LC-32L407I

SERVICE MANUAL

No. S40F6LC32L40M

LCD COLOUR TELEVISION

MODEL

In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified should be used.

CONTENTS

SAFETY PRECAUTION

IMPORTANT SERVICE SAFETY

PRECAUTION............................................................ i

PRECAUTIONS FOR USING LEAD-FREE

SOLDER ................................................................... ii

OUTLINE

MAJOR SERVICE PARTS ........................................iii

CHAPTER 1. SPECIFICATIONS

[1] SPECIFICATIONS .................................................1-1

CHAPTER 2. OPERATION MANUAL

[1] OPERATION MANUAL ..........................................2-1

CHAPTER 3. DIMENSIONS

[1] DIMENSIONS ........................................................3-1

CHAPTER 4. REMOVING OF MAJOR PARTS

[1] REMOVING OF MAJOR PARTS ...........................4-1

LC-32L407I

CHAPTER 9. SCHEMATIC DIAGRAM

[1] DESCRIPTION OF SCHEMATIC DIAGRAM.........9-1

[2] MAIN Unit...............................................................9-2

[3] POWER SUB Unit................................................9-12

[4] R/C, LED Unit.......................................................9-16

Parts Guide

CHAPTER 5. ADJUSTMENT

[1] ADJUSTMENT PROCEDURE ...............................5-1

CHAPTER 6. TROUBLESHOOTING TABLE

[1] TROUBLESHOOTING TABLE...............................6-1

CHAPTER 7. OVERALL WIRING/BLOCK DIAGRAM

[1] OVERALL WIRING DIAGRAM ..............................7-1

[2] SYSTEM BLOCK DIAGRAM .................................7-2

CHAPTER 8. PRINTED WIRING BOARD ASSEMBLIES

[1] MAIN Unit...............................................................8-1

[2] POWER SUB Unit..................................................8-3

[3] R/C, LED Unit.........................................................8-5

Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the safety and performance of the set.

This document has been published to be used for after sales service only. The contents are subject to change without notice.

LC-32L407I

LC-32L400M

SAFETY PRECAUTION

Service Manual

IMPORTANT SERVICE SAFETY PRECAUTION

Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow:

WARNING

1. For continued safety, no modification of any circuit should be attempted.

2. Disconnect AC power before servicing.

BEFORE RETURNING THE RECEIVER (Fire &

All checks must be repeated with the AC cord plug connection reversed. (If necessary, a nonpolarized adaptor plug must be used only for the purpose of completing these checks.)

Any reading of 0.74 Vrms (this corresponds to 0.5 mA rms AC.) or more is excessive and indicates a potential shock hazard which must be corrected before returning the monitor to the owner.

Shock Hazard)

Before returning the receiver to the user, perform the following safety checks:

3. Inspect all lead dress to make certain that leads are not pinched, and check that hardware is not lodged between the chassis and other metal parts in the receiver.

4. Inspect all protective devices such as non-metallic control knobs, insulation materials, cabinet backs, adjustment and compartment covers or shields, isolation resistor-capacitor networks, mechanical insulators, etc.

5. To be sure that no shock hazard exists, check for leakage current in the following manner.

• Plug the AC cord directly into a 110-240 volt AC outlet.

• Using two clip leads, connect a 1.5k ohm, 10 watt resistor paralleled by a 0.15 F capacitor in series with all exposed metal cabinet parts and a known earth ground, such as electrical conduit or electrical ground connected to an earth ground.

• Use an AC voltmeter having with 5000 ohm per volt, or higher, sensitivity or measure the AC voltage drop across the resistor.

• Connect the resistor connection to all exposed metal parts having a return to the chassis (antenna, metal cabinet, screw heads, knobs and control shafts, escutcheon, etc.) and measure the AC voltage drop across the resistor.

///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////

TO EXPOSED METAL PARTS

DVM

AC SCALE

1.5k ohm 10W

0.15µF

TEST PROBE

CONNECT TO KNOWN EARTH GROUND

SAFETY NOTICE

Many electrical and mechanical parts in LCD colour television have special safety-related characteristics.

These characteristics are often not evident from visual inspection, nor can protection afforded by them be necessarily increased by using replacement components rated for higher voltage, wattage, etc.

Replacement parts which have these special safety characteristics are identified in this manual; electrical components having such features

are identified by " " and shaded areas in the Replacement Parts List and Schematic Diagrams.

For continued protection, replacement parts must be identical to those used in the original circuit.

The use of a substitute replacement parts which do not have the same safety characteristics as the factory recommended replacement parts shown in this service manual, may create shock, fire or other hazards.

LC-32L407I

PRECAUTIONS FOR USING LEAD-FREE SOLDER

Employing lead-free solder

• “PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The alphabetical character following LF shows the type of lead-free solder.

Example:

Indicates lead-free solder of tin, silver and copper. Indicates lead-free solder of tin, silver and copper.

Using lead-free wire solder

• When fixing the PWB soldered with the lead-free solder, apply lead-free wire solder. Repairing with conventional lead wire solder may cause damage or accident due to cracks.

As the melting point of lead-free solder (Sn-Ag-Cu) is higher than the lead wire solder by 40 C, we recommend you to use a dedicated soldering bit, if you are not familiar with how to obtain lead-free wire solder or soldering bit, contact our service station or service branch in your area.

Soldering

• As the melting point of lead-free solder (Sn-Ag-Cu) is about 220 C which is higher than the conventional lead solder by 40 C, and as it has poor solder wettability, you may be apt to keep the soldering bit in contact with the PWB for extended period of time. However, Since the land may be peeled off or the maximum heat-resistance temperature of parts may be exceeded, remove the bit from the PWB as soon as you confirm the steady soldering condition.

Lead-free solder contains more tin, and the end of the soldering bit may be easily corroded. Make sure to turn on and off the power of the bit as required.

If a different type of solder stays on the tip of the soldering bit, it is alloyed with lead-free solder. Clean the bit after every use of it.

When the tip of the soldering bit is blackened during use, file it with steel wool or fine sandpaper.

• Be careful when replacing parts with polarity indication on the PWB silk.

Lead-free wire solder for servicing

PARTS CODE

ZHNDAi123250E BL J 0.3mm 250g (1roll) ZHNDAi126500E BK J 0.6mm 500g (1roll) ZHNDAi12801KE BM J 1.0mm 1kg (1roll)

PRICE RANK

PART

DELIVERY

DESCRIPTION

LC-32L407I

LC-32L400M

OUTLINE

Service Manual

MAJOR SERVICE PARTS

PWB UNIT

Ref No. Part No. Description

N B3KU3L47I1 DUNTKF537FM02, MAIN Unit

DUNTKF539FM02, N N RDENC2590TPZZ INVERTER Unit

B3KU3L47I2 DUNTKF538FM02, POWER SUB Unit

OTHER UNIT

Ref No. Part No. Description

N B3KU32L50 32” LCD Panel Module (R1LK315T3LA5BX)

N B3KU3L47I 32” LCD Panel Module (R1LK315T3LW70W) ALTERNATIVE

IC FOR EXCLUSIVE USE OF THE SERVICE

Ref No. Part No. Description Q'ty

IC508 RH-iXD169WJQZS IC, PC EDID 1

IC1503 RH-iXD170WJQZS IC, HDMI EDID 1

R/C - LED Unit

SERVICE JIGS

Ref No. Part No. Description Q’ty

N QCNW-L077WJQZ Connecting Cord, MAIN-LCD CONTROL (LW) 1 N QCNW-K814WJQZ Connecting Cord, POWER-INVERTER (PI) 1 N QCNW-J413WJQZ Connecting Cord, MAIN-SPEAKER (SP) 1

iii

LC-32L400M

CHAPTER 1. SPECIFICATIONS

[1] SPECIFICATIONS

LC-32L407I

Service Manual

Item

LCD panel

Resolution

Video Colour System PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60

TV Function

Viewing angles H : 176º V : 176º

Audio amplifier

Speakers

Terminals Rear Antenna input

OSD language English/Simplified Chinese/Arabic/French/Portuguese/Russian/Persian/Thai/

Power Requirement AC 110_240 V, 50/60 Hz

Power Consumption 112 W (0.9 W Standby)

Dimensions

Weight

Operating Temperature 0°C_40°C

As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.

TV-Standard PAL: B/G, D/K, I SECAM: B/G, D/K, K/K

Receiving Channel

TV-Tuning System Auto Preset 99 ch

STEREO/BILINGUAL NICAM: B/G, I, D/K A2 stereo: B/G

INPUT 1

INPUT 2 S-VIDEO in, VIDEO in, AUDIO in

INPUT 3 VIDEO in, AUDIO in

INPUT 4 AUDIO in, COMPONENT in (480I, 576I, 480P, 576P, 720P/50Hz, 720P/60Hz,

INPUT 5 (PC input)

RS-232C 9 pin D-sub male connector

without stand

with stand

without stand 10.0 kg

with stand 11.0 kg

Model

VHF/UHF 44.25_863.25 MHz

CATV S1_S41ch (including Hyperband)

LC-32L407I

32" (800 mm) Advanced Super View & BLACK TFT LCD

1,049,088 pixels (1366 768)

NTSC: M

5W 2

9 5 cm 2pcs

UHF/VHF 75 DIN type

HDMI (HDMI input) (480I,576I, 480P, 576P, 720P/50Hz, 720P/60Hz, 1080I/50Hz, 1080I/60Hz), AUDIO in ( 3.5 mm jack)

1080I/50Hz, 1080I/60Hz)

15 pin mini D-sub, AUDIO in (common use with INPUT 1) (

Vietnamese/Indonesian

797 (W) 535 (H) 115 (D) mm

797 (W) 580 (H) 262 (D) mm

3.5 mm jack)

1 – 1

LC-32L407I

LC-32L400M

CHAPTER 2. OPERATION MANUAL

[1] OPERATION MANUAL

Part names

TV (Front)

TV (Rear)

ANALOGUE RGB (PC)

Service Manual

OP C s ens or

R emote control s ensor

POWER indicator

Light off Power off

Lighted (Red) The TV is in standby mode.

Lighted (Green) The TV is on.

1 POWER (On/Off) button 2MENUbutton 3 TV/VIDEO button 4 Channel up ( )/down ( ) buttons 5 Volume up ( )/down ( ) buttons 6 Antenna input terminal 7 INPUT 5 (PC) terminals* 8 INPUT 1 (HDMI) terminal* 9 RS-232C terminal

10 SERVICE ONLY terminal** 11 INPUT 2 terminals 12 INPUT 3 terminals 13 INPUT 4 terminals

* The INPUT 1 and INPUT 5 terminals can both use the same audio input terminal. However, the proper item must be

selected in the "PC Audio Select" menu.

**Usually do not connect anything to this terminal as it is reserved only for service personnel.

The illustrations in this operation manual are for explanation purposes and may vary slightly from the actual operations.

2 – 1

Remote control unit

3 4 5

1 (Mute)

Press Mutes sound. Press again Restores sound.

Mute will be cancelled after 30 minutes. However, the TV will not suddenly output loud sound as the volume level will be set to 0 automatically. Increase the volume level by pressing VOL

20_9

Set the channel. TELETEXT mode: Set the page.

3 (Flashback)

Press to return to the previous selected channel

or external input mode.

4WIDE

Change the wide image mode.

5 VOL /VOL

Set the volume. (VOL ) Increase the volume. (VOL ) Decrease the volume.

6 FREEZE

Freeze a motion picture on the screen.

10 11 12

13 14

15 16

17 18

7 EXIT

Return to the default screen.

8 Colour (Red/Green/Yellow/Blue)

TELETEXT mode: Select a page.

9 POWER (STANDBY/ON)

To switch the power on and off.

10 DISPLAY

Display the channel or input information.

11 SLEEP

Set the Sleep timer.

0hr.30min. 1hr.00min.

Off

2hr.30min.

12 AV MODE

Select an audio and video setting.

13 MPX

Select the sound multiplex mode.

14 TV/VIDEO (INPUT SOURCE)

Select an input source.

15 CH /CH

TV input mode: Select the channel. (CH ) Increase the channel number. (CH ) Decrease the channel number. TELETEXT mode: Select the page.

16 PC

Directly select the PC terminal.

17 MENU

Display the menu screen.

18 / / / (Cursor)

Select a desired item on the setting screen.

ENTER

Execute a command.

19 RETURN

MENU mode: Return to the previous menu screen.

20 (TELETEXT)

Select the TELETEXT mode. (all TV image, all TEXT image, TV/TEXT image)

(Reveal hidden for TELETEXT)

TELETEXT mode: Display hidden characters.

(SUBTITLE for TELETEXT)

To turn the subtitles on and off.

(Hold)

TELETEXT mode: Stop updating Teletext pages automatically. Press again to release the hold mode.

(Subpage)

Display the Teletext subpage directly when in Teletext mode.

(Top/Bottom/Full)

TELETEXT mode: Set the area of magnification.

1hr.30min.

2hr.00min.

LC-32L407I

Inserting the battery

Before using the TV for the first time, insert a "AA" size battery (supplied). When the battery become depleted and the remote control fails to operate, replace the battery with new "AA" size battery.

Open the battery cover.

CAUTION

Battery (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like.

Insert the supplied "AA" size battery.

Place battery with their terminals corresponding to the ( ) and ( ) indications in the battery compartment.

Close the battery cover.

2 – 2

LC-32L407I

Attaching the stand

Before attaching (or detaching) the stand, unplug the AC cord from the AC outlet. Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being damaged.

Confirm the screws supplied with the TV.

Screws ( 4)

(usedinstep3)

Insert the stand base to the stand post on the bottom of the TV. ( )

Insert and tighten the 4 screws into the 4 holes on the bottom of the stand base. ( )

NOTE

To detach the stand, perform the steps in reverse order.

Soft cushion

Screw

Screw driver

2 – 3

Unit: mm

LC-32L400M

CHAPTER 3. DIMENSIONS

[1] DIMENSIONS

LC-32L407I

Service Manual

3 – 1

LC-32L407I

LC-32L400M

CHAPTER 4. REMOVING OF MAJOR PARTS

Service Manual

[1] REMOVING OF MAJOR PARTS

1. Removing of the Stand and Back Cover

1. Detach the Stand Hinge Cover [1].

2. Remove the 4 lock screws [2] and detach the Stand.

3. Remove the 1 lock screw [3], 1 lock screw [4], 1 lock screw [5], 6 lock screws [6] and detach the Back Cover.

Back Cover

Stand

Stand Hinge Cover

4 – 1

2. Disconnect the connectors

1. Disconnect the connectors from the MAIN Unit, POWER SUB Unit [1].

MAIN Unit

LC-32L407I

POWER SUB Unit

4 – 2

LC-32L407I

3. Removing of the MAIN Unit and POWER SUB Unit

1. Remove the 2 lock shafts [1], 2 lock shafts [2], 2 lock screws [3] and detach the MAIN Unit.

2. Remove the 5 lock screws [4] and detach the POWER SUB Unit.

MAIN Unit

POWER SUB Unit

4 – 3

4. Removing of the Rear Cabinet

1. Remove the 7 lock screws [1] and detach the Rear Cabinet.

LC-32L407I

Rear Cabinet

4 – 4

LC-32L407I

5. Removing of the Speaker and R/C, LED Unit

1. Disconnect the connectors from the INVERTER Unit and LCD Panel Module [1].

2. Disconnect SP connectors [2]. Remove the 4 lock screws [3] and detach the Speaker, remove the 2 Speaker rubber [3a] and 2 Molt Plane [3b].

3. Detach the R/C, LED Unit [4] and disconnect RA connector [5].

LCD Panel Module

LVDS

INVERTER Unit

R/C, LED Unit

Speaker

4 – 5

6. Removing of the Top Bracket, Bottom Bracket and LCD Panel Module

1. Remove the 4 lock screws [1].

2. Remove the 6 lock screws [2] and detach the Top Bracket, Bottom Bracket.

3. Remove the 2 lock screws [3] and detach the LCD Panel Module.

Top Bracket

LC-32L407I

LCD Panel Module

Bottom Bracket

4 – 6

LC-32L407I

LC-32L400M

CHAPTER 5. ADJUSTMENT

Service Manual

[1] ADJUSTMENT PROCEDURE

1. Entering and cancel the adjustment process mode

While holding down the TV/VIDEO and Volume DOWN keys at the same time, plug in the AC cord to turn on the power. (“K123” standing for

inspection process mode is displayed on the middle right section of the screen.)

Press the Channel DOWN and Volume DOWN keys at the same time. (The adjustment process mode screen appears.)

To cancel it, turn off the power using the Power switch or remote control.

2. Remote controller key operation and description of display in adjustment process mode.

1. key operation

Remote controller key Main unit key Function

CH ( / ) VOL (+ / –) VOL (+ / –) Changing volume (UP/DOWN) Cursor ( / )

Cursor ( / ) TV/VIDEO button on remote controller ENTER —————— ——————

CH ( / )

—————— Turning a page (PREVIOUS/NEXT) —————— Changing a selected line setting (+10/-10)

TV/VIDEO button Input source switching (toggle switching)

Changing channel (UP/DOWN)

(T V-DAV-1/SAV-1 AV- 2 COMPONENT HDMI PC)

* Input mode is switched automatically when relevant adjustment is started so far as the necessary input signal is available.

3. Signal adjustment

3.1. Signal check

Confirmation of signal from generator (setting to spec level)

PAL Composite signal : 0.7Vp-p 0.02Vp-p (Pedestal to white level) 15K Component signal (50Hz) : Y level:

Pb, Pr level:

33K component signal : Y level:

Pb, Pr level:

3.1.1 PROCESS MODE

Adjustment item Adjustment conditions Adjustment procedure

1 Adjustment mode 1) Press the test key at the test remote control.

*On double screen models, the tuner, composite signal and component signal adjustment are made for their single screen mode and double screen mode as well.

3.1.2 Component 15K 50Hz signal adjustment (COMP-SD)

Adjustment item Adjustment conditions Adjustment procedure

1 Adjustment [Signal]

COMP 15K 50Hz (576i) 100% Full-field Colour Bar

[Terminal] INPUT 4 COMPONENT

0.7Vp-p 0.02Vp-p (Pedestal to white level)

0.7Vp-p 0.02Vp-p

0.7Vp-p 0.02Vp-p (Pedestal to white level)

0.7Vp-p 0.02Vp-Com

Feed the COMPONENT 15K 50Hz (576i) 100% Full-field Colour Bar signal (100% colour saturation) to INPUT 4 COMPONENT terminal.

2 Auto adjustment

performance

Process Mode page 4 (COMP SD)

100% white Black

1) At the related page, move cursor to [COMP SD ADJ], press ENTER.

2) [OK] appears when finished.

5 – 1

3.1.3 Component 33K 60Hz signal adjustment (COMP-HD)

Adjustment item Adjustment conditions Adjustment procedure

1 Adjustment [Signal]

COMP 33K 60Hz (1080i) 100% Full-field Colour Bar

[Terminal] INPUT 4 COMPONENT

Feed the COMPONENT 33K 60Hz (1080i) 100% Full-field Colour Bar signal (100% colour saturation) to INPUT 4 COMPONENT terminal.

100% white Black

LC-32L407I

2 Auto adjustment

performance

Process Mode page 5 (COMP HD)

1) At the related page, move cursor to [COMP HD ADJ], press ENTER.

2) [OK] appears when finished.

3.1.4 PC (ANALOG RGB) signal adjustment (PC-RGB)

Adjustment item Adjustment conditions Adjustment procedure

1 Adjustment [Signal]

XGA 60Hz 100% Checkered Pattern

[Terminal] PC INPUT

2 Auto adjustment

performance

Process Mode page 6 (PC-RGB)

Feed the XGA 60Hz 100% Checkered pattern signal (100% colour saturation) to PC INPUT. *Please make sure SYNC is OFF.

1) At the related page, move cursor to [RGB ADJ], press ENTER.

2) [OK] appears when finished.

5 – 2

LC-32L407I

Level

Spec Data

Adjustment

Spec.

Inspection

Spec.

Point 2

ref.

values

Point 1

ref.

values

204

128

x=0.272 y=0.277

0.0010

0.0045

0.0020

0.0090

3.2. White balance adjustment

Adjustment item Adjustment conditions Adjustment procedure

1 Adjustment Brightness : MAX

Set the luminance meter on the center of the screen

For the details of white balance adjustment procedure, please refer to white balance adjustment spec for current model.

1) Confirm the set condition.

2) Connect the luminance meter CA-210.

3) Through RS-232C command, adjustment mode screen is displayed.

2 Auto Adjustment

performance

[command] Adjustment Mode KRSW0001 KKT10037

Setting KYOF0001 OSDS0001 SBSL0016

Multi point adj. Mode MSET0001

Point 2 LEV20204 WBI20204 MG2G**** MG2B**** MG2R****

Point 1 LEV10128 WBI10128 MG1G**** MG1B**** MG1R****

Write MSET0003

[Adjustment Procedure]

1) Using the remote control, set the LCD TV to adjustment mode.

2) Set the specified gradation for point 2, fix the most faint colour to get reference value, adjust others 2 colour to minus adjustment for reference value of point 2.

3) Set the specified gradation for point 1. Set G of point 1 to the default value [(2048xG value of point 2/3264), with fractions rounded] and adjust RB to the reference value of point 1.

4) Adjusted value is writing at [command] MSET0003, and then shut down the AC power.

*Initial value at RGB 2 point : 3264 *Initial value at RGB 1 point : 2048

[Adjustment Value]  Specification data by engineering dept is set as reference.

[Reference value for adjustment reference] Equipment: Luminance meter [Minolta CA-210]

Ref. : For inspection, set the LCD TV as below.

AV MODE: [DYNAMIC] (Reset) Monochrome: ON Aging Time: Minimum 60 minutes

4. Factory setting

AC power is plug off after shipment setting is done.

CAUTION: Do not plug on again after shipment setting is done. If do, please re-do the shipment setting. Do not off with remote control.

Adjustment item Adjustment condition Adjustment procedure

Factory setting AC power off to exit the fac-

tory setting.

1) Setting is done with test remote control.

2) When Green background appears on screen and “K” mark disappears, setting is completed.

The followings are initialized to factory setting

1) User setting

2) Channel data (e. g. broadcast frequencies)

3) Manufacturer’s option settings

4) Password data

5) Setting values are set based on model destination

5 – 3

5. Software upgrading

Do not power off Chip programming >>>>>>>>

1) Plug off the LCD TV.

2) Insert the USB device to the USB terminal at the LCD TV.

(Make sure that latest software is installed in the USB device)

3) Hold the LCD TV power key and plug on the LCD TV.

4) LCD TV is on and detecting the USB device.

USB device found

5) A few seconds later, the software upgrading will start automatically.

LC-32L407I

6) Let the process running & entering verification.

Verifying

Verified

7) Software is successfully installed when the following appears at the end of the process.

Please re-boot the system Update Finished

8) Plug off the LCD TV & plug on again as usual.

9) LCD TV is running with the latest software.

5 – 4

LC-32L407I

LC-32L400M

CHAPTER 6. TROUBLESHOOTING TABLE

Service Manual

[1] TROUBLESHOOTING TABLE

No power (front LED failure to light up) or no startup (front LED failure to turn from red to green)

Is the AC cord connector tightly connected to the set? NO Reconnect the AC cord tightly and turn on the power again.

YES Is the output voltage at pin (7), (8), (9) and (10) of P5201 (13.0V line) as specified?

YES Are the wire harnesses and other cables properly connected in

the set?

YES Is there the AC_DET and PNL_ON signal input at pins (14) and (1) of P5201?

NO Replace the power unit.

NO Reconnect the wire harnesses and other cables properly in the

set.

NO Check the AC_DET signal line PNL_ON signal line.

YES Are the DC/DC converter outputs and the output voltages along the control lines as specified?

1) B1.26V (IC9606)

2) D2.6V (IC9603)

3) STB+3.3V (IC9602)

4) D3.3V (IC9653)

5) B5V (IC9652)

NO Check the DC/DC converters and the control lines. Replace

defective parts as required.

6 – 1

With [RF] signal input No video onscreen (1)

No video in the UHF/VHF reception

Is there IF output from the tuner pin(12) of TU1101 as specified? NO Check TU1101 and its peripheral circuits.

YES Is there VIF input at pin 57 & 58 of IC3301? NO Check the circuit between TU1101 & IC3301.

YES Are there the signal outputs of IC3301? NO Check IC3301 and its peripheral circuit.

YES Check LVDS cable, LCD controller (incl. panel) and their periph-

eral circuits.

With <Video> signal input No video onscreen (2)

LC-32L407I

No external input video onscreen <INPUT 2>

Is INPUT 2 selected on the input select menu screen? NO Select INPUT 2 on the input select menu screen to pick up the

right input signal.

YES Is there the video signal input at pin (33) of IC3301? NO Check the line between pin (3) of J5510 and pin (33) of IC3301.

YES Are there signal outputs of IC3301? NO Check IC3301 and its peripheral circuits.

YES Check LVDS cable, LCD controller (incl. panel) and their peripheral circuits.

6 – 2

LC-32L407I

With <Video> signal input No video onscreen (3)

No external input video onscreen <INPUT 3>

Is INPUT 3 selected on the input select menu screen? NO Select INPUT 3 on the input select menu screen to pick up the

YES Is there the video signal input at pin (35) of IC3301? NO Check the line between pin (3) of J5508 and pin (35) of IC3301.

YES Are there signal outputs of IC3301? NO Check IC3301 and its peripheral circuits.

YES Check LVDS cable, LCD controller (incl. panel) and their periph-

eral circuits.

With <S-video> signal input No video onscreen (4)

right input signal.

No external input video onscreen <INPUT 2>

Is INPUT 2 selected on the input select menu screen? NO Select INPUT 2 on the input select menu screen to pick up the

right input signal.

YES Are there the following signal inputs at the input terminals of

IC3301?

<S-video signal> Are there the Y and C signal inputs at pins (30) and (29), respectively?

YES Are there signal outputs of IC3301? NO Check IC3301 and its peripheral circuits.

YES Check LCD controller (incl. panel) and their peripheral circuits.

NO <S-video signal>

Check the line between pins (3), (4) of J5511 and pins (30)/(29) of IC3301.

6 – 3

LC-32L407I

With <Component> signal input No video onscreen (5)

No external input video onscreen <INPUT 4>

Is INPUT 4 selected on the input select menu screen? NO Select INPUT 4 on the input select menu screen to pick up the

YES Are there the Y, Pb and Pr signal inputs at pins (15), (13) and (17) of IC3301 respectively?

YES Is input waveform of IC3301 normal? Y=(15) pin, Pb=(13) pin, Pr=(17) pin

YES Check LVDS cable, LCD controller (incl. panel) and their periph-

eral circuits.

With <HDMI> signal input No video onscreen (6)

NO Check the line between pins (3)/(5)/(7) of J5509 and pins (15)/

NO Check IC3301 and its peripheral circuits.

right input signal.

(13)/(17) of IC3301.

No external input video onscreen <INPUT 1>

Is INPUT 1 selected on the input select menu screen? NO Select INPUT 1 on the input select menu screen to pick up the

right input signal.

YES Are there the signal inputs from the HDMI (SC1501)

connector to the following input terminals of IC3301.

YES Are there signal outputs of IC3301? NO Check IC3301 and its peripheral circuits.

YES Check LVDS cable, LCD controller (incl. panel) and their peripheral circuits.

NO Check IC3301 and their peripheral circuits.

6 – 4

LC-32L407I

No audio heard (1)

No sound in the UHF/VHF reception.

Is the IF output from the tuner pin (12) of TU1101 as specified? NO Check TU1101 and its peripheral circuits.

YES

Is there the I2S signal input at pins (180), (181) of IC3301? NO Check IC3301 and its peripheral circuits.

YES Is there L-ch audio signal input at pin(3) of IC2701? NO Check connection between IC3301 and IC2701 and its Is there R-ch audio signal input at pin(7) of IC2701?

YES Is the L-ch audio signal output at pin(27), (28), (29) and (30) of IC2701 normal? Is the R-ch audio signal output at pin(11), (12), (13) and (14) of IC2701 normal?

NO Check IC2701 and its peripheral circuits.

peripheral circuits.

YES Are the audio signal L-ch and R-ch output at (1)/(2) and (3)/(4) of

P2701 normal?

YES Check speakers and their peripheral circuits.

NO Check circuit between IC2701 & P2701.

6 – 5

LC-32L407I

No audio heard (2)

No external audio heard <INPUT 2> Is there the L-ch audio signal input from pin (5) of input terminal

J5510 to pin (77) of IC3301? Is there the R-ch audio signal input from pin (7) of input terminal J5510 to pin (78) of IC3301?

<INPUT 3> Is there the L-ch audio signal input from pin (5) of input terminal

J5508 to pin (75) of IC3301? Is there the R-ch audio signal input from pin (7) of input terminal J5508 to pin (76) of IC3301? <INPUT 4> Is there the L-ch audio signal input from pin (2) of input terminal J5503 to pin (72) of IC3301? Is there the R-ch audio signal input from pin (4) of input terminal J5503 to pin (73) of IC3301?

YES

Is there the I2S signal input at pin (180), (181) of IC3301? NO Check IC3301 and its peripheral circuits.

YES Is there L-ch audio signal input at pin(3) of IC2701? NO Check connection between IC3301 and IC2701 and its periphIs there R-ch audio signal input at pin(7) of IC2701?

eral circuits.

YES Is the L-ch audio signal output at pin(27), (28), (29) and (30) of

IC2701 normal? Is the R-ch audio signal output at pin(11), (12), (13) and (14) of

IC2701 normal?

YES Are the audio signal L-ch and R-ch output at (1)/(2) and (3)/(4) of P2701 normal?

YES Check speakers and their peripheral circuits.

NO Check IC2701 and its peripheral circuits.

NO Check circuit between IC2701 & P2701.

6 – 6

LC-32L407I

No audio heard (3)

No HDMI sound heard. <INPUT 1> (*INPUT 1 is digital audio.)

Does the HDMI image appear onscreen? NO Refer to “<INPUT 1> in No external input video onscreen

(HDMI)”.

YES No audio output from INPUT 1. NO Check the EDID.

YES Are waveforms input in to the pins of IC3301 normally and I2S output from the pins (180), (181) normally?

YES Is there L-ch audio signal input at pin(3) of IC2701? NO Check connection between IC3301 and IC2701 and its periphIs there R-ch audio signal input at pin(7) of IC2701?

NO Check peripheral circuits of IC3301.

eral circuits.

YES Is the L-ch audio signal output at pin(27), (28), (29) and (30) of IC2701 normal? Is the R-ch audio signal output at pin(11), (12), (13) and (14) of IC2701 normal?

YES Are the audio signal L-ch and R-ch output at (1)/(2) and (3)/(4) of

P2701 normal?

YES Check speakers and their peripheral circuits.

NO Check IC2701 and its peripheral circuits.

NO Check circuit between IC2701 & P2701.

6 – 7

LC-32L407I

No audio heard (4)

No sound from the HDMI sound input terminal. (INPUT 1 analog audio)

YES Is there the L-ch audio signal input from pin (2) of external input terminal J506 (HDMI AUDIO IN) to pin (70) of IC3301? Is there the R-ch audio signal input from pin (3) of external input terminal J506 (HDMI AUDIO IN) to pin (71) of IC3301?

YES Are I2S signal output from the pins (180), (181) of IC3301 nor-

mally?

YES Is there L-ch audio signal input at pin(3) of IC2701? NO Check connection between IC3301 and IC2701 and its periphIs there R-ch audio signal input at pin(7) of IC2701?

YES Is the L-ch audio signal output at pin(27), (28), (29) and (30) of IC2701 normal? Is the R-ch audio signal output at pin(11), (12), (13) and (14) of IC2701 normal?

NO Check peripheral circuits of IC3301.

eral circuits.

NO Check IC2701 and its peripheral circuits.

YES Are the audio signal L-ch and R-ch output at (1)/(2) and (3)/(4) of P2701 normal?

YES Check speakers and their peripheral circuits.

NO Check circuit between IC2701 & P2701.

6 – 8

LC-32L407I

No audio heard (5)

No PC audio output

YES Pin (2) of J506: Is L-ch input into the pin (70) of IC3301? Pin (3) of J506: Is R-ch input into the pin (71) of IC3301?

YES Are I2S signal output from the pins (180), (181) of IC3301 normally? NO Check peripheral circuits of IC3301.

YES Is there L-ch audio signal input at pin(3) of IC2701? NO Check connection between IC3301 and IC2701 and its Is there R-ch audio signal input at pin(7) of IC2701?

YES Is the L-ch audio signal output at pin(27), (28), (29) and (30) of IC2701 normal? Is the R-ch audio signal output at pin(11), (12), (13) and (14) of IC2701 normal?

NO Check IC2701 and its peripheral circuits.

peripheral circuits.

YES Are the audio signal L-ch and R-ch output at (1)/(2) and (3)/(4) of P2701 normal?

YES Check speakers and their peripheral circuits.

NO Check circuit between IC2701 & P2701.

6 – 9

LC-32L400M

CHAPTER 7. OVERALL WIRING/BLOCK DIAGRAM

[1] OVERALL WIRING DIAGRAM

LC-32L407I

Service Manual

1234567891011121314151617181920 21 22

7 – 1

LC-32L407I

[2] SYSTEM BLOCK DIAGRAM

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22

7 – 2

LC-32L400M

CHAPTER 8. PRINTED WIRING BOARD ASSEMBLIES

[1] MAIN Unit

MAIN Unit (Side-A)

LC-32L407I

Service Manual

12345678910111213141516171819

8 – 1

20 21 22

LC-32L407I

MAIN Unit

(Side-B)

12345678910111213141516171819

8 – 2

20 21 22

[2] POWER SUB Unit

LC-32L407I

POWER SUB Unit (Side-A)

12345678910111213141516171819

8 – 3

20 21 22

LC-32L407I

POWER SUB Unit (Side-B)

12345678910111213141516171819

8 – 4

20 21 22

[3] R/C, LED Unit

R/C, LED Unit (Side-A)

LC-32L407I

R/C, LED Unit (Side-B)

12345678910111213141516171819

8 – 5

20 21 22

LC-32L407I

LC-32L400M

CHAPTER 9. SCHEMATIC DIAGRAM

[1] DESCRIPTION OF SCHEMATIC DIAGRAM

1. VOLTAGE MEASUREMENT CONDITION:

1) The voltages at test points are measured on exclusive AC adaptor and the stable supply voltage of AC 110-240V. Signals are fed by a color bar signal generator for servicing purpose and the above voltages are measured with a 20k ohm/V tester.

2. INDICATION OF RESISTOR & CAPACITOR:

RESISTOR

1) The unit of resistance " " is omitted.

(K=k =1000 , M=M ).

2) All resistors are ± 5%, unless otherwise noted.

(K= ± 10%, F= ± 1%, D= ± 0.5%)

3) All resistors are 1/16W, unless otherwise noted.

CAPACITOR

1) All capacitors are F, unless otherwise noted.

(P=pF= F).

2) All capacitors are 50V, unless otherwise noted.

CAUTION:

This circuit diagram is original one, therefore there may be a slight difference from yours.

Service Manual

SAFETY NOTES:

1) DISCONNECT THE AC PLUG FROM THE AC OUTLET BEFORE REPLACING PARTS.

2) SEMICONDUCTOR HEAT SINKS SHOULD BE REGARDED AS POTENTIAL SHOCK HAZARDS WHEN THE CHASSIS IS OPERATING.

IMPORTANT SAFETY NOTICE:

PARTS MARKED WITH " " ( ) ARE IMPORTANT FOR MAINTAINING THE SAFETY OF THE SET. BE SURE TO REPLACE THESE PARTS WITH SPECIFIED ONES FOR MAINTAINING THE SAFETY AND PERFORMANCE OF THE SET.

9 – 1

LC-32L407I

12345678910111213141516171819

20 21 22

[2] MAIN Unit

•MAIN Unit-1/14

9 – 2

LC-32L407I

•MAIN Unit-2/14

12345678910111213141516171819

9 – 3

20 21 22

•MAIN Unit-3/14

LC-32L407I

12345678910111213141516171819

9 – 4

20 21 22

LC-32L407I

•MAIN Unit-4/14

12345678910111213141516171819

9 – 5

20 21 22

•MAIN Unit-5/14

LC-32L407I

12345678910111213141516171819

9 – 6

20 21 22

LC-32L407I

• MAIN Unit-6/14 (*On this model, the MAIN Circuit Basic Diagram 7/14 is not applied.)

12345678910111213141516171819

9 – 7

20 21 22

•MAIN Unit-8/14

LC-32L407I

12345678910111213141516171819

9 – 8

20 21 22

LC-32L407I

•MAIN Unit-9/14

12345678910111213141516171819

9 – 9

20 21 22

• MAIN Unit-10/14 (*On this model, the MAIN Circuit Basic Diagram 11/14, 12/14, 13/14 is not applied.)

LC-32L407I

12345678910111213141516171819

9 – 10

20 21 22

LC-32L407I

• MAIN Unit-14/14

12345678910111213141516171819

9 – 11

20 21 22

LC-32L407I

12345678910111213141516171819

20 21 22

[3] POWER SUB Unit

• POWER SUB Unit-1/4

9 – 12

LC-32L407I

• POWER SUB Unit-2/4

12345678910111213141516171819

9 – 13

20 21 22

• POWER SUB Unit-3/4

LC-32L407I

12345678910111213141516171819

9 – 14

20 21 22

LC-32L407I

• POWER SUB Unit-4/4

12345678910111213141516171819

9 – 15

20 21 22

[4] R/C, LED Unit

LC-32L407I

12345678910111213141516171819

9 – 16

20 21 22

LC-32L407I

9 – 17

PartsGuide

LC-32L407I

PARTS GUIDE

LCD COLOUR TELEVISION

Note:

The reference numbers on the PWB are arranged in alphabetical order.

[1] PRINTED WIRING BOARD ASSEMBLIES

[2] LCD PANEL

[3] DUNTKF537FM02 (MAIN Unit)

[4] DUNTKF538FM02 (POWER SUB Unit)

[5] DUNTKF539FM02 (R/C, LED Unit)

MODEL

CONTENTS

LC-32L407I

[6] CABINET AND MECHANICAL PARTS

[7] LCD MODULE Assembly

[8] SUPPLIED ACCESSORIES

[9] PACKING PARTS

(NOT REPLACEMENT ITEM)

[10] SERVICE JIGS (USE FOR SERVICING)

Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the safety and performance of the set.

This document has been published to be used for after sales service only. The contents are subject to change without notice.

LC-32L407I

NO. PARTS CODE

PRICE

RANK

NEW

MARK

PAR T

DELIVERY

[1] PRINTED WIRING BOARD ASSEMBLIES

N B3 KU 3L47 I1

B3 KU 3L47 I2 BH N V DUNTKF538FM02, POWER SUB Unit

N R DEN C25 90T PZZ BB V INVERTER Unit

BP N V DUNTKF537FM02, MAIN Unit AS N V DUNTKF539FM02, R/C - LED Unit

[2] LCD PANEL

N B 3KU 3L47I DA N V 32"LCD Panel Module (R1LK315T3LW70W)

[3] DUNTKF537FM02 (MAIN Unit)

C501 R C-K ZA6 16W JQZ Y A B J Capacitor C503 R C-K ZA6 16W JQZ Y A B J Capacitor C504 V CKY CY1 HB1 04K Y A A J Capacitor, 0.1 50V Ceramic C505 V CKY CY1 HB1 04K Y A A J Capacitor, 0.1 50V Ceramic C506 V CKY CY1 HB1 04K Y A A J Capacitor, 0.1 50V Ceramic C507 V CKY CY1 HB1 04K Y A A J Capacitor, 0.1 50V Ceramic C510 V CKY CZ1 EF1 04Z Y A A J Capacitor, 0.1 25V Ceramic C519 V CCC CZ1 HH1 02J Y A A J Capacitor, 1000p 50V Ceramic C543 V CCC CZ1 HH5 60J Y A B J Capacitor, 56p 50V Ceramic C544 V CCC CZ1 HH5 60J Y A B J Capacitor, 56p 50V Ceramic C548 V CCC CZ1 HH1 02J Y A A J Capacitor, 1000p 50V Ceramic C553 V CCC CZ1 HH1 02J Y A A J Capacitor, 1000p 50V Ceramic C560 V CCC CZ1 HH4 70J Y A B J Capacitor, 47p 50V Ceramic C561 V CCC CZ1 HH4 70J Y A B J Capacitor, 47p 50V Ceramic C565 R C-K ZA6 16W JQZ Y A B J Capacitor

C566 V CKY CZ1 EB1 03K Y A A J Capacitor, 0.01 25V Ceramic C1103 V CKY CZ1 EF1 04Z Y A A J Capacitor, 0.1 25V Ceramic C1105 R C-K ZA6 16W JQZ Y A B J Capacitor C1106 R C-K ZA6 16W JQZ Y A B J Capacitor C1107 R C-K ZA6 16W JQZ Y A B J Capacitor C1108 V CKY CZ1 EB1 03K Y A A J Capacitor, 0.01 25V Ceramic C1110 V CKY CZ1 EB1 03K Y A A J Capacitor, 0.01 25V Ceramic C1113 V CKY CZ1 EB1 03K Y A A J Capacitor, 0.01 25V Ceramic C1114 V CKY CZ1 EB1 03K Y A A J Capacitor, 0.01 25V Ceramic C1115 V CKY CZ1 EB1 03K Y A A J Capacitor, 0.01 25V Ceramic C1116 V CKY CZ1 EB1 03K Y A A J Capacitor, 0.01 25V Ceramic C1117 V CKY CZ1 EB1 03K Y A A J Capacitor, 0.01 25V Ceramic C1118 V CKY CZ1 EB1 03K Y A A J Capacitor, 0.01 25V Ceramic C1120 V CKY CZ1 EB1 03K Y A A J Capacitor, 0.01 25V Ceramic C1121 R C-K ZA6 16W JQZ Y A B J Capacitor C1503 R C-K ZA6 16W JQZ Y A B J Capacitor C1506 V CKY CZ1 EB1 03K Y A A J Capacitor, 0.01 25V Ceramic C1509 R C-K ZA6 16W JQZ Y A B J Capacitor C1512 V CKY CZ1 EF1 04Z Y A A J C2701 V CKY CZ1 HB1 02K Y A B J Capacitor, 1000p 50V Ceramic C2702 R C-K ZA6 21W JQZ Y A A J Capacitor C2706 R C-K ZA6 21W JQZ Y A A J Capacitor C2713 R C-K ZA6 21W JQZ Y A A J Capacitor C2714 R C-K ZA6 21W JQZ Y A A J Capacitor C2715 V CKY CZ1 HB1 02K Y A B J Capacitor, 1000p 50V Ceramic C2716 R C-K ZA6 16W JQZ Y A B J Capacitor C2717 R C-K ZA3 83W JZZ Y A C J Capacitor C2718 V CKY CZ1 EF1 04Z Y A A J Capacitor, 0.1 25V Ceramic C2719 V CCC CZ1 HH1 01J Y A B J Capacitor, 100p 50V Ceramic C2720 V CKY CZ1 EF1 04Z Y A A J Capacitor, 0.1 25V Ceramic C2721 R C-K ZA6 21W JQZ Y A A J Capacitor C2722 R C-K ZA6 21W JQZ Y A A J Capacitor C2723 R C-K ZA6 21W JQZ Y A A J Capacitor C2724 R C-K ZA6 21W JQZ Y A A J Capacitor C2725 V CKY CZ1 EF1 04Z Y A A J Capacitor, 0.1 25V Ceramic C2726 V CKY CZ1 EF1 04Z Y A A J Capacitor, 0.1 25V Ceramic C2727 V CKY CZ1 EF1 04Z Y A A J Capacitor, 0.1 25V Ceramic C2728 V CKY CZ1 EF1 04Z Y A A J Capacitor, 0.1 25V Ceramic C2729 V CKY TV1 EB2 24K Y A A J Capacitor, 0.22 25V Ceramic C2730 V CKY TV1 EB2 24K Y A A J Capacitor, 0.22 25V Ceramic C2731 V CCC CZ1 HH1 51J Y A B J Capacitor, 150p 50V Ceramic C2732 V CCC CZ1 HH1 51J Y A B J Capacitor, 150p 50V Ceramic C2733 V CCC CZ1 HH1 51J Y A B J Capacitor, 150p 50V Ceramic C2734 V CCC CZ1 HH1 51J Y A B J Capacitor, 150p 50V Ceramic C2735 V CKY CY1 HB1 04K Y A A J Capacitor, 0.1 50V Ceramic C2736 V CKY CY1 HB1 04K Y A A J Capacitor, 0.1 50V Ceramic C2737 V CKY CY1 HB1 04K Y A A J Capacitor, 0.1 50V Ceramic C2738 V CKY CY1 HB1 04K Y A A J Capacitor, 0.1 50V Ceramic C2739 R C-K ZA3 83W JZZ Y A C J Capacitor C2740 R C-K ZA3 83W JZZ Y A C J Capacitor C3301 R C-K ZA1 15W JZZ Y A B J Capacitor C3302 V CKY CZ1 AB4 73K Y A B J Capacitor, 0.047 10V Ceramic C3303 C3304 V CKY CZ1 AB4 73K Y A B J Capacitor, 0.047 10V Ceramic C3305 V CKY CZ1 HB1 02K Y A B J Capacitor, 1000p 50V Ceramic C3307 V CKY CZ1 AB4 73K Y A B J Capacitor, 0.047 10V Ceramic C3308 V CKY CZ1 AB4 73K Y A B J Capacitor, 0.047 10V Ceramic C3309 R C-K ZA1 15W JZZ Y A B J Capacitor C3311 V CKY CZ1 AB4 73K Y A B J Capacitor, 0.047 10V Ceramic C3312 V CKY CZ1 AB4 73K Y A B J Capacitor, 0.047 10V Ceramic C3313 V CKY CZ1 AB4 73K Y A B J Capacitor, 0.047 10V Ceramic

V CKY CZ1 AB4 73K Y A B J Capacitor, 0.047 10V Ceramic

Capacitor, 0.1 25V Ceramic

DESCRIPTION

LC-32L407I

NO. PARTS CODE

PRICE

RANK

NEW

MARK

PAR T

DELIVERY

[3] DUNTKF537FM02 (MAIN Unit)

C3314 V CKY CZ 1HB 221 KY AA J Capacitor, 220p 50V Ceramic C3315 V CKY CZ 1AB 473 KY AB J Capacitor, 0.047 10V Ceramic C3316 V CKY CZ 1HB 221 KY AA J Capacitor, 220p 50V Ceramic C3317 V CKY CZ 1AB 473 KY AB J Capacitor, 0.047 10V Ceramic C3318 V CKY CZ 1AB 473 KY AB J Capacitor, 0.047 10V Ceramic C3319 V CKY CZ 1AB 473 KY AB J Capacitor, 0.047 10V Ceramic C3320 V CKY CZ 1AB 473 KY AB J Capacitor, 0.047 10V Ceramic C3321 V CKY CZ 1AB 473 KY AB J Capacitor, 0.047 10V Ceramic C3322 R C-K ZA 616 WJQ ZY AB J Capacitor C3323 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3324 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3325 R C-K ZA 115 WJZ ZY AB J Capacitor C3326 R C-K ZA 115 WJZ ZY AB J Capacitor C3327 R C-K ZA 115 WJZ ZY AB J Capacitor C3328 R C-K ZA 115 WJZ ZY AB J Capacitor C3329 R C-K ZA 115 WJZ ZY AB J Capacitor C3330 R C-K ZA 115 WJZ ZY AB J Capacitor C3331 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3332 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3333 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3334 R C-K ZA 616 WJQ ZY AB J Capacitor C3337 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3339 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3340 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3341 V CCC CZ 1HH 101 JY AB J Capacitor, 100p 50V Ceramic C3342 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3343 V CKY CZ 1EB 103 KY AA J Capacitor, 0.01 25V Ceramic C3344 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3345 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3346 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3347 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3348 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3349 V CCC CZ 1HH 120 JY AB J Capacitor, 12p 50V Ceramic C3350 V CCC CZ 1HH 100 DY AB J C3351 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3352 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3353 R C-K ZA 616 WJQ ZY AB J Capacitor C3354 R C-K ZA 621 WJQ ZY AA J Capacitor C3355 R C-K ZA 616 WJQ ZY AB J Capacitor C3356 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3357 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3358 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3359 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3360 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3361 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3362 R C-K ZA 616 WJQ ZY AB J Capacitor C3363 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3364 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3365 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3366 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3367 V CCC CZ 1HH 101 JY AB J Capacitor, 100p 50V Ceramic C3368 V CCC CZ 1HH 101 JY AB J Capacitor, 100p 50V Ceramic C3369 V CCC CZ 1HH 101 JY AB J Capacitor, 100p 50V Ceramic C3370 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3371 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3372 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3373 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3374 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3375 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3376 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3377 V CKY CZ 1AB 473 KY AB J Capacitor, 0.047 10V Ceramic C3378 R C-K ZA 146 WJZ ZY AA J Capacitor C3379 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3391 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3398 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3404 R C-K ZA 616 WJQ ZY AB J Capacitor C3502 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3504 C3506 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3507 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3508 R C-K ZA 616 WJQ ZY AB J Capacitor C3509 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3510 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3511 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3514 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3515 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3517 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C3518 R C-K ZA 117 WJZ ZY AC J Capacitor C3519 R C-K ZA 117 WJZ ZY AC J Capacitor C5299 V CKY CY 1HB 103 KY AA J Capacitor, 0.01 50V Ceramic C8401 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C8402 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C8403 V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic C9609 R C-K ZA 616 WJQ ZY AB J Capacitor C9651 V CKY CZ 1CB 333 KY AA J Capacitor, 0.033 16V Ceramic

V CKY CZ 1AB 104 KY AB J Capacitor, 0.1 10V Ceramic

Capacitor, 10p 50V Ceramic

DESCRIPTION

LC-32L407I

NO. PARTS CODE

PRICE

RANK

NEW

MARK

PAR T

DELIVERY

[3] DUNTKF537FM02 (MAIN Unit)

C9652 R C-K ZA3 83W JZZ Y A C J Capacitor C9653 V CKY CZ1 EB1 03K Y A A J Capacitor, 0.01 25V Ceramic C9654 V CKY CY1 HB6 82K Y A A J Capacitor, 6800p 50V Ceramic C9656 R C-K ZA6 16W JQZ Y A B J Capacitor C9657 R C-K ZA6 16W JQZ Y A B J Capacitor C9658 V CKY CZ1 CB3 33K Y A A J Capacitor, 0.033 16V Ceramic C9659 V CKY CZ1 EB1 03K Y A A J Capacitor, 0.01 25V Ceramic C9660 R C-K ZA3 83W JZZ Y A C J Capacitor C9661 V CKY CZ1 CB1 53K Y A B J Capacitor, 0.015 16V Ceramic C9664 R C-K ZA6 16W JQZ Y A B J Capacitor C9665 R C-K ZA6 16W JQZ Y A B J Capacitor C9666 R C-K ZA6 16W JQZ Y A B J Capacitor C9667 R C-K ZA6 16W JQZ Y A B J Capacitor C9668 R C-K ZA6 16W JQZ Y A B J Capacitor C9669 R C-K ZA6 16W JQZ Y A B J Capacitor C9670 R C-K ZA6 16W JQZ Y A B J Capacitor C9671 R C-K ZA6 16W JQZ Y A B J Capacitor C9672 R C-K ZA6 16W JQZ Y A B J Capacitor

D501 V HEB ZB8 4B1 2-1 Y A B J Zener Diode

D502 V HEB ZB8 4B1 2-1 Y A B J Zener Diode

D503 R H-E XA6 33W JQZ Y A A J Zener Diode, RKZ5.6B2KG

D510 V HDB AV7 0++ +-1 Y A B J Diode, BAV70,215 D1101 V HD1 SS3 90+ +-1 Y A B N J Diode, 1SS390TE61 D1102 V HD1 SS3 90+ +-1 Y A B N J Diode, 1SS390TE61 D1502 V HD0 203 CTR F-1 Y A B V Diode, HRC0203CTRF-E D1511 V HD0 203 CTR F-1 Y A B V Diode, HRC0203CTRF-E D3301 V RS- CY1 JF1 01J Y A A J Diode, 100 1/16W Metal Oxide D9601 V HDC US0 2TE +-1 Y A B J Diode, CUS02(TE85L,Q)

FB505 R BLN -A0 42W JZZ Y A B J Ferrite Core FB506 R BLN -A0 42W JZZ Y A B J Ferrite Core FB507 R BLN -A0 42W JZZ Y A B J Ferrite Core FB508 R BLN -A1 92W JZZ Y A A J Ferrite Core FB517 R BLN -A3 69W JZZ Y A B V Ferrite Core FB518 R BLN -A3 69W JZZ Y A B V FB519 R BLN -A3 69W JZZ Y A B V Ferrite Core FB520 R BLN -A3 69W JZZ Y A B V Ferrite Core FB521 R BLN -A1 85W JZZ Y A B N V Ferrite Core FB522 R BLN -A1 85W JZZ Y A B N V Ferrite Core

FB523 R BLN -A1 85W JZZ Y A B N V Ferrite Core FB1101 R BLN -A1 91W JZZ Y A B J Ferrite Core FB1102 R BLN -A1 91W JZZ Y A B J Ferrite Core FB3301 R BLN -A1 92W JZZ Y A A J Ferrite Core FB3302 R BLN -A1 92W JZZ Y A A J Ferrite Core FB3303 R BLN -A1 92W JZZ Y A A J Ferrite Core FB3304 R BLN -A1 92W JZZ Y A A J Ferrite Core FB3308 R BLN -A1 92W JZZ Y A A J Ferrite Core FB3311 R BLN -A1 92W JZZ Y A A J Ferrite Core FB3312 R BLN -A1 92W JZZ Y A A J Ferrite Core FB3328 R BLN -A1 92W JZZ Y A A J Ferrite Core FL1101 R FIL CA0 59W JZZ AF N V Filter FL1102 R FIL CA0 58W JZZ AG N V Filter FL3501 R FIL NA1 19W JZZ Y A C J Filter

IC501 V HIM 322 1EI P-1 Y A K J IC, MAX3221EIPWR IC503 V HIA HT1 G08 W-1 Y A D J IC, 74AHCT1G08GW/G,125

IC508 R H-I XD1 69W JQZ S N V IC, BQC (PC EDID) IC1503 R H-I XD1 70W JQZ S N V IC, BQC (HDMI EDID) IC2701 V HIY DA1 48Q Z-1 Y A L J IC, YDA148-QZE2 IC3301 R H-I XD0 18W JZZ Q B A N V IC IC3302 V HIP ST8 429 U-1 Y A C J IC, IC-PST8429UR IC3501 R H-I XC9 94W JQZ Q A N J IC, H5DU1262GTR-E3C IC8401 R H-I XD1 42W JN1 Q A L N V IC IC8402 V HIR 240 64A S-1 Y A D J IC, R1EX24064ASAS0A IC8403 R H-I XD1 10W JQZ Y A G N V IC IC9602 V HIS 170 B33 U-1 Y A D J IC, S-1170B33UC-OTSTFG IC9603 V HIS 170 B26 U-1 Y A D N V IC, S-1170B26UC-OTLTFG IC9606 V HIM P23 01E +-1 Y A F J IC, MP2301ENE-LF-Z IC9651 V HIM P23 01E +-1 Y A F J IC, MP2301ENE-LF-Z IC9652 IC9653 V HIS 132 B33 M-1 Y A D J IC, S-1132B33-M5T1G

L1103 V PSB NR8 2JR 34N Y A B N V Coil, Peaking 0.82 H L2602 R CIL FA3 62W JZZ Y A C N V Coil L2603 R CIL FA3 62W JZZ Y A C N V Coil L2606 R CIL FA3 62W JZZ Y A C N V Coil L2701 R CIL PB0 92W JQZ Y A C N V Coil L2702 R CIL PB0 92W JQZ Y A C N V Coil L2703 R CIL PB0 92W JQZ Y A C N V Coil L2704 R CIL PB0 92W JQZ Y A C N V Coil L9651 R CIL PB0 14W JQZ Y A C N J Coil

L9652 R CIL PB5 10W JQZ Y A C V Coil LUG501 Q LUG HA0 06W JZZ Y A C J Lug LUG502 Q LUG HA0 06W JZZ Y A C J Lug

P2601 Q PLG NA4 17W JZZ Y A L N J Plug

V HIS 170 B50 U-1 Y A D V IC, S-1170B50UC-OUJTFG

J502 Q SOC ZA1 53W JQZ AG J Socket J506 Q JAK JA0 24W JZZ AD J Jack

L501 R CIL FA1 54W JZZ Y A C J Coil

Ferrite Core

DESCRIPTION

LC-32L407I

NO. PARTS CODE

PRICE

RANK

NEW

MARK

PAR T

DELIVERY

[3] DUNTKF537FM02 (MAIN Unit)

P2701 Q PLG NA 160 WJZ ZY AD J Plug P3301 Q PLG NA 327 WJZ ZY AC J Plug

Q501 V SHN 7G 04F UA- 1Y AB N J Transistor, HN7G04FU-A(TE85L,F Q1101 V S2S C2 735 //1 EY AC J Transistor, 2SC2735JC21TL Q1103 V SRT 1N 441 U/- 1Y AB J Transistor, RT1N441U-T111-1 Q1104 V SRT 1N 441 U/- 1Y AB J Transistor, RT1N441U-T111-1 Q1105 V SRT 1N 441 U/- 1Y AB J Transistor, RT1N441U-T111-1 Q1501 V SRT 1N 441 U/- 1Y AB J Transistor, RT1N441U-T111-1 Q1504 V SRT 1N 441 U/- 1Y AB J Transistor, RT1N441U-T111-1 Q1508 V SRT 1N 441 U/- 1Y AB J Transistor, RT1N441U-T111-1 Q1511 V SSS M6 N15 FU- 1Y AB J Transistor, SSM6N15FU(TE85L,F) Q2703 V SRT 1N 441 U/- 1Y AB J Transistor, RT1N441U-T111-1 Q3303 V SRT 1N 141 U/- 1Y AB J Transistor, RT1N141U-T111-1 Q9601 V SRT 1N 141 U/- 1Y AB J Transistor, RT1N141U-T111-1 Q9602 V S2S A2 061 ++- 1Y AC N V Transistor, 2SA2061(TE85L,F)

R501 V RS- CZ 1JF 102 JY AA J Resistor, 1k 1/16W Metal Oxide R502 V RS- TV 1JD 101 JY AA J Resistor, 100 1/10W Metal Oxide R503 V RS- TV 1JD 101 JY AA J Resistor, 100 1/10W Metal Oxide R505 V RS- CZ 1JF 472 JY AA J Resistor, 4.7k 1/16W Metal Oxide R506 V RS- CZ 1JF 101 JY AA J Resistor, 100 1/16W Metal Oxide R507 V RS- TV 1JD 101 JY AA J Resistor, 100 1/10W Metal Oxide R577 V RS- CZ 1JF 183 JY AA J Resistor, 18k 1/16W Metal Oxide R578 V RS- CZ 1JF 183 JY AA J Resistor, 18k 1/16W Metal Oxide R581 V RS- CZ 1JF 123 JY AA J Resistor, 12k 1/16W Metal Oxide R582 V RS- TQ 2EF 750 JY AA J Resistor, 75 1/4W Metal Oxide R583 V RS- TQ 2EF 750 JY AA J Resistor, 75 1/4W Metal Oxide R584 V RS- TQ 2EF 750 JY AA J Resistor, 75 1/4W Metal Oxide R585 V RS- CZ 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R586 V RS- CZ 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R590 V RS- CZ 1JF 123 JY AA J Resistor, 12k 1/16W Metal Oxide R607 V RS- CZ 1JF 473 JY AA J Resistor, 47k 1/16W Metal Oxide R608 V RS- CZ 1JF 473 JY AA J Resistor, 47k 1/16W Metal Oxide R610 V RS- CZ 1JF 222 JY AA J Resistor, 2.2k 1/16W Metal Oxide R611 V RS- CZ 1JF 222 JY AA J R613 V RS- CZ 1JF 101 JY AA J Resistor, 100 1/16W Metal Oxide R614 V RS- CZ 1JF 101 JY AA J Resistor, 100 1/16W Metal Oxide R616 V RS- CJ 1JF 101 JY AA J Resistor, 100 1/16W Metal Oxide R620 V RS- CZ 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R621 V RS- CZ 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R625 V RS- CZ 1JF 473 JY AA J Resistor, 47k 1/16W Metal Oxide R628 V RS- CZ 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide

R629 V RS- CZ 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R1101 V RS- CZ 1JF 102 JY AA J Resistor, 1k 1/16W Metal Oxide R1102 V RS- CZ 1JF 682 JY AA J Resistor, 6.8k 1/16W Metal Oxide R1103 V RS- CZ 1JF 682 JY AA J Resistor, 6.8k 1/16W Metal Oxide R1105 V RS- CZ 1JF 101 JY AA J Resistor, 100 1/16W Metal Oxide R1110 V RS- CZ 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R1111 V RS- CZ 1JF 123 JY AA J Resistor, 12k 1/16W Metal Oxide R1112 V RS- CZ 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R1113 V RS- CZ 1JF 560 JY AA J Resistor, 56 1/16W Metal Oxide R1114 V RS- CZ 1JF 821 JY AA J Resistor, 820 1/16W Metal Oxide R1115 V RS- CZ 1JF 152 JY AA J Resistor, 1.5k 1/16W Metal Oxide R1116 V RS- CZ 1JF 271 JY AA J Resistor, 270 1/16W Metal Oxide R1117 V RS- CZ 1JF 680 JY AB J Resistor, 68 1/16W Metal Oxide R1118 V RS- CZ 1JF 681 JY AA J Resistor, 680 1/16W Metal Oxide R1119 V RS- CZ 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R1120 V RS- CZ 1JF 682 JY AA J Resistor, 6.8k 1/16W Metal Oxide R1121 V RS- CZ 1JF 682 JY AA J Resistor, 6.8k 1/16W Metal Oxide R1122 V RS- CZ 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R1123 V RS- CZ 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R1124 V RS- CZ 1JF 332 JY AA J Resistor, 3.3k 1/16W Metal Oxide R1127 V RS- CZ 1JF 332 JY AA J Resistor, 3.3k 1/16W Metal Oxide R1130 V RS- CZ 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R1131 V RS- CZ 1JF 223 JY AA J Resistor, 22k 1/16W Metal Oxide R1132 V RS- CZ 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R1133 V RS- CZ 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R1134 V RS- CZ 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R1135 R1136 V RS- CZ 1JF 223 JY AA J Resistor, 22k 1/16W Metal Oxide R1137 V RS- CZ 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R1138 V RS- CZ 1JF 473 JY AA J Resistor, 47k 1/16W Metal Oxide R1139 V RS- CZ 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R1143 V RS- CZ 1JF 102 JY AA J Resistor, 1k 1/16W Metal Oxide R1502 V RS- CZ 1JF 102 JY AA J Resistor, 1k 1/16W Metal Oxide R1511 V RS- CZ 1JF 473 JY AA J Resistor, 47k 1/16W Metal Oxide R1517 V RS- CZ 1JF 101 JY AA J Resistor, 100 1/16W Metal Oxide R1519 V RK- SA 1JF 473 JY AC J Resistor, 47k 1/16W Metal Composition R1523 V RS- CJ 1JF 101 JY AA J Resistor, 100 1/16W Metal Oxide R1527 V RS- CZ 1JF 473 JY AA J Resistor, 47k 1/16W Metal Oxide R1539 V RK- SA 1JF 472 JY AA J Resistor, 4.7k 1/16W Metal Composition R1542 V RS- CZ 1JF 103 JY AA J Resistor, 10k 1/16W Metal Oxide R2602 V RS- CZ 1JF 101 JY AA J Resistor, 100 1/16W Metal Oxide R2701 V RS- CZ 1JF 562 JY AA J Resistor, 5.6k 1/16W Metal Oxide R2702 V RS- CZ 1JF 224 FY AA J Resistor, 220k 1/16W Metal Oxide R2703 V RS- CZ 1JF 224 FY AA J Resistor, 220k 1/16W Metal Oxide

V RS- CZ 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide

Resistor, 2.2k 1/16W Metal Oxide

DESCRIPTION

LC-32L407I

NO. PARTS CODE

PRICE

RANK

NEW

MARK

PAR T

DELIVERY

[3] DUNTKF537FM02 (MAIN Unit)

R2704 V RS- CZ1 JF2 73F Y A A J Resistor, 27k 1/16W Metal Oxide R2705 V RS- CZ1 JF6 83F Y A A J Resistor, 68k 1/16W Metal Oxide R2707 V RS- CZ1 JF2 23F Y A A J Resistor, 22k 1/16W Metal Oxide R2712 V RS- CY1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R2713 V RS- CY1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R2714 V RS- CY1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R2715 V RS- CY1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R2716 V RS- CZ1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R2717 V RS- CZ1 JF2 24F Y A A J Resistor, 220k 1/16W Metal Oxide R3301 V RS- CZ1 JF2 72F Y A A J Resistor, 2.7k 1/16W Metal Oxide R3302 V RS- CZ1 JF1 01J Y A A J Resistor, 100 1/16W Metal Oxide R3303 V RS- CZ1 JF2 24J Y A A J Resistor, 220k 1/16W Metal Oxide R3304 V RS- CZ1 JF2 24J Y A A J Resistor, 220k 1/16W Metal Oxide R3306 V RS- CZ1 JF4 70J Y A A J Resistor, 47 1/16W Metal Oxide R3307 V RS- CZ1 JF4 70J Y A A J Resistor, 47 1/16W Metal Oxide R3308 V RS- CZ1 JF4 70J Y A A J Resistor, 47 1/16W Metal Oxide R3309 V RS- CZ1 JF1 02J Y A A J Resistor, 1k 1/16W Metal Oxide R3310 V RS- CZ1 JF4 70J Y A A J Resistor, 47 1/16W Metal Oxide R3311 V RS- CZ1 JF1 02J Y A A J Resistor, 1k 1/16W Metal Oxide R3312 V RS- CZ1 JF4 70J Y A A J Resistor, 47 1/16W Metal Oxide R3313 V RS- CZ1 JF4 70J Y A A J Resistor, 47 1/16W Metal Oxide R3314 V RS- CZ1 JF4 70J Y A A J Resistor, 47 1/16W Metal Oxide R3315 V RS- CZ1 JF4 70J Y A A J Resistor, 47 1/16W Metal Oxide R3316 V RS- CZ1 JF4 70J Y A A J Resistor, 47 1/16W Metal Oxide R3320 V RS- CZ1 JF8 R2F Y A B N V Resistor, 8.2 1/16W Metal Oxide R3321 V RS- CZ1 JF8 R2F Y A B N V Resistor, 8.2 1/16W Metal Oxide R3322 V RS- CZ1 JF8 R2F Y A B N V Resistor, 8.2 1/16W Metal Oxide R3323 V RK- SA1 JF1 00J Y A B J Resistor, 10 1/16W Metal Composition R3324 V RS- CZ1 JF8 R2F Y A B N V Resistor, 8.2 1/16W Metal Oxide R3325 V RS- CZ1 JF8 R2F Y A B N V Resistor, 8.2 1/16W Metal Oxide R3326 V RK- SA1 JF4 72J Y A A J Resistor, 4.7k 1/16W Metal Composition R3327 V RS- CZ1 JF4 72J Y A A J Resistor, 4.7k 1/16W Metal Oxide R3328 V RS- CZ1 JF1 02J Y A A J Resistor, 1k 1/16W Metal Oxide R3329 V RS- CZ1 JF1 82J Y A A J R3330 V RS- CZ1 JF1 82J Y A A J Resistor, 1.8k 1/16W Metal Oxide R3331 V RS- CZ1 JF1 03J Y A A J Resistor, 10k 1/16W Metal Oxide R3332 V RS- CZ1 JF3 91J Y A A J Resistor, 390 1/16W Metal Oxide R3333 V RS- CZ1 JF5 62J Y A A J Resistor, 5.6k 1/16W Metal Oxide R3334 V RS- CZ1 JF4 72J Y A A J Resistor, 4.7k 1/16W Metal Oxide R3336 V RK- SA1 JF1 00J Y A B J Resistor, 10 1/16W Metal Composition R3337 V RS- CZ1 JF8 R2F Y A B N V Resistor, 8.2 1/16W Metal Oxide R3338 V RS- CZ1 JF4 72J Y A A J Resistor, 4.7k 1/16W Metal Oxide R3339 V RS- CZ1 JF4 70J Y A A J Resistor, 47 1/16W Metal Oxide R3340 V RS- CZ1 JF8 R2F Y A B N V Resistor, 8.2 1/16W Metal Oxide R3341 V RS- CZ1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R3343 V RS- CZ1 JF8 R2F Y A B N V Resistor, 8.2 1/16W Metal Oxide R3344 V RS- CZ1 JF3 33J Y A A J Resistor, 33k 1/16W Metal Oxide R3352 V RS- CZ1 JF4 70J Y A A J Resistor, 47 1/16W Metal Oxide R3353 V RS- CZ1 JF4 70J Y A A J Resistor, 47 1/16W Metal Oxide R3362 V RS- CZ1 JF1 02J Y A A J Resistor, 1k 1/16W Metal Oxide R3363 V RS- CZ1 JF1 01J Y A A J Resistor, 100 1/16W Metal Oxide R3365 V RS- CZ1 JF1 01J Y A A J Resistor, 100 1/16W Metal Oxide R3366 V RS- CZ1 JF1 01J Y A A J Resistor, 100 1/16W Metal Oxide R3371 V RK- SA1 JF3 33J Y A B J Resistor, 33k 1/16W Metal Composition R3372 V RK- SA1 JF1 02J Y A B J Resistor, 1k 1/16W Metal Composition R3373 V RS- CZ1 JF1 01J Y A A J Resistor, 100 1/16W Metal Oxide R3374 V RS- CZ1 JF1 03J Y A A J Resistor, 10k 1/16W Metal Oxide R3375 V RS- CZ1 JF4 70J Y A A J Resistor, 47 1/16W Metal Oxide R3376 V RS- CZ1 JF4 71J Y A A J Resistor, 470 1/16W Metal Oxide R3377 V RS- CZ1 JF1 52J Y A A J Resistor, 1.5k 1/16W Metal Oxide R3378 V RK- SA1 JF1 00J Y A B J Resistor, 10 1/16W Metal Composition R3386 V RS- CZ1 JF1 03J Y A A J Resistor, 10k 1/16W Metal Oxide R3388 V RS- CZ1 JF4 72J Y A A J Resistor, 4.7k 1/16W Metal Oxide R3421 V RS- CZ1 JF1 03J Y A A J Resistor, 10k 1/16W Metal Oxide R3424 V RS- CZ1 JF1 01J Y A A J Resistor, 100 1/16W Metal Oxide R3437 V RS- CZ1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R3438 V RS- CZ1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R3439 R3501 V RS- CG1 JF4 70J Y A A N J Resistor, 47 1/16W Metal Oxide R3502 V RS- CZ1 JF1 51F Y A A J Resistor, 150 1/16W Metal Oxide R3503 V RS- CZ1 JF4 70J Y A A J Resistor, 47 1/16W Metal Oxide R3504 V RS- CZ1 JF4 70J Y A A J Resistor, 47 1/16W Metal Oxide R3506 V RS- CZ1 JF4 70J Y A A J Resistor, 47 1/16W Metal Oxide R3507 V RS- CZ1 JF4 70J Y A A J Resistor, 47 1/16W Metal Oxide R3508 V RS- CZ1 JF1 01J Y A A J Resistor, 100 1/16W Metal Oxide R3509 V RS- CZ1 JF1 01J Y A A J Resistor, 100 1/16W Metal Oxide R3510 V RS- CZ1 JF1 01J Y A A J Resistor, 100 1/16W Metal Oxide R3511 V RS- CZ1 JF1 01J Y A A J Resistor, 100 1/16W Metal Oxide R3512 V RS- CZ1 JF1 01J Y A A J Resistor, 100 1/16W Metal Oxide R3513 V RS- CZ1 JF1 01J Y A A J Resistor, 100 1/16W Metal Oxide R3515 V RS- CZ1 JF4 70J Y A A J Resistor, 47 1/16W Metal Oxide R3516 V RS- CZ1 JF4 70J Y A A J Resistor, 47 1/16W Metal Oxide R3517 V RS- CG1 JF4 70J Y A A N J Resistor, 47 1/16W Metal Oxide R3518 V RS- CG1 JF4 70J Y A A N J Resistor, 47 1/16W Metal Oxide R3519 V RS- CG1 JF4 70J Y A A N J Resistor, 47 1/16W Metal Oxide

V RS- CZ1 JF2 23J Y A A J Resistor, 22k 1/16W Metal Oxide

Resistor, 1.8k 1/16W Metal Oxide

DESCRIPTION

LC-32L407I

NO. PARTS CODE

PRICE

RANK

NEW

MARK

PAR T

DELIVERY

[3] DUNTKF537FM02 (MAIN Unit)

R3520 V RS- CG 1JF 101 JY AA J Resistor, 100 1/16W Metal Oxide R3521 V RS- CG 1JF 101 JY AA J Resistor, 100 1/16W Metal Oxide R3522 V RS- CG 1JF 101 JY AA J Resistor, 100 1/16W Metal Oxide R3523 V RS- CZ 1JF 101 JY AA J Resistor, 100 1/16W Metal Oxide R3524 V RS- CZ 1JF 101 JY AA J Resistor, 100 1/16W Metal Oxide R3525 V RS- CZ 1JF 102 FY AA J Resistor, 1k 1/16W Metal Oxide R3526 V RS- CZ 1JF 102 FY AA J Resistor, 1k 1/16W Metal Oxide R5203 V RS- CZ 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R8401 V RS- CZ 1JF 472 JY AA J Resistor, 4.7k 1/16W Metal Oxide R8403 V RK- SA 1JF 000 JY AB J Resistor, 0 1/16W Metal Composition R8406 V RK- SA 1JF 000 JY AB J Resistor, 0 1/16W Metal Composition R9601 V RS- CZ 1JF 102 JY AA J Resistor, 1k 1/16W Metal Oxide R9602 V RS- CZ 1JF 104 JY AA J Resistor, 100k 1/16W Metal Oxide R9612 V RS- TW 2HF 3R9 JY AB N V Resistor, 3.9 1/2W Metal Oxide R9613 V RS- TW 2HF 3R9 JY AB N V Resistor, 3.9 1/2W Metal Oxide R9622 V RS- CZ 1JF 103 JY AA J Resistor, 10k 1/16W Metal Oxide R9651 V RS- CZ 1JF 104 JY AA J Resistor, 100k 1/16W Metal Oxide R9652 V RS- CZ 1JF 3R9 JY AA J Resistor, 3.9 1/16W Metal Oxide R9653 V RS- CZ 1JF 472 JY AA J Resistor, 4.7k 1/16W Metal Oxide R9654 V RS- CZ 1JF 103 FY AB J Resistor, 10k 1/16W Metal Oxide R9655 V RS- CZ 1JF 563 FY AA J Resistor, 56k 1/16W Metal Oxide R9656 V RS- CZ 1JF 392 JY AA J Resistor, 3.9k 1/16W Metal Oxide R9657 V RS- TW 2HF 2R2 JY AA N J Resistor, 2.2 1/2W Metal Oxide R9658 V RS- CZ 1JF 104 JY AA J Resistor, 100k 1/16W Metal Oxide R9659 V RS- CZ 1JF 272 JY AA J Resistor, 2.7k 1/16W Metal Oxide R9660 V RS- CZ 1JF 103 FY AB J Resistor, 10k 1/16W Metal Oxide R9662 V RS- CZ 1JF 562 FY AA J Resistor, 5.6k 1/16W Metal Oxide R9664 V RS- CZ 1JF 151 JY AA J Resistor, 150 1/16W Metal Oxide R9665 V RS- TW 2HF 2R2 JY AA N J Resistor, 2.2 1/2W Metal Oxide R9666 V RS- TW 2HF 8R2 JY AB N V Resistor, 8.2 1/2W Metal Oxide

RDA3301 P RDA RA 912 WJF W A E N V Radiator

SC501 Q SOC NA 810 WJQ Z A F N J Socket SC502 Q SOC NA 880 WJQ Z A G N V Socket

SC1501 Q SOC ZA 173 WJQ ZY AG J SC5201 Q CNC WA 010 WJZ ZY AE N J Connector SC5202 Q CNC WA 010 WJZ ZY AE N J Connector SC5203 Q CNC WA 010 WJZ ZY AE N J Connector TH3301 R H-H XA 047 WJQ ZY AB J Thermistor, NTCG103JF103HT TU1101 R TUN QA 063 WJQ Z A T N V Tuner

VA505 R H-V XA 074 WJZ ZY AB J Varistor, AVRL101A1R1NTB VA506 R H-V XA 074 WJZ ZY AB J Varistor, AVRL101A1R1NTB X3301 R CRS CA 209 WJQ ZY AE J Crystal

N P SPA ZC 517 WJK Z A E N V Spacer

Socket

[4] DUNTKF538FM02 (POWER SUB Unit)

C5201 V CCC CY 1HH 102 JY AB J Capacitor, 1000p 50V Ceramic C5509 V CCC CY 1HH 560 JY AB J Capacitor, 56p 50V Ceramic C5510 V CKY CY 1HB 102 KY AA J Capacitor, 1000p 50V Ceramic C5511 V CCC CY 1HH 560 JY AB J Capacitor, 56p 50V Ceramic C5512 V CKY CY 1HB 102 KY AA J Capacitor, 1000p 50V Ceramic C5515 V CCC CY 1HH 560 JY AB J Capacitor, 56p 50V Ceramic C5517 V CCC CY 1HH 560 JY AB J Capacitor, 56p 50V Ceramic C5518 V CKY CY 1HB 102 KY AA J Capacitor, 1000p 50V Ceramic C5520 V CKY CY 1HB 102 KY AA J Capacitor, 1000p 50V Ceramic C5522 V CCC CY 1HH 560 JY AB J Capacitor, 56p 50V Ceramic C5523 V CKY CY 1HB 102 KY AA J Capacitor, 1000p 50V Ceramic C5536 V CCC CY 1HH 560 JY AB J Capacitor, 56p 50V Ceramic C5537 V CKY CY 1HB 102 KY AA J Capacitor, 1000p 50V Ceramic C5543 V CCC CY 1HH 471 JY AA J Capacitor, 470p 50V Ceramic C5544 V CCC CY 1HH 471 JY AA J Capacitor, 470p 50V Ceramic C7001 R C-F ZA 560 WJZ Z A C J Capacitor

C7010 R C-E ZB 742 WJZ Z A P N V Capacitor C7011 R C-E ZB 742 WJZ Z A P N V Capacitor C7201 R C-F ZA 564 WJZ Z A D J Capacitor C7202 R C-K Z1 003 CEZ Z+ AC V Capacitor C7204 V CEA 0A 1HW 106 M+ AB J Capacitor, 10 50V Electrolytic C7205 R C-E ZB 741 WJZ Z+ AD N V Capacitor C7206 V CKY CY 1HB 472 KY AA J Capacitor, 4700p 50V Ceramic C7207 V CCC CY 1HH 220 JY AA J Capacitor, 22p 50V Ceramic C7208 V CKY CY 1HB 104 KY AA J Capacitor, 0.1 50V Ceramic C7209 V CKY CY 1HB 104 KY AA J Capacitor, 0.1 50V Ceramic C7211 V CKY CY 1HB 221 KY AA J Capacitor, 220p 50V Ceramic C7217 R C-K ZA 476 WJZ Z+ AC V Capacitor C7241 R C-K ZA 550 WJZ Z A C J Capacitor

C7242 R C-K ZA 550 WJZ Z A C J Capacitor

C7302 R C-E ZB 740 WJZ Z A G N V Capacitor C7303 R C-E ZB 740 WJZ Z A G N V Capacitor C7304 V CEA 0A 1VW 477 M+ AB J Capacitor, 470 35V Electrolytic C7305 R C-K Z1 008 CEZ Z+ AC J Capacitor C7306 V CEA 0A 2AW 104 M+ AB J Capacitor, 0.1 100V Electrolytic C7307 R C-E ZB 739 WJZ Z+ AE N V Capacitor C7308 R C-K ZA 486 WJZ Z A D J Capacitor C7309 V CEA 0A 1CW 477 M+ AC J Capacitor, 470 16V Electrolytic C7310 V CEA 0A 1CW 477 M+ AC J Capacitor, 470 16V Electrolytic C7311 V CKY CY 1EB 103 KY AA J Capacitor, 0.01 25V Ceramic

DESCRIPTION

LC-32L407I

NO. PARTS CODE

PRICE

RANK

NEW

MARK

PAR T

DELIVERY

[4] DUNTKF538FM02 (POWER SUB Unit)

C7312 V CEA 0A1 HW1 05M + A B J Capacitor, 1 50V Electrolytic C7313 V CEA 0A1 HW4 75M + A B J Capacitor, 4.7 50V Electrolytic C7314 V CKY CY1 EB1 04K Y A B J Capacitor, 0.1 25V Ceramic C7318 V CKY PA2 HB1 02K + A A J Capacitor, 1000p 500V Ceramic C7319 V CKY PA2 HB1 02K + A A J Capacitor, 1000p 500V Ceramic C7403 V CEA 0A1 HW1 07M + A B J Capacitor, 100 50V Electrolytic C7404 V CKY TV1 EB1 05K Y A B J Capacitor, 1 25V Ceramic D7001 R H-D X04 77C EZZ AF J Diode, D5SB60

D7202 V HD1 SS2 44/ /-1 Y A B J Diode, 1SS244T-72 D7203 R H-E X06 48G EZZ Y A B J Zener Diode, MTZJT-7216A D7205 R H-D X03 21C EZZ Y A C J Diode, EG01CV1 D7211 V HDC US0 2TE +-1 Y A B J Diode, CUS02(TE85L,Q) D7212 R H-D XA0 95W JZZ Y A B J Diode, 1N4004G D7301 V HDH SS4 148 +-1 Y A A J Diode, HSS4148TA-E D7302 V HDH SS4 148 +-1 Y A A J Diode, HSS4148TA-E D7303 V HDH SS4 148 +-1 Y A A J Diode, HSS4148TA-E D7304 V HDH SS4 148 +-1 Y A A J Diode, HSS4148TA-E D7305 R H-E X06 40G EZZ Y A A J Zener Diode, MTZJT-7212B D7311 R H-D XA1 44W JQZ AE J Diode, FMEN-220B D7312 R H-D XA1 44W JQZ AE J Diode, FMEN-220B

F7001 Q FS- CA0 22W JZZ AC J Fuse, 5A 250V

F7002 Q FS- CA0 22W JZZ AC J Fuse, 5A 250V

FB7202 R BLN -00 20C EZZ + A B J Ferrite Core FB7205 R BLN -00 20C EZZ + A B J Ferrite Core FB7305 R BLN -00 20C EZZ + A B J Ferrite Core

FB7306 R BLN -00 20C EZZ + A B J Ferrite Core FH7001 Q FSH DA0 08W JZZ + A B J Fuse Holder FH7002 Q FSH DA0 08W JZZ + A B J Fuse Holder FH7003 Q FSH DA0 08W JZZ + A B J Fuse Holder FH7004 Q FSH DA0 08W JZZ + A B J Fuse Holder

HM7001 L X-G Z30 01P EZZ AB J Screw HM7002 L X-G Z30 01P EZZ AB J Screw HM7009 L X-G Z30 02P EZZ AB J Screw HM7010 L X-G Z30 02P EZZ AB J Screw HM7201 L X-G Z30 01P EZZ AB J Screw HM7301 L X-G Z30 01P EZZ AB J Screw

IC7201 V HIF A55 71+ +-1 Y A G N V IC, FA5571N-D1 IC7241 R H-F XA0 14W JZZ AC J IC, TLP781F(D4-GRL,F)

IC7301 V HIK IA4 31A +-1 + A C J IC, KIA431A-AT/P

J5503 Q JAK FA0 68W JQZ AD J Jack J5508 Q JAK GA1 64W JQZ AD N V Jack J5509 Q JAK GA1 31W JZZ AG J Jack J5510 Q JAK GA1 64W JQZ AD N V Jack J5511 Q SOC DA0 35W JZZ AD J Socket

L7002 R CIL FA3 61W JQZ AF N V Coil

L7301 R CIL PA7 03W JZZ + A D V Coil L7302 R CIL PA7 07W JZZ + A D J Coil L7303 R CIL PA7 07W JZZ + A D J Coil P5201 Q CNC MA0 12W JZZ AD J Connector P5202 Q CNC MA0 12W JZZ AD J Connector P5203 Q CNC MA0 12W JZZ AD J Connector P5204 Q PLG NA0 53W JZZ AF J Plug

P7001 Q PLG N02 69G EZZ AB J Plug Q7201 V S2S C39 28A R-1 Y A B J Transistor, 2SC3928A-T112-1R Q7202 V STK 13A 60D +-1 AK N V Transistor, TK13A60D(LBS1SP,Q) Q7303 V S2S C39 28A R-1 Y A B J Transistor, 2SC3928A-T112-1R Q7304 V S2S C39 28A R-1 Y A B J Transistor, 2SC3928A-T112-1R Q7309 V S2S C39 28A R-1 Y A B J Transistor, 2SC3928A-T112-1R Q7401 V SRS S07 5P0 3-1 Y A F J Transistor, RSS075P03TB Q7402 V S2S C39 28A R-1 Y A B J Transistor, 2SC3928A-T112-1R Q7403 V S2S A12 71- Y-1 + A C J Transistor, 2SA1271Y-AT/P

R901 V RS- CY1 JF8 22J Y A A J Resistor, 8.2k 1/16W Metal Oxide R902 V RS- CY1 JF1 23J Y A A J Resistor, 12k 1/16W Metal Oxide R903 V RS- CY1 JF8 22J Y A A J Resistor, 8.2k 1/16W Metal Oxide

R904 V RS- CY1 JF1 23J Y A A J Resistor, 12k 1/16W Metal Oxide R5203 V RS- CY1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R5206 V RS- CY1 JF1 01J Y A A J Resistor, 100 1/16W Metal Oxide R5207 V RS- CY1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R5501 V RS- CY1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R5502 V RS- CY1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R5503 V RS- CY1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R5504 V RS- CY1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R5505 V RS- CY1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R5506 V RS- CY1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R5507 V RS- CY1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R5508 V RS- CY1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R5509 V RS- CY1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R5515 V RS- CY1 JF1 23J Y A A J R5516 V RS- CY1 JF1 83J Y A A J Resistor, 18k 1/16W Metal Oxide R5517 V RS- CY1 JF1 23J Y A A J Resistor, 12k 1/16W Metal Oxide R5519 V RS- CY1 JF1 83J Y A A J Resistor, 18k 1/16W Metal Oxide R5521 V RS- CY1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R5523 V RS- TQ2 EF7 50J Y A A J Resistor, 75 1/4W Metal Oxide R5529 V RS- CY1 JF1 23J Y A A J Resistor, 12k 1/16W Metal Oxide R5530 V RS- CY1 JF1 23J Y A A J Resistor, 12k 1/16W Metal Oxide

Resistor, 12k 1/16W Metal Oxide

DESCRIPTION

LC-32L407I

NO. PARTS CODE

PRICE

RANK

NEW

MARK

PAR T

DELIVERY

[4] DUNTKF538FM02 (POWER SUB Unit)

R5532 V RS- CY 1JF 183 JY AA J Resistor, 18k 1/16W Metal Oxide R5535 V RS- CY 1JF 183 JY AA J Resistor, 18k 1/16W Metal Oxide R5537 V RS- TQ 2EF 750 JY AA J Resistor, 75 1/4W Metal Oxide R5538 V RS- CY 1JF 123 JY AA J Resistor, 12k 1/16W Metal Oxide R5539 V RS- CY 1JF 183 JY AA J Resistor, 18k 1/16W Metal Oxide R5540 V RS- TQ 2EF 750 JY AA J Resistor, 75 1/4W Metal Oxide R5542 V RS- CY 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R5543 V RS- CY 1JF 123 JY AA J Resistor, 12k 1/16W Metal Oxide R5545 V RS- TQ 2EF 750 JY AA J Resistor, 75 1/4W Metal Oxide R5546 V RS- TQ 2EF 750 JY AA J Resistor, 75 1/4W Metal Oxide R5551 V RS- CY 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R5552 V RS- CY 1JF 000 JY AA J Resistor, 0 1/16W Metal Oxide R5553 V RS- CY 1JF 102 JY AA J Resistor, 1k 1/16W Metal Oxide R5555 V RS- TQ 2EF 750 JY AA J Resistor, 75 1/4W Metal Oxide R5556 V RS- TQ 2EF 750 JY AA J Resistor, 75 1/4W Metal Oxide R5563 V RS- CY 1JF 183 JY AA J Resistor, 18k 1/16W Metal Oxide R7001 R R-H Z0 041 CEZ ZY AB J Resistor

R7204 V RN- VV 3DB R15 J A B J Resistor, 0.15 2W Metal Film R7206 V RS- CY 1JF 101 JY AA J Resistor, 100 1/16W Metal Oxide R7209 V RS- CY 1JF 184 JY AA J Resistor, 180k 1/16W Metal Oxide R7213 V RS- TV 1JD 122 JY AA J Resistor, 1.2k 1/10W Metal Oxide R7214 V RS- TV 1JD 220 JY AA J Resistor, 22 1/10W Metal Oxide R7215 V RS- TV 1JD 330 JY AA J Resistor, 33 1/10W Metal Oxide R7217 V RS- TV 1JD 472 JY AA J Resistor, 4.7k 1/10W Metal Oxide R7219 V RS- TV 1JD 472 JY AA J Resistor, 4.7k 1/10W Metal Oxide R7220 V RS- TV 1JD 222 JY AA J Resistor, 2.2k 1/10W Metal Oxide R7221 V RS- TQ 2BD 102 JY AA J Resistor, 1k 1/8W Metal Oxide R7222 V RS- TQ 2BD 102 JY AA J Resistor, 1k 1/8W Metal Oxide R7224 V RS- VV 3DB 223 J A A J Resistor, 22k 2W Metal Oxide R7225 V RS- VV 3DB 223 J A A J Resistor, 22k 2W Metal Oxide R7241 R R-H Z0 014 GEZ ZY AE J Resistor

R7261 V RS- TQ 2EF 105 JY AB V Resistor, 1M 1/4W Metal Oxide R7262 V RS- TQ 2EF 105 JY AB V Resistor, 1M 1/4W Metal Oxide R7263 V RS- TQ 2EF 105 JY AB V Resistor, 1M 1/4W Metal Oxide R7306 V RS- CY 1JF 562 FY AA J Resistor, 5.6k 1/16W Metal Oxide R7307 V RS- CY 1JF 822 FY AA J Resistor, 8.2k 1/16W Metal Oxide R7308 V RS- CY 1JF 183 FY AA J Resistor, 18k 1/16W Metal Oxide R7309 V RS- CY 1JF 622 FY AA J Resistor, 6.2k 1/16W Metal Oxide R7310 V RS- CY 1JF 223 JY AA J Resistor, 22k 1/16W Metal Oxide R7311 V RS- TV 1JD 821 JY AA J Resistor, 820 1/10W Metal Oxide R7312 V RS- CY 1JF 182 JY AA J Resistor, 1.8k 1/16W Metal Oxide R7313 V RS- TV 1JD 470 JY AA J Resistor, 47 1/10W Metal Oxide R7314 V RS- TV 1JD 623 FY AB J Resistor, 62k 1/10W Metal Oxide R7315 V RS- CY 1JF 823 JY AA J Resistor, 82k 1/16W Metal Oxide R7316 V RS- CY 1JF 102 JY AA J Resistor, 1k 1/16W Metal Oxide R7317 V RS- CY 1JF 223 JY AA J Resistor, 22k 1/16W Metal Oxide R7319 V RD- RA 2BE 103 JY AA J Resistor, 10k 1/8W Carbon R7320 V RS- TQ 2EF 331 JY AA J Resistor, 330 1/4W Metal Oxide R7321 V RS- TV 1JD 750 JY AA J Resistor, 75 1/10W Metal Oxide R7334 V RS- TV 1JD 102 JY AA J Resistor, 1k 1/10W Metal Oxide R7335 V RS- TQ 2EF 103 JY AA J Resistor, 10k 1/4W Metal Oxide R7401 V RS- CY 1JF 103 JY AA J Resistor, 10k 1/16W Metal Oxide R7402 V RS- CY 1JF 104 JY AA J Resistor, 100k 1/16W Metal Oxide R7403 V RS- CY 1JF 184 JY AA J Resistor, 180k 1/16W Metal Oxide R7404 V RS- CY 1JF 104 JY AA J Resistor, 100k 1/16W Metal Oxide R7405 V RS- TV 1JD 750 JY AA J Resistor, 75 1/10W Metal Oxide R7406 V RS- RG 3DB 151 J+ AB J Resistor, 150 2W Metal Oxide R7408 V RS- RG 3DB 151 J+ AB J Resistor, 150 2W Metal Oxide

R7410 V RS- CY 1JF 562 FY AA J Resistor, 5.6k 1/16W Metal Oxide RDA7001 P RDA RA 902 WJF W A E N V Radiator RDA7201 P RDA RA 920 WJF W A E N V Radiator RDA7301 P RDA RA 921 WJF W A F N V Radiator

RJ7309 V RS- CY 1JF 000 JY AA J Chip Jumper, 0 1/16W Metal Oxide

S901 Q SW- K0 003 AJZ Z+ AB J S902 Q SW- K0 003 AJZ Z+ AB J Switch S903 Q SW- K0 003 AJZ Z+ AB J Switch S904 Q SW- K0 003 AJZ Z+ AB J Switch S905 Q SW- K0 003 AJZ Z+ AB J Switch S906 Q SW- K0 003 AJZ Z+ AB J Switch S907 Q SW- K0 003 AJZ Z+ AB J Switch

T7241 R TRN WA 383 WJQ Z A R N V Transformer

TH7001 R H-H XA 053 WJZ Z A E N V Thermistor, B57237S 509A 3

VA7001 R H-V XA 182 WJZ Z A C J Varistor, B72210S2421K102V57

N L X-B Z3 049 GEF 7 A A J Screw, x4

Switch

DESCRIPTION

LC-32L407I

NO. PARTS CODE

PRICE

RANK

NEW

MARK

PAR T

DELIVERY

[5] DUNTKF539FM02 (R/C, LED Unit)

C104 R C-K ZA6 16W JQZ Y A B J Capacitor C105 V CKY CY1 HF1 03Z Y A A J Capacitor, 0.01 50V Ceramic C107 R C-K ZA2 37W JZZ Y A B J Capacitor C108 R C-K ZA2 37W JZZ Y A B J Capacitor D102 R H-P XA1 93W JQZ Y A B N V Diode D103 R H-P XA1 94W JQZ Y A B N V Diode

IC101 V HIG A1S 100 W-1 Y A E J IC, GA1A1S100WP

P101 Q PLG NA3 27W JZZ Y A C J Plug Q102 V S2S C39 28A R-1 Y A B J Transistor, 2SC3928A-T112-1R Q103 V S2S C39 28A R-1 Y A B J Transistor, 2SC3928A-T112-1R R101 V RS- CY1 JF1 01J Y A A J Resistor, 100 1/16W Metal Oxide R102 V RS- CY1 JF1 03J Y A A J Resistor, 10k 1/16W Metal Oxide R104 V RS- CY1 JF1 03J Y A A J Resistor, 10k 1/16W Metal Oxide R108 V RS- CY1 JF1 81J Y A A J Resistor, 180 1/16W Metal Oxide R109 V RS- CY1 JF1 22J Y A A J Resistor, 1.2k 1/16W Metal Oxide R135 V RS- CY1 JF0 00J Y A A J Resistor, 0 1/16W Metal Oxide R136 V RS- CZ1 JF4 73J Y A A J Resistor, 47k 1/16W Metal Oxide

RMC101 R RMC UA0 88W JZZ AE V Remote Control

DESCRIPTION

[6] CABINET AND MECHANICAL PARTS

1-11

1-6

2-8

1-6

1-9

2-1

2-4

1-1

1-2

1-5

1-8

1-10

1-6

1-8

2-9

1-6

1-11

1-6

1-9

2-3

1-4

2-8

POWER SUB Unit

1-7

1-12

1-3

MAIN Unit

R/C, LED Unit

3-4

LC-32L407I

3-2

3-5

3-6

3-3

3-1

8-2

2-6

6-1

2-4

5-2

5-1

4-3

4-2

4-1

2-10

2-6

8-4

8-1

8-3

8-2

8-4

2-11

2-6

7-2

2-2

2-11

7-3

7-1

7-4

LCD Panel Module

2-10

2-7

2-6

2-8

LC-32L407I

NO. PARTS CODE

PRICE

RANK

[6] CABINET AND MECHANICAL PARTS

1 C CAB AC5 98W J01 BD N V Front Cabinet Ass'y 1-1 N ot Ava ila ble - N - Front Cabinet 1-2 H DEC AA0 41W J6A AP N V Shine Trim 1-3 H DEC QB4 91W J6A AC N V LED Cover 1-4 H DEC QB4 92W J6A AC N V Power Decoration 1-5 H PNL SA3 30W J6A AQ N V Speaker Sheet 1-6 P SPA HC2 45W J00 AB J Spacer, x6 1-7 P SPA HC2 46W J00 AB N V Spacer for LED Cover

1-8 P SPA HC2 84W J00 AD N V Spacer L, x3

1-9 P SPA HC2 85W J00 AD N V Spacer S, x2

1-10 P SPA ZC5 58W JZZ AC V Spacer 1-11 P SPA ZC5 59W J4Z AB N V Spacer, x2 1-12 X EBS 930 P10 000 AA J Screw

2 C CAB BB8 05W J01 BC N V Rear Cabinet Ass'y 2-1 N ot Ava ila ble - N - Rear Cabinet 2-2 L HLD ZA9 29W JZZ AE J VESA Holder, x2 2-3 P SPA HC2 39W J00 AC N V Spacer 2-4 P SPA HC0 09W J4Z AD J Spacer, x2 2-5 P SPA HC1 29W J00 AB J Spacer, x1 2-6 P SPA HC2 67W J00 AC N V Spacer, x4 2-7 P SPA HC2 68W J00 AC N V Spacer, x2 2-8 P SPA HC2 69W J00 AD N V Spacer, x2 2-9 P SPA HC2 70W J00 AB N V Spacer

2-10 P SPA ZC5 56W J4Z AB N V Spacer, x2 2-11 X EBS 930 P08 000 AA J Screw, x2

3 C COV AD7 65W J01 AS N V Back Cover Ass'y 3-1 N ot Ava ila ble - N - Back Cover 3-2 H IND PD9 41W J4A AF N V Terminal Label 3-3 H IND PD8 86W J4A AE N V Indicator 3-4 J BTN -A8 77W J4A AD N V Control Button 3-5 P SLD MB7 10W J4W AD N V Barrier Shield 3-6 P SPA HC2 40W J00 AB N V

4 C DAI -A6 72W J01 AR N V Support Ass'y 4-1 N ot Ava ila ble - N - Support Angle 4-2 N ot Ava ila ble - - Bottom Angle 4-3 L X-B ZA2 09W JF7 AB J Screw, x4

5 C COV AD7 75W J01 AK N V Stand Hinge Cover Ass'y 5-1 N ot Ava ila ble - N - Stand Hinge Cover 5-2 P SPA HA6 60W J00 AB V Spacer, x2

6 H IND PD9 21W J6A AC N V Model Label

6-1 T LAB ZC6 71W J6Z AC N V Regulation Label

7 C ANG KC8 61W J01 AU N V Top Bracket Ass'y 7-1 N ot Ava ila ble - N - Top Bracket 7-2 P SPA HC2 72W J00 AB N V Spacer 7-3 P SPA HC2 76W J00 AB N V Spacer, x2 7-4 P SPA ZC5 07W JZZ AC V Spacer, x2

8 C ANG KC8 62W J01 AN N V Bottom Bracket Ass'y 8-1 N ot Ava ila ble - N - Bottom Bracket 8-2 P SPA HC2 71W J00 AB N V Spacer, x2 8-3 P SPA HC2 72W J00 AB N V Spacer 8-4 P SPA HC2 75W J00 AB N V Spacer, x2

9 L HLD WA1 01W JKZ AD J AC Cord Hook

10 L X-B ZA2 09W JF7 AB J Screw (for Stand), x4 11 L X-H Z30 98G EF7 AA J Screw (for PWB), x13 12 L X-T Z30 11C EF7 AB J Screw (for Panel), x2

13 Q ACC ZA0 92W JPZ AK J AC Cord (for Indonesia/Malaysia/UAE/Vietnam/ASEAN) 14 Q CNW -K7 70W JQZ AK N V Connecting Cord (RA) 15 Q CNW -K8 11W JQZ AV N V Connecting Cord (LVDS) 16 Q CNW -K9 03W JQZ AK N V Connecting Cord (SP) 17 Q CNW -K9 04W JQZ AK N V Connecting Cord (PI)

18 N ot Ava ila ble - N - No. Label 19 V SP9 050 PA0 98A AL N V Speaker, x2

20 X BBS 740 P06 000 AA J Screw (for Bracket), x4 21 X BPS 830 P06 000 AA J Screw (for HDMI) 22 X EBS 930 P10 000 AA J Screw (for AV/SP), x1 23 X EBS 940 P16 000 AB J Screw (for Rear Cabinet/Cover), x17 24 X HPS 830 P10 WS0 AB J Screw

25 P SPA ZC5 98W JZZ AB J Speaker Rubber, x2 26 P MLT -A6 38W JZZ AB J Molt Plane, x2 27 P SPA HC2 19W J00 AB J Spacer, x2 28 P SPA HC2 92W J00 AB N V Spacer, x2 29 P SPA HC2 93W J00 AB N V Spacer, x3 30 P SPA HC2 94W J00 AC N V Spacer 31 P SPA HC2 95W J00 AC N V Spacer

NEW

MARK

PAR T

DELIVERY

DESCRIPTION

Spacer

LC-32L407I

[7] LCD MODULE Assembly

LC-32L407I

NO. PARTS CODE

PRICE

RANK

[7] LCD MODULE Assembly

1 B 3KU 32 L50 DA N V 32"LCD Panel Module (R1LK315T3LA5BX) 2 C ANG K4 434 TP0 1 A K J Bezel Ass'y (Top) 3 C ANG K4 327 TP0 1 A K J Bezel Ass'y (Bottom) 4 C ANG K4 328 TP0 1 A G J Bezel Ass'y (L/R), x2 5 C HLD Z4 113 TP0 1 A K J P Chassis Ass'y (Top) 6 C HLD Z4 114 TP0 2 A K J P Chassis Ass'y (Bottom) 7 C HLD Z4 115 TP0 2 A H J P Chassis Ass'y (L) 8 C HLD Z4 115 TP0 1 A H J P Chassis Ass'y (R)

9 P SLD K3 100 TPZ Z A Q J Diffusion Sheet, x3 10 P SLD K3 097 TPZ Z A S J Diffusion Plate 11 C HLD Z4 117 TP0 1 A M J Lamp Holder Ass'y, x2 12 R LMP -0 754 TPZ Z A K J Lamp, x10 13 Q SOC F0 003 TPZ Z A D J Socket (Hot), x10 14 Q SOC F0 005 TPZ Z A C J Socket (GND), x10 15 L ANG K4 331 TPZ Z A D J GND Angle 16 L HLD Z4 081 TPZ Z A B J Lamp Clip A, x2 17 L HLD Z4 082 TPZ Z A B J Lamp Clip B, x2 18 P REF L2 780 TPZ Z A N J Reflection Sheet 19 C CHS M0 060 TP0 1 A Z J BL Chassis Ass'y 20 R DEN C2 590 TPZ Z B B V INVERTER Unit 21 P COV P2 685 TPZ Z A H J Inverter Cover 22 L X-H ZA 039 WJF 7 A B J Screw (for Bezel/BL Chassis), x8 23 L X-H Z2 203 TPZ Z A B J Screw (for INVERTER Unit), x5 24 X HPS 73 0P0 6KS 0 A B J Screw (for GND Angle), x3 25 P TPE H1 708 TPZ Z A D J Double-Stick Tape (for Diffusion Plate)

[8] SUPPLIED ACCESSORIES

NEW

MARK

PAR T

DELIVERY

"AA" Size Battery

DESCRIPTION

Stand Base Ass'yRemote Control Unit Operation Manual

Screw (for Stand)

NO. PARTS CODE

PRICE

RANK

NEW

MARK

PAR T

DELIVERY

[8] SUPPLIED ACCESSORIES

X1 R RMC GA 867 WJS A A M N V Remote Control Unit X2 T INS -E 823 WJZ Z A C N V Operation Manual (For Indonesia) X3 N ot Av ail abl e - N - "AA" Size Battery X4 C DAI -A 671 WJ0 1 A V N V Stand Base Ass'y X5 X BBS N5 0P1 2JS 0 A B J Screw (for Stand), x4 X6 T GAN -0 006 WJZ Z A G V Warranty Card (for Indonesia)

DESCRIPTION

LC-32L407I

[9] PACKING PARTS (NOT REPLACEMENT ITEM)

S6 X2 X6

S3 X4

S7 X3 X5

NO. PARTS CODE

PRICE

RANK

NEW

MARK

PAR T

DELIVERY

[9] PACKING PARTS (NOT REPLACEMENT ITEM)

S1 SPAKCF773WJZZ - N - Packing Case S2 SPAKPB579WJZZ - - Wrapping Paper S3 SPAKPB514WJ4Z - - Mirror Mat Base S4 SPAKXD036WJZZ - N - Packing Add. (Top) S5 - N - Packing Add. (Bottom)

SPAKXD036WJZZ

S6 SSAKA0037CEZZ - - Polyethylene Bag S7 SSAKHA061WJZZ - - Polyethylene Bag (for Screw) S8 TLABVA405WJZZ - - No. Card S9 SPAKAA654WJZZ - - Cushion pad

DESCRIPTION

[10] SERVICE JIGS (USE FOR SERVICING)

N Q CNW -L0 77W JQZ N V Connecting Cord, MAIN-LCD CONTROL (LW) N Q CNW -K8 14W JQZ N V Connecting Cord, POWER-INVERTER (PI) N Q CNW -J4 13W JQZ AQ N V Connecting Cord, MAIN-SPEAKER (SP)

MEMO

LC-32L407I

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.

LC-32L407I

July, 2010

PT. SHARP ELECTRONICS INDONESIA

TV Engineering Dept.

Jakarta , Indonesia

Sharp LC-32L407I Schematic

Specifications and Main Features

Frequently Asked Questions

User Manual

TopPage

SAFETY PRECAUTION

IMPORTANT SERVICE SAFETY PRECAUTION

WARNING

PRECAUTIONS FOR USING LEAD-FREE SOLDER

Employing lead-free solder

Using lead-free wire solder

Soldering

OUTLINE

MAJOR SERVICE PARTS

PWB UNIT

OTHER UNIT

IC FOR EXCLUSIVE USE OF THE SERVICE

SERVICE JIGS

CHAPTER 1. SPECIFICATIONS

[1] SPECIFICATIONS

CHAPTER 2. OPERATION MANUAL

[1] OPERATION MANUAL

CHAPTER 3. DIMENSIONS

[1] DIMENSIONS

CHAPTER 4. REMOVING OF MAJOR PARTS

[1] REMOVING OF MAJOR PARTS

1. Removing of the Stand and Back Cover

2. Disconnect the connectors

3. Removing of the MAIN Unit and POWER SUB Unit

4. Removing of the Rear Cabinet

5. Removing of the Speaker and R/C, LED Unit

6. Removing of the Top Bracket, Bottom Bracket and LCD Panel Module

CHAPTER 5. ADJUSTMENT

[1] ADJUSTMENT PROCEDURE

1. Entering and cancel the adjustment process mode

2. Remote controller key operation and description of display in adjustment process mode.

3. Signal adjustment

4. Factory setting

5. Software upgrading

CHAPTER 6. TROUBLESHOOTING TABLE

[1] TROUBLESHOOTING TABLE

CHAPTER 7. OVERALL WIRING/BLOCK DIAGRAM

[1] OVERALL WIRING DIAGRAM

[2] SYSTEM BLOCK DIAGRAM

CHAPTER 8. PRINTED WIRING BOARD ASSEMBLIES

[1] MAIN Unit

[2] POWER SUB Unit

[3] R/C, LED Unit

CHAPTER 9. SCHEMATIC DIAGRAM

[1] DESCRIPTION OF SCHEMATIC DIAGRAM

1. VOLTAGE MEASUREMENT CONDITION:

2. INDICATION OF RESISTOR & CAPACITOR:

[2] MAIN Unit

[3] POWER SUB Unit

[4] R/C, LED Unit

PartsGuide

[1] PRINTED WIRING BOARD ASSEMBLIES

[2] LCD PANEL

[3] DUNTKF537FM02 (MAIN Unit)

[4] DUNTKF538FM02 (POWER SUB Unit)

[5] DUNTKF539FM02 (R/C, LED Unit)

[6] CABINET AND MECHANICAL PARTS

[7] LCD MODULE Assembly

[8] SUPPLIED ACCESSORIES

[9] PACKING PARTS (NOT REPLACEMENT ITEM)

[10] SERVICE JIGS (USE FOR SERVICING)
