Pioneer VSX-40 Operating Instruction

Download

AUDIO/VIDEO MULTI-CHANNEL RECEIVER

VSX-40

http://www.pioneerelectronics.com (US) http://www.pioneerelectronics.ca (Canada)

• Protect your new investment

The details of your purchase will be on file for reference in the event of an insurance claim such as loss or theft.

• Receive free tips, updates and service bulletins on your new product

• Improve product development

Your input helps us continue to design products that meet your needs.

• Receive a free Pioneer newsletter

Registered customers can opt in to receive a monthly newsletter.

Operating Instructions

IMPORTANT

VENTILATION CAUTION

When installing this unit, make sure to leave space around the unit for ventilation to improve heat radiation (at least 40 cm at top, 20 cm at rear, and 20 cm at each side).

WARNING

Slots and openings in the cabinet are provided for ventilation to ensure reliable operation of the product, and to protect it from overheating. To prevent fire hazard, the openings should never be blocked or covered with items (such as newspapers, table-cloths, curtains) or by operating the equipment on thick carpet or a bed.

D3-4-2-1-7b*_A1_En

Operating Environment

Operating environment temperature and humidity: +5 °C to +35 °C (+41 °F to +95 °F); less than 85 %RH (cooling vents not blocked) Do not install this unit in a poorly ventilated area, or in locations exposed to high humidity or direct sunlight (or strong artificial light)

D3-4-2-1-7c*_A1_En

Caution

To prevent fire hazard, the Class 2 Wiring Cable should be used for connection with speaker, and should be routed away from hazards to avoid damage to the insulation of the cable.

D3-7-13-67*_A1_En

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

NOTE:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: — Reorient or relocate the receiving antenna. — Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help.

Information to User

Alterations or modifications carried out without appropriate authorization may invalidate the user’s right to operate the equipment.

WARNING

This equipment is not waterproof. To prevent a fire or shock hazard, do not place any container filled with liquid near this equipment (such as a vase or flower pot) or expose it to dripping, splashing, rain or moisture.

WARNING

o prevent a fire hazard, do not place any naked flame

sources (such as a lighted candle) on the equipment.

CAUTION:

TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

D3-4-2-1-3_A1_En

D3-4-2-1-7a_A1_En

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

D3-4-2-1-1_A1_En

D8-10-1-2_A1_En

D8-10-2_A1_En

WARNING

Before plugging in for the first time, read the following section carefully.

The voltage of the available power supply differs according to country or region. Be sure that the power supply voltage of the area where this unit will be used meets the required voltage (e.g., 230 V or 120 V) written on the rear panel.

D3-4-2-1-4*_A1_En

This Class B digital apparatus complies with Canadian ICES-003.

D8-10-1-3_A1_En

Read these instructions.

CAUTION

This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other equipment. To prevent electromagnetic interference with electric appliances such as radios and televisions, use shielded cables and connectors for connections.

D8-10-3a_A1_En

IMPORTANT NOTICE

THE MODEL NUMBER AND SERIAL NUMBER OF THIS EQUIPMENT ARE ON THE REAR OR BOTTOM. RECORD THESE NUMBERS ON YOUR ENCLOSED WARRANTY CARD AND KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.

D36-AP9-1_A1_En

WARNING: Handling the cord on this product or

cords associated with accessories sold with the product may expose you to chemicals listed on proposition 65 known to the State of California and other governmental entities to cause cancer and birth defect or other reproductive harm.

D36-P5_B1_En

This product is for general household purposes. Any failure due to use for other than household purposes (such as long-term use for business purposes in a restaurant or use in a car or ship) and which requires repair will be charged for even during the warranty period.

K041_A1_En

These symbols are only valid in the European Union.

K058c_A1_En

(Symbol examples for batteries)

1) Keep these instructions.

2) Heed all warnings.

3) Follow all instructions.

4) Do not use this apparatus near water.

5) Clean only with dry cloth.

6) Do not block any ventilation openings. Install in

7) accordance with the manufacturer’s instructions. Do not install near any heat sources such as

8) radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. Do not defeat the safety purpose of the polarized

9) or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. Protect the power cord from being walked on or

10) pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11)

Only use attachments/accessories specified by the manufacturer.

12)

Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13)

Unplug this apparatus during lightning storms or when unused for long periods of time.

14)

Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

D3-7-13-69_En

If the AC plug of this unit does not match the AC outlet you want to use, the plug must be removed and appropriate one fitted. Replacement and mounting of an AC plug on the power supply cord of this unit should be performed only by qualified service personnel. If connected to an AC outlet, the

plug can cause severe electrical shock. Make

cut-off sure it is properly disposed of after removal. The equipment should be disconnected by removing the mains plug from the wall socket when left unused for a long period of time (for example, when on vacation).

D3-4-2-2-1a_A1_En

CAUTION

The STANDBY/ON switch on this unit will not completely shut off all power from the AC outlet. Since the power cord serves as the main disconnect device for the unit, you will need to unplug it from the AC outlet to shut down all power. Therefore, make sure the unit has been installed so that the power cord can be easily unplugged from the AC outlet in case of an accident. To avoid fire hazard, the power cord should also be unplugged from the AC outlet when left example, when on vacation).

unused for a long period of time (for

D3-4-2-2-2a*_A1_En

Thank you for buying this Pioneer product. Please read through these operating instructions so you will know how to operate your model properly. After you have finished reading the instructions, put them away in a safe place for future reference.

Contents

Before you start

Checking what’s in the box . . . . . . . . . . . . . . . . . . . . . . . . 5

Installing the receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Flow of settings on the receiver

01 Controls and displays

Front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Loading the batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Operating range of remote control . . . . . . . . . . . . . . . . . 9

02 Connecting your equipment

Determining the speakers’ application . . . . . . . . . . . . . . 10

Some tips for improving sound quality . . . . . . . . . . . . . 10

Connecting the speakers. . . . . . . . . . . . . . . . . . . . . . . . . 12

Switching the speaker terminal . . . . . . . . . . . . . . . . . . 12

Making cable connections . . . . . . . . . . . . . . . . . . . . . . . 13

HDMI cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

About HDMI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Analog audio cables. . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Digital audio cables . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Video cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

About the video converter . . . . . . . . . . . . . . . . . . . . . . . . 14

Connecting a TV and playback components . . . . . . . . . . 15

Connecting using HDMI . . . . . . . . . . . . . . . . . . . . . . . 15

Connecting your TV with no HDMI input . . . . . . . . . . . 16

Connecting your DVD player with no HDMI output . . . 17 Connecting a satellite receiver or other digital

set-top box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Connecting an HDD/DVD recorder, Blu-ray Disc

recorder and other video sources . . . . . . . . . . . . . . . . . .18

Using the component video jacks . . . . . . . . . . . . . . . . . . 19

Connecting other audio components . . . . . . . . . . . . . . . 19

Connecting optional Bluetooth® ADAPTER . . . . . . . . . . 20

Connecting your SiriusConnect™ Tuner . . . . . . . . . . . . . 20

Connecting antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Using external antennas . . . . . . . . . . . . . . . . . . . . . . . 21

Connecting to the front panel video terminal. . . . . . . . . . 21

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

. . . . . . . . . . . . . . 5

Connecting an iPod . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Connecting a USB device . . . . . . . . . . . . . . . . . . . . . . . . 22

Connecting an IR receiver . . . . . . . . . . . . . . . . . . . . . . . 22

Switching components on and off using the 12 volt

trigger. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Plugging in the receiver . . . . . . . . . . . . . . . . . . . . . . . . . 23

03 Basic Setup

Automatically setting up for surround sound (MCACC)

Other problems when using the Auto MCACC setup

04 Basic playback

Playing a source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Selecting the audio input signal . . . . . . . . . . . . . . . . . 26

Playing an iPod. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Playing back files stored on an iPod . . . . . . . . . . . . . . 28

Basic playback controls. . . . . . . . . . . . . . . . . . . . . . . . 28

Watching photos and video content . . . . . . . . . . . . . . 28

Playing a USB device . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Basic playback controls. . . . . . . . . . . . . . . . . . . . . . . . 29

Compressed audio compatibility . . . . . . . . . . . . . . . . . 29

Bluetooth

® ADAPTER for Wireless Enjoyment of Music

Wireless music play . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Pairing the Bluetooth ADAPTER and Bluetooth

wireless technology device . . . . . . . . . . . . . . . . . . . . . 30

Listening to Music Contents of Bluetooth wireless

technology device with Your System . . . . . . . . . . . . . . 30

Listening to Satellite Radio . . . . . . . . . . . . . . . . . . . . . . . 30

Listening to SIRIUS Radio. . . . . . . . . . . . . . . . . . . . . . . . 31

Saving channel presets . . . . . . . . . . . . . . . . . . . . . . . . 31

Using the SIRIUS Menu. . . . . . . . . . . . . . . . . . . . . . . . 31

Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Improving FM sound . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Saving station presets . . . . . . . . . . . . . . . . . . . . . . . . . 32

Listening to station presets . . . . . . . . . . . . . . . . . . . . . 32

Naming preset stations . . . . . . . . . . . . . . . . . . . . . . . . 32

05 Listening to your system

Choosing the listening mode . . . . . . . . . . . . . . . . . . . . . 33

Auto playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Listening in surround sound . . . . . . . . . . . . . . . . . . . . 33

Using the Advanced surround . . . . . . . . . . . . . . . . . . 34

Using Stream Direct . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Using the Sound Retriever . . . . . . . . . . . . . . . . . . . . . . . 34

Listening with Acoustic Calibration EQ. . . . . . . . . . . . . . 34

Better sound using Phase Control . . . . . . . . . . . . . . . . . 35

Using surround back channel processing . . . . . . . . . . . 35

Setting the Up Mix function . . . . . . . . . . . . . . . . . . . . . . 35

Setting the Audio options . . . . . . . . . . . . . . . . . . . . . . . . 36

Making an audio or a video recording. . . . . . . . . . . . . . . 37

. . . 24 . . . 25

. . . 29

06 The System Setup menu

Using the System Setup menu. . . . . . . . . . . . . . . . . . . . 38

Manual speaker setup . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Speaker Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Crossover Network . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Channel Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Speaker Distance . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

The Input Assign menu . . . . . . . . . . . . . . . . . . . . . . . . . 40

The Speaker System setting . . . . . . . . . . . . . . . . . . . . . . 41

The Video Parameter setting . . . . . . . . . . . . . . . . . . . . . 41

Video Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Aspect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

The Auto Power Down menu . . . . . . . . . . . . . . . . . . . . . 42

The 12 V Trigger Setting . . . . . . . . . . . . . . . . . . . . . . . . . 42

07 Control with HDMI function

Making Control with HDMI connections . . . . . . . . . . . . 43

HDMI Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Before using synchronization. . . . . . . . . . . . . . . . . . . . . 44

About synchronized operations . . . . . . . . . . . . . . . . . . . 44

About connections with a product of a different brand

that supports the Control with HDMI function . . . . . . 44

Cautions on the Control with HDMI function . . . . . . . . . 44

08 Using the MULTI-ZONE feature

MULTI-ZONE listening . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Making MULTI-ZONE connections . . . . . . . . . . . . . . . 45

Using the MULTI-ZONE controls . . . . . . . . . . . . . . . . . 45

09 Controlling the rest of your system

Setting the remote to control other components . . . . . . 46

Selecting preset codes directly . . . . . . . . . . . . . . . . . . . 46

Clearing all the remote control settings . . . . . . . . . . . . . 46

Controls for TVs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Controls for other components . . . . . . . . . . . . . . . . . . . 47

Preset Code List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

10 Additional information

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Important information regarding the HDMI connection

iPod messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

USB messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

SIRIUS radio messages . . . . . . . . . . . . . . . . . . . . . . . 52

About iPod/iPhone/iPad. . . . . . . . . . . . . . . . . . . . . . . . . 52

Resetting the main unit . . . . . . . . . . . . . . . . . . . . . . . . . 52

Cleaning the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

. . . 51

Before you start

Checking what’s in the box

Please check that you’ve received the following supplied accessories:

• Setup microphone

• Remote control

• AAA size IEC R03 dry cell batteries (to confirm system operation) x2

• AM loop antenna

• FM wire antenna

• iPod cable

• These operating instructions

Installing the receiver

• When installing this unit, make sure to put it on a level and stable surface.

Don’t install it on the following places: – on a color TV (the screen may distort) – near a cassette deck (or close to a device that gives off a magnetic field). This may interfere with the sound. – in direct sunlight – in damp or wet areas – in extremely hot or cold areas – in places where there is vibration or other movement – in places that are very dusty – in places that have hot fumes or oils (such as a kitchen)

Flow of settings on the receiver

The unit is a full-fledged AV receiver equipped with an abundance of functions and terminals. It can be used easily after following the procedure below to make the connections and settings.

The colors of the steps indicate the following:

Required setting item

Setting to be made as necessary

Connecting the speakers

Where you place the speakers will have a big effect on the sound.

• Determining the speakers’ application (page 10)

• Connecting the speakers (page 12)

• Switching the speaker terminal (page 12)



Connecting the components

For surround sound, you’ll want to hook up using a digital connection from the Blu-ray Disc/DVD player to the receiver.

• About the video converter (page 14)

• Connecting a TV and playback components (page 15)

• Connecting antennas (page 20)

• Plugging in the receiver (page 23)



Power On

Make sure you’ve set the video input on your TV to this receiver. Check the manual that came with the TV if you don’t know how to do this.



The Speaker System setting (page 41)

(Specify either using the surround back or front height speaker.)

The Input Assign menu (page 40)

(When using connections other than the recommended connections.)

Using the Audio Return Channel function (page 43)

(When the connected TV supports the HDMI Audio Return Channel function.)



Use the on-screen automatic MCACC setup to set up

your system

• Automatically setting up for surround sound (MCACC) (page 24)



Playing a source (page 26)

• Selecting the audio input signal (page 26)

• Playing an iPod (page 27)

• Playing a USB device (page 28)

• Choosing the listening mode (page 33)



Adjusting the sound as desired

• Using the Sound Retriever (page 34)

• Better sound using Phase Control (page 35)

• Listening with Acoustic Calibration EQ (page 34)

• Using surround back channel processing (page 35)

• Setting the Up Mix function (page 35)

• Setting the Audio options (page 36)

• Manual speaker setup (page 38)



Making maximum use of the remote control

• Setting the remote to control other components (page 46)

Controls and displays

MASTER VOLUME

STANDBY/ON

INPUT SELECTOR

MCACC

SETUP MIC

L AUDIO R VIDEO

VIDEO 2 INPUT

iPod

iPhone

iPad

USB

5V 2.1

iPod iPhone iPad DIRECT

CONTROL

STEREO

PHONES

SPEAKERS CONTROL - MULTI-ZONE - ON/OFF BAND TUNER EDIT TUNE PRESET ENTER

iPod iPhone iPadHDMIMCACC

VSX

-40

1 2 56

9 10 11 12 13 14 15

478

ADVANCED SURROUND

ALC/

STANDARD SURR

AUTO SURROUND

STREAM DIRECT

Chapter 1:

Controls and displays

Front panel

1 INPUT SELECTOR dial

Selects an input source (page 26).

2 SPEAKERS button

See Switching the speaker terminal on page 12.

3 Indicators

MCACC – Lights when Acoustic Calibration EQ (page 34)

is on (Acoustic Calibration EQ is automatically set to on after the Auto MCACC setup (page 24)).

HDMI – Blinks when connecting an HDMI-equipped component; lights when the component is connected (page 15).

iPod iPhone iPad – Lights when an iPod/iPhone/iPad is connected and iPod USB input is selected (page 21).

4 ZONE controls

If you’ve made MULTI-ZONE connections (see Making MULTIZONE connections on page 45) use these controls to control the sub zone from the main zone (see Using the MULTI- ZONE controls on page 45).

5 Character display

See Display on page 7.

6 Tuner control buttons

16 17 18 2019 21 18

BAND – Switches between AM, FM ST (stereo) and FM MONO radio bands (page 32).

TUNER EDIT – Use with TUNE /, PRESET / and ENTER to memorize and name stations for recall

(page 32). Used to preset the channel in SIRIUS Radio (page 31).

TUNE / – Used to find radio frequencies (page 32) and SIRIUS Radio channels (page 31).

24 25 26 27 27 2928

PRESET / – Use to select preset radio stations (page 32) and to select SIRIUS Radio channels (page 31).

7 Remote sensor

Receives the signals from the remote control (see Operating range of remote control on page 9).

8 MASTER VOLUME dial

 STANDBY/ON

10 PHONES jack

Use to connect headphones. When the headphones are connected, there is no sound output from the speakers. The listening mode when the sound is heard from the headphone can be selected only from PHONES SURR, STEREO or

STEREO ALC mode (S.R AIR mode can be also selected with ADAPTER input).

Controls and displays

11 Listening mode buttons

AUTO SURROUND/STREAM DIRECT – Switches

between Auto surround mode (page 33) and Stream Direct playback (page 34).

ALC/STANDARD SURR – Press for standard decoding and to switch between the modes of 2 Pro Logic II, 2 Pro Logic IIx, 2 Pro Logic IIz and NEO:6, and the Auto level control stereo mode (page 33).

ADVANCED SURROUND – Switches between the various surround modes (page 34).

STEREO – Press to select stereo playback (page 33).

12 MCACC SETUP MIC jack

Use to connect a microphone when performing Auto MCACC setup (page 24).

13 AUDIO/VIDEO input terminal

See Connecting to the front panel video terminal on page 21.

14 iPod iPhone iPad/USB terminal

Use to connect your Apple iPod or USB mass storage device as an audio source (page 21).

15 iPod iPhone iPad DIRECT CONTROL

Change the receiver’s input to the iPod and enable iPod operations on the iPod (page 28).

Display

16 PHASE

Lights when the Phase Control is switched on (page 35).

17 AUTO

Lights when the Auto Surround feature is switched on (page 33).

18 Tuner/SIRIUS indicators

ST – Lights when a stereo FM broadcast is being received

in auto stereo mode (page 32). TUNE – Lights when a normal broadcast channel or

SIRIUS channel is being received. PRESET – Shows when a preset radio station is registered

or called.

MEM – Blinks when a radio station is registered. kHz/MHz – Lights when the character display is showing

the currently received AM/FM broadcast frequency.

19 Speaker indicators

Indicates the speaker terminal, A and/or B, to which audio signal output is currently set (page 12).

20 ZONE

Lights when the MULTI-ZONE feature is active (page 45).

21 Sleep timer indicator

Lights when the receiver is in sleep mode (page 8).

22 PRESET information or input signal indicator

Shows the preset number of the tuner or the input signal type, etc.

23 Character display

Displays various system information.

24 DTS indicators

DTS – Lights when a source with DTS encoded audio

signals is detected. HD – Lights when a source with DTS-EXPRESS or DTS-

HD encoded audio signals is detected.

ES – Lights to indicate DTS-ES decoding. 96/24 – Lights when a source with DTS 96/24 encoded

audio signals is detected. NEO:6 – When one of the NEO:6 modes of the receiver is

on, this lights to indicate NEO:6 processing (page 33).

25 Dolby Digital indicators

2D – Lights when a Dolby Digital encoded signal is detected.

2D+ – Lights when a source with Dolby Digital Plus encoded audio signals is detected.

2HD – Lights when a source with Dolby TrueHD encoded audio signals is detected.

EX – Lights to indicate Dolby Digital EX decoding. 2PLII(x) – Lights to indicate 2 Pro Logic II/2 Pro Logic

IIx decoding. Light will go off during 2 Pro Logic IIz decoding (see Listening in surround sound on page 33 for more on this).

26 ADV.S.

Lights when one of the Advanced Surround modes has been selected (see Using the Advanced surround on page 34 for more on this).

27 SIGNAL SELECT indicators

DIGITAL – Lights when a digital audio signal is selected.

Blinks when a digital audio signal is selected and selected audio input is not provided.

HDMI – Lights when an HDMI signal is selected. Blinks when an HDMI signal is selected and selected HDMI input is not provided.

28 Up Mix/DIMMER indicator

Lights when the Up Mix function is set to ON (page 35). Also, lights when DIMMER is set to off.

29 DIR.

Lights when the DIRECT or PURE DIRECT mode is switched on (page 34).

Controls and displays

BD DVD

INPUT SELECT

SOURCESLEEP

CONTROL

DIMMER

SIGNAL SEL

D.ACCESS

INPUT

MIDNIGHT

S.RETRIEVER

HDD

RECEIVER

DVR/BDR

CD-R

ADAPTER

iPod USB VIDEO 1

VIDEO

SIRIUS

TUNER

BD MENU

ENTER

ALC/

STANDARD

ADV SURR

STEREO

AUTO/

DIRECT

VOL

SPEAKERS

LEV

SB CH

DISP

CLR

MEMORY

PHASE

DVD

ENTER

CH SELECT

VCR

SHIFT

MUTE

RETURN

AUDIO

PARAMETER

TUNER EDIT

TOOLS

MASTER VOLUME

iPod CTRL

CATEGORY

BAND

HOME MENU SETUP

DTV/ TV

TRE

BASS

TOP MENU

RECEIVER

3 4

RECEIVER

Remote control

1 SLEEP

Press to change the amount of time before the receiver switches into standby (30 min – 60 min – 90 min – Off). You can check the remaining sleep time at any time by pressing

SLEEP once.

 RECEIVER

Switches the receiver between standby and on. To switch ZONE 2 on/off, press and hold press  RECEIVER button.

SHIFT

button, then

Switches the remote to control the receiver (used to select the white commands above the number buttons (MIDNIGHT, etc)). Also use this button to set up surround sound (page 38) or Audio parameters (page 36).

4 INPUT SELECT

Use to select the input source (page 26).

5 Input function buttons

Use to select the input source to this receiver (page 26). This will enable you to control other components with the remote control (page 46).

6 Listening mode buttons

AUTO/DIRECT – Switches between Auto surround mode

(page 33) and Stream Direct playback (page 34).

STEREO – Press to select stereo playback (page 33). ALC/STANDARD SURR – Press for standard decoding

and to switch between the modes of 2 Pro Logic II, 2 Pro Logic IIx, 2 Pro Logic IIz and NEO:6, and the Auto level control stereo mode (page 33).

ADV SURR – Switches between the various surround modes (page 34).

Press BD first to access:

BD MENU* – Displays the disc menu of Blu-ray Discs.

7 System Setup and component control buttons

The following button controls can be accessed after you have selected the corresponding input function button (BD, DVD, etc.).

Press first to access:

AUDIO PARAMETER – Use to access the Audio options (page 36).

SETUP – Press to access the System Setup menu (page 38).

RETURN – Confirm and exit the current menu screen.

Press BD, DVD or DVR/BDR first to access:

TOP MENU – Displays the disc ‘top’ menu of a Blu-ray Disc/DVD.

HOME MENU – Displays the HOME MENU screen. RETURN – Confirm and exit the current menu screen. MENU – Displays the TOOLS menu of Blu-ray Disc player.

Press TUNER or SIRIUS first to access:

TUNER EDIT – Memorizes stations for recall (page 32).

When TUNER is pressed, also used to change the name (page 32).

BAND – Switches between AM, FM ST (stereo) and FM MONO radio bands (page 32).

CATEGORY – Press to browse SIRIUS radio broadcasts.

Press iPod USB first to access:

iPod CTRL – Switches between the iPod controls and the receiver controls (page 28).

///

Use the arrow buttons when setting up your surround sound system (page 38). Also used to control Blu-ray Disc/DVD menus/options. Use TUNE / can be used to find radio frequencies and PRESET / can be used to select preset radio stations (page 32).

9 Component control buttons

The main buttons (, , etc.) are used to control a component after you have selected it using the input function buttons. The controls above these buttons can be accessed after you have selected the corresponding input function button (BD, DVD, DVR/BDR and CD). These buttons also function as described below.

(TUNE

/

, PRESET

/

), ENTER

Press first to access:

BASS –/+, TRE –/+ – Use to adjust Bass or Treble.

• These controls are disabled when the listening mode is

set to DIRECT or PURE DIRECT.

Controls and displays

CAUTION

RECEIVER

30°

7 m (23 ft.)

30°

• When the front speaker is set at SMALL in the Speaker

Setting (or automatically via the Auto MCACC setup) and the Crossover Network is set above 150 Hz, the subwoofer channel level will be adjusted by pressing BASS –/+ (page 39).

Press TV first to access:

DTV/TV – Switches between the DTV and analog TV input modes for Pioneer TVs.

10 Number buttons and other component controls

Use the number buttons to directly select a radio frequency (page 32) or the tracks on a CD, etc. There are other buttons that can be accessed after is pressed. (For example MIDNIGHT, etc.)

HDD*, DVD*, VCR* – These buttons switch between the hard disk, DVD and VCR controls for HDD/DVD/VCR recorders.

S.RETRIEVER – Press to restore CD quality sound to compressed audio sources (page 34).

SB CH – Press to select ON, AUTO or OFF the surround back channel (page 35).

CH SELECT – Press repeatedly to select a channel, then use LEV +/– to adjust the level (page 39).

LEV +/– – Use to adjust the channel level. EQ – Press to switch on/off Acoustic Calibration EQ

setting (page 34). MIDNIGHT – Switches to Midnight or Loudness listening

(page 36). SPEAKERS – See Switching the speaker terminal on

page 12.

PHASE – Press to switch on/off Phase Control (page 35). DIMMER – Dims or brightens the display. The brightness

can be controlled in four steps. SIGNAL SEL – Press to select the audio input signal of the

component to play back (page 26).

Press SIRIUS first to access:

D.ACCESS – After pressing, you can access a radio station directly using the number buttons (page 31).

 SOURCE

Press to turn on/off other components connected to the receiver (page 47).

12 TV CONTROL buttons

These buttons are dedicated to control the TV assigned to the TV button. Thus if you only have one TV to hook up to this system assign it to the TV button (page 47).

 – Use to turn on/off the power of the TV.

INPUT – Use to select the TV input signal. CH +/– – Use to select channels. VOL +/– – Use to adjust the volume on your TV.

13 MASTER VOLUME +/–

Use to set the listening volume.

14 MUTE

Mutes/unmutes the sound.

15 DISP

Switches the display of this unit. The listening mode, sound volume, Speaker System setting or input name can be checked by selecting an input source.

• The Speaker System setting may or may not be displayed, depending on the input source you have selected.

16 SHIFT

Press to access the ‘boxed’ commands (above the buttons) on the remote. These buttons are marked with an asterisk (*) in this section. This button is also used for operating ZONE 2 (page 45).

Loading the batteries

The batteries included with the unit are to check initial operations; they may not last over a long period. We recommend using alkaline batteries that have a longer life.

• Incorrect use of batteries may result in such hazards as leakage and bursting. Observe the following precautions:

Never use new and old batteries together.

Insert the plus and minus sides of the batteries properly according to the marks in the battery case.

Batteries with the same shape may have different voltages. Do not use different batteries together.

When disposing of used batteries, please comply with governmental regulations or environmental public instruction’s rules that apply in your country or area.

Do not use or store batteries in direct sunlight or other excessively hot place, such as inside a car or near a heater. This can cause batteries to leak, overheat, explode or catch fire. It can also reduce the life or performance of batteries.

Operating range of remote control

The remote control may not work properly if:

• There are obstacles between the remote control and the receiver’s remote sensor.

• Direct sunlight or fluorescent light is shining onto the remote sensor.

• The receiver is located near a device that is emitting infrared rays.

• The receiver is operated simultaneously with another infrared remote control unit.

Connecting your equipment

Note

Important

5.1 channel surround system:

6.1 channel surround (Surround back) system:

7.1 channel surround (Surround back) system:

7.1 channel surround (Front height) system:

Main zone

Speaker B

Main zone

Sub zone

Chapter 2:

Connecting your equipment

Determining the speakers’ application

By connecting the left and right front speakers (L/R), the center speaker (C), the left and right surround speakers (SL/ SR), the left and right surround back speakers (SBL/SBR) (or the left and right front height speakers (FHL/FHR)), and the subwoofer (SW), a surround sound system up to 7.1 channel can be enjoyed.

The 5.1 channel surround system is the most commonlyused in home theaters. To achieve the best possible surround sound, install your speakers as shown below.

SBL

SBR

• To connect the ZONE 2 speakers, an additional

• Both the surround back speakers and the front height speakers can be connected at the same time. In this case, sound will be output from either the front height speaker or the surround back speaker depending on which one was selected in the Speaker System setting (see The Speaker System setting on page 41).

Speaker B connection

You can use the speakers connected to the B speaker terminals to listen to stereo playback in another room. See Switching the speaker terminal on page 12 for the listening options with this setup.

• You will not be able to connect the B speakers if you connect the front height speakers in the main zone. Further, if you use the B speakers, a 5.1 ch playback will be the maximum in the main zone. (No sound is output from the surround back speaker.)

• The Speaker System setting must be set if the above

FHR

FHL

connections are performed. Select Surr.Back if the surround back speaker or speaker B is connected, and

Height if the front height speaker is connected (see The Speaker System setting on page 41).

ZONE 2 connection (Multi Zone)

With these connections you can simultaneously enjoy the surround sound in the main zone with stereo playback on another component in ZONE 2 (The selection of input devices is limited). See

MULTI-ZONE listening

on page 45.

amplifier is required.

Some tips for improving sound quality

Where you put your speakers in the room has a big effect on the quality of the sound. The following guidelines should help you to get the best sound from your system.

• It is best to angle the speakers towards the listening position. The angle depends on the size of the room. Use less of an angle for bigger rooms.

• Refer to the chart below for placement of speakers you intend to connect.

FHL

30 30

120 120

Place the surround speakers at 120º from the center. If you, (1) use the surround back speaker, and, (2) don’t use the front height speakers, we recommend placing the surround speaker right beside you.

If you intend to connect only one surround back speakers, place it directly behind you.

SBL

FHR

SBR

Connecting your equipment

Front height setting

Speaker B setting

Front right

Subwoofer

Center

Front left

Surround right

Surround left

Surround back right

Surround

back left

Front height right

Speaker B - right

Front height left

Speaker B - left

The front height terminals can also be used for Speaker B.

When using only one surround back speaker, connect it to the SURROUND BACK L (Single) terminals.

If the surround speakers cannot be set directly to the side of the listening position with a 7.1-channel system, the surround effect can be enhanced by turning off the Up Mix function (see Setting the Up Mix function on page 35).

• For the best stereo effect, place the front speakers 2 m to 3 m (6 ft. to 9 ft.) apart, at equal distance from the TV.

• If you’re using a center speaker, place the front speakers at a wider angle. If not, place them at a narrower angle.

• Place the center speaker above or below the TV so that the sound of the center channel is localized at the TV screen. Also, make sure the center speaker does not cross the line formed by the leading edge of the front left and right speakers.

• Surround and surround back speakers should be positioned 60 cm to 90 cm (2 ft. to 3 ft.) higher than your ears and titled slight downward. Make sure the speakers don’t face each other. For DVD-Audio, the speakers should be more directly behind the listener than for home theater playback.

• Try not to place the surround speakers farther away from the listening position than the front and center speakers. Doing so can weaken the surround sound effect.

• Place the left and right front height speakers at least one meter (3.3 ft.) directly above the left and right front speakers.

• If you’re going to place speakers around your CRT TV, use shielded speakers or place the speakers at a sufficient distance from your CRT TV.

• The subwoofer can be placed on the floor. Ideally, the other speakers should be at about ear-level when you’re listening to them. Putting the speakers on the floor (except the subwoofer), or mounting them very high on a wall is not recommended.

• When not connecting a subwoofer, connect speakers with low frequency reproduction capabilities to the front channel. (The subwoofer’s low frequency component is played from the front speakers, so the speakers could be damaged.)

• After connecting, be sure to conduct the Auto MCACC (speaker environment setting) procedure. See Automatically setting up for surround sound (MCACC) on page 24.

DVR/BDR IN DVD IN BD IN VIDEO 1 IN

HDMI

VIDEO

MONITOR

TV/SATINBD

OUT

DVR/

OUT

BDR

12 V TRIGGER

OUT IN DVD IN

(

OUTPUT

(

)

DVD

12 V

ASSIGN ABLE

50 mA

)

MAX

(

DVR/

)

BDR

MONITOR OUT

COMPONENT VIDEO

BPR

LINE LEVEL

INPUT

AUDIO

ZONE2

DVR/BDR

CD-R/TAPE

OUT

IN IN

TV/SAT

DVD

OUT

COAXIAL

(CD)

(

OUTPUT 5 V

0.1 A MAX

ANTENNA

FM UNBAL 75

SIRIUS

SUBWOOFER

PRE OUT

ASSIGNABLE

ADAPTER PORT

)

AM LOOP

(

TV/SAT

FRONT

)

(

CD-R/TAPE

OPTICAL

ASSIGNABLE

)

CENTER

SURROUND

SPEAKERS

SURROUND BACK

Class 2 Wiring

FRONT HEIGHT /

(

)

Single

Connecting your equipment

CAUTION

Note

12 3

10 mm (3/8 in.)

• Make sure that all speakers are securely installed. This

not only improves sound quality, but also reduces the risk of damage or injury resulting from speakers being knocked over or falling in the event of external shocks such as earthquakes.

Connecting the speakers

The receiver will work with just two stereo speakers (the front speakers in the diagram) but using at least three speakers is recommended, and a complete setup is best for surround sound.

Make sure you connect the speaker on the right to the right (R) terminal and the speaker on the left to the left (L) terminal. Also make sure the positive and negative (+/–) terminals on the receiver match those on the speakers. You can use speakers with a normal impedance between 6 Ω and 16 Ω.

Be sure to complete all connections before connect ing this unit to the AC power source.

Bare wire connections

A-Speaker terminals:

Twist exposed wire strands together.

Loosen terminal and insert exposed wire.

Tighten terminal.

B-Speaker terminals:

Twist exposed wire strands together.

Push open the tabs and insert exposed wire.

Release the tabs.

12 3

• These speaker terminals carry HAZARDOUS LIVE voltage. To prevent the risk of electric shock when

connecting or disconnecting the speaker cables, disconnect the power cord before touching any uninsulated parts.

• Make sure that all the bare speaker wire is twisted together and inserted fully into the speaker terminal. If any of the bare speaker wire touches the back panel it may cause the power to cut off as a safety measure.

Switching the speaker terminal

If you selected Surr.Back in The Speaker System setting on page 41, you can switch between speakers using the SPEAKERS button. If you selected Height, the button will simply switch your main speaker terminal on or off. The options below are for the Surr.Back setting only.



Use the SPEAKERS button on the front panel to select a

speaker terminal setting.

CONTROL - MULTI-ZONE - ON/OFF

SPEAKERS

Press repeatedly to choose a speaker terminal option:

• SPA – Sound is output from the speakers connected to

the A-speaker terminals (multichannel playback is possible).

• SPB – Sound is output from the two speakers connected

to the B-speaker terminals (only stereo playback is possible).

• SPAB – Sound is output from the A-speaker terminals,

the two speakers in the B-speaker terminals, and the subwoofer. Multichannel sources are downmixed only when the STEREO or STEREO ALC mode is selected for stereo output from A- and B-speaker terminals.

• SP – No sound is output from the speakers.

• The subwoofer output depends on the settings you made

in Speaker Setting on page 38. However, if SPB is selected above, no sound is heard from the subwoofer (the LFE channel is not downmixed).

• All speaker terminals are switched off when headphones are connected.

Connecting your equipment

Important

Note

AUDIO

White (Left)

Red (Right)

COAXIAL

OPTICAL

Coaxial digital

audio cable

Optical cable

Making cable connections

Make sure not to bend the cables over the top of this unit (as shown in the illustration). If this happens, the magnetic field produced by the transformers in this unit may cause a humming noise from the speakers.

• Before making or changing connections, switch off the power and disconnect the power cord from the AC outlet.

• Before unplugging the power cord, switch the power into standby.

HDMI cables

Both video and sound signals can be transmitted simultaneously with one cable. If connecting the player and the TV via this receiver, for both connections, we recommend using HDMI cables.

HDMI

Be careful to connect the terminal in the proper direction.

• Set the HDMI parameter in Setting the Audio options on page 36 to THRU (THROUGH) and set the input signal in Selecting the audio input signal on page 26 to HDMI, if you want to hear HDMI audio output from your TV (no sound will be heard from this receiver).

• If the video signal does not appear on your TV, try adjusting the resolution settings on your component or di sp la y. Not e t ha t s ome co mp on en ts ( su ch as vid eo ga me units) have resolutions that may not be displayed. In this case, use a (analog) composite connection.

• When the video signal from the HDMI is 480i, 480p, 576i or 576p, Multi Ch PCM sound and HD sound cannot be received.

About HDMI

The HDMI connection transfers uncompressed digital video, as well as almost every kind of digital audio that the connected component is compatible with, including DVDVideo, DVD-Audio, SACD, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio (see below for limitations), Video CD/ Super VCD and CD. This receiver incorporates High-Definition Multimedia Interface (HDMI

This receiver supports the functions described below through HDMI connections.

• Digital transfer of uncompressed video (contents protected by HDCP (1080p/24, 1080p/60, etc.))

• 3D signal transfer

• Deep Color signal transfer

• x.v.Color signal transfer

• Audio Return Channel

• Input of multi-channel linear PCM digital audio signals (192 kHz or less) for up to 8 channels

• Input of the following digital audio formats: – Dolby Digital, Dolby Digital Plus, DTS, High bitrate audio (Dolby TrueHD, DTS-HD Master Audio), DVDAudio, CD, SACD (DSD 2 ch only), Video CD, Super VCD

• Synchronized operation with components using the

Control with HDMI function (see Control with HDMI function on page 43)

• Use a High Speed HDMI® cable. If HDMI cable other than a High Speed HDMI properly.

• When an HDMI cable with a built-in equalizer is connected, it may not operate properly.

) technology.

cable is used, it may not work

• 3D, Deep Color, x.v.Color signal transfer and Audio Return Channel are only possible when connected to a compatible component.

• HDMI format digital audio transmissions require a longer time to be recognized. Due to this, interruption in the audio may occur when switching between audio formats or beginning playback.

• Turning on/off the device connected to this unit’s HDMI OUT terminal during playback, or disconnecting/ connecting the HDMI cable during playback, may cause noise or interrupted audio.

HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing, LLC in the United States and other countries.

“x.v.Color” and are trademarks of Sony Corporation.

Analog audio cables

Use stereo RCA phono cables to connect analog audio components. These cables are typically red and white, and you should connect the red plugs to R (right) terminals and white plugs to L (left) terminals.

Digital audio cables

Commercially available coaxial digital audio cables or optical cables should be used to connect digital components to this receiver.

Connecting your equipment

Note

VIDEO

Yellow

Green (Y)

Red (PR)

Blue (PB)

VIDEO

HDMI

COMPONENT VIDEO

MONITOR OUT

YPBP

MONITOR

OUT

COMPONENT VIDEO

YPBP

HDMI

OUT

Terminal for connection with source device

Terminal for connection with TV monitor

Playback

component

Video signals can be output.

This item incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited.

• When connecting optical cables, be careful when inserting the plug not to damage the shutter protecting the optical socket.

• When storing optical cable, co il loosely. The cable may be damaged if bent around sharp corners.

• You can also use a standard RCA video cable for coaxial digital connections.

Video cables

Standard RCA video cables

These cables are the most common type of video connection and are used to connect to the composite video terminals. The yellow plugs distinguish them from cables for audio.

Component video cables

Use component video cables to get the best possible color reproduction of your video source. The color signal of the TV is divided into the luminance (Y) signal and the color (P

R) signals and then output. In this way, interference between

the signals is avoided.

COMPONENT VIDEO

About the video converter

The video converter ensures that all video sources are output from HDMI OUT terminal. The only exception is HDMI: since this resolution cannot be downsampled, you must connect your monitor/TV to the receiver’s HDMI video outputs when connecting this video source.

• If several video components are assigned to the same input function, the converter gives priority to HDMI, component, then composite (in that order).

• If the video signal does not appear on your TV, try adjusting the resolution settings on your component or display. Note that some components (such as video game units) have resolutions that may not be converted. In this case, try switching Video Converter OFF (see Video Converter on page 41).

• The signal input resolutions that can be converted from the component video input for the HDMI output are 480i/ 576i, 480p/576p, 720p and 1080i. 1080p signal cannot be converted.

B and

Connecting your equipment

MONITOR

OUT

ZONE2

HDMI

VIDEO

COMPONENT VIDEO

DVR/ BDR

BPR

AUDI O

ANTENNA

OPTICAL

ASSIGNABLE

ASSIGN ABLE

ASSIGNABLE

OUT

DVR/BDR

OUT

CD-R/TAPE

COAXIAL

(CD)

PRE OUT

SUBWOOFER

IN IN

OUT

MONITOR

OUT

TV/SATINBD

OUT

IN DVD IN

TV/SAT

DVD

(

DVD

)

MONITOR OUT

(

DVR/ BDR

)

DVR/BDR IN

DVD IN

BD IN

VIDEO 1 IN

(

TV/SAT

)

(

CD-R/TAPE

)

FM UNBAL 75

(

OUTPUT 5 V

0.1 A MAX

)

ADAPTER PORT

AM LOOP

SIRIUS

FRONT

R L

CENTER

12 V TRIGGER

(

OUTPUT

12 V

50 mA MAX

)

OUT

HDMI IN

HDMI OUT

DIGITAL AUDIO OUTANALOG AUDIO OUT

OPTICAL

Select one

HDMI/DVI-compatible TV

HDMI/DVI-compatible

Blu-ray Disc player

If the TV does not support the HDMI Audio Return Channel function, this connection is required to listen to the TV sound over the receiver.

Connecting a TV and playback components

Connecting using HDMI

If you have an HDMI or DVI (with HDCP) equipped component (Blu-ray Disc player, etc.), you can connect it to this receiver using a commercially available HDMI cable. If the TV and playback components support the Control with HDMI feature, the convenient Control with HDMI functions can be used (see Control with HDMI function on page 43).

• The following connection/setting is required to listen to the sound of the TV over this receiver.

If the TV does not support the HDMI Audio Return Channel function, connect the receiver and TV with audio cables (as shown).

If the TV supports the HDMI Audio Return Channel function, the sound of the TV is input to the receiver via the HDMI terminal, so there is no need to connect an audio cable. In this case, set ARC at HDMI Setup to ON (see HDMI Setup on page 43).

Connecting your equipment

Note

RECEIVER

Select one

DVD player

Select one

This connection is required in order to listen to the sound of the TV over the receiver.

Connecting your TV with no HDMI input

This diagram shows connections of a TV (with no HDMI input) and DVD player (or other playback component) to the receiver.

• With these connections, the picture is not output to the

TV even if the DVD player is connected with an HDMI cable. Connect the DVD player’s video signals using a composite or component cable.

• Connect using an HDMI cable to listen to HD audio on the

receiver. Do not use an HDMI cable to input video signals. Depending on the video component, it may not be possible to output signals connected by HDMI and other methods simultaneously, and it may be necessary to make output settings. Please refer to the operating instructions supplied with your component for more information.

• If both TV and player has a component video jacks, you

can connect these too. See Using the component video jacks on page 19 for more on this.

• In order to listen to the audio from the DVD player that is

connected to this receiver using an optical cable or a coaxial cable, first, switch to the DVD input, then use

and SIGNAL SEL to choose the audio signal O2

(OPTICAL2) or C1 (COAXIAL1) (see Selecting the audio input signal on page 26).

HDMI

OUT

12 V TRIGGER

(

OUTPUT

12 V

50 mA

)

MAX

DVR/BDR IN

VIDEO

MONITOR

OUT

DVR/ BDR

OUT

(

)

DVD

ASSIGN ABLE

(

DVR/

)

BDR

MONITOR OUT

COMPONENT VIDEO

DVD IN

TV/SATINBD

IN DVD IN

BPR

VIDEO 1 IN

BD IN

AUDIO

DVR/BDR

CD-R/TAPE

OUT

IN IN

TV/SAT

COAXIAL

OUT

ASSIGNABLE

(CD)

ZONE2

DVD

OUT

ANTENNA

FM UNBAL 75

SIRIUS

(

OUTPUT 5 V

0.1 A MAX

SUBWOOFER

PRE OUT

ADAPTER PORT

)

AM LOOP

(

TV/SAT

FRONT

R L

)

(

CD-R/TAPE

OPTICAL

ASSIGNABLE

)

CENTER

VIDEO IN

OPTICAL

DIGITAL AUDIO OUT ANALOG AUDIO OUT

VIDEO OUT

OPTICAL COAXIAL

DIGITAL AUDIO OUTANALOG AUDIO OUT

HDMI OUT

Connecting your equipment

Note

HDMI

OUT

HDMI IN

DIGITAL AUDIO OUTANALOG AUDIO OUT

OPTICAL COAXIAL

VIDEO OUT

DIGITAL AUDIO OUT ANALOG AUDIO OUT

OPTICAL

Select one

DVD player

Select one

If the TV does not support the HDMI Audio Return Channel function, this connection is required to listen to the TV sound over the receiver.

Connecting your DVD player with no HDMI output

This diagram shows connections of a TV (with HDMI input) and DVD player (or other playback component with no HDMI output) to the receiver.

• If your player has a component video output, you can connect these too. See Using the component video jacks on page 19 for more on this.

• The following connection/setting is required to listen to the sound of the TV over this receiver.

If the TV does not support the HDMI Audio Return Channel function, connect the receiver and TV with audio cables (as shown).

• In order to listen to the audio from the DVD player that is connected to this receiver using an optical cable or a coaxial cable, first, switch to the DVD input, then use

RECEIVER

(OPTICAL2) or C1 (COAXIAL1) (see Selecting the audio input signal on page 26).

and SIGNAL SEL to choose the audio signal O2

HDMI

12 V TRIGGER

(

OUTPUT

12 V

50 mA MAX

OUT

)

DVR/BDR IN

VIDEO

MONITOR

OUT

DVR/ BDR

OUT

(

)

DVD

ASSIGN ABLE

(

DVR/

)

BDR

MONITOR OUT

COMPONENT VIDEO

DVD IN

TV/SATINBD

IN DVD IN

BPR

VIDEO 1 IN

BD IN

AUDI O

DVR/BDR

CD-R/TAPE

OUT

IN IN

TV/SAT

COAXIAL

OUT

ASSIGNABLE

(CD)

ZONE2

DVD

OUT

ANTENNA

FM UNBAL 75

SIRIUS

(

OUTPUT 5 V

0.1 A MAX

SUBWOOFER

PRE OUT

ADAPTER PORT

)

AM LOOP

(

TV/SAT

FRONT

R L

)

(

CD-R/TAPE

OPTICAL

ASSIGNABLE

)

CENTER

Connecting your equipment

Note

Select one

Set-top box, etc.

DIGITAL AUDIO OUTANALOG AUDIO OUT

ANALOG AUDIO IN

OPTICAL

VIDEO IN

VIDEO OUT

Select one

HDD/DVD recorder, Blu-ray Disc recorder, etc.

RECEIVER

Connecting a satellite receiver or other digital set-top box

Satellite and cable receivers, and terrestrial digital TV tuners are all examples of so-called ‘settop boxes’.

• If the set-top box or video component also has an HDMI or a component video output, you

can connect this too. See Connecting using HDMI on page 15 or Using the component video jacks on page 19 for more on this.

COAXIAL

HDMI

OUT

12 V TRIGGER

(

OUTPUT

12 V

50 mA

)

MAX

DVR/BDR IN

VIDEO

MONITOR

OUT

DVR/ BDR

OUT

(

)

DVD

ASSIGN ABLE

(

DVR/

)

BDR

MONITOR OUT

COMPONENT VIDEO

VIDEO OUT

DVD IN

TV/SATINBD

IN DVD IN

BPR

BD IN

AUDIO

DVR/BDR

OUT

IN IN

TV/SAT

VIDEO 1 IN

CD-R/TAPE

ZONE2

DVD

OUT

(

OUTPUT 5 V

OUT

0.1 A MAX

ANTENNA

FM UNBAL

SIRIUS

SUBWOOFER

PRE OUT

(CD)

AM LOOP

ASSIGNABLE

ADAPTER PORT

)

R L

(

TV/SAT

FRONT

)

(

DIGITAL AUDIO OUTANALOG AUDIO OUT

CD-R/TAPE

OPTICAL

ASSIGNABLE

)

CENTER

OPTICALCOAXIAL

Connecting an HDD/DVD recorder, Blu-ray Disc recorder and other video sources

This receiver has audio/video inputs and outputs suitable for connecting analog or digital video recorders, including HDD/DVD recorders and Blu-ray Disc recorders.

• Only the signals that are input to the VIDEO IN terminal can be output from the VIDEO OUT terminal.

• Audio signals that are input through the digital ter minal will not be output from the analog terminal.

COAXIAL

HDMI

OUT

12 V TRIGGER

(

OUTPUT 12 V

50 mA

)

MAX

DVR/BDR IN

VIDEO

MONITOR

OUT

DVR/ BDR

OUT

(

)

DVD

ASSIGN ABLE

(

DVR/

)

BDR

MONITOR OUT

COMPONENT VIDEO

DVD IN

TV/SATINBD

IN DVD IN

BPR

BD IN

AUDIO

DVR/BDR

OUT

IN IN

TV/SAT

VIDEO 1 IN

CD-R/TAPE

ZONE2

OUT

ASSIGNABLE

(CD)

ADAPTER PORT

(

OUTPUT 5 V

OUT

)

0.1 A MAX

ANTENNA

FM UNBAL

AM LOOP

SIRIUS

SUBWOOFER

DVD

PRE OUT

(

TV/SAT

FRONT

R L

)

(

CD-R/TAPE

OPTICAL

ASSIGNABLE

)

CENTER

• In order to listen to the audio from the source component that is connected to this receiver

using a coaxial cable, first, switch to the TV/SAT, then use and SIGNAL SEL to choose the audio signal C1 (COAXIAL1) (see Selecting the audio input signal on page 26).

RECEIVER

• In order to listen to the audio from the source component that is connected to this receiver using an optical cable, first, switch to the to choose the audio signal

DVR/BDR

(OPTICAL2) (see

input, then use and

Selecting the audio input signal

SIGNAL SEL

on page 26).

Connecting your equipment

Important

Note

VIDEO

COMPONENT VIDEO IN

COMPONENT VIDEO OUT

DVD player

REC

DIGITAL AUDIO OUTANALOG AUDIO OUT

ANALOG AUDIO IN

OPTICALCOAXIAL

Select one

CD-R, MD, DAT, Tape recorder, etc.

RECEIVER

Using the component video jacks

Component video should deliver superior picture quality when compared to composite video. A further advantage (if your source and TV are both compatible) is progressive-scan video, which delivers a very stable, flicker-free picture. See the manuals that came with your TV and source component to check whether they are compatible with progressive-scan video.

• For the audio connection, refer to Connecting your DVD player with no HDMI output on

page 17.

• If you connect any source component to the receiver using a component video input, you

must also have your TV connected to this receiver’s COMPONENT VIDEO MONITOR OUT jacks.

• If necessary, assign the component video inputs to the input source you’ve connected. This only needs to be done if you didn’t connect according to the following defaults:

COMPONENT VIDEO IN 1: DVD

COMPONENT VIDEO IN 2: DVR/BDR

See The Input Assign menu on page 40 for more on this.

MONITOR

TV/SATINBD

OUT

DVR/

OUT

BDR

12 V TRIGGER

OUT

IN DVD IN

(

OUTPUT

(

)

DVD

12 V

ASSIGN ABLE

50 mA

)

MAX

(

DVR/

)

BDR

MONITOR OUT

BPR

COMPONENT VIDEO

DVR/BDR

OUT

IN IN

TV/SAT

CD-R/TAPE

ZONE2

ADAPTER PORT

(

OUTPUT 5 V

OUT

)

0.1 A MAX

ANTENNA

FM UNBAL

AM LOOP

SIRIUS

DVD

R L

SUBWOOFER

PRE OUT

FRONT

CENTER

Connecting other audio components

The number and kind of connections depends on the kind of component you’re connecting. Follow the steps below to connect a CD-R, MD, DAT, tape recorder or other audio component.

• Note that you must connect digital components to analog audio jacks if you want to record to/from digital components (like an MD) to/from analog components.

COAXIAL

DVD IN

DVR/BDR IN

HDMI

VIDEO

MONITOR

DVR/

OUT

BDR

12 V TRIGGER

(

OUTPUT

(

)

DVD

12 V

ASSIGN ABLE

50 mA

)

MAX

(

DVR/

)

BDR

MONITOR OUT

COMPONENT VIDEO

• In order to listen to the audio from the CD player that is connected to this receiver using a coaxial cable, first, switch to the CD-R input, then use and SIGNAL SEL to choose the audio signal C1 (COAXIAL1) (see Selecting the audio input signal on page 26).

TV/SATINBD

OUT

IN DVD IN

BPR

BD IN

AUDIO

DVR/BDR

OUT

IN IN

TV/SAT

VIDEO 1 IN

CD-R/TAPE

ZONE2

OUT

ASSIGNABLE

(CD)

ADAPTER PORT

(

OUTPUT 5 V

OUT

)

0.1 A MAX

ANTENNA

FM UNBAL

AM LOOP

SIRIUS

SUBWOOFER

DVD

PRE OUT

(

TV/SAT

FRONT

R L

)

(

CD-R/TAPE

OPTICAL

ASSIGNABLE

)

CENTER

Connecting your equipment

Important

ZONE2

HDMI

VIDEO

COMPONENT VIDEO

DVR/ BDR

BPR

AUDIO

ANTENNA

ASSIGNABLE

ASSIGN ABLE

ASS

OUT

DVR/BDR

OUT

CD-R/TAPE

COAXIAL

(CD)

PRE OUT

SUBWOOFER

IN IN

OUT

MONITOR

OUT

TV/SATINBD

OUT IN DVD IN

TV/SAT

DVD

(

DVD

)

MONITOR OUT

(

DVR/ BDR

)

DVR/BDR IN DVD IN BD IN VIDEO 1 IN

(

TV/SAT

)

(

CD-R/TAPE

FM UNBAL 75

(

OUTPUT 5 V

0.1 A MAX

)

ADAPTER PORT

AM LOOP

SIRIUS

FRONT

12 V TRIGGER

(

OUTPUT

12 V

50 mA MAX

)

OUT

Bluetooth® ADAPTER

ZONE2

HDMI

VIDEO

COMPONENT VIDEO

DVR/ BDR

BPR

AUDIO

ANTENNA

ASSIGNABLE

ASSIGN ABLE

ASS

OUT

DVR/BDR

OUT

CD-R/TAPE

COAXIAL

(CD)

PRE OUT

SUBWOOFER

IN IN

OUT

MONITOR

OUT

TV/SATINBD

OUT

IN DVD IN

TV/SAT

DVD

(

DVD

)

MONITOR OUT

(

DVR/

BDR

)

DVR/BDR IN

DVD IN

BD IN

VIDEO 1 IN

(

TV/SAT

)

(

CD-R/TAPE

FM UNBAL 75

(

OUTPUT 5 V

0.1 A MAX

)

ADAPTER PORT

AM LOOP

SIRIUS

FRONT

R L

12 V TRIGGER

(

OUTPUT 12 V

50 mA MAX

)

OUT

SIRIUS

Antenna

SiriusConnect™

HOME tuner

AC adapter

ANTENNA

FM UNBAL 75

AM LOOP

fig. a

fig. b

Connecting optional



Connect a

terminal on the rear panel.

• For instructions on playing the Bluetooth wireless technology device, see Pairing the Bluetooth ADAPTER and Bluetooth wireless technology device on page 30.

• Do not move the receiver with the Bluetooth ADAPTER connected. Doing so could cause damage or faulty contact.

Bluetooth

Bluetooth® ADAPTER

ADAPTER to the ADAPTER PORT

Connecting your SiriusConnect™ Tuner

To receive SIRIUS Satellite Radio broadcasts, you will need to activate your SiriusConnect tuner.



Connect a SiriusConnect tuner to the SIRIUS IN jack on

the rear panel.

• You will also need to connect the antenna and AC adapter to the SiriusConnect tuner.

• For instructions on playing the SIRIUS Radio, see Listening to SIRIUS Radio on page 31.

Connecting antennas

Connect the AM loop antenna and the FM wire antenna as shown below. To improve reception and sound quality, connect external antennas (see Using external antennas below).

Push open the tabs, then insert one wire fully into each terminal, then release the tabs to secure the AM antenna wires.

Fix the AM loop antenna to the attached stand.

To fix the stand to the antenna, bend in the direction indicated by the arrow (fig. a) then clip the loop onto the stand (fig. b).

Place the AM antenna on a flat surface and in a direction giving the best reception.

Connect the FM wire antenna into the FM antenna socket.

For best results, extend the FM antenna fully and fix to a wall or door frame. Don’t drape loosely or leave coiled up.

Connecting your equipment

F connector

ANTENNA

FM UNBAL 75

AM LOOP

Outdoor antenna

5 m to 6 m

(16 ft. to 20 ft.)

Indoor antenna

(vinyl-coated wire)

CONTROL ON / OFF

AUDIO

VIDEO

OUTPUT

MCACC

SETUP MIC

L AUDIO R VIDEO

VIDEO 2 INPUT

iPod

iPhone

iPad

USB

5V 2.1

PHONES

This receiver

Video camera, etc.

MCACC

SETUP MIC

L AUDIO R VIDEO

VIDEO 2 INPUT

iPod

iPhone

iPad

USB

5V 2.1

PHONES

Music





Genius >

Playlists Artists Albums Songs Radio Genres Composers Audiobooks

CONTROL ON / OFF

iPod

iPod cable

This receiver

Using external antennas

To improve FM reception

Use an F connector (not supplied) to connect an external FM antenna.

ANTENNA

FM UNBAL 75

To improve AM reception

Connect a 5 m to 6 m (16 ft. to 20 ft.) length of vinyl-coated wire to the AM antenna terminal without disconnecting the supplied AM loop antenna.

For the best possible reception, suspend horizontally outdoors.

Connecting to the front panel video terminal

Front video connections are accessed via the front panel using the INPUT SELECTOR or VIDEO2 button on the remote control. There are standard audio/video jacks. Hook them up the same way you made the rear panel connections.

• Push down on the PUSH OPEN tab to access the front

video connections.

Connecting an iPod

This receiver has a dedicated iPod terminal that will allow you to control playback of audio content from your iPod using the controls of this receiver.



Switch the receiver into standby, and then use the iPod cable to connect your iPod to the iPod terminal on the front panel of this receiver.

• Push down on the PUSH OPEN tab to access the iPod

terminal.

• For the cable connection, refer to also the operating instructions for iPod.

• For instructions on playing the iPod, see Playing an iPod on page 27.

Connecting your equipment

Note

MCACC

SETUP MIC

L AUDIO R VIDEO

VIDEO 2 INPUT

iPod

iPhone

iPad

USB

5V 2.1

PHONES

CONTROL ON / OFF

USB mass

storage device

This receiver

IR receiver

Closet or shelving unit

Other component

HDMI

VIDEO

COMPONENT VIDEO

DVR/ BDR

YPBP

AUDIO

ASSIGN ABLE

DVR/BDR

OUT

MONITOR

OUT

TV/SATINBD

OUT

IN DVD IN

TV/SAT

(

DVD

)

MONITOR OUT

(

DVR/ BDR

)

DVR/BDR IN

DVD IN

BD IN

12 V TRIGGER

(

OUTPUT 12 V

50 mA MAX

)

OUT

12 V TRIGGER

INPUT

Connecting a USB device

It is possible to listen to two-channel audio using the USB interface on the front of this receiver.



Switch the receiver into standby then connect your USB device to the USB terminal on the front panel of this receiver.

• Push down on the PUSH OPEN tab to access the USB

terminal.

• This receiver does not support a USB hub.

• For instructions on playing the USB device, see Playing a USB device on page 28.

Connecting an IR receiver

If you keep your stereo components in a closed cabinet or shelving unit, or you wish to use the sub zone remote control in another zone, you can use an optional IR receiver (such as a Niles or Xantech unit) to control your system instead of the remote sensor on the front panel of this receiver.

• Remote operation may not be possible if direct light from a strong fluorescent lamp is shining on the IR receiver remote sensor window.

• Note that other manufacturers may not use the IR terminology. Refer to the manual that came with your component to check for IR compatibility.

DVD IN

DVR/BDR IN

HDMI

VIDEO

DVR/

OUT

BDR

12 V TRIGGER

(

OUTPUT

(

DVD

12 V

ASSIGN ABLE

50 mA

)

MAX

(

DVR/ BDR

MONITOR OUT



Connect the IR receiver sensor to the IR IN jack on the

rear of this receiver.

For more information on connecting the IR receiver, see the Installation Instructions for the IR Receiver.

MONITOR

TV/SATINBD

OUT

OUT IN DVD IN

)

YPBP

COMPONENT VIDEO

BD IN

AUDIO

DVR/BDR

OUT

TV/SAT

Switching components on and off using the 12 volt trigger

You can connect components in your system (such as a screen or projector) to this receiver so that they switch on or off using 12 volt triggers when you select an input function. However, you must specify which input functions switch on the trigger using the The 12 V Trigger Setting on page 42. Note that this will only work with components that have a standby mode.



Connect the 12 V TRIGGER jack of this receiver to the 12

V trigger of another component.

Use a cable with a mono mini-plug on each end for the connection.

After you’ve specified the input functions that will switch on the trigger, you’ll be able to switch the component on or off just by pressing the input function(s) you’ve set on page 42.

Connecting your equipment

CAUTION

Note

Plugging in the receiver

Only plug in after you have connected all your components to this receiver, including the speakers.



Plug the AC power cord into a convenient AC power

outlet.

• Handle the power cord by the plug part. Do not pull out the plug by tugging the cord, and never touch the power cord when your hands are wet, as this could cause a short circuit or electric shock. Do not place the unit, a piece of furniture, or other object on the power cord or pinch the cord in any other way. Never make a knot in the cord or tie it with other cables. The power cords should be routed so that they are not likely to be stepped on. A damaged power cord can cause a fire or give you an electric shock. Check the power cord once in a while. If you find it damaged, ask your nearest Pioneer authorized independent service company for a replacement.

• The receiver should be disconnected by removing the mains plug from the wall socket when not in regular use, e.g., when on vacation.

• After this receiver is connected to an AC outlet, a 2 second to 10 second HDMI initialization process begins. You cannot carry out any operations during this process. The HDMI indicator in the front panel display blinks during this process, and you can turn on this receiver once it has stopped blinking. When you set the Control with HDMI to OFF, you can skip this process. For details about the Control with HDMI feature, see Control with HDMI function on page 43.

CAUTION

Important

MCACC

SETUP MIC

L AUDIO R VIDEO

VIDEO 2 INPUT

iPod

iPhone

iPad

USB

5V 2.1

PHONES

CONTROL ON / OFF

Tripod

Microphone

System Setup

1.Auto MCACC

2.Manual SP Setup

3.Input Assign

4.Speaker System

5.Video Parameter

6.HDMI Setup

7.Auto Power Down

8.12V Trigger

Return

1.Auto MCACC

Now Analyzing

Environment Check Ambient Noise Speaker YES/NO

Return

Chapter 3:

Basic Setup

Automatically setting up for surround sound (MCACC)

The Auto Multi-Channel Acoustic Calibration (MCACC) setup measures the acoustic characteristics of your listening area, taking into account ambient noise, speaker size and distance, and tests for both channel delay and channel level. After you have set up the microphone provided with your system, the receiver uses the information from a series of test tones to optimize the speaker settings and equalization for your particular room.

Basic Setup

• The test tones used in the Auto MCACC setup are output

at high volume.

• The Auto MCACC setup will overwrite any existing

speaker settings you’ve made.

• Before using the Auto MCACC setup, the iPod USB input

should not be selected as an input source.

• When both the surround back speaker and the front

height speaker are connected, conduct Auto MCACC setup twice: once with the Speaker System setting is in

Surr.Back and once with the Speaker System setting is in Height. (There is no need to conduct Auto MCACC setup

every time the Speaker System setting is changed.)

PARAMETER

TOP

RECEIVER

BD DVD

SOURCESLEEP

INPUT SELECT

CONTROL

INPUT

S E

HOME MENU

SETUP

iPod CTRL

CATEGORY

ENTER

VOLUME

TOOLS

E S

BAND

RETURN

MUTE

DTV/ TV

Switch on the receiver and your TV.

Switch the TV input so that it connects to the receiver.

Connect the microphone to the MCACC SETUP MIC jack

on the front panel.

Make sure there are no obstacles between the speakers and the microphone.

If you have a tripod, use it to place the microphone so that it’s about ear level at your normal listening position. Otherwise, place the microphone at ear level using a table or a chair.

RECEIVER

Press on the remote control, then press the

SETUP button.

The System Setup menu appears on your TV. Use /// and ENTER on the remote control to navigate through the screens and select menu items. Press RETURN to exit the current menu.

• Press SETUP at any time to exit the System Setup menu.

If you cancel the Auto MCACC setup at any time, the receiver automatically exits and no settings will be made.

• The screensaver automatically starts after three minutes of inactivity.

Select ‘Auto MCACC’ from the System Setup menu, then

press ENTER.

• MIC IN blinks when the microphone is not connected to

MCACC SETUP MIC jack.

Try to be as quiet as possible after pressing ENTER. The system outputs a series of test tones to establish the ambient noise level.

Follow the instructions on-screen.

• Make sure the microphone is connected.

• Make sure the subwoofer is on and the volume is turned up.

• When using surround back or front height speakers, turn on the power to the amplifier to which the surround back or front height speakers are connected, and adjust the sound level to the desired level.

• See below for notes regarding background noise and other possible interference.

Wait for the test tones to finish.

A progress report is displayed on-screen while the receiver outputs test tones to determine the speakers present in your setup. Try to be as quiet as possible while it’s doing this.

• For correct speaker settings, do not adjust the volume during the test tones.

Basic Setup

Note

1.Auto MCACC

Check!

Return

10:Next

Front Center Surr Surr. Back Subwoofer

[ YES ] [ YES ] [ YES ] [YESx2] [ YES ]

1.Auto MCACC

Now Analyzing

Surround Analyzing Speaker System Speaker Distance Channel Level Acoustic Cal EQ

Return

Confirm the speaker configuration.

The configuration shown on-screen should reflect the actual speakers you have.

• With error messages (such as Too much ambient noise) select RETRY after checking for ambient noise (see Other problems when using the Auto MCACC setup below).

If the speaker configuration displayed isn’t correct, use / to select the speaker and / to change the setting. When you’re finished, go to the next step.

If you see an error message (ERR) in the right side column, there may be a problem with the speaker connection. If selecting RETRY doesn’t fix the problem, turn off the power and check the speaker connections.

Make sure ‘OK’ is selected, then press ENTER.

If the screen in step 7 is left untouched for 10 seconds and ENTER is not pressed in step 8, the Auto MCACC setup will start automatically as shown.

A progress report is displayed on-screen while the receiver outputs more test tones to determine the optimum receiver settings for channel level, speaker distance, and Acoustic Calibration EQ. Again, try to be as quiet as possible while this is happening. It may take 1 to 3 minutes.

The Auto MCACC setup has finished! You return to the

System Setup menu.

The settings made in the Auto MCACC setup should give you excellent surround sound from your system, but it is also possible to adjust these settings manually using the System Setup menu (starting on page 38).

• Depending on the characteristics of your room, sometimes identical speakers with cone sizes of around 12 cm (5 inches) will end up with different size settings. You can correct the setting manually using the Speaker Setting on page 38.

• The subwoofer distance setting may be farther than the actual distance from the listening position. This setting should be accurate (taking delay and room characteristics into account) and generally does not need to be changed.

Other problems when using the Auto MCACC setup

If the room environment is not optimal for the Auto MCACC setup (too much background noise, echo off the walls, obstacles blocking the speakers from the microphone) the final settings may be incorrect. Check for household appliances (air conditioner, fridge, fan, etc.), that may be affecting the environment and switch them off if necessary. If there are any instructions showing in the front panel display, please follow them.

• Some older TVs may interfere with the operation of the microphone. If this seems to be happening, switch off the TV when doing the Auto MCACC setup.

Note

BD DVD

INPUT SELECT

SOURCESLEEP

CONTROL

INPUT

DVR/BDRCDCD-R

ADAPTER

iPod USB VIDEO 1

VIDEO

SIRIUS

TUNER

RECEIVER

VOL

RECEIVER

ENTER

ADV SURR

AUTO/

DIRECT

MUTE

RETURN

AUDIO

PARAMETER

TUNER EDIT

TOOLS

MASTER VOLUME

iPod CTRL

CATEGORY

BAND

HOME MENU SETUP

DTV/ TV

TRE

BASS

TOP MENU

E S

BD MENU

ALC/

STANDARD

STEREO

RECEIVER

INPUT SELECT

SOURCESLEEP

CONTROL

INPUT

RECEIVER

DIMMER

SIGNAL SEL

D.ACCESS

MIDNIGHT

S.RETRIEVER

SPEAKERS

LEV

SB CH

CLR

PHASE

ENTER

CH SELECT

SHIFT

RECEIVER

Basic playback

Chapter 4:

Basic playback

Playing a source

Here are the basic instructions for playing a source (such as a DVD disc) with your home theater system.

Switch on your system components and receiver.

Start by switching on the playback component (for example a DVD player), your TV and subwoofer (if you have one), then the receiver (press  RECEIVER).

• Make sure the setup microphone is disconnected.

Switch the TV input to the input that connects this

receiver.

For example, if you connected this receiver to the VIDEO jacks on your TV, make sure that the VIDEO input is now selected.

Press input function buttons to select the input function

you want to play.

• The input of the receiver will switch over, and you will be able to operate other components using the remote control. To operate the receiver, first press on the remote control, then press the appropriate button to operate.

• The input source can also be selected by using INPUT SELECT buttons on the remote control, or by using the front panel INPUT SELECTOR dial. In this case, the remote control won’t switch operational modes.

If you selected the proper input source and there is still no sound, select the audio input signal for playback (see Selecting the audio input signal below).

Press AUTO/DIRECT to select ‘AUTO SURROUND’ and

start playback of the source.

If you’re playing a Dolby Digital or DTS surround sound DVD disc, with a digital audio connection, you should hear surround sound. If you’re playing a stereo source or if the connection is an analog audio connection, you will only hear sound from the front left/right speakers in the default listening mode. It is possible to check on the front panel display whether or not surround sound playback is being performed properly.

When using a surround back speaker, 2D+PLIIx is displayed when playing Dolby Digital 5.1-channel signals, and DTS+NEO:6 is displayed when playing DTS 5.1-channel signals.

When not using a surround back speaker, 2D is displayed when playing Dolby Digital signals. If the display does not correspond to the input signal and listening mode, check the connections and settings.

• You may need to check the digital audio output settings on your DVD player or digital satellite receiver. It should be set to output Dolby Digital, DTS and 88.2 kHz/96 kHz PCM (2 channel) audio, and if there is an MPEG audio option, set this to convert the MPEG audio to PCM.

• Depending on your DVD player or source discs, you may only get digital 2 channel stereo and analog sound. In this case, the receiver must be set to a multichannel listening mode if you want multichannel surround sound.

Use MASTER VOLUME to adjust the volume level.

Turn down the volume of your TV so that all sound is coming from the speakers connected to this receiver.

Selecting the audio input signal

The audio input signal can be selected for each input source. Once it is set, the audio input that was selected will be applied whenever you select the input source using the input function buttons.



Press , then press SIGNAL SEL to select the

audio input signal corresponding to the source component.

Each press cycles through the following:

• H – Selects an HDMI signal. H can be selected for BD, DVD, DVR/BDR or VIDEO1 input. For other inputs, H cannot be selected.

When the HDMI option in Setting the Audio options on page 36 is set to THRU, the sound will be heard t hrough your TV, not from this receiver.

• A – Selects the analog inputs.

• C1/O1/O2 – Selects the digital input. The coaxial 1 input is selected for C1, and the optical 1 or 2 audio input is selected for O1 or O2.

When H (HDMI) or C1/O1/O2 (digital) is selected and the selected audio input is not provided, A (analog) is automatically selected.

• VIDEO1 input is fixed to H (HDMI). It cannot be changed.

•For the TV/SAT input, only A (analog) or C1/O1/O2 (digital) can be selected. However, if the ARC at HDMI Setup is set to ON, the input is fixed to H (HDMI) and cannot be changed.

• When set to H (HDMI) or C1/O1/O2 (digital), 2 lights when a Dolby Digital signal is input, and DTS lights when a DTS signal is input.

• When the H (HDMI) is selected, the A and DIGITAL indicators are off (see page 7).

Basic playback

Important

Note

Tip

ZONE2

OUT

DVD BD

CD-R

ADAPTER

TUNER

SIRIUS

DVR/BDR

TV BD

DVR/BDR

DVD

DVR/BDR

DVD

CD-R CD

DVR/BDR

BD DVDTV

SIGNAL SEL

RECEIVER

VIDEO 1

1. 1.

SIGNAL SEL

RECEIVER

SIGNAL SEL

RECEIVER

SIGNAL SEL

RECEIVER

Audio

Other than CD input

Audio

Video/Audio (HDMI)

Video

Other than TV/SAT input

Other than CD-R input

(CD input)

(TV/SAT input)

(CD-R input)

Reassignable

(page 40)

• When digital input (optical or coaxial) is selected, this receiver can only play back Dolby Digital, PCM (32 kHz to 96 kHz) and DTS (including DTS 96 kHz/24 bit) digital signal formats. The compatible signals via the HDMI terminals are: Dolby Digital, DTS, SACD (DSD 2 ch only), PCM (32 kHz to 192 kHz sampling frequencies), Dolby TrueHD, Dolby Digital Plus, DTS-EXPRESS, DTS-HD Master Audio and DVD Audio (including 192 kHz). With other digital signal formats, set to A (analog).

• In order to enjoy the picture and/or sound from devices connected to each terminal, select the input by doing the following.

DVR/BDR IN DVD IN BD IN VIDEO 1 IN

HDMI

VIDEO

MONITOR

TV/SATINBD

OUT

DVR/ BDR

OUT IN DVD IN

(

)

DVD

ASSIGNABLE

(

DVR/

)

BDR

MONITOR OUT

COMPONENT VIDEO

BPR

AUDIO

DVR/BDR

CD-R/TAPE

OUT

IN IN

TV/SAT

DVD

OUT

ANTENNA

FM UNBAL 75

SIRIUS

• You may get digital noise when a LD or CD player compatible with DTS is playing an analog signal. To prevent noise, make the proper digital connections (page 13) and set the signal input to C1/O1/O2 (digital).

• Some DVD players don’t output DTS signals. For more details, refer to the instruction manual supplied with your DVD player.

COAXIAL

ASSIGNABLE

(CD)

ADAPTER PORT

(

OUTPUT 5 V

)

0.1A MAX

AM LOOP

OPTICAL

ASSIGNABLE

(

)

(

CD-R/TAPE

)

TV/SAT

Playing an iPod

This receiver has a dedicated iPod terminal that will allow you to control playback of audio content from your iPod using the controls of this receiver.

• Pioneer cannot under any circumstances accept responsibility for any direct or indirect loss arising from any inconvenience or loss of recorded material resulting from the iPod failure.

•This receiver is compatible with the audio and the video of the iPod nano, iPod (fifth generation), iPod classic, iPod touch and iPhone (only supports iPod (fifth generation) and iPod nano (first and second generation) audio playback) (iPod shuffle not supported). However, that some of the functions may be restricted for some models.

• This receiver has been developed and tested for the software version of iPod/iPhone/iPad indicated on the website of Pioneer (http://pioneer.jp/homeav/support/ios/ na/).

•Installing software versions other than indicated on the website of Pioneer to your iPod/iPhone/iPad may result in incompatibility with this receiver.

• iPod and iPhone are licensed for reproduction of noncopyrighted materials or materials the user is legally permitted to reproduce.

• Features such as the equalizer cannot be controlled using this receiver, and we recommend switching the equalizer off before connecting.

Switch on the receiver and your TV.

See Connecting an iPod on page 21.

Switch the TV input so that it connects to the receiver.

Press iPod USB on the remote control to switch the

receiver to the iPod USB input.

The front panel display shows Loading while the receiver verifies the connection and retrieves data from the iPod.

Use TOP MENU to display iPod Top menu.

When the display shows Top Menu you’re ready to play music from the iPod.

Tip

Important

Tip

Important

Note

MUTE

Basic playback

•If after pressing iPod the display shows NO DEVICE, try

switching off the receiver and reconnecting the iPod to the receiver.

• The controls of your iPod will be inoperable when connected to this receiver.

Playing back files stored on an iPod

To navigate songs on your iPod, you can take advantage of the OSD of your TV connected to this receiver. You can also control all operations for music in the front panel display of this receiver.

• Note that non-roman characters in the title are displayed as ‘*’.

• This feature is not available for photos or video clips on your iPod.

Finding what you want to play

When your iPod is connected to this receiver, you can browse songs stored on your iPod by playlist, artist, album name, song name, genre or composer, similar to using your iPod directly.

Use

/

browse that category.

• To return to the previous level any time, press RETURN.

albums).

•Use / to move to previous/next levels.

play, then press

• If you’re in the song category, you can also press ENTER

• You can play all of the songs in a particular category by

to select a category, then press ENTER to

Use

/

to browse the selected category (e.g.,

Continue browsing until you arrive at what you want to



to start playback.

selecting the All item at the top of each category list. For example, you can play all the songs by a particular artist.

Basic playback controls

This receiver’s remote control buttons can be used for basic playback of files stored on an iPod.

• Press iPod USB to switch the remote control to the iPod/

USB operation mode.

STEREO

ENTER

ALC/

STANDARD

TUNER EDIT

TOOLS

E S

RETURN

BAND

BD MENU

ADV SURR

MASTER VOLUME

AUTO/

DIRECT

AUDIO

PARAMETER

TOP MENU

S E

HOME MENU SETUP

iPod CTRL

CATEGORY

• During Audiobook playback, press / to switch the playback speed: Faster  Normal  Slower

BASS

HDD DVD VCR

S.RETRIEVER

SB CH

MIDNIGHT

SPEAKERS

DIMMER

SIGNAL SEL

DTV/ TV

CH SELECT

LEV

TRE

MEMORY

DISP

PHASE

SHIFT

Watching photos and video content

To view photos or video on your iPod, since video control is not possible using this receiver, you must use the main controls of your iPod instead.

• iPod photos and video content can be viewed only when the iPod is connected to the iPod VIDEO input on the front panel.

• This feature can only be used with an iPod having video output.

Press iPod CTRL to switch to the iPod controls for photo

and video playback.

The receiver controls will be unavailable while you are watching iPod videos or browsing photos.

Press iPod CTRL again to switch back to the receiver

controls when you’re done.

• Change the receiver’s input to the iPod in one action by pressing iPod iPhone iPad DIRECT CONTROL on the front panel to enable iPod operations on the iPod.

Playing a USB device

It is possible to listen to two-channel audio using the USB interface on the front of this receiver.

• Pioneer cannot guarantee compatibility (operation and/or bus power) with all USB mass storage devices and assumes no responsibility for any loss of data that may occur when connected to this receiver.

• This includes playback of WMA/MP3/MPEG-4 AAC files (except files with copy-protection or restricted playback).

• Compatible USB devices include external magnetic hard drives, portable flash memory (particularly keydrives) and digital audio players (MP3 players) of format FAT16/32. It is not possible to connect this receiver to a personal computer for USB playback.

• With large amounts of data, it may take longer for the receiver to read the contents of a USB device.

• If the file selected cannot be played back, this receiver automatically skips to the next file playable.

• When the file currently being played back has no title assigned to it, the file name is displayed in the OSD instead; when neither the album name nor the artist name is present, the row is displayed as a blank space.

• Note that non-roman characters in the playlist are displayed as ‘*’.

• Make sure the receiver is in standby when disconnecting the USB device.

Switch on the receiver and your TV.

See Connecting a USB device on page 22.

Switch the TV input so that it connects to the receiver.

Press iPod USB on the remote control to switch the

receiver to the iPod USB input. Loading appears in the OSD as this receiver starts

recognizing the USB device connected. After the recognition, a playback screen appears in the OSD and playback starts automatically.

Basic playback

Important

MUTE

Bluetooth wireless technology enabled device: cell phone

Bluetooth wireless technology enabled device: Digital music player

Device not equipped with Bluetooth wireless technology: Digital music player + Bluetooth audio transmitter (sold commercially)

Music data

Remote control

operation

Bluetooth®

ADAPTER

This receiver

Basic playback controls

This receiver’s remote control buttons can be used for basic playback of files stored on USB devices.

•Press iPod USB to switch the remote control to the iPod/

USB operation mode.

AUTO/

DIRECT

AUDIO

PARAMETER

TOP MENU

S E

HOME MENU SETUP

iPod CTRL

CATEGORY

If a USB Error message lights in the display, try following the points below:

• Switch the receiver off, then on again.

• Reconnect the USB device with the receiver switched off.

• Select another input source (like BD), then switch back to iPod USB.

• Use a dedicated AC adapter (supplied with the device) for USB power.

For more information on error messages, see USB messages on page 52. If this doesn’t remedy the problem, it is likely your USB device is incompatible.

STEREO

ENTER

ALC/

STANDARD

TUNER EDIT

TOOLS

RETURN

E S

BD MENU

ADV SURR

MASTER VOLUME

BAND

BASS

HDD DVD VCR

S.RETRIEVER

MIDNIGHT

DIMMER

SB CH

SPEAKERS

SIGNAL SEL

DTV/ TV

CH SELECT

LEV

TRE

MEMORY

PHASE

SHIFT

Compressed audio compatibility

Note that although most standard bit/sampling rate combinations for compressed audio are compatible, some irregularly encoded files may not play back. The list below shows compatible formats for compressed audio files:

• MP3 (MPEG-1/2/2.5 Audio Layer 3) – Sampling rates:

8 kHz to 48 kHz; Bit rates: 8 kbps to 320 kbps (128 kbps or higher recommended); File extension: .mp3

• WMA (Windows Media Audio) – Sampling rates: 32 kHz/

44.1 kHz; Bit rates: 32 kbps to 192 kbps (128 kbps or

DISP

higher recommended); File extension: .wma; WMA9 Pro and WMA lossless encoding: No

• AAC (MPEG-4 Advanced Audio Coding) – Sampling rates:

11.025 kHz to 48 kHz; Bit rates: 16 kbps to 320 kbps (128 kbps or higher recommended); File extension: .m4a; Apple lossless encoding: No

Other compatibility information

• VBR (variable bit rate) MP3/WM A/MPEG-4 AAC playback: Yes (Note that in some cases playback time will not be displayed correctly.)

• DRM (Digital Rights Management) protection compatible: Yes (DRM-protected audio files will not play in this receiver.)

About MPEG-4 AAC

Advanced Audio Coding (AAC) is at the core of the MPEG-4 AAC standard, which incorporates MPEG-2 AAC, forming the basis of the MPEG-4 audio compression technology. The file format and extension used depend on the application used to encode the AAC file. This receiver plays back AAC files encoded by iTunes protected files will not play, and files encoded with some versions of iTunes

Apple and iTunes are trademarks of Apple Inc., registered in the U.S. and other countries.

About WMA

WMA is an acronym for Windows Media Audio and refers to an audio compression technology developed by Microsoft Corporation. This receiver plays back WMA files encoded using Windows Media Note that DRM-protected files will not play, and files encoded with some versions of Windows Media

bearing the extension ‘.m4a’. DRM-

may not play.

Player bearing the extension ‘.wma’.

Player may not play.

Bluetooth® ADAPTER for Wireless Enjoyment

of Music

Wireless music play

When the Bluetooth ADAPTER (Pioneer Model No. AS-BT100 or AS-BT200) is connected to this unit, a product equipped with Bluetooth wireless technology (portable cell phone, digital music player, etc.) can be used to listen to music wirelessly. Also, by using a commercially available transmitter supporting Bluetooth wireless technology, you can listen to music on a device not equipped with Bluetooth wireless technology. The AS-BT100 and AS-BT200 model supports SCMS-T contents protection, so music can also be enjoyed on devices equipped with SCMS-T type Bluetooth wireless technology.

• It must be necessary that the Bluetooth wireless

technology enabled device supports A2DP profiles.

Important

CATEGORY

Basic playback

• Pioneer does not guarantee proper connection and

operation of this unit with all Bluetooth wireless technology enabled devices.

Remote control operation

The remote control supplied with this unit allows you to play and stop media, and perform other operations.

• It must be necessary that the Bluetooth wireless

technology enabled device supports AVRCP profiles.

• Remote control operations cannot be guaranteed for all

Bluetooth wireless technology enabled devices.

Pairing the wireless technology device

“Pairing” must be done before you start playback of Bluetooth wireless technology content using Bluetooth ADAPTER. Make sure to perform pairing first time you operate the system or any time pairing data is cleared. “Pairing” is the step necessary to register Bluetooth wireless technology device to enable Bluetooth communications. For more details, see also the operating instructions of your Bluetooth wireless technology device.

• Pairing is required when you first use Bluetooth wireless technology device and Bluetooth ADAPTER.

• To enable Bluetooth communication, pairing should be done with both of your system and Bluetooth wireless technology device.

•If the Bluetooth wireless technology device’s security code is “0000”, there is no need to make the security code setting on the receiver. Press ADAPTER to switch the ADAPTER input, then conduct the pairing operation on the Bluetooth wireless technology device. If pairing is successful, there is no need to performing the pairing operation below.

• When using the AS-BT200 only: If the Bluetooth wireless technology device supports SSP (Secure Simple Pairing), there is no need to make the security code setting. Press ADAPTER to switch the ADAPTER input, then conduct the pairing operation on the Bluetooth wireless technology device. If pairing is successful, there is no need to performing the pairing operation below.

Bluetooth

ADAPTER and

Bluetooth

Press TOP MENU.

Press ENTER to enter PAIRING.

Select the PIN code to be used from 0000/1234/8888

using

/

PAIRING blinks.

• You can use any of 0000/1234/8888 PIN codes. Bluetooth

that you want to make pairing, place it near the system and set it into the pairing mode.

the

When Bluetooth wireless technology device is connected: Bluetooth wireless technology device name appears in the

receiver display.

• The system can display alphanumeric characters only.

When Bluetooth wireless technology device is not connected:

NODEVICE appears in the receiver display. In this case, perform the connection operation from the side of the Bluetooth wireless technology device.

select in the step 4.

• PIN code may in some case be referred to as PASSKEY.

Listening to Music Contents of

, then press ENTER.

wireless technology device using any other PIN code cannot be used with this system.

Switch on the

Check to see that the

Bluetooth

Other characters may not be displayed correctly.

From the

Bluetooth

wireless technology device

Bluetooth

wireless technology device.

Bluetooth

wireless technology device list,

ADAPTER and enter the PIN code selected

ADAPTER is detected by

Bluetooth

wireless

technology device with Your System

Press ADAPTER to switch the receiver to ADAPTER input. The ADAPTER input can also be selected by pressing SOUND RETRIEVER AIR on the front panel. In this case, S.R AIR, the optimum listening mode, is selected automatically.

Perform the connection operation from the side of the

Bluetooth

wireless technology device to the

ADAPTER.

• When the Bluetooth ADAPTER is not plugged into the

ADAPTER PORT terminal, NO ADAPTER will be

displayed if ADAPTER input is selected.

Bluetooth

Start playback of music contents stored in

wireless technology device.

This receiver’s remote control buttons can be used for basic playback of files stored on the Bluetooth wireless technology device.

• Bluetooth wireless technology device should be

compatible with AVRCP profile.

• Depending on Bluetooth wireless technology device you

use, operation may differ from what is shown in the remote control buttons.

MUTE

DTV/ TV

TRE

BASS

MEMORY

The Bluetooth trademarks owned by Bluetooth SIG, Inc. and any use of such marks by PIONEER CORPORATION is under license. Other trademarks and trade names are those of their respective owners.

word mark and logos are registered

Bluetooth

Listening to Satellite Radio

To listen to Satellite Radio, you’ll need to connect a SIRIUS Satellite Radio tuner (sold separately) to your Sirius-Ready receiver. SIRIUS Satellite Radio is available to residents of the US (except Alaska and Hawaii) and Canada.

Satellite Radio delivers a variety of commercial-free music from categories ranging from Pop, Rock, Country, R&B, Dance, Jazz, Classical and many more plus coverage of all the top professional and college sports including play by play games from select leagues and teams. Additional programming includes expert sports talk, uncensored entertainment, comedy, family programming, local traffic and weather and news from your most trusted sources. Once you’ve purchased a SIRIUS tuner you’ll need to activate it and subscribe to begin enjoying the service. Easy to follow installation and setup instructions are provided with the SIRIUS tuner. There are a variety of programming packages available, including the option of adding ‘The Best of XM’

Basic playback

Note

Tip

programming to the SIRIUS service. The ‘Best of XM’ service is not available to SIRIUS Canada subscribers at this time. Please check with SIRIUS Canada for any updates using the numbers and web address below. Family friendly packages are also available to restrict channels featuring content that may be inappropriate for children.

To subscribe to SIRIUS, U.S. and Canadian customers can call 1-888-539-SIRI (1-888-539-7474) or visit sirius.com (US) or siriuscanada.ca (Canada).

Listening to SIRIUS Radio

After connecting, you will be able to use this receiver to select channels using the front panel display.

• In order to activate your radio subscription, you will need the SIRIUS ID (SID) which uniquely identifies your tuner. The SID may be found on a sticker located on the packaging, or on the bottom of the tuner itself. The label will have a printed 12-digit SID number. When you have located the SID, write it down in the space provided near the end of this manual. Connect SIRIUS on the internet at: https://activate.siriusradio.com Follow the prompts to activate your subscription, or you can also call SIRIUS toll-free at 1-888-539-SIRIUS (1-888539-7474).



Press SIRIUS to switch to the SIRIUS input.

For best reception, you may need to move the SiriusConnect tuner antenna near a window (refer to the manual for the SiriusConnect Home tuner for antenna placement recommendations).

• If after pressing SIRIUS the display shows Antenna Error, try disconnecting the antenna and reconnecting. If the display shows Check Sirius Tuner, check the connection of the AC adapter and this receiver to the SiriusConnect tuner.

You can check the strength of reception by pressing DISP (DISPLAY).

Selecting channels and browsing by genre

Use the front panel display to select channels. You can select channels from your favorite genre.

• You can, however, use just the front panel display to do everything if you prefer.



Press

/

the radio broadcast is automatically tuned in.

• To select a channel from your favorite genre, press CATEGORY and use / to select a genre, and then use / and ENTER to select a channel from the selected genre.

• To cancel and exit any time, press RETURN.

• You can select channels directly by pressing D.ACCESS then the three-digit channel number.

• You can press DISP (DISPLAY) to change SIRIUS Radio information in the front panel display.

• The currently selected channel is automatically chosen (without pressing ENTER) after 2 seconds.

to select the channel. In the next 2 seconds,

Select SR000 (SIRIUS ID) from the front panel display to check the Radio ID of the SIRIUS Connect tuner.

Saving channel presets

This receiver can memorize up to 30 channels, stored.

Select the channel you want to memorize.

See Selecting channels and browsing by genre above.

Press T.EDIT.

The display shows a blinking memory number.

Press

/

You can also use the number buttons to select a preset.

Press ENTER.

After pressing ENTER, the preset number stop blinking and the receiver stores the SIRIUS channel.

Listening to channel presets

You will need to have some presets stored to do this.



Press

• You can also use the number buttons on the remote control to recall the channel preset.

to select the channel preset you want.

/

to select the channel preset you want.

Using the SIRIUS Menu

The SIRIUS Menu provides additional SIRIUS Radio features.

Press TOP MENU.

Use

/

Choose between the following menu items:

• All CHANNEL SKIP CLEAR – Clear the channel skip

• Parental Lock – Use / and ENTER to select channels

• Password Set – Set the parental lock password.

reception display.

• You can reset the channel presets, parental lock and

to select a menu item then press ENTER.

function set by the SiriusConnect tuner. If the channel skip function is not cleared here, not all channels are displayed because this receiver stores the channels set for skipping in the SiriusConnect tuner.

you would like to place under parental lock. Channels put under parental lock are not displayed in the Channel Guide, but may be accessed by directly inputting their channel number and providing the parental lock password.

When you’re finished press TOP MENU to return to the

Password Set in Resetting the main unit on page 52.

Note

Tip

DVR/BDRCDCD-R

ADAPTER

iPod USB VIDEO 1

VIDEO

2SIRIUS

TUNER

VOL

ENTER

RETURN

AUDIO

PARAMETER

TUNER EDIT

TOOLS

MASTER VOLUME

iPod CTRL

CATEGORY

BAND

HOME MENU SETUP

TOP MENU

E S

BD DVD

INPUT SELECT

SOURCESLEEP

CONTROL

INPUT

DVR/BDRCDCD-R

ADAPTER

iPod USB VIDEO 1

VIDEO

SIRIUS

TUNER

RECEIVER

VOL

RECEIVER

ENTER

DISP

MEMORY

MUTE

RETURN

AUDIO

PARAMETER

TUNER EDIT

TOOLS

MASTER VOLUME

iPod CTRL

CATEGORY

BAND

HOME MENU SETUP

DTV/ TV

TRE

BASS

TOP MENU

E S

HDD DVD VCR

Basic playback

Listening to the radio

The following steps show you how to tune in to FM and AM radio broadcasts using the automatic (search) and manual (step) tuning functions. Once you are tuned to a station you can memorize the frequency for recall later—see Saving station presets below for more on how to do this.

Press TUNER to select the tuner.

Use BAND to change the band (FM or AM), if necessary.

Each press switches the band between FM (stereo or mono) and AM.

Tune to a station.

There are three ways to do this:

Automatic tuning

To search for stations in the currently selected band, press and hold TUNE / for about a second. The receiver will start searching for the next station, stopping when it has found one. Repeat to search for other stations.

Manual tuning

To change the frequency one step at a time, press

TUNE /.

High speed tuning

Press and hold TUNE / for high speed tuning. Release the button at the frequency you want.

Improving FM sound

If the TUNE or ST indicators don’t light when tuning to an FM station because the signal is weak, set the receiver to the mono reception mode.



Press BAND to select FM MONO.

This should improve the sound quality and allow you to enjoy the broadcast.

Saving station presets

If you often listen to a particular radio station, it’s convenient to have the receiver store the frequency for easy recall whenever you want to listen to that station. This saves the effort of manually tuning in each time. This unit can memorize up to 30 stations.

Tune to a station you want to memorize.

See Listening to the radio on page 32 for more on this.

Press TUNER EDIT.

The display shows PRESET, then a blinking MEM and station preset.

Press PRESET

want.

You can also use the number buttons.

Press ENTER.

The preset number stop blinking and the receiver stores the station.

• If the receiver is left disconnected from the AC power

outlet for over a month, the station memories will be lost and will have to be reprogrammed.

• Stations are stored in stereo. When the station is stored

in the FM MONO mode, it shows as ST when recalled.

/

to select the station preset you

Listening to station presets

You will need to have some presets stored to do this. See Saving station presets above if you haven’t done this already.



Press PRESET

want.

• You can also use the number buttons on the remote control to recall the station preset.

/

to select the station preset you

Naming preset stations

For easier identification, you can name all of your preset stations.

Choose the station preset you want to name.

See Listening to station presets above for how to do this.

Press TUNER EDIT twice.

The cursor at the first character position is blinking on the display.

Input the name you want.

Choose a name up to eight characters long.

•Use PRESET / to select character position.

•Use TUNE / to select characters.

• The name is stored when ENTER is pressed.

• To erase a station name, follow steps 1 and 2, and press ENTER while the display is blank. Press TUNER EDIT while the display is blank, to keep the previous name.

• Once you have named a station preset, Press DISP to show the name. When you want to return to the frequency display, press DISP several times to show the frequency.

Listening to your system

Important

Note

ADV SURR

AUTO/

DIRECT

AUDIO

PARAMETER

TUNER EDIT

TOOLS

MASTER VOLUME

BD MENU

ALC/

STANDARD

STEREO

ALC/

STANDARD

ALC/

STANDARD SURR

Chapter 5:

Listening to your system

Choosing the listening mode

This receiver offers a variety of listening modes to accommodate playback of various audio formats. Choose one according to your speaker environment or the source.



While listening to a source, press the listening mode

button repeatedly to select a listening mode you want.

ULTI-ZONE - ON/OFF

• The listening mode is shown on the display on the front panel.

• The listening modes and many features described in this section may not be available depending on the current source, settings and status of the receiver.

BAND TUNER EDIT TUNE

AUTO SURROUND

STREAM DIRECT

ALC/

STANDARD SURR

ADVANCED SURROUND

iPod iPhone iPad

DIRECT

CONTROLSTEREO

AUTO SURROUND

STREAM DIRECT

Auto playback

The simplest, most direct listening option is the AUTO SURROUND feature. With this, the receiver automatically

detects what kind of source you’re playing and selects multichannel or stereo playback as necessary.

•Press AUTO/DIRECT repeatedly until AUTO SURROUND

shows briefly in the display (it will then show the decoding or playback format). Check the digital format indicators in the display to see how the source is being processed.

• Stereo surround (matrix) formats are decoded

accordingly using NEO:6 CINEMA or DOLBY PLIIx MOVIE (see Listening in surround sound below for more on these decoding formats).

• When listening to the ADAPTER input, the S.R AIR

feature is selected automatically (see Using the Advanced surround on page 34 for more on this).

AUTO/

DIRECT

Listening in surround sound

Using this receiver, you can listen to any source in surround sound. However, the options available will depend on your speaker setup and the type of source you’re listening to.

• If the source is Dolby Digital, DTS, or Dolby Surround encoded, the proper decoding format will automatically be selected and shows in the display.

When you select STEREO ALC (Auto Level Control stereo mode), this unit equalizes playback sound levels if each sound level varies with the music source recorded in a portable audio player.

When you select STEREO, you will hear the source through just the front left and right speakers (and possibly your subwoofer depending on your speaker settings). Dolby Digital and DTS multichannel sources are downmixed to stereo. The following modes provide basic surround sound for stereo and multichannel sources.

Explanatory notes No: No connected / Yes: Connected / Two: Two speakers are

connected / –: Whether connected or no

Type of surround modes

Suitable sources

Surround back

speaker(s)

Two channel sources

STEREO ALC See above. – –

DOLBY PLIIx MOVIE Movie

Yes

DOLBY PLII MOVIE No –

DOLBY PLIIx MUSIC

DOLBY PLII MUSIC

Music

DOLBY PLIIx GAME Video games

Yes

No –

Yes

DOLBY PLII GAME No –

DOLBY PLIIz HEIGHT

NEO:6 CINEMA

NEO:6 MUSIC

Movie/Music No Yes

Movie – –

Music – –

DOLBY PRO LOGIC Old movies – –

Straight Decode

STEREO

No additional effects No –

See above. – –

Multichannel sources

STEREO ALC See above. – –

DOLBY PLIIx MOVIE Movie

Two

DOLBY PLII MOVIE No –

DOLBY PLIIx MUSIC

DOLBY PLII MUSIC

Music

Two

No –

DOLBY DIGITAL EX Movie/Music Yes No

DTS-ES Movie/Music Yes No

DTS NEO:6 Movie/Music Yes No

DOLBY PLIIz HEIGHT Movie/Music No Yes

Straight Decode

STEREO

No additional effects – –

See above. – –

Front height

speakers

Listening to your system

Note

Front left

speaker

Front right

speaker

AUTO/

DIRECT

AUTO SURROUND

STREAM DIRECT

INPUT SELECT

SOURCESLEEP

CONTROL

INPUT

RECEIVER

MIDNIGHT

S.RETRIEVER

SPEAKERS

LEV

SB CH

DISP

PHASE

CH SELECT

HDD DVD VCR

RECEIVER

INPUT SELECT

SOURCESLEEP

CONTROL

INPUT

RECEIVER

MIDNIGHT

S.RETRIEVER

SPEAKERS

LEV

SB CH

DISP

PHASE

CH SELECT

HDD DVD VCR

RECEIVER

a. If surround back channel processing (page 35) is switched off,

or the surround back speakers are set to NO, DOLBY PLIIx becomes DOLBY PLII (5.1 channel sound).

b. You can also adjust the C.WIDTH, DIMEN., and PNRM. effect

(see Setting the Audio options on page 36).

c. You can also adjust the H.GAIN effect (see Setting the Audio

options on page 36).

d. You can also adjust the C.IMG effect (see Setting the Audio

options on page 36).

e. Cannot be selected when the Speaker System is set to Surr.

Back (see The Speaker System setting on page 41).

f. • You can choose the STEREO mode by using STEREO button.

• The audio is heard with your surround settings and you can still use the Midnight, Loudness, Phase Control, Sound Retriever and Tone functions.

• In modes that give 6.1 channel sound, the same signal is heard from both surround back speakers.

ADVANCED

BD MENU

SURROUND

Using the Advanced surround

The Advanced surround feature creates a variety of surround effects. Try different modes with various soundtracks to see which you like.

ACTION Designed for action movies with dynamic

soundtracks.

ADV SURR

DRAMA Designed for movies with lots of dialog.

ENT.SHOW Suitable for musical sources.

ADVANCED GAME Suitable for video games.

SPORTS Suitable for sports programs.

CLASSICAL Gives a large concert hall-type sound

ROCK/POP Creates a live concert sound for rock and/

or pop music.

UNPLUGGED Suitable for acoustic music sources.

EXT.STEREO Gives multichannel sound to a stereo

source, using all of your speakers

F.S.S.ADVANCE (Front Stage Surround ADVANCE)

S.R AIR (Sound Retriever AIR)

PHONES SURR When listening through headphones, you

Allows you to create natural surround sound effects using just the front speakers and the subwoofer. Use to provide a rich surround sound effect directed to the center of where the front left and right speakers sound projection area converges.

Suitable for listening to the sound from a Bluetooth wireless technology device. The S.R AIR listening mode can only selected when the ADAPTER input.

can still get the effect of overall surround.

Using Stream Direct

Use the Stream Direct modes when you want to hear the truest possible reproduction of a source. All unnecessary signal processing is bypassed.

AUTO SURROUND

DIRECT Sources are heard according to the settings

PURE DIRECT Analog and PCM sources are heard without

See Auto playback on page 33.

made in the Manual SP Setup (speaker setting, channel level, speaker distance), as well as with dual mono settings. You will hear sources according to the number of channels in the signal. Phase Control, Acoustic Calibration EQ, Sound Delay, Auto Delay, LFE Attenuate and Center image functions are available.

any digital processing.

Using the Sound Retriever

When audio data is removed during the compression process, sound quality often suffers from an uneven sound image. The Sound Retriever feature employs new DSP technology that helps bring CD quality sound back to compressed 2-channel audio by restoring sound pressure and smoothing jagged artifacts left over after compression.



Press , then press S.RETRIEVER to switch the

S.RTV (Sound Retriever) ON or OFF.

• The Sound Retriever is only applicable to 2-channel sources.

Listening with Acoustic Calibration EQ

You can listen to sources using the Acoustic Calibration Equalization set in Automatically setting up for surround sound (MCACC) on page 24. Refer to these pages for more on Acoustic Calibration Equalization.



While listening to a source, press , then press

EQ to switch the EQ (Acoustic Calibration EQ) ON or OFF.

The MCACC indicator on the front panel lights when Acoustic Calibration EQ is active.

• You can’t use Acoustic Calibration EQ with Stream Direct mode and it has no effect with headphones.

Listening to your system

Note

RECEIVER

INPUT SELECT

SOURCESLEEP

CONTROL

INPUT

RECEIVER

MIDNIGHT

S.RETRIEVER

SPEAKERS

LEV

SB CH

DISP

PHASE

CH SELECT

HDD DVD VCR

RECEIVER

L R

SL SR

SBL SBR SBL SBR

L R

SL SR

UP MIX OFF UP MIX ON

Better sound using Phase Control

This receiver’s Phase Control feature uses phase correction measures to make sure your sound source arrives at the listening position in phase, preventing unwanted distortion and/or coloring of the sound.

Phase Control technology provides coherent sound reproduction through the use of phase matching for an optimal sound image at your listening position. The default setting is on and we recommend leaving Phase Control switched on for all sound sources.

HDD DVD VCR

S.RETRIEVER

MIDNIGHT

RECEIVER

SOURCESLEEP

RECEIVER

INPUT SELECT



Press , then press PHASE to switch the P.CTL

(Phase Control) ON or OFF.

• Phase matching is a very important factor in achieving proper sound reproduction. If two waveforms are ‘in phase’, they crest and trough together, resulting in increased amplitude, clarity and presence of the sound signal. If a crest of a wave meets a trough, then the sound will be ‘out of phase’ and an unreliable sound image will be produced.

• If your subwoofer has a phase control switch, set it to the plus (+) sign (or 0°). However, the effect you can actually feel when Phase Control is set to ON on this receiver depends on the type of your subwoofer. Set your subwoofer to maximize the effect. It is also recommended you try changing the orientation or the place of your subwoofer.

• Set the built-in lowpass filter switch of your subwoofer to OFF. If this cannot be done on your subwoofer, set the cutoff frequency to a higher value.

• If the speaker distance is not properly set, you may not have a maximized Phase Control effect.

• The Phase Control mode cannot be set to ON in the following cases:

When the PURE DIRECT mode is switched on.

When the headphones are connected.

CONTROL

INPUT

SB CH

SPEAKERS

CH SELECT

LEV

PHASE

Using surround back channel processing

You can have the receiver automatically use 6.1 or 7.1 decoding for 6.1 encoded sources (for example, Dolby Digital EX or DTS-ES), or you can choose to always use 6.1 or 7.1 decoding (for example, with 5.1 encoded material). With 5.1 encoded sources, a surround back channel will be generated, but the material may sound better in the 5.1 format for which it was originally encoded (in which case, you can simply switch surround back channel processing off).

• With a 7.1-channel surround system, audio signals that have undergone matrix decoding processing through

DISP

surround back channel processing to which the Up Mix function is added are output from the surround back speakers.



Press , then press SB CH repeatedly to cycle

the surround back channel options.

Each press cycles through the options as follows:

• SB ON – Matrix decoding processing for generating the surround back component from the surround component is turned on.

• SB AUTO – Matrix decoding processing for generating the surround back component from the surround component is switched automatically. Matrix decoding processing is only performed when surround back channel signals are detected in the input signals.

• SB OFF – Matrix decoding processing for generating the surround back component from the surround component is turned off.

Setting the Up Mix function

In a 7.1-channel surround system with surround speakers placed directly at the sides of the listening position, the surround sound of 5.1-channel sources is heard from the side. The Up Mix function mixes the sound of the surround speakers with the surround back speakers so that the surround sound is heard from diagonally to the rear as it should be.

• Using the Up Mix function is effective when the speakers in the 7.1-channel surround system are set up as recommended in the example on page 10.

• Depending on the positions of the speakers and the sound source, in some cases it may not be possible to achieve good results. In this case, set the setting to OFF.

Switch the receiver into standby.

While holding down PRESET on the front panel, and

hold the

 STANDBY/ON

UP MIX: OFF appears and the Up Mix function turns off. If

you want to turn this function on, perform steps 1 and 2 again.

• When set to ON, the (Up Mix) indicator on the front panel lights.

•Set to ON regardless of this setting when playing DTS-HD signals.

• May automatically be set to OFF even when set to ON, depending on the input signal and listening mode.

for about two seconds.

Listening to your system

Important

RECEIVER

Setting the Audio options

There are a number of additional sound settings you can make using the AUDIO PARAMETER menu. The defaults, if not stated, are listed in bold.

• Note that if a setting doesn’t appear in the AUDIO PARAMETER menu, it is unavailable due to the current source, settings and status of the receiver.

AUDIO

PARAMETER

RECEIVER

BD DVD

Press , then press AUDIO PARAMETER button.

Use

/

Depending on the current status/mode of the receiver, certain options may not be able to be selected. Check the table below for notes on this.

Use

/

See the table below for the options available for each setting.

Press RETURN to confirm and exit the menu.

CONTROL

SOURCESLEEP

INPUT SELECT

INPUT

to select the setting you want to adjust.

to set it as necessary.

TOP MENU

HOME MENU SETUP

iPod CTRL

S E

Setting/What it does Option(s)

EQ (Acoustic Calibration EQ)

Switches on/off the effect of Acoustic Calibration EQ.

S.DELAY (Sound Delay) Some monitors have a slight delay when showing video, so the soundtrack will be slightly out of sync with the picture. By adding a bit of delay, you can adjust the sound to match the presentation of the video.

TUNER EDIT

TOOLS

ENTER

RETURN

1 second = 30 frames (NTSC)

Default: 0.0

MASTER VOLUME

E S

BAND

OFF

0.0 to 9.0 (frames)

Setting/What it does Option(s)

MIDNIGHT/LOUDNESS

The MIDNIGHT allows you to hear effective surround sound of movies at low volumes. The LOUDNESS is used to get good bass and treble from music sources at low volumes.

S.RTV (Sound Retriever) When audio data is removed during the WMA/MP3c compression process, sound quality often suffers from an uneven sound image. The Sound Retriever feature employs new DSP technology that helps bring CD quality sound back to compressed 2-channel audio by restoring sound pressure and smoothing jagged artifacts left over after compression.

DUAL MONO

Specifies how dual mono encoded Dolby Digital soundtracks should be played.

F.PCM (Fixed PCM) This is useful if you find there is a slight delay before OFF recognizes the PCM signal on a CD, for instance. When ON is selected, noise may be output during playback of non-PCM sources. Please select another input signal if this is a problem.

DRC (Dynamic Range Control) Adjusts the level of dynamic range for movie soundtracks optimized for Dolby Digital, DTS, Dolby Digital Plus, Dolby TrueHD, DTS-HD and DTS-HD Master Audio (you may need to use this feature when listening to surround sound at low volumes).

M/L OFF

MIDNIGHT

LOUDNESS

OFF

CH1 – Channel 1

is heard only

CH2 – Channel 2

is heard only

CH1 CH2 – Both

channels heard

from front

speakers

OFF

AUTO

MAX

MID

OFF

Setting/What it does Option(s)

LFE ATT (LFE Attenuate)

Some Dolby Digital and DTS audio sources include ultra-low bass tones. Set the LFE attenuator as necessary to prevent the ultralow bass tones from distorting the sound from

the speakers. The LFE is not limited when set to 0 dB, which is the recommended value. When set to –15 dB, the LFE is limited by the respective degree. When OFF is selected, no sound is output from the LFE channel.

SACD G. (SACD Gain) Brings out detail in SACDs by maximizing the dynamic range (during digital processing).

HDMI (HDMI Audio) Specifies the routi ng of the HDMI audio signal out of this receiver (AMP) or through to a TV (THRU). When THRU is selected, no sound is output from this receiver.

A.DLY (Auto Delay) This feature automatically corrects the audioto-video delay between components connected with an HDMI cable. The audio delay time is set depending on the operational status of the display connected with an HDMI cable. The video delay time is automatically adjusted according to the audio delay time.

C.WIDTH (Center Width) (Applicable only when using a center speaker) Spreads the center channel between the front right and left speakers, making it sound wider

(higher settings) or narrower (lower settings).

DIMEN (Dimension) Adjusts the surround sound balance from front to back, making the sound more distant (minus settings), or more forward (positive settings).

0 (0 dB)

5 (–5 dB)

10 (–10 dB)

15 (–15 dB)

20 (–20 dB)

** (OFF)

0 (0 dB)

+6 (+6 dB)

AMP

THRU

OFF

0 to 7

Default: 3

–3 to +3

Default: 0

Listening to your system

Note

BD DVD

INPUT SELECT

SOURCESLEEP

CONTROL

INPUT

DVR/BDRCDCD-R

ADAPTER

iPod USB VIDEO 1

VIDEO

2SIRIUS

TUNER

RECEIVER

VOL

RECEIVER

DIMMER

SIGNAL SEL

D.ACCESS

MIDNIGHT

S.RETRIEVER

SPEAKERS

LEV

SB CH

DISP

CLR

PHASE

ENTER

CH SELECT

SHIFT

HDD DVD VCR

RECEIVER

Setting/What it does Option(s)

PNRM. (Panorama)

Extends the front stereo image to include surround speakers for a ‘wraparound’ effect.

C.IMG (Center Image) (Applicable only when using a center speaker) Adjust the center image to create a wider stereo effect with vocals. Adjust the effect from 0 (all center channel sent to front right and left speakers) to 10 (center channel sent to the center speaker only).

H.GAIN (Height Gain) Adjusts the output from the front height speaker when listening in DOLBY PLIIz HEIGHT mode. If set to H, the sound from the top will be more emphasized.

a. You can change the MIDNIGHT/LOUDNESS options at any

time by using MIDNIGHT button.

b. You can change the Sound Retriever feature at any time by

using S.RETRIEVER button.

c. WMA and MP3 playback available only via iPod USB input. d. The default setting when the iPod USB or ADAPTER input is

selected is ON.

e. This setting works only with dual mono encoded Dolby Digital

and DTS soundtracks.

f. The initial set AUTO is only available for Dolby TrueHD signals.

Select MAX or MID for signals other than Dolby TrueHD.

g. You shouldn’t have any problems using this with most SACD

discs, but if the sound distorts, it is best to switch the gain setting back to 0 dB.

h. This feature is only available when the connected display

supports the automatic audio/video synchronizing capability (‘lip-sync’) for HDMI. If you find the automatically set delay time unsuitable, set A.DLY to OFF and adjust the delay time manually. For more details about the lip-sync feature of your display, contact the manufacturer directly.

i. Only available with 2-channel sources in DOLBY PLII MUSIC

mode.

j. Only when listening to 2-channel sources in NEO:6 CINEMA

and NEO:6 MUSIC mode.

OFF

0 to 10

Default: 3

(NEO:6 MUSIC),

10 (NEO:6

CINEMA)

L (Low)

M (Mid)

H (High)

Making an audio or a video recording

You can make an audio or a video recording from the built-in tuner, or from an audio or video source connected to the receiver (such as a CD player or TV).

Only video signals that were input to this receiver through a composite video cable or analog audio inputs can be recorded. Signals that were input through an HDMI cable, component video cable or digital audio cable (see Connecting other audio components on page 19 for more on connections).

Press input function buttons to select the input function

you want to record.

The input of the receiver will switch over, and you will be able to operate other components using the remote control.

• The input source can also be selected by using INPUT SELECT buttons on the remote control, or by using the front panel INPUT SELECTOR dial.

Select the audio input signal (if necessary).

Press then press SIGNAL SEL and select the analog inputs (A) for the source component of which you want to record (see page 26 for more on this).

Prepare the source you want to record.

Tune to the radio station, load the CD, video, DVD etc.

Prepare the recorder.

Insert a blank tape, MD, video etc. into the recording device and set the recording levels.

Refer to the instructions that came with the recorder if you are unsure how to do this. Most video recorders set the audio recording level automatically—check the component’s instruction manual if you’re unsure.

Start recording, then start playback of the source

component.

• The receiver’s volume, balance, tone (bass, treble, loudness), and surround effects have no effect on the recorded signal.

• Some video sources are copy-protected. These cannot be recorded.

The System Setup menu

Important

CAUTION

Important

RECEIVER

System Setup

1.Auto MCACC

2.Manual SP Setup

3.Input Assign

4.Speaker System

5.Video Parameter

6.HDMI Setup

7.Auto Power Down

8.12V Trigger

Return

2.Manual SP Setup

Return

a.Speaker Setting

b.Crossover Network

c.Channel Level

d.Speaker Distance

2a.Speaker Setting

Front Front Height Center Surr Surr. Back Subwoofer:

Return

[ SMALL ] [ SMALL ] [ SMALL ] [ NO ] YES

SMALL

Chapter 6:

The System Setup menu

Using the System Setup menu

The following section shows you how to make detailed settings to specify how you’re using the receiver, and also explains how to fine-tune individual speaker system settings to your liking.

• If headphones are connected to the receiver, disconnect them.

• You can’t use the System Setup menu when the iPod USB input is selected.

PARAMETER

TOP

SOURCESLEEP

INPUT SELECT

CONTROL

INPUT

RECEIVER

BD DVD

Switch on the receiver and your TV.

Press  RECEIVER to switch on.

Switch the TV input so that it connects to the receiver.

Press , then press SETUP.

The System Setup menu appears on your TV. Use /// and ENTER on the remote control to navigate through the screens and select menu items. Press RETURN to confirm and exit the current menu.

HOME MENU

SETUP

iPod CTRL

CATEGORY

S E

• Press SETUP at any time to exit the System Setup menu.

Select the setting you want to adjust.

ENTER

VOLUME

TOOLS

E S

BAND

RETURN

MUTE

DTV/ TV

• Auto MCACC – This is a quick and effective automatic

surround setup (see Automatically setting up for surround sound (MCACC) on page 24).

• Manual SP Setup

Speaker Setting – Specify the size and number of speakers you’ve connected (see below).

Crossover Network – Specify which frequencies will be sent to the subwoofer (page 39).

Channel Level – Adjust the overall balance of your speaker system (page 39).

Speaker Distance – Specify the distance of your speakers from the listening position (page 40).

• Input Assign – Specify what you’ve connected to the

component video inputs (see The Input Assign menu on page 40).

• Speaker System – Specifies how you are using the

speaker terminals (see The Speaker System setting on page 41).

• Video Parameter

Video Converter – Converts video signals for output from the HDMI OUT terminal for all video types (page 41).

Resolution – Specifies the output resolution of the video signal (page 41).

Aspect – Specifies the aspect ratio (page 42).

• HDMI Setup – Sets synchronized operations when connected to a device/TV that supports the Control with HDMI function (see HDMI Setup on page 43).

• Auto Power Down – Sets to automatically turn off the power when the receiver has not operated for several hours (see The Auto Power Down menu on page 42).

• 12V Trigger – Sets the input function that enables the signal output from the 12 V trigger terminal (see The 12 V Trigger Setting on page 42).

Manual speaker setup

This receiver allows you to make detailed settings to optimize the surround sound performance. You only need to make these settings once (unless you change the placement of your current speaker system or add new speakers).

These settings are designed to fine-tune your system, but if you’re satisfied with the settings made in Automatically setting up for surround sound (MCACC) on page 24, it isn’t necessary to make all of these settings.

• The test tones used in the System Setup are output at high volume.

• Depending on the Speaker System setting, there will be differences in the speaker items that can be adjusted. The OSD display for these operating instructions is an example of when the Speaker System setting is set to Surr. Back.

Speaker Setting

Use this setting to specify your speaker configuration (size, number of speakers). It is a good idea to make sure that the settings made in Automatically setting up for surround sound (MCACC) on page 24 are correct.

Select ‘Manual SP Setup’ from the System Setup menu.

Select ‘Speaker Setting’ from the Manual SP Setup

menu.

Choose the set of speakers that you want to set then

select a speaker size.

Use / to select the size (and number) of each of the following speakers:

The System Setup menu

Note

2.Manual SP Setup

Return

a.Speaker Setting

b.Crossover Network

c.Channel Level

d.Speaker Distance

2b.Crossover Network

Return

Frequency 100Hz

2.Manual SP Setup

Return

a.Speaker Setting

b.Crossover Network

c.Channel Level

d.Speaker Distance

2c.Channel Level

Test Tone Manual

ENTER:NextReturn

2c.Channel Level

Test Tone [ Manual ]

Please Wait . . .20

Caution Loud test tones will be output.

 Return

• Front – Select LARGE if your front speakers reproduce

bass frequencies effectively, or if you didn’t connect a subwoofer. Select SMALL to send the bass frequencies to the subwoofer.

• Center – Select LARGE if your center speaker reproduces bass frequencies effectively, or select SMALL to send bass frequencies to the other speakers or subwoofer. If you didn’t connect a center speaker, choose NO (the center channel is sent to the other speakers).

• Front Height – Select LARGE if your front height speakers reproduce bass frequencies effectively. Select SMALL to send bass frequencies to the other speakers or subwoofer. If you didn’t connect front height speakers choose NO.

• Surr – Select LARGE if your surround speakers reproduce bass frequencies effectively. Select SMALL to send bass frequencies to the other speakers or subwoofer. If you didn’t connect surround speakers choose NO (the sound of the surround channels is sent to the other speakers).

• Surr. Back – Select the number of surround back speakers you have (one, two or none). Select LARGE if your surround back speakers reproduce bass frequencies effectively. Select SMALL to send bass frequencies to the other speakers or subwoofer. If you didn’t connect surround back speakers choose NO.

When using only one surround back speaker, connect it to the SURROUND BACK L (Single) terminals.

• Subwoofer – LFE signals and bass frequencies of channels set to SMALL are output from the subwoofer when YES is selected (see notes below). Choose the PLUS setting if you want the subwoofer to output bass sound continuously or you want deeper bass (the bass frequencies that would normally come out the front and center speakers are also routed to the subwoofer). If you did not connect a subwoofer choose NO (the bass frequencies are output from other speakers).

When you’re finished, press RETURN.

You return to the Manual SP Setup menu.

• If you select SMALL for the front speakers, the subwoofer will automatically be fixed to YES. Also, the center, surround, surround back and front height speakers can’t be set to LARGE if the front speakers are set to SMALL. In this case, all bass frequencies are sent to the subwoofer.

• If the surround speakers are set to NO, the surround back speakers will automatically be set to NO.

• If you have a subwoofer and like lots of bass, it may seem logical to select LARGE for your front speakers and PLUS for the subwoofer. This may not, however, yield the best bass results. Depending on the speaker placement of your room you may actually experience a decrease in the amount of bass due to low frequency cancellations. In this case, try changing the position or direction of speakers. If you can’t get good results, listen to the bass response with it set to PLUS and YES or the front speakers set to LARGE and SMALL alternatively and let your ears judge which sounds best. If you’re having problems, the easiest option is to route all the bass sounds to the subwoofer by selecting SMALL for the front speakers.

Crossover Network

• Default setting: 100Hz

This setting decides the cutoff between bass sounds playing back from the speakers selected as LARGE, or the subwoofer, and bass sounds playing back from those selected as SMALL. It also decides where the cutoff will be for bass sounds in the LFE channel.

• For more on selecting the speaker sizes, see Speaker Setting on page 38.

Select ‘Manual SP Setup’ from the System Setup menu.

Select ‘Crossover Network’ from the Manual SP Setup

menu.

Choose the frequency cutoff point.

Frequencies below the cutoff point will be sent to the subwoofer (or LARGE speakers).

When you’re finished, press RETURN.

You return to the Manual SP Setup menu.

Channel Level

Using the channel level settings, you can adjust the overall balance of your speaker system, an important factor when setting up a home theater system.

Select ‘Manual SP Setup’ from the System Setup menu.

Select ‘Channel Level’ from the Manual SP Setup menu.

Select a setup option.

• Manual – Move the test tone manually from speaker to

speaker and adjust individual channel levels.

• Auto – Adjust channel levels as the test tone moves from

speaker to speaker automatically.

Confirm your selected setup option.

The test tones will start after you press ENTER. After the volume increases to the reference level, test tones will be output.

The System Setup menu

Note

Tip

Important

2c.Channel Level

Front L Center Front R Surround R Surr. Back R Surr. Back L Surround L Subwoofer

Return

[ 0dB] [ 0dB] [ 0dB] [ ––– ] [ ––– ] [ 0dB] [ 0dB]

0dB

RECEIVER

2.Manual SP Setup

Return

a.Speaker Setting

b.Crossover Network

c.Channel Level

d.Speaker Distance

System Setup

1.Auto MCACC

2.Manual SP Setup

3.Input Assign

4.Speaker System

5.Video Parameter

6.HDMI Setup

7.Auto Power Down

8.12V Trigger

Return

3.Input Assign

Return

a.Component Input

3a.Component Input

Return

Component–1

DVD

Component–2 [ DVR ]

Adjust the level of each channel using

If you selected Manual, use / to switch speakers. The Auto setup will output test tones in the order shown on-

screen:

Adjust the level of each speaker as the test tone is emitted.

• If you are using a Sound Pressure Level (SPL) meter, take the readings from your main listening position and adjust the level of each speaker to 75 dB SPL (C-weighting/slow reading).

• The subwoofer test tone is output at low volumes. You may need to adjust the level after testing with an actual soundtrack.

When you’re finished, press RETURN.

You return to the Manual SP Setup menu.

• You can change the channel levels at any time by press

remote control. You can also press CH SELECT and use / to select the channel, and then use / to adjust the channel levels.

, then press CH SELECT and LEV +/– on the

/

Speaker Distance

For good sound depth and separation from your system, you need to specify the distance of your speakers from the listening position. The receiver can then add the proper delay needed for effective surround sound.

Select ‘Manual SP Setup’ from the System Setup menu.

Select ‘Speaker Distance’ from the Manual SP Setup

menu.

2d.Speaker Distance

Front L Center Front R Surround R Surr. Back R Surr. Back L Surround L Subwoofer

Adjust the distance of each speaker using

You can adjust the distance of each speaker in 0.1 feet increments.

When you’re finished, press RETURN.

You return to the Manual SP Setup menu.

10.0 ft

[ 10.0 ft ] [ 10.0 tt ] [ 10.0 ft ] [ –––– ] [ –––– ] [ 10.0 ft ] [ 10.0 ft ]

Return

/

The Input Assign menu

You only need to make settings in the Input Assign menu if you didn’t hook up your equipment according to the default settings for the component video inputs.

• Default settings:

Component-1: DVD

Component-2: DVR (DVR/BDR)

If you didn’t make component video connections according to the defaults above, you must assign the numbered input to the component you’ve connected (or else you may see the video signal of a different component). For more on this, see Using the component video jacks on page 19.

Select ‘Input Assign’ from the System Setup menu.

Select ‘Component Input’ from the Input Assign menu.

Select the number of the component video input to

which you’ve connected your video component.

The numbers correspond with the numbers beside the inputs on the rear of the receiver.

Select the component that corresponds with the one you connected to that input. Select between BD, DVD, TV (TV/SAT), DVR (DVR/BDR) or OFF.

•Use / and ENTER to do this.

• If you connect any source component to the receiver using a component video input, you should have your TV connected to this receiver’s COMPONENT VIDEO MONITOR OUT or HDMI OUT output (down converting component video is not possible after assigning an input).

• If you a ssign a component input to a certain function, any component inputs previously assigned to that function will automatically be switched off.

• Make sure you have connected the audio from the component to the corresponding inputs on the rear of the receiver.

When you’re finished, press RETURN.

You return to the Input Assign menu.

• For the assignment of the digital signal inputs, see Selecting the audio input signal on page 26.

The System Setup menu

Note

System Setup

1.Auto MCACC

2.Manual SP Setup

3.Input Assign

4.Speaker System

5.Video Parameter

6.HDMI Setup

7.Auto Power Down

8.12V Trigger

Return

4.Speaker System

Return

SP System Surr. Back

5a.Video Converter

BD DVD DVR/BDR VIDEO1

Return

[ OFF ] [ OFF ] [ OFF ]

The Speaker System setting

Specify either using the surround back speaker (or the speaker B), or the front height speaker connection with the Bspeaker terminals.

• Default setting: Surr. Back

Select ‘Speaker System’ from the System Setup menu.

Select the speaker system setting using

• Surr. Back – Sound is output from the surround back

speaker or the speaker B.

• Height – Sound is output from front height speaker.

When you’re finished, press RETURN.

You return to the System Setup menu.

/

The Video Parameter setting

This receiver can up-convert the video signal input from the composite/component video terminals; the output is from the HDMI OUT terminal. The following shows the various settings for this function.

Video Converter

This setting specifies valid/invalid for the function that converts the input video signal from each composite/ component video terminal. When OFF is selected, Resolution and Aspect can not be set.

Select ‘Video Parameter’ from the System Setup menu.

Select ‘Video Converter’ from the Video Parameter

menu.

5.Video Parameter

a.Video Converter

b.Resolution

c.Aspect

Return

Select the setting for converting each type of video

input.

• ON – The signal is output also to the HDMI OUT terminal.

• OFF – The signal input from the HDMI terminal of the

selected input function will be output from the HDMI OUT terminal. The signal input from the analog composite video and the component video will not be output from the HDMI OUT terminal.

When you’re finished, press RETURN.

You return to the Video Parameter menu.

Resolution

Specifies the output resolution of the video signal (when video input signals are output at the HDMI OUT terminal, select this according to the resolution of your monitor and the images you wish to watch).

Select ‘Video Parameter’ from the System Setup menu.

Select ‘Resolution’ from the Video Parameter menu.

Return

5b.Resolution

Resolution

AUTO

Return

5.Video Parameter

a.Video Converter

b.Resolution

c.Aspect

Select output resolution.

• AUTO – The resolution is selected automatically

according to the capacity of the TV (monitor) connected by HDMI.

• PURE – The signals are output with the same resolution

as when input.

• 480p/720p/1080i/1080p – The signal is output with the resolution specified here (480p means the resolution of 480p/576p).

When you’re finished, press RETURN.

You return to the Video Parameter menu.

• When set to a resolution with which the TV (monitor) is not compatible, no picture is output. Also, in some cases no picture will be output due to copyright protection signals. In this case, change the setting.

• When a display is connected by HDMI, if this is set to something other than PURE and 480i/576i analog signals are input, 480p/576p signals are output from the component output terminals.

The System Setup menu

Note

System Setup

1.Auto MCACC

2.Manual SP Setup

3.Input Assign

4.Speaker System

5.Video Parameter

6.HDMI Setup

7.Auto Power Down

8.12V Trigger

Return

7.Auto Power Down

Return

OFF

Aspect

Specifies the aspect ratio when analog video input signals are output at the HDMI OUT terminal. Make your desired settings while checking each setting on your display (if the image doesn’t match your monitor type, cropping or black bands appear).

Select ‘Video Parameter’ from the System Setup menu.

Select ‘Aspect’ from the Video Parameter menu.

Return

5c.Aspect

BD DVD DVR/BDR VIDEO1 VIDEO2 TV/SAT

NORMAL

[THROUGH] [THROUGH] [ NORMAL ] [ NORMAL ] [ NORMAL ]

Return

5.Video Parameter

a.Video Converter

b.Resolution

c.Aspect

Select desired output aspect ratio.

• THROUGH – The input video signal is output unchanged.

• NORMAL – Black bands will appear either at top and

bottom or on both sides.

When you’re finished, press RETURN.

You return to the Video Parameter menu.

• If the image doesn’t match your monitor type, adjust the aspect ratio on the source component or on the monitor.

The Auto Power Down menu

Set to automatically turn off the receiver after a specified time has passed (when the power has been on with no operation for several hours.

• Default setting: OFF

Select ‘Auto Power Down’ from the System Setup

menu.

Specify the amount of time to allow before the power

is turned off (when there has been no operation).

• You can select 2, 4 or 6 hours, or OFF (if no automatic

shutoff is desired).

When you’re finished, press RETURN.

You return to the System Setup menu.

• Turning the power off using the Auto Power Down will apply to both the main zone and the sub zone. However, if the Control at HDMI Setup is set to ON, the Auto Power Down may not work in the sub zone.

The 12 V Trigger Setting

If the input switches over to the input function set here, a control signal is output from the receiver’s 12 V trigger terminal, and operations such as power coupling with other devices and equipment can be achieved.

Select ‘12V Trigger’ from the System Setup menu.

Return

8.12V Trigger

BD DVD DVR VIDEO1 VIDEO2 TV/SAT

[OFF] [OFF] [OFF] [OFF] [OFF]

iPod CD CDR TUNER ADAPT SIRIUS

[OFF] [OFF] [OFF] [OFF] [OFF] [OFF]

Return

System Setup

1.Auto MCACC

2.Manual SP Setup

3.Input Assign

4.Speaker System

5.Video Parameter

6.HDMI Setup

7.Auto Power Down

8.12V Trigger

Choose the setting of the 12 V trigger output coupling

for each input function.

When you’re finished, press RETURN.

You return to the System Setup menu.

Control with HDMI function

Important

RECEIVER

System Setup

1.Auto MCACC

2.Manual SP Setup

3.Input Assign

4.Speaker System

5.Video Parameter

6.HDMI Setup

7.Auto Power Down

8.12V Trigger

Return

6.HDMI Setup

Return

Control ON ARC [ OFF ]

Chapter 7:

Control with HDMI function

Synchronized operations below with a Control with HDMIcompatible Pioneer TV or Blu-ray Disc player or with a component of another make that supports the Control with HDMI functions are possible when the component is connected to the receiver using an HDMI cable.

• Synchronized amp mode

The receiver’s volume can be set and the sound can be muted using the TV’s remote control.

• Power synchronization with TV

• Automatic switching of inputs

The receiver’s input switches over automatically when the TV’s input is changed or a Control with HDMI-compatible component is played.

• With Pioneer devices, the Control with HDMI functions

are referred to as “KURO LINK”.

• You cannot use this function with components that do not

support Control with HDMI.

• We only guarantee this receiver will work with Pioneer

made Control with HDMI-compatible components and components of other makes that support the Control with HDMI function. However, we do not guarantee that all synchronized operations will work with components of other makes that support the Control with HDMI function.

• Use a High Speed HD MI

Control with HDMI function. The Control with HDMI function may not work properly if a different type of HDMI cable is used.

• For details about concrete operations, settings, etc., refer to also the operating instructions for each component.

cable when you want to use the

Making Control with HDMI connections

You can use synchronized operation for a connected TV and up to four other components.

• Be sure to connect the TV’s audio cable to the audio in put of this unit. When the TV and receiver are connected by HDMI connections, if the TV supports the HDMI Audio Return Channel function, the sound of the TV is input to the receiver via the HDMI terminal, so there is no need to connect an audio cable. In this case, set ARC at HDMI Setup to ON (see HDMI Setup below).

For details, see Connecting using HDMI on page 15.

• When connecting this system or changing connections, be sure to switch the power off and disconnect the power cord from the wall socket. After completing all connections, connect the power cords to the wall socket.

• After this receiver is connected to an AC outlet, a 2 second to 10 second HDMI initialization process begins. You cannot carry out any operations during initialization. The HDMI indicator on the display unit blinks during initialization, and you can turn this receiver on once it has stopped blinking.

• To get the most out of this function, we recommend that you connect your HDMI component not to a TV but rather directly to the HDMI terminal on this receiver.

• While the r eceiver is equipped with four HDMI inputs, the Control with HDMI function can only be used with up to three DVD or Blu-ray Disc players or up to three DVD or Blu-ray Disc recorders.

HDMI Setup

You must adjust the settings of this receiver as well as the connected Control with HDMI-compatible components in order to make use of the Control with HDMI function. For more information see the operating instructions for each component.

Switch on the receiver and your TV.

Press  RECEIVER to switch on.

Switch the TV input so that it connects to the receiver.

Press , then press SETUP.

The System Setup menu appears on your TV. Use /// and ENTER on the remote control to navigate through the screens and select menu items. Press RETURN to confirm and exit the current menu.

• Press SETUP at any time to exit the System Setup menu.

Select ‘HDMI Setup’ from the System Setup menu.

Select the ‘Control’ setting you want.

Choose whether to set this unit’s Control with HDMI function ON or OFF. You will need to set it to ON to use the Control with HDMI function.

When using a component that does not support the Control with HDMI function, set this to OFF.

• ON – Enables the Control with HDMI function. When this

unit’s power is turned off and you have a supported source begin playback while using the Control with HDMI function, the audio and video outputs from the HDMI connection are output from the TV.

• OFF – The Control with HDMI is disabled. Synchronized

operations cannot be used. When this unit’s power is turned off, audio and video of sources connected via HDMI are not output.

Control with HDMI function

Select the ‘ARC’ setting you want.

When a TV supporting the HDMI Audio Return Channel function is connected to the receiver, the sound of the TV can be input via the HDMI terminal.

• ON – The TV’s sound is input via the HDMI terminal. This can only be selected when Control is set to ON.

• OFF – The TV’s sound is input from the audio input terminals other than HDMI inputs.

When you’re finished, press RETURN.

You return to the System Setup menu.

Before using synchronization

Once you have finished all connections and settings, you must:

Put all components into standby mode.

Turn the power on for all components, with the power

for the TV being turned on last.

Choose the HDMI input to which the TV is connected to

this receiver, and see if video output from connected components displays properly on the screen or not.

Check whether the components connected to all HDMI

inputs are properly displayed.

About synchronized operations

The Control with HDMI-compatible component connected to the receiver operates in sync as described below.

• Synchronized amp mode

From the menu screen of the Control with HDMIcompatible TV, set audio to be played through this receiver, and the receiver will switch to the synchronized amp mode.

When in the synchronized amp mode, the synchronized amp mode is canceled when the receiver’s power is tu rne d off . To tur n th e sy nch roni zed amp mod e ba ck o n, set audio to be played through the receiver from the TV’s menu screen, etc. This receiver will power up and switch to the synchronized amp mode.

When in the synchronized amp mode, the synchronized amp mode is canceled if an operation that produces sound from the TV is performed from the TV’s menu screen, etc.

When the synchronized amp mode is canceled, the receiver’s power turns off if you were viewing an HDMI input or a TV program on the TV.

• Power synchronization with TV

When the TV’s power is set to standby, the receiver’s power is also set to standby. (Only when the input for a component connected to the receiver by HDMI connection is selected or when watching the TV.)

• Automatic switching of inputs

The receiver’s input switches automatically when the Control with HDMI-compatible component is played.

The receiver’s input switches automatically when the TV’s input is switched.

The synchronized amp mode remains in effect even if the receiver’s input is switched to a component other than one connected by HDMI.

About connections with a product of a different brand that supports the Control with HDMI function

The synchronized operations below can be used when the receiver’s Control with HDMI function is connected to a TV of a brand other than Pioneer that supports the Control with HDMI function. (Depending on the TV, however, some of the Control with HDMI functions may not work.)

• When the TV’s power is set to standby, the receiver’s power is also set to standby. (Only when the input for a component connected to the receiver by HDMI connection is selected or when watching the TV)

• The sound of TV programs or an external input connected to the TV can also be output from the speakers connected to the receiver. (If the TV does not support the HDMI Audio Return Channel function, this requires connection of an optical digital cable, etc., in addition to the HDMI cable.)

The synchronized operations below can be used when the receiver’s Control with HDMI function is connected to a player or recorder of a brand other than Pioneer tha t supports the Control with HDMI function.

• When playback starts on the player or recorder, the receiver’s input switches to the HDMI input to which that component is connected.

See the Pioneer website for the latest information on the models of non-Pioneer brands and products that support the Control with HDMI function.

Cautions on the Control with HDMI function

• Connect the TV and components (Blu-ray Disc player, etc.) directly to this receiver. Interrupting a direct connection with other amps or an AV converter (such as an HDMI switch) can cause operational errors.

• When the receiver’s Control is turned ON, even if the receiver’s power is in the standby mode, it is possible to output the audio and video signals from a player via HDMI to the TV without producing sound from the receiver, but only when a Control with HDMI-compatible component (Blu-ray Disc player, etc.) and compatible TV are connected. In this case, the receiver’s power turns on and the power and HDMI indicators light.

Using the MULTI-ZONE feature

Note

Separate amplifier

Sub zone

Chapter 8:

Using the MULTI-ZONE feature

MULTI-ZONE listening

This receiver can power up to two independent systems in separate rooms after you have made the proper MULTI-ZONE connections.

Different sources can be playing in two zones at the same time or, depending on your needs, the same source can also be used. The main and sub zones have independent power (the main zone power can be off while the sub zone is on) and the sub zone can be controlled by the remote or front panel controls.

Making MULTI-ZONE connections

It is possible to make these connections if you have a separate speakers for your sub zone (ZONE 2). You will also need a separate amplifier for your sub zone.

• You can’t use sound controls (such as the bass/treble controls or Midnight listening) or any surround modes with a separate amplifier in the sub zone. You can, however, use the features available with your sub zone amplifier

MULTI-ZONE listening options

The following table shows what you can listen to in the sub zone:

Sub Zone Input sources available

ZONE 2 The built-in tuner and other analog audio

Basic MULTI-ZONE setup



Connect a separate amplifier to the ZONE 2 AUDIO OUT

jacks on the rear of this receiver.

You should have a pair of speakers attached to the sub zone amplifier as shown in the following illustration.

sources.

AUDIO IN

ANALOG

DVR/BDR IN DVD IN BD IN VIDEO 1 IN

HDMI

VIDEO

MONITOR

TV/SATINBD

OUT

DVR/

OUT

BDR

SPEAKER RSPEAKER

COAXIAL

OUT

ZONE2

OUT

(CD)

(

OUTPUT 5 V

0.1 A MAX

ANTENNA

FM UNBAL 75

AUDIO

DVR/BDR

CD-R/TAPE

OUT

ASSIGNABLE

(

TV/SAT

ADAPTER PORT

)

(

CD-R/TAPE

OPTICAL

ASSIGNABLE

)

Using the MULTI-ZONE controls

The following steps use the front panel controls to select sources. See MULTI-ZONE remote controls below.

CONTROL - MULTI-ZONE - ON/OFF

SPEAKERS BAND

Press the MULTI-ZONE ON/OFF button on the front

panel.

Each press selects a MULTI-ZONE option:

• ZONE 2 ON – Switches the MULTI-ZONE feature on

• ZONE 2 OFF – Switches the MULTI-ZONE feature off

The ZONE indicator lights when the MULTI-ZONE control has been switched ON.

Press CONTROL.

• When the receiver is on, make sure that any operations for the sub zone are done while If this is not showing, the front panel controls affect the main zone only. If the receiver is in standby, the display is dimmed, and

ZONE2 ON

ZONE 2

shows in the display.

continues to show in the display.

Use the INPUT SELECTOR dial to select the source for the zone you have selected. For example, Z2: CDR sends the source connected to the CDR inputs to the sub room (ZONE 2).

• If you select TUNER, you can use the tuner controls to

select a preset station (see Saving station presets on

page 32 if you’re unsure how to do this). The tuner cannot

be tuned to more than one station at a time. Therefore,

changing the station in one zone also changes the station

in the other zone. Please be careful not to change stations

when recording a radio broadcast.

When you’re finished, press CONTROL again to return to the main zone controls.

You can also press the front panel to switch off all output to the sub zone.

• You won’t be able to switch the main zone off completely unless you’ve switched off the MULTI-ZONE control first.

• If you don’t plan to use the MULTI-ZONE feature for a while, turn off the power in both the sub and main rooms so that this receiver is in standby.

• Volume level cannot be adjusted with this receiver. Use the separate amplifier connected to the ZONE2 OUT to adjust the volume.

MULTI-ZONE ON/OFF

button on the

MULTI-ZONE remote controls

Press the button on the remote control, then with the SHIFT button pressed, press the buttons below to operate the corresponding zone.

The following table shows the possible MULTI-ZONE remote controls:

RECEIVER

Button What it does

 RECEIVER Switches on/off power in the sub zone.

INPUT SELECT

Input function buttons

Use to select the input source in the sub zone.

Use to select the input source directly in the sub zone.

Controlling the rest of your system

Note

RECEIVER

BD DVD

INPUT SELECT

SOURCESLEEP

CONTROL

INPUT

DVR/BDRCDCD-R

ADAPTER

iPod USB VIDEO 1

VIDEO

2SIRIUS

TUNER

RECEIVER

VOL

RECEIVER

DIMMER

SIGNAL SEL

D.ACCESS

MIDNIGHT

S.RETRIEVER

SPEAKERS

LEV

SB CH

DISP

CLR

PHASE

ENTER

CH SELECT

SHIFT

HDD DVD VCR

RECEIVER

Chapter 9:

Controlling the rest of your system

Setting the remote to control other components

Most components can be assigned to one of the input function buttons using the component’s manufacturer preset code stored in the remote. However, please note that there are cases where only certain functions may be controllable after assigning the proper preset code, or the codes for the manufacturer in the remote control will not work for the model that you are using.

• TV CONTROL buttons are only dedicated to control the TV

(for example, codes for TV, CATV, Satellite TV or DTV).

• You can cancel or exit any of the steps by pressing

• After one minute of inactivity, the remote automatically

exits the operation.

Selecting preset codes directly

While pressing , press and hold the ‘1’ button

for three seconds.

Press the input function button for the component you want to control. The component can be assigned to the BD, DVD, TV, DVR/ BDR, CD, CD-R, VIDEO1 or VIDEO2 button.

• When assigning preset codes to TV CONTROL, press INPUT here.

Use the number buttons to enter the preset code.

You can find the preset codes on page 47. If the correct code has been input the power of the component being input will turn on or off. The power of the component being input will only turn on or off if that component is able to be turned on directly by remote control.

Repeat steps 2 through 3 to try a different code, or to

enter a code for another component you want to control.

When you’re done, press .

Clearing all the remote control settings

You can clear all presets and restore the factory default settings.



While pressing , press and hold the ‘0’ button

for three seconds.

Default preset codes

Input function button

BD 2255

DVD 2256

TV 0291

DVR/BDR 2257

CD 5000

CD-R 5001

VIDEO1 6099

VIDEO2 1053

TV CONTROL 0291

RECEIVER

Preset code

Controlling the rest of your system

Important

Pioneer

0291

example:

Category Preset code

Manufacturer

Controls for TVs

This remote control can control components after entering the proper codes or teaching the receiver the commands (see Controlling the rest of your system on page 46 for more on this). Use the input function buttons to select the component.

•The TV CONTROL buttons on the remote control are dedicated to control the TV assigned to the TV CONTROL

INPUT button.

Button(s) Function

TV CONTROL Switches the DTV on or off. –  –

Switches the TV or CATV between

TV CONTROL INPUT

TV CONTROL CH +/–

TV CONTROL VOL +/–

 SOURCE Press to switch the component

DTV/TV Switches between the DTV and

HOME MENU

RETURN Use to select closed captioning

Number buttons

ENTER Use to enter a channel.  

MENU Press to display the DTV menu. –  –

////

ENTER

CH +/– Selects channels.  

standby and on.

Switches the TV input. (Not possible with all models.)

Selects channels.  

Adjust the TV volume.  

assigned to the TV button on or off.

analog TV input modes for Pioneer TVs.

Use as the GUIDE button for navigating.

with DTV.

Use to select a specific TV channel.  

Select the menu screen.  – 

Press to select or adjust and navigate items on the menu screen.

DTV

Satellite/

 – 

 ––

 

 –

 

–  –

 

Controls for other components

This remote control can control these components (BD, DVD, CD, DVR (BDR), VCR, CD-R) after entering the proper codes or teaching the receiver the commands (see Controlling the rest of your system on page 46 for more on this). Use the input function buttons to select the component.

Button(s) Function

For Blu-ray Disc player, DVD player, CD player, DVR (BDR), VCR, CD-R

 SOURCE Press to switch the component between

Cable TV

 Press to return to the start of the current

 Press to advance to the start of the next track.

 Pause playback or recording.

 Start playback.

 Hold down for fast forward playback.

 Hold down for fast reverse playback.

 Stops playback (on some models, pressing

Number buttons Use to enter a title/chapter/track number.

DISP Press to display information.

TOP MENU Displays the disc ‘top’ menu of a BD/DVD

MENU Displays menus for the current BD/DVD or

////

ENTER/RETURN

HOME MENU Displays the HOME MENU.

CH +/– Selects channels. (DVR/VCR only)

standby and on.

track. Repeated presses skips to the start of previous tracks.

Repeated presses skips to the start of following tracks.

this when the disc is already stopped will cause the disc tray to open).

player.

DVR you are using.

Navigates BD/DVD menu/options.

Button(s) Function

For HDD/DVD/VCR recorder

HDD (SHIFT + 1) Switches to the hard disk controls.

DVD (SHIFT + 2) Switches to the DVD controls.

VCR (SHIFT + 3) Switches to the VCR controls.

Preset Code List

You should have no problem controlling a component if you find the manufacturer in this list, but please note that there are cases where codes for the manufacturer in the list will not work for the model that you are using. There are also cases where only certain functions may be controllable after assigning the proper preset code.

• We do not guarantee the operations of all the manufacturers and devices listed. Operation may not be possible even if a preset code is entered.

Controlling the rest of your system

Pioneer Admiral Adventura Aiwa Akai Albatron Alleron America Action Amtron Anam Anam National AOC Apex Audiovox Aventura Axion Bang & Olufsen Belcor Bell & Howell Benq Bradford Brillian Brockwood Broksonic Candle Carnivale Carver CCE Celebrity Celera Changhong Citizen Clarion Coby Colortyme Concerto Contec Contec/Cony Craig Crosley Crown CTX Curtis Mathes

CXC Cytron Daewoo

Daytron Dell DiamondVision Dimensia Disney Dumont Durabrand Dwin Electroband Electrograph

0291, 0113, 0294, 0296

0001, 0014

0012

0002

0002, 0100

0097

0009

0104

0008

0104

0003, 0008

0004, 0005, 0006, 0100

0021, 0102, 0106

0008, 0104

0103

0094

0111

0004

0001

0064

0008, 0104

0109

0004

0104

0004, 0006, 0012, 0100

0100

0101

0110

0002

0106

0106 0004, 0006, 0008, 0100 0104

0056

0004, 0006

0104

0007, 0008

0008, 0104

0081, 0101

0008, 0104

0063

0008, 0104

0093

0004, 0005, 0006,

0004 0006

0073

0000

0046

0004, 0011, 0099

0041, 0103, 0104

0014

0000, 0004,

0096

0002

0107

0006, 0014, 0100, 0101

0023

Electrohome

Element Emerson

Emprex Envision Epson ESA Fujitsu Funai Futuretech Gateway GE

GFM Gibralter

Goldstar

Gradiente Grunpy Haier Hallmark Harman/Kardon Harvard Havermy Hewlett Packard Hisense Hitachi Hyundai Ilo IMA Infinity InFocus Initial Insignia Inteq Janeil JBL JC Penney

JCB Jensen JVC Kawasho KEC Kenwood KLH Kloss Novabeam KTV LG Logik Luxman LXI Magnavox

Majestic Marantz

Maxent

0002, 0003, 0004,

0006

0082

0004, 0006, 0007,

0008, 0009, 0023, 0103, 0104

0092

0004, 0006, 0100

0061

0103

0009

0008, 0009, 0103, 0104

0008, 0104

0067, 0107, 0108

0000, 0003, 0004, 0006, 0010,

0016, 0039

0080, 0084

0004, 0011, 0099,

0100

0004, 0005, 0006,

0007, 0100

0066

0008, 0009, 0104

0112

0004, 0006

0101

0008, 0104

0014

0053

0069

0004, 0006, 0007

0098

0089, 0091

0008

0101

0074

0091

0085, 0086

0099

0012

0101

0000, 0004, 0005,

0006, 0010

0002

0004, 0006

0007, 0010, 0044

0002, 0004, 0006

0104

0004, 0006, 0100

0106

0008, 0100, 0104, 0110

0005, 0052, 0078, 0097

0000, 0006, 0101, 0102

0020, 0037, 0042, 0100, 0101

0100, 0101

0001

0004, 0006

0004, 0006, 0019,

0001 0004, 0006, 0062,

0087, 0107

0008, 0012

Megapower Megatron Memorex

MGA Midland Mintek Mitsubishi

Monivision Montgomery Ward Motorola MTC Multitech NAD NEC

Net-TV Nikko Norcent Olevia Onwa Oppo Optimus Optoma Optonica Orion Panasonic

Penney Philco

Philips

Philips Magnavox Pilot Polaroid Portland Prima Princeton Prism Proscan Proton Protron Proview Pulsar Quasar Radio Shack Radio Shack/Realistic

RCA

Realistic Runco Sampo Samsung

Sansui Sanyo Sceptre

0097

0006

0001, 0005, 0006,

0041

0004, 0005, 0006, 0100

0010, 0011, 0099

0091

0004, 0005, 0006,

0014, 0045

0097

0001

0003, 0014

0004, 0005, 0006, 0100

0008, 0104, 0110 0006, 0102 0003, 0004, 0005, 0006,

0100

0107

0006, 0100

0060 0048, 0054, 0059 0008, 0104

0095

0105

0075

0014

0025

0003, 0010, 0017,

0027, 0105, 0114

0100, 0102

0003, 0004, 0005, 0006,

0007, 0100, 0101

0003, 0004, 0007, 0019,

0020, 0101

0004, 0100

0065

0010

0004, 0006, 0007, 0008

0000, 0003, 0004, 0005,

0006, 0013, 0024, 0035

0007, 0022, 0032, 0076, 0077, 0083, 0100, 0110

0019

0057, 0106 0004, 0005, 0006

0097

0000

0004, 0006, 0007

0055

0068 0004, 0011, 0099

0003, 0010, 0105

0100, 0104

0100, 0104 0011, 0099, 0100

0004, 0006, 0100, 0107

0004, 0005, 0006,

0025

0004, 0050

0072

Scotch Scott

Sears

Sharp

Sheng Chia Shogun Signature Sony

Soundesign

Squareview SSS Starlite Superscan Supre-Macy Supreme SVA Sylvania

Symphonic

Syntax Syntax-Brillian Tandy Tatung Technics Techwood Teknika

TMK TNCi Toshiba

Vector Research Vidikron Vidtech Viewsonic Viking Viore Vizio Wards

Waycon

0000,

Westinghouse White Westinghouse Yamaha Zenith

0006

0004, 0006, 0007, 0008,

0009, 0090, 0104

0000, 0004, 0006, 0009,

0101, 0102, 0103

0004, 0006, 0007, 0014,

0033

0014

0004

0001

0002, 0018, 0029, 0030,

0031, 0034

0004, 0006, 0008,

0009, 0104

0103

0004, 0008, 0104

0008, 0104

0014

0012

0002

0088

0004, 0006, 0049,

0079, 0080, 0100, 0101, 0103

0008, 0041, 0103,

0104

0054

0014

0003, 0108

0010, 0105

0004, 0006, 0010

0001, 0004, 0005, 0006, 0007, 0008, 0009, 0101, 0104

0004, 0006 0099

0026, 0028, 0036, 0038, 0040, 0043, 0102

0006, 0009, 0100, 0101

0099

0100

0101

0004, 0005, 0006

0058, 0107

0012 0089 0004, 0070, 0071, 0108

0000, 0001, 0004, 0005,

0102

0047, 0051

0004, 0005, 0006, 0100

0001, 0004, 0011, 0015,

0023

DVD

If operations are not possible using the preset codes below, you may be able to conduct operations with the preset codes for the BD,

DVR (BDR, HDR)

Pioneer

2256, 2014

Accurian

2092

Advent

2072

Aiwa

2012

Akai

2066

Alco

2070

Allegro

2087

Amphion MediaWorks AMW

2037

Apex

2002, 2018, 2079, 2080

Apple

2058

Arrgo

2088

Aspire

2073

Astar

2052

Audiovox

2070

Axion

2040

Bang & Olufsen Blaupunkt

2080

Blue Parade Boston

2059

Broksonic

2066

California Audio Labs CambridgeSoundWorks

2065

CineVision Coby

2029

Curtis Mathes CyberHome Cytron

2039

Daewoo

2021, 2087

Denon

2026, 2068

Desay

2055

DiamondVision Disney

2022

Durabrand Emerson

2067, 2082, 2091

Enterprise

2082

ESA

2053, 2091

Fisher

2083

Funai

2091

2016, 2077, 2080

GFM

2043

Go Video

2087

Gradiente

2068

Greenhill

2080

Haier

2094

Harman/Kardon Hitachi

2011

Hiteker

2079

iLive

2062

Ilo

2038

Initial

2038, 2080

2081

2078

2087

2089

2000, 2088

2042

2090

2030, 2084

2037

2068

Insignia

2036, 2064, 2091

Integra

2078

iSymphony JBL

2084

JVC

2013

Kawasaki

2070

Kenwood

2028, 2068

KLH

2070, 2080

Koss

2024, 2069, 2075

Landel

2093

Lasonic

2085

Lenoxx

2074, 2090

2019, 2051, 2061, 2082, 2087

Liquid Video Liteon

2025, 2092

Magnavox Memorex

2066

Microsoft

2077

Mintek

2038, 2080, 2086

Mitsubishi Nesa

2080

Next Base

2093

Nexxtech

2056

Onkyo

2076

Oppo

2041, 2057

Oritron

2069, 2075

Panasonic

2005, 2007, 2017,

2032, 2033, 2050, 2068, 2076

Philips

2045, 2076

Proceed

2079

Proscan

2077

Qwestar

2069

RCA

2008, 2016, 2070, 2077,

2078, 2080

Regent

2074

Rio

2087

Rowa

2071

Samsung

2009, 2011, 2015,

2031, 2044, 2068

Sansui

2066

Sanyo

2066, 2083

Sharp

2035

Sherwood Shinsonic

2086

Sonic Blue Sony

2003, 2004, 2010, 2012,

2027, 2046, 2047, 2048

Sungale

2054

Superscan Sylvania

2023, 2067, 2091

Symphonic Teac

2070

Technics

2068

Theta Digital Toshiba

2001, 2006, 2049,

2066, 2076

Trutech

2000

Urban Concepts US Logic

2086

Venturer

2070

Xbox

2077

2060

2075

2067, 2076, 2091

2020

2063

2087

2067

2023

2078

2076

Yamaha

2005, 2068

Zenith

2019, 2076, 2082, 2087

If operations are not possible using the preset codes below, you may be able to conduct operations with the preset codes for the

DVD, DVR (BDR,

HDR)

Pioneer

2255, 2192, 2281

Denon

2310, 2311, 2312

Hitachi

2307, 2308, 2309

JVC

2290, 2291, 2293, 2294,

2295, 2296

2286, 2287

Marantz

2302, 2303

Mitsubishi

2300, 2301

Onkyo

2289

Panasonic

2277, 2278, 2279,

Philips

2280

Samsung

2282

Sharp

2304, 2305, 2306

Sony

2283, 2284, 2285, 2292

Toshiba

2288, 2262

Yamaha

2297, 2298, 2299

DVR (BDR, HDR)

If operations are not possible using the preset codes below, you may be able to conduct operations with the preset codes for the

DVD, BD

Pioneer

Panasonic Sharp Sony

Toshiba

2257, 2193, 2258, 2259, 2260, 2261, 2264, 2265, 2266, 2270

2263, 2269

2267, 2275

2268, 2271, 2272, 2273,

2276

2274

VCR

Pioneer

1053, 1108

ABS

1017

Adventura

1005

Aiwa

1005

Alienware

1017

American High Asha Audio Dynamics Audiovox Bang & Olufsen Beaumark

1002

1003

1002

1004

1000

1032

Controlling the rest of your system

Bell & Howell Calix Candle Canon Citizen Colortyme Craig Curtis Mathes

Cybernex CyberPower Daewoo DBX Dell DIRECTV

Dish Network Dishpro Durabrand Dynatech Echostar Electrohome Electrophonic Emerson Expressvu Fisher Fuji Funai Garrard Gateway GE GOI Goldstar Gradiente Harley Davidson Harman/Kardon Headquarter Hewlett Packard HNS Howard Computers HP HTS Hughes Network Systems

Humax Hush iBUYPOWER Instant Replay JC Penney

JCL JVC Kenwood Kodak LG Linksys Lloyd’s LXI Magnavox Magnin Marantz

1001

1003

1002, 1003

1004

1002, 1003

1000

1002, 1003

1000, 1002,

1004

1002

1017

1005

1000

1017

1016, 1020, 1022,

1023, 1024, 1027, 1030, 1031

1029

1018

1005

1029

1003

1003, 1004, 1005

1029

1001

1004

1005

1017

1002, 1004

1029

1000, 1003

1005

1000

1001

1016, 1020

1017

1000, 1001, 1002,

1000, 1001

1003, 1004

1017

1005

1004, 1018

1003

1000, 1001, 1004

1017

1004

1016

1017

1029

1016, 1020, 1022, 1023, 1024

1003, 1004

1004

1000, 1001, 1020, 1029

1003

Marta

1003

Media Center PC MEI

1004

Memorex

1004, 1005, 1018, 1019

MGN Technology Microsoft Mind Mitsubishi Motorola MTC

1002

Multitech NEC

1000, 1001

Nikko Niveus Media Noblex Northgate Olympus Optimus Orion Panasonic Philco Philips

1022, 1023, 1024, 1025

Philips Magnavox Pilot Proscan Pulsar Quarter Quartz Quasar Radio Shack Radio Shack/Realistic

1002, 1003, 1004, 1005

Radix Randex RCA

1002, 1004, 1007, 1016,

1020, 1022, 1030, 1031

Realistic

1004, 1005

ReplayTV Ricavision Runco Samsung

1024

Sanky Sansui Sanyo Sears Sharp Shogun Singer Sonic Blue Sony Stack STS

1004

Sylvania Symphonic Systemax Tagar Systems Tandy

1017

1001, 1002, 1003,

1002

1017

1010

1004

1002, 1005

1003

1017

1002

1017

1004

1003

1014, 1019

1004, 1008 1004 1004, 1011, 1016, 1020,

1003

1030

1018

1001

1004

1003

1001, 1002, 1003,

1026

1017

1018

1002, 1016, 1022,

1018

1014, 1019

1001, 1002

1001, 1003, 1004

1012

1002

1004

1026

1006, 1009, 1017, 1021

1017

1004, 1005

1005

1017

1001

Tashiko Teac Technics Teknika Tivo

TMK Toshiba Totevision Touch UltimateTV Unitech Vector Research Video Concepts Videosonic Viewsonic Voodoo Wards XR-1000 Yamaha Zenith ZT Group

Satellite Set Top Box

1011

Pioneer ADB Akai Alba Allsat Alltech Amstrad Anttron

1001,

Asat Austar Bell ExpressVu British Sky Broadcasting

Canal Chaparral CNS Coolsat Crossdigital Digeniu Digiwave DirecTV

Dish Network System

Dishpro Echostar

Expressvu Fortec Star Fresat Funai GE General Instrument GOI

1003

1005

1004

1003, 1004, 1005

1016, 1020, 1021, 1022,

1025

1002

1015, 1017, 1028

1002, 1003

1017

1031

1002

1000

1002

1017

1002, 1003, 1004, 1005

1004, 1005 1000, 1001

1013, 1018

1017

6097, 6098

6035, 6001

6102 6005, 6011, 6013

6102

6011

6033, 6030, 6044

6013

6102

6000, 6045

6002, 6003

6030

6105

6034

6001

6021

6043

s 6104

6053

6070, 6110, 6111, 6062, 6063, 6113, 6008, 6038, 6054, 6069, 6060, 6059, 6043, 6018, 6114, 6115, 6116, 6093

6089, 6003, 6004

6002, 6089, 6004

6002, 6089, 6036,

6005, 6003, 6004

6014

6070

6111

6002, 6004

6123, 6023

6002,

6032

Grundig

6007, 6030

Hirschmann Hisense Hitachi Houston HTS Hughes Network Systems

Hyundai iLo Innova Jerrold JVC Kathrein Lava LG Marantz McIntosh Mitsubishi Motorola NEC Netsat Next Level nfusion Nokia

Pace Panarex Panasonic Pansat Philips

Primestar Proscan Proton RadioShack Radix RCA

Saba Sagem Samsung

Sanyo Sat Cruiser Schwaiger Siemens SKY SM Electronic Smart Sonicview Sony Star Choice Star Trak TechniSa Thomson Tivo Toshiba TPS

6033

6020

6038, 6049

6002

6002, 6004

6113, 6038, 6054, 6114, 6115, 6116

6016

6020

6059 6032

6002, 6003, 6004

6096

6053

6047, 6018

6102

6032

6038

6032, 6042

6050

6059

6032

6015

6025, 6026, 6118, 6119,

6121

6035, 6005, 6030, 6031

6016

6008, 6009, 6030 6016, 6022 6002, 6113, 6038, 6054,

6060, 6059, 6102, 6103, 6030, 6114

6032

6110, 6111

6020

6002, 6111, 6032

6036

6002, 6110, 6111, 6113,

6109, 6061, 6114

6014

6041, 6120

6070, 6113, 6091,

6043, 6017, 6114, 6093

6046

6015

6066

6007, 6036

6042, 6059, 6030, 6031

6011

6051

6055, 6107

6062, 6063, 6030

6032

t 6033

6110, 6111, 6014

6113, 6114, 6115, 6116

6038, 6054, 6039

6041

Triasat

6033

Ultrasat

6021

US Digital

6020

USDTV

6020

ViewSat

6048

Voom

6032

Zehnder

6101

Zenith

6042, 6069, 6037

Satellite Set Top Box (SAT/PVR Combination)

Bell ExpressVu DirecTV

6060, 6059, 6114, 6115, 6116

Dish Network System

6089

Dishpro Echostar Expressvu Hughes Network Systems

6113, 6114, 6115, 6116

JVC Motorola Philips Proscan Samsung Sonicview Sony Star Choice Tivo

Cable Set Top Box

Pioneer

0297

ABC Accuphase Amino Auna BCC Bell & Howell Bright House Cable One Cablevision Charter Cisco Comcast Cox Digeo Director Emerson Fosgate General Instrument

6072, 6122

Homecast i3 Micro Insight Jebsee

6002, 6003

6070, 6110, 6062, 6113,

6002, 6089

6002, 6089, 6003

6002

6003

6032

6113, 6114

6110

6114

6055, 6107

6062

6032

6113, 6114, 6115, 6116

6029, 6028, 6095, 6099,

6122

6077, 6078

6082

6072

6122

6074, 6029

6074, 6029, 6058

6029, 6028, 6083

6074, 6029, 1982

6074, 6029

6029, 6058

6073

6122

6072

6024

6077

6074, 6073, 6029

6122

Jerrold Knology Macab Mediacom Memorex Motorola

6029, 6122, 6094

MTS Myrio Noos Pace

6083

Panasonic Paragon Penney Philips Pulsar

6002,

Quasar Regal Rogers Runco Samsung Scientific Atlanta

6027, 6112

Sejin Shaw Starcom Stargate Suddenlink Supercable Time Warner Tivo Toshiba United Cable US Electronics Videoway Zenith

Cable Set Top Box (Cable/PVR Combination)

Pioneer Amino Bright House Cable One Cablevision Charter Cisco Comcast

6076

Cox Digeo Homecast

6073,

Insight Knology Mediacom Motorola Myrio Pace

6073, 6072, 6122

6029

6040

6074, 6029

6112

6074, 6073, 6072,

6094

6077, 6078 6040 6074, 6029, 6028, 6106,

6112, 6083

6112

6012

6112

6072

6029

6112

6095

6029, 6028,

6077

6074

6122

6074, 6029 6072

6074, 6029, 6058

6076

6112

6072, 6122

6072

6112

6029

6078

6074, 6029

6074, 6029, 6058

6029, 6083

6074, 6029, 6083,

6074, 6029

6081, 6058

6024

6074, 6029

6029

6074, 6029

6074, 6081

6078

6029

Panasonic

6083

Rogers

6029

Scientific Atlanta Shaw Suddenlink Supercable Time Warner Tivo

6076

Pioneer AKAI

5043

Asuka Denon Fisher Goldstar Hitachi Kenwood Luxman Marantz Onkyo Panasonic Philips RCA

5013, 5029

Roadstar Sharp Sony

5012, 5023, 5026, 5027,

5028, 5039

TEAC

5015, 5016, 5034, 5035,

5037

Technics Victor Yamaha

5046, 5047

CD-R

Pioneer Philips Yamaha

Tuner

Pioneer

Laser Disc Player

Pioneer

Casette Deck

Pioneer

Digital Tape

Pioneer

6029

6074

6074, 6029

6072

6074, 6029, 6058

5000, 5011

5045 5019

5048

5040

5042

5020, 5021, 5031

5049

5033

5017, 5018, 5030, 5050

5036

5022, 5032, 5044

5052

5051

5041

5014

5024, 5025, 5038,

5001, 5053

5054

5055

5060

5002, 5003

5058, 5059

5057

5056

Additional information

RECEIVER

Chapter 10:

Additional information

Troubleshooting

Incorrect operations are often mistaken for trouble and malfunctions. If you think that there is something wrong with this component, check the points below. Take a look at the other components and electrical appliances being used, because sometimes the problem may lie there. If the trouble isn’t sorted out even after going through the checks below, ask your nearest Pioneer authorized independent service company to carry out repair work.

• If the unit does not operate normally due to external effects such as static electricity disconnect the power plug from the outlet and insert again to return to normal operating conditions.

General

The power does not turn on.

 Disconnect the power plug from the outlet, and insert again.  Make sure there are no loose strands of speaker wire touching

the rear panel. This could cause the receiver to shut off automatically.

Power cannot be turned off. (ZONE2 ON is displayed.)

 Press the button, then with the SHIFT button

pressed, press the  RECEIVER button to switch the sub zone off.

The receiver suddenly switches off.

 When the Auto Power Down function is working, the power

will automatically turn off if the receiver has not operated for several hours. Check the setting for the Auto Power Down function (see The Auto Power Down menu on page 42).

 After about a minute (you won’t be able to switch the unit on

during this time), switch the receiver back on. If the message persists, call a Pioneer authorized independent service company.

The power suddenly turns on or off, or the input suddenly changes (When the Control with HDMI is ON).

 This happens because of the synchronized operation due to

the Control with HDMI function. If synchronized operations are not needed, set the Control with HDMI to OFF (see HDMI Setup on page 43).

OVERHEAT shows in the display and the power turns off.

 The temperature within the unit has exceeded the allowable

value. Try moving the unit for better ventilation (see page 2).

 Lower the volume level.

TEMP shows in the display and the volume level drops.

 The temperature within the unit has exceeded the allowable

value. Try moving the unit for better ventilation (see page 2).

 Lower the volume level.

No sound is output when an input function is selected.

 Use MASTER VOLUME to turn up the volume.  Press MUTE on the remote control to turn muting off.  Press SPEAKERS to select the proper speaker set (see

Switching the speaker terminal on page 12).

 Set the SIGNAL SEL to H (HDMI), C1/O1/O2 (digital) or A

(analog) according to the type of connections made (refer to page 26).

 Make sure the component is connected correctly (refer to

Connecting your equipment on page 10).

 Check the audio output settings of the source component.  Refer to the instruction manual supplied with the source

component.

No image is output when an input function is selected.

 Make sure the component is connected correctly (refer to

Connecting your equipment on page 10).

 Check The Input Assign menu on page 40 to make sure you’re

assigned the correct input.

 The video input selected on the TV monitor is incorrect. Refer

to the instruction manual supplied with the TV.

 For HDMI, or when Video Converter is set to OFF and a TV and

another component are connected with different cords (in Video Converter on page 41), you must connect your TV to this receiver using the same type of video cable as you used to connect your video component.

 Some components (such as video game units) have

resolutions that may not be converted. If adjusting this receiver’s Resolution setting (in Resolution on page 41) and/or the resolution settings on your component or display doesn’t work, try switching Video Converter (in Video Converter on page 41) OFF.

No sound from subwoofer.

 Make sure the subwoofer is switched on.  If the subwoofer has a volume knob, make sure it’s turned up.  The Dolby Digital or DTS source you are listening to may not

have an LFE channel.

 Switch the subwoofer setting in Speaker Setting on page 38 to

YES or PLUS.

 Switch the LFE ATT (LFE Attenuate) on page 36 to LFEATT 0 or

LFEATT 5.

No sound from surround or center speakers.

 Connect the speakers properly (refer to page 12).  Refer to Speaker Setting on page 38 to check the speaker

settings.

 Refer to Channel Level on page 39 to check the speaker levels.

The Phase Control feature doesn’t seem to have an audible effect.

 If applicable, check that the lowpass filter switch on your

subwoofer is off, or the lowpass cutoff is set to the highest frequency setting. If there is a PHASE setting on your subwoofer, set it to 0º (or depending on the subwoofer, the setting where you think it has the best overall effect on the sound).

 Make sure the speaker distance setting is correct for all

speakers (see Speaker Distance on page 40).

Considerable noise in radio broadcasts.

 Connect the antenna (page 20) and adjust the position for

best reception.

 Route any loose cables away from the antenna terminals and

wires.

 Fully extend the FM wire antenna, position for best reception,

and secure to a wall (or connect an outdoor FM antenna).

 Connect an additional internal or external AM antenna

(page 21).

 Turn off equipment causing interference or move it away from

the receiver (or move antennas farther away from equipment causing noise).

Broadcast stations cannot be selected automatically.

 Connect an outdoor antenna (refer to page 21).

Noise during playback of a cassette deck.

 Move the cassette deck away from your receiver, until the

noise disappears.

No sound is output or a noise is output when software with DTS is played back.

 Make sure the player’s settings are correct and/or the DTS

signal out is on. Refer to the instruction manual supplied with the DVD player.

There seems to be a time lag between the speakers and the output of the subwoofer.

 See Automatically setting up for surround sound (MCACC) on

page 24 to set up your system again using MCACC (this will automatically compensate for a delay in the subwoofer output).

Additional information

Note

After using the Auto MCACC setup, the speaker size setting (LARGE or SMALL) is incorrect.

 Low-frequency noise could have been caused by an air

conditioner or motor. Switch off all appliances in the room and rerun the Auto MCACC setup.

Can’t operate the remote control.

 Replace the batteries (refer to page 9).  Operate within 7 m (23 ft.), 30º of the remote sensor (refer to

page 9).

 Remove the obstacle or operate from another position.  Avoid exposing the remote sensor on the front panel to direct

light.

The display is dark or off.

 Press DIMMER on the remote control repeatedly to return to

the default.

Display blinks 12V ERR.

 An error has arisen in the 12 V trigger jack. Reconnect

accurately then turn the power back on.

The receiver doesn’t recognize iPod touch/iPhone.

 Try the following.

1. Simultaneously keep pressing the sleep button and home button on the iPod touch or iPhone for over 10 seconds to restart.

2. Turn on the receiver.

3. Connect the iPod touch/iPhone to the receiver.

The

Bluetooth

connected or operated. Sound from the technology device is not emitted or the sound is interrupted.

 Check that no object that emits electromagnetic waves in the

2.4 GHz band (microwave oven, wireless LAN device or Bluetooth wireless technology apparatus) is near the unit. If such an object is near the unit, set the unit far from it. Or, stop using the object emitting the electromagnetic waves.

 Check that the Bluetooth wireless technology device is not too

far from the unit and that obstructions are not set between the

Bluetooth wireless technology device and the unit. Set the Bluetooth wireless technology device and the unit so that the

distance between them is less than about 10 m (32 ft.) and no obstructions exist between them.

 Check that the Bluetooth ADAPTER and the ADAPTER PORT

terminal of the unit are correctly connected.

 The Bluetooth wireless technology device may not be set to the

communication mode supporting the Bluetooth wireless technology. Check the setting of the Bluetooth wireless technology device.

wireless technology device cannot be

Bluetooth

wireless

 Check that pairing is correct. The pairing setting was deleted

from this unit or the Bluetooth wireless technology device. Reset the pairing.

 Check that the profile is correct. Use a Bluetooth wireless

technology device that supports A2DP profile and AVRCP profile.

HDMI

No picture or sound.

 If the problem still persists when connecting your HDMI

component directly to your monitor, please consult the component or monitor manual or contact the manufacturer for support.

No picture.

 Depending in the output settings of the source component, it

may be outputting a video format that can’t be displayed. Change the output settings of the source, or connect using the component or composite jacks.

 This receiver is HDCP-compatible. Check that the components

you are connecting are also HDCP-compatible. If they are not, please connect them using the component or composite video jacks.

 Depending on the connected source component, it’s possible

that it will not work with this receiver (even if it is HDCPcompatible). In this case, connect using the component or composite video jacks between source and receiver.

 If video images do not appear on your TV, try adjusting the

resolution, Deep Color or other setting for your component.

 To output signals in Deep Color, use an HDMI cable (High

Speed HDMI® Cable) to connect this receiver to a component or TV with the Deep Color feature.

No sound, or sound suddenly ceases.  Check that the Audio Parameter setting is set to HDMI AMP/

THRU (refer to page 36).

 If the component is a DVI device, use a separate connection

for the audio.

 HDMI format digital audio transmissions require a longer time

to be recognized. Due to this, interruption in the audio may occur when switching between audio formats or beginning playback.

 Turning on/off the device connected to this unit’s HDMI OUT

terminal during playback, or disconnecting/connecting the HDMI cable during playback, may cause noise or interrupted audio.

Synchronized operation not possible using Control with HDMI function.

 Check the HDMI connections.  The cable may be damaged.  Select ON for the Control with HDMI setting (see HDMI Setup

on page 43).

 Turn the TV’s power on before turning on this receiver’s power.  Set the TV side Control with HDMI setting to on (see TV’s

operating instructions).

Important information regarding the HDMI connection

There are cases where you may not be able to route HDMI signals through this receiver (this depends on the HDMI equipped component you are connecting-check with the manufacturer for HDMI compatibility information).

If you aren’t receiving HDMI signals properly through this receiver (from your component), please try the following configuration when connecting up.

Configuration A

Use component video cables to connect the video output of your HDMI-equipped component to the receiver’s component video input. The receiver can then convert the analog component video signal to a digital HDMI signal for transmission to the display. For this configuration, use the most convenient connection (digital is recommended) for sending audio to the receiver. See the operating instructions for more on audio connections.

• The picture quality will change slightly during conversion.

Configuration B

Connect your HDMI-equipped component directly to the display using an HDMI cable. Then use the most convenient connection (digital is recommended) for sending audio to the receiver. See the operating instructions for more on audio connections. Set the display volume to minimum when using this configuration.

Additional information

Note

Important

• Depending on the component, audio output may be limited to the number of channels available from the connected display unit (for example audio output is reduced to 2 channels for a monitor with stereo audio limitations).

• If you want to switch the input source, you’ll have to switch functions on both the receiver and your display unit.

• Since the sound is muted on the display when using the HDMI connection, you must adjust the volume on the display every time you switch input sources.

iPod messages

‘iPod/USB Error 1 (I/U ERR1)’, ‘iPod/USB Error 3 (I/U ERR3)’

 Switch off the receiver and reconnect the iPod to the receiver.

If this doesn’t seem to work, try resetting your iPod.

‘iPod/USB Error 2 (I/U ERR2)’

 Switch off the receiver and reconnect the iPod to the receiver.

If this doesn’t seem to work, try resetting your iPod.

 An iPod not supported by this receiver is connected. Connect

the iPod supported by this receiver (see page 27).

‘No Track’

 When there are no tracks in the category selected on the iPod.

Select a different category.

USB messages

‘iPod/USB Error 1 (I/U ERR1)’

 There is a problem with the signal path from the USB to the

receiver. Switch off the receiver and reconnect the USB to the receiver.

‘iPod/USB Error 3 (I/U ERR3)’

 When there is no response from the USB. Switch off the

receiver and reconnect the USB to the receiver.

‘iPod/USB Error 4 (I/U ERR4)’

 The power requirements of the USB device are too high for

this receiver. Switch off the receiver and reconnect the USB to the receiver.

SIRIUS radio messages

‘NO ANT’

 Antenna is not properly connected. Check that the antenna

cable is attached securely.

‘CHECK SIRIUS TUNER’

 SIRIUS Connect tuner is not properly connected. Check that

the 8 pin mini DIN cable and AC Adapter are attached securely.

‘NO SIG’

 The SIRIUS signal is too weak at the curren t location. There is

no SIRIUS signal or the SiriusConnect Tuner is connected.

‘SUB UPDT’

 Unit is updating subscription. Wait until the encryption code

has been updated.

‘UPD ***%’

 Unit is updating channels. Wait until the encryption code has

been updated.

‘INVLD CH’

 Selected channel is not available/does not exist. Select

another channel.

About iPod/iPhone/iPad

“Made for iPod,” “Made for iPhone” and “Made for iPad” mean that an electronic accessory has been designed to connect specifically to iPod, iPhone, or iPad, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod, iPhone, or iPad may affect wireless performance.

Apple, iPad, iPhone, iPod, iPod shuffle, iPod nano, iPod classic, iPod touch and iTunes are trademarks of Apple Inc., registered in the U.S. and other countries.

Resetting the main unit

Use this procedure to reset all the receiver’s settings to the factory default. Use the front panel controls to do this.

Switch the receiver into standby.

While holding down BAND, press and hold

 STANDBY/ON

When you see RESET? appear in the display, press AUTO SURROUND/STREAM DIRECT. OK? shows in the display.

Press ALC/STANDARD SURR to confirm. OK appears in the display to indicate that the receiver has

been reset to the factory default settings.

•If the Control with HDMI function is set to ON, you may

not be able to reset the unit. In this case, reset either by

turning OFF the Control with HDMI function, or by

putting the unit into standby mode by turning off the

power of all the connected devices, and resetting after the

HDMI indicator on the front panel turns off.

for about two seconds.

Additional information

Note

Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic”, “Surround EX”, and the double-D symbol are trademarks of Dolby Laboratories.

Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,226,616; 6,487,535; 7,212,872; 7,333,929; 7,392,195; 7,272,567 & other U.S. and worldwide patents issued & pending. DTS and the Symbol are registered trademarks, & DTS-HD, DTS-HD Master Audio, and the DTS logos are trademarks of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.

Cleaning the unit

• Use a polishing cloth or dry cloth to wipe off dust and dirt.

• When the surface is dirty, wipe with a soft cloth dipped in some neutral cleanser diluted five or six times with water, and wrung out well, and then wipe again with a dry cloth. Do not use furniture wax or cleansers.

• Never use thinners, benzine, insecticide sprays or other chemicals on or near this unit, since these will corrode the surface.

Specifications

Amplifier section

Continuous average power output of 80 watts* per channel, min., at 8 ohms, from 20 Hz to 20 000 Hz with no more than 0.08 %** total harmonic distortion.

Front (stereo) . . . . . . . . . . . . . . . . . . . . . . . . . .80 W + 80 W

Guaranteed speaker impedance. . . . . . . . . . . . . . 6 Ω to 16 Ω

* Measured pursuant to the Federal Trade Commission’s Trade Regulation rule on Power Output Claims for Amplifiers ** Measured by Audio Spectrum Analyzer

Audio Section

Input (Sensitivity/Impedance)

LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 mV/47 kΩ

Output (Level/Impedance)

REC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .200 mV/2.2 kΩ

Signal-to-Noise Ratio (IHF, short circuited, A network)

LINE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98 dB

Signal-to-Noise Ratio [EIA, at 1 W (1 kHz)]

LINE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79 dB

Video Section

Signal level

Composite. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Vp-p (75 Ω)

Component Video. . . . . . . . . . . . . . . . . . . .Y: 1.0 Vp-p (75 Ω)

Corresponding maximum resolution

Component Video. . . . . . . . . . . . . . . . . . . . . . 1080p (1125p)

PB, PR: 0.7 Vp-p (75 Ω)

Tuner Section

Frequency Range (FM) . . . . . . . . . . . . . .87.5 MHz to 108 MHz

Antenna Input (FM) . . . . . . . . . . . . . . . . . . . 75 Ω unbalanced

Frequency Range (AM) . . . . . . . . . . . . . . 530 kHz to 1700 kHz

Antenna (AM) . . . . . . . . . . . . . . . . . . . . . . . . . . . Loop antenna

Digital In/Out Section

HDMI terminal . . . . . . . . . . . . . . . . . . . . . . . . . Type A (19-pin)

HDMI output type . . . . . . . . . . . . . . . . . . . . . . . . . .5 V, 100 mA

USB terminal. . . . . . . . . . . . . . . . .USB2.0 Full Speed (Type A)

iPod terminal. . . . . . . . . . . . . . . .USB, and Video (Composite)

SIRIUS antenna cable . . . . . . . . . . . . . . 8-pin mini DIN cable

ADAPTER PORT terminal . . . . . . . . . . . . . . . . . . .5 V, 100 mA

Integrated control section

Control (IR) terminal. . . . . . . . . . . . . Ø 3.5 Mini-jack (MONO)

IR signal. . . . . . . . . . . . . . . . . . High Active (High Level: 2.0 V)

12 V Trigger terminal 12 V Trigger output type

Miscellaneous

Power Requirements . . . . . . . . . . . . . . . . . . . AC 120 V, 60 Hz

Power Consumption. . . . . . . . . . . . . . . . . . . . . . . . . . . . .500 W

In standby . . . . . . . . . . . . . . . . . . . . . . . 0.4 W (Control OFF)

Dimensions . . . . . 435 mm (W) x 168 mm (H) x 362.5 mm (D)

Weight (without package) . . . . . . . . . . . . . . 9.6 kg (21 lb 3 oz)

Furnished Parts

Microphone (for Auto MCACC setup). . . . . . . . . . . . . . . . . . . 1

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Dry cell batteries (AAA size IEC R03) . . . . . . . . . . . . . . . . . . . 2

AM loop antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

FM wire antenna. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

iPod cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

These operating instructions

• Specifications and the design are subject to possible modifications without notice, due to improvements.

. . . . . . . . . . . . . Ø 3.5 Mini-jack (MONO)

. . . . . . . . . . . . . . . . . . . . .12 V, 50 mA

/16 in. (W) x 65/8 in. (H) x 145/16 in. (D)

The Safety of Your Ears is in Your Hands

Get the most out of your equipment by playing it at a safe level – a level that lets the sound come through clearly without annoying blaring or distortion and, most importantly, without affecting your sensitive hearing. Sound can be deceiving. Over time, your hearing “comfort level” adapts to higher volumes of sound, so what sounds “normal” can actually be loud and harmful to your hearing. Guard against this by setting your equipment at a safe level BEFORE your hearing adapts.

ESTABLISH A SAFE LEVEL:

• Set your volume control at a low setting.

• Slowly increase the sound until you can hear it

comfortably and clearly, without distortion.

• Once you have established a comfortable sound

level, set the dial and leave it there.

BE SURE TO OBSERVE THE FOLLOWING GUIDELINES:

• Do not turn up the volume so high that you can’t

hear what’s around you.

• Use caution or temporarily discontinue use in

potentially hazardous situations.

• Do not use headphones while operating a motorized

vehicle; the use of headphones may create a traffic hazard and is illegal in many areas.

S001a_A1_En

Additional information

LIMITED WARRANTY

WARRANTY VALID ONLY IN COUNTRY OF PRODUCT PURCHASE

WARRANTY

Pioneer Electronics (USA) Inc. (PUSA), and Pioneer Electronics Of Canada, Inc. (POC), warrant that products distributed by PUSA in the U.S.A., and by POC in Canada that fail to function

properly under normal use due to a manufacturing defect when installed and operated according to the owner’s manual enclosed with the unit will be repaired or replaced with a unit of comparable

value, at the option of PUSA or POC, without charge to you for parts or actual repair work. Parts supplied under this warranty may be new or rebuilt at the option of PUSA or POC.

THIS LIMITED WARRANTY APPLIES TO THE ORIGINAL OR ANY SUBSEQUENT OWNER OF THIS PIONEER PRODUCT DURING THE WARRANTY PERIOD PROVIDED THE

PRODUCT WAS PURCHASED FROM AN AUTHORIZED PIONEER DISTRIBUTOR/DEALER IN THE U.S.A. OR CANADA. YOU WILL BE REQUIRED TO PROVIDE A SALES

RECEIPT OR OTHER VALID PROOF OF PURCHASE SHOWING THE DATE OF ORIGINAL PURCHASE OR, IF RENTED, YOUR RENTAL CONTRACT SHOWING THE PLACE

AND DATE OF FIRST RENTAL. IN THE EVENT SERVICE IS REQUIRED, THE PRODUCT MUST BE DELIVERED WITHIN THE WARRANTY PERIOD, TRANSPORTATION PREPAID,

ONLY FROM WITHIN THE COUNTRY OF PURCHASE AS EXPLAINED IN THIS DOCUMENT. YOU WILL BE RESPONSIBLE FOR REMOVAL AND INSTALLATION OF THE

PRODUCT. PUSA OR POC, AS APPROPRIATE, WILL PAY TO RETURN THE REPAIRED OR REPLACEMENT PRODUCT TO YOU WITHIN THE COUNTRY OF PURCHASE.

PRODUCT WARRANTY PERIOD

Home Audio and Video .........................................................................................................................................................

Microphones, Headphones, Phono Cartridges and Styluses ................................................................................................

Shorter limited warranty periods apply to some models. Please refer to the limited warranty document enclosed with the product for a definitive statement of the warranty period.

The warranty period for retail customers who rent the product commences upon the date product is first put into use (a) during the rental period or (b) retail sale, whichever occurs first.

WHAT IS NOT COVERED

IF THIS PRODUCT WAS PURCHASED FROM AN UNAUTHORIZED DISTRIBUTOR, THERE ARE NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE IMPLIED WARRANTY

OF MERCHANTABILITY AND THE IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE AND THIS PRODUCT IS SOLD STRICTLY “AS IS” AND “WITH ALL FAULTS".

PIONEER SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL AND/OR INCIDENTAL DAMAGES.

PIONEER DOES NOT WARRANT ANY PRODUCT LISTED ABOVE WHEN IT IS USED IN A TRADE OR BUSINESS OR IN ANY INDUSTRIAL OR COMMERCIAL APPLICATION.

THIS WARRANTY DOES NOT APPLY IF THE PRODUCT HAS BEEN SUBJECTED TO POWER IN EXCESS OF ITS PUBLISHED POWER RATING.

THIS WARRANTY DOES NOT COVER TELEVISION OR DISPLAY SCREENS DAMAGED BY STATIC, NON-MOVING, IMAGES APPLIED FOR LENGTHY PERIODS (BURN-IN).

THIS WARRANTY DOES NOT COVER THE CABINET OR ANY APPEARANCE ITEM, USER ATTACHED ANTENNA, ANY DAMAGE TO RECORDS OR RECORDING TAPES OR DISCS,

ANY

DAMAGE TO THE PRODUCT RESULTING FROM ALTERATIONS, MODIFICATIONS NOT AUTHORIZED IN WRITING BY PIONEER, ACCIDENT, MISUSE OR ABUSE, DAMAGE DUE TO

LIGHTNING OR TO POWER SURGES, SUBSEQUENT DAMAGE FROM LEAKING, DAMAGE FROM INOPERATIVE BATTERIES, OR THE USE OF BATTERIES NOT CONFORMING TO THOSE

SPECIFIED IN THE OWNER’S MANUAL.

THIS WARRANTY DOES NOT COVER THE COST OF PARTS OR LABOR WHICH WOULD BE OTHERWISE PROVIDED WITHOUT CHARGE UNDER THIS WARRANTY OBTAINED FROM

ANY SOURCE OTHER THAN A PIONEER AUTHORIZED SERVICE COMPANY OR OTHER DESIGNATED LOCATION. THIS WARRANTY DOES NOT COVER DEFECTS OR DAMAGE CAUSED

BY THE USE OF UNAUTHORIZED PARTS OR LABOR OR FROM IMPROPER MAINTENANCE.

ALTERED, DEFACED, OR REMOVED SERIAL NUMBERS VOID THIS ENTIRE WARRANTY

NO OTHER WARRANTIES

IN THE U.S.A. - PIONEER LIMITS ITS OBLIGATIONS UNDER ANY IMPLIED WARRANTIES INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, TO A PERIOD NOT TO EXCEED THE WARRANTY PERIOD. NO WARRANTIES SHALL APPLY AFTER THE

WARRANTY PERIOD. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS AND SOME STATES DO NOT ALLOW THE EXCLUSIONS

OR LIMITATIONS OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES

YOU SPECIFIC LEGAL RIGHTS AND YOU MAY HAVE OTHER RIGHTS WHICH MAY VARY FROM STATE TO STATE.

IN CANADA - EXCEPT AS EXPRESSLY PROVIDED HEREIN, THERE ARE NO REPRESENTATIONS, WARRANTIES, OBLIGATIONS OR CONDITIONS, IMPLIED, STATUTORY

OR OTHERWISE, APPLICABLE TO THIS PRODUCT.

TO OBTAIN SERVICE

PUSA and POC have appointed a number of Authorized Service Companies throughout the U.S.A. and Canada should your product require service. To receive warranty service

you need to present your sales receipt or, if rented, your rental contract showing place and date of original owner’s transaction. If shipping the unit you will need to package

it carefully and send it, transportation prepaid by a traceable, insured method, to an Authorized Service Company. Package the product using adequate padding material to

prevent damage in transit. The original container is ideal for this purpose. Include your name, address and telephone number where you can be reached during business hours.

On all complaints and concerns in the U.S.A. call Customer Support at 1-800-421-1404, or, in Canada, call Customer Satisfaction at 1-877-283-5901.

DISPUTE RESOLUTION

IN THE U.S.A. - Following our response to any initial request to Customer Support, should a dispute arise between you and Pioneer, Pioneer makes available its Complaint

Resolution Program to resolve the dispute. The Complaint Resolution Program is available to you without charge. You are required to use the Complaint Resolution Program

before you exercise any rights under, or seek any remedies, created by Title I of the Magnuson-Moss Warranty-Federal Trade Commission Improvement Act, 15 U.S.C. 2301 et seq.

To use the Complaint Resolution Program call 1-800-421-1404 and explain to the customer service representative the problem you are experiencing, steps you have taken

to have the product repaired during the warranty period and the name of the authorized Distributor/Dealer from whom the Pioneer product was purchased. After the complaint

has been explained to the representative, a resolution number will be issued. Within 40 days of receiving your complaint, Pioneer will investigate the dispute and will either:

(1) respond to your complaint in writing informing you what action Pioneer will take, and in what time period, to resolve the dispute; or (2) respond to your complaint in writing

informing you why it will not take any action.

IN CANADA - Call the Customer Satisfaction Manager at (905) 946-7446 to discuss your complaint and to obtain a prompt resolution.

PIONEER ELECTRONICS (USA) INC. PIONEER ELECTRONICS OF CANADA, INC.

IN THE U.S.A.

For hook-up and operation of your unit or to locate an

Authorized Service Company, please call or write:

PIONEER ELECTRONICS SERVICE, INC.

P.O. BOX 1760

LONG BEACH, CALIFORNIA 90801

1-800-421-1404

http://www.pioneerelectronics.com

IN CANADA

For additional information on this warranty,

please call or write:

CUSTOMER SATISFACTION GROUP

PIONEER ELECTRONICS OF CANADA, INC.

300 ALLSTATE PARKWAY

MARKHAM, ON L3R 0P2

(905) 479-4411

1-877-283-5901

http://www.pioneerelectronics.ca

RECORD THE PLACE AND DATE OF PURCHASE FOR FUTURE REFERENCE

Model No. ____________________________________________ Serial No. _________________________________________ Purchase Date _______________________

Purchased From _______________________________________________________________________________________________________________________________

KEEP THIS INFORMATION AND YOUR SALES RECEIPT IN A SAFE PLACE

Parts Labor

1 Year 1 Year

90 Days 90 D ays

<5707-00000-498-0S>

To register your product, find the nearest authorized ser vice location, to purchase replacement parts, operating instructions, or accessories, please go to one of following URLs :

Pour enregistrer votre produit, trouver le service après-vente agréé le plus proche et pour acheter des pièces de rechange, des modes d’emploi ou des accessoires, reportez-vous aux URL suivantes :

In the USA/Aux Etats-Unis http://www.pioneerelectronics.com

In Canada/Aux Canada http://www.pioneerelectronics.ca

S018_B1_EnFr

Download an electronic version of this manual from our website.

Printed in China

PIONEER CORPORATION

1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan

PIONEER ELECTRONICS (USA) INC.

P.O. BOX 1540, Long Beach, California 90801-1540, U.S.A. TEL: (800) 421-1404

PIONEER ELECTRONICS OF CANADA, INC.

340 Ferrier Street, Unit 2, Markham, Ontario L3R 2Z5, Canada TEL: 1-877-283-5901, 905-479-4411

PIONEER EUROPE NV

Haven 1087, Keetberglaan 1, B-9120 Melsele, Belgium TEL: 03/570.05.11

PIONEER ELECTRONICS ASIACENTRE PTE. LTD.

253 Alexandra Road, #04-01, Singapore 159936 TEL: 65-6472-7555

PIONEER ELECTRONICS AUSTRALIA PTY. LTD.

5 Arco Lane, Heatherton, Victoria, 3202, Australia, TEL: (03) 9586-6300

PIONEER ELECTRONICS DE MEXICO S.A. DE C.V.

Blvd.Manuel Avila Camacho 138 10 piso Col.Lomas de Chapultepec, Mexico, D.F. 11000 TEL: 55-9178-4270

K002_B3_En

Pioneer VSX-40 Operating Instruction

Specifications and Main Features

Frequently Asked Questions

User Manual
