Sharp XG-P610X, XG-P610X-N User Manual

Download

DATA PROJECTOR

Introduction

MODEL

XG-P610X

(Standard zoom lens attached)

XG-P610X-N

(No lens attached)

OPERATION MANUAL

Quick Start

Setup

Connections

Basic Operation

Useful Features

Appendix

IMPORTANT

••

• For your assistance in reporting the loss or theft of your Projector, please record

••

the Model and Serial Numbers located on the side of the projector and retain this information.

••

• Before recycling the packaging, please ensure that you have checked the contents

••

of the carton thoroughly against the list of “Supplied accessories” on page 11.

SPECIAL NOTE FOR USERS IN THE U.K.

The mains lead of this product is fitted with a non-rewireable (moulded) plug incorporating a 13A fuse. Should the fuse need to be replaced, a BSI or ASTA approved BS 1362 fuse marked or and of the same rating as above, which is also indicated on the pin face of the plug, must be used. Always refit the fuse cover after replacing the fuse. Never use the plug without the fuse cover fitted. In the unlikely event of the socket outlet in your home not being compatible with the plug supplied, cut off the mains plug and fit an appropriate type.

DANGER:

The fuse from the cut-off plug should be removed and the cut-off plug destroyed immediately and disposed of in a safe manner. Under no circumstances should the cut-off plug be inserted elsewhere into a 13A socket outlet, as a serious electric shock may occur. To fit an appropriate plug to the mains lead, follow the instructions below:

WARNING:

THIS APPARATUS MUST BE EARTHED.

IMPORTANT:

The wires in this mains lead are coloured in accordance with the following code:

Green-and-yellow : Earth Blue : Neutral

Brown : Live As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug proceed as follows:

• The wire which is coloured green-and-yellow must be connected to the terminal in the plug which is marked by the

letter E or by the safety earth symbol or coloured green or green-and-yellow.

• The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black.

• The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red.

IF YOU HAVE ANY DOUBT, CONSULT A QUALIFIED ELECTRICIAN.

Model No.:

Serial No.:

The supplied CD-ROM contains operation instructions in English, German, French, Spanish, Italian, Dutch, Swedish, Portuguese, Chinese, Korean and Japanese. Carefully read through the operation instructions before operating the projector.

Die mitgelieferte CD-ROM enthält Bedienungsanleitungen in Englisch, Deutsch, Französisch, Spanisch, Italienisch, Niederländisch, Schwedisch, Portugiesisch, Chinesisch, Koreanisch und Japanisch. Bitte lesen Sie die Bedienungsanleitung vor der Verwendung des Projektors sorgfältig durch.

Le CD-ROM fourni contient les instructions de fonctionnement en anglais, allemand, français, espagnol, italien, néerlandais, suédois, portugais, chinois, coréen et japonais. Veuillez lire attentivement ces instructions avant de faire fonctionner le projecteur.

El CD-ROM suministrado contiene instrucciones de operación en inglés, alemán, francés, español, italiano, holandés, sueco, portugués, chino, coreano y japonés. Lea cuidadosamente las instrucciones de operación antes de utilizar el proyector.

Il CD-ROM in dotazione contiene istruzioni per l’uso in inglese, tedesco, francese, spagnolo, italiano, olandese, svedese, portoghese, cinese, coreano e giapponese. Leggere attentamente le istruzioni per l’uso prima di usare il proiettore.

De meegeleverde CD-ROM bevat handleidingen in het Engels, Duits, Frans, Spaans, Italiaans, Nederlands, Zweeds, Portugees, Chinees, Koreaans en Japans. Lees de handleiding zorgvuldig door voor u de projector in gebruik neemt.

Den medföljande CD-ROM-skivan innehåller bruksanvisningar på engelska, tyska, franska, spanska, italienska, holländska, svenska, portugisiska, kinesiska, koreanska och japanska. Läs noga igenom bruksanvisningen innan projektorn tas i bruk.

O CD-ROM fornecido contém instruções de operação em Inglês, Alemão, Francês, Espanhol, Italiano, Holandês, Sueco, Português, Chinês, Coreano e Japonês. Leia cuidadosamente todas as instruções de operação antes de operar o projetor.

Before using the projector, please read this operation manual carefully.

Introduction

ENGLISH

There are two important reasons for prompt warranty registration of your new SHARP Projector, using the REGISTRATION CARD packed with the projector.

1. WARRANTY

This is to assure that you immediately receive the full benefit of the parts, service and labor warranty applicable to your purchase.

2. CONSUMER PRODUCT SAFETY ACT

To ensure that you will promptly receive any safety notification of inspection, modification, or recall that SHARP may be required to give under the 1972 Consumer Product Safety Act, PLEASE READ CAREFULLY THE IMPORTANT “LIMITED WARRANTY” CLAUSE.

U.S.A. ONLY

WARNING: High brightness light source. Do not stare into the beam of light, or view directly. Be especially

careful that children do not stare directly into the beam of light.

WARNING: To r educe the risk of fire or electric shock, do not expose this product to

rain or moisture.

See side of projector.

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT REMOVE SCREWS

EXCEPT SPECIFIED USER

SERVICE SCREW.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk or electric shock to persons.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

NO USER-SERVICEABLE PARTS EXCEPT LAMP UNIT.

WARNING:

DO NOT REMOVE COVER.

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment.

The exclamation point within a triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

U.S.A. ONLY

INFORMATION

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the operation manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense.

The enclosed computer cable must be used with the device. The cable is provided to ensure that the device complies with FCC Class A verification.

U.S.A. ONLY

WARNING:

This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.

-1

PRODUCT DISPOSAL

This product utilizes tin-lead solder, and lamp containing a small amount of mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities, the Electronics Industries Alliance: www.eiae.org, the lamp recycling organization www.lamprecycle.org, or Sharp at 1-800-BE-SHARP.

U.S.A. ONLY

Caution Concerning Lamp Replacement

See “Replacing the Lamp” on page 71.

This SHARP projector uses a DLP® chip. This very sophisticated panel contains 786,432 pixels (micromirrors). As with any high technology electronic equipment such as large screen TVs, video systems and video cameras, there are certain acceptable tolerances that the equipment must conform to. This unit has some inactive pixels within acceptable tolerances which may result in inactive dots on the picture screen. This will not affect the picture quality or the life expectancy of the unit.

• DLP® and the DLP logo are registered trademarks of Texas Instruments.

• Microsoft

and Windows® are registered trademarks of Microsoft Corporation in the United States and/or

other countries.

• PC/AT is a registered trademark of International Business Machines Corporation in the United States.

• Adobe

• Macintosh

Reader® is a trademark of Adobe Systems Incorporated.

is a registered trademark of Apple Computer, Inc. in the United States and/or other countries.

• HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks

of HDMI Licensing LLC.

• All other company or product names are trademarks or registered trademarks of their respective compa-

nies.

• Some IC chips in this product include confidential and/or trade secret property belonging to Texas Instru-

ments. Therefore you may not copy, modify, adapt, translate, distribute, reverse engineer, reverse assemble or discompile the contents thereof.

Authorized representative responsible for the European Union Community Market

SHARP ELECTRONICS (Europe) GmbH Sonninstraße 3, D-20097 Hamburg

E.U. ONLY

-2

How to Read This Operation Manual

••

• In this operation manual, the illustrations and on-screen displays are simplified for explana-

••

tion. This may differ from the actual on-screen display.

Using the Menu Screen

MENU button

Buttons used in this operation

Button used in this step

Menu Selections

• This operation can also be performed by using the buttons on the projector.

Press MENU.

• The “Picture” menu screen for the selected input mode is displayed.

Press

\ or

menu items.

• Menu items are as shown below.

Adjustment buttons ('/"/\/|) ENTER button

UNDO button

| to display the other

Menu items

Menu item

MENU button

Mouse/adjustment button ('/"/\/|)

ENTER button

UNDO button

Example: “Picture” screen menu for

COMPUTER1 (RGB) mode

Buttons used in this operation

On-screen display

Introduction

Useful Features

Note

• The “Fine Sync” menu is not available

for VIDEO or S-VIDEO.

-47

Info

...........Indicates safeguards when using the projector.

........Indicates additional information for setting up and operating the projector.

Note

For Future Reference

Maintenance Troubleshooting Index

Page 66

Pages 79 and 80

Page 83

-3

Contents

Preparing

Introduction

How to Read This Operation Manual ............ 3

Contents.......................................................... 4

How to Access the PDF

Operation Manuals ................................... 7

IMPORTANT SAFEGUARDS .......................... 8

Accessories .................................................. 11

Part Names and Functions .......................... 13

Quick Start

Quick Start .................................................... 19

Setup

Setting Up the Projector .............................. 21

Setting Up the Projector .................................... 21

Standard Zoom Lens (AN-P18EZ : Standard

Equipment with XG-P610X) ......................... 22

Projecting a Reversed Image ............................ 23

Connections

Connecting the Projector to Other

Equipment ............................................... 24

Controlling the Projector by a Computer... 27

Using the Remote Control ........................... 16

Usable Range .................................................... 16

Inserting the Batteries ....................................... 16

Using the Remote Control with

a Signal Cable ............................................. 17

Switching the Remote Control Mode ................. 17

Using the Remote Control as

a Wireless Computer Mouse ....................... 18

Using

Basic Operation

Turning the Projector On/Off ....................... 28

Connecting the Power Cord .............................. 28

Tur ning the Projector On .................................... 28

Tur ning the Power Off (Putting the Projector

into Standby Mode) ..................................... 28

Image Projection .......................................... 29

Shifting the Lens ................................................ 29

Using the Adjustment Feet ................................ 30

Adjusting the Focus ........................................... 31

Adjusting the Projected Image Size .................. 31

-4

Correcting Trapezoidal Distortion ...................... 32

Switching the Input Mode .................................. 36

Adjusting the Volume......................................... 36

Tur ning Off the Sound Temporarily .................... 37

Displaying an Enlarged Portion of an Image ..... 37

Freezing a Moving Image .................................. 38

Selecting the Picture Mode ............................... 38

Resize Mode ...................................................... 39

Hiding the Projected Image

(Shutter function) ......................................... 41

Displaying and Setting the Break Timer ............ 41

Useful Features

Introduction

Menu Items ................................................... 42

Using the Menu Screen ............................... 47

Menu Selections ................................................ 47

Picture Adjustment (“Picture” menu) ......... 49

Selecting the Picture Mode ............................... 49

Adjusting the Image .......................................... 49

Adjusting the Color Temperature ....................... 50

Selecting the Progressive Mode........................ 50

Reducing Image Noise (DNR) ........................... 50

Selecting the Signal Type .................................. 51

Selecting the Dynamic Range ........................... 51

Selecting the Color Space ................................. 51

Color Management System

(“C. M. S.” menu) ..................................... 52

Selecting the Color Reproduction Mode ........... 52

Selecting the Target Color ................................. 52

Setting the Brightness of the Target Color ......... 52

Setting the Chromatic Value of

the Target Color ...........................................52

Setting the Hue of the Target Color ................... 52

Resetting User-defined Color Settings .............. 52

Overview of All Color Settings ........................... 52

Computer Image Adjustment

(“Fine Sync” menu) ................................ 53

Adjusting the Computer Image ......................... 53

Saving Adjustment Settings .............................. 53

Accessing Adjustment Settings ........................ 53

Setting the Resolution ........................................ 53

Checking the Input Signal ................................. 54

Auto Sync Adjustment ....................................... 54

Setting the Auto Sync Display Function ............ 54

Audio Adjustment (“Audio” menu) ............. 55

Adjusting the Audio ........................................... 55

Setting the Audio Output Type .......................... 55

Setting the Speaker ........................................... 55

Using the “Options 1” Menu........................ 56

Displaying Dual Pictures (Pict in Pict) ............... 56

Setting the Resize Mode ................................... 56

Shifting the Projected Image Vertically

(Digital Shift) ................................................ 57

Setting On-screen Display................................. 57

Setting the Video System................................... 57

Capturing Projected Images ............................. 57

Selecting the Background Image ...................... 58

Selecting the Startup Image .............................. 58

Setting the Eco Mode ........................................ 58

Detecting the Input Signals Automatically ........ 58

Setting the Auto Power Off Function.................. 58

Setting the System Lock Function ..................... 59

Helpful Functions Set during Installation

(“Options 2” menu) ................................. 61

Setting a Password ............................................ 61

Setting the Lamp Mode ..................................... 62

Selecting the Lens Type .................................... 62

Reversing/Inverting Projected Images .............. 62

Controlling Multiple Projectors with the One

Remote Control ........................................... 62

Shortcut to Make Projector Stack Settings ........ 63

Locking the Operation Buttons

on the Projector ........................................... 63

Bypassing Unused Input Selections ................. 63

Selecting the Fan Mode .................................... 63

Setting the Auto Restart Function ...................... 63

Selecting the Transmission Speed

(RS-232C) ................................................... 64

Setting the Monitor Output ................................ 64

Setting the LAN/RS232C ................................... 64

Setting the DHCP Client .................................... 64

Helpful Functions Set during Installation

(“Options 2” menu)/Using the Other Menus

(“Language” and “Status” menus) ...............

Setting the TCP/IP ............................................. 65

Service Mode .................................................... 65

Returning to the Default Settings ....................... 65

Selecting the On-screen Display Language ..... 65

Overview of All Menu Settings and the Lamp Life

.... 65

Reference

Appendix

Maintenance ................................................. 66

Cleaning and Replacing the Dust Filters ... 67

Cleaning the Dust Filters ................................... 67

Replacing the Dust Filters ................................. 68

Maintenance Indicators ............................... 69

Regarding the Lamp .................................... 71

Lamp ................................................................. 71

Caution Concerning the Lamp .......................... 71

Replacing the Lamp .......................................... 71

The optional lenses are introduced on page 12. Please purchase the lens for your desired usage.

Removing and Installing the Lamp Unit ............ 72

Resetting the Lamp Timer ................................. 74

Computer Compatibility Chart .................... 75

Attaching the Optional Lens ....................... 77

Troubleshooting ........................................... 79

For SHARP Assistance ................................ 81

Specifications ............................................... 82

Index .............................................................. 83

-5

Contents

SETUP MANUAL

Refer to the “SETUP MANUAL” contained on the supplied CD-ROM for details.

Setting up the Screen .................................... 2

Screen Size and Projection Distance ........... 3

Connecting Pin Assignments ..................... 11

Wired Remote Control Terminal

Specifications ......................................... 13

RS-232C Specifications and Commands ... 14 Setting up the Projector Network

Environment............................................ 20

Controlling the Projector via LAN .............. 26

Setting the Projector Using

RS-232C or Telnet ................................... 31

Controlling the Projector Using RS-232C

or Telnet ................................................... 34

Stack Projection ........................................... 41

Video Wall Projection ................................... 44

Resetting the Lamp Timer of the Projector

via LAN .................................................... 53

Troubleshooting ........................................... 55

Dimensions ................................................... 58

-6

How to Access the PDF Operation Manuals

PDF operation manuals in several languages are included in the CD-ROM, so that you can work with the projector. To utilize these manuals, you need to install Adobe® Reader® on your computer (Windows® or Macintosh®).

Please download Adobe® Reader® from the Internet (http://www.adobe.com).

Accessing the PDF manuals

For Windows®:

1 Insert the CD-ROM in the CD-ROM drive. 2 Double click the “My Computer” icon. 3 Double click the “CD-ROM” drive. 4

When you want to view the operation manual

1) Double click the “MANUALS” folder.

2) Double click the language (name of the folder) that you want to view.

3) Double click the pdf file to access the projector manuals.

When you want to view the setup manual

1) Double click the “SETUP” folder.

2) Double click the language (name of the folder) that you want to view.

3) Double click the pdf file to access the SETUP MANUAL.

For Macintosh

1 Insert the CD-ROM in the CD-ROM drive. 2 Double click the “CD-ROM” icon. 3

When you want to view the operation manual

1) Double click the “MANUALS” folder.

2) Double click the language (name of the

3) Double click the pdf file to access the pro-

When you want to view the setup manual

1) Double click the “SETUP” folder.

2) Double click the language (name of the

3) Double click the pdf file to access the SETUP

folder) that you want to view.

jector manuals.

folder) that you want to view.

MANUAL.

Introduction

Info

• If the desired pdf file cannot be opened by double clicking the mouse, start Adobe® Reader® first, then specify the desired file using the “File”, “Open” menu.

-7

IMPORTANT SAFEGUARDS

CAUTION: Please read all of these instructions before you operate this product and save these

instructions for later use.

Electrical energy can perform many useful functions. This product has been engineered and manufactured to assure your personal safety. BUT IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARDS. In order not to defeat the safeguards incorporated in this product, observe the following basic rules for its installation, use and servicing.

1. Read Instructions

All the safety and operating instructions should be read before the product is operated.

2. Retain Instructions

The safety and operating instructions should be retained for future reference.

3. Heed Warnings

All warnings on the product and in the operating instructions should be adhered to.

4. Follow Instructions

All operating and use instructions should be followed.

5. Cleaning

Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

6. Attachments

Do not use attachments not recommended by the product manufacturer as they may cause hazards.

7. Water and Moisture

Do not use this product near water–for example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like.

8. Accessories

Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the product should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

9. Transportation

A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn.

10. Ventilation

Slots and openings in the cabinet are provided for ventilation to ensure reliable operation of the product and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

11. Power Sources

This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.

12. Grounding or Polarization

This product is provided with one of the following types of plugs. If the plug should fail to fit into the power outlet, please contact your electrician. Do not defeat the safety purpose of the plug.

a. Two-wire type (mains) plug. b. Three-wire grounding type (mains) plug with a

grounding terminal. This plug will only fit into a grounding type power outlet.

13. Power-Cord Protection

Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.

14. Lightning

For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the cable system. This will prevent damage to the product due to lightning and power-line surges.

15. Overloading

Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.

16. Object and Liquid Entry

Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

17. Servicing

Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

18. Damage Requiring Service

Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a. When the power-supply cord or plug is damaged. b. If liquid has been spilled, or objects have fallen into

the product. c. If the product has been exposed to rain or water. d. If the product does not operate normally by following

the operating instructions. Adjust only those controls

that are covered by the operating instructions, as an

improper adjustment of other controls may result in

damage and will often require extensive work by a

qualified technician to restore the product to normal

operation. e. If the product has been dropped or damaged in any

way. f. When the product exhibits a distinct change in

performance, this indicates a need for service.

19. Replacement Parts

When replacement parts are required, ensure that the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

20. Safety Check

Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.

21.Wall or Ceiling Mounting

This product should be mounted to a wall or ceiling only as recommended by the manufacturer.

22. Heat

This product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

-8

Ensure that you read the following safeguards when setting up your projector.

Introduction

Caution concerning the lamp unit

■ Potential hazard of glass particles if lamp ruptures. In case of lamp rupture, contact your nearest Sharp Authorized Projector Dealer or Service Center for replacement. See “Regarding the Lamp” on page 71.

Caution concerning the setup of the projector

■ For minimal servicing and to maintain high image quality, SHARP recommends that this projector be installed in an area free from humidity, dust and cigarette smoke. When the projector is subjected to these environments, the vents and lens must be cleaned more often. As long as the projector is regularly cleaned, use in these environments will not reduce the overall operation life of the unit. Internal cleaning should only be performed by a Sharp Authorized Projector Dealer or Service Center.

Do not set up the projector in places exposed to direct sunlight or bright light.

■ Position the screen so that it is not in direct sunlight or room light. Light falling directly on the screen washes out the colors, making viewing difficult. Close the curtains and dim the lights when setting up the screen in a sunny or bright room.

The projector may be safely tilted to a maximum angle of 9 degrees.

■ Placement should be within 9 degrees of horizontal. If you have application requiring tilt angle exceeding 9 degrees, please check with your local Sharp sales office.

When using the projector in high-altitude areas such as mountains (at altitudes of approximately 1,500 meters (4,900 feet) or more)

■ When you use the projector in high-altitude areas with thin air, set “Fan Mode” to “High”. Neglecting this can affect the longevity of the optical system.

Warning about placing the projector in a high position

■ When placing the projector in a high position, make certain it is carefully secured to avoid personal injury caused by the projector falling down.

Do not subject the projector to hard impact and/or vibration.

■ Ta ke care with the lens so as not to hit or damage the surface of the lens.

Rest your eyes occasionally.

■ Continuously watching the screen for long hours will cause eye strain. Take regular breaks to rest your eyes.

Avoid locations with extremes of temperature.

■ The operating temperature of the projector is from 41°F to 104°F (+5°C to +40°C).

■ The storage temperature of the projector is from –4°F to 140°F (–20°C to +60°C).

-9

IMPORTANT SAFEGUARDS

Do not block the intake and exhaust vents.

■ Allow at least 11 13/16 inches (30 cm) of space between the exhaust vent and the nearest wall or obstruction.

■ Set up the projector where air will not stay near its exhaust vent. In order to avoid allowing the heat from the exhaust vent to enter the intake vent area, leave at least more than 11 13/16 inches (30 cm) of space between the intake vent and the surrounding walls or objects.

■ If the cooling fan becomes obstructed, a protection circuit will automatically put the projector into standby mode to prevent overheat damage. This does not indicate a malfunction (See pages 69 and 70.). Remove the pro- jector power cord from the wall outlet and wait at least 10 minutes. Place the projector where the intake and exhaust vents are not blocked, plug the power cord back in and turn on the projector. This will return the projector to the normal operating condition.

Caution regarding usage of the projector

■

When using the projector, take care not to subject it to hard impact and/or vibration, as this can result in damage. Take extra care with the lens. If you are not to use the projector for a long time, make certain you unplug the power cord from the wall outlet, and disconnect any other cables connected to it.

■ Do not carry the projector by holding the lens.

■ When storing the projector, ensure you at-

tach the lens cap or dustproof cap to the projector. (See page 13.)

■ Do not expose the projector to direct sunlight or near heat sources. The projector may change color or become deformed.

Other connected equipment

■ When connecting a computer or other audiovisual equipment to the projector, make the connections AFTER unplugging the power cord of the projector from the AC outlet and turning off the equipment to be connected.

■ Please read the operation manuals of the projector and the equipment to be connected for instructions on how to make the connections.

Using the projector in other countries

■ The power supply voltage and the shape of the plug may vary depending on the region or country you are using the projector in. When using the projector overseas, make sure you use an appropriate power cord for the country you are in.

Temperature monitor function

■

If the projector starts to overheat due to setup problems or blockage of the air vents, “ ” and “ ” will illuminate in the lower left corner of the picture. If the temperature continues to rise, the lamp will turn off, the temperature warning indicator on the projector will blink, and after a 90-second coolingoff period the projector will enter the standby mode. Refer to “Maintenance Indicators” on page 69 for details.

Info

• The cooling fan regulates the internal temperature, and its performance is automatically controlled. The sound of the fan may change during projector operation due to changes in the fan speed. This does not indicate malfunction.

• Even if you unplug the power cord after projector operation, the cooling fan continues to run for a while. When you place the projector into the storage case, make sure that the cooling fan has stopped.

Optional lens installation

■ For installing an optional lens, refer to “Attaching the Optional Lens” on page 77 or the lens installation manual (supplied with the optional lens).

■ Remove the optional lens when carrying the projector. Carrying the projector with an optional lens attached can cause the projector to be damaged by vibration or other factors.

-10

Accessories

Supplied accessories

Introduction

Tw o R-6 batteries (“AA” size, UM/SUM-3, HP-7 or similar)

For U.K., Hong Kong and Singapore (6' (1.8 m)) <9NK3090152900>

Power cord

(1)

For U.S., Canada, etc. (6' (1.8 m)) <9NK3090204900>

Remote control <9NK5041816900>

(2) (3)

For Europe, except U.K. (6' (1.8 m)) <9NK3090152700>

*Use the power cord that corresponds to the wall outlet in your country.

RGB cable (10' (3.0 m)) <9NK3080431000>

Lens cap (Only supplied with XG-P610X) <9NK3392072800> Dustproof cap (Only supplied with XG-P610X-N) <9NK3392072900>

(4)

For Australia, New Zealand and Oceania (6' (1.8 m)) <9NK3090152600>

• Projector manual and technical reference CD-ROM <9NK3534059900>

• Operation manual (this manual) <9NK5010071200>

Note

• Codes in “< >” are Replacement parts codes.

• When the lens is attached, use the lens cap supplied with the lens.

• You can attach the dustproof cap to the projector only when no lens is attached. (Do not attach the

dustproof cap when the lens is attached.)

Optional accessories

■ Lamp unit AN-P610LP

■ Ceiling-mount adaptor AN-P610T

■ Ceiling-mount unit AN-TK201

AN-TK202

■ Remote receiver AN-MR2

■ 3 RCA to mini D-sub 15 pin cable (10'

(3.0 m)) AN-C3CP2

Note

• Some of the optional accessories may not be available depending on the region. Please check with your nearest Sharp Authorized Projector Dealer or Service Center.

-11

Accessories

Optional lenses

■ Lens Projection distance for 100" screen size

Fixed wide lens (× 0.8) AN-P8EX 5'4" (1.6 m) Fixed wide lens (× 1.2) AN-P12EX 8' (2.4 m) Wide-zoom lens (× 1.5 – 1.8) AN-P15EZ 10' – 12' (3.0 m – 3.7 m) Standard zoom lens (× 1.8 – 2.25) AN-P18EZ 12' – 15' (3.7 m – 4.6 m) (attached to XG-P610X) Tele-zoom lens (× 2.25 – 3.0) AN-P23EZ 15' – 20' (4.6 m – 6.1 m) Tele-zoom lens (× 3.0 – 4.5) AN-P30EZ 20' – 30' (6.1 m – 9.1 m) Tele-zoom lens (× 4.5 –7.0) AN-P45EZ 30' – 46'8" (9.1 m – 14.2 m)

No lens is attached to XG-P610X-N. The standard zoom lens is attached to XG-P610X. The optional lenses from Sharp are also available for specialized application. Please see your nearest Sharp Authorized Projector Dealer for details on all the lenses. (Refer to the lens operation manual when using a lens.)

Throw Distance

The graph below is for 100-inch (254 cm) screen with 4:3 normal mode.

Screen

Fixed wide lens (AN-P8EX)

5'4" (1.6 m)

Throw distance ratio 1:0.8

Fixed wide lens (AN-P12EX)

Throw distance ratio 1:1.2

8' (2.4 m)

Wide-zoom lens (AN-P15EZ)

10' – 12' (3.0 m – 3.7 m)

Throw distance ratio 1:1.5–1.8

Standard zoom lens (AN-P18EZ : Standard equipment with XG-P610X)

12' – 15' (3.7 m – 4.6 m)

Throw distance ratio 1:1.8–2.25

Tele-zoom lens (AN-P23EZ)

15' – 20' (4.6 m – 6.1 m)

Throw distance ratio 1:2.25–3.00

Tele-zoom lens (AN-P30EZ)

20' – 30' (6.1 m – 9.1 m)

Throw distance ratio 1:3.0–4.5

Tele-zoom lens (AN-P45EZ) 30' – 46' 8" (9.1 m – 14.2 m)

Throw distance ratio 1:4.5–7.0

5101520253035 455040 (ft)

-12

Part Names and Functions

Numbers in refer to the main pages in this operation manual where the topic is explained.

Projector

Rear View

H&V LENS SHIFT button

For shifting the lens horizontally

and vertically.

30 32

KEYSTONE button

For entering the Keystone Correction mode.

Introduction

For turning the power on.

ON button

STANDBY button

For putting the projector

into standby mode.

ZOOM buttons

For adjusting the projected

image size.

FOCUS buttons

For adjusting the focus.

SHUTTER buttons

• OPEN: For opening the shutter.

• CLOSE: For closing the shutter and hiding the projected

AUTO SYNC button

For automatically

adjusting images when

connected to a computer.

image.

Front View

Lamp 2 indicator

Temperature warning

indicator

Speaker

Adjustment foot

(on the bottom of

the projector)

Attaching the lens cap/dustproof cap

Snap on the lens cap/dustproof cap straight.

Removing the lens cap/dustproof cap

Pull the lens cap/dustproof cap directly outward.

INPUT buttons

For switching input mode.

MENU button

For displaying adjustment and setting screens.

Volume buttons

For adjusting the speaker sound level.

ENTER button

For setting items selected or adjusted on the menu.

UNDO button

For undoing an operation or returning to the previous display.

Adjustment buttons

('/"/\/|)

For selecting menu items and other settings.

Lamp 1 indicator

Power indicator

Lamp unit cover

Speaker

Remote control sensor

Exhaust vent

Lens cover removal button

Adjustment foot

(on the bottom of the projector)

Lens cover

-13

Part Names and Functions

Numbers in refer to the main pages in this operation manual where the topic is explained.

Projector (Rear View)

Terminals Refer to “Connecting the Projector to Other Equipment” on pages 24–26.

HDMI terminal

Terminal for HDMI input.

DVI-D input terminals

Terminals for DVI digital

RGB and digital component

signals and audio input

COMPUTER/COMPONENT1

Terminals for computer RGB

and component signals and

audio input terminal.

MONITOR OUT terminals

∫

COMPUTER/COMPONENT Output terminal for computer RGB and component signals. (Shared for COMPUTER/ COMPONENT 1 and 2 input.)

∫

AUDIO Output terminal. (Shared for all inputs)

VIDEO input terminals

Terminals for connecting

video equipment and audio

terminal.

input terminals

input terminal.

24 25

COMPUTER/COMPONENT 2

terminals

BNC terminals for computer RGB and component signals and audio input terminal.

LAN terminal

Terminal for controlling the projector using a computer via network.

RS-232C terminal

Terminal for controlling the projector using a computer.

WIRED REMOTE terminal

For connecting the remote control to the projector when the signals from the remote control cannot reach the remote control sensor.

S-VIDEO input terminals

Terminals for connecting video equipment with an S-video terminal and audio input terminal.

AC socket

Connect the supplied power cord.

Filter cover

(Intake vent)

Kensington Security

Standard connector

Using the Kensington Lock

• This projector has a Kensington Security Standard connector for use with a Kensington MicroSaver Security System. Refer to the information that came with the system for instructions on how to use it to secure the projector.

Carrying handle

For carrying the projector.

Remote control sensor

-14

Numbers in refer to the main pages in this operation manual where the topic is explained.

Remote Control

Introduction

FOCUS buttons

For adjusting the focus.

STANDBY button

For putting the projector into

standby mode.

ZOOM buttons

For adjusting the projected image size.

KEYSTONE button

For entering the Keystone

Correction mode.

Mouse/adjustment button ('/"/\/|)

• For moving the computer cursor while the ADJ./MOUSE switch is in the MOUSE position.

• For selecting menu items while the ADJ./MOUSE switch is in the ADJ. position.

ENTER button

For setting items selected or adjusted on the menu.

L-CLICK button

For left-clicking while the ADJ./MOUSE

switch is in the MOUSE position.

MAGNIFY (enlarge/reduce) buttons

For enlarging/reducing part of the image.

BREAK TIMER button

For setting the break time.

AUTO SYNC button

For automatically adjusting images

when connected to a computer.

18•47

ON button

For turning the power on.

ADJ./MOUSE switch

For switching the remote control modes.

H&V LENS SHIFT button

For shifting the lens horizontally and vertically.

MENU button

For displaying adjustment and setting screens.

18•47

R-CLICK/UNDO button

• For right-clicking while the ADJ./MOUSE switch is in the MOUSE position.

• For undoing an operation or returning to the previous display while the ADJ./MOUSE switch is in the ADJ. position.

SHUTTER buttons

• OPEN: For opening the shutter.

• CLOSE:

hiding the projected Image.

Volume buttons

For adjusting the speaker sound level.

MUTE button

For temporarily turning off the sound.

FREEZE button

For freezing images.

RESIZE button

For switching the screen size.

For closing the shutter and

COMPUTER 1/2, DVI, HDMI,

VIDEO, S-VIDEO buttons

For switching to the respective

input modes.

LIGHT button

For lighting all buttons on the

remote control.

PICTURE MODE button

For switching the picture mode.

WIRED R/C JACK

For connecting the remote control to the projector when the signals from the remote control cannot reach the remote control sensor.

Note

• The LIGHT button on the remote control is made of luminous material that is visible in the dark. Visibility will diminish over time. Exposure to light will recharge the luminous buttons.

-15

Using the Remote Control

Usable Range

The remote control can be used to control the projector within the ranges shown in the illustration.

Note

• The signal from the remote control can be reflected off a screen for easy operation. However, the effective distance of the signal may differ depending on the screen material.

When using the remote control:

• Ensure that you do not drop it or expose it to moisture or high temperature.

• The remote control may malfunction under a fluorescent lamp. In this case, move the projector away from the fluorescent lamp.

Inserting the Batteries

Front View

Remote control signal transmitters

Rear View

Remote control sensor

Remote control

Remote control signal transmitters

23' (7 m)

Remote control sensor

23' (7 m)

Remote control

Press the tab and lift open the battery cover in the direction of the arrow

2 Insert the batteries.

• Insert the batteries making sure the polarities correctly match the marks inside the battery compartment.

and

3 Insert the tabs on the end of the

battery cover into their slots and press the cover into position.

Incorrect use of the batteries may cause them to leak or explode. Please follow the precautions below.

Caution

• Danger of explosion if battery is incorrectly replaced. Replace only with the alkaline or manganese batteries.

• Insert the batteries making sure the polarities correctly match the

• Batteries of different types have different properties, therefore do not mix batteries of different types.

• Do not mix new and old batteries.

This may shorten the life of new batteries or may cause old batteries to leak.

• Remove the batteries from the remote control once they have run out, as leaving them in can cause them to leak. Battery fluid from leaked batteries is harmful to skin, therefore ensure you wipe them first and then remove them using a cloth.

• The batteries included with this projector may run down in a short period, depending on how they are kept. Be sure to replace them as soon as possible with new batteries.

• Remove the batteries from the remote control if you will not be using the remote control for a long time.

• Comply with the rules (ordinance) of each local government when disposing of worn-out batteries.

and marks inside the battery compartment.

-16

Using the Remote Control with a Signal Cable

When the signals from the remote control cannot be reached due to the positioning of the projector, use a ø3.5 mm minijack cable to connect the remote control to the projector. Now you can control the projector with the remote control.

Introduction

Rear view

To WIRED REMOTE terminal

ø3.5 mm minijack cable (commercially available or available as Sharp service part QCNWGA038WJPZ)

Remote control

To WIRED R/C JACK

Note

• The wireless remote function is not possible when the ø3.5 mm minijack cable is connected to the projector. Should the wireless remote operation be required, the ø3.5 mm minijack cable should be disconnected from the projector.

Switching the Remote Control Mode

The remote control has two functions. One is projector control and the other is wireless computer mouse. Slide the ADJ./MOUSE switch on the remote control to other side compatible to the desired usage.

Projector control Wireless computer mouse

ADJ.

MOUSE

ADJ.

MOUSE

Info

• When using the remote control as the wireless computer mouse, connect the optional remote receiver (AN-MR2) to the computer. (See page 18.)

-17

Using the Remote Control

Using the Remote Control as a Wireless Computer Mouse

When connecting the optional remote receiver (AN-MR2) to the computer, you can use the remote control as the wireless computer mouse.

1 Connect the optional remote re-

ceiver to the USB terminal on the computer.

2 Slide the ADJ./MOUSE

ADJ.

switch on the remote control to the MOUSE position.

MOUSE

3 Use the mouse function.

• Point the remote control at the remote receiver.

■ When moving the cursor

Press '/"/\/|.

■ When left-clicking

Press L-CLICK.

■ When right-clicking

Press R-CLICK.

Computer

To USB terminal

Remote receiver

ADJ./MOUSE switch

Mouse/adjustment button ('/"/\/|)

■ When your computer supports only a one-click mouse (such as Macintosh

Press L-CLICK or R-CLICK. (L-CLICK and R-CLICK have common function.)

Note

• This function only works with the Microsoft Windows® OS and Mac OS®. However, this function does not work with the following operation systems that do not support USB.

• Versions earlier than Windows

• Versions earlier than Mac OS

• Confirm that the computer recognizes the USB

connection.

• While the remote control is connected to the projector with a signal cable, you cannot use the wireless computer mouse function.

-18

95.

NT4.0.

8.5.

)

R-CLICK button

L-CLICK button

Quick Start

This section shows the basic operation (projector connecting with the computer). For details, see the page described below for each step.

Setup and Projection

In this section, connection of the projector and the computer is explained using one example.

8 5 3 6

8 5 3

Quick Start

4 6

1. Place the projector facing a screen

Page 21

2. Connect the projector to the computer and plug the power

cord into the AC socket of the projector

When connecting equipment other than the computer, see pages 25 and 26.

3. Remove the lens cap and turn the projector on

Press ON on the projector or on the remote control.

Pages 24, 28

Page 28

-19

Quick Start

4. Adjust the angle

Adjust the projector angle:

••

•

Shift the lens horizontally and vertically.

••

Press H&V LENS SHIFT on the projector or

on the remote control.

Press

••

•

Adjust the projector angle by rotating the adjust-

••

ment feet.

', ", \ or |

remote control.

on the projector or the

Pages 29, 30

5. Adjust the focus and the zoom

1 Press FOCUS +/– on the projector or on the remote control to adjust the focus.

11 22

2 Press ZOOM +/– on the projector or on the remote control to adjust the zoom.

Correcting the image distortion due to the projection angle

1 Press KEYSTONE on the projector or on the remote control.

11 22

2 Press ENTER on the projector or on the remote control.

22 33

3 Press ', ", \ or | to move the position for the upper left of the image.

33 44

4 Press ENTER to set the position.

44 55

Repeat the same procedure with the positions for the upper right, lower right and lower left of the image.

••

•

When the position of the lower left is set, the correction is made and the display disappears.

••

Page 31

Page 32

7. Select the input mode

Press INPUT on the projector or COMPUTER1 on the remote control to select the “COMPUTER1” mode.

On the

projector

••

• When you press INPUT on the projector, the INPUT list appears.

••

Press '/" to switch the INPUT mode and then press ENTER.

••

•

When using the remote control, press COMPUTER1/2, DVI, HDMI, VIDEO or S-VIDEO to switch the input mode.

••

On the remote

control

INPUT list

On-screen display (RGB)

Page 36

8. Turn the power off

Press STANDBY on the projector or on the remote control. While the confirmation message is displayed, press STANDBY again.

••

• You can unplug the power cord even if the projector is operating.

••

• Even if you unplug the power cord from the AC outlet, the cooling fan continues to run for a while.

••

-20

" On-screen display

Page 28

Setting Up the Projector

For optimal image quality, position the projector perpendicular to the screen with the projector’s feet flat and level. Doing so will eliminate the need for Keystone correction and provide the best image quality.

Note

• The projector lens should be centered in the middle of the screen. If the horizontal line passing through the lens center is not perpendicular to the screen, the image will be distorted, making viewing difficult.

• For an optimal image, position the screen so that it is not in direct sunlight or room light. Light falling directly on the screen washes out the colors, making viewing difficult. Close the curtains and dim the lights when setting up the projector in a sunny or bright room.

Standard Setup (Front Projection)

■ Place the projector at the required distance from the screen according to the desired picture size. (For details, refer to “SETUP MANUAL” contained on the supplied CD-ROM.)

Setup

Side View

Screen

Center of screen

Lens center

Lower lens shift position (High mount setup)

Lens center

Upper lens shift position (Desktop setup)

Top View

Screen

Center of screen

Indication of the Projection Image Size and Projection Distance

For details, refer to “SETUP MANUAL” contained on the supplied CD-ROM. Example : NORMAL Mode (4:3) for the standard zoom lens (AN-P18EZ)

Picture Size

300"

200"

100"

80" 60"

48"

64"

36"

80"

60"

48"

160"

120"

240"×180"

Projection Distance

Lens center

Leftmost lens shift position

Rightmost lens shift position

"–

7'2

(2.2 m – 2.7 m)

9'7

12'

"– (2.9 m

3.7 m)

–

12'

15'

–

(3.7 m

4.6 m)

–

24'

30'

– (7.3 m

9.1 m)

–

36'

45'

–

(11.0 m – 13.7 m)

-21

Setting Up the Projector

Standard Zoom Lens (AN-P18EZ : Standard Equipment with XG-P610X)

F2.5, f=25.5-32 mm

4:3 Signal Input (Normal Mode)

Picture (Screen) size Projection distance [L]

Distance from the lens center to

the bottom of the image [H]

Diag. [χ] Width Height Minimum [L1] Maximum [L2] Lower [H1] Upper [H2]

300'' (762 cm)

250'' (635 cm)

200'' (508 cm)

150'' (381 cm)

120'' (305 cm)

100'' (254 cm)

80'' (203 cm)

70'' (178 cm)

60'' (152 cm)

: Picture size (diag.) (in/cm) L1: Minimum projection distance (m/ft) L2: Maximum projection distance (m/ft) H1: Lower distance from the lens center to the bottom of the image (cm/in) H2: Upper distance from the lens center to the bottom of the image (cm/in) W: Distance from the lens center to the center of the image (cm/in)

610 cm (240'')

508 cm (200'')

406 cm (160'')

305 cm (120'')

244 cm (96'')

203 cm (80'')

163 cm (64'')

142 cm (56'')

122 cm (48'')

457 cm (180'')

381 cm (150'')

305 cm (120'')

229 cm (90'')

183 cm (72'')

152 cm (60'')

122 cm (48'')

107 cm (42'')

91 cm (36'')

11.0 m (36' 0'')

9.1 m (30' 0'')

7.3 m (24' 0'')

5.5 m (18' 0'')

4.4 m (14' 5'')

3.7 m (12' 0'')

2.9 m (9' 7'')

2.6 m (8' 5'')

2.2 m (7' 2'')

13.7 m (45' 0'')

11.4 m (37' 6'')

9.1 m (30' 0'')

6.9 m (22' 6'')

5.5 m (18' 0'')

4.6 m (15' 0'')

3.7 m (12' 0'')

3.2 m (10' 6'')

2.7 m (9' 0'')

–480.1 cm (–189")

–400.1 cm (–157

–320.0 cm (–126'')

–240.0 cm (–94

–192.0 cm (–75

–160.0 cm (–63'')

–128.0 cm (–50

–112.0 cm (–44

–96.0 cm (–37

The formula for picture size and projection distance

[m/cm]

L1 (m) = 0.03658 L2 (m) = 0.04572 H1 (cm) = –1.6002 H2 (cm) = 0.0762 W (cm) = ±0.7112

[Feet/inches]

L1 (ft) = 0.03658χ / 0.3048 L2 (ft) = 0.04572 H1 (in) = –1.6002χ / 2.54 H2 (in) = 0.0762χ / 2.54 W (in) = ±0.7112

/2"

/32"

/64"

)

22.9 cm (9")

19.1 cm (7

15.2 cm (6'')

11.4 cm (4

9.1 cm (3

7.6 cm (3'')

6.1 cm (2

5.3 cm (2

4.6 cm (1

χ χ

/ 0.3048

/ 2.54

Distance from the lens

center to the center of

±213.4 cm (84'')

±177.8 cm (70'')

/2")

±142.2 cm (56'')

±106.7 cm (42'')

/2")

/32")

/64")

the image [W]

±85.3 cm (33

±71.1 cm (28'')

±56.9 cm (22

±49.8 cm (19

±42.7 cm (16

/32")

/64")

16:9 Signal Input (Stretch Mode)

Picture (Screen) size Projection distance [L]

Diag. [χ]

250'' (635 cm)

200'' (508 cm)

150'' (381 cm)

120'' (305 cm)

100'' (254 cm)

80'' (203 cm)

60'' (152 cm)

Width Height Minimum [L1] Maximum [L2] Lower [H1] Upper [H2]

553 cm (218'')

443 cm (174'')

332 cm (131'')

266 cm (105'')

221 cm (87'')

177 cm (70'')

133 cm (52'')

311 cm (123'')

249 cm (98'')

187 cm (74'')

149 cm (59'')

125 cm (49'')

100 cm (39'')

75 cm (29'')

10.0 m (32' 8")

8.0 m (26' 2")

6.0 m (19' 7")

4.8 m (15' 8")

4.0 m (13' 1")

3.2 m (10' 6")

2.4 m (7' 10")

12.5 m (40' 10")

10.0 m (32' 8")

7.5 m (24' 6")

6.0 m (19' 7")

5.0 m (16' 4")

4.0 m (13' 1")

3.0 m (9' 10")

Distance from the lens center to

the bottom of the image [H]

–384.0 cm (–151 11/64")

–307.2 cm (–120

–230.4 cm (–90

–184.3 cm (–72

–153.6 cm (–60

–122.9 cm (–48

–92.1 cm (–36

The formula for picture size and projection distance

[m/cm]

L1 (m) = 0.03985 L2 (m) = 0.04981 H1 (cm) = –1.53583 H2 (cm) = 0.29056 W (cm) = ±0.77483

[Feet/inches]

L1 (ft) = 0.03985 L2 (ft) = 0.04981χ / 0.3048 H1 (in) = –1.53583χ / 2.54 H2 (in) = 0.29056 W (in) = ±0.77483χ / 2.54

72.6 cm (28 19/32")

58.1 cm (22

/16")

43.6 cm (17

/64")

34.9 cm (13

/16")

29.1 cm (11

/32")

23.2 cm (9

/8")

17.4 cm (6

/32")

χ χ

/ 0.3048

/ 2.54

/32")

Distance from the lens

center to the center of

±193.7 cm (76

±155.0 cm (61

/8")

±116.2 cm (45

/32")

/64")

/16")

/64")

the image [W]

±93.0 cm (36

±77.5 cm (30

±62.0 cm (24

±46.5 cm (18

/64")

/4")

/64")

/2")

/32")

/64")

Note

• Allow a margin of error in the value in the diagrams above.

• When the distance from the lens center to the bottom of the image [H] is a negative number, this indicates

that the bottom of the image is below the lens center.

• See page 21 about projection distance [L] and distance from the lens center to the bottom of the image [H].

-22

Projecting a Reversed Image

Projection from behind the Screen

■ Place a translucent screen between the projector and the audience.

■ Reverse the image by selecting “Rear” in the “PRJ Mode” menu. (See page 62.)

Tr anslucent screen

Audience

Projection Using a Mirror

■ Place a mirror (normal flat type) in front of the lens.

■ When the translucent screen is placed between the mirror and audience, select “Front” in the “PRJ Mode”

menu. (See page 62.)

■ When the mirror is placed on the audience side, select “Rear” in the “PRJ Mode” menu. (See page 62.)

Set to “Front”

Mirror

Set to “Rear”

Setup

Tr anslucent screen

Audience

Info

• When using a mirror, ensure that both the projector and the mirror are carefully placed so the projected light does not shine into the eyes of the audience.

Audience

Mirror

Ceiling-mount Setup

■ It is recommended that you use the optional Sharp ceiling-mount adaptor and unit for this installation. Before mounting the projector, contact your nearest Sharp Authorized Projector Dealer or Service Center to obtain the recommended ceiling-mount adaptor and unit (sold separately).

■ Invert the image by selecting “Ceiling + Front” in “PRJ Mode”. See page 62 for use of this function.

-23

Connecting the Projector to Other Equipment

Before connecting, ensure that the power cord of the projector is unplugged from the AC outlet and turn off the equipment to be connected. After making all connections, turn on the projector and then the other pieces of equipment. When connecting a computer, ensure that it is the last equipment to be turned on after all the connections are made.

IMPORTANT: Ensure that the appropriate input mode has been selected on the projector before you

turn on the connected equipment.

• For more details of connection and cables, refer to the operation manual of the connected equipment.

• You may need other cables or connectors not listed below.

Terminals on the Projector

Equipment Cable

Computer

Terminal on connected equipment

RGB output terminal

Computer audio output terminal

RGB output terminal

Computer audio output terminal

DVI digital output terminal

Computer audio output terminal

HDMI digital output terminal

RGB cable (supplied)

Computer audio cable (ø3.5 mm stereo minijack, commercially available)

Mini D-sub 15 pin/5 BNC cable (commercially available)

Computer audio cable (ø3.5 mm stereo minijack, commercially available)

DVI Digital cable (commercially available)

Computer audio cable (ø3.5 mm stereo minijack, commercially available)

HDMI cable (commercially available) HDMI

Terminal on the projector

COMPUTER/COMPONENT1

COMPUTER/COMPONENT2

DVI-D

Note

• When connecting the projector to a compatible computer other than a PC (VGA/SVGA/XGA/SXGA/UXGA) or Macintosh (i.e. Workstation), a separate cable may be needed. Please contact your dealer for more information.

• With the DVI digital connection, select “D. PC RGB” for “Signal Type” in the “Picture” menu.

• See page 75 “Computer Compatibility Chart” for a list of computer signals compatible with the projector. Use

with computer signals other than those listed may cause some of the functions to not work.

• A Macintosh adaptor may be required for use with some Macintosh computers. Contact your nearest Macintosh Dealer.

• Depending on the computer you are using, an image may not be projected unless the computer’s external output port is switched on (e.g. Press “Fn” and “F5” keys simultaneously when using a SHARP notebook computer). Refer to the specific instructions in your computer's operation manual to

enable your computer’s external output port.

-24

Equipment Cable

Video equipment, Camera, Video game

Terminal on connected equipment

HDMI digital output terminal

DVI digital output terminal

HDMI cable (commercially available)

DVI Digital cable (commercially available)

Terminal on the projector

HDMI

DVI-D

Audio output terminal

RGB video output terminal

Audio output terminal

Component video output terminal

Audio output terminal

D-video output terminal

Audio output terminal

ø3.5 mm stereo minijack to RCA audio cable (commercially available)

5 BNC cable (commercially available)

ø3.5 mm stereo minijack to RCA audio cable (commercially available)

Component cable (commercially available) + BNCRCA adaptor plug (commercially available)

ø3.5 mm stereo minijack to RCA audio cable (commercially available)

Cables for a camera or a video game/3 RCA to mini D-sub 15 pin cable (optional, AN-C3CP2)

ø3.5 mm stereo minijack to RCA audio cable (commercially available)

RCA adaptor plug (commercially available)

COMPUTER/COMPONENT2

COMPUTER/COMPONENT1

Note

• Select the input signal type of the video equipment when connecting to the COMPUTER1/2, DVI-D or HDMI terminal. See page 51.

• The HD/C sync and VD terminals may be used depending on the specifications of the DTV decoder connected to this projector. Please refer to the operation manual of the DTV decoder for details.

• The HD/C sync terminal of the 5 BNC terminal is only for TTL signal.

• Select “480P” or “576P” for “Resolution” on the “Fine Sync” menu, if necessary. (See page 53.)

• While the projector is connected to video equipment that has an HDMI output terminal, only the video

signal can be input to the projector. (Connect the AUDIO input terminal for audio input.)

• Depending on specifications of video equipment or HDMI to DVI digital cable, the signal transmission may not work property. (The HDMI specification does not support all connections to video equipment that has HDMI digital output terminal using HDMI to DVI digital cable.)

• For details on compatibility for connection, see support information on DVI connection provided by the video equipment manufacturer.

• When you connect video equipment with a 21-pin RGB output (Euro-scart) to the projector, use a commercially available cable that fits in the projector terminal you want to connect.

• The projector does not support RGBC signals via the Euro-scart.

Connections

-25

Connecting the Projector to Other Equipment

Equipment Cable

Video equipment, Camera, Video game

Monitor

Amplifier

Terminal on connected equipment

S-video output terminal

Audio output terminal

Video output terminal

Audio output terminal

RGB input terminal

Audio output terminal

S-video cable (commercially available)

RCA audio cable (commercially available)

Video cable (commercially available)

RCA audio cable (commercially available)

RGB cable (supplied or commercially available)

ø3.5 mm stereo minijack to RCA audio cable (commercially available)

Terminal on the projector

S-VIDEO

VIDEO

MONITOR OUT

Note

• When using the ø3.5 mm mono audio cable, the volume level will be half of when using the ø3.5 mm stereo audio cable.

• Video signal for monitor output is analog RGB signal as well as component signal (COMPUTER1/2). DVI and HDMI input video signals would not be output.

• When the audio from HDMI input is directed to the MONITOR OUT (AUDIO) terminal, output will be generated as Linear PCM audio.

• HDMI (High-Definition Multimedia Interface) is a digital AV interface that can deliver a high-definition video signal, multi-channel audio signal, and bi-directional control signal all in just one cable.

• Because it is compatible with the HDCP (High-bandwidth Digital Content Protection) system, the digital video signal does not degrade when transmitted, and a high-quality image with a simple connection can be enjoyed.

• The HDMI terminal does not support the CEC signal.

This projector is able to process the following signals when connected to HDMI equipment:

• Video signal: For details, see “HDMI Support” in the list of “Computer Compatibility Chart” on page 75.

• Audio signal: Linear PCM audio

• Sampling frequency: 48kHz/44.1kHz/32kHz

-26

Controlling the Projector by a Computer

When the RS-232C terminal on the projector is connected to the RS-232C serial terminal on the computer, or when the LAN terminal on the projector is connected to the LAN terminal on the computer, the computer can be used to control the projector. Refer to the “SETUP MANUAL” contained on the supplied CD-ROM for details.

When connecting to a computer using an RS-232C serial control cable

Computer

To RS-232C terminal

Rear view

To RS-232C terminal

RS-232C serial control cable

(cross type, commercially available)

Note

• The RS-232C function may not operate if your computer terminal is not correctly set up. Refer to the operation manual of the computer for details.

• Refer to “SETUP MANUAL” contained on the supplied CD-ROM for the RS-232C specifications and commands.

Info

• Do not connect the RS-232C cable to a terminal other than the RS-232C terminal on the computer. This may damage your computer or projector.

• Do not connect or disconnect an RS-232C serial control cable to or from the computer while it is on. This may damage your computer.

Connections

When connecting to the LAN terminal using a LAN cable

LINK LED (green)

Hub or computer

Illuminates when linked.

TX/RX LED (yellow) Illuminates when transmitting/receiving data.

Rear view

* To ensure safety, do not

connect the LAN terminal with any cables such as a telephone line that may

To LAN terminal

cause excessive voltage.

LAN cable (Category 5 type, commercially available)

Note

•

When connecting to a hub, use straight-through Category 5 (CAT.5) type cable (commercially available).

• When connecting to a computer, use cross-over Category 5 (CAT.5) type cable (commercially available).

-27

Turning the Projector On/Off

Connecting the Power Cord

Plug the supplied power cord into the AC socket on the rear of the projector. Then plug into the AC outlet.

Turning the Projector On

Before performing the steps in this section, connect any equipment that you use with the projector. (See pages 24–27.)

Remove the lens cap and press ON on the projector or on the remote control.

• The power indicator illuminates green.

• After the lamp indicator illuminates, the projec-

tor is ready to start operation.

• When System Lock is set, the keycode input screen appears. Enter the right keycode to start projection. See page 60 for details.

Note

• The lamp indicator illuminates or blinks, in-

dicating the status of the lamp.

Green: The lamp is on. Blinking green: The lamp is warming up. Red:

The lamp is shut down abnormally

•

• If the projector is put into standby mode and

or the lamp should be replaced.

When switching on the projector, a slight flickering of the image may be experienced within the first minute after the lamp has been illuminated. This is normal operation as the lamp’s control circuitry is stabilizing the lamp output characteristics. This does not indicate malfunction.

immediately turned on again, the lamp may take some time to illuminate.

Supplied accessory

Rear view

To AC socket

Power cord

To AC outlet

Info

• When “Auto Restart” is set to “On”:

If the power cord is unplugged from the AC outlet or the breaker switch is turned off when the projector is on, then the projector automatically turns on when the power cord is plugged into the AC outlet or the breaker switch is turned on. (See page 63.)

• English is the factory preset language. If you want to change the on-screen display to another language, change the language according to the procedure on page 65.

STANDBY button

ON button

STANDBY

button

Turning the Power Off

(Put-

ting the Projector into Standby Mode)

Press STANDBY on the projector or on the remote control, then press that button again while the confirmation message is displayed, to put the projector into standby mode.

-28

Power indicator

Lens cap

▼On-screen display

Lamp indicators1, 2

Info

• You can unplug the power cord from the AC outlet even if the cooling fan is still running. Even if you unplug the power cord from the projector, the cooling fan continues to run for a while.

Image Projection

Shifting the Lens

In addition to the zoom function and adjustment of projection angle using the adjustment feet, you can adjust the position of the projection using the lens shift function. This is a useful function in cases such as when the screen cannot be moved.

When moving upward or downward When moving in the left and right direction

Adjustable range

••

• The adjustable range is shown below.

••

Horizontal range: ±35% Vertical range: ±55% The adjustable range has limitations even within the range shown above. Select the correct type of lens that match with the installed lens (see page 62).

••

• The image can be adjusted as shown on the diagram.

••

Adjustable range

AN-P15EZ, AN-P18EZ, AN-P23EZ, AN-P30EZ, AN-P45EZ

Position of the image when the image is centered, both vertically and horizontally, in lens shift

H X 55%

Height of the image

Width of the image

W X 20%

W X 35% W X 35%

W X 20%

H X 31%

AN-P8EX, AN-P12EX

Position of the image when the image is centered, both vertically and horizontally, in lens shift

H X 18%

Height of the image

Width of the image

W X 11%W X 11%

Basic Operation

-29

Image Projection

1 Press H&V LENS SHIFT on the

projector or on the remote control.

• Pressing ENTER on the projector or on the remote control displays the test pattern. Checking the test pattern is useful for more accurate adjustment.

▼On-screen display

2 Press ', ", \ or | on the pro-

jector or the remote control to adjust the image position.

H&V LENS SHIFT button

Mouse/adjustment button ('/"/\/|) ENTER button

UNDO button

H&V LENS SHIFT button

Adjustment button

('/"/\/|) ENTER button

UNDO button

Note

• When UNDO is pressed, the lens shift reset screen is displayed. Lens shift can be reset to factory default with this screen.

Using the Adjustment Feet

• When the position of the projected image cannot be adjusted with the lens shift function, use the adjustment feet to adjust the projected angle.

• The height of the projector can be adjusted using the adjustment feet when the screen is located higher than the projector, the screen is inclined or when the installation site is slightly inclined.

• Install the projector so that it is as perpendicular to the screen as possible.

1 Rotate the adjustment feet to

adjust the projected angle.

• The projector is adjustable up to approximately 5 degrees.

Warning!

• Do not hold the lens and lens cover when projector angle is adjusted.

• Use caution not to pinch your finger in the space between the adjustment foot and the projector when the projector angle is lowered.

Down

Adjustment feet

Down

-30

Adjusting the Focus

Press FOCUS +/– on the projector or on the remote control to adjust the focus.

▼On-screen display

Info

• It is recommended that the focus be adjusted after the projector has warmed up for at least 30 minutes.

ZOOM buttons

FOCUS buttons

ZOOM buttons

Basic Operation

Adjusting the Projected Image Size

Press ZOOM +/– on the projector or on the remote control to adjust the projected image size.

▼On-screen display

• After you have pressed FOCUS or ZOOM on the remote control or the projector, you can display the test pattern by pressing ENTER. The test pattern is useful for making more accurate adjustments.

• For fine adjustments, when H&V LENS SHIFT, FOCUS or ZOOM is pressed, the

projected image moves a small amount in the desired direction for approximately one second. Hold down the buttons to move the projected image quickly.

Note

-31

Image Projection

Correcting Trapezoidal Distortion

When the image is projected either from the top or from the bottom towards the screen at an angle, the image becomes distorted trapezoidally. The function for correcting trapezoidal distortion is called Keystone Correction.

There are the two types of the Keystone Correction.

1) “GEOMETRIC ADJUSTMENT” for correcting an image designating the corner of the projected image

2) “H&V KEYSTONE” for designating the correction of the horizontal and vertical axes

Selecting the Type of the Correction

Select the type of the keystone correction.

Press KEYSTONE on the projector or on the remote control.

• “GEOMETRIC ADJUSTMENT” will be dis-

played.

• Each time

toggles as follows:

GEOMETRIC → H&V KEYSTONE ADJUSTMENT

The display ← IMAGE RESIZING * disappears.

GEOMETRIC ADJUSTMENT

H&V KEYSTONE

IMAGE RESIZING

↑

KEYSTONE

For correcting an image designating the corner of the projected image

For correcting an image designating the horizontal or vertical axes

For correcting the image distortion which cannot be corrected with “H&V KEYSTONE”. *Only when “H&V KEYSTONE” is set to the values other than “0”, “IMAGE RESIZING” can be adjusted. (This function cannot be used when correcting with “GEOMETRIC ADJUSTMENT”.)

is pressed, the display

↑

KEYSTONE button

Mouse/adjustment button ('/"/\/|) ENTER button

UNDO button

KEYSTONE button

Adjustment button ('/"/\/|)

ENTER button

UNDO button

-32

GEOMETRIC ADJUSTMENT

1 Press KEYSTONE on the pro-

jector or on the remote control repeatedly until “GEOMETRIC

ADJUSTMENT” is displayed.

2 Press the buttons below to ad-

just the position, size or focus of the projected image.

• Match screen’s four sides to green test pattern.

• Pressing or H&V LENS SHIFT on the remote control allows you to shift the lens.

• Pressing ZOOM +/– on the projector or on the remote control allows you to adjust the projected image size.

• Pressing FOCUS +/– on the projector or on the remote control allows you to adjust the focus.

\ or

| on the projector

3 Press ENTER on the projector

or on the remote control.

4 Press ', ", \ or | to move the

position for the upper left of the image.

• Move the upper left of the yellow frame onto the upper left of the screen.

▼On-screen display

Geometric Adjustment

Upper Left Upper Right Lower Right

Basic Operation

Lower Left

5 Press ENTER to set the posi-

tion.

Repeat the same procedure with the positions for the upper right, lower right and lower left of the image.

• At this time, pressing UNDO on the projector or on the remote control returns to the previous screen.

• Before correcting the upper left of the image, pressing UNDO returns to the re- set confirmation screen.

• When the position of the lower left is set, the correction is made and the display disappears.

• If the message “Can not correct.” is displayed, step 2 may have been performed incorrectly. In this case, go back to step 2 and try the procedure again.

-33

Image Projection

H&V KEYSTONE

1 Press KEYSTONE on the pro-

jector or on the remote control repeatedly until “H&V KEYSTONE” is displayed.

• When the correction has already been made with “GEOMETRIC ADJUST-

MENT”, the confirmation message for resetting the correction before “H&V KEYSTONE” is displayed, and then reset.

2 Press ' or " to parallelize the

left and right sides of the projected image.

▼On-screen display

Vertical Keystone Correction (Adjustment with

' / "

)

3 Press \ or |

to parallelize the

upper and lower sides of the projected image.

4 Press KEYSTONE to display

“IMAGE RESIZING”.

• Only when “H&V KEYSTONE” is set to the values other than “0”, “IMAGE

RESIZING” works.

Horizontal Keystone Correction

\ / |

(Adjustment with

▼On-screen display

)

-34

5 Press ', ", \ or | to correct

the image distortion.

6 Press KEYSTONE to set the

position.

IMAGE RESIZING (Adjustment with

' / " / \ / |

)

Basic Operation

-35

Image Projection

Switching the Input Mode

Select the appropriate input mode for the connected equipment.

Press COMPUTER1/2, DVI, HDMI, VIDEO or S-VIDEO on the remote control to select the input mode.

■ When you select the input mode with

INPUT the remote control:

• When pears. While the Input list is displayed, follow the procedure below to switch the input mode. – Press

mode and then press ENTER.

• When “AUTO SEARCH” is selected,

• If ENTER is not pressed, the projector

Note

• When no signal is received, “NO SIGNAL” will be displayed. When non-supported signal is received, “NOT REG.” is displayed.

• The input mode is not displayed when “OSD Display” of the “Options1” menu is set to “Level A” or “Level B”. (See page 57.)

R on the projector or

R is pressed, the Input list ap-

R to select the desired input

input signal is automatically detected.

switches to the selected input mode in a few seconds.

R on

'/" buttons

COMPUTER1/2, DVI, HDMI, VIDEO and S-VIDEO buttons

Input mode menu

Adjusting the Volume

Press VOL +/– on the projector or on the remote control to adjust the volume.

Note

• Pressing VOL– will lower the volume. Pressing VOL+ will raise the volume.

• When “Pict in Pict” (see page 56) is set to “On”, audio volume cannot be adjusted on the projector. The audio volume buttons will instead function as location shift button for the smaller screen.

-36

Volume buttons

"On-screen display

Turning Off the Sound Temporarily

Press MUTE on the remote control to temporarily turn off the sound.

Note

• Pressing MUTE again will turn the sound back on.

Displaying an Enlarged Portion of an Image

Graphs, tables and other portions of projected images can be enlarged. This is helpful when providing more detailed explanations.

1 Press MAGNIFY on the re-

mote control.

• Enlarges the image.

• Pressing

duces the projected image.

or enlarges or re-

MAGNIFY (enlarge/reduce) buttons

MUTE button

"On-screen display

Mouse/adjustment button ('/"/\/|)

UNDO button

RESIZE button

Note

×1 ×4 ×9 ×16 ×36 ×64×2 ×3

• You can change the location of the en-

larged image using ', ", \ and |.

2 Press UNDO on the remote con-

trol to cancel the operation.

• The magnification then returns to ×1.

Note

In the following cases, the image will return to the normal size (×1).

- When switching the input mode.

- When UNDO has been pressed.

- When the input signal is changed.

When the input signal resolution and

refresh rate (vertical frequency) change.

- When RESIZE has been pressed.

Basic Operation

-37

Image Projection

Freezing a Moving Image

1 Press FREEZE on the remote

control.

• The projected image is frozen.

2 Press FREEZE again to return

to the moving image from the currently connected equipment.

Selecting the Picture Mode

FREEZE button

You can select the suitable picture mode for the projected image, such as movie or video game.

Press PICTURE MODE on the remote control.

• When pressing PICTURE MODE, the picture mode changes in order of

STANDARD PRESENTATION MOVIE CUSTOM

Note

• Press UNDO to return to the “STANDARD” mode while the selected picture mode is displayed.

• This function can also be accessed from the OSD menu (see page 49).

UNDO button

PICTURE MODE button

-38

This function allows you to modify or customize the resize mode to enhance the input image. Depending on the input signal, you can choose a desired image.

Resize Mode

Press RESIZE on the remote control.

• Pressing RESIZE changes the display as shown in the tables below.

• To return to the standard image, press UNDO while “RESIZE” is displayed on the screen.

• This function can also be accessed from the OSD menu (see page 56).

COMPUTER

NORMAL

1024 × 768

968 × 768

1024 × 576

1024 × 578

1024 × 576

1024 × 614

1024 × 640

NORMAL FULL BORDER

4:3 aspect ratio

Other aspect ratios

Computer

Resolution

lower than

XGA

SXGA

(1152 × 864)

Resolution

higher than

SXGA

(1280 × 1024)

Main resolution

SVGA (800 × 600)

XGA (1024 × 768)

SXGA (1152 × 864)

SXGA+ (1400 × 1050)

SXGA (1280 × 1024)

1280 × 720

1360 × 768

1366 × 768

1280 × 768

1280 × 800

Input signal

Image type

4:3 aspect ratio

5:4 aspect ratio

Mouse/adjustment button ('/"/\/|)

UNDO button

RESIZE button

FULL BORDER STRETCHDOT BY DOT

800 × 600

—

1024 × 768

For 4:3 screen For 16:9 screen

—

1152 × 864

1400 × 1050

1280 × 1024

1280 × 720

1360 × 768

1366 × 768

1280 × 768

1280 × 800

DOT BY DOT

768 × 576

—

720 × 576

—

960 × 576

922 × 576

1024 × 576

STRETCH

—

Basic Operation

1280 × 720

1360 × 768 1366 × 768

1280 × 768

1280 × 800

: Cutout area on which images cannot be projected : Area where the signals are off screen

The Digital Shift function can be used for these images.

Same as NORMAL mode.

16:9 aspect ratio

16:10 aspect ratio

*2 *2

-39

Image Projection

VIDEO/DTV

480I, 480P, 576I, 576P,

NTSC, PAL,

SECAM

720P, 1035I,

1080I, 1080P

540P

Input signal

(4:3 aspect ratio in 16:9)

Image type NORMALVideo/DTV

4:3 aspect ratio

Squeeze

Letter box

16:9 aspect ratio

For 4:3 screen For 16:9 screen

AREA ZOOM

V-STRETCH

BORDER STRETCH SMART STRETCH

*2*2 *2*2

: Cutout area on which images cannot be projected : Area on which the image is not included in the original signals

The Digital Shift function can be used for these images.

Same as NORMAL mode.

About Copyrights

• When using the RESIZE function to select an image size with a different aspect ratio to a TV program or video

image, the image will look different from its original appearance. Keep this in mind while choosing an image size.

• The use of the Resize or Keystone Correction function to compress or stretch the image for commercial

purposes/public displays in a café, hotel, etc. may be an infringement of copyright protected by law for copyright holders. Please use caution.

-40

Hiding the Projected Image (Shutter function)

This function allows you to temporarily hide the projected image.

1 Press SHUTTER CLOSE.

• The projected image is hidden.

2 Pressing SHUTTER OPEN will

turn the projected image back on.

Note

In the following cases, hiding will be cancelled automatically.

• When STANDBY on the projector or on the

remote control is pressed.

• When a caution or information message is

displayed.

• When the power is turned on.

Displaying and Setting the Break Timer

This function allows you to show the remaining time for break during meeting.

1 Press BREAK TIMER.

SHUTTER button

Mouse/adjustment button

'/"/\/|

(

UNDO button

)

Basic Operation

2 While “ ” is displayed, press ',

", \ or | to set the break timer.

• You can set anywhere between 1 and 60 minutes (in 1 units).

• The break timer starts to count down as

soon as

Note

• Pressing UNDO will cancel the break timer.

• Auto Power Off function will be temporarily dis-

abled during the break timer. When no input signal is detected for more than 15 minutes, the projector will automatically enter the standby mode if the break timer has elapsed.

• The break timer will be displayed on the startup image. To change the screen displayed during the break timer, change the setting of “Startup Image” (see page 58).

• When “Slave” is set for “Stack Setting”, the break timer is not displayed. (See page 62.)

\ or

| is pressed.

BREAK TIMER button

▼On-screen display

-41

Menu Items

The following shows the items that can be set in the projector.

“Picture” menu

COMPUTER1/2, DVI, HDMI

Main Menu Sub Menu

+30-30

Standard Presentation Movie Custom

4500K

10500K

2D Progressive 3D Progressive Film Mode

Standard Custom 1 Custom 2 Custom 3 sRGB

Off Level 1 Level 2 Level 3

COMPUTER1/2

Auto RGB Component

Auto Standard Enhanced

Auto ITU601 ITU709

*1 *4

D.PC RGB D.PC Comp. D.Video RGB D.Video Comp.

DVI


Page 49

Picture Mode

Page 49

Contrast

Bright

Color

Tint

Red

Green

Blue

Sharp

Page 49

CLR Temp

Page 50

Progressive

Page 50

C.M.S. Adjustment

Page 52

DNR

Page 50

Reset

Page 49

Signal Type

Page 51

Dynamic Range

Page 51

Color Space

Page 51

+30-30

HDMI

D.Video Auto D.Video RGB D.Video Comp. D.PC. RGB D.PC. Comp.

*1 “Color”, “Tint”, “Red”, “Green”, “Blue” and “CLR Temp” cannot be adjusted when “C. M. S. Adjustment” is set to

“sRGB”. *2 “Sharp” can be adjusted only when 480I, 480P, 540P, 576I, 576P, 720P, 1035I, 1080I or 1080P signal is input. *3 “Progressive” can be adjusted only when 480I or 576I signal is input. *4 “sRGB” can be selected under the conditions below.

• When “Signal Type” is set to “RGB”, “D. PC. RGB” or “D. Video RGB”.

• When “Signal Type” is set to “Auto” or “D. Video Auto” and the input signal is distinguished as “RGB”.

*5 “DNR” can be adjusted only when 480I, 480P, 576I or 576P signal is input. *6 “Dynamic Range” and “Color Space” can be worked only when DVI or HDMI signal is input.

-42

“Picture” menu

VIDEO/S-VIDEO

Main Menu Sub Menu


Page 49

Picture Mode

Page 49

Contrast

Bright

Color

Tint

Red

Green

Blue

Sharp

Page 49

CLR Temp

Page 50

Progressive

Page 50

C.M.S. Adjustment

Page 52

DNR

Page 50

Reset

Page 49

+30-30

Standard Presentation Movie Custom

4500K

10500K

2D Progressive 3D Progressive Film Mode

Standard Custom 1 Custom 2 Custom 3

Off Level 1 Level 2 Level 3

Useful Features

-43

Menu Items

“C.M.S.” menu

Main Menu

C.M.S.

Page 52

Sub Menu

C.M.S. Adjustment

Page 52

Target

Page 52

Lightness

Page 52

Chroma

Page 52

Hue

Page 52

Reset (This Color)

Page 52

Reset (All Colors)

Page 52

View Settings

Page 52

“Fine Sync” menu

COMPUTER1/2, DVI, HDMI

Main Menu

Fine Sync

Page 53

*6 *7

Clock

Phase

H-Pos

V-Pos

Reset

Save Setting

Select Setting

Resolution

Signal Info

Auto Sync

Auto Sync Disp

Sub Menu

+150-150

Page 53

Page 54

+30-30

+60-60

Standard Custom 1 Custom 2 Custom 3 sRGB

[R] Red [Y] Yellow [G] Green [C] Cyan [B] Blue [M] Magenta

Off Normal High Speed

Background Adjusting Disp.

*6 The “Fine Sync” menu is displayed only while the input mode is COMPUTER1/2, DVI or HDMI. *7 “Clock”, “Phase”, “H-Pos”, “V-Pos”, “Reset”, “Save Setting”, “Select Setting” and “Resolution” can be adjusted only

while the input mode is COMPUTER1 or 2.

-44

“Audio” menu

Main Menu

Audio

Page 55

Sub Menu

Balance

Treble

Bass

Reset

Page 55

Audio Out

Page 55

Speaker

Page 55

“Options 1” menu

+30-30

FAO VAO

On Off

Main Menu Sub Menu

Options 1

Page 56

Pict in Pict

Page 56

Resize

Page 56

Digi. Shift

On Off

Normal Full Dot By Dot Area Zoom V-Stretch Border Stretch Smart Stretch

+96-96

Page 57

*10

Normal Level A Level B

Auto PAL (50/60Hz) SECAM NTSC4.43 NTSC3.58 PAL-M PAL-N

Delete

Logo Custom Blue None

Logo Custom None

On Off

OSD Display

Page 57

Video System

Page 57

Image Capture Save Image

Page 57

Background

Page 58

Startup Image

Page 58

Eco Mode

Page 58

Auto Search

Page 58

Auto Power Off

Page 58

System Lock

Page 59

*8 Item when inputting RGB signal through COMPUTER1/2, DVI or HDMI. *9 Selectable items in “Resize” mode may differ depending on the signal. *10 Item when selecting VIDEO or S-VIDEO.

Useful Features

-45

Menu Items

“Options 2” menu

Main Menu Sub Menu

Options 2

Page 61

Password

Page 61

Lamp Mode

Page 62

Lens Type

Page 62

PRJ Mode

Page 62

Stack Setting

Page 62

Pair Stack

Page 63

Keylock Level

Page 63

Set Inputs

Page 63

Fan Mode

Page 63

Auto Restart

Page 63

RS-232C

Page 64

Monitor Out

Page 64

LAN/RS232C

Page 64

Network

Page 64

Service Mode

Page 65

All Reset

Page 65

Old Password New Password Reconfirm

Both Lamps Lamp 1 Only Lamp 2 Only Equal Use

Type 1 Type 2 Type 3 Type 4 Type 5 Type 6 Type 7

Front Ceiling + Front Rear Ceiling + Rear

Normal Master Slave

Normal Level A Level B

COMPUTER1 [ON/OFF] COMPUTER2 [ON/OFF] DVI [ON/OFF] HDMI [ON/OFF] VIDEO [ON/OFF] S-VIDEO [ON/OFF]

Normal High

On Off

9600 bps 38400 bps 115200 bps

Enable Disable

DHCP Client [ON/OFF]

TCP/IP

Page 65

*11

IP Address Subnet Mask Gateway

“Language” menu

Main Menu Sub Menu

Language

Page 65

English Deutsch Español Nederlands Français Italiano Svenska Português

polski Türkçe

“Status” menu

Main menu

Status

Page 65

*11 Adjustable only when “DHCP Client” is set to “OFF”

-46

Using the Menu Screen

MENU button

Adjustment buttons ('/"/\/|) ENTER button

UNDO button

Menu Selections

• This operation can also be performed by using the buttons on the projector.

1 Press MENU.

• The “Picture” menu screen for the selected input mode is displayed.

2 Press

menu items.

\ or

| to display the other

Menu items

Example: “Picture” screen menu for

COMPUTER1 (RGB) mode

MENU button

Mouse/adjustment button ('/"/\/|)

ENTER button

UNDO button

• Menu items are as shown below.

Menu item

Note

• The “Fine Sync” menu is not available for VIDEO or S-VIDEO.

Useful Features

-47

Using the Menu Screen

There are two methods of adjustment depending on the menu item. Use the applicable method from Example 1 or 2 shown below.

Example 1: Adjusting “Bright”

3 Press

' or

" to select the item

you want to adjust.

• Pressing displays the items on the lower part of the “Picture” menu.

To adjust the projected image while viewing it

Press ENTER.

• The selected single adjustment item (e.g. “Bright”) appears instead of the menu.

• When pressing item (“Color” after “Bright”) will be displayed.

' or

", the following

Single adjustment item

Note

• Press UNDO to return to the previ- ous screen.

4 Press

\ or

| to adjust the item

selected.

• The adjustment is stored.

5 Press MENU.

• The menu screen will disappear.

Example 2: Selecting “Signal Type”

3 Press

' or

" to select the item

you want to set and then press ENTER.

4 Press

' or

" to select the de-

sired item and then press ENTER.

5 Press MENU.

• The menu screen will disappear.

-48

Picture Adjustment (“Picture” menu)

| |

| Page 1

| |

| Page 2

| |

Menu operation Page 47

6 7 8

Selecting the Picture Mode

This function allows you to select the picture mode in accordance with brightness of the room or content of the image to be projected. In all picture modes, items on the “Picture” menu can be adjusted and saved.

Selectable items Standard Presentation

Movie

Custom

For standard image Brightens darker portions of image for more enhanced presentations. Gives greater depth to darker portions of image for a more exciting theater experience. The factory preset value is the same as the one of “Standard”. Using the dedicated software “Sharp Gamma Manager” allows you to adjust the gamma curve. Visit “http://sharp-world.com/projector/” for details.

Description

Note

• You can also press PICTURE MODE on the re- mote control to select the picture mode. (See page 38.)

3 4

6 7 8

2 Adjusting the Image

Select a picture mode before adjusting the image.

Selectable items Contrast Bright

Color

Tint

Red

Green

Blue

Sharp

Press

For less contrast For less brightness For less color intensity For making skin tones purplish For weaker red For weaker green For weaker blue For less sharpness

Press

For more contrast For more brightness For more color intensity For making skin tones greenish For stronger red For stronger green For stronger blue For more sharpness

*1 “Color”, “Tint”, “Red”, “Green” and “Blue” cannot

be adjusted when “C.M.S. Adjustment” on the “C.M.S.” menu is set to “sRGB”. (See page 52.)

*2 “Sharp” can be adjusted only when 480I, 480P,

540P, 576I , 576P, 720P, 1035I, 1080I or 1080P DTV signal is input during the COMPUTER1/2, DVI, HDMI mode; or the input mode is set to VIDEO or S-VIDEO.

Note

• To reset all adjustment items, select “Reset” and press ENTER.

Useful Features

-49

Picture Adjustment (“Picture” menu)

3 Adjusting the Color Temperature

5 Reducing Image Noise (DNR)

Menu operation Page 47

Selectable items

4500K

10500K

For lower color temperature for warmer, reddish incandescent-like images.

For higher color temperature for cooler, bluish, fluorescent-like images.

Description

Note

• “CLR Temp” cannot be set when “C.M.S. Adjustment” on the “C.M.S.” menu is set to “sRGB”. (See page 52.)

Selecting the Progressive Mode

Selectable items 2D Progressive 3D Progressive

Film Mode

The film source is a digital video recording with the original encoded as is at 24 frames/second. The projector can convert this film source to progressive video at 60 frames/second with NTSC and PAL60Hz or at 50 frames/second with PAL50Hz and SECAM to play back a high-definition image.

Useful to display fast-moving images such as sports and action films. Useful to display relatively slowmoving images such as drama and documentary more clearly. Reproduces the image of film source* clearly. Displays the optimized image of film transformed with three-two pull down (NTSC and PAL60Hz) or two-two pull down (PAL50Hz and SECAM) enhancement to progressive mode images.

Description

Video digital noise reduction (DNR) provides high quality images with minimal dot crawl and cross color noise.

Selectable items Off Level 1–3

DNR does not function. Sets the DNR level.

Description

Note

• Set a level so as to view a clearer picture.

Make sure to set “DNR” to “Off” in the following cases:

• When the image is blurry.

• When the contours and colors of moving im-

ages drag.

• When TV broadcasts with weak signals are projected.

Info

• This function is available for all signals with VIDEO or S-VIDEO.

• This function is available for 480I, 480P, 576I and 576P signals with COMPUTER1/2, DVI or HDMI.

Note

•

In NTSC or PAL60Hz, even if the 3D Progressive mode has been set, the three-two pull down enhancement will be enabled automatically when the film source has been entered.

•

When the image is blurred or noisy, switch to the optimal mode.

•

When using progressive inputs, inputs are directly displayed so that “2D Progressive”, “3D Progressive” and “Film Mode” cannot be selected.

-50

Menu operation Page 47

6 Selecting the Signal Type

When using an input mode other than S-VIDEO or VIDEO input, set the signal type setting to the corresponding input signal type (RBG or Component).

■ When COMPUTER1/2 is selected for the input mode

Selectable items

Auto

RGB Component

Automatically selects the appropriate input signal between RGB and Component. Set when RGB signals are received. Set when component signals are received.

Description

■ When DVI is selected for the input mode

Selectable items

D. PC RGB

D. PC Comp.

D. Video RGB

D. Video Comp.

Set when digital PC RGB signals are received from the computer. Set when digital PC component signals are received from the computer. Set when digital video RGB signals are received from video equipment. Set when digital video component signals are received from video equipment.

Description

■ When HDMI is selected for the input mode

This function sets the type of picture signal input from HDMI-compatible equipment.

Selectable items

D. Video Auto

D. Video RGB

D. Video Comp.

D. PC RGB

D. PC Comp.

Automatically set the RGB or component signal when digital video signals are received from video equipment. Set when digital video RGB signals are received from video equipment. Set when digital video component signals are received from video equipment. Set when digital PC RGB signals are received from the computer. Set when digital PC component signals are received from the computer.

Description

7 Selecting the Dynamic

Range

An optimum picture may not be displayed if a DVI-D or HDMI capable device’s output signal type and the projector’s input signal type do not match. If this should occur, switch the “Dynamic Range”mode.

Selectable items

Auto

Standard

Enhanced

8 Selecting the Color Space

This function select the color space for signals input from a DVI-D- or HDMI-compatible device.

Selectable items

Auto

ITU601 ITU709

In most circumstances, “Auto” should be selected. When the black levels of the image show banding or appear faded, select the item that results in the better picture quality.

In most circumstances, “Auto” should be selected. Select the item that results in the better picture quality.

Description

Useful Features

-51

Color Management System (“C. M. S.” menu)

Menu operation Page 47

Setting the Brightness of

1 Selecting the Color

Reproduction Mode

This function allows you to select the color reproduction mode for the projected images.

Selectable items Standard Custom 1 – 3

sRGB

Standard settings “Lightness”, “Chroma” and “Hue” can be adjusted for each of the six colors. A natural tint based on an original image from the computer.

Description

the Target Color

This function allows you to set the brightness of the selected target color.

Press \ Press |

For less brightness of the target color

Setting the Chromatic

For more brightness of the target color

Value of the Target Color

This function allows you to set the chromatic value of the selected target color.

Press \ Press |

For less chromatic value of the target color

5 Setting the Hue of the

For more chromatic value of the target color

Target Color

Note

• sRGB is an international standard of color reproduction regulated by the IEC (International Electrotechnical Commission). As the fixed color area has been decided by the IEC, the images are displayed in a natural tint based on an original image, when “C.M.S. Adjustment” is set to “sRGB”.

• You cannot set “Color”, “Tint”, “Red”, “Green”, “Blue”, “CLR Temp” on the “Picture” menu, when “C.M.S. Adjustment” is set to “sRGB”.

• For additional information about the sRGB function, visit “http://www.srgb.com/”.

Info

• When “C.M.S. Adjustment” is set to “sRGB”, the projected image may become dark, but this does not indicate a malfunction.

2 Selecting the Target Color

This function allows you to select the target color for adjusting the display characteristics.

Red Cyan Yellow Blue Green Magenta

This function allows you to set the hue of the selected target color.

Press \ Press |

For stronger red of the target color

6 Resetting User-defined

For stronger yellow of the target color

Color Settings

This function allows you to reset the specific target color or all of the six colors.

Selectable items

Reset (This Color)

Reset (All Colors)

7 Overview of All Color Settings

This function allows you to confirm the settings of all the colors.

“Lightness”, “Chroma” and “Hue” of the color selected for “Target” are reset. “Lightness”, “Chroma” and “Hue” of all colors are reset.

Description

-52

Computer Image Adjustment (“Fine Sync” menu)

Menu operation Page 47

2 Saving Adjustment Settings

This projector allows you to store up to seven

adjustment settings for use with various computers.

1 Adjusting the Computer


Use the Fine Sync function in case of irregularities such as vertical stripes or flickering in portions of the screen.

Selectable items

Clock Phase

H-Pos

V-Po s

Note

• You can automatically adjust the computer image by setting “Auto Sync” on the “Fine Sync” menu to “Normal” or “High Speed”, or by pressing AUTO SYNC on the projector or on the remote control. See page 54 for details.

• To reset all adjustment items, select “Reset” and press ENTER.

Adjusts vertical noise. Adjusts horizontal noise (similar to tracking on your VCR). Centers the on-screen image by moving it to the left or right. Centers the on-screen image by moving it up or down.

Description

3 Accessing Adjustment

Settings

Adjustment settings stored in the projector can be easily accessed.

Note

• If a memory has not been set, the resolution and frequency setting will not be displayed.

• When selecting a stored adjustment setting with “Select Setting”, you can set the projector in the stored adjustments.

4 Setting the Resolution

Ordinarily, the type of input signal is detected and the correct resolution mode is automatically selected. However, for some signals, the optimal resolution mode in “Resolution” on the “Fine Sync” menu may need to be selected to match the computer display mode.

Note

• If your computer displays patterns which repeat every other line (horizontal stripes), flickering may occur which makes the image hard to see.

• See “Checking the Input Signal” on page 54 for information on the currently selected input signal.

Useful Features

-53

Computer Image Adjustment (“Fine Sync” menu)

5 Checking the Input Signal

You can check the input signal information.

6 Auto Sync Adjustment

Used to automatically adjust a computer image.

Selectable items

Off

Normal

High Speed

Auto Sync adjustment is not automatically performed. Auto Sync adjustment will occur when the projector is turned on or when the input signals are switched, when connected to a computer. “Normal” takes more time than “High Speed” for more accurate Auto Sync adjustment.

Description

7 Setting the Auto Sync

Display Function

Used to set the display during Auto Sync.

Selectable items

Background

Adjusting Disp.

Menu operation Page 47

Description The image set as a background image is projected. See page 58. The computer image being adjusted is displayed.

Note

• Auto Sync adjustment is also performed by pressing AUTO SYNC on the projector or on the remote control.

• The Auto Sync adjustment may take some time to complete, depending on the image of the computer connected to the projector.

• When the optimum image cannot be achieved with Auto Sync adjustment, use manual adjustments. (See page 53.)

• When AUTO SYNC is pressed while “Auto Sync” is “High Speed” or “Off”, Auto Sync will be executed in “High Speed” mode. If the button is pressed again within one minute, Auto Sync will be executed in “Normal” mode.

-54

Audio Adjustment (“Audio” menu)

Note

When the projector is connected to audio equipment:

•

It is recommended that “FAO” be selected on “Audio

1 Adjusting the Audio

This function allows you to adjust the projector’s audio.

Selectable items

Balance

Treble Bass

Press \ Press |

Increased audio from the left speaker For weaker treble For weaker bass

Increased audio from the right speaker For stronger treble For stronger bass

Out”. Because the audio signal from the audio equipment does not vary in strength with the volume level of the projector, you can enjoy better sound.

• When “FAO” is selected on “Audio Out”, video and audio may not synchronize.

- When connecting audio equipment that has a

function for adjusting audio delay time, adjust the delay time for synchronizing video and audio.

- When the audio equipment does not have such

a function and the unsynchronized video and audio bothers you, select “VAO” on “Audio Out”. Selecting “VAO” synchronizes video and audio automatically.

• The HDMI audio will not output from the MONITOR OUT AUDIO terminal when the projector is in the standby mode.

Menu operation Page 47

3 Setting the Speaker

Note

• To reset all adjustment items, select “Reset” and press ENTER.

2 Setting the Audio Output Type

This function determines whether the audio level output from the AUDIO OUTPUT terminal is fixed or variable by linking with VOLUME.

Selectable items FAO (Fixed Audio Output) VAO (Variable Audio Output)

Audio output that does not vary in strength with the volume level of the source projector. Audio output that varies in strength with the volume level of the source projector.

Description

This function allows you to turn the audio output of the internal speaker on or off when the projector is connected to an external amplifier.

Selectable items

Off

• The HDMI audio will not output from the

Info

•

When “Audio Out” has been set to “VAO”, first make sure to lower the volume of the projector before turning the power on or off and when switching the input.

Description The audio signal is output from the internal speaker. The audio signal is not output from the internal speaker.

Useful Features

Note

MONITOR OUT AUDIO terminal when the projector is in the standby mode.

-55

Using the “Options 1” Menu

COMPUTER1/2, DVI, HDMI

VIDEO, S-VIDEO

2 3

1 Displaying Dual Pictures

(Pict in Pict)

The Pict in Pict (picture in picture) function allows you to display two pictures on the same screen. You can display the image input from VIDEO or S-VIDEO as an inset picture overlapping the main picture input from COMPUTER1/2, DVI or HDMI.

Menu operation Page 47

Note

• You can press ' / " / \ / | on the projector or

on the remote control to change the location of the inset picture image.

(The inset picture frame will be displayed. To display the inset picture to the desired position, move the frame and press ENTER on the projector or on the remote control.)

• When “On” is selected, INPUT and VOL on the projector will function as location shift button for the inset picture.

• Inset picture can only be displayed in composite video or S-video signal of NTSC/PAL/ SECAM.

• The audio of the inset picture will come out of the projector’s speakers.

• While the “Pict in Pict” function is working, the “FREEZE” function only works for the inset picture.

• The “Pict in Pict” function does not work when the following signals are input to the main picture.

−UXGA/SXGA+/SXGA/WXGA signal

−480I/480P/540P/576I/576P/720P/1035I/1080I/

1080P signal

−Interlaced RGB signal

−

All signals (when “Resize” is set to “Dot by Dot”)

−

No signal (or when the resolution or refresh rate (vertical frequency) of the signal is changed)

2 Setting the Resize Mode

Depending on the input signal, you can select the screen image.

When inputting RGB signal

Normal Full Dot By Dot Border Stretch

When inputting HDMI/ DTV/video signal Normal Area Zoom V-Stretch Border Stretch Smart Stretch

Note

• For details of the Resize mode, see pages 39 and 40.

• You can also press RESIZE on the remote con- trol to change the Resize mode. (See page 39.)

-56

Menu operation Page 47

Shifting the Projected

Image Vertically (Digital Shift)

For easier viewing, this function shifts the image projected on the screen up or down eliminating either the upper or lower black band found in 16:9 and other wide aspect ratios.

Press \

Shifts the projected image down.

Note

• This function will not work depending on the type of resize mode. See pages 39 and 40 for details.

Setting On-screen Display

This function allows you to turn the on-screen messages on or off.

Selectable items

Normal Level A

Level B

• When “Keylock Level” is set to “Level A” or “Level B”, pressing STANDBY displays “All buttons on Projector are locked.” regardless of the “OSD Display” setting.

All on-screen displays are displayed. INPUT/VOLUME/MUTE/FREEZE/AUTO SYNC/MAGNIFY/ “An invalid button has been pressed.” are not displayed. All on-screen displays are not displayed (except the menu, H&V LENS SHIFT, KEYSTONE, FOCUS, ZOOM, “All buttons on Projector are locked.” and warning displays).

Note

Shifts the projected image up.

Description

Press |

Setting the Video System

The video input system mode is factory preset to “Auto”; however, a clear picture from the connected audio-visual equipment may not be received, depending on the video signal difference. In that case, switch the video signal.

Selectable items

PAL (50/60 Hz) SECAM NTSC4.43

NTSC3.58

Note

• The video signal can only be set in VIDEO or S-VIDEO mode.

• When “Video System” is set to “Auto”, you may not receive a clear picture due to signal differences. Should this occur, switch to the video system of the source signal.

• While “Video System” is set to “Auto”, when PAL-M or PAL-N signal is input, the image from PAL signal will be displayed.

Capturing Projected Images

This projector allows you to capture projected images (RGB signals) and set them as a startup image, or background image when no signals are being received.

Note

•

Images can be captured only when they are from XGA (1024 × 768) non-interlace signals in COMPUTER1/2, DVI or HDMI mode with “RESIZE” set to “Normal”.

• The saved image is reduced to 256 colors.

• Images from equipment connected to VIDEO

or S-VIDEO terminal cannot be captured.

• Only one image can be captured and saved.

• The color of images may differ before and after

saving if an image is captured on which image adjustment has been performed using the “C.M.S.” function.

• To delete the captured image, select “Delete”, and then press ENTER.

When connected to PAL video equipment. When connected to SECAM video equipment. When reproducing NTSC signals in PAL video equipment. When connected to NTSC video equipment.

Description

Useful Features

-57

Using the “Options 1” Menu

7 Selecting the Background


Selectable items

Logo

Custom

Blue

None

• When “Custom” is selected, an image saved using “Image Capture” can be displayed as a background image.

Selectable items

Logo

Custom None

• When “Custom” is selected, an image saved using “Image Capture” can be displayed as a startup image.

9 Setting the Eco Mode

When the two lamps are lit at the same time

Selectable items

Off

* This is a reference value and is not guaranteed.

Default image

User customized image (e.g. company logo)

Blue screen

Black screen

Note

Selecting the Startup Image

Default image

User customized image (e.g. company logo)

Black screen

Note

Brightness

Approx.

77%

100%

Description

Power consumption (When

using AC 100V)

82%

100%

Lamp life

Approx. 3,000 hours*

Approx. 2,000 hours*

Menu operation

0 Detecting the Input

Page 47

Signals Automatically

Selectable items

Off

• While the “Auto Search” function is detecting the input signal, pressing a button on the projector or the remote control stops the “Auto Search” function. After the “Auto Search” function finishes completely, press the desired button.

q Setting the

Automatically searches for and switches to

the input mode in which signals are being

received.

“Auto Search” does not function.

Note

Description

Auto Power

Off Function

Selectable items

Off

• When “Auto Power Off” is set to “On”, 5 minutes before the projector enters the standby mode, the message “Enter STANDBY mode in X min.” will appear on the screen to indicate the remaining minutes.

The projector automatically enters the standby mode when no input signal is detected for 15 minutes or longer. The “Auto Power Off” function will be disabled.

Note

Description

Note

• When “Eco Mode” is set to “On”, the power consumption will decrease and the lamp life will extend.

-58

w Setting the System Lock

Function

This function prevents unauthorized use of the projector. Once this function is activated, users must enter the correct keycode each time the projector is turned on. We suggest you record the keycode in a safe place where only authorized users have access.

Info

•

If you lose or forget your keycode, contact your nearest Sharp Authorized Projector Dealer or Service Center (see page 81). Even if the product warranty is valid, the keycode reset will incur a charge.

Setting the keycode

3 Press the 4 buttons on the remote

control or on the projector to enter the new keycode in “New Code”.

Note

• You cannot use the following buttons for keycode:

ON, STANDBY, ENTER, L-CLICK, R-CLICK/ UNDO, MENU, ZOOM, FOCUS, H&V LENS SHIFT

• System Lock function recognizes each button on the remote control or on the projector as an individual button, even if they share the same button name. If you set the keycode with the buttons on the projector, use only those buttons on the projector. If you set the keycode with the buttons on the remote control, use only those buttons on the remote control.

1 Select “System Lock” on the “Op-

tions 1” menu, then press

• A message is displayed.

• Read this message, and press ENTER.

2 Press the 4 buttons on the remote

control or on the projector to enter the preset keycode in “Old Code”.

• When setting the keycode for the first time,

press " on the projector for four times.

Note

• If you input a wrong keycode, the cursor returns to the first point of the “Old Code”.

• The preset keycode is 4 " buttons on the projec- tor. If this keycode is set, the keycode input screen does not appear when turning the power on.

4 Enter the same keycode in “Recon-

firm”.

Note

Not displaying the keycode input screen when turning the projector on

• Press " on the projector for four times in steps

3 and 4 above.

When the System Lock is set

• When System Lock is set, the keycode input screen appears after the power is turned on. When it appears, enter the right keycode to start projection. Failure to enter the keycode will cause images not to be projected even when signals are entered to the projector.

Useful Features

-59

Using the “Options 1” Menu

Changing the keycode

1 Press the 4 buttons on the remote

control or on the projector to enter the preset keycode in “Old Code”.

Press the 4 buttons on the remote control or on the projector to enter the new keycode in “New Code”.

3 Enter the same keycode in “Recon-

firm”.

When the system lock is set

If you have set the system lock, enter the keycode and follow the procedure below to release the system lock.

▼Input screen for keycode

Note

• When System Lock is set, the keycode input screen appears after the power is turned on.

• If no keycode is entered, the image will not be displayed, even if the projector receives the input signal.

1 Press ON on the remote control or

on the projector to turn on the projector.

2 When the keycode input screen ap-

pears, enter the right keycode to start projection.

-60

Note

Helpful Functions Set during Installation (“Options 2” menu)

Menu operation Page 47

Changing the password

2 3

1 Press

word in “Old Password” and press ENTER.

2 Press

password in “New Password” and press ENTER.

3 Enter the same 4-digit password in

“Reconfirm” and press ENTER.

" and

| to enter the pass-

| to set the new

1 Setting a Password

••

• There is no factory preset for the password,

••

so the “Options 2” menu is enabled.

••

• If you do not want others to operate the

••

“Options 2” menu, set a password.

1 Select “Password” from the

“Options 2” menu, and press

2 Press

' or

" to set the first digit in

“New Password” and then press

3 Enter the remaining 3 digits and

press ENTER.

4 Enter the same password in

“Reconfirm” and press ENTER.

Info

• The password must be entered to use the “Options 2” menu when a password has been set.

Note

• If you do not want to set a password, leave the

fields blank in steps 2 and 3 and press ENTER.

• To cancel the password settings, press UNDO.

If You Forget Your Password

If you forget the password, delete it using the following procedure and set a new password.

Press

projector.

on the

-61

Useful Features

Helpful Functions Set during Installation (“Options 2” menu)

2 Setting the Lamp Mode

This function allows you to select the usage of the two lamps installed in the projector.

Selectable items Both Lamps

Lamp 1 Only

Lamp 2 Only

Equal Use

3 Selecting the Lens Type

When you change the lens, you need to set the lens type. See the table below to select the lens type.

Selectable items Type 1 Type 2 Type 3 Type 4 Type 5 Type 6 Type 7

Both lamps are used for greater brightness. The lamp 1 is used. When the lamp 1 burns out, the lamp 2 automatically switches in use. The lamp 2 is used. When the lamp 2 burns out, the lamp 1 automatically switches in use. Both lamps are used alternately for certain periods.

AN-P8EX AN-P12EX AN-P15EZ AN-P18EZ AN-P23EZ AN-P30EZ AN-P45EZ

Description

Attached lens

Info

•

The Lens Shift, Keystone Correction, etc. may not properly function if the correct lens type is not selected.

Menu operation

4 Reversing/Inverting

Page 47

Projected Images

This projector is equipped with a reverse/invert image function that allows you to reverse or invert the projected image for various applications.

Selectable items Front

Ceiling + Front

Rear

Ceiling + Rear

Normal image

Inverted image

Reversed image

Reversed and inverted image

Description

Note

• This function is used for the reversed image and ceiling-mount setups. (See page 23.)

5 Controlling Multiple

Projectors with the One Remote Control

This function allows you to control multiple projectors with the one remote control during the stack projection or the video wall projection. When using this function, connect the projectors with LAN cables and assign a projector as the master and the other projectors as the slaves.

Selectable items Normal

Master

Slave

See page 27 for connecting LAN cables.

Description The stack setting is not available.

Set the projector as the master.

Set the projector as the slave.

Note

• When “Lens Type” is changed, “GEOMETRIC ADJUSTMENT”, “H&V KEYSTONE” and “IMAGE RESIZING” will be reset.

-62

Note

•

When controlling multiple projectors with the one remote control, settings via web browser are required. Refer to the “SETUP MANUAL” contained on the supplied CD-ROM for details.

•

Only when controlling two projectors with the one remote control, using “Pair Stack” allows you to skip settings via web browser. (See page 63.)

•

When “Slave” is selected on “Stack Setting”, the slave projector cannot be controlled with the remote control. To control the slave projector with the remote control, connect the remote control to the projector. (See page 17.)

Menu operation Page 47

6 Shortcut to Make

Projector Stack Settings

Normally, settings via web browser are required for the stack projection. You can skip the settings via web browser by using “Pair Stack”, only when you use the two projectors for the stack projection.

Note

• Before setting “Pair Stack”, select “Master” or “Slave” on “Stack Setting”.

1 Select “Pair Stack” on the “Option

2” menu, and then press ENTER.

• The confirmation screen will be displayed.

2 Select “OK”, and then press

ENTER.

• The network settings of the projector will change as shown below.

Master Slave IP Address 192.168.150.2 192.168.150.3 Subnet Mask 255.255.255.0 255.255.255.0 DHCP Client OFF OFF Gateway 0.0.0.0 0.0.0.0 User Name (Reset) (Reset) Password (Reset) (Reset) Data Port 10002 10002

8 Bypassing Unused Input

Selections

This function allows you to skip the input mode that you rarely use. You can skip the input modes

“Auto Search” works

when

Selectable items Description

COMPUTER 1 COMPUTER 2 DVI, HDMI, VIDEO, S-VIDEO

9 Selecting the Fan Mode

This function changes the fan rotation speed.

Selectable items

Normal

High

Note

• When “Fan Mode” is set to “High”, the fan rotation speeds up, and the fan noise becomes louder.

0 Setting the Auto Restart

OFF

Suitable for normal environments. Select this when using the projector at attitudes of approximately 1,500 meters (4,900 feet) or more.

Sets each input mode selectable respectively. Sets each input mode unavailable respectively.

Description

Function

Useful Features

7 Locking the Operation

Buttons on the Projector

This function can be used to lock the use of certain operation buttons on the projector.

Selectable items Normal

Level A

Level B

All operation buttons are functional.

Only INPUT/VOLUME buttons on the

projector are available.

All operation buttons on the projector

are unavailable.

Description

Selectable items

Off

Description

If the power cord is unplugged from the outlet or the breaker switch is turned off when the projector is on, then the projector automatically turns on when the power cord is plugged into the AC outlet or the breaker switch is turned on. The projector does not turn on automatically when the power cord is plugged into the AC outlet or the breaker switch is turned on.

-63

Helpful Functions Set during Installation (“Options 2” menu)

Menu operation Page 47

Selecting the Transmission

Speed (RS-232C)

Make sure that both the projector and computer are set for the same baud rate.

Selectable items 9600 bps

38400 bps

115200 bps

Note

• Refer to the “SETUP MANUAL” contained on the supplied CD-ROM for RS-232C Specifications and Command Settings.

• Refer to the computer’s operation manual for instructions for setting the computer’s baud rate.

w Setting the Monitor

Tr ansmission speed is slow.

Tr ansmission speed is rapid.

Description

Output

e Setting the LAN/RS232C

When the LAN/RS232C has been set to “Enable”, the LAN/RS232C is activated and power is consumed even in the standby mode. It is recommended that the LAN/RS232C be set to “Disable” when it is not connected. consumption when the projector is in the standby mode.

Selectable items Enable

Disable

Note

• When you want to control the projector using the LAN/RS232C function, select “Enable.”

• The item “LAN/RS232C” will be made unavailable for setting when “Master” or “Slave” is selected on “Stack Setting”. (“LAN/RS232C” will be set to “Enable” automatically.) (See page 62.)

The LAN/RS232C function is activated even if the projector is in standby mode. The LAN/RS232C function is switched off when the projector is in standby mode.

This reduces power

Description

When the Monitor Out has been set to “Enable”, the monitor output is activated and power is consumed even in the standby mode. It is recommended that the Monitor Out be set to “Disable” when it is not connected. This reduces power consumption when the projector is in the standby mode.

Selectable items Enable

Disable

-64

The monitor output function is activated even if the projector is in standby mode. The monitor output function is switched off when the projector is in standby mode.

Description

r Setting the DHCP Client

Connect the LAN cable before turning the projector on. If not, the DHCP Client function does not work.

Selectable items ON

OFF

Note

•

Select “ON” for “DHCP Client”. “Obtaining IP Address...” appears, then the message “The network settings have been changed.”, IP Address, Subnet Mask and Gateway will be displayed.

• If the DHCP server is not available, “Could not obtain IP Address.” appears. In this case, set the TCP/IP manually. (See “Setting the TCP/IP” on page 65.)

Obtains configuration parameters for TCP/IP network automatically. Sets the TCP/IP manually.

Description

Helpful Functions Set during Installation (“Options 2” menu)/Using the Other Menus (“Language” and “Status” menus)

Menu operation Page 47

t Setting the TCP/IP

Set the TCP/IP manually.

Select “TCP/IP”, then press ENTER.

2 Enter “IP Address” using

and \, then press ENTER.

3 Enter “Subnet Mask” using

| and \, then press ENTER.

4 Enter “Gateway” using

\, then press ENTER.

Selectable items IP Address

Subnet Mask

Gateway

Factory default setting:

192.168.150.002 Enter an IP address appropriate for the network. Factory default setting:

255.255.255.000 Set the subnet mask to the same as that of the computer and equipment on the network. Factory default setting:

000. 000. 000. 000 * When not in use, set to: “000. 000. 000. 000”.

Description

| and

Service Mode

Only the service centers use the menu. Do not use the menu.

u Returning to the Default

Settings

This function allows you to initialize the settings you have made in the projector.

Note

About the network settings

• “IP Address”, “Subnet Mask”, “Gateway” and other network setting items are initialized.

The following items or menu cannot be initialized.

• “C. M. S.” menu

-“Lightness”, “Chroma” and “Hue” respectively

saved for Custom 1-3 on the “C.M.S.” menu.

• “Fine Sync” menu

-Resolution

• “Options 1” menu

-System Lock

• “Options 2” menu

-Lens Type

• “Language” menu

• Image stored using “Image Capture”

• Lamp Timer (Life)

Selecting the On-screen Display Language

Useful Features

Note

• Before setting “TCP/IP”, select “OFF” for “DHCP Client”.

• Confirm the existing network’s segment (IP address group) to avoid setting an IP address that duplicates the IP addresses of other network equipment or computers. If “192.168.150.002” is not used in a network with an IP address of “192.168.150.XXX”, you don’t have to change the projector IP address.

• For details about each setting, consult your network administrator.

The projector can switch the on-screen display language among 16 languages.

Overview of All Menu Settings and the Lamp Life

This function can be used to display all the adjusted settings as a list on the screen and you can confirm the lamp life.

-65

Maintenance

Cleaning the projector

■ Ensure the power cord is unplugged before cleaning the projector.

■ The cabinet as well as the operation panel is made of plastic. Avoid using benzene or thinner, as these can damage the finish on the cabinet.

■ Do not use volatile agents such as insecticides on the projector. Do not attach rubber or plastic items to the projector for long periods. The effects of some of the agents in the plastic may cause damage to the quality or finish of the projector.

Mild detergent

diluted with water

Thinner

Wax

Cleaning the air vents and the intake vent cover

■ Use a vacuum cleaner to clean dust from the exhaust vent, the intake vents and the intake vent cover (on the bottom of the projector).

Info

• If you want to clean the air vents and the intake vent cover during projector operation, ensure you press STANDBY on the projector or on the remote control and put the projector into standby mode. After the cooling fan has stopped, unplug the power cord from the AC socket and clean the air vents and the intake vent cover.

■ Wipe off dirt gently with a soft flannel cloth.

■ When the dirt is hard to remove, soak a cloth in a

mild detergent diluted with water, wring the cloth well and then wipe the projector. Strong cleaning detergents may discolor, warp or damage the coating on the projector. Make sure to test on a small, inconspicuous area on the projector before use.

Cleaning the lens

■ Use a commercially available blower or lens cleaning paper (for glasses and camera lenses) for cleaning the lens. Do not use any liquid type cleaning agents, as they may wear off the coating film on the surface of the lens.

■ As the surface of the lens can easily get damaged, be careful not to scrape or hit the lens.

Cleaning

Paper

-66

Cleaning and Replacing the Dust Filters

Cleaning the Dust Filters

Info

• The dust filters should be cleaned every 100 hours of use. Clean the filters more often when the projector is used in a dusty or smoky location.

1 Press STANDBY on the projec-

tor or on the remote control to put the projector into standby mode.

• Disconnect the power cord and unplug the power cord from the AC socket after the cooling fan stops.

2 Remove the filter cover.

• Remove the filter cover as shown in the figures while pressing down the tabs.

STANDBY button

Power cord

3 Clean the dust off the dust fil-

ters and the cover with a hand broom.

Appendix

-67

Cleaning and Replacing the Dust Filters

4 Replace the filter cover.

• Insert the filter cover as shown in the figure and push both the two tabs until you hear a click.

Note

• Be sure the filter cover is securely installed. The power will not turn on unless it is correctly installed.

Replacing the Dust Filters

Info

•

If the filters become too dirty to clean effectively, purchase new ones (9NK3243101400) from your nearest Sharp Authorized Projector Dealer or Service Center.

Remove

After removing the filter cover (see step 2 of “Cleaning the Dust Filters”), remove the dust filters, then replace with new ones.

• Pick the dust filters up with your fingers and lift them out of the filter cover.

• When attaching the dust filters, make sure that these are inserted below the tabs on both left and right, and that the slits are pierced through.

Attach

Pierced through the nine slits.

Insert the filter below the six tabs on both left and right sides.

-68

Maintenance Indicators

■ The warning lights on the projector indicate problems inside the projector.

■ If a problem occurs, either the temperature warning indicator or the lamp indicator will illuminate

red, and the projector will enter the standby mode. After the projector has entered the standby mode, follow the procedures given below.

Maintenance Indicators

Power indicator Lamp (1, 2) indicators Temperature warning indicator

About the temperature warning indicator

If the temperature inside the projector increases, due to blockage of the air vents, or the setting location, “ turn off and the temperature warning indicator will blink, the cooling fan will run for a further 90 seconds, and then the projector will enter the standby mode. After “ described on page 70.

” will illuminate in the lower left corner of the picture. If the temperature keeps on rising, the lamp will

” appears, ensure you perform the measures

About the lamp indicator

“Change The Lamp. (LAMP 2)” is displayed when the remaining life of the lamp 2 becomes 5% or less.

■ When the remaining lamp life becomes 5% or less, “ ” (yellow) and “Change The Lamp. (LAMP 1/

2)” will be displayed on the screen.

■ When the percentage becomes 0%, it will change to “ this time, the lamp indicator will illuminate in red.

If you try to turn on the projector a fourth time without replacing the lamp, the lamp whose life is 0%

will not light up.

” (red), the lamp will automatically turn off. At

Indicators on the Projector

Power indicator

Lamp (1, 2) indicators

Temperature warning indicato

Red on Green on Red blinks Green blinks Green on Green blinks Red on Off

Red on

Normal (Standby) Normal (Power on) Abnormal (See page 70.) Normal (Cooling) Normal The lamp is warming up. The lamp is shut down abnormally or requires to be changed. (See page 70.) Normal The internal temperature is abnormally high. (See page 70.)

Appendix

-69

Maintenance Indicators

Maintenance indicator

Temperature

warning

indicator

Lamp (1, 2)

indicators

Power

indicator

Normal

Off

Green on

Green blinks when the lamp is warming up.

Green on/

Red on

Abnormal

Red on

(Standby)

Red on

(Standby)

Red blinks

Problem

The internal temperature is abnormally high.

The lamp does not illuminate.

Time to change the lamp.

The lamp does not illuminate.

The power indicator blinks in red when the projector is on.

Cause Possible solution

• Relocate the projector to an area

• Blocked air intake

• Cooling fan break-

down

• Internal circuit failure

• Clogged air intake

• Clogged dust filter

• The lamp is shut

down abnormally.

• Remaining lamp life becomes 5% or less.

• Burnt-out lamp

• Lamp circuit failure

••

• The filter cover is

••

open.

••

• The lens cover is

••

open.

with proper ventilation. (See page

10.)

• Ta ke the projector to your nearest Sharp Authorized Projector Dealer or Service Center for repair. (See page 81.)

• Clean the air vents and the dust filter. (See page 67.)

• Disconnect the power cord from the AC outlet, and then connect it again.

• Carefully replace the lamp. (See page 72.)

• Ta ke the projector to your nearest Sharp Authorized Projector Dealer or Service Center for repair. (See page 81.)

• Please exercise care when replacing the lamp.

••

• Securely install the filter cover or

••

lens cover.

••

• If the power indicator blinks even

••

when the filter cover or lens cover is securely installed, contact your nearest Sharp Authorized Projector Dealer or Service Center for advice. (See page 81.)

Info

• If the temperature warning indicator blinks and the projector enters the standby mode, the temperature warning indicator starts to illuminate. Check whether any of the ventilation holes are blocked (see page 10) and then try turning the power back on. Wait until the projector has cooled down completely before plugging in the power cord and turning the power back on. (At least 10 minutes.)

• If the power is turned off for a brief moment due to power outage or some other cause while using the projector, and the power supply recovers immediately after that, the lamp indicator will illuminate in red and the lamp may not be lit. In this case, unplug the power cord from the AC outlet, replace the power cord in the AC outlet and then turn the power on again.

• The cooling fan keeps the internal temperature of the projector constant and this function is controlled automatically. The sound of the cooling fan may change during operation because the fan speed may change and this is not a malfunction.

-70

Regarding the Lamp

Lamp

■ It is recommended that the lamp unit (sold separately) be replaced when the remaining lamp life becomes 5% or less, or when you notice a significant deterioration in the picture and color quality. The lamp life (percentage) can be checked with the on-screen display. See page 65.

■ Purchase a replacement lamp unit of type AN-P610LP from your place of purchase, nearest Sharp Authorized Projector Dealer or Service Center.

IMPORTANT NOTE TO U.S. CUSTOMERS:

The lamp included with this projector is backed by a 90-day parts and labor limited warranty. All service of this projector under warranty, including lamp replacement, must be obtained through a Sharp Authorized Projector Dealer or Service Center. For the name of the nearest Sharp Authorized Projector Dealer or Service Center, please call toll-free: 1-888-GO-SHARP (1-888-467-4277).

Hg LAMP CONTAINS MERCURY For State Lamp Disposal Information www.lamprecycle.org or 1-800-BE-SHARP

Caution Concerning the Lamp

■ This projector utilizes a pressurized mercury lamp. A loud sound may indicate lamp failure. Lamp failure can be attributed to numerous sources such as: excessive shock, improper cooling, surface scratches or deterioration of the lamp due to a lapse of usage time. The period of time up to failure largely varies depending on the individual lamp and/or the condition and the frequency of use. It is important to note that failure can often result in the bulb cracking.

■ When the lamp indicator and on-screen display icon are illuminated, it is recommended that the lamp be replaced with a new one immediately, even if the lamp appears to be operating normally.

■ Should the lamp break, the glass particles may spread inside the lamp cage or gas contained in the lamp may be vented into the room from the exhaust vent. Because the gas in this lamp includes mercury, ventilate the room well if the lamp breaks and avoid all exposure to the released gas. In case of exposure to the gas, consult a doctor as soon as possible.

■ Should the lamp break, there is also a possibility that glass particles may spread inside of the projector. In such a case, it is recommended you contact your nearest Sharp Authorized Projector Dealer or Service Center to assure safe operation.

U.S.A. ONLY

Replacing the Lamp

Caution

• Do not remove the lamp unit from the projector right after use. The lamp will be very hot and may cause burn

or injury.

• Wait at least one hour after the power cord is disconnected to allow the surface of the lamp unit to fully cool

before removing the lamp unit.

■ Carefully change the lamp by following the instructions described in this section. *If you wish, you

may have the lamp replaced at your nearest Sharp Authorized Projector Dealer or Service Center.

* If the new lamp does not illuminate after replacement, take your projector to the nearest Sharp Authorized

Projector Dealer or Service Center for repair.

Appendix

-71

Regarding the Lamp

Removing and Installing the Lamp Unit

Warning!

• Do not remove the lamp unit from the projector right after use. The lamp and parts around the lamp will be very hot and may cause burn or injury.

Info

• Make sure the lamp unit is removed using the handle. Make sure the glass surface of the lamp unit or the inside of the projector are not touched.

• To avoid injury to yourself and damage to the lamp, make sure you carefully follow the steps below.

• Do not loosen other screws except for the lamp unit cover and lamp unit.

Optional

accessory

Lamp unit AN-P610LP

STANDBY button

1 Press STANDBY on the projec-

tor or on the remote control to put the projector into standby mode.

• Disconnect the power cord and unplug the power cord from the AC socket after the cooling fan stops.

• The cooling fan may continue to run for a while even after the power cord is removed.

• Leave the lamp until it has fully cooled down (about 1 hour).

2 Remove the lamp unit cover.

• Loosen the user service screw (1) that secures the lamp unit cover. Remove the lamp unit cover to slide it in the direction of the arrow (2).

Power cord

User service screw

-72

3 Remove the lamp unit.

• Loosen the securing screws (two for each lamp) from the lamp unit. Hold the lamp unit by the handle and pull it in the direction of the arrow. At this time, keep the lamp unit horizontal and do not tilt it.

4 Insert the new lamp unit.

• Fully insert the lamp unit into the lamp unit compartment. Press the handles back to their positions, and tighten the securing screws.

Securing screws

Handle

5 Replace the lamp unit cover.

• Slide the lamp unit cover to the position where the indicator “ unit and the “ to close the cover. Then tighten the user service screw to secure the lamp unit cover.

Info

• If the lamp unit and lamp unit cover are not correctly installed, the power will not turn on, even if the power cord is connected to the projector.

|” of the lamp cover

\” of the projector will meet

Compartment

for

Lamp 1

Compartment

for

Lamp 2

AN-P610LP

User service screw

Appendix

-73

Regarding the Lamp

Resetting the Lamp Timer

Reset the lamp timer after replacing the lamp.

Info

• Make sure to reset the lamp timer only when replacing the lamp. If you reset the lamp timer and continue to use the same lamp, this may cause the lamp to become damaged or explode.

1 Connect the power cord.

• Plug the power cord into the AC socket of the projector.

2 Reset the lamp timer.

For Lamp 1

• When you reset the timer, while simultaneously holding down \, " and ENTER, press ON on the projector.

• “LAMP 1 0000H” is displayed, indicating that the lamp timer is reset.

For Lamp 2

• When you reset the timer, while simultaneously holding down |, " and ENTER, press ON on the projector.

• “LAMP 2 0000H” is displayed, indicating that the lamp timer is reset.

ON button

Power cord

ENTER button

, ",

| buttons

-74

Computer Compatibility Chart

The table below lists signal codes that are compatible with the projector. When the images are distorted or cannot be projected, adjust the output signal of your computer and so forth while referring to the table below.

Computer

• Multiple signal support Horizontal Frequency: 15–126 kHz Ver tical Frequency: 43–200 Hz

The following is a list of modes that conform to VESA. However, this projector supports other signals that are not VESA standards.

PC/

MAC/

VGA

SVGA

XGA

Resolution

640

720

640

720

640

800

1024

350

400

480

600

768

Horizontal

Frequency

(kHz)

27.0 60

31.5 70

37.9 85

27.0 60

31.5 70

27.0 60

31.5 70

37.9

27.0

31.5

37.9

26.2

31.5

34.7

37.9

37.5

43.3

48.0

53.0

63.6

79.5

81.3

100.4 200

31.3 50

35.2 56

37.9 60

46.6 70

48.1 72

46.9 75

53.7 85

57.0 90

64.5 101

76.2 120

95.6 150

101.9 160

127.4 200

35.5 43

40.3 50

48.4 60

56.5 70

58.1 72

60.0 75

68.7 85

72.9 90

77.0 95

80.8 100

96.8 120

113.3 140

Vertical

(Hz)

100

120

150

160

VESA

Standard

DVI

Support

HDMI

Support

Display

Upscale

True

Pixel Clock: 12–230 MHz Sync signal: Compatible with TTL level

• Compatible with sync on green signal

PC/

MAC/

MAC 13"

MAC 16"

MAC 19"

MAC 21" HP (WS)

PC (WS)

SUN (WS)

Resolution Display

720

1280

768

1280

WXGA

SXGA

SXGA+

UXGA

VGA

SVGA

XGA

SXGA

800

1280

768

1360

768

1366

864

1152

882

1024

1280

1400

1050

1200

1600

640

480

832

624

768

1024

1152

870

1024

1280

960

1152 ´ 900

Horizontal

Frequency

(kHz)

45.0 60

47.8 60

49.7 60

62.8 75

47.7 60

47.8 60

55.0 60

66.2 70

64.9 72

67.5 75

76.6 80

77.1 85

90.2 100

54.5 60

65.9 72

67.4 74

64.0 60

74.6 70

78.9 74

80.0 75

91.1 85

107.2 100

64.0 60

65.3 60

74.7 52

75.0 60

81.3 65

87.5 70

90.0 72

93.8 75

106.3 85

35.0

49.7 75

60.2

68.7

78.1 72

60.0 60

85.9 85

61.8 66

71.7 76

Vertical

(Hz)

VESA

Standard

Support

DVI

HDMI

Support

Advanced Intelligent

Compression

Intelligent

Compression

Upscale

True

Advanced Intelligent

Compression

Appendix

-75

Computer Compatibility Chart

Note

• This projector may not be able to display images from notebook computers in simultaneous (CRT/LCD)

mode. Should this occur, turn off the LCD display on the notebook computer and output the display data in “CRT only” mode. Details on how to change display modes can be found in your notebook computer’s operation manual.

• When this projector receives 640 × 350 VESA format VGA signals, “640 × 400” appears on the screen.

• When projecting the RGB interlace signal using COMPUTER 1/2 with “Signal Type” set to “Auto” or

“RGB”, the image may not be projected as desired. In this case, select either VIDEO or S-VIDEO.

• When “Screen resolution” of the computer is different from the resolution displayed on the projected

image, follow the procedures shown below. –Refer to “Setting the Resolution” on page 53 and select the same resolution as the resolution in “Screen

resolution” of the computer.

–Depending on the computer you are using, the output signal may not be faithful to the “Screen resolu-

tion” adjustment. Check the settings of the computer’s signal output. If the settings cannot be changed, it is recommended that the resolution be set to the one that corresponds to “True” in the “Display” column.

DTV

Signal Vertical Frequency (Hz)

480 480P 540P

576 576P

720P

1035

1080

1080P*

* When 1080P signal is input, the image is compressed before it is displayed on the screen.

Horizontal Frequency (kHz)

15.7

31.5

33.8

15.6

31.3

45.0

37.5

33.8

28.1

67.5

56.3

60 60 60 50 50 60 50 60 60 50 60 50

DVI/HDMI Support

(Compatible with HDCP)

-76

Attaching the Optional Lens

Do not attempt to exchange the lens when the projector is installed hanging from the ceiling. Injury may occur if the lens cover and lens fall.

Before exchanging the lens, reset lens shift to the center position. (The lens shift is located at the center in the factory preset.)

When resetting the lens shift to the center position, press H&V LENS SHIFT and then press UNDO.

• The lens shift reset screen will be displayed. Select “Yes” to reset.

1 Press STANDBY on the projector

or on the remote control to put the projector into standby mode.

• Disconnect the power cord and unplug the power cord from the AC socket after the cooling fan stops.

2 Remove the lens cover.

• Press the lens cover removal button (1). Slide the lens cover forward (2).

STANDBY button

H&V LENS SHIFT button

UNDO button

Power cord

3 Turn the lens in the direction of the

arrow while pressing the lens removal lever to pull the lens out.

Removal lever

Appendix

-77

Attaching the Optional Lens

4 Remove the lens cap from a re-

placement lens.

5 Insert the hook of the replacement

lens to the notch, and turn the lens in the direction of the arrow.

• Make sure that the lens is locked with the lens removal lever when you hear a click sound.

Info

If you try to attach the lens to the projector without removing this cap, the optional lens attachment part can be damaged.

6 Slide and attach the lens cover.

• The power cannot be turned on unless the lens cover is fully inserted.

7 After changing (setting) the lens,

select the correct lens type. (See page 62.)

-78

Troubleshooting

Problem Page

No picture and no sound

or projector does not start.

Sound is heard but no

picture appears.

Color is faded or poor.

Picture is blurred;

noise appears.

Picture appears but no

sound is heard.

Check

• Projector power cord is not plugged into the wall outlet.

• Power to the external connected devices is off.

• The selected input mode is wrong.

• Cables are incorrectly connected to the projector.

• Remote control batteries have run out.

•

External output has not been set when connecting notebook computer.

•

When the connected DVI digital equipment is turned on before the “DVI” input mode is selected on the projector, the image may not be projected properly or may not be displayed at all. Ensure that the appropriate input mode has been selected and set the input signal type on the projector before you turn on the connected equipment.

•

Is the lens cover correctly attached?

•

Is the filter cover correctly attached?

•

Is the lamp unit cover correctly attached?

• Cables are incorrectly connected to the projector.

• “Bright” is set to minimum position.

• The “Shutter” is closed.

• Image adjustments are incorrectly set.

(COMPUTER 1/2, DVI, HDMI only)

• Input signal type (RGB/Component) is incorrectly set. (VIDEO, S-VIDEO only)

• Video Input system is incorrectly set.

• Adjust the focus.

• The projection distance exceeds the focus range.

• When an optional lens is attached, refer to the operation

manual of the lens.

•

There is fog on the lens. If the projector is carried from a cold room into a warm room, or if it is suddenly heated, condensation may form on the surface of the lens and the image will become blurred. Please set up the projector at least one hour before it is to be used. If condensation should form, remove the power cord from the wall outlet and wait for it to clear.

(Computer Input only)

• Perform “Fine Sync” Adjustments. (“Clock” Adjustment)

• Perform “Fine Sync” Adjustments. (“Phase” Adjustment)

• Tu rn off the LCD display of the notebook computer.

• Noise may appear depending on the computer.

• The “DNR” (Digital Noise Reduction) setting is not correct.

• Cables are incorrectly connected to the projector.

• Volume is set to minimum.

• The “MUTE” function is working.

• The “Speaker” menu is set to “Off”.

—

24–27

16 24

78 68 73

24–27

31 22

—

53 53

—

24–27

36 37 55

Appendix

-79

Troubleshooting

CheckProblem Page

An unusual sound is

occasionally heard

from the cabinet.

Maintenance

indicator illuminates or

blinks in red.

The projector cannot be turned on or put into the standby mode using the ON or STANDBY button

on the projector.

All buttons on the

projector and the remote

control are unavailable.

Picture is green on COMPUTER 1or 2

(COMPONENT).

Picture is pink (no green)

on COMPUTER 1/ 2 or

DVI (RGB).

The black levels of the image show banding or appear faded when DVI

or HDMI is selected.

Picture is too bright and

whitish.

The cooling fan

becomes noisy.

The lamp does not light

up even after the

projector turns on.

The lamp suddenly turns

off during projection.

The image sometimes

flickers.

The lamps take a long

time to turn on. Picture is dark.

The remote control

cannot be used.

• If the picture is normal, the sound is due to cabinet shrinkage caused by room temperature changes. This will not affect operation or performance.

• See “Maintenance Indicators”.

• If the “Keylock Level” menu is set to “Level A” or “Level B”, all or

specific buttons on the projector are unavailable. Use the remote control to operate the projector.

• If the “Stack Setting” menu is set to “Slave” and the “Keylock Level” menu is set to “Level B”, all buttons on the projector and the remote control are unavailable. Connect the remote control to the projector, and then use the remote control to operate the projector.

• Change the input signal type setting.

• Make adjustments that result in the best picture quality in the

“Dynamic Range” setting.

• Image adjustments are incorrectly set.

• When temperature inside the projector increases, the cooling

fan runs faster.

• The lamp indicator is illuminating in red. Replace the lamp.

• Cables are incorrectly connected to the projector or the connected equipment works improperly.

• If this happens frequently, replace the lamp.

• The lamps will eventually need to be changed.

The lamps have reached the end of its life. Replace the lamps.

• Operate the remote control while pointing it at the projector’s remote control sensor.

• The remote control may be too far away from the projector.

• If direct sunlight or a strong fluorescent light is shining on the

projector’s remote control sensor, place the projector where it will not be affected by strong light.

• Is a ø3.5 mm minijack cable plugged into the WIRED REMOTE terminal?

• The batteries may be depleted or inserted incorrectly. Make sure the batteries are inserted correctly or insert new ones.

This projector is equipped with a microprocessor. Its performance could be adversely affected by incorrect operation or interference. If this should happen, unplug the projector and plug it in again after more than 5 minutes.

-80

—

17 62 63

9, 10

66, 69, 70

24–27

72 72

For SHARP Assistance

If you encounter any problems during setup or operation of this projector, first refer to the “Troubleshooting” section on pages 79 and 80. If this operation manual does not answer your question, please contact the SHARP Service departments listed below.

U.S.A. Sharp Electronics Corporation

1-888-GO-SHARP (1-888-467-4277) lcdsupport@sharpsec.com http://www.sharpusa.com

Canada Sharp Electronics of Canada Ltd.

(905) 568-7140 http://www.sharp.ca

Mexico Sharp Electronics Corporation Mexico

Branch

(525) 716-9000 http://www.sharp.com.mx

Latin America Sharp Electronics Corp. Latin American

Group

(305) 264-2277 www.servicio@sharpsec.com http://www.siempresharp.com

Germany Sharp Electronics (Europe) GMBH

01805-234675 http://www.sharp.de

U.K. Sharp Electronics (U.K.) Ltd.

08705 274277 http://www.sharp.co.uk/customersupport

Italy Sharp Electronics (Italy) S.P.A.

(39) 02-89595-1 http://www.sharp.it

Benelux SHARP Electronics Benelux BV

0900-SHARPCE (0900-7427723) Nederland 9900-0159 Belgium http://www.sharp.nl http://www.sharp.be http://www.sharp.lu

Australia Sharp Corporation of Australia

Pty. Ltd.

1300-135-022 http://www.sharp.net.au

New Zealand Sharp Corporation of New Zealand

Phone:(09) 573-0111 Fax:(09) 573-0112 http://www.sharp.net.nz

Singapore Sharp-Roxy Sales (S) Pte. Ltd.

65-226-6556 ckng@srs.global.sharp.co.jp http://www.sharp.com.sg

Hong Kong Sharp-Roxy (HK) Ltd.

(852) 2410-2623 dcmktg@srh.global.sharp.co.jp http://www.sharp.com.hk

Taiwan Sharp Corporation (Taiwan)

0800-025111 http://www.sharp-scot.com.tw

France Sharp Electronics France

01 49 90 35 40 hotlineced@sef.sharp-eu.com http://www.sharp.fr

Spain Sharp Electronica Espana, S.A.

93 5819700 sharplcd@sees.sharp-eu.com http://www.sharp.es

Switzerland Sharp Electronics (Schweiz) AG

0041 1 846 63 11 cattaneo@sez.sharp-eu.com http://www.sharp.ch

Sweden Sharp Electronics ( Nordic ) AB

(46) 8 6343600 vision.support@sen.sharp-eu.com http://www.sharp.se

Austria Sharp Electronics (Europe) GMBH

Branch Office Austria

0043 1 727 19 123 pogats@sea.sharp-eu.com http://www.sharp.at

Malaysia Sharp-Roxy Sales & Service Co.

(60) 3-5125678

U.A.E. Sharp Middle East Fze

971-4-81-5311 helpdesk@smef.global.sharp.co.jp

Thailand Sharp Thebnakorn Co. Ltd.

02-236-0170 svc@stcl.global.sharp.co.jp http://www.sharp-th.com

Korea Sharp Electronics Incorporated of

Korea

(82) 2-3660-2002 lcd@sharp-korea.co.kr http://www.sharpkorea.co.kr

India Sharp Business Systems (India)

Limited

(91) 11- 6431313 service@sharp-oa.com

Appendix

-81

Specifications

Model

Display devices Resolution Lens (Standard)

Lens shift Input terminals

Output terminals

Control and communication terminals

Speakers Projection lamp Rated voltage Rated frequency Input current Power consumption (Standby)

Operation temperature Cabinet Dimensions (main body only) [W × H × D]

Weight (approx.)

F number Zoom Focus

HDMI DVI-D (Compatible with HDCP) Computer / Component (5BNC) Computer/Component (mini D-sub 15 pin) S-Video (mini DIN 4 pin) Video (RCA) Audio (ø3.5 mm stereo minijack) Audio (RCA) Computer/Component (mini D-sub 15 pin) Audio (ø3.5 mm stereo minijack) LAN (RJ-45) RS-232C (mini DIN 9 pin) Wired Remote (ø3.5mm stereo minijack)

XG-P610X (Standard zoom lens attached) / XG-P610X-N (No lens attached)

0.7" DLP XGA (1024 × 768) F 2.5 Powe r, ×1.25 (f = 25.5 – 32.0 mm) Powe r Power (V : ±55% / H : ±35%)

×1 ×1 ×1 ×1

×1 ×1 ×3 ×2 (L/R) ×1

×1 (variable audio output) ×1 ×1 ×1

3 W × 2 (Stereo) 280 W × 2 lamps AC 100 – 240 V 50/60 Hz

7.7 A 755 W (16.7 W) with AC 100 V

710 W (16.9 W) with AC 240 V 41°F to 104°F (+5°C to +40°C) Plastic 19

(500 × 637 × 190 mm) XG-P610X: 57.4 lbs. (26.0 kg) XG-P610X-N: 54.1 lbs. (24.5 kg)

Chip ×3

/32" × 25 3/32" × 7 31/64"

As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.

-82

Index

AC socket ....................................................................... 28

ADJ./MOUSE switch...................................................... 17

Adjustment buttons ........................................................ 47

Adjustment feet .............................................................. 30

Advanced intelligent compression ................................ 75

All Reset ........................................................................ 65

Area zoom ..................................................................... 40

Aspect ratio .................................................................... 39

Audio .............................................................................. 55

Audio Out ....................................................................... 55

Auto Power Off ............................................................... 58

Auto Restart ................................................................... 63

Auto Search ................................................................... 58

Auto Sync (Auto Sync adjustment) ............................... 54

AUTO SYNC button ....................................................... 54

Auto Sync Disp .............................................................. 54

Background.................................................................... 58

Border ............................................................................ 39

BREAK TIMER button ................................................... 41

C.M.S. (Color Management System) ............................ 52

C.M.S. Adjustment ......................................................... 52

Carrying handle ............................................................. 14

Clock .............................................................................. 53

CLR Temp (Color Temperature) .................................... 50

COMPUTER1 button ..................................................... 36

COMPUTER2 button ..................................................... 36

COMPUTER/COMPONENT1 terminals ....................... 24

COMPUTER/COMPONENT2 terminals ....................... 24

DHCP Client .................................................................. 64

Digi. Shift........................................................................ 57

DNR ............................................................................... 50

Dot By Dot ..................................................................... 39

Dustproof cap ................................................................ 13

DVI button ...................................................................... 36

DVI-D terminals ............................................................. 24

Eco Mode ....................................................................... 58

ENTER button................................................................ 47

Exhaust vent .................................................................. 66

Fan Mode ....................................................................... 63

Filter cover ..................................................................... 67

Fine Sync ....................................................................... 53

FOCUS buttons ............................................................. 31

FREEZE button ............................................................. 38

Gateway ......................................................................... 65

Geometric adjustment ................................................... 33

H-Pos ............................................................................. 53

H & V keystone .............................................................. 34

H & V LENS SHIFT button ............................................ 30

HDMI button................................................................... 36

HDMI terminal ................................................................ 24

Image Capture ............................................................... 57

Image resizing ............................................................... 35

INPUT buttons ............................................................... 36

Intake vent ..................................................................... 66

IP Address ..................................................................... 65

Kensington Security Standard connector ..................... 14

Keycode ......................................................................... 59

Keylock Level ................................................................. 63

KEYSTONE button ........................................................ 32

Keystone Correction ...................................................... 32

Lamp .............................................................................. 71

Lamp indicators 1, 2 ...................................................... 69

Lamp Mode .................................................................... 62

Lamp Timer (Life) .......................................................... 65

Lamp unit cover ............................................................. 72

LAN terminal .................................................................. 27

LAN/RS232C ................................................................. 64

Language ....................................................................... 65

L-CLICK button .............................................................. 18

Lens cover ..................................................................... 77

MAGNIFY buttons.......................................................... 37

MENU button ................................................................. 47

Monitor Out .................................................................... 64

MONITOR OUT terminals ............................................. 26

Mouse button ................................................................. 18

MUTE button.................................................................. 37

Network .......................................................................... 64

Normal ........................................................................... 39

ON button ...................................................................... 28

Options 1 ....................................................................... 56

Options 2 ....................................................................... 61

OSD Display .................................................................. 57

Pair Stack....................................................................... 63

Password ....................................................................... 61

Phase ............................................................................. 53

Pict in Pict ...................................................................... 56

Picture ............................................................................ 49

Picture Mode ................................................................. 49

PICTURE MODE button ................................................ 38

Power cord ..................................................................... 28

Power indicator .............................................................. 69

PRJ Mode ...................................................................... 62

Progressive .................................................................... 50

R-CLICK button ............................................................. 18

Remote control .............................................................. 16

Remote control sensor .................................................. 16

Remote receiver ............................................................ 18

Resize ............................................................................ 39

RESIZE button ............................................................... 39

Resolution ...................................................................... 53

RGB cable ..................................................................... 24

RS-232C ........................................................................ 64

RS-232C terminal .......................................................... 27

S-VIDEO button ............................................................. 36

S-VIDEO terminals ........................................................ 26

Save Setting .................................................................. 53

Select Setting ................................................................ 53

Service Mode ................................................................. 65

Set Inputs....................................................................... 63

SHUTTER buttons ......................................................... 41

Signal Info ...................................................................... 54

Signal Type .................................................................... 51

Smart Stretch ................................................................ 40

Speaker.......................................................................... 55

sRGB ............................................................................. 52

Stack Setting ................................................................. 62

STANDBY button ........................................................... 28

Startup Image ................................................................ 58

Status ............................................................................. 65

Stretch ........................................................................... 39

Subnet Mask .................................................................. 65

System Lock .................................................................. 59

TCP/IP ........................................................................... 65

Temperature warning indicator ...................................... 69

UNDO button ................................................................. 47

V-Pos .............................................................................. 53

V-stretch......................................................................... 40

VIDEO button................................................................. 36

VIDEO terminals ............................................................ 26

Video System ................................................................ 57

Volume buttons .............................................................. 36

WIRED R/C JACK ......................................................... 17

WIRED REMOTE terminal ............................................ 17

ZOOM buttons ............................................................... 31

Appendix

-83

SHARP CORPORATION

Sharp XG-P610X, XG-P610X-N User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
