DOUBLE DOOR REFRIGERATOR
FREEZER - FRIDGE
Instruction booklet
FRIGORIFICO DE DOS PUERTAS
Manual de instrucciones
FRIGORIFICO DE DOS PUERTAS
Manual de instrucciones
FRIGORÍFICO
Manual de Instruções
DE PORTA DUPLA
SFES2520A+
"Todas las informaciones incluidas en este manual podrían verse sujetas a errores
tipográficos o de otra índole y por tanto diferir del producto real."
Contents
BEFORE USING THE APPLIANCE ........................................................ 2
General warnings ........................................................................................... 2
Old and out-of-order fridges ............................................................................ 4
Safety warnings ............................................................................................. 4
Installing and operating your fridge ................................................................. 5
Before Using your Fridge ................................................................................ 5
THE VARIOUS FUNCTION AND POSSIBILITIES..................................6
Thermostat setting ......................................................................................... 6
Accessoires .................................................................................................. 7
Ice tray ........................................................................................................................... 7
If turbo fan is available on your product ; ................................................................... 7
ARRANGING FOOD IN THE APPLIANCE .............................................. 7
Refrigerator Compartment .............................................................................. 7
Freezer Compartment .................................................................................... 8
CLEANING AND MAINTENANCE ........................................................... 9
Defrosting ..................................................................................................... 10
Replacing the light bulb ................................................................................. 11
SHIPMENT AND REPOSITIONING ...................................................... 11
Repositioning the Door .................................................................................. 11
BEFORE CALLING YOUR AFTER SALES SERVICE .......................... 12
Tips for saving energy ................................................................................... 14
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS ....... 15
EN - 1 -
PART - 1. BEFORE USING THE APPLIANCE
General warnings
WARNING: Keep vantilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means to
accelerate the defrosting process, other than those recommended
by the manufacturer.
WARNING: Do not use electrical appliances inside the food storage
compartments of the
appliance, unless they are of the type recommended by the
manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: To avoid a hazard due to the instability of the appliance,
it must be fixed in accordance with the instructions.
• If your appliance uses R600a as a refrigerant – you can learn
this information from the label on the cooler- you should be careful
during shipment and montage to prevent your appliance’s cooler
elements from being damaged. Although R600a is a
environmental friendly and natural gas, as it is explosive, in case
of a leakage to be occurred due to a damage in the cooler
elements move your fridge from open flame or heat sources and
ventilate the room where the appliance is located for a few
minutes.
• While carrying and positioning the fridge, do not give damage
to the cooler gas circuit.
• Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
• This appliance is intended to be used in household and similar
applications such as;
EN - 2 -
- staff kitchen areas in shops, offices and other working
environments
- farm houses and by clients in hotels, motels and other residential
type environments
- bed and breakfast type environments;
- catering and similar non-retail applications
• If the socket does not match the refrigerator plug, it must be
replaced by the manufacturer, its service agent or similar qualified
persons in order to avoid a hazard.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
• A specially grounded plug has been connected to the power
cable of your refrigerator. This plug should be used with a
specially grounded socket of 16 amperes. If there is no such
socket in your house, please have it installed by an authorized
electrician.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understandt the hazard involved.
Children shall not play with the appliance. Cleaning and user
maintenance, shall not be made by children without supervision.
• If the supply cord is demaged, it must be replaced by the
manufacturer, its service agent or similar qualified persons in
order to avoid a hazard.
EN - 3 -
Old and out-of-order fridges
• If your old fridge has a lock, break or remove the lock before discarding it, because
children may get trapped inside it and may cause an accident.
• Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore,
take care not to harm environment when you are discarding your old fridges.
Please ask your municipal authority about the disposal of the W EEE for the
reuse, recycle and recovery purposes.
Notes:
• Please read the instruction manual carefully before installing and using your appliance.
We are not responsible of the damage occurred due to misuse.
• Follow all instructions on your appliance and instruction manual, and keep this
manual in a safe place to resolve the problems that may occur in the future.
• This appliance is produced to be used at houses and it can only be used in house
and for the specified purposes. It is not suitable for commercial or common use.
Such use will cause the guarantee of the appliance to be cancelled and our company
will not be responsible for the losses to be occurred.
• This appliance is produced to be used in houses and it is only suitable for cooling /
storing foods. It is not suitable for commercial or common use and/or for storing
substances except for food. Our company is not responsible for the losses to be
occurred in the contrary case.
Safety warnings
• Do not use multiple receptacles or extension cord.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• This appliance is designed for use by adults, do not allow
children to play with the appliance or let them to hang over the
door.
• Do not plug-in or out the plug from the receptacle with wet hands
to prevent electrocution!
• Do not place glass bottles or beverage cans in the freezer
department. Bottles or cans may explode.
• Do not place explosive or flammable material in your fridge for
your safety. Place drinks with higher alcohol amount vertically
and by closing their necks tightly in the fridge department.
EN - 4 -
• When taking ice made in the freezer department, do not touch it, ice
may cause ice burns and/or cuts.
• Do not touch frozen goods with wet hands! Do not eat ice-cream and
ice cubes immediately after you take them out of the freezer department!
• Do not re-freeze the frozen goods after being melted. This may cause health issues
like food poisoning.
• Do not cover the body or top of fridge with lace. This affects the performance of your
fridge.
• Fix the accessories in the fridge during transpo rtation to prevent damage to
accessories.
Installing and operating your fridge
Before starting to use your fridge, you should pay attention to the following points:
• Operating voltage for your fridge is 220-240 V at 50Hz.
• We do not take the responsibility of the damages that occur due to ungrounded
usage.
• Place your fridge in a place that it would not be exposed to direct sunlight.
• Your appliance should be at least 50 cm away from stoves, Gas
ovens and heater cores, and should be at least 5 cm away from
electrical ovens.
• Your fridge should never be used outdoors or left under the rain.
• When your fridge is placed next to a deep freezer, there should be at
least 2 cm between them to prevent humidity on the outer surface.
• Do not place anything on your fridge, and install your fridge in a
suitable place so that at least 15 cm is available on the upper side.
• The adjustable front legs should stabilized in an appropriate height to allow your
fridge operate in a stable and proper way. You can adjust the legs by turning them
clockwise (or in the opposite direction). This should be done before placing food in
the fridge.
• Before using your fridge, wipe all parts with warm water added with a tea spoonful of
sodium bicarbonate, and then rinse with clean water and dry. Place all parts after
cleaning.
• Install the distance adjustment plastic (the part with black vanes
at the rear) by turning it 90° as shown in the figure to prevent the
condenser from touching the wall.
Before Using your Fridge
• W hen it is operated for the first time or after transportation, keep
your fridge in the upright position for 3 hours and plug it on to
allow efficient operation. Otherwise, you may damage the
compressor.
• Your fridge may have a smell when it is operated for the first time; the smell will fade
away when your fridge starts to cool.
EN - 5 -
PART - 2.
THE VARIOUS FUNCTION AND POSSIBILITIES
Thermostat setting
• Thermo stat automatically regulates the inside temperature of the refrigerator
compartment and freezer compartment.By rotating the knob from position 1 to 5,
colder temperatures can be obtained. «•» position shows thermostat is closed and
no cooling will be avaible.
• For short-term storage of food in the freezer compartment, you can set the knob
between 1 and 3 position.
• For long-term storage of food in the freezer compartment, you can set knop 3-4
position.
Note that; the ambiant temperature, temperature of the freshly stored food and how often
the door is opened, affects the temperature in the refrigerator compartment. If required,
change the temperature setting.
If super switch is available:
In order to ensure proper operation with an ambient
temperature below 20°C, press the button next to the
thermostat. Press the button again to turn it off when
the temperature is high (above 20°C).
EN - 6 -
Accessoires
Ice tray
• Fill the ice tray with water and place in freezer compartment.
• After the water completely turned into ice, you can twist the tray as shown below to get
the ice cube.
If turbo fan is available on your product ;
Turbo fan
• Do not block air inlet and outlet openings when storing food, otherwise air circulation
that provided by turbo fan will be impaired.
PART - 3. ARRANGING FOOD IN THE APPLIANCE
Refrigerator Compartment
• To reduce humidity and consequent increase of frost never place liquids in unsealed
containers in the refrigerator. Frost tends to concentrate in the coldest parts of the
evaporator and in time will require more frequent defrosting.
• Never place warm food in the refrigerator. Warm food should be allowed to cool at
room temperature and should be arranged to ensure adequate air circulation in the
refrigerator compartment.
• Nothing should touch on the back wall as it will cause frost and the packages can
stick on the back wall. Do not open the refrigerator door too frequently.
• Arrange the meat and cleaned fish(wrapped in packages or sheets of plastic) which
you will use in 1-2 days,in the bottom section of the refrigerator compartment(that is
above the crisper) as this is the coldest section and will ensure the best storing
conditions.
• You can put the fruits and vegetables into crisper without packing.
EN - 7 -
Freezer Compartment
• The use of freezer is, storing of deep-frozen or frozen foods for long periods of time
and making ice cubes.
• To freeze fresh food, ensure that as much of the surface as possible of food to be
frozen is in contact with the cooling surface.
• Do not put fresh food with frozen on side by side as it can thaw the frozen food.
• While freezing fresh foods(i.e meat,fish and mincemeat), divide them in parts you
will use in one time.
• Once the unit has been defrosted replace the foods into freezer and remember to
consume them in as short period of time.
• Never place warm food in the freezer compartment. As it will disturb the frozen foods.
• For storing the frozen foods;the instructions shown on frozen food packages should
always be followed carefully and if no information is provided food should not be
stored for more than 3 months from the purchased date.
• When buying frozen foods ensure that these have been frozen at suitable
temperatures and that the packing is intact.
• Frozen foods should be transported in appopriate containers to maintain the quality
of the food and should be returned to the freezing surfaces of the unit in the shortest
possible time.
• If a package of frozen food shows the sign of humidity and abnormal swelling it is
probable that it has been previously stored at an unsuitable temperature and that
the contents have deteriorated.
• The strorage life of froozen foods depends on the room temperature, thermostat
setting, how often the door is opened, the type of food and the length of time required
to transport the product from the shop to your home. Always follow the instruductions
printed on the package and never exceed the maximum storage life indicated.
Not that; if you want to open again immediately after closing the freezer door, it will not be
opened easily. It’s quite normal! After reaching equilibrium condition, the door will be
opened easily.
EN - 8 -
PART - 4. CLEANING AND MAINTENANCE
• Make sure to unplug the fridge before starting to clean it.
• Do not wash your fridge by pouring water.
• You can wipe the inner and outer sides with a soft cloth or a
sponge using warm and soapy water.
• Remo ve the part s individ ually and clean with
soapy water. Do not wash in washing machine.
• Never use flammable, explosive or corrosive material like thinner,
gas, acid for cleaning.
• You should clean the condenser with broom at least
once a year in order to provide energy saving and
increase the productivity.
Make sure that your fridge is unplugged while cleaning.
EN - 9 -
Defrosting
Refrigerator Compartment;
• Defrosting occurs automatically in refrigerator compartment during operation ; the
defrost water is collected by the evaporating tray and evoparates automatically.
• The evaporating tray and the defrost water drain hole should be cleaned periodically
with defrost drain plug to prevent the water from collecting on the bottom of the
refrigerator instead of flowing out.
• You can also pour 1/2 glass of the water to drain hole to clean inside.
Freezer Compartment;
The frost, accumulated in the freezer compartment, should be removed periodically. (Use
the plastic scraper provided) The freezer compartment should be cleaned in the way as
the refrigerator compartment, with the defrost operations of the compartment at least
twice a year.
For this;
• The day before you defrost, set the thermostat dial to “5” position to freeze the foods
completely.
• During defrosting, frozen foods should be wrapped in several layers of paper and
kept in a cool place. The inevitable rise in temperature will shorten their storage life.
Remember to use these foods within a relatively short period of time.
• Set thermostat knob to position « • » or unplug the unit; leave the door open until
completely defrosted.
• To accelerate the defrosting process one or more basins of warm water can be
placed in the freezer compartment.
• Dry the inside of the unit carefully and set the thermostat knob to MAX position.
EN - 10 -
Replacing the light bulb
To replace the bulb in freezer and fridge departments;
1- Unplug your fridge.
2- Remove the cover of the box from the claws using a screwdriver.
3- Replace with a bulb of maximum 15 W atts.
4- Install the cover.
5- Wait for 5 minutes before re-plugging and bring the thermostat to its original position.
PART - 5.
• Original package and foam may be kept for re-transportation (optionally).
• You should fasten your fridge with thick package, bands or strong cords and follow
the instructions for transportation on the package for re-transportation.
• Remove movable parts (shelves,
accessories, vegetable bins etc.) or fix
them into the fridge against shocks
using bands during re-positioning and
transportation.
Carry your fridge in the upright position.
SHIPMENT AND REPOSITIONING
Repositioning the Door
• It is not possible to change the opening direction of your fridge door, if the door
handles on your fridge are installed from the front surface of the door.
• It is possible to change the opening direction of the door on models without any
handles.
• If the door opening direction of your fridge may be changed, you should contact the
nearest Authorized Service to have the opening direction changed.
EN - 11 -
PART - 6.
If your refrigerator is not working properly,it may be a minor problem, therefore check the
following, before calling an electrician to save time and money.
What to do if your refrigerator does not operate ;
Check that ;
• There is no power ,
• The general switch in your home is disconnected ,
• The thermostat setting is on « • » position ,
• The socket is not sufficient. To check this, plug in another appliance that you know
which is working into the same socket.
What to do if your refrigerator performs poorly ;
Check that ;
• You have not overloaded the appliance ,
• The doors are closed perfectly ,
• There is no dust on the condenser ,
• There is enough place at the rear and side walls.
If there is noise ;
The cooling gas which circulates in the refrigerator circuit may make a slight noise(bubbling
sound) even when the compressor is not running. Do not worry this is quite normal. If
these sounds are different check that ;
• The appliance is well leveled
• Nothing is touching the rear.
• The stuffs on the appliance are vibrating.
BEFORE CALLING YOUR AFTER SALES SERVICE
If there is water in the lower part of the refrigerator ;
Check that ;
The drain hole for defrost water is not clogged(Use defrost drain plug to clean the drain
hole)
EN - 12 -
If your fridge is not cooling enough;
Your fridge is designed to operate in the ambient temperature intervals stated in the
standards, according to the climate class stated in the information label. We do not
recommend operating your fridge out of stated temperatures value limits in terms of cooling
effectiveness.
Climate Class Ambient Temperature (°C)
T
Between 16 and 43 (°C)
ST Between 16 and 38 (°C)
N
Between 16 and 32 (°C)
SN Between 10 and 32 (°C)
Recommendations
• In order to increase space and improve the appearance,the « cooling section » of
this appliance is positioned inside the back wall of the refrigerator compartment.
When the appliance is running, this wall is covered with frost or water drops,according
to weather the compressor is running or not. Do not worry. This is quite normal. The
appliance should be defrosted only if an excessively thick layer forms on the wall.
• If the applianc e is not used for long time (for examp le during the summer
holidays)Defrost and clean the refrigerator leaving the door open to prevent the
formation of midew and smell.
• To stop the appliance completely, unplug from main socket (for cleaning and when
the doors are left open).
• If the problem persists after you have followed all the instructions above, please
consult to the nearest Authorized Service.
• The appliance you have purchased is designed for home type use and can be used
only at home and for the stated purposes. It is not suitable for commercial or common
use. If the consumer use the appliance in a way that does not comply with these
features, we emphasize that the producer and the dealer shall not be responsible
for any repair and failure within the guarantee period.
• The lifetime of your appliance stated and declared by the Department of the Industry
(the period for retaining parts required for the proper functioning of the appliance) is
10 years.
Conformity Information
• This equipment is designed for use at an ambient tem-perature within the 16°C 32°C range.
• The appliance is designed in compliance with the IEC60335-1 / IEC60335-2-24,
2004/108/EC standards.
EN - 13 -
Tips for saving energy
1– Install the appliance in a cool, well ventilated room , but not in direct sunlight and not
near heat source (radiator, cooker.. etc. ). Otherwise use an insulating plate.
2– Allow warm food and drinks to cool down outside the appliance.
3– When thawing frozen food, place it in th e refrigerator compartment. The low
temperature of the frozen food will help to cool the refrigerator compartment when it
is thawing. So it reduces the energy requirements.
4– W hen placing, drinks and liquids they must be covered. Otherwise humidity increases
at the appliance. Therefore the working time gets longer. Also covering drinks and
liquids helps preserve the smell and taste.
5– When placing food and drinks, open the appliance door as briefly as possible.
6– Keep the covers closed of any different temperature compartment in the appliance
(crisper, chiller ...etc. ).
7– Door gasket must be clean and pliable. Replace gaskets if worn.
EN - 14 -
PART - 7.
1
2
9
1011121314
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
3
A
4
5
B
6
7
8
This presentation is only for information about the parts of the appliance.
Parts may vary according to the appliance model.
A) Freezer compartment
B) Refrigerator compartment
1) Plastic scraper
2) Ice tray
3) Freezer shelf
4) Turbo fan (In some models)
5) Thermostat box
6) Refrigerator shelves
7) Crisper cover
8) Crisper
9) Leveling foot
10) Bottle shelf
11) Butter Cheese shelves
12) Egg holder
13) Butter Cheese shelf cover
14) Lamp switch
EN - 15 -
Inhalt
AUFSTELLUNG .................................................................................... 17
Allgemeine Warnungen ................................................................................. 17
Sicherheits Information.................................................................................. 19
Hinweise.......................................................................................................19
Installation und Anschluss des Gerätes ......................................................... 20
Vor Inbetriebnahme ....................................................................................... 20
FUNKTIONEN ....................................................................................... 21
Temperaturregelung....................................................................................... 21
Zubehör ........................................................................................................ 22
Eisschale ................................................................................................................... 22
Wenn Ihr Produkt mit dem Turboventilator ausgestattet ist .................................. 22
AUFBEWAHRUNG VON LEBENSMITTEL ........................................... 22
Kühlschrank ................................................................................................. 22
Gefrierfach.................................................................................................... 23
REINIGUNG UND PFLEGE .................................................................. 24
Abtauen ........................................................................................................ 25
Wechseln der Glühlampe .............................................................................. 26
TRANSPORT UND STANDORTÄNDERUNG ...................................... 26
Wechsel des Türanschlages ......................................................................... 26
BEVOR SIE DEN KUNDENDIENST RUFEN ....................................... 27
BAUTEILE UND VORRATSFÄCHER.................................................... 29
DE - 16 -
TEIL 1. AUFSTELLUNG
Allgemeine Warnungen
WARNUNG: Belüftungsöffnungen in der Geräteverkleidung oder in
der integrierten Struktur, frei von Hindernissen halten.
WARNUNG: Verwenden Sie keine mechanischen Werkzeuge oder
andere Mittel als vom Hersteller vorgeschlagen, um den Abtauvorgang
zu beschleunigen.
WARNUNG: Verwenden Sie keine elektrischen Geräte innerhalb
der Kühlfächer des
Gerätes, sofern sie nicht vom Hersteller empfohlenen sind.
WARNUNG: Achten Sie darauf, die Kältemittelkreise des Kühlgeräts
nicht zu beschädigen.
WARNUNG: Um eine Gefahr aufgrund der Instabilität des Gerätes
zu vermeiden, muss es in Übereinstimmung mit den Anweisungen
fixiert werden.
• Die Geräte mit dem Kühlgas R600a, sind sehr umweltfreundlich,
aber auch leicht entzündlich. Während des Transportes und der
Installation ist mit größter Sorgfalt darauf zu achten, daß der
Kühlkreislauf nicht beschädigt wird. Falls es doch zu einer
Beschädigung kommt, müssen offene Flammen vermieden
werden. Den Raum, in dem das Gerät steht, für einige Minuten
gut lüften.
• Benutzen Sie keine mechanischen Vorrichtungen oder
künstlichen Mittel, um den Gefrierprozess zu beschleunigen.
• Lagern Sie in diesem Gerät keine explosiven Stoffe wie
Spraydosen mit brennbarem Treibmittel.
• Das Gerät soll im Haushalt und in ähnliche Anwendungen wie
folgt verwendet werden;
- Personal Küchenbereich in Läden, Büros und anderen
Arbeitsumgebungen
DE - 17 -
- Bauernhäusern und von Kunden in Hotels, Motels und anderen
Unterkünften
- Bett and Frühstück-Typ-Umgebungen;
- Gastronomie und ähnliche Non-Retail-Anwendungen
• Wenn die Steckdose nicht mit dem Kühlschrank Stecker
zusammenpasst, muss es, um Gefahren zu vermeiden durch
den Hersteller, dessen Kundendienst oder einer ähnlich
qualifizierten Personen ersetzt werden.
• Dieses Gerät ist nicht zur Verwendung durch Personen
(einschließlich Kinder) mit eingeschränkten physischen,
sensorischen oder geistigen Fähigkeiten oder mangelnder
Erfahrung und Wissen bestimmt, es sei denn sie stehen unter
Aufsicht oder ausführlicher Anleitung zur Benutzung des Gerätes
durch eine verantwortliche Person, für ihre Sicherheit. Kinder
sollten daran gehindert werden, mit dem Gerät zu spielen.
• Das Netzkabel des Kühlschranks ist mit einem geerdeten
Netzstecker ausgestattet. Dieser Netzstecker muss in eine
geerdete, mit mindestens 16 Ampere gesicherte Steckdose
gesteckt werden. Wenn Sie keine geeignete Steckdose haben,
lassen Sie eine solche von einem qualifizierten Elektriker
installieren.
• Dieses Gerät kann von Kindern ab 8 Jahren und älter und
Personen mit eingeschränkten physischen, sensorischen oder
geistigen Fähigkeiten oder mangelnder Erfahrung und Wissen
DE - 18 -
Sicherheits Information
• In dem Kühlschrank dürfen keine elektrischen Geräte benutzt werden.
• Falls das Gerä t einen alten Kühlsc hrank ersetzen soll, empfehle n wir als
Sicherheitsvorkehrung, das Türschloß des alten Gerätes zu zerstö ren oder zu
entfernen. Diese Maßnahme verhindert, daß spielende Kinder sich selbst darin
einsperren.
• Ältere Geräte enthalten Kühl- und Isolierungsgas, diese müssen ordnungsgemäß
entsorgt werden. Zur Entsorgung eines Altgerätes sollten Sie sich einer fachkundigen
Müllbeseitungsstelle anvertrauen.Für weitere Fragen kontaktieren Sie Ihre lokale
Behörde oder einen Fachhändler. Bitte stellen Sie sicher, daß die Rohrleitungen bis
zur ordnungsgemäßen Entsorgung nicht beschädigt werden.
Fragen Sie bitte Ihre Stadtverwaltung über die Entsorgung von W EEE für
Wiederverwendung, Recycling und Recovery-Zwecke.
WICHTIGER HINWEIS :
Um Betriebsstörungen zu vermeiden und mehr Freude an Ihrem Gerät zu haben, bitten
wir Sie, vor In b etriebn ahme des Gerätes die Bedienu n gsanleitung aufmerk sam
durchzulesen. Der Hersteller übernimmt keine Garantie bei unsachgemäßer Installation
und Bedienung des Gerätes.
Hinweise
• Zur Verhinderung von Brandgefahr oder Überhitzung dürfen keine
Adapter oder Vielfachstecker benutzt werden.
• Schließen Sie keine alten, verbogenen Verlängerungskabel an
das Gerät.
• Die Kabel nicht wickeln oder knicken.
• Wenn die Anschlußleitung dieses Gerätes beschädigt wird, muß
sie durch den Hersteller oder seinen Kundendienst oder eine
ähnlich qualifizierte Person ersetzt werden, um Gefährdungen
zu vermeinden
• Verbieten Sie Kindern mit dem Gerät zu spielen. Niemals auf
dem Gerät sitzen oder sich an die schwingende Tür hängen.
• Benutzen Sie keine scharfkantigen Metallgegenstände um Eis
au s dem Gefrierfach zu entfernen . Diese k ö nn t en d en
Kühlschrank irreparabel beschädigen. Bitte benutzen Sie den
hierfür vorgesehenen Plastikschaber.
• Den Kühlschrank nicht mit nassen Händen an das Stromnetz
anschließen.
DE - 19 -
• Stellen sie keine mit Gasen gefüllte Flaschen , Dosen oder Behältnisse
in das Gef rier fac h, da diese während des Gefrier vorganges
explodieren könnten.
• Hochprozentige Alkoholika müssen gut verschlossen, senkrecht im
Kühlteil aufbewahrt werden.
• Niemals, vor allem nicht mit n assen Händen die Innenwände des Gefrierfaches
berühren. Verbrennungsgefahr!
• Das aus dem Gefrierfach entfernte Eis nicht essen!
Installation und Anschluss des Gerätes
• Der Kühlschrank wird am Stromnetz mit 220-240V~ 50 Hz angeschlossen.
• Bevor Sie das Gerät an das Stromnetz anschließen, überprüfen Sie die Stromart und
Spannung am Aufstellort mit den Angaben auf dem Typenschild des Gerätes.
• Nach dem Transport Gerät 3 Stu nden stehen lassen, erst dann über eine
vorschriftsmäßige geerdete Schutzkontakt-Steckdose anschließen. Ist die Steckdose
nicht geerdet, muss das Gerät von einem Elektriker angeschlossen werden.
• Der Hersteller ist nicht für die unsachgemäße Installation oder Bedienerfehler
verantwortlich.
• Der Kühlschrank darf weder der direkten Sonneneinstrahlung,
noch anderen thermischen Einflüssen ausgesetzt werden.
• Das Gerät darf nicht im Freien stehen.
• Stellen sie das Gerät nicht in die Nähe von W ärmequellen. Ist
dies unvermeidbar, halten Sie den Mindestabstand von 50 cm
zu Heizkörpern, Gas- oder Kohleöfen und 5 cm zu Elektroöfen
ein. Die notwendige Luftzirk ulation darf nicht beeinträchtigt
werden.
• Der Abstand zur Decke muß mind. 15 cm betragen.
• Stellen Sie keine schweren oder viele Gegenstände auf das
Gerät.
• Stellen Sie das Gerät neben einen anderen Kühlschrank oder
Gefriertruhe, muss zur Vermeidung einer Kondensation ein
Abstand von 2 cm eingehalten werden.
• Montieren Sie die Wandabstandhalter am oberen Teil des Kondensators (Riffelblech
auf der Rückseite). Diese vermeiden ein Anlehnen des Gerätes an der Wand.
• Der Kühlschrank ist stabil und waagerecht auf den Boden zu stellen. Durch die zwei
vorderen verstellbaren Füße kann das Gerät waagerecht ausgerichtet werden.
• Zur regelmäßigen Reinigung eignet sich lauwarmes Wasser mit einem leicht
desinfizierendem Reinigungsmittel (Handspülmittel).Das Gehäuse und Zubehör
separat mit Seifenwasser reinigen. Die getrockneten Zubehörteile wieder in das
Gerät einsetzen.
Vor Inbetriebnahme
• Bevor Sie das Gerät anschließen, sollten Sie das Gerät nach dem
Transp ort 3 Stunden stehen lassen. Dies ist wichtig fü r eine
einwandfreie Funktion.
• Nach der ersten Inbetriebnahme kann ein Geruch entstehen. Sobald die Kühlung
beginnt, verschwindet der Geruch.
DE - 20 -
TEIL 2.
FUNKTIONEN
Temperaturregelung
• Die Temperatur im Kühlteil und Gefrierfach wird durch ein Thermostat automatisch
konstant gehalten. Die Regelung der Temperatur erfolgt durch einen Drehschalter.
Wenn der Handgriff in der rechten Endposition /Po sition 5/ steht, sind die
Temperaturen relativ niedrig ; wenn der Handgriff in der linken Endposition /Position
1/ steht, sind die Temperaturen relativ hoch. Die übrigen Positionen dazwischen
entsprechen den Zwischenstufen der Kühlung. Die Position «0» besagt, Thermostat
ist ausgeschaltet , es kommt zu keiner Kühlung.
• Für kurzweilige Lagerung von Lebensmitteln im Gefrierfach, können Sie den Schalter
zwischen die minimale bis mittlere Position stellen. Bei langfristiger Lagerung stellen
Sie den Schalter auf mittlere Position.(3-4)
• Beachten Sie, daß die Temperatur im Kühlfach von vielen Faktoren abhängig ist: z.B.
der Thermostatposition, der Umgebungstemperatur, häufigem Türöffnen, sowie der
Menge und Beschaffenheit der zu frierenden und lagernden Lebensmittel. Je nach
Bedarf können Sie die Temperatureinstellung ändern.
Wenn der Super-Schalter verfügbar ist
Um die richtige Funktion bei
Umgebung stemperaturen unter 20°C
sicherzustellen, drücken Sie die Taste neben dem
Thermostat. Drücken Sie nochmals diese Taste,
wenn die Temperatur darüber liegt (über 20°C).
DE - 21 -
Loading...
