Sony DAV-HDX685 User Manual

4-122-238-12(1)

DVD Home Theatre System

Operating Instructions

DAV-HDX285 / HDX585 / HDX685

WARNING

To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.

Caution – The use of optical instruments with this product will increase eye hazard.

Do not install the appliance in a confined space, such as a bookcase or built-in cabinet.

To reduce the risk of fire, do not cover the ventilation opening of the apparatus with newspapers, tablecloths, curtains, etc. Do not place the naked flame sources such as lighted candles on the apparatus.

To reduce the risk of fire or electric shock, do not expose this apparatus to dripping or splashing, and do not place objects filled with liquids, such as vases, on the apparatus.

Do not expose batteries or apparatus with batteryinstalled to excessive heat such as sunshine, fire or the like.

To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions.

Indoor use only.

This appliance is classified as a CLASS 1 LASER product. This marking is loca ted on the rear exterior.

Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems)

This symbol on the product or

on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The recycling of materials will help to conserve natural

resources. For more detailed information about recycling of this product, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

Precautions

On power sources

• The unit is not disconnected from the mains as long as it is connected to the AC outlet, even if the unit itself has been turned off.

• As the main plug is used to disconnect the unit from the mains, connect the unit to an easily accessible AC outlet. Should you notice an abnormality in the unit, disconnect the main plug from the AC outlet immediately.

For the customers in the U.S.A.

This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

Owner’s Record

The model and serial numbers are located on the rear exterior of the unit. Record the serial number in the space provided below. Refer to them whenever you call upon your Sony dealer regarding this product.

Model No. DAV-HDX285/DAV-HDX585

Serial No.______________

Date of Manufacture Marking is located on the bottom exterior.

The following FCC statement applies only to the version of this model manufactured for sale in the USA. Other versions may not comply with FCC technical regulations.

NOTE:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna (aerial).

– Increase the separation between the equipment and

receiver.

– Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV

technician for help.

CAUTION

You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

ENERGY STAR registered mark.

As an ENERGY STAR

is a U.S.

partner, Sony Corporation has determined that this product meets the ENERGY

STAR

guidelines for energy

efficiency.

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

About These Operating Instructions

“DVD-RW,” “DVD-R,” “DVD+RW,” “DVD+R,” “DVD VIDEO,” and the “CD” logos are trademarks.

• The instructions in these Operating

Instructions describe the controls on the remote. You can also use the controls on the unit if they have the same or similar names as those on the remote.

• The Control Menu items may vary depending

on the area.

• “DVD” may be used as a general term for a

DVD VIDEO, DVD+RW/DVD+R, and DVDRW/DVD-R.

• Measurements are expressed in feet (ft) for

North American models.

• The default setting is underlined.

Copyrights

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

This system incorporates with Dolby* Digital and Dolby Pro Logic (II) adaptive matrix surround decoder and the DTS** Digital Surround System.

* Manufactured under license from Dolby

Laboratories. Dolby, Pro Logic, and the double-D symbol are trademarks of Dolby Laboratories.

** Manufactured under license under U.S. Patent #’s:

5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,487,535 & other U.S. and worldwide patents issued & pending. DTS and DTS Digital Surround are registered trademarks and the DTS logos and Symbol are trademarks of DTS, Inc. © 1996-2008 DTS, Inc. All Rights Reserved.

“BRAVIA” is a trademark of Sony Corporation.

“PLAYSTATION” is a trademark of Sony Computer Entertainment Inc.

DivX

is a video file compression technology, developed by DivX, Inc. (Except for North American models).

DivX, DivX Certified, and associated logos are trademarks of DivX, Inc. and are used under license (Except for North American models).

“S-AIR” and its logo are trademarks of Sony Corporation.

About MPEG-4 Visual

(Except for North American models)

THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NONCOMMERCIAL USE OF A CONSUMER FOR DECODING VIDEO IN COMPLIANCE WITH THE MPEG-4 VISUAL STANDARD (“MPEG-4 VIDEO”) THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG-4 VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION INCLUDING THAT RELATING TO PROMOTIONAL, INTERNAL AND COMMERCIAL USES AND LICENSING MAY BE OBTAINED FROM MPEG LA, LLC. SEE HTTP:// WWW.MPEGLA.COM

This system incorporates High-Definition

Multimedia Interface (HDMI

) technology. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

About the S-AIR function

The system is compatible with the S-AIR function, which allows transmission of sound between S-AIR products wirelessly. The following S-AIR products can be used with the system:

• Surround amplifier: You can enjoy surround speaker sound wirelessly.

• S-AIR receiver: You can enjoy system sound in another room.

These S-AIR products can be purchased as an options (the S-AIR product lineup differs depending on the area).

Notes or instructions for the surround amplifier or S-AIR receiver in these Operating Instructions refer only to when the surround amplifier or S-AIR receiver is used. For details on the S-AIR function, see “Using an S-AIR Product” (page 74).

Table of Contents

About These Operating Instructions ....... 4

About the S-AIR function .......................5

Playable Discs......................................... 7

Getting Started

Step 1: Installing the System .......14

Step 2: Connecting the System ...25 Step 3: Performing the Quick

Setup ........................................33

Step 4: Selecting the Source .......36

Step 5: Enjoying Surround

Sound .......................................37

Disc

Playing a Disc ....................................... 40

Using Play Mode...................................46

Searching/Selecting Disc Contents ....... 48

Playing MP3 Files/JPEG Image Files... 50

Enjoying Video Files ............................ 54

Adjusting the Delay Between the Picture

and Sound ....................................... 56

Restricting Playback of the Disc...........57

Changing the System Settings by Using

the Setup Display............................ 59

Tuner

Presetting Radio Stations ...................... 67

Listening to the Radio...........................68

Control for HDMI/External Audio Device

Using the Control for HDMI Function for

“BRAVIA” Sync ............................ 70

Using the DIGITAL MEDIA PORT

Adapter ........................................... 73

Using an S-AIR Product ....................... 74

Other Operations

Getting Optimal Surround Sound for a

Room .............................................. 80

Calibrating the Appropriate Settings

Automatically................................. 81

Controlling the TV with the Supplied

Remote ........................................... 82

Using the Sound Effect......................... 83

Selecting the Effect to Suit

the Source....................................... 84

Enjoying Multiplex Broadcast

Sound.............................................. 84

Changing the Input Level of the Sound

from Connected Components......... 85

Using the Sleep Timer .......................... 85

Changing the Brightness of the Front

Panel Display.................................. 86

Viewing Information About the Disc... 86

Returning to the Default Settings ......... 89

Additional Information

Precautions ........................................... 90

Notes about the Discs ........................... 91

Troubleshooting.................................... 92

Self-diagnosis Function ........................ 99

Specifications ..................................... 100

Glossary.............................................. 102

Playback priority of file types ............ 105

Language Code List............................ 106

Index to Parts and Control .................. 107

Guide to the Control Menu Display ... 111

Index ................................................... 114

Playable Discs

Type Disc logo Characteristics Icon

DVD VIDEO • DVD VIDEO

• DVD-R/DVD-RW in DVD VIDEO format or video mode

• DVD+R/DVD+RW in DVD VIDEO format

VR (Video Recording) mode

• DVD-R/DVD-RW in VR (Video Recording) mode (except for DVD-R DL)

VIDEO CD • VIDEO CD (Ver. 1.1 and 2.0 discs)

• Super VCD

• CD-R/CD-RW/CD-ROM in video CD format or Super VCD format

Super Audio CD • Super Audio CD

CD • Audio CD

• CD-R/CD-RW in audio CD format

DATA CD – • CD-R/CD-RW/CD-ROM in DATA CD

format, containing MP3 image files MPEG4 video files ISO 9660

, DivX video files3), and

Level 1/Level 2, or Joliet

files1), JPEG

, and conforming to

(extended format)

DATA DVD – • DVD-ROM/DVD-R/DVD-RW/

DVD+R/DVD+RW in DATA DVD format, containing MP3 files1), JPEG image files2), DivX video files3), and MPEG4 video files

, and conforming to

UDF (Universal Disk Format)

MP3 (MPEG1 Audio Layer 3) is a standard format defined by ISO/MPEG for compresses audio data. MP3 files

must be in MPEG1 Audio Layer 3 format.

JPEG image files must conform to the DCF image file format. (DCF “Design rule for Camera File system”: Image

standards for digital cameras regulated by Japan Electronics and Information Technology Industries Association (JEITA).)

Except for North American models.

A logical format of files and folders on CD-ROMs, defined by ISO (International Organization for

Standardization).

Notes on discs

This product is designed to playback discs that conform to the Compact Disc (CD) standard. DualDiscs and some of the music discs encoded with copyright protection technologies do not conform to the Compact Disc (CD) standard, therefore, these discs may not be playable by this product.

Example of discs that the system cannot play

The system cannot play the following discs:

• CD-ROM/CD-R/CD-RW other than those recorded in the formats listed on page 7

• CD-ROM recorded in PHOTO CD format

• Data part of CD-Extra

• CD Graphics disc

• DVD Audio

• DATA CD/DATA DVD that does not contain MP3 files, JPEG image files, DivX video files*, or MPEG4 video files*

•DVD-RAM

•Blu-ray Disc

* Except for North American models.

Also, the system cannot play the following discs:

• A DVD VIDEO with a different region code (page 9)

• A disc that has a non-standard shape (e.g., card, heart)

• A disc with paper or stickers on it

• A disc that has the adhesive of cellophane tape or a sticker still left on it

Note about CD-R/CD-RW/DVD-R/DVD-RW/DVD+R/DVD+RW

In some cases, CD-R/CD-RW/DVD-R/DVD-RW/DVD+R/DVD+RW cannot be played on this system due to the recording quality or physical condition of the disc, or the characteristics of the recording device and authoring software. The disc will not play if it has not been correctly finalized. For more information, refer to the operating instructions for the recording device. Note that some playback functions may not work with some DVD+RWs/DVD+Rs, even if they have been correctly finalized. In this case, view the disc by normal playback. Also some DATA CDs/DATA DVDs created in Packet Write format cannot be played.

About Multi Session CD

• This system can play a Multi Session CD when an MP3 file is contained in the first session. Any subsequent MP3 files recorded in later sessions can also be played back.

• This system can play a Multi Session CD when a JPEG image file is contained in the first session. Any subsequent JPEG image files recorded in later sessions can also be played back.

• If MP3 files and JPEG image files in music CD format or video CD format are recorded in the first session, only the first session will be played back.

Region code

Your system has a region code printed on the rear of the unit and will only play a DVD labeled with the same region code.

A DVD VIDEO labeled will also play on this system. If you try to play any other DVD VIDEO, the message [Playback prohibited by area limitations.] will appear on the TV screen. Depending on the DVD VIDEO, no region code indication may be given even though playing the DVD VIDEO is prohibited by area restrictions.

ALL

Note about playback operations of a DVD or VIDEO CD

Some playback operations on a DVD or VIDEO CD may be intentionally set by software producers. Since this system will play a DVD or VIDEO CD according to the disc contents the software producers designed, some playback features may not be available. Be sure to read the operating instructions supplied with the DVD or VIDEO CD.

Getting Started

Unpacking

DAV-HDX285

Getting Started

• Front speakers (2)

• Center speaker (1)

• Surround speakers (2)

• Subwoofer (1)

• FM wire antenna (aerial) (1)

• Speaker cords (6, red/white/ green/gray/blue/purple)

•Video cord (1)

• Remote commander (remote) (1)

• R6 (size AA) batteries (2)

• Foot pads (1 set)

• Operating Instructions

• Quick Setup Guide

For U.S. and Australian models

• DIGITAL MEDIA PORT adapter (TDM-iP20) (1)

• Operating Instructions for the DIGITAL MEDIA PORT adapter (TDM-iP20)

For U.S. models

• Setup Disc (DVD)

• AM loop antenna (aerial) (1)

• Calibration mic (1)

DAV-HDX585

• Front speakers (2)

• Center speaker (1)

• Surround speakers (2)

• Subwoofer (1)

• AM loop antenna (aerial) (1)

• FM wire antenna (aerial) (1)

• Speaker cords (6, red/white/ green/gray/blue/purple)

• Video cord (1)

• Remote commander (remote) (1)

• R6 (size AA) batteries (2)

• Calibration mic (1)

• Foot pads (1 set)

• Posts (2)

• Bases (2)

• Screws (black) (4)

• Screws (with washer) (4)

• Operating Instructions

• Quick Setup Guide

• Setup Disc (DVD)

• DIGITAL MEDIA PORT adapter (TDM-iP20) (1)

• Operating Instructions for the DIGITAL MEDIA PORT adapter (TDM-iP20)

Getting Started

DAV-HDX685

• Front speakers (2)

Getting Started

• Center speaker (1)

• Surround speakers (2)

• Subwoofer (1)

• AM loop antenna (aerial) (1)

• FM wire antenna (aerial) (1)

• Speaker cords (6, red/white/ green/gray/blue/purple)

•Video cord (1)

• Remote commander (remote) (1)

• R6 (size AA) batteries (2)

• Calibration mic (1)

• Foot pads (1 set)

•Posts (4)

• Bases (4)

• Screws (black) (8)

• Screws (with washer) (8)

• Operating Instructions

• Quick Setup Guide

• Setup Disc (DVD)

Inserting batteries into the remote

Insert two R6 (size AA) batteries (supplied) by matching the 3 and # ends on the batteries to the markings inside the compartment. To use the remote, point it at the remote sensor on the unit.

Note

• Do not leave the remote in an extremely hot or humid place.

• Do not use a new battery with an old one.

• Do not drop any foreign object into the remote casing, particularly when replacing the batteries.

• Do not expose the remote sensor to direct sunlight or lighting apparatus. Doing so may cause a malfunction.

• If you do not intend to use the remote for an extended period of time, remove the batteries to avoid possible damage from battery leakage and corrosion.

Getting Started

Step 1: Installing the System

Positioning the system

For the best possible surround sound, place all speakers at the same distance from the listening position

Getting Started

(A). The distance can be between 1.0 to 7.0 meters. If you cannot place the center speaker and surround speakers at the same distance as (A), you can move the center speaker up to 1.6 meters closer to the listening position (B), and the surround speakers up to 5.0 meters closer to the listening position (C). The subwoofer can be placed anywhere in the room.

Subwoofer

Front left speaker (L)

Center speaker

Front right speaker (R)

Surround left speaker (L)

Note

• Use caution when placing the speakers and/or speaker stands attached to the speakers on a specially treated (waxed, oiled, polished, etc.) floor, as staining or discoloration may result.

• Do not lean or hang on a speaker, as it may fall down.

Surround right speaker (R)

Attaching the foot pads to the subwoofer

Attach the foot pads (supplied) to the bottom of the subwoofer to stabilize the subwoofer and prevent it from slipping.

Remove the foot pads from the protective cover.

Getting Started

Assembling the speakers

(DAV-HDX585/DAV-HDX685 only)

Before connecting the speakers, attach the speaker stand to the speaker. (For the front speakers of DAV-HDX585, and the front and surround speakers of DAV-HDX685)

Use the parts as follows:

Getting Started

DAV-HDX585

• Front speakers (2)

• Speaker cords (2, red/white)

• Posts (2)

• Bases (2)

• Screws (black) (4)

• Screws (with washer) (4)

DAV-HDX685

• Front and surround speakers (4)

• Speaker cords (4, red/white/blue/gray)

• Posts (4)

• Bases (4)

• Screws (black) (8)

• Screws (with washer) (8)

For details of how to connect the speaker cords to the SPEAKER jacks, see page 25.

Note

• Spread a cloth on the floor to avoid damaging the floor when you assemble the speakers.

• You can use the speaker without the speaker stand by installing it on the wall (page 22).

1 Insert the post into the hole on the bottom of the speaker so that the screw on the post

faces the front of the speaker.

Speaker

Getting Started

Screw

Post

2 Adjust the height of the speaker, then secure the post with two screws (with washer).

You can change the height of the speaker depending on the screw positions. Adjust the screw holes of the post to the holes on the rear of the speaker (A, B, C, or D). The height of the speaker can be increased by using the holes in order from A to D.

Rear of the speaker

Post

Example: Lowest position

Secure two screws (with washer).

3 Thread the speaker cord through the hole in the base and post.

The connector and color tube of the speaker cords are the same color as the label of the jacks to be connected. Use the speaker cords as follows:

• Front left speaker (L): White

• Front right speaker (R): Red

• Surround left speaker (L): Blue (DAV-HDX685 only)

Getting Started

• Surround right speaker (R): Gray (DAV-HDX685 only)

Be careful with the orientation of the post. Thread the speaker cord into the end of the post that has two holes.

Bottom of the base

Speaker cord

Post

Top of the base

Base

Rear of the speaker

4 Connect the speaker cords to the speaker.

Be sure to match the speaker cords to the appropriate terminals on the speakers: the speaker cord with the color tube to 3, and the speaker cord without the color tube to #.

Color tube Front left speaker (L): White Front right speaker (R): Red Surround left speaker (L): Blue (DAV-HDX685 only) Surround right speaker (R): Gray (DAV-HDX685 only)

Rear of the speaker

5 Attach the post to the base.

Insert the post so that the slot on the lower part of the post aligns with the projection of the base, then secure the post with the two screws (black).

Post

Slot

Getting Started

Projection

Base

Note

• Make sure that the slot on the post aligns with the projection of the base by rotating the post slightly.

Screws (black)

6 Take up any speaker cord slack.

Take up slack in the speaker cord by pulling from the bottom of the base.

Getting Started

Fully-assembled illustration

DAV-HDX585

Front left speaker (L): White label

Secure the speaker cord by running it through the slot.

Adjust the length of the cord.

Front right speaker (R): Red label

White

Red

DAV-HDX685

Front left speaker (L): White label

Front right speaker (R): Red label

Surround left speaker (L): Blue label

Surround right speaker (R) Gray label

Getting Started

White Red

Blue

Gray

Installing the speakers on a wall

Caution

• Contact a screw shop or installer for information regarding the wall material or screws to be used.

• Use screws that are suitable for the wall material and strength. As a plaster board wall is especially fragile, attach the screws securely to a beam. Install the speakers on a vertical and flat wall where reinforcement is applied.

• Sony is not responsible for accidents or damage caused by improper installation, insufficient wall strength or

Getting Started

improper screw installation, natural calamity, etc.

Before installing the speakers on a wall, connect the speaker cord to the speaker. Be sure to match the speaker cords to the appropriate terminals on the speakers: the speaker cord with the color tube to 3, and the speaker cord without the color tube to #.

Color tube Front left speaker (L): White Front right speaker (R): Red Center speaker: Green Surround left speaker (L): Blue Surround right speaker (R): Gray

1 Prepare screws (not supplied) that are suitable for the hole on the back of each speaker.

See the illustrations below.

4 mm (

30 mm (1 3/16 inches)

2 Fasten the screws to the wall.

DAV-HDX285

For the center speaker

145 mm (5

8 to 10 mm

/32 to 13/32

(

inch

)

/32 inch)

/4 inches)

5 mm

/32 inch)

(

10 mm

/32 inch)

(

For the other speakers

8 to 10 mm

/32 to 13/32

(

inch

)

Hole on the back of the speaker

DAV-HDX585

For the center speaker

145 mm

/4 inches)

For the front speakers

101.6 mm (

4 inches

Getting Started

)

8 to 10 mm

/32 to 13/32

(

inch

)

For the surround speakers

8 to 10 mm

/32 to 13/32

(

inch

)

DAV-HDX685

For the center speaker

8 to 10 mm

(

/32 to 13/32

inch

)

145 mm

/4 inches)

8 to 10 mm

/32 to 13/32

(

inch

)

For the other speakers

8 to 10 mm

/32 to 13/32

(

inch

)

101.6 mm 4 inches

(

)

3 Hang the speakers on the screws.

Getting Started

5 mm

/32 inch)

(

10 mm

/32 inch)

(

Rear of the speaker

Hole on the back of the speaker

Step 2: Connecting the System

For connecting the system, read the information on the following pages. Do not connect the AC power cord (mains lead) of the unit to a wall outlet (mains) until all the other connections are made.

Note

• When you connect another component with a volume control, turn down the volume of the other components to a level where sound is not distorted.

Connecting the speakers

The connector of the speaker cords and the color tube are color-coded depending on the type of speaker. Connect the speaker cords to match the color of the SPEAKER jacks of the unit. Be sure to match the speaker cords to the appropriate terminals on the speakers: the speaker cord with the color tube to 3, and the speaker cord without the color tube to #. Do not catch the speaker cord insulation (rubber covering) in the speaker terminals.

To connect speaker cords to the unit

When connecting to the unit, insert the connector until it clicks.

COAXIAL 75

TV/VIDEO

AUDIO IN

Purple (Subwoofer)

Red (Front right speaker (R))

B U S

CENTER

White (Front left speaker (L))

FRONT L SUR R

I O

FRONT R

DIGITAL IN

COAXIALOPTICAL

VIDEO

OUT

SUR L

V 5 C

M A

Blue (Surround left speaker (L))

Gray (Surround right speaker (R))

Getting Started

Green (Center speaker)

To connect speaker cords to the speaker

Connector

Color tube

(–)

(+)

Rear of the speaker

Connecting the TV (Video connection)

This connection sends a video signal to the TV. Depending on the jacks on your TV, select the connection method.

COAXIAL 75

TV/VIDEO

AUDIO IN

A Video cord (supplied)

Getting Started

C Component video cable (not supplied)

SUR L

FRONT L SUR R

I O

FRONT R

DIGITAL IN

W B U

CENTER

COAXIALOPTICAL

-T

VIDEO

OUT

B HDMI cable (not supplied)

To the HDMI IN jack of the TV.

To the component video input jacks of the TV.

To the video input jack of the TV.

Method 1: Video cord (A) connection

This is the basic connection.

Method 2: HDMI* cable (B) and video cord (A) connection

If your TV has an HDMI jack, connect to the TV both with an HDMI cable and video cord. Picture quality will be improved compared to using only the video cord connection. When connecting with the HDMI cable, you need to select the type of output signal (page 35). To view images from the DIGITAL MEDIA PORT adapter, you need to connect to the TV with the video cord. Video signals from the DIGITAL MEDIA PORT adapter are not output via the HDMI OUT jack.

* HDMI (High-Definition Multimedia Interface)

Method 3: Component video cable (C) and video cord (A) connection

If your TV does not have an HDMI jack, but has component video input jacks, connect to the TV both with a component video cable and video cord. Picture quality will be improved compared to using only the video cord connection. When connecting with the component video cable, you need to set the type of output signal to progressive format (page 35). To view images from the DIGITAL MEDIA PORT adapter, you need to connect to the TV with the video cord. Video signals from the DIGITAL MEDIA PORT adapter are not output via the COMPONENT VIDEO OUT jack.

To change the color system (PAL or NTSC) (Asian, Australian, and Middle Eastern models only)

Depending on the TV to be connected, you may be required to select either PAL or NTSC for the color system. The initial setting of the system for Australian and Middle Eastern models is PAL. The initial setting of the system for Asian models is NTSC.

1 Turn off the system by pressing "/1. 2 Turn on the system by pressing "/1 on the unit while pressing . on the unit.

Each time you perform this operation, the color system toggles between PAL and NTSC. “NTSC” lights up in the front panel display when the color system is set to NTSC.

Getting Started

Connecting the TV (Audio connection)

This connection sends an audio signal to the unit from the TV. To listen to TV sound via the system, perform this connection.

Getting Started

SUR L

FRONT L SUR R

I O

FRONT R

X A

F Digital coaxial cord (not supplied)

CENTER

E Digital optical cord (not supplied)

DIGITAL IN

COAXIALOPTICAL

To the digital optical out jack of the TV.

To the digital coaxial out jack of the TV.

Method 1: Audio cord (D) connection

This is the basic connection and sends an analog audio signal.

COAXIAL 75

TV/VIDEO

VIDEO

OUT

AUDIO IN

D Audio cord (not supplied)

To the audio out jacks of the TV.

Method 2: Digital optical cord (E) or digital coaxial cord (F) connection

When the TV has a digital optical or coaxial output jack, you can improve sound quality by connecting with a digital optical or coaxial cord in addition to an audio cord connection.

Note

• The system can accept both digital and analog signals. Digital signals have priority over analog signals. (COAXIAL has priority over OPTICAL.) If the digital signal ceases, the analog signal will be processed after 2 seconds.

• You can connect another component, such as a VCR, digital satellite receiver, or PlayStation, to the TV/VIDEO (AUDIO IN R/L) jacks or DIGITAL IN OPTICAL/COAXIAL jacks instead of the TV.

Connecting the other components

You can enjoy connected components via the system’s speakers. Portable audio source (not supplied): G DIGITAL MEDIA PORT adapter: H (TDM-iP20 is supplied with U.S. and Australian models. You can also use other DIGITAL MEDIA PORT adapters.)

G Stereo mini-plug cord (not supplied)

To a portable audio source

EZW-T100 slot (See “Wireless system options”.)

DIGITAL IN

R E

W B U

CENTER

COAXIAL

OPTICAL

FRONT R

FRONT L SUR R SUR L

I O

VIDEO

OUT

5 C D

A .7 0

H DIGITAL MEDIA PORT adapter (page 73)

Note

• Connect the DIGITAL MEDIA PORT

adapter so that the V marks are aligned. When disconnecting, pull out while pressing .

COAXIAL 75

TV/VIDEO

AUDIO IN

Getting Started

• You can connect another component, such as a VCR, digital satellite receiver, or PlayStation, to the TV/VIDEO (AUDIO IN R/L) jacks or DIGITAL IN OPTICAL/COAXIAL jacks instead of the TV.

Wireless system options

By using an S-AIR product (not supplied), you can enjoy wireless performance by transmission from the system. For details, see “Using an S-AIR Product” (page 74) or refer to the operating instructions of the S-AIR product.

If your TV has multiple audio/video inputs

You can enjoy sound with the speakers of the system through the connected TV. Connect the components as follows.

VCR, digital satellite receiver, PlayStation, etc.

Getting Started

System

VCR, digital satellite receiver, PlayStation, etc.

:Signal flow

Select the component on the TV. For details, refer to the operating instructions of the TV. If the TV does not have multiple audio/video inputs, a switcher will be necessary to receive sound from more than one component.

+ 86 hidden pages

Sony DAV-HDX685 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

WARNING

About These Operating Instructions

About the S-AIR function

Playable Discs

Example of discs that the system cannot play

Note about CD-R/CD-RW/DVD-R/DVD-RW/DVD+R/DVD+RW

About Multi Session CD

Region code

Note about playback operations of a DVD or VIDEO CD

Getting Started

Unpacking

Step 1: Installing the System

Positioning the system

Assembling the speakers

Installing the speakers on a wall

Step 2: Connecting the System

Connecting the speakers

Connecting the TV (Video connection)

Connecting the TV (Audio connection)

Connecting the other components
