User Manual
2 Sagem SPFX 40 · 45
EN
Dear Customer,
In buying this device you have chosen a quality product
made by Sagem. Their device fulfils the most varied requirements for private use or in your office and business
everyday.
Your device is delivered with an already inserted free ink
film for a few test pages. For this film, you do not require
any Plug’n’Print card (= chip card with information regarding ink film capacity).
Telephone book
In the telephone book of your machine, you can save entries with multiple numbers and collect multiple entries
into groups. You can assign various ring tones to the entries.
Short Dialling
You can assign short dial numbers to frequently dialled telephone numbers. You can load these numbers quickly
with the short dial button and the number buttons.
The cordless telephone is provided with its own telephone
book. With the cordless telephone you can send and read
SMS messages (function is not supported in all countries
and networks).
Functions
You can individually set ringer tones and notification
tones, wallpaper and menu colours of the cordless telephone. Additional functions such as alarms, timer, birthday reminder or a room monitoring function are also available to you. You can register up to five cordless telephones
with your device.
You can send fax messages in different resolutions to one
or more recipients or a group. You can also poll faxes and
prepare documents for polling.
Fax Templates
Five fax templates, which you can use, are stored in your
device. With these templates you can quickly create, for example, a short fax note or an invitation.
Select the resolution for text and photo in order to copy
documents with your machine. You can also create multiple copies.
You can send SMS messages from your machine if this
service is activated for your telephone line (this function is
not supported in all countries and networks). Received
SMS messages can be managed with the extensive functions of the SMS menu.
Activate notification by SMS to receive an SMS message,
for instance on your mobile phone, when calls, fax transmissions or other messages arrive in your absence (this
function is not supported in all countries and networks).
If you want, your device can print Sudoku puzzles in four
different difficulty levels with solution.
We hope you enjoy your machine and its many functions!
About this User Manual
With the installation guide on the following pages, you can
start using your machine quickly and easily. Detailed descriptions can be found in the following sections of this
user manual.
Read the entire user manual carefully. Follow all safety instructions in order to ensure proper operation of your machine. The manufacturer accepts no liability if these instructions are not followed.
Multiple models of this machine series are described in this
user manual. Please note that some functions are only
available with specific models.
Symbols Used
Dangers
Tips
Warns about dangers for people, damage to the machine or other objects as well as possible loss of data.
Injuries or damage can result from improper handling.
This symbol designates tips that will help you to use
your machine more effectively and easily.
Installation guide 3
EN
Installation guide
Contained in the packing
Packing contents Sagem basic
‚ Device
ƒ Paper tray
„ Power cord with plug (country-specific)
… Telephone cord with plug (country-specific)
† Additional document holder
Packing contents Sagem basic Dect
‡ Charging station
ˆ Three batteries
‰ Cordless telephone
User Manual
User manual with installation guide (not depicted)
Verpackungsinhalt
Packing Contents
Opening the cover
Opening the cover
Pull down the cover for paper and document feeder behind
the panel.
Geräteklappe öffnen
Attaching paper tray
Attaching paper tray
If you just want to insert paper temporarily, fold the paper
support in the cover up (A). You can remove the paper after receiving fax or copying and close the cover again.
If you constantly require paper in the device, insert the paper tray in the opening provided for it behind the paper
feed (B).
Papierhalter installieren
Inserting paper
Paper Format
Before you can receive or copy documents, you must insert
paper. Please use only suitable paper in the standard format
A4 (210 × 297 millimetre · preferably 80 g/m
2
). Observe
the information in the technical data.
Loading Paper
Preparing Paper
Loading paper Sagem
1 Fold open the lever on the right beside the paper feed
towards front.
2 Insert paper in the paper feeder. You can use the paper
support in the cover to load up to 15 sheets (A4 · 80
g/m²). In the paper tray you can insert maximum 50
sheets (A4 · 80 g/m2).
3 Fold open the lever on the right beside the paper feed
backward in order to enclose the paper.
Papier einlegen
If one of the parts is missing or damaged, please contact your retailer or our customer service.
Separate the paper sheets by fanning them out, then
align them by tapping edge of the stack lightly
against a flat surface. This will prevent several sheets
of paper from being drawn in all at once.
4 Sagem SPFX 40 · 45
EN
Connecting the Telephone Cord
Connecting the Telephone Cable
Connect the telephone cord to the device by inserting it in
the socket designated with LINE (RJ-11-Connector). In-
sert the telephone plug into your telephone connection
socket.
Telefonkabel anschließen
PABX Systems 1
Ireland
Two-pin
When connecting to the telephone line socket, use only a
two-pin RJ-11-telephone cable (modular plug). The use
of a four-pin cable may lead to the machine not functioning correctly.
Connecting the Power Cord
Mains Voltage at Setup Loca tion
Device power cord
Connecting power cord of the device
Connecting the Mai ns Cable
Insert the mains cable into the connection located on the
rear side of the device. Connect the mains cable to the electrical socket.
Netzkabel anschließen
Charging station power cord
Connecting the power cord of the charging station
Connect the mains cable of the charging station to the
electrical socket.
Ladestation anschließen
Initial installation
Starting Initial Installation
After you connect your device to the mains voltage, the initial installation commences. Press
î
. Your device prints a help page.
Selecting the Language
1 Use [ to select the desired display language.
2 Confirm with OK.
Selecting the Country
Setting the Country Correctly
Setting the Country
1 Use [ to select the country in which you are operat-
ing the machine.
2 Confirm with OK.
After this input, the machine prints another help page and
checks the telephone line.
Entering Your Number
Header
Your name and number are added together with date, time and
page number at the top edge of each fax transmission (= header).
Entering Your Number
1 Enter your number. Using # or * you can enter a
plus sign.
2 Confirm with OK.
Entering name
1 Enter the name using the letter keypad. Enter capital
letters by pressing and holding + button. You can delete
individual characters using \. You can enter a space us-
ing ½. Press CTRL and the respective letter key to en-
ter the special character printed on it.
2 Confirm using OK.
Entering the Time and Date
Entering Time/Date
1 Enter the time, e.g. 1400 for 2 pm.
2 Enter the date (two digits each) e.g. 080607
for 8 June 2007.
3 Confirm with OK.
Help 2 · Initial Installation P rocess
Inserting batteries in cordless telephone
1 Insert the new batteries in the battery compartment
with the positive and negative poles as shown in the picture in the battery compartment.
If you connect your device as extension to a telephone system, you must set it for working as an extension (also see Chapter "Telephone connections
and additional devices, page 35).
Check whether the mains voltage of your device (indicated on the type label) matches the mains voltage
available at the setup location.
Always set the country in which you are operating the machine. Otherwise, your machine is not adapted to the telephone network. If your country is not included in the list,
you must select a different setting and use the correct telephone cable for the country. Consult your retailer.
You can move the cursor using [. Use C to de-
lete individual characters.
You can restart the initial installation process any
time. Press î and 2.
Never use non-rechargeable batteries in the
cordless telephone. Follow the specifications in
the technical data.
Installation guide 5
EN
2 Place the cover on the battery compartment and slide it
upward until it snaps into place.
3 Place the cordless telephone into the charging station.
Putting cordless telephone in operation
Switching on cordless telephone
Press the green “ button for at least two seconds for
switching on your cordless telephone.
Configuring the Cordless Telephone
Normally your cordless telephone is registered with your
device in the factory. In the starting mode, press OK. The
display shows on which base unit and with which number
the cordless telephone is registered.
Unregistered cordless telephones
Never place the cordless telephone into the charging station without batteries.
Leave the cordless telephone in the charging station for at least twelve hours. The batteries will
heat up slightly during charging; this is not dangerous.
If you acquired a model with several cordless telephones, only one cordless telephone is registered
with your device in the factory. Insert the batteries as
described above and register the cordless telephones
with your device (also see Chapter "Telephone Connections and Additional Devices", page 35).
6 Sagem SPFX 40 · 45
EN
Overview
Overview of the Menu Functions
The following functions are available on your device.
There are two ways in which you can call functions:
Menu Navigation
Navigating in the menu: Press OK or one of the two
arrow keys [ to open the function menu. Page through
[ menu entries. Use OK to select a function. Press C to
return to the previous menu level. Press j to close the
menu and return to the starting mode.
Direct Loading
Calling functions directly: You can call a menu func-
tion directly using the function number. Press OK and en-
ter the appropriate function number using the numeric
keypad. Confirm using OK. You will find the function
number in the following list.
Help 6 · Function List
1 Telephone book
11 Looking Up an Entry (SPFX 40 · 45)
11 Looking up an entry ..................................page 21
12 New Entry (SPFX)
12 New entry..................................................page 15
13 Creating Group
13 Creating group ..........................................page 15
14 Short Dial without Short Dia lling Button
14 Short dial...................................................page 16
15 Changing Entries
15 Modifying an entry....................................page 15
16 Deleting Entries
16 Deleting entries .........................................page 15
17 Printing Entries
17 Printing entries..........................................page 31
2 Calls
21 Received Calls (SPFX 40 · 45)
21 Received calls.............................................page 21
22 Outgoing Calls (SPFX 4 0 · 45)
22 Outgoing calls ...........................................page 21
23 Printing Entries
23 Printing entries..........................................page 31
3 Fax
31 Polling
31 Polled reception.........................................page 22
32 Polling Send
32 Polling send...............................................page 23
33 Sending Fax Later
33 Sending fax later........................................page 22
34 Broadcasting
34 Sending to multiple recipients (= broadcast)
.......................................................................page 22
35 Printing Fax Journal
35 Printing fax journal....................................page 31
36 Printing transmission report
36 Printing transmission report ......................page 31
37 Print Reduced in Size
37 Print reduced in size ..................................page 30
38 Reducing transmission speed
38 Reducing transmission speed .....................page 30
4 Miscellaneous
41 Printing Call Log
41 Printing call list .........................................page 31
43 Using Fax Templates
43 Using fax templates....................................page 23
44 Setting the Contrast
44 Setting the contrast....................................page 30
45 Using Service Codes
45 Using service codes ....................................page 42
46 Checking the Ink Film R eserve
46 Checking the ink film reserve ....................page 38
47 Checking the Firmware Version
47 Checking the firmware version ..................page 42
48 Sudoku
48 Sudoku......................................................page 29
5 Fax switch
51 Configuring Day Mode
51 Configuring day mode .............................. page 31
52 Configuring Night Mode
52 Configuring night mode ........................... page 31
53 Setting the timer
53 Setting the timer ....................................... page 31
54 Easylink
54 Easylink .................................................... page 37
55 Setting the Ring Tones
55 Setting the ring tones ................................ page 30
6 SMS
61 Sending SMS (SPFX 40/45 · 48/49)
61 Sending SMS............................................ page 25
62 Reading SMS (PPF 650 · 685/695 · SPFX 40/45 · 48/49)
62 Reading SMS............................................ page 26
63 Printing SMS
63 Printing SMS............................................ page 27
64 Deleting SMS (PPF 650 · 685/695 · SPFX 40/45 · 48/49)
64 Deleting SMS ........................................... page 27
65 Notification by SMS
65 Notification by SMS................................. page 26
66 SMS Access
66 SMS access................................................ page 27
8 Cordless Telephone
(Type 2)
(SPFX¦45)
81 Locating cordless phones
81 Locating cordless phones........................... page 18
82 Registering Cordless Telephone
82 Registering cordless telephone................... page 35
83 Deregistering Cordless Telephone
83 De-registering cordless telephone .............. page 36
9 Settings
91 Entering the Date and Tim e
91 Entering the date and time........................ page 30
92 Selecting the Language
92 Selecting the language............................... page 30
93 Selecting the Country
93 Selecting the country ................................ page 30
94 Entering Number
94 Entering number....................................... page 30
95 Entering Name (SPFX)
95 Entering name .......................................... page 30
96 Configuring T elephone Lines and Services
96 Configuring telephone lines and services... page 35
Press î and 6 to print a list of all functions and set-
tings of your device.
Overview 7
EN
Device Overview
Basic Description
‚ Paper tray
ƒ Document feeder (writing facing up)
„ Panel with display
… EXT-Socket—Connection socket for additional de-
vices
† LINE-Socket—Connection socket for telephone cable
SPFX 40
Internal Description
‚ Scanner glass
ƒ Rollers of the automatic document feeder
„ Rests of the intake rollers
… Document guide / scanner film
† Cover for scanner and automatic document feeder
‡ Toothed wheel for tightening the ink film
ˆ Ink film roll in the rear ink film compartment
‰ Ink film roll in the front ink film compartment
Š Slot for the Plug’n’Print card
‹ Locks for the cover of the scanner and automatic doc-
ument feeder
Innenansicht numme riert
8 Sagem SPFX 40 · 45
EN
Cordless Telephone Panel
Panel Monochrome Dect
Programmable button left
õ—Programmable button (the saved function appears on
the display)
Programmable button right
ô—Programmable button (the saved function appears
on the display) / calling options / confirming selection
The green button
“/@—Press briefly: Place calls / receives calls / hands
free / press and hold: Redialling / switching on cordless telephones
Red button
’—Press briefly: Ending calls / aborting menu functions
/ press and hold: switching off cordless telephone
Telephone book button
m—Press briefly: Calling up the telephone book from the
device / hold pressed: Calling the telephone book of the
cordless telephone
SMS button
_—Calling the SMS menu (function is not supported
in all countries and networks)
Arrow Keys
[—Calling the menu functions / navigation within the
menu / selecting options / moving the cursor / adjusting
the volume level
C button
C—Returning to the previous menu level / deleting indi-
vidual digits
OK button
OK—Calling the menu functions/ confirming input
Keypad lock
*/•—Press and hold: Turning keypad lock on/off
0 button
0—Inputting special characters
R button
R—Switching between calls (= call toggling)
Intercom key
{—Forwarding a call to the device or to other cordless
telephones
Symbols on the LCD Display
Display Monochrome Dect
Rechargeable Batteries
·—Display of the battery charge
Telephone INT
¢—Internal telephone call (= intercom) with another
cordless telephone or the device
Telephone EXT
£—External telephone call
SMS
_—New SMS received
Alarm
¥—Alarm clock switched on
Timer
©—Timer switched on
Registration number
1—Number with which the cordless telephone is regis-
tered with the base unit
Overview 9
EN
Panel
Telephone Book
m—Press briefly: Calling up the telephone book entries.
Selecting the entries with the [ / press and hold:
Fax Switch
º/»—Setting the timer and the fax reception modes (=
fax switch). Modes set on the display
™ (day), ˜ (night).
Activated timer is indicated with
›
SMS (not supported everywhere)
_—Calling the SMS menu (function is not supported
in all countries and networks)
Short Dial (Type 1)
Ý (SPFX¦40)—Press briefly: Load short dial entries. Se-
lecting the entries with the [ or numeric keys / press and
hold: Assign a new short dial entry
Dect (Type 2)
{ (SPFX¦45)—During a call: Forwarding a call to a spe-
cific or all cordless telephones / in the starting mode: Locating cordless phones (all registered cordless phones start
ringing)
Stop
j—Function abort / return to the starting mode / docu-
ments eject
C
C—Return to the previous menu level / press briefly: de-
leting individual characters / press and hold: deleting complete input
Arrow Keys
[—Calling the menu functions / navigation within the
menu / selecting options / moving the cursor / adjusting
the volume level
OK
OK—Calling the menu functions/ confirming input
Start
o—Press briefly: Starting transmission of messages / press
and hold: Starting fax polling
Letter Keypad
Letter keypad—Entering characters. Entering capital let-
ters by pressing and holding + button. Deleting using \.
Entering a break using |. Entering a space using ½. En-
tering special characters by pressing and holding CTRL
button.
Message
ä—Lights up, if new messages are received / list of
the new messages with submenus / blinks in the case of device error (for example no ink film)
Copy (SMS)
COPY—Press briefly: creating a copy / press and hold:
creating multiple copies / printing SMS
Resolution
RES—Setting higher resolution for faxes and copying
(
RESOL.: STANDARD, RESOL.: FINE, RESOL.:
)
Help
î—Press briefly: Printing help pages and setting lists /
press and hold: Starting initial installation process
Redialling
@—Press briefly: Toggling between the list of the last 10
dialled numbers (= redial list) / press and hold: List of last
ten callers (caller list)
Speaker (PPF 620 · 633 · 650 · SPFX 40 · 45)
l—Listening while connection is established
R
R—Press briefly: insert short line interruption (Hook
Flash) as office index on PABX or for calling special functions in the public telephone network (PSTN)/long press:
Inserting dialling pause
Numeric keys (short dial)
Numeric keypad—Inputting digits, characters and special
characters / press and hold: Recalling short dial numbers
SPFX 45
10 Sagem SPFX 40 · 45
EN
General Safety Information
Your device has been tested in conformity with standards
EN 60950-1 and IEC 60950-1 and should only be operated with telephone systems and power equipment that meet
these standards. The device was built exclusively for use in
the indicated sales region.
Do not make any changes or settings that are not described
in this user manual.
Setting Up the Machine
The device should rest securely on a stabile, flat surface.
The device should rest securely on a stabile, flat surface. If
the device should fall, it can be damaged or can cause injury to people, especially small children. Position all cables in
such a way that no one will stumble on them, thus avoiding possible injuries to persons or damage to the device itself.
The distance between t he device and other ap pliances or objects, m ust be at least 15 ce ntimetres.
The distance between the device and other devices or objects must be at least 15 centimetres; this also applies to the
use of additional cordless telephones. Do not place the device in the vicinity of radios or televisions.
Lock the cover of the device co mpletely into place
Lock the cover of the device completely into place when
opening the device. You could be injured if the cover falls
while you are working on the device.
Protect the device against direct sunlight
Protect the device against direct sunlight, heat, large temperature fluctuations and moisture. Do not place the device in the vicinity of heaters or air conditioners. Observe
the information on temperature and humidity in the technical data.
The device must have sufficient ventilation
The device must have sufficient ventilation and may not be
covered. Do not put your device in closed cabinets or boxes. Do not place the machine on soft surfaces such as tablecloths or carpets and do not cover the ventilation slits.
Otherwise, the device can overheat and catch on fire.
In the event that the device becomes too hot, or if you see smoke com ing from the device
In the event that the device becomes too hot, or if you see
smoke coming from the device, you must immediately pull
the power cable out of the power socket. Have your device
examined by trained professionals at a technical service location. To prevent the spread of fire, open flames should
be kept away from the device.
Do not plug in the device in moist rooms.
Do not plug in the device in moist rooms. Never touch the
mains cable, the mains connection or the telephone socket
with wet hands.
Do not allow liquids to enter into the device.
Do not allow liquids to enter into the device. Disconnect
the device from the power socket if liquids or foreign objects have entered the device and have your device examined by trained professionals at a technical service location.
Do not allow children to handle th e device without supervision.
Do not allow children to handle the device without supervision. The packing materials should be kept out of the
hands of children.
Magnetic telephone handset
The telephone handset of the device is magnetic. Caution,
small metallic objects (paper clips) may be retained if
placed near or on the telephone handset.
Power Supply
Check whether the mains voltage of your device
Check whether the mains voltage of your device (indicated
on the type label) matches the mains voltage available at
the setup location.
Use only the power and telephones cables supplied.
Use only the power and telephones cables supplied.
The device does not have an on/off button.
Set up your device so that the power socket is easily accessible. The device does not have an on/off button. In an
emergency, disconnect your device from the power supply
by pulling the power plug.
Never touch the power or telephone cable if the insulation is damaged.
Never touch the power or telephone cable if the insulation
is damaged.
Disconnect your device from the power and t elephone networks during an electrical storm.
Disconnect your device from the power and telephone networks during an electrical storm. If this is not possible, do
not use the device during an electrical storm.
Before cleaning the surface of your device, disconnect it from the power and telephone networks.
Before cleaning the surface of your device, disconnect it
from the power and telephone networks. Never use liquid,
gaseous or easily flammable cleansers (sprays, abrasives,
polishes, alcohol).
Only clean the display with a dry , soft cloth.
Only clean the display with a dry, soft cloth. If the display
breaks, a mildly corrosive liquid may escape. Avoid all contact with your skin and eyes.
In the event of a power failure, you r device will not function;
In the event of a power failure, your device will not function; saved data is retained.
Repairs
Should disruptions occur, follow the instructions on the
display and on the error report.
Do not make any repairs to the device yourself. Improper
maintenance can result in injuries or damage to the device.
Only have your device repaired by an authorised service
centre.
Do not remove the type label from your device; this would
void the warranty.
Consumable Materials
Use only original consumable materials. These are available from a specialised retailer or through our order service.
Other consumable materials could damage the device or
shorten its service life.
Dispose of old consumable materials according to the
waste regulations of your country.
Cordless Telephone
Never place the cordless telephone in the charging station
without rechargeable batteries or with non-rechargeable
batteries.
Do not install or use your cordless telephone in a damp environment. Never touch the cordless telephone with wet
hands.
The functioning of security systems, medical equipment or
sensitive devices can be disrupted by the transmission power of the cordless telephone. Observe any usage regulations
(or restrictions) in the vicinity of such equipment.
The batteries used should be disposed of according to the
recycling regulations of your country.
Table of Contents 11
EN
Table of Contents
Dear Customer, ......................................................... 2
About this User Manual ............................................ 2
Installation guide .................................... 3
Contained in the packing .......................................... 3
Opening the cover ..................................................... 3
Attaching paper tray .................................................. 3
Inserting paper ........................................................... 3
Connecting the Telephone Cord ............................... 4
Connecting the Power Cord ...................................... 4
Initial installation ...................................................... 4
Inserting batteries in cordless telephone ..................... 4
Putting cordless telephone in operation ..................... 5
Overview ................................................. 6
Overview of the Menu Functions .............................. 6
Device Overview ........................................................ 7
Cordless Telephone Panel .......................................... 8
Panel ......................................................................... 9
General Safety Information................. 10
1 Telephone functions........................ 13
Putting a call from cordless telephone ...................... 13
Calling additional telephone functions .................... 13
Getting outside line ................................................. 13
Hands-free ............................................................... 14
Forwarding a call ..................................................... 14
Placing internal calls ................................................ 14
Calling Line Identification (CLIP) ........................... 14
Missed Calls ............................................................ 14
2 Telephone book of the device........ 15
Saving entry ............................................................. 15
Edit Entry ................................................................ 15
Deleting an Entry .................................................... 15
Groups .................................................................... 15
Short Dial ................................................................ 16
3 Telephone book of the cordless tele-
phone ..................................................... 17
Saving entry ............................................................. 17
Edit Entry ................................................................ 17
Deleting an entry ..................................................... 17
Adding an additional number .................................. 17
Changing the ringer tone ......................................... 17
Calling Options ....................................................... 17
4 Cordless telephone.......................... 18
Looking for cordless telephone ................................ 18
Switching on and off ............................................... 18
Navigating in the menu ........................................... 18
Keypad lock ............................................................. 18
Activating emergency call number ........................... 18
Additional functions ................................................ 18
5 Fax..................................................... 21
Sending fax .............................................................. 21
Manually Sending a Fax ........................................... 21
Direct inward dialling or selecting sub-address ........ 22
Listening while a connection is established .............. 22
Broadcasting ............................................................ 22
Delayed Fax Transmission ....................................... 22
Receiving Faxes ........................................................ 22
Receiving fax manually ............................................ 22
Polling Faxes ............................................................ 22
Using Fax Templates ............................................... 23
6 Copier............................................... 24
Inserting the document ............................................ 24
Creating a Copy ....................................................... 24
Creating Multiple Copies ......................................... 24
7 SMS................................................... 25
SMS Requirements .................................................. 25
Sending SMS ........................................................... 25
Notification by SMS ................................................ 26
Receiving an SMS .................................................... 26
Reading an SMS ...................................................... 26
Calling SMS functions ............................................. 27
Printing SMS Messages ............................................ 27
Deleting SMS .......................................................... 27
Modifying the settings ............................................. 27
8 Fun and Games................................ 29
Sudoku .................................................................... 29
9 Settings on the device..................... 30
Entering the Date and Time .................................... 30
Selecting the Language ............................................. 30
Selecting the Country .............................................. 30
Entering Your Number ............................................ 30
Entering name ......................................................... 30
Setting the Contrast ................................................. 30
Lowering the Transmission Speed ............................ 30
Switching Page Adjustment On and Off .................. 30
Setting the Ring Tone .............................................. 30
Setting the Fax Switch ............................................. 31
Printing Lists and Help Pages .................................. 31
Starting the Initial Installation ................................. 32
10 Settings on the cordless telephone 33
Selecting the language .............................................. 33
Setting the ring tone ................................................ 33
Turning key-tones and signal-tones on and off ........ 33
Setting up silent mode ............................................. 33
Programmable buttons ............................................. 33
Automatic picking up and hanging up the phone .... 33
Resetting the cordless telephone ............................... 34
Displaying call logs and events ................................. 34
11 Telephone Lines and Additional Devic-
es ........................................................... 35
Configuring Telephone Lines and Services ............... 35
Registering and de-registering additional cordless tele-
phones ..................................................................... 35
Connecting Additional Devices ................................ 36
Using Additional Telephones (Easylink) .................. 36
12 Service .............................................. 38
Checking the Ink Film Reserve ................................ 38
Changing the ink film .............................................. 38
12 Sagem SPFX 40 · 45
EN
Fixing a paper jam ................................................... 39
Fixing a document jam ............................................ 40
Cleaning .................................................................. 40
Displaying the battery charge ................................... 41
Changing the batteries in the cordless telephone ...... 41
Checking the Firmware Version .............................. 42
Using Service Codes ................................................ 42
Power Cycling ......................................................... 42
13 Appendix........................................... 44
Technical Data ........................................................ 44
Guarantee ................................................................ 44
Declaration of Conformity (DoC) ........................... 45
Customer Information ............................................. 48
Telephone functions 13
EN
1 Telephone functions
For information on how to connect additional cordless telephones and another device and which functions are available to you, please refer the chapter on Telephone Connections and additional devices, Page 35.
Putting a call from cordless telephone
Dialling a number
Dial the desired number. There are several ways to do this:
Then press “.
Direct dialling
Forwarding fax to the device
Manual dialling: Dial the desired number using the numeric keypad.
Telephone Book of the Cordless Telephone:
1 Hold m pressed (for at least two seconds).
2 Select an entry using [. Enter the starting letters with
the numeric keypad to quickly navigate through the telephone book.
Telephone Book of the Device:
1 Press m.
2 Select an entry using [. Enter the starting letters with
the numeric keypad to quickly navigate through the telephone book.
Redial list: Press and hold @ (at least two seconds). Use
[ to select an entry from the list of the dialled numbers.
Caller List:
1 Press [, and using [
CALLS select PERSON-
ALIS.
.
2 Confirm with OK.
3 Using [, select from which list you would like to dial
a number.
4 Confirm with OK.
5 Select the desired number using [.
Adjusting volume level
Looking up Numbers
Looking up Numbers
During a call, you can look up the telephone book entries.
1 During a call, press ô
Menu.
2 Use [ to select
PHONEBOOK.
3 Using [, dial the desired entry.
Previous menu
Calling additional telephone functions
Function is not supported in all countries and networks
(Function is not supported in all countries and
networks)
Additional telephone functions
You can use additional telephone functions with your device for example call on hold, three-way call or forwarding.
Contact your telephone company to inquire whether or
not these functions are available for your connection. The
signal to the switchboard to call these services is a short line
interruption (Hook Flash). Press the R key to call the ad-
ditional telephone functions.
Receiving a second call
During a call, press ô ACCEPT to accept the new call.
Switching between calls (= hold)
2: Call waiting
1 During a call, press ô Menu.
2 Using [ select
SWITCH.
3 Confirm with OK.
Making a second call
Dialling another numbe r
1 During a call, press ô Menu.
2 Dial using [
SECOND CALL.
3 Enter the desired number using the numeric keypad.
4 Press ô
Call.
1: Ending a call
Getting outside line
PABX Systems
Private branch exchanges (PABX) are typical in many offices and some households. You must dial an outside line
access code in order to get a connection to the public telephone network (PSTN) from a PABX.
Enter the outside line access code with which you reach the
public telephone network before you enter the desired
number or select a stored entry. The outside line access
code is usually 0.
Outside Line Access Code Error
Setting up an extension
You can also press “ first and then dial a number.
The dialling process begins immediately.
If you receive a call on the cordless telephone and
hear that it is a fax call (whistling tone or silence), you
can start the fax reception on the device. Press either
o on the device or *5 on the cordless telephone.
If you have added an additional number to an entry, this entry appears twice in the telephone
book. The symbol of the category appears before
the name.
You can adjust the volume level of the speaker on the
cordless telephone using [ even during a call.
Press õ
Return to return to the previous menu lev-
el.
Hot key: Press R, to toggle between the calls.
Hot key: Pressõ, and dial the other number.
Hot key: Press õ and 1, to end the call and to ac-
tivate the call on hold.
In rare cases, the outside line access code may be a
different number or a two-digit number. For older
telephone systems, the outside line access code can be
R (= Flash). Press R to enter this outside line access
code. If the connexion to the public telephone network is not possible, contact your telephone system
supplier.
If you operate your device permanently at an extension, store the outside line access code with the 96
function (see page 35).
14 Sagem SPFX 40 · 45
EN
Hands-free
Low battery charge
Switching on hands-free
1 During a call, press ô Menu.
2 Using [ select
Deact..
3 Confirm with OK.
Switching off hands-free
1 Select Deact. again.
2 Press ô
Deact..
Switching hands-free on/off
Forwarding a call
Forwarding a call to DectExistence of several devices is the prere quisite
1 During a call, press ô Menu.
2 Using [ select
CALL TRANSFER.
3 Confirm using OK.
4 Select the cordless telephone to which you would like
to transfer the call using [.
5 Confirm using OK.
6 Press ’, to hang up.
Getting back the telephone call
You can get a transmitted telephone call back, before the
cordless telephone is picked up.
1 Press ô
Menu.
2 Using [ select
HANGING UP.
3 Confirm using OK.
Placing internal calls
Intercom DectExistence of several devices is the prere quisite
1 In the starting mode, press {.
2
Using [ dial the cordless telephone you would like to call.
3 Press ô Call.
Calling Line Identification (CLIP)
Function is not supported in all countries and networks
(Function is not supported in all countries and
networks)
CLIP Definition
The number of an incoming call appears on the display.
For this function to work, the Calling Line Identification
Presentation (CLIP) must be activated for your telephone
connection. Enquire with your telephone company. Caller
Line Identification may be associated with a fee.
Setting the Country
Missed Calls
Displaying Telephone Book Names
Missed calls on Dect
If you receive calls in your absence, a message appears on
the display of the cordless telephone.
1 Press OK.
2 Using [, you can page through the list of missed calls.
3 Press “, to go back.
This function is not available if the battery charge of
the cordless telephone is low. Place the cordless telephone into the charging station.
You can switch the hands-free mode on and off by
pressing “ button during a telephone call.
This function is available only if you have registered
several cordless telephones with your device and the
telephones are within the range of the machine.
This function is available only if you have registered
several cordless telephones with your device and the
telephones are within the range of the machine.
If the Caller Line Identification does not work even
though the function is activated for your telephone
connection, check if you have set the correct country
(also see Chapter Settings, page 30).
Your machine displays the name with which you
have saved the number in the telephone book. The
number and name will not be shown if the caller suppresses his number.
Telephone book of the device 15
EN
2 Telephone book of the device
Help 3 · Telephone Functions
Telephone Book
In the telephone book of your device, you can save entries
with multiple numbers and collect multiple entries into
groups. You can assign various ring tones to the entries.
Follow the specifications in the technical data.
Cursor navigation 1
Saving entry
1 Hold m pressed (for at least two seconds).
2 Enter the name using the letter keypad. Enter capital
letters by pressing and holding + button. You can delete
individual characters using \. You can enter a space us-
ing ½. Press CTRL and the respective letter key to en-
ter the special character printed on it.
3 Confirm using OK.
4 Using [, select the category for which you would like
to enter a number:
CATEGORY: HOME, CATEGO-
RY: WORK
, CATEGORY: MOBILE or CATEGO-
RY: FAX
.
5 Confirm with OK.
6 Enter the telephone number.
7 Confirm with OK.
8 You can assign a ring tone to the number. Use the
number buttons 0 to 9 to select a ring tone. Using
[, set the volume.
9 Confirm with OK. The entry is saved.
Edit Entry
1 Press OK, 15 and OK.
2 Using [ select the entry which you would like to edit.
3 Confirm with OK.
4 Edit the name.
5 Confirm with OK.
6 Using [, select the category for which you would like
to enter a number:
CATEGORY: HOME, CATEGO-
RY: WORK
, CATEGORY: MOBILE or CATEGO-
RY: FAX
.
7 Confirm with OK.
8 Enter the telephone number.
9 Confirm with OK.
10 You can assign a ring tone to the number. Use the
number buttons 0 to 9 to select a ring tone. Using
[, set the volume.
11 Confirm with OK. The entry is saved.
Deleting an Entry
1 Press OK, 16 and OK.
2 Using [ select the entry which you would like to de-
lete.
3 Confirm with OK.
4 Confirm
DELETE: YES with OK.
Groups
Groups
You can combine several telephone book entries into a
group. A message is sent to all members of this group in
succession.
Adding Group Entries
1 Press OK, 13 and OK.
2 Use [ to select the group you would like to create.
3 Confirm with OK. You can add entries to the group,
display the members of the group, delete the group or
send a fax to the group.
4 Using [ select
ADD MEMBER?.
5 Confirm with OK.
6 Use [ to select the entry you would like to add to the
group.
7 Confirm with OK.
8 Repeat steps 4 to 6 to add additional entries to the
group.
9 Press j to end the input.
Displaying Group Entries
1 Press OK, 13 and OK.
2 Use [ to select the group you would like to display.
3 Confirm with OK.
4 Using [ select
VIEW MEMBERS?.
5 Confirm with OK.
6 Page through the entries of the group with [.
7 Press j twice to return to the starting mode.
Deleting Individual or All Group Entries
Deleting an Individual Entry
1 Press OK, 13 and OK.
2 Using [ select the group from which you would like
to delete entries.
3 Confirm with OK.
4 Using [ select
DELETE MEMBER?.
5 Confirm with OK.
6 Using [ select the entry which you would like to de-
lete.
7 Confirm with OK.
8 Using [ select
DELETE: YES.
9 Confirm with OK. The entry is deleted.
Press î and 3 to print an overview of the tele-
phone book functions.
You can move the cursor using [. Use C to delete
individual characters. Press j to close the menu and
return to the starting mode.
You can also call the function by pressing OK,
12 and OK.
You can move the cursor using [. Use C to de-
lete individual characters.
Loading...
