Sagem myZ5 User Manual

ENGLISH

You have just purchased a SAGEM phone, we congratulate you; it is recommended that you read this handbook carefully in order to use your phone efficiently and in the best conditions. Your phone can be used internationally in the various networks (GSM 900 MHz and DCS 1800 MHz or PCS 1900 MHz, depending on model) depending on the roaming arrangements with your operator. We remind you that this phone is approved to meet European standards.

WARNING

Depending on the model, network configuration and associated subscription cards, certain functions may not be available. Ensure that your SIM card is a 3 V SIM type t hat is compatible with your phone. Inserting an incompatible card will be indicated

by a message when your phone is switched on. Contact your operator. Your phone is identified by its IMEI number. Write this number down, and do not keep it with your phone, because you may be asked for it if your phone is stolen, in order to prevent it from being used, even with a different SIM card. In order to display

the IMEI on your phone's screen, type: *#06#.

SAGEM™ is a trademark of SAFRAN. AT® is a registered trademark of Hayes Microcomputer Products Inc. Hayes is a registered trademark of Hayes Microcomputer Products Inc. T9 is protected by one or more of the following US patents: 5,818,437, 5,953,541, 5,187,480, 5,945,928, 6,011,554 and other patents are being applied for worldwide.

Java™ and all Java™ based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. The WAP navigator and some message softwares (i-mode) are under licence Openwave. The WAP navigator and the softwares included are the exclusive property of Openwave. For this reason, you may not modify, translate, disassemble or even decompile all or part of these softwares. © 2003 GAMELOFT® - All rights reserved - GAMELOFT® is a registered trademark of GAMELOFT S.A. - All rights reserved. Wellphone™ and SmartCom™ are registered trademarks owned by SmartCom SARL France.

Menus............................................................................................................................................ 7

Your phone package - Accessories ........................................................................................... 8

Activating your phone ................................................................................................................. 9

Information on the SIM card................................................................................................................... 9

Installing the SIM card and the battery ................................................................................................ 10

Getting started ..................................................................................................................................... 10

PIN number.......................................................................................................................................... 11

Setting time and date ........................................................................................................................... 11

Network................................................................................................................................................ 12

First call................................................................................................................................................ 12

Receiving a call.................................................................................................................................... 13

Switching off......................................................................................................................................... 13

Description ................................................................................................................................. 14

Initial screen ............................................................................................................................... 16

Navigation principles ................................................................................................................. 17

Using your phone....................................................................................................................... 18

Increase the efficiency of your phone ..................................................................................................18

Charging the battery ............................................................................................................................ 18

Games ......................................................................................................................................... 20

WAP............................................................................................................................................. 21

The WAP Menu.................................................................................................................................... 21

Configuring WAP parameters ..............................................................................................................22

WAP Logging on .................................................................................................................................. 23

Downloading objects............................................................................................................................ 23

WAP Logging off .................................................................................................................................. 23

GPRS................................................................................................................................................... 23

Contents 3

Applications................................................................................................................................ 24

Services ............................................................................................................................................... 24

Calculator............................................................................................................................................. 24

Converter ............................................................................................................................................. 25

Audio player......................................................................................................................................... 25

Alarm ................................................................................................................................................... 26

Timer.................................................................................................................................................... 26

ToDo .................................................................................................................................................... 26

Sending a vCal .................................................................................................................................... 27

Receiving a vCal.................................................................................................................................. 27

Exchange of data with a PC ................................................................................................................ 27

Messages .................................................................................................................................... 28

Compose SMS..................................................................................................................................... 28

Compose MMS .................................................................................................................................... 30

Receiving messages............................................................................................................................ 31

Inbox .................................................................................................................................................... 31

Outbox ................................................................................................................................................. 31

Sentbox................................................................................................................................................ 32

Drafts ................................................................................................................................................... 32

Sending options ................................................................................................................................... 32

Memory................................................................................................................................................ 33

Local information ................................................................................................................................. 33

Calling voicemail.................................................................................................................................. 33

Mailing list ............................................................................................................................................ 34

Photo - Video .............................................................................................................................. 35

Take and send a photo ........................................................................................................................ 35

Take a video ........................................................................................................................................ 37

Multimedia .................................................................................................................................. 38

My Videos ............................................................................................................................................ 38

My Pictures .......................................................................................................................................... 39

My Sounds........................................................................................................................................... 39

Memory................................................................................................................................................ 40

4 Contents

Organizer .................................................................................................................................... 41

Calendar menu .................................................................................................................................... 41

Sending a vCal..................................................................................................................................... 42

Receiving a vCal .................................................................................................................................. 42

Phonebook.................................................................................................................................. 43

Using the phonebook ........................................................................................................................... 43

Storing a new contact .......................................................................................................................... 44

Phonebook options ..............................................................................................................................44

Options from a contact saved ..............................................................................................................45

Sending a vCard ..................................................................................................................................46

Receiving a vCard................................................................................................................................ 46

Settings ....................................................................................................................................... 47

Sounds................................................................................................................................................. 47

Display .................................................................................................................................................48

Camera ................................................................................................................................................49

Languages ...........................................................................................................................................49

Phonebook........................................................................................................................................... 50

Contacts list ......................................................................................................................................... 50

Calls ..................................................................................................................................................... 50

Security ................................................................................................................................................ 53

Networks .............................................................................................................................................. 55

Shortcuts.............................................................................................................................................. 56

Date / Time .......................................................................................................................................... 56

Active slide........................................................................................................................................... 57

WAP settings ....................................................................................................................................... 57

Help...................................................................................................................................................... 57

Connectivity ......................................................................................................................................... 58

Technical features...................................................................................................................... 59

Conformance Document ........................................................................................................... 60

Contents 5

Care and safety information...................................................................................................... 61

SAR ..................................................................................................................................................... 61

Advice for limiting exposure to radiofrequency (RF) fields .................................................................. 61

Safety................................................................................................................................................... 62

Environment......................................................................................................................................... 63

Warranty...................................................................................................................................... 64

End User Licence Agreement (EULA), for the software ......................................................... 67

Java™.......................................................................................................................................... 71

Troubleshooting ......................................................................................................................... 75

Customer care ............................................................................................................................ 79

Index ............................................................................................................................................ 80

6 Contents

Menus

Games

WAP

Applications

ToDo Calculator Converter Audio player Alarm Timer

Messages

Compose Inbox Outbox Sentbox Drafts Options Memory Local info. Call Voice Mail Mailing list

Menus 7

Camera

Video Photo

Multimedia

My Videos My Pictures My Sounds Memory Help

Organizer

See month See week See today See date Calendar menu Help

Phonebook

Settings

Sounds Display Camera Languages Phonebook Contacts list Calls Security Networks Shortcuts Date / Time Active slide Wap settings Help Connectivity

Your phone package - Accessories

When you open the box, check that all items are present (some items may vary from the pictures shown below):

1 - Phone 2 - Charger 3 - Battery 4 - User guide

Accessories

We advise you the use of SAGEM brand accessories for an optimal operating of your phone and of your accessories. You can also find (as an option) or order the following accessories:

- Pedestrian kit

- Additional battery

- Additional charger

- Data cable (with associated drivers) to connect your phone to a PC

- Cigar lighter charger

8 Your phone package - Accesso ries

Activating your phone

Information on the SIM card

To use your phone, you need a card called SIM card. It contains personal information that you can modify: Secret codes (PIN(s): Personal Identification Numbers), these codes allow you to protect access to your SIM card and phone. Phonebook, Messages, How special services work. Your phone is compatible with the SIM 3V cards.

WARNING

This card must be handled and stored with care in order not to be damaged. If you should lose your SIM card, contact your network provider or your SMC (Services Marketing Company) immediately. Please keep your SIM card out of reach of young children.

Activating your phone 9

Installing the SIM card and the battery

234

The SIM card is inserted under the phone's battery. Ensure that the phone is switched off and the charger disconnected.

Turn the phone back and press lock button to unblock cover.

Remove the back cover.

Take out battery if already installed.

Slide the SIM card, with cut corner as shown on the phone, into the card holder with fold face down.

Place the battery by positioning first the top of it, as shown on the battery.

Replace the back cover by sliding it then push the lower part into the lock position.

Getting started

You are now ready to use your phone for the first time. Switch on the phone by pressing the key. A short display appears. When you switch on your phone for the first time, you must configure it with various settings that will remain by default until you choose to modify them (depending on model). After entering your PIN code and the date and time, make your choice for the following settings: time zone, daylight savings,

wallpaper, screensaver, ring tone, volume, vibrate and voicemail number. If there are contacts saved in your SIM card, you are invited, if you wish, to copy them in the phone contacts memory.

10 Activating your phone

PIN number

This is your SIM's secret code.

If access to the SIM card is protected, the device prompts you to enter the PIN number:

Enter the code

for security reasons. Press the If your phone indicates that the SIM is missing, press the key to switch off your phone and check that the SIM card is correctly installed.

Warning

If a wrong PIN number is entered three times in succession, your SIM card is blocked. You must then:

- Enter « **05* ».

- Enter the PUK (Personal Unblocking Key) code provided by your operator, and validate.

- Enter your PIN number and validate.

- Enter your PIN number again and validate.

After 5 or 10 failed attempts (depending on the type of SIM card), the SIM card is definitely locked. You must then contact your operator or your SMC to obtain a new card.

between 4 and 8 digits given to you when the SIM card was issued. These digits do not appear on the screen

key or the key to validate.

Setting time and date

When you use your phone for the first time, you need to set the date and time. In due course, when the battery is completely discharged, or if it has been removed, you will be prompted systematically to

confirm date and time.

Setting the date:

Set the date by entering it directly in numerical form or by using the T S keys to increase or decrease the default values. Use the

key (or W key) to access the

Once the date is correct, press the key to validate.

Setting the time:

Same procedure as for setting the date.

Activating your phone 11

(or last) data input field.

Network

From now on the phone hunts for a network on which it can make calls. If it finds one, it displays the name of the network on the screen. You are then ready to send or receive a call.

If the network icon appears, calls are possible on your operator's network. If the letter R and a network name are displayed, calls are possible on the network of a different operator. If the letter R is displayed without any network name, only the emergency services are accessible (ambulance, police, fire brigade). If the network icon flashes, the phone is in permanent search mode. There is no network available. The signal strength indicator received allows you to display the quality of reception. If it indicates less than three bars, search for better reception in order to call in good conditions.

First call

Dial the number of your correspondent. Press the key. During the call, the call in progress icon flashes on screen and tones may indicate the establishment of the call. Once communication has been established, the call icon stops flashing. You can adjust the sound level (volume) using the At the end of the conversation press the key to hang up.

International call

Press 0 (hold down) to display « + », then dial the country code without waiting for the dial tone, then the number of the called party.

Emergency services

Depending on the operators you can obtain the emergency service with or without SIM card or when the keypad is locked. It is enough to be in an area served by a network. To obtain the international emergency service, dial

12 Activating your phone

T S keys.

112

then press the key.

Receiving a call

When you receive a call, the number of your correspondent is displayed when it is presented by the network. Press the key or the key to answer, and speak. To refuse the call, press the key or the key. To stop the ring tone or the vibrate, without refusing the call, press the key.

Hands-free mode

During a call, press twice the key or the OK key to switch into hands-free mode.

WARNING:

in this mode do not bring the phone up to your ear.

All the numbers corresponding to incoming and outgoing calls are logged in the list of recent calls.

When a call is on hand, pressing [ holding a call, switching to mute mode, ending the call, displaying menus.

Mute ON

Pressing [ you want to speak to other people.

] allows you to switch off the sound temporarily when you do not want that your correspondent listens when

Options

] allows you to have access to different functions: switching to hands-free mode,

Switching off

Press the key for one second. The end message is displayed. The phone switches off.

Activating your phone 13

Description

Programmable keys and Short cut keys

Microphone

Hold down: Switch on/off In a call context: Reject a call - hang up In menus: Return to initial screen

Hold down: hands-free mode

WAR NING :

do not use the phone in hands-free mode near to your ear, or you

may suffer hearing loss

In call context: Call - receiving a call In idle screen: Fast access to the list of calls

Right programmable key:

In initial screen: Access to certain functions (shortcuts) In menus: Access to the selection shown on screen in the tab

Long press: when the slide is closed this key deactivates auto keylock

Left programmable key:

In initial screen: Access to certain functions (shortcuts) In menus: Access to the selection shown on screen in the tab

Previous choice/increase value/up During call: Increase volume

Next choice/reduce value/down During call: Reduce volume

Previous input field/move left

Next input field/move right

In initial screen: Access to main menu In the menus: Context-sensitive access to different functions During a call: Take a call

When composing a message:

Short press: Switches from one input mode to another (T9, ABC, 123) Long press: Upper case/lower case

(Function available depending on model)

14 Description

Programmable keys and Short cut keys

Hold down: In initial screen: Silent mode Short press: When composing a message, access to the symbol table Zoom mode (see

In call reception mode: Short press stops ring tone In ring tone setting mode: Activate/deactivate ring tone

Messages

and

WAP

menus)

Mirror

Description 15

Camera

Initial screen

The initial screen contains the following information:

1 - The title bar icons:

Battery Calls forwarded Call (establishing the call) Call (hands free) Message (reception of a message, message memory full) FAX communication DATA communication Silent mode Message in answering machine WAP (@) communication GPRS Home zone Roaming Keypad locking Protected WAP logon Protected WAP logon icon with certificate Signal strength level (5 bars).

2 - Date and time, in digital or analog mode 3 - Network provider 4 - Thumbnail centred on bottom line:

The main menu can be accessed by pressing on

The following information may also be displayed: « 1 message received »; or « 1 call ». They can be deleted by pressing key briefly.

16 Initial screen

Navigation principles

These basic principles bring a great intuitiveness to your phone.

Val idat e

by pressing the key or the OK key.

Cancel

by pressing the key. The thumbnails at the bottom of the screen refer to the In the menus, a title bar reminds you of the previous level. The

T S

navigation keys are used to navigate from one menu to another within the same menu structure. From the home page, pressing the The

key is used to go from a menu to a sub-menu. The key is used to go from a sub-menu to a menu. The

key (press briefly) is used to go back to the initial screen (current function is abandoned).

In some menus there is a

Navigation principles 17

key displays the icons of the main menus.

Help

menu ( icon) which informs you on the various functions of the sub-menus.

keys.

Using your phone

Increase the efficiency of your phone

- Don't press the keys when not necessary: each keypress activates the backlight, and uses much power.

- Don't obstruct the antenna with your fingers.

Charging the battery

Your phone is powered by a rechargeable battery. A new battery must be charged for 4 hours at least before being used for the first time. It reaches its optimum capacity after a few cycles of use. When your battery has been discharged, the phone displays the state (empty battery icon flashes). In this case recharge your battery for at least 15 minutes before making any calls in order not to be cut off in the middle of a call.

18 Using your phone

To recharge the battery

Connect the charger to a socket. Plug the end of the cable into the bottom connector of the phone. The phone is then charging up. The battery icon is scrolling up and down to indicate that it is charging. When the battery is fully charged, the charging stops on its own. Disconnect the cable. When charging, the battery may warm up, this phenomenon is normal.

WARNING

There is danger of explosion if the battery is placed in an incorrectly way or if it is exposed to fire. Do not short circuit it. The battery does not have any part that you can change. Do not try to open the battery casing. Use only the appropriate chargers and batteries as shown in the phone manufacturer's catalogue. The use of other types of chargers or batteries may be dangerous or invalidate the warranty. Used batteries must be disposed of in the appropriate places. We advise you to take the battery out if you plan not to use the phone for extended periods. You are strongly advised not to connect your phone to the charger if it doesn’t contain a battery. The charger is a safety step-down transformer, it is forbidden to modify, alter or replace it by another component (power supply plug, etc.).

Using your phone 19

Games

The games being designed by Java™, many compatible games can be downloaded in your phone.

The

More games

remote server. Depending on the operator, the connection URL may not be present. To add a new URL, select a game, press [

Settings/Connection Delete all

20 Games

function allows you to download games connecting on a

Options

menu: deletes all the games you have downloaded.

] and go to

General

WAP

WAP (Wireless Application Protocol): a protocol that translates the Internet language into WML and HTML languages that can be read by a phone. The WAP function allows you to log onto certain Internet sites. You can log onto sites that allow you to download ringtones, icons, animated screensavers, JavaTM applications to your phone.

The WAP Menu

The WAP navigator is under licence:

The WAP navigator and the softwares included are the exclusive property o Openwave. For this reason, it is forbidden to modify, translate, disassemble or even decompile all o part of these softwares.

You can activate the magnifying glass to increase the size of the characters by holding down the

key.

Advanced…:

- Settings

- Show URL

- Disconnect

- Circuit prompt (if user wants to confirm each logon)

- Security (is used to access information on making WAP connections secure).

- Delete Cookies

- View title

WAP 21

choose one of the following advanced settings

The

Services

navigating through WAP pages pressing the key. It contains the following sub menus:

Welcome: Bookmarks:

Internet sites in order to make the access easy. You can receive bookmarks from messages and add them to this list (see chapter

on SMS). You can also send messages by SMS: select a bookmark, press

Options

[

Go to URL: Inbox: Save Objects: Snapshots: History:

memory.

Reload: Reset cache:

menu, a dropdown menu, can be accessed at all times when

logs onto the home page, (carries the name of your access provider)

is used to save in a phonebook the names and addresses of

], then select

this menu allows you to check the messages sent by the Internet site.

backward and forward navigation of the pages displayed are kept in

refreshes the current page.

Send by message

this menu allows you to input an Internet address directly.

is used to save a WAP site items.

takes a snapshot of the currently displayed page.

clears the stored information on previous connections.

About…:

information on the browser.

Exit:

returns to the phone's home page.

Configuring WAP parameters

Select the

Advanced…

Profiles

is used to select or modify your access provider's logon parameters or configure the parameters of other access

providers.

The active profile is preceded with a star.

The

is used to add a new profile or to display the memory size available.

Configuration of GSM and GPRS parameters:

All information to be entered in the parameters are provided by your operator or access provider. On a profile in the list, press [

connections (see next page), GSM parameters and GPRS parameters (see next page).

Preferred connections:

- GSM if not GPRS (by default): the logon to WAP services uses the GPRS as a priority. However, in the event of

unavailability of the GPRS network, the GSM network is used to establish the link.

- GPRS

: the logon to WAP services uses the GPRS network exclusively.

- GSM

: the logon to WAP services uses the GSM network exclusively.

GSM parameters:

- Login

- Password

- IP address of WAP gateway

- Port type (secure or insecure)

- Dial-up number

- Mode (digital, analog or automatic)

GPRS parameters:

- Login

- Password

- IP address of WAP gateway

- Port type (secure or insecure)

- APN: if no APN has been defined, press [

Once all the settings have been entered, you can activate the chosen access provider. Select him from the list. Validate your choice.

Linger timer

a service.

22 WAP

menu, then the

is used to choose the time after which the call is automatically disconnected if you have forgotten to log off from

Options

Settings

], select

menu.

Modify

. The different parameters are: Provider title, Home page, Preferred

Options

] then the APN menu. Select or add an APN.

WAP Logging on

The connection to a WAP service on the GPRS network is not cut if an incoming call is received. You can answer the call.

Using the

Welcome

If you are logging onto the GSM or GPRS network, the @ symbol flashes, the metering of the cost of the call starts as soon as it stops flashing.

menu, you can log onto your access provider's WAP site by pressing the key.

Downloading objects

Some WAP sites allow you to download ringtones, icons, animated screensavers, games or JAVATM applications. Once downloaded, they are stored in your phone's memory. You can then save them in your phone (same operation as used for downloading using messages).

WAP Logging off

To log off, press the key. The logoff happens automatically after a few seconds of inactivity if you forget to log off. This period is defined by the linger time setting.

GPRS

A flashing icon indicates that the phone is logging onto a GPRS network. A non-flashing icon indicates that the GPRS network is available; if the icon is dark, it indicates that the phone is logged onto the GPRS network: see page 22 for the attachment options. This icon is not displayed if the GPRS network is not available or if the SIM card inserted in your phone does not include the

GPRS service. It may also disappear when accessing WAP services if the connection uses the GSM network instead of the GPRS network.

WAP 23

Applications

The Java™ function allows you to download applications and utilities in your phone.

Downloading is done through the WAP function. Please go to the

Services

This item may not be present on your phone’s menu, as it depends on your SIM.

Calculator

This menu allows you to use your phone as a calculator.

On the You can use the calculator thanks to the following keys:

If no calculations are being run, pressing [

24 Applications

Applications

menu, please select the

Up key: Down key: Right key: Left key: Left programmable key: Right programmable key:

∗ key or #

: Decimal point.

menu to use the applications already installed or install others.

Calculator

menu and [OK].

Add Subtract Multiply Divide Equals or convert Delete

Convert

] allows you to use the value in the

converter

directly.

Converter

This menu allows you to convert one currency to another.

On the

Applications

Enter a value and press the Pressing [

Go to Calculator

This option allows you to use immediately the value converted in the

Rapid exchange

If the Rapid exchange is activated, the converter will work in the initial screen by entering the desired numbers and pressing

S T

the

Exchange rate

Enter the exchange rate corresponding to the chosen currency.

Currency

Enter the two types of currency to be converted.

menu, please select the

Options

] allows you to use the following options:

keys to convert.

key to convert from one currency to another, or the T key to convert back.

Converter

menu and [OK].

calculator

Audio player

In the

Multimedia/My Sounds

Select each music, press [ Once your selection completed, in the

Note:

to play only one music, select it and press OK.

Remove from list

Clear list

Note:

Applications 25

: deletes all the musics from the Audio player list.

both options delete the musics from the Audio player list but do not delete them from

menu, select the musics you want to insert in Audio player.

Options

] and select

Add to playlist

Applications/Audio player

: deletes a music from the Audio player list.

menu, press [

Options

] and select

Play list

Multimedia/My Sounds

+ 58 hidden pages
