Roland VF-1 MIDI IMPLEMENTATION

24-BIT MULTIPLE EFFECTS PROCESSOR Date: Apr. 17, 2000 Model VF-1 Version: 1.10

MIDI インプリメンテーション

1. 受信データ

■チャンネル・ボイス・メッセージ

●コントロール・チェンジ

ステータス第2 バイト第3バイト BnH ccH vvH

n = MIDI チャンネル・ナンバー : 0H - FH (ch.1 - ch.16) cc = コントローラー・ナンバー : 00H , 20H (0 , 32)

01H - 1FH (1 - 31) 40H - 5FH (64 - 95)

vv = バリュー : 00H - 7FH (0 -127)

※ コントローラ・ナンバーが00H,20H の場合、バンクセレクトとして認識します。

00H の場合 : バリューが00H, 01H の場合はプログラム・チェンジマップを使用します。

バリューが02H以上の場合は次のようなバンクが選択されます。

02H : プリセット A 03H : プリセット B 04H : ユーザー A 03H : ユーザー B その他 : プログラム・チェンジマップ

20H の場合 : バリューに関係なく受信したデータを無視します。

※「パラメーターのリアルタイム・コントロール」のためのSource として設定すると、

コントロール・チェンジでTargetがコントロール出来ます。

●プログラム・チェンジ

ステータス第2 バイト CnH ppH

n = MIDI チャンネル・ナンバー : 0H - FH (ch.1 - ch.16) pp = プログラム・ナンバー : 00H - 7FH (No.1 - No.128)

※ 受信したプログラムナンバーに応じてエフェクト・パッチが切り替わります。

■システム・リアルタイム・メッセージ

ステータス F8H

DELAY TIME/RATE など BPM 設定できるパラメーターを MIDI 同期としたとき、テンポを算出する為に使用します。

■システム・エクスクルーシブ・メッセージ

ステータスデータ・バイトステータス F0H iiH,ddH ...eeH F7H

F0H = システム・エクスクルーシブ ii = マニファクチャラーID : 41H (Roland ) dd ,..ee = データ : 00H - 7FH (0 - 127) F7H = EOX (End of Exclusive/System common)

※ 詳細は「ローランドのエクスクルーシブ・メッセージについて」（P.56）を参照してく

ださい。

2. 送信データ

■システム・エクスクルーシブ・メッセージ

ステータスデータ・バイトステータス F0H iiH,ddH...eeH F7H

F0H = システム・エクスクルーシブ ii = マニファクチャラーID : 41H(Roland ) dd ,..ee = データ : 00H- 7FH(0 - 127) F7H = EOX (End of Exclusive/System common)

※ 詳細は「ローランドのエクスクルーシブ・メッセージについて」（P.56）を参照してく

ださい。

3. エクスクルーシブ・コミュニケーション

VF-1 はエクスクルーシブ・メッセージによってシステム／パッチ・データの送受信が行えます。

VF-1 のエクスクルーシブ・メッセージのモデル ID は 00H 23H、デバイス ID は 00H 〜 1FH で設定可能です。

■ワン・ウェイ・コミュニケーション

●リクエスト・データ 1RQ1(11H)

バイト解説 F0H エクスクルーシブ・ステータス 41H マニュファクチャラー ID(Roland) Dev デバイスID(Dev=00H-1FH) 00H モデル ID(VF-1)MSB 23H モデル ID(VF-1)LSB 11H コマンド ID(RQ1) aaH アドレスMSB bbH アドレス ccH アドレスLSB ssH サイズMSB ttH サイズ uuH サイズ LSB sum チェック・サム F7H EOX（エンド・オブ・エクスクルーシブ）

※ このメッセージは受信だけが可能で、VF-1本体からは送信しません。

●データ・セット 1DT1(12H)

バイト解説 F0H エクスクルーシブ・ステータス 41H マニュファクチャラー ID(Roland) Dev デバイスID(Dev=00H-1FH) 00H モデル ID(VF-1)MSB 23H モデル ID(VF-1)LSB 12H コマンド ID(DT1) aaH アドレスMSB bbH アドレス ccH アドレスLSB ddH データ

:: ffH データ sum チェック・サム F7H EOX（エンド・オブ・エクスクルーシブ）

1999 ボス本書の一部、もしくは全部を無断で複写・転載することを禁じます。

©

1

MIDI インプリメンテーション

■データの形式とチェックサムの計算について

VF-1がエクスクルーシブ・コミュニケーションで扱うデータは 4bit ニブル表記となっています。DATA 欄の範囲の値をSIZE バイト分4bit 単位で分割して使用して下さい。

例 )UTILITYの GLOBAL BPM を 180BPM にします。

1. 4.パラメーター・アドレス・マップを利用して UTILITY GLOBAL BPM のアドレスを算出します。

アドレス・ブロック・マップから UTILITYブロックのベース・アドレスは 08 00 00H

また、GLOBAL BPMパラメーターのオフセットは UTILITY AREA テーブルを参照して ** 01 2CH

これらから、実際のアドレスを求めます。

08 00 00H BASE ADDRESS +00 01 2CH OFFSET ADDRESS

---------- 08 01 2CH

2. UTILITY AREA テーブルより、180BPM の時のデータ値 B4H を求めます。

データはパラメータサイズ分バイトのニブルでの設定になります。UTILITY AREA テーブルからGLOBAL BPM パラメーターは 4 バイトとなります。

16bit 4bit MSB LSB 0000_0000_1011_0100B 0000_0000B 0000_0000B 0000_1011B 0000_0100B B4H 00H 00H 0BH 04H

3. ローランドのエクスクルーシブ・フォーマットにより、(1)から (7) までを設定します。データは 2. で作成した4 バイトのデータをMSB から LSB へと順に設定し

ます。

F0 41 00 00 23 12 08 01 2C 00 00 0B 04 ??? F7 (1) (2) (3) (4) (5) (6) ^^^^^^^^^^ ^^^^^^^^^^^^^^ (9) (10) (7) (8) (1) Exclusive Status (2) Manufacture ID (Roland) (3) Device ID (DEV:00H - 1FH) (4) MODEL ID MSB (VF-1:00H) (5) MODEL ID LSB (VF-1:23H) (6) Common ID (DT1) (7) Address (8) Data (4bit nibbled, MSB first) (9) Checksum (10) End of Exclusive

4. (9)チェックサムの計算をします。

(7)アドレス + (8)データー =

08H + 01H + 2CH + 00H + 00H + 0BH + 04H = 44H(sum) 8 + 1 + 44 + 0 + 0 + 11 + 4 = 68

68(sum) / 128 = 0(商 (quotient))...68( checksum = 128 - 68(

剰余

(remainder)) = 60 = 3CH

5. 3.,4. からメッセージを作成します。

F0 41 00 00 23 12 08 01 2C 00 00 0B 04 3C F7

剰余

(remainder))

■ dummy パラメータについて

dummyパラメータにデータ・セットしても無視されます。

4. パラメーター・アドレス・マップ

アドレスおよびサイズは、7ビットごとの 16 進表示です。

バイナリー 0aaa aaaa 0bbbbbbb 0ccc cccc 7ビット・16 進 AA BB CC

バイナリー 0sss ssss 0ttt tttt 0uuu uuuu 7ビット・16 進 SS TT UU

■パラメーター・ベース・アドレス

各パラメーターの実際のアドレスは、各ブロックの先頭のアドレスにオフセット・アドレスを加えた値です。

○アドレス・ブロック・マップ

Base Address Block Sub Block Note 00 00 00 +-------------------+ +-----------------+

| User Patch | | USER PATCH A001 |••••Bulk | | +-----------------+ 00 04 00 | | +-----------------+ | | | USER PATCH A002 | | | +-----------------+ : | | : : | | : 03 10 00 | | +-----------------+ | | | USER PATCH A101 | | | +-----------------+ 04 00 00 | | +-----------------+ | | | USER PATCH B001 | | | +-----------------+ : | | : : | | : 07 10 00 | | +-----------------+ | | | USER PATCH B101 | +-------------------+ +-----------------+ 08 00 00 +---------------------------------------+ | UTILITY |••••Individual +---------------------------------------+ 10 00 00 +---------------------------------------+ | TEMPORARY AREA |••••Bulk +---------------------------------------+ 20 00 00 +---------------------------------------+ | INDIVIDUAL TEMPORARY AREA |•••• +---------------------------------------+ 60 00 00 +---------------------------------------+ | SOUND CHANGE REQUEST (SCR) |••••Individual +---------------------------------------+ 70 00 00 +---------------------------------------+ | PATCH WRITE REQUEST (PWR) |••••Bulk +---------------------------------------+

※ VF-1には、インディビジュアル・パラメータとバルク・ダンプの２種類のコミニュ

ケーション方法があります。

※ バルクのデータは、ユーティリティ内でバルク・ロード待機させておけば受信可能で

す。

※ インディビジュアルのデータは常に受信可能ですが、必ず［F0....F7］の１パケットに

は１つのパラメータに対するバリューを過不足なく記述してください。

※ データ・リクエストを受信するには、ユーティリティ内でバルク・ロード待機させてお

いてください。 ※ Size が 2 以上のパラメーターは、分割せずに必ず同じパケット内で送ってください。 ※ Sound Change Request（SCR）は、TEMPORARY のバルク・エリアでのみ有効で

す。TEMPORARYのバルク・エリアに、エクスクルーシブ・メッセージを送信して

データを変更するには、パラメーターのバリューを送った後に、SCRのアドレスに

データを送る必要があります。（refer to Table-37.[SCR]） ※ Patch Write Request（PWR）を受信すると、User Patch、UTILITY MIDI PC MAP

のデータをメモリーに保存します。User Patch、UTILITY MIDI PC MAPのバルク・エ

リア又はインディビジュアル・エリアに、エクスクルーシブ・メッセージを送信して本

体メモリーに保存するには、パラメーターのバリューを送った後に、PWRのアドレス

にデータを送信する必要があります。（refer to Table-38.[PWR]） ※ OFFSET の右横に $ のついているパラメーターは FX SELECTパラメーター等の設定

によりパラメーターの種類が変化します。

アドレス MSB LSB

サイズ MSB LSB

Individual(Write Only)

2

MIDI インプリメンテーション

○ UTILITY AREA

OFFSET (H) SIZE (H) DATA (H) PARAMETER DESCRIPTION ** 00 00 00 00 04 0000 - 000A TUNER PITCH 00h : 435 Hz

** 00 04 00 00 04 0000 - 0064 TUNER LEVEL MUTE, 01 - 100 ** 00 08 00 00 04 0000 - 000F SYSTEM CONTRAST 1 - 16 ** 00 0C 0000 04 0000 - 0001 SYSTEM EFFECTS OFFMD 00h : MUTE

** 00 10 00 00 04 0000 - 018F SYSTEM NUMBER U/DMIN 0000 - 0064 : PA 1 - 101(PRESET A)

** 00 14 00 00 04 0000 - 018F SYSTEM NUMBER U/DMAX 0000 - 0063 : PA 1 - 101(PRESET A)

** 00 18 00 00 04 0000 - 0004 SYSTEM CONTROL1 00h : EFFECTS ON/OFF

** 00 1C 0000 04 0000 - 0004 SYSTEM CONTROL2 00h : EFFECTS ON/OFF

** 00 20 00 00 04 0000 - 0001 SYSTEM ASSIGN HOLD 00h : OFF

** 00 24 00 00 02 00 - 30 SYSTEM USER SCALE#1 [C] (refer to Table-34.[USERSCALE]) ** 00 26 00 00 02 00 - 30 SYSTEM USER SCALE#1 [C#] (refer to Table-34.[USERSCALE]) ** 00 28 00 00 02 00 - 30 SYSTEM USER SCALE#1 [D] (refer to Table-34.[USERSCALE]) ** 00 2A 0000 02 00 - 30 SYSTEM USER SCALE#1 [D#] (refer to Table-34.[USERSCALE]) ** 00 2C 0000 02 00 - 30 SYSTEM USER SCALE#1 [E] (refer to Table-34.[USERSCALE]) ** 00 2E 00 00 02 00 - 30 SYSTEM USER SCALE#1 [F] (refer to Table-34.[USERSCALE]) ** 00 30 00 00 02 00 - 30 SYSTEM USER SCALE#1 [F#] (refer to Table-34.[USERSCALE]) ** 00 32 00 00 02 00 - 30 SYSTEM USER SCALE#1 [G] (refer to Table-34.[USERSCALE]) ** 00 34 00 00 02 00 - 30 SYSTEM USER SCALE#1 [G#] (refer to Table-34.[USERSCALE]) ** 00 36 00 00 02 00 - 30 SYSTEM USER SCALE#1 [A] (refer to Table-34.[USERSCALE]) ** 00 38 00 00 02 00 - 30 SYSTEM USER SCALE#1 [A#] (refer to Table-34.[USERSCALE]) ** 00 3A 0000 02 00 - 30 SYSTEM USER SCALE#1 [B] (refer to Table-34.[USERSCALE]) ** 00 3C 0000 02 00 - 30 SYSTEM USER SCALE#2 [C] (refer to Table-34.[USERSCALE]) ** 00 3E 00 00 02 00 - 30 SYSTEM USER SCALE#2 [C#] (refer to Table-34.[USERSCALE]) ** 00 40 00 00 02 00 - 30 SYSTEM USER SCALE#2 [D] (refer to Table-34.[USERSCALE]) ** 00 42 00 00 02 00 - 30 SYSTEM USER SCALE#2 [D#] (refer to Table-34.[USERSCALE]) ** 00 44 00 00 02 00 - 30 SYSTEM USER SCALE#2 [E] (refer to Table-34.[USERSCALE]) ** 00 46 00 00 02 00 - 30 SYSTEM USER SCALE#2 [F] (refer to Table-34.[USERSCALE]) ** 00 48 00 00 02 00 - 30 SYSTEM USER SCALE#2 [F#] (refer to Table-34.[USERSCALE]) ** 00 4A 0000 02 00 - 30 SYSTEM USER SCALE#2 [G] (refer to Table-34.[USERSCALE]) ** 00 4C 0000 02 00 - 30 SYSTEM USER SCALE#2 [G#] (refer to Table-34.[USERSCALE]) ** 00 4E 00 00 02 00 - 30 SYSTEM USER SCALE#2 [A] (refer to Table-34.[USERSCALE]) ** 00 50 00 00 02 00 - 30 SYSTEM USER SCALE#2 [A#] (refer to Table-34.[USERSCALE]) ** 00 52 00 00 02 00 - 30 SYSTEM USER SCALE#2 [B] (refer to Table-34.[USERSCALE]) ** 00 54 00 00 02 00 - 30 SYSTEM USER SCALE#3 [C] (refer to Table-34.[USERSCALE]) ** 00 56 00 00 02 00 - 30 SYSTEM USER SCALE#3 [C#] (refer to Table-34.[USERSCALE]) ** 00 58 00 00 02 00 - 30 SYSTEM USER SCALE#3 [D] (refer to Table-34.[USERSCALE]) ** 00 5A 0000 02 00 - 30 SYSTEM USER SCALE#3 [D#] (refer to Table-34.[USERSCALE]) ** 00 5C 0000 02 00 - 30 SYSTEM USER SCALE#3 [E] (refer to Table-34.[USERSCALE]) ** 00 5E 00 00 02 00 - 30 SYSTEM USER SCALE#3 [F] (refer to Table-34.[USERSCALE]) ** 00 60 00 00 02 00 - 30 SYSTEM USER SCALE#3 [F#] (refer to Table-34.[USERSCALE]) ** 00 62 00 00 02 00 - 30 SYSTEM USER SCALE#3 [G] (refer to Table-34.[USERSCALE]) ** 00 64 00 00 02 00 - 30 SYSTEM USER SCALE#3 [G#] (refer to Table-34.[USERSCALE]) ** 00 66 00 00 02 00 - 30 SYSTEM USER SCALE#3 [A] (refer to Table-34.[USERSCALE]) ** 00 68 00 00 02 00 - 30 SYSTEM USER SCALE#3 [A#] (refer to Table-34.[USERSCALE]) ** 00 6A 0000 02 00 - 30 SYSTEM USER SCALE#3 [B] (refer to Table-34.[USERSCALE]) ** 00 6C 0000 02 00 - 30 SYSTEM USER SCALE#4 [C] (refer to Table-34.[USERSCALE]) ** 00 6E 00 00 02 00 - 30 SYSTEM USER SCALE#4 [C#] (refer to Table-34.[USERSCALE]) ** 00 70 00 00 02 00 - 30 SYSTEM USER SCALE#4 [D] (refer to Table-34.[USERSCALE]) ** 00 72 00 00 02 00 - 30 SYSTEM USER SCALE#4 [D#] (refer to Table-34.[USERSCALE])

01h : 436 Hz 02h : 437 Hz 03h : 438 Hz 04h : 439 Hz 05h : 440 Hz 06h : 441 Hz 07h : 442 Hz 08h : 443 Hz 09h : 444 Hz 0Ah : 445 Hz

01h : DIRECT

0065 - 00C9 : PB 1 - 101(PRESET B) 00CA - 012D : UA 1 - 101(USER A) 012E - 0191 : UB1 - 101(USER B)

0064 - 00C7 : PB 1 - 101(PRESET B) 00C8 - 012B : UA 1 - 101(USER A) 012C - 018F : UB 1 - 101(USER B)

01h : TUNER 02h : NUMBER DOWN 03h : NUMBER UP 04h : ASSIGNABLE

01h : ON

3

MIDI インプリメンテーション

** 00 74 00 00 02 00 - 30 SYSTEM USER SCALE#4 [E] (refer to Table-34.[USERSCALE]) ** 00 76 00 00 02 00 - 30 SYSTEM USER SCALE#4 [F] (refer to Table-34.[USERSCALE]) ** 00 78 00 00 02 00 - 30 SYSTEM USER SCALE#4 [F#] (refer to Table-34.[USERSCALE]) ** 00 7A 0000 02 00 - 30 SYSTEM USER SCALE#4 [G] (refer to Table-34.[USERSCALE]) ** 00 7C 0000 02 00 - 30 SYSTEM USER SCALE#4 [G#] (refer to Table-34.[USERSCALE]) ** 00 7E 00 00 02 00 - 30 SYSTEM USER SCALE#4 [A] (refer to Table-34.[USERSCALE]) ** 01 00 00 00 02 00 - 30 SYSTEM USER SCALE#4 [A#] (refer to Table-34.[USERSCALE]) ** 01 02 00 00 02 00 - 30 SYSTEM USER SCALE#4 [B] (refer to Table-34.[USERSCALE]) ** 01 04 00 00 02 00 - 30 SYSTEM USER SCALE#5 [C] (refer to Table-34.[USERSCALE]) ** 01 06 00 00 02 00 - 30 SYSTEM USER SCALE#5 [C#] (refer to Table-34.[USERSCALE]) ** 01 08 00 00 02 00 - 30 SYSTEM USER SCALE#5 [D] (refer to Table-34.[USERSCALE]) ** 01 0A 0000 02 00 - 30 SYSTEM USER SCALE#5 [D#] (refer to Table-34.[USERSCALE]) ** 01 0C 0000 02 00 - 30 SYSTEM USER SCALE#5 [E] (refer to Table-34.[USERSCALE]) ** 01 0E 00 00 02 00 - 30 SYSTEM USER SCALE#5 [F] (refer to Table-34.[USERSCALE]) ** 01 10 00 00 02 00 - 30 SYSTEM USER SCALE#5 [F#] (refer to Table-34.[USERSCALE]) ** 01 12 00 00 02 00 - 30 SYSTEM USER SCALE#5 [G] (refer to Table-34.[USERSCALE]) ** 01 14 00 00 02 00 - 30 SYSTEM USER SCALE#5 [G#] (refer to Table-34.[USERSCALE]) ** 01 16 00 00 02 00 - 30 SYSTEM USER SCALE#5 [A] (refer to Table-34.[USERSCALE]) ** 01 18 00 00 02 00 - 30 SYSTEM USER SCALE#5 [A#] (refer to Table-34.[USERSCALE]) ** 01 1A 0000 02 00 - 30 SYSTEM USER SCALE#5 [B] (refer to Table-34.[USERSCALE]) ** 01 1C 0000 04 0000 - 0064 GLOBAL OUT LEVEL 0 - 200% (step=2) ** 01 20 00 00 04 0000 - 0028 GLOBAL NS THRESHOLD -20[dB] - +20[dB] ** 01 24 00 00 04 0000 - 0064 GLOBAL REVERB LEVEL 0 - 200% (setp=2) ** 01 28 00 00 04 0000 - 0004 GLOBAL OUTPUT SELECT 00h : GUITAR AMP(COMBO)

** 01 2C 0000 04 0028 - 00FB GLOBAL GLOBAL BPM 40 - 250, MIDI ** 01 30 00 00 04 0000 - 0001 Global DIRECT MIX 00h : Off

** 01 34 00 00 04 0000 - 000F MIDI CH 1 - 16 ** 01 38 00 00 04 0000 - 0001 MIDI OMNI MODE 00h : Off

** 01 3C 0000 04 0000 - 0003 MIDI PC MAP #1 BANK 00h : PA(PRESET A)

** 01 40 00 00 04 0000 - 0064 MIDI PC MAP #1 PATCH NO 1 - 101 ** 01 44 00 00 04 0000 - 0003 MIDI PC MAP #2 BANK 00h : PA(PRESET A)

** 01 48 00 00 04 0000 - 0064 MIDI PC MAP #2 PATCH NO 1 - 101

:

** 09 34 00 00 04 0000 - 0003 MIDI PC MAP #128 BANK 00h : PA(PRESET A)

** 09 38 00 00 04 0000 - 0064 MIDI PC MAP #128 PATCH NO 1 - 101

01h : GUITAR AMP(STACK) 02h : POWER AMP(COMBO) 03h : POWER AMP(STACK) 04h : LINE

01h : Patch

01h : On

01h : PB(PRESET B) 02h : UA(USER A) 03h : UB(USER B)

4

MIDI インプリメンテーション

○ TEMPORARY AREA

common area

OFFSET (H) SIZE (H) DATA (H) PARAMETER DESCRIPTION ** 00 00 00 00 04 00 - 23 ALGORITHM TYPE 00h : GUITAR MULTI 1

** 00 04 00 00 04 00 - 0C CATEGORY TYPE 00h : E.GUITAR

** 00 08 00 00 02 20 - 7D PATCH NAME#1 (refer to Table-35.[ASCIINAME]) ** 00 0A 0000 02 20 - 7D PATCH NAME#2 (refer to Table-35.[ASCIINAME]) ** 00 0C 0000 02 20 - 7D PATCH NAME#3 (refer to Table-35.[ASCIINAME]) ** 00 0E 00 00 02 20 - 7D PATCH NAME#4 (refer to Table-35.[ASCIINAME]) ** 00 10 00 00 02 20 - 7D PATCH NAME#5 (refer to Table-35.[ASCIINAME]) ** 00 12 00 00 02 20 - 7D PATCH NAME#6 (refer to Table-35.[ASCIINAME]) ** 00 14 00 00 02 20 - 7D PATCH NAME#7 (refer to Table-35.[ASCIINAME]) ** 00 16 00 00 02 20 - 7D PATCH NAME#8 (refer to Table-35.[ASCIINAME]) ** 00 18 00 00 02 20 - 7D PATCH NAME#9 (refer to Table-35.[ASCIINAME]) ** 00 1A 0000 02 20 - 7D PATCH NAME#10 (refer to Table-35.[ASCIINAME]) ** 00 1C 0000 02 20 - 7D PATCH NAME#11 (refer to Table-35.[ASCIINAME]) ** 00 1E 00 00 02 20 - 7D PATCH NAME#12 (refer to Table-35.[ASCIINAME]) ** 00 20 00 00 02 20 - 7D PATCH NAME#13 (refer to Table-35.[ASCIINAME]) ** 00 22 00 00 02 00 must '0' TERMINATOR ** 00 24 00 00 04 0000 - **** ASSIGN #1 TARGET MIN TARGET MIN パラメーターの最大値は TARGET TYPE によって決まります。 ** 00 28 00 00 04 0000 - **** ASSIGN #1 TARGET MAX TARGET MAX パラメーターの最大値は TARGET TYPE によって決まります。 ** 00 2C 0000 04 0000 - **** ASSIGN #1 TARGET TYPE (refer to Table-38.[TARGETTYPE]) ** 00 30 00 00 04 0000 - 0041 ASSIGN #1 SOURCE TYPE (refer to Table-36.[SOURCETYPE]) ** 00 34 00 00 04 0000 - 0001 ASSIGN #1 SOURCE MODE 00h : NORMAL

** 00 38 00 00 04 0000 - 007F ASSIGN #1 SOURCE MIN 0 - 126 ** 00 3C 0000 04 0000 - 007F ASSIGN #1 SOURCE MAX 1 - 127

01h : GUITAR MULTI 2 02h : BASS MULTI 03h : ACOUSTIC MULTI 04h : KEYBOARD MULTI 05h : ROTARY MULTI 06h : VOCAL MULTI 07h : VOCODER 08h : VOICE TRANSFORMER 09h : ISOLATOR 0Ah : LOFI PROCESSOR 0Bh : REVERB 1 0Ch : REVERB 2 0Dh : GATE REVERB 0Eh : 2CH RSS 0Fh : DELAY RSS 10h : CHORUS RSS 11h : REVERB RSS 12h : RSS PANNER 13h : DELAY 14h : MULTI TAP DELAY 15h : TAPE ECHO 201 16h : MIC SIMULATOR 17h : SPACE CHORUS 18h : STEREO FLANGER DELAY 19h : STEREO PHASER DELAY 1Ah : STEREO CHORUS DELAY 1Bh : STEREO PITCH SHIFT DELAY 1Ch : STEREO MULTI 1Dh : 10BAND GRAPHIC EQ 1Eh : HUM CANCELER 1Fh : VOCAL CANCELER 20h : REVERB REVERB 21h : CHORUS REVERB 22h : DELAY REVERB 23h : DELAY CHORUS 24h : SPEAKER MODELING

01h : A.GUITAR 02h : BASS 03h : KEYBOARD 04h : VOCAL 05h : GROOVE 06h : REVERB 07h : RSS 08h : STUDIO 09h : MASTER 0Ah : OTHERS1 0Bh : OTHERS2 0Ch : OTHERS3 0Dh : ALL

01h : TOGGLE

5

MIDI インプリメンテーション

** 00 40 00 00 04 0000 - 0001 ASSIGN #1 ON/OFF 00h : OFF

** 00 44 00 00 04 0000 - **** ASSIGN #2 TARGET MIN TARGET MIN パラメーターの最大値は TARGET TYPE によって決まります。 ** 00 48 00 00 04 0000 - **** ASSIGN #2 TARGET MAX TARGET MAX パラメーターの最大値は TARGET TYPE によって決まります。 ** 00 4C 0000 04 0000 - **** ASSIGN #2 TARGET TYPE (refer to Table-38.[TARGETTYPE]) ** 00 50 00 00 04 0000 - 0041 ASSIGN #2 SOURCE TYPE (refer to Table-36.[SOURCETYPE]) ** 00 54 00 00 04 0000 - 0001 ASSIGN #2 SOURCE MODE 00h : NORMAL

** 00 58 00 00 04 0000 - 007F ASSIGN #2 SOURCE MIN 0 - 126 ** 00 5C 0000 04 0000 - 007F ASSIGN #2 SOURCE MAX 1 - 127 ** 00 60 00 00 04 0000 - 0001 ASSIGN #2 ON/OFF 00h : OFF

** 00 64 00 00 04 0000 - **** ASSIGN #3 TARGET MIN TARGET MIN パラメーターの最大値は TARGET TYPE によって決まります。 ** 00 68 00 00 04 0000 - **** ASSIGN #3 TARGET MAX TARGET MAX パラメーターの最大値は TARGET TYPE によって決まります。 ** 00 6C 0000 04 0000 - **** ASSIGN #3 TARGET TYPE (refer to Table-38.[TARGETTYPE]) ** 00 70 00 00 04 0000 - 0041 ASSIGN #3 SOURCE TYPE (refer to Table-36.[SOURCETYPE]) ** 00 74 00 00 04 0000 - 0001 ASSIGN #3 SOURCE MODE 00h : NORMAL

** 00 78 00 00 04 0000 - 007F ASSIGN #3 SOURCE MIN 0 - 126 ** 00 7C 0000 04 0000 - 007F ASSIGN #3 SOURCE MAX 1 - 127 ** 01 00 00 00 04 0000 - 0001 ASSIGN #3 ON/OFF 00h : OFF

** 01 04 00 00 04 0000 - **** ASSIGN #4 TARGET MIN TARGET MIN パラメーターの最大値は TARGET TYPE によって決まります。 ** 01 08 00 00 04 0000 - **** ASSIGN #4 TARGET MAX TARGET MAX パラメーターの最大値は TARGET TYPE によって決まります。 ** 01 0C 0000 04 0000 - **** ASSIGN #4 TARGET TYPE (refer to Table-38.[TARGETTYPE]) ** 01 10 00 00 04 0000 - 0041 ASSIGN #4 SOURCE TYPE (refer to Table-36.[SOURCETYPE]) ** 01 14 00 00 04 0000 - 0001 ASSIGN #4 SOURCE MODE 00h : NORMAL

** 01 18 00 00 04 0000 - 007F ASSIGN #4 SOURCE MIN 0 - 126 ** 01 1C 0000 04 0000 - 007F ASSIGN #4 SOURCE MAX 1 - 127 ** 01 20 00 00 04 0000 - 0001 ASSIGN #4 ON/OFF 00h : OFF

01h : ON

01h : TOGGLE

01h : ON

01h : TOGGLE

01h : ON

01h : TOGGLE

01h : ON

6

MIDI インプリメンテーション

○ ALGORITHM PARAMETER

※（step=**）は入力値（DATA）×**= 表示値の意味です。

<<< 10BAND GRAPHICEQUALIZER >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 COMP EffectOn/Off OFF

* 01 26 00 00 02 00 COMP FX Select COMP

* 01 28 00 00 02 00 COMP Detect L

* 01 2A 00 00 02 COMP dummy * 01 2C $ 0000 02 00 - 64 COMP [COMP]Threshold 0 - 100 * 01 2E $ 00 00 02 00 COMP [COMP]Ratio 1.5:1

* 01 30 $ 00 00 02 00 - 64 COMP [COMP]Attack 0 - 100 * 01 32 $ 00 00 02 00 - 64 COMP [COMP]Release 0 - 100 * 01 34 $ 00 00 02 00 - 64 COMP [COMP]Tone -50 - +50 * 01 36 $ 00 00 02 00 - 64 COMP [COMP]Level 0 - 100 * 01 2C $ 0000 02 00 - 64 COMP [LIMIT]Threshold 0 - 100 * 01 2E $ 00 00 02 00 - 64 COMP [LIMIT]Release 0 - 100 * 01 30 $ 00 00 02 00 - 64 COMP [LIMIT]Tone -50 - +50 * 01 32 $ 00 00 02 00 - 64 COMP [LIMIT]Level 0 - 100 * 01 38 00 00 02 00 NS EffectOn/Off OFF

* 01 3A 00 00 02 00 NS Detect L

* 01 3C 00 00 02 00 - 64 NS Threshold 0 - 100 * 01 3E 00 00 02 00 - 64 NS Release 0 - 100 * 01 40 00 00 02 00 ENH EffectOn/Off OFF

* 01 42 00 00 02 00 ENH Detect L

* 01 44 00 00 02 00 - 64 ENH Sens 0 - 100 * 01 46 00 00 02 00 - 0A ENH Frequency (refer to Table-23.[VOCALFREQ]) * 01 48 00 00 02 00 - 64 ENH Mix Level 0 - 100 * 01 4A 00 00 02 00 - 64 ENH Low Mix Level 0 - 100 * 01 4C 00 00 02 00 - 64 ENH Level 0 - 100 * 01 50 00 00 02 00 GEQ Effect On/Off OFF

* 01 52 00 00 02 00 - 18 GEQ Input Gain -12 - +12 [dB] * 01 54 00 00 02 00 - 18 GEQ Level -12 - +12 [dB] * 01 56 00 00 02 00 - 18 GEQ 31.2 Hz -12 - +12 [dB] * 01 58 00 00 02 00 - 18 GEQ 62.5 Hz -12 - +12 [dB] * 01 5A 00 00 02 00 - 18 GEQ 125 Hz -12 - +12 [dB] * 01 5C 00 00 02 00 - 18 GEQ 250 Hz -12 - +12 [dB] * 01 5E 00 00 02 00 - 18 GEQ 500 Hz -12 - +12 [dB] * 01 60 00 00 02 00 - 18 GEQ 1.0 kHz -12 - +12 [dB] * 01 62 00 00 02 00 - 18 GEQ 2.0 kHz -12 - +12 [dB] * 01 64 00 00 02 00 - 18 GEQ 4.0 kHz -12 - +12 [dB] * 01 66 00 00 02 00 - 18 GEQ 8.0 kHz -12 - +12 [dB] * 01 68 00 00 02 00 - 18 GEQ 16 kHz -12 - +12 [dB] * 01 6A 00 00 02 GEQ dummy * 01 6C 00 00 02 00 DELAY Effect On/Off OFF

* 01 6E 00 00 02 00 - 78 DELAY FX Level 0 - 120 * 01 70 00 00 02 00 - 64 DELAY Dir Level 0 - 100 * 01 72 00 00 02 00 - 32 DELAY High Damp Gain -50 - 0 [dB] * 01 74 00 00 02 00 - 09 DELAY High Cut Filter (refer to Table-16.[HICUT]) * 01 76 00 00 02 DELAY dummy * 01 78 00 00 02 00 - 46 DELAY Delay Time L 0 - 1400 [ms] (step=20)

* 01 7A 00 00 02 00 - 14 DELAY Fine Time L 0 - 20 [ms] * 01 7C 00 00 02 00 - 64 DELAY Feedbk L 0 - 100 * 01 7E 00 00 02 DELAY dummy * 02 00 00 00 02 00 - 46 DELAY Delay Time R 0 - 1400 [ms] (step=20)

* 02 02 00 00 02 00 - 14 DELAY Fine Time R 0 - 20 [ms] * 02 04 00 00 02 00 - 64 DELAY Feedbk R 0 - 100 * 02 06 00 00 02 DELAY dummy * 02 08 00 00 02 MASTER dummy * 02 0A 00 00 02 00 - 64 MASTER MasterLevel 0 - 100

01 ON

01 LIMIT

01 R 02 LINK

01 2:1 02 4:1 03 100:1

01 ON

01 R 02 LINK

01 ON

01 R 02 LINK

01 ON

47 - 53 BPM 1/4 - 4.0 (refer to Table-4.[BPMPARAM4])

7

MIDI インプリメンテーション

* 02 0C 00 00 02 28 - FA MASTER Master BPM 40 - 250

* 02 0E 00 00 02 00 - 64 MASTER Foot Level 0 - 100

FB MIDI FC GLOBAL

<<< 2CH RSS >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 EQ Effect On/Off OFF

* 01 26 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 28 00 00 02 00 - 14 EQ Lo-Mid f 100- 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 2A 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 2C 00 00 02 00 - 28 EQ Lo-Mi EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 2E 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 30 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 32 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 34 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 36 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 38 00 00 02 00 RSS Effect On/Off OFF

* 01 3A 00 00 02 00 - 3C RSS Azimuth L (refer to Table-29.[AZIMUTH]) * 01 3C 00 00 02 00 - 06 RSS Elevation L (refer to Table-28.[ELEVATION]) * 01 3E 00 00 02 00 - 3C RSS Azimuth R (refer to Table-29.[AZIMUTH]) * 01 40 00 00 02 00 - 06 RSS Elevation R (refer to Table-28.[ELEVATION]) * 01 42 00 00 02 RSS dummy * 01 44 00 00 02 MASTER dummy * 01 46 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 48 00 00 02 MASTER dummy * 01 4A 00 00 02 00 - 64 MASTER Foot Level 0 - 100

01 ON

<<< ACOUSTIC MULTI >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 COMP Effect On/Off OFF

* 01 26 00 00 02 00 COMP FX Select COMP

* 01 28 $ 00 00 02 00 - 64 COMP [COMP]Sustain 0 - 100 * 01 2A $ 0000 02 00 - 64 COMP [COMP]Attack 0 - 100 * 01 2C $ 0000 02 00 - 64 COMP [COMP]Tone -50 - +50 * 01 2E $ 00 00 02 00 - 64 COMP [COMP]Level 0 - 100 * 01 28 $ 00 00 02 00 - 64 COMP [LIMIT]Threshold 0 - 100 * 01 2A $ 0000 02 00 - 64 COMP [LIMIT]Release 0 - 100 * 01 2C $ 0000 02 00 - 64 COMP [LIMIT]Tone -50 - +50 * 01 2E $ 00 00 02 00 - 64 COMP [LIMIT]Level 0 - 100 * 01 30 00 00 02 00 PREAMP Effect On/Off OFF

* 01 32 00 00 02 00 - 64 PREAMP Volume 0 - 100 * 01 34 00 00 02 00 - 64 PREAMP Bass 0 - 100 * 01 36 00 00 02 00 - 64 PREAMP Middle 0 - 100 * 01 38 00 00 02 00 - 64 PREAMP Treble 0 - 100 * 01 3A 00 00 02 00 - 64 PREAMP Presence 0 - 100 * 01 3C 00 00 02 00 - 64 PREAMP Master 0 - 100 * 01 3E 00 00 02 00 PREAMP Gain LOW

* 01 40 00 00 02 00 - 0A PREAMP Mic Setting CENT, 1 - 10 [cm] * 01 42 00 00 02 00 - 64 PREAMP Mic Level 0 - 100 * 01 44 00 00 02 00 - 64 PREAMP Dir Level 0 - 100 * 01 46 00 00 02 PREAMP dummy * 01 48 00 00 02 00 ACOUSTIC Effect On/Off OFF

* 01 4A 00 00 02 00 - 64 ACOUSTIC Body 0 - 100 * 01 4C 00 00 02 00 - 64 ACOUSTIC Mic Distance 0 - 100 * 01 4E 00 00 02 ACOUSTIC dummy * 01 50 00 00 02 00 AFB Effect On/Off OFF

* 01 52 00 00 02 00 - 64 AFB Depth 0 - 100 * 01 54 00 00 02 00 - 64 AFB Frequency 0 - 100 * 01 56 00 00 02 AFB dummy * 01 58 00 00 02 00 NS Effect On/Off OFF

* 01 5A 00 00 02 00 - 64 NS Threshold 0 - 100 * 01 5C 00 00 02 00 - 64 NS Release 0 - 100 * 01 5E 00 00 02 NS dummy * 01 60 00 00 02 00 CHORUS Effect On/Off OFF

* 01 62 00 00 02 00 - 10 CHORUS Xover f (refer to Table-15.[2CEXOVER])

01 ON

01 LIMIT

01 ON

01 MID 02 HIGH

01 ON

8

MIDI インプリメンテーション

* 01 64 00 00 02 00 - 64 CHORUS Low Rate 0 - 100

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1]) * 01 66 00 00 02 00 - 64 CHORUS Low Depth 0 - 100 * 01 68 00 00 02 00 - 50 CHORUS Low Pre Delay 0.0 - 40.0 [ms] (step=0.5) * 01 6A 00 00 02 00 - 64 CHORUS Low Level 0 - 100 * 01 6C 00 00 02 00 - 64 CHORUS High Rate 0 - 100

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1]) * 01 6E 00 00 02 00 - 64 CHORUS High Depth 0 - 100 * 01 70 00 00 02 00 - 50 CHORUS High Pre Delay 0.0 - 40.0 [ms] (step=0.5) * 01 72 00 00 02 00 - 64 CHORUS High Level 0 - 100 * 01 74 00 00 02 00 REVERB EffectOn/Off OFF

01 ON * 01 76 00 00 02 00 REVERB Type ROOM 1

01 ROOM 2

02 HALL 1

03 HALL 2

04 PLATE * 01 78 00 00 02 01 - 64 REVERB ReverbTime 0.1 - 10.0 [s] * 01 7A 00 00 02 00 - 64 REVERB PreDelay 0 - 100 [ms] * 01 7C 00 00 02 00 - 09 REVERB Low Cut (refer to Table-17.[LOCUT]) * 01 7E 00 00 02 00 - 09 REVERB High Cut (refer to Table-16.[HICUT]) * 02 00 00 00 02 00 - 0A REVERB Density 0 - 10 * 02 02 00 00 02 00 - 64 REVERB FX Level 0 - 100 * 02 04 00 00 02 MASTER dummy * 02 06 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 02 08 00 00 02 28 - FA MASTER MasterBPM 40 - 250

FB MIDI

FC GLOBAL * 02 0A 00 00 02 00 - 64 MASTER Foot Level 0 - 100

<<< BASS MULTI >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 DEFRET Effect On/Off OFF

01 ON * 01 26 00 00 02 00 DEFRET FX Select COMP

01 DEFRET * 01 28 $ 00 00 02 00 - 0F DEFRET [COMP]Sustain 0 - 100 (refer to Table-19.[BASS1]) * 01 2A $ 0000 02 00 - 0F DEFRET [COMP]Attack 0 - 100 (refer to Table-19.[BASS1]) * 01 2C $ 0000 02 00 - 03 DEFRET [COMP]Enh Freq 0 - 3 * 01 2E $ 00 00 02 00 - 64 DEFRET [COMP]Enh Level 0 - 100 * 01 30 $ 00 00 02 00 - 64 DEFRET [COMP]Level 0 - 100 * 01 28 $ 00 00 02 00 - 0F DEFRET [DEFRET]Sens 0 - 100 (refer to Table-19.[BASS1]) * 01 2A $ 0000 02 00 - 0F DEFRET [DEFRET]Attack 0 - 100 (refer to Table-19.[BASS1]) * 01 2C $ 0000 02 00 - 0F DEFRET [DEFRET]Depth 0 - 100 (refer to Table-19.[BASS1]) * 01 2E $ 00 00 02 00 - 64 DEFRET [DEFRET]Level 0 - 100 * 01 32 00 00 02 DEFRET dummy * 01 34 00 00 02 00 OCT Effect On/Off OFF

01 ON * 01 36 00 00 02 00 - 64 OCT Oct Level 0 - 100 * 01 38 00 00 02 00 - 64 OCT Dir Level 0 - 100 * 01 3A 00 00 02 OCT dummy * 01 3C 00 00 02 00 PREAMP Effect On/Off OFF

01 ON * 01 3E 00 00 02 00 PREAMP Preamp Type AC

01 AMG * 01 40 00 00 02 00 - 64 PREAMP Volume 0 - 100 * 01 42 00 00 02 00 - C8 PREAMP Bass -100 - +100 * 01 44 00 00 02 00 - C8 PREAMP Middle -100 - +100 * 01 46 00 00 02 00 - C8 PREAMP Treble -100 - +100 * 01 48 00 00 02 PREAMP dummy * 01 4A 00 00 02 00 - 64 PREAMP Master 0 - 100 * 01 4C 00 00 02 00 PREAMP Bright OFF

01 ON * 01 4E 00 00 02 00 PREAMP Gain LOW

01 MID

02 HIGH * 01 50 00 00 02 00 - 0B PREAMP Mic Setting CENT, 1 - 10 [cm], OFF * 01 52 00 00 02 00 - 64 PREAMP Mic Level 0 - 100 * 01 54 00 00 02 00 - 64 PREAMP Dir Level 0 - 100 * 01 56 00 00 02 00 - 08 PREAMP Position 0 - 8 * 01 58 00 00 02 00 DIST Effect On/Off OFF

01 ON * 01 5A 00 00 02 00 DIST Type TURBO OD

01 BASS OD

02 HARD DS

03 FUZZ 1

04 FUZZ 2 * 01 5C 00 00 02 00 - 1F DIST Drive 0 - 100 (refer to Table-20.[BASS2])

9

MIDI インプリメンテーション

* 01 5E 00 00 02 00 - 0E DIST Bass -50 - +50 (refer to Table-21.[BASS3]) * 01 60 00 00 02 00 - 0E DIST Treble -50 - +50 (refer to Table-21.[BASS3]) * 01 62 00 00 02 00 - 64 DIST FX Level 0 - 100 * 01 64 00 00 02 00 - 64 DIST Dir Level 0 - 100 * 01 66 00 00 02 DIST dummy * 01 68 00 00 02 00 EQ/TWAH Effect On/Off OFF

* 01 6A 00 00 02 00 EQ/TWAH FX Select 4BAND EQ

* 01 6C $ 0000 02 00 - 28 EQ/TWAH [EQ] Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 6E $ 00 00 02 00 - 14 EQ/TWAH [EQ] Lo-Mid f 100- 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 70 $ 00 00 02 00 - 05 EQ/TWAH [EQ] Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 72 $ 00 00 02 00 - 28 EQ/TWAH [EQ] Lo-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 74 $ 00 00 02 00 - 14 EQ/TWAH [EQ] Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 76 $ 00 00 02 00 - 05 EQ/TWAH [EQ] Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 78 $ 00 00 02 00 - 28 EQ/TWAH [EQ] Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 7A $ 0000 02 00 - 28 EQ/TWAH [EQ] High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 7C $ 0000 02 00 - 28 EQ/TWAH [EQ] Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 6C $ 0000 02 00 - 0F EQ/TWAH [TWAH] Sens 0 - 100 (refer to Table-19.[BASS1]) * 01 6E $ 00 00 02 00 EQ/TWAH [TWAH] Start DOWN

* 01 70 $ 00 00 02 00 - 0F EQ/TWAH [TWAH] Stop 0 - 100 (refer to Table-19.[BASS1]) * 01 72 $ 00 00 02 00 - 0F EQ/TWAH [TWAH] Resonance 0 - 100 (refer to Table-19.[BASS1]) * 01 74 $ 00 00 02 00 - 64 EQ/TWAH [TWAH] FX Level 0 - 100 * 01 76 $ 00 00 02 00 - 64 EQ/TWAH [TWAH] Dir Level 0 - 100 * 01 7E $ 00 00 02 EQ/TWAH dummy * 02 00 00 00 02 00 NS Effect On/Off OFF

* 02 02 00 00 02 00 - 64 NS Threshold 0 - 100 * 02 04 00 00 02 00 - 64 NS Release 0 - 100 * 02 06 00 00 02 NS dummy * 02 08 00 00 02 00 DELAY Effect On/Off OFF

* 02 0A 00 00 02 00 DELAY Type SINGLE

* 02 0C 00 00 02 00 - 5A DELAY Delay Time 0 - 1800 [ms] (step=20)

* 02 0E 00 00 02 00 - 14 DELAY Fine Time 0 - 20 [ms] * 02 10 00 00 02 00 - 64 DELAY Tap Time 0 - 100 [%] * 02 12 00 00 02 00 - 64 DELAY Feedback 0 - 100 * 02 14 00 00 02 00 - 09 DELAY High Cut (refer to Table-16.[HICUT]) * 02 16 00 00 02 00 - 78 DELAY FX Level 0 - 120 * 02 18 00 00 02 00 MOD Effect On/Off OFF

* 02 1A 00 00 02 00 MOD FX Select FL

* 02 1C 00 00 02 00 - 08 MOD Position 0 - 8 * 02 1E 00 00 02 MOD dummy * 02 20 $ 00 00 02 00 - 64 MOD [FL] Rate 0 - 100

* 02 22 $ 00 00 02 00 - 64 MOD [FL] Depth 0 - 100 * 02 24 $ 00 00 02 00 - 64 MOD [FL] Manual 0 - 100 * 02 26 $ 00 00 02 00 - 64 MOD [FL] Resonance 0 - 100 * 02 28 $ 00 00 02 00 - 64 MOD [FL] Sepatate 0 - 100 * 02 2A $ 0000 02 00 - 64 MOD [FL] Level 0 - 100 * 02 20 $ 00 00 02 00 - 64 MOD [PH] Rate 0 - 100

* 02 22 $ 00 00 02 00 - 64 MOD [PH] Depth 0 - 100 * 02 24 $ 00 00 02 00 - 64 MOD [PH] Manual 0 - 100 * 02 26 $ 00 00 02 00 - 64 MOD [PH] Resonance 0 - 100 * 02 20 $ 00 00 02 00 MOD [CE] Mode MONO

* 02 22 $ 00 00 02 00 - 64 MOD [CE] Rate 0 - 100

* 02 24 $ 00 00 02 00 - 64 MOD [CE] Depth 0 - 100 * 02 26 $ 00 00 02 00 - 50 MOD [CE] Pre Delay 0.0 - 40.0 [ms] (step=0.5) * 02 28 $ 00 00 02 00 - 0A MOD [CE] Low Cut (refer to Table-22.[LOCUT2]) * 02 2A $ 0000 02 00 - 64 MOD [CE] FX Level 0 - 100 * 02 2C 00 00 02 00 REVERB EffectOn/Off OFF

* 02 2E 00 00 02 00 REVERB Type ROOM 1

* 02 30 00 00 02 01 - 64 REVERB ReverbTime 0.1 - 10.0 [s] * 02 32 00 00 02 00 - 64 REVERB PreDelay 0 - 100 [ms] * 02 34 00 00 02 00 - 09 REVERB Low Cut (refer to Table-17.[LOCUT])

01 ON

01 T-WAH

01 UP

01 ON

01 TAP

5B - 67 BPM 1/4 - 4.0 (refer to Table-5.[BPMPARAM5])

01 ON

01 PH

02 CE

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 ST.

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 ON

01 ROOM 2

02 HALL 1

03 HALL 2

04 PLATE

10

MIDI インプリメンテーション

* 02 36 00 00 02 00 - 09 REVERB High Cut (refer to Table-16.[HICUT]) * 02 38 00 00 02 00 - 0A REVERB Density 0 - 10 * 02 3A 00 00 02 00 - 64 REVERB FX Level 0 - 100 * 02 3C 00 00 02 MASTER dummy * 02 3E 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 02 40 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 02 42 00 00 02 00 - 64 MASTER Foot Level 0 - 100

<<< CHORUS RSS >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 EQ Effect On/Off OFF

* 01 26 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 28 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 2A 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 2C 00 00 02 00 - 28 EQ Lo-Mi EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 2E 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 30 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 32 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 34 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 36 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 38 00 00 02 00 CE Effect On/Off OFF

* 01 3A 00 00 02 00 CE Polarity SYNC

* 01 3C 00 00 02 00 - 64 CE Rate 0 - 100

* 01 3E 00 00 02 00 - 64 CE Depth 0 - 100 * 01 40 00 00 02 00 - 50 CE Pre Delay 0.0 - 40.0 [ms] (step=0.5) * 01 42 00 00 02 00 - 0A CE Low Cut (refer to Table-22.[LOCUT2]) * 01 44 00 00 02 00 - 09 CE High Cut (refer to Table-16.[HICUT]) * 01 46 00 00 02 00 - 64 CE Effect Level 0 - 100 * 01 48 00 00 02 00 CE Direct On/Off OFF

* 01 4A 00 00 02 00 CE RSS On/Off OFF

* 01 4C 00 00 02 MASTER dummy * 01 4E 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 50 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 01 52 00 00 02 00 - 64 MASTER Foot Level 0 - 100

FB MIDI

FC GLOBAL

01 ON

01 INVERT

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 ON

FB MIDI

FC GLOBAL

<<< CHORUS + REVERB >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 EQL EffectOn/Off OFF

* 01 26 00 00 02 00 - 28 EQL Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 28 00 00 02 00 - 14 EQL Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 2A 00 00 02 00 - 05 EQL Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 2C 00 00 02 00 - 28 EQL Lo-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 2E 00 00 02 00 - 14 EQL Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 30 00 00 02 00 - 05 EQL Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 32 00 00 02 00 - 28 EQL Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 34 00 00 02 00 - 28 EQL High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 36 00 00 02 00 - 28 EQL Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 38 00 00 02 00 EQR Effect On/Off OFF

* 01 3A 00 00 02 00 - 28 EQR Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 3C 00 00 02 00 - 14 EQR Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 3E 00 00 02 00 - 05 EQR Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 40 00 00 02 00 - 28 EQR Lo-MidEQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 42 00 00 02 00 - 14 EQR Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 44 00 00 02 00 - 05 EQR Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 46 00 00 02 00 - 28 EQR Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 48 00 00 02 00 - 28 EQR High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 4A 00 00 02 00 - 28 EQR Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 4C 00 00 02 00 REV Effect On/Off OFF

* 01 4E 00 00 02 00 REV Type ROOM 1

* 01 50 00 00 02 01 - 64 REV Reverb Time 0.1 - 10.0 [s]

01 ON

01 ROOM 2

02 HALL 1

03 HALL 2

04 PLATE

11

MIDI インプリメンテーション

* 01 52 00 00 02 00 - C8 REV Balance DIR:FX 100:0 - 0:100 * 01 54 00 00 02 00 - 64 REV Effect Level 0 - 100 * 01 56 00 00 02 00 - 64 REV Pre Delay 0 - 100 [ms] * 01 58 00 00 02 00 - 0A REV Density 0 - 10 * 01 5A 00 00 02 00 - 0A REV Low Cut (refer to Table-22.[LOCUT2]) * 01 5C 00 00 02 00 - 09 REV High Cut (refer to Table-16.[HICUT]) * 01 5E 00 00 02 REV dummy * 01 60 00 00 02 00 CE Effect On/Off OFF

* 01 62 00 00 02 00 CE Mode MONO

* 01 64 00 00 02 00 - 64 CE Rate 0 - 100

* 01 66 00 00 02 00 - 64 CE Depth 0 - 100 * 01 68 00 00 02 00 - 50 CE Pre Delay 0.0 - 40.0 [ms] (step=0.5) * 01 6A 00 00 02 00 - 0A CE Low Cut (refer to Table-22.[LOCUT2]) * 01 6C 00 00 02 00 - 09 CE High Cut (refer to Table-16.[HICUT]) * 01 6E 00 00 02 00 - 64 CE FX Level 0 - 100 * 01 70 00 00 02 00 CE Direct On/Off OFF

* 01 72 00 00 02 CE dummy * 01 74 00 00 02 MASTER dummy * 01 76 00 00 02 00 MASTER Master Level 0 - 100 * 01 78 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 01 7A 00 00 02 00 - 64 MASTER Foot Level 0 - 100

01 ON

01 ST.

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 ON

FB MIDI

FC GLOBAL

<<< DELAY >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 EQ Effect On/Off OFF

* 01 26 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 28 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 2A 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 2C 00 00 02 00 - 28 EQ Lo-Mi EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 2E 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 30 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 32 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 34 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 36 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 38 00 00 02 00 DELAY Effect On/Off OFF

* 01 3A 00 00 02 00 DELAY Type SINGLE

* 01 3C $ 0000 02 00 - 8C DELAY [SINGLE]Delay Time 0 - 2800 [ms] (step=20)

* 01 3E $ 00 00 02 00 - 14 DELAY [SINGLE]Fine Time 0 - 20 [ms] * 01 3C $ 0000 02 00 - 8C DELAY [3TAP]Delay Time C 0 - 2800 [ms] (step=20)

* 01 3E $ 00 00 02 00 - 14 DELAY [3TAP]Fine Time C 0 - 20 [ms] * 01 40 $ 00 00 04 0001- 0190 DELAY [3TAP]Time L 1 - 400 [%] * 01 44 $ 00 00 04 0001- 0190 DELAY [3TAP]Time R 1 - 400 [%] * 01 48 00 00 02 00 - 64 DELAY Feedback 0 - 100 * 01 4A 00 00 02 00 - 64 DELAY Level C 0 - 100 * 01 4C 00 00 02 00 - 64 DELAY Level L 0 - 100 * 01 4E 00 00 02 00 - 64 DELAY Level R 0 - 100 * 01 50 00 00 02 00 - 78 DELAY FX Level 0 - 120 * 01 52 00 00 02 00 - 64 DELAY Dir Level 0 - 100 * 01 54 00 00 02 00 - 32 DELAY High Damp Gain -50 - 0 [dB] * 01 56 00 00 02 00 - 09 DELAY High Cut Filter (refer to Table-16.[HICUT]) * 01 58 00 00 02 DELAY dummy * 01 5A 00 00 02 DELAY dummy * 01 5C 00 00 02 MASTER dummy * 01 5E 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 60 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 01 62 00 00 02 00 - 64 MASTER Foot Level 0 - 100

01 ON

01 3TAP

8D - 99 BPM 1/4 - 4.0 (refer to Table-6.[BPMPARAM6])

FB MIDI

FC GLOBAL

<<< DELAY RSS >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 EQ Effect On/Off OFF

* 01 26 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 28 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 2A 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM])

01 ON

12

MIDI インプリメンテーション

* 01 2C 00 00 02 00 - 28 EQ Lo-Mi EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 2E 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 30 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 32 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 34 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 36 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 38 00 00 02 00 DELAY Effect On/Off OFF

* 01 3A 00 00 02 DELAY dummy * 01 3C 00 00 02 00 - 8C DELAY Delay Time C 0 - 2800 [ms] (step=20)

* 01 3E 00 00 02 00 - 14 DELAY Fine Time C 0 - 20 [ms] * 01 40 00 00 04 0001- 0190 DELAY Time L 1 - 400 [%] * 01 44 00 00 04 0001- 0190 DELAY Time R 1 - 400 [%] * 01 48 00 00 02 00 - 64 DELAY Feedback 0 - 100 * 01 4A 00 00 02 00 - 64 DELAY Level C 0 - 100 * 01 4C 00 00 02 00 - 64 DELAY Level L 0 - 100 * 01 4E 00 00 02 00 - 64 DELAY Level R 0 - 100 * 01 50 00 00 02 00 - 78 DELAY FX Level 0 - 120 * 01 52 00 00 02 00 - 64 DELAY Dir Level 0 - 100 * 01 54 00 00 02 00 - 32 DELAY High Damp Gain -50 - 0 [dB] * 01 56 00 00 02 00 - 09 DELAY High Cut Filter (refer to Table-16.[HICUT]) * 01 58 00 00 02 DELAY dummy * 01 5A 00 00 02 00 DELAY RSS On/Off OFF

* 01 5C 00 00 02 MASTER dummy * 01 5E 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 60 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 01 62 00 00 02 00 - 64 MASTER Foot Level 0 - 100

01 ON

8D - 99 BPM 1/4 - 4.0 (refer to Table-6.[BPMPARAM6])

01 ON

FB MIDI

FC GLOBAL

<<< DELAY + CHORUS >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 EQL EffectOn/Off OFF

01 ON * 01 26 00 00 02 00 - 28 EQL Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 28 00 00 02 00 - 14 EQL Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 2A 00 00 02 00 - 05 EQL Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 2C 00 00 02 00 - 28 EQL Lo-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 2E 00 00 02 00 - 14 EQL Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 30 00 00 02 00 - 05 EQL Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 32 00 00 02 00 - 28 EQL Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 34 00 00 02 00 - 28 EQL High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 36 00 00 02 00 - 28 EQL Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 38 00 00 02 00 EQR Effect On/Off OFF

01 ON * 01 3A 00 00 02 00 - 28 EQR Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 3C 00 00 02 00 - 14 EQR Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 3E 00 00 02 00 - 05 EQR Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 40 00 00 02 00 - 28 EQR Lo-MidEQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 42 00 00 02 00 - 14 EQR Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 44 00 00 02 00 - 05 EQR Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 46 00 00 02 00 - 28 EQR Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 48 00 00 02 00 - 28 EQR High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 4A 00 00 02 00 - 28 EQR Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 4C 00 00 02 00 DLY EffectOn/Off OFF

01 ON * 01 4E 00 00 02 00 DLY Type SINGLE

01 3TAP * 01 50 $ 00 00 02 00 - 5A DLY [SINGLE]Delay Time 0 - 1800 [ms] (step=20)

5B - 67 BPM 1/4 - 4.0 (refer to Table-5.[BPMPARAM5]) * 01 52 $ 00 00 02 00 - 14 DLY [SINGLE]Fine Time 0 - 20 [ms] * 01 50 $ 00 00 02 00 - 5A DLY [3TAP]Delay Time C 0 - 1800 [ms] (step=20)

5B - 67 BPM 1/4 - 4.0 (refer to Table-5.[BPMPARAM5]) * 01 52 $ 00 00 02 00 - 14 DLY [3TAP]Fine Time C 0 -20[ms] * 01 54 $ 00 00 04 0001- 0190 DLY [3TAP]Time L 1 - 400 [%] * 01 58 $ 00 00 04 0001- 0190 DLY [3TAP]Time R 1 - 400 [%] * 01 5C 00 00 02 00 - 64 DLY Feedback 0 - 100 * 01 5E 00 00 02 00 - 64 DLY Level C 0 - 100 * 01 60 00 00 02 00 - 64 DLY Level L 0 - 100 * 01 62 00 00 02 00 - 64 DLY Level R 0 - 100 * 01 64 00 00 02 00 - 78 DLY FX Level 0 - 120 * 01 66 00 00 02 00 - 64 DLY Dir Level 0 - 100 * 01 68 00 00 02 00 - 32 DLY High Damp Gain -50 - 0[dB] * 01 6A 00 00 02 00 - 09 DLY High Cut Filter (refer to Table-16.[HICUT]) * 01 6C 00 00 02 DLY dummy * 01 6E 00 00 02 DLY dummy

13

MIDI インプリメンテーション

* 01 70 00 00 02 00 CE Effect On/Off OFF

* 01 72 00 00 02 00 CE Mode MONO

* 01 74 00 00 02 00 - 64 CE Rate 0 - 100

* 01 76 00 00 02 00 - 64 CE Depth 0 - 100 * 01 78 00 00 02 00 - 50 CE Pre Delay 0.0 - 40.0 [ms] (step=0.5) * 01 7A 00 00 02 00 - 0A CE Low Cut (refer to Table-22.[LOCUT2]) * 01 7C 00 00 02 00 - 09 CE High Cut (refer to Table-16.[HICUT]) * 01 7E 00 00 02 00 - 64 CE FX Level 0 - 100 * 02 00 00 00 02 00 CE Direct On/Off OFF

* 02 02 00 00 02 CE dummy * 02 04 00 00 02 MASTER dummy * 02 06 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 02 08 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 02 0A 00 00 02 00 - 64 MASTER Foot Level 0 - 100

01 ON

01 ST.

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 ON

FB MIDI

FC GLOBAL

<<< DELAY + REVERB >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 EQL EffectOn/Off OFF

* 01 26 00 00 02 00 - 28 EQL Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 28 00 00 02 00 - 14 EQL Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 2A 00 00 02 00 - 05 EQL Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 2C 00 00 02 00 - 28 EQL Lo-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 2E 00 00 02 00 - 14 EQL Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 30 00 00 02 00 - 05 EQL Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 32 00 00 02 00 - 28 EQL Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 34 00 00 02 00 - 28 EQL High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 36 00 00 02 00 - 28 EQL Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 38 00 00 02 00 EQR Effect On/Off OFF

* 01 3A 00 00 02 00 - 28 EQR Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 3C 00 00 02 00 - 14 EQR Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 3E 00 00 02 00 - 05 EQR Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 40 00 00 02 00 - 28 EQR Lo-MidEQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 42 00 00 02 00 - 14 EQR Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 44 00 00 02 00 - 05 EQR Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 46 00 00 02 00 - 28 EQR Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 48 00 00 02 00 - 28 EQR High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 4A 00 00 02 00 - 28 EQR Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 4C 00 00 02 00 DLY EffectOn/Off OFF

* 01 4E 00 00 02 00 DLY Type SINGLE

* 01 50 $ 00 00 02 00 - 5A DLY [SINGLE]Delay Time 0 - 1800 [ms] (step=20)

* 01 52 $ 00 00 02 00 - 14 DLY [SINGLE]Fine Time 0 - 20 [ms] * 01 50 $ 00 00 02 00 - 5A DLY [3TAP]Delay Time C 0 - 1800 [ms] (step=20)

* 01 52 $ 00 00 02 00 - 14 DLY [3TAP]Fine Time C 0 - 20 [ms] * 01 54 $ 00 00 04 0001- 0190 DLY [3TAP]Time L 1 - 400 [%] * 01 58 $ 00 00 04 0001- 0190 DLY [3TAP]Time R 1 - 400 [%] * 01 5C 00 00 02 00 - 64 DLY Feedback 0 - 100 * 01 5E 00 00 02 00 - 64 DLY Level C 0 - 100 * 01 60 00 00 02 00 - 64 DLY Level L 0 - 100 * 01 62 00 00 02 00 - 64 DLY Level R 0 - 100 * 01 64 00 00 02 00 - 78 DLY FX Level 0 - 120 * 01 66 00 00 02 00 - 64 DLY Dir Level 0 - 100 * 01 68 00 00 02 00 - 32 DLY High Damp Gain -50 - 0[dB] * 01 6A 00 00 02 00 - 09 DLY High Cut Filter (refer to Table-16.[HICUT]) * 01 6C 00 00 02 DLY dummy * 01 6E 00 00 02 DLY dummy * 01 70 00 00 02 00 REV Effect On/Off OFF

* 01 72 00 00 02 00 REV Type ROOM 1

* 01 74 00 00 02 01 - 64 REV Reverb Time 0.1 - 10.0 [s] * 01 76 00 00 02 00 - C8 REV Balance DIR:FX 100:0 - 0:100 * 01 78 00 00 02 00 - 64 REV Effect Level 0 - 100 * 01 7A 00 00 02 00 - 64 REV Pre Delay 0 - 100 [ms]

01 ON

01 3TAP

5B - 67 BPM 1/4 - 4.0 (refer to Table-5.[BPMPARAM5])

01 ON

01 ROOM 2

02 HALL 1

03 HALL 2

04 PLATE

14

MIDI インプリメンテーション

* 01 7C 00 00 02 00 - 0A REV Density 0 - 10 * 01 7E 00 00 02 00 - 0A REV Low Cut (refer to Table-22.[LOCUT2]) * 02 00 00 00 02 00 - 09 REV High Cut (refer to Table-16.[HICUT]) * 02 02 00 00 02 REV dummy * 02 04 00 00 02 MASTER dummy * 02 06 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 02 08 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 02 0A 00 00 02 00 - 64 MASTER Foot Level 0 - 100

<<< GATE REVERB >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 EQ Effect On/Off OFF

* 01 26 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 28 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 2A 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 2C 00 00 02 00 - 28 EQ Lo-Mi EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 2E 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 30 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 32 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 34 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 36 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 38 00 00 02 00 REVERB Effect On/Off OFF

* 01 3A 00 00 02 REVERB dummy * 01 3C 00 00 04 0038- 0146 REVERB Room Size 5.6 - 32.6 [m] * 01 40 00 00 04 0001- 0140 REVERB Reverb Time 0.1 - 32.0 [s] * 01 44 00 00 02 00 - C8 REVERB Balance Dir:FX 100:0 - 0:100 * 01 46 00 00 02 00 - 64 REVERB Effect Level 0 - 100 * 01 48 00 00 02 00 - C8 REVERB Pre Delay 0 - 200 [ms] * 01 4A 00 00 02 00 - 64 REVERB Density 0 - 100 * 01 4C 00 00 02 00 - 64 REVERB ER Level 0 - 100 * 01 4E 00 00 02 00 - 64 REVERB Release Dnsty 0 - 100 * 01 50 00 00 02 00 - 30 REVERB Low Damp Gain (refer to Table-24.[DAMPGAIN]) * 01 52 00 00 02 00 - 10 REVERB Low Damp Freq (refer to Table-25.[LODMP]) * 01 54 00 00 02 00 - 30 REVERB High Damp Gain (refer to Table-24.[DAMPGAIN]) * 01 56 00 00 02 00 - 10 REVERB High Damp Freq (refer to Table-26.[HIDMP]) * 01 58 00 00 02 00 - 21 REVERB High Cut Filter (refer to Table-27.[REVHICUT]) * 01 5A 00 00 02 REVERB dummy * 01 5C 00 00 02 00 GATE Gate On/Off OFF

* 01 5E 00 00 02 00 - 64 GATE Threshold 0 - 100 * 01 60 00 00 02 01 - 64 GATE Hold Time 1 - 100 * 01 62 00 00 02 01 - 64 GATE Rls Time 1 - 100 * 01 64 00 00 02 MASTER dummy * 01 66 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 68 00 00 02 MASTER dummy * 01 6A 00 00 02 00 - 64 MASTER Foot Level 0 - 100

FB MIDI

FC GLOBAL

01 ON

<<< GUITAR MULTI 1 >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 COMP Effect On/Off OFF

01 ON * 01 26 00 00 02 00 COMP FX Select COMP

01 LIMIT * 01 28 $ 00 00 02 00 - 64 COMP [COMP]Sustain 0 - 100 * 01 2A $ 0000 02 00 - 64 COMP [COMP]Attack 0 - 100 * 01 2C $ 0000 02 00 - 64 COMP [COMP]Tone -50 - +50 * 01 2E $ 00 00 02 00 - 64 COMP [COMP]Level 0 - 100 * 01 28 $ 00 00 02 00 - 64 COMP [LIMIT]Threshold 0 - 100 * 01 2A $ 0000 02 00 - 64 COMP [LIMIT]Release 0 - 100 * 01 2C $ 0000 02 00 - 64 COMP [LIMIT]Tone -50 - +50 * 01 2E $ 00 00 02 00 - 64 COMP [LIMIT]Level 0 - 100 * 01 30 00 00 02 00 WAH EffectOn/Off OFF

01 ON * 01 32 00 00 02 00 WAH FX Select WAH

01 AW * 01 34 $ 00 00 02 00 - 64 WAH [WAH]Pedal 0 - 100 * 01 36 $ 00 00 02 00 - 64 WAH [WAH]Level 0 - 100 * 01 34 $ 00 00 02 00 WAH [AW]Mode LPF

01 BPF * 01 36 $ 00 00 02 00 WAH [AW]Polarity DOWN

01 UP * 01 38 $ 00 00 02 00 - 64 WAH [AW]Sens 0 - 100 * 01 3A $ 0000 02 00 - 64 WAH [AW]Freq 0 - 100

15

MIDI インプリメンテーション

* 01 3C $ 0000 02 00 - 64 WAH [AW]Peak 0 - 100 * 01 3E $ 00 00 02 00 - 64 WAH [AW]Rate 0 - 100

* 01 40 $ 00 00 02 00 - 64 WAH [AW]Depth 0 - 100 * 01 42 $ 00 00 02 00 - 64 WAH [AW]Level 0 - 100 * 01 44 00 00 02 00 PREAMP Effect On/Off OFF

* 01 46 00 00 02 00 - 11 PREAMP Preamp Type (refer to Table-9.[PREAMPTYPE]) * 01 48 00 00 02 00 - 64 PREAMP Volume 0 - 100 * 01 4A 00 00 02 00 - 64 PREAMP Bass 0 - 100 * 01 4C 00 00 02 00 - 64 PREAMP Middle 0 - 100 * 01 4E 00 00 02 00 - 64 PREAMP Treble 0 - 100 * 01 50 00 00 02 00 - 64 PREAMP Presence 0 - 100 * 01 52 00 00 02 00 - 64 PREAMP Master 0 - 100 * 01 54 00 00 02 00 PREAMP Bright OFF

* 01 56 00 00 02 00 PREAMP Gain LOW

* 01 58 00 00 02 00 - 0A PREAMP Mic Setting (refer to Table-10.[PREAMPMICSET]) * 01 5A 00 00 02 00 - 64 PREAMP Mic Level 0 - 100 * 01 5C 00 00 02 00 - 64 PREAMP Direct Level 0 - 100 * 01 5E 00 00 02 00 - 08 PREAMP Position 0 - 8 * 01 60 00 00 02 00 EQ Effect On/Off OFF

* 01 62 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 64 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 66 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 68 00 00 02 00 - 28 EQ Lo-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 6A 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 6C 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 6E 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 70 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 72 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 74 00 00 02 00 NS Effect On/Off OFF

* 01 76 00 00 02 00 - 64 NS Threshold 0 - 100 * 01 78 00 00 02 00 - 64 NS Release 0 - 100 *017A 000002 00 NS * 01 7C 00 00 02 00 MOD Effect On/Off OFF

* 01 7E 00 00 02 00 - 0A MOD FX Select (refer to Table-12.[MOD]) * 02 00 00 00 02 00 - 08 MOD Position 0 - 8 *0202 000002 MOD * 02 04 $ 00 00 02 00 MOD [HR]Voice 1 MONO

* 02 06 $ 00 00 02 00 - 0B MOD [HR]Key C(Am) - B(G#m) (refer to Table-13.[HARMKEY]) * 02 08 $ 00 00 02 00 - 64 MOD [HR]Dir Level 0 - 100 * 02 0A $ 0000 02 00 MOD dummy * 02 0C $ 0000 02 00 MOD [HR][1] Mode FAST

* 02 0E $ 00 00 02 00 - 30 MOD [HR][1] Pitch -24 - +24 * 02 10 $ 00 00 02 00 - 64 MOD [HR][1] Fine -50 - +50 * 02 12 $ 00 00 02 00 - 21 MOD [HR][1] Harmony -2OCT - +2OCT, SCALE1 - SCALE5

* 02 14 $ 00 00 02 00 - 64 MOD [HR][1] Feedback 0 - 100 * 02 16 $ 00 00 02 00 - 64 MOD [HR][1] Level 0 - 100 * 02 18 $ 00 00 04 0000- 012C MOD [HR][1] Pre Delay 0 - 300 [ms]

* 02 1C $ 0000 02 00 MOD [HR][2] Mode FAST

* 02 1E $ 00 00 02 00 - 30 MOD [HR][2] Pitch -24 - +24 * 02 20 $ 00 00 02 00 - 64 MOD [HR][2] Fine -50 - +50 * 02 22 $ 00 00 02 00 - 21 MOD [HR][2] Harmony -2OCT - +2OCT, SCALE1 - SCALE5

* 02 24 $ 00 00 02 MOD dummy * 02 26 $ 00 00 02 00 - 64 MOD [HR][2] Level 0 - 100 * 02 28 $ 00 00 04 0000- 012C MOD [HR][2] Pre Delay 0 - 300 [ms]

* 02 04 $ 00 00 02 00 - 64 MOD [FL] Rate 0 - 100

* 02 06 $ 00 00 02 00 - 64 MOD [FL] Depth 0 - 100

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 ON

01 MID

02 HIGH

01 ON

01 2 MONO

02 2 STEREO

01 MEDIUM

02 SLOW

03 MONO

04 HARMONY

(refer to Table-14.[HARMHARMONY])

012D- 0139 BPM 1/4 - 4.0 (refer to Table-7.[BPMPARAM7])

01 MEDIUM

02 SLOW

03 MONO

04 HARMONY

(refer to Table-14.[HARMHARMONY])

012D- 0139 BPM 1/4 - 4.0 (refer to Table-7.[BPMPARAM7])

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

16

MIDI インプリメンテーション

* 02 08 $ 00 00 02 00 - 64 MOD [FL] Manual 0 - 100 * 02 0A $ 0000 02 00 - 64 MOD [FL] Resonance 0 - 100 * 02 0C $ 0000 02 00 - 64 MOD [FL] Separate 0 - 100 * 02 0E $ 00 00 02 00 - 64 MOD [FL] Level 0 - 100 * 02 04 $ 00 00 02 00 MOD [FL] Type 4STAGE

* 02 06 $ 00 00 02 00 - 64 MOD [PH] Rate 0 - 100

* 02 08 $ 00 00 02 00 - 64 MOD [PH] Depth 0 - 100 * 02 0A $ 0000 02 00 - 64 MOD [PH] Manual 0 - 100 * 02 0C $ 0000 02 00 - 64 MOD [PH] Resonance 0 - 100 * 02 0E $ 00 00 02 MOD dummy * 02 10 $ 00 00 02 00 MOD [PH] Step OFF

* 02 12 $ 00 00 02 00 - 64 MOD [PH] Level 0 - 100 * 02 04 $ 00 00 02 00 - 28 MOD [SEQ] Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 02 06 $ 00 00 02 00 - 14 MOD [SEQ] Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 02 08 $ 00 00 02 00 - 05 MOD [SEQ] Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 02 0A $ 0000 02 00 - 28 MOD [SEQ] Lo-Mi EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 02 0C $ 0000 02 00 - 14 MOD [SEQ] Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 02 0E $ 00 00 02 00 - 05 MOD [SEQ] Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 02 10 $ 00 00 02 00 - 28 MOD [SEQ] Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 02 12 $ 00 00 02 00 - 28 MOD [SEQ] High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 02 14 $ 00 00 02 00 - 28 MOD [SEQ] Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 02 04 $ 00 00 02 00 - 10 MOD [2CE] Xover f 100Hz - 4.00kHz (refer to Table-15.[2CEXOVER]) * 02 06 $ 00 00 02 00 - 64 MOD [2CE] Low Rate 0 - 100

* 02 08 $ 00 00 02 00 - 64 MOD [2CE] Low Depth 0 - 100 * 02 0A $ 0000 02 00 - 50 MOD [2CE] Low PreDelay 0.0 - 40.0 [ms] (step=0.5) * 02 0C $ 0000 02 00 - 64 MOD [2CE] Low Level 0 - 100 * 02 0E $ 00 00 02 00 - 64 MOD [2CE] High Rate 0 - 100

* 02 10 $ 00 00 02 00 - 64 MOD [2CE] High Depth 0 - 100 * 02 12 $ 00 00 02 00 - 50 MOD [2CE] High PreDelay 0.0 - 40.0 [ms] (step=0.5) * 02 14 $ 00 00 02 00 - 64 MOD [2CE] High Level 0 - 100 * 02 04 $ 00 00 04 0000- 0190 MOD [SDD] Delay Time 0 - 400 [ms] (step=20)

* 02 08 $ 00 00 02 00 - 64 MOD [SDD] Feedback 0 - 100 * 02 0A $ 0000 02 00 - 78 MOD [SDD] FX Level * 02 04 $ 00 00 02 00 MOD [HU] Mode PICK

* 02 06 $ 00 00 02 00 - 04 MOD [HU] Vowel 1 a,e,i,o,u * 02 08 $ 00 00 02 00 - 04 MOD [HU] Vowel 2 a,e,i,o,u * 02 0A $ 0000 02 00 - 64 MOD [HU] Sens 0 - 100 * 02 0C $ 0000 02 00 - 64 MOD [HU] Rate 0 - 100

* 02 0E $ 00 00 02 00 - 64 MOD [HU] Depth 0 - 100 * 02 10 $ 00 00 02 00 - 64 MOD [HU] Manual 0 - 100 * 02 12 $ 00 00 02 00 - 64 MOD [HU] Level 0 - 100 * 02 04 $ 00 00 02 00 - 64 MOD [VB] Rate 0 - 100

* 02 06 $ 00 00 02 00 - 64 MOD [VB] Depth 0 - 100 * 02 08 $ 00 00 02 00 MOD [VB] Trigger OFF

* 02 0A $ 0000 02 00 - 64 MOD [VB] Rise Time 0 - 100 * 02 04 $ 00 00 02 00 - 64 MOD [SYN] Sens 0 - 100 * 02 06 $ 00 00 02 00 MOD [SYN] Wave SQR

* 02 08 $ 00 00 02 00 MOD [SYN] Chromatic OFF

* 02 0A $ 0000 02 00 MOD [SYN] Oct Shift 0

* 02 0C $ 0000 02 00 - 64 MOD [SYN] PWM Rate 0 - 100 * 02 0E $ 00 00 02 00 - 64 MOD [SYN] PWM Depth 0 - 100 * 02 10 $ 00 00 02 00 - 64 MOD [SYN] Cutoff F 0 - 100 * 02 12 $ 00 00 02 00 - 64 MOD [SYN] Resonance 0 - 100 * 02 14 $ 00 00 02 00 - 64 MOD [SYN] FLT.Sens 0 - 100 * 02 16 $ 00 00 02 00 - 64 MOD [SYN] FLT.Decay 0 - 100 * 02 18 $ 00 00 02 00 - C8 MOD [SYN] FLT. Depth -100 - +100 * 02 1A $ 0000 02 00 MOD [SYN] Attack DECAY

* 02 1C $ 0000 02 00 - 64 MOD [SYN] Release 0 - 100 * 02 1E $ 00 00 02 00 - 64 MOD [SYN] Velocity 0 - 100

01 8STAGE

02 12STAGE

03 BI-PHASE

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 - 64 1 - 100

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

0191- 019D BPM 1/4 - 4.0 (refer to Table-8.[BPMPARAM8])

01 AUTO

02 RANDOM

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 ON

01 SAW

02 BRASS

03 BOW

01 ON

01 -1

02 -2

01 - 65 0 - 100

17

MIDI インプリメンテーション

* 02 20 $ 00 00 02 00 MOD [SYN] Hold OFF

* 02 22 $ 00 00 02 00 - 64 MOD [SYN] SynthLevel 0 - 100 * 02 24 $ 00 00 02 00 - 64 MOD [SYN] DirLevel 0 - 100 * 02 04 $ 00 00 02 00 MOD [RM] Mode NORMAL

* 02 06 $ 00 00 02 00 - 64 MOD [RM] Freq 0 - 100 * 02 08 $ 00 00 02 00 - 64 MOD [RM] FX Level 0 - 100 * 02 0A $ 0000 02 00 - 64 MOD [RM] Dir Level 0 - 100 * 02 04 $ 00 00 02 00 - 13 MOD [SL] Pattern P1 - P20 * 02 06 $ 00 00 02 00 - 64 MOD [SL] Rate 0 - 100

* 02 08 $ 00 00 02 00 - 64 MOD [SL] Trigger Sens 0 - 100 * 02 2A $ 0000 02 MOD dummy * 02 2C 00 00 02 00 DELAY EffectOn/Off OFF

* 02 2E 00 00 02 00 DELAY Type SINGLE

* 02 30 00 00 02 00 - 5A DELAY Delay Time 0 - 1800 [ms] (step=20)

* 02 32 00 00 02 00 - 14 DELAY Fine Time 0 - 20 [ms] * 02 34 00 00 02 00 - 64 DELAY Tap Time 0 - 100 [%] * 02 36 00 00 02 00 - 64 DELAY Feedback 0 - 100 * 02 38 00 00 02 00 - 09 DELAY High Cut 700Hz - 11.0 kHz, Flat (refer to Table-16.[HICUT]) * 02 3A 00 00 02 00 - 78 DELAY FX Level 0 - 120 * 02 3C 00 00 02 00 CHORUS Effect On/Off OFF

* 02 3E 00 00 02 00 CHORUS Mode MONO

* 02 40 00 00 02 00 - 64 CHORUS Rate 0 - 100

* 02 42 00 00 02 00 - 64 CHORUS Depth 0 - 100 * 02 44 00 00 02 00 - 50 CHORUS Pre Delay 0.0 - 40.0 [ms] (step=0.5) * 02 46 00 00 02 00 - 09 CHORUS High Cut 700Hz - 11.0 kHz, Flat (refer to Table-16.[HICUT]) * 02 48 00 00 02 00 - 64 CHORUS FX Level 0 - 100 * 02 4A 00 00 02 CHORUS * 02 4C 00 00 02 00 REVERB Effect On/Off OFF

* 02 4E 00 00 02 00 REVERB Type ROOM 1

* 02 50 00 00 02 01 - 64 REVERB Reverb Time 0.1 - 10.0 [s] * 02 52 00 00 02 00 - 64 REVERB Pre Delay 0 - 100 [ms] * 02 54 00 00 02 00 - 09 REVERB Low Cut 55.0Hz - 800Hz (refer to Table-17.[LOCUT]) * 02 56 00 00 02 00 - 09 REVERB High Cut 700Hz - 11.0kHz,Flat (refer to Table-16.[HICUT]) * 02 58 00 00 02 00 - 0A REVERB Density 0 - 10 * 02 5A 00 00 02 00 - 64 REVERB FX Level 0 - 100 * 02 5C 00 00 02 MASTER * 02 5E 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 02 60 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 02 62 00 00 02 00 - 64 MASTER Foot Level 0 - 100

01 ON

01 INTELLIGENT

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 ON

01 TAP

5B - 67 BPM 1/4 - 4.0 (refer to Table-5.[BPMPARAM5])

01 ON

01 ST.

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 ON

01 ROOM 2

02 HALL 1

03 HALL 2

04 PLATE

FB MIDI

FC GLOBAL

<<< GUITAR MULTI 2 >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 COMP Effect On/Off OFF

* 01 26 00 00 02 00 COMP FX Select COMP

* 01 28 $ 00 00 02 00 - 64 COMP [COMP]Sustain 0 - 100 * 01 2A $ 0000 02 00 - 64 COMP [COMP]Attack 0 - 100 * 01 2C $ 0000 02 00 - 64 COMP [COMP]Tone -50 - +50 * 01 2E $ 00 00 02 00 - 64 COMP [COMP]Level 0 - 100 * 01 28 $ 00 00 02 00 - 64 COMP [LIMIT]Threshold 0 - 100 * 01 2A $ 0000 02 00 - 64 COMP [LIMIT]Release 0 - 100 * 01 2C $ 0000 02 00 - 64 COMP [LIMIT]Tone -50 - +50 * 01 2E $ 00 00 02 00 - 64 COMP [LIMIT]Level 0 - 100 * 01 30 00 00 02 00 WAH EffectOn/Off OFF

* 01 32 00 00 02 00 WAH FX Select WAH

* 01 34 $ 00 00 02 00 - 64 WAH [WAH]Pedal 0 - 100 * 01 36 $ 00 00 02 00 - 64 WAH [WAH]Level 0 - 100 * 01 34 $ 00 00 02 00 WAH [AW]Mode LPF

01 ON

01 LIMIT

01 ON

01 AW

01 BPF

18

MIDI インプリメンテーション

* 01 36 $ 00 00 02 00 WAH [AW]Polarity DOWN

* 01 38 $ 00 00 02 00 - 64 WAH [AW]Sens 0 - 100 * 01 3A $ 0000 02 00 - 64 WAH [AW]Freq 0 - 100 * 01 3C $ 0000 02 00 - 64 WAH [AW]Peak 0 - 100 * 01 3E $ 00 00 02 00 - 64 WAH [AW]Rate 0 - 100

* 01 40 $ 00 00 02 00 - 64 WAH [AW]Depth 0 - 100 * 01 42 $ 00 00 02 00 - 64 WAH [AW]Level 0 - 100 * 01 44 00 00 02 00 PREAMP Effect On/Off OFF

* 01 46 00 00 02 00 - 11 PREAMP Preamp Type (refer to Table-9.[PREAMPTYPE]) * 01 48 00 00 02 00 - 64 PREAMP Volume 0 - 100 * 01 4A 00 00 02 00 - 64 PREAMP Bass 0 - 100 * 01 4C 00 00 02 00 - 64 PREAMP Middle 0 - 100 * 01 4E 00 00 02 00 - 64 PREAMP Treble 0 - 100 * 01 50 00 00 02 00 - 64 PREAMP Presence 0 - 100 * 01 52 00 00 02 00 - 64 PREAMP Master 0 - 100 * 01 54 00 00 02 00 PREAMP Bright OFF

* 01 56 00 00 02 00 PREAMP Gain LOW

* 01 58 00 00 02 00 - 0A PREAMP Mic Setting (refer to Table-10.[PREAMPMICSET]) * 01 5A 00 00 02 00 - 64 PREAMP Mic Level 0 - 100 * 01 5C 00 00 02 00 - 64 PREAMP Direct Level 0 - 100 * 01 5E 00 00 02 00 - 08 PREAMP Position 0 - 8 * 01 60 00 00 02 00 EQ Effect On/Off OFF

* 01 62 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 64 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 66 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 68 00 00 02 00 - 28 EQ Lo-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 6A 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 6C 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 6E 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 70 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 72 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 74 00 00 02 00 NS Effect On/Off OFF

* 01 76 00 00 02 00 - 64 NS Threshold 0 - 100 * 01 78 00 00 02 00 - 64 NS Release 0 - 100 * 01 7A 00 00 02 NS dummy * 01 7C 00 00 02 00 SFX EffectOn/Off OFF

* 01 7E 00 00 02 00 - 05 SFX FX Select (refer to Table-18.[SFXSELECT]) * 02 00 00 00 02 00 - 08 SFX Position 0 - 8 * 02 02 00 00 02 SFX dummy * 02 04 $ 00 00 02 00 - 64 SFX [AC]Top 0 - 100 * 02 06 $ 00 00 02 00 - 64 SFX [AC]Body 0 - 100 * 02 08 $ 00 00 02 00 - 64 SFX [AC]Level 0 - 100 * 02 04 $ 00 00 02 00 SFX [BSS]Character LOOSE

* 02 06 $ 00 00 02 00 - 64 SFX [BSS]FX Level 0 - 100 * 02 08 $ 00 00 02 00 - 64 SFX [BSS]Dir Level 0 - 100 * 02 04 $ 00 00 02 00 - 64 SFX [SG]Sens 0 - 100 * 02 06 $ 00 00 02 00 - 64 SFX [SG]Rise Time 0 - 100 * 02 04 $ 00 00 02 00 SFX [FB]Mode OSC

* 02 06 $ 00 00 02 00 - 64 SFX [FB]Rise Time 0 - 100 * 02 08 $ 00 00 02 00 - 64 SFX [FB]Rise Time ( ▲ ) 0 - 100 * 02 0A $ 0000 02 00 - 64 SFX [FB]F.B.Level 0 - 100 * 02 0C $ 0000 02 00 - 64 SFX [FB]F.B.Level( ▲ ) 0 - 100 * 02 0E $ 00 00 02 00 - 64 SFX [FB]Vib Rate 0 - 100 * 02 10 $ 00 00 02 00 - 64 SFX [FB]Vib Depth 0 - 100 * 02 12 $ 00 00 02 00 - 64 SFX [FB]F.B.Depth 0 - 100 * 02 14 $ 00 00 02 00 SFX [FB]F.B.Tone NORMAL

* 02 04 $ 00 00 02 00 SFX [PIC]Type 'S' to 'H'

* 02 06 $ 00 00 02 00 - 64 SFX [PIC]Tone -50 - +50 * 02 08 $ 00 00 02 00 - 64 SFX [PIC]Level 0 - 100 * 02 04 $ 00 00 02 00 SFX [TR]Mode TREMOLO

* 02 06 $ 00 00 02 00 - 64 SFX [TR]Wave Shape 0 - 100 * 02 08 $ 00 00 02 00 - 64 SFX [TR]Rate 0 - 100

* 02 0A $ 0000 02 00 - 64 SFX [TR]Depth 0 - 100

01 UP

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 ON

01 MID

02 HIGH

01 ON

01 TIGHT

01 BOOST

01 +1OCT

01 'H' to 'S'

02 'H to 'HF'

01 PAN

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

19

MIDI インプリメンテーション

* 02 16 $ 00 00 02 SFX [TR]dummy * 02 18 00 00 02 00 DELAY Effect On/Off OFF

* 02 1A 00 00 02 00 DELAY Type SINGLE

* 02 1C 00 00 02 00 - 5A DELAY Delay Time 0 - 1800 [ms] (step=20)

* 02 1E 00 00 02 00 - 14 DELAY Fine Time 0 - 20 [ms] * 02 20 00 00 02 00 - 64 DELAY Tap Time 0 - 100 [%] * 02 22 00 00 02 00 - 64 DELAY Feedback 0 - 100 * 02 24 00 00 02 00 - 09 DELAY High Cut (refer to Table-16.[HICUT]) * 02 26 00 00 02 00 - 78 DELAY FX Level 0 - 120 * 02 28 00 00 02 00 CHORUS Effect On/Off OFF

* 02 2A 00 00 02 00 CHORUS Mode MONO

* 02 2C 00 00 02 00 - 64 CHORUS Rate 0 - 100

* 02 2E 00 00 02 00 - 64 CHORUS Depth 0 - 100 * 02 30 00 00 02 00 - 50 CHORUS Pre Delay 0.0 - 40.0 [ms] (step=0.5) * 02 32 00 00 02 00 - 09 CHORUS High Cut (refer to Table-16.[HICUT]) * 02 34 00 00 02 00 - 64 CHORUS FX Level 0 - 100 * 02 36 00 00 02 CHORUS dummy * 02 38 00 00 02 00 REVERB Effect On/Off OFF

* 02 3A 00 00 02 00 REVERB Type ROOM 1

* 02 3C 00 00 02 01 - 64 REVERB Reverb Time 0.1 - 10.0 [s] * 02 3E 00 00 02 00 - 64 REVERB Pre Delay 0 - 100 [ms] * 02 40 00 00 02 00 - 09 REVERB Low Cut (refer to Table-17.[LOCUT]) * 02 42 00 00 02 00 - 09 REVERB High Cut (refer to Table-16.[HICUT]) * 02 44 00 00 02 00 - 0A REVERB Density 0 - 10 * 02 46 00 00 02 00 - 64 REVERB FX Level 0 - 100 * 02 48 00 00 02 MASTER dummy * 02 4A 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 02 4C 00 00 02 28 - FA MASTER Master BPM 40 - 250

* 02 4E 00 00 02 00 - 64 MASTER Foot Level 0 - 100

01 ON

01 TAP

5B - 67 BPM 1/4 - 4.0 (refer to Table-5.[BPMPARAM5])

01 ON

01 ST.

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 ON

01 ROOM 2

02 HALL 1

03 HALL 2

04 PLATE

FB MIDI

FC GLOBAL

<<< HUM CANCELER >>>

※Frequencyは入力値（DATA）× 10 ＋ 20が表示値です。

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 HUM Effect On/Off OFF

* 01 26 00 00 02 00 - 4E HUM Frequency 20.0 - 800.0 [Hz] (DATA x 10 + 20) * 01 28 00 00 02 0A - 28 HUM Width 10 - 40 [%] * 01 2A 00 00 02 00 - 64 HUM Depth 0 - 100 * 01 2C 00 00 02 00 - 64 HUM Threshold 0 - 100 * 01 2E 00 00 02 00 - 12 HUM Range Low (refer to Table-30.[RANGELO]) * 01 30 00 00 02 00 - 14 HUM Range High (refer to Table-31.[RANGEHI]) * 01 32 00 00 02 HUM dummy * 01 34 00 00 02 00 NS Effect On/Off OFF

* 01 36 00 00 02 00 - 64 NS Threshold 0 - 100 * 01 38 00 00 02 00 - 64 NS Release 0 - 100 * 01 3A 00 00 02 00 NS dummy * 01 3C 00 00 02 00 MASTER dummy * 01 3E 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 40 00 00 02 MASTER dummy * 01 42 00 00 02 00 - 64 MASTER Foot Level 0 - 100

01 ON

<<< ISOLATOR >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 ISO EffectOn/Off OFF

* 01 26 00 00 02 00 - 64 ISO AntiPhase LowLevel 0 - 100 * 01 28 00 00 02 00 - 64 ISO AntiPhase MidLevel 0 - 100 * 01 2A 00 00 02 00 ISO Low Mix Switch OFF

* 01 2C 00 00 02 00 ISO Mid Mix Switch OFF

* 01 2E 00 00 02 00 - 40 ISO Low Level -60 - +4 * 01 30 00 00 02 00 - 40 ISO Mid Level -60 - +4

01 ON

20

MIDI インプリメンテーション

* 01 32 00 00 02 00 - 40 ISO High Level -60 - +4 * 01 34 00 00 02 00 MOD Effect On/Off OFF

* 01 36 00 00 02 00 MOD FX Select PH

* 01 38 $ 00 00 02 00 MOD [PH] Mode 4STAGE

* 01 3A $ 0000 02 00 - 64 MOD [PH] Rate 0 - 100

* 01 3C $ 0000 02 00 - 64 MOD [PH] Depth 0 - 100 * 01 3E $ 00 00 02 00 - 64 MOD [PH] Manual 0 - 100 * 01 40 $ 00 00 02 00 - C8 MOD [PH] Resonance -100 - +100 * 01 42 $ 00 00 02 00 - 64 MOD [PH] Separate 0 - 100 * 01 44 $ 00 00 02 00 - 64 MOD [PH] Step OFF, 1 - 100 * 01 38 $ 00 00 02 00 - 64 MOD [FL] Rate 0 - 100

* 01 3A $ 0000 02 00 - 64 MOD [FL] Depth 0 - 100 * 01 3C $ 0000 02 00 - 64 MOD [FL] Manual 0 - 100 * 01 3E $ 00 00 02 00 - 64 MOD [FL] Resonance 0 - 100 * 01 40 $ 00 00 02 00 - 64 MOD [FL] Separate 0 - 100 * 01 42 $ 00 00 02 00 - 64 MOD [FL] Gate * 01 44 $ 00 00 02 MOD [FL] dummy * 01 38 $ 00 00 02 00 MOD [CE] Polarity SYNC

* 01 3A $ 0000 02 00 - 64 MOD [CE] Rate 0 - 100

* 01 3C $ 0000 02 00 - 64 MOD [CE] Depth 0 - 100 * 01 3E $ 00 00 02 00 - 50 MOD [CE] Pre Delay 0.0 - 40.0 [ms] (step=0.5) * 01 40 $ 00 00 02 00 - 0A MOD [CE] Low Cut (refer to Table-22.[LOCUT2]) * 01 42 $ 00 00 02 00 - 09 MOD [CE] High Cut (refer to Table-16.[HICUT]) * 01 44 $ 00 00 02 00 - 64 MOD [CE] Effect Level 0 - 100 * 01 46 $ 00 00 02 MOD [CE] dummy * 01 38 $ 00 00 02 00 - 13 MOD [SL] Pattern P1 - P20 * 01 3A $ 0000 02 00 - 64 MOD [SL] Rate 0 - 100

* 01 3C $ 0000 02 00 - 64 MOD [SL] Trigger Sens 0 - 100 * 01 48 00 00 02 00 DELAY Effect On/Off OFF

* 01 4A 00 00 02 00 - 78 DELAY FX Level 0 - 120 * 01 4C 00 00 02 00 - 64 DELAY Dir Level 0 - 100 * 01 4E 00 00 02 00 - 32 DELAY High DampGain -50 - 0 [dB] * 01 50 00 00 02 00 - 09 DELAY High Cut Filter (refer to Table-16.[HICUT]) * 01 52 00 00 02 DELAY dummy * 01 54 00 00 02 00 - 46 DELAY Delay Time L 0 - 1400 [ms] (step=20)

* 01 56 00 00 02 00 - 14 DELAY Fine Time L 0 - 20 [ms] * 01 58 00 00 02 00 - 64 DELAY Feedbk L 0 - 100 * 01 5A 00 00 02 DELAY dummy * 01 5C 00 00 02 00 - 46 DELAY Delay Time R 0 - 1400 [ms] (step=20)

* 01 5E 00 00 02 00 - 14 DELAY Fine Time R 0 - 20 [ms] * 01 60 00 00 02 00 - 64 DELAY Feedbk R 0 - 100 * 01 62 00 00 02 DELAY dummy * 01 64 00 00 02 MASTER dummy * 01 66 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 68 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 01 6A 00 00 02 00 - 64 MASTER Foot Level 0 - 100

01 ON

01 FL

02 CE

03 SL

01 6STAGE

02 8STAGE

03 10STAGE

04 12STAGE

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 INVERT

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 ON

47 - 53 BPM 1/4 - 4.0 (refer to Table-4.[BPMPARAM4])

FB MIDI

FC GLOBAL

<<< KEYBOARD MULTI >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 RING Effect On/Off OFF

* 01 26 00 00 02 00 - 64 RING Freq 0 - 100 * 01 28 00 00 02 00 - 64 RING FX Level 0 - 100 * 01 2A 00 00 02 00 - 64 RING Dir Level 0 - 100 * 01 2C 00 00 02 00 EQ Effect On/Off OFF

* 01 2E 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 30 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 32 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 34 00 00 02 00 - 28 EQ Lo-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM])

01 ON

21

MIDI インプリメンテーション

* 01 36 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 38 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 3A 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 3C 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 3E 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 40 00 00 02 00 NS Effect On/Off OFF

01 ON * 01 42 00 00 02 00 - 64 NS Threshold 0 - 100 * 01 44 00 00 02 00 - 64 NS Release 0 - 100 * 01 46 00 00 02 NS dummy * 01 48 00 00 02 00 PS Effect On/Off OFF

01 ON * 01 4A 00 00 02 00 PS Mode FAST

01 MEDIUM

02 SLOW * 01 4C 00 00 02 00 - 30 PS Pitch -24 - +24 * 01 4E 00 00 02 00 - 64 PS Fine -50 - +50 * 01 50 00 00 02 00 - C8 PS Balance Dir:FX 100:0- 0:100 * 01 52 00 00 02 00 - 64 PS Level 0 - 100 * 01 54 00 00 02 00 MOD Effect On/Off OFF

01 ON * 01 56 00 00 02 00 MOD FX Select FL

01 PH * 01 58 $ 00 00 02 00 - 64 MOD [FL] Rate 0 - 100

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1]) * 01 5A $ 0000 02 00 - 64 MOD [FL] Depth 0 - 100 * 01 5C $ 0000 02 00 - 64 MOD [FL] Manual 0 - 100 * 01 5E $ 00 00 02 00 - 64 MOD [FL] Resonance 0 - 100 * 01 60 $ 00 00 02 00 - 64 MOD [FL] Separate 0 - 100 * 01 58 $ 00 00 02 00 - 64 MOD [PH] Rate 0 - 100

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1]) * 01 5A $ 0000 02 00 - 64 MOD [PH] Depth 0 - 100 * 01 5C $ 0000 02 00 - 64 MOD [PH] Manual 0 - 100 * 01 5E $ 00 00 02 00 - C8 MOD [PH] Resonance -100 - +100 * 01 60 $ 00 00 02 00 - 64 MOD [PH] Separate 0 - 100 * 01 62 00 00 02 MOD dummy * 01 64 00 00 02 00 DELAY Effect On/Off OFF

01 ON * 01 66 00 00 02 00 - 28 DELAY Delay Time 0 - 800 [ms] (step=20)

29 - 35 BPM 1/4 - 4.0 (refer to Table-2.[BPMPARAM2]) * 01 68 00 00 02 00 - 14 DELAY Fine Time 0 - 20 [ms] * 01 6A 00 00 02 00 - 64 DELAY Feedback 0 - 100 * 01 6C 00 00 02 00 - 78 DELAY FX Level 0 - 120 * 01 6E 00 00 02 DELAY dummy * 01 70 00 00 02 00 CHORUS Effect On/Off OFF

01 ON * 01 72 00 00 02 00 CHORUS Polarity SYNC

01 INVERT * 01 74 00 00 02 00 - 64 CHORUS Rate 0 - 100

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1]) * 01 76 00 00 02 00 - 64 CHORUS Depth 0 - 100 * 01 78 00 00 02 00 - 50 CHORUS Pre Delay 0.0 - 40.0 [ms] (step=0.5) * 01 7A 00 00 02 CHORUS dummy * 01 7C 00 00 02 00 - 09 CHORUS High Cut (refer to Table-16.[HICUT]) * 01 7E 00 00 02 00 - 64 CHORUS Effect Level 0 - 100 * 02 00 00 00 02 CHORUS dummy * 02 02 00 00 02 CHORUS dummy * 02 04 00 00 02 00 TREMOLO EffectOn/Off OFF

01 ON * 02 06 00 00 02 00 TREMOLO FX Select TREMOLO

01 PAN * 02 08 00 00 02 00 - 64 TREMOLO Wave Shape 0 - 100 * 02 0A 00 00 02 00 - 64 TREMOLO Rate 0 - 100

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1]) * 02 0C 00 00 02 00 - 64 TREMOLO Depth 0 - 100 * 02 0E 00 00 02 TREMOLO dummy * 02 10 00 00 02 00 REVERB Effect On/Off OFF

01 ON * 02 12 00 00 02 00 REVERB Type ROOM 1

01 ROOM 2

02 HALL 1

03 HALL 2

04 PLATE * 02 14 00 00 02 01 - 64 REVERB Reverb Time 0.1 - 10.0 [s] * 02 16 00 00 02 00 - 64 REVERB Pre Delay 0 - 100 [ms] * 02 18 00 00 02 00 - 09 REVERB Low Cut (refer to Table-17.[LOCUT]) * 02 1A 00 00 02 00 - 09 REVERB High Cut (refer to Table-16.[HICUT]) * 02 1C 00 00 02 00 - 0A REVERB Density 0 - 10 * 02 1E 00 00 02 00 - 64 REVERB FX Level 0 - 100

22

MIDI インプリメンテーション

* 02 20 00 00 02 MASTER dummy * 02 22 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 02 24 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 02 26 00 00 02 00 - 64 MASTER Foot Level 0 - 100

<<< LOFI PROCESSOR >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 EQ Effect On/Off OFF

* 01 26 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 28 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 2A 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 2C 00 00 02 00 - 28 EQ Lo-Mi EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 2E 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 30 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 32 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 34 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 36 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 38 00 00 02 00 BOX Effect On/Off OFF

* 01 3A 00 00 02 00 BOX FX Select RADIO

* 01 3C $ 0000 02 00 - 64 BOX [RADIO]Tuning 0 - 100 * 01 3E $ 00 00 02 00 - 64 BOX [RADIO]Noise 0 - 100 * 01 40 $ 00 00 02 00 - 64 BOX [RADIO]Filter 0 - 100 * 01 42 $ 00 00 02 00 - 64 BOX [RADIO]Sound 0 - 100 * 01 3C $ 0000 02 00 - 64 BOX [PLAYER]Wow Flutter 0 - 100 * 01 3E $ 00 00 02 00 - 64 BOX [PLAYER]Noise 0 - 100 * 01 40 $ 00 00 02 00 - 64 BOX [PLAYER]Filter 0 - 100 * 01 42 $ 00 00 02 00 - 64 BOX [PLAYER]Sound 0 - 100 * 01 3C $ 0000 02 00 BOX [PROCESSOR]Pre Filter OFF

* 01 3E $ 00 00 02 00 - 1F BOX [PROCESSOR]Sample Rate OFF, 1/2 - 1/32 * 01 40 $ 00 00 02 00 - 0F BOX [PROCESSOR]Bit OFF, 15 bit - 1bit * 01 42 $ 00 00 02 00 BOX [PROCESSOR]Post Filter OFF

* 01 44 $ 00 00 02 00 - 64 BOX [PROCESSOR]FX Level 0 - 100 * 01 46 $ 00 00 02 00 - 64 BOX [PROCESSOR]Dir Level 0 - 100 * 01 48 $ 00 00 02 00 BOX [PROCESSOR]R M F OFF

* 01 4A $ 0000 02 00 - 64 BOX [PROCESSOR]Cut Off 0 - 100 * 01 4C $ 0000 02 00 - 64 BOX [PROCESSOR]Resonance 0 - 100 * 01 4E $ 00 00 02 00 - 18 BOX [PROCESSOR]Gain 0 - 24 [dB] * 01 50 00 00 02 00 NS Effect On/Off OFF

* 01 52 00 00 02 00 - 64 NS Threshold 0 - 100 * 01 54 00 00 02 00 - 64 NS Release 0 - 100 * 01 56 00 00 02 NS dummy * 01 58 00 00 02 MASTER dummy * 01 5A 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 5C 00 00 02 MASTER dummy * 01 5E 00 00 02 00 - 64 MASTER Foot Level 0 - 100

FB MIDI

FC GLOBAL

01 ON

01 PLAYER

02 PROCESSOR

01 ON

01 LPF

02 BPF

03 HPF

01 ON

<<< MIC SIMULATOR >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 MCVL EffectOn/Off OFF

* 01 26 00 00 02 00 MCVL Input DR-20

* 01 28 00 00 02 00 MCVL Output SML.DY

* 01 2A 00 00 02 00 MCVL Phase NOR

* 01 2C 00 00 02 00 BCTL Effect On/Off OFF

01 ON

01 SML.DY

02 HED.DY

03 MIN.CN

04 FLAT

01 VOC.DY

02 LRG.DY

03 SML.CN

04 LRG.CN

05 VNT.CN

06 FLAT

01 INV

23

MIDI インプリメンテーション

* 01 2E 00 00 02 01 BCTL Frequency THRU

* 01 30 00 00 02 00 DSTL Effect On/Off OFF

* 01 32 00 00 02 00 - 18 DSTL Prox.Fx -12 - +12 * 01 34 00 00 04 0000- 0BB8 DSTL Time 0 - 3000 [cm] * 01 38 00 00 02 00 LIMITL Effect On/Off OFF

* 01 3A 00 00 02 00 - 3C LIMITL Threshold -60 - 0 [dB] * 01 3C 00 00 02 00 - 64 LIMITL Attack 0 - 100 * 01 3E 00 00 02 00 - 64 LIMITL Release 0 - 100 * 01 40 00 00 02 01 LIMITL Detect HPF THRU

* 01 42 00 00 02 00 - 40 LIMITL Level -60 - +4 [dB] * 01 44 00 00 02 00 MCVR Effect On/Off OFF

* 01 46 00 00 02 00 MCVR Input DR-20

* 01 48 00 00 02 00 MCVR Output SML.DY

* 01 4A 00 00 02 00 MCVR Phase NOR

* 01 4C 00 00 02 00 BCTR Effect On/Off OFF

* 01 4E 00 00 02 01 BCTR Frequency THRU

* 01 50 00 00 02 00 DSTR Effect On/Off OFF

* 01 52 00 00 02 00 - 18 DSTR Prox.Fx -12 - +12 * 01 54 00 00 04 0000- 0BB8 DSTR Time 0 - 3000 [cm] * 01 58 00 00 02 00 LIMITR Effect On/Off OFF

* 01 5A 00 00 02 00 - 3C LIMITR Threshold -60 - 0 [dB] * 01 5C 00 00 02 00 - 64 LIMITR Attack 0 - 100 * 01 5E 00 00 02 00 - 64 LIMITR Release 0 - 100 * 01 60 00 00 02 01 LIMITR Detect HPF THRU

* 01 62 00 00 02 00 - 40 LIMITR Level -60 - +4 [dB] * 01 64 00 00 02 MASTER dummy * 01 66 00 00 02 00 MASTER Link OFF

* 01 68 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 6A 00 00 02 MASTER dummy * 01 6C 00 00 02 00 - 64 MASTER Foot Level 0 - 100 * 01 6E 00 00 02 MASTER dummy

01 ON

02 - C8 20- 2000 [Hz] (step=10)

01 ON

02 - C8 20- 2000 [Hz] (step=10)

01 ON

01 SML.DY

02 HED.DY

03 MIN.CN

04 FLAT

01 VOC.DY

02 LRG.DY

03 SML.CN

04 LRG.CN

05 VNT.CN

06 FLAT

01 INV

01 ON

02 - C8 20- 2000 [Hz] (step=10)

01 ON

02 - C8 20- 2000 [Hz] (step=10)

01 ON

<<< MULTI TAPDELAY >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 EQ Effect On/Off OFF

* 01 26 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 28 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 2A 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 2C 00 00 02 00 - 28 EQ Lo-Mi EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 2E 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 30 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 32 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 34 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 36 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 38 00 00 02 00 DLY Effect On/Off OFF

* 01 3A 00 00 02 01 - 64 DLY Ratio 1 - 100 [%] * 01 3C 00 00 02 00 - 8C DLY FB Delay 1 - 2800 [ms] * 01 3E 00 00 02 00 - 14 DLY FB Fine 0 - 20 [ms] * 01 40 00 00 02 00 - 64 DLY FB Level 0 - 100 * 01 42 00 00 02 00 - 0A DLY Low Cut (refer to Table-22.[LOCUT2]) * 01 44 00 00 02 00 - 09 DLY High Cut (refer to Table-16.[HICUT]) * 01 46 00 00 02 00 - 78 DLY FX Level 0 - 120 * 01 48 00 00 02 00 - 64 DLY Dir Level 0 - 100

01 ON

24

MIDI インプリメンテーション

* 01 4A 00 00 02 DLY dummy * 01 4C 00 00 02 00 - 8C DLY DelayTime1 0 - 2800 [ms] (step=20)

* 01 4E 00 00 02 00 - 14 DLY Fine Time 1 0 - 20 [ms] * 01 50 00 00 02 00 - 64 DLY Pan1 L100:R0- L0:R100 * 01 52 00 00 02 00 - 64 DLY Tap Level1 0 - 100 * 01 54 00 00 02 00 - 8C DLY Delay Time2 0 - 2800 [ms] (step=20)

* 01 56 00 00 02 00 - 14 DLY Fine Time 2 0 - 20 [ms] * 01 58 00 00 02 00 - 64 DLY Pan2 L100:R0- L0:R100 * 01 5A 00 00 02 00 - 64 DLY Tap Level2 0 - 100 * 01 5C 00 00 02 00 - 8C DLY DelayTime3 0 - 2800 [ms] (step=20)

* 01 5E 00 00 02 00 - 14 DLY Fine Time 3 0 - 20 [ms] * 01 60 00 00 02 00 - 64 DLY Pan3 L100:R0- L0:R100 * 01 62 00 00 02 00 - 64 DLY Tap Level3 0 - 100 * 01 64 00 00 02 00 - 8C DLY Delay Time4 0 - 2800 [ms] (step=20)

* 01 66 00 00 02 00 - 14 DLY Fine Time 4 0 - 20 [ms] * 01 68 00 00 02 00 - 64 DLY Pan4 L100:R0- L0:R100 * 01 6A 00 00 02 00 - 64 DLY Tap Level4 0 - 100 * 01 6C 00 00 02 00 - 8C DLY DelayTime5 0 - 2800 [ms] (step=20)

* 01 6E 00 00 02 00 - 14 DLY Fine Time 5 0 - 20 [ms] * 01 70 00 00 02 00 - 64 DLY Pan5 L100:R0- L0:R100 * 01 72 00 00 02 00 - 64 DLY Tap Level5 0 - 100 * 01 74 00 00 02 00 - 8C DLY Delay Time6 0 - 2800 [ms] (step=20)

* 01 76 00 00 02 00 - 14 DLY Fine Time6 0 - 20 [ms] * 01 78 00 00 02 00 - 64 DLY Pan6 L100:R0- L0:R100 * 01 7A 00 00 02 00 - 64 DLY Tap Level6 0 - 100 * 01 7C 00 00 02 00 - 8C DLY DelayTime7 0 - 2800 [ms] (step=20)

* 01 7E 00 00 02 00 - 14 DLY Fine Time 7 0 - 20 [ms] * 02 00 00 00 02 00 - 64 DLY Pan7 L100:R0- L0:R100 * 02 02 00 00 02 00 - 64 DLY Tap Level7 0 - 100 * 02 04 00 00 02 00 - 8C DLY Delay Time8 0 - 2800 [ms] (step=20)

* 02 06 00 00 02 00 - 14 DLY Fine Time 8 0 - 20 [ms] * 02 08 00 00 02 00 - 64 DLY Pan8 L100:R0- L0:R100 * 02 0A 00 00 02 00 - 64 DLY Tap Level8 0 - 100 * 02 0C 00 00 02 00 - 8C DLY DelayTime9 0 - 2800 [ms] (step=20)

* 02 0E 00 00 02 00 - 14 DLY Fine Time 9 0 - 20 [ms] * 02 10 00 00 02 00 - 64 DLY Pan9 L100:R0- L0:R100 * 02 12 00 00 02 00 - 64 DLY Tap Level9 0 - 100 * 02 14 00 00 02 00 - 8C DLY Delay Time10 0 - 2800 [ms] (step=20)

* 02 16 00 00 02 00 - 14 DLY Fine Time 10 0 - 20 [ms] * 02 18 00 00 02 00 - 64 DLY Pan10 L100:R0- L0:R100 * 02 1A 00 00 02 00 - 64 DLY Tap Level10 0 - 100 * 02 1C 00 00 02 00 - 8C DLY DelayTime11 0 - 2800 [ms] (step=20)

* 02 1E 00 00 02 00 - 14 DLY Fine Time 11 0 - 20 [ms] * 02 20 00 00 02 00 - 64 DLY Pan11 L100:R0- L0:R100 * 02 22 00 00 02 00 - 64 DLY Tap Level11 0 - 100 * 02 24 00 00 02 00 - 8C DLY Delay Time12 0 - 2800 [ms] (step=20)

* 02 26 00 00 02 00 - 14 DLY Fine Time 12 0 - 20 [ms] * 02 28 00 00 02 00 - 64 DLY Pan12 L100:R0- L0:R100 * 02 2A 00 00 02 00 - 64 DLY Tap Level12 0 - 100 * 02 2C 00 00 02 00 - 8C DLY DelayTime13 0 - 2800 [ms] (step=20)

* 02 2E 00 00 02 00 - 14 DLY Fine Time 13 0 - 20 [ms] * 02 30 00 00 02 00 - 64 DLY Pan13 L100:R0- L0:R100 * 02 32 00 00 02 00 - 64 DLY Tap Level13 0 - 100 * 02 34 00 00 02 00 - 8C DLY Delay Time14 0 - 2800 [ms] (step=20)

* 02 36 00 00 02 00 - 14 DLY Fine Time 14 0 - 20 [ms] * 02 38 00 00 02 00 - 64 DLY Pan14 L100:R0- L0:R100 * 02 3A 00 00 02 00 - 64 DLY Tap Level14 0 - 100 * 02 3C 00 00 02 00 - 8C DLY DelayTime15 0 - 2800 [ms] (step=20)

* 02 3E 00 00 02 00 - 14 DLY Fine Time 15 0 - 20 [ms] * 02 40 00 00 02 00 - 64 DLY Pan15 L100:R0- L0:R100 * 02 42 00 00 02 00 - 64 DLY Tap Level15 0 - 100 * 02 44 00 00 02 00 - 8C DLY Delay Time16 0 - 2800 [ms] (step=20)

* 02 46 00 00 02 00 - 14 DLY Fine Time 16 0 - 20 [ms]

8D - 99 BPM 1/4 - 4.0 (refer to Table-6.[BPMPARAM6])

25

MIDI インプリメンテーション

* 02 48 00 00 02 00 - 64 DLY Pan16 L100:R0- L0:R100 * 02 4A 00 00 02 00 - 64 DLY Tap Level16 0 - 100 * 02 4C 00 00 02 00 - 8C DLY DelayTime17 0 - 2800 [ms] (step=20)

* 02 4E 00 00 02 00 - 14 DLY Fine Time 17 0 - 20 [ms] * 02 50 00 00 02 00 - 64 DLY Pan17 L100:R0- L0:R100 * 02 52 00 00 02 00 - 64 DLY Tap Level17 0 - 100 * 02 54 00 00 02 00 - 8C DLY Delay Time18 0 - 2800 [ms] (step=20)

* 02 56 00 00 02 00 - 14 DLY Fine Time 18 0 - 20 [ms] * 02 58 00 00 02 00 - 64 DLY Pan18 L100:R0- L0:R100 * 02 5A 00 00 02 00 - 64 DLY Tap Level18 0 - 100 * 02 5C 00 00 02 00 - 8C DLY DelayTime19 0 - 2800 [ms] (step=20)

* 02 5E 00 00 02 00 - 14 DLY Fine Time 19 0 - 20 [ms] * 02 60 00 00 02 00 - 64 DLY Pan19 L100:R0- L0:R100 * 02 62 00 00 02 00 - 64 DLY Tap Level19 0 - 100 * 02 64 00 00 02 00 - 8C DLY Delay Time20 0 - 2800 [ms] (step=20)

* 02 66 00 00 02 00 - 14 DLY Fine Time 20 0 - 20 [ms] * 02 68 00 00 02 00 - 64 DLY Pan20 L100:R0- L0:R100 * 02 6A 00 00 02 00 - 64 DLY Tap Level20 0 - 100 * 02 6C 00 00 02 MASTER dummy * 02 6E 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 02 70 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 02 72 00 00 02 00 - 64 MASTER Foot Level 0 - 100

8D - 99 BPM 1/4 - 4.0 (refer to Table-6.[BPMPARAM6])

FB MIDI

FC GLOBAL

<<< REVERB 1 >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 EQ Effect On/Off OFF

* 01 26 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 28 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 2A 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 2C 00 00 02 00 - 28 EQ Lo-Mi EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 2E 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 30 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 32 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 34 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 36 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 38 00 00 02 00 REVERB Effect On/Off OFF

* 01 3A 00 00 02 REVERB dummy * 01 3C 00 00 04 0038- 0146 REVERB Room Size 5.6 - 32.6 [m] * 01 40 00 00 04 0001- 0140 REVERB Reverb Time 0.1 - 32.0 [s] * 01 44 00 00 02 00 - C8 REVERB Balance Dir:FX 100:0 - 0:100 * 01 46 00 00 02 00 - 64 REVERB Effect Level 0 - 100 * 01 48 00 00 02 00 - C8 REVERB Pre Delay 0 - 200 [ms] * 01 4A 00 00 02 00 - 64 REVERB Density 0 - 100 * 01 4C 00 00 02 00 - 64 REVERB ER Level 0 - 100 * 01 4E 00 00 02 00 - 64 REVERB Release Density 0 - 100 * 01 50 00 00 02 00 - 30 REVERB Low Damp Gain (refer to Table-24.[DAMPGAIN]) * 01 52 00 00 02 00 - 10 REVERB Low Damp Freq (refer to Table-25.[LODMP]) * 01 54 00 00 02 00 - 30 REVERB High Damp Gain (refer to Table-24.[DAMPGAIN]) * 01 56 00 00 02 00 - 10 REVERB High Damp Freq (refer to Table-26.[HIDMP]) * 01 58 00 00 02 00 - 21 REVERB High Cut Filter (refer to Table-27.[REVHICUT]) * 01 5A 00 00 02 REVERB dummy * 01 5C 00 00 02 00 DELAY EffectOn/Off OFF

* 01 5E 00 00 02 00 DELAY Type SINGLE

* 01 60 $ 00 00 02 00 - 5A DELAY [SINGLE]Delay Time 0 - 1800 [ms] (step=20)

* 01 62 $ 00 00 02 00 - 14 DELAY [SINGLE]Fine Time 0 - 20 [ms] * 01 60 $ 00 00 02 00 - 5A DELAY [3TAP]Delay Time C 0 - 1800 [ms] (step=20)

* 01 62 $ 00 00 02 00 - 14 DELAY [3TAP]Fine Time C 0 - 20 [ms] * 01 64 $ 00 00 04 0001- 0190 DELAY [3TAP]Time L 1 - 400 [%] * 01 68 $ 00 00 04 0001- 0190 DELAY [3TAP]Time R 1 - 400 [%] * 01 6C 00 00 02 00 - 64 DELAY Feedback 0 - 100 * 01 6E 00 00 02 00 - 64 DELAY Level C 0 - 100 * 01 70 00 00 02 00 - 64 DELAY Level L 0 - 100 * 01 72 00 00 02 00 - 64 DELAY Level R 0 - 100 * 01 74 00 00 02 00 - 78 DELAY FX Level 0 - 120 * 01 76 00 00 02 DELAY dummy * 01 78 00 00 02 00 - 32 DELAY High Damp Gain -50 - 0 [dB]

01 ON

01 3TAP

5B - 67 BPM 1/4 - 4.0 (refer to Table-5.[BPMPARAM5])

26

MIDI インプリメンテーション

* 01 7A 00 00 02 00 - 09 DELAY High Cut Filter (refer to Table-16.[HICUT]) * 01 7C 00 00 02 DELAY dummy * 01 7E 00 00 02 DELAY dummy * 02 00 00 00 02 MASTER dummy * 02 02 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 02 04 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 02 06 00 00 02 00 - 64 MASTER Foot Level 0 - 100

<<< REVERB 2 >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 EQ Effect On/Off OFF

* 01 26 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 28 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 2A 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 2C 00 00 02 00 - 28 EQ Lo-Mi EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 2E 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 30 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 32 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 34 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 36 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 38 00 00 02 00 REVERB Effect On/Off OFF

* 01 3A 00 00 02 00 REVERB Reverb Type ROOM

* 01 3C 00 00 04 0000- 0009 REVERB Room Size 1 - 10 * 01 40 00 00 04 0001- 0140 REVERB Reverb Time 0.1 - 32.0 [s] * 01 44 00 00 02 00 - C8 REVERB Balance Dir:FX 100:0 - 0:100 * 01 46 00 00 02 00 - 64 REVERB Effect Level 0 - 100 * 01 48 00 00 02 00 - C8 REVERB Pre Delay 0 - 200 [ms] * 01 4A 00 00 02 00 - 64 REVERB Density 0 - 100 * 01 4C 00 00 02 00 - 64 REVERB ER Level 0 - 100 * 01 4E 00 00 02 REVERB dummy * 01 50 00 00 02 00 - 30 REVERB Low Damp Gain (refer to Table-24.[DAMPGAIN]) * 01 52 00 00 02 00 - 10 REVERB Low Damp Freq (refer to Table-25.[LODMP]) * 01 54 00 00 02 00 - 30 REVERB High Damp Gain (refer to Table-24.[DAMPGAIN]) * 01 56 00 00 02 00 - 10 REVERB High Damp Freq (refer to Table-26.[HIDMP]) * 01 58 00 00 02 00 - 21 REVERB High Cut Filter (refer to Table-27.[REVHICUT]) * 01 5A 00 00 02 REVERB dummy * 01 5C 00 00 02 00 CHORUS Effect On/Off OFF

* 01 5E 00 00 02 00 CHORUS Polarity SYNC

* 01 60 00 00 02 00 - 64 CHORUS Rate 0 - 100

* 01 62 00 00 02 00 - 64 CHORUS Depth 0 - 100 * 01 64 00 00 02 00 - 50 CHORUS Pre Delay 0.0 - 40.0 [ms] (step=0.5) * 01 66 00 00 02 00 - 0A CHORUS Low Cut (refer to Table-22.[LOCUT2]) * 01 68 00 00 02 00 - 09 CHORUS High Cut (refer to Table-16.[HICUT]) * 01 6A 00 00 02 00 - 64 CHORUS Effect Level 0 - 100 * 01 6C 00 00 02 00 CHORUS Direct On/Off OFF

* 01 6E 00 00 02 CHORUS dummy * 01 70 00 00 02 MASTER dummy * 01 72 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 74 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 01 76 00 00 02 00 - 64 MASTER Foot Level 0 - 100

FB MIDI

FC GLOBAL

01 ON

01 HALL

01 ON

01 INVERT

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 ON

FB MIDI

FC GLOBAL

<<< REVERB RSS >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 EQ Effect On/Off OFF

* 01 26 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 28 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 2A 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 2C 00 00 02 00 - 28 EQ Lo-Mi EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 2E 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 30 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 32 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 34 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 36 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 38 00 00 02 00 REVERB Effect On/Off OFF

01 ON

27

MIDI インプリメンテーション

* 01 3A 00 00 02 00 REVERB Type ROOM

* 01 3C 00 00 04 00 - 09 REVERB Size 1 - 10 * 01 40 00 00 04 0001- 0140 REVERB Reverb Time 0.1 - 32.0 [s] * 01 44 00 00 02 00 - C8 REVERB Balance Dir:FX 100:0 - 0:100 * 01 46 00 00 02 00 - 64 REVERB Level 0 - 100 * 01 48 00 00 02 00 - C8 REVERB Pre Delay 0 - 200 [ms] * 01 4A 00 00 02 00 - 64 REVERB Density 0 - 100 * 01 4C 00 00 02 00 - 64 REVERB ER Level 0 - 100 * 01 4E 00 00 02 REVERB dummy * 01 50 00 00 02 00 - 30 REVERB Low Damp Gain (refer to Table-24.[DAMPGAIN]) * 01 52 00 00 02 00 - 10 REVERB Low Damp Freq (refer to Table-25.[LODMP]) * 01 54 00 00 02 00 - 30 REVERB High Damp Gain (refer to Table-24.[DAMPGAIN]) * 01 56 00 00 02 00 - 10 REVERB High Damp Freq (refer to Table-26.[HIDMP]) * 01 58 00 00 02 00 - 21 REVERB High Cut Filter (refer to Table-27.[REVHICUT]) * 01 5A 00 00 02 00 REVERB RSS On/Off OFF

* 01 5C 00 00 02 MASTER dummy * 01 5E 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 60 00 00 02 MASTER dummy * 01 62 00 00 02 00 - 64 MASTER Foot Level 0 - 100

01 HALL

01 ON

<<< REVERB +REVERB >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 EQL EffectOn/Off OFF

* 01 26 00 00 02 00 - 28 EQL Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 28 00 00 02 00 - 14 EQL Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 2A 00 00 02 00 - 05 EQL Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 2C 00 00 02 00 - 28 EQL Lo-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 2E 00 00 02 00 - 14 EQL Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 30 00 00 02 00 - 05 EQL Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 32 00 00 02 00 - 28 EQL Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 34 00 00 02 00 - 28 EQL High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 36 00 00 02 00 - 28 EQL Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 38 00 00 02 00 EQR Effect On/Off OFF

* 01 3A 00 00 02 00 - 28 EQR Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 3C 00 00 02 00 - 14 EQR Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 3E 00 00 02 00 - 05 EQR Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 40 00 00 02 00 - 28 EQR Lo-MidEQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 42 00 00 02 00 - 14 EQR Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 44 00 00 02 00 - 05 EQR Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 46 00 00 02 00 - 28 EQR Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 48 00 00 02 00 - 28 EQR High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 4A 00 00 02 00 - 28 EQR Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 4C 00 00 02 00 RVL Effect On/Off OFF

* 01 4E 00 00 02 00 RVL Type ROOM

* 01 50 00 00 04 0000- 0009 RVL Size 1 - 10 * 01 54 00 00 04 0001- 0140 RVL Reverb Time 0.1 - 32.0 [s] * 01 58 00 00 02 00 - C8 RVL Balance Dir:FX 100:0 - 0:100 * 01 5A 00 00 02 00 - 64 RVL Effect Level 0 - 100 * 01 5C 00 00 02 00 - C8 RVL Pre Delay 0 - 200 [ms] * 01 5E 00 00 02 00 - 64 RVL Density 0 - 100 * 01 60 00 00 02 00 - 64 RVL ER Level 0 - 100 * 01 62 00 00 02 RVL dummy * 01 64 00 00 02 00 - 30 RVL Low Damp Gain (refer to Table-24.[DAMPGAIN]) * 01 66 00 00 02 00 - 10 RVL Low Damp Freq (refer to Table-25.[LODMP]) * 01 68 00 00 02 00 - 30 RVL High Damp Gain (refer to Table-24.[DAMPGAIN]) * 01 6A 00 00 02 00 - 10 RVL High Damp Freq (refer to Table-26.[HIDMP]) * 01 6C 00 00 02 00 - 21 RVL High Cut Filter (refer to Table-27.[REVHICUT]) * 01 6E 00 00 02 RVL dummy * 01 70 00 00 02 00 RVR Effect On/Off OFF

* 01 72 00 00 02 00 RVR Type ROOM 1

* 01 74 00 00 02 01 - 64 RVR Reverb Time 0.1 - 10.0 [s] * 01 76 00 00 02 00 - C8 RVR Balance DIR:FX 100:0 - 0:100 * 01 78 00 00 02 00 - 64 RVR Effect Level 0 - 100 * 01 7A 00 00 02 00 - 64 RVR Pre Delay 0 - 100 [ms] * 01 7C 00 00 02 00 - 0A RVR Density 0 - 10 * 01 7E 00 00 02 00 - 0A RVR Low Cut (refer to Table-22.[LOCUT2]) * 02 00 00 00 02 00 - 09 RVR High Cut (refer to Table-16.[HICUT])

01 ON

01 HALL

01 ON

01 ROOM 2

02 HALL 1

03 HALL 2

04 PLATE

28

MIDI インプリメンテーション

* 02 02 00 00 02 RVR dummy * 02 04 00 00 02 MASTER dummy * 02 06 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 02 08 00 00 02 MASTER dummy * 02 0A 00 00 02 00 - 64 MASTER Foot Level 0 - 100

<<< ROTARY MULTI >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 EQ Effect On/Off OFF

* 01 26 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 28 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 2A 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 2C 00 00 02 00 - 28 EQ Lo-Mi EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 2E 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 30 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 32 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 34 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 36 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 38 00 00 02 00 ODV Effect On/Off OFF

* 01 3A 00 00 02 00 - 64 ODV Gain 0 - 100 * 01 3C 00 00 02 01 - 64 ODV Drive 1 - 100 * 01 3E 00 00 02 00 - 64 ODV Level 0 - 100 * 01 40 00 00 02 00 ROTARY EffectOn/Off OFF

* 01 42 00 00 02 00 ROTARY Speed Select SLOW

* 01 44 00 00 04 01F4- 03E8 ROTARY Horn Fast 5.00 - 10.00 [Hz] * 01 48 00 00 04 01F4- 03E8 ROTARY Rotor Fast 5.00 - 10.00 [Hz] * 01 4C 00 00 04 0005- 01F4 ROTARY Horn Slow 0.05 - 5.00 [Hz] * 01 50 00 00 04 0005- 01F4 ROTARY Rotor Slow 0.05 - 5.00 [Hz] * 01 54 00 00 02 01 - 64 ROTARY Rise Time Horn 1 - 100 * 01 56 00 00 02 01 - 64 ROTARY Rise Time Rotor 1 - 100 * 01 58 00 00 02 01 - 64 ROTARY Fall Time Horn 1 - 100 * 01 5A 00 00 02 01 - 64 ROTARY Fall Time Rotor 1 - 100 * 01 5C 00 00 02 0A - 5A ROTARY R:H Balance 90:10 - 10:90 * 01 5E 00 00 02 00 ROTARY Mic Setting OFF MIC

* 01 60 00 00 02 00 - 64 ROTARY Horn Depth 0 - 100 * 01 62 00 00 02 00 - 64 ROTARY Rotor Depth 0 - 100 * 01 64 00 00 02 00 - 64 ROTARY Horn Trmlo 0 - 100 * 01 66 00 00 02 00 - 64 ROTARY Rotor Trmlo 0 - 100 * 01 68 00 00 02 00 - 64 ROTARY Diffusion 0 - 100 * 01 6A 00 00 02 00 - 64 ROTARY FX Level 0 - 100 * 01 6C 00 00 02 00 NS Effect On/Off OFF

* 01 6E 00 00 02 00 - 64 NS Threshold 0 - 100 * 01 70 00 00 02 00 - 64 NS Release 0 - 100 * 01 72 00 00 02 NS dummy * 01 74 00 00 02 00 REVERB Effect On/Off OFF

* 01 76 00 00 02 00 REVERB Type ROOM 1

* 01 78 00 00 02 01 - 64 REVERB Reverb Time 0.1 - 10.0 [s] * 01 7A 00 00 02 00 - 64 REVERB Pre Delay 0 - 100 [ms] * 01 7C 00 00 02 00 - 09 REVERB Low Cut (refer to Table-17.[LOCUT]) * 01 7E 00 00 02 00 - 09 REVERB High Cut (refer to Table-16.[HICUT]) * 02 00 00 00 02 00 - 0A REVERB Density 0 - 10 * 02 02 00 00 02 00 - 64 REVERB FX Level 0 - 100 * 02 04 00 00 02 00 MASTER * 02 06 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 02 08 00 00 02 00 MASTER * 02 0A 00 00 02 00 - 64 MASTER Foot Level 0 - 100

01 ON

01 FAST

01 ON MIC

01 ON

01 ROOM 2

02 HALL 1

03 HALL 2

04 PLATE

<<< RSS PANNER >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 EQ Effect On/Off OFF,

* 01 26 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB], (refer to Table-11.[EQPARAM]), * 01 28 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz], (refer to Table-11.[EQPARAM]), * 01 2A 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16, (refer to Table-11.[EQPARAM]), * 01 2C 00 00 02 00 - 28 EQ Lo-Mi EQ -20 - +20 [dB], (refer to Table-11.[EQPARAM]), * 01 2E 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz], (refer to Table-11.[EQPARAM]),

01 ON,

29

MIDI インプリメンテーション

* 01 30 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16, (refer to Table-11.[EQPARAM]), * 01 32 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB], (refer to Table-11.[EQPARAM]), * 01 34 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB], (refer to Table-11.[EQPARAM]), * 01 36 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]), * 01 38 00 00 02 00 FLANGER EffectOn/Off OFF,

* 01 3A 00 00 02 00 - 64 FLANGER Rate 0 - 100,

* 01 3C 00 00 02 00 - 64 FLANGER Depth 0 - 100, * 01 3E 00 00 02 00 - 64 FLANGER Manual 0 - 100 * 01 40 00 00 02 00 - 64 FLANGER Resonance 0 - 100 * 01 42 00 00 02 FLANGER dummy * 01 44 00 00 02 00 FLANGER Gate OFF

* 01 46 00 00 02 00 FLANGER Direct Switch OFF

* 01 48 00 00 02 00 PANNER Effect On/Off OFF

* 01 4A 00 00 02 00 - 64 PANNER Speed 0 - 100

* 01 4C 00 00 02 00 PANNER Direction CW

* 01 4E 00 00 02 PANNER dummy * 01 50 00 00 02 MASTER dummy * 01 52 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 54 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 01 56 00 00 02 00 - 64 MASTER Foot Level 0 - 100

01 ON,

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1]),

01 - 64 1 - 100

01 ON

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 CCW

FB MIDI

FC GLOBAL

<<< SPACE CHORUS >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 CHORUS Effect On/Off OFF

* 01 26 00 00 02 00 CHORUS Input MONO

* 01 28 00 00 02 00 - 06 CHORUS Mode 1, 2, 3, 4, 1+4, 2+4, 3+4 * 01 2A 00 00 02 00 - 64 CHORUS Effect Level 0 - 100 * 01 2C 00 00 02 00 CHORUS Direct On/Off OFF

* 01 2E 00 00 02 00 CHORUS dummy * 01 30 00 00 02 00 EQ Effect On/Off OFF

* 01 32 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 34 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 36 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 38 00 00 02 00 - 28 EQ Lo-Mi EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 3A 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 3C 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 3E 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 40 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 42 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 44 00 00 02 MASTER dummy * 01 46 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 48 00 00 02 MASTER dummy * 01 4A 00 00 02 00 - 64 MASTER Foot Level 0 - 100

01 ON

01 ST.

01 ON

<<< SPEAKER MODELING>>>

ADDRESS SIZE DATA EFFECTOR PARAMETER DESCRIPTION * 01 24 00 00 02 00 SP MODEL Effect On/Off OFF

* 01 26 00 00 02 00 - 0A SP MODEL Model (refer to Table-32.[MODEL]) * 01 28 00 00 02 00 SP MODEL Phase NOR

* 01 2A 00 00 02 SP MODEL dummy

01 ON

01 INV

* 01 2C 00 00 02 00 BCF Effect On/Off OFF

01 ON * 01 2E 00 00 02 01 BCF Frequency THRU

02 - C8 BCF 20 - 2000 [Hz] (step=10)

* 01 30 00 00 02 00 LMT Effect On/Off OFF

01 ON * 01 32 00 00 02 00 - 18 LMT Gain -12 - +12 * 01 34 00 00 02 00 - 1A LMT Frequency 20 - 2000 [Hz] (refer to Table-33.[LMTFRQ]) * 01 36 00 00 02 LMT dummy

30

MIDI インプリメンテーション

* 01 38 00 00 02 00 HMT Effect On/Off OFF

* 01 3A 00 00 02 00 - 18 HMT Gain -12 - +12 * 01 3C 00 00 02 00 - 12 HMT Frequency 1.0k - 20.0k[Hz] (refer to Table-31.[HMTFRQ]) * 01 3E 00 00 02 HMT dummy

* 01 40 00 00 02 00 LIMIT Effect On/Off OFF

* 01 42 00 00 02 00 - 3C LIMIT Threshold -60 - 0 [dB] * 01 44 00 00 02 00 - 64 LIMIT Release 0 - 100 * 01 46 00 00 02 00 - 54 LIMIT Level -60 - +24 [dB] * 01 48 00 00 02 LIMIT dummy

* 01 4A 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 4C 00 00 02 MASTER dummy * 01 4E 00 00 02 00 - 64 MASTER Level 0 - 100

01 ON

<<< STEREO CHORUSDELAY >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 DELAY Effect On/Off OFF

* 01 26 00 00 02 00 - 78 DELAY FX Level 0 - 120 * 01 28 00 00 02 00 - 64 DELAY Dir Level 0 - 100 * 01 2A 00 00 02 00 - 32 DELAY High DampGain -50 - 0 [dB] * 01 2C 00 00 02 00 - 09 DELAY High Cut Filter (refer to Table-16.[HICUT]) * 01 2E 00 00 02 DELAY dummy * 01 30 00 00 02 00 - 46 DELAY Delay Time L 0 - 1400 [ms] (step=20)

* 01 32 00 00 02 00 - 14 DELAY Fine Time L 0 - 20 [ms] * 01 34 00 00 02 00 - 64 DELAY Feedbk L 0 - 100 * 01 36 00 00 02 DELAY dummy * 01 38 00 00 02 00 - 46 DELAY Delay Time R 0 - 1400 [ms] (step=20)

* 01 3A 00 00 02 00 - 14 DELAY Fine Time R 0 - 20 [ms] * 01 3C 00 00 02 00 - 64 DELAY Feedbk R 0 - 100 * 01 3E 00 00 02 DELAY dummy * 01 40 00 00 02 00 CE Effect On/Off OFF

* 01 42 00 00 02 00 CE Polarity SYNC

* 01 44 00 00 02 00 - 64 CE Rate 0 - 100

* 01 46 00 00 02 00 - 64 CE Depth 0 - 100 * 01 48 00 00 02 00 - 50 CE Pre Delay 0.0 - 40.0 [ms] (step=0.5) * 01 4A 00 00 02 00 - 0A CE Low Cut (refer to Table-22.[LOCUT2]) * 01 4C 00 00 02 00 - 09 CE High Cut (refer to Table-16.[HICUT]) * 01 4E 00 00 02 00 - 64 CE EffectLevel 0 - 100 * 01 50 00 00 02 00 CE Direct On/Off OFF

* 01 52 00 00 02 CE dummy * 01 54 00 00 02 00 EQ Effect On/Off OFF

* 01 56 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 58 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 5A 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 5C 00 00 02 00 - 28 EQ Lo-Mi EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 5E 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 60 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 62 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 64 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 66 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 68 00 00 02 MASTER dummy * 01 6A 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 6C 00 00 02 28 - FA MASTER Master BPM 40 - 250

* 01 6E 00 00 02 00 - 64 MASTER Foot Level 0 - 100

01 ON

47 - 53 BPM 1/4 - 4.0 (refer to Table-4.[BPMPARAM4])

01 ON

01 INVERT

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 ON

FB MIDI

FC GLOBAL

<<< STEREO FLANGER DELAY >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 DELAY Effect On/Off OFF

* 01 26 00 00 02 00 - 78 DELAY FX Level 0 - 120 * 01 28 00 00 02 00 - 64 DELAY Dir Level 0 - 100 * 01 2A 00 00 02 00 - 32 DELAY High DampGain -50 - 0 [dB] * 01 2C 00 00 02 00 - 09 DELAY High Cut Filter (refer to Table-16.[HICUT]) * 01 2E 00 00 02 DELAY dummy

01 ON

31

MIDI インプリメンテーション

* 01 30 00 00 02 00 - 46 DELAY Delay Time L 0 - 1400 [ms] (step=20)

* 01 32 00 00 02 00 - 14 DELAY Fine Time L 0 - 20 [ms] * 01 34 00 00 02 00 - 64 DELAY Feedbk L 0 - 100 * 01 36 00 00 02 DELAY dummy * 01 38 00 00 02 00 - 46 DELAY Delay Time R 0 - 1400 [ms] (step=20)

* 01 3A 00 00 02 00 - 14 DELAY Fine Time R 0 - 20 [ms] * 01 3C 00 00 02 00 - 64 DELAY Feedback R 0 - 100 * 01 3E 00 00 02 DELAY dummy * 01 40 00 00 02 00 FL Effect On/Off OFF

* 01 42 00 00 02 00 - 64 FL Rate 0 - 100

* 01 44 00 00 02 00 - 64 FL Depth 0 - 100 * 01 46 00 00 02 00 - 64 FL Manual 0 - 100 * 01 48 00 00 02 00 - 64 FL Resonance 0 - 100 * 01 4A 00 00 02 00 - 64 FL Separate 0 - 100 * 01 4C 00 00 02 00 - 64 FL Gate OFF, 1 - 100 * 01 4E 00 00 02 00 FL Direct Switch OFF

* 01 50 00 00 02 00 EQ Effect On/Off OFF

* 01 52 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 54 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 56 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 58 00 00 02 00 - 28 EQ Lo-Mi EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 5A 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 5C 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 5E 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 60 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 62 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 64 00 00 02 MASTER dummy * 01 66 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 68 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 01 6A 00 00 02 00 - 64 MASTER Foot Level 0 - 100

47 - 53 BPM 1/4 - 4.0 (refer to Table-4.[BPMPARAM4])

01 ON

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 ON

FB MIDI

FC GLOBAL

<<< STEREO MULTI >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 COMP Effect On/Off OFF

* 01 26 00 00 02 00 COMP FX Select COMP

* 01 28 00 00 02 00 COMP Detect L

* 01 2A 00 00 02 COMP dummy * 01 2C $ 0000 02 00 - 64 COMP [COMP]Threshold 0 - 100 * 01 2E $ 00 00 02 00 COMP [COMP]Ratio 1.5:1

* 01 30 $ 00 00 02 00 - 64 COMP [COMP]Attack 0 - 100 * 01 32 $ 00 00 02 00 - 64 COMP [COMP]Release 0 - 100 * 01 34 $ 00 00 02 00 - 64 COMP [COMP]Tone -50 - +50 * 01 36 $ 00 00 02 00 - 64 COMP [COMP]Level 0 - 100 * 01 2C $ 0000 02 00 - 64 COMP [LIMIT]Threshold 0 - 100 * 01 2E $ 00 00 02 00 - 64 COMP [LIMIT]Release 0 - 100 * 01 30 $ 00 00 02 00 - 64 COMP [LIMIT]Tone -50 - +50 * 01 32 $ 00 00 02 00 - 64 COMP [LIMIT]Level 0 - 100 * 01 38 00 00 02 00 NS Effect On/Off OFF

* 01 3A 00 00 02 00 NS Detect L

* 01 3C 00 00 02 00 - 64 NS Threshold 0 - 100 * 01 3E 00 00 02 00 - 64 NS Release 0 - 100 * 01 40 00 00 02 00 ENH Effect On/Off OFF

* 01 42 00 00 02 00 ENH Detect L

* 01 44 00 00 02 00 - 64 ENH Sens 0 - 100 * 01 46 00 00 02 00 - 0A ENH Frequency (refer to Table-23.[VOCALFREQ]) * 01 48 00 00 02 00 - 64 ENH Mix Level 0 - 100 * 01 4A 00 00 02 00 - 64 ENH Low Mix Level 0 - 100

01 ON

01 LIMIT

01 R

02 LINK

01 2:1

02 4:1

03 100:1

01 ON

01 R

02 LINK

01 ON

01 R

02 LINK

32

MIDI インプリメンテーション

* 01 4C 00 00 02 00 - 64 ENH Level 0 - 100 * 01 50 00 00 02 00 EQ Effect On/Off OFF

* 01 52 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 54 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 56 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 58 00 00 02 00 - 28 EQ Lo-Mi EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 5A 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 5C 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 5E 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 60 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 62 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 64 00 00 02 00 DELAY Effect On/Off OFF

* 01 66 00 00 02 00 - 78 DELAY FX Level 0 - 120 * 01 68 00 00 02 00 - 64 DELAY Dir Level 0 - 100 * 01 6A 00 00 02 00 - 32 DELAY High DampGain -50 - 0 [dB] * 01 6C 00 00 02 00 - 09 DELAY High Cut Filter (refer to Table-16.[HICUT]) * 01 6E 00 00 02 DELAY dummy * 01 70 00 00 02 00 - 46 DELAY Delay Time L 0 - 1400 [ms] (step=20)

* 01 72 00 00 02 00 - 14 DELAY Fine Time L 0 - 20 [ms] * 01 74 00 00 02 00 - 64 DELAY Feedbk L 0 - 100 * 01 76 00 00 02 DELAY dummy * 01 78 00 00 02 00 - 46 DELAY Delay Time R 0 - 1400 [ms] (step=20)

* 01 7A 00 00 02 00 - 14 DELAY Fine Time R 0 - 20 [ms] * 01 7C 00 00 02 00 - 64 DELAY Feedbk R 0 - 100 * 01 7E 00 00 02 DELAY dummy * 02 00 00 00 02 MASTER dummy * 02 02 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 02 04 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 02 06 00 00 02 00 - 64 MASTER Foot Level 0 - 100

01 ON

47 - 53 BPM 1/4 - 4.0 (refer to Table-4.[BPMPARAM4])

FB MIDI

FC GLOBAL

<<< STEREO PHASER DELAY >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 DELAY Effect On/Off OFF

* 01 26 00 00 02 00 - 78 DELAY FX Level 0 - 120 * 01 28 00 00 02 00 - 64 DELAY Dir Level 0 - 100 * 01 2A 00 00 02 00 - 32 DELAY High DampGain -50 - 0 [dB] * 01 2C 00 00 02 00 - 09 DELAY High Cut Filter (refer to Table-16.[HICUT]) * 01 2E 00 00 02 DELAY dummy * 01 30 00 00 02 00 - 46 DELAY Delay Time L 0 - 1400 [ms] (step=20)

* 01 32 00 00 02 00 - 14 DELAY Fine Time L 0 - 20 [ms] * 01 34 00 00 02 00 - 64 DELAY Feedbk L 0 - 100 * 01 36 00 00 02 DELAY dummy * 01 38 00 00 02 00 - 46 DELAY Delay Time R 0 - 1400 [ms] (step=20)

* 01 3A 00 00 02 00 - 14 DELAY Fine Time R 0 - 20 [ms] * 01 3C 00 00 02 00 - 64 DELAY Feedbk R 0 - 100 * 01 3E 00 00 02 DELAY dummy * 01 40 00 00 02 00 PH Phaser On/Off OFF

* 01 42 00 00 02 00 PH Type 4STAGE

* 01 44 00 00 02 00 - 64 PH Rate 0 - 100

* 01 46 00 00 02 00 - 64 PH Depth 0 - 100 * 01 48 00 00 02 00 - 64 PH Manual 0 - 100 * 01 4A 00 00 02 00 - C8 PH Resonance -100 - +100 * 01 4C 00 00 02 00 - 64 PH Separate 0 - 100 * 01 4E 00 00 02 00 PH Step OFF

* 01 50 00 00 02 00 EQ Effect On/Off OFF

* 01 52 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 54 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 56 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 58 00 00 02 00 - 28 EQ Lo-Mi EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 5A 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 5C 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM])

01 ON

47 - 53 BPM 1/4 - 4.0 (refer to Table-4.[BPMPARAM4])

01 ON

01 6STAGE

02 8STAGE

03 10STAGE

04 12STAGE

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 - 64 1 - 100

01 ON

33

MIDI インプリメンテーション

* 01 5E 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 60 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 62 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 64 00 00 02 MASTER dummy * 01 66 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 68 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 01 6A 00 00 02 00 - 64 MASTER Foot Level 0 - 100

<<< STEREO PITCH SHIFTER DELAY >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 PS Effect ON/Off OFF

* 01 26 00 00 02 00 PS Mode FAST

* 01 28 00 00 02 00 - C8 PS Balance Dir:FX 100:0- 0:100 * 01 2A 00 00 02 00 - 64 PS Level 0 - 100 * 01 2C 00 00 02 PS dummy * 01 2E 00 00 02 PS dummy * 01 30 00 00 02 00 - 30 PS Pitch L -24 - +24 * 01 32 00 00 02 00 - 64 PS Fine L -50 - +50 * 01 34 00 00 02 00 - 64 PS Pre Delay L 0.0 - 50.0 [ms] (step=0.5) * 01 36 00 00 02 00 - 3C PS FB Delay Time L 0 - 1200 [ms] (step=20)

* 01 38 00 00 02 00 - 14 PS FB Fine Time L 0 - 20 [ms] * 01 3A 00 00 02 00 - 64 PS FB Level L 0 - 100 * 01 3C 00 00 02 00 - 30 PS Pitch R -24 - +24 * 01 3E 00 00 02 00 - 64 PS Fine R -50 - +50 * 01 40 00 00 02 00 - 64 PS Pre Delay R 0.0 - 50.0 [ms] (step=0.5) * 01 42 00 00 02 00 - 3C PS FB Delay Time R 0 - 1200 [ms] (step=20)

* 01 44 00 00 02 00 - 14 PS FB Fine Time R 0 - 20 [ms] * 01 46 00 00 02 00 - 64 PS FB Level R 0 - 100 * 01 48 00 00 02 00 EQ Effect On/Off OFF

* 01 4A 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 4C 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 4E 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 50 00 00 02 00 - 28 EQ Lo-Mi EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 52 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 54 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 56 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 58 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 5A 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 5C 00 00 02 MASTER dummy * 01 5E 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 60 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 01 62 00 00 02 00 - 64 MASTER Foot Level 0 - 100

FB MIDI

FC GLOBAL

01 ON

01 MEDIUM

02 SLOW

3D - 49 BPM 1/4 - 4.0 (refer to Table-3.[BPMPARAM3])

01 ON

FB MIDI

FC GLOBAL

<<< TAPE ECHO 201 >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 ECHO Effect On/Off OFF

01 ON * 01 26 00 00 02 01 - 07 ECHO Mode 1 - 7 * 01 28 00 00 02 00 - 64 ECHO Repeat Rate 0 - 100 * 01 2A 00 00 02 00 - 64 ECHO Intensity 0 - 100 * 01 2C 00 00 02 00 - C8 ECHO Tone Bass -100 - +100 * 01 2E 00 00 02 00 - C8 ECHO Tone Treble -100 - +100 * 01 30 00 00 02 00 - 64 ECHO Pan Head S 100:0- 0:100 * 01 32 00 00 02 00 - 64 ECHO Pan Head M 100:0 - 0:100 * 01 34 00 00 02 00 - 64 ECHO Pan Head L 100:0 - 0:100 * 01 36 00 00 02 00 - 64 ECHO Tape Dist 0 - 100 * 01 38 00 00 02 00 - 64 ECHO Wow Rate 0 - 100 * 01 3A 00 00 02 00 - 64 ECHO Wow Depth 0 - 100 * 01 3C 00 00 02 00 - 64 ECHO FX Level 0 - 100 * 01 3E 00 00 02 00 - 64 ECHO Dir Level 0 - 100 * 01 40 00 00 02 MASTER dummy * 01 42 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 44 00 00 02 MASTER dummy * 01 46 00 00 02 00 - 64 MASTER Foot Level 0 - 100

34

MIDI インプリメンテーション

<<< VOCAL CANCELER >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 VCL Effect On/Off OFF

* 01 26 00 00 02 00 - 64 VCL Balance 0 - 100 * 01 28 00 00 02 00 - 12 VCL Range Low (refer to Table-30.[RANGELO]) * 01 2A 00 00 02 00 - 14 VCL Range High (refer to Table-31.[RANGEHI]) * 01 2C 00 00 02 00 NS Effect On/Off OFF

* 01 2E 00 00 02 00 - 64 NS Threshold 0 - 100 * 01 30 00 00 02 00 - 64 NS Release 0 - 100 * 01 32 00 00 02 NS dummy * 01 34 00 00 02 00 EQ Effect On/Off OFF

* 01 36 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 38 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 3A 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 3C 00 00 02 00 - 28 EQ Lo-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 3E 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz] (refer to Table-11.[EQPARAM]) * 01 40 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16 (refer to Table-11.[EQPARAM]) * 01 42 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 44 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 46 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]) * 01 48 00 00 02 MASTER dummy * 01 4A 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 4C 00 00 02 MASTER dummy * 01 4E 00 00 02 00 - 64 MASTER Foot Level 0 - 100

01 ON

<<< VOCAL MULTI >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 COMP Effect On/Off OFF

* 01 26 00 00 02 00 COMP FX Select COMP

* 01 28 $ 00 00 02 00 - 64 COMP [COMP]Threshold 0 - 100 * 01 2A $ 0000 02 00 COMP [COMP]Ratio 1.5:1

* 01 2C $ 0000 02 00 - 64 COMP [COMP]Attack 0 - 100 * 01 2E $ 00 00 02 00 - 64 COMP [COMP]Release 0 - 100 * 01 30 $ 00 00 02 00 - 64 COMP [COMP]Tone -50 - +50 * 01 32 $ 00 00 02 00 - 64 COMP [COMP]Level 0 - 100 * 01 28 $ 00 00 02 00 - 64 COMP [LIMIT]Threshold 0 - 100 * 01 2A $ 0000 02 00 - 64 COMP [LIMIT]Release 0 - 100 * 01 2C $ 0000 02 00 - 64 COMP [LIMIT]Tone -50 - +50 * 01 2E $ 00 00 02 00 - 64 COMP [LIMIT]Level 0 - 100, * 01 34 00 00 02 00 DES Effect On/Off OFF,

* 01 36 00 00 02 00 - 64 DES Sens 0 - 100, * 01 38 00 00 02 00 - 0A DES Frequency (refer to Table-23.[VOCALFREQ]), * 01 3C 00 00 02 00 EQ Effect On/Off OFF,

* 01 3E 00 00 02 00 - 28 EQ Low EQ -20 - +20 [dB], (refer to Table-11.[EQPARAM]), * 01 40 00 00 02 00 - 14 EQ Lo-Mid f 100 - 10.0k [Hz], (refer to Table-11.[EQPARAM]), * 01 42 00 00 02 00 - 05 EQ Lo-Mid Q 0.5 - 16, (refer to Table-11.[EQPARAM]), * 01 44 00 00 02 00 - 28 EQ Lo-Mi EQ -20 - +20 [dB], (refer to Table-11.[EQPARAM]), * 01 46 00 00 02 00 - 14 EQ Hi-Mid f 100 - 10.0k [Hz], (refer to Table-11.[EQPARAM]), * 01 48 00 00 02 00 - 05 EQ Hi-Mid Q 0.5 - 16, (refer to Table-11.[EQPARAM]), * 01 4A 00 00 02 00 - 28 EQ Hi-Mid EQ -20 - +20 [dB], (refer to Table-11.[EQPARAM]), * 01 4C 00 00 02 00 - 28 EQ High EQ -20 - +20 [dB], (refer to Table-11.[EQPARAM]), * 01 4E 00 00 02 00 - 28 EQ Level -20 - +20 [dB] (refer to Table-11.[EQPARAM]), * 01 50 00 00 02 00 EN Effect On/Off OFF

* 01 52 00 00 02 00 - 64 EN Sens 0 - 100 * 01 54 00 00 02 00 - 0A EN Frequency (refer to Table-23.[VOCALFREQ]) * 01 56 00 00 02 00 - 64 EN Mix Level 0 - 100 * 01 58 00 00 02 00 - 64 EN Lo Mix Level 0 - 100 * 01 5A 00 00 02 00 - 64 EN Level 0 - 100 * 01 5C 00 00 02 00 NS Effect On/Off OFF

* 01 5E 00 00 02 00 - 64 NS Threshold 0 - 100 * 01 60 00 00 02 00 - 64 NS Release 0 - 100 * 01 62 00 00 02 NS dummy * 01 64 00 00 02 00 MOD Effect On/Off OFF

* 01 66 00 00 02 00 MOD FX Select FL

01 ON

01 LIMIT

01 2:1

02 4:1

03 100:1

01 ON,

01 ON

35

MIDI インプリメンテーション

01 PH

* 01 68 $ 00 00 02 00 - 64 MOD [FL] Rate 0 - 100

* 01 6A $ 0000 02 00 - 64 MOD [FL] Depth 0 - 100 * 01 6C $ 0000 02 00 - 64 MOD [FL] Manual 0 - 100 * 01 6E $ 00 00 02 00 - 64 MOD [FL] Resonance 0 - 100 * 01 70 $ 00 00 02 00 - 64 MOD [FL] Separate 0 - 100 * 01 72 $ 00 00 02 00 - 64 MOD [FL] Level 0 - 100 * 01 68 $ 00 00 02 00 MOD [PH] Type 4STAGE

* 01 6A $ 0000 02 00 - 64 MOD [PH] Rate 0 - 100

* 01 6C $ 0000 02 00 - 64 MOD [PH] Depth 0 - 100 * 01 6E $ 00 00 02 00 - 64 MOD [PH] Manual 0 - 100 * 01 70 $ 00 00 02 00 - 64 MOD [PH] Resonance 0 - 100 * 01 72 $ 00 00 02 MOD [PH] dummy * 01 74 $ 00 00 02 00 MOD [PH] Step OFF

* 01 76 $ 00 00 02 00 - 64 MOD [PH] Level 0 - 100 * 01 68 $ 00 00 02 00 MOD [PS] Mode FAST

* 01 6A $ 0000 02 00 - 30 MOD [PS] Pitch -24 - +24 * 01 6C $ 0000 02 00 - 64 MOD [PS] Fine -50 - +50 * 01 6E $ 00 00 02 00 - C8 MOD [PS] Balance Dir:FX 100:0 - 0:100 * 01 70 $ 00 00 02 00 - 64 MOD [PS] Level 0 - 100 * 01 78 00 00 02 00 DELAY Effect On/Off OFF

* 01 7A 00 00 02 00 DELAY Type SINGLE

* 01 7C 00 00 02 00 - 3C DELAY Delay Time 0 - 1200 [ms] (step=20)

* 01 7E 00 00 02 00 - 14 DELAY Fine Time 0 - 20 [ms] * 02 00 00 00 02 00 - 64 DELAY Tap Time 0 - 100 [%] * 02 02 00 00 02 00 - 64 DELAY Feedback 0 - 100 * 02 04 00 00 02 00 - 09 DELAY High Cut (refer to Table-16.[HICUT]) * 02 06 00 00 02 00 - 78 DELAY FX Level 0 - 120 * 02 08 00 00 02 00 CHORUS Effect On/Off OFF

* 02 0A 00 00 02 00 CHORUS Mode MONO

* 02 0C 00 00 02 00 - 64 CHORUS Rate 0 - 100

* 02 0E 00 00 02 00 - 64 CHORUS Depth 0 - 100 * 02 10 00 00 02 00 - 50 CHORUS Pre Delay 0.0 - 40.0 [ms] (step=0.5) * 02 12 00 00 02 00 - 0A CHORUS Low Cut (refer to Table-22.[LOCUT2]) * 02 14 00 00 02 00 - 09 CHORUS High Cut (refer to Table-16.[HICUT]) * 02 16 00 00 02 00 - 64 CHORUS FX Level 0 - 100 * 02 18 00 00 02 CHORUS dummy * 02 1A 00 00 02 CHORUS dummy * 02 1C 00 00 02 00 REVERB Effect On/Off OFF

* 02 1E 00 00 02 00 REVERB Type ROOM 1

* 02 20 00 00 02 01 - 64 REVERB Reverb Time 0.1 - 10.0 [s] * 02 22 00 00 02 00 - 64 REVERB Pre Delay 0 - 100 [ms] * 02 24 00 00 02 00 - 09 REVERB Low Cut (refer to Table-17.[LOCUT]) * 02 26 00 00 02 00 - 09 REVERB High Cut (refer to Table-16.[HICUT]) * 02 28 00 00 02 00 - 0A REVERB Density 0 - 10 * 02 2A 00 00 02 00 - 64 REVERB FX Level 0 - 100 * 02 2C 00 00 02 MASTER dummy * 02 2E 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 02 30 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 02 32 00 00 02 00 - 64 MASTER Foot Level 0 - 100

02 PS

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 8STAGE

02 12STAGE

03 BI-PHASE

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 - 64 1 - 100

01 MEDIUM

02 SLOW

03 INV1

04 INV2

01 ON

01 TAP

3D - 49 BPM 1/4 - 4.0 (refer to Table-3.[BPMPARAM3])

01 ON

01 ST.

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 ON

01 ROOM 2

02 HALL 1

03 HALL 2

04 PLATE

FB MIDI

FC GLOBAL

36

MIDI インプリメンテーション

<<< VOCODER >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 VC Effect On/Off OFF

* 01 26 00 00 02 00 VC Envelope SHARP

* 01 28 00 00 02 00 VC Pan Mode MONO

* 01 2A 00 00 02 00 VC Hold OFF

* 01 2C 00 00 02 00 - 64 VC Mic Sens 0 - 100 * 01 2E 00 00 02 00 - 64 VC Synth Level 0 - 100 * 01 30 00 00 02 00 - 64 VC Mic Mix 0 - 100 * 01 32 00 00 02 00 - 14 VC Mic HPF THRU, 1.0 - 20.0 [kHz] (refer to Table-37.[VOCHPF]) * 01 34 00 00 02 00 - 64 VC Mic Pan 100:0 - 0:100 * 01 36 00 00 02 00 - 64 VC NS Threshold 0 - 100 * 01 38 00 00 02 00 - 64 VC CharacterCh1 0 - 100 * 01 3A 00 00 02 00 - 64 VC Character Ch2 0 - 100 * 01 3C 00 00 02 00 - 64 VC Character Ch3 0 - 100 * 01 3E 00 00 02 00 - 64 VC Character Ch4 0 - 100 * 01 40 00 00 02 00 - 64 VC CharacterCh5 0 - 100 * 01 42 00 00 02 00 - 64 VC CharacterCh6 0 - 100 * 01 44 00 00 02 00 - 64 VC CharacterCh7 0 - 100 * 01 46 00 00 02 00 - 64 VC CharacterCh8 0 - 100 * 01 48 00 00 02 00 - 64 VC CharacterCh9 0 - 100 * 01 4A 00 00 02 00 - 64 VC Character Ch10 0 - 100 * 01 4C 00 00 02 00 CHORUS Effect On/Off OFF

* 01 4E 00 00 02 00 CHORUS Polarity SYNC

* 01 50 00 00 02 00 - 64 CHORUS Rate 0 - 100

* 01 52 00 00 02 00 - 64 CHORUS Depth 0 - 100 * 01 54 00 00 02 00 - 50 CHORUS Pre Delay 0.0 - 40.0 [ms] (step=0.5) * 01 56 00 00 02 00 - 0A CHORUS Low Cut (refer to Table-22.[LOCUT2]) * 01 58 00 00 02 00 - 09 CHORUS High Cut (refer to Table-16.[HICUT]) * 01 5A 00 00 02 00 - 64 CHORUS Effect Level 0 - 100 * 01 5C 00 00 02 CHORUS dummy * 01 5E 00 00 02 CHORUS dummy * 01 60 00 00 02 00 REVERB Effect On/Off OFF

* 01 62 00 00 02 00 REVERB Type ROOM 1

* 01 64 00 00 02 01 - 64 REVERB Reverb Time 0.1 - 10.0 [s] * 01 66 00 00 02 00 - 64 REVERB Pre Delay 0 - 100 [ms] * 01 68 00 00 02 00 - 09 REVERB Low Cut (refer to Table-17.[LOCUT]) * 01 6A 00 00 02 00 - 09 REVERB High Cut (refer to Table-16.[HICUT]) * 01 6C 00 00 02 00 - 0A REVERB Density 0 - 10 * 01 6E 00 00 02 00 - 64 REVERB FX Level 0 - 100 * 01 70 00 00 02 MASTER dummy * 01 72 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 74 00 00 02 28 - FA MASTER MasterBPM 40 - 250

* 01 76 00 00 02 00 - 64 MASTER Foot Level 0 - 100

01 ON

01 SOFT

02 LONG

01 STEREO

02 L->R

03 R->L

01 MIDI

01 ON

01 INVERT

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 ON

01 ROOM 2

02 HALL 1

03 HALL 2

04 PLATE

FB MIDI

FC GLOBAL

<<< VOICE TRANSFORMER >>>

OFFSET (H) SIZE (H) DATA (H) EFFECT PARAMETER DESCRIPTION * 01 24 00 00 02 00 VT Effect On/Off OFF

* 01 26 00 00 02 00 VT Robot OFF

* 01 28 00 00 02 00 - 18 VT Crmtc Pitch -12 - +12 * 01 2A 00 00 02 00 - C8 VT Fine Pitch -100 - +100 * 01 2C 00 00 02 00 - 18 VT Crmtc Frmt -12 - +12 * 01 2E 00 00 02 00 - C8 VT Fine Frmt -100 - +100 * 01 30 00 00 02 00 - 64 VT Mix Bal 0 - 100 * 01 32 00 00 02 VT dummy * 01 34 00 00 02 00 CHORUS Effect On/Off OFF

* 01 36 00 00 02 00 CHORUS Mode MONO

01 ON

37

MIDI インプリメンテーション

* 01 38 00 00 02 00 - 64 CHORUS Rate 0 - 100

* 01 3A 00 00 02 00 - 64 CHORUS Depth 0 - 100 * 01 3C 00 00 02 00 - 50 CHORUS Pre Delay 0.0 - 40.0 [ms] (step=0.5) * 01 3E 00 00 02 00 - 0A CHORUS Low Cut (refer to Table-22.[LOCUT2]) * 01 40 00 00 02 00 - 09 CHORUS High Cut (refer to Table-16.[HICUT]) * 01 42 00 00 02 00 - 64 CHORUS FX Level 0 - 100 * 01 44 00 00 02 CHORUS dummy * 01 46 00 00 02 CHORUS dummy * 01 48 00 00 02 00 REVERB Effect On/Off OFF

* 01 4A 00 00 02 00 REVERB Type ROOM 1

* 01 4C 00 00 02 01 - 64 REVERB Reverb Time 0.1 - 10.0 [s] * 01 4E 00 00 02 00 - 64 REVERB Pre Delay 0 - 100 [ms] * 01 50 00 00 02 00 - 09 REVERB Low Cut (refer to Table-17.[LOCUT]) * 01 52 00 00 02 00 - 09 REVERB High Cut (refer to Table-16.[HICUT]) * 01 54 00 00 02 00 - 0A REVERB Density 0 - 10 * 01 56 00 00 02 00 - 64 REVERB FX Level 0 - 100 * 01 58 00 00 02 MASTER dummy * 01 5A 00 00 02 00 - 64 MASTER Master Level 0 - 100 * 01 5C 00 00 02 28 - FA MASTER Master BPM 40 - 250

* 01 5E 00 00 02 00 - 64 MASTER Foot Level 0 - 100

01 ST.

65 - 71 BPM 4.0 - 1/4 (refer to Table-1.[BPMPARAM1])

01 ON

01 ROOM 2

02 HALL 1

03 HALL 2

04 PLATE

FB MIDI

FC GLOBAL

38

MIDI インプリメンテーション

○ TABLE

Table-1. [BPMPARAM1]

Data(H) Description 65 BPM 4.0 66 BPM 3.0 67 BPM 8/3 68 BPM 2.0 69 BPM 1.5 6A BPM 4/3 6B BPM 1.0 6C BPM 3/4 6D BPM 2/3 6E BPM 1/2 6F BPM 3/8 70 BPM 1/3 71 BPM 1/4

Table-2. [BPMPARAM2]

Data(H) Description 29 BPM 1/4 2A BPM 1/3 2B BPM 3/8 2C BPM 1/2 2D BPM 2/3 2E BPM 3/4 2F BPM 1.0 30 BPM 4/3 31 BPM 1.5 32 BPM 2.0 33 BPM 8/3 34 BPM 3.0 35 BPM 4.0

Table-3. [BPMPARAM3]

Data(H) Description 3D BPM 1/4 3E BPM 1/3 3F BPM 3/8 40 BPM 1/2 41 BPM 2/3 42 BPM 3/4 43 BPM 1.0 44 BPM 4/3 45 BPM 1.5 46 BPM 2.0 47 BPM 8/3 48 BPM 3.0 49 BPM 4.0

Table-4. [BPMPARAM4]

Data(H) Description 47 BPM 1/4 48 BPM 1/3 49 BPM 3/8 4A BPM 1/2 4B BPM 2/3 4C BPM 3/4 4D BPM 1.0 4E BPM 4/3 4F BPM 1.5 50 BPM 2.0 51 BPM 8/3 52 BPM 3.0 53 BPM 4.0

Table-5. [BPMPARAM5]

Data(H) Description 5B BPM 1/4 5C BPM 1/3 5D BPM 3/8 5E BPM 1/2 5F BPM 2/3 60 BPM 3/4 61 BPM 1.0 62 BPM 4/3 63 BPM 1.5

64 BPM 2.0 65 BPM 8/3 66 BPM 3.0 67 BPM 4.0

Table-6. [BPMPARAM6]

Data(H) Description 8D BPM 1/4 8E BPM 1/3 8F BPM 3/8 90 BPM 1/2 91 BPM 2/3 92 BPM 3/4 93 BPM 1.0 94 BPM 4/3 95 BPM 1.5 96 BPM 2.0 97 BPM 8/3 98 BPM 3.0 99 BPM 4.0

Table-7. [BPMPARAM7]

Data(H) Description 012D BPM 1/4 012E BPM 1/3 012F BPM 3/8 0130 BPM 1/2 0131 BPM 2/3 0132 BPM 3/4 0133 BPM 1.0 0134 BPM 4/3 0135 BPM 1.5 0136 BPM 2.0 0137 BPM 8/3 0138 BPM 3.0 0139 BPM 4.0

Table-8. [BPMPARAM8]

Data(H) Description 0191 BPM 1/4 0192 BPM 1/3 0193 BPM 3/8 0194 BPM 1/2 0195 BPM 2/3 0196 BPM 3/4 0197 BPM 1.0 0198 BPM 4/3 0199 BPM 1.5 019A BPM 2.0 019B BPM 8/3 019C BPM 3.0 019D BPM 4.0

Table-9. [PREAMPTYPE]

Data(H) Description 00 JC-120 01 CLEAN TWIN 02 CRUNCH 03 MATCH DRIVE 04 VO DRIVE 05 BLUES 06 BG LEAD 07 MS1959 (I) 08 MS1959 (II) 09 MS1959 (I+II) 0A SLDN LEAD 0B METAL 5150 0C METAL DRIVE 0D AC.GUITAR 0E OD-1 0F OD-2 TURBO 10 DISTORTION 11 FUZZ

Table-10. [PREAMPMICSET]

Data(H) Description 00 Center

01 1cm 02 2cm 03 3cm 04 4cm 05 5cm 06 6cm 07 7cm 08 8cm 09 9cm 0A 10cm

Table-11. [EQPARAM]

Data(H) Description 00 -20dB 01 -19dB 02 -18dB 03 -17dB 04 -16dB 05 -15dB 06 -14dB 07 -13dB 08 -12dB 09 -11dB 0A -10dB 0B -9dB 0C -8dB 0D -7dB 0E -6dB 0F -5dB 10 -4dB 11 -3dB 12 -2dB 13 -1dB 14 0dB 15 +1dB 16 +2dB 17 +3dB 18 +4dB 19 +5dB 1A +6dB 1B +7dB 1C +8dB 1D +9dB 1E +10dB 1F +11dB 20 +12dB 21 +13dB 22 +14dB 23 +15dB 24 +16dB 25 +17dB 26 +18dB 27 +19dB 28 +20dB

Data(H) Description 00 100Hz 01 125Hz 02 160Hz 03 200Hz 04 250Hz 05 315Hz 06 400Hz 07 500Hz 08 630Hz 09 800Hz 0A 1000Hz 0B 1250Hz 0C 1600Hz 0D 2000Hz

[Low EQ] [Lo-Mid EQ] [Hi-MidEQ] [High EQ] [Level]

[Lo-Mid f] [Hi-Midf]

39

MIDI インプリメンテーション

0E 2500Hz 0F 3150Hz 10 4000Hz 11 5000Hz 12 6300Hz 13 8000Hz 14 10000Hz

[Lo-Mid Q] [Hi-MidQ]

Data(H) Description 00 0.5 01 1 02 2 03 4 04 8 05 16

Table-12. [MOD]

Data(H) Description 00 HR:HARMONIST 01 FL:FLANGER 02 PH:PHASER 03 SEQ:SUB EQ 04 2CE:2× 2 CHORUS 05 SDD:SHORT DELAY 06 HU:HUMANIZER 07 VB:VIBRATO 08 SYN:GUITAR SYNTH 09 RM:RING MODULATOR 0A SL:SLICER

Table-13. [HARMKEY]

Data(H) Description 00 C <Am> 01 Db <Bbm> 02 D <Bm> 03 Eb <Cm> 04 E <C#m> 05 F <Dm > 06 F# <Ebm> 07 G <Em > 08 Ab <Fm > 09 A <F#m> 0A Bb <Gm > 0B B <G#m>

Table-14. [HARMHARMONY]

Data(H) Description 00 -2oct 01 -14th 02 -13th 03 -12th 04 -11th 05 -10th 06 -9th 07 -1oct 08 -7th 09 -6th 0A -5th 0B -4th 0C -3rd 0D -2nd 0E TONIC 0F +2nd 10 +3rd 11 +4th 12 +5th 13 +6th 14 +7th 15 +1oct 16 +9th 17 +10th 18 +11th 19 +12th 1A +13th 1B +14th

1C +2oct 1D Scale1 1E Scale2 1F Scale3 20 Scale4 21 Scale5

Table-15. [2CEXOVER]

Data(H) Description 00 100Hz 01 125Hz 02 160Hz 03 200Hz 04 250Hz 05 315Hz 06 400Hz 07 500Hz 08 630Hz 09 800Hz 0A 1000Hz 0B 1250Hz 0C 1600Hz 0D 2000Hz 0E 2500Hz 0F 3150Hz 10 4000Hz

Table-16. [HICUT]

Data(H) Description 00 700Hz 01 1000Hz 02 1400Hz 03 2000Hz 04 3000Hz 05 4000Hz 06 6000Hz 07 8000Hz 08 11000Hz 09 FLAT

Table-17. [LOCUT]

Data(H) Description 00 55Hz 01 110Hz 02 165Hz 03 220Hz 04 280Hz 05 340Hz 06 400Hz 07 500Hz 08 630Hz 09 800Hz

Table-18. [SFXSELECT]

Data(H) Description 00 01 BSS:BASS GUITAR SIMULATOR 02 SG :SLOW GEAR 03 FB :FEEDBACKER 04 PIC:PICKUP SIMULATOR 05 TR :TREMOLO/PAN

AC :ACOUSTIC GUITAR SIMULATOR

Table-19. [BASS1]

Data(H) Description 00 0 01 5 02 10 03 15 04 20 05 25 06 30 07 35 08 40 09 45 0A 50 0B 60 0C 70

0D 80 0E 90 0F 100

Table-20. [BASS2]

Data(H) Description 00 0 01 2 02 4 03 6 04 8 05 10 06 12 07 14 08 16 09 18 0A 20 0B 22 0C 24 0D 26 0E 28 0F 30 10 32 11 34 12 36 13 40 14 45 15 50 16 55 17 60 18 65 19 70 1A 75 1B 80 1C 85 1D 90 1E 95 1F 100

Table-21. [BASS3]

Data(H) Description 00 -50 01 -40 02 -30 03 -20 04 -15 05 -10 06 -5 07 0 08 +5 09 +10 0A +15 0B +20 0C +30 0D +40 0E +50

Table-22. [LOCUT2]

Data(H) Description 00 FLAT 01 55Hz 02 110Hz 03 165Hz 04 220Hz 05 280Hz 06 340Hz 07 400Hz 08 500Hz 09 630Hz 0A 800Hz

Table-23. [VOCALFREQ]

Data(H) Description 00 1.00kHz 01 1.25kHz 02 1.60kHz 03 2.00kHz 04 2.50kHz

40

MIDI インプリメンテーション

05 3.15kHz 06 4.00kHz 07 5.00kHz 08 6.30kHz 09 8.00kHz 0A 10.00kHz

Table-24. [DAMPGAIN]

Data(H) Description 00 -36.0 01 -35.0 02 -34.0 03 -33.0 04 -32.0 05 -31.0 06 -30.0 07 -29.0 08 -28.0 09 -27.0 0A -26.0 0B -25.0 0C -24.0 0D -23.0 0E -22.0 0F -21.0 10 -20.0 11 -19.0 12 -18.0 13 -17.0 14 -16.0 15 -15.0 16 -14.0 17 -13.0 18 -12.0 19 -11.5 1A -11.0 1B -10.5 1C -10.0 1D -9.5 1E -9.0 1F -8.5 20 -8.0 21 -7.5 22 -7.0 23 -6.5 24 -6.0 25 -5.5 26 -5.0 27 -4.5 28 -4.0 29 -3.5 2A -3.0 2B -2.5 2C -2.0 2D -1.5 2E -1.0 2F -0.5 30 0.0

Table-25. [LODMP]

Data(H) Description 00 55Hz 01 110Hz 02 165Hz 03 220Hz 04 280Hz 05 340Hz 06 400Hz 07 500Hz 08 630Hz 09 800Hz 0A 1000Hz 0B 1250Hz 0C 1600Hz 0D 2000Hz 0E 2500Hz 0F 3150Hz 10 4000Hz

Table-26. [HIDMP]

Data(H) Description 00 4000Hz 01 5000Hz 02 6000Hz 03 7000Hz 04 8000Hz 05 9000Hz 06 10000Hz 07 11000Hz 08 12000Hz 09 13000Hz 0A 14000Hz 0B 15000Hz 0C 16000Hz 0D 17000Hz 0E 18000Hz 0F 19000Hz 10 20000Hz

Table-27. [REVHICUT]

Data(H) Description 00 200Hz 01 300Hz 02 400Hz 03 500Hz 04 600Hz 05 700Hz 06 800Hz 07 900Hz 08 1000Hz 09 1100Hz 0A 1200Hz 0B 1300Hz 0C 1400Hz 0D 1500Hz 0E 1600Hz 0F 1700Hz 10 1800Hz 11 1900Hz 12 2000Hz 13 3000Hz 14 4000Hz 15 5000Hz 16 6000Hz 17 7000Hz 18 8000Hz 19 9000Hz 1A 10000Hz 1B 11000Hz 1C 12000Hz 1D 13000Hz 1E 14000Hz 1F 16000Hz 20 18000Hz 21 20000Hz

Table-28. [ELEVATION]

Data(H) Description 00 -54 01 -36 02 -18 03 0 04 +18 05 +36 06 +54

Table-29. [AZIMUTH]

Data(H) Description 00 L180 01 L174 02 L168 03 L162 04 L156 05 L150 06 L144 07 L138

08 L132 09 L126 0A L120 0B L114 0C L108 0D L102 0E L096 0F L090 10 L084 11 L078 12 L072 13 L066 14 L060 15 L054 16 L048 17 L042 18 L036 19 L030 1A L024 1B L018 1C L012 1D L006 1E 0000 1F R006 20 R012 21 R018 22 R024 23 R030 24 R036 25 R042 26 R048 27 R054 28 R060 29 R066 2A R072 2B R078 2C R084 2D R090 2E R096 2F R102 30 R108 31 R114 32 R120 33 R126 34 R132 35 R138 36 R144 37 R150 38 R156 39 R162 3A R168 3B R174 3C R180

Table-30. [RANGELO]

Data(H) Description 00 20 01 40 02 60 03 80 04 100 05 200 06 300 07 400 08 500 09 600 0A 700 0B 800 0C 900 0D 1000 0E 1200 0F 1400 10 1600 11 1800 12 2000

41

MIDI インプリメンテーション

Table-31. [HMTFRQ]

[RANGEHI]

Data(H) Description 00 1.0k 01 1.2k 02 1.4k 03 1.6k 04 1.8k 05 2.0k 06 3.0k 07 4.0k 08 5.0k 09 6.0k 0A 7.0k 0B 8.0k 0C 9.0k 0D 10.0k 0E 11.0k 0F 12.0k 10 13.0k 11 14.0k 12 16.0k 13 18.0k

14 20.0k

Table-32. [MODEL]

DATA(H) Description 00 SUPER FLAT 01 PWD.BLACK 02 PWD.E-BAS 03 PWD.MACK 04 SMALL CUBE 05 WHITE CONE 06 WHITE C+TIS 07 SMALL RADIO 08 SMALL TV 09 BOOM BOX 0A BOOM LO-Bst

Table-33 [LMTFRQ]

DATA(H) Description 00 20 01 30 02 40 03 50 04 60 05 70

Table-34. [USERSCALE]

Data(H) Description

INPUT C C# D D# E F F# G G# A A# B 00 ↓↓ C ↓↓ C# ↓↓D ↓↓ D# ↓↓ E ↓↓ F ↓↓ F# ↓↓ G ↓↓ G# ↓↓ A ↓↓ A# ↓↓ B 01 ↓C# ↓D ↓D# ↓E ↓F ↓F# ↓G ↓G# ↓A ↓A# ↓B ↓C 02 ↓ D ↓D# ↓E ↓ F ↓ F# ↓G ↓G# ↓ A ↓ A# ↓B ↓C ↓ C# 03 ↓ D# ↓E ↓F ↓ F# ↓ G ↓ G# ↓A ↓ A# ↓ B ↓ C ↓ C# ↓ D 04 ↓ E ↓F ↓F# ↓ G ↓ G# ↓A ↓A# ↓ B ↓ C ↓C# ↓D ↓ D# 05 ↓ F ↓F# ↓G ↓ G# ↓ A ↓A# ↓B ↓ C ↓ C# ↓D ↓D# ↓ E 06 ↓F# ↓G ↓G# ↓A ↓A# ↓B ↓C ↓C# ↓D ↓D# ↓E ↓F 07 ↓ G ↓G# ↓A ↓ A# ↓ B ↓C ↓C# ↓ D ↓ D# ↓E ↓F ↓ F# 08 ↓G# ↓A ↓A# ↓B ↓C ↓C# ↓D ↓D# ↓E ↓F ↓F# ↓G 09 ↓ A ↓A# ↓B ↓ C ↓ C# ↓D ↓D# ↓ E ↓ F ↓F# ↓G ↓ G# 0A ↓ A# ↓B ↓C ↓ C# ↓ D ↓ D# ↓E ↓ F ↓ F# ↓G ↓G# ↓ A 0B ↓ B ↓C ↓C# ↓ D ↓ D# ↓E ↓F ↓ F# ↓ G ↓G# ↓A ↓ A# 0C ↓ C ↓C# ↓D ‑D# ↓ E ↓F ↓F# ↓ G ↓ G# ↓A ↓A# ↓ B 0D ‑C# ‑D ‑D# ‑E ‑F ‑F# ‑G ‑G# ‑A ‑A# ‑B ‑C 0E ‑D ‑D# ‑E ‑F ‑F# ‑G ‑G# ‑A ‑A# ‑B ‑C ‑C# 0F ‑D# ‑E ‑F ‑F# ‑G ‑G# ‑A ‑A# ‑B ‑C ‑C# ‑D 10 ‑E ‑F ‑F# ‑G ‑G# ‑A ‑A# ‑B ‑C ‑C# ‑D ‑D# 11 ‑F ‑F# ‑G ‑G# ‑A ‑A# ‑B ‑C ‑C# ‑D ‑D# ‑E 12 ‑F# ‑G ‑G# ‑A ‑A# ‑B ‑C ‑C# ‑D ‑D# ‑E ‑F 13 ‑G ‑G# ‑A ‑A# ‑B ‑C ‑C# ‑D ‑D# ‑E ‑F ‑F# 14 ‑G# ‑A ‑A# ‑B ‑C ‑C# ‑D ‑D# ‑E ‑F ‑F# ‑G 15 ‑A ‑A# ‑B ‑C ‑C# ‑D ‑D# ‑E ‑F ‑F# ‑G ‑G# 16 ‑A# ‑B ‑C ‑C# ‑D ‑D# ‑E ‑F ‑F# ‑G ‑G# ‑A 17 ‑B ‑C ‑C# ‑D ‑D# ‑E ‑F ‑F# ‑G ‑G# ‑A ‑A# 18 C C# D D# E F F# G G# A A# B 19 +C# +D +D# +E +F +F# +G +G# +A +A# +B +C 1A +D +D# +E +F +F# +G +G# +A +A# +B +C +C# 1B +D# +E +F +F# +G +G# +A +A# +B +C +C# +D 1C +E +F +F# +G +G# +A +A# +B +C +C# +D +D# 1D +F +F# +G +G# +A +A# +B +C +C# +D +D# +E 1E +F# +G +G# +A +A# +B +C +C# +D +D# +E +F 1F +G +G# +A +A# +B +C +C# +D +D# +E +F +F# 20 +G# +A +A# +B +C +C# +D +D# +E +F +F# +G 21 +A +A# +B +C +C# +D +D# +E +F +F# +G +G# 22 +A# +B +C +C# +D +D# +E +F +F# +G +G# +A 23 +B +C +C# +D +D# +E +F +F# +G +G# +A +A# 24 ↑ C ↑C# ↑D ↑ D# ↑ E ↑F ↑F# ↑ G ↑ G# ↑A ↑A# ↑ B 25 ↑C# ↑D ↑D# ↑E ↑F ↑F# ↑G ↑G# ↑A ↑A# ↑B ↑C 26 ↑ D ↑D# ↑E ↑ F ↑ F# ↑G ↑G# ↑ A ↑ A# ↑B ↑C ↑ C 27 ↑D# ↑E ↑F ↑F# ↑G ↑G# ↑A ↑A# ↑B ↑C ↑C ↑D 28 ↑ E ↑F ↑F# ↑ G ↑ G# ↑A ↑A# ↑ B ↑ C ↑C ↑D ↑ D# 29 ↑F↑F#↑G↑G#↑A↑A#↑B↑C↑C↑D↑D#↑E 2A ↑F#↑G↑G#↑A↑A#↑B↑C↑C↑D↑D#↑E↑F 2B ↑G ↑G# ↑A ↑A# ↑B ↑C ↑C ↑D ↑D# ↑E ↑F ↑F# 2C ↑G# ↑A ↑A# ↑B ↑C ↑C ↑D ↑D# ↑E ↑F ↑F# ↑G 2D ↑A↑A#↑B↑C↑C↑D↑D#↑E↑F↑F#↑G↑G# 2E ↑A#↑B↑C↑C↑D↑D#↑E↑F↑F#↑G↑G#↑A 2F ↑B ↑C ↑C ↑D ↑D# ↑E ↑F ↑F# ↑G ↑G# ↑A ↑A# 30 ↑↑ C ↑↑ C# ↑↑D ↑↑ D# ↑↑ E ↑↑ F ↑↑ F# ↑↑ G ↑↑ G# ↑↑ A ↑↑ A# ↑↑ B

06 80 07 90 08 100 09 120 0A 140 0B 160 0C 180 0D 200 0E 300 0F 400 10 500 11 600 12 700 13 800 14 900 15 1000 16 1200 17 1400 18 1600 19 1800 1A 2000

42

MIDI インプリメンテーション

Table-35. [ASCIINAME]

Data(H) Description 20 21 ! 22 " 23 # 24 $ 25 % 26 & 27 ' 28 ( 29 ) 2A * 2B + 2C , 2D 2E . 2F / 30 0 31 1 32 2 33 3 34 4 35 5 36 6 37 7 38 8 39 9 3A : 3B ; 3C < 3D = 3E > 3F ? 40 @ 41 A 42 B 43 C 44 D 45 E 46 F 47 G 48 H 49 I 4A J 4B K 4C L 4D M 4E N 4F O 50 P 51 Q 52 R 53 S 54 T 55 U 56 V 57 W 58 X 59 Y 5A Z 5B [ 5C ¥ 5D ] 5E ^ 5F  60  61 a 62 b 63 c 64 d 65 e 66 f 67 g 68 h 69 i 6A j 6B k 6C l

6D m 6E n 6F o 70 p 71 q 72 r 73 s 74 t 75 u 76 v 77 w 78 x 79 y 7A z 7B { 7C ¦ 7D }

Table-36. [SOURCETYPE]

Data(H) Description 00 ExpPEDAL 01 CONTROL1 02 CONTROL2 03 MIDI-1 04 MIDI-2 05 MIDI-3 06 MIDI-4 07 MIDI-5 08 MIDI-6 09 MIDI-7 0A MIDI-8 0B MIDI-9 0C MIDI-10 0D MIDI-11 0E MIDI-12 0F MIDI-13 10 MIDI-14 11 MIDI-15 12 MIDI-16 13 MIDI-17 14 MIDI-18 15 MIDI-19 16 MIDI-20 17 MIDI-21 18 MIDI-22 19 MIDI-23 1A MIDI-24 1B MIDI-25 1C MIDI-26 1D MIDI-27 1E MIDI-28 1F MIDI-29 20 MIDI-30 21 MIDI-31 22 MIDI-64 23 MIDI-65 24 MIDI-66 25 MIDI-67 26 MIDI-68 27 MIDI-69 28 MIDI-70 29 MIDI-71 2A MIDI-72 2B MIDI-73 2C MIDI-74 2D MIDI-75 2E MIDI-76 2F MIDI-77 30 MIDI-78 31 MIDI-79 32 MIDI-80 33 MIDI-81 34 MIDI-82 35 MIDI-83 36 MIDI-84 37 MIDI-85 38 MIDI-86 39 MIDI-87

3A MIDI-88 3B MIDI-89 3C MIDI-90 3D MIDI-91 3E MIDI-92 3F MIDI-93 40 MIDI-94 41 MIDI-95

Table-37. [VOCHPF]

Data(H) Description 00 THRU 01 1.0 02 2.0 03 3.0 04 4.0 05 5.0 06 6.0 07 7.0 08 8.0 09 9.0 0A 10.0 0B 11.0 0C 12.0 0D 13.0 0E 14.0 0F 15.0 10 16.0 11 17.0 12 18.0 13 19.0 14 20.0

43

MIDI インプリメンテーション

Table-38. [TARGETTYPE]

<<< 10BAND GRAPHICEQUALIZER >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 COMP Effect On/Off 06 COMP Detect 07 COMP [COMP]Threshold 08 COMP [COMP]Ratio 09 COMP [COMP]Attack 0A COMP [COMP]Release 0B COMP [COMP]Tone 0C COMP [COMP]Level 0D COMP [LIMIT]Threshold 0E COMP [LIMIT]Release 0F COMP [LIMIT]Tone 10 COMP [LIMIT]Level 11 NS Effect On/Off 12 NS Detect 13 NS Threshold 14 NS Release 15 ENH Effect On/Off 16 ENH Detect 17 ENH Sens 18 ENH Frequency 19 ENH Mix Level 1A ENH Low Mix Level 1B ENH Level 1C GEQ Effect On/Off 1D GEQ Input Gain 1E GEQ Level 1F GEQ 31.2 Hz 20 GEQ 62.5 Hz 21 GEQ 125 Hz 22 GEQ 250 Hz 23 GEQ 500 Hz 24 GEQ 1.0 kHz 25 GEQ 2.0 kHz 26 GEQ 4.0 kHz 27 GEQ 8.0 kHz 28 GEQ 16 kHz 29 DELAY Effect On/Off 2A DELAY Delay Time L 2B DELAY Fine Time L 2C DELAY Delay Time R 2D DELAY Fine Time R 2E DELAY Feedbk L 2F DELAY Feedbk R 30 DELAY FX Level 31 DELAY Dir Level 32 DELAY High Damp Gain 33 DELAY High Cut Filter

<<< 2CH RSS >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 EQ Effect On/Off 05 EQ Low EQ 06 EQ High EQ 07 EQ Level 08 EQ Lo-Mid f 09 EQ Lo-Mid Q 0A EQ Lo-Mi EQ 0B EQ Hi-Mid f 0C EQ Hi-Mid Q 0D EQ Hi-Mid EQ 0E RSS Effect On/Off 0F RSS Azimuth L 10 RSS Elevation L 11 RSS Azimuth R 12 RSS Elevation R

<<< ACOUSTIC MULTI >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 ACOUSTIC Effect On/Off 06 ACOUSTIC Body 07 ACOUSTIC Mic Distance 08 COMP Effect On/Off 09 COMP [COMP]Sustain 0A COMP [COMP]Attack 0B COMP [COMP]Tone 0C COMP [COMP]Level 0D COMP [LIMIT]Threshold 0E COMP [LIMIT]Release 0F COMP [LIMIT]Tone 10 COMP [LIMIT]Level 11 PREAMP Effect On/Off 12 PREAMP Volume 13 PREAMP Bass 14 PREAMP Middle 15 PREAMP Treble 16 PREAMP Presence 17 PREAMP Master 18 PREAMP Gain 19 PREAMP Mic Setting 1A PREAMP MicLevel 1B PREAMP Dir Level 1C AFB Effect On/Off 1D AFB Depth 1E AFB Frequency 1F NS Effect On/Off 20 NS Threshold 21 NS Release 22 CHORUS Effect On/Off 23 CHORUS Xover f 24 CHORUS Low Rate 25 CHORUS Low Depth 26 CHORUS Low Pre Delay 27 CHORUS Low Level 28 CHORUS High Rate 29 CHORUS High Depth 2A CHORUS HighPre Delay 2B CHORUS HighLevel 2C REVERB Effect On/Off 2D REVERB Reverb Time 2E REVERB Pre Delay 2F REVERB Low Cut 30 REVERB High Cut 31 REVERB Density 32 REVERB FX Level

<<< BASS MULTI >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 DEFRET Effect On/Off 06 DEFRET [COMP]Sustain 07 DEFRET [COMP]Attack 08 DEFRET [COMP]Enh Freq 09 DEFRET [COMP]Enh Level 0A DEFRET [COMP]Level 0B DEFRET [DEFRET]Sens 0C DEFRET [DEFRET]Attack 0D DEFRET [DEFRET]Depth 0E DEFRET [DEFRET]Level 0F OCT Effect On/Off 10 OCT Oct Level 11 OCT Dir Level 12 PREAMP Effect On/Off 13 PREAMP Volume 14 PREAMP Bass

44

MIDI インプリメンテーション

15 PREAMP Middle 16 PREAMP Treble 17 PREAMP Master 18 PREAMP Bright 19 PREAMP Gain 1A PREAMP Mic Setting 1B PREAMP Mic Level 1C PREAMP Dir Level 1D DIST Effect On/Off 1E DIST Drive 1F DIST Bass 20 DIST Treble 21 DIST FX Level 22 DIST Dir Level 23 EQ/TWAH Effect On/Off 24 EQ/TWAH [EQ] Low EQ 25 EQ/TWAH [EQ] High EQ 26 EQ/TWAH [EQ] Level 27 EQ/TWAH [EQ] Lo-Mid f 28 EQ/TWAH [EQ] Lo-Mid Q 29 EQ/TWAH [EQ] Lo-Mid EQ 2A EQ/TWAH [EQ] Hi-Mid f 2B EQ/TWAH [EQ] Hi-Mid Q 2C EQ/TWAH [EQ] Hi-Mid EQ 2D EQ/TWAH [TWAH] Sens 2E EQ/TWAH [TWAH] Start 2F EQ/TWAH [TWAH] Stop 30 EQ/TWAH [TWAH] Resonance 31 EQ/TWAH [TWAH] FX Level 32 EQ/TWAH [TWAH] Dir Level 33 NS Effect On/Off 34 NS Threshold 35 NS Release 36 DELAY Effect On/Off 37 DELAY Delay Time 38 DELAY Fine Time 39 DELAY Tap Time 3A DELAY Feedback 3B DELAY High Cut 3C DELAY FX Level 3D MOD Effect On/Off 3E MOD [FL] Rate 3F MOD [FL] Depth 40 MOD [FL] Manual 41 MOD [FL] Resonance 42 MOD [FL] Sepatate 43 MOD [FL] Level 44 MOD [PH] Rate 45 MOD [PH] Depth 46 MOD [PH] Manual 47 MOD [PH] Resonance 48 MOD [CE] Mode 49 MOD [CE] Rate 4A MOD [CE] Depth 4B MOD [CE] Pre Delay 4C MOD [CE] Low Cut 4D MOD [CE] FXLevel 4E REVERB Effect On/Off 4F REVERB Reverb Time 50 REVERB Pre Delay 51 REVERB Low Cut 52 REVERB High Cut 53 REVERB Density 54 REVERB FX Level

<<< CHORUS RSS >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 EQ Effect On/Off 06 EQ Low EQ 07 EQ High EQ 08 EQ Level 09 EQ Lo-Mid f 0A EQ Lo-Mid Q

0B EQ Lo-Mi EQ 0C EQ Hi-Midf 0D EQ Hi-MidQ 0E EQ Hi-Mid EQ 0F CE Effect On/Off 10 CE Polarity 11 CE Rate 12 CE Depth 13 CE Pre Delay 14 CE LowCut 15 CE HighCut 16 CE Effect Level 17 CE Direct On/Off 18 CE RSS On/Off

<<< CHORUS + REVERB >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 EQL Effect On/Off 06 EQL Low EQ 07 EQL High EQ 08 EQL Level 09 EQL Lo-Mid f 0A EQL Lo-MidQ 0B EQL Lo-MidEQ 0C EQL Hi-Midf 0D EQL Hi-MidQ 0E EQL Hi-MidEQ 0F CE Effect On/Off 10 CE Rate 11 CE Depth 12 CE Pre Delay 13 CE LowCut 14 CE HighCut 15 CE FXLevel 16 CE Direct On/Off 17 EQR Effect On/Off 18 EQR LowEQ 19 EQR HighEQ 1A EQR Level 1B EQR Lo-Mid f 1C EQR Lo-Mid Q 1D EQR Lo-Mid EQ 1E EQR Hi-Mid f 1F EQR Hi-Mid Q 20 EQR Hi-MidEQ 21 REV Effect On/Off 22 REV Reverb Time 23 REV Balance DIR:FX 24 REV Effect Level 25 REV Pre Delay 26 REV Density 27 REV Low Cut 28 REV High Cut

<<< DELAY >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 EQ Effect On/Off 06 EQ Low EQ 07 EQ High EQ 08 EQ Level 09 EQ Lo-Mid f 0A EQ Lo-Mid Q 0B EQ Lo-Mi EQ 0C EQ Hi-Midf 0D EQ Hi-MidQ 0E EQ Hi-Mid EQ 0F DELAY Effect On/Off 10 DELAY [SINGLE]Delay Time

45

MIDI インプリメンテーション

11 DELAY [SINGLE]Fine Time 12 DELAY [3TAP]Delay Time C 13 DELAY [3TAP]Fine Time C 14 DELAY [3TAP]Time L 15 DELAY [3TAP]Time R 16 DELAY Feedback 17 DELAY Level C 18 DELAY Level L 19 DELAY Level R 1A DELAY FX Level 1B DELAY Dir Level 1C DELAY High Damp Gain 1D DELAY High Cut Filter

<<< DELAY RSS >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 EQ Effect On/Off 06 EQ Low EQ 07 EQ High EQ 08 EQ Level 09 EQ Lo-Mid f 0A EQ Lo-Mid Q 0B EQ Lo-Mi EQ 0C EQ Hi-Mid f 0D EQ Hi-Mid Q 0E EQ Hi-Mid EQ 0F DELAY Effect On/Off 10 DELAY Delay Time C 11 DELAY Fine Time C 12 DELAY Time L 13 DELAY Time R 14 DELAY Feedback 15 DELAY Level C 16 DELAY Level L 17 DELAY Level R 18 DELAY FX Level 19 DELAY Dir Level 1A DELAY High Damp Gain 1B DELAY High Cut Filter 1C DELAY RSS On/Off

<<< DELAY + CHORUS >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 EQL Effect On/Off 06 EQL Low EQ 07 EQL High EQ 08 EQL Level 09 EQL Lo-Mid f 0A EQL Lo-Mid Q 0B EQL Lo-Mid EQ 0C EQL Hi-Mid f 0D EQL Hi-Mid Q 0E EQL Hi-Mid EQ 0F DLY Effect On/Off 10 DLY [SINGLE]Delay Time 11 DLY [SINGLE]Fine Time 12 DLY [3TAP]Delay Time C 13 DLY [3TAP]Fine Time C 14 DLY [3TAP]Time L 15 DLY [3TAP]Time R 16 DLY Feedback 17 DLY Level C 18 DLY Level L 19 DLY Level R 1A DLY FX Level 1B DLY Dir Level 1C DLY High Damp Gain 1D DLY High Cut Filter

1E EQR Effect On/Off 1F EQR LowEQ 20 EQR HighEQ 21 EQR Level 22 EQR Lo-Mid f 23 EQR Lo-Mid Q 24 EQR Lo-Mid EQ 25 EQR Hi-Midf 26 EQR Hi-MidQ 27 EQR Hi-MidEQ 28 CE Effect On/Off 29 CE Rate 2A CE Depth 2B CE Pre Delay 2C CE Low Cut 2D CE High Cut 2E CE FX Level 2F CE Direct On/Off

<<< DELAY + REVERB >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 EQL Effect On/Off 06 EQL Low EQ 07 EQL High EQ 08 EQL Level 09 EQL Lo-Mid f 0A EQL Lo-MidQ 0B EQL Lo-MidEQ 0C EQL Hi-Midf 0D EQL Hi-MidQ 0E EQL Hi-MidEQ 0F DLY Effect On/Off 10 DLY [SINGLE]Delay Time 11 DLY [SINGLE]Fine Time 12 DLY [3TAP]Delay Time C 13 DLY [3TAP]Fine Time C 14 DLY [3TAP]Time L 15 DLY [3TAP]Time R 16 DLY Feedback 17 DLY Level C 18 DLY Level L 19 DLY Level R 1A DLY FX Level 1B DLY Dir Level 1C DLY High Damp Gain 1D DLY High Cut Filter 1E EQR Effect On/Off 1F EQR LowEQ 20 EQR HighEQ 21 EQR Level 22 EQR Lo-Mid f 23 EQR Lo-Mid Q 24 EQR Lo-Mid EQ 25 EQR Hi-Midf 26 EQR Hi-MidQ 27 EQR Hi-MidEQ 28 REV Effect On/Off 29 REV Reverb Time 2A REV Balance DIR:FX 2B REV Effect Level 2C REV Pre Delay 2D REV Density 2E REV Low Cut 2F REV High Cut

<<< GATE REVERB >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 EQ Effect On/Off 05 EQ Low EQ

46

MIDI インプリメンテーション

06 EQ High EQ 07 EQ Level 08 EQ Lo-Mid f 09 EQ Lo-Mid Q 0A EQ Lo-Mi EQ 0B EQ Hi-Mid f 0C EQ Hi-Mid Q 0D EQ Hi-Mid EQ 0E REVERB Effect On/Off 0F REVERB Room Size 10 REVERB Reverb Time 11 REVERB Balance Dir:FX 12 REVERB Effect Level 13 REVERB Pre Delay 14 REVERB Density 15 REVERB ER Level 16 REVERB Release Dnsty 17 REVERB Low Damp Gain 18 REVERB Low Damp Freq 19 REVERB High Damp Gain 1A REVERB High Damp Freq 1B REVERB High Cut Filter 1C GATE Gate On/Off 1D GATE Threshold 1E GATE Hold Time 1F GATE Rls Time

<<< GUITAR MULTI 1 >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 COMP Effect On/Off 06 COMP [COMP]Sustain 07 COMP [COMP]Attack 08 COMP [COMP]Tone 09 COMP [COMP]Level 0A COMP [LIMIT]Threshold 0B COMP [LIMIT]Release 0C COMP [LIMIT]Tone 0D COMP [LIMIT]Level 0E WAH Effect On/Off 0F WAH [WAH]Pedal 10 WAH [WAH]Level 11 WAH [AW]Mode 12 WAH [AW]Polarity 13 WAH [AW]Sens 14 WAH [AW]Freq 15 WAH [AW]Peak 16 WAH [AW]Rate 17 WAH [AW]Depth 18 WAH [AW]Level 19 PREAMP Effect On/Off 1A PREAMP Volume 1B PREAMP Bass 1C PREAMP Middle 1D PREAMP Treble 1E PREAMP Presence 1F PREAMP Master 20 PREAMP Bright 21 PREAMP Gain 22 PREAMP Mic Setting 23 PREAMP Mic Level 24 PREAMP Direct Level 25 EQ Effect On/Off 26 EQ Low EQ 27 EQ High EQ 28 EQ Level 29 EQ Lo-Mid f 2A EQ Lo-Mid Q 2B EQ Lo-Mid EQ 2C EQ Hi-Mid f 2D EQ Hi-Mid Q 2E EQ Hi-Mid EQ 2F NS Effect On/Off 30 NS Threshold

31 NS Release 32 MOD Effect On/Off 33 MOD [HR]Voice 34 MOD [HR][1]Mode 35 MOD [HR][2]Mode 36 MOD [HR][1]Pitch 37 MOD [HR][1]Fine 38 MOD [HR][2]Pitch 39 MOD [HR][2]Fine 3A MOD [HR][1] Harmony 3B MOD [HR][2] Harmony 3C MOD [HR][1] Pre Delay 3D MOD [HR][2] Pre Delay 3E MOD [HR][1]Feedback 3F MOD [HR][1]Level 40 MOD [HR][2]Level 41 MOD [HR]Key 42 MOD [HR]Dir Level 43 MOD [FL] Rate 44 MOD [FL] Depth 45 MOD [FL] Manual 46 MOD [FL] Resonance 47 MOD [FL] Separate 48 MOD [FL] Level 49 MOD [FL] Type 4A MOD [PH] Rate 4B MOD [PH] Depth 4C MOD [PH] Manual 4D MOD [PH] Resonance 4E MOD [PH] dummy 4F MOD [PH] Step 50 MOD [PH] Level 51 MOD [SEQ] Low EQ 52 MOD [SEQ] High EQ 53 MOD [SEQ] Lo-Mid f 54 MOD [SEQ] Lo-Mid Q 55 MOD [SEQ] Lo-Mi EQ 56 MOD [SEQ] Hi-Mid f 57 MOD [SEQ] Hi-Mid Q 58 MOD [SEQ] Hi-Mid EQ 59 MOD [SEQ] Level 5A MOD [2CE] Xover f 5B MOD [2CE] Low Rate 5C MOD [2CE] Low Depth 5D MOD [2CE] Low Pre Delay 5E MOD [2CE] Low Level 5F MOD [2CE] High Rate 60 MOD [2CE] High Depth 61 MOD [2CE] High Pre Delay 62 MOD [2CE] High Level 63 MOD [SDD] Delay Time 64 MOD [SDD] Feedback 65 MOD [SDD] FX Level 66 MOD [HU]Mode 67 MOD [HU]Vowel 1 68 MOD [HU]Vowel 2 69 MOD [HU]Sens 6A MOD [HU] Rate 6B MOD [HU] Depth 6C MOD [HU] Manual 6D MOD [HU] Level 6E MOD [VB]Rate 6F MOD [VB]Depth 70 MOD [VB]Trigger 71 MOD [VB]Rise Time 72 MOD [SYN]Sens 73 MOD [SYN]Wave 74 MOD [SYN]Chromatic 75 MOD [SYN]Oct Shift 76 MOD [SYN]PWM Rate 77 MOD [SYN]PWM Depth 78 MOD [SYN]Cutoff F 79 MOD [SYN]Resonance 7A MOD [SYN] FLT. Sens 7B MOD [SYN] FLT. Decay 7C MOD [SYN] FLT. Depth 7D MOD [SYN] Attack 7E MOD [SYN] Release 7F MOD [SYN] Velocity

47

MIDI インプリメンテーション

80 MOD [SYN] Hold 81 MOD [SYN] Synth Level 82 MOD [SYN] Dir Level 83 MOD [RM] Mode 84 MOD [RM] Freq 85 MOD [RM] FX Level 86 MOD [RM] Dir Level 87 MOD [SL] Pattern 88 MOD [SL] Rate 89 MOD [SL] Trigger Sens 8A DELAY Effect On/Off 8B DELAY Delay Time 8C DELAY Fine Time 8D DELAY Tap Time 8E DELAY Feedback 8F DELAY High Cut 90 DELAY FX Level 91 CHORUS Effect On/Off 92 CHORUS Mode 93 CHORUS Rate 94 CHORUS Depth 95 CHORUS Pre Delay 96 CHORUS High Cut 97 CHORUS FX Level 98 REVERB Effect On/Off 99 REVERB Reverb Time 9A REVERB Pre Delay 9B REVERB Low Cut 9C REVERB High Cut 9D REVERB Density 9E REVERB FX Level

<<< GUITAR MULTI 2 >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 COMP Effect On/Off 06 COMP [COMP]Sustain 07 COMP [COMP]Attack 08 COMP [COMP]Tone 09 COMP [COMP]Level 0A COMP [LIMIT]Threshold 0B COMP [LIMIT]Release 0C COMP [LIMIT]Tone 0D COMP [LIMIT]Level 0E WAH Effect On/Off 0F WAH [WAH]Pedal 10 WAH [WAH]Level 11 WAH [AW]Mode 12 WAH [AW]Polarity 13 WAH [AW]Sens 14 WAH [AW]Freq 15 WAH [AW]Peak 16 WAH [AW]Rate 17 WAH [AW]Depth 18 WAH [AW]Level 19 PREAMP Effect On/Off 1A PREAMP Volume 1B PREAMP Bass 1C PREAMP Middle 1D PREAMP Treble 1E PREAMP Presence 1F PREAMP Master 20 PREAMP Bright 21 PREAMP Gain 22 PREAMP Mic Setting 23 PREAMP Mic Level 24 PREAMP Direct Level 25 EQ Effect On/Off 26 EQ Low EQ 27 EQ High EQ 28 EQ Level 29 EQ Lo-Mid f 2A EQ Lo-Mid Q 2B EQ Lo-Mid EQ

2C EQ Hi-Midf 2D EQ Hi-MidQ 2E EQ Hi-Mid EQ 2F NS Effect On/Off 30 NS Threshold 31 NS Release 32 SFX Effect On/Off 33 SFX [AC]Top 34 SFX [AC]Body 35 SFX [AC]Level 36 SFX [BSS]Character 37 SFX [BSS]FX Level 38 SFX [BSS]Dir Level 39 SFX [SG]Sens 3A SFX [SG]Rise Time 3B SFX [FB]Mode 3C SFX [FB]RiseTime 3D SFX [FB]RiseTime ( ▲ ) 3E SFX [FB]F.B.Level 3F SFX [FB]F.B.Level(▲ ) 40 SFX [FB]Vib Rate 41 SFX [FB]Vib Depth 42 SFX [FB]F.B.Depth 43 SFX [FB]F.B.Tone 44 SFX [PIC]Type 45 SFX [PIC]Tone 46 SFX [PIC]Level 47 SFX [TR]Mode 48 SFX [TR]Wave Shape 49 SFX [TR]Rate 4A SFX [TR]Depth 4B DELAY EffectOn/Off 4C DELAY Delay Time 4D DELAY FineTime 4E DELAY Tap Time 4F DELAY Feedback 50 DELAY High Cut 51 DELAY FX Level 52 CHORUS Effect On/Off 53 CHORUS Mode 54 CHORUS Rate 55 CHORUS Depth 56 CHORUS Pre Delay 57 CHORUS High Cut 58 CHORUS FX Level 59 REVERB Effect On/Off 5A REVERB Reverb Time 5B REVERB Pre Delay 5C REVERB Low Cut 5D REVERB High Cut 5E REVERB Density 5F REVERB FX Level

<<< HUM CANCELER >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 HUM Effect On/Off 05 HUM Frequency 06 HUM Width 07 HUM Depth 08 HUM Threshold 09 HUM Range Low 0A HUM Range High 0B NS Effect On/Off 0C NS Threshold 0D NS Release

<<< ISOLATOR >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 ISO EffectOn/Off

48

MIDI インプリメンテーション

06 ISO AntiPhase LowLevel 07 ISO AntiPhase MidLevel 08 ISO Low Mix Switch 09 ISO Mid Mix Switch 0A ISO Low Level 0B ISO Mid Level 0C ISO High Level 0D MOD Effect On/Off 0E MOD [PH] Mode 0F MOD [PH] Rate 10 MOD [PH] Depth 11 MOD [PH] Manual 12 MOD [PH] Resonance 13 MOD [PH] Separate 14 MOD [PH] Step 15 MOD [FL] Rate 16 MOD [FL] Depth 17 MOD [FL] Manual 18 MOD [FL] Resonance 19 MOD [FL] Separate 1A MOD [FL] Gate 1B MOD [CE] Polarity 1C MOD [CE] Rate 1D MOD [CE] Depth 1E MOD [CE] PreDelay 1F MOD [CE] Low Cut 20 MOD [CE] High Cut 21 MOD [CE] Effect Level 22 MOD [SL] Pattern 23 MOD [SL] Rate 24 MOD [SL] Trigger Sens 25 DELAY Effect On/Off 26 DELAY Delay Time L 27 DELAY Fine Time L 28 DELAY Delay Time R 29 DELAY Fine Time R 2A DELAY Feedbk L 2B DELAY Feedbk R 2C DELAY FX Level 2D DELAY Dir Level 2E DELAY High Damp Gain 2F DELAY High Cut Filter

<<< KEYBOARD MULTI >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 RING Effect On/Off 06 RING Freq 07 RING FX Level 08 RING Dir Level 09 EQ Effect On/Off 0A EQ Low EQ 0B EQ High EQ 0C EQ Level 0D EQ Lo-Mid f 0E EQ Lo-Mid Q 0F EQ Lo-Mid EQ 10 EQ Hi-Mid f 11 EQ Hi-Mid Q 12 EQ Hi-Mid EQ 13 NS Effect On/Off 14 NS Threshold 15 NS Release 16 PS Effect On/Off 17 PS Mode 18 PS Pitch 19 PS Fine 1A PS Balance Dir:FX 1B PS Level 1C MOD Effect On/Off 1D MOD [FL] Rate 1E MOD [FL] Depth 1F MOD [FL] Manual 20 MOD [FL] Resonance

21 MOD [FL] Separate 22 MOD [PH] Rate 23 MOD [PH] Depth 24 MOD [PH] Manual 25 MOD [PH] Resonance 26 MOD [PH] Separate 27 DELAY Effect On/Off 28 DELAY Delay Time 29 DELAY Fine Time 2A DELAY Feedback 2B DELAY FXLevel 2C CHORUS EffectOn/Off 2D CHORUS Polarity 2E CHORUS Rate 2F CHORUS Depth 30 CHORUS Pre Delay 31 CHORUS High Cut 32 CHORUS Effect Level 33 TREMOLO EffectOn/Off 34 TREMOLO FXSelect 35 TREMOLO WaveShape 36 TREMOLO Rate 37 TREMOLO Depth 38 REVERB Effect On/Off 39 REVERB Reverb Time 3A REVERB Pre Delay 3B REVERB Low Cut 3C REVERB High Cut 3D REVERB Density 3E REVERB FX Level

<<< LOFI PROCESSOR >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 EQ Effect On/Off 05 EQ Low EQ 06 EQ High EQ 07 EQ Level 08 EQ Lo-Mid f 09 EQ Lo-Mid Q 0A EQ Lo-Mi EQ 0B EQ Hi-Midf 0C EQ Hi-MidQ 0D EQ Hi-MidEQ 0E BOX Effect On/Off 0F BOX [RADIO]Tuning 10 BOX [RADIO]Noise 11 BOX [RADIO]Filter 12 BOX [RADIO]Sound 13 BOX [PLAYER]Wow Flutter 14 BOX [PLAYER]Noise 15 BOX [PLAYER]Filter 16 BOX [PLAYER]Sound 17 BOX [PROCESSOR]Pre Filter 18 BOX [PROCESSOR]Sample Rate 19 BOX [PROCESSOR]Bit 1A BOX [PROCESSOR]PostFilter 1B BOX [PROCESSOR]FX Level 1C BOX [PROCESSOR]DirLevel 1D BOX [PROCESSOR]RM F 1E BOX [PROCESSOR]Cut Off 1F BOX [PROCESSOR]Resonance 20 BOX [PROCESSOR]Gain 21 NS Effect On/Off 22 NS Threshold 23 NS Release

<<< MIC SIMULATOR >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER MasterLink 03 MASTER Master Level 04 MASTER Foot Level 05 MCVL EffectOn/Off

49

MIDI インプリメンテーション

06 MCVL Input 07 MCVL Output 08 MCVL Phase 09 BCTL Effect On/Off 0A BCTL Frequency 0B DSTL Effect On/Off 0C DSTL Prox.Fx 0D DSTL Time 0E LIMITL Effect On/Off 0F LIMITL Threshold 10 LIMITL Attack 11 LIMITL Release 12 LIMITL Detect HPF 13 LIMITL Level 14 MCVR Effect On/Off 15 MCVR Input 16 MCVR Output 17 MCVR Phase 18 BCTR Effect On/Off 19 BCTR Frequency 1A DSTR Effect On/Off 1B DSTR Prox.Fx 1C DSTR Time 1D LIMITR Effect On/Off 1E LIMITR Threshold 1F LIMITR Attack 20 LIMITR Release 21 LIMITR Detect HPF 22 LIMITR Level

<<< MULTI TAPDELAY >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 EQ Effect On/Off 06 EQ Low EQ 07 EQ High EQ 08 EQ Level 09 EQ Lo-Mid f 0A EQ Lo-Mid Q 0B EQ Lo-Mi EQ 0C EQ Hi-Mid f 0D EQ Hi-Mid Q 0E EQ Hi-Mid EQ 0F DLY Effect On/Off 10 DLY Ratio 11 DLY Delay Time1 12 DLY Fine Time 1 13 DLY Pan1 14 DLY Tap Level1 15 DLY Delay Time2 16 DLY Fine Time 2 17 DLY Pan2 18 DLY Tap Level2 19 DLY Delay Time3 1A DLY Fine Time 3 1B DLY Pan3 1C DLY Tap Level3 1D DLY Delay Time4 1E DLY Fine Time 4 1F DLY Pan4 20 DLY Tap Level4 21 DLY Delay Time5 22 DLY Fine Time 5 23 DLY Pan5 24 DLY Tap Level5 25 DLY Delay Time6 26 DLY Fine Time6 27 DLY Pan6 28 DLY Tap Level6 29 DLY Delay Time7 2A DLY Fine Time 7 2B DLY Pan7 2C DLY Tap Level7 2D DLY Delay Time8

2E DLY Fine Time 8 2F DLY Pan8 30 DLY Tap Level8 31 DLY Delay Time9 32 DLY Fine Time 9 33 DLY Pan9 34 DLY Tap Level9 35 DLY Delay Time10 36 DLY Fine Time 10 37 DLY Pan10 38 DLY Tap Level10 39 DLY Delay Time11 3A DLY Fine Time 11 3B DLY Pan11 3C DLY Tap Level11 3D DLY Delay Time12 3E DLY Fine Time 12 3F DLY Pan12 40 DLY Tap Level12 41 DLY Delay Time13 42 DLY Fine Time 13 43 DLY Pan13 44 DLY Tap Level13 45 DLY Delay Time14 46 DLY Fine Time 14 47 DLY Pan14 48 DLY Tap Level14 49 DLY Delay Time15 4A DLY Fine Time 15 4B DLY Pan15 4C DLY Tap Level15 4D DLY Delay Time16 4E DLY Fine Time 16 4F DLY Pan16 50 DLY Tap Level16 51 DLY Delay Time17 52 DLY Fine Time 17 53 DLY Pan17 54 DLY Tap Level17 55 DLY Delay Time18 56 DLY Fine Time 18 57 DLY Pan18 58 DLY Tap Level18 59 DLY Delay Time19 5A DLY Fine Time 19 5B DLY Pan19 5C DLY Tap Level19 5D DLY Delay Time20 5E DLY Fine Time 20 5F DLY Pan20 60 DLY Tap Level20 61 DLY FB Delay 62 DLY FB Fine 63 DLY FB Level 64 DLY Low Cut 65 DLY High Cut 66 DLY Dir Level 67 DLY FX Level

<<< REVERB 1 >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 EQ Effect On/Off 06 EQ Low EQ 07 EQ High EQ 08 EQ Level 09 EQ Lo-Mid f 0A EQ Lo-Mid Q 0B EQ Lo-Mi EQ 0C EQ Hi-Midf 0D EQ Hi-MidQ 0E EQ Hi-Mid EQ 0F REVERB Effect On/Off 10 REVERB Room Size

50

MIDI インプリメンテーション

11 REVERB Reverb Time 12 REVERB Balance Dir:FX 13 REVERB Effect Level 14 REVERB Pre Delay 15 REVERB Density 16 REVERB ER Level 17 REVERB Release Density 18 REVERB Low Damp Gain 19 REVERB Low Damp Freq 1A REVERB High Damp Gain 1B REVERB High Damp Freq 1C REVERB High Cut Filter 1D DELAY Effect On/Off 1E DELAY [SINGLE]Delay Time 1F DELAY [SINGLE]Fine Time 20 DELAY [3TAP]Delay Time C 21 DELAY [3TAP]Fine Time C 22 DELAY [3TAP]Time L 23 DELAY [3TAP]Time R 24 DELAY Feedback 25 DELAY Level C 26 DELAY Level L 27 DELAY Level R 28 DELAY FX Level 29 DELAY dummy 2A DELAY High Damp Gain 2B DELAY High Cut Filter

<<< REVERB 2 >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 EQ Effect On/Off 06 EQ Low EQ 07 EQ High EQ 08 EQ Level 09 EQ Lo-Mid f 0A EQ Lo-Mid Q 0B EQ Lo-Mi EQ 0C EQ Hi-Mid f 0D EQ Hi-Mid Q 0E EQ Hi-Mid EQ 0F CHORUS Effect On/Off 10 CHORUS Polarity 11 CHORUS Rate 12 CHORUS Depth 13 CHORUS Pre Delay 14 CHORUS Low Cut 15 CHORUS High Cut 16 CHORUS Effect Level 17 CHORUS Direct On/Off 18 REVERB Effect On/Off 19 REVERB Reverb Type 1A REVERB Room Size 1B REVERB Reverb Time 1C REVERB Balance Dir:FX 1D REVERB Effect Level 1E REVERB Pre Delay 1F REVERB Density 20 REVERB ER Level 21 REVERB Low Damp Gain 22 REVERB Low Damp Freq 23 REVERB High Damp Gain 24 REVERB High Damp Freq 25 REVERB High Cut Filter

<<< REVERB RSS >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 EQ Effect On/Off 05 EQ Low EQ 06 EQ High EQ

07 EQ Level 08 EQ Lo-Mid f 09 EQ Lo-Mid Q 0A EQ Lo-Mi EQ 0B EQ Hi-Midf 0C EQ Hi-MidQ 0D EQ Hi-MidEQ 0E REVERB Effect On/Off 0F REVERB Size 10 REVERB Reverb Time 11 REVERB Balance Dir:FX 12 REVERB Level 13 REVERB Pre Delay 14 REVERB Density 15 REVERB ER Level 16 REVERB Low Damp Gain 17 REVERB Low Damp Freq 18 REVERB High Damp Gain 19 REVERB High Damp Freq 1A REVERB High Cut Filter 1B REVERB RSS On/Off

<<< REVERB + REVERB >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 EQL Effect On/Off 05 EQL Low EQ 06 EQL High EQ 07 EQL Level 08 EQL Lo-Mid f 09 EQL Lo-Mid Q 0A EQL Lo-Mi EQ 0B EQL Hi-Midf 0C EQL Hi-MidQ 0D EQL Hi-MidEQ 0E RVL Effect On/Off 0F RVL Size 10 RVL Reverb Time 11 RVL Balance Dir:FX 12 RVL Effect Level 13 RVL Pre Delay 14 RVL Density 15 RVL ER Level 16 RVL Low Damp Gain 17 RVL Low Damp Freq 18 RVL High Damp Gain 19 RVL High Damp Freq 1A RVL High Cut Filter 1B EQR Effect On/Off 1C EQR Low EQ 1D EQR High EQ 1E EQR Level 1F EQR Lo-Mid f 20 EQR Lo-Mid Q 21 EQR Lo-Mi EQ 22 EQR Hi-Midf 23 EQR Hi-MidQ 24 EQR Hi-MidEQ 25 RVR Effect On/Off 26 RVR Reverb Time 27 RVR Balance DIR:FX 28 RVR Effect Level 29 RVR Pre Delay 2A RVR Density 2B RVR LowCut 2C RVR HighCut

<<< ROTARY MULTI >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 EQ Effect On/Off 05 EQ Low EQ

51

MIDI インプリメンテーション

06 EQ High EQ 07 EQ Level 08 EQ Lo-Mid f 09 EQ Lo-Mid Q 0A EQ Lo-Mi EQ 0B EQ Hi-Mid f 0C EQ Hi-Mid Q 0D EQ Hi-Mid EQ 0E ODV Effect On/Off 0F ODV Gain 10 ODV Drive 11 ODV Level 12 ROTARY Effect On/Off 13 ROTARY Speed Select 14 ROTARY Horn Fast 15 ROTARY Rotor Fast 16 ROTARY Horn Slow 17 ROTARY Rotor Slow 18 ROTARY Rise Time Horn 19 ROTARY Rise Time Rotor 1A ROTARY Fall Time Horn 1B ROTARY Fall Time Rotor 1C ROTARY R:H Balance 1D ROTARY Mic Setting 1E ROTARY Horn Depth 1F ROTARY Rotor Depth 20 ROTARY Horn Trmlo 21 ROTARY Rotor Trmlo 22 ROTARY Diffusion 23 ROTARY FX Level 24 NS Effect On/Off 25 NS Threshold 26 NS Release 27 REVERB Effect On/Off 28 REVERB Reverb Time 29 REVERB Pre Delay 2A REVERB Low Cut 2B REVERB High Cut 2C REVERB Density 2D REVERB FX Level

<<< RSS PANNER >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 EQ Effect On/Off 06 EQ Low EQ 07 EQ High EQ 08 EQ Level 09 EQ Lo-Mid f 0A EQ Lo-Mid Q 0B EQ Lo-Mi EQ 0C EQ Hi-Mid f 0D EQ Hi-Mid Q 0E EQ Hi-Mid EQ 0F FLANGER Effect On/Off 10 FLANGER Rate 11 FLANGER Depth 12 FLANGER Manual 13 FLANGER Resonance 14 FLANGER dummy 15 FLANGER Gate 16 FLANGER Direct Switch 17 PANNER Effect On/Off 18 PANNER Speed 19 PANNER Direction

<<< SPACE CHORUS >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 CHORUS Effect On/Off 05 CHORUS Input

06 CHORUS Mode 07 CHORUS Effect Level 08 CHORUS Direct On/Off 09 EQ Effect On/Off 0A EQ LowEQ 0B EQ HighEQ 0C EQ Level 0D EQ Lo-Mid f 0E EQ Lo-Mid Q 0F EQ Lo-Mi EQ 10 EQ Hi-Mid f 11 EQ Hi-Mid Q 12 EQ Hi-Mid EQ

<<<SPEAKER MODELING>>>

ADATA DESCRIPTION 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 05 SP MODEL Effect On/Off 06 SP MODEL MODEL 07 SP MODEL Phase 08 BCF Effect On/Off 09 BCF Frequency 0A LMT Effect On/Off 0B LMT Gain 0C LMT Frequency 0D HMT EffectOn/Off 0E HMT Gain 0F HMT Frequency 10 LIMIT Effect On/Off 11 LIMIT Threshold 12 LIMIT Release 13 LIMIT Level

<<< STEREO CHORUS DELAY>>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 DELAY Effect On/Off 06 DELAY Delay Time L 07 DELAY Fine Time L 08 DELAY Delay Time R 09 DELAY Fine Time R 0A DELAY Feedbk L 0B DELAY Feedbk R 0C DELAY FXLevel 0D DELAY Dir Level 0E DELAY High Damp Gain 0F DELAY High Cut Filter 10 CE Effect On/Off 11 CE Polarity 12 CE Rate 13 CE Depth 14 CE Pre Delay 15 CE LowCut 16 CE HighCut 17 CE Effect Level 18 CE Direct On/Off 19 EQ Effect On/Off 1A EQ LowEQ 1B EQ HighEQ 1C EQ Level 1D EQ Lo-Mid f 1E EQ Lo-Mid Q 1F EQ Lo-Mi EQ 20 EQ Hi-Mid f 21 EQ Hi-Mid Q 22 EQ Hi-Mid EQ

<<< STEREO FLANGER DELAY >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off

52

MIDI インプリメンテーション

02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 DELAY Effect On/Off 06 DELAY Delay Time L 07 DELAY Fine Time L 08 DELAY Delay Time R 09 DELAY Fine Time R 0A DELAY Feedbk L 0B DELAY Feedback R 0C DELAY FX Level 0D DELAY Dir Level 0E DELAY High Damp Gain 0F DELAY High Cut Filter 10 FL Effect On/Off 11 FL Rate 12 FL Depth 13 FL Manual 14 FL Resonance 15 FL Separate 16 FL Gate 17 FL Direct Switch 18 EQ Effect On/Off 19 EQ Low EQ 1A EQ High EQ 1B EQ Level 1C EQ Lo-Mid f 1D EQ Lo-Mid Q 1E EQ Lo-Mi EQ 1F EQ Hi-Mid f 20 EQ Hi-Mid Q 21 EQ Hi-Mid EQ

<<< STEREO MULTI >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 COMP Effect On/Off 06 COMP Detect 07 COMP [COMP]Threshold 08 COMP [COMP]Ratio 09 COMP [COMP]Attack 0A COMP [COMP]Release 0B COMP [COMP]Tone 0C COMP [COMP]Level 0D COMP [LIMIT]Threshold 0E COMP [LIMIT]Release 0F COMP [LIMIT]Tone 10 COMP [LIMIT]Level 11 NS Effect On/Off 12 NS Detect 13 NS Threshold 14 NS Release 15 ENH Effect On/Off 16 ENH Detect 17 ENH Sens 18 ENH Frequency 19 ENH Mix Level 1A ENH Low Mix Level 1B ENH Level 1C EQ Effect On/Off 1D EQ Low EQ 1E EQ High EQ 1F EQ Level 20 EQ Lo-Mid f 21 EQ Lo-Mid Q 22 EQ Lo-Mi EQ 23 EQ Hi-Mid f 24 EQ Hi-Mid Q 25 EQ Hi-Mid EQ 26 DELAY Effect On/Off 27 DELAY Delay Time L 28 DELAY Fine Time L 29 DELAY Delay Time R 2A DELAY Fine Time R

2B DELAY Feedbk L 2C DELAY Feedbk R 2D DELAY FXLevel 2E DELAY Dir Level 2F DELAY High Damp Gain 30 DELAY High Cut Filter

<<< STEREO PHASER DELAY >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 DELAY Effect On/Off 06 DELAY Delay Time L 07 DELAY Fine Time L 08 DELAY Delay Time R 09 DELAY Fine Time R 0A DELAY Feedbk L 0B DELAY Feedbk R 0C DELAY FXLevel 0D DELAY Dir Level 0E DELAY High Damp Gain 0F DELAY High Cut Filter 10 PH Phaser On/Off 11 PH Type 12 PH Rate 13 PH Depth 14 PH Manual 15 PH Resonance 16 PH Separate 17 PH Step 18 EQ Effect On/Off 19 EQ Low EQ 1A EQ HighEQ 1B EQ Level 1C EQ Lo-Mid f 1D EQ Lo-Mid Q 1E EQ Lo-Mi EQ 1F EQ Hi-Mid f 20 EQ Hi-Mid Q 21 EQ Hi-Mid EQ

<<< STEREO PITCH SHIFTER DELAY >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 PS Effect ON/Off 06 PS Mode 07 PS Pitch L 08 PS Fine L 09 PS Pitch R 0A PS FineR 0B PS Pre Delay L 0C PS Pre Delay R 0D PS FB Delay Time L 0E PS FB FineTime L 0F PS FB Delay Time R 10 PS FB Fine Time R 11 PS FB Level L 12 PS FB Level R 13 PS Balance Dir:FX 14 PS Level 15 EQ Effect On/Off 16 EQ Low EQ 17 EQ High EQ 18 EQ Level 19 EQ Lo-Mid f 1A EQ Lo-Mid Q 1B EQ Lo-Mi EQ 1C EQ Hi-Midf 1D EQ Hi-MidQ 1E EQ Hi-Mid EQ

53

MIDI インプリメンテーション

<<< TAPE ECHO 201 >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 ECHO Effect On/Off 05 ECHO Mode 06 ECHO Repeat Rate 07 ECHO Intensity 08 ECHO Tone Bass 09 ECHO Tone Treble 0A ECHO Pan HeadS 0B ECHO Pan HeadM 0C ECHO Pan HeadL 0D ECHO Tape Dist 0E ECHO Wow Rate 0F ECHO Wow Depth 10 ECHO FX Level 11 ECHO Dir Level

<<< VOCAL CANCELER >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 VCL Effect On/Off 05 VCL Balance 06 VCL Range Low 07 VCL Range High 08 NS Effect On/Off 09 NS Threshold 0A NS Release 0B EQ Effect On/Off 0C EQ Low EQ 0D EQ High EQ 0E EQ Level 0F EQ Lo-Mid f 10 EQ Lo-Mid Q 11 EQ Lo-Mi EQ 12 EQ Hi-Mid f 13 EQ Hi-Mid Q 14 EQ Hi-Mid EQ

<<< VOCAL MULTI >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 COMP Effect On/Off 06 COMP [COMP]Threshold 07 COMP [COMP]Ratio 08 COMP [COMP]Attack 09 COMP [COMP]Release 0A COMP [COMP]Tone 0B COMP [COMP]Level 0C COMP [LIMIT]Threshold 0D COMP [LIMIT]Release 0E COMP [LIMIT]Tone 0F COMP [LIMIT]Level 10 DES Effect On/Off 11 DES Sens 12 DES Frequency 13 EQ Effect On/Off 14 EQ Low EQ 15 EQ High EQ 16 EQ Level 17 EQ Lo-Mid f 18 EQ Lo-Mid Q 19 EQ Lo-Mi EQ 1A EQ Hi-Mid f 1B EQ Hi-Mid Q 1C EQ Hi-Mid EQ 1D EN Effect On/Off 1E EN Sens

1F EN Frequency 20 EN Mix Level 21 EN Lo Mix Level 22 EN Level 23 NS Effect On/Off 24 NS Threshold 25 NS Release 26 MOD Effect On/Off 27 MOD [FL] Rate 28 MOD [FL] Depth 29 MOD [FL] Manual 2A MOD [FL] Resonance 2B MOD [FL] Separate 2C MOD [FL] Level 2D MOD [PH] Type 2E MOD [PH] Rate 2F MOD [PH] Depth 30 MOD [PH] Manual 31 MOD [PH] Resonance 32 MOD [PH] dummy 33 MOD [PH] Step 34 MOD [PH] Level 35 MOD [PS] Mode 36 MOD [PS] Pitch 37 MOD [PS] Fine 38 MOD [PS] Balance Dir:FX 39 MOD [PS] Level 3A DELAY EffectOn/Off 3B DELAY Delay Time 3C DELAY FineTime 3D DELAY Tap Time 3E DELAY Feedback 3F DELAY High Cut 40 DELAY FX Level 41 CHORUS Effect On/Off 42 CHORUS Mode 43 CHORUS Rate 44 CHORUS Depth 45 CHORUS Pre Delay 46 CHORUS Low Cut 47 CHORUS High Cut 48 CHORUS FX Level 49 REVERB Effect On/Off 4A REVERB Reverb Time 4B REVERB Pre Delay 4C REVERB Low Cut 4D REVERB High Cut 4E REVERB Density 4F REVERB FX Level

<<< VOCODER >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 VC Effect On/Off 06 VC Envelope 07 VC Pan Mode 08 VC Hold 09 VC MicSens 0A VC Synth Level 0B VC Character Ch1 0C VC Character Ch2 0D VC Character Ch3 0E VC Character Ch4 0F VC Character Ch5 10 VC Character Ch6 11 VC Character Ch7 12 VC Character Ch8 13 VC Character Ch9 14 VC Character Ch10 15 VC MicMix 16 VC MicHPF 17 VC MicPan 18 VC NS Threshold 19 CHORUS Effect On/Off

54

1A CHORUS Polarity 1B CHORUS Rate 1C CHORUS Depth 1D CHORUS Pre Delay 1E CHORUS Low Cut 1F CHORUS High Cut 20 CHORUS Effect Level 21 REVERB Effect On/Off 22 REVERB Reverb Time 23 REVERB Pre Delay 24 REVERB Low Cut 25 REVERB High Cut 26 REVERB Density 27 REVERB FX Level

<<< VOICE TRANSFORMER >>>

Data(H) Description 00 GLOBAL Tuner On/Off 01 GLOBAL Effects On/Off 02 MASTER Master Level 03 MASTER Foot Level 04 MASTER Master BPM 05 VT Effect On/Off 06 VT Robot 07 VT Crmtc Pitch 08 VT Fine Pitch 09 VT Crmtc Frmt 0A VT Fine Frmt 0B VT Mix Bal 0C CHORUS Effect On/Off 0D CHORUS Mode 0E CHORUS Rate 0F CHORUS Depth 10 CHORUS Pre Delay 11 CHORUS Low Cut 12 CHORUS High Cut 13 CHORUS FX Level 14 REVERB Effect On/Off 15 REVERB Reverb Time 16 REVERB Pre Delay 17 REVERB Low Cut 18 REVERB High Cut 19 REVERB Density 1A REVERB FX Level

MIDI インプリメンテーション

Table-37. [SCR]

OFFSET SIZE DATA DESCRIPTION ** 00 00 00 00 02 00 Sound Change Request

※ TEMPORARY(バルク・エリア ) のデータを送信した後で、Sound Change

Request(SCR)を送ると、送信したデータにかわります。

Table-38. [PWR]

OFFSET SIZE DATA DESCRIPTION ** 00 00 00 00 02 00 Patch Write Request

※ User Patch, UTILITY MIDI PC MAP のデータを送信した後で、Patch Write

Request(PWR)を送ると、送信したデータを、本体メモリーに保存します。

55

ローランドのエクスクルーシブ・メッセージについて





ローランドのエクスクルーシブ・メッセージについて

MIDI インプリメンテーション

1.メッセージのフォーマット 

ローランドのエクスクルーシブ･フォーマット（タイプIV）はすべて以下の表のようになっています。



バイト

 

F0H



41H



DEV

 

MDL



CMD



[BODY]

 

F7H



説明 エクスクルーシブ・ステータス ローランドID デバイスID モデルID コマンドID データ本体 エンド・オブ・エクスクルーシブ



■MIDIステータス[MIDIstatus] （F0H）,（F7H) 

エクスクルーシブ･メッセージは2つのステータスによって囲まれ、（F0H）の次には「マニュファクチャラーID」を必要とします。 （MIDI規格Ver1.0による。）



■マニュファクチャラーID[ManufacturerID]（41H）

 ローランドのIDです。「マニュファクチャラーID」により、どのメーカーのエクスクルーシブ･メッセージであるかを判断することができます。



■デバイスID[Device-ID] DEV 

複数の機器を区別するためにあります。通常「ベーシック･チャンネル」から1を引いた値（00H−0FH）が使用されますが、複数のベーシック･チャンネルを持つ機器などでは（00H−1FH）を設定して使用することもあります。



■モデルID[Model-ID] MDL 

機種ごとに決まった値を持ちます。ただし、機種が違っても同じデータを扱うものは共通に使用されます。 拡張のために（00H）を使用し、（00H）の個数によっても各々区別されます。例えば、  （01H）,  （02H）,  （03H）,  （00H,01H）,  （00H,02H）,  （00H,00H,01H） は各々、別の機種を表します。



■コマンドID[Command-ID] CMD 

メッセージの役割を表します。 拡張のために（00H）を使用し、（00H）の個数によっても各々区別されます。例えば、  （01H）,  （02H）,  （03H）,  （00H,01H）,  （00H,02H）,  （00H,00H,01H） は各々、別の役割を表します。



■データ本体[BODY] 

送受信されるデータ本体。「モデルID」および「コマンドID」によってサイズや内容が変わります。

 

2.アドレス･マッピング方式によるデータ転送 

アドレス･マッピング方式とは1.のフォーマットにしたがったデータ転送の方式です。この方式では、波形データ、音色データ、スイッチ情報やパラメーターなどを、その機種ごとに設定したアドレス空間に割り付けることによって、さまざまなデータを、そのアドレスを示すことで、データの転送を行ないます。 以上により、機種やデータの種類によってデータの転送方法が変わることはありません。転送方法としては、ワン･ウエイ方式とハンドシェイク方式の2 方式があります。 機器によって、データの種類により、2方式を使い分けていたり、1つの方式しかできない場合もあります。

■ワン･ウエイ方式（3.参照） 

この方式は、比較的少ないデータの転送に適しており、一方的にエクスクルーシブ･メッセージを送信することによってデータ転送を行っています。 

接続図



機器A 機器B



MIDIOUT

  

MIDIIN

1

MIDIIN

2

MIDIOUT



「データ要求」（3.参照）を使用するとき、2の接続が必要です。



■ハンドシェイク方式（本機では対応していません） 

この方式は、送る側と受ける側でお互いに確認（ハンドシェイク）をしてデータ転送を行っています。多量のデータの転送では、信頼性が高く、転送速度も速くなります。 



接続図



機器A 機器B



MIDIOUT

   

必ず1及び2の接続が必要です。

MIDIIN

1

MIDIIN

2

MIDIOUT



上記2方式について

 ＊転送方式により「コマンドID」が決まっています。  ＊機器Aおよび機器Bが各々、同じ方式を採用しており、データ転送ができる

状態にあって、さらに、「デバイスID」と「モデルID」が一致していなければ、データ転送を行なうことはできません。

 

3.ワン･ウエイ方式によるデータ転送 

この方式は比較的少量のデータを転送するときにメッセージごとの確認を行わず一方的に送る方法です。ただし多量のデータを続けて送る時は、適当な時間間隔（20msec以上）を取って送ります。この方式では受信側はその時間内で正しくデータを受け取らなければなりません。



メッセージの種類



メッセージ



データ要求1

 

データ・セット1

 

■データ要求1[Requestdata1] RQ1（11H） 

相手の機器からデータを送ってもらうときに送信します。アドレスとサイズで要求するデータと量を示しています。  このメッセージを受信した場合、その機器がデータを送られる状態にあり、アドレスとサイズが適当なものであれば、要求されたデータを「データ･セット1」メッセージで送信します。そうでない場合は何も送信をしません。

 



コマンドID RQ1（11H） DT1（12H）

バイト

説明

F0H

エクスクルーシブ・ステータス

41H

ローランドID

DEV

デバイスID

MDL

モデルID

11H

コマンドID

aaH

アドレスMSB

¦

¦

¦

¦ LSB

ssH

サイズMSB

¦

¦

¦

¦ LSB

sum

チェックサム

F7H

エンド・オブ・エクスクルーシブ



56

＊サイズは要求するデータ全体のアドレスを示しており、1つの「データ･セ

ット1」のメッセージのデータのバイト数ではありません。



＊機種ごとに、データの種類によって1度に転送するデータの数があらかじ

め決まっていたり、決められたアドレスで区切って送受信しなければならない場合もあります。



＊アドレスとサイズは同じバイト数で、「モデルID」ごとに決められます。



＊チェックサムは、アドレス、サイズ、及びチェックサム自身を加算した値

の下位7ビットがゼロになる値になっています。



■データ･セット1[Dataset1] DT1（12H） 

実際のデータの転送を行ないます。 データはそれぞれ1バイトごとにアドレスを持ちますが、このメッセージでは、 1つまたは、複数データの先頭のアドレスと、データだけをアドレス順にならべたものを送ることができます。



MIDI規格により、リアル･タイム･メッセージ以外のメッセージはエクスクルーシブ･メッセージにはわり込めません。ローランドでは、ソフト･スルーする機器を考えて、1つの「データ･セット1」メッセージで転送するデータを最大256バイトとしていますので、256バイトを超えるような多量のデータは、区切って何回かに分けて送ります。

 

バイト

                 

＊このメッセージは、「データ要求1」メッセージで示される範囲の中で有

効な部分のみを転送することができます。



＊機種ごとに、データの種類によって1度に転送するデータの数があらかじ

め決まっていたり、決められたアドレスで区切って送受信しなければならない場合もあります。



＊アドレスのバイト数では、「モデルID」ごとに決められます。



＊チェック･サムは、アドレス、データ、及びチェック･サム自身を加算した

値の下位7ビットがゼロになる値になっています。

説明

F0H

エクスクルーシブ・ステータス

41H

ローランドID

DEV

デバイスID

MDL

モデルID

12H

コマンドID

aaH

アドレスMSB

¦

¦

¦

¦ LSB

ddH

データMSB

¦

¦

¦

¦ LSB

sum

チェックサム

F7H

エンド・オブ・エクスクルーシブ



■送受信の例



●機器Aが機器Bにデータを転送するとき。  単に「データ･セット1」のメッセージを送信します。



機器A 機器B

 

[データ・セット1]



＊20msec以上の時間間隔をあける



[データ・セット1]

  

[データ・セット1]



●機器Bが機器Aからデータを転送してもらうとき。 

最初に「データ要求1」メッセージを送信します。そして、機器Aは「データ･セット1」メッセージを送信します。



機器A



[データ・セット1]

＊20msec以上の時間間隔をあける

[データ・セット1]



機器B

[データ要求]

MIDI インプリメンテーション

[データ・セット1]

57

Roland VF-1 MIDI IMPLEMENTATION [ja]

Specifications and Main Features

Frequently Asked Questions

User Manual
