HoMan-IA-en-17 | Version 1.7 ENGLISH
Installation Manual
SUNNY HOME MANAGER
Page 2
Legal Provisions SMA Solar Technology AG
2 HoMan-IA-en-17 Installation Manual
Legal Provisions
The information contained in this document is the property of SMA Solar Technology AG. Publishing
its content, either partially or in full, requires the written permission of SMA Solar Technology AG.
Any internal company copying of the document for the purposes of evaluating the product or its
correct implementation is allowed and does not require permission.
Declaration of Conformity
SMA Solar Technology AG hereby declares that this equipment is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC. You can find the entire CE
declaration of conformity at www.SMA-Solar.com.
SMA Warranty
You can download the current warranty conditions from the Internet at www.SMA-Solar.com.
Software Licenses
The licenses for the software modules used can be found on the CD provided.
Trademarks
All trademarks are recognized, even if not explicitly identified as such. A lack of identification does
not mean that a product or symbol is not trademarked.
The BLUETOOTH
®
word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
and any use of these marks by SMA Solar Technology AG is under license.
Modbus® is a registered trademark of Schneider Electric and is licensed by the Modbus
Organization, Inc.
QR Code is a registered trademark of DENSO WAVE INCORPORATED.
Phillips
®
and Pozidriv® are registered trademarks of Phillips Screw Company.
Torx® is a registered trademark of Acument Global Technologies, Inc.
SMA Solar Technology AG
Sonnenallee 1
34266 Niestetal
Germany
Tel. +49 561 9522-0
Fax +49 561 9522-100
www.SMA.de
E-mail: info@SMA.de
© 2004 to 2014 SMA Solar Technology AG. All rights reserved.
Page 3
SMA Solar Technology AG Table of Contents
Installation Manual HoMan-IA-en-17 3
Table of Contents
1 Information on this Document. . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1 Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2 Supported Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.2.1 SMA Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.2.2 Devices from Other Manufacturers . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.3 Skills of Qualified Persons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.4 Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3 Scope of Delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4 Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.1 Sunny Home Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.1.1 Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.1.2 Type Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.1.3 LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.1.4 System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.2 SMA Radio-Controlled Socket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.2.1 Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.2.2 LED Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
5 Preparing for Mounting and Commissioning of the
Sunny Home Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.1 Preparing for BLUETOOTH Communication . . . . . . . . . . . . . . . . . . . 28
5.1.1 Commissioning a BLUETOOTH PV System . . . . . . . . . . . . . . . . . . . 28
5.1.2 Configuring the NetID on the Sunny Home Manager. . . . . . . . . . . 29
5.1.3 Configuring the NetID on the SMA Radio-Controlled Socket . . . . . 29
5.2 Preparing for Speedwire Communication . . . . . . . . . . . . . . . . . . . . . 30
6 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.1 Requirements for the Mounting Location of the
Sunny Home Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.2 Requirements for the Mounting Location of the
SMA Radio-Controlled Socket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Page 4
Table of Contents SMA Solar Technology AG
4 HoMan-IA-en-17 Installation Manual
6.3 Checking the BLUETOOTH Connection at the
Designated Mounting Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
6.4 Mounting the Sunny Home Manager . . . . . . . . . . . . . . . . . . . . . . . . 33
6.4.1 Mounting the Sunny Home Manager on the Wall . . . . . . . . . . . . . 33
6.4.2 Mounting the Sunny Home Manager on the Top-Hat Rail. . . . . . . . 33
7 Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.1 Connection Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.2 Connecting the Sunny Home Manager to Energy Meters. . . . . . . . . 37
7.2.1 Connecting the Sunny Home Manager to the
SMA Energy Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7.2.2 Connecting the Sunny Home Manager to Energy Meters with D0
Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7.2.3 Connecting the Sunny Home Manager to Energy Meters with S0
Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
7.3 Replacing Energy Meters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
7.4 Connecting the Sunny Home Manager to the Router . . . . . . . . . . . . 41
7.5 Connecting a Device to be Controlled via a
Data Exchange Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
7.6 Supplying the Sunny Home Manager with Voltage . . . . . . . . . . . . . 42
7.6.1 Supplying the Sunny Home Manager with Voltage via the
Plug-In Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7.6.2 Supplying the Sunny Home Manager with Voltage via the
Top-Hat Rail Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
8 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.1 Establishing a Connection to Sunny Portal . . . . . . . . . . . . . . . . . . . . 45
8.2 Registering in Sunny Portal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.3 Setting the Operating Mode of the SMA Radio-Controlled Socket. . 50
9 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
9.1 Errors in the Sunny Home Manager . . . . . . . . . . . . . . . . . . . . . . . . . 52
9.1.1 States of All LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
9.1.2 States of the Status LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
9.1.3 States of the BLUETOOTH LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
9.2 Errors in the SMA Radio-Controlled Socket. . . . . . . . . . . . . . . . . . . . 55
Page 5
SMA Solar Technology AG Table of Contents
Installation Manual HoMan-IA-en-17 5
9.3 Errors during Registration in Sunny Portal . . . . . . . . . . . . . . . . . . . . . 56
9.4 Using the Sunny Home Manager Assistant . . . . . . . . . . . . . . . . . . . . 62
9.5 Error in the Sunny Home Manager Assistant. . . . . . . . . . . . . . . . . . . 62
9.6 Resetting the Sunny Home Manager. . . . . . . . . . . . . . . . . . . . . . . . . 63
9.7 Reassigning the Sunny Home Manager after Resetting the
Sunny Home Manager System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
9.8 Resetting the SMA Radio-Controlled Socket to Default Settings . . . . 65
10 Decommissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
10.1 Disassembling the Sunny Home Manager . . . . . . . . . . . . . . . . . . . . 66
10.2 Packing the Sunny Home Manager/SMA Radio-Controlled
Socket for Shipping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
10.3 Disposing of the Sunny Home Manager/SMA Radio-Controlled
Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
11 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
11.1 Sunny Home Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
11.2 SMA Radio-Controlled Socket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
11.3 Plug-In Power Supplies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
12 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
13 Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Page 6
1 Information on this Document SMA Solar Technology AG
6 HoMan-IA-en-17 Installation Manual
1 Information on this Document
Validity
This document is valid for the following device types:
• HM-BT-10.GR2 (Sunny Home Manager) from firmware version 1.10
• BT-SOCKET-10 (SMA radio-controlled socket) from firmware version 12.12.111.R
You can find the latest version of this document, matching the current software version of the products,
at www.SMA-Solar.com.
Target Group
This document is intended for qualified persons. Only persons with the appropriate skills are allowed
to perform the activities described in this document (see Section2.3 "Skills of Qualified Persons",
page13).
Further Information
Links to additional information can be found at www.SMA-Solar.com:
Document title Document type
SMA Bluetooth - SMA Bluetooth
®
Wireless Technology
in Practice
Technical information
SMA BLUETOOTH
®
Wireless Technology Technical description
SMA SMART HOME - The System Solution for More
Independence
Planning guidelines
SMA FLEXIBLE STORAGE SYSTEM - Increased
Self-Consumption with SUNNY ISLAND and
SUNNY HOME MANAGER
Quick reference guide
Power Reducer Box - Compatibility List Planning guidelines
Page 7
SMA Solar Technology AG 1 Information on this Document
Installation Manual HoMan-IA-en-17 7
Symbols
Typographies
Symbol Explanation
%"/(&3
Indicates a hazardous situation which, if not avoided, will result in death
or serious injury
8"3/*/(
Indicates a hazardous situation which, if not avoided, can result in death
or serious injury
$"65*0/
Indicates a hazardous situation which, if not avoided, can result in minor
or moderate injury
/05*$&
Indicates a situation which, if not avoided, can result in property damage
Information that is important for a specific topic or goal, but is not
safety-relevant
☐ Indicates a requirement for meeting a specific goal
☑ Desired result
✖ A problem that could occur.
Typography Use Example
bold • Display texts
• Elements on a user
interface
•Terminals
• Elements to be selected or
entered
• The value can be found in the field
Energy.
• Select Settings.
• Enter the value 10 in the field
Minutes.
> • Connects several
elements to be selected
• Select Settings > Date.
[Button/Key] • Button or key to be
selected or pressed
• Select [Next].
Page 8
1 Information on this Document SMA Solar Technology AG
8 HoMan-IA-en-17 Installation Manual
Nomenclature
Complete designation Designation in this manual
SMA BLUETOOTH
®
Piggy-Back,
SMA BLUETOOTH® Piggy-Back Plus
BLUETOOTH Piggy-Back
SMA BLUETOOTH® Piggy-Back Off-Grid BLUETOOTH Piggy-Back Off-Grid
SMA BLUETOOTH
®
Repeater,
SMA BLUETOOTH
®
Repeater Outdoor
BLUETOOTH Repeater
Sunny WebBox, Sunny WebBox mit
BLUETOOTH
®
Wireless Technology
Sunny WebBox
SMA BLUETOOTH
®
Wireless Technology BLUETOOTH
SMA radio-controlled socket with BLUETOOTH
®
Wireless Technology
SMA Radio-Controlled Socket
Page 9
SMA Solar Technology AG 2 Safety
Installation Manual HoMan-IA-en-17 9
2 Safety
2.1 Intended Use
Sunny Home Manager
The Sunny Home Manager is a device for monitoring PV systems and for controlling loads in
households with PV systems.
The product is not splash-proof.
The product is designed for indoor use only.
Use this product only in accordance with the information provided in the enclosed documentation and
with the locally applicable standards and directives. Any other application may cause personal injury
or property damage.
Do not use the Sunny Home Manager in systems which include a Sunny WebBox.
For safety reasons, it is not permitted to modify the product or install components that are not explicitly
recommended or distributed by SMA Solar Technology AG for the product. Unauthorized changes
and modifications will void all warranty claims and the operating permission.
Any use of the product other than described in the Intended Use section does not qualify as
appropriate.
The enclosed documentation is an integral part of this product. Keep the documentation in a
convenient place for future reference and observe all instructions contained therein.
The type label must remain permanently attached to the product.
Page 10
2 Safety SMA Solar Technology AG
10 HoMan-IA-en-17 Installation Manual
SMA Radio-Controlled Socket
The SMA radio-controlled socket supports load control in households with the
Sunny Home Manager.
The product is not splash-proof.
The product is designed for indoor use only.
The product is approved for use in all EU member states.
Use this product only in accordance with the information provided in the enclosed documentation and
with the locally applicable standards and directives. Any other application may cause personal injury
or property damage.
Do not connect any medical devices to the product.
Do not connect any loads to the product if they require a continuous supply of electric current
(e.g. refrigerator, freezer).
Do not connect any loads to the product if they can cause injuries or fires if unintentionally switched
on (e.g. iron).
Only connect loads to the product if they are suitable for the voltage and power range of the wall
outlet and the product (see Section11.2 "SMA Radio-Controlled Socket", page70).
Only connect the product to properly installed outlets with a protective contact.
For safety reasons, it is not permitted to modify the product or install components that are not explicitly
recommended or distributed by SMA Solar Technology AG for this product. Unauthorized changes
and modifications will void all warranty claims and the operating permission.
Any use of the product other than described in the Intended Use section does not qualify as
appropriate.
The enclosed documentation is an integral part of this product. Keep the documentation in a
convenient place for future reference and observe all instructions contained therein.
The type label must remain permanently attached to the product.
Page 11
SMA Solar Technology AG 2 Safety
Installation Manual HoMan-IA-en-17 11
2.2 Supported Devices
2.2.1 SMA Devices
The Sunny Home Manager supports a maximum of 16 SMA devices. Of the 16 devices, the
Sunny Home Manager supports a maximum of twelve SMA inverters or ten SMA radio-controlled
sockets.
SMA Inverters
•Sunny Boy (SB):
– SB 3600SE-10/SB 5000SE-10 from firmware version 2.3.35.R
– SB 3000TL-20 from firmware version 3.01.00.R*
– SB 4000TL-20/SB 5000TL-20 from firmware version 3.01.02.R*
– SB 3600TL-20 from firmware version 3.25.01.R*
– SB 3000TL-21/SB 4000TL-21/SB 5000TL-21/SB 3600TL-21 from firmware version
2.00.00.R*
– SB 2500TLST-21/SB 3000TLST-21 from firmware version 2.00.27.R*
– SB 2000HF/SB 2500HF/SB 3000HF from firmware version 2.30.06.R*
• Sunny Tripower (STP):
– STP 8000TL-10/STP 10000TL-10/STP 12000TL-10/STP 15000TL-10/ STP 17000TL-10
from firmware version 2.33.02.R*
– STP 15000TLEE-10/20000TLEE-10/STP 15000TLHE-10/STP 20000TLHE-10 from
firmware version 2.10.20.R*
– STP 5000TL-20/STP 6000TL-20/STP 7000TL-20/STP 8000TL-20/STP 9000TL-20 from
firmware version 2.00.15.R*
• Inverters with BLUETOOTH Piggy-Back from firmware version 02.00.06.R** ,
excluding inverters of type WB (Windy Boy)
• Inverters with SMA Speedwire/Webconnect data module from firmware version 1.00.00.R.**,
excluding inverters of type WB (Windy Boy)
• Inverters with SMA Speedwire/Webconnect Piggy-Back from firmware version 1.00.00.R.**,
excluding inverters of type WB (Windy Boy)
• Sunny Island 6.0H-11/ Sunny Island 8.0H-11/Sunny Island 3.0M-11/ Sunny Island 4.4M-11
with SMA Speedwire data module Sunny Island from firmware version 1.00.00.R
• Sunny Backup 2200 with BLUETOOTH Piggy-Back Off-Grid from firmware version 01.01.4.R
* This firmware version is the minimum requirement for the function Limitation of active power feed-in.
** A list of these inverters can be found in the BLUETOOTH Piggy-Back manual. To learn which inverters support the function
"Limitation of active power feed-in", see the planning guidelines "Power Reducer Box - Compatibility List".
Page 12
2 Safety SMA Solar Technology AG
12 HoMan-IA-en-17 Installation Manual
Other SMA Devices
• SMA Radio-Controlled Socket
•SMA Energy Meter
• SMA BLUETOOTH Repeater
• SMA BLUETOOTH Repeater Outdoor
• Sunny SensorBox with SMA Power Injector with BLUETOOTH
2.2.2 Devices from Other Manufacturers
Inverters
Inverters from other manufacturers can be integrated in PV systems with Sunny Home Manager
provided that the following requirements are met:
☐ The power output of the inverters must be captured via a separate SMA Energy Meter.
☐ The SMA Energy Meter must be configured in Sunny Portal as a PV production meter
(for information on how to configure the energy meters, see the user manual of the
Sunny Home Manager).
☐ In hybrid systems with SMA inverters and inverters from other manufacturers, the PV production
meter must measure the joint power of all
inverters taken together. As soon as you have
registered and configured a PV production meter in the Sunny Home Manager system,
the Sunny Home Manager will no longer query the power data of the SMA inverters directly
from the inverters via BLUETOOTH or Speedwire, but will receive the power data from the
PV production meter.
Monitoring of the PV system and the dynamic limitation of the active power fed into the utility grid are
not
possible with inverters from other manufacturers. In this case, verify whether operation of the
PV system without dynamic active power limitation is permitted in the given country, or whether
dynamic active power limitation can be performed independently by the inverter itself.
Energy Meters
The Sunny Home Manager supports the following energy meter types:
• Energy meters with D0 interface* :
You can find a list of supported energy meters with D0 interface in the planning guidelines
"SMA SMART HOME - The System Solution for more Independence“ at www.SMA-Solar.com.
Recommended resolution: at least 10 Wh
Information: for the function Limitation of active power feed-in, the energy meters with D0
interface must have a resolution of at least 1 Wh.
* D0 interface in accordance with IEC 62056-21, part 4.3
Page 13
SMA Solar Technology AG 2 Safety
Installation Manual HoMan-IA-en-17 13
• Energy meters with S0 interface* :
Energy meters with an S0 interface must output values netted across the line phases at the S0
interface. If necessary, contact the manufacturer of the energy meter.
Bidirectional meters with an S0 interface must be equipped with two S0 interfaces.
Recommended pulse length: at least 20 ms
Recommended pulse rate: 1,000 pulses per kWh
Information: for the function Limitation of active power feed-in, energy meters with an S0
interface must have the following minimum pulse rates:
– At a maximum allowed grid feed-in of more than 1,500 W: at least 250 pulses per kWh
– At a maximum allowed grid feed-in of less than 1,500 W: at least 500 pulses per kWh
Routers
SMA Solar Technology AG recommends the use of a router that supports DHCP.
Other Devices:
• Heat pump Stiebel Eltron WWK 300
• Heat pump Tecalor TTA 300
• Miele@home devices (e.g. washing machines, dryers) with Miele@home Gateway from
firmware version 4.0.x
• Devices which receive control commands directly from the Sunny Home Manager, or forward
such commands to connected loads, via a data exchange protocol defined by
SMA Solar Technology AG
– Air/heat pump Stiebel Eltron LWZ with Internet service gateway
– Air/heat pump Tecalor THZ with Internet service gateway
2.3 Skills of Qualified Persons
The tasks described in this manual must be performed by qualified persons only. Qualified persons
must have the following skills:
• Training in the installation and commissioning of electrical devices
• Knowledge of all applicable standards and directives
* S0 interface in accordance with DIN EN 62053-31, class A
Page 14
2 Safety SMA Solar Technology AG
14 HoMan-IA-en-17 Installation Manual
2.4 Safety Precautions
This section contains safety precautions that must be observed at all times when working on or with
the product.
To prevent personal injury and property damage and to ensure long-term operation of the product,
read this section carefully and follow all safety precautions at all times.
Sunny Home Manager
8"3/*/(
Danger to life due to electric shock
Lethal voltages are present in the conductive parts of the plug-in power supply and the top-hat rail
power supply.
• Only use the Sunny Home Manager indoors and in a dry environment, keeping it away from
liquids.
• Do not open the plug-in power supply.
$"65*0/
Risk of injury due to incorrect cable routing
Incorrectly routed cables may cause a tripping hazard.
•Ensure that the cables are routed so that no one can step on or trip over them.
/05*$&
Damage to the Sunny Home Manager due to moisture penetration
The Sunny Home Manager is not splash-proof.
• Only use the Sunny Home Manager indoors and in a dry environment.
Damage to the Sunny Home Manager due to condensation
If the Sunny Home Manager is taken from a cold environment into a warm environment,
condensation water may form in the Sunny Home Manager.
• In the event of large temperature differences, only supply the Sunny Home Manager with
voltage once it has reached room temperature.
Page 15
SMA Solar Technology AG 2 Safety
Installation Manual HoMan-IA-en-17 15
SMA Radio-Controlled Socket
8"3/*/(
Danger to life due to electric shock
Lethal voltages are present in the live components.
• Only use the SMA radio-controlled socket indoors and in a dry environment (e.g. not in damp
rooms) and keep away from liquids.
• Only insert suitable plugs into the SMA radio-controlled socket.
• Unplug the SMA radio-controlled socket from the outlet prior to cleaning and clean with a dry
cloth only.
The SMA radio-controlled socket is equipped with a relay with μ contact.
• To ensure safe disconnection from the utility grid, pull the SMA radio-controlled socket out of
the wall outlet.
Risk of injury and fire due to unintentional and unattended switching on of loads
Loads that are activated via an SMA radio-controlled socket unintentionally and while unattended
can cause injuries and fires (e.g. iron).
• Do not connect any loads to the SMA radio-controlled socket that could endanger persons or
cause damage if unintentionally switched on.
/05*$&
Damage to the SMA radio-controlled socket
If the SMA radio-controlled socket is not operated properly, it could be damaged.
• Do not operate SMA radio-controlled sockets plugged into each other.
Damage to the wall outlet
If the SMA radio-controlled socket is operated in a wall outlet that is not suitable for the power of
the connected load, damage to the wall outlet could result.
• Only operate the SMA radio-controlled socket in wall outlets that are suitable for the power
of the connected load.
Page 16
3 Scope of Delivery SMA Solar Technology AG
16 HoMan-IA-en-17 Installation Manual
3 Scope of Delivery
Scope of Delivery of the Sunny Home Manager
Check the scope of delivery for completeness and any visible external damage. Contact your
distributor if the delivery is incomplete or damaged.
Figure1: Components included in the scope of delivery
Scope of Delivery of SMA Radio-Controlled Socket
Figure2: Components included in the scope of delivery
Position Quantity Designation
A 1 Sunny Home Manager
B 1 Plug-in power supply
C 1 Network cable
D2Screw
E2Screw anchor
F 3 4-pole plug
G 1 CD with product documentation and Sunny Home Manager Assistant
H 1 Quick reference guide for commissioning
I 6 Label
Position Quantity Designation
A 1 SMA radio-controlled socket
B 1 Installation manual and supplementary sheet
Page 17
SMA Solar Technology AG 4 Product Description
Installation Manual HoMan-IA-en-17 17
4 Product Description
4.1 Sunny Home Manager
4.1.1 Functions
The Sunny Home Manager is a device for monitoring PV systems and for controlling loads in
households with PV systems. The Sunny Home Manager carries out the following tasks:
• Read-out of energy meter data and data from SMA devices with BLUETOOTH or Speedwire
communication interface
• Transmission of data to Sunny Portal
• Support for increased self-consumption
• Limitation of active power feed-in
• Implementation of grid management services via Ethernet-based communication
Figure3: Sunny Home Manager
Position Designation
A Status LED and energy consumption LED
BUSB port*
* The USB ports on the right-hand and left-hand sides of the enclosure currently have no function.
C Connection area with BLUETOOTH LED
Page 18
4 Product Description SMA Solar Technology AG
18 HoMan-IA-en-17 Installation Manual
Reading Out Energy Meter Data and Data from SMA Devices with BLUETOOTH
or Speedwire Communication Interface
The Sunny Home Manager reads out the data of the connected energy meters and SMA devices.
The Sunny Home Manager is connected to the energy meters via network cables.
The Sunny Home Manager establishes the wireless connection to the BLUETOOTH devices
(e.g. SMA radio-controlled sockets) via BLUETOOTH.
The communication between the Sunny Home Manager and an SMA inverter is possible either via
BLUETOOTH or via Speedwire. It is not necessary for all inverters in a PV system to use the same
interface. The Sunny Home Manager can manage and regulate inverters with BLUETOOTH and
inverters with Speedwire as one PV system.
The Sunny Home Manager establishes the connection to Speedwire devices via a router/network
switch in the local network.
SMA inverters are either available fitted with Speedwire or BLUETOOTH ex works, or they can be
retrofitted accordingly (see product page of the respective inverter at www.SMA-Solar.com).
PV System Monitoring and Parameterization via Sunny Portal
Sunny Portal serves as the user interface of the Sunny Home Manager. The Sunny Home Manager
establishes the Internet connection to Sunny Portal and sends the read-out data to Sunny Portal via a
router.
Using Sunny Portal, the Sunny Home Manager enables monitoring of the system, a display of the
PV energy available over the course of the day, and a live display of all energy flows in the
household. Taking the different electricity prices into account, the Sunny Home Manager derives from
this recommendations for the prudent use of electrical energy.
Support for Increased Self-Consumption
Self-consumption means that the PV power is consumed at the site where it is generated.
In every household, there is "natural" self-consumption, because loads (e.g. oven) are in operation
while PV power is being produced and because certain loads continuously consume current
(e.g. refrigerator, devices in standby mode). If the PV system produces a lot of PV power, it is possible
that only a part of that PV power will be self-consumed. The excess PV power is fed into the utility grid.
A higher self-consumption quota can be achieved if loads are specifically switched on when excess
PV power is available.
The following functions of the Sunny Home Manager make it possible to increase the
self-consumption quota:
Function Explanation
Creation of a PV yield
forecast
The Sunny Home Manager continuously logs the energy generated by
the PV system. It also receives location-based weather forecasts via the
Internet* .
Based on this information, the Sunny Home Manager creates a PV
yield forecast for the PV system.
Page 19
SMA Solar Technology AG 4 Product Description
Installation Manual HoMan-IA-en-17 19
Creation of a load profile The Sunny Home Manager logs the PV generation, the grid feed-in,
and the purchased electricity. Based on PV generation, grid feed-in and
purchased electricity, the Sunny Home Manager determines how
much energy is typically consumed at certain times and uses this to
create a load profile for the household. This load profile can be
different for each day of the week.
The Sunny Home Manager obtains the PV generation data from the
connected SMA inverters, from an SMA Energy Meter, or from
another energy meter. The Sunny Home Manager receives the data on
grid feed-in and purchased electricity from an SMA Energy Meter or at
least one other energy meter.
Control of
SMA radio-controlled
sockets
Specific loads connected to SMA radio-controlled sockets can be
switched on and off by the Sunny Home Manager. The
Sunny Home Manager uses the PV yield forecast and the load profile
to determine favorable time periods for optimization of internal power
supply and self-consumption. In accordance with the PV system
operator's specifications and taking the determined time periods into
account, the Sunny Home Manager controls switch-on and switch-off
of the loads.
Also, SMA radio-controlled sockets provide the facility to individually
monitor and record the consumption of loads.
Control of Miele devices
via the Miele@home
system
The Sunny Home Manager can control supported devices from
Miele & Cie KG via a Miele@home gateway** .
The Sunny Home Manager uses the PV yield forecast and the load
profile to determine favorable time periods for optimization of internal
power supply and self-consumption. In accordance with the PV system
operator's specifications and taking the determined time periods into
account, the Sunny Home Manager controls switch-on and switch-off
of the loads.
Control of devices via a
data exchange protocol
The Sunny Home Manager can control devices using a data exchange
protocol defined by SMA Solar Technology AG by communicating
with the devices either directly or via an appropriate gateway using
Ethernet. The device reports its energy demand to the Sunny Home
Manager and the Sunny Home Manager allocates the available
energy to the device taking the PV yield forecast and the consumption
forecast into account.
Function Explanation
Page 20
4 Product Description SMA Solar Technology AG
20 HoMan-IA-en-17 Installation Manual
Limitation of Active Power Feed-In
Local regulations, for example, the Renewable Energy Sources Act (EEG) in Germany, can call for
permanent limitation of active power feed-in for your PV system, that is, a limitation of the active power
fed into the utility grid to a fixed amount or a percentage share of the installed nominal PV system
power. If required, ask your grid operator whether a permanent limitation of the active power feed-in
is necessary and whether you are allowed to use the Sunny Home Manager for this purpose (see the
Manufacturer's Declaration "Feed-In Management In Accordance with the Renewable Energy
Sources Act (EEG) 2012 with SMA Sunny Home Manager (SHM) from SMA" available at
www.SMA-Solar.com). Using an SMA Energy Meter or a suitable feed-in meter, the
Sunny Home Manager monitors the active power that is fed into the utility grid. If the active power
feed-in exceeds the prescribed limit, the Sunny Home Manager limits the PV generation of the
inverters accordingly.
When used with SMA
battery inverters:
Prevention of derating
losses
The Sunny Home Manager prevents derating losses which can arise
due to the limitation of active power feed-in. Taking the PV yield
forecast and the consumption forecast into account, the timing and
duration of battery charging are controlled and the battery charge is
optimized according to the available energy supply, if excess
PV energy cannot otherwise be used.
When used with SMA
battery inverters:
Optimized discharge of
lead-acid batteries
The Sunny Home Manager uses the calculated load profile and the PV
yield forecast to control battery discharge. The battery is discharged
when the following criteria are met:
• It is possible for the battery to be discharged to a point where
sufficient storage capacity is free to absorb the amount of PV
energy forecast for the next battery charge.
• The discharged lead-acid battery can then promptly be charged
with excess PV energy.
The use of these criteria ensures that the lead-acid battery is conserved
while making optimum use of the battery capacity.
Transmission of
SMA Energy Meter data
to Sunny Island systems
If an SMA Speedwire Sunny Island data module is installed in the
Sunny Island, the Sunny Home Manager can send SMA Energy Meter
data to the Sunny Island system.
Transmission of energy
meter data to
Sunny Backup systems
If a BLUETOOTH Piggy-Back Off-Grid is installed in the Sunny Backup,
the Sunny Home Manager can transfer the energy meter data to the
Sunny Backup system.
* Data is not available in all countries
** This function is not available in all countries.
Function Explanation
Page 21
SMA Solar Technology AG 4 Product Description
Installation Manual HoMan-IA-en-17 21
The Sunny Home Manager avoids derating losses due to limitation of PV power generation by taking
the current self-consumption of the household into account. Sunny Home Manager helps to use excess
PV power in households directly and increases the self-consumption quota as a result. For PV systems
with SMA battery inverters, the Sunny Home Manager preferentially uses the derated active power
to charge the battery.
Implementation of Grid Management Services via Ethernet-Based
Communication
As part of grid management services, it may be necessary to implement grid operator specifications
for active power limitation and for reactive power feed-in (e.g. the active power feed-in of your PV
system will be reduced in the event of grid overloads).
The Sunny Home Manager can implement requirements for grid management services that the grid
operator sends to the Sunny Home Manager via Ethernet-based communication.
If applicable, ask your grid operator whether your PV system is required to implement grid
management services.
4.1.2 Type Label
The type label clearly identifies the product. The type label is located on the back of the product.
You can read off the following data from the type label:
•Serial number
•Registration ID
•Assembly name (type)
• Hardware version (version)
You will require the information on the type label to use the product safely and when seeking customer
support from the SMA Service Line.
Example: Limitation of the active power feed-in to 70% of the nominal PV system power
Due to high levels of solar irradiation, the system can currently produce 90% of the nominal PV
system power.
• At this time, 20% of the nominal PV system power is being consumed by loads in the
household. The remaining 70% of the nominal PV system power is being fed into the utility
grid.
☑ No limitation of PV generation is required.
• A load is switched off and only 10% of the nominal PV system power is consumed in the
household. As a result, 80% of the nominal system power is available for feed-in to the utility
grid – more than allowed.
☑ The Sunny Home Manager reduces PV generation from the theoretically possible 90% of
nominal PV system power to 80%. 70% of the nominal PV system power continues to be
fed into the utility grid.
Page 22
4 Product Description SMA Solar Technology AG
22 HoMan-IA-en-17 Installation Manual
Symbols on the Type Label
4.1.3 LEDs
Figure4: LEDs of the Sunny Home Manager
Symbol Designation Explanation
C-Tick The product complies with the
requirements of the applicable
Australian EMC standards.
FCC marking The product complies with the
requirements of the applicable FCC
standards.
BLUETOOTH Wireless
Technology
The product has a BLUETOOTH
interface.
Data matrix code 2D code for device-specific
characteristics
Position Designation Explanation
A Energy consumption LED Displays the current electricity consumption
B Status LED Displays the current status of the
Sunny Home Manager
C BLUETOOTH LED Displays the status of the BLUETOOTH
connection.
Page 23
SMA Solar Technology AG 4 Product Description
Installation Manual HoMan-IA-en-17 23
Energy Consumption LED
The energy consumption LED is only active if either the bidirectional meter for grid feed-in and
purchased electricity is connected or one feed-in meter and one purchased electricity meter are
connected.
Status LED
Further states of the status LED are described in the Section "Troubleshooting" (see Section9.1.2
"States of the Status LED", page52).
BLUETOOTH LED
Further states of the BLUETOOTH LED are described in the Section "Troubleshooting"
(see Section9.1.3 "States of the BLUETOOTH LED", page54).
LEDs on the Network Terminal
Figure5: LEDs on the network terminal
LED status Explanation
Glowing green The household is being supplied with energy from the PV system only.
Flashing green and
orange intermittently
The household is being supplied with energy from the PV system and from
the utility grid.
Glowing orange The household is being supplied with energy from the utility grid only.
LED status Explanation
Glowing green The Sunny Home Manager is connected to the devices of the PV system
and Sunny Portal.
LED status Explanation
Glowing blue The BLUETOOTH connection to the devices of the PV system is good.
Position LED LED status Explanation
A Link/Activity
LED (green)
Glowing Network connection established
Flashing Network connection established. Data is being sent or
received.
Off No network connection established
B Speed LED
(yellow)
Glowing The data transfer rate is up to 100 Mbit/s.
Off The data transfer rate is up to 10 Mbit/s.
Page 24
4 Product Description SMA Solar Technology AG
24 HoMan-IA-en-17 Installation Manual
4.1.4 System Requirements
Operating systems supported by the Sunny Home Manager Assistant:
• Microsoft Windows 8
• Microsoft Windows 7
• Microsoft Windows Vista
• Microsoft Windows XP Service Pack 2
• Linux with kernel from version 2.6.12, with Oracle Java Runtime Environment from version 6
• MAC OS from version 10.6, with Java Runtime Environment from version 6
Internet access requirements:
• Permanent Internet access. Recommended: DSL access with flat rate
Supported web browsers:
• Google Chrome from version 14.0
• Microsoft Internet Explorer from version 8
• Mozilla Firefox from version 5
• Opera from version 11.0
• Safari from version 5.0
Recommended display resolution:
• Minimum 1,024 pixels x 768 pixels
Energy meters:
Minimum energy meter types recommended by SMA Solar Technology AG for connection to the
Sunny Home Manager:
• Feed-in meter and purchased electricity meter
or
• Bidirectional meter for grid feed-in and purchased electricity
At least one feed-in meter is required for the function Limitation of active power feed-in
(recommended: SMA Energy Meter).
The Sunny Home Manager receives the PV generation data via the connected SMA inverters or via
an optionally connected PV production meter.
Page 25
SMA Solar Technology AG 4 Product Description
Installation Manual HoMan-IA-en-17 25
Network cable requirements:
• Cable length between two nodes: max. 50 m with patch cable, max. 100 m with installation
cable
• Cross-section: at least 2 x 2 x 0.22 mm
2
or at least 2 x 2 x 24 AWG
• Cable category: Cat5, Cat5e, Cat6, Cat6a, Cat7
• Cable shield: SF/UTP, S/UTP, SF/FTP, S/FTP
• Plug type: RJ45 for Cat5, Cat5e, Cat6, Cat6a
4.2 SMA Radio-Controlled Socket
4.2.1 Functions
The SMA radio-controlled socket supports load control in households with the
Sunny Home Manager. The SMA radio-controlled socket carries out the following tasks:
• Implementing control commands issued by the Sunny Home Manager
• Measuring the energy consumption of the connected loads
• Improving the wireless connection between BLUETOOTH devices
Implementing Control Commands of the Sunny Home Manager
The Sunny Home Manager can switch the SMA radio-controlled socket on and off. As a result,
specific electrical devices can be switched on if e.g. a lot of PV power is available.
The times at which the Sunny Home Manager switches the radio-controlled socket on or off depend
on the configuration of the SMA radio-controlled socket and the scheduling of the
Sunny Home Manager (see the user manual "SUNNY HOME MANAGER in Sunny Portal").
Measuring the Energy Consumption of the Connected Loads
The SMA radio-controlled socket measures the energy consumption of the connected loads and
transmits the measured values via the Sunny Home Manager to Sunny Portal.
Page 26
4 Product Description SMA Solar Technology AG
26 HoMan-IA-en-17 Installation Manual
Improving the Wireless Connection between BLUETOOTH Devices
If the distance between BLUETOOTH devices is too great or obstructions interfere with the
BLUETOOTH connection, the SMA radio-controlled socket can be used as a repeater to bridge the
dead zone.
Figure6: SMA radio-controlled socket
4.2.2 LED Display
Upper Horizontal LED
Figure7: Upper horizontal LED of the LED display
Position Designation Explanation
A LED display Displays status, operating modes, and NetIDs
B Touch key Operation of the SMA radio-controlled socket
LED status Operating mode/status of the SMA radio-controlled socket
Glowing green Manually switched on
No control of the SMA radio-controlled socket by the Sunny Home Manager
Glowing orange Manually switched off
No control of the SMA radio-controlled socket by the Sunny Home Manager
Flashing green Automatically switched on
Control of the SMA radio-controlled socket by the Sunny Home Manager
Flashing orange Automatically switched off
Control of the SMA radio-controlled socket by the Sunny Home Manager
Page 27
SMA Solar Technology AG 4 Product Description
Installation Manual HoMan-IA-en-17 27
Lower Horizontal LED
Figure8: Lower horizontal LED of the LED display
Further states of the lower horizontal LED are described in the Section "Troubleshooting"
(see Section9.2 "Errors in the SMA Radio-Controlled Socket", page55).
Vertical LEDs
Figure9: Vertical LEDs of the LED display
All LEDs of the LED Display
Figure10: Display of NetIDs
Glowing red System is starting.
or
Update process is running.
In this status, do not unplug the SMA radio-controlled socket from the outlet.
Otherwise, the SMA radio-controlled socket could be damaged.
LED status Explanation
Glowing blue The BLUETOOTH connection to the Sunny Home Manager is good.
LED status Operating mode/status of the SMA radio-controlled socket
Glowing green The touch key is ready for operation.
In this status, the SMA radio-controlled socket can be reset to the default
settings (see Section9.8, page65).
Flashing green The SMA radio-controlled socket is initializing.
LED status Operating mode/status of the SMA radio-controlled socket
0; 2 to 9; A to F NetID configuration mode and display of the configured NetID
LED status Operating mode/status of the SMA radio-controlled socket
Page 28
5 Preparing for Mounting and Commissioning of the Sunny Home Manager SMA Solar Technology AG
28 HoMan-IA-en-17 Installation Manual
5 Preparing for Mounting and Commissioning of the
Sunny Home Manager
5.1 Preparing for BLUETOOTH Communication
If the Sunny Home Manager is to communicate with other SMA devices via BLUETOOTH,
e.g. with SMA radio-controlled sockets, you must carry out the following preparatory steps.
5.1.1 Commissioning a BLUETOOTH PV System
All devices must be set to the same NetID so that the SMA BLUETOOTH devices in a PV system can
communicate with each other. The NetID is used to distinguish between PV systems using
SMA BLUETOOTH located in close proximity to one another.
The NetID can be a number from 1 to 9 or a letter from A to F.
To make sure that you do not set a NetID which is already being used by another BLUETOOTH PV
system in the vicinity, you need to determine a free NetID prior to commissioning your BLUETOOTH
PV system.
Procedure
1. If another system with BLUETOOTH is located within 500 m of your system, determine a free
NetID at the planned mounting location of every BLUETOOTH device and make a note of this
(see Sunny Explorer manual).
2. For all devices that are to communicate with the Sunny Home Manager via BLUETOOTH,
set the previously noted free NetID and commission the devices (see manual of BLUETOOTH
device or BLUETOOTH Piggy-Back).
3. Note the serial numbers of the Sunny Home Manager and all other SMA devices. For the
SMA radio-controlled sockets, also note the load that you wish to assign to the respective
SMA radio-controlled socket.
Requirement for detecting a free NetID
You can only detect a free NetID using a computer with integrated BLUETOOTH or with a
BLUETOOTH stick (BLUETOOTH class 1) and the software Sunny Explorer (see Sunny Explorer
help). You can obtain Sunny Explorer free of charge from the download area at
www.SMA-Solar.com.
Requirement for selecting NetID "1" as the NetID of the PV system
For BLUETOOTH devices, NetID 1 is preset at the factory. If NetID 1 is set in the Sunny Home
Manager, it can connect to a maximum of one other device via BLUETOOTH or Speedwire.
• If you would like to connect more SMA devices than one inverter and
one Sunny Home Manager, select a NetID other than NetID 1.
Page 29
SMA Solar Technology AG 5 Preparing for Mounting and Commissioning of the Sunny Home Manager
Installation Manual HoMan-IA-en-17 29
4. Note the registration ID of the Sunny Home Manager.
5. With the exception of the Sunny Home Manager and the SMA radio-controlled socket,
commission all BLUETOOTH devices (see BLUETOOTH device manuals).
5.1.2 Configuring the NetID on the Sunny Home Manager
Requirement:
☐ The BLUETOOTH PV system must be commissioned (see Section5.1.1 "Commissioning a
BLUETOOTH PV System", page28).
Procedure
• Use a screwdriver to turn the arrow of the rotary switch NetID to the desired NetID (blade width
of the screwdriver: 2.5 mm).
5.1.3 Configuring the NetID on the SMA Radio-Controlled Socket
Configuring the NetID for the First Time
1. Insert the SMA radio-controlled socket into an outlet.
☑ The upper horizontal LED glows red for approximately ten seconds, then the vertical LEDs
glow green for approximately four seconds.
2. As soon as the LED display shows 0, keep tapping the touch key until the LED display shows the
desired NetID.
3. To adopt the NetID, wait five seconds. During this time, do not tap the touch key.
Changing the NetID
Requirements:
☐ The SMA radio-controlled socket must be inserted in an outlet.
☐ The upper horizontal LED must be glowing orange or green.
Procedure
1. Hold the touch key down for approximately two seconds.
☑ The LED display shows the last configured NetID.
2. Keep tapping the touch key until the desired NetID is displayed.
3. To adopt the NetID, wait five seconds. During this time, do not tap the touch key.
Reading off the serial number and registration ID
You can read off the serial number and the registration ID of the Sunny Home Manager
at the following locations:
• On the type label on the back of the Sunny Home Manager
• On the cover of the supplied CD
Page 30
5 Preparing for Mounting and Commissioning of the Sunny Home Manager SMA Solar Technology AG
30 HoMan-IA-en-17 Installation Manual
5.2 Preparing for Speedwire Communication
If the Sunny Home Manager is to communicate with other SMA devices via Speedwire,
the Sunny Home Manager and the Speedwire devices must be in the same local network.
Perform the following preparatory steps.
Requirements:
☐ A NetID other than NetID 1 must be set on the Sunny Home Manager (see Section5.1.2
"Configuring the NetID on the Sunny Home Manager", page29). This enables the
Sunny Home Manager to connect to several devices simultaneously via Speedwire or
BLUETOOTH.
☐ DHCP must be activated on the router (see router manual). If your router does not support
DHCP, you can configure the static network settings on the Speedwire device using
SMA Connection Assist* .
☐ All UDP ports > 1024 on the router or modem must be open for outgoing connections. If there
is a firewall installed on the router or modem, you might have to adjust the firewall rules.
☐ It must be possible for the outgoing router or modem connections to reach all Internet
destinations (target IP, target port). If there is a firewall installed on the router or modem,
you might have to adjust the firewall rules.
☐ On a router or modem with NAT (Network Address Translation), no port forwarding should be
set up. This will help prevent potential communication problems.
☐ There must be no packet filtering or manipulation for SIP packets installed on the router or
modem.
Procedure
2. Connect the Speedwire devices to the router/network switch (see Speedwire device manual).
Make sure that the distance to the mounting location of the Sunny Home Manager is not too
great, as the Sunny Home Manager must later be connected to the same router/network switch.
Inverters with Webconnect function
If an inverter is already registered in Sunny Portal with the Webconnect function, the inverter
cannot be added to the Sunny Home Manager system.
• Delete the inverter with Webconnect function from the Webconnect system or deactivate
data reception for the inverter in the Webconnect system.
* You can obtain the SMA Connection Assist software free of charge from the download area at www.SMA-Solar.com.
1.
Deactivating the BLUETOOTH communication of the inverters
If an inverter communicates with the Sunny Home Manager simultaneously via
Speedwire and BLUETOOTH, data recording errors will result.
• For inverters with BLUETOOTH interface, set NetID 0 (see inverter or Bluetooth
Piggy-Back manual). This deactivates communication via BLUETOOTH.
Page 31
SMA Solar Technology AG 6 Installation
Installation Manual HoMan-IA-en-17 31
6 Installation
6.1 Requirements for the Mounting Location of the
Sunny Home Manager
☐ The mounting location must be indoors.
☐ The mounting location must be protected against dust, moisture and corrosive substances.
☐ The cable route from the mounting location to the router must not exceed a maximum length of
100 m.
☐ The cable route from the mounting location of the Sunny Home Manager to the energy meters
with D0 interface must not exceed a maximum length of 15 m.
☐ The cable route from the mounting location of the Sunny Home Manager to the energy meters
with S0 interface must not exceed a maximum length of 30 m.
☐ A minimum distance of of 1 m must be maintained from devices using the 2.4 GHz radio
spectrum (e.g. WLAN devices, microwave ovens). This will prevent reduced connection quality
and data transmission speed.
☐ The Sunny Home Manager must not have radio shielding (e.g. in a metal cabinet).
Minimum Clearances:
Figure11: Minimum clearances
• Observe minimum clearances to walls, other communication products, inverters, or objects.
6.2 Requirements for the Mounting Location of the
SMA Radio-Controlled Socket
☐ The SMA radio-controlled socket must only be operated in wall outlets that are suitable for the
power of the connected load.
☐ A minimum distance of of 1 m must be maintained from devices using the 2.4 GHz radio
spectrum (e.g. WLAN devices, microwave ovens). This will prevent reduced connection quality
and data transmission speed.
SUNNY HOME MANAGER
70 mm70 mm
150 mm
50 mm
50 mm
Page 32
6 Installation SMA Solar Technology AG
32 HoMan-IA-en-17 Installation Manual
6.3 Checking the BLUETOOTH Connection at the Designated
Mounting Location
If the Sunny Home Manager is to communicate with other SMA devices via BLUETOOTH, e.g. with
SMA radio-controlled sockets, you must check the BLUETOOTH connection at the designated
mounting location.
Requirements:
☐ The same NetID must be configured for all BLUETOOTH devices and on the
Sunny Home Manager (see Section5 "Preparing for Mounting and Commissioning of the
Sunny Home Manager", page28).
☐ The BLUETOOTH PV system must be commissioned (see Section5.1 "Preparing for
BLUETOOTH Communication", page28).
Procedure
1. Supply the Sunny Home Manager with voltage via the plug-in power supply
(see Section 7.6.1).
☑ After approx. two minutes, the BLUETOOTH LED is glowing blue. The connection to the
BLUETOOTH devices is good.
✖ The BLUETOOTH LED is flashing blue?
The BLUETOOTH connection is critical.
• If possible, select a different mounting location and check the connection.
• If no other mounting location is possible, use a BLUETOOTH Repeater or an
SMA radio-controlled socket. This will extend the wireless range of your BLUETOOTH
network.
2. Pull the plug-in power supply out of the outlet.
3. Unplug the DC plug of the plug-in power supply from the Power terminal of the
Sunny Home Manager.
Page 33
SMA Solar Technology AG 6 Installation
Installation Manual HoMan-IA-en-17 33
6.4 Mounting the Sunny Home Manager
6.4.1 Mounting the Sunny Home Manager on the Wall
1. Define the position of the Sunny Home Manager on the wall.
2. Mark the position of the drill holes on the wall (distance between drill holes: 58 mm).
3. Drill the holes (diameter: 6 mm).
4. Insert the screw anchors into the holes.
5. Screw in the screws leaving approximately 6 mm protruding from the wall.
6. Hook the Sunny Home Manager onto the screws.
Ensure that the heads of the screws are engaged in
the holes at the back of the Sunny Home Manager.
6.4.2 Mounting the Sunny Home Manager on the Top-Hat Rail
Requirement:
☐ The top-hat rail must be firmly installed on the wall.
Procedure
1. Press the Sunny Home Manager with the upper
retainers into the upper edge of the top-hat rail.
2. Hook the lower retainers into the lower edge of the
top-hat rail.
Page 34
7 Connection SMA Solar Technology AG
34 HoMan-IA-en-17 Installation Manual
7 Connection
7.1 Connection Area
Bottom of Enclosure
Figure12: Terminals on the bottom of the enclosure
Position Designation Explanation
A Power Pin connector for plug-in power supply
B NetID Rotary switch for configuring the NetID
C BLUETOOTH LED Status display of BLUETOOTH connection
D Meter 1 Pin connector for:
• 1 purchased electricity meter with D0 or
S0 interface
or
• 1 bidirectional meter with D0 interface for
grid feed-in and purchased electricity
E Meter 2 Pin connector for 1 feed-in meter with D0 or S0
interface*
* If a bidirectional meter is connected to the pin connector Meter 1, the pin connector Meter 2 has no function.
F Meter 3 Pin connector for 1 PV production meter with D0
or S0 interface
G Network terminal RJ45 pin connector for the network cable
Page 35
SMA Solar Technology AG 7 Connection
Installation Manual HoMan-IA-en-17 35
Right Side of Enclosure
Figure13: Terminal on the right side of the enclosure
Left Side of Enclosure
Figure14: Terminal on the left side of the enclosure
Position Designation Explanation
A USB port Currently without function
Position Designation Explanation
A USB port Currently without function
Page 36
7 Connection SMA Solar Technology AG
36 HoMan-IA-en-17 Installation Manual
Contact Pin Assignment of the Pin Connector
Figure15: Contact pin assignment of the pin connectors at the bottom of the Sunny Home Manager enclosure
Upper contact pin row for D0:
Lower contact pin row for S0:
Pin Signal Specification Description
A GND Voltage supply Ground
B TX Transmitter output Transmit D0
C RX Receiver input Receive D0
D VCC_D0, +8 Volt Voltage supply output Voltage supply for the optical probe
Pin Signal Specification Description
E S0- Input and output S0 signal
F S0+ Input and output S0 signal
G GND Voltage supply Ground of the external voltage
supply when supplied via top-hat
rail power supply
H +12 Volt, DC Voltage supply input External voltage supply when
supplied via top-hat rail power
supply
Page 37
SMA Solar Technology AG 7 Connection
Installation Manual HoMan-IA-en-17 37
7.2 Connecting the Sunny Home Manager to Energy Meters
7.2.1 Connecting the Sunny Home Manager to the
SMA Energy Meter
The SMA Energy Meter and the Sunny Home Manager must be connected to the same router.
Additionally required material (not included in the scope of delivery):
☐ 1 network cable (for cable requirements, see Section 4.1.4)
Procedure
1. Connect the SMA Energy Meter to the router (see installation manual of the
SMA Energy Meter).
2. Connect the Sunny Home Manager to the router (see Section7.4, page41).
7.2.2 Connecting the Sunny Home Manager to Energy Meters
with D0 Interface
Additionally required material (not included in the scope of delivery):
☐ Cable with optical probe and 4-pole plug (see Section12 "Accessories", page73).
Requirements for energy meters with D0 interface:
☐ D0 interface in accordance with IEC 62056-21, part 4.3
☐ Recommended resolution: at least 10 Wh.
Energy meters with a D0 interface must have a resolution of at least 1 Wh for the function
Limitation of active power feed-in.
List of recommended energy meters
You can find a list of recommended energy meters with D0 interfaces in the Planning Guidelines
"SMA SMART HOME - The System Solution for more Independence" at www.SMA-Solar.com.
Activation of the D0 interface by the grid operator
It is possible that the D0 interface will need to be cleared by the grid operator. If necessary,
contact your grid operator.
Page 38
7 Connection SMA Solar Technology AG
38 HoMan-IA-en-17 Installation Manual
Procedure
1. Position the magnet retainer of the optical probe at
the front upper right-hand corner of the energy
meter. The infrared interfaces on the optical probe
and on the energy meter must be perfectly aligned.
2. Connect the plug of the optical probe to the pin
connector to which the corresponding energy meter
is assigned. Insert the four-pole plug into the upper
contact pin row:
• For purchased electricity meters, insert the
four-pole plug into the pin connector Meter 1.
• For feed-in meters, insert the four-pole plug into
the pin connector Meter 2.
• For PV production meters, insert the four-pole
plug into the pin connector Meter 3.
• For bidirectional meters for grid feed-in and purchased electricity, insert the four-pole plug
into the pin connector Meter 1.
3. Use the labels provided to mark each cable with the pin connector and energy meter to which
it is assigned.
7.2.3 Connecting the Sunny Home Manager to Energy Meters
with S0 Interface
Additionally required material (not included in the scope of delivery):
☐ 1 cable with at least 2 insulated conductors
Cable requirements:
☐ Conductor cross-section: 0.2 mm
2
to 1.5 mm
2
☐ Maximum cable length: 30 m
Requirements for energy meters with an S0 interface:
☐ S0 interface in accordance with DIN EN 62053-31, class A
☐ Bidirectional meters with an S0 interface must be equipped with two S0 interfaces.
☐ Energy meters with an S0 interface must output values netted across the line phases at the S0
interface. If necessary, contact the manufacturer of the energy meter.
☐ Recommended pulse length: at least 20 ms
Page 39
SMA Solar Technology AG 7 Connection
Installation Manual HoMan-IA-en-17 39
☐ Recommended pulse length: 1,000 pulses per kWh
For the function Limitation of active power feed-in, energy meters with an S0 interface must
have the following pulse rates:
– For systems with maximum permitted grid feed-in of more than 1,500 W:
at least 250 pulses per kWh
– For systems with maximum permitted grid feed-in of less than 1,500 W:
at least 500 pulses per kWh
Page 40
7 Connection SMA Solar Technology AG
40 HoMan-IA-en-17 Installation Manual
Procedure
1. Remove 4 cm of cable sheath.
2. Shorten the cable shield to approximately 5 mm.
Fold the surplus cable shield back onto the cable
sheath.
3. Shorten unused insulated conductors flush with the
cable sheath.
4. Strip the insulated conductors by 6 mm.
5. Release the pin connectors of the four-pole plug
with a screwdriver. Insert the insulated conductors
into the contact pins 1 and 2 of the four-pole plug.
6. Write down the color of the insulated conductors.
7. Connect the four-pole plug to the pin connector
assigned to the corresponding energy meter. Insert
the four-pole plug into the lower contact pin row:
• For purchased electricity meters, insert the
four-pole plug into the pin connector Meter 1.
• For feed-in meters, insert the four-pole plug into
the pin connector Meter 2.
• For PV production meters, insert the four-pole
plug into the pin connector Meter 3.
• For bidirectional meters for grid feed-in and purchased electricity, insert the connection plug
of the cable for purchased electricity into the pin connector Meter 1. Insert the connection
plug of the cable for grid feed-in into the pin connector Meter 2.
8. Connect the end of the cable to the energy meter. Observe the polarity of the insulated
conductors.
9. Use the labels provided to mark each cable with the pin connector and energy meter to which
it is assigned.
10. Note the S0 pulses per kWh of each energy meter. This will facilitate the meter configuration in
Sunny Portal.
1
Page 41
SMA Solar Technology AG 7 Connection
Installation Manual HoMan-IA-en-17 41
7.3 Replacing Energy Meters
1. Decommission the energy meter to be replaced (see energy meter manual).
2. If the SMA Energy Meter is replaced, note the serial number of the new SMA Energy Meter.
The serial number is to be found on the type label of the SMA Energy Meter.
3. When replacing the SMA Energy Meter, or if the new energy meter with S0 interface has a
different pulse rate from the old energy meter with S0 interface, configure the new energy meter
in Sunny Portal (see user manual of the Sunny Home Manager).
7.4 Connecting the Sunny Home Manager to the Router
1. Connect the network cable to the network terminal
of the Sunny Home Manager. If using a different
network cable to that supplied with the delivery,
the cable must be suitable for connection to the
Sunny Home Manager (for cable requirements,
see Section 4.1.4).
2. Connect the other end of the network cable to the router.
7.5 Connecting a Device to be Controlled via a Data Exchange
Protocol
Devices controlled by the Sunny Home Manager via a data exchange protocol are not connected to
SMA radio-controlled sockets, but are connected to the Sunny Home Manager via the local network.
The Sunny Home Manager communicates with the devices either directly or via a corresponding
gateway. For the purposes of load control, the Sunny Home Manager sends the devices
recommendations on their power requirement or operating mode.
Requirements:
☐ The device must support the data exchange protocol defined by SMA Solar Technology AG.
☐ The Sunny Home Manager must be located in the same local network as the device.
Additionally required material (not included in the scope of delivery):
☐ 1 network cable (for cable requirements, see Section 4.1.4)
Procedure
1. Connect the network cable to the device (see device manual).
2. Connect the other end of the network cable to the router or network switch.
☑ The device is automatically recognized by the Sunny Home Manager. Once you have added
the device to the Sunny Home Manager system via the configuration wizard in Sunny Portal,
the Sunny Home Manager will control the device automatically via the defined data exchange
protocol.
Page 42
7 Connection SMA Solar Technology AG
42 HoMan-IA-en-17 Installation Manual
7.6 Supplying the Sunny Home Manager with Voltage
7.6.1 Supplying the Sunny Home Manager with Voltage via the
Plug-In Power Supply
1. Connect the DC plug of the plug-in power supply to the Power connector of the
Sunny Home Manager.
2. Plug the plug-in power supply into the outlet.
☑ The status LED of the Sunny Home Manager first glows red, and then flashes red.
After approximately two minutes, the status LED intermittently flashes green and orange.
The Sunny Home Manager is connected to Sunny Portal.
✖ The status LED is not intermittently flashing green and orange?
It is possible that the Sunny Home Manager is not correctly connected to the router.
• Ensure that the Sunny Home Manager is correctly connected to the router
(see Section 7.4).
7.6.2 Supplying the Sunny Home Manager with Voltage via the
Top-Hat Rail Power Supply
As an alternative to the plug-in power supply, you can supply the Sunny Home Manager with voltage
using a top-hat rail power supply.
Additionally required accessories (not included in scope of delivery):
☐ Top-hat rail power supply
☐ 1 AC connection cable
☐ 1 cable for connecting the top-hat rail power supply to the Sunny Home Manager
Requirements for the top-hat rail power supply:
☐ Output voltage DC: 12 V (tolerance: ± 10%)
☐ Nominal current: 1.5 A
Requirements for the cable used for connection of the top-hat rail power supply to the
Sunny Home Manager:
☐ Conductor cross-section: 0.2 mm2 to 1.5 mm
2
☐ Cable with at least 2 insulated conductors
Procedure
1. Mount the top-hat rail power supply on the top-hat rail (see manual of the top-hat rail power
supply).
2. Connect the cable for the Sunny Home Manager to the top-hat rail power supply (see manual
of the top-hat rail power supply). Shorten the unused insulated conductors flush with the cable
shield.
Page 43
SMA Solar Technology AG 7 Connection
Installation Manual HoMan-IA-en-17 43
3. Write down the color of the insulated conductors:
4. Remove 4 cm of the cable sheath at the other end of the cable.
5. Shorten the cable shield to approximately 5 mm.
Fold the surplus cable shield back onto the cable
sheath.
6. Shorten unused insulated conductors flush with the
cable sheath.
7. Strip the insulated conductors by 6 mm.
8. Release the pin connectors of the four-pole plug
with a screwdriver. Insert the DC − insulated
conductor into contact pin 3 and the DC+ insulated
conductor into contact pin 4 of the four-pole plug.
9. If no energy meter is connected to the four-pole
plug, insert the four-pole plug into the lower contact
pin row of any one of the pin connectors on the
Sunny Home Manager.
10. If an energy meter is connected to the four-pole
plug, insert the four-pole plug into the lower contact
pin row of the pin connector assigned to the given
energy meter (see Section7.1 "Connection Area",
page34).
11. Connect the AC connection cable to the top-hat rail power supply (see manual of the top-hat
rail power supply).
Terminals on the top-hat rail
power supply
Insulated conductor color
DC+
DC −
Page 44
7 Connection SMA Solar Technology AG
44 HoMan-IA-en-17 Installation Manual
13. Connect the other end of the AC connection cable to the electricity supply.
14. Connect the connection point to the utility grid.
☑ The status LED first glows red and then flashes red. After approximately two minutes,
the status LED intermittently flashes green and orange.
✖ The status LED is not intermittently flashing green and orange?
It is possible that the Sunny Home Manager is not correctly connected to the router.
• Ensure that the Sunny Home Manager is correctly connected to the router
(see Section 7.4).
12.
%"/(&3
Danger to life due to electric shock
Lethal voltages are present at the connection point of the utility grid.
• Disconnect the connection point from the utility grid via the disconnector (e.g. in the
distribution board).
Page 45
SMA Solar Technology AG 8 Commissioning
Installation Manual HoMan-IA-en-17 45
8 Commissioning
8.1 Establishing a Connection to Sunny Portal
Requirements:
☐ DHCP must be activated on the router (see router manual). If your router does not support
DHCP, you can configure the static network settings on the Sunny Home Manager using the
Sunny Home Manager Assistant (see Section9.4, page62).
☐ The Sunny Home Manager must be connected to the router (see Section7.4, page41).
☐ The Sunny Home Manager must be supplied with voltage (see Section7.6, page42).
The Sunny Home Manager automatically establishes a connection to Sunny Portal. As soon as the
status LED is intermittently flashing green and orange (after approximately two minutes), you can
register the Sunny Home Manager in Sunny Portal (see Section8.2, page45).
If the status LED is continuously flashing red, the Sunny Home Manager cannot automatically
establish the connection to Sunny Portal. This is the case, for example, if there is a proxy server in your
network or if your router does not support DHCP.
• If the status LED is continuously flashing red or you have to manually configure the IP address
in your network, use the Sunny Home Manager Assistant (see Section9.4, page62).
8.2 Registering in Sunny Portal
Sunny Portal is the user interface of the Sunny Home Manager. Therefore, you must register the
Sunny Home Manager in Sunny Portal.
Requirements:
☐ The status LED of the Sunny Home Manager must be intermittently flashing green and orange
(see Section8.1 "Establishing a Connection to Sunny Portal", page45).
☐ The PV system must be in operation.
– The same NetID must be set for all BLUETOOTH devices.
– The BLUETOOTH PV system must be in operation.
– The Speedwire devices must be in operation and connected to the Sunny Home Manager
via a router/network switch.
–NetID 0 must be set for Speedwire devices with integrated BLUETOOTH interface.
Procedure
• Start the PV System Setup Assistant.
• Register as a new user in the Sunny Portal.
or
Log in to Sunny Portal as an existing user.
• Register Sunny Home Manager system in Sunny Portal.
• Configure the energy meter.
• Enter the PV system data.
Page 46
8 Commissioning SMA Solar Technology AG
46 HoMan-IA-en-17 Installation Manual
Tip: If you have SMA radio-controlled sockets, insert these into outlets and configure the NetID of the
PV system (see Section5.1.3 "Configuring the NetID on the SMA Radio-Controlled Socket",
page29). This will enable you to register the SMA radio-controlled sockets together with the
Sunny Home Manager.
Starting the PV System Setup Assistant
The PV System Setup Assistant is a step-by-step guide of the processes required for user registration
and the registration of Sunny Home Manager systems in Sunny Portal.
Procedure
1. Open www.SunnyPortal.com and select [PV System Setup Assistant].
or
Go to www.SunnyPortal.com/Register.
☑ The PV System Setup Assistant opens.
2. Select [Next].
☑The page User registration opens.
Registering as a New User in Sunny Portal
1. Activate the field I am not yet registered and select [Next].
2. Enter the necessary data for registration.
3. Select [Next].
☑ After a few minutes you will receive an e-mail containing a link and your access data to
Sunny Portal.
✖ No e-mail received from Sunny Portal?
The e-mail may have been automatically redirected to your spam mail folder.
• Check whether the e-mail is in the spam mail folder.
You may have stated a different e-mail address.
• Check whether the e-mail was sent to another e-mail address.
• If the other e-mail address is an unknown address, restart the PV System Setup Assistant
and register as a new user again.
4. Follow the link in the confirmation e-mail within 24 hours.
☑ Sunny Portal opens a separate window to confirm successful registration.
• Select [Next].
•The page Select PV system opens.
Page 47
SMA Solar Technology AG 8 Commissioning
Installation Manual HoMan-IA-en-17 47
Logging in as an Existing User in Sunny Portal
Requirement:
☐ You must already have one PV system in Sunny Portal.
Procedure
1. Select the field I am already registered in Sunny Portal.
2. Enter the e-mail address and the Sunny Portal password in the fields E-mail address and
Password.
3. Select [Next].
☑The page Select PV system opens.
Registering a Sunny Home Manager System in Sunny Portal
All devices with an identical password and NetID form a system. Therefore, a uniform password for
all devices in a system is called a system password. The system password is the same as the device
password for the user group Installer.
Requirements:
☐ The BLUETOOTH LED on the inverter or BLUETOOTH Piggy-Back must be glowing blue.
☐ Either a uniform user-defined system password or the factory-set standard password 1111 must
be set on all BLUETOOTH and Speedwire devices for the user group Installer. If necessary,
set a uniform system password for all BLUETOOTH and Speedwire devices (see Sunny Explorer
Help).
Procedure
1. Activate the field Create a new PV system and enter a system name
(e.g. My Sunny Home Manager system).
2. In the window for entering the system password, enter the system password of the user role
Installer:
• If the standard password 1111 is still set on all devices for the user group Installer,
enter a new system password.
• If a different uniform password has already been set on all devices, enter this password as
the system password.
• If a uniform password has not been set on all devices, set a uniform password for the user
group Installer using the Sunny Explorer software (see Sunny Explorer help) and enter this
password in the PV System Setup Assistant as the system password.
3. Enter the system password again in the field Repeat password.
4. Select [Next].
☑The page Select devices opens.
5. Enter the serial number of the Sunny Home Manager in the PIC field. Enter the registration ID
of the Sunny Home Manager in the RID field.
Page 48
8 Commissioning SMA Solar Technology AG
48 HoMan-IA-en-17 Installation Manual
6. Select [Identify].
☑ Sunny Portal searches for the Sunny Home Manager with the corresponding serial number
and registration ID. The PV System Setup Assistant displays the correct
Sunny Home Manager with a green tick.
✖ The PV System Setup Assistant cannot find any Sunny Home Manager with the entered
serial number and registration ID?
• See troubleshooting (see Section9 "Troubleshooting", page52).
7. Select [Next].
☑ The Sunny Home Manager now searches for BLUETOOTH devices within range and for
devices in the local network. After a maximum of ten minutes the PV System Setup Assistant
lists the serial numbers of any available BLUETOOTH devices and devices in the local
network.
✖ The PV System Setup Assistant is unable to establish a connection to the
Sunny Home Manager, the BLUETOOTH devices within range or the Speedwire devices?
or
✖ The PV System Setup Assistant lists none or not all of the BLUETOOTH devices or Speedwire
devices in your PV system?
• Select [Refresh]. If the PV System Setup Assistant continues to list none or not all of the
BLUETOOTH and Speedwire devices, see troubleshooting (see Section9.3 "Errors
during Registration in Sunny Portal", page56).
or
✖ The PV System Setup Assistant lists own and third-party devices?
• See troubleshooting (see Section9.3 "Errors during Registration in Sunny Portal",
page56).
8. Activate the checkboxes of the devices you wish to add to the Sunny Home Manager system.
Tip: You can identify devices using the previously noted serial numbers.
9. Select [Add] to add the devices to the Sunny Home Manager system immediately.
☑ The system password is transferred to the devices. This process can take several minutes.
The devices are then shown with a green tick: .
✖ Some devices are shown with the warning symbol: ?
Sunny Home Manager cannot access the devices. You may have entered an invalid system
password or the connection to the devices could not be established.
• See troubleshooting (see Section9.3 "Errors during Registration in Sunny Portal",
page56).
Select [Next].
☑The window Meter configuration opens.
or
10. Select [Skip forward] to add the devices to the Sunny Home Manager system at a later time
and continue with registration. Tip: You can add the devices to the Sunny Home Manager
system as new devices after registration (see user manual "SUNNY HOME MANAGER in
Sunny Portal").
☑The window Meter configuration opens.
Page 49
SMA Solar Technology AG 8 Commissioning
Installation Manual HoMan-IA-en-17 49
Configuring Energy Meters
1. If energy meters are connected to the Sunny Home Manager, select the energy meter type
connected to the respective meter input in the drop-down lists Meter input 1, Meter input 2
and Meter input 3:
2. Select [Next].
☑The page Extended PV System Properties opens.
Entering PV System Data
1. Enter the PV system data.
2. Select [Next].
☑ The PV System Setup Assistant shows a summary of your entered data.
3. Select [Finish].
☑ Sunny Portal confirms successful registration of the Sunny Home Manager system in a
separate window.
4. To change to the Sunny Home Manager system, select [To the PV system].
☑ The Sunny Home Manager system opens.
5. Enter the system properties (see user manual "Sunny Home Manager in Sunny Portal").
Connected energy meter type Drop-down list
Energy meter with D0 Interface • Select D0.
Bidirectional meter with D0 interface • Select D0.
• Activate the field Bidirectional meter
(consumption and feed-in).
☑The area Meter input 2 is not
available.
Energy meter with S0 interface • Select S0.
•In the text field S0 pulses/kWh, specify
the pulse rate of the energy meter
(see energy meter manual).
SMA Energy Meter • Select SMA Energy Meter xxx.
The placeholder for the SMA Energy
Meter serial number is xxx. If there are
two SMA Energy Meters in the PV system,
select the desired SMA Energy Meter.
• Activate the checkbox Bidirectional
meter (consumption and feed-in).
No energy meter • Select no meter.
Page 50
8 Commissioning SMA Solar Technology AG
50 HoMan-IA-en-17 Installation Manual
8.3 Setting the Operating Mode of the SMA Radio-Controlled
Socket
You can configure the operating mode of the SMA radio-controlled socket via the touch key on the
SMA radio-controlled socket or via Sunny Portal (see user manual "SUNNY HOME MANAGER in
Sunny Portal").
Requirements:
☐ The SMA radio-controlled socket must be inserted in an outlet.
☐ The upper horizontal LED must be glowing orange or green.
Procedure
Operating mode Explanation
Automatic The SMA radio-controlled socket is controlled by the
Sunny Home Manager. Depending on the current control command of the
Sunny Home Manager, the SMA radio-controlled socket is either
switched on or off in this mode.
• On: The connected load can draw electric current.
• Off: The connected load cannot draw electric current.
Manually switched on The SMA radio-controlled socket is switched on. The connected load can
draw electric current.
The SMA radio-controlled socket is not controlled by the
Sunny Home Manager.
Manually switched off The SMA radio-controlled socket is switched off. The connected load
cannot draw electric current.
The SMA radio-controlled socket is not controlled by the
Sunny Home Manager.
1.
Requirement for "Automatic" mode
You can only set Automatic mode if you have configured the SMA radio-controlled
socket for the connected load in Sunny Portal.
• If the SMA radio-controlled socket was not registered together with the
Sunny Home Manager in Sunny Portal, add the SMA radio-controlled socket to the
system as a new device (see user manual "SUNNY HOME MANAGER in
Sunny Portal").
Page 51
SMA Solar Technology AG 8 Commissioning
Installation Manual HoMan-IA-en-17 51
2. Keep tapping the touch key until the upper horizontal LED displays the desired operating mode:
3. To adopt the operating mode, wait approximately one second. Do not tap the touch key.
☑ After approximately two seconds, the SMA radio-controlled socket audibly switches to the
selected operating mode.
Operating mode LED status
Manually switched on Glowing green
Automatic Off (subsequently flashing orange)
Manually switched off Glowing orange
Page 52
9 Troubleshooting SMA Solar Technology AG
52 HoMan-IA-en-17 Installation Manual
9 Troubleshooting
9.1 Errors in the Sunny Home Manager
9.1.1 States of All LEDs
9.1.2 States of the Status LED
LED status Cause and corrective measures
Off The Sunny Home Manager does not have voltage supply.
Corrective measures:
• Supply the Sunny Home Manager with voltage (see Section 7.6).
LED status Cause and corrective measures
Glowing red The system is starting.
Corrective measures:
• Do not disconnect the Sunny Home Manager from the voltage
supply.
If the status persists: Error.
Corrective measures:
• Disconnect the Sunny Home Manager from the voltage supply and
then reconnect (see Section 7.6).
• If the status persists, contact the SMA Service Line.
Flashing red The Sunny Home Manager cannot establish a connection to Sunny Portal.
It is possible that there is a proxy server in your network or DHCP is not
activated in your router.
Corrective measures:
• Use the Sunny Home Manager Assistant (see Section 9.4).
The Sunny Home Manager cannot establish a connection to Sunny Portal.
It is possible that the Sunny Home Manager is not correctly connected to
the router.
Corrective measures:
• Ensure that the Sunny Home Manager is correctly connected to the
router (see Section 7.4).
• If the Sunny Home Manager is correctly connected to the router and
the status LED continues to flash red, perform a complete reset of the
Sunny Home Manager (see Section 9.6).
Page 53
SMA Solar Technology AG 9 Troubleshooting
Installation Manual HoMan-IA-en-17 53
Flashing green and
orange intermittently
The Sunny Home Manager is connected to Sunny Portal, but is not yet
registered in Sunny Portal.
Corrective measures:
• Register the Sunny Home Manager in Sunny Portal
(see Section 8.2).
Flashing green The Sunny Home Manager is connected to the devices of the PV system
and to Sunny Portal. There is an event type Error present in at least one
device or at least one device is not connected to the
Sunny Home Manager (event type Disturbance).
Corrective measures:
• Call up the event in the system log book of Sunny Portal (see user
manual "Sunny Home Manager in Sunny Portal").
In the case of an event type Error, look up the meaning of the error
in the manual of the affected device.
Glowing orange The Sunny Home Manager has not been connected to Sunny Portal for at
least ten minutes.
There are no new events in the cache of the Sunny Home Manager.
Corrective measures:
• If the status persists, check the connection status using the
Sunny Home Manager Assistant (see Section9.4, page62).
LED status Cause and corrective measures
Page 54
9 Troubleshooting SMA Solar Technology AG
54 HoMan-IA-en-17 Installation Manual
9.1.3 States of the BLUETOOTH LED
Flashing red and
orange intermittently
The Sunny Home Manager has not been connected to Sunny Portal for at
least ten minutes.
There is an event type Error present in at least one device or at least one
device is not connected to the Sunny Home Manager (event type
Disturbance).
The event and the data read out cannot be sent to Sunny Portal. The event
and the data are cached in the Sunny Home Manager.
Corrective measures:
• Ensure that the Sunny Home Manager is correctly connected to the
router (see Section 7.4).
• Check whether the Internet connection is functioning:
• In the web browser address line, enter e.g.
www.SMA-Solar.com and confirm with the [Enter] key.
• If the Internet connection is permanently impaired, ensure that
the router is functioning correctly. If necessary, contact the
Internet service provider and read off the device errors present
on the inverter display (see inverter manual).
• Once the Sunny Home Manager is reconnected to Sunny Portal, call
up the event in the Sunny Portal system log book (see user manual
"SUNNY HOME MANAGER in Sunny Portal").
LED status Cause and corrective measures
Flashing blue The BLUETOOTH connection to the devices of the PV system is critical.
Corrective measures:
• If possible, select a different mounting location and check the
connection.
• If no other mounting location is possible, use an
SMA BLUETOOTH Repeater or an SMA radio-controlled socket.
This will extend the wireless range of your BLUETOOTH network.
LED status Cause and corrective measures
Page 55
SMA Solar Technology AG 9 Troubleshooting
Installation Manual HoMan-IA-en-17 55
9.2 Errors in the SMA Radio-Controlled Socket
States of the Lower Horizontal LED
Off There is no BLUETOOTH connection to the devices of the PV system.
Corrective measures:
• Commission the SMA BLUETOOTH devices.
• For inverters with BLUETOOTH Piggy-Back: wait until the inverters
switch on.
It is possible that the NetID configured on the Sunny Home Manager is not
identical with that of the PV system devices.
Corrective measures:
• Ensure that the same NetID is configured on the
Sunny Home Manager and the devices of the PV system
(see Section5.1.3, page29).
There may already be more than one additional master in your
BLUETOOTH network (e.g. Sunny Beam and computer with Sunny
Explorer). As a result, the Sunny Home Manager cannot establish a
connection to the BLUETOOTH devices.
Corrective measures:
• Together with the Sunny Home Manager, use a maximum of one
additional master in the BLUETOOTH network.
LED status Cause and corrective measures
Flashing blue The BLUETOOTH connection to the Sunny Home Manager is critical.
Corrective measures:
• If possible, select a different mounting location.
• If no other mounting location is possible, use an
SMA BLUETOOTH Repeater or an additional SMA radio-controlled
socket. This will extend the wireless range of your BLUETOOTH
network.
LED status Cause and corrective measures
Page 56
9 Troubleshooting SMA Solar Technology AG
56 HoMan-IA-en-17 Installation Manual
9.3 Errors during Registration in Sunny Portal
Off There is no BLUETOOTH connection between the SMA radio-controlled
socket and the Sunny Home Manager.
Corrective measures:
• Ensure that the Sunny Home Manager is supplied with voltage
(see Section 7.6).
• Ensure that the same NetID is configured on the
SMA radio-controlled socket and the Sunny Home Manager
(see Section5.1.3, page29).
• If possible, select a different mounting location.
• If no other mounting location is possible, use an
SMA BLUETOOTH Repeater or an additional SMA radio-controlled
socket. This will extend the wireless range of your BLUETOOTH
network.
Problem Cause and corrective measures
The PV System Setup Assistant
cannot establish a connection
to the Sunny Home Manager.
It is possible that the Sunny Home Manager is not correctly
connected to the router.
or
It is possible that the Sunny Home Manager does not have
voltage supply. In this case, all LEDs on the
Sunny Home Manager will be off.
Corrective measures:
• Ensure that the Sunny Home Manager is correctly
connected to the router (see Section 7.4).
• Ensure that the Sunny Home Manager is supplied with
voltage (see Section7.6, page42).
• Contact the SMA Service Line if the Sunny Home Manager
is correctly connected to the router and is supplied with
voltage but all LEDs remain off.
The PV System Setup Assistant
lists none or not all of the
BLUETOOTH devices in your PV
system.
The NetID of the PV system may not be configured on certain
devices.
Corrective measures:
• Ensure that the NetID of the system is set on all devices.
LED status Cause and corrective measures
Page 57
SMA Solar Technology AG 9 Troubleshooting
Installation Manual HoMan-IA-en-17 57
The PV System Setup Assistant
lists none or not all of the
BLUETOOTH devices in your PV
system.
The wireless connection of several devices may be disturbed by
ambient conditions.
Corrective measures:
• Ensure that the connection quality for the BLUETOOTH
devices is at least "good" (see BLUETOOTH device
manuals).
• If the connection quality is not at least "good", use a
BLUETOOTH repeater or SMA radio-controlled socket.
This will extend the wireless range of your BLUETOOTH
network.
Inverters with BLUETOOTH Piggy-Back shut down overnight.
For this reason, the Sunny Home Manager cannot establish a
connection to these inverters during this time.
Corrective measures:
• Select [Skip forward] and continue with registration.
After registration, add devices to the system as new devices
when there is sufficient irradiation (see user manual
"SUNNY HOME MANAGER in Sunny Portal").
The devices of your PV system may not be commissioned. In this
case, the Sunny Home Manager cannot establish a connection to
these devices.
Corrective measures:
• Commission the devices.
Insufficient radio range of the inverter with BLUETOOTH
communication interface.
Corrective measures:
• Use SMA BLUETOOTH Repeater or SMA radio-controlled
socket. This will extend the wireless range of your
BLUETOOTH network.
Insufficient transmission power of the inverter with
SMA BLUETOOTH Piggy-Back Plus
Corrective measures:
• Use the antenna extension add-on kit "ANTEXTKIT25-10".
Problem Cause and corrective measures
Page 58
9 Troubleshooting SMA Solar Technology AG
58 HoMan-IA-en-17 Installation Manual
The PV System Setup Assistant
lists none or not all of the
BLUETOOTH devices in your PV
system.
Sunny Home Manager is too far from your PV system or the
BLUETOOTH connection is interrupted. This could be due to walls
or ceilings that absorb the radio waves.
Corrective measures:
• Mount the Sunny Home Manager closer to a device in your
system. If this is not possible, use SMA BLUETOOTH
Repeater, SMA BLUETOOTH Repeater Outdoor or SMA
radio-controlled socket with BLUETOOTH. This bridges the
dead zone.
Problem Cause and corrective measures
The PV System Setup Assistant
lists none or not all of the new
SMA devices that are
connected via Speedwire.
It is possible that the SMA device is not correctly connected to the
router or is not supplied with voltage.
Corrective measures:
• Ensure that the SMA device is correctly connected to the
router and supplied with voltage (see manual of the
SMA device).
The SMA device is already registered in Sunny Portal via
Webconnect.
Corrective measures:
• Delete the SMA device from the Webconnect system or
deactivate the data reception of the device in the
Webconnect system.
For Speedwire devices with integrated BLUETOOTH interface:
It is possible that the communication via BLUETOOTH is not
deactivated.
Corrective measures:
•Set NetID 0 on the Speedwire device with BLUETOOTH
interface. This deactivates communication via BLUETOOTH.
The SMA device is no longer in the same local network as the
Sunny Home Manager.
Corrective measures:
• Connect the SMA device to the same router/network switch
as the Sunny Home Manager.
Problem Cause and corrective measures
Page 59
SMA Solar Technology AG 9 Troubleshooting
Installation Manual HoMan-IA-en-17 59
The PV System Setup Assistant
lists none or not all of the new
SMA devices that are
connected via Speedwire.
The network cable that connects the SMA device to the router/
network switch is not suitable for 100 MBit/s.
Corrective measures:
• Use a network cable suitable for Speedwire (for the network
cable requirements, see the manual of the Speedwire
device).
DHCP is not activated in your router.
Corrective measures:
•Activate DHCP in the router.
• If your router does not support DHCP, configure the static
network settings on the Speedwire device using SMA
Connection Assist. You can obtain the SMA Connection
Assist software free of charge from the download area at
www.SMA-Solar.com.
The router/network switch used in the network deactivates the
LAN ports when they appear to be inactive in order to save
energy. As a result, it is not possible to establish any connection
to the SMA device.
Corrective measures:
• Configure the router/network switch so that the LAN ports
are not deactivated.
The network switch used in the network uses IGMP snooping.
This means that the connection to the SMA device is disconnected
if it appears to be inactive and cannot be subsequently restored.
Corrective measures:
• Deactivate the IGMP snooping function in the network
switch.
The firewall may not have been set up correctly.
Corrective measures:
• Enable ports 9523 and 3478 in the firewall (see firewall
manual).
The firewall or IP filter may not have been set up correctly.
Corrective measures:
• Adjust firewall or IP filter settings (see firewall or router
manual).
Problem Cause and corrective measures
Page 60
9 Troubleshooting SMA Solar Technology AG
60 HoMan-IA-en-17 Installation Manual
The PV System Setup Assistant
lists own and third-party
devices.
A different BLUETOOTH system within radio range of the
Sunny Home Manager is using the same NetID as your
BLUETOOTH system.
Corrective measures:
• Find a free NetID for your system using Sunny Explorer
(see Sunny Explorer help).
• Adjust the new NetID in all devices.
The PV System Setup Assistant
cannot find a Sunny Home
Manager with the serial number
and registration ID entered.
The serial number and/or the registration ID may have been
entered incorrectly.
Corrective measures:
• Ensure that the entries are correct.
It is possible that the registration procedure was previously
initiated but not completed.
Corrective measures:
• Perform a complete reset of the Sunny Home Manager
(see Section 9.6).
It is possible that the Sunny Home Manager is not correctly
connected to the router.
Corrective measures:
• Ensure that the Sunny Home Manager is correctly
connected to the router (see Section 7.4).
DHCP is possibly not activated on your router or there is a proxy
server in your network. For this reason, Sunny Home Manager
cannot establish a connection to Sunny Portal.
Corrective measures:
• Establish the connection to Sunny Portal using the
Sunny Home Manager Assistant (see Section9.4,
page62).
The Sunny Home Manager has already been assigned to a
system in Sunny Portal with your e-mail address.
Corrective measures:
• Delete the Sunny Home Manager from the system (see user
manual "SUNNY HOME MANAGER in Sunny Portal").
or
• Re-register the Sunny Home Manager with the PV System
Setup Assistant (see Section9.7, page64).
Problem Cause and corrective measures
Page 61
SMA Solar Technology AG 9 Troubleshooting
Installation Manual HoMan-IA-en-17 61
The PV System Setup Assistant
cannot find a Sunny Home
Manager with the serial number
and registration ID entered.
The Sunny Home Manager is assigned to a different system in
Sunny Portal, for instance, if you have bought the Sunny Home
Manager second-hand.
Corrective measures:
• If possible, contact the previous owners and ask them to
delete the Sunny Home Manager system in Sunny Portal.
or
• Contact the SMA Service Line.
After you have entered the
system password, some devices
are shown with a warning
symbol in the PV System Setup
Assistant.
The devices with warning symbols are inverters with BLUETOOTH
Piggy-Back. These inverters switch off after dark. For this reason,
the Sunny Home Manager cannot access the inverters at this time.
Corrective measures:
1. Select [Skip forward] in the PV System Setup Assistant and
finish registration without selecting the inverters.
2. Once there is daylight and the inverters are switched on, log
in to Sunny Portal and add the inverters as new devices to
the Sunny Home Manager system using the configuration
wizard (see user manual "SUNNY HOME MANAGER in
Sunny Portal").
There is a different installer password configured in the devices
with warning symbols.
Corrective measures:
1. Select [Skip forward] in the PV System Setup Assistant and
finish registration without selecting the devices.
2. Set a uniform installer password for all devices using the
Sunny Explorer software (see Sunny Explorer help).
3. If you do not know the password set on each device, apply
for a Personal Unlocking Key (PUK) for each device from
the SMA Service Line.
4. Use Sunny Explorer to enable each device with the
corresponding PUK. Then set a uniform installer password in
all devices (see Sunny Explorer Help).
5. Log in to Sunny Portal and add the devices to the Sunny
Home Manager system as new devices using the
configuration wizard (see user manual "SUNNY HOME
MANAGER in Sunny Portal").
Problem Cause and corrective measures
Page 62
9 Troubleshooting SMA Solar Technology AG
62 HoMan-IA-en-17 Installation Manual
9.4 Using the Sunny Home Manager Assistant
The Sunny Home Manager Assistant will help you configure the Sunny Home Manager for your
network if it does not automatically connect to Sunny Portal.
In addition, you can use the Sunny Home Manager Assistant to display the latest connection status to
Sunny Portal, the network settings and the connected BLUETOOTH devices, and save these as a log
file. If servicing should be necessary, the SMA Service Line can use this log file to analyze the
problem.
Procedure
1. Use a network cable to connect the computer to the router to which the Sunny Home Manager
is connected.
2. In the download area at www.SMA-Solar.com, download the Sunny Home Manager Assistant
for the operating system of your computer.
or
Insert the CD provided into the drive of your computer.
3. Start the Sunny Home Manager Assistant by double-clicking on the file name.
4. Follow the instructions given in the Sunny Home Manager Assistant.
9.5 Error in the Sunny Home Manager Assistant
While the PV System Setup
Assistant is performing the
device search, the status LED of
the Sunny Home Manager first
flashes red for one to two
minutes . After this, the status
LED glows green again.
Device detection takes a few minutes longer.
Corrective measures:
• No measures are required.
Problem Cause and corrective measures
The Sunny Home Manager
Assistant does not detect a
Sunny Home Manager.
The computer with the Sunny Home Manager Assistant is not
connected to the router to which the Sunny Home Manager is
connected.
Corrective measures:
• Connect the computer with the Sunny Home Manager
Assistant to the router to which the Sunny Home Manager is
connected.
Problem Cause and corrective measures
Page 63
SMA Solar Technology AG 9 Troubleshooting
Installation Manual HoMan-IA-en-17 63
9.6 Resetting the Sunny Home Manager
The reset button is located in a small aperture on the bottom of the Sunny Home Manager.
Depending on how long you hold down the reset button, the Sunny Home Manager is partially or
completely reset.
Procedure
• Press the reset button with a sharp object (e.g.
paper clip) and hold until the desired reset result
has been achieved:
• To reset the network settings of the
Sunny Home Manager, press the reset button
until the s tatus LED and the energy consumption
LED are intermittently flashing orange.
• To completely reset the Sunny Home Manager,
press the reset button until the status LED and
the energy consumption LED are intermittently
flashing red.
Duration Result Status of the status LED and the
energy consumption LED
1 to 5 seconds ☑ The network settings of the
Sunny Home Manager are
reset.
Flashing orange intermittently
5 to 10 seconds The Sunny Home Manager is
completely reset:
☑ All settings of the Sunny Home
Manager are deleted.
☑ All cached PV system data
(energy values, events, etc.) are
deleted.
☑ The Sunny Home Manager
redetects the BLUETOOTH
devices located within range.
☑ The Sunny Home Manager must
be re-registered in Sunny Portal
(see Section9.7, page64).
Flashing red intermittently
Page 64
9 Troubleshooting SMA Solar Technology AG
64 HoMan-IA-en-17 Installation Manual
9.7 Reassigning the Sunny Home Manager after Resetting the
Sunny
Home Manager System
If you have performed a complete reset of the Sunny Home Manager (see Section 9.6), you must
reassign the Sunny Home Manager to your Sunny Home Manager system in Sunny Portal. Otherwise,
Sunny Portal will not accept any data from the Sunny Home Manager.
You have the following options for reassigning the Sunny Home Manager to your
Sunny Home Manager system:
• Reassign the Sunny Home Manager via the PV System Setup Assistant.
or
• Reassign the Sunny Home Manager via the Sunny Portal access (see user manual
"SUNNY HOME MANAGER in Sunny Portal").
Reassigning the Sunny Home Manager to the Sunny Home Manager System via
the PV System Setup Assistant
Requirement:
☐You must be the PV system administrator (for user roles and user rights, see user manual
"SUNNY HOME MANAGER in Sunny Portal").
Procedure
1. Open www.SunnyPortal.com and select the PV System Setup Assistant.
or
Go to www.SunnyPortal.com/Register.
☑ The PV System Setup Assistant opens.
2. Select [Next].
☑The page User registration opens.
3. Activate the checkbox I am already registered in Sunny Portal.
4. Enter the e-mail address and the Sunny Portal password in the fields E-mail address and
Password.
5. Select [Next].
☑The page Select PV system opens.
6. Activate the field Add or replace devices.
7. In the line of the Sunny Home Manager system to which you would like to reassign the
Sunny Home Manager, select .
8. Select [Next].
☑The page Select devices opens.
Page 65
SMA Solar Technology AG 9 Troubleshooting
Installation Manual HoMan-IA-en-17 65
9. Enter the serial number of the Sunny Home Manager in the PIC field. Enter the registration ID
of the Sunny Home Manager in the RID field.
10. Select [Identify].
☑ Sunny Portal checks whether the serial number and registration ID correspond to the
connected Sunny Home Manager.
✖ The PV System Setup Assistant cannot find any Sunny Home Manager with the serial
number and registration ID?
An error has occurred.
• Rectify the error (see Section9 "Troubleshooting", page52).
11. Select [Next].
12. Select [Finish].
9.8 Resetting the SMA Radio-Controlled Socket to Default Settings
You must reset the SMA radio-controlled socket to default settings in the following cases:
• You wish to operate the SMA radio-controlled socket in a different system.
• You wish to reset the measured values of the SMA radio-controlled socket.
Procedure
1. Unplug the SMA radio-controlled socket from the outlet and then plug it back in.
☑ The upper horizontal LED glows red for approximately ten seconds.
2. As soon as the vertical LEDs are glowing green, press and hold the touch key for five seconds.
Do not release the key until the upper horizontal LED is glowing red.
☑ The NetID is reset to 0.
☑ The measured values are reset.
☑ The system password is reset to the standard password of 1111 for the user group
Installer.
Reading off the serial number and registration ID
You can read off the serial number and the registration ID at the following locations:
• On the type label at the back of the Sunny Home Manager
• On the cover of the supplied CD
Page 66
10 Decommissioning SMA Solar Technology AG
66 HoMan-IA-en-17 Installation Manual
10 Decommissioning
10.1 Disassembling the Sunny Home Manager
1. If the Sunny Home Manager is supplied with voltage via the plug-in power supply:
• Pull the plug-in power supply out of the outlet.
• Unplug the DC plug of the plug-in power supply from the Power terminal of the
Sunny Home Manager.
2. If the Sunny Home Manager is supplied with voltage via a top-hat rail power supply:
3. Unplug the connection plugs of the energy meters from the pin connector on the
Sunny Home Manager.
4. Unplug the network cable from the network terminal of the Sunny Home Manager.
5. Unplug the other end of the network cable from the router.
6. If the Sunny Home Manager is mounted on the wall, push the Sunny Home Manager upwards
and remove it from the wall.
7. If the Sunny Home Manager is mounted on a top-hat rail, remove the Sunny Home Manager
from the top-hat rail as follows:
• Press the Sunny Home Manager down.
To to this, tilt the lower edge of the Sunny Home
Manager forwards and remove from the
top-hat rail.
%"/(&3
Danger to life due to electric shock
Lethal voltages are present at the connection point of the utility grid.
• Disconnect the connection point from the utility grid via the disconnector
(e.g. in the distribution board).
• Unplug the connection plug of the top-hat rail power supply from the pin connector on
the Sunny Home Manager.
Page 67
SMA Solar Technology AG 10 Decommissioning
Installation Manual HoMan-IA-en-17 67
10.2 Packing the Sunny Home Manager/SMA Radio-Controlled
Socket for Shipping
• Pack the device for shipment. Use the original packaging or packaging that is suitable for the
weight and size of the device (see Section11 "Technical Data", page68).
10.3 Disposing of the Sunny Home Manager/SMA
Radio-Controlled Socket
• Dispose of the device in accordance with the locally applicable disposal regulations for
electronic waste.
Page 68
11 Technical Data SMA Solar Technology AG
68 HoMan-IA-en-17 Installation Manual
11 Technical Data
11.1 Sunny Home Manager
General Data
Status display LEDs
Maximum length of cables to energy meters with
S0 interface
30 m
Maximum length of cables to energy meters with
D0 interface
15 m
Certified countries Australia, Belgium, Germany, France, Italy,
Greece, Great Britain, Canada, Luxembourg,
Portugal, Spain, Czech Republic, Austria,
Switzerland, USA
Mechanical Data
Width x height x depth 170 mm x 124.5 mm x 41.5 mm
Weight 220 g
Voltage Supply
Voltage supply Plug-in power supply, top-hat rail power supply
DC input voltage 12 V
Maximum typical power consumption 6 W
Maximum power consumption 14.3 W
Terminals
Speedwire/Ethernet*
* Data transfer rate 10 Mbit per second or 100 Mbit per second
RJ45
Number of 2 x 4-pole pin connectors for
energy meters
3
Number of USB pin connectors**
** Currently without function
2
Page 69
SMA Solar Technology AG 11 Technical Data
Installation Manual HoMan-IA-en-17 69
Ambient Conditions during Operation
Ambient temperature*
* When using the Sunny Home Manager at temperatures below 0°C and exceeding 40°C: do not use the supplied plug-in
power supply (see Section11.3 "Plug-In Power Supplies", page71). Requirements for the plug-in power supply: 12 V DC,
nominal current: 1.5 A.
− 25°C to +60°C
Relative humidity**
** non-condensing
5% to 95%
Degree of protection***
*** in accordance with IEC 60529
IP20
Maximum altitude above MSL (Mean Sea Level) 2,000 m
Communication Interface to Other Devices
SMA devices BLUETOOTH, Speedwire
Devices controlled via a data exchange protocol Ethernet
Computer Ethernet
Sunny Portal Ethernet
Maximum Range
BLUETOOTH*
* maximum range in free-field conditions
100 m
Ethernet 100 m
Internal Memory
Cache for PV system data 5 days
Number of Devices
Maximum number of SMA devices 16
Maximum number of SMA inverters 12
Maximum number of SMA radio-controlled
sockets
10
Maximum number of devices controlled via a
data exchange protocol
32
Page 70
11 Technical Data SMA Solar Technology AG
70 HoMan-IA-en-17 Installation Manual
11.2 SMA Radio-Controlled Socket
General Data
Status display LEDs
Certified countries Belgium, Germany, France, Greece, Great
Britain, Italy, Luxembourg, Austria, Portugal,
Spain, Czech Republic, Switzerland
Minimum service life*
* when switched at full load (16 A)
20,000 switching cycles
Mechanical Data
Width x height x depth 118 mm x 76 mm x 56 mm
Weight 156 g
Voltage Supply
Voltage 100 V to 240 V
Frequency 50/60 Hz
Maximum current 16 A
Minimum power consumption 0.25 W
Maximum power consumption 1.5 W
Maximum switching power with resistive load 3,680 W
Maximum switching power with lamp load 600 W
Maximum switching power with lagging load
with a displacement power factor of
cos phi > 0.65
1,200 VA
Ambient Conditions during Operation
Ambient temperature − 5°C to +65°C
Relative humidity*
*non-condensing
5% to 95%
Degree of protection**
** in accordance with IEC 60529
IP20
Maximum altitude above MSL 3,000 m
Page 71
SMA Solar Technology AG 11 Technical Data
Installation Manual HoMan-IA-en-17 71
11.3 Plug-In Power Supplies
TaiyTech, TYT251200200UV/3000M
Ambient Conditions for Storage/Transport
Ambient temperature − 25°C to +80°C
Relative humidity*
*non-condensing
5% to 95%
Maximum altitude above MSL 3,000 m
Communication Interface to Other Devices
Sunny Home Manager BLUETOOTH, Speedwire
Maximum Range
BLUETOOTH*
* maximum range in free-field conditions
100 m
Mechanical Data
Width x height x depth 92.0 mm x 58.0 mm x 41.4 mm
Weight 244 g
Voltage Supply
Voltage 100 V AC to 240 V AC
Frequency 50/60 Hz
Maximum current 0.85 A
Ambient Conditions during Operation
Ambient temperature 0°C to +45°C
Page 72
11 Technical Data SMA Solar Technology AG
72 HoMan-IA-en-17 Installation Manual
TaiyTech, TYT251200200EU/3000M
Mechanical Data
Width x height x depth 92.0 mm x 90.6 mm x 36.0 mm
Weight 190 g
Voltage Supply
Voltage 100 V AC to 240 V AC
Frequency 50/60 Hz
Maximum current 0.85 A
Ambient Conditions during Operation
Ambient temperature 0°C to +45°C
Page 73
SMA Solar Technology AG 12 Accessories
Installation Manual HoMan-IA-en-17 73
12 Accessories
You will find the corresponding accessories and spare parts for your product in the following
overview. If required, you can order these from SMA Solar Technology AG or from your distributor.
Designation Brief description SMA order number
Optical probe Cable with optical probe and
four-pole plug for energy meters
with D0 interface
HM-D0-METERADAPTER
SMA radio-controlled socket Radio-controlled socket with
SMA BLUETOOTH Wireless
Technology
BT-SOCKET-10
Page 74
13 Contact SMA Solar Technology AG
74 HoMan-IA-en-17 Installation Manual
13 Contact
If you have technical problems concerning our products, please contact the SMA Service Line.
We require the following information in order to provide you with the necessary assistance:
• Serial number and software package of the Sunny Home Manager
• Serial number and firmware version of the SMA radio-controlled socket
• Name of the Sunny Home Manager system
• Type of energy meters
• Type of optical probes
Australia SMA Australia Pty Ltd.
Sydney
Toll free for
Australia:
1800 SMA AUS
(1800 762 287)
International: +61 2 9491 4200
Belgien/
Belgique/
België
SMA Benelux BVBA/SPRL
Mechelen
+32 15 286 730
Brasil Vide España (Espanha)
Česko SMA Central & Eastern Europe
s.r.o.
Praha
+420 235 010 417
Chile Ver España
Danmark Se Deutschland (Tyskland)
Deutschland SMA Solar Technology AG
Niestetal
Medium Power Solutions
Wechselrichter:
Kommunikation:
+49 561 9522-1499
+49 561 9522-2499
SMA Online Service Center:
www.SMA.de/Service
Hybrid Energy Solutions
Sunny Island: +49 561 9522-399
PV-Diesel
Hybridsysteme:
+49 561 9522-3199
Power Plant Solutions
Sunny Central: +49 561 9522-299
España SMA Ibérica Tecnología Solar,
S.L.U.
Barcelona
Llamada gratuita en
España:
900 14 22 22
Internacional: +34 902 14 24 24
Page 75
SMA Solar Technology AG 13 Contact
Installation Manual HoMan-IA-en-17 75
France SMA France S.A.S.
Lyon
Medium Power Solutions
Onduleurs :
Communication :
+33 472 09 04 40
+33 472 09 04 41
Hybrid Energy Solutions
Sunny Island : +33 472 09 04 42
Power Plant Solutions
Sunny Central : +33 472 09 04 43
India SMA Solar India Pvt. Ltd.
Mumbai
+91 22 61713888
Italia SMA Italia S.r.l.
Milano
+39 02 8934-7299
Κύπρος/
Kıbrıs
Βλέπε Ελλάδα/
Bkz. Ελλάδα (Yunanistan)
Luxemburg/
Luxembourg
Siehe Belgien
Voir Belgique
Magyarország lásd Česko (Csehország)
Nederland zie Belgien (België)
Österreich Siehe Deutschland
Perú Ver España
Polska Patrz Česko (Czechy)
Portugal SMA Solar Technology Portugal,
Unipessoal Lda
Lisboa
Gratuito em
Portugal:
800 20 89 87
Internacional: +351 2 12 37 78 60
România Vezi Česko (Cehia)
Schweiz Siehe Deutschland
Slovensko pozri Česko (Česká republika)
South Africa SMA Solar Technology
South Africa Pty Ltd.
Centurion (Pretoria)
08600 SUNNY
(08600 78669)
International: +27 (12) 643 1785
United
Kingdom
SMA Solar UK Ltd.
Milton Keynes
+44 1908 304899
Ελλάδα SMA Hellas AE
Αθήνα
801 222 9 222
International: +30 212 222 9 222
България Вижте Ελλάδα (Гърция)
Page 76
13 Contact SMA Solar Technology AG
76 HoMan-IA-en-17 Installation Manual
SMA Solar (Thailand) Co., Ltd. +66 2 670 6999
대한민국 SMA Technology Korea Co., Ltd.
서울
+82 2 508-8599
+971 2 234-6177 SMA Middle East LLC
Other
countries
International SMA Service Line
Niestetal
Toll free worldwide: 00800 SMA SERVICE
(+800 762 7378423)
!
Page 77
www.SMA-Solar.com
SMA Solar Technology
Loading...
