Samsung LED TV MONITOR, SyncMaster TB750 User Manual
LED TV MONITOR
(MFM TV)
user manual
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/register
Model _____________ Serial No. _____________
5#
Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearances. Product
design and specifications may be changed without notice.
Important Warranty Information Regarding Television Format Viewing
✎
See the warranty card for more information on warranty terms.
Wide screen format LED Displays (with 16:9 aspect ratios, the ratio of the screen width to height) are primarily designed to view wide
screen format full-motion video. The images displayed on them should primarily be in the wide screen 16:9 ratio format, or expanded to fill
the screen if your model offers this feature with the images constantly in motion. Displaying stationary graphics and images on the screen,
such as the dark sidebars on non-expanded standard format television video and Programmeming, should be limited to no more than 5%
of the total television viewing per week.
Additionally, viewing other stationary images and text such as stock market reports, video game displays, station logos, web sites or
computer graphics and patterns, should be limited as described above for all televisions. Displaying stationary images that exceed the
above guidelines can cause uneven aging of LED Displays that leave subtle, but permanent burned-in ghost images in the LED picture. To
avoid this, vary the Programmeming and images, and primarily display full screen moving images, not stationary patterns or dark bars. On
LED models that offer picture sizing features, use these controls to view different formats as a full screen picture.
Be careful about the television formats you select and the length of time you view them. Uneven LED aging as a result of format selection
and use, as well as burned in images, are not covered by your Samsung limited warranty.
• SAMSUNG ELECTRONICS NORTH AMERICAN LIMITED WARRANTY STATEMENT
Subject to the requirements, conditions, exclusions and limitations of the original Limited Warranty supplied with Samsung
Electronics (SAMSUNG) products, and the requirements, conditions, exclusions and limitations contained herein, SAMSUNG will
additionally provide Warranty Repair Service in the United States on SAMSUNG products purchased in Canada, and in Canada on
SAMSUNG products purchased in the United States, for the warranty period originally specified, and to the Original Purchaser only.
The above described warranty repairs must be performed by a SAMSUNG Authorized Service Centre. Along with this Statement,
the Original Limited Warranty Statement and a dated Bill of Sale as Proof of Purchase must be presented to the Service Centre.
Transportation to and from the Service Centre is the responsibility of the purchaser. Conditions covered are limited only to
manufacturing defects in material or workmanship, and only those encountered in normal use of the product.
Excluded, but not limited to, are any originally specified provisions for, in-home or on-site services, minimum or maximum repair
times, exchanges or replacements, accessories, options, upgrades, or consumables.
For the location of a SAMSUNG Authorized Service Centre, please call toll-free:
– In the United States : 1-800-SAMSUNG (1-800-726-7864)
– In Canada : 1-800-SAMSUNG
Still image warning
Avoid displaying still images (such as jpeg picture files), still image elements (such as channel logos, stock or news bars at the screen
bottom etc.), or Programmes in panorama or 4:3 image format on the screen. Constantly displaying still pictures can cause image burn-in
on the screen, which will affect image quality. To reduce risk of this effect, please follow the recommendations below:
• Avoid displaying the same channel for long periods.
• Always try to display a full screen image.
• Reduce brightness and contrast to avoid the appearance of after-images.
• Use all product features designed to reduce image retention and screen burn. Refer to proper user manual section for details.
English - 2
English - 3
Contents
Getting Started
y Safety Precautions .................................................... 5
y Providing Proper Ventilation for Your Product .......... 13
y List of Features ....................................................... 13
y Accessories and Cables .......................................... 14
y Using the Control Panel .......................................... 15
y Using Smart Hub .................................................... 16
y The Standard Remote Control ................................ 17
y The Standard Remote Control Buttons ................... 18
y How to Navigate Menus .......................................... 19
y Connecting the Power Cord and the
Aerial or Cable Connection ..................................... 20
y Configuring the Basic Settings in Initial Setup .......... 21
Connections
y Connecting to AV Devices (Blu-ray Players, DVD
Players, etc.) ........................................................... 25
y Connecting to Audio Devices .................................. 27
y The Service Cable Connection ............................... 28
y Connecting to a PC ................................................ 28
y Changing the Input Source ..................................... 30
Basic Features for the Monitor
y Correct posture to use the product ......................... 33
y Changing the Preset Picture Mode .......................... 33
y Adjusting Picture Settings ....................................... 34
y Changing the Picture Size ....................................... 35
y Calibrating the Screen Display ................................. 36
y Changing the Picture Options ................................. 37
y Changing the Preset Sound Mode .......................... 38
y Adjusting Sound Settings ........................................ 39
Basic Features for the TV
y Using the INFO button (Now & Next guide) ............. 41
y Using the Channel Menu ......................................... 41
y Memorising Channels ............................................. 52
y Other Features ........................................................ 54
y Changing the Preset Picture Mode .......................... 55
y Adjusting Picture Settings ....................................... 56
y Changing the Picture Size ....................................... 57
y Changing the Picture Options ................................. 59
y Changing the Preset Sound Mode .......................... 62
y Adjusting Sound Settings ........................................ 63
Network Features
y Connecting to the Network ..................................... 67
y Setting up a Wired Network .................................... 70
y Setting up the Wireless Network ............................. 73
y Managing the Network Devices ............................... 77
Preference Features
y Setting the Time...................................................... 80
y Economical Solutions .............................................. 83
y Blocking Programmes ............................................. 84
y Picture In Picture (PIP) ............................................. 85
y Using the Product with a Keyboard and a Mouse .... 86
y Other Features ........................................................ 88
y Support Menu ......................................................... 92
Check the Symbol!
Note Step by Step Guide
Indicates additional information. Check here for instructions on how to open the relevant submenu
within the OSD (on screen display).
English - 4
English - 4
Advanced Features
y Smart Hub .............................................................. 97
y Using Samsung Apps ........................................... 108
y Search .................................................................. 111
y Your Video ............................................................ 113
y Family Story .......................................................... 114
y Fitness .................................................................. 124
y Kids ...................................................................... 126
y Web Browser ........................................................ 129
y AllShare Play ......................................................... 135
y My list (In AllShare Play) ......................................... 139
y Videos (In AllShare Play) ........................................ 141
y Photos (In AllShare Play) ....................................... 145
y Music (In AllShare Play) ......................................... 149
y Recorded TV product (In AllShare Play) ................. 152
y Timeshift ............................................................... 155
y Using the DLNA Function ...................................... 157
y Using the MHL function ........................................ 159
y Anynet+ (HDMI-CEC) ............................................ 160
Other Information
y Troubleshooting .................................................... 163
y Supported Subtitle and AllShare Play file formats .. 174
y Analogue Channel Teletext Feature ....................... 177
y Adjusting the Product Tilt ...................................... 178
y Anti-theft Kensington Lock .................................... 178
y Assembling the Cables ......................................... 179
y Storage and Maintenance ..................................... 179
y Licence ................................................................. 180
y Index .................................................................... 182
Getting Started
English - 5
English - 5
Getting Started
Safety Precautions
Icons used for safety precautions
WARNING
Failing to follow the precautions marked with this sign may result in a serious injury or
even a fatality.
CAUTION
Failing to follow the precautions marked with this sign may result in a personal injury
or property damage.
Do not perform.
Must be followed.
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK). THERE ARE NO USER
SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO
QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present
inside. It is dangerous to make any kind of contact
with any internal part of this product.
This symbol alerts you that important literature
concerning operation and maintenance has been
included with this product.a
Power Related
✎
The following images are for your reference and may differ depending on models and countries.
Warning
Avoid using a damaged power cord
or plug or a loose power outlet.
• Otherwise, it may result in
electric shock or fire.
Avoid connecting multiple electric
appliances to a single wall outlet.
• Otherwise, it may result in fire
due to overheating of the wall
outlet.
Avoid plugging in or unplugging the
power supply with wet hands.
• Otherwise, it may result in
electric shock.
!
Plug the power plug in firmly.
• Otherwise, it may result in fire.
!
Make sure to connect the power
cord to a grounded wall outlet (for
insulation class 1 equipment only).
• Otherwise, it may result in
electric shock or injury.
Avoid bending or twisting the
power cord excessively and avoid
placing heavy objects on the cord.
• Otherwise, it may result in
electric shock or fire due to a
damaged power cord.
Keep the power cord and the
product away from a heater.
• Otherwise, it may result in
electric shock or fire.
!
If the pins of the power plug or
the wall outlet are covered in dust,
clean it using a dry cloth.
• Otherwise, it may result in fire.
Getting Started
English - 6
Caution
Avoid unplugging the power plug
while the product is operating.
• Otherwise, it may damage the
product due to electric shock.
!
Make sure to use only the power
cord supplied by our company.
In addition, do not use the power
cord of another electric appliance.
• Otherwise, it may result in
electric shock or fi re.
!
When unplugging the power plug
from the wall outlet, make sure to
hold it by the plug and not by the
cord.
• Otherwise, it may result in
electric shock or fi re.
!
Connect the power plug to a wall
outlet that can be easily reached.
• When a problem occurs
with the product, you must
unplug the power plug to cut
the power off completely.
You cannot cut the power
off completely using only the
power button on the product.
Installation Related
Warning
Avoid placing burning candles,
mosquitorepellentor cigarettes on
the product.
• Otherwise, it may result in fi re.
!
Ask an installation engineer or
relevant company to install the
product onto the wall.
• Otherwise, it may result in
injury.
• Make sure to use the specifi ed
wall mount.
Avoid installing the product in a
badly-ventilated location such as
inside a bookshelf or closet.
• Otherwise, it may result in fi re
due to internal over-heating.
!
Keep the plastic bags used to pack
the product away from children.
• If children place the plastic
bags over their heads, they
may suffocate.
Avoid installing the product in a
location that is unstable or exposed
to excessive vibration such as on
an unstable or slanted shelf.
• The product may fall and this
may result in damage to the
product or injury.
• If you use the product in a
location exposed to excessive
vibrations, it may result in a
problem with the product or
fi r e .
!
Avoid installing the product in a
location exposed to dust, moisture
(sauna), oil, smoke or water (rain
drops) and installing it within a
vehicle.
• This may result in electric
shock or fi re.
Getting Started
English - 7
Avoid installing the product in a
location exposed to direct sunlight
and installing the product near a
heat source such as a fi replace or
heater.
• This may shorten the product
life cycle or cause fi re.
Avoid installing the product where
children may reach it.
• If a child touches the product,
the product may fall and this
may result in injury.
• Since the front part is heavier,
install the product on a fl at and
stable surface.
!
Bend the outdoor aerial cable
downwards at the location where
it comes in the house so that
rainwater does not fl ow in.
• If rainwater enters the product,
it may result in electric shock
or fi re.
!
Install the aerial far away from any
high voltage cables.
• If the aerial touches or falls
onto a high voltage cable, it
may result in electric shock
or fi re.
Caution
!
Do not let the product drop while
moving it.
• This may result in a problem
with the product or injury.
Do not place the product face
down on the fl oor.
• This may damage the panel of
the product.
When installing the product on a
console or shelf, make sure that
the front of the product does not
protrude out of the console or shelf.
• Otherwise, this may cause the
product to fall off and result in a
malfunction or injury.
• Make sure to use a cabinet or
shelf suitable to the size of the
product.
!
When putting the product down,
handle it gently.
• Otherwise, it may result in a
problem with the product or
injury.
SAMSUNG
!
If the product is installed in a
location where the operating
conditions vary considerably,
a serious quality problem may
occur due to the surrounding
environment. In this case, install the
product only after consulting one
of our service engineers about the
matter.
• Places exposed to microscopic
dust, chemicals, too high or
low temperature, high humidity,
airports or stations where the
product is continuously used.
Getting Started
English - 8
Cleaning Related
Warning
!
Before cleaning the product, unplug
the power cord.
• Otherwise, it may result in
electric shock or fi re.
When cleaning the product, do
not spray water directly over the
product parts.
• Make sure that water does not
enter the product.
• Otherwise, it may result in fi re,
electric shock or a problem
with the product.
Caution
Avoid spraying cleansing agent
directly onto the product.
• This may result in
discolouration or cracking of
the exterior of the product or
the panel coming off.
!
When cleaning the product,
disconnect the power cord and
clean the product with the supplied
cleaning cloth.
• Avoid using chemicals such as
wax, benzene, alcohol, thinner,
mosquitorepellent, fragrance,
lubrication or cleansing agent
when cleaning the product.
This may result in the exterior
being deformed or the print
being removed.
!
If you can't get the product clean
with just the supplied cloth, use a
soft, damp cloth with a "monitorexclusive cleansing agent" and
wipe the product with it.
• If no monitor-exclusive
cleansing agent is available,
dilute a cleansing agent with
water at a ratio of 1:10 before
cleaning the product.
!
Since the exterior of the product is
easily scratched, be sure to use the
supplied cleansing cloth.
Usage Related
Warning
Since a high voltage runs through
the product, never disassemble,
repair or modify the product
yourself.
• Otherwise, it may result in fi re
or electric shock.
• If the product needs to be
fi xed, contact a service centre.
!
To move the product, turn the
power off and unplug the power
cord, the aerial cable and any other
wires connected to the product.
• Otherwise, it may result in
electric shock or fi re due to the
damaged power cord.
Getting Started
English - 9
!
If the product generates a strange
noise, a burning smell, or smoke,
unplug the power plug immediately
and contact a service centre.
• Otherwise, it may result in
electric shock or fire.
Avoid letting children hang or climb
onto the product.
• Otherwise, it may result in the
product falling and this may
result in injury or death.
If you drop the product or the case
is damaged, turn the power off and
unplug the power cord. Contact a
service centre.
• Otherwise, it may result in fire
or electric shock.
Avoid placing objects such as toys
and cookies on top of the product.
• If a child hangs over the
product to grab an object, the
object or the product may fall
and this may result in injury or
even death.
!
When thunder or lighting occurs,
unplug the power cord and under
no circumstance touch the aerial
cable as this is dangerous.
• Otherwise, it may result in
electric shock or fire.
!
Avoid dropping an object over the
product or cause impact to the
product.
• Otherwise, it may result in
electric shock or fire.
Avoid moving the product by pulling
the power cord or aerial cable.
• Otherwise, it may result in
electric shock, fire or a problem
with the product due to
damage to the cable.
!
GAS
When a gas leak occurs, do not
touch the product or the power
plug and ventilate immediately.
• A spark may result in an
explosion or fire.
• During a thunder or lighting
storm, do not touch the power
cord or aerial cable.
Avoid lifting up or moving the
product by holding only the power
cord or signal cable.
• Otherwise, it may result in
electric shock, fire or a problem
with the product due to
damage to the cable.
!
Avoid using or placing inflammable
spray or objects near the product.
• This may result in an explosion
or fire.
Take care not to block the vent by a
table cloth or curtain.
• Otherwise, it may result in fire
due to internal overheating.
100
Avoid inserting metal objects such
as a chopsticks, coins or hairpins,
or inflammable objects into the
product (the vents, ports, etc).
• If water or substances enters
the product, turn the power
off, unplug the power cord and
contact a service centre.
• Otherwise, it may result in a
problem with the product,
electric shock or fire.
Getting Started
English - 10
Avoid placing a liquid container
such as a vase, fl owerpot,
beverage, cosmetics or drugs, or a
metal object over the product.
• If water or substances enter
the product, turn the power
off, unplug the power cord and
contact a service centre.
• Otherwise, it may result in a
problem with the product,
electric shock or fi re.
Do not press down hard on the
product. The product may become
deformed or damaged.
Caution
!
!
Displaying a still image for a long
time may create a persistent image
or stain on the screen.
• If you do not use the product
for a long time, use the
power-saving mode or set the
screensaver to the moving
picture mode.
-_-
!
When not using the product for
a long time such as leaving your
home, unplug the power cord from
the wall outlet.
• Otherwise, it may cause dust
accumulation and result in fi re
caused by overheating or short
circuit or result in an electric
shock.
!
Set the appropriate resolution and
frequency for the product.
• Otherwise, it may result in eye
strain.
Avoid turning the product upside
down or move the product holding
only the stand.
• This may cause the product to
fall, resulting in damage to the
product or injury.
!
Watching the product from too
close a distance continuously may
damage your eyesight.
Avoid using a humidifi er or cooker
near the product.
• Otherwise, it may result in
electric shock or fi re.
!
It is important to give your eyes
some rest (5 minutes every hour)
when viewing the product screen
for long periods of time.
• This will alleviate any eye strain.
Since the display panel is hot after
using it for a long time, do not
touch the product.
!
Keep the small accessories in a
location out of the reach of children.
!
Take care when adjusting the angle
of the product or the height of the
stand.
• If your hand or fi nger is caught,
you may be injured.
• If the product is tilted
excessively, the product may
fall and this may result in injury.
Getting Started
English - 11
Avoid placing a heavy object over
the product.
• Otherwise, it may result in a
problem with the product or
injury.
When using headphones or
earphones, do not turn the volume
too high.
• Having the sound too loud may
damage your hearing.
Be careful that children do not
place the batteries in their mouths
when removed from the remote
control. Place the battery in a
location that children or infants
cannot reach.
• If children have had the battery
in their mouths, consult your
doctor immediately.
!
When replacing the batteries, insert
them with right polarity (+, -).
• Otherwise, the battery may
become damaged or it may
cause fi re, personal injury or
damage due to leakage of the
internal liquid.
Use only specifi ed standard
batteries. Do not use new and used
batteries together.
• This may cause a battery to
break or leak and may cause
fi re, injury, or contamination
(damage).
!
The batteries (and rechargeable
batteries) are not ordinary refuse
and must be returned for recycling
purposes. The customer is
responsible for returning the used
or rechargeable batteries for
recycling.
• The customer can return used
or rechargeable batteries
to a nearby public recycling
centre or to a store selling the
same type of the battery or
rechargeable battery.
Do not place the adapter on top of
another adapter.
• Otherwise, it may result in fi re.
Keep power adaptor away from any
other heat source.
• Otherwise, it may result in fi re.
Remove the vinyl cover of the adapter
before using the adaptor.
• Otherwise, it may result in fi re.
Always keep power adaptor in wellventilated area.
Be careful that adaptor should not be
in contact with water and therefore not
be wet.
• This may cause a malfunction,
electric shock or fi re. Do not use
adaptor by the waterside or outside
particularly when it rains or snows.
Be careful that adaptor should not
be wet while cleaning fl oor with
water.
Getting Started
English - 12
Caution
Exercise caution when adjusting the angle of the product.
• Your fingers may get caught and injured when folding the product. Ensure you take extra caution.
Providing Proper Ventilation for Your Product
When you install your product, maintain a distance of at least 4 inches between the product and other objects (walls,
cabinet sides, etc.) to ensure proper ventilation. Failing to maintain proper ventilation may result in a fire or a problem
with the product caused by an increase in its internal temperature.
✎
Whether you install your product using a stand or a wall-mount, we strongly recommend you use parts provided
by Samsung Electronics only.
• If you use parts provided by another manufacturer, it may cause difficulties with the product or result in injury
caused by the product falling.
4 inches
4 inches
4 inches
Other Warnings
✎
The actual appearance of the product may differ from the images in this manual, depending on the model.
✎
Be careful when you touch the product. Some parts can be somewhat hot.
List of Features
• SMART HUB: Your gateway to all your content, integrated in one place.
– Provides diverse entertainment choices.
– Lets you control your entertainment life with an easy-to-use, user friendly user interface.
– Gives you easy access to diverse apps, with more being added every day.
– Lets you customize your product by grouping and sorting apps to your taste.
• AllShare Play: Lets you access, view, or play photos, videos, or music located on USB devices, digital cameras, cell
phones, and PCs. PCs and cell phones can be accessed wirelessly, through your wireless network.
• Anynet+ (HDMI-CEC): Allows you to control all connected Samsung devices that support Anynet+ with your
Samsung product’s remote.
Getting Started
English - 13
Accessories and Cables
✎
Please make sure the following items are included with your product. If any items are missing, contact your dealer.
✎
The items’ colours and shapes may vary depending on the model.
✎
Make sure that there are no accessories hidden behind or under packing materials after you open the box.
[
[CAUTION] INSERT SECURELY LEST SHOULD BE DETACHED IN SET
• Remote Control & Batteries (AAA x 2)
• User Manual (CD)
• Warranty Card / Safety Guide / Quick Setup Guide
• Cleaning Cloth
• Power Cord / DC Adapter
• Cable Holder
Stereo Cable D-Sub Cable MHL Cable Ferrite Core
Getting Started
English - 14
Using the Control Panel
✎
The product colour and shape may vary depending on the model.
Control Panel
SOURCEE
Toggles between all the available input sources. In the on-screen menu, use this button
as you would use the SOURCE E button on the remote control.
MENU
Displays an on-screen menu, the OSD (on screen display) of your product’s features.
Y
Adjusts the volume. In the OSD, use the Y buttons as you would use the l and
r buttons on the remote control.
< P >
Changes the channels. In the OSD, use the < P > buttons as you would use the u
and d buttons on the remote control.
P (Power)
Turns the product on or off.
Remote control sensor
Aim the remote control towards this spot on the product.
Power Indicator
Blinks and turns off when the power is on and lights up in standby mode.
Standby mode
Your product enters Standby mode when you turn it off and continues to consume a small amount of electric power. To
be safe and to decrease power consumption, do not leave your product in standby mode for long periods of time (when
you are away on vacation, for example). It is best to unplug the power cord.
Getting Started
English - 15
Using Smart Hub
Smart Hub provides easy, on-screen access to four functions that let you manage and access channels, set favourite
channels, access photos, videos, or music on USB devices, cameras, and PCs, select video sources, and set the
product to turn on automatically when a show you want to watch is on. The four functions are listed below:
• Web Browser: Lets you browse the Internet.
• Schedule Manager: Lets you schedule shows and channels for viewing.
• Source: Lets you select a connected external video source to view.
• AllShare Play: Lets you access, view, or play photos, videos, or music located on USB devices, digital cameras, cell
phones, and PCs. PCs and cell phones can be accessed wirelessly, through your wireless network.
Smart Hub also provides an easy-to-use gateway to a host of on-line media and entertainment including apps from the
Samsung Apps store, streaming videos and movies, kids sites, and more.
✎
To access Smart Hub, press the ™ button on your remote.
✎
For more information about Smart Hub, see page 97
Getting Started
English - 16
The Standard Remote Control
Installing batteries (Battery size: AAA)
Match the polarity of the batteries to the symbols in the battery compartment.
✎
NOTE
• Install the batteries so that the polarity of the batteries (+/-) matches the illustration in the battery compartment.
• Use the remote control within 23 feet of the product.
• Bright light may affect the performance of the remote control. Avoid using it near fluorescent lights or neon
signs.
• The colour and shape of the remote may vary depending on the model.
Getting Started
English - 17
The Standard Remote Control Buttons
✎
This remote control has Braille points on the Power, Channel, and Volume buttons and can be used by visually
impaired persons.
MUTE
SEARCHPIP DUAL I-II
USB HUB
P.SIZE AD/SUBT.
M
BCD
l
l
l
l
HDMI
SOURCE
Turns the product on and off.
Displays and selects the available
video sources. (page 30)
Selects the HDMI mode directly.
Returns to the previous channel.
Cuts off the sound temporarily.
Changes channels.
Displays the EPG (Electronic
Programme Guide). (page 41)
Brings up the Smart Hub
applications. (page 97)
Displays information on the product
screen.
Exits the menu.
PIP: Turns the PIP on or off. (page
85)
SEARCH: Support to
recommendation search word and
search function.
DUAL f-g: Sound effect selection.
USB HUB: You can set the Connect
USB Hub to function by choosing
product or PC. (page 90)
P.SIZE: Lets you select the Picture
Size. (pages 35, 57)
AD/SUBT.: Turns the audio
description on and off. This is
not available in some locations. /
Displays digital subtitles.
Gives direct access to channels.
Alternately select Teletext ON,
Double, Mix or OFF.
Adjusts the volume.
Displays channel lists on the screen.
(page 49)
Opens the OSD (Menu).
Quickly select frequently used
functions. Use this button in a
specific feature.
Moves the cursor, selects the onscreen menu items, and changes
the values seen on the TV's menu.
Returns to the previous menu.
Use these buttons according to the
directions on TV's screen.
Use these buttons in a specific
feature.
Getting Started
English - 18
How to Navigate Menus
Your product’s Main and Tools menus contains functions that let you control the product’s features. For example, in the
Main menu you can change the size and configuration of the picture, its brightness, its contrast and so on. There are
also functions that let you control the product’s sound, channel configuration, energy use, and a host of other features.
To access the main, on-screen menu, press the MENUm button on your remote. To access Tools menus, press the
TOOLST button. Tools menus are available when the TOOLST menu Icon is displayed on the bottom right of the
screen
MUTE
PRE-
CH
C
H
LIST
SOURC
E
DM
2
5
1
3
4
RETURN EXIT
1 MENUm button: Displays the main on-screen menu.
2 TOOLST button: Displays the Tools menus when available.
3 E and Direction buttons: Use the Direction buttons to move the cursor and highight an item. Use the E button to
select an item or confirm the setting.
4 RETURNR button: Returns to the previous menu.
5 EXITe button: Exits the on-screen menu.
How to Operate the Main Menu (OSD - On Screen Display)
The access steps may differ depending on the menu option you select.
1
MENUm
The main menu options appear on the screen:
Picture, Sound, Channel, Network, System, Support.
2
u / d
Select a main menu option on the left side of the screen with the u or d button.
3
E
Press E to access the sub-menus.
4
u / d
Select the desired submenu with the u or d button.
5
u / d / l / r
Adjust the value of an item with the l, r, u, or d button. The adjustment in the
OSD may differ depending on the selected menu.
6
E
Press E to confirm the selection.
7
EXITe
Press EXITe.
Getting Started
English - 19
Connecting the Power Cord and the Aerial or Cable Connection
ANT OUT
Power Input
or
Cable
Aerial Cable (Not Supplied)
VHF/UHF Aerial
✎
Plug the power cord into a wall outlet only after you have made all other connections.
✎
If you are connecting your product to a cable or satellite box using HDMI, Component, or Composite connections,
you do not need to connect the ANT IN jack to an aerial or a cable connection.
✎
Connect the power adapter to DC 14 V on the rear of the product. Connect the power cord to the adapter and wall
socket. (The input voltage is switched automatically.)
✎
Use caution when you move or tilt the product if the aerial cable is tightly connected. You could break the aerial
jack off the product.
Getting Started
English - 20
Configuring the Basic Settings in Initial Setup
When you turn the product on for the first time, a sequence of screens and on-screen prompts will assist you in
configuring the product’s basic settings. Plug the power cord into a wall outlet, and then press the P button to turn on
the product.
✎
Setup is available only when the Source is set to TV. See "Changing the Input Source" (page 30).
✎
To return to the previous step in the Setup sequence, select Previous.
✎
If you are not using a cable box or satellite box, make sure you have connected the product to an aerial or cable
connection before you turn on the product. See page 20 for instructions.
✎
If you want to configure a wired network connection during Setup, make sure you've connected a LAN cable to
your product. See page 68 for instructions. If you want to configure a wireless network connection during Setup,
make sure your wireless modem or router is on and working. See page 67 for instructions.
1
Use Mode: Select the
Home Use Mode.
On the Use Mode screen, select the Home Use mode using your remote, and then
select Next. The Network Settings screen appears.
✎
Store Demo mode is for retail environments only. If you select Store Demo,
some functions will not work, and the product will reset all functions to their
factory default after a certain period of time. For more information about
Store Demo, go to the end of this section.
2
Network Settings:
Configure the network
settings
✎
To configure
later, select Skip.
You can set up
the network
connection later
using the onscreen Network
menu.
To configuring your network settings, select Next using your remote, and then go
to 3A - Wireless Network or 3B - Wired Network on the next page.
If you do not know your network configuration information or want to configure
the settings later, or do not have a network, select Skip, and then go to 6 - Auto
Tuning (1) on page 52.
To configure network settings later, refer to the Network Connection sections in
this manual (pages 70 and 73).
Getting Started
English - 21
2
a
Wireless Network 1. The product searches for and then displays all the wireless networks within
range. When done, it displays a list of the networks. In the list of networks,
move the Highlight to select a network, and then select Next. If the selected
network requires a Security Key, the Security Key screen appears.
✎
If you have a WPS(PBC) compatible router, select WPS(PBC) instead,
and then follow the directions on the screen. When done, go to Step 4.
2. Enter your network security key or WPS PIN using your remote.
✎
Enter numbers and letters using your remote.
• If you are using the standard remote, you can enter numbers by
pressing the number buttons on the remote.
• To enter a letter, move the Highlight to the letter, and then select it.
You can enter numbers in the same fashion if you choose.
✎
To display capital letters (or redisplay small letters if capital letters are
displayed), select Caps or Shift.
✎
To display symbols and punctuation, select . To redisplay letters,
select
again.
3. When done, select Next if you have entered a security key or WPS PIN if you
have entered a WPS PIN.
4. The product checks the wireless connection. If the connection is successful,
the You are connected to the Internet. If you have any problems using online
services, please contact your Internet service provider. message appears.
Select Next, and then go to 4 Software Update Step.
✎
If the connection fails, select Previous, repeat Step 1 and 2, carefully reenter your security key or WPS PIN, then repeat Steps 3 and 4. If it fails
again, select Next on the “Connection Failed” screen, and then go to 6
-Auto Tuning (1) on the next page. Configure your network later through
Network Settings in the product’s Menu. For more information, refer to
the Network Connection sections in this manual (pages 70 and 73).
2
b
Wired Network The product checks the network connection, then displays the You are connected
to the Internet. If you have any problems using online services, please contact your
Internet service provider. message appears. Select Next. The Software Update
screen appears.
Getting Started
English - 22
3
Software Update:
Update the software
to the latest version
✎
To update later,
select Skip.
When Network Settings is complete, your product will check for a new software
version automatically. If new software is available, the product downloads and
installs the new software. When the download is complete, select Next.
✎
If you want to upgrade later, select Skip. For more information, refer to
Software Update section of this manual (page 93)
✎
This may take some time, depending on your network status.
✎
You can only upgrade software if your product has an active network
connection.
✎
If no new update software is available, a no new updates message appears
on the screen. Select OK.
4
Select Country.
(Depending on the
country)
Select the appropriate area by pressing the u or d button.
Press the ENTERE button to confirm your choice.
5
Auto Tuning (1):
Select where your
product signal comes
from.
Let’s find and store channels on your TV. Do you need to search for channels?
• Yes, I need to: All the channels available will be found and stored on your TV. If
you select this option, go to Step 6.
• No, I don’t need to: My set-top box provides all the channels that are
available, so I don't need to search for channels.
If you select this option, go to Step 8.
6
Auto Tuning (2):
Select the search
options.
Select the channel source to memorise. If you select Digital & Analogue, Digital or
Analogue, The Auto Tuning starts.
7
Auto Tuning (3):
Channel memorization
Channel memorisation stars. Channel memorisation can take up to 45 minutes,
depending on your cable system.
For more information, refer to Auto Tuning section of this manual. (page 52)
✎
Select Stop at any time to halt the memorization process.
8
Clock: Set the Clock Select Auto or Manual, and then select Next.
• Auto: Set the current time automatically.
• Manual: Allows you to manually set the current date and time.
Getting Started
English - 23
9
Time Zone (Australia
only): Setting the your
Time Zone
This step is only available when the clock mode is set to Auto.
• Auto: Set the time zone automatically.
• Manual: Set the time zone manually.
✎
If you selected Manual, you can select whether to turn DST (Daylight Savings Time)
On or Off. (Depending on the country)
10
Setup Complete Review the Setup data, and then select Close to finish.
✎
The completed settings are displayed.
If You Want to Rerun Setup...
Menu → System → Setup
If You Want to Turn the Store Demo Mode On or Off.
To set or unset Store Demo mode outside of Setup, press the volume button on the product. When you see the volume
in the OSD, press and hold MENUm button on the product for 5 seconds.
If You Want to Reset This Feature...
Select System - Setup (Initial Setup). Enter your 4 digit PIN number. The default PIN number is “0-0-0-0”. If you want to
change the PIN number, use the Change PIN function. You should do Setup (Menu → System) again at home although
you did in shop.
✎
If you forget the PIN code, press the remote control buttons in the following sequence in Standby mode, which
resets the PIN to “0-0-0-0”: MUTE → 8 → 2 → 4 → POWER (on).
Getting Started
English - 24
Connecting to AV Devices (Blu-ray Players, DVD Players, etc.)
Using an HDMI Cable for an HD connection (up to 1080p, HD digital signals)
For the best quality HD picture, we recommend using an HDMI connection.
Use with DVD players, Blu-ray players, HD cable boxes, and HD Set-Top-Box satellite receivers.
HDMI OUT
HDMI Cable (Not Supplied)
✎
HDMI IN 1 (DVI), HDMI IN 2 (MHL / ARC)
• For the best picture and audio quality, connect digital devices to the product using HDMI cables.
• An HDMI cable supports digital video and audio signals, and does not require an audio cable.
– To connect the product to a digital device that does not support HDMI output, use an HDMI to DVI cable
and audio cables.
• If you connect an external device to the product that uses an older version of HDMI, the video and audio may
not work. If this occurs, ask the manufacturer of the device about the HDMI version and, if it is out of date,
request an upgrade.
• Be sure to purchase a certified HDMI cable. Otherwise, the picture may not display or a connection error may
occur.
• We recommend using a basic high-speed HDMI cable or an HDMI cable that is Ethernet compatible. Note that
this product does not support the Ethernet function via HDMI.
• This product supports the ARC (Audio Return Channel) functions via an HDMI cable. Note that the ARC function
is supported by the HDMI IN 2 (MHL / ARC) port only.
• The ARC function allows digital audio to output via the HDMI IN 2 (MHL / ARC) port on the product. It can be
enabled only when the product is connected with an audio receiver that supports the ARC function.
• This product supports the Mobile High-Definition Link (MHL) function via an HDMI-MHL cable. Note that the
MHL function is supported by the HDMI IN 2 (MHL / ARC) port only.
• The MHL function lets you display a mobile device's screen via the HDMI IN 2 (MHL / ARC) port on the
product. It can be enabled only when the product is connected with a mobile device that supports the MHL
function.
• When you use MHL devices via a MHL cable, Picture Size is set to Screen Fit automatically. But if
you use MHL devices via an HDMI cable, Picture Size is not set to Screen Fit automatically. To view
an original size, select Screen Fit in the Picture Size menu (Menu → Picture → Picture Size).
• If you use MHL devices via an HDMI cable, The product will be recognized as the HDMI input. In
this case, the product may work differently than when you use MHL devices via a MHL cable.
Device
English - 25
ConnectionsConnections
Using a Component Cable (up to 1080p HD signals) or an Audio/Video Cable (480i analog
signals only)
Use with DVD players, Blu-ray players, cable boxes, STB satellite receivers, VCRs.
R GB
R
W
R
W
R GB
R
W
R
B G
Y
R
W
R
W
Y
PR PB Y
COMPONENT OUT
AUDIO OUT
R-AUDIO-L
AUDIO OUT
R-AUDIO-L
VIDEO OUT
Device
Device
Audio Cable
(Not Supplied)
Component Cable
(Not Supplied)
Red
Red
Blue
White
Green
Audio Cable
(Not Supplied)
Video Cable
(Not Supplied)
✎
For better picture quality, we recommend the Component connection over the A/V connection.
✎
When you connect a Video cable to COMPONENT / AV IN, the colour of the COMPONENT / AV IN [VIDEO] jack
(green) will not match the video cable (yellow).
English - 26
Connections
Connecting to Audio Devices
Using an Optical (Digital) Cable and a Headphone Cable Connection
Use with Digital Audio Systems, Amplifiers, and Home Theatres.
OPTICAL
Headphone Cable
(Not Supplied)
Optical Cable
(Not Supplied)
✎
DIGITAL AUDIO OUT (OPTICAL)
• When you connect a Digital Audio System to the DIGITAL AUDIO OUT (OPTICAL) jack, decrease the volume
of both the product and the system.
• 5.1 CH (channel) audio is available when you connect the product to an external device supporting 5.1 CH.
• When the receiver (home theatre) is set to on, you can hear sound output from the product’s optical jack. When
the product is receiving a DTV signal, the product will send 5.1 CH sound to the home theatre receiver. When
the source is a digital component such as a DVD player / Blu-ray player / cable box / STB (Set-Top-Box) satellite
receiver and you connected it to the product via HDMI, you will only hear 2 CH audio from the home theatre
receiver. If you want to hear 5.1 CH audio, connect the digital audio out jack from your DVD / Blu-ray player /
cable box / STB satellite receiver directly to an amplifier or home theatre.
✎
Headphones H: You can connect your headphones to the headphone output jack on your product. While the
headphones are connected, the sound from the built-in speakers will be disabled.
• The sound function may be restricted when you connect headphones to the product.
• Headphone volume and product volume are adjusted separately.
• The earphone jack supports only the 3 conductor tip-ring-sleeve (TRS) type.
English - 27
Connections
The Service Cable Connection
The SERVICE connection is for service only.
Connecting to a PC
Using an HDMI Cable or an HDMI to DVI Cable or a D-sub Cable Connection
✎
Your PC may not suppor t an HDMI connection.
✎
Use your PC speakers for audio.
AUDIO OUT
DVI OUT
AUDIO OUT
PC OUT
HDMI OUT
HDMI Cable
(Not Supplied)
D-sub Cable
(Supplied)
HDMI to DVI Cable
(Not Supplied)
Stereo Cable
(Supplied)
✎
NOTE
• For an HDMI to DVI cable connection, you must use the HDMI IN 1 (DVI) jack.
• For PCs with DVI video out jacks, use an HDMI to DVI cable to connect the DVI out on the PC to the HDMI IN 1
(DVI) jack on the product. Use the PC's speakers for audio.
English - 28
Connections
Display Modes (HDMI/DVI Input)
The optimal PC display resolution for this product is 1920 x 1080 @ 60 Hz. We very strongly recommend you set the
video output of your computer to the optimal resolution. You can also select one of the standard resolutions listed in the
table below and the product will be automatically adjust to the resolution you choose. If you set your computer’s video
output to a resolution not listed in the table, the product screen may go blank and only the power indicator will turn on.
To resolve this issue, adjust the resolution according to the following table, referring to the user guide for the graphics
card.
Display Mode
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Pixel Clock
Frequency
(MHz)
Sync Polarity
(H / V)
Mode Resolution
IBM 720 x 400 70Hz 31.469 70.087 28.322 -/+
VESA DMT 640 x 480 60Hz 31.469 59.940 25.175 -/-
MAC 640 x 480 67Hz 35.000 66.667 30.240 -/-
VESA DMT 640 x 480 72Hz 37.861 72.809 31.500 -/-
VESA DMT 640 x 480 75Hz 37.500 75.000 31.500 -/-
VESA DMT 800 x 600 60Hz 37.879 60.317 40.000 +/+
VESA DMT 800 x 600 72Hz 48.077 72.188 50.000 +/+
VESA DMT 800 x 600 75Hz 46.875 75.000 49.500 +/+
MAC 832 X 624 75Hz 49.726 74.551 57.284 -/-
VESA DMT 1024 x 768 60Hz 48.363 60.004 65.000 -/-
VESA DMT 1024 x 768 70Hz 56.476 70.069 75.000 -/-
VESA DMT 1024 x 768 75Hz 60.023 75.029 78.750 +/+
VESA DMT 1151 x 864 75Hz 67.500 75.000 108.000 +/+
MAC 1151 x 864 75Hz 68.681 75.062 100.000 -/+
VESA DMT 1280 x 720 60Hz 45.000 60.000 74.250 +/+
VESA DMT 1280 x 800 60Hz 49.702 59.810 83.500 -/+
VESA DMT 1280 x 1024 60Hz 63.981 60.020 108.000 +/+
VESA DMT 1280 x 1024 75Hz 79.976 75.025 135.000 +/+
VESA DMT 1366 x 768 60Hz 47.712 59.790 85.500 +/+
VESA DMT 1440 x 900 60Hz 55.935 59.887 106.500 -/+
VESA DMT 1600 x 900RB 60Hz 60.000 60.000 108.000 +/+
VESA DMT 1680 x 1050 60Hz 65.290 59.954 146.250 -/+
VESA DMT 1920 x 1080 60Hz 67.500 60.000 148.500 +/+
✎
For an HDMI to DVI cable connection, you must use the HDMI IN 1 (DVI) jack.
✎
The interlace mode is not supported.
✎
The set may operate abnormally if you select a non-standard video format.
✎
Separate and Composite modes are supported. SOG(Sync On Green) is not supported.
✎
If there is no power cut-off switch, the power consumption is “0” only when the power cord is disconnected.
✎
DPM(Display Power Management) Function does not work if you used in connection with the HDMI port of this
product.
✎
If an HDMI to DVI cable is connected to the HDMI IN 1 (DVI) port, the audio does not work.
English - 29
Connections
Changing the Input Source
Source
™ → Source
When you are watching product and you want to watch a movie on your DVD player or Blu-ray player or switch to your
cable box or STB satellite receiver, you need to change the Source.
TV / PC / Intel® WiDi / HDMI1/DVI / HDMI2 / AV / Component
1. Press the ™ button on your remote. The Smart Hub screen appears.
2. Select Source. The Source screen appears.
3. Select a desired external input source.
✎
Alternatively, you can access the Source screen by selecting the SOURCEs button on your remote.
✎
You can only choose external devices that are connected to the product. In the displayed Source list, connected
inputs are highlighted.
✎
In the Source, Intel® WiDi and PC are always stays activated.
What is Intel® WiDi?
With WiDi display technology, you can pair the product with your laptop computer wirelessly. This technology is based
on the wireless LAN N series that is designed to transfer a high-quality signal of 720p or 1080p between wireless
devices.
This is useful especially if you want to connect your desktop or laptop computer to a bigger screen such as a product.
To implement the WiDi feature, your laptop computer must meet the requirements below.
(For compatibility with your laptop computer, contact the manufacturer of your laptop computer.)
✎
System Requirements
• Processor: Intel Core i3 Series
• Graphics: Intel HD graphics
• Wireless adapter
– Intel® Centrino® Wireless-N 1000, 1030
– Intel® Centrino® Advanced-N 6200, or 6230 6205
– Intel® Centrino® Wireless-N + WiMAX 6150
– Intel® Centrino® Advanced-N + WiMAX 6250
– Intel® Centrino® Ultimate-N 6300
• Software: Intel® My WiFi Technology (Intel® MWT) 2, Intel®wireless display are required to install
• Operating system: Windows 7 32 bit, 64 bit
English - 30
