hank you for buying this Pioneer product. Please read through these operating instructions
so you will know how to operate your model properly. After you have finished reading the
instructions, put them away in a safe place for future reference.
IMPORTANT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
CAUTION:
TO PREVENT THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
D3-4-2-1-1_En-A
CAUTION
This product is a class 1 laser product, but this
product contains a laser diode higher than Class 1.
To ensure continued safety, do not remove any covers
or attempt to gain access to the inside of the product.
Refer all servicing to qualified personnel.
The following caution label appears on your unit.
Location: rear of the unit
Singapore, Malaysia, Taiwan, Indonesia,
Philippines models
CAUTION : CLASS 3B VISIBLE AND INVISIBLE LASER
RADIATION WHEN OPEN, AVOID
EXPOSURE TO THE BEAM.
VRW2159
WARNING
This equipment is not waterproof. To prevent a fire
or shock hazard, do not place any container filed
with liquid near this equipment (such as a vase or
flower pot) or expose it to dripping, splashing, rain
or moisture.
WARNING
Before plugging in for the first time, read the following
D3-4-2-1-3_A_En
section carefully.
The voltage of the available power supply differs
according to country or region. Be sure that the
power supply voltage of the area where this unit
will be used meets the required voltage (e.g., 230V
or 120V) written on the rear panel.
D3-4-2-1-4_A_En
WARNING
To prevent a fire hazard, do not place any naked
flame sources (such as a lighted candle) on the
equipment.
D3-4-2-1-7a_A_En
All other models
CAUTION :
VORSICHT :
ADVARSEL :
VARNING :
VARO! :
VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.
SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG, WENN
ABDECKUNG GEÖFFNET NICHT DEM STRAHL AUSSETZEN!
SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING
UNDGÅ UDSÆTTELSE FOR STRÀLING.
SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA
DEL ÄR ÖPPNAD BETRAKTA EJ STRÅLEN.
AVATTAESSA ALTISTUT NÄKYVÄ JA NÄKYMÄTTÖMÄLLE
LASERSATEIL YLLE. ÄLÄ KATSO SÄTEESEN.
VRW1699
Location: rear of the unit
CLASS 1
LASER PRODUCT
D3-4-2-1-8_A_En
Recording equipment and copyright: Recording
equipment should be used only for lawful copying
and you are advised to check carefully what is lawful
copying in the country in which you are making a
copy. Copying of copyright material such as films or
music is unlawful unless permitted by a legal
exception or consented to by the rightowners.
VENTILATION CAUTION
When installing this unit, make sure to leave space
around the unit for ventilation to improve heat
radiation (at least 10 cm at top, 10 cm at rear, and
10 cm at each side).
WARNING
Slots and openings in the cabinet are provided for
ventilation to ensure reliable operation of the
product, and to protect it from overheating. To
prevent fire hazard, the openings should never be
blocked or covered with items (such as newspapers,
table-cloths, curtains) or by operating the
equipment on thick carpet or a bed.
K018_En
D3-4-2-1-7b_A_En
Y
CAUTION
T
T
The STANDBY/ON switch on this unit will not
completely shut off all power from the AC outlet.
Since the power cord serves as the main disconnect
device for the unit, you will need to unplug it from
the AC outlet to shut down all power. Therefore,
make sure the unit has been installed so that the
power cord can be easily unplugged from the AC
outlet in case of an accident. To avoid fire hazard,
the power cord should also be unplugged from the
AC outlet when left unused for a long period of time
(for example, when on vacation).
D3-4-2-2-2a_A_En
CAUTION
hese speaker terminals carry HAZARDOUS LIVE
voltage. To prevent the risk of electric shock when
connecting or disconnecting the speaker cables,
disconnect the power cord before touching any
uninsulated parts.
D3-4-2-2-3_A_En
Voltage selector
ou can find the voltage selector switch on the rear
panel of multi-voltage models.
The factory setting for the voltage selector is
220V–230V. Please set it to the correct voltage for
your country or region.
• For Taiwan, please set to 110V–120V before using.
Before changing the voltage, disconnect the AC power
cord. Use a medium size screwdriver to change the
voltage selector switch.
Singapore, Malaysia, Taiwan, Indonesia,
Philippines models
110V-120V
220V-230V
VOLTAGE
SELECTOR
240V
Operating Environment
Operating environment temperature and humidity:
+5 ºC – +35 ºC (+41 ºF – +95 ºF); less than 65 %RH
(cooling vents not blocked)
Do not install this unit in a poorly ventilated area, or in
locations exposed to high humidity or direct sunlight (or
strong artificial light)
POWER-CORD CAUTION
Handle the power cord by the plug. Do not pull out the
plug by tugging the cord and never touch the power
cord when your hands are wet as this could cause a
short circuit or electric shock. Do not place the unit, a
piece of furniture, etc., on the power cord, or pinch the
cord. Never make a knot in the cord or tie it with other
cords. The power cords should be routed such that they
are not likely to be stepped on. A damaged power cord
can cause a fire or give you an electrical shock. Check
the power cord once in a while. When you find it
damaged, ask your nearest PIONEER authorized
service center or your dealer for a replacement.
This product incorporates copyright protection
technology that is protected by method claims
of certain U.S. patents and other intellectual
property rights owned by Macrovision
Corporation and other rights owners. Use of
this copyright protection technology must be
authorized by Macrovision Corporation, and is
intended for home and other limited uses only
unless otherwise authorized by Macrovision
Corporation. Reverse engineering or
disassembly is prohibited.
This product is for general household purposes. Any
failure due to use for other than household purposes
(such as long-term use for business purposes in a
restaurant or use in a car or ship) and which
requires repair will be charged for even during the
warranty period.
D3-4-2-1-7c_A_En
S002_En
K041_En
Medium size
screwdriver
All other models
110V-127V
220V-230V
VOLTAGE
SELECTOR
240V
Medium size
screwdriver
D3-4-2-1-5_En
For Taiwan exclusively
aiwanese two pin flat-bladed plug
DRM (digital rights management) copy
protection is a technology designed to
prevent unauthorized copying by restricting
playback, etc. of material on devices other
than the PC (or other WMA recording
equipment) used to record it. For detailed
information, please see the instruction
manuals or help files that came with your
PC and/or software.
This product includes FontAvenue® fonts
licenced by NEC corporation.
FontAvenue is a registered trademark
of NEC Corporation.
Contents
01 Before you start
Checking what’s in the box
Loading the batteries
Attaching the non-skid pads
Removing the front speaker grilles
. . . . . . . . . . . . . . . . . 5
. . . . . . . . . . . . . . . . . . . . . . 5
. . . . . . . . . . . . . . . . 5
. . . . . . . . . . 5
02 Connecting up
Connecting the speaker terminals
Optional surround speaker connections
Connecting the radio antennas
Connecting external antennas
Connecting to your TV
Connecting using component video
Connecting auxiliary components
Connecting the power
Scanning discs
Playing in slow motion
Frame advance/frame reverse
Playing a JPEG slideshow
Browsing DVD or Video CD/Super VCD discs
with the Disc Navigator
Browsing WMA, MP3, DivX video and JPEG
files with the Disc Navigator
Looping a section of a disc
Using repeat play
Using random play
Creating a program list
Using the OSD
Other functions available from the
program menu
Using the front panel display
Searching a disc
Switching subtitles
Switching language / audio channels
Zooming the screen
Switching camera angles
Displaying disc information
Please check that you've received the following
supplied accessories:
• Remote control
• Dry cell batteries (AA/R6) x2
• Video cord
• AM loop antenna
• FM antenna
• Power cord:
Singapore, Malaysia, Taiwan, Indonesia
and Philippines models x2
All other models x1
• Non-skid pads (in speaker box) x8
• These operating instructions
Loading the batteries
Use AA/R6 batteries with the supplied remote
control. Make sure to follow the indications (
) inside the compartment.
Important
Incorrect use of batteries may result in such
hazards as leakage and bursting. Observe the
following precautions:
• Never use new and old batteries together.
• Insert the plus and minus sides of the
batteries properly according to the marks
in the battery case.
• When disposing of used batteries, please
Attaching the non-skid pads
Use the self-adhesive non-skid pads to provide
a stable base for the speakers. Attach four to
each speaker as shown below.
,
Removing the front speaker grilles
If necessary, remove the front speaker grilles
as described below.
1Gently ease the grille loose by gripping
the bottom and pulling towards you.
2Pull the top free in the same way.
When reattaching, start from the top then push
the bottom in until secure.
• It is not recommended (due to dirt and
• If the speaker grille is not properly attached
different voltages. Do not use different
batteries together.
comply with governmental regulations or
environmental public instruction’s rules
that apply in your country or area.
dust) to leave the speaker grilles removed.
to the front of the speaker, it is possible it
may fall off and cause injury. Therefore, we
don’t recommend placing the speaker in
high locations where this is likely to
happen.
English
Deutsch
Français
Italiano
Nederlands
Español
En
5
Connecting up02
Chapter 2
Connecting up
Important
• Before making or changing any
connections, switch off the power and
unplug the power cord from the AC outlet.
• When making cable connections, make
sure not to bend the cables over the top of
this unit. This may cause a humming noise
from the speakers.
Connecting the speaker
terminals
Place the front left and right speakers at equal
distances from the TV
from the speakers to the terminals on the main
unit rear panel as shown below. See Optional surround speaker connections on page 6 to
connect surround speakers.
Caution
• Do not connect this speaker to any amplifier
other than the one supplied with this
system. Connection to any other amplifier
may result in a malfunction or fire.
• Make sure that the bare speaker wires
cannot touch each other, or come into
contact with other metal parts once the
unit is switched on.
• Do not attach these speakers to the wall or
ceiling. They may fall off and cause injury.
1
, then connect the wires
1Twist and pull off the protective shields
on each wire.
2Connect to the FRONT speaker terminals
on the rear of the unit.
Make sure to insert the red wire into the red (+)
tab and the black wire into the black (–) tab.
ª
·
Optional surround speaker
connections
Using RCA speaker cables, you can connect
surround speakers to the left and right
SURROUND speaker jacks on the rear panel
for multichannel sound from this system.
For the best surround effect, place the
surround speakers slightly above ear level and
at the same distance from the listening
position as the front speakers.
Important
• Use speakers with a nominal impedance of
at least 16
Ω.
Note
1 The speakers supplied with this system are magnetically shielded. However, placing them extremely close to a television may
result in color distortion on the screen. If this happens, move the speakers a little further away and switch off the television for
15–30 minutes.
6
En
Connecting up
D
02
• Make sure you connect both surround
speakers or you won’t be able to hear
anything from the surround jacks.
SURROUN
L
R
Connecting the radio antennas
Connecting the supplied antennas will allow
you to listen to both AM and FM radio
broadcasts. If you find that reception quality is
poor, an outdoor antenna should give you
better sound quality—see
antennas
below for more on how to do this.
fig. afig. bfig. c
3
4
Connecting external
FM UNBAL
AM LOOP
75Ω
ANTENNA
ANTENNA
5
1Pull off the protective shields of both AM
antenna wires.
2Push open the tabs, then insert one wire
fully into each terminal, then release the tabs
to secure the AM antenna wires.
3Fix the AM loop antenna to the stand.
To fix the stand to the antenna, bend in the
direction indicated by the arrow (
clip the loop onto the stand (
fig. b
fig. a
).
) then
• If you plan to mount the AM antenna to a
wall or other surface, secure the stand with
screws (
fig. c
) before clipping the loop to
the stand. Make sure the reception is clear.
4Place the AM antenna on a flat surface
and point in the direction giving the best
reception.
Don’t let it come into contact with metal
objects and avoid placing near computers,
television sets or other electrical appliances.
1
5Connect the FM wire antenna to the FM
UNLBAL 75
ΩΩ
ΩΩ
antenna terminal.
For best results, extend the FM antenna fully
and fix to a wall or door frame. Don’t drape
loosely or leave coiled up.
Connecting external antennas
External AM antenna
Use 5–6 meters of vinyl-insulated wire and set
up either indoors or outdoors. Leave the AM
loop antenna connected.
Outdoor antenna
English
Deutsch
Français
Italiano
Nederlands
Español
1
Note
1 The signal ground () is designed to reduce noise that occurs when an antenna is connected. It is not an electrical safety
ground.
2
Indoor
antenna
(vinyl-coated
wire)
5–6m
AM LOOP
ANTENNA
7
En
Connecting up02
O
O
O
External FM antenna
Use a PAL connector to hook up an external
FM antenna.
PAL connector
FM UNBAL
AM LOOP
75Ω
ANTENNA
ANTENNA
Connecting to your TV
This system offers three types of video
connections. If your TV has component video
inputs, see
below.
1Use the supplied yellow video cable to
connect the VIDEO OUT jack to a video input
on your TV.
For a better image, you can also use a
commercially available S-Video cable to
connect the
input on your TV.
Connecting using component video
VIDE
S-VIDEO OUT
jack to an S-Video
S-VIDE
Connecting using component video
If your TV has component video inputs, you can
use these instead of the standard or S-Video
output to connect this system to your TV.
should give you the best quality picture from
the three types of video output available.
•Use a component video cable to connect
the
COMPONENT VIDEO OUT
to a set of
component inputs on your TV.
COMPONENT
VIDEO
P
R
P
B
VIDE
Y
About progressive scan video
Compared to interlace video, progressive scan
video effectively doubles the scanning rate of
the picture, resulting in a very stable, flickerfree image. Progressive scan video is available
only from the component video output.
Important
• If you connect a TV that is not compatible
with a progressive scan signal and switch
the system to progressive, you will not be
able to see any picture at all. In this case,
press
STANDBY/ON
to put the system
in standby, select the interlace setting in
the
System Setup menu options in standby
on page
33, then press ENTER
1
This
..
..
2Optionally: Use a stereo audio cable to
connect the audio outs of your TV (or VCR) to
the LINE IN jacks on the rear of this unit.
This will enable you to hear the TV (or VCR)
sound through this system. See
auxiliary components
Note
1 The component video output is switchable between interlaced and progressive formats. See Video Output settings on page 29.
8
En
below for more on this.
Connecting
Connecting up
02
Compatibility of this player with
progressive-scan and high-definition TVs.
This player is compatible with progressive
video Macro Vision System Copy Guard.
1
This system is compatible with the following
•Connect the LINE OUT jacks on the rear
panel to a recording component.
These include components such as a cassette
deck, VCR, MD recorder, or another recorder
with analog inputs. Connect using RCA pinplug stereo cables.
After making sure that everything is connected
properly, plug in the power cord to the AC inlet,
and the other end to a mains power outlet.
Connecting auxiliary components
This system has both stereo analog inputs and
outputs. Use these to connect external
components, such as a VCR, MD, CD-R or DAT
recorder.
Tape deck, etc.
AUDIO
OUTPUT
COMPONENT
S-VIDEO
VIDEO
VIDEO
P
R
P
B
Y
MONITOR OUT
IN OUT
L
L
R
LINE
SURROUND
L
R
AUDIO
INPUT
Congratulations! You’re done setting up.
AC IN
English
Deutsch
Français
Italiano
Nederlands
Español
XV-GX3
•Connect the LINE IN jacks on the rear
panel to an auxiliary playback component.
These include components such as a VCR,
DAT, or your TV. Connect using RCA pin-plug
stereo cables.
Note
1 Consumers should note that not all high-definition television sets are fully compatible with this product and may cause artifacts to be displayed in the picture. In case of 525 progressive scan picture problems, it is recommended that the user switch
the connection to the ‘standard definition’ output (Interlace). If there are questions regarding our TV set compatibility with this
model, please contact our customer service center.
9
En
Controls and displays03
Chapter 3
Controls and displays
Front panel
56713482
PUSH OPEN
STANDBY/ON
OPEN/CLOSE
REVERSE
P.BA S S
MAINSUB MIN MAX
REC/STOPFUNCTION
MODE
MICMIC VOL
9111210
1
STANDBY/ON
Switches the player on or into standby.
2Remote sensor
3
P.BASS
Press to switch on the bass boost (page 27).
4Display
See Display below.
5Tape cassette controls
REVERSE MODE – Selects the playback
mode for tapes (page 16).
REC/STOP – Starts/stops recording on the
tape deck (page 24).
6
FUNCTION
Selects the source you want to listen to.
7Playback / volume control
The playback controls are used for playing,
pausing, skipping and stopping playback. Turn
the middle section to adjust the volume.
8
PUSH OPEN
Press down on this side of the cassette door to
open the tape deck.
9
OPEN/CLOSE
Ejects the disc.
10 Headphone jack
11
MIC VOL
and MIC input jacks
Controls the volume of the karaoke mics
(MAIN and SUB) (page 26).
12 Disc tray
10
En
Controls and displays
03
Display
15
26734
P.BASS SFC
DTS B.CUT L R
REC
D
910 118
6
1Format indicators
DTS
– Lights during playback of a DTS
source.
2 D
– Lights during playback of a Dolby
Digital source.
2Sound processing indicators
P.BASS
– Lights when the bass boost is
switched on.
SFC
– Lights when one of the Sound Field
Control modes is selected.
3
Lights during playback.
4Character display
5 PRGSVE
Lights when the player is set to output
progressive scan video (page 8).
6Karaoke indicators
ECHO
– Lights when the Karaoke
effect is selected.
KEY
– Lights when the Karaoke pitch
control is selected.
(Vocal cancel) – Vocals in the backing
track are partially eliminated using EQ.
L
– Left channel only. Use for tracks that
have a vocal recorded in the right channel.
R
– Right channel only. Use for tracks that
have a vocal recorded in the left channel.
L R
– Use to put a single-channel vocal
track into the center of the mix.
7
Tuner indicators
– Lights when a broadcast is being
received.
(page 26)
(page 27)
ECHO
KEY ECHO
PRGSVE
RPT–1
kHz PGM
MHz RDM
– Lights when a stereo FM broadcast is
being received in auto stereo mode.
– Lights when FM mono reception is
selected (page 25).
8
Lights when the sleep timer is active (page 17).
9 Cassette deck indicators
B.CUT
– Lights when the beat cut mode
has been switched to
REC
– Lights when recording to the tape
deck (page 24).
– Indicates the direction of tape
playback.
– Indicates the reverse mode
(page 16).
10 kHz / MHz
Indicates the unit of the frequency shown in
the display (
11 Playback mode indicators
RPT-1
1
play) (page 20).
PGM
(page 21).
RDM
(page 21).
kHz
for AM,
–
RPT
lights during repeat one-track/chapter
lights during repeat play (
– Lights during program play
– Lights during random playback
B.CUT 2
MHz
for FM).
English
Deutsch
Français
Italiano
(page 33).
Nederlands
Español
RPT-
11
En
Controls and displays03
Remote control
STANDBY/ ON
1
2
DVD/CD
PGMRPTRDM
3
45
AUDIO
SUBTITLE
789
SYSTEM SETUP
4
HOME
MENU
5
SOUND
MODE
6
SFC
7
SHIFT
CLEAR MUTE
1
STANDBY/ON
8
Switches the player on or into standby.
2Input source function select
Selects the source you want to listen to;
,
TUNER, TAPE
CD
or
3 Number buttons and SHIFT functions
The number buttons can be used for selecting
titles/chapters/tracks directly, the functions
above the buttons are accessed by pressing
SHIFT
at the same time as the button.
PGM (SHIFT+1
) – Use to program/play a
program list (page 21).
P.BASS
9
LINE
FM/AM
TUNERTAPE
312
VOLUME
0
TOP MENU
DVD
MENU
SLEEP
DISPLAY
10
11
12
13
ECHO
TUNE
ENTER
TUNE
KARAOKE
6
ANGLE ZOOM
STST
RETURN
LINE (SHIFT+TAPE
DVD/
).
RPT (SHIFT+2
) – Selects a repeat play
mode (page 20).
RDM (SHIFT+3
) – Selects a random play
mode (page 21).
AUDIO (SHIFT+7
) – Selects the audio
channel or language (page 23).
SUBTITLE (SHIFT+8
) – Selects a subtitle
display (page 23).
ANGLE (SHIFT+9
) – Changes the camera
angle during DVD multi-angle scene
playback (page 23).
ZOOM (SHIFT+0
) – Changes the zoom
level (page 23).
4
HOME MENU
Press to display (or exit) the on-screen
menu for Initial Settings, Play Mode
functions, etc.
SYSTEM SETUP (SHIFT+HOME MENU
Use to make various system settings
(page 33). Also used to save station presets
(page 17 and page 25) and select mono FM
reception (page 25) when using the tuner.
5Cursor buttons,
ENTER
, tuning and
karaoke buttons
Cursor buttons
///
(
– Use the cursor buttons
) to navigate on-screen
displays and menus.
ENTER
– Selects an option or executes a
command.
TUNE (+/–
) –Tunes the radio.
ST (+/–) – Selects station presets when
listening to the radio.
The karaoke functions are accessed by
pressing SHIFT at the same time as the
corresponding button:
KARAOKE (SHIFT+) – Selects audio
channels for karaoke (page 26).
ECHO (SHIFT+) – Changes the echo
level on the karaoke mics (page 26).
Key controls and (SHIFT+/) –
Lowers/raises the pitch of the backing
track (page 26).
)
12
En
Controls and displays
6
SFC
Selects sound modes or custom settings
from the Sound Field Control (page 27).
SOUND MODE (SHIFT+SFC
Accesses settings in the Sound menu,
such as the tone controls (page 27).
7Playback controls
See
Playing discs
cassette tapes
playback features
explanation of these controls.
8
SHIFT
Some of the buttons have alternate functions
(they are outlined on the remote control). Press
and hold
9
Press to switch on the bass boost (page 27).
10 VOLUME
Adjusts the volume level.
11
12
Press to return to a previous menu screen.
13
SHIFT
P.BASS
DVD MENU
Press to display a DVD disc menu, or the
Disc Navigator (page 15).
TOP MENU (SHIFT+DVD MENU
Displays the top menu of a DVD disc in the
play position—this may be the same as
pressing
RETURN
CLEAR
Clears an entry.
MUTE
Mutes the volume (page 27).
DISPLAY
Switches between information displays
(page 23).
SLEEP (SHIFT+DISPLAY) –
the sleep timer (page 17).
on page 14,
on page 16, and
on page 18 for an
to access these.
DVD MENU
)
Playing
Disc
)
(page 15).
Use for setting
Range of the remote control unit
The remote control has a range of about 7
meters at an angle of 30º of the remote control
sensor. It may not work properly if:
• There are obstacles between the remote
control and this unit's remote sensor.
• Direct sunlight or fluorescent light is
shining onto the remote sensor.
• This system is located near a device that is
emitting infrared rays.
• This unit is operated simultaneously with
another infrared remote control unit.
03
English
Deutsch
Français
Italiano
Nederlands
Español
13
En
Getting started04
Chapter 4
Getting started
Using the on-screen displays
For ease of use, this system makes extensive
use of graphical on-screen displays (OSDs).
All the screens are navigated in basically the
same way, using the cursor buttons (
/
) to change the highlighted item and
ENTER
pressing
Important
• Throughout this manual, ‘Select’ means
use the cursor buttons to highlight an item
on-screen, then press
Button
HOME
MENU
ENTER
RETURN
Tip
• The button guide at the bottom of every
OSD screen shows you which buttons
you’ll need to use for that screen.
to select it.
What it does
Displays/exits the on-screen display
Changes the highlighted menu item
Selects the highlighted menu item
Returns to the main menu without
saving changes
1
ENTER
/ /
.
Playing discs
The basic playback controls for playing DVD,
CD, Video CD/Super VCD, DivX video and MP3/
WMA discs are covered here. Further functions
are detailed in chapter 5.
1If the player isn’t already on, switch it on.
If you’re playing a DVD, Video CD/Super VCD or
DivX video, also turn on your TV and make sure
that it is set to the correct video input.
2Press on the front panel to load a disc.
Load a disc with the label side facing up, using
the disc tray guide to align the disc (if you’re
loading a double-sided DVD disc, load it with
the side you want to play face down).
3Press (play) to start playback.
If you’re playing a DVD or Video CD/Super VCD,
a menu may appear. See
menus
on page 15 and
PBC menus
If you’re playing a DivX video or WMA/MP3
disc, it may take a few seconds before playing.
If you loaded a CD/CD-R/RW containing
JPEGs, a slideshow will start. See
JPEG slideshow
on page 16 to navigate these.
on page 18 for more on this.
DVD-Video disc
Video CD/Super VCD
Playing a
Note
1 The screen saver will appear after five minutes of inactivity.
14
En
Loading...
+ 30 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
