Sharp WX-T82 User Guide

Introduction

Congratulations on your new HSDPA WX-T82 phone.

About This User Guide

This user guide is carefully designed to help you learn about your phone’s features and operations quickly and effectively.

NOTICE

• We strongly recommend that you keep separate permanent written records of all important data. Data may be lost or altered in virtually any electronic memory product under certain circumstances. Therefore, we assume no responsibility for data lost or otherwise rend ered unusable, whether as a result of improper use, repairs, defects, battery replacement, use after the specified battery life has expired or any other cause.

• We assume no responsibility, directly or indirectly, for financial losses or claims from third parties resulting from the use of this product and any of its functions, such as stolen credit card numbers, the loss or alteration of stored data, etc.

• All company and/or product names are trademarks and/or registered trademarks of their respective holders.

• Screen layout may differ from that illustrated in this user guide. The information described in this user guide is subject to change without notice.

• All the functions described in this user guide may not be supported by all networks.

• We assume no responsibility for downloaded contents, information, etc. from the network.

• Occasionally, a few b lack or bright pixels may appear on the screen. Please note that this will not have any impact on any of the features or on performance.

Intellectual Property Rights

According to copyright laws, the reproduction, alteration and use of material which is protected by copyright (music, pictures, etc.) is only permitted for personal or private use. If the user is not in possession of more extensive copyright or has not received the explicit permission from the copyright owner to reproduce, alter or use a copy which has been made or modified in this way, this is considered to be a violation of the copyright laws and gives the copyright owner the right to claim for damages. For this reason, avoid the illegal use of material which is protected by copyright.

Windows is a registered trademark of Microsoft Corporation in the United States and/or other countries.

Introduction 1

Powered by JBlend™ Copyright 1997-2005 Aplix Corporation. All rights reserved. JBlend and all JBlend-based trademarks and logos are trademarks or registered trademarks of Aplix Corporation in Japan and other countries.

Licensed by Inter Digital Technology Corporation under one or more of the following United States Patents and/or their domestic or foreign counterparts and other patents pending, including U.S. Patents: 4,675,863: 4,779,262: 4,785,450: 4,811,420: 5,228,056: 5,420,896: 5,799,010: 5,166,951: 5,179,571 & 5,345,467

T9 Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Australian Pat. No. 727539; Canadian Pat. No. 1,331,057; United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro. Pat. No. 0 842 463 (96927260.8) DE/DK, FI, FR, IT, NL,PT.ES,SE,GB; Republic of Korea Pat. Nos. KR201211B1 and KR226206B1; and additional patents are pending worldwide.

is a registered trademark of HI

/Micro3D Edition™

CP8 PATENT

2Introduction

microSD™ is a trademark of the SD Card Association.

Bluetooth is a trademark of the Bluetooth SIG, Inc.

The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sharp is under license. Other trademarks and trade names are those of their respective owners.

Licensed by QUALCOMM Incorporated under one or more of the following United States Patents and/or their counterparts in other nations ; 4,901,307 5,490,165 5,056,109 5,504,773 5,101,501 5,506,865 5,109,390 5,511,073 5,228,054 5,535,239 5,267,261 5,544,196 5,267,262 5,568,483 5,337,338 5,600,754 5,414,796 5,657,420 5,416,797 5,659,569 5,710,784 5,778,338

This product contains NetFront Browser and NetFront Messaging Client of ACCESS CO.,LTD. ACCESS and NetFront are trademarks or registered trademarks of ACCESS CO., LTD. in Japan and other countries. NetFront Browser © Copyright 1996-2007 ACCESS CO., LTD. NetFront Messaging Client © Copyright 2000-2007 ACCESS CO., LTD. This software is based in part on the work of the Independent JPEG Group.

[FarEasTone and Logo] are trademarks or registered trademarks of FarEasTone Telecommunications Co., Ltd. in Taiwan and other countries. Customer Service Call: 0800-058-885

Also Sharp Corp. is authorized with bona fide use of the foregoing trademark in relating course of trade in Japan.

Information contained in this manual is the property of FarEasTone and Sharp. FarEasTone and Sharp reserve the right to change product specifications without prior notice. FarEasTone and Sharp reserve the right to change information contained in this manual without prior notice.

Introduction 3

This product is licensed under the MPEG-4 Visual Patent Portfolio License for the personal and non-commercial use of a consumer to (i) encode video in compliance with the MPEG-4 Video Standard (“MPEG-4 Video”) and/or (ii) decode MPEG-4 Video that was encoded by a consumer engaged in a personal and non-commercial activity and/or was obtained from a licensed video provider. No license is granted or implied for any other use. Additional information may be obtained from MPEG LA. See http://www.mpegla.com.

This product is licensed under the MPEG-4 Systems Patent Portfolio License for encoding in compliance with the MPEG-4 Systems Standard, except that an additional license and payment of royalties are necessary for encoding in connection with (i) data stored or replicated in physical media which is paid for on a title by title basis and/or (ii) data which is paid for on a title by title basis and is transmitted to an end user for permanent storage and/or use. Such additional license may be obtained from MPEG LA, LLC. See http://www.mpegla.com for additional details.

MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.

4Introduction

Useful Functions and Services

Your phone offers you the following features:

• Video Calling. Y ou can talk while viewing each other on respective screens.

• 3D and colour Java™ games. You can also download various games and applications from FarEasTone via the mobile Internet.

• Thin Film Transistor (TFT) colour LCD display with images that are clearer and easier to view.

• A built-in digital camera with an auto focus function for taking pictures and video clips.

• A message function for reading and creating SMS messages.

• MMS (Multimedia Messaging Services) for sending picture, sound and video messages to brighten someone’s day.

• Email for sending up to 300 KB and receiving mail with attachments.

• A colour WAP browser for accessing information on the mobile Internet.

• Your own rington es and ring video clips. You ca n use sound or video clip files as a ringtone or ring video clip.

• A music player that can play back MP3, MPEG-4 and 3GPP format sound files (supported codec of MPEG4 or 3GPP are AMR, AAC, AAC+, and AAC+e).

• Playback of downloaded sound and video clip files.

• A voice recorder function for recording and playing back voice clips.

•A Bluetooth

wireless technology interface for establishing contact and transmitting data with certain devices. You can transmit pictures, sounds, and video clips to OBEX-enabled phones.

• A data synchronisation function for updating Phonebook entries on the Internet.

• A schedule alarm for creating and sending schedule entries with alarm settings.

• A microSD™ memory card slot that expands connectivity with a PC using the memory card.

Introduction 5

Introduction .................................................1

List of Menu Functions ............................... 8

Your Phone ................................................10

Optional Accessories ................................. 10

Getting Started .......................................... 11

Inserting/Removing the SIM/USIM Card and

the Battery ................................................. 15

Charging the Battery ................................. 16

Inserting/Removing the Memory Card ...... 18

Connecting the Handsfree Kit ................... 19

Turning Your Phone On and Off ............... 20

Slide Functions and Keypad Lock ............. 21

Display Indicators ...................................... 22

Navigating Functions ................................24

Voice Call/Video Calling Functions ......... 25

Entering Characters ..................................35

Changing the Input Language ................... 36

Changing the Input Method ....................... 36

Chinese User Dictionary ........................... 41

Using Templates ........................................ 43

Insert Phonebook Entries ........................... 43

6Contents

Using the Menu ..........................................44

Main Menu ................................................44

Shortcut Keys ............................................44

Call Manager ..............................................45

Sending a Message from the Phonebook ... 48

Audiovisual ................................................55

Camera .......................................................62

Taking Pictures .......................................... 62

Recording Video Clips ..............................63

Common Functions in the Photo and

Video Camera Modes ................................63

Functions in Photo Camera Mode .............66

Functions in Video Camera Mode .............69

Messages ...................................................70

SMS ........................................................... 70

Long SMS .................................................. 70

MMS .......................................................... 70

Email .......................................................... 70

FET Mobile Internet ...................................83

Navigating a WAP or Web Page ...............84

Gallery ........................................................88

Java™ ......................................................... 96

Organiser ................................................. 101

SIM Application ....................................... 115

Settings .................................................... 116

Call Log .................................................... 140

Connectivity ............................................. 142

Connecting WX-T82 to Your PC ............. 148

System Requirements ..............................148

3G/GSM Modem .....................................148

Handset Manager .....................................150

Music Manager ........................................ 151

Sync Manager ..........................................153

Troubleshooting ...................................... 154

Safety Precautions and Conditions of

Use ............................................................ 156

Conditions of Use ....................................156

Environment ............................................159

Precautions Concerning Vehicle Use ......159

SAR ..........................................................159

FCC NOTICE ..........................................160

Out of Warranty List ................................ 162

Index ......................................................... 163

Quick Reference ...................................... 165

Contents 7

List of Menu Functions

WX-T82 functions are listed below. See relevant page for details of each function. The menu’s corresponding number is used for shortcuts. For details, see page 44.

1 Java™

1 Java™ Gallery 2 Java™

Settings

3 Java™

Information

2 FET Mobile Internet

1 Homepage 2 Go to URL 3 Bookmarks 4 Alert Inbox 5 My Saved

Page

6 Access History 7 Browser

Settings

p. 96 p. 98

p. 100

p. 83 p. 83 p. 83 p. 83 p. 83

p. 83 p. 85

8 List of Menu Functions

3 Organiser

(Tab 1: Organiser)

1 Calendar 2 Alarms 3 Stopwatch 4 Tasks 5 World Clock 6 Countdown

Timer (Tab 2: Utilities) 1 Calculator

Voi ce Re co rd er

2 3

Scanner

Expenses Memo 5 Phone Help

p. 101 p. 105 p. 106 p. 106 p. 109 p. 109

p. 110 p. 111 p. 111 p. 113 p. 114

4 Messages

1 Create

Message

2 Inbox 3 Alert Inbox 4 Drafts 5 Te mp l at e s 6 Sent 7 Outbox 8 Voice Mail 9 Cell

Broadcasts

10 Area Info 11 Messaging

Settings

12 Memory Status

5 Camera

p. 71

p. 74

– p. 74 p. 43 p. 71 p. 73

– p. 77

p. 78 p. 78

–

p. 62

6 Gallery

1 Picture Gallery 2 Video Gallery 3 SD VIDEO 4 Sound Gallery 5 Themes 6 Java™ Gallery 7 Text

Te mp l at e s

8 Other

Documents

9 Memory Status

7 Audiovisual

1 Video Player 2 Streaming

Player

3 Music Player 4 FM Radio

p. 88 p. 89 p. 90 p. 90 p. 90 p. 96 p. 91

p. 92

p. 95

p. 55 p. 57

p. 57 p. 60

8 Call Manager

(Tab 1: Phonebook)

1 Phonebook 2 Add New 3 My Card

(Tab 2: Services)

1 Call Voicemail 2 Speed Dial List

Service Dialling

4 FDN

(Tab 3: Phonebook Settings)

1 Manage

2 Message

3 Phonebook

4 Advanced

Number

Groups

Settings

p. 45 p. 45 p. 46

– p. 53 p. 47

p. 47

p. 49

p. 53

p. 45

p. 51

9 Settings

(Tab 1: Profiles)

1 Normal 2 Meeting 3 Activity 4 Car 5 Headset 6 Silent

(Tab 2: Phone Settings) 1 Display

Settings

2 Sound

Settings

3 Slider Settings 4 Date & Time 5 Language 6 Shortcuts 7 Switch

Ringtone Output

8 Earpiece

Volume

9 Master Reset

p. 116 p. 116 p. 116 p. 116 p. 116 p. 116

p. 121

p. 125

p. 125 p. 126 p. 127 p. 127

–

p. 127

(Tab 3: Other Settings)

1 Call Settings 2 Video Calling

Settings

3 Security

Settings

4 Internet

Settings

5 Network

Settings

10 SIM

Application

11 Call Log

1 All Calls 2 Dialled

Numbers

3 Missed Calls 4

Received Calls

5 Call Timers 6 Call Costs 7 Data Counter

12 Connectivity

p. 128 p. 132

p. 133

p. 135

1 Bluetooth 2 Mass Storage 3 USB Charge 4 Card Settings 5 Off Line Mode 6 Backup/

Restore

p. 142 p. 146 p. 146 p. 146 p. 146 p. 146

p. 138

* Depends on SIM/USIM



p. 115

p. 140 p. 140

p. 140 p. 140 p. 140

–

p. 141

card contents.

List of Menu Functions 9

Your Phone

Please check the following carefully. Your phone should come complete with:

• HSDPA/3G (UMTS)/EDGE/GSM 900/1800/1900 GPRS phone

• Rechargeable Li-ion Battery

• AC Charger

• Stereo Handsfree

• Chinese User Guide

Optional Accessories

• Li-ion Spare Battery

• Cigarette Lighter Charger

•USB Data Cable

• Handsfree Microphone Unit

•Stereo Headset

The above accessories may not be available in all regions.

For details, please contact FarEasTone.

10 Your Phone

Getting Started

3 4 5

7 8

1313 14

15 16

19 20

24 25

26 27

Getting Started 11

1. Sub Camera

2. Small Light:

Flashes when an incoming call or a new message is received or missed, if Event Light or Status Light (p. 120) is enabled.

3. Navigation Keys (Arrow Keys): abcd

Moves cursor to highlight a menu item, etc.* Up arrow key (a) displays the Shortcut menu when pressed in stand-by. Down arrow key (b) displays the Phonebook entries when pressed in stand-by. Left arrow key (c) displays the list of Java™ Gallery when pressed in stand-by. Right arrow key (d) displays Gallery when pressed in stand-by.

4. Centre Key: B

Displays Main menu in stand-by, and executes functions. Long press in stand-by to initiate keypad lock. Long press when keypad is locked to unlock keypad.

5. Left Soft Key: A

Executes the function in the lower left of the screen. Displays Main menu in stand-by.*

12 Getting Started

6. Send/Redial Key: D

Makes voice calls or accepts calls, and displays the call logs in stand-by.

7. Video Telephony Key: S

Makes video callings or accepts calls, and displays the video calling screen in stand-by.

8. Voicemail Key: G

Long press to connect to the Voicemail centre. (Depending on the SIM/USIM card.)

9. * /Shift Key: P

Switches character input method as follows on the text entry screen. In English mode: Abc, ABC, abc and 123. In T9 mode, T9 Abc, T9 ABC, T9 abc and 123. In traditional Chinese mode: Abc, ABC, abc, 123, T9 BoPoMoFo, and T9 Stroke. Press to enter P, ? or * in stand-by. Long press in stand-by to lock the keypad.

10.Earpiece/Speaker

11.Display

12.Right Soft Key: C

Executes the function in the lower right of the screen. Accesses “FET Mobile Internet” by opening the browser in stand-by.*

13.End/Power Key: F

Ends a call and turns power on/off.

14.Audiovisual Key: T

While in stand-by: Relaunches the corresponding player if playing music and FM Radio in the background. Displays Multimedia menu if not playing.

15.Clear/Back Key: U

Clears the characters before the cursor, returns to the previous screen, etc.

16.Message Key: E

Displays Messaging menu.

17.Keypad

18.#/Silent Key: R

Displays symbol screen on the text entry screen. Long press to switch languages on the text entry screen. Long press in stand-by to switch Profiles settings between the mode most recently activated and Silent mode.

19.Microphone

20.External Connector:

Used to connect either the charger or a USB data cable.

21.Main Camera

22.Built-in Aerial:

Warning: Do not cover the top of the phone with your hand when in use as this may interfere with the performance of the built-in aerial.

23.Battery Cover

24.Camera Key: X

Long press in stand-by to activate the camera. Takes a picture or starts recording video when the camera is active.

Getting Started 13

25.Side Keys: VW

Press in stand-by or during a call to increase or decrease the earpiece volume. Press during incoming call to mute the ringer or disable vibration mode (if active). Press while listening to music (or video) to increase or decrease the earpiece volume.

26.Handsfree Kit/Microphone Connector

27.microSD Card Slot

* Default stand-by assignment can be changed via the

Shortcuts menu. See “Shortcuts” on page 127.

14 Getting Started

Inserting/Removing the SIM/USIM Card and the Battery

1. Slide off the battery cover ( ).

2. Unlock the SIM/USIM lock , slide the SIM/

USIM card into the SIM /USIM holder , and lock the SIM/USIM lock .

SIM/USIM card

3. Hold the battery so that the metal contacts of the

battery are facing down, slide the guides on the top of the battery into the battery slots , and then insert it .

4. Replace the battery cover.

Note

• Make sure that only 3V SIM/USIM cards are used.

• Make sure that the standard accessory battery is

used.

Getting Started 15

Battery Disposal

The device is battery-powered. In order to protect the environment, please read the following points concerning battery disposal:

• Take the used battery to your local waste depot, dealer or customer service centre for recycling.

• Do not expose the used battery to a naked flame, immerse in water or dispose with the household waste.

Please recycle waste batteries

16 Getting Started

Charging the Battery

You must charge the battery for at least 150 minutes before using your phone for the first time.

Using the Charger

1. Open the cover of the external connector, and

connect the charger horizontally to the external socket located at the bottom of the phone until it clicks.

2. Connect the charger to an AC outlet.

When the phone is charging, the battery status icon ( ) displays the current status. The Small Light also lights up. Standard charging time: Approx. 150 minutes

Note

• Charging time may va ry depending on the state of the

battery and other conditions. (See “Battery” on page 157.)

To Disconnect the Charger

When charging is completed, the battery indicator icon displays the full charge status. The Small Light also turns off when completed.

1. Unplug the charger from the AC outlet.

2. Push and hold the side buttons of the charger ,

then disconnect the charger from the external socket of the phone .

3. Close the cover.

Note

• Do not use any non-approved chargers as they may

damage your phone and invalidate any warranties, see “Battery” on page 157 for details.

• Forcibly disconnecting the charger may cause

malfunction.

IMPORTANT SAFETY INSTRUCTIONS — SAVE THIS INSTRUCTION DANGER — TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, CAREFULLY FOLLOW THIS INSTRUCTION

If the shape and size of the plug do not match the power socket, use a plug adapter that matches.

Getting Started 17

To Charge Using the Cigarette Lighter Charger

The optional cigarette lighter charger supplies power for charging from the cigarette lighter socket of a car.

Battery Level Indicator

The current battery level is displayed in the upper right of the screen.

Low Battery during Use

When the battery is running low, an alarm will sound and “ ” is displayed on the screen.

If you are using your phone and you hear the low battery alarm, attach your charger as soon as possible. The phone may not be able to continue normal operation if you continue to use it.

Battery Indicators Charge Level

Sufficiently charged

Charging recommended

Charging required

Empty

18 Getting Started

Inserting/Removing the Memory Card

Note

• Make sure that the phone is turned off before

inserting/removing the memory card.

• Be sure to insert the card in the correct direction and

orientation.

• Keep all memory cards out of the reach of small

children.

1. Turn off the phone.

2. Open the microSD card slot cover.

3. Insert the memory card until it clicks. (To remove

the memory card, push the memory card until it clicks.)

4. Close the cover.

Tip

• You see the following indicators when the memory

card is in use:

: Appears when the card is inserted. : Appears when th e card is damaged or unusable.

Make sure the card is properly inserted.

: Appears when the card is being written to or

read.

: Appears when the card is being formatted.

Connecting the Handsfree Kit

1. Open the connector cover.

2. Connect the handsfree kit.

Getting Started 19

Turning Your Phone On and Off

To turn the power on or off, long press F for approximately 2 seconds.

To Enter the PIN Code

If the PIN (Personal Identification Number) code is enabled you are asked to enter the PIN code each time the phone is switched on. For details on setting the PIN code, see “Enabling/Disabling the PIN Code” on page 134.

1. Enter your PIN code.

The PIN code is 4 to 8 digits.

2. Press B.

Note

• If your PIN code is entered incorrectly three times in a row, the SIM/USIM card is locked. See “Enabling/ Disabling the PIN Code” on page 134.

• If the clock settings have not been entered, the date and time entry screen is displayed (p. 126).

20 Getting Started

To Copy All Phonebook Entries from the SIM/ USIM Card

When you insert the SIM/USIM card into your phone for the first time and start the Phonebook application, you are asked whether you wish to copy Phonebook entries on the SIM/USIM card. Follow the on-screen instructions, or you can do it later using the Phonebook menu as follows:

→

“Call Manager” “Advanced”

“Phonebook Settings” tab →

→

“Copy All Entries”

1. Select “From SIM to Handset”.

Slide Functions and Keypad Lock

When your phone is on, you can make a call or answer an incoming call by sliding open your phone.

You can terminate the call and lock the keypad to prevent it from being pressed accidentally by sliding close your phone.

You can also operate the following actions by sliding open/close your phone.

When opened:

• The display and keypad light up.

• The keypad is unlocked.

• Incoming calls can be answered. See “Slider Settings” on page 125.

When closed:

• The handset sends a busy tone to the caller.

• Calls are terminated. See “Slider Settings” on page 125.

Note

• You can use some applications even when your phone

is closed.

• Some Java™ applications are suspended when your

phone is closed.

• Do not stick items on the back of the LCD display

when the slider is open.

Getting Started 21

Display Indicators

Indicator area

Right soft keyCentre keyLeft soft key

1. / : Strength of received signal/Service out of range

: HSDPA : EDGE : 3G (UMTS)/GPRS / : GPRS enabled/GPRS disabled

: Roaming outside network

22 Getting Started

2. / : Connection to the server [established/ communicating]

3. / : Voice call [incoming/in progress]

4. / / : Video calling communication mode enabled [voice/video/voice and video]

5. / : Alerts [text message and multimedia message/Email]

6. / / : Mailbox full [SIM/USIM card only/ handset only/both SIM/USIM card and handset]

7. : “Voice Calls” diverts set to “Always”

8. ////: Connection status [USB cable/Bluetooth wireless setting [enabled (in stand-by)/exchanging information/talking with the Bluetooth headset/Hide my phone]]

9. ///: Java™ application [executed (colour)/ suspended (grey)]/Music player/FM Radio

10. : Secure WAP page displayed

11. / / / : Silent/vibration setting [silent/ increasing volume/vibration enabled/ silent and vibration enabled]

12. / / : Speaker mode [speaker phone/speaker activated/microphone muted]

13. : Memory card inserted

14. : Battery level

15. : Daily alarm enabled

16. / : Schedule entry enabled [with/without reminder alarm]

17. : Outbox contains unsent messages [text message/multimedia/Email]

18. / / : WAP/OTA provisioning alerts [WAP alert/OTA provisioning alert/WAP and OTA provisioning alerts]

19. : Voicemail message alert

20. : “Show Secret Data” set to “On”

21. : Function Lock enabled

22. : Keypad Lock enabled

23.(No display)/////: Current profile [Normal/Meeting/ Activity/Car/Headset/Silent]

Getting Started 23

Navigating Functions

All applications are accessed from the Main menu. To open the Main menu, press the centre key B in stand-by.

To launch app lications, you will need to highlight menu items, and make selections. To select a menu item (indicated in quotation marks), move the cursor using a, b, c and d, and press B to select.

In certain procedures, you will need to press one of the soft keys (indicated in square brackets), which are displayed in the lower left and right of the screen. Press the corresponding soft key (A or C).

To return to the previous screen, press the right soft key if it displays Back. To close the Main menu, press the right soft key if it displays Back.

Each section in this user guide starts with a list of items you will need to select in order (indicated in italics) before performing the procedures shown. Select each item to reveal the next set of items that you have to choose from. Open subsection items after opening those listed in the main section.

Example:

→

“Java™”

24 Navigating Functions

“Java™ Settings”

The following menus have tabs - Organiser, Call Manager and Settings.

You can select the desired tab with the c/d key, and after that you can select the item you wish to set in the selected tab with the a/b key.

Example:

→

“Call Manager” “Advanced”

“Phonebook Settings” tab →

Voice Call/Video Calling Functions

For details on setting call functions, see “Call Log” on page 140.

Making a Voice Call

1. Enter the area code and the phone number you wish

to dial and press D to dial. If you enter the wrong number, press U to delete

the number to the left of the cursor.

Emergency Calls

1. Enter 112, 110 or 119 using the keypad and press D

to dial.

Note

• Emergency calls may not be able to be made on all

mobile phone networks when certain network services and/or phone features are in use. Contact your service provider for more information.

• This emergency number can normally be used to

make an emergency call in any country, with or without a SIM/USIM card inserted, if a 3G (UMTS)/ GSM network is within range.

International Calls

1. Long press Q until a + (international dialling

prefix) sign is displayed.

2. Enter the country code, followed by the area code

(without the leading zero) and the phone number, and press D to dial.

Adding an Entered Phone Number to the Phonebook

1. After entering a phone number, press [Options] and

select “Save Number”. For details on creating a new entry, see “Adding a

New Phonebook Entry” on page 45.

Showing or Hiding My Phone Number on the Display of the Called Party

1. After entering a phone number, press [Options],

select “Show My ID” or “Hide My ID” and press D to dial.

Voice Call/Video Calling Functions 25

Speed Dialling

Up to 8 phone numbers from the Phonebook memory (Handset and SIM/USIM) can be assigned to speed dials. You can call the numbers using the digit keys (G to O). The phone number of the Voicemail centre is assigned to G.

For details on setting the speed dial list, see “Speed Dial List” on page 53.

1. To dial a number using the speed dial, long press

any of the digit keys (G to O). The phone number saved in the speed dial list is

dialled.

Redialling

You can redial numbers in the call log. Select from specific categories or “All Calls”. Specific categories contain up to 30 numbers and the “All Calls” list contains up to 90.

1. Press D in stand-by.

2. Select the category from “All Calls”, “Dialled

Numbers”, “Missed Calls” or “Received Calls”. To switch logs, press c or d.

3. Highlight the phone number you wish to call.

4. Press D to redial a voice call or long press D to

redial a video calling.

26 Voice Call/Video Calling Functions

Answering a Voice Call

When an incoming call is detected, the phone rings.

1. Press D, B or press [Options] and select “Answer”

to answer the call. Or press any key except F, [Options] or [Busy]

when the “Any Key Answer” function is enabled. Set the Any Key Answer function in the profile of each mode (p. 121). You can answer an incoming call by sliding open your phone if “Calls on Open” is set to “Accept Call” in Slider Settings (p. 125).

Tip

• If you have subscribed to the Calling Line

Identification (CLI) service and the caller’s network sends the number, the ca ller’s number is displayed on the screen. If the caller’s name and number are saved in the Phonebook, the caller’s name is displayed on the screen.

• If the number is a restricted number, the display

shows “Withheld”.

• When you receive a call from the person whose

picture is registered in the Phonebook, the picture and name are displayed.

Rejecting an Incoming Call

1. Press F while the phone is ringing to reject a call

you do not wish to answer.

Letting the Caller Know You are Unavailable

1. Press [Busy] while the phone is ringing to send a

busy tone to the caller.

In Call Menu (Voice Call)

Your phone has additional functions available while a call is in progress.

Adjusting the Earpiece Volume

You can adjust the earpiece volume (and handsfree kit volume, if connected) to five levels.

Press V or W to display the Earpiece Volume screen.

2. Press V (or a/d) to increase the volume of the call

or press W (or b/c) to decrease the volume.

3. Press B when the volume is set to the desired level.

Turning the Speaker On and Off

You can talk via the loudspeaker on the phone when it is on.

1. During a call, press [Options] and select

“Loudspeaker On”.

Putting a Call on Hold

This function allows you to manage two calls at the same time. If you wish to make another call while you are talking to someone, you can put the current call on hold to call someone else.

Voice Call/Video Calling Functions 27

To Make Another Call during a Call

1. During a call, press [Options] and select “Hold”.

The current call is put on hold.

2. Press [Options] and select “Dial New Number”.

3. Enter the phone number you wish to make another

call to, then press D.

Tip

• You can also make another call by entering the phone

number during a call instead of step 1. The current call is automatically put on hold.

Accessing SMS/MMS Menu during a Call

1. During a call, press [Options] and select

“Messages”. The following options are available: “Create

Message” to make an SMS and MMS, or “Inbox”, “Sent” or “Drafts” to access these folders. For details on SMS and MMS, see “SMS” and “MMS” on page 70.

28 Voice Call/Video Calling Functions

Call Waiting

This service notifies you of another incoming call while you have a call in progress.

1. During a call, press [Options] and select “Hold &

Answer” to answer the second call. The first call is put on hold and you can now talk to

the second caller. You can also answer the second call by pressing D.

Note

• You need to set “Call Waiting” to “On” if you wish

to use the Call Waiting service (p. 129).

• Call Waiting service may not be available on all

networks. Contact your service provider for more information.

• If you do not wish to answer the second call, press

[Options] and select “Busy” in step 1. If “Reject” is selected, the log of the second call is saved as a missed call.

Conference Call

Conference call is a call with more than 2 participants. You may include up to 5 participants in a conference call.

To Make a Conference Call

You must have one active call and one held call.

1. During a call, press [Options] and select

“Conference All” to join the conference call.

2. Press F to end the conference call.

Note

• The conference call service may not be available on

all networks. Contact your service provider for more information.

• To end the call with all participants, press [Options]

and select “End All Call(s)”.

• To reject adding more participants to the current

party, press [Options] and select “Reject”, or you can send the busy tone by selecting “Busy”.

• You have more options for the Conference call after

selecting “Conference All” in step 1:

• To put all participants on hold, select “Hold All”.

• To put all participants except the current call on

hold, select “Private”.

To Add New Participants to the Conference Call

1. Press [Options] and select “Dial New Number”.

2. Enter the number you wish to include in the

conference call and press D to dial.

3. Press [Options] and select “Conference All” to join

the conference call. If you wish to add other participants, repeat steps 1

to 3.

To End the Call with a Conference Call Participant

1. During a conference call, highlight the person that

you wish to disconnect from the conference call.

2. Press [Options] and select “End This Call”.

Voice Call/Video Calling Functions 29

To Have a Private Conversation with One of the Participants

If you wish to have a private conversation with one of the participants, you may select the participant from the conference list and put the other participants on hold.

1. During a conference call, select the person that you

wish to talk to.

2. Press [Options] and select “Private”.

3. Once you have finished the private conversation,

press [Options] and select “Conference All” to return to the conference call.

Muting the Microphone

1. During a call, press [Mute].

To use the microphone again, press [Unmute].

30 Voice Call/Video Calling Functions

Making a Video Calling

Note

• Video Callings can only be made and received if both

parties have 3G capable phones and 3G coverage. See “Display Indicators” on page 22.

• Make sure that the battery is fully charged and the

signal is strong before using this function.

• Turn the loudspeaker on or use a handsfree kit so that

you can talk while looking at the video calling screen on the display.

Making a Video Calling

To Make a Video Calling by Entering the Phone Number First

1. Enter the area code and the phone number you wish

to dial.

2. Press [Options] and select “Video Calling” or press

S to dial. If you enter the wrong number, press U to delete

the number to the left of the cursor. When connected, the image of the called party is displayed in the upper part of the screen and yours in the lower left.

Tip

• If the called party’s phone is not video calling

enabled, you can press F and enter the phone number again to make a voice call.

Answering a Video Calling

When an incoming call is detected, the phone rings.

1. Press D to answer the call with video or press

[Options] and select “Hide Picture” to answer with voice only.

If the slider is closed, you can answer the call (with video) by sliding open the phone when the “Calls on Open” function is enabled.

Tip

• If you have subscribed to the Calling Line

Identification (CLI) service and the caller’s network sends the number, the caller’s number is displayed on the screen. If the caller’s name and number are saved in the Phonebook, the caller’s name is displayed on the screen.

Rejecting an Incoming Call

1. Press F while the phone is ringing to reject a call

you do not wish to answer. You can reject an incoming call by sliding close

your phone if “Calls on Close” is set to “End Call” in Slider Settings (p. 125).

Letting the Caller Know You are Unavailable

1. Press [Busy] while the phone is ringing to send a

busy tone to the caller of an incoming call letting them know that you cannot answer the call.

In Call Menu (Video Calling)

Muting the Microphone

1. During a video calling, press [Mute].

To use the microphone again, press [Unmute].

Swapping Images

You can swap images between the main and sub screens.

1. During a video calling, press [Options] and select

“Switch Images”.

Voice Call/Video Calling Functions 31

Changing the Image of Yourself

1. During a video calling, press [Options] and select

“Camera Picture”.

2. Select “Internal Camera”, “External Camera” or

“Alternative Image”. “Internal Camera”: The image through the sub

camera is displayed and sent to the receiver.

“External Camera”: The image through the

camera is displayed and sent to the receiver.

“Alternative Image”: The camera is turned off and

the image selected in “Alternative Image” of “Video Calling Settings” is used.

Turning the Speaker On and Off

You can talk via the loudspeaker on the phone when it is on.

1. During a video calling, press [Options] and select

“Loudspeaker On”.

Note

• In a high-noise environment, you may not be able to

continue a call, or make a clear call. We recommend that you use the handsfree kit.

32 Voice Call/Video Calling Functions

• With this option, there may be interruption if you

increase the earpiece volume. We recommend that you decrease the earpiece volume or use the handsfree kit.

Video Calling Settings

To Adjust the Quality of the Incoming or Outgoing Image

You can adjust the quality of the called party’s or caller’s image.

1. During a video calling, press [Options] and select

“Video Calling Settings”.

2. Select “Incoming Picture Quality” or “Outgoing

Picture Quality”.

3. Select “Normal”, “Quality Priority” or “Frame Rate

Priority”. “Normal”: The standard quality is used.

“Quality Priority”: The quality of the picture

Frame Rate Priority

“

To Turn the Backlight On or Off

You can turn on the backlight of your screen.

takes precedence over the frame rate.

”: The frame rate takes

precedence over the quality.

1. During a video calling, press [Options] and select

“Video Calling Settings”.

2. Select “Backlight”.

3. Select “Always On”, “Always Off” or “As Normal

Setting”. When “Always On” is selected, the backlight will

always be on during a video calling. When “As Normal Setting” is selected, the backlight will time out depending on the Backlight setting (p. 124).

To Adjust the Video Exposure

1. During a video calling, press [Options] and select

“Video Calling Settings”.

2. Select “Exposure”.

3. Press a (Light) or b (Dark).

Voice Call/Video Calling Functions 33

Mirror Image

During a video calling, you can reverse your image on the sub screen.

1. During a video calling, press [Options] and select

“Video Calling Settings”.

2. Select “Mirror Image”.

3. Select “On” or “Off”.

To Change the Sub Camera Image to the Alternative Image

During a video calling, you can switch the image shown to the caller between the sub camera image and an alternative image or display an image while putting a call on hold from the saved picture files.

1. During a video calling, press [Options] and select

“Camera Picture”.

2. Select “Internal Camera”, “External Camera” or

“Alternative Image”. If “Alternative Image” is selected, select “Preset

Picture” or “Picture Gallery”.

34 Voice Call/Video Calling Functions

Entering Characters

When entering characters to create Phonebook entries, text messages or multimedia messages, etc., press the corresponding keys.

In multi-tap input method, press each key until the desired character is displayed. For example, press H once for the letter A or twice for the letter B.

Press the following keys to:

: Enter:

. (full-stop) , (comma) ? ! : ; ' (apostrophe) " / 1

: Enter:

(space)+ = < > € £ $ ¥ % &0

: Switch character case among four modes:

Abc, ABC, abc and 123.

: Enter other characters.

Long press the following keys to:

: Enter 1 - 9 numbers.

: Enter space in Numeric mode or to

: Shift between multi-tap and T9 mode.

: Display the language options screen.

enter 0 in other modes.

Entering Characters 35

Changing the Input Language

1. On the text entry screen, press [Options] and select

“Input Language”.

2. Select the desired language.

Changing the Input Method

1. On the text entry screen, press [Options].

2. Select “Input Method”.

3. Select the input method you wish to use.

Tip

• In T9 or multi-tap mode, you can switch input mode

as follows by pressing P.

English/T9 mode

English/Multi-tap mode

Input

Method

Mode

Multi-tap

mode

Others Symbol Table Symbol Table Symbol Table

36 Entering Characters

Input

Language

= English

T9 Abc

T9 ABC

T9 abc

Abc

ABC

abc

Numeric

Input

Language

= Traditional

Chinese

T9 Stroke

T9 BoPoMoFo

Abc

ABC

abc

Numeric

Input

Language

= Simplified

Chinese

T9 PinYin T9 Stroke

Abc

ABC

abc

Numeric

Traditional Chinese/T9 mode

T9 English Mode

Using T9 English Mode

T9 text input method is a shortcut to enter text easily and quickly.

1. On the text entry screen, press [Options].

2. Select “Input Method”.

3. Select the T9 mode (T9 Abc, T9 ABC, T9 abc) you

wish to change. “ ” is displayed on the main display.

4. Press the keys to enter characters.

5. Press a or b to select the word you wish to input.

6. If you wish to clear the word, highlight it and long

press U.

7. Press B or select [Options] and “Done” to

complete the selection.

Tip

• If you press Q instead of step 6, a space is inserted

next to the selected word.

User Dictionary

You can create your own English words for T9 Alphabet text input.

Note

• This function is only available when “Input

Language” is set to “English”.

1. On the text entry screen in T9 mode, press [Options]

and select “User Dictionary”.

2. Select “Add New Word” and enter a new word.

To edit a word in the list

1. On the text entry screen in T9 mode, press [Options]

and select “User Dictionary”.

2. Highlight the desired word.

3. Press [Options] and select “Edit”.

4. Modify the word.

Entering Characters 37

T9 BoPoMoFo and T9 Stroke Mode

In T 9 BoPoMoFo and T9 S troke mode, keys are as follows.

T9 BoPoMoFo and T9 Stroke Mode keys

Key BoPoMoFo Stroke

G H I J K L

Wildcard

M N O P Q

Go to the FullWidth Symbols screen.

38 Entering Characters

Space

G-O

Changing the Input Method between Stroke and BoPoMoFo

See “Changing the Input Method” on page 36.

: Long press to input corresponding

Chinese character displayed in the candidate field.

: Press to change the input method.

Long press to enter tones “ ” in T9 BoPoMoFo mode.

: Press to display the FullWidth

Symbols screen. Long press to display the Input Language screen.

Using BoPoMoFo Input Mode The following is an example of entering “ ” for

“”.

1. Press J, Q, and M (2

Input field

Long press the

corresponding numeric

key to select the desired

character directly from

the Candidate field.

Candidate field

times quickly) to enter reading. The candidates with the same

reading are displayed in the Candidate field.

2. Long press K if the desired

character is displayed.

3. Repeat steps 1 and 2 to complete messages.

Entering Characters 39

Tip

• When the cursor is placed after the first character, the Candidate field displays characters most likely to follow.

• If you want to use tone options, long press P instead of step 2 to display the desired character. The tone symbols are displayed in the Candidate field. The candidates are displayed. Press the corresponding numeric key (H).

40 Entering Characters

Using Stroke Mode

The following is an example of entering “ ”.

1. Change the input mode to T9

Stroke mode.

2. Press I G J to display

the corresponding stroke for “”.

3. Long press M to complete the selection.

Chinese User Dictionary

You can create your own word list for T9 traditional Chinese input.

You can enter Chinese characters, alphabet, symbols and numbers.

Note

• This function is only available when “Input

Language” is set to “Traditional Chinese”.

Creating a New Entry

1. On the text entry screen, press [Options] and select

“Chinese User Dictionary”.

2. Select “Add New Word”.

3. Enter new word.

Editing a Word in the List

1. On the text entry screen, press [Options] and select

“Chinese User Dictionary”.

2. Highlight the desired word.

3. Press [Options] and select “Edit”.

4. Modify the entry word.

Deleting a Word

1. On the text entry screen, press [Options] and select

“Chinese User Dictionary”.

2. Highlight the desired word.

3. Press [Options] and select “Delete”.

4. Press [Yes] or [No].

Entering Characters 41

Finding an Entry

You can recall Chinese word entries by entering the first few characters.

The following is an example from the Chinese User Dictionary.

Please notice the word is already stored at this example.

1. Press L (3 times quickly),

then long press G and enter “”.

This example is using BoPoMoFo mode

2. The character “ ” appears at

Normally “ ” appears here.

3. Long press O and enter

“”.

42 Entering Characters

4. Long press O, then the

following characters appear.

Note

• This function doesn’t appear, if the entry word was made by less than 4 letters or no Chinese characters included. Though, you can use this as a shortcut if the word was created by Chinese character, since candidate character appears at so you only have to press O without searching for following characters.

• If there were a stored word which shares the first 1-4 character such as “ ”, candidate “ ” appears at or . The latest entry comes to , and if there were three or more entry starts with “ ”, old candidate disappears.

• If there were a stored word which shares the first 5 or more characters, such as “ ”, after “ ” was entered, the latest character of entry completes.

Using Templates

You can use the phrases registered in Text Templates when entering characters.

For details on creating the text template, see “Adding Phrases to Text Templates” on page 91.

1. On the text entry screen, move the cursor to the

point you wish to insert the template.

2. Press [Options] and select “Advanced”.

3. Select “Insert Template”.

4. Select the desired text template.

Copying, Cutting and Pasting Text

1. On the text entry screen, press [Options] and select

“Advanced”.

2. Select “Copy” or “Cut”.

3. Move the cursor to the first letter to be copied or to

be cut, then press B.

4. Move the cursor to the last letter to highlight the

area, then press B.

5. Move the cursor to the point you wish to paste the

letters.

6. Press [Options] and select “Advanced”.

7. Select “Paste”.

Insert Phonebook Entries

You can insert the entries registered in Phonebook when entering characters.

For details on creating the Phonebook entries, see “Call Manager” on page 45.

1. On the text entry screen, move the cursor to the

point you wish to insert the Phonebook Entry.

2. Press [Options] and select “Advanced”.

3. Select “Insert Phonebook Entry”.

4. Select the desired Phonebook Entry.

The selected entry is inserted.

Entering Characters 43

Using the Menu

Main Menu

1. Press B in stand-by.

The Main menu is displayed.

2. Press a, b, c or d to highlight the desired

menu, then press B to access the function. For details on the menu options, see “List of Menu

Functions” on page 8.

44 Using the Menu

Shortcut Keys

You can access menus by pressing B and digit keys for the corresponding number on the Main menu. For numbers 10 to 12, press B and P (10), Q (11) or R (12). For menus with tabs, press d (or c when necessary) to select the desired tab before pressing the digit keys. See “List of Menu Functions” on page 8.

Shortcuts are listed in the headings of this user guide. Example (p. 53): To Access “Manage Groups” Sub

Manage Groups

“Call Manager” “Manage Groups”

Press B N and d twice for the “Phonebook Settings” tab, then press G.

Example (p. 106): To Access “Tasks” Sub Menu

(M 3-4)

Tasks

Press BIJ.

Note

• The shortcut keys work for the first three menu levels only.

(M 8-d-d-1)

→

“Phonebook Settings” tab →

Call Manager

You can store the phone numbers and Email addresses of your friends, family and colleagues in the Phonebook. Your phone can store up to 750 entries. For each entry, you can enter information including up to 3 phone numbers and 3 Email addresses. There is a limit to the number of characters that can be entered for each item. The character limit differs for the handset memory and SIM/USIM card memory.

(M 8)

Adding a New Phonebook Entry

The amount of phone numbers that you can store to the SIM/USIM card is dependent on its capacity. Contact your service provider for details.

Selecting the Storage Memory

You can choose either the phone or SIM/USIM card memory locations to store the new entry.

→

“Call Manager” “Phonebook Settings” → “Save to”

“Phonebook Settings” tab →

1. Select from “Handset”, “SIM” or “Choice”.

If the selected location is different from the list displayed, a confirmation message is displayed.

(M 8-d-d-3-2)

Tip

• “Choice” prompts you to choose the memory every

time you save a new entry.

Registering a New Entry

“Call Manager”

If you select the “Choice” option for the memory to be used, the selection is between “To Handset” and “To SIM”.

→

(M 8-2)

“Phonebook” tab → “Add New”

1. Select the field you wish to fill in, and enter the

relevant information.

2. Press [Save], when finished.

Tip

• To create an entry, at least one field must be filled

(“Last Name”, “First Name”, “Add Phone Numbe r” or “Add Email Address” for the handset memory; “Name”, “Add Phone Number” or “Add Email Address” for the USIM memory; “Name” or “Add Phone Number” for the SIM memory).

Call Manager 45

Saving an Unregistered Number

d-d

After the call ends, you can have the confirmation screen asking you if you wish to register the number to the Phonebook.

→

“Call Manager” “Phonebook Settings”

“Phonebook Settings” tab →

→

“Save Unregistered”

(M 8-d-d-3-5)

1. Select “Incoming Call” or “Outgoing Call”.

2. Select “On” or “Off”.

Registering My Card

You can register and edit your own contact as with other Phonebook entries.

“Call Manager”

(M 8-3)

→

“Phonebook” tab → “My Card”

Searching for an Entry

You can search for the desired entry by entering the first few letters of the name or by sorting the entries.

Changing the List Displayed

→

“Call Manager” “Phonebook Settings”

“Phonebook Settings” tab →

→

(M 8-

“Source”

1. Select from “Handset”, “SIM” or “Both”.

If the selected location is different from the Phonebook storage memory, a confirmation message is displayed.

46 Call Manager

-3-1)

Finding a Name

“Call Manager” “Phonebook”

→

“Phonebook” tab →

1. Enter the first few letters of the name.

The first name corresponding to the entered letters is highlighted.

Tip

• You can select the Phonebook location from “Handset”, “SIM” or “Both” before searching.

Sorting the Phonebook Entries

When Simplified Chinese is selected, you can change the listing order of the Phonebook entries to PinYin order or by different groups.

When another language is selected, you can change the listing order of the Phonebook entries to BoPoMoFo order or by different groups.

→

“Call Manager” “Phonebook Settings” → “View Phonebook”

“Phonebook Settings” tab →

(M 8-d-d-3-3)

1. For Simplified Chinese, select “By PinYin” or “By

Group”. For another language, select “By BOPOMOFO” or “By Group”.

Selecting the Search Mode

“Call Manager” “Search Mode”

→

“Phonebook Settings” tab →

(M 8-d-d-3-4) (M 8-d-3)

1. For Simplified Chinese, select “English Search”,

“PinYin Search” or “Character Search”. For another language, select “English Search”, “BOPOMOFO Search” or “Character Search”.

Dialling from the Phonebook

“Call Manager” → “Phonebook” tab → “Phonebook”

1. Highlight the desired entry and press D (voice call)

or long press D (video calling).

Tip

• If more than one phone number is registered for the

entry, highlight the desired phone number after step 1 and press D (voice call) or long press D (video calling).

• You can also dial from the details screen of the

Phonebook. On the details screen, select the desired phone number and press D (voice call) or long press D (video calling).

Dialling a Service Phone Number

Certain SIM/USIM cards contain service phone numbers that can be dialled. Contact your SIM/USIM card vendor for more information. On the Phonebook screen, “Service Dialling No.” is displayed at the bottom of the list.

→

“Call Manager” Dialling Number”

“Services” tab → “Service

1. Select the desired service phone number.

Tip

• If the SIM/USIM card contains only one service

phone number, you can dial it in step 1 by pressing B.

• If no service phone number is stored in the SIM/

USIM card, this menu is not selected.

Fixed Dialling Numbers

This option is available on most SIM/USIM cards for mobile phones. It allows you to configure a SIM/USIM card so that it can only b e used to make calls to numbers on a predefined list.

Note

• This service depends on the SIM/USIM card.

(M 8-d-4)

Call Manager 47

To Enable Fixed Dialling Numbers

“Call Manager”

→

“Services” tab → “FDN”

1. Enter your PIN2 code.

2. Select “Switch On/Off”.

3. Select “On” to enable this function.

To Add a New Name

“Call Manager”

→

“Services” tab → “FDN”

1. Enter your PIN2 code.

2. Select “Edit Dial List”.

3. Highlight an entry, press [Options], then select

“Add New”.

4. Add a name and a phone number.

For details on add ing a name and phone number, see “Adding a New Phonebook Entry” on page 45.

5. Press [Save].

Sending a Message from the Phonebook

“Call Manager” → “Phonebook” tab → “Phonebook”

1. Select the desired entry including the phone number

or Email address you wish to use.

48 Call Manager

2. Highlight the desired phone number or Email

address.

3. Press [Options] and select “Create Message”.

For further procedures, see “Creating a New Message” on page 71.

Sending a Voice Clip Message or Video Clip Message Using an Address from the Phonebook

→

“Call Manager” “Phonebook”

“Phonebook” tab →

1. Select the desired entry including the pho ne number

or Email address you wish to use.

2. Highlight the desired phone number or Email

address.

3. Press [Options] and select “Create Message”.

For further procedures, see “Creating a New Message” on page 71.

Using Mailing Lists

You can create a mailing list to send the same message to a group of recipients at once. Up to 5 groups can be registered.

To Create a New Mailing List

“Call Manager” “Message Groups”

(M 8-d-d-2)

→

“Phonebook Settings” tab →

→

“Add New Group”

1. Enter the group name.

The new group name is displayed following the last group on the Group List screen.

To Add Recipients to a Group

Up to 20 recipients can be registered in each list.

→

“Call Manager” “Message Groups”

“Phonebook Settings” tab →

1. Highlight the desired group name.

2. Press [Options] and select “View”.

3. Select “Assign New Entry”.

4. Select the desired entry.

The detailed screen is displayed.

5. Select the desired phone number or Email address.

Tip

• If you modify the entry assigned in the group, you

need to re-assign it to the group. Highlight the entry, press [Options], then select “Re-assign Entry” in step 3.

• To remove an entry from the group, highlight the

entry, press [Options], then select “Remove Entry” in step 3.

• To remove a group, highlight a group name and

press [Options] and then select “Delete” in step 2.

To Send a Message Using a Mailing List

→

“Call Manager” “Message Groups”

“Phonebook Settings” tab →

1. Highlight the desired group name.

2. Press [Options] and select “Create Message”.

For further procedures, see “Creating a New Message” on page 71.

Call Manager 49

Editing Phonebook Entries

“Call Manager” → “Phonebook” tab → “Phonebook”

1. Highlight the entry you wish to edit.

2. Press [Options] and select “Edit”.

3. Modify the information.

4. Press [Save] when finished.

Adding a Thumbnail to Entries

Only Phonebook entries saved to the handset can have Thumbnails attached to them.

→

“Call Manager” “Phonebook”

1. Highlight the desired entry.

2. Press [Options] and select “Edit”.

3. Select “Picture”.

4. Select “Assign Picture”.

5. Select the desired picture.

6. Press [Save] when finished.

Note

• If you delete a picture in the handset memory, the

corresponding thumbnail is also deleted.

• To store a picture right after it was taken, select

“Take Picture” in step 4.

50 Call Manager

“Phonebook” tab →

Assigning a Ringtone or a Ring Video Clip to Each Entry

→

“Call Manager” “Phonebook”

“Phonebook” tab →

1. Highlight the desired entry.

2. Press [Options] and select “Edit”.

3. Select “Assign Tone/Video”.

4. Select “For Voice Call”, “For Video Calling” or

“For New Message”.

5. Select “Assign Tone” or “Assign Video”.

When selecting “Assign Video”, go to step 7.

6. Select “Preset Sounds” or “Sound Gallery”.

7. Select the desired tone or video clip.

For details on selecting a ringtone or a ring video clip, see “Assigning a Ringtone for an Incoming Call” on page 117 or “Assigning a Ring Video Clip for an Incoming Call” on page 118.

8. Press [Save] when finished.

Registering Birthday Item to Calendar

A birthday entered in a Phonebook entry can be registered to the calendar.

→

“Call Manager” “Phonebook”

“Phonebook” tab →

1. Highlight the desired entry.

2. Press [Options] and select “View”.

3. Press d to display the second tab.

4. Press b to highlight the birthday entry.

5. Press [Options] and select “Set Reminder”.

Tip

• After registration, the data in Calendar can be

customised. For details on customising a schedule entry, see “To Change the Settings” and etc. on page 101.

• If the Calendar memory is full, “Set Reminder” is not

displayed in step 5.

Deleting Phonebook Entries

Deleting All Phonebook Entries

“Call Manager” → “Phonebook Settings” tab → “Advanced”

→

“Delete All Entries”

1. Select from “Handset Entries”, “SIM Entries” or

“Both Entries”.

2. Enter your handset code.

For details on the handset code, see “Changing the Handset Code” on page 135.

Deleting a Phonebook Entry

“Call Manager” “Phonebook”

→

“Phonebook” tab →

1. Highlight the desired entry.

2. Press [Options] and select “Delete”.

(M 8-d-d-4-3)

Call Manager 51

Managing the Phonebook

Copying Phonebook Entries between SIM/ USIM Card and Handset

“Call Manager” “Advanced”

→

“Copy All Entries”

1. Select “From SIM to Handset” or “From Handset to

SIM”.

Note

• When you insert the SIM/USIM card into your phone

for the first time and start the Ph onebook application, the confirmation screen is displayed automatically, asking you if you wish to copy or not. The number of Phonebook entries to be copied varies depending on the SIM/USIM capacity.

• If the memory space is not enough to save all entries,

you cannot complete copying.

52 Call Manager

(M 8-d-d-4-1)

“Phonebook Settings” tab →

Sending a Phonebook Entry

→

“Call Manager” “Phonebook”

“Phonebook” tab →

1. Highlight the desired entry.

2. Press [Options] and select “Send Phonebook”.

3. Select “As Message” or “Via Bluetooth”.

For “As Message”

For details, see “MMS” on page 70.

For “Via Bluetooth”

For details, see “Bluetooth” on page 142.

Receiving a Phonebook Entry

When the phone receives a Phonebook entry, a confirmation message is displayed in stand-by.

1. Press [Yes].

The received entry is saved in the Phonebook. Press [No] to reject.

Tip

• For details on entering Bluetooth wireless settings, see “Connectivity” on page 142.

Manage Groups

Different ringtones can be set for each category. If you do not change a category ringtone, the ringtone assigned in the Profiles menu is used.

“Call Manager” “Manage Groups”

(M 8-d-d-1)

→

“Phonebook Settings” tab →

1. Highlight the desired category.

2. Press [Options] and select “Assign Tone/Video”.

3. Select “For Voice Call”, “For Video Calling” or

“For New Message”.

4. Select “Assign Tone” or “Assign Video”.

When selecting “Assign Video”, go to step 6.

5. Select “Preset Sounds” or “Sound Gallery”.

6. Select the desired tone or video clip.

For details on selecting a ringtone or a ring video clip, see “Assigning a Ringtone for an Incoming Call” on page 117 or “Assigning a Ring Video Clip for an Incoming Call” on page 118.

Editing the Category Name

You can edit category names to be assigned to the Phonebook entries.

→

“Call Manager” “Manage Groups”

“Phonebook Settings” tab →

1. Highlight the desired category name.

2. Press [Options] and select “Edit Name”.

3. Modify the name.

Speed Dial List

You can set a maximum of 8 phone numbers in the Speed Dial list (p. 26).

Setting Phonebook Entries in the Speed Dial List

“Call Manager” List”

(M 8-

→

“Services” tab → “Speed Dial

-2)

1. Select the desired entry.

2. Highlight the desired phone number.

3. Press [Options] and select “Assign”.

4. Select the desired location.

Tip

• The nine digit keys (G - O) correspond to Speed

Dial list numbers.

• When the list is empty, select “Assign” in step 1.

Call Manager 53

To Edit the Speed Dial List

“Call Manager” List”

→

“Services” tab → “Speed Dial

1. Highlight the entry you wish to edit.

2. Press [Options] and select “Re-Assign” (or

“Assign”).

Memory Status

This function helps you to check the memory used in the Phonebook.

“Call Manager” “Advanced”

54 Call Manager

(M 8-d-d-4-2)

→

“Phonebook Settings” tab →

→

“Memory Status”

Audiovisual

Video Player

Playing Back Video Clip Files

→

“Video Player” → “My Videos”

(M 7)

(M 7-1)

(M 7-1-2)

1. Select “All Videos” or the desired playlist.

2. Select the desired file.

To pause playback, press B. To stop playback, press U.

Tip

• You can control the Video Player by using the

following keys:

a/b: Increases or decreases the volume. b (long press): Mutes. d: Jumps to the next file. c: Returns to the start of the current file. cc: Jumps to the previous file. d (long press): Fast-forwards. c (long press): Rewinds.

The side keys are always available to change the volume level.

• Pressing H changes the size of the video display in

the following order: Original, Enlarged, Full Screen, Original and so on. Note that this does not chan ge the Display Size setting.

• Pressing Q displays this help information.

Searching a File to Be Played Back

→

“Video Player” → “My Videos”

1. Select “All Videos” or the desired playlist.

2. Press [Options] and select “Search”.

3. Enter a few letters of the title.

Search results are displayed in alphabetical order and the matching file is highlighted. The search will match the entered text with any part of the title.

Adding a File to the Playlist

You can add files to a playlist by doing the following.

→

“Video Player” → “My Videos”

1. Select “All Videos” or the desired playlist.

2. Highlight the file you wish to add to the playlist.

3. Press [Options] and select “Add to Playlist”.

The playlists are displayed. For details on creating a playlist, see “Adding a New Playlist” on page 56.

4. Select the desired playlist.

The file highlighted in step 3 is saved. To delete files from the playlist, highlight the file in the playlist and press [Options]. Then select “Delete from Playlist”.

Audiovisual 55

Adding a New Playlist

You can create a playlist and register desired files in it.

→

“Video Player” → “My Videos”

1. Press [Options] and select “Add New Playlist”.

2. Enter the desired playlist name.

3. Press B.

Note

• To delete the playlist, highlight the playlist and press

[Options]. Then select “Delete Playlist”.

Settings

You can select a play mode for “Playback Pattern”, “Backlight”, “Display Size” and “Sound Effect” when playing back video clip files.

→

“Video Player” → “Settings”

1. Select from “Playback Pattern”, “Backlight”,

“Display Size” or “Sound Effect”.

2. Select from the following:

• “Playback Pattern” “Normal”: Plays back all files in the

“Repeat”: Continues playback of

56 Audiovisual

selected folder once and stops playback.

selected file in the selected folder.

“Repeat All”: Plays back all files in the

“Random”: Plays back files in the

• “Backlight” “Always On”: Lit while the file is played

“Always Off”: Unlit while the file is played

“Normal Settings”: Works with the main

• “Display Size” “Original Size”: Displays the file in its

“Enlarge”: Displays the file in an

“Full Screen”: Displays the file on the full

• “Sound Effect” “Surround”: Plays back file with

“Bass”: Plays back file with

Downloading Video Clip Files

→

“Video Player” → “Get Video”

The video clip file download site is displayed.

selected folder.

selected folder at random.

back.

back even if a key is pressed.

backlight setting (p. 124).

original size.

enlarged size.

screen.

surround sound.

emphasised bass sound.

(M 7-1-4)

Playing Back the Video Clip Files

To Play Back the Last File

→

“Video Player” → “Last Played Video”

Streaming Player

You can play back video clip files while downloading them from the mobile network.

You can also register the address of the Web site as a bookmark.

→

“Streaming Player”

(M 7-1-1)

(M 7-2)

1. Select “Last Played”, “Enter URL”, “Favourites”,

“Access Log” or “Settings”. “Last Played”: Shows the last streaming file. “Enter URL”: Enter the desired address of the

“Favourites”: The address of the Web site is

“Access Log”: Shows a log of the Web sites you

“Settings”: The backlight and display size

Web site. The browser opens, starts downloading and plays back.

registered.

have accessed.

settings.

Music Player

Music Player supports MP3, MPEG-4 and 3GPP format sound files. You can access other menus while listening to sound files.

Creating a New Playlist

You can create your own playlist, storing and managing your favourite tracks and the order of tracks.

→

“Music Player” → “My Music” → “Playlists”

(M 7-3)

1. Press [Options] and select “Add New Playlist”.

2. Enter the desired playlist name.

Note

• To delete the playlist, highlight the playlist and press

[Options]. Then select “Delete Playlist”.

• You can create up to 99 playlists.

Audiovisual 57

Playing Back Sound Files

→

“Music Player” → “My Music”

1. Select the item you wish to play back.

• “All Music”: All sound files are displayed.

• “Artists”: The names of all artists are displayed. When an artist is selected, all of their albums are displayed. When an album is selected, all of the sound files in the selected album are displayed.

• “Albums”: The names of all albums are displayed. When an album is selected, all of the sound files in the selected album are displayed.

• “Playlists”: All playlists are displayed. When any playlist is selected, all of the sound files in the selected playlist are displayed.

2. Select the desired sound file.

To pause playback, press B. To stop playback, press F and go back to stand-by, then press F again. Select “Yes” when the pop-up appears.

58 Audiovisual

Note

• Select “My Music” to update the list of available

music tracks.

• You are asked whether or not to play sounds when the

Silent mode is activated.

• To play the last played file, select “Last Played

Music”. “Currently Playing” is di splayed when a file is being played back.

• When you receive a call, playback of the current file

is paused, and you can receive the call. After the call ends, the paused playback resumes automatically in the background.

Tip

• You can return to the Main menu screen while

playing back the file in the background.

• You can create your playlist by listing only the

desired files (p. 57).

• Sound files in both the handset and the memory card

are displayed in a single view.

• When listening to music using an A2DP compatible

Bluetooth handsfree device, play back the file from Music Player.

• You can select the playback pattern in step 2. Press

[Options] and select “Playback Pattern”. “Normal”: Plays back all files in the selected

folder once and stops playback.

“Repeat”: Continues playback of selected file

in the selected folder.

“Repeat All”: Plays back all files in the selected

folder.

“Random”: Plays back fil es in the selected folder

at random.

• While in the Music Player, the player can be

controlled by using the following keys:

a/ b : Increases or decreases the volume. b (long press): Mutes. d: Jumps to the next file. c: Returns to the start of the current file. cc: Jumps to the previous file. d (long press): Fast-forwards. c (long press): Rewinds. F: Plays back the file in the background.

The side keys are always available to change the volume level.

Sorting Files

→

“Music Player” → “My Music” → “All

T Music”

1. Press [Options] and select “Sort”.

2. Select “By Title”, “By Artist”, “By Album” or

“By Genre”. Sort results are displayed.

Adding a File to the Playlist

You can add files to a playlist by doing the following.

→

“Music Player” → “My Music” → “All

T Music”

1. Highlight the file you wish to add to the playlist.

2. Press [Options] and select “Add to Playlist”.

The playlists are displayed. For details on adding a playlist, see “Creating a New Playlist” on page 57.

3. Select the desired folder.

The file highlighted in step 1 is saved. To delete files from the playlist, highlight the file in the playlist and press [Options]. Then select “Delete from Playlist”.

Note

• You can store up to 99 files in one playlist. However,

the total number of files stored on your phone cannot exceed 350 files.

Audiovisual 59

Downloading Music Files

→

“Music Player” → “Download Music”

The music file download site is displayed.

FM Radio

You can connect to the FM Radio service.

Selecting a Radio Station

→

“FM Radio”

(M 7-4)

(M 7-3-3)

1. Press [Options] and select “Select Station”.

2. Highlight the desired radio station and press B.

Tip

• You can play back the program in the background.

Press [Options] and select “Play in Background” while the program is played back.

• A headset radio aerial is necessary to use this

service.

Saving a Radio Station

→

“FM Radio”

1. Press [Options] and select “Save Station”.

2. Press [Options] and select “Assign”.

60 Audiovisual

Searching for Stations

→

“FM Radio”

1. Press [Options] and select “Search”.

2. Select “Auto Search”.

3. Select “Search Upwards” or “Search downwards”.

Note

• You need to plug in the headset when using the FM

Radio.

Tip

• You can scan and save the stations automatically by

selecting “Update station list” in step 2.

• You can also select the desired station by entering the

frequency directly. Select “Enter Frequency” in step

Setting FM Radio Playback

→

“FM Radio”

To Switch the Output

1. Press [Options] and select “Detailed settings”.

2. Select “Sound output settings”.

3. Select “Headset” or “Loudspeaker”.

To Activate the Auto Switch Off

1. Press [Options] and select “Detailed settings”.

2. Select “Auto Switch Off”.

3. Select the desired option.

To Switch between Stereo and Monaural

1. Press [Options] and select “Detailed settings”.

2. Select “Switch to Stereo”.

To Switch the Station List

1. Press [Options] and select “Detailed settings”.

2. Select “Switch station list”.

3. Select the desired list.

Audiovisual 61

Camera

Your phone has a bu ilt-in digital camera that allows you to take pictures and record video clips wherever you are. This section starts with basic functions and operational procedures to take, save and send pictures and video clips, followed by common and unique functions to camera and video modes.

(M 5)

Taking Pictures

“Camera”

1. Press B to take the picture.

The shutter sounds and the still image of the taken picture is displayed.

2. Press [Save].

The taken picture is saved in Gallery. To cancel, press [Cancel]. To send the taken picture, press B in step 2.

62 Camera

Note

• When the video camera is launched, press [Options]

and select “Go to Photo Camera”, or press c.

• When you try to send a picture that has too large a

file size, the picture size is resized for the message. The original sized picture is saved in Gallery.

Tip

• You can activate the camera by long pressing X in stand-by. Simply press X to take pictures, and start and stop recording.

• You can lock the focus by pressing D or pressing X halfway before taking a picture or recording a

video clip.

Recording Video Clips

You can record a video clip with your phone.

“Camera”

The preview is displayed on the screen. When in photo camera mode, press d to switch to

video camera mode.

1. Press B.

2. To stop recording, press B.

3. Select “Save”.

The video clip is saved in Gallery. To view the preview before saving, select “Preview”. To send the video clip, select “Save and Send”. For further procedures, see “Creating a New Message” on page 71.

Note

• You can only send video clips when “For Message”

is selected for the recording time. For details, see “Selecting the Recording Time and Picture Size” on page 69.

Common Functions in the Photo and Video Camera Modes

Using the Digital Zoom Function

To Adjust the Zooming Ratio

1. Press a or b.

Once the phone has returned to stand-by, the zoom settings return to default.

Adjusting the Exposure

“Camera”

1. Press a (Bright) or b (Dark).

→

[Options] → “Exposure”

: (Bright → Normal → Dark)

Once the phone has returned to stand-by, the brightness settings return to default.

Camera 63

Selecting the Picture or Video Quality

Select the appropriate option.

“Camera” “Camera”

→

[Options] → “Picture Quality”

→

[Options] → “Video Quality”

1. Select the desired picture or video quality.

: Super Fine :Fine : Normal

Note

• The better quality you select, the larger the file size

becomes.

Using the Self-Timer

Select the appropriate option.

→

“Camera”

[Options] → “Modes” → “Self-timer”

1. Select “2sec”, “5sec” or “10sec”.

When you select one of these options, the corresponding indicator (“ ”, “ ”, or “ ”) is displayed on the screen. Select “Off” to cancel the self-timer.

64 Camera

Switching the Focus Mode

→

“Camera”

[Options] → “Modes” → “Focus”

1. Select the desired option.

: Auto Focus : Manual Focus :Macro

Switching the Display Direction

You can switch the display direction between portrait and landscape.

→

“Camera” /Portrait”

[Options] → “Settings” → “Landscape

Selecting the Storage Memory

Select the appropriate option.

“Camera” Pictures”

“Camera” Videos”

→

[Options] → “Settings” → “Save New

→

[Options] → “Settings” → “Save New

1. Select the desired location from “To Handset

Memory”, “To Memory Card” or “Choice”.

Note

• If you select “Choice”, select the desired location

every time you save.

Auto Save

You can set the phone to save pictures and video clips automatically.

→

“Camera”

[Options] → “Settings” → “Auto Save”

1. Select “On” or “Off”.

Selecting the Anti-flicker Mode

“Camera” flicker”

→

[Options] → “Settings” → “Anti-

1. Select “Mode 1: 50Hz” or “Mode 2: 60Hz”.

Note

• Vertical stripes may occur on the picture due to the

light source. Change the anti-flicker mode to rectify.

Switching between the Photo and Video Camera Modes

You can switch between the photo and video camera modes by pressing c or d.

Select the appropriate option.

→

“Camera” “Camera”

You can also switch between the Internal (sub) camera and External (main) camera.

Using the Help Function

“Camera”

[Options] → “Go to Video Camera”

→

[Options] → “Go to Photo Camera”

→

[Options] → “Help”

Camera 65

Common Shortcut Keys

If multiple options exist, they switch each time you press each of the following keys.

Photo Camera Video Camera

D Focus Lock G Zoom Max/Min H Switches between internal and external cameras I Focus J Save New Pictures Save New Videos K Picture Size Picture Size L Microphone M Picture Quality Video Quality N Self-timer O Switches between Portrait and Landscape Q Switches Viewfinder

between with and without indicators

P Exposure

66 Camera

Switches the display

modes in the Preview

screen

Note

• The “Switches the displa y modes” option is available

in “Preview” before you save a video clip. See “Recording Video Clips” on page 63.

Functions in Photo Camera Mode

Selecting the Picture Size

You can select the size of pictures. All taken pictures are saved in the JPEG format.

→

“Camera”

1. Select the desired size.

(External Camera) 1200 × 1600 dots/

(Internal Camera) 240 × 320 dots/120 × 160 dots

[Options] → “Picture Size”

960 × 1280 dots/ 768 × 1024 dots/480 × 640 dots/ 240 × 320 dots/120 × 160 dots

Continuous Shoot

There are various modes for taking continuous shots.

“Camera” Shoot”

→

[Options] → “Modes” → “Continuous

1. Select the desired mode.

The following continuous shoot modes are available: “Off”: The continuous shoots are

“4 Pictures”/“9 Pictures” ( / ):

“Overlapped” ( ): Overlaps continuous

cancelled.

Takes 4 or 9 pictures continuously. After selecting this mode, select from “Fast”, “Normal”, “Slow” or “Manual”.

pictures into one picture and makes an afterimage. After selecting this mode, select “Fast” or “Normal”.

Note

• When you select “Manual” to take continuous

pictures, press B manually at the desired speed.

• When the Timer and Continuous Shoot functions are

simultaneously set, “ ” and “ ” (for “2sec” and “4 Pictures”, for example) are alternately displayed.

• You cannot use the Continuous Shoot function for

picture sizes larger than 480 Pictures” and “Overlapped” are not available for picture sizes larger than 240

Camera Effects

You can select from various camera effects.

→

“Camera” Effects”

[Options] → “Modes” → “Camera

640 dots. “9

320 dots.

1. Select from “Sepia”, “Monochrome”, “Negative” or

“Sketch”.

Note

• You cannot use the Camera Effects function for

picture sizes larger than 240 × 320 dots.

Camera 67

Selecting a Frame

You can select the frame from preset patterns or Picture Gallery.

→

“Camera”

[Options] → “Modes” → “Add Frame”

1. Select “Preset Frames” or “Picture Gallery”.

2. Select the desired frame.

The selected frame is confirmed on the display.

3. Press B.

Note

• Images larger than 240 dots [W]

cannot be used.

Using the Full Screen

You can display the preview on the full screen without the soft key area and indicator area.

→

“Camera”

[Options] → “Settings”

320 dots [H]

1. Select “Full Viewfinder”.

To return to the normal viewfinder, select “Normal Viewfinder”.

68 Camera

Selecting the Shutter Sound

“Camera” Sound”

→

[Options] → “Settings” → “Shutter

1. Select the desired shutter sound from 3 preset

patterns. To play back the shutter sound, press [Play] in step

Note

• Continuous Shoot uses the specialised shutter sound

that cannot be changed using the above settings.

• The shutter sound remains active even when

“General Volume” (p. 116) is set to “Silent” to prevent unauthorised use.

Functions in Video Camera Mode

Selecting the Recording Time and Picture Size

“Camera”

1. Select “For Message” or “Extended Video”.

2. Select the desired picture size.

Note

• If you select “For Message” for the recording time,

• “Save and Send” is not displayed after recording in

→

[Options] → “Record Time”

For Message ( ): Limits the size to send a

Extended Video ( ): Less than 30 minutes

If “For Message” is selected, select “Large(QCIF)” or “Small(SubQCIF)”. If “Extended Video” is selected, select “Large(QCIF)” or “Small(SubQCIF)”. When using the external camera, “QVGA” is also available.

the file size is limited depending on the service provider. Therefore, the quality is also limited for the setting.

the Extended Video mode.

message depending on service providers.

(depending on the memory).

Recording Video Clips with Sound

To record a video clip with sound, the microphone needs to be activated.

→

“Camera” “Microphone”

[Options] → “Settings” →

1. Select “On” or “Off”.

Note

• The microphone is already turned on in the default

setting. Select “Off” to record a video clip without the sound.

• The file size of a video clip can be reduced if the

sound is not recorded.

Video Encoding

→

“Camera” Encode”

[Options] → “Settings” → “Video

1. Select the appropriate format.

Note

• For videos, we recommend that you record in the

landscape display position (p. 64). If recorded in the portrait display position, the video may be displayed in a rotated position when viewed on a computer.

Camera 69

Messages

Your phone allows you to send and receive text, multimedia and Email. It is compatible with most POP3 Email providers.

(M 4)

SMS

SMS allows you to send text messages up to 70 Chinese or 160 English characters. If the number of characters used in a sent message exceeds this number, it is split into several segments. As a general rule, if both Chinese and English characters are used, one Chinese character is counted as two English characters. (For punctuation symbols and special symbols, the character count will depend on whether it is full-width or half-width. When the symbol is full-width, it is counted as 2 English characters or 1 Chinese character. When the symbol is half-width, it is counted as 1 English character.) For example, if a message contains more than 200 Chinese characters, it is sent as 3 SMS messages.

70 Messages

Long SMS

The WX-T82 supports Long SMS to allow you to send text messages up to 330 Chinese or 765 English characters. If the number of characters used in a message exceeds this number, it is automatically delivered by MMS and the charge for an MMS is applied.

MMS

With MMS, you can send images, sound or video to brighten someone’s day. Messages of up to 300 KB with images, sound, or video clips can be sent and received.

Email

Email allows you to send messages of up to 300 KB.

Note

• Some MMS functions may not always be available

depending on your network. Contact your service provider for more information.

• Maximum message size varies depending on the

restrictions set by the service provider.

Creating a New Message

(SMS/MMS) “Messages” (Email) “Messages”

→

“Create Message” → “Message”

→

“Create Message” → “E-Mail”

(M 4-1)

1. Select the recipient field.

2. Select the desired method to enter the recipient’s

details.

3. For MMS, enter or select the Email address or

phone number from the Phonebook. For SMS, enter or select a phone number. For Email, enter or select an Email address.

• To add multiple Email addresses or phone numbers, highlight the recipient field, press [Options], and then select “Add Recipient”. Enter or select the Email address or phone number from the existing Phonebook.

• To change the recipient types, press [Options], select “Add Recipient” and highlight the desired recipient. Press [Options] and select “Change to To”, “Change to Cc” or “Change to Bcc”.

• To add a subject, highlight the subject field and press B. Then enter the subject in the subject entry screen and press B.

4. Place the cursor in the message field.

5. Press B to display the message entry screen.

Enter the message and press B.

6. Press [Options] and select “Send”.

“Send” is not available when no recipients are set. After the message is sent, the message is moved to the Sent box.

Note

• When you create an SMS/MMS message, the mode is

automatically switched to MMS in the following cases:

• When “Enter Email Address” in [Options] is

selected for recipient fields.

• When a subject is entered.

• When the size of entered text has exceeded the SMS

size limit.

Tip

• To send the same message to a group of recipients,

select “Select Message Group” in step 2, then select the desired group name. For details on creating a mailing list, see “To Create a New Mailing List” on page 49.

Messages 71

To Add a Slide Show

1. Perform steps 1 to 5 in “Creating a New Message”

on page 71.

2. Press a to highlight your message or other inserted

item such as a picture or sound file.

3. Press [Options] and select “Add Slide”.

4. Select “Add Slide After” or “Add Slide Before”.

5. Enter another message.

If you wish to set the duration of each slide, highlight your message or other inserted item such as a picture or sound file. Press [Options] and select “Slide Duration”, then select the desired duration. Repeat steps 2 to 4 to add more slides.

Tip

• You can create messages up to 300 KB. Each slide

can contain one picture and/or one sound file or video clip.

To Attach Data

1. In step 6 in “Creating a New Message” on page 71,

press [Options] and select “Insert Item”.

72 Messages

2. Select “Picture”, “Sound”, “Video”, “Attach

Contact”, “Attach Appointment” or “Others”. When selecting “Attach Contact” or “Attach

Appointment”, go to step 4.

3. Select the desired option and then select the desired

file. If you wish to attach pictures, sounds or video clips

that are saved, select “Saved Picture”, “Saved Sound” or “Saved Video”. If you wish to take new pictures, record sounds or video clips, select “Take Picture”, “Record Voice” or “Record Video”.

4. Select the desired data.

If you wish to select your own Phonebook entry, select “My Card”. When attaching an appointment, select the desired day including a schedule entry you wish to add and select the desired schedule entry.

Note

• When attaching JPEG files, select the appropriate

resize option, as the maximum message size for sending varies depending on the service provider.

To Remove or Replace Attachments

1. In step 6 in “Creating a New Message” on page 71,

press [Options] and select the corresponding remove option for each attachment.

Using the Sending Options

You can use the message sending options for each type of message.

1. Press [Options] and select “Messaging Settings”.

• “Delivery Report” (“On”, “Off”) (SMS/MMS): Enables or disables Delivery Report when the message is successfully sent to the recipient.

• “Expiry Time” (“Maximum”, “1 hour”, “12 hours”, “1 day”, “1 week”) (SMS/MMS): Sets Expiry Time for a message to be saved in the server.

• “Priority” (“High”, “Normal”, “Low”): Prioritises composed messages.

• “Read Report” (“On”, “Off”) (SMS/MMS): Confirms whether or not a report is sent notifying the sender that the message has been read.

2. Press [Options] and select “Send”.

After the message is sent, the message is moved to the Sent box.

Note

• The current message size displayed while you are

creating the message is an approximation.

• If a message cannot be sent for some reason, the

message stays in the Outbox and the “ ” is displayed in stand-by.

Tip

• To save the message without sending, press

[Options] and select “Save to Drafts” in step 4 in “Creating a New Message” on page 71.

• You can send the following items attached to

multimedia messages. Details are given in the following sections.

• Gallery data

• Phonebook entry

• Schedule entry created by Calendar, etc.

• You can use the template option to help you compose

messages. For details on using this option, see “Using Templates” on page 43.

Messages 73

Sending a Message in the Drafts Box

“Messages”

→

“Drafts”

(M 4-4)

1. Select the desired tab, SMS/MMS or Email.

2. Press [Options] and select “Edit & Send”.

3. Modify the message, if necessary.

4. Press [Options] and select “Send”.

“Send” is not available when no recipients are set.

Sending a Voice Clip Message or Video Clip Message

You can record a new voice or video clip when creating a new message.

Select the appropriate option.

→

“Messages” “Voice Message”

“Messages” “Video Message”

“Create Message” →

→

“Create Message” →

1. Press B to start recording.

2. Press B to stop recording.

3. Select “Accept” to attach to the new message.

74 Messages

4. Select “To Handset Memory” or “To Memory

Card” as the destination to save. For further procedures, see “Creating a New

Message” on page 71.

Tip

• You can play back voice or video clips from Gallery.

Reading a Message

Messages you receive are saved in the Inbox.

→

“Messages”

“Inbox”

1. Select the desired tab, SMS/MMS or Email.

2. Select the message you wish to view.

Storing the Phone Number of a Sender in the Phonebook

“Messages”

→

“Inbox”

1. Select the desired tab, SMS/MMS or Email.

2. Highlight the message from which you wish to store

the phone number or Email address.

3. Press [Options] and select “Save Address”.

The new Phonebook entry screen including the phone number is displayed. For details on creating a new Phonebook entry, see “Adding a New Phonebook Entry” on page 45.

Calling the Phone Number of a Sender Embedded in the Message

→

“Messages”

“Inbox”

1. Select the desired tab, SMS/MMS or Email.

2. Hig hlight the message containing the phone nu mber

you wish to dial.

3. Press [Options] and select “Call Sender”.

Downloading a Single MMS

“Messages”

→

“Inbox”

1. Select the SMS/MMS tab.

2. Highlight the message alert ( ) you wish to

download.

3. Press [Options] and select “Download”.

Tip

• You can download multiple messages at the same

time. See “Downloading Multiple MMS”.

Downloading Multiple MMS

→

“Messages”

“Inbox”

1. Press [Options] and select “Multiple Select”.

2. Select the desired message alerts, press [Options]

and select “Select” or “Select All”.

3. Press [Options] and select “Download”.

The selected messages are downloaded at the same time.

Messages 75

Replying to a Message or to All Addresses

“Messages”

→

“Inbox”

1. Select the desired tab, SMS/MMS or Email.

2. Highlight the message the sender of which you wish

to reply to.

3. Press [Options] and select “Reply” (to sender only)

or “Reply All” (to all other recipients listed in the original To or Cc lists).

4. Select “Reply” or “Reply with History”.

5. Enter the message.

6. Press [Options] and select “Send”.

“Send” is not available when no recipients are set.

Forwarding a Message

“Messages”

→

“Inbox”

1. Select the desired tab, SMS/MMS or Email.

2. Highlight the message you wish to forward.

3. Press [Options] and select “Forward”.

4. Perform steps 1 to 5 in “Creating a New Message”

on page 71.

76 Messages

Sorting the Messages in the List

“Messages”

→

“Inbox”

1. Select the desired tab, SMS/MMS or Email.

2. Press [Options] and select “View Settings”.

3. Select “Sort”.

4. Select the desired sort option.

Cell Broadcasts

You can receive cell broadcast messages or general messages such as weather forecasts and traffic reports. This information is broadcast to subscribers in certain network areas.

This function may not be available on all mobile phone networks. Contact your service provider for more information.

Enabling/Disabling Cell Broadcasts

“Messages” Off”

→

(M 4-9)

“Cell Broadcasts” → “Switch On/

1. Select “On” or “Off”.

Reading Cell Broadcast Messages

“Messages” Messages”

→

“Cell Broadcasts” → “Read

1. Select the desired subject.

2. Scroll the screen to read the message.

3. Press U.

Setting Languages for Cell Broadcast Messages

“Messages” “Language”

The current language is displayed.

→

“Cell Broadcasts” → “Settings” →

1. Press B to check.

2. Press [Save].

Subscribing to Cell Broadcasts

Select the page of the cell broadcast message that you want.

→

“Messages” “Set Info Subjects”

“Cell Broadcasts” → “Settings” →

1. Press [Options] and select “Add/Remove”.

2. Select the desired subject.

3. Press [Save].

Tip

• If the desired subject is not in the list that appears in

step 2, select “Create Subject” in step 1, then enter the subject code to add a page. For details on the subject code, contact your service provider.

Messages 77

Area Info

The Area Info is the message information that operators send to subscribers in certain areas. When you receive Area Info, the message (area code) is displayed in stand-by.

Enabling/Disabling Area Info

“Messages”

(M 4-10) (M 4-11)

→

“Area Info”

1. Select “On” or “Off”.

Note

• This function may not be available on all mobile

phone networks. Contact your service provider for more information.

• If Area Info is set to “On”, the stand-by time will

decrease.

78 Messages

Messaging Settings

General Settings

“Messages” “General Settings”

1. Select the item you wish to set up.

•“Signature”:

• “Auto Delete”:

• “Message List View”:

•“Scroll Unit”:

• “Message Type”:

→

“Messaging Settings” →

Enables or disables “Auto Insert”. Select “Edit” to edit current signature.

Deletes the oldest message automatically, when the Inbox, Sent or Both (Inbox and Sent) is full.

Switches the mailbox listing (“Two-line”, “Oneline”).

Scroll through messages by “Single Line”, “Half Page” or “Whole Page”.

Sets the type of message to send by default when a message is composed. When set to “Free”, the message is sent automatically either as an SMS or MMS as appropriate.

SMS Settings

“Messages”

→

“Messaging Settings” →

“SMS Settings”

1. Select the item you wish to set up.

• “Delivery Report”: Enables or disables Delivery Report request.

• “Signature”: Enables or disables “Auto Insert”. Select “Edit” to edit current signature.

• “Automatic Resend”: Tries to resend the failed SMS/MMS message up to two times (“On” or “Off” selection).

• “Expiry Time”: This indicates the number of days and hours for which a message you send may remain undelivered to the message recipient. During this period, the message service centre will continually try to deliver the message to the recipient.

• “Message Centre”: Enter the message centre number. Up to 2 numbers can be registered.

If you wish to enter a country code for a message to an international number, long press Q until a + sign is displayed.

• “Message Format”: Sets the message format to be used when creating a new message.

•“Reply Path”: Enables or disables adding a reply path to the message.

• “Optimisation”: When set “On” (default), double-byte characters such as European characters with an accent are converted into single-byte characters and sent.

When “Off”, double-byte characters are sent as displayed.

Please note that you may be charged double for double-byte characters sent in an SMS when Optimisation is set “Off”.

• “Connection Type”: Sets the preferred connection type (“GPRS Preferred”, “CSD Preferred”).

Messages 79

MMS Settings

“Messages”

→

“Messaging Settings” →

“MMS Settings”

1. Select the item you wish to set up.

• “MMS Accounts”: Select the des ired account or select “Cre ate New” to enter the following settings.

“Profile Name”: MMS profile name

(Unique name) “Proxy”: Proxy setting for MMS “Relay Server URL”: MMS relay server

• “Home Download”: Controls the message download timing inside your network area.

“Always Download”: Downloads messages

immediately from the server.

“Always Defer”: Defers message download.

80 Messages

• “Roaming Download”: Controls the message download timing when roaming outside of your network.

“Always Download”: Downloads messages

immediately from the server.

“Always Defer”: Defers message download.

• “Delivery Report”: Enables or disables Delivery Report request.

•“Signature”: Enables or disables “Auto Insert”. Select “Edit” to edit current signature.

• “Automatic Resend”: Tries to resend the failed SMS/MMS message up to two times (“On” or “Off” selection).

• “Delivery Report Allow”: Confirms whether or not a report is sent notifying the sender when you receive a message.

• “Read Report”: Enables or disables Read Report request.

•“Read Report Allow”: Enables or disables Read Report Allow when the recipient is required to inform the sender that the message has been read.

• “Slide Duration”: Sets the duration of the slide.

• “Slide Auto Play”: Enables or disables Slide Auto Play.

• “Send File Settings”: Sets whether or not to send and save the file settings.

• “Max Message Size”: Sets the maximum message size for sending and disables sending MMS messages exceeding that size.

• “Creation Mode”: When set to “Free”, you can attach files of any format to the mail. When set to “Restricted”, only certain formats and message sizes can be attached. The “Restricted” setting has priority over “Max Message Size”.

• “Emoticons”: Enables or disables the Emoticons when entering text.

• “Hide Number”: Sets whether to show or hide the sender’s address.

• “Delivery Time” (“Immediate”, “1 hour”, “12 hours”, “1 day”, “1 week”): Sets the time the message is delivered after the Send key is pressed.

• “Anonymous Rejection”: Enables or disables the rejection of messages from anonymous senders.

To Activate the MMS Account Profile

1. Select “MMS Accounts”.

2. Select the desired profile you wish to activate.

Messages 81

Email Settings

“Messages” “Email Settings”

To Set an Email Account

→

“Messaging Settings” →

1. Select “Email Accounts” and highlight the preset

Email account. You can also create a new account.

2. Press [Options] and select “Edit”.

3. Select the item you wish to set up.

“Account Name”: Email account name

“Incoming Server”: Server name, user ID,

“Outgoing Server”: Server name, user ID,

“Access Point”: Access point for Email “Email Address”: Email address

82 Messages

(Unique name)

password, port number, APOP authentication and encryption for the incoming server

password, port number, SMTP authentication and encryption for the outgoing server

“Advanced Settings”: Your name, signature,

download interval, download configuration, maximum download limit, save sent messages

To Activate the Email Account Profile

1. Select “Email Accounts”.

2. Select the desired profile you wish to activate.

FET Mobile Internet

Your phone is al ready configured to access FET Mobile Internet.

FET Mobile Internet is a new mobile internet portal which is your gateway to a new world of information, games, music and services.

Because your phone uses 3G (UMTS), it has a system that is faster than previous ways of getting mobile information. Also, the connection is ‘always on’ which means there is no need to wait for dialling up. You only have to pay for the data you send or receive, not how long you’re connected.

Your phone contains a WAP browser used for surfing on the Mobile Internet, where you can get a lot of useful information. Normally, pages are designed for a mobile phone.

Your phone is already setup to FET Mobile Internet site for WAP/MMS Settings.

(M 2)

Main Menu

→

“FET Mobile Internet”

The FET Mobile Internet service page is displayed.

“FET Mobile Internet”

The URL entry screen is displayed. You can type in the URL of a site directly.

“FET Mobile Internet”

See page 84.

“FET Mobile Internet”

WAP Push alerts are displayed.

“FET Mobile Internet”

You can view all the screenshots that have been saved onto the handset memory.

“FET Mobile Internet”

The history of pages you have recently browsed is displayed.

“FET Mobile Internet”

See page 85.

“Homepage”

→

“Go to URL”

→

“Bookmarks”

→

“Alert Inbox”

→

“My Saved Page”

→

“Access History”

→

“Browser Settings”

FET Mobile Internet 83

Navigating a WAP or Web Page

• a b c d:

Moves the highlight around in the screen.

• A: Launches the option menu if it has not

been launched. Used to select an option from the option menu.

• B: Executes the highlighted item in the

screen.

• C: Launches “FET Mobile Internet” by

opening the browser when in stand-by. Moves to previous page when the browser is active.

• F (short press):

Exits the browser.

(long press):

Turns off the phone.

84 FET Mobile Internet

Editing Bookmarks

“FET Mobile Internet”

(M 2-3)

→

“Bookmarks”

1. Select the desired URL, and press [Options].

You can edit the list of Bookmarks by the following options: (When a bookmark is focused) “Open”: Selects a bookmark. “Edit”: Edits URL address of the

“Add New Bookmark”:

“Create Folder”: Creates new folders. “Send via SMS”: Sends the URL address to

“Move”: Moves bookmarks to

“Details”: Displays detailed

“Delete”: Deletes a bookmark. “Delete All”: Deletes all bookmarks.

bookmark.

Creates new bookmarks.

recipients.

another location or into a folder.

information of the WAP/ web page.

(When a folder is focused) “Select”: Selects the folder. “Add New Bookmark”:

Creates new bookmarks. “Create Folder”: Creates new folders. “Move”: Moves folder and

bookmarks in the folder to

another location. “Rename Folder”: Renames the folder. “Delete”: Deletes the folder and

bookmarks in the folder. “Delete All”: Deletes all folders and

bookmarks. (When there are no bookmarks) “Add New Bookmark”:

Creates new bookmarks. “Create Folder”: Creates new folders.

Browser Settings

“FET Mobile Internet”

(M 2-7)

→

“Browser Settings”

“Font Size”: Sets the font size for

browsing. “Scroll Step”: Sets the speed of scrolling. “Send Referrer”: Enables or disables the

notification of the referrer. “Cookies”: Adjusts the setting of

cookies. “Downloads”: Sets whether or not to show

images when accessing the

WAP/web page. “Security”: Adjusts the security prompt

level. “WAP Push”: Sets whether you need

confirmation for push

message. “Download to”: Sets the preferred download

location.

FET Mobile Internet 85

Browser Options when Online

You can use the various options of the browser.

→

[Options]

“Select”: Selects a WAP page. “Open This Frame”: Opens the selected frame.

(This option is available only when a frame page is

displayed.) “Home”: Goes to the homepage. “Forward”: Goes to the next page. “Reload Page”: Reloads the WAP page to

get updated information. “Bookmarks”: See page 84. “Save This Page”: Saves the currently viewed

browser screenshots to the

handset memory. “Save Items”: Saves items from the

browsing pages. “Go to URL”: Allows you to type in the

URL of a site directly.

Handset browser will go to

the web/WAP page that you

entered.

86 FET Mobile Internet

“Access History”: Shows the history where

you have browsed.

“Complete Page Display”:

Allows the browser to display in complete page mode or Virtual Screen mode.

“Zoom In/Out”: Zooms in on or out from the

browsing page. This option is available only when “Complete Page Display” is set to “ON”.

“Advanced”: Displays the advanced

option menu of the browser. “Help”: Displays the browser help. “Exit”: Exits the browser.

The Advanced Options

→

[Options] → “Advanced”

“Send URL via SMS”: Sends the URL of this WAP/

web page via SMS.

“Details”: Shows detailed information

of the WAP/web page.

“Delete Browser Data”:

Deletes the browser data. You can clear the cache/ cookies/history/ authentication information.

“Search This Page”: Searches for specific words

in the WAP/web page.

“Jump to Top”: Jumps to the top of the

WAP/web page.

“Jump to Bottom”: Jumps to the bottom of the

WAP/web page.

“Copy Text”: Copies the text on the WAP/

web page.

“Browser Settings”: Displays the settings menus

(p. 85).

FET Mobile Internet 87

Gallery

Gallery contains all your pictures, music and videos. Also included in Gallery are Text Templates. You can also transmit pictures, sounds and video clips via Bluetooth wireless technology to other Bluetooth-enabled devices.

Picture Gallery

Pictures that are taken by your phone’s camera or images that are downloaded from mobile Internet sites can be viewed, edited and organised.

Viewing Pictures

“Gallery”

(M 6)

(M 6-1)

→

“Picture Gallery”

1. Select the file you wish to view.

The selected picture is displayed.

Note

• To switch between viewing handset or memory card

content, select the first item in the options menu.

Tip

• You can scroll through your pictures with P and R.

• To change the default view of pictures (list or grid), press [Options], select “Manage Items” and then select “Change List View”.

88 Gallery

Using Images as Wallpaper

→

“Gallery”

“Picture Gallery”

1. Highlight the file you wish to use as wallpaper.

2. Press [Options] and select “Set as Wallpaper”.

Editing Pictures

“Gallery”

→

“Picture Gallery”

1. Highlight the file you wish to edit.

2. Press [Options] and select “Edit”.

3. Select “Picture editor” or “Composite”.

4. Select the desired option.

Note

• “Picture editor” may not be available depending on

the original picture and copyright issued.

Saving an Image to Phonebook Entries

You can use this option only for pictures saved in the handset memory.

→

“Gallery”

“Picture Gallery”

1. Highlight the file you wish to add to Phonebook.

2. Press [Options] and select “Add to Contacts”.

To overwrite, select the data you wish to save. To save as a new entry, select “As New Contact”. For details on entering a name, see “Adding a New Phonebook Entry” on page 45.

Downloading Picture Files

→

“Gallery”

The picture file download site is displayed.

Video Gallery

Video clips that are recorded by your phone’s video camera or video clips that are downloaded from mobile Internet sites can be viewed and organised.

Playing Back Video Clip Files

“Gallery”

“Picture Gallery” → “Download More”

(M 6-2)

→

“Video Gallery”

1. Select the file you wish to play back.

To pause playback, press B. To resume, press B again. To stop playback, press U.

Note

• To switch between viewing handset or memory card

content, select the first item in the options menu.

Using a Video Clip as a Ring Video Clip

You can set your video clip to play back when the phone rings.

→

“Gallery”

“Video Gallery”

1. Highlight the desired video clip.

2. Press [Options] and select “Set as Ring Video”.

Tip

• For other option menus, see “Common Option

Menus” on page 92.

Downloading Video Clip Files

→

“Gallery”

The video clip file download site is displayed.

“Video Gallery” → “Download More”

Gallery 89

SD VIDEO

Video clips with the “ASF” format that are recorded by a video camera or downloaded from mobile Internet sites can also be managed with SD VIDEO.

“Gallery”

(M 6-3)

→

“SD VIDEO”

1. Select the desired file.

To pause playback, press B. To resume, press B again. To delete a file, highlight the file, press [Options] and select “Delete”.

Note

• In order to manage video clips with SD Video, perform recording as follows: [Options]

→

Sound Gallery

The downloaded sound files and the AMR data recorded by Voice Recorder are managed in Sound Gallery. The default ringtones are not contained within Sound Gallery. Only the sound files that can be played back on the phone are stored in Sound Gallery.

Playing Back Sound Files

“Gallery”

→

“QVGA(asf)”.

“Record Time” → “Extended Video”

→

“Sound Gallery”

(M 6-4)

1. Select the file you wish to play back.

To stop playback, press U.

90 Gallery

Note

• Playback may not be available for some sound files.

• To switch between viewing handset or memory card

content, select the first item in the options menu.

Using the Sound Files as a Ringtone

→

“Gallery”

“Sound Gallery”

1. Highlight the file you wish to use as a ringtone.

2. Press [Options] and select “Set as ringtone”.

Tip

• For other option menus, see “Common Option

Menus” on page 92.

Downloading Sound Files

→

“Gallery”

The sound file download site is displayed.

Themes

You can easily customise the display by using the theme files.

Viewing Previews

“Gallery”

“Sound Gallery” → “Download More”

(M 6-5)

→

“Themes”

1. Highlight the theme file you wish to preview.

2. Press B.

The selected theme file is displayed.

Note

• To switch between viewing handset or memory card

content, select the first item in the options menu.

Setting Theme

→

“Gallery”

“Themes”

1. Select the desired theme file.

The selected theme file is set as the default theme.

Tip

• Even after a theme is set, you can set a wallpaper

regardless of the set theme. In this case, the other items follow the set theme.

• For other option menus, see “Common Option

Menus” on page 92.

Downloading Theme Files

→

“Gallery”

The theme file download site is displayed.

“Themes” → “Download More”

Text Templates

You can register up to 50 text templates for use in text messages and multimedia messages. The maximum capacity of the text templates is 256 characters.

Adding Phrases to Text Templates

→

“Gallery” Template”

“Text Templates” → “Add New

(M 6-7)

1. Enter the text and press B.

Editing Text Templates

“Gallery”

→

“Text Templates”

1. Highlight the text template you wish to edit.

2. Press [Options] and select “Edit”.

To view the text template, press B. To delete the text template, press [Options] and select “Delete”.

3. Modify the text and press B.

Sending Text Templates

“Gallery”

→

“Text Templates”

1. Highlight the text template you wish to send.

2. Press [Options] and select “Send Template”.

Gallery 91

Java™

Java™ Gallery

The list of Java™ applications is displayed. Downloaded applications are displayed in order

starting from the latest one.

Downloading Applications

“Java™”

(M 1)

(M 1-1)

→

“Java™ Gallery” → “Download More”

1. Select the desired application.

Before downloading the application you are asked to confirm what you are about to receive. After checking the information on the confirmation screen, the application can be downloaded.

2. Press B to start downloading.

3. Press B when finished.

Note

• User authentication may be required before

downloading the application on some information screens.

96 Java™

Executing Applications

→

“Java™”

“Java™ Gallery”

1. Select the title of the application you wish to

execute. The selected application is executed. When using

network connection type applications, connection to the network can be selected.

2. To end the application, press F and select “End”.

Setting as a Screensaver for the Display

“Java™”

→

“Java™ Gallery”

1. Highlight the file you wish to use as a screensaver.

2. Press [Options] and select “Set as Screensaver”.

Setting Permission

You can set permission for selected Java™ applications.

→

“Java™”

“Java™ Gallery”

1. Highlight the desired Java™ application.

2. Press [Options] and select “Permission”.

3. Select one of the following options:

“Phone Call”: Sets permission to make voice

calls.

“Network Access”: Sets permission to access the

network.

“Messaging”: Sets permission to perform

SMS messaging.

“Autorun”: Sets permission to perfo rm the

Autorun function.

“Local Connection”: Sets permission to connect to

local devices.

“Read User Data”: Sets permission to read user

data, such as Phonebook entries, mailbox (Inbox) and Gallery data.

“Write User Data”: Sets permission to write

entries in your phone, such as Phonebook entries, mailbox (Inbox) and Gallery data.

“Use Multimedia”: Sets permission to use the

multimedia recording.

4. Select one of the following options:

“Session”: The confirmation message is

not displayed until you exit the application, while execution of network access is authorised.

“Ask Once”: The confirmation message is

displayed every time network access is executed.

“Blanket”: The confirmation message is

not displayed until the application is deleted or you change the settings, while execution of network access is authorised.

“No”: Execution of network access

is not authorised.

Note

• To clear all the permission settings, select “Reset” in

step 3.

• Some permissions are not available for some Java™

applications.

• “Read User Data” and “Write User Data” may not

be available in step 3.

Java™ 97

Viewing Application Information

You can check the information of Java™ applications.

“Java™”

→

“Java™ Gallery”

1. Highlight the desired Java™ application.

2. Press [Options] and select “Information”.

Deleting an Application

You can delete an application in the folder.

“Java™”

→

“Java™ Gallery”

1. Highlight the desired Java™ application.

2. Press [Options] and select “Delete”.

98 Java™

Java™ Settings

Application Volume

You can set the volume of the application such as the sound effect to one of the five levels or silent. When the profile is set to “Silent”, the “General Volume” setting (p. 116) has priority.

→

“Java™” Volume”

“Java™ Settings” → “Application

(M 1-2)

1. Press a (or d) to increase the volume or press b

(or c) to decrease the volume and then press B.

Backlight

“Java™” “Switch On/Off”

→

“Java™ Settings” → “Backlight” →

1. Select from “Always On”, “Always Off” or

“Normal Settings”. “Always On”: Lit while the application is

“Always Off”: Unlit while the application is

“Normal Settings”: Works with the main

operated.

operated even if a key is pressed.

backlight setting (p. 124).

To Set the Blinking Operation

This setting enables the backlight to be controlled by the application. If set to “Off”, the backlight cannot be turned on from the application.

→

“Java™” “Blink”

“Java™ Settings” → “Backlight” →

1. Select “On” or “Off”.

Vibration

When the vibrator is set in the application, you can choose whether the operation is enabled or disabled.

→

“Java™”

“Java™ Settings” → “Vibration”

1. Select “On” or “Off”.

Calls & Alarms

You can set the priority of incoming calls and alarms while an application is operating.

→

“Java™”

“Java™ Settings” → “Calls & Alarms”

1. Select “Voice Call”, “Video Calling”, “Incoming

Message” or “Alarm”.

2. Select the desired method.

• “Call Priority”, “Message Priority” or “Alarm Priority”: The application is suspended automatically, and you can receive a call or a message, or the alarm will sound. After finishing the call or sending the message, or when the alarm ends, the suspend indicator ( ) is displ ayed letting you kn ow there is a suspended application.

• “Call Notice”, “Message Notice” or “Alarm Notice”: The marquee (character scrolls) is displayed on the first line of the screen while the application continues. If you press D, the application is suspended, and you can receive a call. After finishing the call or sending the message, the suspend indicator ( ) is displayed letting you know there is a suspended application.

Java™ 99

Sharp WX-T82 User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction

Contents

List of Menu Functions

Your Phone

Optional Accessories

Getting Started

Inserting/Removing the SIM/USIM Card and the Battery

Charging the Battery

Inserting/Removing the Memory Card

Connecting the Handsfree Kit

Turning Your Phone On and Off

Slide Functions and Keypad Lock

Display Indicators

Navigating Functions

Voice Call/Video Calling Functions

Entering Characters

Changing the Input Language

Changing the Input Method

Chinese User Dictionary

Using Templates

Insert Phonebook Entries

Using the Menu

Main Menu

Shortcut Keys

Call Manager

Sending a Message from the Phonebook

Audiovisual

Camera

Taking Pictures

Recording Video Clips

Common Functions in the Photo and Video Camera Modes

Functions in Photo Camera Mode

Functions in Video Camera Mode

Messages

Long SMS

Email

FET Mobile Internet

Navigating a WAP or Web Page

Gallery

Java™
