Model No:
DP19647
Owner’s Manual
Table of Contents . . . . . . . . . . . 5
Frequent Asked
Questions (FAQ) . . . . . . . . . . . 45
© 2007 Sanyo Manufacturing Corporation
If you need additional assistance?
Call toll free 1.800.877.5032
We can Help!
Welcome to the World of Sanyo
Thank you for purchasing this Sanyo High-Definition Digital Television. You made
an excellent choice for Performance, Reliability, Features, Value, and Styling.
Important Information
Before installing and operating this DTV, read this manual thoroughly. This DTV
provides many convenient features and functions. Operating the DTV properly
enables you to manage those features and maintain it in good condition for many
years to come.
If your DTV seems to operate improperly, read this manual again, check
operations and cable connections and try the solutions in the “Helpful Hints”
sections of this manual.
If the problem still persists, please call
1-800-877-5032. We can help!
TO THE OWNER
2
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.
THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING
AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THIS UNIT.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION: PLEASE ADHERE TO ALL WARNINGS ON THE PRODUCT AND IN THE OPERATING INSTRUCTIONS.
BEFORE OPERATING THE PRODUCT, PLEASE READ ALL OF THE SAFETY AND OPERATING INSTRUCTIONS.
RETAIN THIS LITERATURE FOR REFERENCE.
Follow all instructions...
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install
in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has
two blades with one wider than the other. A
grounding-type plug has two blades and a third
grounding prong. The wide blade or the third
prong are provided for your safety. If the provided plug does not fit fully into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11. Only use attachments/accessories specified by
the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as powersupply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not operate normally, or has been
dropped.
3
(CONTINUED ON NEXT PAGE.)
4
15. If an outside antenna is connected to the television equipment, be sure the antenna system is
grounded so as to provide some protection
against voltage surges and built up static
charges. In the U.S. Selection 810-21 of the
National Electrical Code provides information
with respect to proper grounding of the mast
and supporting structure, grounding of the leadin wire to an antenna discharge unit, size of
grounding conductors, location of antenna discharge unit, connection to grounding electrodes,
and requirements for the grounding electrodes.
16. An outside antenna system should not be
located in the vicinity of overhead power lines or
other electrical light or power circuits, or where
it can fall into such power lines or circuits. When
installing an outside antenna system, extreme
care should be taken to keep from touching such
power lines or circuits as contact with them
might be fatal.
17. Wall or Ceiling Mounting—The product should
be mounted to a wall or ceiling only as recommended by the manufacturer.
18. "Apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such
as vases, shall be placed on the apparatus."
19. When the MAINS plug is used as the disconnect
device, the disconnect device shall remain
readily operable.
CAUTION: PLEASE ADHERE TO ALL WARNINGS ON THE PRODUCT AND IN THE OPERATING INSTRUCTIONS.
BEFORE OPERATING THE PRODUCT, PLEASE READ ALL OF THE SAFETY AND OPERATING INSTRUCTIONS.
RETAIN THIS LITERATURE FOR REFERENCE.
Follow all instructions...
IMPORTANT SAFETY INSTRUCTIONS
EXAMPLE OF ANTENNA GROUNDING ACCORDING TO NATIONAL
ELECTRICAL CODE,
ANSI/NFPA 70
“Note to CATV system installer:
This reminder is provided to call the CATV system installer’s attention to Article
820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that
the cable ground shall be connected to the grounding system of the building, as close to the point
of cable entry as practical.”
TO THE OWNER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . 3 ~ 4
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
DTV BACK LEFT SIDE PANEL—JACKS LOCATIONS
& FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
DTV BACK RIGHT SIDE PANEL—JACKS LOCATIONS
& FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 ~ 10
OPTIONAL FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . 11
GLOSSARY OF CABLES . . . . . . . . . . . . . . . . . . . . . . . . 12
CHOOSE YOUR CONNECTION . . . . . . . . . . . . . . . . . . . . 13
Installing two “AA” Batteries . . . . . . . . . . . . . . . . . . . . . . . 14
Initial Signal Connections Integrated Digital (DTV) /
Analog (RF) Antenna Connection . . . . . . . . . . . . . . . . . . . 14
All Channel Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
VIDEO2 / VIDEO3 Component Jacks
OPTION 1: Connect a Set-Top (STB) . . . . . . . . . . . . . . . . . 16
Helpful Hints for Video2/3 connections . . . . . . . . . . . 14
OPTION 2: Connect a DVD Player . . . . . . . . . . . . . . . . . . 13
Helpful Hints for Video2/3 connections . . . . . . . . . . . 14
OPTION 3: Connect a Game System . . . . . . . . . . . . . . . . . 14
Helpful Hints for Video2/3 connections . . . . . . . . . . . 14
VIDEO1 COMPOSITE JACKS
OPTION 1: Connect Analog Cable, Cable Box, VCR,
and an Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Helpful Hints for Video1 connections . . . . . . . . . . . . . 15
OPTION 2: Connect Analog Cable, VCR, and an Antenna 16
Helpful Hints for Video1 connections . . . . . . . . . . . . . 16
OPTION 3: Connect a DVD Player . . . . . . . . . . . . . . . . . . . 17
Helpful Hints for Video1 connections . . . . . . . . . . . . . 17
Connecting an AV Receiver . . . . . . . . . . . . . . . . . . . . . . . 18
Helpful Hints for Digital Audio Out connections . . . . . 18
Connecting a Stereo Amplifier . . . . . . . . . . . . . . . . . . . . . . 19
Helpful Hints for Analog Audio Out connections . . . . . 19
Remote Control Keys (functions) . . . . . . . . . . . . . . . 24 ~ 27
Helpful Hints for Remote Control . . . . . . . . . . . . . . . . 27
How to Operate the On-Screen Menu . . . . . . . . . . . . . . . . 28
Menu Navigation Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
All Channel Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Digital Cable Search (Optional) . . . . . . . . . . . . . . . . . . . . . 30
Helpful Hints for Digital Cable Search . . . . . . . . . . . . . 30
Digital Add-On Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Helpful Hints for Digital Add-On Search . . . . . . . . . . . 31
Analog Antenna Signal (Optional) . . . . . . . . . . . . . . . . . . . 32
Helpful Hints for Analog Antenna Signal . . . . . . . . . . . 32
Channel Scan Memory: Deleting Channels . . . . . . . . . . . . 33
Helpful Hints for Channel Scan Memory . . . . . . . . . . 33
Channel Scan Memory: Adding Channels . . . . . . . . . . . . . 34
Helpful Hints for Channel Scan Memory . . . . . . . . . . 34
Digital Caption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Changing the Look of Digital Captioning . . . . . . . . . . . 35
To View Captions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Helpful Hints for Digital Caption . . . . . . . . . . . . . . . . . 36
V-Guide (Parental Control) . . . . . . . . . . . . . . . . . . . . . . . . .37
To Block MPAA Movie or TV Programs . . . . . . . . . . . . 37
To Setup V-Guide Ratings . . . . . . . . . . . . . . . . . . . . . . 37
On-Screen View of Blocked TV program . . . . . . . . . . . 38
To Temporarily Unblock MPAA Movie or TV Rating . . 38
To Unblock All MPAA Movie or All TV Rating . . . . . . . 38
TV Ratings (Age and Content-Based)
Symbol Explanation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
MPAA Movie Ratings (Age-Based)
Symbol Explanation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Picture/Sound Adjustment . . . . . . . . . . . . . . . . . . . . 40 ~ 41
Helpful Hints for Picture/Sound . . . . . . . . . . . . . . . . . 41
Menu Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Energy (Power) Saver . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
GLOSSARY OF TERMS . . . . . . . . . . . . . . . . . . . . . . . . . 44
FAQ (FREQUENTLY ASKED QUESTIONS) . . . . . . . . . . . . . 45
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
CONTENTS
5
DIGITAL AV CONNECTIONS
GETTING STARTED (REQUIRED INITIAL SETUP) . . . . . . . . 14
ANALOG AV CONNECTIONS
AUDIO CONNECTIONS
MENU OPTIONS
DTV ADJUSTMENT AND SETUP
USING THE REMOTE CONTROL
6
19" Flat Screen
Tilt Stand (Detachable)
Trilingual Menu Options (English, Spanish, or
French)
Integrated Digital/Analog Tuner
Energy Saver Mode (Backlight)
Automatic Channel Search
3-D Y/C Comb Filter
V-Chip for Movies and TV guidelines rating
limits (parental control)
Closed-Captioning: Analog EIA-608B
Digital EIA-708B
Audio Modes: Digital—Main and Sub
Analog—Stereo, Mono,
and SAP
Front speakers (two): 5 x 9 cm
Factory preset adjustments for picture/sound:
Auto, Manual with Tone Control
Picture Shape: PIX1 ~ PIX4
Audio Format: Dolby
®
Digital for ATSC (DTV)
and Analog for NTSC
Receivable Formats: Digital Tuner for ATSC
terrestrial broadcasts and nonscrambled
(ClearQAM) cable channels.
NTSC analog tuner for VHF/UHF or CATV
Channel Scan Memory
Receives 181 Analog Channels (VHF 2~13 and
UHF 14~69; Cable 14~125); and 99 Digital
Channels
XDS (Extended Data Services) displays station
call letters, title of show, and ratings when
broadcast
Sleep Timer (3 hours)
32-Key Remote Control
TERMINAL and CONNECTORS:
RF Antenna Input Jack: Digital and Analog
Component Video (Y-Pb-Pr) Input (Two Sets)
S-Video Input
Rear Composite AV Input Jacks
Coaxial Digital Audio Out
Fixed Audio Out (Left/Right)
FEATURES
7
SPECIFICATIONS
SCREEN SIZE: 19" Flat Screen
SCANNING FORMAT: 720p (All Signals are
Converted to 720p)
RESOLUTION (PANEL): 1440 x 900 (WXGA)
RF ANTENNA INPUT: 75 ohm—Digital/Analog
POWER REQUIREMENT: Source: AC 120V, 60Hz
POWER CONSUMPTION: 50 Watts (Average)
SOUND: Two Speakers, size: 5 x 9 cm
MOUNTING BRACKET: Vesa Standard 100 x 100
AMPLIFIER: Built-in with 2.0W/ch
JACKS / CONNECTORS:
VIDEO1 Composite Video and Audio R/L
S-Video
VIDEO2 Component (Y/ Pb / Pr) with
Audio R/L Input
VIDEO3 Component (Y/ Pb / Pr) with
Audio R/L Input
Digital Audio Output: Dolby® Digital (Coaxial Cable)
Analog Audio Output: Audio R/L
SIZE AND WEIGHT (APPROXIMATELY):
Horizontal Dim. (Width): 18.9 in. (480mm)
Vertical Dim. (Height): 15.1 in. (383mm)
Depth Dim. (Thickness): 7.2 in. (184mm)
Weight: 10.8 (lbs.) 4.9 (Kg)
Specifications are subject to change without notice.
CAUTION: FCC Regulations state that improper modifications or un-
authorized changes to this unit may void the user’s authority
to operate the unit.
This symbol on the nameplate means the product is
Listed by Underwriters’ Laboratories Inc. It is designed
and manufactured to meet rigid U.L. safety standards
against risk of fire, casualty and electrical hazards.
Trademarks Information:
Manufactured under license from Dolby Laboratories.
“Dolby” is a trademark of Dolby Laboratories.
“As an ENERGY STA R®Partner, Sanyo
Manufacturing Corporation has determined
that this product meets the ENERGY STA R
®
guidelines for energy efficiency.”
with a double “Z” is a registered trademark of
Sanyo Manufacturing Corporation.
8
DTV BACK— LEFT SIDE PANEL
These keys operate exactly like the Remote Control
keys. (Go to page 24, for more detail information, if
needed.)
POWER
VOLUME
+ –
CHANNEL
9
DTV BACK— RIGHT SIDE PANEL
S-Video Input (VIDEO1)—To enhance video
detail use the S-Video jack instead of the Video
jack, if available on your external equipment.
(S-Video connection will override a connection
to the Video input jack [VIDEO1]).
See PAGES
19 and 21 for S-Video connection.
Component Video Input (VIDEO2 or
VIDEO3)—Connect digital video equipment to
the Y (green), Pb (blue), Pr (red) and Audio L/R
jacks. These jacks will automatically detect the
type of signal being received.
See PAGES 16,
17, and 18 for Component jack connections.
Analog / Digital Antenna Input—Connect an
RF antenna or Analog Cable system to this
jack.
See PAGE 14 for Signal connections.
(CONTINUED ON NEXT PAGE.)
Analog Audio Out (L/R) Jacks—Connect
external audio equipment here.
See PAGE 23
for Audio Out jack connections.
10
DTV BACK— RIGHT SIDE PANEL
(Continued)
Digital Audio Output—Use a Phono-Type
Coaxial Digital Audio Out Cable to connect
Digital Audio Output to an advanced stereo
home theater system equipped with Dolby
®
Digital 5.1.
See PAGE 22 for Digital Audio
Out jack connection.
Audio/Video Input (VIDEO1)—Connect
analog video equipment here.
See PAGES 19,
20, and 21 for AV VIDEO1 jack connection.
Note: S-Video connection overrides the (Video1) com-
posite video connection.
11
OPTIONAL FEATURES
WALL MOUNTING
Use the threaded inserts on the back of your DTV to
secure it using a wall mounting kit. (VESA standard interface 100 x 100.)
Note: Wall Mounting kit is not supplied.
LCD Mounting screws measurements:
M4 Diameter, Length—10mm (maximum).
DETACHING THE TV TILT STAND
Tools Needed: Phillips screwdriver
Important Note: Place DTV face down on a padded
or cushioned surface to protect the screen and finish.
1
Remove two (2) screws from the metal bracket.
CAUTION: Hold the stand firmly as you remove the
last screw.
2
Carefully remove the DTV stand.
DTV BACK VIEW
USING THE DETACHABLE TV TILT
STAND
To change the viewing angle of your TV, position your
hand on the top and hold the stand firmly, then tilt the
LCD screen forward or backward. CAUTION: Do not
position hand under the screen while tilting the TV
forward.
75 Ohm Coaxial Cable with F-Connector—
Used to connect a signal to your digital or
Analog RF Antenna In terminal.
Coaxial Digital Audio—Use this cable to
connect the DTV‘s digital audio output to a
multichannel audio receiver.
S-Video Cable—This cable provides separate
luminance and color signals for higher resolution and better picture quality. Use this cable
instead of the regular composite video cable
(RCA type), when available.
NOTE: None of these cables are supplied with this
DTV.
Audio Cables—Provides analog left/right
audio for your external equipment
connections.
Component: Y, Pb, Pr—Use these cables to
connect your component equipment. This
connection provides the best picture, but does
not include sound. (Cable colors: Y = green, Pb
= blue, and Pr = red.)
Composite Audio/Video (RCA type)—Use
these cables for standard analog audio/video
connections. Normally cables are color coded:
Yellow for Video, White for (L) Audio, and Red
for (R) Audio.
12
GLOSSARY OF CABLES
13
CHOOSE YOUR CONNECTION
Digital Signal Compatible External Cables Needed Go to
Connections Equipment
(Not Supplied)
Page
16
17
18
This DTV is designed to handle several different connections making it compatible with Digital and Analog
devices.
In order to receive the best performance from your DTV,
choose your connection using this chart; then go to the
specified page for detailed instructions.
COMPONENT
(Y, Pb, Pr) IN
Will accept HDTV,
EDTV, or SDTV Video
content.
(Requires separate
audio connections.)
COMPONENT VIDEO
CABLE
COMPOSITE VIDEO
OR
S-VIDEO IN
19
20
21
DIGITAL AUDIO
OUT
(Only available when
received as part of the
Digital RF signal displayed on-screen.)
COAXIAL DIGITAL
CABLE
22
ANALOG AUDIO
OUT JACKS
23
AUDIO CABLE
S-VIDEO CABLE
Analog Signal Compatible External Cables Needed Go to
Connections Equipment
(Not Supplied)
Page
COMPOSITE VIDEO
CABLE
AV RECEIVER
VCR
STEREO AMPLIFIER
SYSTEM
LEFT / RIGHT
ANALOG AUDIO IN
AUDIO CABLE
DIGITAL SET-TOP BOX
or DVD PLAYER
VIDEO GAME
VIDEO GAME
DVD PLAYER
1
Install batteries in remote control (2AA, not included).
14
2
Connect Signal to the DTV’s Integrated Analog / Digital
75 ohm Antenna Input terminal.
GETTING STARTED (REQUIRED INITIAL SETUP)
PRECAUTIONS
To ensure safe operation, please observe the following
precautions:
Replace both batteries at the same time. Do not use a new
battery with a used battery.
Risk of explosion, if battery is replaced by an incorrect type.
Do not expose the Remote Control Unit to moisture or heat.
Remove the batteries if the Remote Control will not be used for
a month or more. Discharged batteries may leak and damage
the unit.
RF ANTENNA
CABLE
OR
CABLE BOX OR SATELLITE BOX
OR
ANALOG / DIGITAL ANTENNA IN
THE TUNER IN THIS DTV CAN RECEIVE:
1. Digital and / or Analog Off-Air Signals from an RF
antenna.
OR
2. Analog or ClearQAM cable channels.
Note:You must search for ClearQAM channels using
the “Digital Cable Search” menu option.
OR
3. The output from a VCR or cable box.
Digital signals from a Set-top (STB) Box should be
received through the Component jacks.
This DTV can receive ANY unscrambled RF signal
being broadcast.
(CONTINUED ON NEXT PAGE.)
Match the “+” and “–”
signs on the batteries with
marks inside the remote
control.
15
5
Perform “All Channel Search.” The All Channel
Search will search for off-air digital and analog channels, and analog cable channels. The DTV can
receive cable or off-air channels, but not at the same
time. If after two searches the DTV still fails to
detect any channels, the DTV will tune to Video1.
ANALOG CHANNELS
Note: If
EXIT
is pressed, the DTV will skip
Channel Search and tune to Video1
without storing any channels in the
Channel Map databases.
DIGITAL CHANNELS
3
Plug AC Power Cord (supplied) into an
electrical outlet as shown here.
To 120 V AC outlet.
GETTING STARTED (REQUIRED INITIAL SETUP)
Continued
INITIAL ON-SCREEN ALL CHANNEL SEARCH
4
Press the POWER key.
(Follow on-screen instructions).
16
SET-TOP BOX
(HD Satellite, HD Cable, etc.)
1
Connect a Component Cable to the VIDEO2 Green,
Blue, and Red video jacks.
2
Connect an Audio Cable to the matching VIDEO2
White and Red audio jacks.
3
Press INPUT to select Video 2 to view the program.
Note: VIDEO2 and VIDEO3 jacks have identical functions.
Compatible video devices can be connected to either
or both set of jacks.
VIDEO2 & 3 COMPONENT JACKS:
Connection Option 1
GREEN, BLUE,
RED JACKS
CONNECTING A SET-TOP (STB)
DTV VIDEO2
AUDIO L/R
JACKS
OPERATING TIP:
Refer to the owner’s manuals and user’s guides
that came with your external equipment for
connection options.
HELP HINTS (PROBLEMS/SOLUTIONS)
SYMPTOM CHECK THESE CONDITIONS TRY THESE SOLUTIONS
“No Signal” will appear randomly
on the screen when no signal is
detected at the video jack.
Check Audio/Video connections.
Check external equipment
connections.
Check external equipment
settings.
Press the INPUT key.
Switch on external equipment.
If you continue to experience problems, please call toll free
1-800-877-5032. We can Help!
REMOTE CONTROL
INPUT
1
Connect a Component Cable to the VIDEO3 Green,
Blue, and Red video jacks.
2
Connect an Audio Cable to the matching VIDEO3
White and Red audio jacks.
3
Press INPUT to select Video 3 to view the program.
Note: VIDEO2 and VIDEO3 jacks have identical functions.
Compatible video devices can be connected to either
or both set of jacks.
CONNECTING A DVD PLAYER
DVD PLAYER
(HD Satellite, HD Cable, etc.)
GREEN, BLUE,
RED JACKS
DTV VIDEO3
AUDIO L/R
JACKS
17
OPERATING TIP:
Refer to the owner’s manuals and user’s
guides that came with your external equipment
for connection options.
VIDEO2 & 3 COMPONENT JACKS:
Connection Option 2
HELP HINTS (PROBLEMS/SOLUTIONS)
SYMPTOM CHECK THESE CONDITIONS TRY THESE SOLUTIONS
“No Signal” will appear randomly
on the screen when no signal is
detected at the video jack.
Check Audio/Video connections.
Check external equipment
connections.
Check external equipment
settings.
Press the INPUT key.
Switch on external equipment.
If you continue to experience problems, please call toll free
1-800-877-5032. We can Help!
REMOTE CONTROL
INPUT
18
VIDEO2 & 3 COMPONENT JACKS:
Connection Option 3
1
Connect your game’s component HD AV cable
video connectors to a set of Green, Blue, and Red
video jacks (VIDEO2 / VIDEO3 ).
2
Connect your game’s component HD AV Cable
Audio connectors to the matching White and Red
audio jacks.
3
Press INPUT to select Video 2 or Video 3 to view
the game.
CONNECTING A GAME SYSTEM
GAME
SYSTEM
GREEN, BLUE,
RED JACKS
DTV VIDEO2
AUDIO L/R
JACKS
OPERATING TIPS:
Press the INPUT key after connecting cables to
access the VIDEO2 or VIDEO3 input. There is NO
need to tune to a blank channel.
VIDEO2 and VIDEO3 jacks have identical functions.
Compatible video devices can be connected to either
or both jacks.
Refer to the owner’s manuals and user’s guides that
came with your external equipment for connection
options.
SYMPTOM CHECK THESE CONDITIONS TRY THESE SOLUTIONS
“No Signal” will appear randomly
on the screen when no signal is
detected at the video jack.
Check Audio/Video connections.
Check external equipment
connections.
Check external equipment
settings.
Press the INPUT key.
Switch on external equipment.
If you continue to experience problems, please call toll free
1-800-877-5032. We can Help!
HELP HINTS (PROBLEMS/SOLUTIONS)
REMOTE CONTROL
INPUT
19
CONNECTING ANALOG CABLE, CABLE BOX, VCR, AND AN ANTENNA TO
THE DTV
VIDEO1 COMPOSITE (ANALOG) JACKS:
Connection Option 1
VCR
1
Connect Analog Cable Box “Antenna Out” to the
VCR “Antenna In.”
2
Connect the VCR AV out jacks to VIDEO1 Yellow,
White, and Red jacks.
33
OPTIONAL FOR A SUPER VHS VCR
Connect VCR to the DTV S-Video In Jack. Disconnect the VIDEO1 yellow connector
Note: S-Video jack connection overrides a Video jack connection
(VIDEO1).
4
Connect an Antenna to the DTV Analog / Digital
ANT. terminal.
5
Tune VCR to channel 3 or 4 to match your Cable
Box.
6
Press INPUT to select Video 1 to watch Analog
Cable channels OR to TV channels to watch
Antenna channels.
7
Select Cable channels with the cable box remote
control. Select Antenna channels with the DTV
remote control.
S-VIDEO JACK
(Optional)
IMPORTANT FACTS:
Composite jacks offer
only 480i (SDTV)
resolution.
“No Signal” will appear randomly
on the screen when no signal is
detected at the video jack.
Check Audio/ Video connections.
Check external equipment
connections.
Check external equipment
settings.
Press the INPUT key.
Switch on external equipment.
SYMPTOM CHECK THESE CONDITIONS TRY THESE SOLUTIONS
If you continue to experience problems, please call toll free
1-800-877-5032. We can Help!
CABLE BOX
DTV ANALOG/DIGITAL
ANTENNA IN
OPERATING TIP:
Refer to the owner’s manuals and user’s
guides that came with your external
equipment for connection options.
CABLE SYSTEM
(Service provider)
HELP HINTS (PROBLEMS/SOLUTIONS)
DTV VIDEO1
REMOTE CONTROL
INPUT
YELLOW,
WHITE, & RED
JACKS
VCR
20
CONNECTING ANALOG CABLE, VCR, AND AN ANTENNA TO THE DTV
VIDEO1 COMPOSITE (ANALOG) JACKS:
Connection Option 2
VCR
1
Connect Analog Cable system to the VCR
“Antenna In.”
2
Connect the VCR AV out jacks to VIDEO1 Yellow,
White, and Red jacks.
3
Connect an Antenna to the DTV Analog / Digital
Antenna In terminal.
4
Press INPUT to select Video 1 to watch Analog
Cable channels OR to TV channels to watch
Antenna channels.
5
Select channels with the VCR’s remote control.
Select Antenna channels with the DTV remote
control.
IMPORTANT FACTS:
Composite jacks offer only
480i (SDTV ) resolution.
YELLOW,
WHITE, & RED,
JACKS
“No Signal” will appear randomly
on the screen when no signal is
detected at the video jack.
Check Audio/ Video connections.
Check external equipment
connections.
Check external equipment
settings.
Press the INPUT key.
Switch on external equipment.
SYMPTOM CHECK THESE CONDITIONS TRY THESE SOLUTIONS
If you continue to experience problems, please call toll free
1-800-877-5032. We can Help!
DTV VIDEO1
DTV ANALOG/DIGITAL
ANTENNA IN
CABLE SYSTEM
(Service provider)
OPERATING TIP:
Refer to the owner’s manuals and
user’s guides that came with your
external equipment for connection
options.
REMOTE CONTROL
INPUT
HELP HINTS (PROBLEMS/SOLUTIONS)
21
CONNECTING A DVD PLAYER TO THE DTV
DVD PLAYER
DTV AV INPUT JACKS
S-VIDEO JACK
AUDIO
L/R
JACKS
VIDEO1 COMPOSITE (ANALOG) JACKS:
Connection Option 3
“No Signal” will appear randomly
on the screen when no signal is
detected at the video jack.
Check Audio/ Video connections.
Check external equipment
connections.
Check external equipment
settings.
Press the INPUT key.
Switch on external equipment.
.
VIDEO1 jack connection
SYMPTOM CHECK THESE CONDITIONS TRY THESE SOLUTIONS
If you continue to experience problems, please call toll free
1-800-877-5032. We can Help!
HELP HINTS (PROBLEMS/SOLUTIONS)
OPERATING TIP:
Refer to the owner’s
manuals and user’s
guides that came with
your external equipment for connection
options.
DTV VIDEO1
REMOTE CONTROL
INPUT
1
Connect DVD to the TV S-Video In Jack.
2
Connect an Audio cable to the VIDEO1 White and
Red AV jacks.
3
Press INPUT to select Video1 to view the DVD
program.
22
CONNECTING AN AV RECEIVER TO THE DTV
DTV AUDIO OUT (DIGITAL) JACK
BACK VIEW OF DTV
COAXIAL CABLE
AV RECEIVER
No Sound or Poor Sound
Check external equipment
connections.
Switch on external equipment.
HELP HINTS (PROBLEMS/SOLUTIONS)
SYMPTOM
CHECK THESE CONDITIONS TRY THESE SOLUTIONS
If you continue to experience problems, please call toll free
1-800-877-5032. We can Help!
OPERATING TIP:
Refer to the owner’s
manual that came with
your external equipment for connection
options.
AUDIO OUT
[For Stereo
Sound]
1
Connect a Coaxial Digital Audio cable from the
DTV Digital Audio Output jack to a Coaxial
Digital Audio In jack on an AV Receiver.
2
Connect an Audio cable from the DTV Audio
Out jacks to Audio In jacks on the AV
Receiver.
Note: Dolby® Digital 5.1 audio is available at the Digital
Audio Output only when received as part of a
Digital Antenna signal.
23
CONNECTING A STEREO AMPLIFIER TO THE DTV
STEREO AMPLIFIER
BACK VIEW OF DTV
1
Connect a Stereo Amplifier to the TV Audio
Out jacks as shown.
Note:
Do not
connect external speakers directly
to the DTV.
DTV AUDIO OUT (ANALOG) JACKS
HELP HINTS (PROBLEMS/SOLUTIONS)
SYMPTOM CHECK THESE CONDITIONS TRY THESE SOLUTIONS
OPERATING TIP:
Refer to the owner’s
manual that came with
your external equipment for connection
options.
No Sound or Poor Sound
Check external equipment
connections.
Switch on external equipment.
If you continue to experience problems, please call toll free
1-800-877-5032. We can Help!
24
REMOTE CONTROL OPERATION
Input Key—Press to select the program source to
watch: Analog Channels, Digital Channels, Video 1,
Video 2, or Video 3.
Volume Keys—Press VOL – + to adjust.
Number Keys—Press two keys to select a channel.
Example: Press 0 then 6 to select channel 6.
(See #13.)
Note: Numerical direct channel selection works for either
Analog or Digital channels in memory but not both at
the same time.
Channel Scanning (CH ) Keys—Press to scan
through the channels in memory.
Menu Navigational Keys:
Menu—Press to display on-screen menu.
Cursor (up) (down) keys—Press these keys to
move the cursor up and down within the menu.
Cursor < (left) > (right) keys—Press these keys to
move the cursor left and right within the menu.
Enter Key—Press to select an option from the menu
system, when required.
Exit Key—Press to exit from the menu system.
PIX Shape Key—Use to change the video display
format. Available options depend on signal received
and the broadcast’s aspect ratio.
Note: Cannot display picture on a full screen.
Check Aspect Ratio of broadcast. Then press the
PIX Shape key to change setting.
(CONTINUED ON NEXT PAGE.)
POINT
TOWARDS TV
25
Reset Key—Press this key twice to restore factory
settings. The TV will automatically start Channel
Search and clear all customized settings.
Note: Channel scan memory database list of digital
and analog channels will be replaced. If desired, per-
sonal settings can be made again using the menu
options.
Audio Key—Press to select the desired audio mode
(if available as part of the broadcast signal).
REMOTE CONTROL OPERATION
(CONTINUED ON NEXT PAGE.)
DIGITAL AUDIO MODE SELECTIONS
ANALOG AUDIO MODE SELECTIONS
POINT TOWARDS
TV
26
REMOTE CONTROL OPERATION
(Continued)
POINT
TOWARDS TV
Mute Key—Press once to mute the sound.
Press again to restore the sound.
Recall Key—Press to switch between the last
two channels selected. The Recall key cannot
toggle between a Digital channel and an Analog
channel.
Sleep Key—Press this key then the “0” key to
set the Sleep Off Timer. Time can be set in 30minute increments up to 3 hours.
Note: The Sleep Timer cancels when the TV is turned
off or if a power failure occurs.
11
11
12
Caption Key—Captioning is text information
transmitted along with the picture and sound so it
can be displayed on the TV screen.
Press CAPTION to select mode options: Digital
CC1 ~ Digital CC6, or Analog CC1 ~ CC4, OFF, or
QuikCap. (QuikCap switches captions on and off
with the Mute function.) Digital Captions can be
changed using the menu settings.
12
27
REMOTE CONTROL OPERATION
(Continued)
1– – Key—For Analog Cable channels above
100, press this key, then press the other two
numbers.
Info Key—Press to display the Digital and
Analog Full Banner information. The banner
contains the following: program title, station
ID, program rating, signal strength, channel
number, tuner ID, and audio information.
14
13
13
14
Remote Control will NOT operate
the TV.
Check batteries.
Check if TV is plugged in
Replace batteries.
Aim remote control at front of TV.
HELP HINTS (PROBLEMS/SOLUTIONS)
SYMPTOM CHECK THESE CONDITIONS TRY THESE SOLUTIONS
If you continue to experience problems, please call toll free
1-800-877-5032. We can Help!
DIGITAL INFO BANNER
ANALOG INFO BANNER
POINT
TOWARDS TV
DTV ADJUSTMENT AND SETUP
MENU NAVIGATION MAP
(Composite view)
MAIN SUB MENUS
All Channel Search
Digital Cable Search
Digital Add-on Search
No
Yes
No
Yes
No
Yes
Analog Antenna Signal
Cable
VHF/UHF
Channel Scan Memory
Delete?
Add?
Digital Caption
Font Size
Font Style
Background Color
Foreground Color
Background Opacity
Foreground Opacity
V-Guide
Off
On
Picture/Sound
Auto
Manual
Menu Language
English
Español
Français
Color
Tint
Contrast
Brightness
Sharpness
Tone
Adjust
HOW TO OPERATE THE MENU
1
Press the MENU key to display the Main menu.
2
Use the CURSOR keys to highlight menu
item.
3
Use the CURSOR < > keys to select or adjust
menu item.
4
Press ENTER to activate setting, if needed.
5
When you have finished making adjustments,
press the EXIT key to return to normal TV viewing.
Note: For menu items that have sub menus, follow
on-screen instructions to select and make
adjustments.
OPERATING TIPS:
Some Menu options are specific to Digital or
Analog signals. To access these options, you
must first tune the TV to a digital or Analog
channel Use the INPUT key on the remote to
step through the input options. (See INPUT key
on page 24.)
“Not Available” will be displayed on the screen
if an unavailable menu option is selected.
REMOTE CONTROL NAVIGATION KEYS
MENU options:
Along with the on-screen instructions,
each menu feature is explained in
detail on the following pages.
Energy Saver
Off
Low
High
MENU
EXIT
ENTER and CURSOR
29
MENU OPTION—
ALL CHANNEL SEARCH
1
Press the MENU key to display the Main menu.
2
Use the CURSOR keys to highlight the All
Channel Search. Press ENTER.
3
Use the CURSOR key to select Yes. Press ENTER.
The All Channel Search will search for off-air digital and
analog channels, and analog cable channels. The DTV can
receive cable or off-air channels, but not at the same
time. If after two searches the DTV still fails to detect any
channels, the DTV will tune to Video1.
OPERATING TIPS:
DTV will select the correct Antenna
mode for the type of signal connected
automatically.
If you move the DTV to a new location, press
the RESET key twice after connecting the
signal and turning on the DTV.
SEARCHING FOR DIGITAL CHANNELS
SEARCHING FOR ANALOG CHANNELS
30
MENU OPTION—
DIGITAL CABLE SEARCH (Optional)
IMPORTANT FACTS:
This DTV maintains only one
database of digital channels. Therefore, when you
search for ClearQAM digital cable channels, the database of antenna digital channels will be deleted. You
will be able to receive only those ClearQAM channels
your cable company provides.
To restore the antenna digital channel database, reconnect the antenna and use the menu system to perform
an All Channel Search.
This DTV can receive unscrambled (ClearQAM) digital
cable channels, when available. However, not all cable
companies provide ClearQAM digital channels.
Digital Cable Search process will take about 10 minutes,
please be patient.
NOTE: After Channel Search is complete, the DTV will tune
to the lowest Digital Cable channel.
4
Use the CURSOR key to select Yes. Press
ENTER.
1
Tune to a Digital Channel.
2
Press the MENU key to display the Main menu.
3
Use the CURSOR keys to highlight the Digital
Cable Search. Press ENTER.
SYMPTOM CHECK THESE CONDITIONS TRY THESE SOLUTIONS
HELP HINTS (PROBLEMS/SOLUTIONS)
Cannot select menu option, DIGITAL
CABLE SEARCH.
Did the word Not Available
appear on-screen?
DTV must be connected to a digital
signal.
The DTV is in the Analog mode,
therefore, select a Digital Channel,
then press MENU.
If you continue to experience problems, please call toll free
1-800-877-5032. We can Help!
31
MENU OPTION—
DIGITAL ADD-ON SEARCH
To add new digital channels to the existing antenna
channel database, use Digital Add-on Search. Also, use
this feature to add channels when broadcast towers are
in multiple directions from your location.
For more info go to www.antennaweb.org and type in
your zip code to obtain specific tower and antenna information. Then adjust your antenna and repeat the Digital
Add-on Search.
4
Use the CURSOR key to select Yes. Press
ENTER.
1
Tune to a Digital Channel.
2
Press the MENU key to display the Main menu.
3
Use the CURSOR keys to highlight the Digital
Add-on Search. Press ENTER.
Cannot select menu option, DIGITAL
ADD-ON SEARCH.
Did the word Not Available
appear on-screen?
DTV must be connected to a digital
signal.
The DTV is in the Analog mode,
therefore, select a Digital Channel,
then press MENU.
SYMPTOM CHECK THESE CONDITIONS TRY THESE SOLUTIONS
If you continue to experience problems, please call toll free
1-800-877-5032. We can Help!
HELP HINTS (PROBLEMS/SOLUTIONS)
32
MENU OPTION—
ANALOG ANTENNA SIGNAL (Optional)
HELP HINTS (PROBLEMS/SOLUTIONS)
SYMPTOM CHECK THESE CONDITIONS TRY THESE SOLUTIONS
4
Use the CURSOR keys to choose Cable or
VHF/ UHF. Press ENTER.
Use this feature to switch between analog off-air
channels and analog cable channels.
1
Tune to an Analog Channel.
2
Press the MENU key to display the Main menu.
3
2
Use the CURSOR keys to highlight Analog
Antenna Signal. Press ENTER.
Cannot select menu option,
ANALOG ANTENNA SIGNAL.
NO Cable channels above
number 13
NO UHF; VHF Channels OK.
Did the word Not Available
appear on-screen?
Cable Channel Indicator “C”
should appear next to channel
number.
Cable Channel Indicator C should
not
appear next to the channel
number.
Press INPUT Key to select TV
Analog Channels.
Switch Menu option–Analog
Antenna Signal selection to
CABLE.
Switch Menu option–Analog
Antenna Signal to VHF/UHF.
If you continue to experience problems, please call toll free
1-800-877-5032. We can Help!
MENU OPTION—
CHANNEL SCAN MEMORY
Cannot select or scan some
channels.
Channels may be removed from
memory.
Check antenna connections.
NO digital signal being broadcast.
Weak Signal.
V-Guide is set to block program-
ming.
Select Channel Scan memory and
manually add channels or start an
“All Channel Search.”
Turn antenna, install signal
booster.
Set V-Guide to “Off” or press
RESET key to clear all settings and
restart channel search.
HELP HINTS (PROBLEMS/SOLUTIONS)
SYMPTOM CHECK THESE CONDITIONS TRY THESE SOLUTIONS
If you continue to experience problems, please call toll free
1-800-877-5032. We can Help!
3
Use the CHANNEL (CH ) keys or numerical
0 ~ 9 keys to select desired channel.
4
Press the ENTER key to delete the channel. The
display will change to “deleted.”
1
Press the MENU key to display the Main menu.
2
Use the CURSOR keys to highlight Channel
Scan Memory. Press ENTER.
DELETING ANALOG OR DIGITAL
CHANNELS FROM MEMORY
Channel Scan Memory is a list of active channels that
you can scan through using the Channel Scan CH (up)
CH (down) keys. This list can be customized by delet-
ing and/or adding channels.
After 3 seconds the TV screen will display
“Add?”
OPERATING TIPS:
When a digital channel is deleted, all of that
channel’s sub-channels are deleted as well.
Only previously deleted digital channels can be
added back to the Channel Scan Memory.
33
MENU OPTION—
CHANNEL SCAN MEMORY
Cannot select or scan some
channels.
Channels may be removed from
memory.
Check antenna connections.
NO digital signal being broadcast.
Weak Signal.
V-Guide is set to block program-
ming.
Select Channel Scan memory and
manually add channels or start an
“All Channel Search.”
Turn antenna, install signal
booster.
Set V-Guide to “Off” or press
RESET key to clear all settings and
restart channel search.
HELP HINTS (PROBLEMS/SOLUTIONS)
SYMPTOM CHECK THESE CONDITIONS TRY THESE SOLUTIONS
If you continue to experience problems, please call toll free
1-800-877-5032. We can Help!
3
Use the CHANNEL (CH ) keys or numerical
0 ~ 9 keys to select desired channel.
4
Press the ENTER key to add the channel. The
display will change to “added.”
1
Press the MENU key to display the Main menu.
2
Use the CURSOR keys to highlight Channel
Scan Memory. Press ENTER.
ADDING DIGITAL OR ANALOG
CHANNELS TO MEMORY
Channel Scan Memory is a list of active channels that
you can scan through using the Channel Scan CH
(up) CH (down) keys. This list can be customized by
deleting and/or adding channels.
After 3 seconds the TV screen will display
“Delete?”
OPERATING TIP:
If one digital sub-channel is added back to the
Channel Scan Memory list, all of that channel’s
sub-channels will be added back.
34
35
MENU OPTION—
DIGITAL CAPTION
1
Tune to a Digital Channel.
2
Press the MENU key to display the Main menu.
3
Use the CURSOR keys to highlight Digital
Caption. Press ENTER.
4
Use the CURSOR keys to highlight an option.
Press ENTER.
Closed-Captioning is text information transmitted
along with the picture and sound. Turning Captioning
ON causes the DTV to open these captions (digital or
analog) and superimpose them on the screen. (Local
broadcasters decide which caption signals to transmit.)
Digital Captions can be changed using the menu
settings as shown.
(CONTINUED ON NEXT PAGE)
5
Use the CURSOR < > keys to select the desired
effect.
OPERATING TIPS:
If Background Opacity is set to transparent,
captions may be difficult to see.
Only true EIA 708B Digital Closed-Captions
are affected by all of these settings.
QUIKCAP OPERATION
QuikCap turns captioning on and off with the Mute function. Press the MUTE key on the remote control to block
the TV sound; the captions display automatically, if available. Press the MUTE key again to restore the sound.
Captions will disappear.
MUTE
MENU OPTION—
DIGITAL CAPTION (Continued)
NO Captioning
Cannot customize Caption
Check if station is broadcasting a
Closed-Caption signal.
Digital Caption signal not being
broadcast.
Press CAPTION key to select
Captioning.
Press CAPTION key to select
Analog captioning.
SYMPTOM CHECK THESE CONDITIONS TRY THESE SOLUTIONS
If you continue to experience problems, please call toll free
1-800-877-5032. We can Help!
TO VIEW CAPTIONS
Press the CAPTION key to select caption modes.
HELP HINTS (PROBLEMS/SOLUTIONS)
36
Digital modes: Digital CC1 through Digital
CC6, QuikCap, and Off.
Analog modes: CC1 through CC4,
QuikCap, and Off.
CAPTION
MENU OPTION—
V-GUIDE (PARENTAL CONTROL)
NOTE: THIS FEATURE IS DESIGNED TO COMPLY
WITH THE UNITED STATES OF AMERICA’S FCC
V-CHIP REGULATIONS. THEREFORE, IT MAY NOT
FUNCTION WITH BROADCASTS THAT ORIGINATE IN
OTHER COUNTRIES.
Use this feature to automatically block programs with
content you deem as inappropriate for children to view.
This Sanyo television is equipped with an electronic
V-Chip to interpret MPAA (Motion Picture Association of
America) and TV Parental Guidelines rating codes. When
these codes are detected, the DTV will automatically
display or block the program, depending upon choices
you make when setting up the V-Guide system.
TO BLOCK MOVIE OR TV PROGRAM
1
Press the MENU key to display the Main menu.
2
Use the CURSOR keys to highlight
V-Guide. Press ENTER.
3
Use the CURSOR keys to select ON. Press
ENTER.
5
Press CURSOR and < > keys to select MOVIE,
TV Rating, or Content Ratings. (A green square will
appear beside the selected item.)
6
Press the ENTER key to Block or Unblock selected
option. A lock will appear beside the selected rating
option indicating it is blocked.
Content ratings are represented by the initials: FV
(fantasy violence), L (adult language), S (sexual situations), V (violence), and D (suggestive dialog).
(CONTINUED ON NEXT PAGE.)
37
TO SETUP V-GUIDE RATINGS
4
Use the CURSOR to select Adjust. Press ENTER.
38
OPERATING TIPS:
You can block portions of a DTV rating by choosing one or
more of the Content ratings (D, L, S, and V). By blocking
just the L and S content ratings of TV-14, for example, TV14 rated programs with a D and/or V content rating could
still be viewed.
V-Guide limits on programming received via the Analog
antenna input, Digital antenna input, Video 1 input, and any
480i signals received through the Component jacks can be
controlled by this DTV.
V-Guide Limits on digital programming received through
the component jacks are controlled by the external equipment connected to these jacks. Refer to your external
device’s owner’s manual for instructions on setting
V-Guide Limits.
MENU OPTION—
V-GUIDE (PARENTAL CONTROL) Continued
ON-SCREEN VIEW OF BLOCKED TV
PROGRAM
TO TEMPORARILY UNBLOCK MOVIE
OR TV PROGRAM
1
Press the MENU key to display the Main menu.
2
Use the CURSOR keys to highlight V-Guide.
Press ENTER.
3
Use the CURSOR keys to select OFF. Press
ENTER.
This will temporarily set V-Guide to OFF. When
V-Guide is reset to ON (follow steps 1~2), the DTV will
automatically revert to previously selected block ratings.
TO UNBLOCK ALL MOVIE OR ALL
TV RATING
1
Press the MENU key to display the Main menu.
2
Use the CURSOR keys to highlight V-Guide.
Press ENTER.
3
Press ENTER to select Adjust.
4
Highlight the “Allow All” option using the
CURSOR and < > keys, if needed. Press
ENTER.
(CONTINUED ON NEXT PAGE)
39
MENU OPTION—
V-GUIDE (PARENTAL CONTROL) Continued
ALL CHILDREN—Program is designed to
be appropriate for children ages 2-6.
DIRECTED TO OLDER CHILDREN—
Program is designed for children 7 and
above. Material may include mild fantasy
violence (FV) or comedic violence.
GENERAL AUDIENCE—Program suitable
for all ages. Contain little or no violence, no
strong language or sexual dialogue or situations.
PARENTAL GUIDANCE SUGGESTED—
Program contains material that may be
unsuitable for younger children. Material
contains one or more for the following:
moderate violence (V), some sexual situations (S), infrequent coarse language (L), or
some suggestive dialogue (D).
PARENTS STRONGLY CAUTIONED—
Some material is unsuitable for children
under 14 years of age. Parents are strongly
urged to use caution against letting children
under age 14 watch unattended. Material
contains intense violence (V), intense
sexual situations (S), strong coarse
language (L), or intensely suggestive
dialogue (D).
MATURE AUDIENCE ONLY—Program is
designed to be viewed by adults and therefore may be unsuitable for children under
17 years of age.
TV RATINGS (AGE/CONTENT-BASED)
G GENERAL AUDIENCES—All ages admitted.
PG PARENTAL GUIDANCE SUGGESTED—Some
material may not be suitable for children.
PG-13 PARENTAL GUIDANCE CAUTIONED—Some
material may be inappropriate for children
under 13.
R RESTRICTED—Under 17 requires accompany-
ing parent or adult guardian
NC-17 NO ONE 17 AND UNDER ADMITTED
MPAA MOVIE RATINGS (AGE-BASED)
When codes are being transmitted and received, and
V-Guide is set to ON, the V-Chip blocks programming
according to the settings you choose.
40
1
Press the MENU key to display the Main menu.
2
Use the CURSOR keys to highlight
Picture/Sound. Press ENTER.
3
Use the CURSOR keys to highlight Auto
(factory preset settings) or Manual. Press ENTER.
MENU OPTION—
PICTURE/SOUND
(CONTINUED ON NEXT PAGE)
MANUAL ADJUSTMENTS
4
Use the CURSOR keys to select the option you
want to adjust.
5
Then use the CURSOR < > keys to make an
adjustment.
MENU OPTION—
PICTURE/SOUND (Continued)
MANUAL ADJUSTMENTS (CONTINUED)
4
Use the CURSOR keys to select the option you
want to adjust.
5
Then use the CURSOR < > keys to make an
adjustment.
No picture, sound
(Digital Picture)
Poor Picture/Sound
(watching Analog)
Weak Signal.
Check antenna/external
connections.
May be station trouble, NO signal
broadcast.
MUTE function may be on.
Check if program is in color.
Check antenna/external
connections.
Color or Tint misadjusted.
May be station trouble.
May be MUTE function is on.
Adjust antenna. Install booster
Press the RESET key to restart
channel search.
Try a different channel.
Adjust Volume.
Try a different channel.
Adjust antenna.
Press the RESET key to restart
channel search.
SYMPTOM CHECK THESE CONDITIONS TRY THESE SOLUTIONS
If you continue to experience problems, please call toll free
1-800-877-5032. We can Help!
HELP HINTS (PROBLEMS/SOLUTIONS)
41
42
MENU OPTION—
MENU LANGUAGE
1
Press the MENU key to display the Main menu.
2
Use the CURSOR keys to highlight Menu
Language. Press ENTER.
3
Use the CURSOR keys to select English,
Español, or Français.
43
MENU OPTION—
ENERGY (POWER) SAVER
This power saving feature reduces the brightness level.
The power saving function options:
• OFF – the feature is off and the power consumption is
normal.
• LOW – power saving level is low and the brightness
level is lower than normal.
• HIGH – power saving level is high and the brightness is
set to the lowest level.
1
Press the MENU key to display the Main menu.
2
Use the CURSOR keys to highlight Energy
Saver. Press ENTER.
3
Use the CURSOR keys to highlight
desired option.
44
GLOSSARY OF TERMS
Analog—Commonly refers to the current NTSC transmission
standard for televisions.
Aspect Ratio—The ratio of the width to the height of a TV screen
independent of the screen size (x units wide by x units high). Analog
is 4:3; Digital can be 4:3 or 16:9 (also called wide screen).
ATSC—Advanced Television Systems Committee
AV Jacks—Audio Video Jacks
Bandwidth—The range of frequencies assigned to a broadcast
channel. A TV channel is 6 MHz wide.
Component Jacks (Y Pb Pr)—Green, Blue, and Red video jacks
that accept 480i, 480p, 720p, and 1080i signals. By separating the
Green (Y), Blue (Pb), and Red (Pr) video signal components, clearer,
more-defined images that exceed the performance of S-Video and
Composite video jacks are achieved.
Composite Jacks—White, Red, and Yellow AV jacks. The White
and Red jacks carry the Left and Right audio signals while the
Yellow jack carries the composite video signal.
Dolby® Digital (Formally known as Dolby AC-3)—A 5.1 channel
(Front L/R, Rear L/R, Center, and Bass) surround sound audio
standard for digital television.
Downconverting—The removal of pixels. Frame rate and/or scanning format may also change. Broadcasters may use this process to
make room in their bandwidth for additional services, such as,
sub-channels.
DTV (Digital Television)—Comprises four elements, HDTV,
EDTV, SDTV, and Multicasting.
DVI—Digital Visual Interface. A pure digital video interface that
can pass standard-definition and high-definition video signals. It
supports the HDCP copy protection standard, allowing transmission
of copy-protected digital content.
EDTV—Enhanced-Definition TV (480p)
HDMI—High-Definition Multimedia Interface. An all digital
audio/video interface that accepts uncompressed video signals for
the very best picture possible. It supports the HDCP copy protection
standard, allowing transmission of copy-protected digital content.
The signal can also include Dolby
®
Digital or PCM audio, when
available.
HDTV—High-Definition TV (720p, 1080i, & 1080p)
Input / Output Jacks—Used to receive (input) and send (output)
signals from one device to another. Such as, from a DVD player
(Output) to the TV (Input).
Interlaced Scanning—The process of scanning two fields of video
then combining (interlacing) them to make one frame of video (or
one complete image).
Letter Box—This term is used to describe a 16:9 ratio image being
displayed on a 4:3 ratio display device. Black bands appear at the top
and bottom of the screen.
MPEG2—A compression scheme for moving images and audio. It
was developed by the Motion Picture Experts Group. This makes
HDTV and multicasting possible.
Multicasting—The dividing of a station’s broadcast signal into subchannels of programming or data services. The resolution of the
main channel must be reduced to make room for sub-channels.
NTSC—National Television Systems Committee
Pillar Boxing—This term is used to describe a 4:3 ratio image being
displayed on a 16:9 ratio display device. Black bars (or pillars)
appear at the sides of the screen.
Pixel—Picture Element
Progressive Scanning—The process of scanning lines sequentially.
One scan produces one frame of video (or one complete image).
Set-Top Box (STB)—A device that receives and converts signals for
display on a television screen (can be digital or analog). Many digital
STBs have cable and over-the-air tuners.
SDTV—Standard-Definition TV (480i)
Signal—The picture, sound, and data transmitted or received
through the air to an antenna, over a Cable TV system, from a Satellite to a dish and receiver, or between external components of an
Audio/Video system.
Simulcast—Simultaneously broadcasting the same program on two
or more channels. This is required by the FCC during the transition
from analog to digital. Simulcasting is scheduled to end and only
digital broadcasts will continue after February 17, 2009.
S-Video Jack—A round 4-pin jack that accepts separated luminance
and chroma signals from a DVD player, Super VHS VCR, or similar
analog device. The resolution of this input exceeds that of a composite video input (yellow connector), but is lesser than the
resolution of component inputs (Y Pb Pr).
Terrestrial—An over-the-air broadcast to an antenna.
Upconverting—A process of converting original analog program-
ming to digital for DTV broadcasting. Pixels may be duplicated and
inserted between existing pixels to simulate HDTV. This does not
increase the resolution. The resolution of an image is set during the
recording process. It cannot be increased through conversion
processes.
Wide Screen—Used to describe a 16:9 or greater aspect ratio. 16:9
is the standard aspect ratio for HDTV digital displays. Movies
screens are often slightly wider.
1. What channel do I put my television on to watch a DVD
player?
To determine where the DVD player is connected, turn the DVD
player and TV on and set the TV on channel 3. Then press the
INPUT key on the remote control to scroll through the signal
inputs to locate the DVD player startup screen.
2. I am not receiving all of my VHF and UHF channels or cable
channels?
Make sure an antenna or your cable service is connected to
the ANT. Terminal. If there is a VCR connected, make sure it is
turned off. Press the RESET key on the remote two times to
begin an automatic channel search.
3. I connected a satellite receiver directly to the digital connection on the television and cannot receive my satellite
channels?
Although the satellite signal is digital, it still must be processed
by a satellite receiver. The “Out to TV” connection on the
satellite receiver must be connected to the ANT. Terminal on
the television.
4. How do you turn the caption on and off?
To turn captioning on or off, press and release the CAPTION
key on the remote until the desired caption mode appears (CC1
and Digital CC1 are used most commonly).
5. I’m connected to a satellite system. How do I get my
television to go to channel 73?
Turn on the satellite receiver then press the RESET key on the
remote twice to begin a channel search. If after the search no
satellite channels appear. Press the MENU key on the remote
and select “Analog Antenna Signal.” Use the CURSOR keys
to select CABLE. Press the EXIT key, then press in channel 73.
6. How do I get a full picture on the screen?
If you are connected to a Cable box or Satellite receiver, bring
up the box menus and select 4:3 as the screen aspect ratio.
Then press the PIX SHAPE key on the television remote
control for the desired screen shape.
7. Is my remote universal?
No, this remote control is designed to operate a Sanyo
television only.
8. When I do a channel search some of my digital channels
disappear. What is wrong?
Many digital stations are not on-the-air 24 hours a day. After
doing the initial channel search, always use the menu system
to perform a “Digital Add-on Search” to add new digital channels, so that stations not on-the-air during the search will not
be erased.
9. There is no picture, sound is ok?
Check appropriate video connection to make sure it corresponds to the audio connection being used. If the sound is
associated with component jacks on a DVD player, it may be
necessary to access the DVD menu to select the component
outputs or S-Video output.
10. There is no sound, picture is clear?
If you are connecting your television through the Composite
jacks (Video1), S-Video jack (Video1), or Component jacks
(Video2 or Video3) the matching audio jacks must also be
connected.
11. The picture is not as clear as it should be. Am I using the
best quality connection?
Picture quality is classified as follows:
Analog RF cable connection . . . . . . . . . . . . . . . . . . . . . Basic
Video1 (Composite – yellow) . . . . . . . . . . . . . . . . . . . . . Good
Video1 (S-Video) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Better
Video2 (Component – green, blue, red) . . . . . . Exceptional
Video3 (Component – green, blue, red) . . . . . . Exceptional
Digital Antenna In . . . . . . . . . . . . . . . . . . . . . . . . . Exceptional
12. How do I register my television warranty?
No registration is necessary, just hold on to your sales receipt.
We will warranty the television from the date on the receipt.
13. Where is the code for a Sanyo television to program into
my universal remote?
You must obtain the code from the manufacturer of the remote
control you want to program. Refer to the remote’s owner’s
manual.
14. When I adjust the volume on the television why does the
volume level on the surround sound system remain steady?
The audio output jacks are set to a fixed level and do not vary
with the television volume. The volume control on the surround
sound system must be used.
15. My digital channel number doesn’t match the station
number.
On some digital channels the channel number displayed on the
television will be different than the channel ID number. This is
determined by the digital package broadcasted from the local
station through the digital signal.
16. What is the recommended method for cleaning the cabinet
and screen?
Clean the cabinet with a soft-dry
cloth. Clean the screen using a
damp-soft-cotton cloth.
45
FREQUENTLY ASKED QUESTIONS (FAQ)
46
For your protection in the event of theft or loss of this product, please fill in the information requested below and KEEP IN A SAFE
PLACE FOR YOUR OWN PERSONAL RECORDS.
Model No.______________________________ Date of Purchase _________________________
Serial No.______________________________ Purchase Price ___________________________
Where Purchased_________________________
(Located on back of unit)
AS
Sanyo Manufacturing Corp.
3333 Sanyo Road, Forrest City, AR 72335
ONE-YEAR LIMITED PARTS AND LABOR WARRANTY
THIS LIMITED PARTS AND LABOR WARRANTY IS VALID ONLY ON SANYO TELEVISIONS PURCHASED AND
USED IN THE UNITED STATES OF AMERICA, CANADA, AND PUERTO RICO, EXCLUDING ALL OTHER U.S.
TERRITORIES AND PROTECTORATES. THIS LIMITED WARRANTY APPLIES ONLY TO THE ORIGINAL RETAIL
PURCHASER, AND DOES NOT APPLY TO PRODUCTS USED FOR INDUSTRIAL OR COMMERCIAL PURPOSES.
WARRANTY APPLICATION
FOR ONE YEAR from the date of original retail purchase Sanyo Manufacturing Corporation (SMC) warrants
this TV to be free from manufacturing defects in materials and workmanship under normal use and
conditions for parts and labor.
For the FIRST 90 DAYS from the date of original retail purchase, Sanyo Manufacturing Corporation will
replace any defective TV via exchange at the retailer. To ensure proper warranty application, keep the
original-dated-sales receipt for evidence of purchase. Return the defective TV to the retailer along with
the receipt and the included accessories, such as the remote control. The defective TV will be
exchanged for the same model, or a replacement model of equal value, if necessary. Replacement model
will be contingent on availability and at the sole discretion of Sanyo Manufacturing Corporation.
THE FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
OBLIGATIONS
For one year
from the date of purchase, Sanyo Manufacturing Corporation warrants this product to be free
from defects in material and workmanship under normal use and conditions. During the first 90 days
under
this warranty for any manufacturing defect or malfunction Sanyo Manufacturing Corporation will provide
a new TV via exchange at the retailer.
HOW TO MAKE A CLAIM UNDER THIS WARRANTY
Please call 1-800-877-5032. Please be prepared to give us the television’s model number and serial number
when you call. The model number and serial number are printed on a label attached to the back of the unit.
For customer assistance, call toll free 1-800-877-5032.
Weekdays 7:30 AM – 7:00 PM Central Time
Saturday 7:30 AM – 4:00 PM Central Time
This warranty expresses specific contractual rights; retail purchasers may have additional statutory rights
which vary from state to state.
(EFFECTIVE: March 1, 2007)
