Silver)
3-078-890-11
1.7
1.7
#4: M1.4 X 2.5 (Tapping)
(Dark Silver)
3-348-998-81
1.4
2.5
#8: M1.7 X 3.5 (Tapping)
(Silver)
3-078-890-01
1.7
3.5
#12:M1.7 X 5.0 (Tapping)
(Black)
3-080-204-21
5.0
#13:M1.7 X 2.5 (Tapping)
(Silver)
3-085-397-01
2.5
#17:M1.7 X 1.5
(Silver)
2-586-389-01
1.7 2.2
1.5
3.5
1.7
1.7
#14:M1.7 X 2.5
(Silver)
2-599-475-11
#18:M1.4 X 2.5
(Silver)
2-635-591-21
4.0
2.5
2.5
1.7
1.7
1.4
4.0
#15:M1.4 X 1.5
(Silver)
3-062-214-01
1.5
#19:M1.2 X 4.0 (Tapping)
(Red)
3-086-156-21
4.0
1.4
1.7
1.2
1.7
5.0
#16:M1.4 X 2.5
(Silver)
2-586-337-01
1.4
2.5
#20:M1.4 X 3.0
(Silver)
2-635-591-31
1.4
3.0
Page 76
HARDWARE LIST (2/4)
#21:M1.4 X 3.0
(Black)
2-662-396-21
#25:M1.7 X 3.0
(Black)
2-635-562-21
#29:M1.4 X 2.5
(Black)
2-662-396-01
3.0
3.0
1.4
1.7
#22:M1.7 X 5.0 (Tapping)
(Silver)
3-083-261-01
5.0
#26:M1.4 X 2.0
(Silver)
2-635-591-11
2.0
#30:M1.2 X 4.0 (Tapping)
(White)
3-086-156-11
1.7
1.4
#23:M1.7 X 4.0 (Tapping)
(Black)
3-080-204-11
4.0
#27:M1.4 X 2.0
(Black)
2-662-396-11
2.0
#31:M3.0 X 4.0
(Silver)
2-102-434-01
1.7
1.4
#24:B1.7 X 5.5 (Tapping)
(Black)
4-679-805-11
1.7
5.5
#28:M1.4 X 4.0 (Tapping)
(Dark Silver)
3-348-998-61
1.4
4.0
#32:M2.0 X 4.5 (Tapping)
(Silver)
2-102-498-01
2.5
#33:M3.0 X 6.0
(Silver)
3-077-331-21
6.0
#37:M2.0 X 6.0 (Tapping)
(Black)
3-080-206-31
6.0
3.0
1.4
2.0
3.5
#34:M3.0 X 8.0
(Black)
3-077-331-41
8.0
#38:M3.0 X 20.0 (Tapping)
(Silver)
7-685-651-79
20.0
1.2
3.0
3.0
4.0
#35:M4.0 X 6.0 (Tapping)
(Silver)
3-975-291-02
6.0
#39:M2.6 X 5.0 (Tapping)
(Black)
7-685-791-09
5.0
4.0
2.6
3.0
2.0
4.5
#36:M3.0 X 6.0
(Silver)
4-886-821-11
3.0
6.0
#40:M2.0 X 4.0 (Tapping)
(Silver)
7-685-851-04
2.0
4.0
Page 77
HARDWARE LIST (3/4)
#41:M3.0 X 8.0 (Tapping)
(Silver)
3-065-748-01
8.0
#45:M1.4 X 2.5
(Silver)
2-587-151-01
2.5
#49:M2.0 X 4.0
(Black)
2-630-005-31
3.0
1.4
#42:M2.0 X 4.0 (Tapping)
(Silver)
7-628-253-00
4.0
#46:M1.7 X 3.0
(Red)
2-660-401-11
3.0
#50:M2.0 X 3.0
(Red)
2-891-494-11
1.7
2.0
#43:M1.7 X 4.0
(Red)
2-660-401-31
4.0
#47:M1.4 X 3.0 (Tapping)
(Silver)
2-665-774-01
3.0
#51:M2.0 X 2.5
(Silver)
3-073-686-01
1.7
1.4
#44:M1.7 X 3.0 (Tapping)
(Silver)
3-078-890-61
1.7
3.0
#48:M1.7 X 2.5
(Silver)
3-973-497-91
1.7
2.5
#52:M2.0 X 4.0 (Tapping)
(Black)
3-080-206-11
4.0
#53:M2.0 X 5.0 (Tapping)
(Black)
3-080-206-21
5.0
#57:M1.7 X 4.0
(Black)
7-627-852-18
4.0
2.0
2.0
1.7
3.0
#54:M1.75 X 6.0 (Tapping)
(Black)
3-318-203-11
6.0
#58:M2.0 X 6.0 (Tapping)
(Silver)
3-719-408-11
6.0
2.0
1.75
2.0
2.5
#55:M2.0 X 4.0
(Silver)
2-655-582-11
4.0
#59:M2.0 X 5.0 (Tapping)
(Silver)
3-080-205-21
5.0
2.0
2.0
2.0
2.0
4.0
#56:M2.0 X 3.5
(Silver)
3-067-187-11
2.0
3.5
#60:M2.6 X 5.0
(Black)
3-061-062-11
2.6
5.0
Page 78
HARDWARE LIST (4/4)
#61:M3.0 X 10.0
(Black)
7-682-549-09
10.0
3.0
#62:M2.0 X 3.0
(Silver)
3-080-202-21
3.0
2.0
#63:M5.0 X 12.5
(Black)
3-060-811-21
12.5
5.0
#64:M1.7 X 5.0 (Tapping)
(Silver)
2-666-551-21
1.7
5.0
Page 79
ENGLISH JAPANESE
ENGLISH JAPANESE
[Description of main button functions on toolbar of the Adobe Acrobat Reader Ver5.0 (for Windows)]
Toolbar
Printing a text
1. Click the Print button .
2. Specify a printer, print range, number of copies, and other options, and then click [OK].
Application of printing:
To set a range to be printed within a page, select the graphic
selection tool
be printed, and then click the Print button.
and drag on the page to enclose a range to
Finding a text
1. Click the Find button .
2. Enter a character string to be found into a text box, and click
the [Find]. (Specify the find options as necessary)
Application to the Service Manual:
To execute “find” from current page toward the previous pages,
select the check box “Find Backward” and then click the
“Find”.
3. Open the find dialog box again, and click the [Find Again] and
you can find the matched character strings displayed next.
(Character strings entered previously are displayed as they are
in the text box.)
Reversing the screens displayed once
•To reverse the previous screens (operation) one by one, click
the .
•To advance the reversed screens (operation) one by one, click
the .
Application to the Service Manual:
This function allows you to go and back between circuit diagram and printed circuit board diagram, and accordingly it
will be convenient for the voltage check.
Moving with link
1. Select either palm tool , zoom tool , text selection tool
, or graphic selection tool .
2. Place the pointer in the position in a text where the link exists
(such as a button on cover and the table of contents page, or
blue characters on the removal flowchart page or dra wing page),
and the pointer will change to the forefinger form
3. Then, click the link. (You will go to the link destination.)
.
Moving with bookmark:
Click an item (text) on the bookmark pallet, and you can move
to the link destination. Also, clicking
hidden items.
(To go back to original state, click )
can display the
Application to the Service Manual:
The parts on the drawing pages (block diagrams, circuit diagrams, printed circuit boards) and parts list pages in a text
can be found using this find function. For example, find a
Ref. No. of IC on the block diagram, and click the [Find Again]
continuously, so that you can move to the Ref. No. of IC on
the circuit diagram or printed circuit board diagram successively.
Note: The find function may not be applied to the Service
Manual depending on the date of issue.
Switching a page
•To move to the first page, click the .
•To move to the last page, click the .
•To move to the previous page, click the
•To move to the next page, click the
.
.
Zooming or rotating the screen display
“Zoom in/out”
• Click the triangle button in the zoom control box to select the
display magnification. Or, you may click
ing in or out.
“Rotate”
•Click rotate tool , and the page then rotates 90 degrees each.
or for zoom-
Application to the Service Manual:
The printed circuit board diagram you see now can be changed
to the same direction as the set.
Page 80
ENGLISH JAPANESE
ENGLISH JAPANESE
【AdobeAcrobatReaderVer5.0（forWindows）ツールバー内にある主なボタンの機能説明】
ツールバー
文章を印刷する
1. 印刷ボタン をクリックする。
2. プリンター、印刷範囲、印刷部数、および他のオプショ
ンを指定して「OK」をクリックする。
印刷の応用：
ページ内で印刷したい範囲を設定するには、グラフィッ
ク選択ツール を選択し、ページ上をドラッグして印
刷したい範囲を囲んでから印刷ボタンをクリックする。
文章内を検索する
1. 検索ボタン をクリックする。
2. 検索したい文字列をテキストボックスに入力して「検索」
をクリックする。（必要に応じて検索オプションを指定
する）
サービスマニュアルへの応用：
現在のページから前ページに向かって検索する場合は
「先頭に向かって検索」のチェックボックスを選択してか
ら「検索」をクリックする。
一度表示した画面へ逆戻りする
・ 前の画面（操作）へ1つずつ逆戻りする場合、 をクリック
する。
・ 戻した画面（操作）を1 つずつ前に進める場合、 をク
リックする。
サービスマニュアルへの応用：
回路図とプリント図を行き来できるので電圧チェックに
便利です。
リンクを使用して移動する
1. 手のひらツール 、ズームツール 、テキスト選択
ツール 、グラフィック選択ツール のいずれかを選
択する。
2. 文章内のリンクのある場所（表紙および章目次ページの
ボタン、外し方のフローページ、図面ページでは文字が
青色になっているところなど）にポインタを置くと、ポ
インタが人差し指の形「
3. そのままリンクをクリックする。（リンク先へ移動する）
」に変わる。
しおりを利用して移動する：
しおりパレット上の項目（テキスト）をクリックするとリ
ンク先へ移動することができる。また、「 」をクリッ
クすると隠れている項目を表示することができる。
（「 」をクリックすると元に戻る）
3. 検索ダイアログボックスをもう一度開き、「次を検索」
をクリックすると次に出てくる一致文字列を検索するこ
とができる。（前回入力した文字列が、テキストボックス
にそのまま表示されている）
サービスマニュアルへの応用：
文章内にある図面ページ（ブロックダイヤグラム、回路
図、プリント図）および部品表ページなどは、この検索
機能を使って部品検索することができる。例えば、ブ
ロックダイヤグラム上でICのRef. No.を検索し、「次を
検索」を続けることによって回路図、プリント図上にあ
るICのRef.No.へ次々と移動する。
注意：発行年月日によって検索できない場合もあります。
ページを切り換える
・ 最初のページに移動する場合、 をクリックする。
・ 最後のページに移動する場合、
・ 前のページに移動する場合、
・ 次のページに移動する場合、
をクリックする。
をクリックする。
をクリックする。
画面の表示を拡大、縮小または回転させる
「拡大/ 縮小」
・ 倍率ボックスの三角矢印ボタンをクリックし、表示倍率を
選択する。または 、 をクリックしても使えます。
「回転」
・ 回転ツール をクリックすると、ページが90度ずつ回
転する。
サービスマニュアルへの応用：
見ているプリント図をセットと同じ向きに変えられます。
Page 81
Reverse
985217032.pdf
Revision History
Ver.
1.0
1.1
Date
2006.12
2007.03
History
Official Release
Correction-1
(C1)
Contents
—
• Correction of Repair Parts
S.M. correction: Page 5-21, 5-22
S.M. Rev.
issued
—
Yes
DCR-HC47E/HC48/HC48E_L2
Loading...
