SAMSUNG DVD-S128, DVD-S124 Service Manual Part List
Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark
Samsung Electronics
5-1
CN8 3708-001364 CONNECTOR-FPC/FFC/PIC;35P,1.25MM,STRAIGH
DC1 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
DC2 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
DCN1 3708-001696 CONNECTOR-FPC/FFC/PIC;24P,1MM,STRAIGHT,S
DCN2 3708-001695 CONNECTOR-FPC/FFC/PIC;13P,1MM,STRAIGHT,S
DCN3 3711-001018 CONNECTOR-HEADER;BOX,5P,1R,2mm,STRAIGHT,
DD1 0407-000116 DIODE-ARRAY;DAP202K,80V,100mA,CK2-3,SOTDQ1 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOTDQ2 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOTDQ3 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOTDR1 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
DR2 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
DR3 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
DR4 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
DR5 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
DR6 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
DR7 2007-000116 R-CHIP;120ohm,5%,1/16W,DA,TP,1608
DR8 2007-000116 R-CHIP;120ohm,5%,1/16W,DA,TP,1608
MC1 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
MC11 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
MC12 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
MC13 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
MC14 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
MC16 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
MC17 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
MC18 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
MC19 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
MC2 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
MC20 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
MC3 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
MC4 2203-000426 C-CERAMIC,CHIP;0.018nF,5%,50V,NP0,TP,160
MC5 2203-000426 C-CERAMIC,CHIP;0.018nF,5%,50V,NP0,TP,160
MC6 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
MC7 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
MC8 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
MC9 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
MIC1 0903-001271 IC-MICROCONTROLLER;91C829,16BIT,QFP,100P
MIC2 3704-000472 SOCKET-IC;32P,DIP,SN,2.54mm
MIC2B 1102-001090 IC-EPROM;27C081,1MX8BIT,DIP,32P,600MIL,
MIC4 1103-001204 IC-EEPROM;24C021,256x8Bit,SOP,8P,150MIL,
MIC5 0801-002097 IC-CMOS LOGIC;7ST08,AND GATE,SOP,5P,110M
MIC6 0801-002143 IC-CMOS LOGIC;7S32,OR GATE,SOT-23,5P,63M
MIC7 0801-002517 IC-CMOS LOGIC;7SET00,NAND GATE,SOP,5P,63
MR1 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
MR10 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
MR11 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
MR13 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
MR14 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
MR15 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
MR16 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
MR17 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
MR18 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
MR19 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
MR2 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
MR20 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
MR21 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
MR23 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
MR25 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
MR26 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
MR27 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
MR28 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
MR29 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
MR3 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
MR30 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
MR31 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
MR32 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
MR33 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
MR4 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
MR6 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
MR7 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
MR8 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
MR9 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
MY1 2802-001152 RESONATOR-CERAMIC;20MHZ,0.5%,TP,5.5X3.5X
PC1 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
PC2 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
PC3 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
PC4 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
PC5 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
PC6 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
PCN1 3711-001137 CONNECTOR-HEADER;BOX,8P,1R,2mm,STRAIGHT,
PE1 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
PE2 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
PE3 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
PE4 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
PE5 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
PIC1 1203-002178 IC-VOLTAGE REGULATOR;1563,SOP,7P,173MIL,
R1 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R2 2007-000080 R-CHIP;2Kohm,5%,1/16W,DA,TP,1608
R3 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
R4 2007-000671 R-CHIP;2KOHM,5%,1/10W,DA,TP,2012
RC1 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,
RC14 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
RC15 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
RC16 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
RC17 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
RC18 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
RC19 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,
RC2 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
RC20 2203-000236 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,1608
RC21 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,
RC22 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
RC23 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
RC24 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
RC26 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
RC27 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
RC3 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
RC30 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
RC31 2203-000236 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,1608
RC32 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
RC33 2203-005065 C-CERAMIC,CHIP;1000nF,+80-20%,10V,Y5V,TP
RC34 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,RC35 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
RC37 2203-000236 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,1608
RC38 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608
RC4 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
RC41 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
RC5 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
RC50 2203-001607 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,1608
5. Electrical Parts List
ASSY-PCB-MAIN
Loc.No Part No Description ; Specification RemarkLoc.No Part No Description ; Specification Remark
5-2
Samsung Electronics
Electrical Parts List
RC6 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
RC7 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
RC8 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
RE1 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
RE10 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11,5
RE12 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11,5
RE13 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
RE14 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
RE22 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
RE29 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
RE39 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
RE40 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
RE41 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
RIC1 AH13-00009A IC ASIC;KS1462B,DVD-M201/XAA,80,+5V,-4
RL11 3301-000314 CORE-FERRITE BEAD;AB,120ohm,1.6x0.8x0.8m
RL3 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
RQ1 0501-000279 TR-SMALL SIGNAL;KSA1182-Y,PNP,150mW,SOTRQ2 0501-000279 TR-SMALL SIGNAL;KSA1182-Y,PNP,150mW,SOTRR1 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
RR10 2007-000312 R-CHIP;10OHM,5%,1/8W,DA,TP,3216
RR12 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RR13 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RR14 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
RR15 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RR16 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RR2 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
RR21 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
RR22 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
RR23 2007-000655 R-CHIP;27Kohm,5%,1/16W,DA,TP,1608
RR24 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
RR25 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RR26 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RR3 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
RR32 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RR33 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RR34 2007-000087 R-CHIP;6.8Kohm,5%,1/16W,DA,TP,1608
RR36 2007-001235 R-CHIP;910Kohm,5%,1/16W,DA,TP,1608
RR4 2007-001179 R-CHIP;8.2Kohm,5%,1/16W,DA,TP,1608
RR6 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
RR7 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
RR8 2007-000312 R-CHIP;10OHM,5%,1/8W,DA,TP,3216
RR9 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
SC10 2203-001634 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,1608,
SC11 2203-000715 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,1608
SC12 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608
SC13 2203-001652 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP,
SC14 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
SC15 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC16 2203-002398 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,1608
SC17 2203-001126 C-CERAMIC,CHIP;0.68nF,10%,50V,X7R,TP,160
SC18 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC19 2203-002398 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,1608
SC2 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC20 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC21 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC23 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
SC24 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
SC25 2203-000372 C-CERAMIC,CHIP;15nF,10%,50V,X7R,TP,1608,
SC26 2203-000372 C-CERAMIC,CHIP;15nF,10%,50V,X7R,TP,1608,
SC27 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
SC28 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
SC29 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
SC30 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
SC32 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
SC33 2203-000681 C-CERAMIC,CHIP;0.027nF,5%,50V,NP0,TP,160
SC34 2203-000681 C-CERAMIC,CHIP;0.027nF,5%,50V,NP0,TP,160
SC35 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
SC36 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
SC37 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
SC38 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
SC39 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
SC40 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
SC41 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
SC42 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
SC43 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
SC44 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
SC45 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC46 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
SC47 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
SC48 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
SC49 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC50 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC51 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC52 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC54 2203-001222 C-CERAMIC,CHIP;820pF,10%,50V,X7R,TP,1608
SC55 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC56 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC57 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC58 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC59 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC60 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC61 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC62 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC63 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC7 2203-001222 C-CERAMIC,CHIP;820pF,10%,50V,X7R,TP,1608
SC8 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC9 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
SC90 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
SE1 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
SE10 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
SE11 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
SE2 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
SE3 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
SE4 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
SE6 2401-001225 C-AL;4.7uF,20%,16V,GP,TP,3x5,5
SE7 2401-001225 C-AL;4.7uF,20%,16V,GP,TP,3x5,5
SE8 2401-001225 C-AL;4.7uF,20%,16V,GP,TP,3x5,5
SE9 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
SIC1 AH13-00006A IC ASIC;KS1454,DVD-611/XAA,160,+3.3V,+
SIC2 1105-001243 IC-DRAM;416C256,256KX16BIT,SOJ,40P,400
SIC3 1003-001298 IC-MOTOR DRIVER;KA3017,HQFP,48P,550MIL,1
SIC4 0801-002097 IC-CMOS LOGIC;7ST08,AND GATE,SOP,5P,110M
SQ1 0504-000156 TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT
SR1 2007-000381 R-CHIP;13Kohm,5%,1/16W,DA,TP,1608
SR14 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
SR15 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
SR16 2007-000133 R-CHIP;330Kohm,5%,1/16W,DA,TP,1608
SR18 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
SR19 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
SR20 2007-001235 R-CHIP;910Kohm,5%,1/16W,DA,TP,1608
SR21 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
SR23 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
SR24 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
SR25 2007-000093 R-CHIP;20Kohm,5%,1/16W,DA,TP,1608
SR26 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
SR27 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
SR29 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
SR30 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
SR31 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
SR32 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
SR4 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
SR40 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark
Electrical Parts List
Samsung Electronics
5-3
SR44 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
SR48 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
SR49 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
SR50 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
SR51 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
SR55 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
SR56 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
SR57 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
SR58 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
SR59 2007-000087 R-CHIP;6.8Kohm,5%,1/16W,DA,TP,1608
SR60 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
SR61 2007-000107 R-CHIP;470Kohm,5%,1/16W,DA,TP,1608
SR67 2007-000034 R-CHIP;1OHM,5%,1/4W,DA,TP,3216
SR68 2007-000034 R-CHIP;1OHM,5%,1/4W,DA,TP,3216
SR69 2007-000655 R-CHIP;27Kohm,5%,1/16W,DA,TP,1608
SR70 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
SR71 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
SR72 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
SR73 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
SR74 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
SR75 2007-000093 R-CHIP;20Kohm,5%,1/16W,DA,TP,1608
SR76 2007-000093 R-CHIP;20Kohm,5%,1/16W,DA,TP,1608
SR77 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
SR79 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
SR8 2007-000799 R-CHIP;360ohm,5%,1/16W,DA,TP,1608
SR80 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
SR9 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
SW2 3404-001203 SWITCH-TACT;12V DC,50MA,100GF,6.55X7.5,S
DVD-S124/S126/S126G/S127/S128/S223/S224/S227/S228/S1515 ONLY
SY1 2801-000261 CRYSTAL-UNIT;33.8688MHz,50ppm,28-AAA,12p
VR1 2104-001068 VR-SMD;10Kohm,25%,1/20W,TOP
ZC1 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC10 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC11 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC12 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC13 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC14 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC15 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC16 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC17 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC18 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC19 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC2 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC29 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC3 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC37 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC38 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC39 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC4 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
ZC40 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC41 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC42 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC43 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
ZC44 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC45 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC46 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC47 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC48 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC49 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC5 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
ZC50 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC51 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC56 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
ZC58 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,ZC59 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
ZC6 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
ZC60 2203-000681 C-CERAMIC,CHIP;0.027nF,5%,50V,NP0,TP,160
ZC61 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
ZC62 2203-000681 C-CERAMIC,CHIP;0.027nF,5%,50V,NP0,TP,160
ZC63 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
ZC66 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
ZC67 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
ZC68 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
ZC69 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC7 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC70 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC78 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
ZC8 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZC81 2203-000815 C-CERAMIC,CHIP;0.033nF,5%,50V,NP0,TP,160
ZC82 2203-000815 C-CERAMIC,CHIP;0.033nF,5%,50V,NP0,TP,160
ZC83 2203-000815 C-CERAMIC,CHIP;0.033nF,5%,50V,NP0,TP,160
ZC84 2203-000815 C-CERAMIC,CHIP;0.033nF,5%,50V,NP0,TP,160
ZC9 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
ZD1 0402-000309 DIODE-RECTIFIER;1SR154-400,400V,1A,SOD-1
ZE30 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
ZE34 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
ZE36 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
ZE37 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
ZIC1 1204-001919 IC-DECODER;ZIVA4.1 B0,QFP,208P,28X28MM,P
ZIC2 1105-001305 IC-DRAM;4S641632,1Mx16x4Bit,TSOP,54P,4
ZIC4 AH14-10004R IC;M74HCU04,SOP,TAPE 14P
ZL10 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
ZL12 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
ZL13 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m
ZL14 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m
ZL15 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m
ZL16 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m
ZL2 3301-000314 CORE-FERRITE BEAD;AB,120ohm,1.6x0.8x0.8m
ZL5 2007-000607 R-CHIP;240OHM,5%,1/10W,DA,TP,2012
ZL6 3301-000314 CORE-FERRITE BEAD;AB,120ohm,1.6x0.8x0.8m
ZL7 3301-000314 CORE-FERRITE BEAD;AB,120ohm,1.6x0.8x0.8m
ZL9 3301-000314 CORE-FERRITE BEAD;AB,120ohm,1.6x0.8x0.8m
ZR10 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
ZR16 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
ZR17 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
ZR18 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
ZR2 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608
ZR23 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
ZR27 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
ZR28 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
ZR29 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
ZR3 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608
ZR35 3301-001309 CORE-FERRITE BEAD;AB,47ohm,1.6x0.8x0.8mm
ZR4 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608
ZR5 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608
ZR6 2007-001164 R-CHIP;75ohm,1%,1/16W,DA,TP,1608
ZR68 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
ZR69 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
ZR7 2007-001164 R-CHIP;75ohm,1%,1/16W,DA,TP,1608
ZR70 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
ZR72 2011-000816 R-NETWORK;100ohm,5%,63mW,L,CHIP,8P,TP
ZR73 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
ZR74 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
ZR75 2007-001164 R-CHIP;75ohm,1%,1/16W,DA,TP,1608
ZR76 2007-001164 R-CHIP;75ohm,1%,1/16W,DA,TP,1608
ZR77 2007-001164 R-CHIP;75ohm,1%,1/16W,DA,TP,1608
ZR78 2007-001164 R-CHIP;75ohm,1%,1/16W,DA,TP,1608
ZR79 2007-007332 R-CHIP;1.18KOHM,1%,1/10W,DA,TP,2012
ZR8 2007-001164 R-CHIP;75ohm,1%,1/16W,DA,TP,1608
ZR84 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
ZR86 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
ZR88 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
ZR89 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
ZR9 2007-001164 R-CHIP;75ohm,1%,1/16W,DA,TP,1608
ZR91 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
ZR92 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
ZR93 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
ZR94 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
ZR95 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
ZR96 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
ZY1 2801-003554 CRYSTAL-UNIT;27MHz,10ppm,28-AAM,12pF,40o
SW2 3404-001203 SWITCH-TACT;12V DC,50MA,100GF,6.55X7.5,S
AC201 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
AC202 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
AC203 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
AC204 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
AC401 2203-000495 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,2012
AC402 2203-000839 C-CERAMIC,CHIP;0.39nF,5%,50V,NP0,TP,2012
AC403 2203-000495 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,2012
AC404 2203-000839 C-CERAMIC,CHIP;0.39nF,5%,50V,NP0,TP,2012
AC407 2203-000126 C-CERAMIC,CHIP;1.2nF,10%,50V,X7R,TP,2012
AC408 2203-000126 C-CERAMIC,CHIP;1.2nF,10%,50V,X7R,TP,2012
AC409 2203-000316 C-CERAMIC,CHIP;0.12nF,5%,50V,NP0,TP,2012
AC410 2203-000316 C-CERAMIC,CHIP;0.12nF,5%,50V,NP0,TP,2012
AC413 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC9 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
ACC2 2203-000595 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,2012
ACC3 2203-000595 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,2012
AD1 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOTAD2 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOTAD51 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOTAD54 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
AD55 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
AE01 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
AE02 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
AE201 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
AE401 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11,5
AE402 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11,5
AE403 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11,5
AE406 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE407 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE51 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
AE52 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
AE6 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11,5
AE9 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11,5
AIC3 AH14-10004R IC;M74HCU04,SOP,TAPE 14P
AIC4 1002-001294 IC-D/A CONVERTER;PCM1742KE,24BIT,TSSOP,1
AL01 3301-000353 CORE-FERRITE BEAD;AB,120ohm,2x1.25x0.9mm
AL02 3301-000353 CORE-FERRITE BEAD;AB,120ohm,2x1.25x0.9mm
AL201 2901-001125 FILTER-EMI ON BOARD;50V,0.5A,-,220pF,7x2
AOP1 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/m
AQ1 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
AQ3 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
AQ4 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP
AQ5 0504-000156 TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT
AQ51 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP
AQ52 0504-000156 TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT
AQ55 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23,
AQ6 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP
AQ7 0504-000156 TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT
AR201 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
AR202 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR203 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR21 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
AR22 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
AR24 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR26 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR35 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
AR36 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
AR38 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR4 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
AR40 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR405 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
AR406 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
Loc.No Part No Description ; Specification Remark
5-4
Samsung Electronics
Electrical Parts List
Loc.No Part No Description ; Specification Remark
ASSY-PCB-JACK
Models ; DVD-S126/S126G/S127/S128/S23/S224/S227/S1515
AR409 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
AR410 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
AR411 2007-000221 R-CHIP;1.2KOHM,5%,1/10W,DA,TP,2012
AR412 2007-000221 R-CHIP;1.2KOHM,5%,1/10W,DA,TP,2012
AR5 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR51 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
AR54 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
AR55 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
AR56 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
AVJ1 3722-001469 JACK-PIN;3P/4P,3.2mm,NI,BLK,AVJ2 3722-001467 JACK-PIN;3P,3.2mm,NI,BLK,AVJ4 3722-001516 JACK-PIN;1P,3.5mm,NI,BLK,AVJ5 3707-001052 CONNECTOR-OPTICAL;PLUG,GP1FA550TZ,6dB,2.
CN1 3708-001364 CONNECTOR-FPC/FFC/PIC;35P,1.25MM,STRAIGH
FC23 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP
FC24 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP
FC25 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP
FC27 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
FC28 2202-000173 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,1
FC7 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
FD7 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
FD9 0403-000551 DIODE-ZENER;MTZ3.9B,3.9V,3.89-4.16V,500m
FE10 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
FE7 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
FE8 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
FE9 2401-001507 C-AL;47uF,20%,16V,GP,TP,6.3x5,5
FEYE AH59-00010A MODULE REMOCON;-,-,37.9KHZ,940NM,-,-,FIC1 AH09-00061L IC MICOM;GM581C2020,-,64PIN,2.7TO 5.5V,
FIC7 1203-001252 IC-VOL. DETECTOR;7545,TO-92,3P,-,PLASTIC
FKR61 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FL01 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
FQ54 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
FR07 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR071 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR072 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR1 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR16 2001-000027 R-CARBON;100OHM,5%,1/4W,AA,TP,2.4X6.4MM
FR17 2001-000027 R-CARBON;100OHM,5%,1/4W,AA,TP,2.4X6.4MM
FR19 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR2 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR20 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR21 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M
FR22 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M
FR23 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR24 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR25 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR28 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR281 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M
FR29 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR3 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR4 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR5 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR54 2001-000490 R-CARBON;200OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR541 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR55 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR56 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR59 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR6 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR60 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FY1 2802-001094 RESONATOR-CERAMIC;4.0MHz,0.5%,TP,8x3x5.5
LED54 0601-001447 LED;ROUND,RED,3.1mm,650nm
PBD11 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,
PBS01 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,
PCD01 2201-000916 C-CERAMIC,DISC;100pF,10%,400V,Y5U,TP,10x
PCD02 2201-000812 C-CERAMIC,DISC;2.2nF,20%,400V,Y5U,BK,12.
PCD03 2201-000812 C-CERAMIC,DISC;2.2nF,20%,400V,Y5U,BK,12.
PCD11 2305-001029 C-FILM,MPEF;10nF,10%,630V,TP,12x9x12.5,5
PCD12 2201-000129 C-CERAMIC,DISC;0.1nF,10%,1kV,Y5P,TP,7x4,
PCF01 2305-001021 C-FILM,MPEF;100nF,20%,275V,TP,17.5x7x13.
PCF02 2305-001021 C-FILM,MPEF;100nF,20%,275V,TP,17.5x7x13.
PCF13 2201-000376 C-CERAMIC,DISC;0.22nF,5%,50V,SL,TP,6.3x3
PCNS1 AH39-00403A CONNECT WIRE;-,#26,-,-,-,WHT/BLK,-,-,-,PCNS2 3711-000178 CONNECTOR-HEADER;1WALL,2P,1R,3.96mm,STRA
PCS03 2201-000916 C-CERAMIC,DISC;100pF,10%,400V,Y5U,TP,10x
PCS32 2301-000129 C-FILM,PEF;100nF,5%,50V,TP,10X9X4.3X5,5m
PDD35 0402-001195 DIODE-RECTIFIER;F1T4,400V,1.0A,TS-1,TP
PDE31 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
PDF01 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
PDF13 0402-001195 DIODE-RECTIFIER;F1T4,400V,1.0A,TS-1,TP
PDL55 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
PDS01 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
PDS02 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
PDS03 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
PDS04 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
PDS11 0402-000012 DIODE-RECTIFIER;UF4007,1KV,1A,DO-41,TP
PDS31 0402-001195 DIODE-RECTIFIER;F1T4,400V,1.0A,TS-1,TP
PDS32 0402-001194 DIODE-RECTIFIER;UG2D,200V,2A,DO-204AC,TP
PDS33 0402-001438 DIODE-RECTIFIER;SHK55-65,60V,3A,AXIAL,BK
PDS34 0402-001438 DIODE-RECTIFIER;SHK55-65,60V,3A,AXIAL,BK
PDS36 0402-001195 DIODE-RECTIFIER;F1T4,400V,1.0A,TS-1,TP
PDS51 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
PDS52 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
PDS53 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
PEE31 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
PEF10 2401-001682 C-AL;82uF,20%,400V,GP,BK,22x25,10
PEF12 2401-000463 C-AL;10uF,20%,35V,GP,-,5x5,2mm
PES31 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
PES32 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
PES33 2401-003059 C-AL;1000UF,20%,16V,WT,TP,10X16,5
PES34 2401-003785 C-AL;1000UF,20%,16V,WT,TP,10X20MM,5
PES35 2401-003046 C-AL;47uF,20%,50V,WT,TP,6.3x11,2.5
PES36 2401-001353 C-AL;470uF,20%,10V,GP,TP,8x11.5,5
PES37 2401-002042 C-AL;220uF,20%,10V,GP,TP,6.3x11,5
PES51 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
PES52 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
PES53 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
PES54 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
PES56 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
PES57 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
PES58 2401-001353 C-AL;470uF,20%,10V,GP,TP,8x11.5,5
PFD01 3601-001123 FUSE-CARTRIDGE;250V,1.6A,TIME-LAG,CERAMI
PICF1 1203-002063 IC-PWM CONTROLLER;STR-G6351,TO-220F,5P,PICS1 0604-000186 PHOTO-COUPLER;TR,-,200mW,DIP-4,ST
PICS2 AC14-12006D IC;KA431Z,TO-92,TAPING
PICS3 1203-000122 IC-NEGA.FIXED REG.;7908,TO-220,3P,-,PLAS
PICS4 1203-000295 IC-POSI.FIXED REG.;7808,TO-220,3P,-,PLAS
PICS5 1203-002185 IC-VOLTAGE REGULATOR;3RD13,TO-220,4P,402
PLF01 AC29-30050B FILTER-LINE NOISE;-,400uH,-,AC250V,TR12.
PLS01 AC29-00003A FILTER LINE NOISE;-,20mH MIN,-,-,PLS31 AC27-12001N COIL-CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,PQE31 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L
PQS55 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T
PQS56 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TOPQS57 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L
PQS58 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L
PRD12 2003-000148 R-METAL OXIDE;100ohm,5%,2W,AE,TP,6x16mm
PRD31 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
PRD32 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
PRE31 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
PRF01 2002-000121 R-COMPOSITION;1Mohm,10%,1/2W,AA,TP,3.5x9
PRF10 2006-000262 R-CEMENT;2.7ohm,10%,2W,CB,TP,7.5x11x20.
PRF11 2001-000076 R-CARBON;47KOHM,5%,1/4W,AA,TP,2.4X6.4MM
Electrical Parts List
Samsung Electronics
5-5
Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark
PRF12 2001-000076 R-CARBON;47KOHM,5%,1/4W,AA,TP,2.4X6.4MM
PRF13 2001-000076 R-CARBON;47KOHM,5%,1/4W,AA,TP,2.4X6.4MM
PRF14 2001-000954 R-CARBON;750KOHM,5%,1/8W,AA,TP,1.8X3.2M
PRF16 2001-000490 R-CARBON;200OHM,5%,1/8W,AA,TP,1.8X3.2MM
PRF17 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2M
PRF19 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PRF20 2003-000105 R-METAL OXIDE;0.33ohm,5%,2W,AD,TP,6x16mm
PRF99 2003-000148 R-METAL OXIDE;100ohm,5%,2W,AE,TP,6x16mm
PRS11 2003-001040 R-METAL OXIDE(S);47Kohm,5%,2W,AF,TP,3.9x
PRS12 2003-001040 R-METAL OXIDE(S);47Kohm,5%,2W,AF,TP,3.9x
PRS31 2001-000440 R-CARBON;1OHM,5%,1/8W,AA,TP,1.8X3.2MM
PRS32 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PRS33 2004-000869 R-METAL;3Kohm,1%,1/8W,AA,TP,1.8x3.2mm
PRS34 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m
PRS54 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
PRS55 2001-000062 R-CARBON;470OHM,5%,1/4W,AA,TP,2.4X6.4MM
PTD1 AK26-00002A TRANS SWITCHING;SELLINO,FREE,-,110V~240V
PVA1 1405-000186 VARISTOR;470V,2500A,17.5x7.5mm,TP
PZE31 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D
PZS51 0403-000717 DIODE-ZENER;MTZJ5.1B,5.1V,4.94-5.2V,500m
SCIC2 AH14-10004T IC-ANALOG M/PLEXER;MC14053BD,SOP,TAPE 16
SVJ1 3722-001375 JACK-DIN;4P,-,NI,BLK,SW1 3404-001164 SWITCH-TACT;12V DC,50MA,100GF,7X7X6.7MM,
VC1 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
VC106 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
VC11 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
VC12 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
VC13 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
VC14 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
VC15 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
VC3 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
VC5 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
VC6 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
VE1 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
VE11 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
VE12 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
VE3 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
VE5 2401-001479 C-AL;470uF,20%,10V,GP,TP,-,VE7 2401-001479 C-AL;470uF,20%,10V,GP,TP,-,VE9 2401-001479 C-AL;470uF,20%,10V,GP,TP,-,VFD1 AH07-00074A VF DISPLAY;-,DVD-M201,75X20.5MM,1/9,8,10
VIC1 1201-001836 IC-VIDEO AMP;MM1567AJBE,SOP,34P,300MIL,VJ1 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
VJ2 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
VJ3 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
VJ4 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
VJ8 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
VL1 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
VR11 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
VR12 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
VR121 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
VR123 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
VR13 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
VR14 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
VR15 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
VR16 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
VR21 2007-001166 R-CHIP;75OHM,5%,1/10W,DA,TP,2012
VR22 2007-001166 R-CHIP;75OHM,5%,1/10W,DA,TP,2012
VR23 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
VSW1 AH34-00010A SWITCH SLIDE;-,50V DC,-,-,100MOHM,-,-,-,
AC201 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
AC202 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
AC203 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
AC204 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
AC401 2203-000495 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,2012
AC402 2203-000839 C-CERAMIC,CHIP;0.39nF,5%,50V,NP0,TP,2012
AC403 2203-000495 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,2012
AC404 2203-000839 C-CERAMIC,CHIP;0.39nF,5%,50V,NP0,TP,2012
AC407 2203-000126 C-CERAMIC,CHIP;1.2nF,10%,50V,X7R,TP,2012
AC408 2203-000126 C-CERAMIC,CHIP;1.2nF,10%,50V,X7R,TP,2012
AC409 2203-000316 C-CERAMIC,CHIP;0.12nF,5%,50V,NP0,TP,2012
AC410 2203-000316 C-CERAMIC,CHIP;0.12nF,5%,50V,NP0,TP,2012
AC413 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC9 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
ACC1 2203-000595 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,2012
ACC2 2203-000595 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,2012
ACC3 2203-000595 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,2012
ACC4 2203-000595 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,2012
AD1 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOTAD2 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOTAD51 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOTAD54 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
AD55 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
AE01 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
AE02 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
AE201 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
AE401 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11,5
AE402 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11,5
AE403 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11,5
AE406 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE407 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE51 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
AE52 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
AE6 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11,5
AE9 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11,5
AIC3 AH14-10004R IC;M74HCU04,SOP,TAPE 14P
AIC4 1002-001294 IC-D/A CONVERTER;PCM1742KE,24BIT,TSSOP,1
AL01 3301-000353 CORE-FERRITE BEAD;AB,120ohm,2x1.25x0.9mm
AL02 3301-000353 CORE-FERRITE BEAD;AB,120ohm,2x1.25x0.9mm
AL201 2901-001125 FILTER-EMI ON BOARD;50V,0.5A,-,220pF,7x2
AOP1 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/m
AQ1 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
AQ3 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
AQ4 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP
AQ5 0504-000156 TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT
AQ51 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP
AQ52 0504-000156 TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT
AQ55 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23,
AQ6 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP
AQ7 0504-000156 TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT
AR201 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
AR202 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR203 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR21 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
AR22 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
AR24 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR25 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR26 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR35 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
AR36 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
AR38 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR39 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
Loc.No Part No Description ; Specification Remark
5-6
Samsung Electronics
Electrical Parts List
Loc.No Part No Description ; Specification Remark
ASSY-PCB-JACK
Models ; DVD-S323/S327
AR4 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
AR40 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR405 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
AR406 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
AR409 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
AR410 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
AR411 2007-000221 R-CHIP;1.2KOHM,5%,1/10W,DA,TP,2012
AR412 2007-000221 R-CHIP;1.2KOHM,5%,1/10W,DA,TP,2012
AR5 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR51 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
AR54 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
AR55 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
AR56 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
AVJ1 3722-001469 JACK-PIN;3P/4P,3.2mm,NI,BLK,AVJ2 3722-001464 JACK-PIN;6P,3.2mm,NI,BLK,AVJ4 3722-001516 JACK-PIN;1P,3.5mm,NI,BLK,AVJ5 3707-001052 CONNECTOR-OPTICAL;PLUG,GP1FA550TZ,6dB,2.
CN1 3708-001364 CONNECTOR-FPC/FFC/PIC;35P,1.25MM,STRAIGH
CN3 AH39-00309A CONNECT WIRE;-,UL1007,#26,UL1007,#26,7P,
FC23 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP
FC24 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP
FC25 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP
FC27 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
FC28 2202-000173 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,1
FC7 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
FD7 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
FD9 0403-000551 DIODE-ZENER;MTZ3.9B,3.9V,3.89-4.16V,500m
FE10 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
FE7 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
FE8 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
FE9 2401-001507 C-AL;47uF,20%,16V,GP,TP,6.3x5,5
FEYE AH59-00010A MODULE REMOCON;-,-,37.9KHZ,940NM,-,-,FIC1 AH09-00061K IC MICOM;GM581C2020,-,64PIN,2.7TO 5.5V,
FIC7 1203-001252 IC-VOL. DETECTOR;7545,TO-92,3P,-,PLASTIC
FKR61 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FL01 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
FQ29 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
FQ54 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
FR07 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR071 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR072 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR1 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR16 2001-000027 R-CARBON;100OHM,5%,1/4W,AA,TP,2.4X6.4MM
FR17 2001-000027 R-CARBON;100OHM,5%,1/4W,AA,TP,2.4X6.4MM
FR19 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR2 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR20 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR21 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M
FR22 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M
FR23 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR24 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR25 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR28 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR281 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M
FR29 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR291 2001-000490 R-CARBON;200OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR3 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR4 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR5 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR54 2001-000490 R-CARBON;200OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR541 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR55 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR56 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR59 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR6 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR60 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FY1 2802-001094 RESONATOR-CERAMIC;4.0MHz,0.5%,TP,8x3x5.5
HC21 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
HC22 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
HC41 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
HC42 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
HC5 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
HC6 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
HCC1 2202-000173 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,1
HCC2 2202-000173 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,1
HE21 2401-002075 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
HE22 2401-002075 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
HE41 2401-002075 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
HE42 2401-002075 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
HL1 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
HL2 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
HOP1 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/m
HOP2 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/m
HR1 2001-000666 R-CARBON;33OHM,5%,1/8W,AA,TP,1.8X3.2MM
HR15 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
HR16 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
HR26 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
HR29 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
HR4 2001-000666 R-CARBON;33OHM,5%,1/8W,AA,TP,1.8X3.2MM
HR41 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
HR44 2001-000800 R-CARBON;5.1KOHM,5%,1/8W,AA,TP,1.8X3.2M
HR45 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3.2MM
HR46 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
HR48 2001-000800 R-CARBON;5.1KOHM,5%,1/8W,AA,TP,1.8X3.2M
HR49 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3.2MM
HRR1 2001-000527 R-CARBON;22OHM,5%,1/8W,AA,TP,1.8X3.2MM
HRR2 2001-000527 R-CARBON;22OHM,5%,1/8W,AA,TP,1.8X3.2MM
KHR23 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
KHR30 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
KHR32 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
KVR1 2101-001090 VR-ROTARY;20KOHM,20%,1/20W,SIDE
LED54 0601-001587 LED;ROUND,RED,3.1MM,635NM
MIC2 3722-001465 JACK-PHONE;3P,6.43PI,AG,BLK,PBD11 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,
PBS01 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,
PCD01 2201-000916 C-CERAMIC,DISC;100pF,10%,400V,Y5U,TP,10x
PCD02 2201-000812 C-CERAMIC,DISC;2.2nF,20%,400V,Y5U,BK,12.
PCD03 2201-000812 C-CERAMIC,DISC;2.2nF,20%,400V,Y5U,BK,12.
PCD11 2305-001029 C-FILM,MPEF;10nF,10%,630V,TP,12x9x12.5,5
PCD12 2201-000129 C-CERAMIC,DISC;0.1nF,10%,1kV,Y5P,TP,7x4,
PCF01 2305-001021 C-FILM,MPEF;100nF,20%,275V,TP,17.5x7x13.
PCF02 2305-001021 C-FILM,MPEF;100nF,20%,275V,TP,17.5x7x13.
PCF13 2201-000376 C-CERAMIC,DISC;0.22nF,5%,50V,SL,TP,6.3x3
PCNS1 AH39-00403A CONNECT WIRE;-,#26,-,-,-,WHT/BLK,-,-,-,PCNS2 3711-000178 CONNECTOR-HEADER;1WALL,2P,1R,3.96mm,STRA
PCS03 2201-000916 C-CERAMIC,DISC;100pF,10%,400V,Y5U,TP,10x
PCS32 2301-000129 C-FILM,PEF;100nF,5%,50V,TP,10X9X4.3X5,5m
PDD35 0402-001195 DIODE-RECTIFIER;F1T4,400V,1.0A,TS-1,TP
PDE31 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
PDF01 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
PDF13 0402-001195 DIODE-RECTIFIER;F1T4,400V,1.0A,TS-1,TP
PDL55 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
PDS01 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
PDS02 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
PDS03 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
PDS04 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
PDS11 0402-000012 DIODE-RECTIFIER;UF4007,1KV,1A,DO-41,TP
PDS31 0402-001195 DIODE-RECTIFIER;F1T4,400V,1.0A,TS-1,TP
PDS32 0402-001194 DIODE-RECTIFIER;UG2D,200V,2A,DO-204AC,TP
PDS33 0402-001438 DIODE-RECTIFIER;SHK55-65,60V,3A,AXIAL,BK
PDS34 0402-001438 DIODE-RECTIFIER;SHK55-65,60V,3A,AXIAL,BK
PDS36 0402-001195 DIODE-RECTIFIER;F1T4,400V,1.0A,TS-1,TP
Electrical Parts List
Samsung Electronics
5-7
Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark
PDS51 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
PDS52 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
PDS53 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
PEE31 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
PEF10 2401-001682 C-AL;82uF,20%,400V,GP,BK,22x25,10
PEF12 2401-000463 C-AL;10uF,20%,35V,GP,-,5x5,2mm
PES31 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
PES32 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
PES33 2401-003480 C-AL;1000UF,20%,10V,LZ,TP,10X16MM,5
PES34 2401-003785 C-AL;1000UF,20%,16V,WT,TP,10X20MM,5
PES35 2401-003046 C-AL;47uF,20%,50V,WT,TP,6.3x11,2.5
PES36 2401-001353 C-AL;470uF,20%,10V,GP,TP,8x11.5,5
PES37 2401-002042 C-AL;220uF,20%,10V,GP,TP,6.3x11,5
PES51 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
PES52 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
PES53 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
PES54 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
PES56 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
PES57 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
PES58 2401-001353 C-AL;470uF,20%,10V,GP,TP,8x11.5,5
PFD01 3601-001123 FUSE-CARTRIDGE;250V,1.6A,TIME-LAG,CERAMI
PICF1 1203-002063 IC-PWM CONTROLLER;STR-G6351,TO-220F,5P,PICS1 0604-000186 PHOTO-COUPLER;TR,-,200mW,DIP-4,ST
PICS2 AC14-12006D IC;KA431Z,TO-92,TAPING
PICS3 1203-000122 IC-NEGA.FIXED REG.;7908,TO-220,3P,-,PLAS
PICS4 1203-000293 IC-POSI.FIXED REG.;7808,TO-220,3P,-,PLAS
PICS5 1203-002185 IC-VOLTAGE REGULATOR;3RD13,TO-220,4P,402
PLF01 AC29-30050B FILTER-LINE NOISE;-,400uH,-,AC250V,TR12.
PLS01 AC29-00003A FILTER LINE NOISE;-,20mH MIN,-,-,PLS31 AC27-12001N COIL-CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,PQE31 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L
PQS55 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T
PQS56 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TOPQS57 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L
PQS58 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L
PRD12 2003-000148 R-METAL OXIDE;100ohm,5%,2W,AE,TP,6x16mm
PRD31 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
PRD32 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
PRE31 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
PRF01 2002-000121 R-COMPOSITION;1Mohm,10%,1/2W,AA,TP,3.5x9
PRF10 2006-000262 R-CEMENT;2.7ohm,10%,2W,CB,TP,7.5x11x20.
PRF11 2001-000076 R-CARBON;47KOHM,5%,1/4W,AA,TP,2.4X6.4MM
PRF12 2001-000076 R-CARBON;47KOHM,5%,1/4W,AA,TP,2.4X6.4MM
PRF13 2001-000076 R-CARBON;47KOHM,5%,1/4W,AA,TP,2.4X6.4MM
PRF14 2001-000954 R-CARBON;750KOHM,5%,1/8W,AA,TP,1.8X3.2M
PRF16 2001-000490 R-CARBON;200OHM,5%,1/8W,AA,TP,1.8X3.2MM
PRF17 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2M
PRF19 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PRF20 2003-000105 R-METAL OXIDE;0.33ohm,5%,2W,AD,TP,6x16mm
PRF99 2003-000148 R-METAL OXIDE;100ohm,5%,2W,AE,TP,6x16mm
PRS11 2003-001040 R-METAL OXIDE(S);47Kohm,5%,2W,AF,TP,3.9x
PRS12 2003-001040 R-METAL OXIDE(S);47Kohm,5%,2W,AF,TP,3.9x
PRS31 2001-000440 R-CARBON;1OHM,5%,1/8W,AA,TP,1.8X3.2MM
PRS32 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
PRS33 2004-000869 R-METAL;3Kohm,1%,1/8W,AA,TP,1.8x3.2mm
PRS34 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m
PRS54 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
PRS55 2001-000062 R-CARBON;470OHM,5%,1/4W,AA,TP,2.4X6.4MM
PTD1 AK26-00002A TRANS SWITCHING;SELLINO,FREE,-,110V~240V
PVA1 1405-000186 VARISTOR;470V,2500A,17.5x7.5mm,TP
PZE31 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D
PZS51 0403-000717 DIODE-ZENER;MTZJ5.1B,5.1V,4.94-5.2V,500m
SVJ1 3722-001375 JACK-DIN;4P,-,NI,BLK,SW1 3404-001164 SWITCH-TACT;12V DC,50MA,100GF,7X7X6.7MM,
VC1 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
VC106 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
VC11 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
VC12 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
VC13 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
VC14 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
VC15 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
VC3 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
VC5 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
VC6 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
VE1 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
VE11 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
VE12 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
VE3 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
VE5 2401-001479 C-AL;470uF,20%,10V,GP,TP,-,VE7 2401-001479 C-AL;470uF,20%,10V,GP,TP,-,VE9 2401-001479 C-AL;470uF,20%,10V,GP,TP,-,VFD1 AH07-00074A VF DISPLAY;-,DVD-M201,75X20.5MM,1/9,8,10
VFD1A AH61-00994A HOLDER-FLT;DVD-S221,ABS 94HB,-,-,-,BLK,VIC1 1201-001836 IC-VIDEO AMP;MM1567AJBE,SOP,34P,300MIL,VJ1 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
VJ2 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
VJ3 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
VJ4 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
VJ8 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
VL1 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
VR11 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
VR12 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
VR121 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
VR123 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
VR13 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
VR14 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
VR15 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
VR16 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
VR21 2007-001166 R-CHIP;75OHM,5%,1/10W,DA,TP,2012
VR22 2007-001166 R-CHIP;75OHM,5%,1/10W,DA,TP,2012
VR23 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
VSW1 AH34-00010A SWITCH SLIDE;-,50V DC,-,-,100MOHM,-,-,-,
Loc.No Part No Description ; Specification Remark
5-8
Samsung Electronics
Electrical Parts List
Loc.No Part No Description ; Specification Remark
AC109 2203-000533 C-CERAMIC,CHIP;2.7nF,10%,50V,X7R,TP,2012
AC11 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC110 2203-000661 C-CERAMIC,CHIP;0.27nF,5%,50V,NP0,TP,2012
AC111 2203-000533 C-CERAMIC,CHIP;2.7nF,10%,50V,X7R,TP,2012
AC112 2203-000661 C-CERAMIC,CHIP;0.27nF,5%,50V,NP0,TP,2012
AC113 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC114 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC115 2203-000533 C-CERAMIC,CHIP;2.7nF,10%,50V,X7R,TP,2012
AC116 2203-000661 C-CERAMIC,CHIP;0.27nF,5%,50V,NP0,TP,2012
AC117 2203-000533 C-CERAMIC,CHIP;2.7nF,10%,50V,X7R,TP,2012
AC118 2203-000661 C-CERAMIC,CHIP;0.27nF,5%,50V,NP0,TP,2012
AC119 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC12 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC120 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC121 2203-000533 C-CERAMIC,CHIP;2.7nF,10%,50V,X7R,TP,2012
AC122 2203-000661 C-CERAMIC,CHIP;0.27nF,5%,50V,NP0,TP,2012
AC123 2203-000533 C-CERAMIC,CHIP;2.7nF,10%,50V,X7R,TP,2012
AC124 2203-000661 C-CERAMIC,CHIP;0.27nF,5%,50V,NP0,TP,2012
AC125 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC126 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC13 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC14 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC15 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC16 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC17 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC18 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC201 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
AC202 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
AC203 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
AC204 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
AC401 2203-000495 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,2012
AC402 2203-000839 C-CERAMIC,CHIP;0.39nF,5%,50V,NP0,TP,2012
AC403 2203-000495 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,2012
AC404 2203-000839 C-CERAMIC,CHIP;0.39nF,5%,50V,NP0,TP,2012
AC407 2203-000126 C-CERAMIC,CHIP;1.2nF,10%,50V,X7R,TP,2012
AC408 2203-000126 C-CERAMIC,CHIP;1.2nF,10%,50V,X7R,TP,2012
AC409 2203-000316 C-CERAMIC,CHIP;0.12nF,5%,50V,NP0,TP,2012
AC410 2203-000316 C-CERAMIC,CHIP;0.12nF,5%,50V,NP0,TP,2012
AC413 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
AC9 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
ACC1 2203-000595 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,2012
ACC2 2203-000595 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,2012
ACC3 2203-000595 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,2012
ACC4 2203-000595 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,2012
AD1 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOTAD2 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOTAD3 0407-000116 DIODE-ARRAY;DAP202K,80V,100mA,CK2-3,SOTAD4 0407-000116 DIODE-ARRAY;DAP202K,80V,100mA,CK2-3,SOTAD5 0407-000116 DIODE-ARRAY;DAP202K,80V,100mA,CK2-3,SOTAD51 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOTAD54 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
AD55 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
AD61 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOTAE01 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
AE02 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
AE108 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE109 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE11 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE110 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE111 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE112 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE113 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE114 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE115 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE116 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE117 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE118 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE119 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE12 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE13 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE14 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE15 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE16 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE17 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE201 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
AE401 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11,5
AE402 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11,5
AE403 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11,5
AE406 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE407 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
AE51 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
AE52 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
AE6 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11,5
AE9 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11,5
AIC2 1002-001315 IC-D/A CONVERTER;PCM1601Y,24BIT,MQFP,48P
AIC3 AH14-10004R IC;M74HCU04,SOP,TAPE 14P
AIC4 1002-001294 IC-D/A CONVERTER;PCM1742KE,24BIT,TSSOP,1
AL01 3301-000353 CORE-FERRITE BEAD;AB,120ohm,2x1.25x0.9mm
AL02 3301-000353 CORE-FERRITE BEAD;AB,120ohm,2x1.25x0.9mm
AL201 2901-001125 FILTER-EMI ON BOARD;50V,0.5A,-,220pF,7x2
AOP1 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/m
AOP4 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/m
AOP5 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/m
AOP6 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/m
AQ1 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
AQ11 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
AQ12 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
AQ13 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
AQ14 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
AQ15 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
AQ16 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
AQ3 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
AQ4 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP
AQ5 0504-000156 TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT
AQ51 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP
AQ52 0504-000156 TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT
AQ55 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23,
AQ6 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP
AQ61 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP
AQ62 0504-000156 TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT
AQ7 0504-000156 TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT
AR101 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
AR102 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
AR103 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
AR104 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
AR105 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
AR106 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
AR107 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
AR108 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
AR109 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
AR110 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
AR111 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR112 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR113 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR114 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR115 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
AR116 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
AR117 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
Electrical Parts List
Samsung Electronics
5-9
Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark
ASSY-PCB-JACK
Models ; DVD-S423/S427
Loading...
