Introduction

Electrical Sockets

Q

Introduction

Q

Proper handling

The radio-controlled socket set is suitable
for switching electrical equipment on and
off by remote control. It also supports the
dimmer function for the lamps described
in these instructions. The dimmer radio­controlled socket is not designed for use
with energysaving light bulbs and fluo­rescent lamps. Any alterations to this
device are not in accordance with regu­lations and could represent significant
risk of accidents. The manufacturer does
not accept liability for any damage
caused through the device not being
used in accordance with the regulations.
This device is not intended for commercial
use.

Q

Scope of supply

After you have unpacked this set, please
check to make sure all the contents are
complete.

2 Remote-controlled sockets FSE B 20-A
2 Remote-controlled sockets with

dimmer function FSD B 20-A
1 4-channel remote control FSS B 20-A
1 Battery 12 V (for remote control)
1 Set of operating instructions

Q

Control elements

Remote control (fig. A):

Power indicator light

1

Channel ON / OFF button Channel

2

A, B, C, D

Master ON / OFF switch

3

Battery compartment lid

4

Remote-controlled socket (fig. B):

Manual ON / OFF button

5

LED power indicator

6

LEARN button

7

Child protection socket

8

Q

Technical data

Remote control FSS B 20-A:

Battery: A23, 12 V
Transmission
frequency: 433.92 MHz
Licensing: The system is li-

censed for general
use, is free of
charge and does
not require regis­tration.

Range: Depending on the

circumstances
approx. 40 m under
optimum circum­stances.

Radio-controlled sockets
FSE B 20-A and FSD B 20-A:

Rated voltage: 230 V~ 50 Hz
Breaking capacity: FSE B 20-A:

16 A 3.500 W

6 GB

66538_silv_Funkschaltset_Content_GB-PL-CZ-SK.indd 6 28.06.11 15:41

Introduction / Safety

FSD B 20-A:

1.25 A 280 W
Standby power
consumption: < 0,7 W
Transmission
frequency: 433.92 MHz

Advice: The radio-controlled sockets
FSE B 20-A and FSD B 20-A each have
a child protection socket

8

, which sig­nificantly increases safety at home. The
contacts are protected in such a way
that children cannot stick needles or
other sharp objects into them and thus
get an electric shock. Nevertheless,
please keep the device out of the reach
of children at all times.

Q

Safety

Safety advice

Read these operating instructions and
safety advice carefully. Look at the dia­gram page and familiarise yourself with
all functions of the device before start­ing it up for the first time.

c Avoid danger to life from elec-

tric shock!

J Only connect the radio-controlled

sockets to earthed 230 V~ domestic
sockets.

J At all costs, avoid exposure to

damp and extreme temperatures.

J Only use the radio-controlled sockets

in enclosed spaces. They are not
suitable for outdoor use.

J Despite the child protection socket

8

, please keep the device out of

the reach of children at all times.

J Avoid overloading the device.

Overloading can cause a fire hazard
or damage to the device. The maxi­mum capacity is approx. 3.500 W
(FSE B 20-A) per radio-controlled
socket or 280 W (FSD B 20-A).

J Please contact the service department

immediately operational faults arise.

J Do not open the device on any ac-

count. All necessary repairs should
only be carried out by the service
department or a specialist electrical
workshop.

J Before cleaning always disconnect

the device from the mains supply. In
this case always remove the radio­controlled electrical outlet socket
from the mains wall socket and
remove all plugs from the device.

J Do not have one radio-controlled

electrical outlet socket inserted
behind the other.

J Do not use any additional child

protection devices for the radio­controlled sockets. The connection
between the plug and the radio­controlled socket could be impaired
and risk from overheating then arises.
The radio-controlled sockets already
have a child protection device which
prevents children from putting any
objects into the socket.

J Make sure that the connected

radio-controlled electrical outlet
sockets are freely accessible and not
covered by other objects.

7 GB

66538_silv_Funkschaltset_Content_GB-PL-CZ-SK.indd 7 28.06.11 15:41

Safety / Setting up

J If the device malfunctions, switch it

off immediately.

J These instructions are a component

of the device. If you pass the device
on to a third party, these instructions
must also be handed on.

Q

Advice on use of dimmer
radio-controlled

socket

(FSD B 20-A)

Use the remote-controlled dimmer
socket FSD B 20-A only for the following
lamps:

– 230 V~ light bulbs 20–280 W
– 230 V~ high-voltage halogen bulbs

20–280 W

Do not use the dimmer / remote-controlled
electrical outlet socket for energy-saving
lamps, fluorescent lamps, lamps with
their own dimmers and lamps with
transformers, except for incandescent
and halogen lamps with electronic
transformers (12 V / 20–50 W). Do not
use any other consumers. This may
damage the connected consumers and
the remote-controlled sockets.

Q

Setting up

Q

Preparing the remote
control (FSS B 20-A)
(fig. A)

1. Open the battery compartment on

the back of the remote control by

pushing away the battery compart­ment cover

4

downwards. Insert a
12 V battery. Make sure you fit the
battery the right way round (polarity).

2. Press one of the ON / OFF buttons
or 3 to test whether the remote

2

control works; if it does, the power
indicator light will come on

Q

Setting up the remote­controlled socket
(FSE B 20-A) (fig. B)

1. Insert the remote-controlled socket

into an earthed household socket
and switch it on with the ON / OFF
switch
display

2. Point the remote control at the remote-

controlled socket at a distance of
approx. 50 cm.

3. Press the LEARN button

remote-controlled socket for ap­prox. 3 seconds and release it
again. The LED operating status dis­play
seconds. While it is flashing, press the
desired ON button of the channel
ON / OFF button
of the remote control. The LED op­erating status display
shine permanently. You can now
switch a connected consumer on or
off using the remote control.

4. Repeat this procedure with the other

remote-controlled socket.

5. You can switch several remote-con-

trolled sockets on and off at the
same time using the ON / OFF but-

. The LED operating status

5

will come on.

6

7

will flash for approx. 10

6

(A, B, C or D)

2

will now

6

.

1

of the

8 GB

66538_silv_Funkschaltset_Content_GB-PL-CZ-SK.indd 8 28.06.11 15:41

ton 2 of one channel. In addition,
you can programme six remote
controls one after the other and use
them for individual receivers. This
means you can switch one appliance
on and off from up to six different
places.

6. In this case, synchronise every remote­controlled socket with the channel
of the remote control.

7. The coding of the remote control is
maintained when you change the
battery.

8. If you disconnect the remote-con­trolled socket from the power supply,
the codings will be permanently
stored.

9. In order to delete the codings again,
press the LEARN button

longer

7

than 6 seconds until the LED oper­ating status display

starts to flash.

6

All codings will now be deleted.

10. Avoid interference: Make sure that
the distance between the various
remote-controlled sockets is ap­prox. 50 cm.

11. Every remote-controlled socket also
has a manual ON / OFF switch

5

You can switch the remote-controlled
socket on and off without using the
remote control. The LED operating
status display

will indicate

6

whether the remote-controlled sock­et is in the ON / OFF mode.

Setting up

Q

Setting up the remote­controlled dimmer socket
(FSD B 20-A) (fig. B)

1. Insert the remote-controlled socket
into an earthed household socket
and switch it on with the ON / OFF
switch

2. Point the remote control at the remote­controlled socket at a distance of
approx. 50 cm.

3. Press the LEARN button
remote-controlled socket for ap­prox. 3 seconds and release it again.
The LED operating status display
will flash for approx. 10 seconds.
While it is flashing, press the desired
ON button of the channel ON /
OFF button
remote control. The LED operating
status display
permanently. You can now switch a
connected consumer on or off using
the remote control.

4. The coding of the remote control will
be maintained even when you
change the battery.

5. When you unplug the remote-con-

.

trolled sockets from the power supply,
the codings will be stored perma­nently.

6. Avoid interference: Make sure that
the distance between the various
remote-controlled sockets is ap­prox. 50 cm.

7. In order to delete the codings again,
press the LEARN button
than 6 seconds until the LED oper­ating status display
All codings will now be deleted.

.

5

(A, B, C or D) of the

2

will now shine

6

7

7

starts to flash.

6

of the

longer

6

9 GB

66538_silv_Funkschaltset_Content_GB-PL-CZ-SK.indd 9 28.06.11 15:41

Setting up / Setting-up operation

8. Every remote-controlled socket also
has a manual ON / OFF switch

5

You can switch the remote-controlled
socket on and off without using the
remote control. The LED operating
status display

will indicate

6

whether the remote-controlled socket
is in the ON / OFF mode.

Q

Meanings of the
LED operating status
display

Remote-controlled socket with­out dimmer FSE B 20-A:

j The LED operating status display

will shine when the remote-controlled
socket is switched on.

j The LED operating status display

will not shine when the remote-con­trolled socket is switched off.

Remote-controlled socket with
dimmer FSD B 20-A:

j The LED operating status display

will shine when the remote-controlled
socket is switched on.

j The LED operating status display

will not shine when the remote-con­trolled socket is switched off.

j The LED operating status display

will flash when the dimmer function
has been activated.

6

6

6

6

6

Q

Setting-up operation

.

Q

Using the dimmer
radio-controlled socket
(FSD B 20-A) (fig. B)

1. Insert the remote-controlled socket
into an earthed household socket
and switch it on with the ON / OFF
switch

2. Switch the lamp on. The radio-con­trolled socket can only carry out its
function when the lamp to be dimmed
is switched on.

3. Press the manual ON / OFF button

5

socket on directly at the appliance.
The LED operating status display
will shine. Alternatively, you can also
switch the remote-controlled socket
on using the remote control (See
“Using the remote control FSS B
20-A”).

4. Press the manual ON / OFF button

5

socket off directly on the appliance.
The LED operating status display
will go out. Alternatively, you can
also switch the remote-controlled
socket off using the remote control
(See “Using the remote control FSS
B 20-A”).

Adjusting the dimmer function
on remote-controlled socket
(FSD B 20-A):

1. Press the ON / OFF button
The lamp will switch itself on and
the dimming process will start.

.

5

to switch the remote-controlled

to switch the remote-controlled

down.

5

6

6

10 GB

66538_silv_Funkschaltset_Content_GB-PL-CZ-SK.indd 10 28.06.11 15:41

Setting-up operation

2. Release the manual ON / OFF but­ton

when you have got the

5

amount of brightness you desire;
this setting will then be stored.

Adjusting the dimmer function
with remote control (FSS B 20-A):

1. Press the ON button 2 on the
appropriate channel (e.g. A). The
lamp will go on.

2. To dim, press the ON button

2

again. The dimming process will
now start.

3. Press the ON button

again when

2

you have the amount of light you
wish to have. This setting will now
be stored.

Q

Using the radio-controlled
socket (FSE B 20-A)
(fig. B)

1. Put the radio-controlled socket into
any shuttered socket and connect
the appliance you want to operate.

2. Switch the electrical appliance on.
The radio-controlled socket can
only perform its switching function
when the device to be controlled is
switched on.

h ATTENTION! FIRE HAZARD!

Do not attach any appliances which
could cause fires or other damaged
if left unattended when switched
on. The maximum load of every
radio-controlled socket is approx.

3.500 W. Any overload could cause
a risk of fire or damage to the device.

3. Press the manual ON / OFF button
to switch the remote-controlled

5

socket on directly on the appliance.
The LED operating status display
will shine. Alternatively, you can also
switch the remote-controlled socket
on using the remote control (See
“Using the remote control FSS B
20-A”).

4. Press the manual ON / OFF button
to switch the remote-controlled

5

socket off directly on the appliance.
The LED operating status display
will go out. Alternatively, you can
also switch the remote-controlled
socket off using the remote control
(See “Using the remote control FSS
B 20-A”).

Q

Using the remote-con­trol (FSS B 20-A) (fig. A)

1. Use the button ON / OFF

the channel whose device you would
like to switch on or off. The remote
control controls up to 4 radio-con­trolled sockets (individually, in groups,
or all at the same time).

2. Use the ALL-ON / OFF button

switch all radio-controlled sockets on
or off at the same time.

Q

Trouble-shooting

If the remote control does not
work, please check the follow­ing points:

6

6

2

for

3

to

11 GB

66538_silv_Funkschaltset_Content_GB-PL-CZ-SK.indd 11 28.06.11 15:41

Setting-up operation / Cleaning / Disposal

Prob­lem

Rem­edy

Prob­lem

Rem­edy

Prob­lem

Rem­edy

The operating indica­tor

on the remote

1

control device illumi­nates but there is no
reaction

· Check that the current
output from the battery is
adequate. If necessary
insert a new battery.

No indicator light

1

on remote control
when pressing “ON”
or “OFF”

· Check that the battery
has been put in correctly.

· Check that the battery
has good contact with the
clamps, if need be press
it onto them.

No reaction from
consumer

· Check that the appliance
is switched on.

· Assign a new code to the
radio-controlled socket
(see “Setting up the re­mote-controlled socket“,
Point 3 or “Setting up the
remote-controlled dimmer
socket“, Point 3).

· Check - by walking closer
to it - that the range is
correct for the desired
location.

Prob-

Range is too small

lem
Rem-

edy

· For large ranges, ensure
that as few walls and as
little furniture as possible
are in the way of the
remote control and the
radio-controlled socket.

· If the range is too small
at times, the reason could
be a remote control which
works on a similar frequen­cy. Whenever this remote
control is active, the range
declines (e.g. wireless
headphones, radio-con­trolled movement alarms,
radio gongs etc.).

Q

Cleaning

J Ensure that no liquids get into the

inside of the device. Use a soft cloth
to clean the housing. Never use
petroleum, solvents or cleaners
which corrode plastics.

j Before cleaning, always disconnect

the radio-controlled socket from the
wall socket and remove all power
plugs from the device.

Q

Disposal

Electrical appliances
must not be disposed
of with domestic waste.

12 GB

66538_silv_Funkschaltset_Content_GB-PL-CZ-SK.indd 12 28.06.11 15:41

Disposal / Guarantee and service

In accordance with Council Directive
2002 / 96 / EC on waste electrical and
electronic equipment (WEEE), used
electrical appliances, lighting equipment
and batteries have to be collected sep­arately and recycled in an environmentally
friendly way. Enquire at your city council
or local government regarding the possi­bilities of disposing of electronic waste in
a correct and environmentally friendly
way.

Environmental damage
through incorrect dis­posal of the batteries!

Batteries should not be disposed of with
domestic waste. They may contain toxic
heavy metals and are subject to hazard­ous waste treatment rules and regulations.
That is why you should dispose of used
batteries at a local collection point.

Q

Guarantee and service

Q

Guarantee

guarantee, please telephone the service
centre. Only by doing so can we ensure
that your appliance is returned free of
charge.

Q

Service address

BAT, Lindenstraße 35,
72074 Tübingen, Germany
E-mail: [e-mail]
Service Tel.: [phone] – 720 741
(14 cents / min. from a German landline
telephone; mobile phones will be charged
at a max. rate of 42 cents / min.)

For further information, we recommend
you visit the service section / FAQs of
our home page www.dvw-service.com.

Q

Declaration of

conformity

A manufacturer’s Declaration of Con­formity is included with the product.

This appliance comes with a 3-year
guarantee commencing on the date of
purchase. Please keep your receipt as
proof of purchase. The appliance has
been produced to the highest standards
and thoroughly checked before dispatch.
The guarantee only applies to faults in
materials or workmanship when used
properly. The guarantee lapses in cases
of unauthorized tampering. This guar­antee does not restrict your legal rights.
If you wish to make a claim under the

66538_silv_Funkschaltset_Content_GB-PL-CZ-SK.indd 13 28.06.11 15:41

Q

Manufacturer

BAT
Lindenstraße 35
72074 Tübingen
Germany

13 GB

14

66538_silv_Funkschaltset_Content_GB-PL-CZ-SK.indd 14 28.06.11 15:41

Spis zawartości

Wstęp

Użytkowanie zgodne z przeznaczeniem .............................................Strona 16

Zakres dostawy ......................................................................................Strona 16

Elementy obsługi.....................................................................................Strona 16

Dane techniczne .....................................................................................Strona 16

Bezpieczeństwo

Wskazówki dotyczące bezpieczeństwa ..............................................Strona 17

Informacja dot. użytkowania gniazda ze sterowaniem
radiowym i funkcją regulacji

Przygotowanie

Przygotowanie pilota (FSS B 20-A) ......................................................Strona 18

Przygotowanie gniazda radiowego (FSE B 20-A) ..............................Strona 19

Przygotowanie gniazda radiowego ze

ściemniaczem (FSD B 20-A) ..................................................................Strona 19

Znaczenia wskaźnika stanu pracy LED ................................................Strona 20

Uruchomienie

Wykorzystywanie gniazda ze sterowaniem radiowym

z funkcją regulacji oświetlenia (FSD B 20-A) .......................................Strona 20

Wykorzystanie gniazda

Wykorzystanie pilota (FSS B 20-A) .......................................................Strona 22

Wskazówki dotyczące błędów .............................................................Strona 22

oświetlenia (FSD B 20-A) ...................... Strona 18

ze sterowaniem radiowym (FSE B 20-A) .....Strona 21

Czyszczenie .......................................................................................Strona 23

Utylizacja ............................................................................................Strona 23

Gwarancja i serwis

Warunki gwarancji .................................................................................Strona 23

Adres punktu serwisowego ...................................................................Strona 24

Deklaracja zgodności ............................................................................Strona 24

Producent ................................................................................................Strona 24

15 PL

66538_silv_Funkschaltset_Content_GB-PL-CZ-SK.indd 15 28.06.11 15:41

Wstęp

Komplet radiowych
wtyczek

Q

Wstęp

Q

Użytkowanie zgodne z
przeznaczeniem

Zestaw gniazd ze sterowaniem radio­wym jest przystosowany do sterowane­go zdalnie włączania i wyłączania
urządzeń elektrycznych. Wspomaga on
ponadto funkcję regulacji oświetlenia
dla żarówek opisanych w niniejszej in­strukcji. Gniazdo ze sterowaniem radio­wym z funkcją regulacji oświetlenia nie
jest przewidziane dla żarówek energo­oszczędnych oraz świetlówek. Wszelkie
zmiany urządzenia są niezgodne z
przeznaczeniem i oznaczają poważne
zagrożenie nieszczęśliwym wypad­kiem. Za szkody powstałe wskutek
sprzecznego z przeznaczeniem użycia
urządzenia producent nie przejmuje
żadnej odpowiedzialności. Niniejsze
urządzenie nie jest przeznaczone do
zastosowania komercyjnego.

Q

Zakres dostawy

Po wypakowaniu niniejszego zestawu
sprawdź go pod względem kompletności.

2 Gniazda radiowe FSE B 20-A
2 Gniazda radiowe z funkcją

ściemniacza FSD B 20-A

1 4-kanałowy pilot FSS B 20-A

1 Bateria 12 V (do pilota)
1 Instrukcja obsługi

Q

Elementy obsługi

Pilot (rys. A):

1

Lampka kontrolna pracy

2

Przycisk Kanał ON / OFF kanał A,

B, C, D

3

Przycisk ALL-ON- / OFF (Master

ZAŁ. / WYŁ.)

4

Pokrywka schowka na baterie

Gniazdo radiowe (rys. B):

5

Ręczny przycisk ON / OFF

(ZAŁ. / WYŁ.)

6

Wskaźnik stanu pracy LED

7

Przycisk LEARN (uczenie)

8

Gniazdo z zabezpieczeniem przed

dziećmi

Q

Dane techniczne

Pilot FSS B 20-A:

Bateria: A23, 12 V
Częstotliwość przen.
sygnałów: 433,92 MHz
Dopuszczenie: system posiada

dopuszczenie
ogólne (BZT) i nie
wymaga zgłosze­nia ani opłaty.

Zasięg: w zależności od

warunków otocze­nia, około 40 m w
warunkach opty­malnych

16 PL

66538_silv_Funkschaltset_Content_GB-PL-CZ-SK.indd 16 28.06.11 15:41
