Sony BDV-T28 Operating Instruction

Blu-ray Disc/DVD Home Theatre System

Operating Instructions

4-265-162-11 (1)

BDV-E280/BDV-T28

WARNING

comply with FCC technical regulations.

Do not install the appliance in a confined space, such as a bookcase or built-in cabinet.

To reduce the risk of fire, do not cover the ven tilation opening of the apparatus with newspapers, tablecloths, curtains, etc. Do not place the naked flame sources such as lighted candles on the apparatus.

Do not expose batteries or apparatus with battery-installed to excessive heat such as sunshine, fire or the like.

To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions.

Indoor use only.

CAUTION

The use of optical instruments with this product will increase eye hazard. As the laser beam used in this Blu-ray Disc / DVD Home Theatre System is harmful to eyes, do not attempt to disassemble the cabinet.

Refer servicing to qualified personnel only.

This appliance is classified as a CLASS 3R LASER product. Visible and invisible laser radiation is emitted when the laser protective housing is opened, so be sure to avoid direct eye exposure.

This marking is located on the laser protective housing inside the enclosure.

This appliance is classified as a CLASS 1 LASER product. This marking is located on the rear exterior.

For the customers in the U.S.A.

To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.

These following indications are located on the rear exterior.

This symbol is intended to alert the user to the

presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

This symbol is intended to

alert the user to the

presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

Owner’s Record

The model and serial numbers are located on the rear exterior of the unit. Record these numbers in the space provided below. Refer to them whenever you call upon your Sony dealer regarding this product.

Model No. BDV-E280/BDV-T28

Serial No.______________

The following FCC statement applies only to the version of this model manufactured for sale in the U.S.A. Other versions may not

NOTE:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursu ant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving

antenna (aerial).

– Increase the separation between

the equipment and receiver.

– Connect the equipment into an

outlet on a circuit different from that to which the receiver is connected.

– Consult the dealer or an

experienced radio/TV technician for help.

CAUTION

You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.

Properly shielded and grounded cables and connectors must be used for connection to host computers and/or peripherals in order to meet FCC emission limits.

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider th an the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments/ accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

For the customers in Canada, Mexico, and Latin America

To reduce the risk of fire or electric shock, do not expose this apparatus to dripping or splashing, and do not place objects filled with liquids, such as vases, on the apparatus.

Precautions

On power sources

• The unit is not disconnected from

the mains as long as it is connected to the AC outlet, even if the unit itself has been turned off.

• As the main plug is used to

disconnect the unit from the mains, connect the unit to an easily accessible AC outlet. Should you notice an abnormality in the unit, disconnect the main plug from the AC outlet immediately.

On watching 3D video images

Some people may experience discomfort (such as eye strain, fatigue, or nausea) while watching 3D video images. Sony recommends that all viewers take regular breaks while watching 3D video images. The length and frequency of necessary breaks will vary from person to person. You must decide what works best . If you experience any discomfort, you

should stop watching the 3D video images until the discomfort ends; consult a doctor if you believe necessary. You should also review (i) the instruction manual and/or the caution message of any other device used with, or Blu-ray Disc contents played with this product and (ii) our website (http:// esupport.sony.com/) for the latest information. The vision of young children (especially those under six years old) is still under development. Consult your doctor (such as a pediatrician or eye doctor) before allowing young children to watch 3D video images.

Adults should supervise young children to ensure they follow the recommendations listed above.

Copy Protection

Please be advised of the advanced content protection systems used in both Blu-ray Disc media. These systems, called AACS (Advanced Access Content System) and CSS (Content Scramble System), may contain some restrictions on playback, analog output, and other similar features. The operation of this product and the restrictions placed may vary depending on the date of purchase, as the governing board of the AACS may adopt or change its restriction rules after the time of purchase.

and DVD

Copyrights and Trademarks

• This system incorporates with Dolby* Digital and Dolby Pro Logic (II) adaptive matrix surround decoder and the DTS** Digital Surround System.

* Manufactured under license

from Dolby Laboratories. Dolby, Pro Logic, and the double-D symbol are trademarks of Dolby Laboratories.

** Manufactured under license

under U.S. Patent #’s: 5,451,942; 5,956,674;

5,974,380; 5,978,762; 6,226,616; 6,487,535; 7,212,872; 7,333,929; 7,392,195; 7,272,567 & other U.S. and worldwide patents issued & pending. DTS, DTS-HD and the Symbol are registered trademarks, & DTS-HD Master Audio, and the DTS logos are trademarks of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.

• This system incorporates HighDefinition Multimedia Interface

(HDMI

) technology. HDMI, the HDMI logo and HighDefinition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

• Java is a trademark of Oracle and/ or its affiliates.

• “BD-LIVE” and “BONUSVIEW” are trademarks of Blu-ray Disc Association.

• “Blu-ray Disc” is a trademark.

• “Blu-ray Disc,” “DVD+RW,” “DVD-RW,” “DVD+R,” “DVDR,” “DVD VIDEO,” and “CD” logos are trademarks.

• “Blu-ray 3D” and “Blu-ray 3D” logo are trademarks of Blu-ray Disc Association.

• “BRAVIA” is a trademark of Sony Corporation.

• “AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation and Sony Corporation.

• , “XMB,” and “xross media bar” are trademarks of Sony Corporation and Sony Computer Entertainment Inc.

• “PLAYSTATION” is a trademark of Sony Computer Entertainment Inc.

• The Wi-Fi CERTIFIED™ Logo is a certification mark of the Wi-Fi Alliance.

• The Wi-Fi Protected Setup™ Mark is a mark of the Wi-Fi Alliance.

• “Wi-Fi CERTIFIED™” and “WiFi Protected Setup™” are trademarks of the Wi-Fi Alliance.

• “PhotoTV HD” and the “PhotoTV HD” logo are trademarks of Sony Corporation.

• MPEG Layer-3 audio coding technology and patents licensed from Fraunhofer IIS and Thomson.

• iPhone, iPod, iPod classic, iPod nano, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries.

• “Made for iPod,” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifically to iPod or iPhone, respectively, a nd has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod or iPhone may affect wireless performance.

• Windows Media is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries. This product contains technology subject to certain intellectual property rights of Microsoft. Use or distribution of this technology outside of this product is prohibited without the appropriate license(s) from Microsoft. Content owners use Microsoft PlayReady

™

content access technology to protect their intellectual property, including copyrighted content. This device uses PlayReady technology to access PlayReady-protected content and/or WMDRMprotected content. If the device

fails to properly enforce restrictions on content usage, content owners may require Microsoft to revoke the device’s ability to consume PlayReadyprotected content. Revocation should not affect unprotected content or content protected by other content access technol ogies. Content owners may require you to upgrade PlayReady to access their content. If you decline an upgrade, you will not be able to access content that requires the upgrade.

• All other trademarks are trademarks of their respective owners.

• Other system and product names are generally trademarks or registered trademarks of the manufacturers. ™ and ® marks are not indicated in this document.

About These Operating Instructions

• The instructions in these Operating Instructions describe the controls on the remote. You can also use the controls on the unit if they have the same or similar names as those on the remote.

• In this manual, “disc” is used as a general reference for BDs, DVDs, Super Audio CDs, or CDs unless otherwise specified by the text or illustrations.

• The instructions in this manual are for BDV-E280 and BDV-T28. BDV-E280 is the model used for illustration purposes. Any difference in operation is clearly indicated in the text, for example, “BDV-E280 only.”

• Some illustrations are presented as conceptual drawings, and may be different from the actual products.

• The items displayed on the TV screen may vary depending on the area.

• The default setting is underlined.

Table of Contents

About These Operating Instructions ....... 5

Unpacking............................................... 7

Index to Parts and Controls.....................8

Getting Started

Step 1: Installing the System ....... 13

Step 2: Connecting the System ...14 Step 3: Connecting to the

Network ....................................20

Step 4: Performing the Easy

Setup ........................................22

Step 5: Selecting the Source .......23

Step 6: Enjoying Surround

Sound .......................................24

Playback

Playing a Disc ....................................... 27

Playing from a USB Device.................. 28

Enjoying an iPod/iPhone.......................29

Playing via a Network........................... 31

Available Options ................................. 32

Sound Adjustment

Selecting the Effect to Suit

the Source ....................................... 34

Selecting the Audio Format, Multilingual

Tracks, or Channel.......................... 34

Enjoying Multiplex Broadcast

Sound..............................................35

Tuner

Listening to the Radio...........................36

Other Operations

Using the Control for HDMI Function for

“BRAVIA” Sync ............................38

Setting the Speakers ..............................39

Using the Sleep Timer ..........................40

Deactivating the Buttons on

the Unit ........................................... 40

Controlling Your TV with the Supplied

Remote............................................ 41

Changing the Brightness of the Front

Panel Display.................................. 41

Saving Power in Standby Mode............41

Browsing Websites ............................... 42

Setting up the Network ......................... 43

Settings and Adjustments

Using the Setup Display ....................... 47

[Network Update]................................. 47

[Screen Settings]................................... 48

[Audio Settings].................................... 49

[BD/DVD Viewing Settings] ............... 50

[Parental Control Settings] ................... 50

[Music Settings].................................... 51

[System Settings].................................. 51

[Network Settings]................................ 51

[Easy Setup].......................................... 52

[Resetting] ............................................ 52

Additional Information

Precautions ........................................... 53

Notes about the Discs ........................... 54

Troubleshooting.................................... 55

Playable Discs ...................................... 60

Playable Types of Files ........................ 61

Supported Audio Formats..................... 62

Specifications ....................................... 63

Language Code List.............................. 64

Index ..................................................... 65

Unpacking

BDV-E280/BDV-T28

• Front speakers (2)

• Surround speakers (2)

• FM wire antenna (aerial) (1)

• Video cord (1) (U.S. and Canada models only)

• HDMI cable (2) (Mexican and Latin American models of BDVT28 only)

• Dock for iPod/iPhone (TDM-iP30) (1) (U.S. and Canada models only)

• USB cable (1) (U.S. and Canada models only)

• Operating Instructions

• Quick Setup Guide

• Speaker Installation Guide

• Software License Information

• Center speaker (1)

• Subwoofer (1)

• Remote commander (remote) (1)

• R6 (size AA) batteries (2)

• HDMI cable (1) (Mexican and Latin American models of BDVE280 and U.S. and Canada models of BDV-T28 only)

Preparing the remote

Insert two R6 (size AA) batteries (supplied) by matching the 3 and # ends on the batteries to the markings inside the compartment.

Index to Parts and Controls

For more information, refer to the pages indicated in parentheses.

Front panel

A Disc tray (page 27) B Remote sensor C Front panel display D (USB) port (page 28) (Mexican and

Latin American models only)

Used for connecting a USB device.

E Play operation buttons

Z (open/close) (page 27)

Opens or closes the disc tray.

N (play)

Starts or re-starts playback (resume play). Plays a slideshow when a disc containing JPEG image files is inserted.

FUNCTION

x (stop)

VOLUME

Stops playback and remembers the stop point (resume point).

The resume point for a title/track is the last point you played or the last photo for a photo folder.

FUNCTION

Selects the playback source.

VOLUME +/–

Adjusts the system’s volume.

F "/1 (on/standby)

Turns on the unit, or sets it to standby mode.

Front panel display

About the indications in the front panel display

A Displays the system’s playing status. B Lights up when repeat play is

activated.

C Lights up when stereo sound is

received. (Radio only)

D Lights up when the HDMI (OUT) jack is

correctly connected to an HDCP (Highbandwidth Digital Content Protection)compliant device with HDMI or DVI (Digital Visual Interface) input.

E Lights up when muting is on. F Displays the system’s status, such as

radio frequency, etc.

G Lights up when outputting 720p/1080i/

1080p video signals from the HDMI (OUT) jack.

Rear panel

ONLY FOR SS-TSB105

FRONT R FRONT L SUBWOOFER CENTER SUR R

ONLY FOR SS-WSB103

SPEAKERS

ONLY FOR SS-CTB102

ONLY FOR SS-TSB105

SUR L

VIDEO OUT

A SPEAKERS jacks (page 14) B (USB) port (page 28) C AUDIO (AUDIO IN L/R) jacks (page 17) D ANTENNA (FM COAXIAL 75Ω) jack

(page 19)

E TV (DIGITAL IN OPTICAL) jack (page

15)

DIGITAL IN

OPTICAL

ARC

OUT

IN 1 IN 2

LAN (100)

AUDIO IN

AUDIO

F LAN (100) terminal (page 20) G HDMI (IN 2) jack (page 17) H HDMI (IN 1) jack (page 17) I HDMI (OUT) jack (page 15) J VIDEO OUT jack (page 15)

ANTENNA

COAXIAL

Remote control

SPEAKERS

AUDIO

BRAVIA Sync

FUNCTION

FAVORITES

TOP MENU

RETURN OPTIONS

SOUND MODE

PRESET

TUNING

DIMMER

SLEEP

YELLOW

DISPLAY

MUTING

231

564

8097

AUDIO SUBTITLE

GREENREDBLUE

POP UP/ MENU

SOUND MODE

HOME

PLAY

PAUSE

PRESET

TUNING

STOP

TV VOL

TV INPUT

REPLAY ADVANCE

VOL

Number 5, AUDIO, VOL +, and N buttons have a tactile dot. Use the tactile dot as a reference when operating the remote.

• : For TV operations (For details, see “Controlling Your TV with the Supplied Remote” (page 41).)

A Z (open/close)

Opens or closes the disc tray.

SPEAKERS TVyAUDIO

Selects whether TV sound is output from the system’s speakers or the TV’s speaker(s). This function works only when you set [Control for HDMI] to [On] (page 51).

TV "/1 (on/standby) (page 41)

Turns on the TV or sets it to standby mode.

"/1 (on/standby) (pages 22, 36)

Turns on the system or sets it to standby mode.

B Number buttons (pages 37, 41)

Enters the title/chapter numbers, preset station number, etc.

AUDIO (pages 34, 35)

Selects the audio format/track.

SUBTITLE (page 50)

Selects the subtitle language when multilingual subtitles are recorded on a BDROM/DVD VIDEO.

C Color buttons (yellow/blue/red/green)

Short cut keys for selecting items on some BD menus (can also be used for Java interactive operations on BDs).

D TOP MENU

Opens or closes the BD’s or DVD’s Top Menu.

POP UP/MENU

Opens or closes the BD-ROM’s Pop-up Menu, or the DVD’s menu.

OPTIONS (pages 24, 32. 42)

Displays the options menu on the TV screen or in the front panel display. (The location differs based on the selected function.)

RETURN

Returns to the previous display.

C/X/x/c

Moves the highlight to a displayed item.

(enter)

Enters the selected item.

E SOUND MODE +/– (page 34)

Selects the sound mode.

HOME (pages 22, 36, 39, 42, 43, 47)

Enters or exits the system’s home menu.

F Playback operation buttons

See “Playback” (page 27).

./> (previous/next)

Skip to the previous/next chapter, track, or file.

(replay/advance)

Briefly replay the current scenes for 10 seconds./Briefly fast forwards the current scenes for 15 seconds.

m/M (fast/slow/freeze frame)

Fast reverse/fast forward the disc during playback. Each time you press the button, the search speed changes.

Activates slow-motion play when pressed for more than one second in pause mode. Plays one frame at a time when pressed in pause mode.

Slow-motion a nd single-frame playback ar e not available for Blu-ray 3D Discs.

N (play)

Starts or re-starts playback (resume play). Activates One-Touch Play (page 38) when

the system is on and set to the “BD/DVD” function.

X (pause)

Pauses or re-starts playback.

x (stop)

Stops playback and remembers the stop point (resume point). The resume point for a title/track is the last point you played or the last photo for a photo folder.

H DISPLAY (pages 27, 31, 42)

Displays playback and web browsing information on the TV screen.

Displays the preset radio station, frequency, etc., in the front panel display. Displays the stream information/decoding status in the front panel display when the function is set to other than “BD/DVD.” When the system is set to the “HDMI1,” “HDMI2,” or “TV” function, the stream information/decoding status appears only when a digital signal is input. The stream information/decoding status may not appear depending on the stream or item being decoded.

I DIMMER (page 41)

Changes the brightness of the front panel display.

SLEEP (page 40)

Sets the sleep timer.

FUNCTION (pages 23, 36)

Selects the playback source.

FAVORITES

Displays the Internet contents added to the Favorites List. You can save 18 favorite Internet contents.

Radio operation buttons

See “Tuner” (page 36).

PRESET +/–

TUNING +/–

G MUTING

Turns off the sound temporarily.

VOL +/– (page 36)

Adjusts the volume.

TV VOL +/–

Adjusts the TV volume.

TV INPUT

Switches the TV’s input source between the TV and other input sources.

Getting Started

Step 1: Installing the System

How to position the system

Install the system by referring to the illustration below.

• Use caution when placing the speakers and/or speaker stands attached to the speakers on a specially treated (waxed,

oiled, polished, etc.) floor, as staining or discoloration may result.

• Do not lean or hang on a speaker, as it may fall down.

A Front speaker (L (left)) B Front speaker (R (right)) C Center speaker D Surround speaker (L (left)) E Surround speaker (R (r ight)) F Subwoofer G Unit

Getting Started

• You can install the speakers on a wall. For details, refer to the supplied “Speaker Installation Guide.”

Step 2: Connecting the System

For connecting the system, read the information on the following pages. Do not connect the AC power cord (mains lead) of the unit to a wall outlet (mains) until all the other connections are made.

• When you connect another component with a volume control, turn down the volume of the other components to a

Getting Started

level where sound is not distorted.

Connecting the speakers

To connect speaker cords to the unit

Connect the speaker cords to match the color of the SPEAKERS jacks of the unit. When connecting to the unit, insert the connector until it clicks.

White (Front left speaker (L))

Red (Front right speaker (R))

Purple (Subwoofer)

Green (Center speaker)

Rear panel of the unit

ONLY FOR SS-TSB105

ONLY FOR SS-WSB103

FRONT R FRONT L SUBWOOFER CENTER SUR R

Gray (Surround right speaker (R))

ONLY FOR SS-CTB102

SPEAKERS

ONLY FOR SS-TSB105

SUR L

Blue (Surround left speaker (L))

Connecting the TV

Connect the system to your TV to display the image of the system on your TV, and listen to TV sound via the system’s speakers.

Getting Started

Depending on the jacks and functions on your TV, select the connection method.

• When your TV has an HDMI jack that is marked “ARC

”: Connection A

• When your TV has an HDMI jack: Connections A and C

• When your TV does not have HDMI jacks: Connections B and C

Video connections

Audio connection

AB C

HDMI cable

Image quality

Signal flow

: Video signal

: Audio signal

Video cord

(not supplied)

HDMI IN

AB C

Digital optical cord

(not supplied)

VIDEO IN DIGITAL OUT

OPTICAL

Yellow

Rear panel of the unit

Yellow

DIGITAL IN

ARC

OUT

IN 1 IN 2

VIDEO OUT

Audio Return Channel. For details, see “About Audio Return Channel” (page 16).

The HDMI cable is supplied with Mexican and Latin American models and BDV-T28 only.

Available only when your TV is compatible with the Audio Return Channel function.

OPTICAL

A HDMI cable connection

If your TV has an HDMI jack, connect to the TV with an HDMI cable. This will provide better image quality compared to other types of connections. When connecting with an HDMI cable, you need to select the type of output signal when performing the Easy Setup (page 22). For further HDMI settings, see “[HDMI Settings]” (page 51).

About Audio Return Channel

If your TV is compatible with the Audio Return Channel function, an HDMI cable connection also

Getting Started

sends a digital audio signal from the TV. You do not need to make a separate audio connection for listening to TV sound. For setting the Audio Return Channel function, see [Audio Return Channel] (page 51).

B Video cord connection

If your TV does not have an HDMI jack, make this connection.

C Digital optical cord connection

This connection sends an audio signal to the system from the TV. To listen to TV sound via the system, perform this connection. With this connection, the system receives a Dolby Digital multiplex broadcast signal and you can enjoy multiplex broadcast sound.

• You can enjoy the TV sound by selecting the “TV” function (page 23).

• If your TV does not have a digital optical output jack, you can connect the unit and your TV with an audio cord for listening to TV sound via the system. For connection details, see “Connecting the other components” (page 17).

Connecting the other components

When a component you wish to connect to the system has an HDMI (OUT) jack

You can connect a component that has an HDMI (OUT) jack such as a set-top box/digital satellite receiver or PLAYSTATION®3, etc., with an HDMI cable. An HDMI cable connection can send both video and audio signals. By connecting the system and the component using an HDMI cable, you can enjoy high-quality digital picture and sound via the HDMI (IN 1) or HDMI (IN 2) jack.

Rear panel of the unit

ARC

OUT

IN 1 IN 2

HDMI cable (supplied with Mexican and Latin American models of BDV-T28 only) Use HDMI (IN 1) or HDMI (IN 2).

To the HDMI OUT jack of the set-top box/

HDMI OUT

digital satellite receiver or PLAYSTATION

3, etc.

Getting Started

• Video signals from the HDMI (IN 1/2) jacks are sent to the HDMI (OUT) jack only when the “HDMI1” or “HDMI2” function is selected.

• To send an audio signal from the HDMI (IN 1/2) jacks to the HDMI (OUT) jack, you may need to change the audio output setting. For details, see [Audio Output] in [Audio Settings] (page 49).

When the component does not have an HDMI OUT jack

Connect the system so that video signals from the system and other component are sent to the TV, and audio signals from the component are sent to the system as follows.

Video out

Component

Getting Started

Audio out

Signal flow

System

: Video signal

: Audio signal

If the component plays sound only, connect the audio output of the component to the system.

Rear panel of the unit

AUDIO IN

AUDIO

White

: Signal flow

White

Red

Audio cord (not supplied)

Red

To the audio out jacks of the VCR, digital

L R

AUDIO OUT

satellite receiver, PlayStation, or portable audio source, etc.

• If you make connection above, set [Control for HDMI] in [HDMI Settings] of [System Settings] to [Off] (page 51).

• You can enjoy component sound by selecting the “AUDIO” function (page 23).

Connecting the antenna (aerial)

Rear panel of the unit

ANTENNA

COAXIAL

FM wire antenna (aerial)

(supplied)

• Be sure to fully extend the FM wire antenna (aerial).

• After connecting the FM wire antenna (aerial), keep it as horizontal as possible.

• If you have poor FM reception, use a 75-ohm coaxial cable (not supplied) to connect the unit to an outdoor FM antenna (aerial).

Getting Started

Step 3: Connecting to the Network

• To connect the system to your network, you need to make network settings that suit your usage environment and components. For details, see “Setting up the Network” (page 43) and “[Network Settings]” (page 51).

Select the method based on your LAN (Local Area Network) environment.

Getting Started

Rear panel of the unit

Internet

ADSL modem/ cable modem

LAN cable (not supplied)

LAN (100)

Broadband router

LAN 1 LAN 2 LAN 3 LAN 4WANETHER

USB Wireless LAN Adapter (not supplied)

1 Wired Setup

Use a LAN cable to connect to the LAN (100) terminal on the unit.

2 USB Wireless Setup

Use a wireless LAN via the USB Wireless LAN Adapter (Sony UWA-BR100* only). The USB Wireless LAN Adapter may not be available in some regions/countries.

* As of November 2010.

Turn the unit off before connecting the extension cable or inserting the USB Wireless LAN Adapter. After inserting the USB Wireless LAN Adapter to the base and connecting the extension cable to the

(USB) port (front or rear), turn the unit on again.

• The placement distance between the USB Wireless LAN Adapter and your wireless LAN router differs based on your usage environment. If the system cannot connect to the network or the network connection is unstable, move the USB Wireless LAN Adapter to a different position or place the USB Wireless LAN Adapter and the wireless LAN router closer to each other.

• You can also get information for network settings from the following Sony support page:

For customers in the U.S.: http://www.sony.com/support

For customers in Canada: English: http://www.sony.ca/support French: http://fr.sony.ca/support

For customers in Mexico and Latin America: http://esupport.sony.com/LA

Getting Started

+ 47 hidden pages
