BUILT FOR RELIABLE PERFORMANCE.
The Speed Queen® Horizon® line of washers and dryers are ready to meet the demands of your laundry room. Equipped with our
elite Quantum™ Controls and designed to work as a single or stacked laundry setup, they provide maximum energy efficiency and
long-lasting performance. Speed Queen front load laundry products have met every design standard to be 100% ADA compliant.
HORIZON® MACHINES PROVIDE:
ENERGY STAR® qualification that uses less energy, saves money and helps protect the environment
Water use as low as 11.0 gallons (41.7 liters) per cycle to reduce operating costs.
Efficient dryer heating with 25,000 BTU (gas models) and 5,350 Watts (electric models) provide fast drying and lower operating
costs.
Quantum Controls offer total automated management of your laundry room. Its simple, powerful programming gives you
the ability to:
Easily manage your laundry operation with remote internet access.
Establish multi-level vend prices, soil level cycles and dryer top-off times on your machines.
Track coin or card transactions.
FRONT LOAD WASHER
The Speed Queen front load washer gives building owners and property managers unparalleled ability to reduce
water and energy costs through advanced programmability.
FEATURES
HIGH SPEED EXTRACT
1000 RPM final spin exerts 300 G-Force to maximize
moisture removal from clothes.
BIG LOAD DOOR OPENING
Extra wide 15.5" (394 cm) for easy loading and unloading of clothes.
STAINLESS STEEL WASH TUB
Comes with a lifetime warranty, and actually becomes smoother with each use, so it
won’t pill, snag or fray clothes.
CONTROL TYPES
Coin (“C”)
Prep for Coin
(“X”)
Prep for Card
(“Y”)
Page 3
SINGLE LOAD DRYER
Speed Queen’s front control dryer, defined by its simplicity and its performance, provides everything you need to
get the job done – and nothing you don’t. Speed Queen’s single load dryers combine heavy-duty construction with
reliable operation proven to stand the test of time. They’re designed with less moving parts for one reason: so you’ll
face fewer maintenance problems and less wear and tear down the road. Our cabinet design maintains the perfect
balance of heat, airflow and tumble action for optimal performance and efficiency.
FEATURES
SUPERIOR DRYING CONVENIENCE
With a 2.06 sq. . (1914 cm²) door opening, making it the widest in the industry, Speed Queen dryers offer the
convenience of easy loading and unloading.
EFFICIENT DRYER HEATING
With 25,000 BTU (gas models) and up to 5,350 Was (electric models), Speed Queen dryers offer some of
the fastest drying times in the industry.
UPFRONT LINT FILTER
Easy to clean and secured.
REVERSIBLE DOOR (SOLID DOORS ONLY)
For installation flexibility.
STACK DRYER
The Speed Queen stack dryer offers the same great features as the single load dryer. Two commercial dryers in the
space of one, both operating independently, including independent controls for optimum usage. Available with
see-through or solid door models.
STACK WASHER/DRYER
Speed Queen’s stack washer/dryers bring an innovative stacked concept that takes up half the floor space that a
conventional washer and dryer does when situated side by side. The freestanding somount design can be installed
on most floor types or levels. Both washer and dryer have the same hookups and connections as a standard washer
and dryer. No additional plumbing or electrical change is needed. Same great features as the front control washer
and dryer for superior washing and drying convenience.
Page 4
QUANTUM™ SYSTEM COMMERCIAL WASHER & DRYER SPECIFICATIONS
Washers Single Load Dryers Stack Dryers Stack Washer/Dryers
SFNLCFS, SFNLCFJ,
SFNLYFS, SFNLYFJ
Basket/Cylinder Volume - cu.. (liters) 2.84 (80) 7.0 (198) 7.0 (198) 2.84 (80)/7.0 (198)
Width - in (mm) 26 7/8" (683)
Depth - in (mm) 28" (711) 28" (711) 28" (711) 28" (711)
Height* - in (mm) 43" (1092) 43" (1092) 76 5/8" (1946) 76 5/8" (1946)
Weight - lb (kg) 250 (113)
Shipping Weight - lb (kg) 270 (123)
Cycle Time - minutes (default) 27 45 45 27/4 5
Motor HP (Capacitor Start and Thermal
Protected)
Water Consumption - gal (Liter) 11.0 (41.7) N/A N/A 11.0 (41.7)
Water Factor - gal/³ (Liters/Liter/cycle) 4.0 (0.53) N/A N/A 4.0 (0.53)
Modified Energy Factor - ³/kWh/cycle
(Liters/kWh/cycle)
Average Hot Water Usage - gal (Liter) 0.9 (3.3) N/A N/A 0.9 (3.3)
Water Pressure - psi (bar)
Spin Speed - RPM 500, 650, 1000 N/A N/A 500, 650, 1000
Cycle/Temperature
Electrical Specifications and Circuit
Requirements
Btu per Hour (kcal)
Heating Element**
Type of Gas (Gas models only)
Utility Connections - in (mm)
Air Outlet Diameter - in (mm)
Exhaust Airflow† - cfm (liters/sec)
Maximum Exhaust Static Back Pressure
Agency Approval
Activation
Top and Lid Finish
Colors
Door Type Window Solid Solid, Window Window
1 HP, 750W 1/3 HP, 5.5 amps 1/3 HP, 5.5 amps
2.40 (67.97) N/A N/A 2.40 (67.97)
Pressure fill
20 to 120 (1.4/8.3)
Hot Normal
Warm Perm Press
Cold Delicate
120/60/1-15 amp
N/A
N/A 5350W, 240V
N/A Factory-equipped natural/mixed gas
N/A
N/A
N/A
N/A
cULus Electric:
Coin/Card Op
Porcelain
White
Electric:
Gas:
26 7/8"
(683)
Electric:
Gas:
Electric:
Gas::
N/A N/A
High
Medium
Low
Delicate
No Heat
Electric:
Gas:
25,000 (6300) 25,000 (6300) 25,000 (6300)
4750W, 208V
convertible to LP gas***
Gas: 3/8" NPT (9.5) Gas: 3/8” NPT (9.5) Gas: 3/8" NPT (9.5)
4" (102) 4" (102) 4" (102)
220 (105) 220 (105) 220 (105)
0.6" W.C. 0.6" W.C. 0.6" W.C.
Gas:
Coin/Card Op Coin/Card Op Coin/Card Op
Porcelain N/A N/A
White White White
SDELCFG, SDELYFG
SDGLCFG, SDGLYFG
150 (68)
155 (70)
160 (73)
165 (75)
160 º
155 º
145 º
115 º
120/240/60/1-30 amp
120/208/60/1-30 amp
120-60/1-15 amp
cULus
CSA Star
Electric:
Gas:
:
26 7/8" (683) 26 7/8" (683)
Electric:
Gas:
Electric:
Gas:
High
Medium
Low
Delicate
No Heat
Electric:
2 ea
Gas:
2 ea
5350W, 240V
4750W, 208V
Factory-equipped natural/mixed
gas convertible to LP gas***
Electric:
Gas:
* Heights may vary slightly depending on leveling adjustments.
** Electric dryers come equipped for 120/240/60/1 operation. They can be field converted to operate on 120/208/60/1 with optional 61928 conversion kit.
Gas dryers can be field converted for operation on LP gas with optional 458P3 conversion kit.
*** IMPORTANT: Any product revisions or conversions must be made by the Manufacturer’s Authorized Dealers, Distributors, or local service personnel.
† Measured at point of exit from dryer.
For the most accurate information, the installation guide should be used for all design and construction purposes. Due to continuous product improvements, design and specifications subject to change
without notice. The quality management system of Alliance Laundry Systems’ Ripon facility has been registered to ISO 9001 :2008.
Printed in the U.S.A.
©Copyright 2012 Alliance Laundry Systems LLC
SSELCFGS, SSELCFGW
SSELYFGS, SSELYFGS
SSGLCFGS, SSGLCFGW
SSGLYFGS, SSGLYFGW
265 (120)
275 (125)
280 (127)
290 (132)
160 º
155 º
145 º
115 º
120/240/60/1-30 amp
120/208/60/1-30 amp
120-60/1-15 amp
cULus
CSA Star
Electric:
Gas:
Electric:
Gas:
Electric:
Gas:
1 HP, 750W
1/3 HP, 5.5 amps
Pressure fill
20 to 120 (1.4/8.3)
See washer and dryer
columns for corresponding
cycles and temperatures.
See washer and dryer
columns for corresponding
cycles and temperatures.
5350W, 240V
4750W, 208V
Factory-equipped natural/mixed
gas convertible to LP gas***
Electric:
Gas:
STELCFS, STELYFS
STGLCFS, STGLYFS
360 (163)
365 (166)
390 (177)
395 (179)
cULus
CSA Star
© 2012 Alliance Laundry Systems LLC AM10-0780R2
