User Manual

Dear Customer

DANGER!

Notice

Introduction Brand Variable

With the purchase of this device, you have chosen a quality Sagem product brand. Their device fulfils the most varied requirements for private use or in your office and business everyday.

Your device is delivered with an already inserted free ink film for a few test pages. For this film, you do not require any Plug’n’Print card (= chip card with information regarding ink film capacity).

Telephone Book

In the telephone book of your device, you can save entries with multiple numbers and collect multiple entries into groups. You can assign various ring tones to the entries.

You can assign frequently dialled numbers to speed dial keys or short dialling numbers (model-specific). These functions help you to call these numbers quickly.

The built-in answering machine (model dependent) stores up to 30 minutes of messages. You can record internal and external voice messages (= memos). Using remote message retrieval, you can call new messages from each telephone. With the VIP code, callers can also reach you even while the answering machine is switched on.

You can send fax messages in different resolutions to one or more recipients or a group. You can also poll faxes and prepare documents for polling.

Fax Templates

Five fax templates, which you can use, are stored in your device. With these templates you can quickly create, for example, a short fax note or an invitation.

Select the resolution for text and photo in order to copy documents with your device. You can also create multiple copies.

You can send SMS messages from your machine if this service is activated for your telephone line (this function is not supported in all countries and networks, model-specific). Received SMS messages can be managed with the extensive functions of the SMS menu.

Activate notification by SMS to receive an SMS message, for instance on your mobile phone, when calls, fax transmissions or other messages arrive in your absence (this function is not supported in all countries and networks, model-specific).

If you want, your device can print Sudoku puzzles in four different difficulty levels with solution.

We hope you enjoy your device and its many functions!

About this User Manual

With the installation guide on the following pages, you can start using your device quickly and easily. Detailed descriptions can be found in the following sections of this user manual.

Read the entire user manual carefully. Follow all safety instructions in order to ensure proper operation of your device. The manufacturer accepts no liability if these instructions are not followed.

Multiple models of this device series are described in this user manual. Please note that some functions are only available with specific models.

Symbols Used

Dangers

DANGER!

Warns about dangers for people, damage to the device or other objects as well as possible loss of data. Injuries or damage can result from improper handling.

Troubleshooting

This symbol designates tips that will help you to use your device more effectively and easily.

2 Sagem · SPFX 43 · 47 · SP 4840

Dear Customer ............................................................ 2

About this User Manual .............................................. 2

1 General Safety Information................ 4

2 Overview............................................... 5

Overview of the Menu Functions ................................ 5

Device Overview .......................................................... 6

Panel ........................................................................... 7

3 Initial Operation .................................. 8

Packing Contents ........................................................ 8

Opening the Cover ...................................................... 8

Attaching Paper Tray ................................................... 8

Loading Paper ............................................................. 8

Connecting the Handset .............................................. 9

Connecting the Telephone Cable ................................ 9

Connecting the Mains Cable ..................................... 10

Initial Installation ...................................................... 10

4 Telephone Functions......................... 11

Placing a Call on the Device ...................................... 11

Calling Additional Telephone Functions ................... 11

Getting Outside Line ................................................. 12

Chain Dialling ........................................................... 12

Insert Dialling Pause .................................................. 12

Hands-Free ................................................................ 12

Recording a Telephone Conversation ........................ 12

Telephone Book of the Device ................................... 13

Groups ...................................................................... 13

Short dialling ............................................................. 14

Speed dialling ............................................................ 14

Calling Line Identification (CLIP) ............................. 15

Missed Calls .............................................................. 15

5 Answering Machine ........................... 16

Switching On and Off ............................................... 16

Editing the Outgoing Message ................................... 16

Listening to Messages ................................................ 17

Deleting Messages ..................................................... 17

Setting up Forwarding and Remote Access ................ 17

Using Remote Access ................................................. 18

Remote Control Functions ........................................ 18

Recording Internal Memos ........................................ 19

Modifying the Settings .............................................. 19

6 Fax....................................................... 20

Sending a Fax ............................................................ 20

Sending Fax Manually ............................................... 21

Direct Inward Dialling or Selecting Sub-address ........ 21

Eavesdropping while Connection is Established ......... 21

Sending to Multiple Recipients (= Broadcasting) ....... 21

Sending Fax Later ...................................................... 22

Fax Reception ............................................................ 22

Receiving Fax Manually ............................................. 22

Polling Faxes .............................................................. 22

Using Fax Templates ................................................. 22

7 Copier................................................. 23

Inserting Documents ................................................. 23

Making a Copy .......................................................... 23

Creating Multiple Copies ........................................... 23

8 SMS..................................................... 24

SMS Requirements .................................................... 24

Sending SMS ............................................................. 24

Notification by SMS .................................................. 24

Receiving SMS Messages ............................................ 25

Reading SMS Messages .............................................. 25

Calling SMS Functions .............................................. 25

Printing SMS Messages .............................................. 25

Deleting SMS Messages ............................................. 25

Modifying the Settings ............................................... 26

9 Fun and Games.................................. 27

Sudoku ...................................................................... 27

10 Settings............................................... 28

Entering the Date and Time ...................................... 28

Selecting the Language ............................................... 28

Selecting the Country ................................................ 28

Entering Number ....................................................... 28

Entering Name .......................................................... 28

Setting the Contrast ................................................... 28

Reducing Transmission Speed ................................... 29

Switching Page Adjustment On and Off .................... 29

Setting the Ring Tones .............................................. 29

Setting the Fax Switch ............................................... 29

Printing Lists and Help Pages .................................... 30

Starting Initial Installation ......................................... 30

11 Telephone Lines and Additional

Devices .................................................... 31

Configuring Telephone Lines and Services ................. 31

Connecting Additional Devices .................................. 31

Using Additional Telephones (Easylink) .................... 32

12 Service ................................................ 33

Checking the Ink Film Reserve .................................. 33

Changing the Ink Film .............................................. 33

Fixing a Paper Jam ..................................................... 34

Fixing a Document Jam ............................................. 35

Cleaning .................................................................... 36

Checking the Firmware Version ................................. 37

Using Service Codes ................................................... 37

Power Cycling ............................................................ 37

13 Appendix ............................................ 39

Technical Data .......................................................... 39

Guarantee .................................................................. 39

Declaration of Conformity (DoC) ............................. 41

Customer Information ............................................... 44

Table of Contents 3

1 General Safety Information

Introduction 3

Your device has been tested in conformity with standards EN 60950-1 and IEC 60950-1 and should only be operated with telephone systems and power equipment that

meet these standards. The device was built exclusively for use in the indicated sales region.

Introduction 2

Do not make any changes or settings that are not described in this user manual. Physical injury or damage to the device or loss of data can result from improper handling. Take note of all warning and safety notes indicated.

Setting Up the Machine

The device should rest securely on a stabile, flat surface.

The device should rest securely on a stabile, flat surface. If the device should fall, it can be damaged or can cause injury to people, especially small children. Position all cables in such a way that no one will stumble on them, thus avoiding possible injuries to persons or damage to the device itself.

The distance between the devic e and other appliances or objects, must be at least 15 centimetre s.

The distance between the device and other devices or objects must be at least 15 centimetres; this also applies to the use of additional cordless telephones. Do not place the device in the vicinity of radios or televisions.

Lock the cover of the device completely into place

Lock the cover of the device completely into place when opening the device. You could be injured if the cover falls while you are working on the device.

Protect the device against direct sunlight

Protect the device against direct sunlight, heat, large temperature fluctuations and moisture. Do not place the device in the vicinity of heaters or air conditioners. Observe the information on temperature and humidity in the technical data.

The device must have sufficient ventilation

The device must have sufficient ventilation and may not be covered. Do not put your device in closed cabinets or boxes. Do not place the machine on soft surfaces such as tablecloths or carpets and do not cover the ventilation slits. Otherwise, the device can overheat and catch on fire.

In the event that the device becomes too hot, o r if you see smoke coming from the dev ice

In the event that the device becomes too hot, or if you see smoke coming from the device, you must immediately pull the power cable out of the power socket. Have your device examined by trained professionals at a technical service location. To prevent the spread of fire, open flames should be kept away from the device.

Do not plug in the device in moist rooms.

Do not plug in the device in moist rooms. Never touch the mains cable, the mains connection or the telephone socket with wet hands.

Do not allow liquids to enter into the device.

Do not allow liquids to enter into the device. Disconnect the device from the power socket if liquids or foreign objects have entered the device and have your device examined by trained professionals at a technical service location.

Do not allow children to handle the device w ithout supervision.

Do not allow children to handle the device without supervision. The packing materials should be kept out of the hands of children.

Magnetic telephone handset

The telephone handset of the device is magnetic. Caution, small metallic objects (paper clips) may be retained if placed near or on the telephone handset.

Power Supply

Check whether the mains voltage of your device

Check whether the mains voltage of your device (indicated on the type label) matches the mains voltage available at the setup location.

Use only the power and telephones cables supplied.

The device does not have an on/off button.

Set up your device so that the power socket is easily accessible. The device does not have an on/off button. In an emergency, disconnect your device from the power supply by pulling the power plug.

Never touch the power or telephone cable if the insulation is damaged.

Never touch the power or telephone cable if the insulation is damaged. Replace damaged wires immediately. Use suitable cables only; if necessary please contact our technical customer service or your retailer.

Disconnect your device from the power and telephone netwo rks during an electrical storm.

Disconnect your device from the power and telephone networks during an electrical storm. If this is not possible, do not use the device during an electrical storm.

Before cleaning the surface of your device, disconnect it from the power and telephone networks.

Before cleaning the surface of your device, disconnect it from the power and telephone networks. Use a soft, lintfree cloth. Never use liquid, gaseous or easily flammable cleansers (sprays, abrasives, polishes, alcohol). Do not allow any moisture to reach the interior of the device.

Only clean the display with a dry, soft cloth .

Only clean the display with a dry, soft cloth. If the display breaks, a mildly corrosive liquid may escape. Avoid all contact with your skin and eyes.

In the event of a power failure, your device will not function;

In the event of a power failure, your device will not function; saved data is retained.

Repairs

Display

Should disruptions occur, follow the instructions on the display and on the error report.

Repairs

Do not make any repairs to the device yourself. Improper maintenance can result in injuries or damage to the device. Only have your device repaired by an authorised service centre.

Do not remove the type label from your device; this would void the warranty.

Consumable Materials

Original Consumable Mat erial

Use only original consumable materials. These are available from a specialised retailer or through our order service (see back side of this user manual). Other consumable materials could damage the device or shorten its service life.

Environment

Dispose of old consumable materials according to the waste regulations of your country.

4 Sagem · SPFX 43 · 47 · SP 4840

2Overview

Notice

Overview of the Menu Functions

The following functions are available on your device. There are two ways in which you can call functions:

Menu Navigation

Navigating in the Menu: Press OK or one of the two

arrow keys [, to open the function menu. Page through

[ menu entries. Use OK to sele ct a m enu f unct ion. Pres s

C to return to the previous menu level. Press j to close

the menu and return to the starting mode.

Direct Loading

Calling Functions Directly: You can call a menu func-

tion directly using the function number. Press OK and

enter the appropriate function number using the numeric

keypad. Confirm with OK. You will find the function

number in the following list.

Help 6 · Function List

Printing the Functions List

Press î and 6 to print a list of all functions

and settings of your device.

1 Telephone book

11 Looking Up an Entry (PPF 6 xx · SPFX 4x)

11 Looking up an entry...............................page 11

12 New Entry (SPFX)

12 New entry..............................................page 13

13 Creating Group

13 Creating group.......................................page 13

14 Short Dial (Type 3)

14 Short dial (SPFX¦43, SPFX¦47)...............page 14

14 Speed dialling (SP 4840)

14 Speed dialling (SP¦4840) ........................page 14

15 Changing Entries

15 Modifying an entry ................................page 13

16 Deleting Entries

16 Deleting entries......................................page 13

17 Printing Entries

17 Printing entries ......................................page 30

2 Calls

21 Received Calls (PPF 6xx · SPFX 4x)

21 Received calls.........................................page 11

22 Outgoing Calls (PPF 6xx · SPF X 4x)

22 Outgoing calls........................................page 11

23 Printing Entries

23 Printing entries ......................................page 30

3 Fax

31 Polling

31 Polled reception.....................................page 22

32 Polling Send

32 Polling send ...........................................page 22

33 Sending Fax Later

33 Sending fax later ....................................page 22

34 Broadcasting

34 Sending to multiple recipients (= broadcast)

.......................................................................page 21

35 Printing Fax Journal

35 Printing fax journal ................................page 30

36 Printing Transmission Report

36 Printing transmission report...................page 30

37 Print Reduced in Size

37 Print reduced in size...............................page 29

38 Reducing Transmission Speed

38 Reducing transmission speed..................page 29

4 Miscellaneous

41 Printing Call Log

41 Printing call log..................................... page 30

42 Switching Notification Tone for Call Waiting On/Off (Type 2)

42 Switching notification tone for call waiting on/off

(SPFX¦47) ........................................................... page 12

43 Using Fax Templates

43 Using fax templates ............................... page 22

44 Setting the Contrast

44 Setting the contrast................................ page 28

45 Using Service Codes

45 Using service codes................................ page 37

46 Checking the Ink Film Reserve

46 Checking the ink film reserve ................ page 33

47 Checking the Firmware Version

47 Checking the firmware version .............. page 37

48 Sudoku

48 Sudoku.................................................. page 27

5 Fax Switch

51 Configuring Day Mode

51 Configuring day mode .......................... page 29

52 Configuring Night Mode

52 Configuring night mode........................ page 29

53 Setting the Timer

53 Setting the timer.................................... page 29

54 Easylink

54 Easylink.................................................page 32

55 Setting the Ring Tones

55 Setting the ring tones ............................ page 29

6 SMS

(Type 3)

(SPFX¦43, SPFX¦47)

61 Sending SMS (SPFX 43/47)

61 Sending SMS ........................................page 24

62 Reading SMS (PPF 675 · 676 · 6xx · SPFX 43/47)

62 Reading SMS ........................................ page 25

63 Printing SMS

63 Printing SMS ........................................ page 25

64 Deleting SMS (PPF 675 · 676 · 6xx · SPFX 43/47)

64 Deleting SMS........................................ page 25

65 Notification by SMS

65 Notification by SMS ............................. page 24

66 SMS Access

66 SMS access ............................................ page 26

7 Answering Machine

(Type 2)

(SPFX¦47)

71 Switches Answering Machine On/Off (PPF 675 · 676 · 6xx · SPFX 47)

71 Switches answering machine on/off ....... page 16

72 Listening to Messages (PPF 675 · 676 · 6xx · SPFX 47)

72 Listening to messages............................. page 17

73 Recording Internal Memos (PPF 675 · 676 · 6xx · SPFX 47)

73 Recording internal memos..................... page 19

74 Setting the Recording Duration

74 Setting the recording duration............... page 19

75 Editing the Outgoing Message (PPF 675 · 676 · 6xx · SPFX 47)

75 Editing the announcement .................... page 16

76 Using Announcement without Record ing Message

76 Using announcement without recording message

(= external memo)............................................... page 16

77 Forwarding Messages

77 Forwarding messages ............................. page 18

78 Entering the VIP Code

78 Entering the VIP code........................... page 19

79 Entering Access Code

79 Entering access code.............................. page 17

9 Settings

91 Entering the Date and Time

91 Entering the date and time .................... page 28

92 Selecting the Language

92 Selecting the language ........................... page 28

93 Selecting the Country

93 Selecting the country............................. page 28

94 Entering Number

94 Entering number................................... page 28

95 Entering Name (SPFX)

95 Entering name....................................... page 28

96 Configuring Teleph one Lines and Ser vices

96 Configuring telephone lines and services page 31

Overview · Overview of the Menu Functions 5

Device Overview

Primo · Voice overview

‚ Handset

ƒ Paper tray

„ Document feeder (writing facing up)

… Panel with display

† ) socket—Connection socket for the telephone

handset

‡ EXT socket—Connection socket for additional

devices

ˆ LINE socket—Connection socket for telephone cable

SPFX 4x

‚ Scanner glass

ƒ Rollers of the automatic document feeder

„ Rests of the intake rollers

… Document guide / scanner film

† Cover for scanner and automatic document feeder

‡ Toothed wheel for tightening the ink film

ˆ Ink film roll in the rear ink film compartment

‰ Ink film roll in the front ink film compartment

Š Slot for the Plug’n’Print card

‹ Locks for the cover of the scanner and automatic doc-

ument feeder

Innenansicht nummeriert

Internal Description

6 Sagem · SPFX 43 · 47 · SP 4840

Panel

Telephone Book

m—Press briefly: Calling up the telephone book entries.

Selecting the entries with the [ / press and hold: saving

new entries

Fax Switch

º/»—Setting the timer and the fax reception modes (=

fax switch). Modes set on the display Activated timer is indicated with

SMS (Type 3)

_ (SPFX¦43, SPFX¦47)—Calling the SMS menu (func-

tion is not supported in all countries and networks)

Answering Machine (Type 2)

b (SPFX¦47)—Calling answering machine menu

Short Dial (Type 3)

Ý (SPFX¦43, SPFX¦47)—Press briefly: Load short dial

entries. Selecting the entries with the [ or numeric keys

/ press and hold: Assign a new short dial entry

Stop (AM Type 2)

j—Function abort / return to the starting mode / docu-

ments eject / (SPFX¦47): ending message playback

C (AM Type 2)

C—Return to the previous menu level / press briefly:

deleting individual characters / press and hold: deleting complete input / (SPFX¦47): during a playback: deleting individual message / in the starting mode: deleting all messages

Arrow Keys

[—Calling the menu functions / navigation within the

menu / selecting options / moving the cursor / adjusting the volume level

OK—Calling the menu functions / confirming input

Start

o—Press briefly: Starting transmission of messages / press

and hold: Starting fax polling

Speed dialling (SP 4840)

Speed dial buttons ë (SP¦4840)—Press briefly:

Recalling speed dial entry / press and hold: Editing speed dial entry

™ (day), ˜ (night).

›

Letter keypad (Type 3)

Letter keypad (SPFX¦43, SPFX¦47)—Entering characters.

Entering capital letters by pressing and holding + button.

Deleting using \. Entering a break using |. Entering a

space using ½. Entering special characters by pressing and

holding CTRL button.

Message

ä—Lights up, if new messages are received / list of

the new messages with submenus / blinks in the case of device error (for example no ink film)

Copy (SMS Type 3)

COPY—Press briefly: creating a copy / press and hold:

creating multiple copies / (SPFX¦43, SPFX¦47): printing SMS

Resolution

RES—Setting higher resolution for faxes and copying

(

RESOL.: STANDARD, RESOL.: FINE, RESOL.:

)


Help

î—Press briefly: Printing help pages and setting lists /

press and hold: Starting initial installation process

Redialling

@—Press briefly: Toggling between the list of the last 10

dialled numbers (= redial list) / press and hold: List of last ten callers (caller list)

Speaker (SPFX 43 · 47 · SP 4840)

l—(SPFX¦43, SP¦4840): Dialling with the handset

replaced / (SPFX¦47): hands-free

R—Press briefly: insert short line interruption (Hook

Flash) as office index on PABX or for calling special functions in the public telephone network (PSTN)/long press: Inserting dialling pause

Numeric Keys (short dial)

Numeric keypad—Inputting digits, characters and special characters / press and hold: Recalling short dial numbers

SPFX 47

Overview · Panel 7

3 Initial Operation

Notice

Packing Contents

Packing Contents Sagem Primo Voice

‚ Device

ƒ Telephone handset

„ Spiral cable for telephone handset

… Paper tray

† Mains cable with plug (country-specific)

‡ Telephone cable with plug (country-specific)

ˆ Additional document support

User Manual

User manual with installation guide (not depicted)

Verpackungsinhalt

Missing Package Contents

If one of the parts is missing or damaged, please contact your retailer or our customer service.

Opening the Cover

Pull down the cover for paper and document feeder behind the panel.

Geräteklappe öffnen

Attaching Paper Tray

If you just want to insert paper temporarily, fold the paper support in the cover up (A). You can remove the paper after receiving fax or copying and close the cover again.

If you constantly require paper in the device, insert the paper tray in the opening provided for it behind the paper feed (B).

Papierhalter installieren

Loading Paper

Paper Format

Before you can receive documents or make copies, you must load paper into the device. Please use only appropriate paper in standard format A4 (210 × 297 millimetre · preferably 80 g/m nical data.

Loading Paper

Preparing Paper

). Follow the specifications in the tech-

Loading Paper

Separate the paper sheets by fanning them out, then align them by tapping edge of the stack lightly against a flat surface. This will prevent several sheets of paper from being drawn in all at once.

Loading Paper Sagem

1 Fold open the lever on the right beside the paper feed

towards front.

2 Insert paper in the paper feeder. You can use the paper

support in the cover to load up to 15 sheets (A4 · 80 g/m²). In the paper tray you can insert maximum 50

sheets (A4 · 80 g/m2).

8 Sagem · SPFX 43 · 47 · SP 4840

3 Fold open the lever on the right beside the paper feed

Notice

backward in order to enclose the paper.

Papier einlegen

Connecting the Telephone Cable

Connecting the Handset

Plug one end of the spiral cable into the socket on the telephone handset. Insert the other end into the socket desig-

nated with the ) symbol.

Hörer anschließen

Analogue Fax Machine

Connecting the Telephone Cable

Connect the telephone cable to the device by inserting it in

the socket designated with LINE (RJ-11-Connector).

Insert the telephone plug into your PTT line socket.

Telefonkabel anschließen

PABX Systems 1

Connection to Private Automatic Branch Exchange

If you connect your device as extension to a telephone system, you must set it for working as an extension (also see Chapter

tions and additional devices

Telephone connec-

, page 31).

Ireland

Two-pin

When connecting to the telephone line socket, use only a two-pin RJ-11-telephone cable (modular plug). The use of a four-pin telephone cable may lead to the device not functioning correctly.

Initial Operation · Connecting the Handset 9

Connecting the Mains Cable

CAUTION!

Notice

Mains Voltage at the Site of Installation

Mains Voltage at the Site of Installation!

Check whether the mains voltage of your device (indicated on the type label) matches the mains voltage available at the setup location.

Connecting the Mains Cab le

Insert the mains cable into the connection located on the rear side of the device. Plug the power cable into the electrical outlet.

Netzkabel anschließen

Initial Installation

Starting Initial Installation

After you connect your device to the mains voltage, the ini-

tial installation commences. Press î. Your device prints a

help page.

Selecting the Language

1 Use [ to select the desired display language.

2 Confirm with OK.

Entering Number

Page Header

Your name and number are added together with date, time and page number at the top edge of each fax transmission (= header).

Entering Number

1 Enter your number. Using # or * you can enter a

plus sign.

2 Confirm with OK.

Entering Name

1 Enter the name using the letter keypad. Enter capital

letters by pressing and holding + key. You can delete

individual characters using \. You can enter space

using ½. Press CTRL and the respective letter key to

enter the special character printed above it.

Navigating in the Editor

You can move the cursor using [. Use C to

delete individual characters.

2 Confirm with OK.

Entering the Date and Time

Entering Time/Date

1 Enter the time, e.g. 14 00 for 2 pm.

2 Enter the date (two digits for each field), for example

08 06 07 for June 8th, 2007.

3 Confirm with OK.

Help 2 · Initial Installation Process

Starting Initial Installation Process

You can restart the initial installation process

any time. Press î and 2.

Selecting the Country

Setting the Country Correctly

Setting the Country Correctly!

You must set the country in which you are operating the device. Otherwise your device is not adapted to the telephone network. If your country is not included in the list, you must select a different setting and use the correct telephone cable for the country. Consult your retailer.

Setting the Country

1 Use [ to select the country in which you are operat-

ing the device.

2 Confirm with OK.

After this input, the device prints another help page and checks the telephone line.

10 Sagem · SPFX 43 · 47 · SP 4840

4 Telephone Functions

Notice

Help 3 · Telephone Functions

Outgoing Calls

Printing Telephone Book Functions

Press î and 3 to print an overview of the tel-

ephone book functions.

Connecting Additional Telephon es

For information on how to connect additional telephones and which functions are available to you, please refer the chapter on Telephone Connections and Additional Devices, Page 31.

Placing a Call on the Device

Dial the desired number. There are several ways to do this: Then pick up the handset.

Direct Dialling

You can also lift up the receiver first, then dial a number. The dialling process begins immediately.

Manual Dialling: Dial the desired number using the numeric keypad.

Telephone Book:

1 Press m.

Access Function

You can also search for an entry in the tele-

phone book by pressing OK, 11 and

OK.

2 Select an entry using [. Enter the starting letters with

the numeric keypad to quickly navigate through the telephone book.

Multiple Categories for One Entry

You can save an entry multiple times with the same name but in a different category. In the telephone book, the first letter of the category appears after the entry.

Short Dial: Press Ý. Select the desired entry using [

or with the numeric keys.

Recalling Short Dial Number

Access Function

You can also load short dial entries by holding the respective number key pressed (for at least two seconds).

Speed Dialling: Press the desired speed dial key

(ë).

Redial List

Redial List: Press @. Use [ to select an entry from the

list of the dialled numbers.

Access Function

You can also load the redial list by pressing OK,

22 and OK.

Caller List: Press and hold @ (at least two seconds).

Use the [ to select an entry from the list of callers.

Calls Received

Access Function

You can also load the caller list by pressing OK,

21 and OK.

CLIP Prerequisite

Calling Line Identification (CLIP)

For this function to work, the Caller Line Identification (CLIP) must be activated for your telephone connection (country and network dependent). The number and name will not be shown if the caller suppresses his number.

Calling Additional Telephone Functions

Type 2 (großer Core)

(SPFX¦47)

Function is not supported in all countries and networks

(Function is not supported in all countries and networks)

Additional Telephone Functions

You can use additional telephone functions with your device for example call toggling, three-way call or call forwarding. Contact your telephone company to inquire whether or not these functions are available for your connection. The signal to the switchboard to call these services is a short line interruption (Hook Flash). How to call up the functions, depends on your telephone company and may vary from the description found below.

Making a Second Call

1 During a call, press R.

2 Enter the desired number using the numeric keypad or

select a saved entry.

Switching Between Calls (= Call Toggling)

Switching Between Calls

Press R, to toggle between the calls.

Telephone Functions · Placing a Call on the Device 11

Receiving a Second Call

Notice

CAUTION!

Call Waiting

During a call, you can be informed about another call by a notification tone (= call waiting) if your telephone company offers this service. The notification tone for call waiting on the device is switched off in the factory.

Receiving a Second Call

During a call, press R to accept the new call.

CLIP Prerequisite

Calling Line Identification (CLIP)

Switching Notification Tone for Call Waiting On/Off

1 Press OK, 42 and OK.

2 Use [, to select whether you would like to turn the

call waiting on or off.

3 Confirm with OK.

Getting Outside Line

PABX Systems

Private branch exchanges (PABX) are typical in many offices and some households. You must dial an outside line access code in order to get a connection to the public telephone network (PSTN) from a PABX.

Inserting Outside Line Access Code

Enter the outside line access code with which you reach the public telephone network before you enter the desired number or select a stored entry. The outside line access

code is usually 0.

Incorrect Outside Line Access Code

In rare cases, the outside line access code may be a different number or a two-digit number. For older telephone systems, the outside line access

code can be R (= Flash). Press R to enter this

outside line access code. If the connection to the public telephone network is not possible, contact your telephone system supplier.

Setting Up an Extension

Connection to Private Automatic Branch Exchange

If you operate your device permanently at an extension, store the outside line access code with the 96 function (see page 31).

Chain Dialling

You can combine and edit manually entered digits and saved entries, before the dialling process starts. If you have saved, for example, the telephone number prefix of an inexpensive telephone service provider (call-by-call) as a telephone book entry, select this entry and manually enter the subsequent telephone number or select another saved entry.

Insert Dialling Pause

It may be necessary to insert a dial pause in telephone number, for example, for a direct-inward dialling number,

a sub-address or in a long distance number. Hold R

pressed (for at least two seconds).

– appears on the display.

The second part of the number is dialled only after a short pause.

Hands-Free

Type 2 (großer Core)

(SPFX¦47)

1 Press l to dial without lifting up the handset. You will

hear a dial tone from the loudspeaker.

2 Enter the desired number using the numeric keypad or

select a saved entry. The dialling process begins immediately. At this stage, any numbers that have been incorrectly entered can no longer be changed.

Handset Near the Device

Hands-Free

Put the handset near the device with the microphone facing up in order to achieve an optimum communication.

Recording a Telephone Conversation

Type 2 (großer Core)

(SPFX¦47)

Recording a Telephone Conversation

You can record a telephone conversation. After recording,

the ä key flashes, and you can hear the recording

like a message on the answering machine.

Recording a Telephone Conversation

Recording a Telephone Conversation!

You must inform your caller when recording a telephone conversation.

Recording a Telephone Conversation

1 During a call, press b. The recording begins.

2 Press b again to end the recording.

12 Sagem · SPFX 43 · 47 · SP 4840

Telephone Book of the

Notice

Device

Telephone Book

In the telephone book of your device, you can save entries with multiple numbers and collect multiple entries into groups. You can assign various ring tones to the entries. Follow the specifications in the technical data.

Cursor Navigation 1

Navigating in the Editor

You can move the cursor using [. Use C to

delete individual characters. Press j to close the

menu and return to the starting mode.

Saving Entry

1 Hold m pressed (for at least two seconds).

Access Function

You can also call the function by pressing

OK, 12 and OK.

2 Enter the name using the letter keypad. Enter capital

letters by pressing and holding + key. You can delete

individual characters using \. You can enter space

using ½. Press CTRL and the respective letter key to

enter the special character printed above it.

Edit Entry

1 Press OK, 15 and OK.

2 Using [ select the entry which you would like to edit.

3 Confirm with OK.

4 Edit the name.

5 Confirm with OK.

6 Using [, select the category for which you would like

to enter a number:

GORY: WORK GORY: FAX

7 Confirm with OK.

8 Enter the telephone number.

9 Confirm with OK.

10 You can assign a ring tone to the number. Use the

number keys 0 to 9 to select a ring tone. Using

[, set the volume.

11 Confirm with OK. The entry is saved.

CATEGORY: HOME, CATE-

, CATEGORY: MOBILE or CATE-

Deleting an Entry

1 Press OK, 16 and OK.

2 Using [ select the entry which you would like to

delete.

3 Confirm with OK.

4 Confirm

DELETE: YES with OK.

Navigating in the Editor

You can move the cursor using [. Use C to

delete individual characters.

3 Confirm with OK.

4 Using [, select the category for which you would like

to enter a number:

GORY: WORK GORY: FAX

5 Confirm with OK.

6 Enter the telephone number.

7 Confirm with OK.

8 You can assign a ring tone to the number. Use the

number keys 0 to 9 to select a ring tone. Using

[, set the volume.

9 Confirm with OK. The entry is saved.

Telephone Functions · Telephone Book of the Device 13

CATEGORY: HOME, CATE-

, CATEGORY: MOBILE or CATE-

Groups

You can combine several telephone book entries into a group. A message is sent to all members of this group in succession.

Adding Group Entries

1 Press OK, 13 and OK.

2 Use [ to select the group you would like to create.

3 Confirm with OK. You can add entries to the group,

display the members of the group, delete the group or send a fax to the group.

4 Using [ select

5 Confirm with OK.

6 Use [ to select the entry you would like to add to the

group.

7 Confirm with OK.

8 Repeat steps 4 to 6 to add additional entries to the

group.

9 Press j to end the input.

ADD MEMBER?.

Displaying Group Entries

Notice

CAUTION!

Notice

1 Press OK, 13 and OK.

2 Use [ to select the group you would like to display.

3 Confirm with OK.

4 Using [ select

5 Confirm with OK.

6 Page through the entries of the group with [.

7 Press j twice to return to the starting mode.

VIEW MEMBERS?.

Deleting Individual or All Group Entries

Overwriting Short Dial Entries!

If you select a short dial number that is already assigned, the entry is overwritten.

3 Confirm with OK.

4 Use [ to select the telephone book entry you would

like to assign as a short dial entry.

5 Confirm with OK.

Deleting a Short Dial Entry

The Telephone Book Entry is Deleted!

Deleting an Individual Entry

1 Press OK, 13 and OK.

2 Using [ select the group from which you would like

to delete entries.

3 Confirm with OK.

4 Using [ select

5 Confirm with OK.

6 Using [ select the entry which you would like to

delete.

7 Confirm with OK.

8 Using [ select

9 Confirm with OK. The entry is deleted.

DELETE MEMBER?.

DELETE: YES.

Deleting a Group

1 Press OK, 13 and OK.

2 Using [ select the group you would like to delete.

3 Confirm with OK.

4 Using [ select

5 Confirm with OK.

6 Using [ select

7 Confirm with OK. All entries in the group are deleted.

DELETE MEMBER?.

DELETE: ALL.

Short dialling

(model dependent)

Short Dial

You can assign short dial numbers to frequently dialled telephone numbers. You can load these numbers quickly with the short dial key and the number keys.

Assigning or Editing Short Dial Entry

1 Hold Ý pressed (for at least two seconds).

Access Function

You can also call the function by pressing

OK, 14 and OK.

2 Use [ or the respective number key to select the short

dial number you would like to assign or change.

The Telephone Book Entry is Deleted!

This function not only deletes the short dial entry, it also deletes the entire entry from the telephone book. Overwrite the short dial entry if you would like to change the assignment.

1 Press Ý.

Access Function

You can also call the function by pressing

OK, 14 and OK.

2 Use [ or the respective number key to select the entry

you would like to delete.

3 Press C.

4 Confirm the deletion with OK.

Speed dialling

(model dependent)

Speed Dialling

You can assign the speed dial keys to frequently dialled telephone numbers. You can load these telephone numbers quickly with the speed dial keys.

Assigning or editing speed dial entry

1 Press and hold (at least two seconds) the speed dial but-

ton (ë), which you would like to assign or change.

Access Function

You can also call the function by pressing

OK, 14 and OK.

2 Confirm using OK.

3 Using [ select the telephone book entry which you

would like to assign to this speed dial button.

4 Confirm using OK.

14 Sagem · SPFX 43 · 47 · SP 4840

Deleting a speed dial entry

CAUTION!

Notice

The telephone book entry is deleted!

With this function, you can not only delete the speed dial entry, but also the entire entry from the telephone book. Overnight the speed dial entry, if you want to modify the assignment.

1 Press the speed dial button (ë), whose entry you

want to delete.

Access Function

You can also call the function by pressing

OK, 14 and OK.

2 Press C.

3 Confirm the deletion with OK.

Calling Line Identification (CLIP)

Function is not supported in all countries a nd networks

(Function is not supported in all countries and networks)

CLIP Definition

The number of an incoming call appears on the display. For this function to work, the Calling Line Identification Presentation (CLIP) must be activated for your telephone connection. Enquire with your telephone company. Caller Line Identification may be associated with a fee.

Setting the Country Correctly

If the Caller Line Identification does not work even though the function is activated for your telephone connection, check if you have set the correct country (also see Chapter Settings,

page 28

Missed Calls

If you received a call while away, the ä - key flashes.

1 Press ä.

2 Using [, you can page through the list of missed calls.

Additional Messages

If you have received additional messages, first

select the missed calls using [ and confirm

with OK.

3 To call back, pick up the handset.

Displaying Telephone Book Names

Your device displays the name with which you have saved the number in the telephone book. The number and name will not be shown if the caller suppresses his number.

Telephone Functions · Calling Line Identification (CLIP) 15

5 Answering Machine

Notice

(model dependent)

Help 3 · Answering Machine

Printing Answering Machine Functions

Press î and 3 to print an overview of the

answering machine functions.

Switching On and Off

Switching On/Off on the DeviceAnonymous Outgoing Message

Using Anonymous Outgoing Messages

If you do not record a personal announcement, the answering machine uses the anonymous announcement set by the factory.

Press b three times to turn the answering machine on or

off. If the answering machine is turned on, the symbol appears on the display.

Activation

Access Function

You can also call the function by pressing OK,

71 and OK.

Editing the Outgoing Message

Recording the Outgoing Message

During playback, press C and OK in order to

delete the currently playing outgoing message.

Using [, set the volume. Stop the playback

with j.

7 Press OK to end the recording. The recording is played

back.

Recording the Outgoing Message

If the volume of the outgoing message is too low, rerecord the same. For recording, lift up the telephone handset of the device and speak the text into the microphone.

Playing Back the Outgoing Message

1 Press b.

2 Using [ select

3 Confirm with OK.

OUTGOING MSG..

—

Access Function

You can also call the function by pressing

OK, 75 and OK.

4 Using [ select

5 Confirm with OK. The outgoing message is played

back.

MESSAGE: PLAY.

Using Anonymous Outgoing Messages

Anonymous Outgoing Message

You can replace your personal outgoing message with the factory default anonymous message.

1 Press b.

2 Using [ select

3 Confirm with OK.

OUTGOING MSG..

Recording the Outgoing Message

1 Press b.

2 Using [ select

3 Confirm with OK.

4 Using [ select

5 Confirm with OK.

6 Press OK to record an outgoing message. Wait for the

confirmation tone before you say your text.

16 Sagem · SPFX 43 · 47 · SP 4840

OUTGOING MSG..

Access Function

You can also call the function by pressing

OK, 75 and OK.

MESSAGE: RECORD.

Length of Outgoing Message

The outgoing message must be longer than ten seconds and shorter than twenty seconds.

4 Using [ select

5 Confirm with OK. The outgoing message is played

Using Announcement without Recording Message

Outgoing Message Without Recording of Mess ages

You can record an outgoing message which the caller hears for which no message can be recorded in reply (= external memo).

1 Press b.

2 Using [ select

3 Confirm with OK.

Access Function

You can also call the function by pressing

OK, 75 and OK.

MESSAGE: DEFAULT.

back.

EXTERN. MEMO.

Notice

Access Function

Notice

You can also call the function by pressing

OK, 76 and OK.

4 Use [ to select whether you would like the outgoing

message to be switched on/off without recording the message.

5 Confirm with OK.

Access Function

You can also call the function by pressing

OK, 72 and OK.

4 Using [ select

5 Confirm with OK. The messages are played back.

MESSAGE: PLAY.

Deleting Messages

Overwriting Existing Outgoing Message

When you record an outgoing message, you are asked, if you would like to use the old outgoing message or would like to record a

new one. Confirm with OK.

6 Recording a New Outgoing Message: Press OK

to record an outgoing message. Wait for the confirmation tone before you say your text.

Length of Outgoing Message

The outgoing message must be longer than ten seconds.

7 Press OK to end the recording. The recording is played

back.

Listening to Messages

Press # to play the next message. With the

number keys, you can load the desired message

directly. During playback, press C and OK in

order to delete the currently playing outgoing

message. Using [, set the volume. Stop the

playback with j.

Listening to New Messages

Indication of New Messages

If new messages have been received on the answering

machine, the ä key blinks. The number of the new

messages is shown on the display.

1 Press ä.

2 Confirm with OK.

3 The new messages are played back.

Playing Messages again

1 Press b.

2 Using [ select

3 Confirm with OK.

MESSAGES.

Deleting Individual Message

During playback, press C and OK in order to delete the

currently playing outgoing message.

Deleting Messages already Played

Deleting New Messages

Messages not yet heard must be heard first before deleting them.

1 Press b.

2 Using [ select

3 Confirm with OK.

MESSAGES.

Access Function

You can also call the function by pressing

OK, 72 and OK.

4 Using [ select

5 Confirm with OK. The heard messages are deleted.

MESSAGE: DELETE.

Deleting Heard Messages

You can also delete the already heard mes-

sages by pressing C and OK in the starting

mode.

Setting up Forwarding and Remote Access

Entering Access Code

Access Code

You must enter an access code to be able to receive transferred messages, or listen to and control your answering machine from other telephones.

Remote Control On/Off

The remote control is switched off with the factory-installed access code ( access code to switch on the remote control. If you want to switch the remote control off enter the factory-installed code

0000). Change the

0000 again.

Answering Machine · Listening to Messages 17

1 Press b.

Notice

CAUTION!

Notice

2 Using [ select

ACCESS CODE.

3 Confirm with OK.

Access Function

You can also call the function by pressing

OK, 79 and OK.

4 Enter a four-digit code.

No Identically PIN Codes!

The access code may not be identical to the VIP code.

5 Confirm with OK.

Forwarding Messages

The device forwards messages to a specified telephone number. Once the configured number of messages is reached, the device calls the number. If the call is answered, a greeting text is played. Then the person on the line must enter the access code. If no code is entered or an incorrect code is entered three times, the device hangs up.

1 Press b.

2 Using [ select

FORWARDING.

3 Confirm with OK.

Access Function

You can also call the function by pressing

OK, 77 and OK.

4 Use [ to select whether you would like to switch for-

warding on or off.

5 Confirm with OK.

6 Enter the number to which the received messages

should be forwarded.

7 Confirm with OK.

8 Use [ to select how many messages should be col-

lected and forwarded together.

9 Confirm with OK.

Overwriting Existing Outgoing Message

When you record a message, you are asked, if you would like to use the old message or would like to record a new one. Confirm

with OK.

10 Recording a new outgoing message: Press OK

to record an outgoing message. Wait for the confirmation tone before you say your text.

11 Press OK to end the recording. The recording is played

back.

Using Remote Access

Remote Control

You can hear and delete new messages, record a new outgoing message or switch answering machine on or off with a telephone call.

Tone Dialling

The telephone on this connection must be set to tone dialling. Press a key within 50 seconds, otherwise the connection is cut-off (country and network dependent).

1 Call your number. 2 Wait, until the answering machine switches on and

plays the outgoing message.

3 Enter the access code. 4 The device interrupts the outgoing message and plays

new messages. If no new messages have been received, you will hear two confirmation tones.

Conserving Function of Fax Reception Mode

If you select the 5/2 option for the number of rings of the answering machine, the answering machine switches on after two rings, when you have received new messages. If there are no new messages, the device rings five times. If the device does not pick up after two rings, you have no new messages. You can terminate the remote access without incurring any telephone costs.

5 The functions listed below are available using the

numeric keys.

6 Hang up to end the remote access.

Remote Control Functions

Aborting Current Function

Occasionally the answering machine might not react to your entry—for example while you are listening to a message. Cancel the current func-

tion by pressing ‰. Select the next function

with the appropriate number key.

Listening to Messages

Hearing Current Message Again: Press ‚.

Listening to All Messages: Press ƒ.

Listening to Next Message: Press „.

Deleting Messages

To Delete the Current Message: Press ‡ while lis-

tening to the message.

Deleting All Messages: Press ‡ after listening to all

the messages.

18 Sagem · SPFX 43 · 47 · SP 4840

Press ‡ again within five seconds to confirm the deletion.

Notice

CAUTION!

Notice

Outgoing Message

Listening to the Outgoing Message Press †.

Recording a New Outgoing Message:

1 Press ….

2 Wait for the confirmation tones.

3 Press ….

4 Wait for the long confirmation tone before beginning

with the text.

5 Press … to end the recording.

Control Functions

Aborting Last Function: Press ‰.

Switching Off Answering Machine Press ˆ.

Switching On Answering Machine Press Š.

Switching Answering Machine On

Modifying the Settings

Entering the VIP Code

VIP Code

If callers enter the VIP code, the device continues to ring, even if the answering machine has taken over the call. With this function, certain persons can reach you even if you have set the number of rings to zero.

No Identically PIN Codes!

The VIP code may not be identical to the access code for remote control.

1 Press b.

2 Using [ select

3 Confirm with OK.

VIP CODE.

Conserving Function of Fax Reception Mode

If the answering machine is switched off you have to enter the access code while the fax switch analyzing the incoming signal. After the 4th ring the tone heard changes (factory settings of the number of rings for fax switch, also see Chapter

Setting the Fax Switch page 29). Press Š, to

activate the answering machine. Afterwards you can call additional functions.

Recording Internal Memos

Internal Memos on the DeviceInternal Memos

You can record voice messages (= memos), which can be played as messages. The limit on duration of recording set for messages applies even to the recording duration of memos.

Recording Length for Memos

The configured recording length for incoming messages also limits the length of the internal memos.

1 Press b.

2 Using [ select

3 Confirm with OK.

4 Press OK to record a voice message. Wait for the con-

firmation tone before you say your text.

5 Press OK to end the recording. The recording is played

back. After that the ä key starts flashing. The

voice message is displayed as a new message.

QUICK NOTE.

Access Function

You can also call the function by pressing

OK, 73 and OK.

Access Function

You can also call the function by pressing

OK, 78 and OK.

4 Enter a four-digit code.

5 Confirm with OK.

Setting the Recording Duration

Recording Length

You can limit the length of the incoming messages and internal memos.

1 Press b.

2 Using [ select

RECORD. TIME.

3 Confirm with OK.

Access Function

You can also call the function by pressing

OK, 74 and OK.

4 Use [ to select the desired recording length or unlim-

ited time (automatic).

5 Confirm with OK.

Answering Machine · Recording Internal Memos 19

6Fax

Notice

CAUTION!

Notice

Help 4 · Fax

Printing Informations for Fax Transmission

Press î and 4 to print instructions for send-

ing fax messages and for configuring the fax switch.

Unsuitable Doc uments!

Unsuitable Documents!

Do not insert any documents into the device that ...

... are wet, have been edited with correction fluid, are soiled or have a coated surface.

… that are written on with a soft pencil, with paint, chalk or charcoal.

… originate from newspapers or magazines (printing ink).

… that are held together with office or notebook staples or with tape or glue.

… are pasted with note papers. … are creased, crumpled or torn.

10 Documents · A5/A4

Use documents with sizes A5 or A4 with 60 to 100 g/m weight. You can insert up to ten documents at a time.

Fax

2 Insert the documents face up into the document feeder.

The top most document will be fed in first.

3 Set the desired resolution. You can choose between

RESOL.: STANDARD (for documents without spe-

cial features), print or drawings) and

RESOL.: FINE (for texts with small

RESOL.: PHOTO (for pho-

tos). Press RES. The configured resolution appears on

the display. Press RES again to change the resolution.

Setting the Contrast

They can adjust the preset contrast (also see Chapter

Settings

, page 28).

4 Dial the desired number. There are several ways to do

this:

5 Press o.

Busy Number

Cancel Transmission

Press j to eject the documents without sending

them.

Automatic Redial

If the subscriber is busy, the device dials the

number again after some time. Press j, in order

to cancel the transmission process. After the

Sending a Fax

1 Insert the additional document support on the docu-

ment feeder.

transmission, the device prints out a transmission report depending on the settings.

Manual Dialling: Dial the desired number using the numeric keypad.

Telephone Book:

1 Press m.

Access Function

You can also search for an entry in the tele-

phone book by pressing OK, 11 and

OK.

2 Select an entry using [. Enter the starting letters with

the numeric keypad to quickly navigate through the telephone book.

Multiple Categories for One Entry

You can save an entry multiple times with the same name but in a different category. In the telephone book, the first letter of the category appears after the entry.

20 Sagem · SPFX 43 · 47 · SP 4840

Short Dial: Press Ý. Select the desired entry using [

Notice

or with the numeric keys.

Recalling Short Dial Number

4 Press o. The direct-inward dialling number or sub

address is dialled only after a short pause.

Access Function

You can also load short dial entries by holding the respective number key pressed (for at least two seconds).

Speed Dialling: Press the desired speed dial key

(ë).

Redial List

Redial List: Press @. Use [ to select an entry from the

list of the dialled numbers.

Outgoing Calls

Access Function

You can also load the redial list by pressing OK,

22 and OK.

Caller List: Press and hold @ (at least two seconds).

Use the [ to select an entry from the list of callers.

Calls Received

Access Function

You can also load the caller list by pressing OK,

21 and OK.

CLIP Prerequisite

Calling Line Identification (CLIP)

Sending Fax Manually

1 Insert the document. 2 Enter the desired number using the numeric keypad or

select a saved entry.

3 Press l.

4 Press o.

Direct Inward Dialling or Selecting Sub-address

Direct Inward Dialling or Sub-address

You can send a fax to a direct-inward dialling number or a sub addressor or call from a direct-inward dialling number or sub address - for example to use a certain service of a fax database provider. For this purpose, attach the directinward dialling number or sub address with a short dialling pause to the fax number.

1 Enter the desired number using the numeric keypad or

select a saved entry.

2 Hold R pressed (for at least two seconds).

3 Enter the direct-inward dialling number or sub address.

Eavesdropping while Connection is Established

Type 1 (kleiner Core)

(SPFX¦43, SP¦4840)

Eavesdropping while Con nection is Establi shed

You can listen while a connection is established, for example if a fax transmission constantly fails.

Enter the desired number using the numeric keypad or

select a saved entry. Press l.

No Hands-free Operation Possible

Hands-free operation is not possible with this function. You cannot answer if the subscriber picks up.

Sending to Multiple Recipients (= Broadcasting)

Broadcast Transmissions

You can send one fax to multiple recipients in succession.

Entering Recipients Individually

1 Insert the document.

2 Press OK, 34 and OK. The document is now

read.

3 Enter the desired number using the numeric keypad or

select a saved entry.

4 Confirm with OK.

5 Enter the next telephone numbers.

6 Confirm with OK. You can enter up to 25 recipients.

7 Press o. The device transmits the fax message succes-

sively to all recipients.

Sending a Fax to a Group

1 Insert the document.

2 Press OK, 13 and OK.

3 Use [ to select the group to which you would like to

send a fax.

4 Confirm with OK.

5 Using [ select

6 Confirm with OK.

Transmission to Multiple Recipients

If your device cannot reach a recipient, the fax message is sent to the other recipients. After the device has called all recipients, it once again dials the numbers that previously could not be reached.

SEND FAX?.

Fax · Sending Fax Manually 21

Sending Fax Later

Notice

CAUTION!

Notice

Sending Fax Later

If you would like to make use of the lower telephone tariffs or if the recipient can be reached at some specific time only, you can send the fax at a later time—within 24 hours.

1 Insert the document.

2 Press OK, 33 and OK.

3 Enter the time, at which the document should be trans-

mitted, e.g. 14 00 for 2 pm.

4 Confirm with OK.

5 Enter the desired number using the numeric keypad or

select a saved entry.

6 Selecting a Saved Entry: Confirm the selected

entry using OK.

7 Press o. The device goes into standby mode and trans-

mits the fax at the entered time. You can continue to make telephone calls and receive faxes

Sending Fax Later

Cancel a Scheduled Fax Transmission

Press j to eject the document. This interrupts

the standby mode.

Fax Reception

If you have not changed the factory settings, received faxes will be printed out automatically. If no paper or no ink film is inserted, the device saves the incoming faxes. The

ä key blinks. Once paper or a new ink film is

inserted, the saved faxes are printed out.

Paper Not Inserted Correctly

Check if you have inserted clamped paper correctly. The lever on the right hand side next to the paper feeder must be folded backwards.

Message Memory Full

If the message memory is full, no additional messages can be received. A warning appears on the display. Follow the specifications in the technical data.

Delete Fax Memory Service Code

Delete Fax Messages Sent

If there are problems with printing out saved fax messages, a service code is available (see also section

Service

, page 37).

Receiving Fax Manually

Select manual reception under number of rings of the fax switch (see Chapter Setting the Fax Switch, page 29). The device will not receive faxes on its own. This setting is useful, when you want to receive faxes via a modem connected to a computer.

Receiving Fax Manually

You can start fax reception manually, by pressing o.

Polling Faxes

Fax Polling

With the fax polling function, you can retrieve faxes that lie ready in the dialled device. You can keep a document ready in your device, which can be polled by others.

Polling Faxes Directly

1 Enter the desired number using the numeric keypad or

select a saved entry.

2 Hold o pressed (for at least two seconds).

Polling Secure Faxes

Secure Fax Polling

With this function, you can poll faxes that are protected with a code.

1 Press OK, 31 and OK.

2 Enter the code.

3 Confirm with OK.

4 Enter the desired number using the numeric keypad or

select a saved entry.

5 Press o.

Polling Send of Faxes

Unauthorised Fax Polling!

Protect your document against unauthorised polling with a code.

Secure Fax Polling

A caller who knows the code can poll the fax from your device. You can continue to make telephone calls and receive faxes

1 Insert the document.

2 Press OK, 32 and OK.

3 Enter a code (max. 20 characters).

4 Confirm with OK.

Sending Fax Later

Cancel a Scheduled Fax Transmission

Press j to eject the document. This interrupts

the standby mode.

Using Fax Templates

Fax Templates

Five fax templates, which you can use, are stored in your device. With these templates you can quickly create, for example, a short fax note or an invitation.

1 Press OK, 43 and OK.

2 Use [ to select the template you would like to print.

3 Confirm with OK. The device prints the template.

4 Fill the template and send it to the desired recipient per

fax.

22 Sagem · SPFX 43 · 47 · SP 4840

7Copier

Notice

Help 5 · Copier

Printing Informations for Copying

Press î and 5 to print the help for copying.

10 Documents · A5/A4

Use documents with sizes A5 or A4 with 60 to 100 g/m weight. You can insert up to ten documents at a time.

Inserting Documents

1 Insert the additional document support on the docu-

ment feeder.

2 Insert the documents face up into the document feeder.

The top most document will be fed in first.

Making a Copy

Press COPY briefly. The copy is created.

Creating Multiple Copies

1 Hold COPY pressed (for at least two seconds).

2 Enter the number of times you would like to copy the

document (maximum of 15 copies).

3 Press COPY.

4 Using [ select whether to reduce or enlarge the doc-

ument in size when copying. You can magnify up to 200 percent or reduce to as small as 50 percent of the original size.

5 Confirm with OK. The copy is created.

Copier

Cancel Copying

Press j to eject the documents without copying

them.

3 Set the desired resolution. You can choose between

RESOL.: STANDARD (for documents without spe-

cial features), print or drawings) and

tos). Press RES. The configured resolution appears on

the display. Press RES again to change the resolution.

RESOL.: FINE (for texts with small

RESOL.: PHOTO (for pho-

Setting the Contrast

They can adjust the preset contrast (also see Chapter

Settings

, page 28).

Copier · Inserting Documents 23

8SMS

Notice

(model dependent)

Function is not supported in all countries a nd networks

(Function is not supported in all countries and networks)

Help 8 · SMS

½. You can enter a line break using |. Press CTRL

and the respective letter key to enter the special character printed above it.

You can enter 160 characters.

Printing Instructions for SMS Functions

Press î and 8 to print the instructions for

SMS functions.

SMS Requirements

CLIP for SMS

Your device is preset for using the SMS (Short Messaging Service) services. Caller Line Identification (CLIP) must be activated for the SMS to work. It is possible that you will not be able to send and receive SMS messages from a private branch exchange (depending on the country and network).

SMS with Secret Number

Should you face problems in sending SMS, the reason for the same could be that you are using a secret number or that the device is connected to an old ISDN System.

SMS Requirements

Ask your telephone service provider ... ... whether you must register for the SMS Serv-

ice. ... to which mobile telephone service providers

you can send SMS ... which costs are applicable. ... which functions are available.

Sending SMS

1 Press _.

2 Confirm with OK.

Access Function

You can also call the function by pressing

OK, 61 and OK.

SMS Templates

The last five SMS messages written remain

saved as templates. Press @ until the

desired message appears.

3 Enter the text using the letter keypad. Enter capital let-

ters by pressing and holding + key. You can delete indi-

vidual characters using \. You can enter space using

Navigating and Printing

You can move the cursor using [. Use C to

delete individual characters. Press and hold

C (at least two seconds) to delete the entire

text. Press COPY to print the message

before sending it.

4 Confirm with OK.

5 Enter the desired number using the numeric keypad or

select a saved entry.

Sending to Multiple Recipients (= Broadcasting)

You can send an SMS message to up to five

recipients. Press OK after entering the

number.

6 Press _. The message is sent.

SMS in Ireland

In Ireland, some providers will only accept SMS messages with a 140 character limit.

Notification by SMS

SMS Notification

You can have an SMS message sent to a telephone number of your choice when faxes or SMS messages are received or the answering machine receives calls or voice messages in your absence.

1 Press OK, 65 and OK.

2 Use [ to select whether you would like to be

informed about new SMS messages.

3 Confirm with OK.

4 Use [ to select whether you would like to be

informed about calls in your absence.

5 Confirm with OK.

6 Use [ to select whether you would like to be

informed about new fax messages.

7 Confirm with OK.

8 Use [ to select whether you would like to be

informed about new messages on the answering machine.

9 Confirm with OK.

10 Enter the number to which the SMS should be sent.

11 Confirm with OK. A message appears on the display

stating the notification by SMS is activated.

24 Sagem · SPFX 43 · 47 · SP 4840

Receiving SMS Messages

Notice

Receiving an SMS on the DevicePaper Not Inserted Correctly

Paper Not Inserted Correctly

Check if you have inserted clamped paper correctly. The lever on the right hand side next to the paper feeder must be folded backwards.

SMS Reception

Received SMS messages are printed out automatically. If you have turned the automatic printing function off, the SMS messages will be stored. Your device can store up to 30 SMSs.

Reading SMS Messages

Reading an SMS on the Dev ice

After reception of a new SMS message, the ä key

lights up.

1 Press ä.

2 Select the SMS using [.

3 Press ä. The Read SMS menu opens.

Loading Previously Read SMS Messages

1 Press OK, 62 and OK.

2 Using [ select the SMS that you would like to read.

Unread SMS messages are marked with a

3 Confirm with OK.

Navigating and Printing

You can move the cursor using [. Press

COPY to print the SMS message.

4 Press j to return to the SMS list.

Calling Further SMS Functions

Press OK to call additional SMS functions.

Calling SMS Functions

SMS Functions on the Device

1 While reading an SMS message, press OK to load addi-

tional SMS functions.

2 Use [ to select an option: You can display informa-

tion about the SMS message, print or delete the message, forward the message to another recipient or send an SMS response. You can return to the list of SMS messages, or view the next or previous SMS message.

3 Confirm with OK.

SMS in Ireland

Some providers do not include the entire telephone number of the SMS sender. In such cases a direct response to the SMS message will not be delivered. Instead, create a new SMS message. Pay attention when entering the area code.

Printing SMS Messages

Printing an SMS on the Device

1 Press OK, 63 and OK.

2 Using [ select the SMS message you would like to

print.

PRINT: ALL—Prints all received and composed

SMS messages that you have saved

PRINT: INBOX—Prints all received SMS messages PRINT: OUTBOX—Prints all sent SMS messages

that you have saved

PRINT: NEW—Prints all unread SMS messages

3 Confirm with OK.

Printing an Individual SMS message

If you would like to print an individual SMS

message, load the message. Press COPY to

print the message.

Deleting SMS Messages

Deleting an SMS on the DeviceSMS Deletion Introduction

If the message memory is full, the device cannot receive any more messages. Delete SMS messages to free up memory.

1 Press OK, 64 and OK.

2 Use [ to select the SMS messages you would like to

delete:

DELETE: ALL SMS—Deletes all received and com-

posed SMS messages that you have saved

DELETE: READ SMS—Deletes all read SMS mes-

sages

DELETE: SENT SMS—Deletes all sent SMS mes-

sages that you have saved

3 Confirm with OK.

4 Confirm the deletion with OK.

Deleting Single SMS Message

If you would like to delete an individual SMS

message, load the message. Press OK, and

using [ to select

OK.

DELETE. Confirm with

SMS · Receiving SMS Messages 25

Modifying the Settings

Notice

Changing Transmitting and Receiving Numbers

Send and Receive Numbers

All numbers that you need to send and receive SMSs are stored in your device. In case you moved to another telephone service provider, you must change these numbers. You can set your device for two SMS service providers.

1 Press OK, 66 and OK.

2 Use [ to select the SMS service provider that you

would like to set.

3 Confirm with OK.

4 Enter the number for sending SMSs.

5 Confirm with OK.

6 Enter the number for receiving SMSs.

7 Confirm with OK.

8 Use [ to select the SMS service provider through

which you would like to send SMSs.

9 Confirm with OK.

Receiving SMS Messages

You can receive SMS messages via both providers.

Turning Off the Automatic Printing

Automatic Printing

You can deactivate the automatic printing of SMS messages.

1 Press OK, 66 then OK repeatedly until

SMS: YES

2 Using [ indicate whether you would like to turn

printing on or off.

3 Confirm with OK.

appears on the display.

Cancelling Entry

If you have entered the incorrect code, you can cancel the entry with

SURE: NO.

Switching SMS Reception On

1 Press OK, 45 and OK.

2 Enter the service code 41206.

3 Confirm with OK.

4 Using [ select

5 Confirm with OK.

SURE: YES.

Cancelling Entry

If you have entered the incorrect code, you can cancel the entry with

SURE: NO.

Switching SMS Reception On and Off

Switching SMS Rece ption Off

If you are using a cordless telephone with SMS function on the same telephone line, then the specific device at which you will receive an SMS message will depend on the specific manufacturer. Only one of the devices will receive the SMS message. Try to turn off the SMS reception on your cordless telephone. If this is not possible, switch off SMS reception on the device. You can continue to send SMS messages even while SMS reception is switched off.

Switching SMS Reception Off

1 Press OK, 45 and OK.

2 Enter the service code 31207.

3 Confirm with OK.

4 Using [ select

5 Confirm with OK.

26 Sagem · SPFX 43 · 47 · SP 4840

SURE: YES.

9 Fun and Games

Notice

Help 7 Games and Fun

Printing informations for the Games and Fun functions

Press î and 7 to print the instructions for

the Games and Fun functions of your device.

Sudoku

Sudoku is a Japanese number puzzle. The game has 3 × 3 squares divided into 3 × 3 fields. Depending on the difficulty level, lesser or more digits are already given at the beginning of the game. The aim of the game is to fill digits from 1 to 9 in the game field is such a way that each digit appears only once in a row, a column and each of the nine blocks. There is only one solution.

Last Solution Available

The solution of the last printed game is saved. The solutions of earlier games are no longer available.

Printing a Game

1 Press OK, 48 and OK.

2 Using [ select

3 Confirm with OK.

4 Using [ select the difficulty level.

5 Confirm with OK.

6 Enter, how many copies of the Sudoku you would like

to print (maximum 9 copies).

7 Confirm with OK.

8 Using [ select if you would like to print the solution.

9 Confirm with OK.

SUDOKU:NEW.

Printing the Solution

1 Press OK, 48 and OK.

2 Using [ select

3 Confirm with OK.

Sudoku for Every Day

You can have a new Sudoku automatically printed each day.

1 Press OK, 48 and OK.

2 Using [ select

3 Confirm with OK.

4 Enter the time, e.g. 14 00 for 2 pm.

5 Confirm with OK.

6 Using [ select the difficulty level.

7 Confirm with OK.

8 Enter, how many copies of the Sudoku you would like

to print (maximum 9 copies).

9 Confirm with OK.

10 Using [ select if you would like to print the solution.

11 Confirm with OK.

12 Using [ indicate whether you would like to turn

printing on or off.

13 Confirm with OK.

Sudoku for Every Day

Switching Off Function

You can turn off the daily Sudoku print by selecting the function as described above and by switching off the automatic printing under point 12.

SUDOKU:SOLUTION.

SUDOKU:AUTO.

Printing the Last Game Again

1 Press OK, 48 and OK.

2 Using [ select

3 Confirm with OK.

4 Enter, how many copies of the Sudoku you would like

to print (maximum 9 copies).

5 Confirm with OK.

6 Using [ select if you would like to print the solution.

7 Confirm with OK.

Fun and Games · Sudoku 27

SUDOKU:LAST.

10 Settings

Notice

CAUTION!

Notice

Cursor Navigation 1

Navigating in the Editor

You can move the cursor using [. Use C to

delete individual characters. Press j to close the

menu and return to the starting mode.

Entering the Date and Time

1 Press OK, 91 and OK.

2 Enter the time, e.g. 14 00 for 2 pm.

3 Enter the date (two digits for each field), for example

08 06 27 for June 8th, 2027.

4 Confirm with OK.

Time and Date After a Short Power Failure

You must check the time and date after a short

power failure. Confirm with OK.

Selecting the Language

1 Press OK, 92 and OK.

2 Use [ to select the desired display language.

3 Confirm with OK.

Selecting the Country

Setting the Country Correctly

Setting the Country Correctly!

Reset When Setting the Country

Settings will be Deleted!

When you select a new country, all settings are reset to the factory defaults for that country. Saved data remains intact. Check the number entered for the header.

1 Press OK, 93 and OK.

2 Use [ to select the country in which you are operat-

ing the device.

3 Confirm with OK.

4 Using [ select

5 Confirm with OK.

SURE: YES.

Entering Number

Page Header

Your name and number are added together with date, time and page number at the top edge of each fax transmission (= header).

1 Press OK, 94 and OK.

2 Enter your number. Using # or * you can enter a

plus sign.

3 Confirm with OK.

Entering Name

1 Press OK, 95 and OK.

2 Enter the name using the letter keypad. Enter capital

letters by pressing and holding + key. You can delete

individual characters using \. You can enter space

using ½. Press CTRL and the respective letter key to

enter the special character printed above it.

Navigating in the Editor

You can move the cursor using [. Use C to

delete individual characters.

3 Confirm with OK.

Setting the Contrast

For copying and printing of fax messages, you can select different contrast levels.

1 Press OK, 44 and OK.

2 Using [, select the desired contrast:

CONTR.:LIGHT—For brighter copies and fax trans-

mission

CONTR.:NEUTRAL—For all types of originals (for

example white text on black background or documents with coloured background)

CONTR.:OPTIMISED (Factory settings)—Opti-

mized adaptation for text and photo printing

CONTR.:DARK—For darker copies and fax transmis-

sion (for example documents with faint printing)

3 Confirm with OK.

Modifying the Basic Settings

The changed settings are stored as new default settings. If you select a special function for a one-time process, take care to restore the default settings or factory settings after that.

28 Sagem · SPFX 43 · 47 · SP 4840

Reducing Transmission

Notice

Speed

Reducing Transmission Speed

The device adapts the transmission speed to the line quality. This may take some time, especially for overseas connections. Set a lower transmission speed if you are sending faxes into networks with poor line quality.

1 Press OK, 38 and OK.

2 Use [ to set whether you would like to use a lower

transmission speed.

3 Confirm with OK.

Switching Page Adjustment On and Off

Page Adjustment

In order that no information is lost, received faxes are reduced in size when printed.

1 Press OK, 37 and OK.

2 Use [ to select whether you would like to switch size

reduction on or off.

3 Confirm with OK.

Setting the Ring Tones

Selecting the Ring Tone

Ring Tones

You can select from among ten different ring tones.

1 Press OK, 55 and OK.

2 Use the number keys 0 to 9 to select a ring tone.

Using [, set the volume.

3 Confirm with OK.

Adjusting Volume Level

Setting the Ring Tone Volume

Yo u can a djust the volum e of the ring tone when the device is ringing or when you set the ring tone. You can save different volumes for the see Chapter Fax Switch).

Setting the Volume on the Device

Using [ you can set adjust the volume when the device

is ringing.

™ (day) and ˜ (night) modes, (also

Setting the Day Mode

1 Press OK, 51 and OK.

2 (Only for devices with built-in answering machine):

Using [ select the number of rings for the answering

machine. The answering machine responds after these many number of rings.

Conserving Function of Fax Reception Mode

3 Confirm with OK.

4 (Only for devices without built-in answering machine):

Using [ select the total number of rings. . The device

stops the ring after these total number of rings and accepts a call or a possible silent fax.

5 Confirm with OK.

6 Use [ to select the number of rings for the fax switch.

After the number of rings, the fax switch switches on and distinguishes between fax transmissions and telephone calls. While the device is checking the call, it continues to ring.

7 Confirm with OK.

8 Using [, set the volume.

9 Confirm with OK.

Silent Fax Transmission

Older devices do not transmit any fax-tone (= CNG tone) as an announcement for fax transmission (= silent fax transmission). If the total number of rings has been set to a value using silent fax transmissions cannot be received automatically.

Setting the Fax Switch

Fax Switch

The built-in fax switch of your device distinguishes between fax messages and telephone calls. Faxes are automatically received, telephone calls can be received—even

Setting the Night Mode

1 Press OK, 52 and OK.

2 Configure the same settings as for the day mode (see

steps 2 to 9).

on additionally connected devices. While the device is checking the call, it continues to ring.

Day and Night Mode

You can set how often the device should ring before picking up separately for the modes

™ (day) and ˜ (night). This

makes it possible for you to receive faxes silently at night without getting disturbed.

Press º/» to switch between day and night mode. With

the activated timer modes

™ (day) and ˜ (night) at the configured times.

›, the device switches between the

Setting the Timer

Timer

The timer switches between the modes ™ (day) and ˜ (night) at the configured times.

1 Press OK, 53 and OK.

2 Enter the time at which the device should switch to

(day) mode, for example 06 00 for 6 o'clock

a.m.

3 Confirm with OK.

Settings · Reducing Transmission Speed 29

™

4 Enter the time at which the device should switch to ˜

(night) mode, for example 22 00 for 10

o'clock p.m.

5 Confirm with OK.

Special Settings

Silent Fax Reception

If you would like to accept a fax without preceding rings, set the number of rings of the fax switch to

Switching Off All Rings

All Rings Off

If you don't want to be disturbed, e.g. in the night, by any incoming calls, you can set the number of rings to device switches immediately to silent fax reception.

Printing Lists and Help Pages

Printing Numbers and Entries

List of Numbers

The list of numbers and entries contains the last ten calls received and numbers dialled as well as the saved entries and groups.

Press OK, 23 and OK. The list is printed.

Printing Call Log

Call Log

The call log contains the last 50 dialled numbers.

1 Press OK, 41 and OK.

2 Using [ indicate whether you would like to turn

printing on or off.

3 Confirm with OK.

4 Switch on printing: Use [, to select whether the

call list should be printed immediately or after every 50 calls.

5 Confirm with OK.

Printing the Telephone Book

Press OK, 17 and OK. The device prints a list with

the telephone book entries and saved assignments.

Printing Fax Journal

Fax Journal

The fax journal is a list of the last ten faxes sent and received.

1 Press OK, 35 and OK.

2 Using [ indicate whether you would like to turn

printing on or off.

3 Confirm with OK.

4 Switch on printing: Use [, to select whether the

fax journal should be printed immediately or after every ten transmissions.

5 Confirm with OK.

Printing Transmission Report

After every transmission, the device prints out a transmission report. If a transmission error occurs, an error report is printed out. You can switch off printing of the transmission report.

1 Press OK, 36 and OK.

2 Using [ indicate whether you would like to turn

printing on or off.

3 Confirm with OK.

Printing Help Pages

0. The

Help 1 · Overview

Press î and 1 to print an overview of the help pages.

Help 3 · Telephone Book

Press î and 3 to print an overview of the telephone

book and answering machine functions (model dependent).

Help 4 · Fax Transmission

Press î and 4 to print instructions for sending fax mes-

sages and for configuring the fax switch.

Help 5 · Copier

Press î and 5 to print the help for copying.

Help 6 · Function List

Press î and 6 to print a list of all functions and settings

of your device.

Help 7 · Games and Fun

Press î and 7 to print the instructions for the Games

and Fun functions of your device.

Help 8 · SMS

Press î and 8 to print the instructions for SMS func-

tions (depending on the model).

Starting Initial Installation

1 Press î and 2.

2 The device prints out a help page and starts the initial

installation process.

30 Sagem · SPFX 43 · 47 · SP 4840

11 Telephone Lines and Additional Devices

Notice

Configuring Telephone Lines and Services

PABX Systems

Additional Telephone No Extension

An additional telephone connected to the device on a telephone socket is not considered an extension.

1 Press OK, 96 and OK.

2 In some countries you can set the dialling process to

pulse dialling or tone dialling (DTMF tones). Use [

to select the desired dialling process.

Selecting the Dialling Process

Only use pulse dialling if tone dialling is not yet activated for your telephone line.

3 Confirm with OK.

4 Use [ to set whether you operate your device on an

extension.

5 Confirm with OK.

6 Configuring an extension: Enter the outside line

access code with which you reach the public telephone

network. This is usually 0.

DSL Connection

In the event that you use a DSL modem: Connect the device to the slot intended for analogue telephones/fax machines! For additional information, please consult the operating manual of your DSL system. Ask your telephone or internet service provider if necessary.

ISDN Connection

Your device is an analogue fax device (Group 3). It is not an ISDN device (Group 4), and therefore it cannot be operated directly on an ISDN connection. In order to do this, you need either an analogue adapter or a connection for analogue terminals. Details for ISDN connections can be found in the instructions provided with the terminal adapter or the dial-up router.

Voice Mailbox

You cannot simultaneously use the answering machine facility of your telephone service provider (= voice-mail box) and receive faxes on your devices. Get the mail-box function for your telephone connection deactivated or set the number of rings for the fax switch to lower than your device (also see Chapter Setting the Fax Switch, page

29). When the fax switch accepts the call, the mail-box of the service provider does not step in. Enquire with your telephone company.

5 on

Connecting Additional Devices

Additional Devices

You can operate additional devices on a telephone line, such as cordless telephones, answering machines, modems or charge counters.

SMS Reception with Additional Telephone

Incorrect Outside Line Access Code

In rare cases, the outside line access code may be a different number or a two-digit number. For older telephone systems, the outside line

access code can be R (= Flash). Press R to

enter this outside line access code. If the connection to the public telephone network is not possible, contact your telephone system supplier.

7 Confirm with OK.

8 When finished, the device tests the telephone line.

Confirm with OK.

9 Your device checks whether it can establish a connec-

tion with the public telephone network. If it cannot establish the connection, you are once again asked for input.

Telephone Lines and Additional Devices · Configuring Telephone Lines and Services 31

SMS Reception with Additional Telephone

If you are using cordless telephone with SMS function on the same connection, then the specific device at which you will receive and SMS message will depend on the specific manufacturer. Only one of the devices will receive the SMS message. Try to turn off the SMS reception on your cordless telephone.

Connection to the Device

Notice

CAUTION!

Notice

Connection to the Device

You can connect additional devices directly to your device. Insert the telephone cable of the additional device into the

EXT socket (RJ-11-connection) on the device.

Externe Geräte anschließen

Changing Code

Changing Easylink Codes!

Only change the codes if it is absolutely neces-

sary. The codes must begin with * or # and

must be different.

1 Press OK, 54 and OK.

2 Enter the new code for starting fax reception.

3 Confirm with OK.

4 Enter the new code for taking over the line on an addi-

tional device.

5 Confirm with OK.

Direct Connection Recommended

We recommend direct connection to the device because this allows the fax switch to function optimally and to control the additional devices.

Connection to the Telephone Line

Order of Connections

In order for the fax switch to function, the device must be first in the series if multiple devices are connected to the same telephone socket. Follow the correct order.

Connection to the First Telephone Socket

If you have multiple telephone sockets for the same telephone line, the device must be connected to the first telephone socket.

Using Additional Telephones (Easylink)

Easylink

With the Easylink function you can control your device with additional telephones. To use this function, additional telephones must be set to the tone dialling mode (DTMF/MFV tones) (for this purpose see the operating manual of your additional telephone).

Starting Fax Reception

If you pick up at an additional device and hear that you are receiving a fax (whistling tone or silence), you can start the

fax reception by pressing *5 on the additional tele-

phone or pressing o on the device.

Using an External Answering Machine

For the best operation, the answering machine must be

connected to the EXT socket of the device. The numbers

of rings set for the external answering machine should be less than the one set under

Example of the setting: Number of Rings of the External Answering Machine .. 1

FAX RINGS .............................................................. 3

(also see Chapter Setting the Fax Switch, page 29)

External Answering Machine

The outgoing message must be shorter than ten seconds. Avoid music in your announcement.

If the external answering machine has a “conserving function” (i.e. a function that changes the number of rings as soon as new messages have been recorded), deactivate this function.

If the external answering machine records fax signals, but your device cannot receive faxes, inspect the connection of the external answering machine

FAX RINGS by at least two.

Taking Over the Line

If you pick up on an additional telephone and the device continues to ring or attempts to receive a fax, you can dis-

connect the device from the line. Press ** on the

additional telephone.

32 Sagem · SPFX 43 · 47 · SP 4840

12 Service

Notice

CAUTION!

DANGER!

CAUTION!

Disruptions

Troubleshooting

Should disruptions occur, follow the instructions on the display and on the error report.

Checking the Ink Film Reserve

1 Press OK, 46 and OK.

2 The number of pages that can still be printed with the

ink film is shown on the display.

3 Press j to return to the starting mode.

If the ink film used up or if there is no ink film in the device, a message appears on the display.

Changing the Ink Film

Use Original Consumable Materials!

Observe Packaging Instructions

Follow the instructions on the packaging of the consumable materials.

Introduction to Plug’n’Print Card

For receiving or copying documents, an ink film must be inserted in your device. Your device is delivered with an already inserted free ink film for a few test pages. For this film, you do not require any Plug’n’Print card (= chip card with information regarding ink film capacity). For every next ink film that you insert, you must load the capacity memory with the included Plug’n’Print card.

1 Remove the paper from the paper feeder and take the

paper tray out of the device.

2 Open the device by lifting the panel using grip in the

centre and folding it up.

Device can Close with a Snap!

Lock the cover of the device completely into place when opening the device. You could be injured if the cover falls while you are working on the device.

3 Grip the rear ink film roll at both the sides and place it

next to the front ink film roll.

4 Remove both the rolls from the device. The used ink

film cannot be reused.

Data on Used Ink Films!

The messages and copies you have printed out can be read from used ink films. Consider data protection issues when disposing of used ink films.

5 Pull the used Plug’n’Print card out of the plug socket

on the left hand side next to the ink film tray. The Plug’n’Print card cannot be reused.

Service · Checking the Ink Film Reserve 33

6 Carefully remove the rubber bands from the new ink

DANGER!

film. Make sure that the film is not damaged!

7 Place the larger roll with the ink film in the rear ink film

tray. The blue gear wheel must be on the right hand side.

8 Place the smaller roll without ink film in the front tray.

The blue gea r whee l must be on the ri ght hand si de and the pin must be inserted in the depression on the left hand side.

10 Turn the blue gear wheel forward to tension the ink

film. The ink film must not have any creases.

11 Close the device. Insert the paper tray in the opening

provided for it behind the paper feeder. Insert paper again.

Fixing a Paper Jam

1 Remove the paper from the paper feeder and take the

paper tray out of the device.

2 Open the device by lifting the panel using grip in the

centre and folding it up.

Device can Close with a Snap!

9 Break the chip card from the Plug’n’Print card. Insert

the chip card in the plug socket on the left hand side next to the ink film tray.

3 Carefully pull out the paper.

34 Sagem · SPFX 43 · 47 · SP 4840

Lock the cover of the device completely into place when opening the device. You could be injured if the cover falls while you are working on the device.

4 Turn the blue gear wheel forward to tension the ink

DANGER!

film. The ink film must not have any creases.

5 Close the device. Insert the paper tray in the opening

provided for it behind the paper feeder. Insert paper again.

Fixing a Document Jam

1 Remove the paper from the paper feeder and take the

paper tray out of the device.

2 Open the device by lifting the panel using grip in the

centre and folding it up.

3 Open the scanner cover and the cover of the automatic

document feeder by first pushing the support (A) and then the support (B) inside. The cover (C) falls freely.

4 Carefully pull the document to the front or to the back

out of the device.

5 Close the scanner cover and the cover of the automatic

document feeder. Both the supports must securely snap into place.

6 Turn the blue gear wheel forward to tension the ink

film. The ink film must not have any creases.

Device can Close with a Snap!

Lock the cover of the device completely into place when opening the device. You could be injured if the cover falls while you are working on the device.

7 Close the device. Insert the paper tray in the opening

provided for it behind the paper feeder. Insert paper again.

Service · Fixing a Document Jam 35

Cleaning

DANGER!

Notice

DANGER!

Instructions for Cleaning!

Unplug the device from the power socket before cleaning it. Use a soft, lint-free cloth. Never use liquid or easily flammable cleansers (sprays, abrasives, polishes, alcohol, etc.). Do not allow any moisture to reach the interior of the device.

Fax Cleaning Sheets

Special fax cleaning sheets are available as accessories from our call centre. Insert a sheet into the

document feeder. Press j; the page is ejected.

Repeat this process at a few times.

1 Remove the paper from the paper feeder and take the

paper tray out of the device.

2 Open the device by lifting the panel using grip in the

centre and folding it up.

4 Lightly wipe the upper side of the scanner glass (A) and

the lower side of the document feeder/scanner film (= white plastic plate) (B) with a cloth.

5 Clean the feed roller (A) and the underside of the sup-

port pad of the feeder roller (B) with a soft, lint-free cloth moistened with cleaning alcohol (96 percent). Rotate the feed roller; You must clean the entire roller.

6 Close the scanner cover and the cover of the automatic

document feeder. Both the supports must securely snap into place.

7 Turn the blue gear wheel forward to tension the ink

Device can Close with a Snap!

film. The ink film must not have any creases.

Lock the cover of the device completely into place when opening the device. You could be injured if the cover falls while you are working on the device.

3 Open the scanner cover and the cover of the automatic

document feeder by first pushing the support (A) and then the support (B) inside. The cover (C) falls freely.

8 Close the device. Insert the paper tray in the opening

provided for it behind the paper feeder. Insert paper again.

36 Sagem · SPFX 43 · 47 · SP 4840

Checking the Firmware Ver-

CAUTION!

Notice

sion

1 Press OK, 47 and OK.

2 The model designation and the configured country

appear on the display.

3 Confirm with OK.

4 The information on the firmware version of the device

is displayed.

5 Confirm with OK.

Using Service Codes

Introduction

The service codes delete all the changed settings and your device is reset to factory settings. It may be possible that the device with the changed settings reacts differently than expected.

Using Service Codes

Settings will be Deleted!

Only use the service codes if this is absolutely necessary. Some service codes also delete saved messages and telephone book entries.

1 Press OK, 45 and OK.

2 Enter a service code:

7117—Deletes all changed settings and

saved data. The device is reset to factory settings and the initial installation process is started.

7140—Deletes all changed settings. Saved

data and telephone book entries remain intact.

7227—Deletes saved faxes, when there are

problems with printing.

3 Confirm with OK.

4 Using [ select

5 Confirm with OK.

SURE: YES.

Power Cycling

If a problem occurs that cannot be corrected with the instructions in this user manual (see also the help below), follow the steps given here.

1 Pull out the power plug. 2 Wait at least ten seconds, then plug the power plug

back into the socket.

3 Follow the instructions on the display and in the error

report. If the problems repeats, please contact our technical customer service or your retailer.

Cancelling Entry

If you have entered the incorrect code, you can cancel the entry with

Service · Checking the Firmware Version 37

SURE: NO.

General Information

The time and date flash on the display. You must check the time and date after a short power fail-

ure. Confirm with OK.

Problems when Faxing or Printing

Faxes sent are of poor quality.

Change the resolution from

RESOL.: STANDARD to

RESOL.: FINE or RESOL.: PHOTO.

Change the contrast. Clean the scanner and the document feed slot. Test the device by making a copy of the document. If the

device is in order, the device of the recipient might be defective.

The device produces black lines when sending or printing. Clean the scanner and the document feed slot.

Copy is blank. Insert the documents face up into the document feeder.

Printing is interrupted. Paper or document jam, no paper or ink film. Follow the

instructions on the display and in the error report. There could be a small pause after printing several pages.

The device continues printing automatically.

No printing Check if you have inserted clamped paper correctly. The le-

ver on the right hand side next to the paper feeder must be folded backwards.

Documents are not properly fed. Clean the scanner and the document feed slot.

Problems with the Connection

The device rings once, remains silent for a short while and starts ringing again.

This is absolutely normal. The fax switch checks the call after the first ring. If it is a voice call, the device continues to ring.

No dial tone Check the installation of the device. Connect the telephone

cable to the socket marked LINE. Insert the telephone plug

into your PTT line socket.

Fax transmissions are constantly interrupted. Try to send the fax manually: Press l, and dial the

number. If the recipient is using an answering machine,

wait until you hear a whistling tone. Press o.

It is possible that the recipient's device is not ready to receive.

You hear a whistling tone or silence in the handset. The call is a fax: Press o on the device. Press *5 on

the additional telephone. Hang up.

No fax reception or a short fax audio signal as message on the answering machine

Using function 51, set the number of rings for the fax switch to 4 and the total number or the number of rings for the answering machine (model dependent) to 5 (see Page

29). You cannot simultaneously use the answering machine fa-

cility of your telephone service provider (= voice-mail box) and receive faxes on your devices(see page 31).

38 Sagem · SPFX 43 · 47 · SP 4840

13 Appendix

Technical Data

Dimensions

Dimensions (L¦×¦H¦×¦W) ...................303¦×¦126¦×¦195¦mm

Weight

Weight ...................................................................1,9¦kg

Mains Connection

Mains Connection.................. 220¦–¦240¦V¦~ / 50¦–¦60¦Hz

Power Consumption

Stand-by Mode

Stand-by Mode...............................................<¦1,5¦W

Transmission

Transmission ...................................................<¦20¦W

Recommended Ambient

Recommended Ambient..................................18¦–¦28¦ºC

Relative Humidity

Relative Humidity............... 20¦–¦80¦% (non-condensing)

Connection Type

Connection Type......................................PSTN · PABX

Dialling Mode

Dialling Mode Tone / pulse dialling (country dependent)

Standards

Safety EN 60950-1

Safety........................................................... EN¦60950-1

Emissions EN 55022 Class B

Emissions ........................................... EN¦55022 Class B

Immunity to Electrical Noise EN 55024

Immunity ........................................................EN¦55024

Scanner

Scan Width

Scan Width ........................................................212¦mm

Horizontal Resolution

Horizontal Resolution....................................8 dots/mm

Vertical Resolution Standard

Vertical Resolution ................... Standard: 3,85 lines/mm

Vertical Resolution Fine

..................................................... Fine: 7,7 lines/mm

Memory

Telephone Book (Low)

Telephone Book ......up to 50 entries (SPFX¦43, SP¦4840)

Telephone Book (High)

....................................... up to 200 entries (SPFX¦47)

Voice Messages (Type 2)

Voice Messages....................up to 30 minutes (SPFX¦47)

Fax Messages (Low)

Fax Messages

up to 15 pages (standard test letter) (SPFX¦43, SP¦4840)

Fax Messages (High)

........... up to 50 pages (standard test letter) (SPFX¦47)

SMS Messages

SMS Messages ............................ up to 30 SMS messages

Paper

Capacity Without Paper Tray

Capacity ........................... 15 sheets (without paper tray)

Capacity with Paper Tray

..........................................50 sheets (with paper tray)

Size

Size.................................................... A4 · 210¦×¦297¦mm

Thickness

Thickness ................................................0,07¦–¦0,11¦mm

Weight

Weight .........................................................60¦–¦90¦g/m²

Document Feed Slot

Capacity

Capacity ............................................................10 sheets

Width

Width........................................................148¦–¦212¦mm

Length

Length.......................................................100¦–¦600¦mm

Thickness

Thickness ................................................0,06¦–¦0,15¦mm

Fax

Type Group 3

Type.................................................................. Group 3

Compatibility

Compatibility...............................................ITU-T¦T.30

Data Compression

Data Compression...........................................MH · MR

Modulation (Low)

Modulation ....V.21 · V.27ter · V.29 (SPFX¦43, SP¦4840)

Modulation (High)

......................V.17 · V.21 · V.27ter · V.29 (SPFX¦47)

Transmission Speed (Low)

Transfer Speed

.................................... 9.600¦bps (SPFX¦43, SP¦4840)

Transmission Speed (High)

.................................................14.400¦bps (SPFX¦47)

Subject to Change

Technical specifications subject to change without notice.

Guarantee

(Terms and Conditions for United Kingdom only)

In order to supply the guarantee, you should contact your dealer or Sagem Communications Helpdesk. The proof of purchase will be required.

Please make usage of your equipment for the purpose for which it was designed and under normal usage conditions. Sagem Communications do not accept any liability for any usage made out of the frame of its original designed purpose and any consequence that may arise from this usage.

Should any malfunctioning arise, the dealer or Sagem Communications Helpdesk will advise you what to do.

A) General Guarantee Conditions

Sagem Communications undertakes to remedy by repair or exchange at its own convenience, free of charge for labour and replacement parts, any defects in the equipment during the guarantee period of 12—twelve—months (3—three—months for accessories), from the date of original invoice of the Equipment, where those defects are a result of faulty workmanship.

Unless the customer has concluded with Sagem Communications a maintenance contract in respect of the equipment which specifically provides for repairs to be carried out at the customer's premises, the repairs will not be carried out on the equipment at the customer premises. The customer must however return the defective equipment at his/her own expense, to the address given by the dealer or Sagem Communications Helpdesk.

In case a product needs to be sent in for a repair, it always has to be accompanied by a proof of purchase (which is not altered, written on or in any way be made illegible) showing that the product is still under warrantee. In case no proof of purchase is enclosed, the Sagem Communications repair center will use the production date as a reference of establishing the warrantee status of the product.

Apart from all legal obligatory rules, Sagem Communications, do not give any Guarantee, either implicit or explicit which is not set force in the present section, and could not be hold responsible for any direct or indirect, material or immaterial damage, in or out of the frame of the present guarantee.

If any provision of this guarantee shall be held to be in whole or in part invalid or illegal due to an obligatory rule applicable to consumers pursuant to their national legislation, such invalidity or illegality shall not impair or affect the remaining provisions or parts of this guarantee.

This guarantee does not affect the Customer statutory rights.

B) Exclusions From Guarantee

Sagem Communications shall have no liability under the guarantee in respect of:

Appendix · Technical Data 39

•) Damage, defects, breakdown or malfunction due to one or more of the following:

– Failure to properly follow the installation process and instructions for use

– An external cause to the equipment (including but not

limited to: lightening, fire, shock, vandalism, inappropriate conditions of electrical network or water damage of any nature)

– Modifications made without the written approval of Sagem Communications

– Unsuitable operating conditions, particularly of temperature and humidity

– Repair or maintenance of the equipment by persons not authorized by Sagem Communications

•) Wear and tear from normal daily use of the equipment and its accessories

•) Damage due to insufficient or bad packaging of equipment when returned to Sagem Communications

•) Usage of new versions of software without previous approval of Sagem Communications

•) Work on any equipment or software modified or added without the prior written consent of Sagem Communications

•) Malfunctions not resulting from the Equipment or from software installed in user workstations for the purpose of use of the equipment.

Communication problems related to an unsuitable environment including:

– Problems related to access and/or connection to the Internet such as interruptions by access networks or malfunction of the line used by the subscriber or his correspondent

– Transmission faults (for example poor geographical coverage by radio transmitters, interference or poor line quality)

– The local network fault (wiring, servers, workstations) or the failure of the transmission network (such as but not limited to interferences, fault or poor quality of the network)

– Modification of the parameters of the cellular network carried out after the sale of the Product

•) The normal servicing (as defined in the user guide supplied with the equipment) as well as malf unct ioni ng du e to servicing not being carried out. Servicing costs are in any event always borne by the customer.

•) Malfunctions resulting from the usage of products, consumables or accessories not compatibles with the equipment.

C) Out of Guarantee Repairs

In the cases set forth in B) as well as after expiry of the guarantee period, the customer must ask the Authorized Sagem Communications Repair Centre for a cost estimation.

The repair and delivery costs will be invoiced to the customer.

The foregoing shall apply unless otherwise agreed in writing with the customer and only for the United Kingdom.

Helpdesk: 08 45 - 090 03 16

40 Sagem · SPFX 43 · 47 · SP 4840

The CE symbol confirms conformity with the EU directives that apply to the device.

Declaration of Conformity (DoC)

Hereby, Sagem Communications Austria GmbH declares that this SPFX¦43, SPFX¦47, SP¦4840 is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

WWW

You can find the complete Declaration of Conformity on our website www.sagem-ca.at/doc

Energy Star 2007

Energy Star

As a participant in the ENERGY STAR programme, Sagem Communications Austria GmbH has made sure that this machine complies with the ENERGY STAR requirements.

Recycling

Packaging: To facilitate packaging recycling, please conform to your local selective recycling rules.

Batteries: Old batteries have to be deposited in designated collection areas.

WEEE

Product: The crossed out dustbin logo on your product signifies it is classified as Electrical and Electronic Equipment covered by special disposal regulations.

To enforce recycling, recovery of The Waste Electrical and Electronic Equipment (WEEE) and to protect the environment and human health, European regulations requires that you selectively collect waste equipment using one of the following options:

• Your retailer will take your equipment back if you are buying a replacement product.

• Waste equipment can also be deposited in designated collection areas.

The paper and cardboard packaging used can be disposed of as recyclable paper. Have the plastic wrapping and Styrofoam packaging recycled or dispose of it in the non-recyclable waste, depending on the requirements in your country.

Trademarks: The references mentioned in this manual are trademarks of the respective companies. The lack of the

trademarks É and Ë does not justify the assumption that

these dedicated terminologies are free trademarks. Other product names used herein are for identification purposes only and may be trademarks of their respective owners. Sagem Communications disclaims any and all rights in those marks.

Reproduction Not Permitted

The reproduction of certain documents (e.g. by scanning, printing, copying) is prohibited in many countries. The list of such documents below is not intended to be complete, it only offers a general overview. In case of doubt, consult your legal advisor.

· Passports (personal identification)

· Entrance and exit visa papers (immigration papers)

· Military service documents

· Bank notes, travel checks, payment orders

· Postage stamps, tax stamps (stamped or unstamped)

· Loan papers, certificates of deposit, bonds

· Documents protected by copyright Follow the statutory regulations of your country with

regard to the legal validity of fax transmissions—particularly in connection with the validity of signatures, meeting delivery deadlines or disadvantages resulting from the loss of quality in the transmission, etc.

Take care to maintain the statutory regulations of your country regarding telecommunications secrecy and data privacy.

This product is intended for use on an analogue public telecommunications network (PSTN) and in the country specified on the packaging. Use in other countries can result in faulty functioning.

For more information, please contact the technical service centre for your country. Should problems arise during use of your machine, please contact your retailer first.

Neither Sagem Communications nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by the purchaser or third parties as a result of accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or failure to strictly comply with Sagem Communications operating and maintenance instructions.

Sagem Communications shall not be liable for any damages or problems arising from the use of any options or any consumable materials other than those designated as original Sagem Communications products or Sagem Communications approved products.

Sagem Communications shall not be held liable for any damage resulting from electromagnetic interference that occurs from the use of any interface cables other than those designated as Sagem Communications products.

All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Sagem Communications. The information contained herein is designed only for use with this product. Sagem Communications is not responsible, if this information is applied to other devices.

Appendix · Declaration of Conformity (DoC) 41

This user manual is a document that does not represent a contract.

Errors, printing errors and changes are reserved.

2009 Sagem Communications Austria GmbH

42 Sagem · SPFX 43 · 47 · SP 4840

Appendix · Declaration of Conformity (DoC) 43

Customer Information

Introduction 1

As part of our continuing quest for total customer satisfaction, all of our products are made with ease-of-use and reliability in mind.

Introduction 2

In your user manual you will find all the information required to use your machine. If, after consulting your user manual, you still require assistance, you should contact our Call Centre. Our personnel are highly trained specialists who can ensure that you receive the maximum benefit from your product.

Introduction 3

We can assist your more quickly if you do not call us from the machine, rather an external telephone. Keep a printout of the settings as well as the serial number of the machine handy. The serial number can be found on the type label.

United Kingdom

Telephone: 08 45 - 090 03 16 Fax: 02 07 - 519 50 24

Spaltenumbruch

Introduction 1

You can order original accessories from our homepage or—in some countries (see below)—per telephone on our toll-free number.

Introduction 2

Use only original consumable materials. The warrantee does not cover damages to the device resulting from other consumables.

United Kingdom

Telephone: 0800 - 358 08 07

E-Mail

E-Mail: dti.faxinfoline@sagem.com

Internet

Internet: www.sagem-communications.com
