200 VA - 12 kVA
Inverter Series
Specification
UPS/INVERTERS
• Sinusoidal Output from 12-480 V
• Compact Switched Mode Design
• DC Inputs 10-400 V
• Wall or Rack Mounting
• Industrial Grade
• Customised Design Available
Input
Input Voltage • See Table
No load Input Power • 20 W typical
Earth Leakage Current • <3.5 mA at 230 VAC
Output
Output Voltage • See Table
Output Voltage • 110 V version 110 V to 125 V
Adjustment 230 V version 210 V to 245 V
Minimum Load • No minimum load required
Wave Form • Sinusoidal standard, optional wave
shape programmable
by external signal
Frequency • Crystal stabilized 50 Hz, 60 Hz,
400 Hz or 45 to 400 Hz adjustable
Distortion • 3% typical (5% at 400 Hz)
Rise Time • 100 ms typical
Power Factor • Cos Ø≥0.7 inductive/capacitive
Crest Factor •3
Line Regulation • 0.1% for CI models,
2.0 % for I, IT & IV models
(±10% change Vin)
Load Regulation • 50/60 Hz 1% typical 3% max,
400 Hz 3% typical 5% max
(10-90% load change)
Overload • Current limited to approx 105%
Protection I Nom (Steady State)
Short Circuit • Electronically limited to 3 x I Nom
Current
Surge Power • 2 x P Nom for 1 sec
Temperature • 0.05%/°C typical
Coefficient
General
Efficiency • 85-95% I models,
75-90% CI, IT & IV models
Isolation • 3500 VDC Input to Output,
3500 VDC Input to Ground,
3500 VDC Output to Ground
Switching Frequency • Approx 33 kHz converter & 20 kHz
Inverter section
MTBF • 120,000 hours I & IT models,
70,000 hours CI models,
50,000 hours IV models
Dimensions/Weight • Contact Sales
Options • Contact Sales
Environmental
Operating Temperature • -20 °C to +75 °C, derate linearly at
2.5%/°C from +55 °C
Optional -40 °C to +75 °C
Storage Temperature • -40 °C to +85 °C
Cooling • Natural convection
(IT5600 to IT5800 forced cooled)
Operating Humidity • 5-95% RH non-condensing
Operating Altitude • 1000 m
EMC & Safety
Emissions • EN55022 Level A conducted,
optional Class B
EFT/Burst • EN61000-4-4 Level 3
Surge • EN61000-4-5 Level 3
Safety Approvals • EN60950
1
www.powersolve.co.uk
Powersolve Electronics Ltd. 8A, Arnhem Road, Newbury, RG14 5RU. England
Tel:01635 521858 Fax: 01635 523771 Email: sales@powersolve.co.uk
UPS/INVERTERS
CI Series - Converters & Inverters, Isolated DC Input 0.5-3.5 kVA
Input (VDC) 20-32 V Output 40-64 V 50-80 V 80-160 V 160-320 V 320-380 V 320-640 V Output
Output Models Rating Models Models Models Models Models
115 V (110-125 V) CI1626 0.5 kVA CI1636 CI1646 CI1656 CI1676 CI1686Z - 0.6 kVA
230 V (210-245 V) CI1628 0.5 kVA CI1638 CI1648 CI1658 CI1678 CI1688Z - 0.6 kVA
115 V (110-125 V) CI3626 1.0 kVA CI3636 CI3646 CI3656 CI3676 CI3686Z CI3676G 1.2 kVA
230 V (210-245 V) CI3628 1.0 kVA CI3638 CI3648 CI3658 CI3678 CI3688Z CI3678G 1.2 kVA
115 V (110-125 V) CI4826
230 V (210-245 V) CI4828
(3)
(3)
1.4 kVA CI4836
1.4 kVA CI4838
(3)
(3)
CI4846
CI4848
(3)
(3)
CI4856
CI4858
(3)
(3)
CI4876
CI4878
(3)
CI4886Z
(3)
CI4888Z
115 V (110-125 V) CI5626 1.8 kVA CI5636 CI5646 CI5656 CI5676 CI5686Z CI5676G 1.8 kVA
230 V (210-245 V) CI5628 2.0 kVA CI5638 CI5648 CI5658 CI5678 CI5688Z CI5678G 2.0 kVA
115 V (110-125 V) CI5726 2.5 kVA CI5736 CI5746 CI5756 CI5776 CI5786Z CI5776G 2.5 kVA
230 V (210-245 V) CI5728 2.5 kVA CI5738 CI5748 CI5758 CI5778 CI5788Z CI5778G 2.5 kVA
115 V (110-125 V) CI5726F
230 V (210-245 V) CI5728F
Notes:
1. Models supplied by external PFC module with 93-264 VAC input.
(3)
3.0 kVA CI573t6F
(3)
3.0 kVA CI5738F
(3)
(3)
CI5746F
CI5748F
(3)
(3)
CI5756F
CI5758F
(3)
(3)
CI5776F
CI5778F
(3)
(3)
CI5786ZF
CI5788ZF
3. External fan recommended, details to be advised at time of order.
2. For 12 V DC nominal input contact sales.
I Series - Inverters, Non-Isolated 0.2-12.0 kVA
INPUT VOLTAGE DC
20-32 V Output 40-64 V 50-80 V Output 80-160 V Output 160-320 V 170-200 V 320-650 V Output 380-400 V Output
Models Rating Models Models Rating Models Rating Models Models
I1520 0.20 kVA I1530 I1540 0.45 kVA I1550 0.50 kVA I1570 I1506 - 0.80 kVA I1508 1.0 kVA
- - I3530 I3540 0.50 kVA I3550 0.80 kVA I1370 I1306 I3570G 1.20 kVA I3508 1.5 kVA
I3720 0.40 kVA I3730 I3740 0.60 kVA I3750 1.20 kVA I3770 I3706 I3770G 2.00 kVA I3708 2.5 kVA
- - I4730 I4740 1.20 kVA I4750 2.00 kVA I4770 I4706 I4770G 3.00 kVA I4708 4.0 kVA
I5620 1.20 kVA - I5640 2.00 kVA I5650 3.00 kVA I5670 I5606 I5670G 5.00 kVA I5608 6.0 kVA
I5720 1.60 kVA I5730 I5740 3.00 kVA I5750 5.00 kVA I5770 I5706 I5770G 8.00 kVA I5708 10.0 kVA
----- - -I5870 I5806 I5870G 10.0 kVA I5808 12.0 kVA
OUTPUT VOLTAGE AC
(3)
12 V - 24 V 30 V - 50 V - 100 V 115 V 200 V - 230 V -
Notes:
1. Designed for 115 VAC output.
2. Designed for 230 VAC output with pre-connected converter series C,
3. Maximum AC output at minimum DC input voltage. Higher output voltage is
available at higher input voltage. Maximum AC output (Vrms) ≤0.65 input VDC.
or for PFC modules series P (no isolation between input & output).
(1)
Models Rating Models
(1)
Models Rating
(3)
(3)
(3)
(3)
CI4876G
CI4878G
CI5776GF
CI5778GF
(3)
(3)
(3)
(3)
(2)
1.8 kVA
1.8 kVA
3.5 kVA
3.5 kVA
Rating
IT Series - Inverters & Transformers, Isolated 1 Phase 0.2-10.0 kVA
Input (VDC) 20-32 V Output 40-64 V 50-80 V Output 80-160 V Output 160-320 V 340-400 V 360-650 V Output
Output Models Rating Models Models Rating Models Rating Models Models
115 V (110-125 V) IT1626 0.2 kVA IT1636 IT1646 0.4 kVA IT1656 0.5 kVA IT1676 IT1686Z - 0.5 kVA
230 V (210-245 V) IT1628 0.2 kVA IT1638 IT1648 0.4 kVA IT1658 0.5 kVA IT1678 IT1688Z - 0.5 kVA
115 V (110-125 V) --IT3636 IT3646 0.5 kVA IT3656 1.0 kVA IT3676 IT3686Z IT3676G 1.0 kVA
230 V (210-245 V) --IT3638 IT3648 0.5 kVA IT3658 1.0 kVA IT3678 IT3688Z IT3678G 1.0 kVA
115 V (110-125 V) IT3826 0.4 kVA IT3836 IT3846 0.6 kVA IT3856 1.2 kVA IT3876 IT3886Z IT3876G 1.6 kVA
230 V (210-245 V) IT3828 0.4 kVA IT3838 IT3848 0.6 kVA IT3858 1.2 kVA IT3878 IT3888Z IT3878G 1.6 kVA
115 V (110-125 V) -- --1.2 kVA IT4856 2.0 kVA IT4876 IT4886Z IT4876G 2.5 kVA
230 V (210-245 V) -- --1.2 kVA IT4858 2.0 kVA IT4878 IT4888Z IT4878G 2.5 kVA
115 V (110-125 V) --IT5636 IT5646 2.0 kVA IT5656 3.0 kVA IT5676
230 V (210-245 V) --IT5638 IT5648 2.0 kVA IT5658 3.0 kVA IT5678
115 V (110-125 V) --IT5736 IT5746 3.0 kVA IT5756
230 V (210-245 V) --IT5738 IT5748 3.0 kVA IT5758
(2)
5.0 kVA IT5776
(2)
5.0 kVA IT5778
115 V (110-125 V) -- -- - --IT5876
230 V (210-245 V) -- -- - --IT5878Z
Notes:
1. Models supplied by by external PFC module with 93-264 V AC input.
3. For other output voltages the output transformer can be modified - contact Sales.
(2)
(2)
(2)
(2)
(2)
(2)
2. Output transformer needs to be installed externally because of weight
e.g. on mounting plate (wall mount version).
IT5686Z
IT5688Z
IT5786Z
IT5788Z
IT5876Z
IT5878Z
(1)
Models Rating
(2)
IT5676G
(2)
IT5678G
(2)
IT5776G
(2)
IT5778G
(2)
IT5876G
(2)
IT5878G
(2)
(2)
(2)
(2)
(2)
(2)
10.0 kVA
10.0 kVA
5.0 kVA
5.0 kVA
8.0 kVA
8.0 kVA
www.powersolve.co.uk
Powersolve Electronics Ltd. 8A, Arnhem Road, Newbury, RG14 5RU. England
Tel:01635 521858 Fax: 01635 523771 Email: sales@powersolve.co.uk
UPS/INVERTERS
IV Series - Inverters & Transformers, Isolated 3 Phase 0.6-7.5 kVA
Input (VDC) 20-32 V Output 40-64 V 50-80 V Output 80-160 V Output 160-320 V 320-380 V 360-650 V Output
Output Models Rating Models Models Rating Models Rating Models Models
3x200 VAC (Line to Line) IV5526 0.6 kVA IV5536 IV5546 1.2 kVA IV5556 1.5 kVA IV5576 IV5586Z - 1.8 kVA
3x400 VAC (Line to Line) IV5528 0.6 kVA IV5538 IV5548 1.2 kVA IV5558 1.5 kVA IV5578 IV5588Z - 1.8 kVA
3x480 VAC (Line to Line) IV5529 0.6 kVA IV5539 IV5549 1.2 kVA IV5559 1.5 kVA IV5579 IV5589Z - 1.8 kVA
3x200 VAC (Line to Line) --IV5636 IV5646 1.5 kVA IV5656 2.4 kVA IV5676 IV5686Z IV5676G 3.5 kVA
3x400 VAC (Line to Line) --IV5638 IV5648 1.5 kVA IV5658 2.4 kVA IV5678 IV5688Z IV5678G 3.5 kVA
3x480 VAC (Line to Line) --IV5639 IV5649 1.5 kVA IV5659 2.4 kVA IV5679 IV5689Z IV5679G 3.5 kVA
3x200 VAC (Line to Line) IV5726
3x400 VAC (Line to Line) IV5728
3x480 VAC (Line to Line) IV5729
3x200 VAC (Line to Line) -----IV5856
3x400 VAC (Line to Line) -----IV5858
3x480 VAC (Line to Line) -----IV5859
(1)
1.2 kVA IV5736
(1)
1.2 kVA IV5738
(1)
1.2 kVA IV5739
(1)
(1)
(1)
IV5746
IV5748
IV5749
(1)
1.8 kVA IV5756
(1)
1.8 kVA IV5758
(1)
1.8 kVA IV5759
(1)
3.5 kVA IV5776
(1)
3.5 kVA IV5778
(1)
3.5 kVA IV5779
(1)
6.0 kVA IV5876
(1)
6.0 kVA IV5878
(1)
6.0 kVA IV5879
(1)
(1)
(1)
(1)
(1)
(1)
IV Series - Inverters & Transformers, Isolated 3 Phase 0.6-7.5 kVA
Input AC 185-264 V 93-138/185-264 V 3x400 (320-460) V 3x480 (400-530) V Output
Output Models Models Models Models Rating
115 V CI1686 CI1696 --0.6 kVA
230 V CI1688 CI1698 --0.6 kVA
115 V CI3686 CI3696 CI3686V CI3696V 1.2 kVA
230 V CI3688 CI3698 CI3688V CI3698V 1.2 kVA
115 V CI4886 CI4896 CI4886V CI4896V 1.8 kVA
230 V CI4888 CI4898 CI4888V CI4898V 2.0 kVA
115 V CI5686 CI5696 CI5686V CI5696V 1.8 kVA
230 V CI5688 CI5698 CI5688V CI5698V 2.0 kVA
115 V CI5786 CI5796 CI5786V CI5796V 2.5 kVA
230 V CI5788 CI5798 CI5788V CI5798V 2.5 kVA
IT Series - Frequency Converters, Isolated 1 Phase 0.5-10.0 kVA
Input (VAC) 93-138 V
Output
Models
115 V (110-125 V) IT1666
230 V (210-245 V) IT1668
115 V (110-125 V) IT3666
230 V (210-245 V) IT3668
115 V (110-125 V) IT3866
230 V (210-245 V) IT3868
115 V (110-125 V) IT4866
230 V (210-245 V) IT4868
115 V (110-125 V) IT5666
230 V (210-245 V) IT5668
115 V (110-125 V) IT5766
230 V (210-245 V) IT5268
185-264 V
Models
IT1686
IT1688
IT3686
IT3688
IT3886
IT3888
IT4886
(1)
(1)
(1)
(1)
IT4888
IT5686
IT5688
IT5786
IT5788
(1)
(1)
Output
Rating
0.5 kVA
0.5 kVA
0.8 kVA
0.8 kVA
1.4 kVA
1.4 kVA
2.0 kVA
2.0 kVA
4.0 kVA
4.0 kVA
6.0 kVA
6.0 kVA
3x400 (320-460) V
Models
IT3686V
IT3688V
IT3886V
IT3888V
IT4886V
IT4888V
(1)
IT5686V
(1)
IT5688V
(1)
IT5786V
(1)
IT5788V
(1)
IT5886V
(1)
IT5888V
3x480 (400-530) V
IV5786Z
IV5788Z
IV5789Z
IV5886Z
IV5888Z
IV5889Z
Models
IT3696V
IT3698V
IT3896V
IT3898V
IT4696V
IT4898V
IT5696V
IT5698V
IT5796V
IT5798V
IT5896V
IT5898V
(2)
Models Rating
(1)
IV5776G
(1)
IV5778G
(1)
IV5779G
(1)
IV5876G
(1)
IV5878G
(1)
IV5879G
(1)
(1)
(1)
(1)
(1)
(1)
( 1)
(1)
( 1)
(1)
(1)
(1)
Output
Rating
1.0 kVA
1.0 kVA
1.6 kVA
1.6 kVA
2.5 kVA
2.5 kVA
5.0 kVA
5.0 kVA
8.0 kVA
8.0 kVA
10.0 kVA
10.0 kVA
5.0 kVA
5.0 kVA
5.0 kVA
7.5 kVA
7.5 kVA
7.5 kVA
Output Models Models Rating Models Models Rating
Input (VAC) 93-138 V 185-264 V Output 3x400 (320-460) V 3x480 (400-530) V Output
3x200 VAC (Line to Line) IV5566 IV5586 1.5 kVA IV5686 IV5696V 3.5 kVA
3x400 VAC (Line to Line) IV5568 IV5588 1.5 kVA IV5688 IV5698V 3.5 kVA
3x200 VAC (Line to Line) IV5666 IV5686 2.4 kVA IV5786
3x400 VAC (Line to Line) IV5668 IV5688 2.4 kVA IV5788
3x200 VAC (Line to Line) IV5766
3x400 VAC (Line to Line) IV5768
3x200 VAC (Line to Line) IV5866
3x400 VAC (Line to Line) IV5868
(1)
(1)
(1)
(1)
IV5786
IV5788
IV5886
IV5888
(1)
(1)
(1)
(1)
3.5 kVA IV5886
3.5 kVA IV5888
6.0 kVA IV5886VF
6.0 kVA IV5886VF
(1)
(1)
(1)
(1)
(1)
(1)
IV5796V
IV5798V
IV5896V
IV5898V
IV5896VF
IV5898VF
(1)
(1)
(1)
(1)
(1)
(1)
5.0 kVA
5.0 kVA
7.5 kVA
7.5 kVA
10.0 kVA
10.0 kVA
Notes:
1. Output transformers need to be installed externally because of weight.
2. Models supplied by by external PFC module with 93-264 VAC input.
3. For other output voltages the output transformer can be modified - contact Sales.
4. 3-Phase output systems for power up to 36 kVA can be chieved - contact Sales.
.
www.powersolve.co.uk
Powersolve Electronics Ltd. 8A, Arnhem Road, Newbury, RG14 5RU. England
Tel:01635 521858 Fax: 01635 523771 Email: sales@powersolve.co.uk
UPS/INVERTERS
Application Details
Wall Mounting Plate
Option ‘W’ available for 3U/6U models.
Higher input current models use stud terminals.
Ordering Details
Example: CI1628.5 describes an inverter operating from a battery voltage
in the range 18-36 VDC and provides a 50 Hz sinusoidal output of
230 V RMS at 500 VA.
Other Options
See AC-DC C Series for options.
Customised designs - to special order - consult Sales.
SS Series - Static Switch Specification 0.8-10 kVA
Input
Input Voltage • 115 VAC or 230 VAC models - See Table
Input Frequency • 50 Hz, 60 Hz and 400 Hz models
See Application Details
Output
Output Power • 800 VA to 10 kVA - See Tables
Switching Times • Mains to inverter (mains priority) ≤1/2
Switching Point • 0.8 Vnom <voltage <1.15 Vnom
Surge Current • 5 x Inom for 1 sec
Output Protection • Short circuit protected for output
Temperature Coefficient • 0.05%/ºC
period, typ 1/4 period (incl. failure
detection time) or inverter to mains
(inverter priority) 1 period, typ 1/2 period
with a current >15 A
Return to mains (mains priority) or return
to inverter (inverter priority) practically
no interruption
current ≤15 A, external fuse for
output current >15 A
SS Series - Output Ratings & Mechanical Dimensions
Input/Output Output Dimensions Model
Voltage AC Power Height Width Depth (mm) Number
230 V AC 3.2 kVA 6U 21TE 226.0 SS3518
115 V AC
1.6 kVA 6U 21TE 166.5 SS1508
1.6 kVA 6U 21TE 226.0 SS3508
4.6 kVA 6U 21TE 226.0 SS3528
10.0 kVA 6U 21TE 226.0 SS3538
0.8 kVA 6U 21TE 166.5 SS1506
1.6 kVA 6U 21TE 166.5 SS1516
1.6 kVA 6U 21TE 226.0 SS3506
3.0 kVA 6U 21TE 226.0 SS3516
5.0 kVA 6U 21TE 226.0 SS3526
10.0 kVA 6U 21TE 226.0 SS3536
Frequency Designation
Add suffix to model number
.0 External control (specify at time of order)
.1 45-400 Hz adjustable
.2 45-65 Hz Adjustable
.4 400 Hz
.5 50 Hz
.51 Synchronized with 50 Hz mains
.6 60 Hz
.61 Synchronised with 60 Hz mains
.7 50/60 Hz switchable
.1 and .2 Frequency internally or externally adjustable/programmable
.4, 5 and .7 Frequency fixed, crystal stabilised
NOTE: .0 not for IT or IV series.
General
Signal Inputs • Logic low = 0 to 5 V,
logic high = 12 to 30 V via opto coupler
Relay Contacts • V max = 250 VAC, I max = 3 A
Connectors • One H15 and one F48 or terminal block
with wall mount option
Environmental
Operating Temperature • -20 ºC to +75 ºC, derate from +55 ºC at
2.5%/ºC (optional -40 °C to +75 °C)
Storage Temperature • -40 ºC to +85 ºC
EMC & Safety
Isolation Resistance • >10 MΩ at 500 VDC
Isolation Test • EN60950, Class 1
Creepage Distance • VDE 0110 ≥4 mm
Safety Approvals • EN60950, Class 1
Application Details
Frequency Designation
Model Number Designator Frequency
SSXXXX .4 400 Hz
.5 50 Hz
.6 60 Hz
Example:
SS1508.5 is a Static Switch for 230 VAC operation
at 50 Hz and is capable of handling 1.6 kVA.
29-April-09
Loading...
